Cobra Electronics 75WX User Manual

75 WX ST manual 10/9/98 9:24 AM Page 2
Operating instructions for your
75WXST
C O M PACT REMOTE MOUNT
C B RADIO W I T H
COBRA ELECTRONICS CORPORATION
6500 W. Cortland Street
Chicago, Illinois 60707
Printed in Thailand Cobra Electronics Corp.© 1997 Part no. 480-230-P-001
“Cuts Noise Coming In... Strengthens Signals Going Out”
Easier Communication.”
75 WX ST manual 10/9/98 9:24 AM Page 4
How to use your
CITIZENS BAND RADIO WITH SOUNDTRACKER
CONTENTS:
Introduction ..........................................3
Features ............................................3
Technical Support and service ..........3
Controls and Indicators ..................4/5
Included with your 75WX ....................6
Installation ............................................7
Connector Box Location....................7
Mounting Connector Box ..............8/9
Microphone Hanger........................10
Antenna ..........................................11
Speakers..........................................12
Noise Interference ..........................12
SoundTracker System ......................13
Operation............................................13
Turning your CB On ........................14
Selecting a Channel ........................15
Activating SoundTracker ..................16
Testing SoundTracker........................17
Setting the Squelch......................18/19
LCD Readout ..................................20
75 WX ST
Operation (continued)
Receive / Transmit............................21
One Touch Channel 9 & 19........22/23
Key Lock ..........................................24
Frequency Display ..........................25
All Channel Scan ............................26
Weather Channel ............................27
Channel Saver..................................28
Memory Channels ......................28/29
Dual Watch ................................30/31
If you think you need service ..............32
How your CB can serve you................33
A few rules you should know ..........33
Weather Channel Messages..............34
Channel 9 Emergency Messages ......35
CB 10 Codes....................................36
Frequency Ranges................................37
Specifications ......................................38
Warranty Information..........................39
Optional Accessories ..........................40
INTRODUCTION
INTRODUCTION
The Cobra 75 WX ST is the ultimate in remote mount CB transceivers and features the SoundTracker system which dramatically eliminates annoying static to deliver crisp, clear sound quality. The 75’s compact, state-of-the­art design provides consistent, outstanding performance in almost all conditions or situations. For ultimate satisfaction and performance from your Cobra 75 WX ST, please review these operating instructions fully, prior to use.
FEATURES
• SoundTracker System
• 40 CB Radio Channels
• 10 Weather Channels
• One-touch Emergency Channel 9
• One-touch Information Channel 19
• Remote Mount Installation System
• Full Featured LCD Display Panel
• Squelch Control
• Key Lock
• Channel Saver Circuitry
• Dual Watch Channel Monitor
• Full Channel Scan
• Four Memory Locations
• 10-Foot Flexible Cord
• Quick Disconnect
TECHNICAL SUPPORT
For technical assistance, please call our Automated Help Desk
which can assist you by answering the most
frequently asked questions about Cobra products.
(773) 889-3087
24 hours a day, 7 days a week.
A Consumer Service Representative can be reached through this
same number 8:00 am - 8:00 pm, Monday through Friday, CST.
Technical assistance is also available on-line in the Frequently Asked
Question (FAQ) section at www.cobraelec.com or by e-mail
to productinfo@cobraelec.com
3
75 WX ST manual 10/9/98 9:24 AM Page 6
INTRODUCTION
CONTROLS AND INDICATORS
4
4
3
2
1
12
5
6
7
8
9
10
INTRODUCTION
CONTROLS AND INDICATORS
1. SoundTracker Key
2. Memory Key
3. Channel 9 / 19 / Memory Location 1 Key
4. LCD Display Panel
5. Dual Watch / Memory Location 2 Key
6. Scan / Memory Location 3 Key
7. CB / Weather Channel /
Memory Location 4 Key
8. On / Off / Volume Control
9. Lock Key
10. Squelch Control
11. Microphone
12. Speaker
13. Channel Up
14. Channel Down
15. PTT (Push-To-Talk) Key
16. Quick Disconnect Connector
15
16
5
13 14
11
75 WX ST manual 10/9/98 9:24 AM Page 8
INTRODUCTION
COMPONENTS INCLUDED
6
75 WX ST Transceiver Connector Box
INSTALLATION
CONNECTOR BOX LOCATION
7
LOCATION
Mount your Cobra 75 WX ST Connector Box in a convenient location, away from moisture and direct sunlight, in a location that will not interfere with driving.
