Owner’s Manual
VB475
lish
En
1 DIN DVD/CD/AMFM RECEIVER
VB475 1
English
Thank you for purchasing this Clarion product.
• Please read this owner’s manual in its entirety before operating this equipment.
• After reading this manual, keep it handy, such as in your glove compartment.
• Save your sales receipt. The warranty at the end of this manual and your sales
receipt are essential for warranty service.
FCC Approval
The Clarion VB475 has been tested and found to comply within the limits of a Class B digital device, pursuant of Part 15 of the FCC rules. These limitations are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and uses radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
There is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to a radio or television reception, turn off the equipment and contact a local Clarion Dealer for assistance. Changes or modifi cations to this product not approved by the manufacturer will void the warranty and violate FCC Approval.
Contents
FCC Approval .......................................................................................................... 2
1. FEATURES .............................................................................................................. 4
Features .................................................................................................................. 4
2. PRECAUTIONS ....................................................................................................... 4
3. CONTROLS ............................................................................................................. 6
Player with the front panel closed ........................................................................... 6
Player with the front panel open .............................................................................. 8
Remote control ........................................................................................................ 8
4. BASIC OPERATIONS ........................................................................................... 10
Turning the player on ............................................................................................. 10
Selecting the input source ..................................................................................... 10
Controlling audio ................................................................................................... 10
Turning the player off ............................................................................................. 11
Setting the time ..................................................................................................... 12
Protecting the player from theft ............................................................................. 12
Care and maintenance .......................................................................................... 13
Changing the battery in the remote control ........................................................... 14
2 VB475
g
5. DVD/CD/MP3 OPERATIONS ............................................................................... 15
Regions ................................................................................................................. 15
About DVDs ........................................................................................................... 16
About video CDs, VCDs and MP3 fi les ................................................................. 16
Loading discs (DVDs and CDs) ............................................................................. 17
DVD playback features .......................................................................................... 19
CD playback features ............................................................................................ 21
Viewing the contents of the disc ............................................................................ 21
Repeating chapters and tracks .............................................................................. 22
Ejecting a DVD or CD ............................................................................................ 23
Playing back MP3 audio fi les ................................................................................ 23
Setting parental controls ....................................................................................... 23
6. RADIO OPERATIONS .......................................................................................... 25
Searching automatically for a station .................................................................... 25
Searching manually for a station ........................................................................... 26
Presetting frequencies .......................................................................................... 26
Scanning stored stations ....................................................................................... 26
7. AUX-IN OPERATIONS .......................................................................................... 26
Selecting the AUX-IN input source ........................................................................ 26
AUX-IN Playback features ..................................................................................... 26
8. INSTALLATION AND WIRING .............................................................................. 27
Precautions ........................................................................................................... 27
Requirements ........................................................................................................ 27
Options .................................................................................................................. 28
Accessories and hardware .................................................................................... 28
Installing the player ............................................................................................... 28
Cable connections ................................................................................................. 30
Connecting the speakers....................................................................................... 32
Outlet power amplifi er connection ......................................................................... 33
Fuse ...................................................................................................................... 34
9. DVD PREFERENCES ........................................................................................... 34
Language options .................................................................................................. 35
Video options ........................................................................................................ 35
Rating options ....................................................................................................... 36
10. TROUBLESHOOTING ......................................................................................... 38
Restoring factory defaults...................................................................................... 38
11. GLOSSARY ......................................................................................................... 39
12. SPECIFICATIONS ............................................................................................... 40
lish
En
VB475 3
English
1. FEATURES
Features
• Removable front panel with protective case for theft prevention.
• Dolby 4.2 channel sound effects (manufactured under license from Dolby Laboratories. “Dolby” and the double­D symbol are trademarks of Dolby Laboratories.)
• Types of supported discs: DVD-5, DVD-9, DVD-10, DVD-18, SVCD, DVCD, VCD, CD, MP3, MPEG4, etc.
• TV standards supported: NTSC, PAL or Auto
• Image aspect ratio: 4:3 or 16:9
• Audio output: 4.2CH
• Audio input: Stereo
• Disc playback functions: multiple angles, multiple dubbed languages, fast forward,
fast backward, broken point auto memory
• AM/FM radio capabilities: stores 18 FM and 12 AM broadcasting stations; tunes automatically and manually
from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Manufactured under license
2. PRECAUTIONS
Disc handling
• To keep a disc clean, do not touch the play side (non-label side).
• Do not scratch or bend discs.
• Do not attach sticky notes to or put tape on a disc.
• Do not attempt to play back a deformed disc.
• Keep discs away from direct sunlight and heat, such as dashboards and vehicle
heaters; and from dirty, dusty and damp areas, such as vehicle seats.
• Store discs in a protective disc case.
• Before playback, wipe the disc outwards from the center with a clean cloth.
Operating
• Do not operate this product in ways other than those described in this manual. Failure to follow instructions may void the warranty.
• Do not make selections through the front panel or the remote while operating the
4 VB475
g
vehicle. You may cause an accident. Find a place to pull over and stop before you confi gure the player.
• Keep the volume lower than you might if listening at home to ensure safe driving.
• Do not use the player with the ignition off, which could drain the vehicle’s battery.
• Parking in direct sunlight for several hours raises the temperature in the vehicle.
If the internal temperature is extremely high (over 50 degrees Celsius), start the vehicle and let the interior cool down before you use the player.
• Before leaving the vehicle, eject the DVD disc and store it separately, away from
direct sunlight. Heat and humidity can damage DVD discs causing them not to play.
• Do not operate the player using a voltage higher than DC 12V.
General
• Do not pour liquid into the player or poke foreign objects, such as coins, into the
DVD drive slot. Water, humidity, and foreign objects may damage internal circuitry.
• Do not place screwdrivers or other metal objects near the player or disc.
• If the player becomes wet, turn off all power and ask your authorized Clarion Dealer
to clean or service the unit.
