Thank you for purchasing this Clarion product.

∗ Please read this owner’s manual in its entirety before operating this unit. ∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment). ∗ Check the contents of the enclosed warranty card and keep it carefully with this manual. ∗ This manual includes the operating procedures of the CD changer, DAB and TV tuner connected via

the CeNET cable. The CD changer and TV tuner have their own manuals, but no explanations for operating them are described.

CAUTIONS:

This appliance contains a laser system and is classified as a “CLASS 1 LASER PRODUCT”. To use this model properly, read this Owner’s Manual carefully and keep this manual for your future reference. In case of any trouble with this player, please contact your nearest “AUTHORIZED service station”. To prevent direct exposure to the laser beam, do not try to open the enclosure.

!CAUTIONS

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED IN THE OWNER’S MANUAL MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

ADVARSEL.

Denne mærking er anbragt udvendigt på apparatet og indikerer, at apparatet arbejder med laserstråler af klasse 1, hvilket betyder, at der anvendes laserstråler af svageste klasse, og at man ikke på apparatets yderside kan blive udsat for utilladelig kraftig stråling.

APPARATET BØR KUN ÅBNES AF FAGFOLK MED SÆRLIGT KENDSKAB TIL APPARATER MED LASERSTRÅLER!

Indvendigt i apparatet er anbragt den her gengivne advarselsmækning, som advarer imod at foretage sådanne indgreb i apparatet, at man kan komme til at udsaætte sig for laserstråling.

Bottom View of Main Unit

OBS!

Apparaten innehåller laserkomponenten som avger laserstrålning överstigande gränsen för laserklass 1.

VAROITUS

Suojakoteloa si saa avata. Laite sisältää laserdiodin, joka lähettää näkymätöntä silmille vaarallista lasersäteilyä.

2 DXZ958RMC

Contents

1. PRECAUTIONS............................................................................................................................. . 3

Sloping Console .............................................................................................................................. 4

Handling Compact Discs ................................................................................................................ 4

2. CONTROLS ..................................................................................................................................... 5

3. NOMENCLATURE ......................................................................................................................... 6

Names of the Buttons and their Functions ..................................................................................... 6

Operations when External Equipment is Connected to this Unit ..................................................... 7

Touch Panel Buttons ....................................................................................................................... 8

Touch Panel Operations .................................................................................................................. 9

4. DCP .............................................................................................................................................. 10

5. REMOTE CONTROL ..................................................................................................................... 11

Inserting the Battery ...................................................................................................................... 11

Functions of Remote Control Unit Buttons ................................................................................... 12

6. OPERATIONS ............................................................................................................................... 13

Basic Operations .......................................................................................................................... 13

Radio Operations ........................................................................................................................... 17

RDS Operations ............................................................................................................................ 20

CD/MP3/WMA Operations ............................................................................................................ 25

MUSIC CATCHER Operations ....................................................................................................... 30

Sound Adjustment ......................................................................................................................... 32

Common Operations...................................................................................................................... 43

7. OPERATIONS OF ACCESSORIES ............................................................................................. 53

CD Changer Operations ............................................................................................................... 53

TV Operations .............................................................................................................................. 56

Digital Radio/DAB Operations ....................................................................................................... 59

8. IN CASE OF DIFFICULTY ........................................................................................................... 62

9. ERROR DISPLAYS ....................................................................................................................... 64

10. SPECIFICATIONS ......................................................................................................................... 65

English

1. PRECAUTIONS

1. This unit is applicable for on-road 4 wheel vehicle purpose only. Use for tractor, fork truck, bulldozer, off road vehicle, 2 or 3 wheel motor bicycle, marine boat or other special purpose vehicle is not appropriate.

2. When the inside of the car is very cold and the player is used soon after switching on the heater, moisture may form on the disc or the optical parts of the player and proper playback may not be possible. If moisture forms on the disc, wipe it off with a soft cloth. If moisture forms on the optical parts of the player, do not use the player for about 1 hour. The condensation will disappear naturally allowing normal operation.

For your safety, do not watch or operate the touch panel while driving.

3. Driving on extremely bumpy roads may cause severe vibration and cause the sound to skip.

INFORMATION FOR USERS:

CHANGES OR MODIFICATIONS TO THIS PRODUCT NOT APPROVED BY THE MANUFACTURER WILL VOID THE WARRANTY.