Cobra suggests mounting it either under the front seat or on the fire wall.
UNDER THE FRONT SEAT INSTALLATION
FIRE WALL INSTALLATION
Installation Hardware Operating Manual
NOTE: Do not mount under
the hood, near heat ducts or in direct line of the car’s heater.
75 WX ST manual 10/9/98 9:24 AM Page 10
INSTALLATION
CONNECTOR BOX
8
MOUNTING CONNECTOR BOX
1. Hold Cobra 75 WX ST
Connector Box in exact location desired for mounting.
Using it as a template,
2.
mark the location the mounting screws (included).
NOTE: Make certain that nothing will interfere with the installation of the mounting screws, before drilling holes.
3. Mount Connector Box as shown.
for
INSTALLATION
CONNECTOR BOX
9
CONNECTING WIRES
1. Connect the antenna
cable connector.
2. Connect the red wire marked “BATT” (+) directly to the positive side of the battery or to a connection on the fuse box that is always on.
3. Connect the black wire marked “Ground” (-) to the negative side of the car, usually the chassis. Any other location with good electrical contact (paint removed) will also work.
CAUTION: Leaving the 75 WX ST on after your car is turned off can
drain your car battery when connected to a constant 12 volt source. When connected to accessory 12 volt source unit will turn off.
75 WX ST manual 10/9/98 9:24 AM Page 12
INSTALLATION
MICROPHONE HANGER
10
INSTALLING MICROPHONE HANGER
1. Hold microphone hanger
in location desired for mounting. Make certain that nothing will interfere with the hanger’s installation.
2. Mark the location for the three mounting screws (screws included).
3. Drill and mount microphone hanger.
INSTALLATION
CB ANTENNA INSTALLATION
For the most reliable operation and
maximum range, Cobra recommends
using a vertically polarized, quarter wave
length whip antenna (illustration A). Shorter, loaded-type whips are adequate
when maximum range is not required (illustration B).
NOTE: Mobile installations (cars, trucks,
boats, etc) should be made only with a non-directional antenna system.
• A standard antenna connector (Type SO-239) is provided on the
Connector Box for easy connection to
a standard PL-259 cable termination.
• Cobra antenna models are
recommended; see your local CB dealer
or order directly from Cobra. See order form on page 40.
• For maximum efficiency in boat installations, a ground plate is required, unless the vessel has a steel hull. Consult your CB dealer for information regarding
an adequate grounding system.
CB ANTENNA
11
A
B
75 WX ST manual 10/9/98 9:24 AM Page 14
INSTALLATION
SPEAKERS/NOISE INTERFERENCE
EXTERNAL SPEAKER INSTALLATION
1. Mount external speaker in desired location.
2. Plug jack into the back of the Connector Box labled EXT.
*The external speaker should have 4-8 ohms impedance and be able to handle at least 4 watts.
OPERATION
HOW SOUNDTRACKER WORKS
SOUNDTRACKER SYSTEM
While previous systems only “blanked out” or limited noise in higher sound frequencies, the revolutionary new SoundTracker System actually reduces noise while leaving the signal intact in the reception mode. In
the transmission mode, it actually strengthens the signal, providing you
with a significant reduction in noise on reception and transmission.
Sound clarity is measured by the ratio of the signal level to the noise level. The higher the signal-to-noise ratio, the better the sound.
HOW SOUNDTRACKER WORKS
On Reception
With a normal CB, distant signals fall below the squelch level and are unintelligible. With a SoundTracker CB, the noise level is cut by up to 90%, which increases the signal-to-noise ratio and dramatically improves signal clarity. This also allows you to significantly reduce the squelch level, which greatly expands your listening range.
“Cuts Noise Coming In”
1312
IGNITION NOISE INTERFERENCE
The alternator and ignition system in your vehicle may limit your ability to receive low signal levels. Other noise interference can be the result of several different installation variables. Consult your Cobra dealer or a 2-way radio technician to help locate and correct the source of severe noise interference.
On Tra n s m i s s i on
A SoundTracker CB strengthens the transmit signal by more effectively using the available RF power output of the CB.The result is improved transmission signal clarity and an expanded transmission range.
“ S t rengthens Signals Going Out”
75 WX ST manual 10/9/98 9:24 AM Page 16
OPERATION
TURNING CB ON
14
TURNING YOUR CB ON
1. Rotate the power ON-
OFF Volume Control clockwise.
