ORBITAL SANDER

MODEL NO: CON320

PART NO: 6462056

OPERATION & MAINTENANCE

INSTRUCTIONS

ORIGINAL INSTRUCTIONS GC0522 - Rev 1

INTRODUCTION

Thank you for purchasing this CLARKE Orbital Sander, which is designed for
both DIY and trade use.

Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.

SPECIFICATIONS

Dimensions (L x W x H) 290 mm x 118 mm x 175 mm

Weight 2.2 kg

Rated Voltage 230V~50Hz

Power Input 320 W

Sound Pressure Level LpA 76 dB(A), Uncertainty Factor (K) 3 dB(A)

Sound Power Level LWA 87 dB(A), Uncertainty Factor (K) 3 dB(A)

Vibration

Duty Cycle S1 (continuous)

Running speeds 1- 6000 rpm

Sanding Sheet size 115 x 230 mm

4.474 m/s

2- 7000 rpm
3 - 8000 rpm
4 - 9000 rpm
5 -10500 rpm
6 -12000 rpm

2

Uncertainty Factor (K) 1.5 m/s2

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.

Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission. This guarantee does not effect your
statutory rights.

2

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

POWER TOOL SAFETY WARNINGS

WORK AREA

1. Keep the work area clean and well lit. Cluttered and dark areas invite
accidents.

2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids or gases. Power tools create sparks which
may ignite the dust or fumes.

3. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.

ELECTRICAL SAFETY

1. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use adaptor plugs with earthed (grounded) power tools. Unmodified

plugs and matching outlets will reduce the risk of electric shock.

2. Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.

3. Do not abuse the cable. Never use it for carrying, pulling or unplugging the
power tool. Keep the cable away from heat, oil, sharp edges or moving
parts. Damaged or entangled cables increase the risk of electric shock.

4. When operating a power tool outdoors, use an extension cable suitable for
outdoor use. Use of a cable suitable for outdoor use reduces the risk of
electric shock

5. If operating the power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply.

PERSONAL SAFETY

1. Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in personal injury.

2. Use safety equipment. Always wear eye protection. Safety equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.

3. Avoid accidental starting. Ensure the switch is in the off position before
plugging in. Carrying power tools with your finger on the switch or plugging
in power tools that have the switch on invites accidents.

4. Remove any wrench before turning the power tool on. A wrench left
attached to a rotating part may result in personal injury.

3

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

5. Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.

6. Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.

POWER TOOL USE AND CARE

1. Do not force the power tool. Use the correct accessories for your
application. The correct power tool will do the job better and safer at the
rate which it was designed for.

2. Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.

3. Disconnect the plug from the power source before changing accessories,
or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.

4. Store idle tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate it. Power tools
are dangerous in the hands of untrained users.

5. Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power
tool’s operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.

6. Use the power tool and accessories in accordance with these instructions

and in the manner intended, taking into account the working conditions
and the work to be performed. Use of the power tool for operations

different from intended could result in a hazardous situation.

7. The performance of this tool may vary, depending upon variations in line
voltage. Extension cable usage may also affect performance.

SERVICE

1. Have your power tool serviced by qualified service personnel using only
identical replacement parts. This will ensure that the safety of the power

tool is maintained.

ADDITIONAL SAFETY WARNINGS FOR SANDERS

1. Secure the workpiece to a stable platform. Holding the work by hand or
against your body may lead to loss of control.

2. Dust arising from sanding may endanger the health of the operator and
possible bystanders. Wear a dust mask and ensure that persons entering
the work area are also protected.

3. Remove all dust after sanding.

4

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

4. Take care when sanding lead based paint or when sanding wood or metal
which may produce toxic dust, - do not let children or pregnant women
enter the work area.

VIBRATION

The declared vibration emission values stated in the specifications have been
measured in accordance with a standard test method provided by EN 60745
and may be used for comparing one tool with another. The declared vibration
emission value may also be used in a preliminary assessment of exposure.

WARNING: THE VIBRATION EMISSION VALUE DURING ACTUAL USE OF THE
POWER TOOL CAN DIFFER FROM THE DECLARED VALUE DEPENDING ON
THE WAYS IN WHICH THE TOOL IS USED. THE VIBRATION LEVEL MAY
INCREASE ABOVE THE LEVEL STATED.