• Do not drop the player. You may cause permanent damage.
• If the vehicle’s battery dies or you disconnect the player from battery power, the
contents of the player’s memory will be lost and all options will return to their factory defaults.
• The player uses a Class 1 Laser and will emit a visible or invisible hazardous laser
beam. Avoid looking directly at this beam.
lish
En
Installation
Installation of mobile audio and video components requires experience with a variety of mechanical and electrical procedures. Although this manual provides general installation and operation instructions, it does not show the exact installation methods for your particular vehicle.
If you do not have the required knowledge, experience, and/or tools to successfully complete the installation, consult an authorized Clarion Dealer about professional
installation options.
• Video playback requires the installation of a separate monitor, such as Clarion’s
OHM series monitors. The monitor must support both NTSC and PAL TV standards.
• Do not install a video monitor where the driver can be distracted by it. Such
placement may cause a traffi c accident and violate local regulations.
• The vehicle must have a 12V battery with negative grounding. Before installing it in
a recreational vehicle, truck or bus, check the battery voltage.
• For optimal performance and operation, mount the player horizontally. Avoid
mounting the player in a tilted position in excess of 15 degrees.
VB475 5
English
Maintenance
• When washing the vehicle, keep the player dry, including the speaker and any discs.
• Do not disassemble or modify this player. You may damage the player, void the
warranty, and suffer electric shock. All warranty service should be performed by an authorized Clarion service center.
3. CONTROLS
Player with the front panel closed
Audio knob
Open
DISP
(Display)
Forward and reverse
1/DN (down)
Quick reference to controls
1/DN (down) button
2/UP button
3/ZOOM button
4/SCN (scan) button
LCD screen
2/UP
3/ZOOM
4/SCN (scan)
In radio mode, press to select the preset button 1. The station frequency displays on the LCD. Press and hold to store a radio frequency at button 1. In MP3 mode, press to page down a list of MP3 fi les.
In radio mode, press to select the preset button 2. The station frequency displays on the LCD. Press and hold to store a radio frequency at button 2. In MP3 mode, press to page up a list of MP3 fi les.
In radio mode, press to select the preset button 3. The station frequency displays on the LCD. Press and hold to store a radio frequency at button 3. In DVD mode, press to zoom in.
In radio mode, press to select the preset button 4. The station frequency displays on the LCD. Press and hold to store a radio frequency at button 4. In DVD, CD or MP3 modes, press to fast forward playback.
5/RDM (random)
Arrows
Power/mute
BAND SRC (source)
Play/Pause
6/RPT (repeat)
6 VB475
g
5/RDM (random) button
6/RPT (repeat) button
BAND button (B)
Arrow buttons
Display button (D)
Forward (
Play/pause button ( )
Power/mute button (
SRC (source) button (
) and reverse
( ) buttons
LCD screen
Open button
Audio knob
In radio mode, press to select the preset button 5. The station frequency displays on the LCD. Press and hold to store a radio frequency at button 5. In DVD, CD or MP3 modes, press to play back chapters, tracks or fi les randomly.
In radio mode, press to select the preset button 6 The station frequency displays on the LCD. Press and hold to store a radio frequency at button 6. In DVD, CD or MP3 modes, press to alternate among repeat options.
In radio mode, press to select among three FM and two AM bands. Press and hold, then press the Forward (
and reverse ( ) buttons to enter manual station search.
Press to make selections during playback setup.
Press to display the clock. Press and hold to access system setup.
Press and hold to fast forward and reverse through chapters, tracks, fi les or frequencies.
Press once to skip to the next or previous chapter, track, fi le or frequency.
Press repeatedly to move forward or back at the following speeds. Each time you press the speed changes:
>
1x > 2x > 4x > 8x > 20x > normal playback
The small Liquid Crystal Display (LCD) used to display the time, radio frequency, disc, and MP3 information.
Press to open the front panel.
In DVD, CD or MP3 modes, press this button to play or pause the disc.
)
In standby, press to turn the power on. When the power is on, press to mute the volume. Press and hold for two seconds to turn the power off.
)
Press to alternate among input sources: Radio, DVD. etc.
Rotate to the right to increase the volume and to the left to decrease the volume.
<
lish
En
)
>
VB475 7
English
Player with the front panel open
DVD/CD slot
Front panel open
Remote control
Eject button
Display
Menu
Arrows Stop/Band
Play/pause
Volume decrease
Title
Scan
Audio
Subtitle
Folder down
Folder up
Source
Mute
Power
Return Setup
Next Volume increase
Previous
Fast forward
Fast reverse
Slow Go to
Repeat Random
Zoom Angle
PAL/NTSC Clear
Quick reference to controls
8 VB475
g
Angle
Arrows
Audio
Clear
Display (DISP)
Fast forward (
Fast reverse (
Folder (DOWN and
Go to
Menu
Mute
Next (
PAL/NTSC (P/N)
Play/pause (
Power (
Previous (
Random (RDM)
Repeat (RPT)
Return
Scan (SCN)
Setup
Slow
Source (SRC)
Stop/Band (
BAND)
Subtitle
Changes the scene angle while playing back a DVD that includes multiple scene angles.
Selects options on the DVD menu and values on On­Screen Display (OSD) menus.
DVD: Changes the language during playback. VCD/CD: Changes audio channel (left, right, stereo).
DVD: Erases incorrect input. Works in DVD mode only.
Displays playback information.
)
Speeds playback forward at 2x, 4x, 8x, 16x and 32x speeds.
)
Fast reverses playback at 2x, 4x, 8x, 16x and 32x speeds.
Selects the folder when using the OSD menus.
UP)
Starts playback at the selected chapter, track or time.
DVD: Displays the main menu. VCD: Turns playback control (PBC) on and off.
Disables and enables sound.
)
Skips to the next chapter (DVD) or the next track (CD).
