R
FINE FURNITURE
102888
EXTENSION LEAF COUNTER
HEIGHT TABLE WITH STORAGE.
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
www.coastercompany.com
PAGE 1 OF 3
REVISION 0 : 05/11/2010
REVISION 1 : 09/11/2012
ASSEMBLY TIPS :
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to ensure fast & easy
assembly.
! Warning !
1. Don't attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
2. This product is for home use only and not intended for commercial establishmemts.
PARTS IDENTIFICATION :
NO DESCRIPTION FIGURE Q'TY
SIDE PANEL
1
WITH E XTRA CLEAT
SIDE PANEL
2
DOOR PANEL
3
TABLE TOP
4
TABLE LEAF
5
TABLE LEG
6
TOP PANEL
7
BOTTOM PANEL
8
1 PC
2 PCS
1 PC
1 PC
1 PC
4 PCS
1 PC
1 PC
STEP 1
Align & fasten side panels to table legs
using bolts, lock washers & small flat washers.
Tighten with Allen wrench.
B
H
D
C
2
HARDWARE IDENTIFICATION :
NO DESCRIPTION FIGURE Q'TY
HEX NUT
A 4 PCS
BOLT
B 14 PCS
LOCK WASHER
C
SM ALL FLAT
D
WASHER
LARGE FLAT
E
WASHER
SCREWF 4 PCS
DOOR HINGEG 1 PC
ALLEN WRENCH
WRENCH
H
I
5/16 "x12mm
1/4"x 40mm
5/16 "x13mm
5/16 "x19mm
5/16 "x22mm
3x15 mm
120m m
M4x5 9mm
M4x 50mm
STEP 2
2.1 Align & fasten door panel to table legs
using bolts, lock washers & small flat washers.
Tighten with Allen wrench.
2.2 Align & fasten door hinge to extra cleat on
side panel using screw. Tighten with screw
driver ( not included)
B
F
H
1
18 PCS
14 PCS
4 PCS
1 PC
1 PC
D
C
6
2
G
6
1
FINE FURN ITURE
R
2
3
ww w.coastercompany.com
2
PAGE 2 OF 3
STEP 4STEP 3
Place both top & bottom panels into position
as per diagram shown.
7
8
Align & fasten table top to table legs using
large flat washer, lock washer & hex nut.
Tighten with wrench.
4
I
A
E
C
Pull out the table top in order to place the
table leaf into position.
5
STEP 6STEP 5
Close the table top
www .co astercomp any.com
FINE FURN ITURE
R
PAGE 3 OF 3
