CMA Dishmachines L-1X16, L-1X User Manual

-
8
-
2
MODEL L-1X & L-1X16
Installation & Operations
Rev 1.14
CMA DISHMACHINES
12700 KNOTT AVENUE
GARDEN GROVE, CALIFORNIA 92841
800-854-6417
FAX 714
www.cmadishmachines.com
141
TABLE OF CONTENTS
MODEL CMA-L-1X & L-1X16
1. SPECIFICATIONS.........................................................................................2
1.1. L-1X & L-1X16.............................................................................................................................. 2
1.2. L-1X AND L-1X16 OPERATIONAL CYCLE....................................................................................... 3
2. GETTING STARTED .....................................................................................5
2.1. INTRODUCTION TO THE L-1X AND L-1X16..................................................................................... 5
2.2. RECEIVING AND INSTALLATION ...................................................................................................... 6
2.2.1. Electrical ................................................................................................................................ 6
2.2.2. Plumbing................................................................................................................................. 6
2.2.3. Post Instructions..................................................................................................................... 6
2.2.4. Installers Checklist................................................................................................................. 7
3. OPERATION..................................................................................................8
3.1. INITIAL SETUP................................................................................................................................. 8
3.1.1. Check…................................................................................................................................... 8
3.1.2. Chemicals............................................................................................................................... 8
3.1.3. Filling the Machine ................................................................................................................ 8
3.2. GENERAL......................................................................................................................................... 8
3.2.1. Pre-Scrapping......................................................................................................................... 8
3.2.2. Proper Chemical Dosage ....................................................................................................... 8
3.2.3. Proper Filling......................................................................................................................... 9
3.2.4. Water Pump............................................................................................................................ 9
3.2.5. Pump Cavitation..................................................................................................................... 9
4. MAINTENANCE...........................................................................................10
4.1. TIMER ASSEMBLY.......................................................................................................................... 10
4.1.1. Cam Adjustment.................................................................................................................... 10
4.2. QUICK SERVICE GUIDE................................................................................................................... 11
4.3. TROUBLESHOOTING....................................................................................................................... 12
5. ADDENDUM FOR MACHINES INSTALLED IN THE CITY OF CHICAGO.15
APPENDIX A: OPERATOR & CLEANING INSTRUCTIONS ............................16
6. ELECTRICAL DIAGRAM ............................................................................ 17
1. Specifications

1.1. L-1X & L-1X16

WATER CONSUMPTION
PER RACK 1.7 GAL. 6.44 L PER HOUR 40.8 GAL. 154.4 L
OPERATING CYCLE
WASH TIME-SEC 57 57 RINSE TIME-SEC 48 48 DWELL TIME-SEC 15 15 TOTAL CYCLE 2 MIN. 2 MIN.
OPERATING CAPACITY
RACKS PER HOUR 24 24 WASH TANK CAPACITY 1.7 GAL. 6.44 L PUMP CAPACITY 35 GPM 132.5 LPM
WATER REQUIREMENTS
WATER INLET ½” — DRAIN CONNECTION 1” CYCLE TEMPERATURES WASH-°F (Min) 140 60°C FRAME DIMENSIONS DEPTH 23 ½” 59.69 cm WIDTH 24” 60.96 cm L-1X HEIGHT 30” 76.2 cm L-1X16 HEIGHT L-1X MAX CLEARANCE FOR DISHES 12 ¼” 31.11 cm L-1X16 MAX CLEARANCE FOR DISHES 16” 40.64 cm
33 ¾” 85.73 cm
METRIC
EQUIVALENT
140°F 60°C
ELECTRICAL*
SUSTAINER HEATER (Not Booster Heater) WASH PUMP MOTOR 13.4 AMPS
*MUST CONNECT TO DEDICATED 20 AMP SUPPLY CIRCUIT.
COMPLIANCE WITH LOCAL ELECTRICAL CODES MUST BE FOLLOWED.
SHIPPING WEIGHT
L-1X (Approximate) L-1X16 (Approximate)
MODEL L-1X & L-1X16 INSTALLATION & OPERATION MANUAL Rev. 1.14 Page
190# 195#
115 VAC
15.8 AMPS
0.8 kW
86.2 kg
88.5 kg
2
W
r