Selects the video format in which the disc was recorded. NTSC is used in the United States. PAL is used in Europe and elsewhere. Check the disc packaging to determine which you need.
)
In DVD, CD or MP3 modes, starts and pauses the disc.
)
Turns the player on and off.
)
Skips to the previous chapter (DVD) or track (CD).
Plays back chapters or tracks in random order.
In DVD, CD or MP3 modes, alternates among repeat options.
In VCD mode with playback control (PBC) on, goes to the beginning of the current track. Works only in VCD mode.
In DVD/VCD modes, plays back 10 seconds of every track.
Accesses the setup menu used to modify player options.
In DVD mode, plays back in slow motion.
Alternates among input sources: Radio, DVD, etc.
In radio mode, selects among three FM and two AM bands.
In DVD, CD and MP3 modes, stops play back.
Turns pre-recorded subtitles on and off.
lish
En
VB475 9
English
Volume down (VOL-)
Volume up (VOL+)
Title
Zoom
Displays the DVD’s title menu.
Lowers the volume.
Raises the volume.
Zooms in when viewing a movie or photograph. As you press ZOOM, the player alternates among the available zoom settings:
DVD :
VCD: off > 1x > 2x > 3x
>
off > 1x > 2x > 3x > 4x
>
<
>
<
>
4. BASIC OPERATIONS
Turning the player on
To turn on the power, press the power button ( ) on the player or on the remote.
Power button
Locating the power button on both the player and the remote control
The player briefl y displays, “Welcome!” and turns the radio on by default.
Selecting the input source
With the power turned on (either by pressing the power button or loading a disc), select the input source by pressing SRC (source) on the player or SRC ( ) to alternate among:
<
>
Radio > DVD > AUX-IN
AUX-IN is an auxiliary input device, such as a portable audio device.
NOTE
If a DVD or CD is playing, you eject the disc, and then insert it again, the player begins play back from the beginning of the disc.
>
Controlling audio
The audio knob on the player controls not only the volume but also the bass, treble, balance and fader.
10 VB475
g
Confi guring audio options
1. Press the AUDIO button to select audio mode.
The audio button works to adjust the volume.
2. Press the same button again and again to alternate among all audio options:
>
Volume > Bass > Treble > Balance >
Fader > Loud > Sound effect
3. Stop on the attribute you want to control.
Option Knob direction Description Volume
Bass and treble
Balance
Fader
Loud
Sound effect control
Left Reduces volume.
Right Increases volume.
Left Reduces bass or treble.
Right Boosts bass or treble.
Left to right Adjusts the volume proportion from the left
Left to right Adjusts the volume proportion from the
Left Turns off Loud.
Right Turns on Loud, giving an extra volume
Left to right Selects one of the following sound effects,
<
>
to the right.
front to the rear.
boost. When on, turning the volume knob to the right increases the volume more quickly than it would otherwise.
which you can set based on the type of music you listen to:
<
NORMAL > POP > FLAT >
>
CLASSIC > JAZZ > ROCK
lish
En
>
NOTE
After fi ve seconds of inactivity, the player exits audio setup mode.
Muting the sound
To mute sound, briefl y press Power/mute ( mute again.
). To enable sound, briefl y press Power/
Turning the player off
When you’re fi nished, either press the power button on the remote or press and hold the power button on the player for two seconds.
VB475 11
English
The player briefl y displays, “Bye Bye!” and enters its “standby” state. The player never turns off completely. If the clock display is enabled (the default), the player displays the current time prefaced by “AM” or “PM.”
Setting the time
In standby, you can set the time on the clock.
1. If the player is on, press the power button (
2. Press and hold the D button on the player.
The system displays the current time setting.
3. To switch between setting the hours and minutes, press the button again.
3. Press the next button (
4. Press the previous button (
NOTE
After fi ve seconds of inactivity, the player exits time setup mode.
)to increase the hours or minutes.
) to decrease the hours or minutes.
) to turn it off (go into standby mode).
Protecting the player from theft
To discourage theft, detach the front panel, store it in the protective case provided, and take it with you.
Removing the front panel
1. Press the open button ( panel.
) in the upper left corner of the player to open the front
Open button
Left side of the player
CAUTION
Do not grip the front panel buttons or use force to remove and install the front panel.
2. Holding the right side of the front panel, push the panel to the left to release the right pivot hinge.
12 VB475
g
lish
Right pivot hinge
Direction to disconnect the front panel
3. Pull the panel out to release and remove it from the left pivot hinge.
The left pivot hinge is in the lower left Corner of the chassis
Direction to remove the front panel
CAUTION
Do not subject the front panel to excessive shocks.
Do not expose the front panel to direct sunlight or high tem­peratures.
Replacing the front panel
1. Line up the front panel with the opening on the player.
2. Pressing on both left and right edges, snap the panel into place.
En
Care and maintenance
Cleaning the player
• Use a clean, soft, dry cloth to gently wipe dust and dirt from the player.
• Do not use benzene, thinner, vehicle cleaner, or other cleaners. These substances
may damage the system or cause the paint to peel.
• The surface of the LCD screen can be easily scratched. Do not rub it with anything
abrasive.
Servicing the player
In the event that trouble arises, never open the player case, disassemble it or attempt to repair it yourself. The internal parts are not serviceable by the user. Opening any components will void the warranty. All warranty service should be performed by an authorized Clarion service center.
VB475 13
English
CAUTION!
Changes or modifi cations to this product not approved by the manufacturer will void the warranty and will violate FCC approval.
Cleaning the remote control
Use only a clean, soft, damp cloth to clean the remote control. Do not use lighter fl uid, methanol alcohol or other solvents.
Cleaning discs
Before playing a disc, wipe it outwards from the center with a clean, soft cloth.
Changing the battery in the remote control
The remote control uses one CR2025 (3V) lithium battery.
