SUBARU - CLARION

CAR AUDIO

OPERATION

Hi Radio Model

PF-3380I-A

User Manual.doc

- 2 / 156 -

１． Table of Contents

１． Table of Contents ................................................................................................................................................................................................................................................................... 2

２． OUTLINE .......................................................................................................................................................................................................................................................................................... 5

２-１． Destination / Model Set Name ............................................................................................................................................................................................................................ 5

２-２． Warning ............................................................................................................................................................................................................................................................................... 5

２-３． Surface Image ................................................................................................................................................................................................................................................................. 6

３． Feature List .................................................................................................................................................................................................................................................................................... 7

４． Key Disposition .......................................................................................................................................................................................................................................................................... 9

４-１． Body ..................................................................................................................................................................................................................................................................................... 9

４-２． Remote Controller .................................................................................................................................................................................................................................................... 10

５． Operation Specification ..................................................................................................................................................................................................................................................... 11

５-１． Audio Common Operation ................................................................................................................................................................................................................................... 11

５-１-１． VOLUME UP / DOWN ..................................................................................................................................................................................................................................... 11

５-１-２． Switch to TONE / BALANCE Adjustment Mode .......................................................................................................................................................................... 12

５-１-３． Adujust TONE / BALANCE UP / DOWN ................................................................................................................................................................................... 13

５-２． Operation of MENU ............................................................................................................................................................................................................................................... 14

５-２-１． Switch to MENU Mode .................................................................................................................................................................................................................................. 14

５-２-２． BT Audio Setting .................................................................................................................................................................................................................................................. 15

５-２-３． Adjust SPEED VOLUME CONTROL (SVC) ..................................................................................................................................................................................... 17

５-２-４． Adjust SRS Sound .............................................................................................................................................................................................................................................. 18

５-２-５． Adjust BEEP ............................................................................................................................................................................................................................................................ 19

５-３． Operation of RADIO （RBDS） ....................................................................................................................................................................................................................... 20

５-３-１． Initial Setting of RADIO .................................................................................................................................................................................................................................... 20

５-３-２． Call / Switch RADIO Mode ........................................................................................................................................................................................................................... 21

５-３-３． TUNE UP / DOWN ............................................................................................................................................................................................................................................. 22

５-３-４． SEEK UP / DOWN .............................................................................................................................................................................................................................................. 23

５-３-５． Call PRESET ........................................................................................................................................................................................................................................................... 24

５-３-６． Write PRESET ........................................................................................................................................................................................................................................................ 25

５-３-７． SCAN ........................................................................................................................................................................................................................................................................... 26

５-３-８． Select / SEEK PTY ....................................................................................................................................................................................................................................... 27

５-３-９． Switch to PS / RT .............................................................................................................................................................................................................................................. 30

５-４． Operation of Satellite Radio(XM) ..................................................................................................................................................................................................................... 31

５-４-１． Call /switch to XM mode ............................................................................................................................................................................................................................... 31

５-４-２． CH UP / DOWN.................................................................................................................................................................................................................................................... 32

５-４-３． CHANNEL UP/DOWN FOR 10 DIGITS ............................................................................................................................................................................................ 33

５-４-４． Category Search Mode .................................................................................................................................................................................................................................... 34

５-４-５． Call Preset ............................................................................................................................................................................................................................................................. 35

５-４-６． Write Preset .......................................................................................................................................................................................................................................................... 36

５-４-７． SCAN ........................................................................................................................................................................................................................................................................... 37

５-４-８． Switch the Title .................................................................................................................................................................................................................................................. 38

５-４-９． Display RADIO ID .............................................................................................................................................................................................................................................. 39

User Manual.doc

- 3 / 156 -

５-４-１０． Advisory Message List .............................................................................................................................................................................................................................. 40

５-５． Operation of Satellite Radio （Sirius） ........................................................................................................................................................................................................ 41

５-５-１． Call/Switch SR Mode ..................................................................................................................................................................................................................................... 41

５-５-２． CH UP / DOWN.................................................................................................................................................................................................................................................... 42

５-５-３． CHANNEL UP/DOWN FOR 10 DIGITS ............................................................................................................................................................................................ 43

５-５-４． Category Search Mode ................................................................................................................................................................................................................................. 44

５-５-５． Call Preset ................................................................................................................................................................................................................................................................ 45

５-５-６． Write Preset ............................................................................................................................................................................................................................................................. 46

５-５-７． SCAN ........................................................................................................................................................................................................................................................................... 47

５-５-８． Switch the Title .................................................................................................................................................................................................................................................. 48

５-５-９． Display RADIO ID .............................................................................................................................................................................................................................................. 49

５-５-１０． Advisory Message List .............................................................................................................................................................................................................................. 50

５-６． Media HUB Operation .......................................................................................................................................................................................................................................... 51

５-６-１． Call /Switch Media HUB Mode................................................................................................................................................................................................................ 51

５-６-２． Track UP/DOWN ................................................................................................................................................................................................................................................. 52

５-６-３． FF/FB .......................................................................................................................................................................................................................................................................... 53

５-６-４． Browsing Mode ...................................................................................................................................................................................................................................................... 54

５-６-５． Select Operation Mode ................................................................................................................................................................................................................................. 55

５-６-６． Switch to TITLE .................................................................................................................................................................................................................................................... 56

５-７． Operation of DISC ................................................................................................................................................................................................................................................. 57

５-７-１． CD LOADING ......................................................................................................................................................................................................................................................... 57

５-７-２． EJECT CD ............................................................................................................................................................................................................................................................. 58

５-７-３． Playback Object ( CD / USB ) ................................................................................................................................................................................................................ 59

５-７-４． Switch to CD Mode ............................................................................................................................................................................................................................................ 61

５-７-５． Playback / Pause (CD / USB) ................................................................................................................................................................................................................... 62

５-７-６． TRACK UP / DOWN ......................................................................................................................................................................................................................................... 63

５-７-７． FOLDER UP / DOWN （DISC MP3/WMA/AAC） ........................................................................................................................................................................ 64

５-７-８． FF / FB ....................................................................................................................................................................................................................................................................... 65

５-７-９． RPT ............................................................................................................................................................................................................................................................................... 66

５-７-１０． RDM .......................................................................................................................................................................................................................................................................... 67

５-７-１１． RPT/RDM Playlist of Track Transition .......................................................................................................................................................................................... 68

５-７-１２． SCAN ....................................................................................................................................................................................................................................................................... 74

５-７-１３． Switch to TITLE （CD/USB） .............................................................................................................................................................................................................. 77

５-７-１４． Send PAGE （CD/USB） ........................................................................................................................................................................................................................... 78

５-７-１５． Display ERROR Message (CD Mode) ................................................................................................................................................................................................ 79

５-８． Operation of USB ................................................................................................................................................................................................................................................... 80

５-８-１． USB CONNECT .................................................................................................................................................................................................................................................... 80

５-８-２． USB DISCONNECT ........................................................................................................................................................................................................................................... 81

５-８-３． Playback Object (CD/USB) .......................................................................................................................................................................................................................... 82

５-８-４． Switch to USB Mode ......................................................................................................................................................................................................................................... 83

５-８-５． Play / Pause (CD / USB) .............................................................................................................................................................................................................................. 84

５-８-６． TRACK UP / DOWN （MSC） .................................................................................................................................................................................................................... 85

５-８-７． FOLDER UP / DOWN （MSC） .................................................................................................................................................................................................................. 86

５-８-８． TRACK UP / DOWN （iPod） ..................................................................................................................................................................................................................... 87

５-８-９． CHAPTER UP / DOWN （iPod） .............................................................................................................................................................................................................. 88

５-８-１０． FF / FB （MSC） .............................................................................................................................................................................................................................................. 89

５-８-１１． FF / FB （iPod） ............................................................................................................................................................................................................................................... 90

５-８-１２． RPT （MSC） ....................................................................................................................................................................................................................................................... 91

５-８-１３． RDM （MSC） ...................................................................................................................................................................................................................................................... 92

User Manual.doc

- 4 / 156 -

５-８-１４． RPT/RDM Playlist of Track Transition ............................................................................................................................................................................................. 93

５-８-１５． SCAN ....................................................................................................................................................................................................................................................................... 97

５-８-１６． RPT （iPod） ......................................................................................................................................................................................................................................................... 98

５-８-１７． Shuffle （iPod） ................................................................................................................................................................................................................................................... 99

５-８-１８． RPT/Shuffle Playlist of Track Transition .................................................................................................................................................................................. 100

５-８-１９． Select Category （iPod） .......................................................................................................................................................................................................................... 104

５-８-２０． Switch to TITLE ............................................................................................................................................................................................................................................. 106

５-８-２１． Send PAGE ....................................................................................................................................................................................................................................................... 107

５-８-２２． Display ERROR (USB) ............................................................................................................................................................................................................................. 108

５-９． Operation of Bluetooth Audio ......................................................................................................................................................................................................................... 110

５-９-１． Play / Pause ........................................................................................................................................................................................................................................................ 110

５-９-２． TRACK UP / DOWN ...................................................................................................................................................................................................................................... 111

５-９-３． FOLDER UP / DOWN ................................................................................................................................................................................................................................... 112

５-９-４． RPT ............................................................................................................................................................................................................................................................................ 113

５-９-５． RDM ........................................................................................................................................................................................................................................................................... 114

５-９-６． RPT/RDM Playlist of Track Transition.............................................................................................................................................................................................. 115

５-９-７． Switch to TITLE ................................................................................................................................................................................................................................................. 116

５-９-８． Send PAGE ........................................................................................................................................................................................................................................................ 117

５-１０． Operation of Bluetooth HFP ........................................................................................................................................................................................................................ 118

５-１０-１． VOICE COMMAND ................................................................................................................................................................................................................................... 118

５-１０-２． VOICE COMMAND List ........................................................................................................................................................................................................................... 119

５-１０-３． BT TOP MENU ............................................................................................................................................................................................................................................... 121

５-１０-４． INITIAL START (PAIRING) .................................................................................................................................................................................................................... 124

５-１０-５． DIAL ....................................................................................................................................................................................................................................................................... 125

５-１０-６． Incoming Call .................................................................................................................................................................................................................................................... 127

５-１０-７． CALL ..................................................................................................................................................................................................................................................................... 128

５-１０-８． Registration Phone Book ...................................................................................................................................................................................................................... 129

５-１０-９． PHONEBOOK （Others） ......................................................................................................................................................................................................................... 132

５-１０-１０． BT SETUP （SECURITY） .................................................................................................................................................................................................................. 135

５-１０-１１． BT SETUP （PHONE SETUP） ....................................................................................................................................................................................................... 138

５-１０-１２． BT SETUP （SYSTEM SETUP） .................................................................................................................................................................................................... 141

５-１０-１３． DELETE HISTORY .................................................................................................................................................................................................................................. 142

５-１１． Operation of AUX ............................................................................................................................................................................................................................................... 143

５-１２． OTHERS .................................................................................................................................................................................................................................................................. 144

５-１２-１． POWER ON ....................................................................................................................................................................................................................................................... 144

５-１２-２． BEEP ..................................................................................................................................................................................................................................................................... 145

５-１２-３． TEL MUTE ......................................................................................................................................................................................................................................................... 146

５-１２-４． Operation of Steering Controller ........................................................................................................................................................................................................ 147

５-１２-５． CONTROL BRIGHTNESS & ILLUMI ............................................................................................................................................................................................... 156

User Manual.doc

- 5 / 156 -

２． OUTLINE

２-１． Destination / Model Set Name

Outline Car Model Set Destination Note

2DIN size 1CD player EX7 PF-3380 North America （U） Left Handl Drive Car

２-２． Warning ( North America (U) model )

・ Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority

to operate the equipment..

・ This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets

the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated keeping the radiator at least 20cm or more away from person’s body (excluding extremities: hands, wrists, feet and ankles).