1.2. L-1X and L-1X16 Operational Cycle

The L-1X and L-1X16 Operational Cycle has a total cycle time of 2 minutes (120 seconds). The Timing Diagram and the steps listed below detail the individual functions that are executed during each Operational Cycle.
Seconds: 0 10 20 30 40 50 60 70 80 90 100 110
120
Instant
Start Relay
Cam 1
Cam 2
Cam 3
Cam 4
Cam 5
Cam 6
Cam 7
Cam 8
ASH
DRAIN
RINSE
*Heater is optional
Start/Stop
Detergent
Drain/Rack
Counter
Flush/Fill
Sanitize
Rinse
Pump Motor
Heater*
1. With the machine powered up, toggling the START switch begins a cycle. a) Toggling the START switch energizes both the cam timer motor and the instant
start relay. The instant start relay latches ON the power to the cam timer motor so that the START switch can be released a moment after it has been toggled without the cam timer motor losing power.
b) After about 2 seconds, Cam 1—the Start cam—latches ON the power to the cam
timer motor and drops out the instant start relay. The cam timer motor continues to run for a total of 2 minutes, at which time it switches OFF—resetting the cam timer—and waits for the next start command.
2. Cam switch 7 controls the pump motor. The pump motor comes ON at the beginning of the operational cycle and continues to run until the end of the drain function (controlled by cam switch 3), at which time it turns off for about eight seconds
MODEL L-1X & L-1X16 INSTALLATION & OPERATION MANUAL Rev. 1.14 Page
3
allowing time for the machine to refill enough to avoid running the pump dry before the pump motor restarts and runs to the completion of the operational cycle.
The pump motor runs the pump for the 57-second wash cycle, then pumps the water out through the drain, turns off for about 8 seconds (allowing the machine to refill with clean rinse water) and then runs the pump for the 48-second rinse cycle.
3. Cam switch 3 controls the drain function. At the end of the 57-second wash cycle, cam switch 3 energizes the drain valve solenoid allowing the pump motor to drain th e wash water out of the machine. Cam switch 3 also increments the rack counter by one each cycle.
4. Cam switch 4 controls the water valve solenoid on the water supply to flush and fill the machine. At the end of the wash cycle the drain valve is opened, the pump motor continues to run (to pump the wash water out through the drain), and the Flush function begins. At first, flushing the machine because the drain valve is still open, then—with the drain valve closed and the pump motor stopped— the machine begins to fill for the rinse cycle. Once the machine has refilled sufficiently, the pump motor restarts carrying out the rinse portion of the cycle as the filling of the wash tank completes.
5. Cam switch 2 controls the detergent pump and turns ON about 5 seconds after the operational cycle is started and runs for a few seconds to provide sufficient detergent for the wash cycle. This cam can be adjusted as necessary for proper detergent dosage. See section 4.1.1 Cam Adjustment
6. Cam switches 5 and 6 control the sanitizer and rinse pumps respectively. They turn ON at the beginning of the rinse cycle and run for a few seconds to provide sufficient sanitizer and rinse aid for the rinse cycle. These cams can be adjusted as necessary for proper chemical dosage. See section 4.1.1 Cam Adjustment
7. Cam switch 8 operates the optional sustainer heater. This cam assures that the sustainer heater only turns on when the dishmachine is not in a cycle. This prevents the machine from drawing too much electrical current at any one time.
MODEL L-1X & L-1X16 INSTALLATION & OPERATION MANUAL Rev. 1.14 Page
4

Getting Started

2. Getting Started
All sections of the manual address both the L-1X and the L-1X16. Separate information on each machine is only provided where differences exist between the two models.