WARNING

DXZ958RMC 3

Sloping Console

English

This unit uses a SLOPING CONSOLE to make large screen displays possible.

When you use the SLOPING CONSOLE, be sure to close it.

CAUTION

BE CAREFUL NOT TO GET YOUR FINGERS CAUGHT WHEN OPENING AND CLOSING THE SLOPING CONSOLE.

1. For safety’s sake, always close the SLOPING CONSOLE before leaving this unit unused for a prolonged period or switching OFF the ignition key.

If you switch OFF the ignition key with the SLOPING CONSOLE tilted, the SLOPING CONSOLE does not close.

Handling Compact Discs

2. Before the SLOPING CONSOLE closes, there may be a braking sound from the safety mechanism. This is normal.

3. If you move the SLOPING CONSOLE by hand, this may start play. To correct this play, with the power for the unit ON, press the [ button to close the SLOPING CONSOLE.

4. After a disc is ejected, the SLOPING CONSOLE automatically returns to the tilted or closed state. If there is any obstruction when the SLOPING CONSOLE tries to close, the safety mechanism is triggered and the SLOPING CONSOLE returns to the open state. If this happens, remove the obstruction, then press the [

5. To avoid scratching the compact disc, keep the 12 or 8 cm CD level when loading or removing it.

Q] button.

Use only compact discs bearing the

mark.

Do not play heart-shaped, octagonal, or other specially shaped compact discs.

Some CDs recorded in the CD-R/CD-RW mode may not be usable.

Handling

• Compared to ordinary music CDs, CD-R and CD-RW discs are both easily affected by high temperature and humidity and some CD-R and CD-RW discs may not be playable. Therefore, do not leave them for a long time in the car.

• New discs may have some roughness around the edges. If such discs are used, the player may not work or the sound may skip. Use a ball-point pen or the like to remove any roughness from the edge of the disc.

• Never stick labels on the surface of the compact disc or mark the surface with a pencil or pen.

• Never play a compact disc with any cellophane tape or other glue on it or with peeling off marks. If you try to play such a compact disc, you may not be able to remove it from the CD player or it may damage the CD player.

Ball-point pen

Roughness

• Do not use compact discs that have large scratches, are misshapen, cracked, etc. Use of such discs may cause misoperation or damage.

•To remove a compact disc from its storage case, press down on the center of the case and lift the disc out, holding it carefully by the edges.

• Do not use commercially available CD protection sheets or discs equipped with stabilizers, etc. These may damage the disc or break the internal mechanism.

Storage

• Do not expose compact discs to direct sunlight or any heat source.

• Do not expose compact discs to excess humidity or dust.

• Do not expose compact discs to direct heat from heaters.

Cleaning

•To remove fingermarks and dust, use a soft cloth and wipe in a straight line from the center of the compact disc to the circumference.

• Do not use any solvents, such as commercially available cleaners, anti-static spray, or thinner to clean compact discs.

• After using special compact disc cleaner, let the compact disc dry off well before playing it.

4 DXZ958RMC

2. CONTROLS

Main unit

English

[

]

ADJ

IR-Receiver

[

ROTARY

]

Display

With the SLOPING CONSOLE opened

[Q] (OPEN/EJECT)

Photo Sensor

[MODE] [ ] (SOUND)

[TA][SRC]

[CD SLOT]

DCP Detaching Slider

DXZ958RMC 5

English

3. NOMENCLATURE

Names of the Buttons and their Functions

IR-Receiver

• Receiver for remote control unit. (Operating range: 30° in all directions)

[ADJ] button

• Use this button to set or adjust the various settings in the adjust mode.

[Q] (OPEN/EJECT) button

• Open/closes the control panel. To eject a disc, open the control panel first, and then press this button once again.

Photo Sensor

• This sensor detects the brightness inside your car. When the auto-dimmer function is set to “AUTO”, the brightness of the display is dimmed according to the brightness detected by this sensor.

[MODE] button

• Use this button to play in scan, repeat, or random mode.

• Press and hold this button for 2 seconds or longer to switch between standard and simple operation displays.

[ ] (SOUND) button

• Use this button for setting or adjusting various settings such as ADF.