・ This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

User Manual.doc

- 6 / 156 -

２-３． Surface Image

User Manual.doc

- 7 / 156 -

３． Feature List

Mode Function Destination Note

Radio

AM（MW）Frequency Band（kHz） 530～1710 10kHz step FM Frequency band（MHｚ） 87.75～107.9 200ｋHz step Number of Preset AM Station 6×2 Number of Preset FM Station 6×3 MANUAL UP/DOWN ○ SEEK UP/DOWN ○ AUTO STORE ○ Existence Station SCAN UP ○ Switch to LO/DX AUTO PS ○ Selection PTY ○ Group Selection PTY SEEK ○ Group Selection RADIO TEXT ○

SAT

（XM）

Number of Preset Station 6×3 CHANNEL UP/DOWN ○ CHANNEL10Digits UP/DOWN ○ CHANNEL SCAN UP ○ CATEGORY SEARCH MODE ○ CATEGORY UP/DOWN ○ IN CATEGORY SEARCH MODE DISPLAY TITLE ○ WithoutPage transition

SAT

（Sirius）

TRACK UP/DOWN ○ FOLDER UP/DOWN ○ Only for playing compressed audio ＦＦ/FB ○ TRACK REPEAT ○ FOLDER REPEAT ○ Only for playing compressed audio ALL RANDOM ○ FOLDER RANDOM ○ Only for playing compressed audio SCAN ○ DISPLAY CD-TEXT ○ DISPLAY FOLDER/FILE NAME ○ Only for playing compressed audio BACKUP EJECT ○ PLAYBACK COMPRESSED AUDIO ○ Support MP3/WMA/AAC PLAYBACK CD-R/RW ○

USB

TRACK UP/DOWN ○ FOLDER UP/DOWN ○ Only for playing compressed audio ＦＦ/FB ○

User Manual.doc

- 8 / 156 -

TRACK REPEAT ○ FOLDER REPEAT ○ Only for playing compressed audio ALL RANDOM ○ FOLDER RANDOM ○ Only for playing compressed audio FOLDER SCAN ○ Only for playing compressed audio DISPLAY FOLDER/FILE NAME ○ Only for playing compressed audio PLAYBACK COMPRESSED AUDIO ○ SUPPORT MP3/WMA/AAC PLAYBACK iPod ○ MUSIC ONLY

Bluetooth

HFP ○ OPP ○ A2DP ○ AVRCP（Ver.1.3） ○

VOICE

RECOGNIZA

TION

H/F OPERATION ○ AUDIO OPERATION ○ MULTI LANGUAGE

SUPPORT

ENGLISH、FRENCH

AUDIO

VOLUME ○ 0～+40 BASS/MID/TREBLE ○ ±8/±8/±8 BALANCE/FADER ○ ±9/±9 SWITCH BEEP ON/OFF ○ LOUDNESS ○ FIXED ON MUTE ○ Only for the key of Steering Controller BEEP ○ possible to switch ON/OFF SUPPORT STREERING REMOTE

CONTROLLER

○

DISPLAY AREA （LCD） 5×7dot×15digits×2lines BUS Sie-BUS No Ce-NET SUPPORT TEL MUTE ○ CONNECT TO AUX ○ ADJUST AUX VOLUME ○ 1STEP DIMMER ○ イルミコントロール Function ○

CONNECTION DEVICE

XM-BB

Sirius-BB

MEDIA-HUB

Sie-BUS

SPEED VOICE CONTROL（SVC） ○ CAN

User Manual.doc

- 9 / 156 -

４． Key Disposition

４-１． Body

Destination

記号

Key Name

A EJECT B PTY / CAT C A.S. D SCAN E TEXT F RPT / RDM G MENU H LIST / BACK

I CD / AUX J FM K AM L SAT M UP N DOWN O << P >> Q VOLUME R TUNE S 1 T 2 U 3 V 4 W 5 X 6

I J K L

O P Q R

S T U V W X

User Manual.doc

- 10 / 156 -

４-２． Remote Controller

Destination

Symbol

Key Name

Ⅰ VOLUME + Ⅱ VOLUME Ⅲ UP Ⅳ DOWN Ⅴ MODE Ⅵ TALK Ⅶ OFF HOOK Ⅷ ON HOOK

Ⅰ

Ⅱ

Ⅲ

Ⅳ

Ⅴ Ⅵ

Ⅶ Ⅷ

User Manual.doc

- 11 / 156 -

５． Operation Specification

５-１． Audio Common Operation

５-１-１． VOLUME UP / DOWN

Function VOLUME UP / DOWN Operation of button

Turn left/right the VOLUME key

Detail

There are 41 steps in VOLUME STEP from Step0 to Step40. The set will keep the volume value for each of connection AUX and other modes.(such as RADIO,CD mode) Initial volume value is 15. Initial volume value of AUX mode is 15.

If you turn right the VOLUME key, the volume value will be 1 step up.

If you turn left the VOLUME key, the volume value will be 1 step down.

If you adjust volume, it will display the volume value such as “VOLUME 15”. If you turn right when the volume value is the max value (40), or turn left when the volume value is the min value(0), the

volume value will not be changed.

The VOLUME key of set will be effective when playing FF/FB in CD mode.

The VOLUME key of Steering Controller will be not effective when playing FF/FB in CD mode.

The VOLUME key of set will be not effective in BT-TEL mode. (incoming call/calling/voice infomation)

Volume adjustment will be released by following conditions.

No volume adjustment operation in 5 seconds. When you turn ACC / POWER off. When you touch any effective key in any source mode.

User Manual.doc

- 12 / 156 -

５-１-２． Switch to TONE / BALANCE Adjustment Mode

Function Switch to TONE / BALANCE Adjustment Mode （BASS / MIDDLE / TREBLE / FADER / BALANCE） Operation of button

Touch the TUNE key for less than 1.5sec. (Operation when Key is OFF)

Detail

If you touch the TUNE key for less than 1.5sec, it will switch to TONE / BALANCE adjustment mode.

It will go to next mode like following, when you touch the TUNE key.

Normal Mode → BASS → MIDDLE → TREBLE → FADER → BALANCE → Normal Mode

TONE / BALANCE adjustment mode will be released by following conditions.

No operation is done in 5 seconds after you switch to next TONE / BALANCE adjustment mode.

When you turn ACC / POWER off.

When you touch the TUNE key in BALANCE adjustment mode.

When you touch any effective key in any source mode.

User Manual.doc

- 13 / 156 -

５-１-３． Adujust TONE / BALANCE UP / DOWN

Function Adujust TONE / BALANCE UP / DOWN （BASS / MIDDLE / TREBLE / FADER / BALANCE） Operation of button

Turn left/right the TUNE key

Detail

If you turn the TUNE key in T/B adjustment mode, the T/B adjutment value will be up/down.

When the adjustment value becomes 0 (CENTER) by your operation, the value will be hold on for 500msec. If you turn right the keu when the value is the max, or you turn left when the value is the min, the adjustment value will

not be changed.

The range of the T/B adjustment value is the following.

Mode Adjustment Step Adjustment Range Total Steps Init Value

BASS ±1step －8 ～＋8 17 0 MIDDLE ±1step －8 ～＋8 17 0 TREBLE ±1step －8 ～＋8 17 0

FADER R/F ±1step R 9 ～ F 9 19 0

BALANCE L/R ±1step L 9 ～ R 9 19 0

Turn Left ← TUNE → Turn Right

User Manual.doc

- 14 / 156 -

５-２． Operation of MENU

５-２-１． Switch to MENU Mode

Function Call / Switch to MENU Mode Operation of button

Touch the MENU key. （Action when Key is ON.）

Detail

It will go to next mode like following, when you touch the MENU key.

Initial setting is “OFF”.

→ → → → →

MENU mode will be released by following conditions.

No operation is done in 5 seconds after you switch to next menu mode. When you turn ACC / POWER off.

When you touch MENU key in BEEP adjustment mode.

When you touch any effective key in any source mode.

OFF BT Audio SVC

BEEP OFF

SRS Sound

User Manual.doc

- 15 / 156 -

５-２-２． BT Audio Setting

Function

Bluetooth Audio Setting

PAIR AUDIO ： Pair to a mobile phone which has A2Dpprofile. SELECT AUDIO ： Select a mobile phone from registration list. SET PASSKEY ： Set passkey for pairing. DELETE AUDIO ： Delete a mobile phone from registration list.

※ BT Audio setting is not effective when driving. ※ Touch “GO BACK” on the top of each item to release menu mode and go back to the last source.

Operation of button

PAIR AUDIO

1. Select “PAIR AUDIO”

Key Operation ： Turn the TUNE key in BT Audio Setup MENU, select “PAIR AUDIO” and touch.

※ It will display “MEMORY FULL” for 2sec and go to BT Audio Setting Menu if there are more than one BT

audio in registration list.

2. Make it waiting for searching and put in the passkey by mobile phone.

SET SIDE ： It will go to display passkey text automatically after displayed “CAR_M_MEDIA”. MOBILE SIDE ： Put in the passkey by mobile phone after finishing searching. ※The passkey should be the same to the HF set. ○When paired successfully it will display Device Name and go to BT Audio Setting Menu after displaying “PAIRED” . ○When failed in pairing it will go to BT Audio Setting Menu after displaying “FAILED”.

※ Initial passkey is “1234”.

※ Touch the BACK key to release from waiting for searching.

※ Touch the BACK key to go back to BT Audio Setting Menu.

SELECT AUDIO

1. Select “SELECT AUDIO”

Key Operation： Turn the TUNE key in BT Audio Setup MENU, select “SELECT AUDIO” and touch.

※ It will display “EMPTY” for 2sec and go to BT Audio setting if there is no BT audio in registration list.

2. Confirm the connection

Key Operation ： Turn the TUNE key when displaying “BT Audio”, select “CONFIRM” and touch.

When connected successfully it will go to BT Audio setting after displaying “SELECTED”.

When failed in connecting it will go to BT Audio setting after displaying “FAILED”.

User Manual.doc

- 16 / 156 -

SET PASSKEY

1. Select “SET PASSKEY”

Key Operation ： Turn the TUNE key when in BT Audio Setup MENU, select “SET PASSKEY” and touch.

2. Set PASSKEY

It will display the current passkey（PKY：XXXXXXXX）, then display new PASSKEY INPUT TEXT.

※ 4-8 digits number is available. ※ If you set new passkey in BT Audio, the passkey of HF set is also changed. The same is true in

reverse.

※ Initial passkey is “1234”.

Key Operation ： Turn the TUNE key when displaying “BT Audio”, input numbers and touch.

3. Confirm the New Passkey

Key Operation ： Turn the TUNE key when displaying “BT Audio”, select “CONFIRM” and touch.

When finishes reseting the passkey it will go to BT Audio Setting Menu after displaying the New PASSKEY for 2sec.

DELETE AUDIO

1. Select “DELETE AUDIO”

Key Operation ： Turn the TUNE key in BT Audio Setup MENU, select “DELETE AUDIO” and touch.

※ It will display “EMPTY” for 2sec and go to BT Audio setting if there is no BT audio in registration list.

2. Confirm Delection

Key Operation ： Turn the TUNE key to select “CONFIRM” and touch.

When finish deleting the passkey it will go to BT Audio setting after displaying “DELETED” for 2sec.

Detail

It is not available to registrate VOICE TAG. VOICE COMAND is not available for this function. Only one Audio model can be registrated. There is no timeout in BT Audio menu.

User Manual.doc

- 17 / 156 -

５-２-３． Adjust SPEED VOLUME CONTROL (SVC)

Function Adjust SPEED VOLUME CONTROL (SVC) in Menu Mode Operation of button

Turn the TUNE key

Detail

Turn the TUNE key while adjusting SVC in MENU Mode to adjust SVC

Initial setting is OFF. The adjustment value will not be changed if you turn up when it is the MAX value, or turn down when it is the MIN

value.