1. Slide the tray out on the back of the remote control.
Replacing the remote control battery
2. Remove the used battery.
3. Insert the charged battery with the plus (+) and minus (-) poles pointing in the direction shown.
Battery precautions
• Keep batteries out of the reach of children. If swallowed, immediately consult a doctor.
• If you won’t be using the remote control for a month or longer, remove the battery.
• Do not recharge A battery.
• Do not attempt to disassemble a battery.
• Do not handle batteries with metallic tools.
• Do not store batteries with metallic materials.
• If a battery leaks, wipe the remote control completely clean and install a new
battery.
14 VB475
g
• When disposing of used batteries, do not incinerate them. Comply with all
governmental regulations in your area.
• Always check carefully that you are loading the battery with its plus (+) and minus
(-) poles as shown in the illustration above.
5. DVD/CD/MP3 OPERATIONS
To play back DVDs, the player must be connected to a monitor, such as one of the Clarion OHM monitors.
Audio output depends on the type of disc. Carefully read the audio characteristics of the disc before playing back.
Regions
Each player and DVD is programmed for the region of the world in which it was purchased.
lish
En
Region map
The player’s region is on the bottom of the unit. DVDs must be pre-programmed with the same region as the player or they will not play back.
DVD markings
The icons on DVD packages and discs have the following meanings:
Indicates the number of audio output channels, which provide dubbed languages.
Indicates the number of languages for which subtitles are provided.
Indicates the number of viewing angles.
Indicates the picture size (aspect ratio).
,
VB475 15
Indicates the region number(s).
English
About DVDs
The contents of a DVD are organized into titles and chapters. A single work, such as a movie, corresponds to a single title. Each scene corresponds to a chapter.
Chapter structure on a DVD
On karaoke discs, each song corresponds to a title.
Some discs are organized differently. How you access the titles depends on how the disc was recorded:
Playing back some DVD-video discs may not be possible for a variety of reasons.
• With DVD-R discs, only recordings made in the video format (video mode) can be played back.
• With DVD-RW discs, recordings made in the Video Recording format (VR mode) cannot be played back.
• Even when DVD-R and DVD-RW recordings have been made using a playable format (video mode), playback may not be possible due to disc characteristics, scratches or dirt on the disc.
• Dirt and condensation on the lens inside the player may prevent playback.
• Although you may playback discs recorded using the correct format on a PC, the
recording software, environmental settings and other factors may inhibit playback.
With some DVD discs, you may not be able to use all player functions. For example, discs that feature Playback Control (PBC) provide a playback menu and do not allow the use the number buttons on the remote to directly enter chapter and track numbers.
About video CDs, VCDs and MP3 fi les
Video CDs and VCDs discs are organized into tracks with each track corresponding to one song. Some discs also feature an index to the tracks.
16 VB475
g
Track structure on a music CD or video CD
Read the precautions with all CD-R and CD-RW discs before you use them. In addition:
• CD-Extra discs can be played back as music CDs.
• Playback of CD-R and CD-RW discs, other than those recorded with a music CD
recorder, may not be possible.
• Even those CD-R and CD-RW discs recorded using a music CD recorder may not
play back due to disc characteristics or dirt on the disc.
• As with DVDs, dirt and condensation on the lens inside the player may prevent
playback.
• Titles and other text information recorded on a CD-R or CD-RW disc cannot be
displayed on the player.
• With CD-RW discs, the time to play back will be longer than the time required to
play back a conventional CD or CD-R disc.
lish
En
Loading discs (DVDs and CDs)
NOTES
To view a DVD or video CD, the player must be connected to an LCD monitor, such as one of the Clarion OHM monitors.
The player does not need to be turned on to load and unload discs.
1. To release the front panel, press the open button (
VB475 17
).
English
Open button
Left side of the front panel
2. If the slot already contains a DVD or CD, press the eject button ( disc.
DVD/CD slot
Eject button
Player with the front panel open
The player ejects the disc and automatically returns to radio mode.
NOTE
Do not insert 3-inch (8 cm) discs. The player supports only 5-inch (12 cm) discs, which have the same physical dimensions as most commercial audio CDs and computer software CD-ROMs.
3. Insert your DVD or CD.
CD and player
) to remove the
This action turns the power on and selects the DVD player as the input source.
4. Close the front panel.
The player receives the disc, automatically turns the player power on, and briefl y displays, “Loading...” and begins to play back the DVD. It takes a short time to begin playing back the DVD or video CD.
Audio output depends on the type of DVD or CD. Consult the disc jacket for more information.
5. When you’re fi nished, open the front panel and press the eject button ( the disc.
18 VB475
) to remove
g
DVD playback features
Pausing playback
• To pause, press the play/pause button (
• To resume play back, press the play/pause button (
Choosing sections or chapters
• To select a play time when using a CD or video CD, press the GOTO button on the
remote.
• To select a DVD chapter, press the number of the chapter on the remote.
• To skip to the beginning of the next chapter, press the next button (
remote.
• To skip to the beginning of the current chapter, press the previous button ( ) on the
remote.
Displaying playtime, disc type and the clock
• To display the play time, press the DISP (D) button on the player.
• To display the type of disc, press the DISP (D) button again.
• Pressing DISP (D) again displays the clock.
Zooming in and out
To zoom in, press ZOOM on either the player or the remote. Pressing this button repeatedly alternates among magnifi cation values based upon the image type:
• Video CD: 1x > 2x > 3x > off
• DVD/MPG4: 1x > 2x > 3x > 4x > off
• JPEG: 4/3x > 3/2x > 2x > 3x > 1/2x > 3/4x > off
) on the player or the remote.
) again.
) on the
lish
En
Selecting the language for subtitles
The DVD must be pre-programmed to support subtitles for this feature to work. To determine the number of languages for which subtitles are provided, look for this symbol on the DVD packaging: languages are supported.
