102722
LADDER BACK SIDE CHAIR WITH
CUSHION SEAT
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
www.coastercompany.com
REVISION 0 : 06/19/2011
REVISION 1 : 09/13/2011
REVISION 2 : 04/25/2016
PAGE 2 OF 3
ITEM :
ASSEMBLY TIPS :
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instruction in the same sequence as numbered to assure fast & easy assembly.
102722
Warning !
1. Don't attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
2. This product is for home use only and not intended for commercial establishment.
ASSEMBLY INSTRUCTIONS
PARTS IDENTIFICATION:
ASSEMBLY TIME 20 MINUTES
PARTS IDENTIFICATION:
A
B
C
D
E1
F1
CHAIR BACK
FRONT LEG FRAME
SIDE RAIL
CUSHION SEAT
RIGHT STRETCHER
LEFT STRETCHER
HARDWARE IDENTIFICATION:
1PC
1PC
2PCS
1PC
1PC
1PC
1
2
3
4
5
NOTE : QUANTITIES SHOWN ARE FOR ONE CHAIR.
NOTE : PHILLIPS HEAD SCREW DRIVER IS REQUIRED IN THE ASSEMBLY
PROCESS. HOWEVER, MANUFACTURER DOES NOT PROVIDE THIS ITEM.
ALLEN WRENCH
BOLT
LOCK WASHER
SHORT PAN HEAD SCREW
LONG PAN HEAD SCREW
1PC
6PCS
6PCS
4PCS
4PCS
www.coastercompany.com
ITEM :
PAGE 3 OF 3
102722
ASSEMBLY INSTRUCTIONS
STEP 1
C
C
STEP 2
3
2
3
2
1
A
1
E1
B
F1
STEP 3
5
BOTTOM VIEW
STEP 4
4
BOTTOM
VIEW
D
4
4
4
4
www.coastercompany.com