2. Turn the Squelch Control counterclockwise until noise is heard.
3. Adjust volume to a comfortable level.
OPERATION
SELECTING A CHANNEL
15
SELECTING A CHANNEL
1. Change channels by
pressing either the channel up or channel down key .
2. To quick-advance channels, press and hold either key.
75 WX ST manual 10/9/98 9:24 AM Page 18
OPERATION
ACTIVATING SOUNDTRACKER
16
ACTIVATING SOUNDTRACKER
1. Depress the Sound-
Tracker key.
ST
2. will be displayed on the LCD readout.
OPERATION
TESTING SOUNDTRACKER
17
TESTING SOUNDTRACKER
1. Select any unused
channel on your CB.
2. Open the squelch control fully by turning the knob counterclock-wise until it stops.
3. Turn the volume up louder than your normal listening level.
4. Depress the SoundTracker key. Notice the significant reduction in noise.
75 WX ST manual 10/9/98 9:24 AM Page 20
OPERATION
SETTING THE SQUELCH
18
SETTING THE SQUELCH
1. Turn CB on by turning
the volume control clockwise. Adjust the volume to a comfortable level.
2. Before setting the squelch control on your radio, you must select a channel that is not in use.
3. Turn on SoundTracker.
To achieve the Desired
Squelch Setting (DSS):
4. Think of your Squelch
Control as a gate for incoming signals. If you turn the Squelch Control fully clockwise, it raises the “squelch gate” so high that no signals get through.
OPERATION
SETTING THE SQUELCH
19
5. If you turn the squelch
control fully counter­clockwise, it lowers the “squelch gate” so low that everything gets through
- noise, weak signals and strong signals.
6. To set the “squelch gate” to the DSS-Desired Squelch Setting, turn the squelch control counterclockwise until you hear noise. Then turn the squelch control back clockwise just until the noise stops. Now only strong signals get through.
The Desired Squelch Setting, (DSS) only allows actual transmissions to
come through. This effectively blocks out unwanted noise.
75 WX ST manual 10/9/98 9:24 AM Page 22
OPERATION
LCD READOUT
LCD DISPLAY
Your Cobra 75 WX ST CB is designed with a liquid crystal display that indicates channel number, frequency and the operating mode.
2 digit channel display / 5 digit frequency display
M
= Memory Indicator
SCAN
= Scan Indicator
D W
= Dual Watch Indicator
L O C K
= Lock Key Indicator
Memory Channel Number
E M G
= Emergency Channel 9
F
= Function key indicator
A M
= Amplitude Modulation
W X
= Weather Station
RX
= Receive Indicator
ST
= SoundTracker indicator
TX
= Transmit Indicator
Signal Strength Meter
NOTE: To avoid damaging the LCD display, do not subject your CB radio to extreme temperatures (below -5°F or above 140°F) for extended periods of time.
TO RECEIVE
1. Your 75 WX ST is
automatically in the receive mode and is illuminated.
RX
TOTRANSMIT
1. Press the Press-To-Talk
(PTT) key.
2. The TX icon will appear
3. Hold the microphone
about 2 inches from your mouth and speak in a normal voice.
4. Release the PTT button and you will automatically be in the receive mode again.
OPERATION
TRANSMIT/RECEIVE
2120
75 WX ST manual 10/9/98 9:24 AM Page 24
OPERATION
ONE TOUCH CHANNEL 9 AND 19
22
EMERGENCY CHANNEL 9 OR INFORMATION CHANNEL 19
1. To access emergency
channel 9, press Channel 9/19 key once.
2 .You are now on emergency
channel 9 and the icon will appear.
3 .To access information
channel 19, press Channel 9/19 key again.
E M G
OPERATION
ONE TOUCH CHANNEL 9 AND 19
23
4. You are now
on information channel 19
5. Press 9/19 again to return to the original channel selected.
6. Original channel
75 WX ST manual 10/9/98 9:24 AM Page 26
OPERATION
KEY LOCK
24
KEY LOCK
1. Press Key Lock button to
prevent unintentional channel changing.
2 .You are now locked and the
3. Press Key Lock button
again to deactivate.
L O C K
icon will appear.
OPERATION
FREQUENCY DISPLAY
25
5 DIGIT
FREQUENCY DISPLAY
1. Push and hold Memory
key for approximately 3 seconds.