1. Press SUBTITLE on the remote.
If the disc supports only one language for subtitles, this button does not work.
2. Use the arrows on the remote to select the language.
3. Press SUBTITLE again to select the language.
If you press nothing for three seconds, the language subtitle selection option disappears.
VB475 19
. The packaging should also indicate which
English
Selecting a dubbed language
The DVD must be pre-programmed to support additional dubbed languages (audio
channels). To determine the number of dubbed languages, look for this symbol on the DVD packaging:
1. Press AUDIO on the remote.
The player displays the list of dubbed languages from which to choose.
2. Use the arrows on the remote to select the language.
3. Press AUDIO again to select the language.
If you press nothing within three seconds, the list of dubbed languages disappears.
Playing back different camera angles
The DVD must be pre-programmed to support multiple camera angles for this feature to work. Look for this symbol on the DVD packaging:
1. Press ANGLE on the remote.
If the disc supports only one angle, this button does not work.
2. Use the arrows on the remote to select the angle.
3. Press ANGLE again to play back the angle.
If you press nothing within fi ve seconds, the list of angles disappears.
Fast forwarding and reversing
• To fast forward and reverse through chapters, tracks, fi les or frequencies, press and hold the forward ( and fast reverse ( ) buttons on the remote.
• To skip to the next or previous chapter, track, fi le or frequency, press the button once.
• To move forward or back at the following speed, press the button repeatedly. Each time you press the speed changes:
Changing the image aspect ratio
The aspect ratio is the relationship between the width and height of the image. Options are 4:3, which provides normal viewing and 16:9.
1. To enter the SETUP menu, press the SETUP button on the remote.
2. Use the right arrow to select the Video tab.
. The packaging should also indicate the languages.
.
) and reverse ( ) buttons on the player or the fast forward ( )
>
1x > 2x > 4x > 8x > 20x > normal playback
<
>
20 VB475
g
lish
En
Video tab with TV shape option set to 4:3
3. For the TV shape option, press the right or left arrows to select 4:3 or 16:9.
4. Press play/pause button (
Choosing the video format
For a disc to play back correctly, you must select the video format used to record the disc. Press the P/N button on the remote to select either PAL or NTSC.
) to confi rm your selection.
CD playback features
• To pause, press play/pause ( ) on the player or the remote.
• To resume play back, press play/pause ( ) again.
• To play back the fi rst 10 seconds of each track beginning with the current track,
press the scan button: 4/SCN on the player or SCN on the remote.
• To cancel scan mode, press the scan button again.
• To play back all tracts randomly, press the random button: 5/RDM on the player or
RDM on the remote.
• To cancel random play back, press the random button again.
• To repeat the current track press the repeat button: 6/RPT on the player or RPT on
the remote.
To play back the current disc, press the repeat button a second time.
To cancel repeat playback, press it a third time.
NOTE
Other functions work the same as for playing back a DVD.
Viewing the contents of the disc
To view the type of disc and the current track that is playing, press the DISP button on the remote.
The player displays information about the disc:
VB475 21
English
Example of the information displayed for a VCD
Example of the information displayed for a DVD
Example of the information displayed for an MPEG disc
• Use the arrow keys on the remote to move up and down in the list. Use the number keys on the remote to select a different chapter or track.
• To change to another mode, press the RETURN button on the remote.
• To clear the message on the screen, press DISP again.
Repeating chapters and tracks
To repeat the current DVD chapter, CD track or MP3 selection, press 6/RPT on the player or RPT on the remote. Playback alternates among repeat options, which vary depending on the type of disc:
• A single press of the repeat button selects DVD repeat options: Repeat Chapter > Repeat Title > Off.
• A second press of the repeat button selects SVCD, MP3, CD, and VCD repeat options: Repeat single > Repeat all > Off.
• A third press of the repeat button cancels repeat playback.
CAUTION:
If you’re playing back a video CD and playback control (PBC) is on, don’t use the repeat playback function. Follow the instruc­tions on the disc packaging.
22 VB475
g
Ejecting a DVD or CD
1. To release the front panel, press the open button ( ).
DVD/CD slot
Eject button
Player with the front panel open
2. Press the eject button (
The player ejects the disc.
3. Remove the DVD or CD.
Playing back MP3 audio fi les
• To move from folder to folder, press the FOLDER down and up buttons (DOWN and
UP on the remote or DN and UP on the player).
• To access the selected folder, press the play/pause button (
• To return to the parent folder, press the RETURN button on the remote.
• To play back the MP3 title, use the arrow keys to select the title and press the play/
pause button (
) on the remote.
Setting parental controls
).
) on the remote.
lish
En
Some DVDs let you restrict children from viewing violent or adult material. This works by setting the allowable movie rating. Assuming the DVD has been pre-programmed with a movie rating, the player plays back only discs that conform to the rating you set.
Parental control for video
1. To enter the SETUP menu, press the SETUP button on the remote.
2. Use the right arrow to select the Rating tab.
The fi rst time you set parental control, the default password is 3308.
3. Type the default password or the four-number password you set in the password
fi eld and press the play/pause button (
VB475 23
) to confi rm.
English
The Rating tab with the password selected
The lock symbol changes from closed to open when you enter the correct password.
CAUTION
Record your password and store it in a secure location. Without the correct password you will not be able to change ratings
4 To set parental control, press the down arrow and select the Rating option.
Rating menu with Kid Safe rating selected
5. Press the left and right arrows to select among the following:
1 (KID SAF)
2 (G)
3 (PG)
4 (PG 13)
5 (PGR)
6 (R)
7 (NC 17)
8 (ADULT)
6. Press the play/pause button (
24 VB475
Material is safe for children.
Material is safe for general audiences.
Parental guidance suggested.
Some material unsuitable for children under 13.
Some material unsuitable for children under 17.
Some material unsuitable for children under 17.
Not recommended viewing for children under 17.
Only for adults due to the graphic content.