2.1. Introduction to the L-1X and L-1X16

The L-1X and L-1X16 Dishmachines are unique in their field; they have all the features of a standard commercial size machine packed into an under-counter, standalone dishmachine.
Operation of the L-1X and L-1X16 are extremely easy. After initially filling the machine (see section Operational Cycle, which runs automatically.
To reduce service time, all electrical components are mounted in a sliding drawer for easy access. This “Works-In-A-Drawer” can be removed by unplugging a single connector for easy serviceability.
The only external connections necessary are the power source, water supply and drainpipe. There are also accessories that can be chosen when desired such as the optional sustaine r heater
and 6” legs. The optional sustainer heater with thermostat is extremely practical for maintaining wash tank temperature between cycles. The 800 watt heater will hold the wash tank temperature between 130°F and 140°F while the machine is not being run. See section Error! Reference source not found. Error! Reference source not found. for the parts list and accessories available for the machine.
The supply water to the L-1X and L-1X16 must be a minimum of 140°F. The pipe supplying the water must be ½” minimum. The plumbing connection is located at the back of the machine. The drain is a 1" barbed fitting located at the back of the machine for easy attachment of your drain hose. See section
This manual is structured to provide a complete reference guide to the L-1X and L-1X16. It is presented in a manner that all users will be able to comprehend and use as an effective tool in supporting the installation, operation and maintenance of the dishmachine. The first section provides the specifications and details of the operational cycle. The next section explains how the machine is packaged and what to look for when receiving the machine. After unpacking the machine, this manual explains how to install and set up the machine for use. Requirements are given for plumbing, wiring, and space considerations. These attributes of the machine are al ways taken into consideration by our well-trained sales representatives prior to the order bei ng placed. In the manual, guidance is also given for operation to ensure that the machine will be able to run optimally.
The We make this portion of the manual easy to understand so that all levels of operators may be able to read and comprehend the operation of the machine. The function of the machine itself is mostly automatic and takes little training to put into full operation. The diagnostic considerations for the machine if problems occur.
The Maintenance section of the manual is for qualified personnel and provides trouble shooting procedures and specific maintenance instructions.
The final section of the manual is the Parts Manual. This section has the parts lists and wiring diagram for the machine.
CMA warranties the workmanship of the machine. At CMA we are committed to providing the best machines and customer service in the food and
beverage industry and your feedback is welcome.
3.1.3 Filling the Machine), toggling the Fill/Start switch to the “START” position begins the
2.2.2 Plumbing.
Operation section of the manual may be used for instruction and procedures when required.
Operation section also includes
MODEL L-1X & L-1X16 INSTALLATION & OPERATION MANUAL Rev. 1.14 Page
5
Getting Started

2.2. Receiving and Installation

The dishwasher is shipped from the factory in a corrugated box on a wooden pallet. The installation guidelines give a systematic procedure for setting up the machine.
1. Start by removing the box and packaging material. Check for the following component parts:
A. Drain Screen:
The Wash Tank Scrap Screen is shipped inside the wash cavity of the machine. This screen must be in place during operation. It has been designed to perform two basic functions:
Strain water that is circulating through the spray arms and pump assembly.
A basket to catch heavy solids or broken glass that may plug the impeller.
B. Spray Arms
The end caps on the spray arms have been taped to protect them in shipping. Remove the tape from the spray arm end caps.
C. Tube Stiffeners:
The tube stiffeners must be used to prevent the feed tubes from curling up inside the chemical pail allowing the tip to rise out of the chemical. Remove the tie-wraps securing the tube stiffeners to the dishmachine to free them up for use. Be careful not to remove any of the tie-wraps securing the tube bundle.
2. Set the machine in place and, using the leg adjusters, level from side-to-side and front-to-
back.