EXPLANATION OF SYMBOLS & PICTOGRAMS

Read instruction man­ual before use

Wear ear protection
when using this tool

Wear safety glasses or
goggles when using this
tool

Wear a dust mask when
using this tool.

ENVIRONMENTAL RECYCLING POLICY

Through purchase of this product, the customer is taking on the
obligation to deal with the WEEE in accordance with the WEEE
regulations in relation to the treatment, recycling & recovery and
environmentally sound disposal of the WEEE.

In effect, this means that this product must not be disposed of with general
household waste. It must be disposed of according to the laws governing
Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal
facility.

Recycle unwanted materials instead of disposing of them as waste. All
unwanted accessories and packaging should be sorted and taken to a
recycling centre for disposal in a manner which is compatible with the
environment.

5

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

ELECTRICAL CONNECTIONS

Plug must be BS1363/A approved.

Always fit a 5 Amp fuse.

Ensure that the outer sheath of the cable is firmly held by the clamp

Neutral

(Blue)

Live

(Brown)

WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS
THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS
SUPPLY.

Before switching the product on, make sure that the voltage of your electricity
supply is the same as that indicated on the rating plate. This product is
designed to operate on 230VAC 50Hz. Connecting it to any other power
source may cause damage

This product may be fitted with a non-rewireable plug. If it is necessary to
change the fuse in the plug, the fuse cover must be refitted. If the fuse cover
becomes lost or damaged, the plug must not be used until a suitable
replacement is obtained.

If the plug has to be changed because it is not suitable for your socket, or due
to damage, it should be cut off and a replacement fitted, following the wiring
instructions shown below. The old plug must be disposed of safely, as insertion
into a mains socket could cause an electrical hazard

WARNING: THE WIRES IN THE POWER CABLE OF THIS PRODUCT ARE
COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
BLUE = NEUTRAL BROWN = LIVE

If the colours of the wires in the power cable of this product do not correspond
with the markings on the terminals of your plug, proceed as follows.

•The Blue wire must be connected to the terminal which is marked N.

•The Brown wire must be connected to the terminal which is marked L

.

.

We strongly recommend that this machine is connected to the mains supply
via a Residual Current Device (RCD)

This symbol indicates that this is a Class II product, and does not require
an earth connection.

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

6

BEFORE USE

The sander is supplied with the following items:

• Dust extract filter

• 4 x P60 Sanding sheets

• 3 x 120 Sanding sheets

• 3 x 240 Sanding sheets

DUST EXTRACTION

WARNING: HARMFUL OR TOXIC DUST MAY BE PRODUCED WHEN
SANDING LEAD PAINTED SURFACES, WOODS OR METAL. CONTACT WITH,
OR INHALATION OF THESE DUSTS CAN ENDANGER THE HEALTH OF THE
OPERATOR OR BYSTANDERS. CERTAIN DUSTS LIKE OAK AND BEECH ARE
CONSIDERED TO BE CANCEROUS IN CONJUNCTION WITH ADDITIVES IN
WOOD TREATMENTS (CHROMATE, WOOD PRESERVATIVES). ASBESTOS­CONTAINING MATERIALS MAY ONLY BE HANDLED BY EXPERTS.

WARNING: - USE A DUST EXTRACTION DEVICE OR A VACUUM CLEANER.

WARNING: - WORK IN A WELL VENTILATED ROOM. - THE USE OF A DUST
MASK FILTER CLASS P2 IS RECOMMENDED. - OBSERVE LOCAL
REGULATIONS REGARDING THE HANDLING OF CERTAIN MATERIALS.

FITTING THE DUST EXTRACTION FILTER

1. Attach the dust extractor filter by
pushing the filter onto the rear of
the sander as far as it will go and
then twisting clockwise until it
locks into place.

• The filter housing has lugs to

align and secure it. Note their
position matches those on the
sander body before assembly.

NOTE: The user should still wear a

face mask to prevent the inhalation of dust particles.

NOTE: Due to the nature of the tool, some of the dust produced will be forced

into the surrounding atmosphere and will not be collected.