) to confi rm your selection.
g
Filtering out foul language from the audio
TVG mode mutes sentences containing off-color language.
1. Press SETUP on the remote.
2. Select Rating > TVG Mode.
3. Select Tolerant for minimal foul language muting.
Select Strict for maximum foul language muting.
Example showing TVG mode off for audio, but one for closed captions
lish
En
4. Press the play/pause button (
) to confi rm your selection.
6. RADIO OPERATIONS
This procedure assumes that the power is on.
1. If you’ve been playing a DVD or CD, press the SRC button on the player or remote
to select Radio mode.
2. To select one of three FM and two AM bands, press the BAND button. Keep
pressing this button to alternate among:
FM 1 > FM 2 > FM 3 > AM 1 > AM 2>
3. To select a preset station, press one of the numbered buttons (1-6).
The station frequency displays on the LCD.
Searching automatically for a station
• To automatically search forward through radio frequencies, press next ( ). To stop
at a station, press this button again.
• To search back through radio frequencies, press previous (
press the button again.
<
>
). To stop at a station,
VB475 25
English
Searching manually for a station
To manually move up through the radio frequencies, press and hold the BAND button.
Presetting frequencies
• To preset the current frequency, hold one of the numbered buttons for two seconds.
• To display the current frequency, press the DISP (D) button on the player. To display
the clock, press this button again.
Scanning stored stations
• To scan the stored stations for the current band and play back each station for fi ve seconds, press the down arrow ( ).
• To scan the current band and auto store the available stations, press and hold the down arrow (
) for more than two seconds.
7. AUX-IN OPERATIONS
Before operating an external auxiliary source:
• Make sure that the output from the external audio source is properly connected to the AUX-IN.
• Make sure the external audio source is turned on.
• Change the source to AUX-IN by pressing SRC (
remote. The player plays back an external audio source through the auxiliary input.
) on the player or SRC on the
Selecting the AUX-IN input source
With the power turned on (either by pressing the power button or loading a disc), press
SRC (source) on the player or on the remote until AUX-IN displays on the LCD.
AUX-IN Playback features
• To pause, press play/pause ( ) on the player or the remote.
• To resume play back, press play/pause (
• To play back the fi rst 10 seconds of each track beginning with the current track,
press the scan button: 4/SCN on the player or SCN on the remote.
• To cancel scan mode, press the scan button again.
• To play back all tracts randomly, press the random button: 5/RDM on the player or
RDM on the remote.
• To cancel random play back, press the random button again.
26 VB475
) again.
g
• To repeat the current track press the repeat button: 6/RPT on the player or RPT on
the remote.
To play back the current disc, press the repeat button a second time.
To cancel repeat playback, press it a third time.
NOTE
Other functions work the same as for playing back a DVD.
8. INSTALLATION AND WIRING
lish
En
Installation of mobile audio and video components requires experience with a variety of mechanical and electrical procedures. Although this manual provides general installation and operation instructions, it does not show the exact installation methods for your particular vehicle.
If you do not have the required knowledge, experience, and/or tools to successfully complete the installation, consult an authorized Clarion Dealer about professional installation options.
Precautions
• Carefully read the procedure and the installation specifi cations before installing
the player. Connect all components according to the diagrams provided. Incorrect connection may damage the player.
• If installation requires you to drill holes or make other modifi cations to the vehicle,
consult an authorized Clarion Dealer for help.
• Install the player where it will not get in the way of the driver or injure a passenger in
the event of an emergency stop.
• Overheating will damage the semiconductor laser (used to play back discs). Do not
install the player near a heat source, such as a heater outlet.
• Make all connections before you connect the player to the power supply.
• Insulate any exposed cables to prevent them from causing a short circuit with the
vehicle bracket.
• Pack all cables to avoid power supply terminals touching other metal vehicle parts.
• Before making the fi nal installation, temporarily connect the wiring, turn the power
on, make sure the player works correctly and that nothing else in the vehicle has ceased to work.
Requirements
• The player requires a 12V negative (-) grounded voltage power supply.
• Use only the parts included with the player. Using unauthorized parts can cause the
system to malfunction.
VB475 27
English
Options
To connect any auxiliary device to the player, refer to the manual supplied by the manufacturer of the auxiliary unit.
Accessories and hardware
The following components come with the player:
Qty Item Picture Qty Item Picture
1 Mounting
bracket
1 Nut M5 1 Power
1 Assembly bar 1 Remote control
1 Storage box for
front panel
connector
1 Screw (B15
x 16)
1 Bolt 1 Battery
2Keys
1 Trim ring
Installing the player
If the vehicle has a two-inch high slot in the dashboard for a DVD player, you may directly install the player in the dashboard.
1. To avoid shorts in the electrical system, disconnect the vehicle’s battery.
2. Connect the mounting bolt on the back of the player using a crescent wrench.
3. Check all the electrical connections based on the wiring diagram.
4. Insert the power connector into the player’s power receptacle on the back of the player.
28 VB475
g
Location on vehicle
Assembly bar
lish
En
Dashboard face
Power connector
Screw
Nut
Bolt
Connections identifi ed
5. Use the nut to mount one side of the assembly bar with the bolt.
6. Insert the player into the mounting bracket and push it in until it clicks in place.
Front of the player showing how to install the mounting bracket
The front edge of the bracket lines up with the front of the player.
VB475 29
English
7. Use the screw (B15x16) to attach the other side of the assembly bar to the vehicle body.
8. Attach the trim ring to the front of the player.
Cable connections
• Refer to the owner’s manual for the power amplifi er and for other units before you make connections.
• Secure wiring with cable clamps or adhesive tape. To protect the wiring, wrap adhesive tape around the wires where they lie against metal vehicle parts.
• Route and secure all wiring so that it cannot touch any moving parts, such as the gear shift, handbrake and seat rails. Do not route wiring in places that get hot, such as near the heater outlet. If the insulation of the wiring melts or gets torn, it could short circuit to the vehicle body.