2.2.1. Electrical*

A 20-amp, 115 volt, 60 Hz dedicated circuit must be used to supply electrical power to the L-1X or L-1X16 Dishmachine (see specification sheet page there is sufficient length of flexible conduit or power cord to permit the machine to be moved for cleaning.
1). The power connection must be such that

2.2.2. Plumbing*

The machine is equipped with a gate valve with a ½” female NPT connection located at the lower left-hand corner (facing the back) of the machine. A 140°F water line should be plumbed to this point. The water line used must be of sufficient length and flexibility to permit the machine to be moved for cleaning.
A 1” male NPT fitting is provided for the drain connection on the discharge port of the diverter valve (lower, right-hand corner of machine). This fitting may be removed and user provided hardware may be used if necessary to facilitate compliance with local plumbing codes. Code requires that the drain discharge provides an air gap no less than 1” or two pipe diameters, whichever is greater, above the flood level rim of an approved floor drain.

2.2.3. Post Instructions

Mount the wall chart provided in a conspicuous place and instruct the operators on proper cleaning and operation of the L-1X and L-1X16. The instruction chart is also provided as an appendix to this manual (see appendix).
*
Electrical and plumbing connections must be made by a qualified person who will comply with all
available Federal, State, and Local Health, Electrical, Plumbing and Safety codes
MODEL L-1X & L-1X16 Installation & Operations Manual Rev. 1.14 Page6
Getting Started

2.2.4. Installers Checklist

Dishmachine checked for concealed damage Hot water supply is 140° F (60 C) Incoming water supply line is ½” minimum Supply circuit breaker for machine is properly sized (20 amp) Service voltage and phase type are correct to machine data plate Drain hose is installed with adequate air gap Dishmachine is properly grounded Dishmachine is properly leveled Machine circuit breaker is labeled “DISHWASHER” Machine has been connected with correctly sized wire (12 gauge
minimum)
MODEL L-1X & L-1X16 Installation & Operations Manual Rev. 1.14 Page7
3. Operation

3.1. Initial Setup

3.1.1. Check…

Drain screen is in place Spay arms and end plugs are secure

3.1.2. Chemicals

Assure there is a sufficient supply of chemicals before beginning a shift.

3.1.3. Filling the Machine

With the power ON, toggle and hold the Fill/Start switch in the “FILL” position until the water level in the wash tank is about 1” deep, or just below the bottom wash arm.

3.2. General

Caution: Do not operate the dishmachine without the drain screen in place. Debris
getting into the pump impeller can damage the pump.
1. Load a rack of properly pre-scrapped dished into the machine and close the door.
2. With the machine filled to the proper level, toggle the Fill/Start switch to the “START” position – the machine will automatically begin its cycle. The green running light will illuminate while an operational cycle is in process.
3. At the end of the shift, drain the machine by holding the Drain toggle switch in the “DRAIN” position until the machine is completely drained. To avoid running the pump dry, do not hold the Drain toggle switch in the “DRAIN” position any longer than necessary.
4. Remove and clean the drain screen. Remove and clean the spray arms. (See wall chart instructions or instructions provided in Appendix A: Operator & Cleaning Instructions).
5. Replace the drain screen and spray arms.

3.2.1. Pre-Scrapping

It is essential that the operator thoroughly understand the importance of pre-scrapping the dishes before loading them. The L-1X and L-1X16 are equipped with a removable drain screen. The drain screen can be easily removed for cleaning between Operational Cycles of the dishmachine. Properly pre-scrapping the dishes should permit the dishmachine to operate for an entire shift before needing to remove and clean the drain screen.

3.2.2. Proper Chemical Dosage

The amount of chemical delivered, whether it is detergent, sanitizer or rinse aid, is determined by its respective cam on the cam timer.
Cam number 2 runs the detergent pump
Cam number 5 runs the sanitizer pump
Cam number 6 runs the rinse aid pump

Operation

MODEL L-1X & L-1X16 INSTALLATION & OPERATION MANUAL Rev. 1.14 Page
8
Operation
These cams were set at the factory but can be adjusted after final installation to maximize efficiency of chemical use (see section

3.2.3. Proper Filling

The amount the machine is automatically filled each cycle is determined by the number 4 cam. When the number 4 cam switch actuator rides down into the cam groove, the solenoid valve on the fill line is energized causing the machine to fill. Since the cam only controls the duration of the fill, varying water pressure can vary the amount the machine fills. If the water pressure at the facility where the machine is installed is enough higher or lower than the water pressure was at the factory, the number 4 cam may need to be adjusted to correct the difference (see section should be filling to a level about 1” deep over the entire bottom of the wash tank, or just below the lower wash arm. If the water pressure at the facility varies throughout the day, a pressure regulator may have to be installed on the water supply line to the machine to maintain constant pressure.
Note: If the optional sustainer heater is installed, the wash tank must be properly filled, and the machine properly leveled, or the float switch, which prevents the heater from turning on if the level is too low, will not permit the heater to turn on.