[TA] button

• Use this button to turn on/off TA (Traffic Announcement).

[SRC] button

• Switches among sound sources as shown below.

Radio ➜ (DAB) ➜ CD/MP3 ➜ M. CATCHER ➜ (CD changer) ➜ (DVD changer) ➜ (TV) ➜ AUX ➜ Radio...

Note:

External equipment not connected with CeNET is not displayed.

DCP Detaching Slider

• Removes the DCP.

Display

• Displays the various information that indicates the operating state of this unit such as tuning/ play state and indicators.

•You can operate the display by touching or touching the surface. (cf. page 9)

[ROTARY] knob

• Press the knob to turn the power ON.

• Press the knob to turn the power OFF.

•Turn the knob to adjust the volume.

[CD SLOT]

• CD insertion slot.

6 DXZ958RMC

Operations when External Equipment is Connected to this Unit

English

● When the CD/DVD changer is connected

∗ For details, see the section “CD changer

operations” (cf. page 53). For the DVD

changer, refer to the Owner’s Manual provided with the DVD changer.

● When the TV/DAB is connected

∗ For details, see the section “TV

operations” (cf. page 56) or “Digital Radio/DAB operations” (cf. page 59).

DXZ958RMC 7

Touch Panel Buttons

English

● Standard operation display

Left slide button

98.10

SEEK

PRESET BAND DISPPS/AS

Sub buttons

Left slide button

•Touch this button for seek up/down or track up/

down operations.

•Touch and hold this button for fast-forward/fast-

rewind operations.

Right slide button

•Touch this button for preset channel up/down,

folder up/down, and disc up/down operations.

Sub buttons

• Shows functions available in a certain context.

FM1

2:45

Right slide button

P.CH

● Simple operation display

(To switch to the simple operation display, press and hold the [MODE] button for 2 seconds or longer.)

Left button Right button

FM1

SEEK

98.10

PRESET BAND DISPPS/AS

Sub buttons

Left button

•Touch this button for seek down or track down operations.

•Touch and hold this button for fast-rewind operation.

Right button

•Touch this button for seek up or track up operations.

•Touch and hold this button for fast-forward operation.

Sub buttons

• Shows functions available in a certain context.

2:45

P.C H

8 DXZ958RMC

Touch Panel Operations

English

A touch panel display is used as the display on this unit. You can operate this display just by touching it with your fingertip. There are four main display operations as follows:

Touch

Touch the display with your fingertip and take it away within 1 second. This is the most basic operation when operating the display.

Touch and hold

Touch the display with your fingertip and hold it on the display for 1 or 2 seconds or longer. Do not move your finger while you are touching the display.

Touch

Touch the display with your fingertip, and move your finger to the up ( ) or down ( ) with your fingertip still touching the display, and take your fingertip away within 1 second. This operation is used, for example, selecting tracks or discs.

Touch

Touch the display with your fingertip, and move your finger to the up ( ) or down ( ) with your fingertip still touching the display, and keep your fingertip on the display. The current operation continues for the time your fingertip is held on the display. This operation is used, for example, for fast-forwarding/fast-rewinding tracks.

FM1

P.CH

2:45

DISP

98.10

MANU

DXZ958RMC 9

English

4. DCP

The control panel can be detached to prevent theft. When detaching the control panel, store it in the DCP (DETACHABLE CONTROL PANEL) case to prevent scratches.

We recommend taking the DCP with you when leaving the car.

Removing the DCP

1. Turn off the power.

2. Press the [Q] button to open the DCP.

3. Move the DCP detaching slider to the “RELEASE” side.

4. Push and slide the DCP upward to remove.

∗ The SLOPING CONSOLE without DCP

closes automatically in a few seconds.

Attaching the DCP

1. Place the DCP to the SLOPING CONSOLE, adjusting the metal connecters on DCP and the SLOPING CONSOLE.

2. Press the DCP until it clicks into the SLOPING CONSOLE.

CAUTION

• If the slider is on the [RELEASE] side and

the DCP is not locked into place, it may fall out from vibration of the car. This can break the DCP, so after removing it, either firmly reattach it on the unit or put it in its DCP case.

• The connector connecting the unit and the

DCP is an extremely important part. Be careful not to damage it by pressing on it with fingernails, screwdrivers, etc.