• Don’t pass the yellow lead through a hole with a grommet into the engine compartment to connect to the battery. This will damage the lead insulation and cause a very dangerous short.
• Do not shorten any leads. If you do, the protection circuit may fail to work when it should.
• Never feed power to other equipment by cutting the insulation of the player’s power supply lead to tap into the lead. The current capacity of the lead will be exceeded causing overheating.
• When replacing the fuse, use only a fuse with the same rating (10A).
30 VB475
g
SURROUND-L
FRONT-R
FRONT-L
VIDEO2
VIDEO1
AUX- R
WHITE RED
RED
WHITE
YELLOW
YELLOW
RED
WHITE
RED
WHITE
SURROUND-R
SUB.W1
SUB.W2
AUX- L
ANTENNA
lish
En
MUTE
PRK SW
ILLUMI
GROUND
BATTERY
ACC
ANT.CONT
BROWN
BLUE
ORANGE
BLACK
YELLOW
RED
WHITE
1A
WHITE/BLACK
WHITE
GRAY/BLACK
GRAY
VIOLET
VIOLET/BLACK
GREEN
GREEN/BLACK
BLUE/WHITE
FRONT L-
FRONT L+
FRONT R-
FRONT R+
REAR R-
REAR R+
REAR L-
REAR L+
P.CONT
Cable Where to connect
Battery (Yellow) Connect to vehicle storage battery: DC 12V power supply.
ACC (Red) Connect to electric terminal controlled by the ignition switch
(12V DC).
Ground (Black) Connect to a clean and exposed part of the vehicle’s chassis.
ANT.CONT (White) Connect to the auto-antenna relay control terminal (Max
300mA, 12V DC).
ILLUMI (Orange) Connect to the lighting switch terminal used to detect the
on/off status of the night lamp.
Night lamp connections
MUTE (Brown) Connect to the telephone (TEL) mute control connector.
VB475 31
English
Cable Where to connect
NOTE
If the vehicle does not use a telephone (TEL), leave this cable unconnected.
P.CONT (Blu/WHT)
Parking brake (Blue)
Connect to the external amplifi er control terminal (12V DC).
This connection is used by the player to detect when the parking brake is on and off.
Parking brake switch
Brake lamp
Battery
Parking brake cord
Ground (GND)
Parking brake connections
Connecting the speakers
• Speakers connected to this player must be high-power types with a minimum rating of 30W and an impedance of 4 to 8 Ohms. Connecting speakers with output and /or impedance values other than these may damage the speakers, cause them to smoke or even catch fi re.
• To avoid short-circuits, cover disconnected leads with insulating tape. Especially insulate the unused speaker leads.
Connect the speakers using the following color code:
Speaker Left + Left - Right + Right -
Front White White/black Gray Gray/black
Rear Green Green/black Violet Violet/black
Precautions
• Use groundless speakers only.
• The input power of the speakers you use must be over 40W.
Your speakers must be able to support the full power of the amplifi er, if not, the speakers and/or the player may be damaged.
• Speaker impedance is 4W. Speakers with greater than or less than 4W impedance may not be able to handle the output power from the amplifi er, which may result in damage to the speakers or the player.
32 VB475
g
• Do not use a three-cable speaker system and do not connect the speakers to the
vehicle’s body. The player uses BTL circuitry, which requires that each speaker be connected using insulated cables.
• Install the speaker cables and power amplifi ers approximately 12 inches (30cm)
away from the antenna and any antenna extended parts.
Correct speaker wiring
lish
En
Left +
Left -
White
White/black
Right +
Right -
Left and right wiring diagram
Incorrect speaker wiring
Left +
Left -
Right +
Right -
Left + Left -
Right +
Right -
Wiring examples
Outlet power amplifi er connection
Connect the amplifi er carefully using the following diagram. Incorrectly connecting the amplifi er may impact the quality of the audio and could damage the speakers.
• When the player is on, it outputs a control signal through the blue and white lead.
Connect this lead to an external power amp’s system remote control or to the vehicle’s auto-antenna relay control terminal (max. 300mA 12 VCD). If the vehicle features a glass antenna, connect to the antenna booster power supply terminal.
• When using an external power amp, do not connect the blue and white lead to the
amp’s power terminal. Likewise, do not connect the blue and white lead to the power terminal of the auto-antenna. This connection could cause excessive current drain and the player to malfunction.
Gray
Gray/black
Left + Left -
Right +
Right -
CAUTION
VB475 33
English
WHITE
RED
WHITE
YELLOW
YELLOW
RED
SURROUND-L
FRONT-R
FRONT-L
VIDEO2
VIDEO1
AUX-R
POWER
AMP
YELLOW
YELLOW
RED
WHITE
VIDEO1
VIDEO2
AUX-R
AUX-L
MONITOR
MONITOR
EXTERNAL
AUDIO
DEVICE
Fuse
If the fuse requires replacing, use only a 10A fuse. If the fuse malfunctions after installing it, consult an authorized Clarion Dealer.
WARNING
Replacing a 10A fuse with a high-capacity fuse or directly connecting the player without a fuse will easily cause a fi re and or damage the equipment.
9. DVD PREFERENCES
1. Insert a DVD disc.
2. Press STOP (
3. Press SETUP on the remote.
4. Use the right and left arrows on the remote to select one of three options tabs: Language, Video or Rating.
5. Press the play/pause button (
The player displays the options for the tab you selected.
BAND) on the remote.
) to confi rm.
34 VB475
g
Language options
lish
En
Language setup tab
Option Description and Values
OSD Menu
Subtitle
Audio
DVD Menu
Selects the language for the on-screen display menus.
English, Chinese, French, Spanish
Selects the language for subtitles.
English, Chinese, French, Spanish
Auto
Off
Selects the audible language for the DVD audio track.