3.2.4. Water Pump

The water pump takes in water from the drain sump and pumps it to the spray nozzles at a rate of 68 gallons per minute and a pressure at the nozzles of approximately 7 to 10 PSI. After being released through the spray arms and washing or rinsing the dishes, the water runs down the pan to the sump, through the drain screen, and back to the pump.
The pump is driven by a 115 volt, 1 HP motor operating at 3450 RPM. The impeller is mounted with a right-hand thread onto a 5/8” stainless steel shaft, which is coupled to the motor armature shaft. See section Error! Reference source not found. Error! Reference source not found. for a detailed drawing.

3.2.5. Pump Cavitation

By listening to the normal pumping sound of the motor it can be determined if there is insufficient water in the machine, as you will hear a hesitation in the normal pumping rhythm, which is created by the air getting into the pump. Cam 4 can be adjusted to increase the amount of water that is automatically fed into the machine during a cycle (see section
4.1.1 Cam Adjustment).
4.1.1 Cam Adjustment.)
4.1.1 Cam Adjustment). The machine
MODEL L-1X & L-1X16 Installation & Operations Manual Rev. 1.14 Page9

Maintenance

4. Maintenance
The maintenance procedures detailed in this section are to be performed by qualified person nel.

4.1. Timer assembly

The standard timer assembly consists of a ½ RPM (2 minutes per revolution) motor turning a common shaft, which, in turn, rotates eight cams. As the cams rotate, they control various functions and the sequence of the operational cycle.
The individual function of each of the 8 cams is identified by a label on the timer assembly. Cams 1 through 8 are positioned from left to right beginning with the “START” cam (cam 1).
RINSESANI.FLUSHDRAINDET.START
Timer Assembly Label
*The “HEATER” label is not present if the optional sustainer heater is not installed on the machine.
Except for cams 1, and 3, all other cams can be user adjusted. The cam positions are all set at the factory and only the cams controlling the chemical pumps (cams 2, 5 & 6) should ever need adjusting. Each micro switch on the timer assembly is turned on and off by the cam its actuator rides on. For all of the cams, except cams 1, 7 and 8, its corresponding switch is ON when its actuator is down in the cam groove. (Cams 1, 7 and 8 are reverse acting and are turned ON when the micro switch actuator is up out of the groove.) Opening the groove of any cam other than cams 1, 7 or 8 will increase the amount of time that the micro switch is held ON. The cams are slip-fit and a cam adjustment wrench is provided (a small screw driver or the edge of a table knife can also work to adjust the cams).
MOTOR
PAUSE
HEATER
*

4.1.1. Cam Adjustment

The two sides of each cam connect to the shaft with a slip-fit so all cam adjustments are made by rotating one side of the cam on the shaft to either increase or decrease the size of the cam groove.
1. Turn off the circuit breaker providing power to the machine before pulling the control drawer out to access the timer assembly.
Caution: One of the terminals on the main power switch remain s “hot” even when the machine’s main power switch is turned off—so turn the power off at the circuit breaker.
2. Remove the two 8–32 x ½” Screws securing the control drawer and slide it out to its fully extended position.
3. Using the timer assembly label, determine which cam is to be adjusted. Double check by counting over from cam 1 to the cam to be adjusted.
4. Determine which edge of the cam groove to be adjusted is the leading edge (contacts the limit switch actuator first when the shaft is rotating) and which edge of the groove is the trailing edge. The leading edge of the cam groove determines when in the cycle the control action begins and should not be changed.
5. Adjust the trailing edge of the cam groove by rotating the appropriate side of the cam in the proper direction to either increase or decrease the cam’s groove; resulting in increasing or decreasing the total time that switch will be held ON.
MODEL L-1X & L-1X16 PARTS MANUAL Rev. 1.14 Page 10