Note:

• If the DCP is dirty, wipe off the dirt with a soft, dry

cloth only.

CAUTION

• Do not try to remove or attach while driving.

• The DCP can easily be damaged by shocks. After removing it, be careful not to drop it or subject it to strong shocks.

• This DCP is equipped with a highly advanced device. In order to make the best performance, it is required to get an electrical calibration by authorised service shop. Please consult with your Clarion dealer or distributor.

10 DXZ958RMC

5. REMOTE CONTROL

[

SRC

]

[

BND

]

[

]

[

MUTE

]

[TA]

[

PS/AS

]

[a], [d]

[

DISP

]

[

PTY

]

[AF]

[

], [ ]

Operating range : 30° in all directions

English

Receiver for remote control unit

Remote control unit

Inserting the Battery

1. Turn over the remote control unit and slide the

cover in the direction indicated by the arrow in the illustration.

2. Insert the battery (CR2025) into the insertion

guides, with the printed side (+) facing upwards.

3. Press the battery in the direction indicated by the

arrow so that it slides into the compartment.

4. Replace the cover and slide in until it clicks into

place.

Notes:

Misuse may result in rupture of the battery, producing leakage of fluid and resulting in personal injury or damage to surrounding materials. Always follow these safety precautions:

• Use only the designated battery .

• When replacing the battery, insert properly, with +/-

polarities oriented correctly.

• Do not subject battery to heat, or dispose of in fire or

water. Do not attempt to disassemble the battery.

• Dispose of used batteries properly.

Signal transmitter

Insertion guide

DXZ958RMC 11

English

Functions of the Remote Control Unit Buttons

Mode

Button

[SRC]

[BND]

[ ] , [ ]

[ ]

[MUTE]

[TA]

[DISP]

[PS/AS]

Radio (RDS)/DAB

Switches among radio, DAB tuner, CD/MP3/WMA, MC, CD changer, DVD changer, TV and AUX.

Switches reception band.

Increases and decreases volume (in all modes).

Moves preset channels up and down.

No function.

Tu r ns mute on and off.

TA on and off. Press to cancel a traffic announcement broadcast during a TA interrupt.

Switches between the title display and the spectrum analyzer display.

Preset scan. When pressed and held for 2 seconds or longer: Auto store.

CD/MP3/WMA/

M.CATCHER

Returns to the first track.

Moves tracks up and down. When pressed and held for 1 second or longer: Fast-forward/fast-rewind.

Switches between playback and pause.

Scan play. When pressed and held for 1 second or longer: Folder scan play (MP3/WMA disc, MC mode).

CD changer

DVD changer

Moves the next disc in increasing order.

Scan play. When pressed and held for 1 second or longer: Disc scan play.

Switches reception band.

Moves preset channels up and down.

No function.

Preset scan. When pressed and held for 2 seconds or longer: Auto store.

[AF]

[PTY]

∗ Some of the corresponding buttons on the main unit and remote control unit have different functions.

AF function on and off. When pressed and held for 1 second or longer: REG function on and off

Press to cancel an emergency broadcast during an ALARM interrupt.

PTY mode on and off.

Press to cancel a PTY broadcast during a PTY interrupt.

Repeat play. When pressed and held for 1 second or longer: Folder repeat play (MP3/WMA disc, MC mode).

Random play. When pressed and held for 1 second or longer: Folder random play (MP3/WMA disc, MC mode).

Repeat play. When pressed and held for 1 second or longer: Disc repeat play.

Random play. When pressed and held for 1 second or longer: Disc random play.

No function.

Switches between TV and VTR.

No function.

12 DXZ958RMC

6. OPERATIONS

Basic Operations

English

CAUTION

Be sure to lower the volume before switching the unit off or the ignition key. The unit remembers its last volume setting. If you switch the power OFF with the volume up, when you switch the power back ON, the sudden loud volume may hurt your hearing and damage the unit.