English, Chinese, French, Spanish
Selects the language for the DVD menus.
English, Chinese, French, Spanish
Turns subtitles off.
Video options
Video tab with TV shape option set to 4:3
VB475 35
English
Option Description and Values
TV shape
TV system
Video Mode
Priority Content
PictureCD View
JPEG Internal
Selects the aspect ratio (relationship of the image width to height).
4:3
16:9
Selects the TV standard.
PAL
NTSC
Controls how video images display.
FILL
Original
H FIT
W FIT
Lets you defi ne what type of DVDs you listen to most frequently.
DVD-Audio, DVD-Video
Confi gures how to view a CD that contains digital photographs.
Original
Fit to screen
When viewing photographs, this option determines how long the photograph displays.
5 seconds, 10 seconds, 15 seconds
Normal aspect ratio.
Full width aspect ratio.
For Europe and Asia.
For the United States.
Stretches the image so it fi ts the entire screen. This may distort the image slightly.
Displays without distortion, but the image does not fi ll the entire screen.
Extends the left and right sides of the image.
Expands the image horizontally so that it fi ts the entire screen. The expansion ratio increases towards the right and left edges of the screen.
Displays the photo at its original size.
Enlarges each photo to fi t the screen.
Rating options
To change this page requires a password. The default password is 3308. Type four numbers in the password fi eld and press play/pause button ( ) to confi rm the password.
36 VB475
g
The Rating tab with the password selected
The lock symbol changes from closed to open when you enter the correct password.
CAUTION:
Record your password and store it in a secure location. Without the correct password you will not be able to change ratings
Option Description and Values
Rating
Load Factory
DivX registration
TVG Mode
Restricts movie viewing to appropriate ages.
1 (KID SAF)
2 (G)
3 (PG)
4 (PG 13)
5 (PGR)
6 (R)
7 (NC 17)
8 (ADULT)
Reset returns all rating values to their factory defaults.
Displays your registration code. “DivX” refers to the audio codec created by DivXNetworks, Inc.
Simulates, using software, the function of a set-top box that mutes sentences containing off-color language.
Off
Tolerant
Strict
Material is safe for children.
Material is safe for general audiences.
Parental guidance suggested.
Some material unsuitable for children under 13.
Some material unsuitable for children under 17.
Some material unsuitable for children under 17.
Not recommended viewing for children under 17.
Only for adults due to the graphic content.
Turns TV guidance mode off.
Selects minimal foul language muting.
Selects maximum foul language muting.
lish
En
VB475 37
English
10. TROUBLESHOOTING
No sound from the speakers
• Sound may be muted. Press MUTE to restore the sound.
• The player may be fast forwarding, fast reversing, searching or displaying a single
frame.
• Confi rm that the cables are connected correctly.
There is no vehicle-installed phone and the telephone muting cable is connected to the high level.
No picture on the monitor
• Make sure the cables are connected correctly.
• Check to make sure that the parking brake is connected correctly.
• Make sure you are operating the monitor correctly. Turn the monitor off and back on,
and select the video source.
The disc will not play
• Make sure a disc is loaded with the right side up. The side with the label on it should be up.
• Make sure the disc is not damaged or warped.
• Try another disc that you know works.
• If the disc is wet, remove it and let the player dry for about an hour before trying
again.
Restoring factory defaults
If the system is locked, insert a the end of a paper clip into the hole to press the RESET button.
Reset button
Player with the front panel removed
NOTE
Reset returns all option settings to their factory defaults.
38 VB475
g
11. GLOSSARY
CD: Compact Disc.
CD-R/RW: CD Read/Read and Write.
CODEC: Short for Compression/Decompression Module, it applies to audio data.
Dolby Digital: The marketing name for the audio compression technologies developed
by Dolby Laboratories.
DVD : Digital VideoDisc or Digital Versatile Disc.
DVD-R: DVD Read only.
DVD-RW: DVD Read and Write.
IR: Infrared.
MP3: MPEG Audio Layer-3, a standard for sound compression without sacrifi cing
quality.
NTSC: National TV Standards Committee, the group that developed the video formats used in the United States.
OSD: On-Screen Display.
PA L: The primarily European standard for displaying analog television signals.
PBC: PlayBack Controls.
SRC: Source.
TVG: TVGuardian® is a registered trademark of Principle Solutions, Inc.
VCD: Video CD, the standard for storing video on a CD.
Viewing angle: Pre-recorded alternative angles for individual scenes.
lish
En
VB475 39
English
12. SPECIFICATIONS
Power Supply power voltage 12V DC
(10.5~16V DC allowable) MAX Current: 10A
Audio S/N Ratio 80dB
Dynamic Range 80dB Output power 25 W x 4 Load Impedance 4 THD 0.1%
FM Radio Usable Sensitivity (S/N: 30dB) 20 dBu
Frequency Response: 60 Hz ~ 14 kHz S/N Ratio 55dB Antenna Impedance 75
AM Radio Usable Sensitivity(S/N: 20dB) 36dBu
S/N Ratio 43dB Antenna Impedance 75
AUX-IN Frequency Response 20 ~ 20,000Hz
Input Impedance 47K S/N Ratio 70dB Standard Input Level 200mV Max Input Level: 2V
DVD Player Region number: 1
S/N ratio 90dB(1KHZ) Dynamic Range 90dB(1kHZ) Distortion 0.05%(1kHZ)
Output level Video 1.0V /75 ( 0.2V) P-P
Audio 2.0V(1KHZ .0dB) 0.2V Number of channels 4.2 CH
NOTE
For the sake of technical improvements, this technical data and the design of the equipment may change without prior notice.
40 VB475
g
lish
En
VB475 41
English
42 VB475
g
lish
En
VB475 43
English
Clarion Corporation of America
All Rights Reserved. Copyright © 2007: Clarion Corp. of America
44 VB475
Printed in China
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