4.2. Quick service guide

Maintenance
MODELS: L-1X, L-1X16 UNDER COUNTER
TECHNICAL ISSUE CAUSE SOLUTION
Delimer switch in delime position Flip to
Wash Pump motor will not shut off Faulty delimer switch Replace switch, P/N 00475.30
Faulty contactor Replace contactor, P/N 00404.82
Continues cycles Faulty #1 micro switch (start/stop) Replace switch, P/N 00411.00
Faulty #1 micro switch Replace switch, P/N 00411.00
Sustainer heater not working Faulty float switch Replace switch, P/N 13463.10
Machine not level Level machine
Faulty ice cube relay Replace relay, P/N 00631.00
Machine does not drain Faulty #3 micro switch (drain) Replace switch, P/N 00411.00
Faulty drain valve Replace drain valve, P/N 04103.00
Does not hold water Faulty #3 micro switch (drain) Replace switch, P/N 00411.00
Tank overflows overnight Debris in water Solenoid Valve
Water leaks out of Vacuum Breaker
Wash Pump motor not running Faulty door reed switch Replace reed switch, P/N 00557.55
Faulty 7th micro switch Replace switch, P/N 00411.00
Faulty motor contactor Replace contactor, P/N 00404.82
Faulty Start/Fill Switch Replace switch, P/N 03470.01
Timer does not rotate Faulty #1 micro switch Replace switch, P/N 00411.00
Faulty timer motor Replace motor assembly, P/N 00501.00
Faulty #4 Micro switch Replace switch, P/N 00411.00
Machine does not fill
Faulty water solenoid coil Replace solenoid coil, P/N 00738.10
Sanitizer pump does not run Faulty 5th micro switch Replace switch, P/N 00411.00
Faulty manual drain switch Replace switch, P/N 03406.62
Faulty start/fill switch Replace switch, P/N 03470.01
Low water level inside machine
Clogged or defective drain valve Clean and/ or replace drain valve, P/N 04103.00
Dirty or defective vacuum breaker kit assy
Faulty check valve Replace check valve, P/N 00715.00 Male/ female plug on the back of control drawer is loose
Debris inside water solenoid valve or Faulty valve
Delimer switch in wrong position Switch to
Faulty sanitizer pump motor Replace motor, P/N 00416.00
NORMAL
Add water to tank to activate float switch, adjust water cam on timer
Clean and replace valve diaphragm, P/N
00707.00 Clean or replace internal parts, P/N 03623.00
Secure plug
Clean and replace valve diaphragm, P/N
00707.00
position
NORMAL
position
MODEL L-1X & L-1X16 PARTS MANUAL Rev. 1.14 Page 11
Maintenance