Adjustment range is the following.

Mode Adjustment Step Adjustment Range Total Steps Initial Value

SVC ±1step 0FF ～ 2 3 OFF

Turn Left ← TUNE → Turn Right

User Manual.doc

- 18 / 156 -

５-２-４． Adjust SRS Sound

Function Switch SRS Sound ON/OFF in MENU Mode Operation of button

Turn the TUNE key while adjusting SRS Sound.

Detail

Turn the TUNE key while adjusting SRS Sound to switch SRS Sound ON/OFF.

Initial setting is OFF. The adjustment value will not be changed if you turn up when it is ON, or turn down when it is OFF.

User Manual.doc

- 19 / 156 -

５-２-５． Adjust BEEP

Function Switch BEEP ON/OFF in MENU Mode Operation of button

Turn the TUNE key while adjusting BEEP.

Detail

Turn the TUNE key while adjusting BEEP to switch BEEP ON/OFF.

Initial setting is ON. The adjustment value will not be changed if you turn up when it is ON, or turn down when it is OFF.

User Manual.doc

- 20 / 156 -

５-３． Operation of RADIO （RBDS）

５-３-１． Initial Setting of RADIO

Function Initial Setting of RADIO Frequency / Preset CHANNEL Operation of button

－

Detail

■RADIO Setting

BAND

Item

FM AM

Frequency Range 87.75 ～ 107.9 MHz 530 ～ 1710 kHz

Receiving Step 200 kHz 10 kHz

SEEKStep 200 kHz 10 kHz

Band 3 BAND 2 BAND

Initial Value of Band/ Frequency

FM1 98.1 MHz AM1 1000 kHz FM2 87.7 MHz AM2 530kHz FM3 87.7 MHz -

※ 87.75 will be display as 87.7. ※ Preset Number will not be displayed initial.

■Initial Value of Preset CHANNEL

BAND

1ch 2ch 3ch 4ch 5ch 6ch

FM1 （MHｚ） 87.7 90.1 98.1 106.1 107.9 87.7 FM2 （MHｚ） 87.7 87.7 87.7 87.7 87.7 87.7 FM3 （MHｚ） 87.7 87.7 87.7 87.7 87.7 87.7 AM1 （kHｚ） 530 600 1000 1400 1630 530 AM2 （kHｚ） 530 530 530 530 530 530

※ It will display the CHANNEL Number only when you touch the “PRESET” key.

⇒ It will not display preset channel even the Frequency searched bay TUNE/SEEK is tha same as Preset memory..

User Manual.doc

- 21 / 156 -

５-３-２． Call / Switch RADIO Mode

Function Call FM/AM RADIO Mode and Switch to BAND Operation of button

Touch the FM or AM key

Detail

If you touch FM or AM key in other source mode, it will start toreceive Frequency of last Band and last

memory. It is also effective when POWER OFF. (( ST )) indicator will blink while receiving Stereo Broadcast in FM mode.

If you touch the FM key in FM mode, it will switch to next Band like following.

→ → →

If you touch the AM key in AM mode, it will switch to next Band like following.

→ →

FM1

FM2 FM3 FM1

AM1

AM2 AM1

User Manual.doc

- 22 / 156 -

５-３-３． TUNE UP / DOWN

Function RADIO TUNE UP/DOWN Operation of button

Turn the TUNE key

Detail

If you turn right the TUNE key in radio mode, the receiving frequency will be 1 step up.

If you turn left the TUNE key in radio mode, the receiving frequency will be 1 step down.

If you turn up when frequency is the maximum, it will go to the minimum frequency. If you turn down when frequency is the minimum, it will go to the maximum frequency.

User Manual.doc

- 23 / 156 -

５-３-４． SEEK UP / DOWN

Function RADIO SEEK UP/DOWN Operation of button

Touch the >> & << key （Action when Key is ON.）

Detail

If you touch the >> or << key in RADIO mode, the receiving frequency will seek up or down.

It will be MUTE while seeking. If the frequency reaches the maximum when you are seeking up, it will go back to the minimum frequency and go on

seeking up.

If the frequency reaches the minimum when you are seeking down, it will go back to the maximum frequency and go on

seeking down.

When it goes back to the maximum/minimum frequency, it will keep the next frequency for 500msec then go on

seeking.

If you go to volume adjustment mode or T/B adjustment mode while seeking, the adjustment value will be kept even

frequency seek finishes after a receiving station is sought out. Sensitivity of seeking AM is linked to the illumination. It will be LO SEEK when the illumination is ON, and be DX SEEK

when the illumination is OFF.

Sensitivity of seeking FM is fixed to DX.

SEEK mode will be released by following conditions.

When received a station which is possible to be received. When you go to other sourcemode. （The last frequency is the frequency before seeking.） When you switch to other band. （The last frequency is the frequency before seeking） when you turn ACC / POWER OFF. （The last frequency is the frequency before seeking）

When you turn the TUNE key. （Stop at the frequency when key is ON）

When you touch the >> or << key. （Stop at the frequency when key is ON）

When you touch the 1 ～ 6 key. （Call the cahannel you touch when key is ON）

When you touch the SCAN key. （Scan starts from the frequency when key is ON）

When you touch the PTY / CAT key. （Start PTY selection mode from the frequency when key is ON.）

User Manual.doc

- 24 / 156 -

５-３-５． Call PRESET

Function Call RADIO Preset Channel Operation of button

Touch the 1 ～ 6 key for less than 1.5sec.

Detail

If you touch the 1 ～ 6 key for less than 1.5sec in RADIO mode, it will call the frequency which is kept as the

memory of the key. It will switch the channel number display when key is ON. It will switch the frequency display when key is OFF. It is available to receive the frequency of preset channel when key is OFF. It will not work when you touch the key that its preset memory has been received.

The following keys are effective before key OFF. （KEY ON～Less than 1.5sec KEY OFF）

the VOLUME key

the EJECT key

User Manual.doc

- 25 / 156 -

５-３-６． Write PRESET

Function Preset Memori of RADIO frequency Operation of button

Touch the 1 ～ 6 key for more than 1.5sec.

Detail

Touch the 1 ～ 6 key in RADIO mode for more than 1.5sec, it will preset the frequency as the memory of the

key you touched. BEEP sounds when memory is confirmed. The displaying CH number will blink once when memory is confirmed. It will not work when you touch the key which the preset memory has been received.

The following keys are effective before key OFF.

the VOLUME key

the EJECT key

User Manual.doc

- 26 / 156 -

５-３-７． SCAN

Function RADIO Station SCAN UP Operation of button

Touch SCAN key

Detail

If you touch the SCAN key in RADIO mode, it will start to scan radio station which is possible to receive.

It will start to scan radio stations, which is possible to receive, from the next frequency. It will be mute while scaning, if there is no station which is possible to receive. Mute mode will be off and radio sound comes out, when radio station, which is possible to receive, is found. When radio station, which is possible to receive, is found, it will receive the frequency for 5 seconds, then goes on to

scan the next station.

It will scan around for once, and stop when it goes to the frequency that it starts. It will not scan the beginning station (the ending station).

SCAN mode will be released by following conditions.

When you go to other sourcemode. （The last frequency is the frequency before scan.） When you switch to other band. （The last frequency is the frequency before scan.） when you turn ACC / POWER OFF. （The last frequency is the frequency before scan.）

When you turn the TUNE key. （Stop at the frequency when key is ON）

When you touch the >> or << key. （Stop at the frequency when key is ON）

When you touch the 1 ～ 6 key. （Call the cahannel you touch when key is ON）

When you touch the SCAN key. （Scan starts from the frequency when key is ON）

When you touch the PTY / CAT key. （Start PTY selection mode from the frequency when key is ON.）

User Manual.doc

- 27 / 156 -

５-３-８． Select / SEEK PTY

Function Select / Seek RADIO PTY Group

Operation of button

Touch the PTY / CAT key （PTY selection mode ON）

Touch the FOLDER UP or FOLDER DOWN key （PTY UP/DOWN）

Touch the >> or << key （PTY SEEK）

Detail

■PTY Group Selection Mode

If you touch the PTY / CAT key in FM mode, it will go to PTY Group Selection Mode and display the PTYgroup

being selected for 10 seconds. It will display 「PTY」 in PTY Group Selection Mode.

If you touch the FOLDER UP key in PTY Group Selection Mode, PTY group will be 1 step up.

If you touch the FOLDER DOWN key in PTY Group Selection Mode, PTY group will be 1 step down.

Only the display will change by touching the FOLDER UP or FOLDER DOWN key, PTY Group will not. (The

sound will not change, either)

Initial PTY Group is 「ALL PTY」.

■PTY SEEK

If you touch the >> key in PTY Group Selection Mode, it will start to seek up in selected PTY group.

If you touch the << key in PTY Group Selection Mode, it will start to seek down in selected PTY group.

It will keep PTY Group Selection Mode for 10 seconds even if it does not find the station match with the PTY Group.

PTY GROUP Selection Mode will be released by following conditions.

If you do no operation to change PTY for 10seconds. When you turn ACC / POWER OFF. （The last frequency is the frequency when released.） When you go to other source mode. （The last frequency is the frequency when released.） When you switch to other BAND. （The last frequency is the frequency when released.）

Touch the PTY / CAT key

※It will not scan in PTY Group.

User Manual.doc

- 28 / 156 -

５-３-８-１． PTY List

PTY Code PTY Name PTY Code PTY Name

0 NO PTY 16 R&B 1 NEWS 17 SOFT R&B 2 INFORMATION 18 LANGUAGE 3 SPORTS 19 RELIGIOUS MUSIC 4 TALK 20 RELIGIOUS TALK 5 ROCK 21 PERSONALITY 6 CLASSIC ROCK 22 PUBLIC 7 ADULT HITS 23 COLLEGE 8 SOFT ROCK 24 NONE

9 TOP 40 25 NONE 10 COUNTRY 26 NONE 11 OLDIES 27 NONE 12 SOFT 28 NONE 13 NOSTALGIA 29 WEATHER 14 JAZZ 30 EMERGENCY TEST 15 CLASSICAL 31 EMERGENCY

User Manual.doc

- 29 / 156 -

５-３-８-２． PTY GROUP List

No GROUP NAME PTY Code of Objiect

1 ALL PTY 0～30 2 INFO 1～4 3 ROCK 5、6 4 SOFT 7、8、12 5 TOP 40 9 6 COUNTRY 10 7 OLDIES 11、13 8 JAZZ 14

9 CLASSICAL 15 10 R & B 16、17 11 RELIGIOUS 19、20 12 MISC 18、21～28、30 13 WEATHER 29

※ PTY Code 31 （EMERGENCY） is included by all the PTY groups.

※ All the PTY GROUP NAME are capital letter.

User Manual.doc

- 30 / 156 -

５-３-９． Switch to PS / RT

Function Display RADIO PS（Program Service Name） and Switch to RT（Radio Text） Display Operation of button

Touch the TEXT key for less than 0.5sec.

Detail

If PS/RT exists, it will switch to display next like following when you touch the TEXT key for less than 0.5sec.

Initial setting is displaying PS.

Display

→

Display

→

Display

frequency

→

Display

It will display maximum 8 characters of PS. It will display maximum 64 characters of RT.

When RT is more than 13 characters, touch the TEXT key for less than 0.5sec to switch to next page.

Operation specification of switch page is same to “Send Page” in CD Chapter. PS displaying will be Right-aligned.

The TEXT key is effective in SCAN mode.

The TEXT key is not effective while adjusting VOLUME / AUDIO / MENU.

User Manual.doc

- 31 / 156 -

５-４． Operation of Satellite Radio(XM)

５-４-１． Call /switch to XM mode

Function Call /Switch to XM mode Operation of button

Touch SAT key

Detail

If you touch the SAT key when it is in other source mode, it will start to receive the channel signal of last band and

last memory of XM.

