ClearCube CD7600 User Manual

USB Ports
(One or Two)
Power Button
and Indicator
Front
Smart Card Reader
Activity Indicator
PCoIP Session
Indicator
HD
Audio InHDAudio Out
Smart Card
Reader
(On Supporting Models Only)
DVI Connectors
(Two or Four)
USB Ports
Ethernet
Connector
(RJ45 or SFP)
Power Jack
MAC Address
and Serial Number
Rear
HD Audio Out
Kensington® Security Slot
(on Top and
on Bottom)
Cloud Desktop with Monitors
and Peripherals
Network Infrastructure
Chassis with
Blades and VMs
Copper and Fiber Ethernet
(Network Media Varies by Model)
CD9600-Series, CD7600-Series (Tera2)
Cloud Desktop Quick Start Guide

Package Contents CD9600-series, CD7600-series (Tera2)

Cloud Desktop Overview
• CD9600-series or CD7600-series (Tera2) Cloud Desktop
• Power adapter and cable
• Y-cable adapter for single-link-to-dual-link DVI (× 1 for dual-monitor and × 2 for quad-monitor Cloud Desktops)
•This Quick Start Guide
(NOTE: the terms Cloud Desktop and zero client are used interchangeably in this document.)
A Cloud Desktop, or zero client, is a remote computing device that connects a user’s monitors, keyboard, mouse, speakers, and other peripherals to remote ClearCube PC blades (computers) and to virtual desktops (VMs). As shown below, computing resources are typically located in remote data centers. Cloud Desktops enable users to work on a blade or VM as if it is a local PC. The connection between the zero client and the remote device is over PCoIP™ protocol. Inside the remote device, a host card manages the PCoIP session.
ClearCube Technology, Inc. 3700 W Parmer Lane Austin, Texas 78727 (512) 652-3500 www.clearcube.com
Cloud Desktop connected to blade or to VM

Cloud Desktop Features

ClearCube® CD9600-series and CD7600-series zero clients connect to supported ClearCube PC blades containing Tera1 or Tera2 host cards and to virtual machines to provide:
• Up to four USB ports (depending on model)
• Support for copper or fiber Ethernet media (depending on model)
Page 2 of 4
• Support for independently-configurable monitors
Dual-Monitor Cloud Desktop Quad-Monitor Cloud Desktop
2 DVI monitors up to
1920 × 1200
1 DVI monitor up to
2560 × 1600
(requires single-link-DVI-to-dual-
link-DVI Y-cable adapter, included)
4 DVI monitors up to
1920 × 1200
2 DVI monitors up to
2560 × 1600
(requires single-link-DVI-to-dual-
link-DVI Y-cable adapter, included)
• PC–over–IP (PCoIP™) Tera2 processors, delivering PC video, audio, and USB over an IP network
• Integrated smart card reader (on supporting models)
• HD audio in and out (front) and HD audio out (rear)

Client and Host Firmware Compatibility

ClearCube recommends using the same Teradici™ firmware version on PCoIP devices whenever possible.
• CD9600-series and CD7600-series zero clients include Tera2 processors, requiring Teradici firmware 4.0.3 and higher.
• If Tera1 devices (that is, any models other than CD9600­series and CD7600-series) in a deployment connect to Tera2 devices, the Tera1 devices must use Teradici firmware version 4.0.2.
Green (blinking): PCoIP session is sleeping. Press
any key on the keyboard to wake the session.
Orange: device is in low-power state and
wake-on-LAN (WoL) or wake-on-USB (WoUSB) is enabled. ClearCube Sentral or third-party utilities can provide WoL and WoUSB features for devices.
• Power Button Operations
Power on: when orange, press briefly (turns green)
Power off: press and hold for 3 seconds (turns
orange)
While in session:
when connected to a PCoIP host card, press to display the Zero Client Control Panel (on monitor) with options to disconnect or power down host device. Press the power button repeatedly to scroll through options or to cancel.
when connected to a VM, press to disconnect.
PCoIP Session Indicator—shows when a connection, or session, is established between the zero client and a host. The link indicator displays one of the following:
Green—a session is established between the client
and a host.
• Dual-monitor CD9600-series and CD7600-series zero – Off—there is no session between the client and a host.
clients do not support connection to Tera1 quad devices.
• Smart Card Reader (on supporting models only)
See PC-over-IP System User’s Guide and PCoIP Firmware Support and Compatibility Guide on the ClearCube Support
Yellow-Green—smart card reader is powered on.
site for instructions about identifying and updating PCoIP device firmware.
Red—smart card has been reset. When red light is
flashing, the IC Card is reading or writing.

Buttons and Indicators

Mandatory Setup and Cooling Requirements

The list below shows indicators and front panel button operations:
• Power Button Colors
– Green (solid): device is powered on.
ClearCube Technology, Inc. 3700 W Parmer Lane Austin, Texas 78727 (512) 652-3500 www.clearcube.com
• Ensure at least 4 inches of space around all zero client edges and at least 2 inches of space above the client.
• Ambient operating temperature: 0° to 35° C (32° to 95° F).
G0200156 Rev A, 1.0.01.23.2013