4.3. Troubleshooting

PROBLEM LIKELY CAUSE SOLUTION
Machine inoperative
Power off at circuit breaker Reset circuit breaker Defective power switch Replace power switch
P/N: 00433.10
Defective timer assembly motor Replace timer assembly motor
P/N: 00501.00
Pump Motor inoperative
Door is open Close door Control drawer is pulled out Secure control drawer Defective reed (door) switch Replace reed (door) switch
P/N: 00557.55
Defective timer assembly (Cam 7)
Replace timer assembly*
P/N: 00408.80
Defective pump motor contactor Replace contactor
P/N: 00404.82
Defective pump motor Replace pump motor
P/N: 00201.00
Pump Motor runs with door open
Defective reed (door) switch Replace reed (door) switch
P/N: 00557.55
Defective pump motor contactor Replace contactor
P/N: 00404.82
Delime switch is on Turn off delime switch Motor runs continuously Delime switch is on Turn off delime switch Optional Sustainer Heater
(no heat)
Defective thermostat on heater Replace heater
P/N: 04109.10
Defective heater relay Replace heater relay
P/N: 00631.00
Defective timer assembly
(Cam 8)
Replace timer assembly *
P/N: 00408.80
Defective heater Replace heater
P/N: 04109.10
Defective float switch Replace float switch
P/N: 13463.00
Float switch not actuated
Fill wash tank completely Level machine
Optional Sustainer Heater (never turns off)
Defective thermostat on heater Replace heater
P/N: 04109.10
Defective timer assembly
(Cam 8)
Replace timer assembly *
P/N: 00408.80
Defective heater relay Replace heater relay
P/N: 00631.00
*The timer assembly motor (P/N: 00501.00) or micro switches (P/N: 00411.00) can be replaced independently if that is the only component that has failed.
MODEL L-1X & L-1X16 PARTS MANUAL Rev. 1.14 Page 12
Maintenance
PROBLEM LIKELY CAUSE SOLUTION
Low heat during operation
Low spray arm water flow Limed up spray arm nozzles De-lime spray arm nozzles With power on, activating
start switch does not begin cycle
Start switch requires more than 1-second activation to run cycle
Activating fill switch does not fill machine
Fill water won’t shut off
Activating drain switch does not drain machine
Detergent pump does not run
Sani pump does not run
*The timer assembly motor (P/N: 00501.00) or micro switches (P/N: 00411.00) can be replaced independently if that is the only component that has failed.
Low incoming water temperature
(below 140° F)
Turn up supply water heater
Insulate supply water pipe Thermostat out of adjustment Adjust thermostat (Optional) sustainer heater not
installed
Install (optional) sustainer
heater
P/N: 04109.10
Defective sustainer heater Replace heater
P/N: 04109.10
Defective fill/start switch (cycle light will not light either)
Defective timer assembly (Cam 1)
Defective (Instant Start) ice cube relay
Replace fill/start switch
P/N: 03470.01
Replace timer assembly*
P/N: 00408.80
Replace ice cube relay
P/N: 00631.00
Defective fill/start switch Replace fill/start switch
P/N: 03470.01
Defective water solenoid valve Replace water solenoid valve
P/N: 03603.10
Defective water solenoid valve Replace water solenoid valve
P/N: 03603.10
Defective fill/start switch Replace fill/start switch
P/N: 03470.01
Defective timer assembly (Cam 4)
Replace timer assembly*
P/N: 00408.80
Drain hose is kinked Un-kink drain hose Defective drain switch Replace drain switch
P/N: 03406.64
Defective drain valve motor (Pump will still run)
Replace drain valve motor
P/N: 04103.21
Defective detergent pump motor Replace pump motor
P/N: 00416.00
Defective timer assembly (Cam 2)
Replace timer assembly*
P/N: 00408.80
Defective sani pump motor Replace pump motor
P/N: 00416.00
Defective timer assembly (Cam 5)
Replace timer assembly*
P/N: 00408.80
MODEL L-1X & L-1X16 PARTS MANUAL Rev. 1.14 Page 13
Maintenance
PROBLEM LIKELY CAUSE SOLUTION
Rinse pump does not run
Activating detergent primer switch does not run pump
Activating sani primer switch does not run pump
Activating rinse primer switch does not run pump
Counter does not increment
Running light does not light while cycle runs
Power light does not light but machine runs
Wash tank temperature gauge displays wrong temperature
Delime switch does not activate pump motor
Defective rinse pump motor Replace pump motor
P/N: 00416.00
Defective timer assembly (Cam 6) Defective sani/detergent primer
switch
Replace timer assembly*
P/N: 00408.80
Replace primer switch
P/N: 03470.00
Defective detergent pump motor Replace pump motor
P/N: 00416.00
Defective sani/detergent primer switch
Replace primer switch
P/N: 03470.00
Defective sani pump motor Replace pump motor
P/N: 00416.00
Defective rinse primer switch Replace primer switch
P/N: 03470.00
Defective rinse pump motor Replace pump motor
P/N: 00416.00
Defective counter Replace counter
P/N: 03408.50
Defective timer assembly (Cam 3)
Replace timer assembly*
P/N: 00408.80
Defective cycle light Replace running light (green)
P/N: 00476.00
Defective power light Replace power light (red)
P/N: 00406.00
Defective temperature gauge Replace temperature gauge
P/N: 03202.00
Defective delime switch Replace delime switch
P/N: 00475.30
Defective pump motor Replace pump motor
P/N: 00201.00
*The timer assembly motor (P/N: 00501.00) or micro switches (P/N: 00411.00) can be replaced independently if that is the only component that has failed.
MODEL L-1X & L-1X16 PARTS MANUAL Rev. 1.14 Page 14
Addendum