● 3WAY speaker system

High 2ch, Mid 2ch, and Sub-woofer 2ch

Tweeter (left)

Front speaker (left)

Sub-woofer

● Dolby PL II (5.1ch) speaker system

Front 2ch, Surround 2ch, Center, and Sub-woofer

Front speaker (left)

Center speaker

Tweeter (right)

Front speaker (right)

Speaker system

Speaker System 3 WAY High 2ch Mid 2ch 2 WAY High 2ch Mid 2ch Rear 2ch Dolby PL II 5.1ch NORMAL Front 2ch Rear 2ch

To make the best use of Dolby Pro Logic II on this product, we recommend to install a 5.1 channel speaker system.

Even if it is unavailable, a 4 channel speaker and sub-woofer system is also designed to reproduce a sound field close to that of the 5.1 system.

● 2WAY speaker system

High 2ch, Mid 2ch, and Rear 2ch

Tweeter (left)

Front speaker (left)

Rear speaker (left)

● NORMAL speaker system

Front 2ch, Rear 2ch, and Sub-woofer 2ch

Front speaker (left)

Speaker Configuration

Front 2ch

Surround 2ch

Subwoofer 2ch

Center + Subwoofer Subwoofer 2ch

Tweeter (right)

Front speaker (right)

Rear speaker (right)

Front speaker (right)

Surround speaker (left)

Sub-woofer

Surround speaker (right)

Rear speaker (left)

Sub-woofer

Rear speaker (right)

DXZ958RMC 13

Basic Operations

English

Selecting a speaker system

When this product is turned on for the first time, it allows you to select a speaker system. Choose your system in “SPEAKER SELECT” screen by following the procedure below.

1. Touch the speaker system best suited to

your car.

SPEAKER SELECT

3 WAY ?

CANCEL

Dolby PL

NORMAL

3 WAY 2 WAY

2. Touch [OK] to confirm your selection.

SYSTEM CHECK function

If you change your speaker system while the power of this unit is on, perform the SYSTEM CHECK function to display the SPEAKER SELECT screen and select the appropriate speaker system again. For details, see page 51.

CAUTION

Select the speaker system suited to your speaker configuration. Failing to do so can damage your speakers.

Turning ON/OFF the power

Turning on

Note:

• Be careful when using this unit for a long time

without running the engine. If you drain the car’s battery too far, you may not be able to start the engine and this can reduce the service life of the battery.

1. Press the [ROTARY] knob.

The mode that was previously active is displayed.

CODEMATIC function

When “CODEMATIC” is set to “ON”, and the power is turned ON with the DCP attached, the Touch Code display appears. Touch the display in the order that was set in the adjust mode.

ADJ SETTING

CODEMATIC OFF

RTN

For details on the CODEMATIC function, see “Using the security function” (cf. page 51).

Selecting a mode

1. Press the [SRC] button to change the operation mode.

2. Each time you press the [SRC] button, the operation mode changes in the following order:

Radio ➜ (DAB) ➜ CD/MP3 ➜ M. CATCHER ➜ (CD changer) ➜ (DVD changer) ➜ (TV) ➜ AUX ➜ Radio...

∗ External equipment not connected with

CeNET is not displayed.

Adjusting the volume

1. Turning the [ROTARY] knob clockwise increases the volume; turning it counterclockwise decreases the volume. ∗ The volume level is from 0 (minimum) to

33 (maximum).

Switching the operation display mode

There are 2 basic operation displays: standard operation display and simple operation display.

1. Press and hold the [MODE] button for 2 seconds or longer to switch the operation display.

Turning off

1. Press the [ROTARY] knob.

14 DXZ958RMC

FM1

SEEK

98.10

PRESET BAND DISPPS/AS

In the simple operation display, the operations of touching

screen are not required.

in the radio or CD mode display

2:45

P.C H

Descriptions given in this manual are mainly for the standard operation display. For descriptions for operations in the simple operation display, refer to the descriptions for the screen displays in the radio mode or the CD mode.

Switching the background

1. Touch [DISP].

98.10

SEEK

PRESET BAND DISPPS/AS

∗ DISPLAY EDIT screen displays.

2. Touch

on the left of the display to

choose the background.

DISPLAY EDIT

BGV

SP/ANA

∗ The background includes 12 wallpaper

images and 2 motion pictures.

∗ Choose [SCAN] to automatically display all

the wallpaper.