2. Display will change to the 5 digit frequency of the channel selected.
3. Push and hold Memory key for 3 seconds.
4. Display will change back to channel display.
75 WX ST manual 10/9/98 9:24 AM Page 28
OPERATION
CHANNEL SCAN
ALL CHANNEL SCAN
1. Set Squelch Control (SQL)
to desired setting DSS. *See page 18 to set DSS.
2. Press Scan key. When activity is found on a channel scanning will stop.
3. Scan icon will apear.
4. Press any key to stop
scanning sequence.
OPERATION
WEATHER CHANNELS
2726
WEATHER CHANNELS
1. Press the CB/WX key.
2. The unit will change to
the WX function and a weather channel number will be displayed.
2. Press Up/Down Channel keys to locate the weather station in your area.
3. Press the CB/WX key to return to a normal CB channel.
NOTE. The 75 WX ST will stop scanning and monitor a channel
when it receives an incoming transmission. Five seconds after the transmission stops, the 75 WX ST will resume the scanning function.
75 WX ST manual 10/9/98 9:24 AM Page 30
OPERATION
CHANNEL SAVER/MEMORY CHANNELS
28
CHANNEL SAVER FEATURE*
Automatically retains the last channel used when CB is turned off and returns you to that channel when CB is turned back on.
*To function, the “red wire” must be directly connected to either:
1. Positive (+) battery terminal.
2. Connection on the fuse box that is always on.
See installation section for details.
NOTE: Leaving the 75 WX ST on after your car is turned off can drain
your car battery when connected to a constant 12 volt source.
SAVING CHANNELS IN MEMORY
1. Select desired channel to
store in memory.
2. PRESS and RELEASE the Memory key.
3. PRESSand HOLD the desired Memory Location key to lock channel into memory.
OPERATION
MEMORY CHANNELS
29
RETRIEVING CHANNELS FROM MEMORY
1. PRESSand RELEASE the
Memory key.
2. PRESSand RELEASE the desired Memory Location key.
3. The channel in the memory location will be recalled.
4. The Memory Location will appear on the display.
4. Repeat to recall other Memory Locations.
75 WX ST manual 10/9/98 9:24 AM Page 32
OPERATION
DUAL WATCH
30
DUAL WATCH
Allows you to simultaneously monitor any two preselected channels at one time.
1. Adjust squelch (SQL) setting to the DSS level (see page 18).
2. Set CB to one of the stations you wish to monitor.
3. PRESS and Hold the DW key until a beep is heard.
4. Select new channel.
5. Press and hold DW key
until a beep is heard.
D W
6. The icon appears
and monitoring begins.
7. Press any key to stop monitoring function.
OPERATION
00
DUAL WATCH
31
NOTE: The 75 WX ST will alternate between both channels until it
receives an incoming transmission. Five seconds after the transmission stops, it will again alternate between both channels.
75 WX ST manual 10/9/98 9:24 AM Page 34
If You Think You Need Service, Call 773-889-3087
32
“If your product should require factory service please call
Cobra first before sending your unit in. This will ensure the
fastest turnaround time on your repair.”
You may be asked to send your unit to the Cobra factory. It will be necessary to furnish the following, in order to have the product serviced and returned.
1. For Wa r ranty Repair proof-of-purchase, such as a mech a n i c a l
reproduction or carbon or a sales receipt will be required. If you send the original receipt it cannot be returned.
2 . The entire product, including CB unit and microphone must be sent in. 3 . Enclose a description of what is happening with the unit. Include a typed
or clearly printed name and address of where the unit is to be returned.
4 . Pa ck unit securely to prevent damage in transit. If possible, use the
original packing material.
5 . Ship prepaid and insured by way of a traceable carrier (to avoid loss in
transit) such as United Parcel Service (UPS), Roadway Parcel Service
(RPS)
or First Class Insured Mail to Cobra Factory Service, Cobra
Electronics Corporation, 6500 W. Cortland St., Chicago, IL 60707. Cobra is not responsible for units not received if package has not been properly insured.
If the unit is in warranty, upon receipt of your unit it will either be repaired
6 .
or exchanged depending on the model. Please allow approximately 3 to 4 weeks before contacting us for status. If the unit is out of warranty a letter will automatically be sent informing you of the repair charge or replacement charge. If you have any questions, please call 773-889-3087 for assistance. If you re c e ived the Cobra product as a gift and you do not h ave the proof of purchase information necessary for service, i n c l u d e t h e f o l l owing information, with the product:
Clearly printed or typed name and address. Date, month and year yo u
re c e ived
the gift. Model number. Where purchased (if possible)—store name
and location.