It is effective when POWER OFF.

The XM band will switch to next like the following when you touch SAT key in XM mode.。

XM1 → XM2 → XM3 → XM1

※ The display will be "SAT" but not "XM".

When receiving channel signal, it will go to the last mode after displaying the channel No. for 3 seconds. Initial setting is BAND1 (XM1) and CHANNEL001 (PREVIEW CHANNEL).

User Manual.doc

- 32 / 156 -

５-４-２． CH UP / DOWN

Function SAT CHANNEL UP/DOWN Operation of button

Turn up/down the TUNE key

Detail

If you turn right the TUNE key in SAT mode, the receiving channel will be one step up.

If you turn left the TUNE key in SAT mode, the receiving channel will be one step down.

If you turn right the TUNE key in the last channel, it will go to the first channel.

If you turn left the TUNE key in the first channel, it will go to the last channel.

User Manual.doc

- 33 / 156 -

５-４-３． CHANNEL UP/DOWN FOR 10 DIGITS

Function SAT CHANNEL UP/DOWN FOR 10 DIGITS Operation of button

Touch the >> / << key for more than 0.5sec (the function only works while touching)

Detail

If you touch the >> key for more than 0.5sec in SAT mode, the receiving channel will be up for 10 digits a second.

If you touch the << key for more than 0.5sec in SAT mode, the receiving channel will be down for 10 digits a

second.

If you touch the >> key in the last channel, it will go to the first channel.

If you touch the << key in the first channel, it will go to the last channel.

The first digits of channel No. will display as "-" while touching. After released, the third digits and the second digits will display the number which is displaying, and the first digits will be

received from the channel number which is the most possible to receive.

The function will be released by the following operation.

ACC OFF/POWER OFF (The last channel will be the channel when release.)

Release the key.

User Manual.doc

- 34 / 156 -

５-４-４． Category Search Mode

Function SAT Category Search Mode (Category up/down)

Operation of button

Touch PTY/CAT key (Category Search Mode ON)

Touch UP & DOWN key (Category up/down)

Turn up/down the TUNE key (CHANNEL UP/DOWN)

Detail

■Category Search Mode If you touch the "PTY/CAT" key in SAT mode, it will go to Category Search Mode and display the name of the

category which is receiving for 10 seconds.

CAT indicator light will be on in Category Search Mode. The name of the catogory you selected will blink in Category Search Mode.

■Category UP/DOWN If you touch the "UP" key in Category Search Mode, the category wich is possible to receive will be one step up. If you touch the "DOWN" key in Category Search Mode, the category wich is possible to receive will be one step down. Only the display will change by touching "UP"/"DOWN" key, the channel will not. (The sound will not change, either) If you turn right the "TUNE"key in Category Search Mode, the channel in the category you selected will be up. If you turn left the "TUNE"key in Category Search Mode, the channel in the category you selected will be down. When channel is up or down, the sound of signal receiving will be output. CH000 (RADIO ID) cannot be selected when touching "UP" or "DOWN".

Category Search Mode will be released by the following operation.

If you do no operation to change category or channel for 10 seconds. ACC OFF/POWER OFF (The last channel will be the channel when release.) If you switch to other source mode. (The last channel will be the channel when release.) If you switch the BAND. (The last channel will be the channel when release.) Touch the "PTY/CAT" key. (Release by KEY ON) Touch the "<<" or ">>" key for more than 0.5sec. (CHANNEL 10 Digits UP/DOWN) Touch the "1～6" key for less than 1.5sec. (Call the preset channel) Touch the "1～6" key for more than 1.5sec. (Write the preset channel)

User Manual.doc

- 35 / 156 -

５-４-５． Call Preset

Function Call SAT Preset Channel Operation of button

Touch the"1"～"6" key for less than 1.5sec

Detail

If you touch "1"～"6" in SAT mode for less than 1.5sec, it will call the channel which is kept as the memory of each

key.

If you call the channel, it will display the number of preset and receiving channel for 3 seconds, and then go to the last

display mode.

If the preset channel is being received/has been received, it will not work when you touch the same key.

The following keys will be effective before KEY OFF. (KEY ON～1.5sec KEY OFF)

VOLUME key

EJECT key

User Manual.doc

- 36 / 156 -

５-４-６． Write Preset

Function SAT Preset Channel Memory Operation of button

Touch the"1"～"6" key for more than 1.5sec

Detail

If you touch "1"～"6" in SAT mode more than 1.5 sec, the receiving channel will be kept as the memory of the key

you touch. If the memory is confirmed, the preset channel number which is displaying will blink for once. If the memory is confirmed, it will output the "BEEP" sound. It will display the number of preset and receiving channel for 3 seconds, and then go to the last display mode. It is available to keep CH000 (RADIO ID) as preset memory.

The following keys will be effective before KEY OFF.

VOLUME key

EJECT key

User Manual.doc

- 37 / 156 -

５-４-７． SCAN

Function SAT SAT Channel SCAN Operation of button

Touch the "SCAN" key

Detail

If you touch "SCAN" key in SAT mode, it will start to scan. It will scan from the next channel for 5 seconds for each when you start it. If it finishes scaning the last channel, it will go on to scan from the first channel. It will scan the channels which are possible for once, and stop at the beginning channel. It will not scan the beginning channel (the ending channel). The channel number will blink for every 500ms in scan mode. If you touch "SCAN"key in Category Search Mode, it will scan in the category you selected.

Scan will be stopped by the following condition.

When you go to other source mode (The last channel will be the channel when release.) When you switch the BAND (The last channel will be the channel when release.) ACC OFF/POWER OFF (The last channel will be the channel when release.) When you turn the"TUNE" key. (CHANNEL UP/DOWN) When you touch the ">>" or "<<"key for more than 0.5sec When you touch the"PTY/CAT" key.

scan in usual --KEY ON and Category Search Mode ON + release scan scan in Category --KEY ON and Category Search Mode OFF + release scan

When you touch the "UP" or "DOWN"key.

scan in usual -- OFF

scan in Category -- KEY ON and Category UP/DOWN when you touch the "1"～"6" for less than 1.5sec.(Call the preset memory) when you touch the "1"～"6" for more than 1.5sec.(write the preset memory) when you touch the "SCAN" key.(Stop at the channel when KEY is ON)

User Manual.doc

- 38 / 156 -

５-４-８． Switch the Title

Function Switch the XM title Operation of button

Touch the "TEXT" key

Detail

If you touch the "TEXT" key, the title will display like following. Default setting is displaying the channel number.

「CH

NUMBER」

→

「CH

NAME」

→ 「TITLE」 → 「NAME」 → 「CATEGORY」 →

「CH

NUMBER」

When you switch the title, it will display [CH NUMBER], [CH NAME], [TITLE], [NAME] and [CATEGORY] 3seconds

for each, and then display the title. 10 characters information will be supported. (8&16 characters will be not) The "TEXT" key will be effective in scan mode. The "TEXT" key will be not effective in Category Search Mode. The "TEXT" key will be not effective while displaying RADIO ID. The "TEXT" key will be not effective while adjusting Volume/Audio/Menu.。

User Manual.doc

- 39 / 156 -

５-４-９． Display RADIO ID

Function Display XM RADIO ID Operation of button

Detail

If you select CH000, it will display RADIO ID. It will display "RADIO ID" for 2 seconds and then display ID for 10 seconds and repeat. If Category Search Mode is ON when it is displaying RADIO ID, the category name will be "----" and blink.

If error occurs when it is displaying RADIO ID, it will go on displaying RADIO ID but not advisory message, even if the

advisory message should be displayed for the error. (Priority: RADIO ID > Advisory Message)

User Manual.doc

- 40 / 156 -

５-４-１０． Advisory Message List

# Error Contents Display Contents Note 1 Antenna cable is removed from the set. ANTENNA For all the channels

2 User password has been changed and cannot receive

new code by XM signal. (The channel mapping has been changed.)

UPDATING It will go to CH001 in 2 seconds.

3 Signal is not enough strong to be received for decoding. NO SIGNAL For all the channels 4 It is not effective when it is receiving signal or decoding.

(when initial power up.)

5 It is not effective when it is receiving signal or decoding.

(When switch channel.)

6 If you select a channel after broadcast ends. OFF AIR It will go to the last channel in 2 seconds. 7 SID is not effective. CH - - -

(3"-")

It will go to CH001 in 2 seconds.

8 The artist's name and title is blank. - - - - - -

(6"-")

※The operation of the Note depends on the situation of XM/Sirius-BB.

User Manual.doc

- 41 / 156 -

５-５． Operation of Satellite Radio （Sirius）

５-５-１． Call/Switch SR Mode

Function Call and switch the sirius Mode Operation of button

Touch the "SAT" key

Detail

If you touch the "SAT" key when it is in other source mode, it will start to receive the channel signal of last band and

last memory of SR. It is effective when POWER OFF. The SR band will switch to next like the following when you touch "SAT" key in SR mode.

SR1 → SR2 → SR3 → SR1

※The display will be "SAT" but not "SR".

When receiving channel signal, it will go to the last mode after displaying the channel No. for 3 seconds. Initial setting is BAND1 (SR1) and CHANNEL184 (PREVIEW CHANNEL).

User Manual.doc

- 42 / 156 -

５-５-２． CH UP / DOWN

・ The same specification as XM.

User Manual.doc

- 43 / 156 -

５-５-３． CHANNEL UP/DOWN FOR 10 DIGITS

・ The same specification as XM.

User Manual.doc

- 44 / 156 -

５-５-４． Category Search Mode

・ The same specification as XM.

User Manual.doc

- 45 / 156 -

５-５-５． Call Preset

・ The same specification as XM.

User Manual.doc

- 46 / 156 -

５-５-６． Write Preset

・ The same specification as XM. ・ But there are some differences as following.

Changed Point

Detail

CH000 and CH255 (RADIO ID) cannot be presetted.

User Manual.doc

- 47 / 156 -

５-５-７． SCAN

・ The same specification as XM.

User Manual.doc

- 48 / 156 -

５-５-８． Switch the Title

Function Switch Sirius title Operation of button

Touch the "TEXT" key for less than 0.5sec.

Detail

If you touch the "TEXT" key, the title will display like following. Initial setting is displaying the channel number.

「CH

NUMBER」

→

「CH

NAME」

→ 「TITLE」 → 「NAME」 → 「CATEGORY」 →

「CH

NUMBER」

When you switch the title, it will display [CH NUMBER],[CH NAME],[TITLE],[NAME] and [CATEGORY] 3seconds for

each, and then display the title. 10 characters information will be supported. (Same as XM. The information more than 10 characters will be truncated) The "TEXT" key will be effective in scan mode. The "TEXT" key will be not effective in Category Search Mode. The "TEXT" key will be effective while displaying RADIO ID. The "TEXT" key will be not effective while adjusting Volume/Audio/Menu.

User Manual.doc

- 49 / 156 -

５-５-９． Display RADIO ID

Function Display RADIO ID Operation of button

Detail

If you choose CH000, it will display RADIO ID. If you choose CH000, it will go to CH255 and display "RADIO ID" for 2 seconds, the upper 8 digits of ID for 5 seconds,

and the lower 4 digits of ID for 5 seconds, and repeat. (depend on Sirius-BB)

For the problem of communication with Sirius-BB, the title data of CH255 will be kept as RADIO ID. Therefore, if you

do not touch the "TEXT" key to switch to display title, it will not display ID. (It will not display channel number.) If Category Search Mode is ON when it is displaying RADIO ID, the category name will be "----" and blink.

User Manual.doc

- 50 / 156 -

５-５-１０． Advisory Message List

Error Contents

（formal display）

Display Contents Note

ANTENNA ERROR （ANTENNA）

ANTENNA

Updating signed channel （UPDATING）

UPDATING

Updating channel map （UPDATING）

UPDATING

Requesting for channel/music information （ACQUIRING）

Signal is not enough strong to receive （ACQUIRING）

Choose unsigned channe （CALL 888-539-SIRI）

CH - - -

Choose unused channel （INVALID CH）

OFF AIR

※ This specification is equivalent to XM's.