7

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

OPERATION

FITTING THE SANDING SHEET

1. With the sander disconnected from the power supply, select the sanding
sheet appropriate for the task and attach it to the base plate as follows.
Either plain sanding sheets or prepared sheets for hook and loop
attachment can be used.

PLAIN SANDING SHEETS

1. Lift the paper retaining clips to the
open position and insert one end
of the sanding sheet under the
retaining clip. Set the clip back in
the retaining position to hold the
sheet and lightly stretch it over the
baseplate, ensuring it is not folded
or wrinkled, then position it under
the other retaining clip. Lock the
second clip back into the
retaining position.

2. Check the sheet lays straight and
flat on the baseplate. If not,
release either clip and adjust the
sheet before resetting the clip.

HOOK AND LOOP SANDING SHEETS

1. Align the sanding sheet so that
the holes are aligned with those in
the base plate (this is necessary
for dust extraction), press the
sheet evenly onto the base plate
to attach it.

REPLACEMENT SHEETS

The following sanding sheets are available from your CLARKE dealer.

Grit Size (mm) Part No

60 115 x 230 mm 6502072

80 115 x 230 mm 6502073

120 115 x 230 mm 6502074

8

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

STARTING & STOPPING THE SANDER

1. Ensure the sander is switched OFF
before plugging into the power
supply.

2. Switch the machine ON or OFF by
pressing the rocker switch.

3. Lock the switch in the ON position
if required by pressing in the
trigger lock button on the side of
the handle.

OPERATING TECHNIQUE

1. Select the operating speed
appropriate to the job in hand.
The speed required will be
dependant on the material and
will be determined by a practical
trial. Speeds are stated in the
specification.

2. Also select the abrasive grade
appropriate to the task.

3. Always hold the sander securely.

4. Regularly check the condition of the sanding sheet and replace it when
necessary.

5. On very uneven surfaces or when removing layers of paint, start with a
coarse grit. On other surfaces, start with a medium grit. In both cases,
gradually change to a fine grit for a smooth final finish.

6. Always use a sanding sheet that is in top condition, damaged backing will
cause damage to the base plate surface. Please note that base plates are
NOT covered by the warranty.

7. Always place the sander on the workpiece before switching ON. This will
prevent the workpiece from being scored by the edge of a moving
sanding sheet.

8. Move the sander evenly over the surface of the workpiece with light
pressure. This helps to expel dust particles and produce an even finish and
will also prolong the life of the sanding sheet.

9. Let the sander do the work ensuring the sander is flat on the work surface.
DO NOT apply heavy pressure as this will not only produce an uneven finish
but will overload the motor causing it to burn out.

10. Wait until the sander has stopped completely before putting it down.

9

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

MAINTENANCE

WARNING: BEFORE PERFORMING ANY MAINTENANCE, SWITCH OFF AND
UNPLUG THE SANDER.

Your sander will operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon proper care.

Regularly clean the motor ventilation slots using a soft dry brush or dry cloth to
remove dust. Do not use any abrasive or solvent-based cleaner.

A damaged power cable should be replaced by your CLARKE dealer or
qualified electrician.

There are no user-serviceable parts in this sander. The bearings in this sander
are sealed for life and require no maintenance.

FAULTFINDING

SANDER IS OVERHEATING

This indicates the machine is dirty. Clean the ventilation holes, and blow out
with compressed air. Always wear eye protection when using compressed air.

Overloading the machine will also cause overheating. Do not use for heavy
duty work, and do not apply excessive pressure.

EXCESSIVE SPARKING OCCURS

This indicates worn brushes. This problem is quickly remedied but you should
consult your CLARKE dealer for parts and advice.

SANDER DOES NOT OPERATE WHEN SWITCHED ON

Check to ensure the fuse is sound and replace if necessary. If the fuse is sound
or blows repeatedly, consult your CLARKE dealer.

POOR ABRASION

If the sander is not removing material efficiently, check the sanding sheet. If
the abrasive is worn down replace the sheet. The paper must always be stored
in a dry place as if it allowed to become damp, the abrasive particles will
detach from the sheet and will not abrade.

10

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

DECLARATIONS OF CONFORMITY

11

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