33
HOWYOUR CB CAN SERVE YOU
• Warn of traffic tie-ups ahead.
• Provide weather and road information.
• Provide help fast in event of emergency or breakdown.
• Suggest good spots to eat and sleep.
• Make long trips more interesting, and help keep you awake.
• Provide direct contact with your office or home.
• Make friends as you travel.
• Provide “local information” to find your destination.
• Communicate with friends and family during outdoor activities.
• Help law enforcement officers by reporting drunk and reckless drivers.
A FEW RULES YOU SHOULD KNOW
1. You are not allowed to carry on a conversation with another station for more than five minutes at a time without taking a one-minute break to give others a chance to use the channel.
2. You are not allowed to blast others off the air by overpowering them with illegally amplified transmitter power or illegally high antennas.
3. You can’t use the CB to promote illegal activities.
4. You are not allowed to use profanity.
5. You may not play music in your CB.
6. You may not use your CB to sell merchandise or professional service.
For technical assistance, please call our Automated Help Desk
which can assist you by answering the most
frequently asked questions about Cobra products.
(773) 889-3087
24 hours a day, 7 days a week.
A Consumer Service Representative can be reached through this same
number 8:00 am - 8:00 pm, Monday through Friday, CST.
Frequently Asked Question (FAQ) section at www.cobraelec.com or by e-mail
Technical assistance is also available on-line in the
to productinfo@cobraelec.com
75 WX ST manual 10/9/98 9:24 AM Page 36
WEATHER CHANNEL MESSAGES
You can receive up to the minute local area weather reports provided by NOAA (National Oceanic Atmospheric Administration) 24 hours a day, 7 days a week. An agency of the U.S. Department of Commerce, NOAA warns of dangerous weather, charts our seas and skies, guides our use and protection of ocean and coastal resources and conducts research to improve our understanding and stewardship of the environment.
The National Weather Service operates about 380 stations. Approximately 90 percent of the Nation’s population is within listening range of a NOAA Weather Radio broadcast.
A similar network of about 15 stations using the same frequencies broadcast continuous weather information across much of southern Canada.
If you have a question concerning NOAA Weather Radio or wish to receive a listing of NOAA Weather Radio receiver locations, please contact your nearest National Weather Service Office, or write to National Weather Service (Attn: W/OM11), National Oceanic and Atmospheric Administration, Silver Spring, MD. 20910.
Note: Some areas may not have a broadcast tower within the receiving
range of your 75 WX ST.
USE CHANNEL 9 FOR EMERGENCY ONLY
Operating Procedure for Emergency Communications 1 .
For E M E R G E N C Y communications, set radio to Ch. 9. For n o n - e m e r g e n cy communications, select desired Channel by pressing the CHANNEL UP/DOWN tuning buttons until reaching the desired Channel.
Be sure the antenna is properly connected to the radio before transmitting. Prolonged transmitting without an antenna, or use of a poorly matched antenna, could cause damage to the transmitter.
2. When asking for aid on Channel 9 it is suggested that you request a
REACT base to respond by saying “Break Channel 9 for a REACT base” and provide the CB DISTRESS DATA (called “CLIP”):
CALL SIGN-Identify yourself and vehicle. LOCATION-Be exact. INJURIES-Number.Type. Trapped? PROBLEM- Give details and help required. Air CLIP repeatedly so any
monitor can aid you.
If you don't receive a response on Ch. 9; try Ch.14 or 19. FCC gives the following examples of permitted and prohibited types of
communications for use on Channel 9. These are guidelines and are not intended to be all-inclusive .
Permitted Example Message
Yes “A tornado sighted six miles north of town.” No “This is observation post number 10. No tornado sighted.” Yes “I am out of gas on Interstate 95 at mile marker 121.” No “I am out of gas in my driveway.” Yes “There is a four-car collision at Exit 10 on the Beltway,
No “Traffic is moving smoothly on the Beltway.” Yes “Base to Unit 1, the Weather Bureau has just issued a
No “Attention all motorists. The Weather Bureau advises that
Yes “There is a fire in the building on the corner of 6th and
No “This is Halloween patrol unit number 3. Everything is
send police and ambulance.”
thunderstorm warning. Bring the sailboat into port.”
the snow tomorrow will accumulate 4 to 6 inches.”