User Manual.doc

- 51 / 156 -

５-６． Media HUB Operation

５-６-１． Call /Switch Media HUB Mode

Function Call /Switch Media HUB Mode

Operation of button

Touch the "SAT" key.

Detail

If you touch the "SAT" key when it is in other source mode, it will start to receive the channel signal of last band and

last memory of XM/MEDIA. If you touch the "SAT" key in Media HUB mode, it will switch to next like following.。

XM1/SR1 → XM2/SR2 → XM3/SR3 → MEDIA1 → MEDIA2 → XM1

※When XM/SR1-3 is chosen, it will display SAT1-3.

Common Specification

It is effective when POWER OFF. When you select MEDIA1/ MEDIA2, it will display MEDIA1/ MEDIA2. When receiving channel signal, it will go to the last mode after displaying the channel No. for 3 seconds.

□ The pass key to connect BT Audio is "0000".

User Manual.doc

- 52 / 156 -

５-６-２． Track UP/DOWN

Function Track UP/DOWN Operation of button

Turn the TUNE key

Detail

If you turn right the TUNE key in Media HUB Mode, it will track up.

If you turn left the TUNE key in Media HUB Mode, it will track down.

It will display 001 as CH Number normally.

User Manual.doc

- 53 / 156 -

５-６-３． FF/FB

Function FF/REW Operation of button

Touch the >> / << key for more than 0.5sec. （Operate only when touching.）

Detail

It will wind forward from the playing track if you touch the >> key for more than 0.5sec in Media HUBMode.

It will fast backward from the playing track if you touch the << key for more than 0.5sec in Media HUBMode.

FF/FB will be released by following Operation.

When you turn ACC / POWER OF.

When you release the key.

User Manual.doc

- 54 / 156 -

５-６-４． Browsing Mode

Function Browsing Mode (Presetting Button)

Operation of button

Touch the PTY / CAT key. （CategorySearch Mode ON）

Touch the UP and DOWN key. （Category UP/DOWN）

Detail

■Browsing Mode

If you touch the PTY / CAT key in MediaHub Mode, it will go to Browsing Mode, and display the Browsing Mode name

for selected P.ch for 5sec.

CAT indicator will be ON in Browsing Mode.

■List UP/DOWN

If you touch the UP key in Browsing Mode, the list for selected P.ch will be up.

If you touch the DOWN key in Browsing Mode, the list for selected P.ch will be down.

If you touch the UP or DOWN key, it will start to play the tracks of the selected list in 2 sec. It will keep Browsing

Mode.

Browsing Mode will be released by following operation.

If you do no operation to change the list for 5sec.

Touch the PTY / CAT key.

Turn ACC / POWER OFF. Switch to other mode. Switch to Band.

User Manual.doc

- 55 / 156 -

５-６-５． Select Operation Mode

Function Select Operation Mode Operation of button

Touch the 1 ～ 6 key.

Detail

If you touch the 1 ～ 6 key in MediaHub Mode, it will display the Operation Mode for the key. (It will do the same

action no matter long touch or not.)

・When connect to iPod

1：Settings(Shuffle/Repeat) -> Display ： SETTINGS 2：Playlist Select -> Display ： PLAYLISTS 3：Artist Select -> Display ： ARTISTS 4：Album Select -> Display ： ALBUMS 5：Podcast Select -> Display ： PODCASTS 6：Audiobook Select -> Display ： AUDIOBOOKS

・When connect to USB Storage

1：Settings(Shuffle/Repeat) -> Display ： SETTINGS 2～6：Folder Select -> Display ： FOLDERS

・When connect to BT Audio

1～6：Display the connection device name.

After displaying operation mode for 3sec when call the CH, it will display the title name if you touch the TEXT key.

(Display CH Number.)

The following key will be effective while KEY is ON. (From Key ON to less than 1.5sec. Key OFF.)

the VOLUME key

the EJECT key

User Manual.doc

- 56 / 156 -

５-６-６． Switch to TITLE

Function Switch to TITLE Operation of button

Touch the TEXT key

Detail

If you touch the TEXT key each time in MediaHub Mode, it will switch to next title like following.

Initial setting is displaying “CH NUMBER”. If you switch to next title, it will display 「CH NUMBER」/「CH NAME」/「TITLE」/「NAME」/「CATEGORY」 for 3sec,

then display the title.

「CH

NUMBER」

→

「CH

NAME」

→ 「TITLE」 → 「NAME」 → 「CATEGORY」 →

「CH

NUMBER」

“CH001”

fixed

※1 ※2 ※3 ※4

“CH001”

fixed

※1 When it is in MEDIA1 Mode,

It will display 「USB DEVICE**」 if it is not connected with a device. It will display 「USB iPod****」 if it is connected with a iPod. It will display 「USB MEMORY**」 if it is connected with a USB.

When it is in MEDIA2 Mode,、

It will display 「BT AUDIO****」 if it is not connected with a device. （The display may be different in fact depending on MediaHub.）

※2 It will display the song name when you select P.ch1～4, display podcast when you select P.ch5, and display audiobook name when you select P.ch6. ※3 It will display the information of artist and album when you select P.ch1～4, display podcast when you select P.ch5, and display the information of author when you select P.ch6. ※4 It will display (Such as Shuffle/Repeat, PLAYLIST MODE) the operatin name. ※2～4 It will display 「DETACHED****」 when it is not connected with a device, or display 「ATTACHED****」 when it is connected with a device for 3 seconds, and then display as shown in the above for selected P.ch.

In 3 seconds.

User Manual.doc

- 57 / 156 -

５-７． Operation of DISC

５-７-１． CD LOADING

Function CD Loading Operation of button

Insert CD Disc

Detail

It will start CD LOADING, if you insert a CD disk when there is no CD in it. It will display “CD LOADING” while CD loading. It will display P-TIME and start to play from the first track. It is also effective when POWER is OFF. It is not effective when ACC is OFF basically. （It may be available right after BACKUP EJECT, and so on.）

User Manual.doc

- 58 / 156 -

５-７-２． EJECT CD

Function EJECT CD Operation of button

Touch the EJECT key

Detail

If you touch the EJECT key when there is a CD in, it will eject the CD.

It will keep CD Mode even if it ejects the CD in CD Mode. It will keep the current mode when it eject the CD in other mode except CD Mode. It will go on ejecting even if ACC/POWER is turned off while ejecting. It will go on ejecting even if it goes to other mode while ejecting. If you leave the CD on reload for 15 seconds after it rejects, it will pull in the CD again. It will start to play from the first track after reloads and keep the current mode. It will eject again for twice if it fails ejecting for it is caught or something else.

User Manual.doc

- 59 / 156 -

５-７-３． Playback Object ( CD / USB )

Function The Following Data is Able to be Playbacked Operation

of button

－－－

Detail

Maximum number of folders/files

USB

Memory

Maximum number of folders 512

Maximum number of files in a folder 255

Maximum number of files 130560

Maximum number of folders 255

Maximum number of files in a folder 255

Maximum number of files 510 ※ Maximum 8- layer (include ROOT) Folder is available. ※ In CD Mode, the number of total folders (include ROOT Folder) and total Tracks should be less than 512.

Media that is able to be played

DISCMedia

・Format： Based on ISO9660 LEVEL1,2(MODE1,2 Form1)

USB Memory （Mass Storage）・USB Meomory of Mass Storage Class ・USB Memory that has HUB Class is unable to be played ・USB Memory of ATAP Subclass is unable tobe played

iPod

5G ○

5.5G ○ classic 1G ○ classic 2G ○ nano 1G ×※1 nano 2G ○ nano 3G ○ nano 4G ○ touch 1G ○ touch 2G ○

iPhone

1G(GSM) ○※2 3G ○※2

3G S

Will be

supported in

schedule ※ 1： It may burn in charging for the bug of iPod hardware. It will not be the subject. ※ 2： There are too many bugs of F/W of iPod. Something that depends on those bugs becomes limitations.

User Manual.doc

- 60 / 156 -

Playback Object Files ( CD / USB )

MP3

Based on Layer3 of MPEG 1, 2 & 2.5 Sampling Rate (kHz)：48,44.1,32,24,22.05,16,12,11.025,8 Bit Rate (kbps)：8～320 Variable Bit Rate Supported ID3 Tag (ver1.x,ver2.x)

WMA

Based on Windows Media Audio9 Bit Rate (kbps)：32～192 Unable to Playback DRM Protected Files

AAC

MPEG4 AAC（Based on ISO/IEC 14496-12：2003 + iTune Meta-data Specification） Sampling Rate (kHz)：48,44.1,32,24,22.05,16,12,11.025,8 Bit Rate (kbps)：8～320

Number of Channels：1～2ch ※ Copyright protected files are not able to be play. ※ It does not support Lossless, Professional and Voice of WMA9.

User Manual.doc

- 61 / 156 -

５-７-４． Switch to CD Mode

Function Switch to CD Mode Operation of button

Touch the CD / AUX key

Detail

It will go to CD Mode if you touch the CD / AUX key in other mode except CD Mode.

It will also go to CD Mode when disk roading. It is also effective when POWER is OFF.

It will switch to next mode like following if you touch the CD / AUX key in CD Mode.

CD → USB(iPod) → BT Audio → AUX → MediaHub → CD → ・・・・

※ MediaHub Mode is able to be selected by touching the SAT key.

It will resume playing whe you switch to CD Mode. （RPT/RDM Setting will be kept.）

User Manual.doc

- 62 / 156 -

５-７-５． Playback / Pause (CD / USB)

Function Playback / Pause the Music Operation of button

Steering Controller Operation Only Refer to Steering Controller Operation Specification

Detail

It will be paused if you touch to pause while playing music. It will fade out and become mute, then pause. It will display MUTE when pauses. It will fade in when returns to play mode from pause mode. It will fade in from where it paused. The volume adjustment while fading out/in is based on the current (fading out/in) volume value. Then the fade result will

not effect on the volume, and the volume value you adjustedwill be set It is able to set volume value from “VOL 00” if you adjust the volume when it is in MUTE. The operation of FF / FB, Track( Folder) UP / DOWN will be not available in PAUSE Mode. Pause Mode will be released by the following operation.

When you set volume. When you switch to other mode and return. (Be released when return to the mode) ACC OFF / ON, BackUp OFF / ON

■ When playing CD The Pause Function stops disk rotating in fact. It will fade in after Pause Mode released, but it takes time before the sound comes out because it starts to rotate the

disk.

■ When playing USB ( MSC ) It is same to CD Mode basically.

※ There is no operation to stop rotating for the USB is not a disk.

■ When playing USB ( iPod ) Make iPod PAUSE. It will play from where iPod kept, when Pause Mode released.

User Manual.doc

- 63 / 156 -

５-７-６． TRACK UP / DOWN

Function CDのTRACK UP/DOWN Operation of button

Turn the TUNE key

Detail

It will go to next track if you turn right the TUNE key in CD Mode.

It will play from the beginning of current track if you turn left the TUNE key in CD Mode.

It will go to previous track if you turn TUNE the key in 1sec after operation for changing track.

The operation of TRACK UP/DOWN is not effective while DISC LOADING or READING.

■ When playing CD-DA It will go to the first track in the same disk if you track UP when it is playing the last track in the disk. It will go to the last track in the same disk if you track DOWN when it is playing the first track in the disk. （When it has

played for less than 1sec.）

■ When playing DISC MP3/WMA/AAC It will go to the first track in the same folder if you track UP when it is playing the last track in the folder. It will go to the last track in the same disk if you track DOWN when it is playing the first track in the disk. （When it has

played for less than 1sec.）

User Manual.doc

- 64 / 156 -

５-７-７． FOLDER UP / DOWN （DISC MP3/WMA/AAC）

Function CDのFOLDER UP/DOWN （DISC MP3/WMA/AAC）

Operation of button

Touch the UP or DOWN key.