5. Addendum for Machines Installed in the City of Chicago

“All food dispensing establishments using chlorine or other approved chemical sanitizers shall, at all times, maintain an adequate testing device.”
“Dishes and other eating and drinking utensils to be washed in a dishwashing machine shall be properly scraped and pre-rinsed and shall be stacked in racks or trays so as to avoid overcrowding, and so as to permit the wash and rinse waters to reach all surfaces of each utensil.”
“In machine washing, multi-use eating and drinking utensils shall be washed in water containing a suitable detergent at a temperature of 120° F to 140° F or other method approved by the Department of Health.”
“The water in the wash tank shall be changed during operation as often as is necessary to keep it reasonably clean. An effective concentration of detergent in the wash water shall be maintained at all times.”
“Bactericidal treatment shall consist of exposure of all surfaces of dishes an d utensils bein g washed to a rinse of clean water, at a temperature of not less than 180° F or other method approved by the Department of Health.”
“All dishwashing machines shall maintain a flow pressure not less than 15 or more than 25 pounds per square inch on the fresh water line at the machine and not less than 10 pounds per square inch at the rinse nozzles. A suitable gauge cock shall be provided immediately upstream from the final rinse sprays to permit checking the flow of the final rinse water. An easily readable thermometer accurate to a dishwashing machine which will indicate the temperature of the water solution there in.”
“Dishwashing machines shall be thoroughly cleaned at least once each day. The pumps and the wash and rinse sprays or jets shall be so designed that a forceful stream of water will reach all surfaces of the utensils when they are properly racked. These parts shall be thoroughly cleaned at least once each day. The pumps and the wash and rinse sprays or jets shall be designed that a forceful stream of water will reach all surfaces of the utensils when they are properly racked. These pars shall be readily accessible for inspection and cleaning.
“After bactericidal treatment, utensils and containers shall be stored at a sufficient height above the floor in a clean, dry place, protected from flies, splash, dust, overhead leakage and condensation, and other contamination. Containers and utensils shall be inverted, covered, or otherwise protected from contamination until used for serving.”
Drain racks, trays and shelves shall be made of non-corrodible material and shall be kept clean. In handling containers and utensils the surfaces thereof which come in contact with food or drink shall not be touched by the hands, except during the process of washing. Tables for clean and dirty dishes and food shall be so arranged that the dirty dishes will be as far removed from the food and clean dishes as may be possible.
All single service articles and utensils shall be purchased in sanitary cartons and stored in a clean, dry place until used, and after removal from the cartons, these articles shall be handled in such a manner as to prevent contamination.
Please note the following procedures must be followed for City of Chicago Approval:
1. All low energy models must have low level sani-alarms, both visual and audio.
2. All models must have a City of Chicago approval data label affixed to the machine.
3. Chlorine sanitizer must be a minimum of 100 PPM.
+2° F. shall be provided on both the wash and rinse water lines of the
MODEL L-1X & L-1X16 PARTS MANUAL Rev. 1.14 Page 15

Appendix A: Operator & Cleaning Instructions

MODEL L-1X & L-1X16 INSTALLATION & OPERATION MANUAL Rev. 1.14 Page16
ELECTRICAL DIAGRAM

6. Electrical Diagram

MODEL L-1X & L-1X16 INSTALLATION & OPERATION MANUAL Rev. 1.14 Page17
Loading...