Main Streets.”
quiet here.”
3534
75 WX ST manual 10/9/98 9:24 AM Page 38
CB 10-CODES
Citizens Band radio operators have largely adopted the “10-code” for standard questions and answers. Its use permits faster communications and better understanding in noisy areas. The following table lists some of the more common codes and their meanings:
Code Meaning
10-1 Receiving poorly 10-2 Receiving well 10-3 Stop transmitting 10-4 OK, message received 10-5 Relay message 10-6 Busy, stand by 10-7 Out of service, leaving air 10-8 In service, subject to call 10-9 Repeat message 10-10 Transmission completed,
standing by 10-11 Talking too rapidly 10-12 Visitors present 10-13 Advise Weather/Road
conditions 10-16 Make pick up at 10-17 Urgent business 10-18 Anything for us? 10-19 Nothing for you, return to base 10-20 My location is 10-21 Call by telephone 10-22 Report in person to 10-23 Stand by 10-24 Completed last assignment 10-25 Can you contact 10-26 Disregard last information 10-27 I am moving to channel 10-28 Identify your station 10-29 Time is up for contact 10-30 Does not conform to FCC rules 10-32 I will give you a radio check 10-33 EMERGENCY TRAFFIC 10-34 Trouble at this station 10-35 Confidential information 10-36 Correct time is
Code Meaning
10-37 Wrecker needed at 10-38 Ambulance needed at 10-39 Your message delivered 10-41 Please turn to channel 10-42 Traffic accident at 10-43 Traffic Tie up at 10-44 I have a message for you 10-45 All units within range
please report 10-50 Break channel 10-60 What is next
message number? 10-62 Unable to copy,
use phone 10-63 Net directed to 10-64 Net clear 10-65 Awaiting your next
message/assignment 10-67 All units comply 10-70 Fire at
Proceed with transmission
10-71
in sequence 10-77 Negative contact 10-81 Reserve hotel room for 10-82 Reserve room for 10-84 My telephone number is 10-85 My address is 10-91 Talk closer to mike 10-93 Check my frequency on this
channel 10-94 Please give me a
long count 10-99 Mission completed, all
units secure 10-200 Police needed at
FREQUENCY RANGE
Your COBRA transceiver represents one of the most advanced AM two­way radios used as a Class D station in the Citizens Radio Service. This unit features advanced Phase Lock Loop (PLL) circuitry providing complete coverage of all 40 CB channels and 10 weather channels as shown below.
CB Channel Freq.
Channel in MHz
1 26.965 2 26.975
3 26.985
4 27.005 5 27.015
6 27.025
7 27.035
8 27.055
9 27.065
10 27.075 11 27.085
12 27.105 13 27.115 14 27.125 15 27.135
16 27.155 17 27.165 18 27.175 19 27.185 20 27.205
This device complies with part 15 of the FCC rules. Operation is subject to the following conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received, including interference that may cause undesired operation.
CB Channel Freq.
Channel in MHz
21 27.215 22 27.225 23 27.255 24 27.235 25 27.245
26 27.265 27 27.275 28 27.285 29 27.295 30 27.305
31 27.315 32 27.325 33 27.335 34 27.345 35 27.355
36 27.365 37 27.375 38 27.385 39 27.395 40 27.405
Weather Weather Freq. Channel in MHz
1 162.550 2 162.400 3 162.475 4 162.425 5 162.450 6 162.500 7 162.525 8 161.650 9 161.775 0 163.275
3736
75 WX ST manual 10/9/98 9:24 AM Page 40
38
75WXST SPECIFICATIONS
GENERAL
CHANNELS CB - 40 CH
WEATHER - 10 CH
FREQUENCY RANGE CB - 26.965 TO 27.405 MHZ
WEATHER - 161.650 TO 163.275 MHZ FREQUENCY TOLERANCE 0.005 % FREQUENCY CONTROL PLL (PHASE LOCK LOOP) SYNTHESIZER OPERATING TEMPERATURE RANGE -30° C TO + 65° C MICROPHONE ELECTRET, PUSH-TO-TALK INPUT VOLTAGE 13.8 VDC, EXTERNAL ANTENNA CONNECTOR SO239 METER LCD DISPLAY, ICONS SIZE L 2 3/4" x W 1 7/8" x H 4 1/4" WEIGHT 1 LB.