The Operation of the UP or DOWN key of Steering Controller.

Detail

It will go to the next folder of current folder, if you touch the UP key in CD（DISC MP3/WMA/AAC） Mode.

It will go to the previours folder of current folder, if you touch the DOWN key in CD（DISC MP3/WMA/AAC） Mode.

It will go to the first folder if you touch the UP key when current folder is the last.

It will go to the last folder if you touch the DOWN key when current folder is the first.

The operation of FOLDER UP/DOWN is not effective while DISC LOADING or READING. Long touch of FOLDER UP/DOWN is not effective.

User Manual.doc

- 65 / 156 -

５-７-８． FF / FB

Function CD FF/FB Operation of button

Touch the >> or << key for more than 0.5sec （Action only when touching）

Detail

It will play fast foreward if you touch the >> key for more than 0.5sec in CD Mode.

It will play fast backward if you touch the << key for more than 0.5sec in CD Mode.

BEEP occurs when you touch the >> or << key for more than 0.5sec.

It will display P-TIME when playing fast FF/FB. It will go to the beginning of the next track and keep playing FF when it comes to the end of the track. It will go to the end of the previours track and keep playing FB when it comes to the beginning of the track.

■ When playing CD-DA The speed will be 3 times in the beginning 3 seconds, and then it will up to 10 times when playing FF/FB. It will release FF Mode when it comes to the end of the last track in the disk, and play normally. It will release FB Mode when it comes to the beginning of the first track in the disk, and play normally. Sound comes out when playing FF/FB.

■ When playing DISC MP3/WMA/AAC The speed will be 10 times (fixed) when playing FF/FB. (However, the real speed depends on Bit rate.) It will release FF Mode when it comes to the end of the last track in the folder, and go to the first track of the next

folder and play normally.

It will release FF Mode when it comes to the end of the last track of the last folder in the disk, and go to the first track

of the first folder in the same disk and play normally.

It will release FB Mode when it comes to the beginning of the first track in the folder, and play normally. Sound comes out when playing FF/FB.

FF/FB Mode will be released by following conditions.

When you release the key. When it comes to the first track in the disk. When it comes to the first track in the folde. （Only for DISC MP3/WMA/AAC Mode） When you turn ACC / POWER OFF. When you EJECT（CD） or DISCONNECT(USB).

User Manual.doc

- 66 / 156 -

５-７-９． RPT

Function Repeat Mode of CD Operation of button

Touch the RPT / RDM key for less than 0.5sec.

Detail

■ When playing CD-DA

Repeat Mode will switch to next like following, if you touch the RPT / RDM key for less than 0.5sec.

REPEAT

OFF

→

TRACK

REPEAT

→

REPEAT

OFF

■ When playing DISCMP3/WMA/AAC

Repeat Mode will switch to next like following, if you touch the RPT / RDM key for less than 0.5sec.

REPEAT

OFF

→

TRACK

REPEAT

→

FOLDER REPEAT

→

REPEAT

OFF

Initial Mode is OFF. It will display repeat mode name for 3sec when you switch to a repeat mode, then displays P-TIME. It will return to the

last display. RPT indicator will be on in repeat mode. It will keep the repeat mode even if you turn ACC/POWER OFF, or switch to other source mode.

RPT Mode will be released by the following operation.

Touch the SCAN key. （Key is ON and Scan Mode is ON.）

Touch the RPT / RDM key for less than 0.5sec in TRACK RPT Mode.（Only CD-DA ： Release RPT Mode）

Touch the RPT / RDM key in FOLDER RPT Mode for less than 0.5sec. （Only MP3/WMA/AAC ： Release

RPT Mode）

Touch the RPT / RDM key for less than 0.5sec. （RDM :ON）

EJECT the CD.

User Manual.doc

- 67 / 156 -

５-７-１０． RDM

Function CD RDM Mode Operation of button

Touch the RPT / RDM key for more than 0.5sec.

Detail

■ When playing CD-DA

It will switch to next mode like the following if you touch the RPT / RDM key for more than 0.5sec.

RANDOM

OFF

→

ALL

RANDOM

→

RANDOM

OFF

■ When playing DISC MP3/WMA/AAC

It will switch to next mode like the following if you touch the RPT / RDM key for more than 0.5sec.

RANDOM

OFF

→

FOLDER

RANDOM

→

ALL

RANDOM

→

RANDOM

OFF

Initial setting is OFF. BEEP sounds when you swtich the Mode. If you switch RDM modes, it will display the RDM Mode Name for 3sec, then return to the last display mode. If it has not got the title, it will display P-TIME until it gets the title. RDM indicator is ON in RDM Mode. It will keep RDM Mode setting even if you turn ACC/POWER OFF or go to other source mode.

RDM Mode will be released by following operations.

Touch the UP or DOWN key. （Only MP3/WMA/AAC： FOLDER UP/DOWN (Steering Controller is

OK, too)）

Touch the SCAN key. （Scan Mode is ON when Key is ON.）

Touch the RPT / RDM key for less than 0.5sec. （RPT Mode is ON）

Touch the RPT / RDM key for more than 0.5sec in all the RDM Modes. （Release RDM Mode）

EJECT the CD.

User Manual.doc

- 68 / 156 -

５-７-１１． RPT/RDM Playlist of Track Transition

５-７-１１-１． TRACK RPT （CD-DA,）

RPT Modes Operation # Item/State Specification

TRACK

RPT

Playback normally in RPT Mode

1 Playback Method

Repeat the current track

When it goes to the end of the track

Go to the beginning of the same track Go on repeating

TRACK UP

1 Track UP

Go to the next track Go on repeating

2 Track UP when it is the last track

Go to the first track Go on repeating

TRACK DOWN

Track DOWN （ playing for more than 1sec ）

Go to the beginning of the same track Go on repeating

Track DOWN （ playing for less than 1sec ）

Go to the previours track Go on repeating

Track DOWN when it is the first track （playing for less than 1sec）

Go to the last track Go on repeating

FF 1 Play FF until it reaches the end

Go to the beginning of the same track Release FF Mode Go on repeating

FB 1

Play FB until it reaches the beginning

Go to the beginning of the same track Release FB Mode Go on repeating

User Manual.doc

- 69 / 156 -

５-７-１１-２． ALL RDM（CD-DA）

RDM Mode Operation # Item/State Specification

ALL

RDM

Playback normally

in RDM Mode

1 RDM extraction Method

Playback the track extracted from all the tracks in media by RDM

When it goes to the end

of current track

Extract the next track from all the tracks in media by RDM Go on RDM playing

TRACK UP 1 Track UP

Extract the next track from all the tracks in media by RDM Go on RDM playing

TRACK DOWN 1 Track DOWN

Go to the beginning of the same track No track transition Go on RDM playing

FF 1

Play FF until it reaches the end

Extract the next track from all the tracks in media by RDM Release FF Mode Go on RDM playing

FB 1

Play FB until it reaches the beginning

Go to the beginning of the same track Release FB Mode Go on RDM playing

User Manual.doc

- 70 / 156 -

５-７-１１-３． TRACK RPT （DISC MP3/WMA/AAC）

RPT Mode Operation # Item/State Specifiction

TRACK

RPT

Playback normally in RPT Mode

1 Repeat Method

Repeat the current track

When it goes to the end of the track

Go to the beginning of the same track Go on repeating

TRACK UP

1 Track UP

Go to the next track Go on repeating

Track UP when it is the last

trackin the folder

Go to the first track in the same folder Go on repeating

TRACK DOWN

Track DOWN （playing for more than 1sec）

Go to the beginning of the same track Go on repeating

Track DOWN （playing for less than 1sec）

Go to the previours track Go on repeating

Track DOWN when it is the first track in the folder （ playing for less than 1sec）

Go to the last track in the same folder Go on repeating

FOLDER UP 1 Folder UP

Go to the first track of the next folder Go on repeating

FOLDER DOWN 1 Folder DOWN

o to the first track of the previours folder Go on repeating

FF 1 Play FF until it reaches the end

Go to the beginning of the same track Release FF Mode Go on repeating

FB 1

Play FB until it reaches the beginning

Release FB Mode Go on repeating

User Manual.doc

- 71 / 156 -

５-７-１１-４． FOLDER RPT （DISC MP3/WMA/AAC）

RPT Mode Operation # Item/State Specification

FOLDER

RPT

Playback normally

in RPT Mode

1 Repeat Method

Repeat the tracks in current folder

When it goes to the last track in

thefolder

Go to the first track in the same folder Go on repeating

TRACK UP

1 Track UP

Go to the next track in the same folder Go on repeating

Track up when it is the last track in

the folder

Go to the first track in the same folder Go on repeating

TRACK DOWN

Track DOWN （playing for more than 1sec）

Go to the beginning of current track Go on repeating

Track DOWN （playing for less than 1sec）

Go to the previours track Go on repeating

Track down when it is the first

trackin the folder

（playing for less than 1sec）

Go to the last track in the same folder Go on repeating

FOLDER UP 1 FOLDER UP

Go to the first track of the next folder Go on repeating

FOLDER DOWN 1 FOLDER DOWN

Go to the first track of the previours folder Go on repeating

1 Play FF until it reaches the end

Go to the next track Keep FF Mode Go on repeating

Play FF until it reaches the end of

the last track in the folder.

Go to the first track in the same folder Release FF Mode Go on repeating

Play FB until it reaches the beginning

Go to the previours track Keep FB Mode Go on repeating

Play FB until it reaches the beginning of the first track in the folder

Release FB Mode Go on repeating

User Manual.doc

- 72 / 156 -

５-７-１１-５． FOLDER RDM （DISC MP3/WMA/AAC）

RDM Mode Operation # Item/State Specification

FOLDER

RDM

Playback normally in RDM Mode

1 RDM extraction Method

Playback the track extracted from all the tracks in the folder by

RDM

When it goes to the end of the track

Extract the next track from all the tracks in the folder by RDM Go on RDM playing

When it goes to the end of the last track in the folder （The last track in RDM）

Go to the next folder Extract the track from all the tracks in the next folder by RDM Go on RDM playing

TRACK UP

1 Track UP

Extract the next track from the same folderby RDM Go on RDM playing

Track UP when it is the last track in the folder （The last track in RDM）

Extract the next track from the same folderby RDM

（RDM the folder again）

Go on RDM playing

TRACK DOWN 1 Track DOWN

Go to the beginning of the same track Go on RDM playing

FOLDER UP 1 Folder UP

Release RDM Mode Playback the first track of the next folder normally

FOLDER DOWN 1 Folder DOWN

Release RDM Mode Playback the first track of the previours folder normally

Play FF until it reaches the end

Extract the next track by RDM Keep FF Mode Go on RDM playing

Play FF until it reaches the end of the last track in the folder （The last track in RDM）

Extract the next track from the same folderby RDM

（RDM the folder again）

Keep FF Mode Go on RDM playing

FB 1

Play FB until it reaches the beginning

Playback from the beginning of the same track Release FB Mode Go on RDM playing

User Manual.doc

- 73 / 156 -

５-７-１１-６． ALL RDM（DISC MP3/WMA/AAC）

RDM Mode Operation # Item/State Specification

ALL

RDM

Playback normally in RDM Mode

1 RDM extraction Method

Plackback the track extracted from all the tracks in media by

RDM

※ It will not play the same track continued, but may play

again when the next ends because it does not caculate all the folders in media, just extracts the next track each time in a simple way.

When it goes to the end

of the track

Extract the next track from media by RDM Go on RDM playing

TRACK UP 1 Track UP

Extract the next track from media by RDM Go on RDM playing

TRACK DOWN 1 Track DOWN

Go to the beginning of current track No track transition Go on RDM playing

FOLDER UP 1 Folder UP

Release RDM Mode Playback the first tracck of the next folder normally

FOLDER DOWN 1 Folder DOWN

Release RDM Mode Playback the first tracck of the previours folder normally

FF 1

Play FF until it reaches the end

Extract the next track media by RDM Keep FF Mode Go on RDM playing

FB 1

Play FB until it reaches the beginning

Playback from the beginning of the same track Release FB Mode Go on RDM playing

User Manual.doc

- 74 / 156 -

５-７-１２． SCAN

Function CD Scan Mode Operation of button

Touch the SCAN key （Action when Key is ON）

Detail

■ When playing CD-DA

It will switch to next scan mode like following if you touch the SCAN key each time.

It will play each track in the disk for 10sec in scan mode. It will go to the first track and keep the scan mode when it finishes playing the last track in the disk in scan mode.

SCAN

OFF

→

DISC

SCAN

→

SCAN

OFF

■ When playing DISC MP3/WMA/AAC

It will switch to next scan mode like following if you touch the SCAN key each time.

It will start to play each track in the folder for 10sec from the next track when you switch to FOLDER SCAN Mode. It will go to the first track and keep the scan mode when it finishes playing the last track in the folder in FOLDER SCAN

Mode.

SCAN

OFF

→

FOLDER

SCAN

→

SCAN

OFF

Initial setting is OFF. It will display the SCAN Mode name for 3sec, then display P-TIME if you switch to scan mode. It will scan from the next track to the track when you operate the folder. It will scan around once in the DISK/FOLDER, and stop when it goes to the track before scan starts.

SCAN Mode will be released by following operations.

Turn ACC/POWER OFF. Switch to other source mode.

Turn the TUNE key. （TRACK UP/DOWN）

Touch the >> or << keyfor more than 0.5sec. （FF/FB）

Touch the UP or DOWN key. （Only DISC MP3/WMA/AAC ： FOLDER UP/DOWN）

Touch RPT / RDM key for less than 0.5sec. （RPT Mode ON）

Touch the RPT / RDM key for more than 0.5sec. （RDM Mode ON）

Touch the SCAN key. （SCAN Mode relleased）

User Manual.doc

- 75 / 156 -

５-７-１２-１． DISC SCAN （CD-DA）

SCAN Mode Operation # Item/State Specification

DISC

SCAN

Playback normally in Scan Mode

1SCAN

Playback each track for 10sec from the next track. Go to the first track of the DISC if current track is the last.

When finishes playing for 10sec.

Playback the next track for 10sec. Go to the first track of the DISC if current track is the last. Keep SCAN Mode.

When returns to the track when SCAN begins

Playback normally. Release SCAN Mode

TRACK UP 1 Track UP

Playback the next track normally. Go to the first track of the DISC if current track is the last. Release SCAN Mode

TRACK DOWN 1 Track DOWN

Go back to the beginning of the same track. Release SCAN Mode

FF 1 Play FF

Play FF. Release SCAN Mode

FB 1 Play FB

Play FB. Release SCAN Mode

User Manual.doc

- 76 / 156 -

５-７-１２-２． FOLDER SCAN （DISC MP3/WMA/AAC）

SCAN Mode Operation # Item/State Specification

FOLDER

SCAN

Playback normally in Scan Mode

1SCAN

Playback each track for 10sec from the next track. Go to the first track of the FOLDER if current track is the last.

When finishes playing for 10sec.

Playback the next track for 10sec. Go to the first track of the FOLDER if current track is the last. Keep SCAN Mode.

When returns to the track when SCAN begins

Playback normally. Release SCAN Mode

TRACK UP 1 Track UP

Playback the next track. Go to the first track of the FOLDER if current track is the last. Release SCAN Mode

TRACK DOWN 1 Track DOWN

Go to the beginning of the same track. Release SCAN Mode

FOLDER UP 1 Folder UP

Playback the first track of the next folder normally Release SCAN Mode

FOLDER DOWN 1 Folder DOWN

Playback the first track of the previours folder normally Release SCAN Mode

FF 1 Play FF

Play FF Release SCAN Mode

FB 1 Play FB

Play FB Release SCAN Mode

User Manual.doc

- 77 / 156 -

５-７-１３． Switch to TITLE （CD/USB）

Function Switch to TITLE （CD/USB） Operation of button

Touch the TEXT key for less than 0.5

Detail

It will switch to next title mode like following if you touch the TEXT key for less than 0.5sec in CD Mode.

Initial setting is displaying P-TIME. It will go to display the last mode when connects next time even when ACC（POWER） OFF/ON, NO DISC/NO

DEVICE.

It will display the mode name for 3sec then display the title if you switch to Displaying TITLE Mode. It will display [NO TITLE] if there is no title.

The TEXT key is effective in every trick play mode.

The TEXT key is not effective when displaying VOLUME / AUDIO / MENU / iPod LIST screen.

It will keep the last display mode for each media mode.（Such as display mode of ARTIST TITLE, ALBUM TITLE.）

■ When displaying CD-DA It will switch to next title mode like following no matter whether there is CD-TEXT or not when playing CD-DA.

P-TIME →

DISC

TITLE

→

ARTIST

TITLE

→

TRACK

TITLE

→ P-TIME

It will display TRACK ARTIST for ARTIST TITLE, if there is no TRACK ARTIST it display DISC ARTIST instead. It

willdisplay [NO TITLE] when there is neither TRACK ARTIST nor DISC ARTIST.

■ When playing DISC/MSC MP3/WMA/AAC It will switch to next title display like following when playing DISC/MSC MP3/WMA/AAC. It will display [ROOT] for folder name if you select ROOT folder (the top layer). It will also display the extension when displys FILE TITLE.

P-TIME →

FOLDER

TITLE

→

FILE

TITLE

→ P-TIME

■ When playing iPod It will display the information of the track playing now. It will display the conent which is got from iPod.

P-TIME →

ARTIST

TITLE

→

ALBUM

TITLE

→

SONG

TITLE

→ P-TIME

※ It does not support to display chapter name.

User Manual.doc

- 78 / 156 -

５-７-１４． Send PAGE （CD/USB）

Function Send CD / USB TITLE Displaying PAGE （2-line display） Operation of button

Touch the TEXT key for more than 0.5sec

Detail

There are 2 display modes. One displays the lower line only (1-line Display Mode), the other displays both upper and

Lower lines (2-line Display Mode).

Initial mode is 1-line Display Mode.

・ 1-line Display Mode

It displays Mode name, DISC number, FOLDER number, TRACK number and CHANNEL number on the Upper line of

screen.

It displays P-TIME, Frequency or Title on the Lower line of screen.

It will switch to next display if you touch the TEXT key for less than 0.5sec.

It will display error message instead when error occurs. （Refer to Displaying Specification for displaying error

message.）

・ 2-line Display Mode

2-line Display Mode is the mode to display the title name that more than 16 characters for 2 lines.

It will go to 2-line Display Mode if you touch the TEXT key for more than 0.5sec in 1-line Display Mode.

It will not go to 2-line Display Mode if there are less than 16 characters in the title.

It will display the beginning 15 characters of title string on the Upper line and the 16rd to 30th characters on the Lower

line.

It will turn to next page if you touch the TEXT key for more than 0.5sec in 2-line Display Mode when there are more

than 31 characters in the title.

However, the number characters which would be turned up depends on the conent of the title.

It will return to 1-line Display Mode if you touch the TEXT key for more than 0.5sec in 2-line Display Mode when it

is displaying the last page.

It does not break words.

2-line Display Mode will be released by the following condition.

When you touch the TEXT key for more than 0.5sec when it is displaying the last page.

No operation for 10sec. When it goes to a track that there is less than 16 characters in title name.

User Manual.doc

- 79 / 156 -

５-７-１５． Display ERROR Message (CD Mode)

Function

Display ERROR Message

Operation of button

Detail

It is available to switch modes or adjust AUDIO even when error occurs. The displaying of ERROR Message will be released when switch modes. It will not display ERROR Message even if error occurs when ejecting in other mode except CD Mode. Displaying Priority will be the following: 「Mechanism ERROR > Forcus ERROR > DISC ERROR > Format ERROR」.

・ Mechanism ERROR

When Mechanism ERROR occurs in CD. When it cannot EJECT DISC. It will display “PUSH EJECT” when Mechanism ERROR occurs.

・ Forcus ERROR

DISC stops when it read TOC. There is a flaw in the DISC. It will display “CHECK DISC” when Forcus ERROR occurs.

・ DISC ERROR

Insert the DISC uncrrectly. It is a dirty DISC. Insert a unwritten CD-R TOC information is damaged. It will display “CHECK DISC” when DISC ERROR occurs.

・ Format ERROR

Sound will not come out if it is unable to decode. It will take 3sec to detect the file that unable to decode, and keep the state for 5sec then goes to the next file. It will display nothing when Format ERROR occurs.

・ No File ERROR

There is no DISC MP3/WMA/AAC file in the DISC. It will display “CHECK DISC” when No File ERROR occurs.

・ Digital Rights Mana gement （DRM）

It will not come out sound if the DRM of WMA of the playing file is ON. It will take 3sec to detect DRM, and keep the state for 5sec then goes to the next file. It will display nothing when DRM occurs.

User Manual.doc

- 80 / 156 -

５-８． Operation of USB

５-８-１． USB CONNECT

Function Connect to USB Media (1 USB Drive) Operation

of button

Connect to USB Media with USB Concave shape A Connector.

Detail

It will not switch to USB Mode automatically even if it connects to USB Media.

・ In USB Mode

It will display [NO DEVICE] if it connects to nothing with USB connector. It will display [USB READING] until it gets ready to play the device that connected. It will display [USB READING] no matter what it is connecting to, iPod, MSC or unsuport device.

・ Connected to MSC(Mass Storage Class) in USB Mode

It will play from the first track of the first folder when it finishes USB READING. （TOP PLAY） It will play the resume when reconnected to the same MSC. Resume information will be scraped each time it connects to an iPod.

・ Connected to iPod in USB Mode

It will start to play from where controlled by iPod when it finishes USB READING. （Depends on iPod） It will start to play from the first track of song category after it finishes USB READING when it is connected to an

iPod that is stopped.

It will start to play from the first track of song category after it finishes USB READING when it is connected to an

iPod that is playing VIDEO.

It will be ALL RPT Mode if it is connected in RPT Mode. It sets ALL RPT automaitically by USB Control Comand. It supports audio only for iPod. （Video is not supported.） The Logo of SUBARU will be displayed on iPod screen when connected.

※ You cannot do an operation on iPod while connected. However, Touch Pannel Model iPod will be effective.

・ Others

It is able to connect to an iPod when ACC is OFF, but it cannot recognaize the device. Response latency for USB DEVICE will be 15sec when turn ACC OFF/ON. It will display [USB READING] in the

time even if nothing connected with USB connector. （Specification for bad reaction device.）

User Manual.doc

- 81 / 156 -

５-８-２． USB DISCONNECT

Function Disconnect USB Device Operation

of butto n

Disconnect USB Connector by hand

Detail

It will keep USB Mode when you disconnect USB device in USB Mode. It will keep current Mode when you disconnect USB device in other mode except USB Mode. It will start USB Mode when you turn POWER ON next time if you disconnect the device when POWER is OFF. It will work like following if you replace the connected device when POWER(ACC) is OFF.（Destination for All Models）

If you replace the connected device with an iPod, it will start to play from where controlled by the iPod. If you replace the connected device with a MSC (Even it is the same MSC.), it will start to play from top.

It will display [USB READING] and start USB Mode when you turn POWER ON next time if you disconnect the device

in USB Mode when POWER is OFF. If no device detected it will go to NO DEVICE. （It takes 15sec to confirm NO

DEVICE.） Trickplay Mode will be released if you disconnect the USB device. Trickplay Mode will be kept when you turn ACC on next time if you disconnectand connect the same USB device When

ACC is OFF.