TRANSMITTER
POWER OUTPUT 4.0 W AT 13.8 VDC MODULATION AM FREQUENCY RESPONSE 300 - 3000 HZ AT -6 DB OUTPUT IMPEDANCE 50 OHMS, UNBALANCED
RECEIVER
CB SENSITIVITY LESS THAN 1 uV FOR 10 DB S/N IF FREQUENCY DUAL CONVERSION
1 ST - 10.690 MHZ, 2ND - 455 KHZ AUDIO OUTPUT 500 mW MAXIMUM AT 10 % THD FREQUENCY RESPONSE 300 - 3000 HZ AT -6 DB 2ND IF IMAGE REJECTION GREATER THAN 60 DB ADJACENT CH. REJECTION 50 DB MIN. AUTOMATIC NOISE LIMITER BUILT- IN. FREQUENCY CONTROL PLL (PHASE LOCK LOOP)
WEATHER
SENSITIVITY LESS THAN 1 uV FOR 12 DB SINAD IF FREQUENCY DUAL CONVERSION
1st: -10.690 MHz
2nd: -455 KHz AUDIO OUTPUT MAXIMUM 500 mW AT 10 % THD FREQUENCY RESPONSE 300 - 3000 HZ AT -6 DB
39
LIMITED TWO YEAR WARRANTY
COBRA ELECTRONICS CORPORATION warrants that its COBRA CB Radios, and
the component parts thereof, will be free of defects in workmanship and materials for a period of two (2) years from the date of first consumer purchase. This warranty may be enforced by the first consumer purchaser, provided that the product is utilized within the U.S.A.
COBRA will, without charge, repair or replace, at its option, defective CB radios, products or component parts upon delivery to the COBRA factory Service Department, accompanied by proof of the date of first consumer purchase, such as a duplicated copy of a sales receipt.
You must pay any initial shipping charges required to ship the product for warranty service, but the return charges will be at Cobra's expense, if the product is repaired or replaced under warranty. For further details concerning procedures for obtaining service, see the “If You Think You Need Service” section of the Owner’s Manual.
Exclusions: This limited warranty does not apply; 1) to any product damaged by accident; 2) in the event of misuse or abuse of the product or as a result of unauthorized alterations or repairs; 3) if the serial number has been altered, defaced or removed; 4) if the owner of the product resides outside the U.S.A.
All implied warranties, including warranties of merchantability and fitness for a particular purpose are limited in duration to the length of this warranty.
COBRA shall not be liable for any incidental, consequential or other damages; including, without limitation, damages resulting from loss of use or cost of installation.
Some states do not allow limitations on how long an implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you.
COBRA ELECTRONICS CORPORATION
6500 W. Cortland Street
Chicago, Illinois 60707
75 WX ST manual 10/9/98 9:24 AM Page 42
40
OPTIONAL ACCESSORIES
You can find these fine accessories at your local Cobra CB dealer.
High Performance Magnetic Mount Weather/CB Antenna. ATW-400 $39.95
Remote connector box. AC-701 $29.95
4 foot extension cord. AC-702 $19.95
If you wish, you can order directly from Cobra
Order by phone:
Call 1-773-889-3087 (Press 1 from the main menu) 8a.m.-8p.m. M-F CST.
Order by mail or fax: Please fill out order form below, and mail/fax directly to Cobra.
Part No. Cost Ea. X Qty. = Amount
AC-701 $29.95 AC-702 $19.95 ATW-400 $39.95
(Prices subject to change without notice)
Fax to:
1-773-622-2269
Please print clearly:
Name Address (Not P.O. Box) City State Zip Credit Card No. Exp. Date Customer Signature
Circle One: Visa MasterCard Discover
Amount (Tax if applicable) Shipping//handling $3.75 Total
Allow 4 to 6 weeks for delivery. Offer valid in Continental U.S. only.
★★
Illinois residents add 7%
★ ★
Cook Co. residents add .75% (7.75% total)
★ ★
Chicago residents add 1% (8.75% total)
★★
Indiana residents add 5%
★★
Michigan residents add 4 %
★★
Minnesota residents add 6%
★★
Ohio residents add 6%
★★
Wisconsin residents add 5%
Mail to:
Cobra Accessories Dept.
6500 W. Cortland St.,
Chicago, IL 60707
Loading...