User Manual.doc

- 82 / 156 -

５-８-３． Playback Object (CD/USB)

Refer to Playback Object (CD/USB).

User Manual.doc

- 83 / 156 -

５-８-４． Switch to USB Mode

Function Switch to USB Mode Operation of button

Touch CD / AUX key （Action when Key is ON.）

Detail

Touch the CD / AUX key to switch to USB Mode when in other source mode.

It is effective when POWER is OFF.

It will switch to next source mode like following if you touch the CD / AUX key in USB Mode.

CD → USB(iPod) → BT Audio → AUX → MediaHub → CD → ・・・・

It will play resume if you switch to USB Mode when it is connected to Memory or iPod. （RPT/RDM Mode is kept.）

User Manual.doc

- 84 / 156 -

５-８-５． Play / Pause (CD / USB)

Please refer to CD Mode for it includes the operation.

User Manual.doc

- 85 / 156 -

５-８-６． TRACK UP / DOWN （MSC）

・ It is the same to CD（DISC MP3/WMA/AAC When playing）.

User Manual.doc

- 86 / 156 -

５-８-７． FOLDER UP / DOWN （MSC）

・ It is the same to CD（DISC MP3/WMA/AAC When playing）.

User Manual.doc

- 87 / 156 -

５-８-８． TRACK UP / DOWN （iPod）

Function Index UP/DOWN ※It display trck index in iPod. Operation of button

Turn the TUNE key

Detail

It will go to the next index if you turn right the TUNE key in iPod Mode.

It will go to the beginning of the playing ndex if you turn left the TUNE key in iPod Mode.

It will go to the previours index if you turn left the TUNE key when it plays the index for less than 1sec. However, the

timing may be different for different model or F/M Version because of that going to previours track or not is controlled by iPod.

It is not available to operate in READING.

User Manual.doc

- 88 / 156 -

５-８-９． CHAPTER UP / DOWN （iPod）

Function CHAPTER UP/DOWN

Operation of button

Turn the TUNE key

It is possible to operate in Podcasts or Audio Books. (There is ST with or without chapter for different content ) It will track up if you chapter up when it is the last chapter. It will track down if you chapter down when it is the first chapter.

Detail

It will go to the next chapter if you turn right the TUNE key in a file with chapters in iPod mode.

It will go to the beginning of the chapter if you turn left the TUNE key in a file with chapters in iPod mode.

It will go to the previours chapter if you turn left the TUNE key when it palys the chapter for less than 1sec.

It will go to the next index if you turn right the TUNE key when it is the last chapter.

It will go to the previours index if you turn left the TUNE key when it is the first chapterand it has played for less than

1sec. It is not available to oprate when READING.

User Manual.doc

- 89 / 156 -

５-８-１０． FF / FB （MSC）

・ It is the same to Operation Specification of CD（DISC MP3/WMA/AAC When playing）.

User Manual.doc

- 90 / 156 -

５-８-１１． FF / FB （iPod）

・ Track is discripted as Index in iPod.

Function

Playing FF/FB of iPod Sound comes out when playing FF/FB. （Sound comes out or not depending on the condition of iPod.）

Operation

of butto n

Touch the >> or << key for more than 0.5sec. （Action only while touching.）

Detail

It will play FF if you touch the >> key fot more than 0.5sec in iPod Mode.

It will play FB if you touch the << key fot more than 0.5sec in iPod Mode.

BEEP sounds when confirms the key operation. It will display P-TIME in playing FF/FB. It will not display P-TIME but keep displaying menu if it is in iPod MENU Mode. It will go to the next index and released from FF mode if it plays FF in the end of the index. （Depending on Specification

of iPod.） It will be released from FB mode and start to play if it plays FB at the beginning of the index. （Depending on

Specification of iPod.） The speed of playing FF/FB is depending on Specification of iPod for it is controlled by iPod.

FF/FB mode will be released by following conditions.

When you release the key. When you switch to other source mode. Whe you disconnect the device. When you turn ACC / POWER OFF.

User Manual.doc

- 91 / 156 -

５-８-１２． RPT （MSC）

Function RPT Mode of MSC Operation of button

Touch the RPT / RDM key for less than 0.5sec.

Detail

It will switch to next RPT mode like following if you touch the RPT / RDM key for less than 0.5sec each time.

REPEAT

OFF

→

TRACK

REPEAT

→

FOLDER REPEAT

→

REPEAT

OFF

Initial setting is OFF. It will display the RPTmode name for 3sec, then trturns to the last display (such as ARTIST NAME, P-TIME) when you

switch to RPT Mode. RPT indicator will be on in RPT Mode. It will keep RPT Mode when you turn ACC/POWER OFF or switch to other source mode.

RPT Mode will be released by following operation.

Touch the SCAN key. （SCAN Mode will be ON when Key is ON）

Touch the RPT / RDM key for less than 0.5sec in FOLDER RPT Mode. （RPT Mode released.）

Touch the RPT / RDM key for more than 0.5sec. （RDM Mode will be ON）

Disconnect the media device. （Replaced with other media device.）

User Manual.doc

- 92 / 156 -

５-８-１３． RDM （MSC）

Function RDM Mode of MSC Operation of button

Touch the RPT / RDM key for more than 0.5sec.

Detail

It will switch to next RDM mode like following if you touch the RPT / RDM key for more than 0.5sec each time.

RANDOM

OFF

→

FOLDER

RANDOM

→

ALL

RANDOM

→

RANDOM

OFF

Initial setting is OFF. BEEP sounds when you switch to RDM Mode. It will display the RDM mode name for 3sec, then trturns to the last display when you switch to RDM Mode. It will keep displaying P-TIME until it gets the title. RDM Indicator will be on in RDM Mode. It will keep RDM Mode when you turn ACC/POWER OFF or switch to other source mode.

RDM Mode will be released by following operation.

Touch the UP or DOWN key.

Touch the SCAN key. （SCAN Mode will be ON when Key is ON）

Touch the RPT / RDM key for less than 0.5sec. （RPT Mode will be ON）

Touch the RPT / RDM key for more than 0.5sec in ALL RDM Mode. （RDM Mode released）

Disconnect the media device. （Replaced with other media device.）

User Manual.doc

- 93 / 156 -

５-８-１４． RPT/RDM Playlist of Track Transition

５-８-１４-１． TRACK RPT （MSC）

・ Omitted for the same Operation Specification to TRACK RPT （DISC MP3/WMA/AAC）.

User Manual.doc

- 94 / 156 -

５-８-１４-２． FOLDER RPT （MSC）

・ Omitted for the same Operation Specification to FOLDER RPT （DISC MP3/WMA/AAC）.

User Manual.doc

- 95 / 156 -

５-８-１４-３． FOLDER RDM（MSC）

・ Omitted for the same Operation Specification to FOLDER RDM （DISC MP3/WMA/AAC）.

User Manual.doc

- 96 / 156 -

５-８-１４-４． ALL RDM（MSC）

・ Omitted for the same Operation Specification to ALL RDM（DISC MP3/WMA/AAC）.

User Manual.doc

- 97 / 156 -

５-８-１５． SCAN

Function SCAN Mode of USB（MSC Only） Operation of button

Touch the SCAN key.

Detail

It will switch to next SCAN mode like following if you touch the SCAN key each time.

It will start to play all the tracks in the folder for 10sec each from the next track if you switch to FOLDER SCAN Mode. It will go to the first track and go on scaning when it is the end of the last track in the folder in FOLDER SCAN Mode.

SCAN

OFF

→

FOLDER

SCAN

→

SCAN

OFF

Initial setting is OFF. It will display SCAN Mode name for 3sec, then displays P-TIME when you switch to SCAN Mode. It will go to the first track when it finishes scaning the last track in the folder. It will scan the folder around once and stops when it returns to the track before it starts.

SCAN Mode will be released by following operation.

Turn ACC / POWER OFF. Switch to other source mode.

Turn the TUNE key. （Track UP / DOWN）

Touch the >> or << key for more than 0.5sec. （FF / FB）

Touch the UP or DOWN key. （DISC / MSC MP3 / WMA / AAC Only ： FOLDER UP / DOWN）

Touch the RPT / RDM key for lessthan 0.5sec. （RPT Mode ON）

Touch the RPT / RDM key for more than 0.5sec. （RDM ON）

Touch the SCAN key. （SCAN Mode released when Key is ON）

User Manual.doc

- 98 / 156 -

５-８-１６． RPT （iPod）

Function

RPT Mode of iPod Initial setting may be different depending on the RPT setting of iPod when connecting. It is available to set RPT and Shuffle together depending on the Specification of iPod.

Operation of button

□ Touch the RPT / RDM key for less than 0.5sec.

Detail

It will switch to next RPT Mode like following if you touch the RPT / RDM key for less than 0.5sec.

⇔

Initial setting is ALL REPEAT. It will display RPTMode name for 3sec, then returns to the last display (Such as ARTIST TITLE, P-TIME) when you

switch to RPT Mode. RPT Indication will be ON in RPT Mode. IPod will keep the setting even if it is disconnected.

※ The setting may be relesed depending on the Specification.

It is not available to set RPT when playing Audiobook.

ALL

REPEAT

SONG

REPEAT

User Manual.doc

- 99 / 156 -

５-８-１７． Shuffle （iPod）

Function

Shuffle Mode of iPod It will display “RANDOM” or “RDM”instead of “Shuffle” for there are too many character. ShuffleFunction is carried on by iPod.

It is available to set RPT and SHUFFLE together depending on Specification of iPod. It will act like following depending on Specification of iPod.

SONG Shuffle ： Reorder the playing order in selected DB by random. ALBUM Shuffle ： Reorder the playing order of album unit in selected DB by random.

Operation of button

Touch the RPT / RDM key for more than 0.5sec.

Detail

It will switch to next Shuffle Mode like following if you touch the RPT / RDM for more than 0.5sec.

Shuffle

OFF

→

ALBUM

Shuffle

→

SONG

Shuffle

→

Shuffle

OFF

Initial setting is depending on the shuffle setting of the connecting iPod. BEEP counds when you switch to next shuffle mode. It will display Shuffle name for 3sec then returns to the last display when you switch to Shuffle Mode. It will display P-TIME until it gets the title. RDM indicator is on in Shuffle Mode. It will keep Shuffle Mode even if you turn ACC/POWER OFF or switch to other source mode.

※ It may be released depending on iPod Specification.

IPod will keep the shuffle setting even it is disconnected.

Shuffle Mode will be released by following operation.

Touch the RPT / RDM key for more than 0.5sec in SONG Shuffle Mode.

It is not available to set Shuffle Mode when playing Audiobook / Podcasts. RDM indicator will be OFF when playing Audiobook / Podcasts.

User Manual.doc

- 100 / 156 -

５-８-１８． RPT/Shuffle Playlist of Track Transition

５-８-１８-１． SONG RPT （iPod）

※ The following is the reference only for the action is controlled by iPod. There may be different actions for different iPod model or F/M Specification.

※ACTION FOR REFERENCE※

RPT Mode Operation # Item/State Specification

SONG

RPT

Play normally in RPT Mode

1 Repeat Method

Repeat the current index.

When it goes to the end of current track.

Go to the beginning of current index. Go on repeating

Track UP

1 Track UP

Go to the beginning of current index. Go on repeating

Track up when it is the last track in the DB

Go to the beginning of current index. Go on repeating

Track DOWN

Track DOWN （Has played for more than 1sec）

Go to the beginning of current index. Go on repeating

Track DOWN （Has played for less than 1 sec）

Go to the beginning of current index. Go on repeating

FF 1 Play FF until it reach the end

Go to the beginning of current index. FF Mode Released Go on repeating

FB 1

Play FB until it reach the beginning

FB Mode Released Go on repeating

Clarion SUBARU PF-3380I-A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