● Background M01: WRC

M02: Landscape P01: Car and Checker Flag P02: 307WRC from Two View Points P03: Rally Driver P04: Driving Scene P05: Cube P06: Bubble P07: Speaker P08: Digital Image1 (Disc media) P09: Digital Image2 (Broadcast media such

as satellite)

P10: Mixer P11: Record Player P12: Meter

3. Touch [RTN].

■ To change wallpaper color

You can change the colors of the wallpaper (from P05 to P12).

• It can be set to both “DAY” mode and “NIGHT”

mode.

1. Touch [DISP].

FM1

2:45

RTN

P.CH

TITLE

Basic Operations

2. Touch [COLOR].

DISPLAY EDIT

BGV

D-BLUE

SP/ANA COLOR

AUTO

SCROLLPRTN

∗ The [COLOR] is displayed only when you

choose wallpaper from P05 to P12.

3. Touch

on the left of the display to

select [DAY] or [NIGHT].

COLOR SELECT

NIGHT DARK BLUE

RTN

4. Touch

on the right of the display to

select the color to set.

● COLOR

• DARK BLUE

• IVORY

• WINE RED

• LIGHT BLUE

• GREEN

Adjusting the spectrum analyzer

1. Touch [DISP].

TRACK

01:01

∗ Display edit mode appears.

2. Touch [SP/ANA].

BGV

SP/ANA COLOR

∗ The display shows the spectrum analyzer

mode.

3. Touch

select the spectrum analyzer to set.

BGV

•You can choose from four types.

• When [SCAN] is selected, each of them is displayed for about 10 seconds.

Don tStop

DISPLAY EDIT

D-BLUE

2:45

DISPTOPREC

INPUTPRTN

on the right of the display to

DISPLAY EDIT

D-BLUE

MID

RTNTITLE COLOR SENS

DXZ958RMC 15

TITLE

SPE/ANA

English

Basic Operations

English

4. Touch [SENS] to select the sensitivity.

BGV

DISPLAY EDIT

D-BLUE

LOW

RTNTITLE COLOR SENS

•You can choose from [HIGH], [MID], or [LOW].

5. Touch [RTN].

Switching the title display

You can display stored information such as disc titles or track titles when playing back music in CD, CD changer, or MUSIC CATCHER mode.

1. Touch [DISP] while a title is shown.

TRACK

02:53

REC TOP

∗ Display edit mode appears.

2. Touch [TITLE].

DISPLAY EDIT

BGV

D-BLUE

∗ Title edit mode appears.

3. Touch

on the right of the display to

choose the kind of title to show.

DISPLAY EDIT

BGV

TRACK

D-BLUE

SP/ANA COLOR

∗ The title you have chosen is displayed. If it

is too long to fit into the display, it automatically scrolls.

4. Touch [SCROLL].

• Select [AUTO] to scroll the title repeatedly.

• Select [ONCE] to scroll the title only once.

Notes:

•You cannot set the scroll options in User title and MUSIC CATCHER mode.

5. Touch [RTN].

LOW

AUTO

SCROLL

2:45

DISP

RTNTITLE COLOR SENS

RTN

SPE/ANA

TITLE

●CD mode (MP3/WMA)

Folder title (when using a folder) ➜ Play list (when using a play list) ➜ Track title ➜ Album TAG ➜ Artist TAG ➜ Title TAG ➜ Folder title (when using a folder)...

●MUSIC CATHCHER mode

Folder title ➜ Track title ➜ Folder title...

Notes:

• MP3 supports ID3 Tags V2.3 / 2.2 / 1.1 / 1.0.

•Tag displays give priority to V2.3 / 2.2.

• In the case of album Tags for WMA, the information written into the extension header is displayed.

• Only ASCII characters can be displayed in Tags.

CT (Clock Time) function

The CT allows you to receive CT data sent from an RDS station and display the time. To display the CT screen, touch the centre of the display.

• If CT data is not being received, “--:-- CT”

appears in the display.

Note:

• CT data is not transmitted in some countries and by some broadcast stations. Also, in some areas, the CT data may not display accurately.

16 DXZ958RMC

Radio Operations

Screen displays in the radio mode

● Standard operation display

The standard operation display appears by pressing the [SRC] button and selecting the radio mode.

Preset No.

FM1

2:45

PS/AS

display

P.CH

DISP

Frequency display

98.10

SEEK

PRESET BAND DISPPS/AS

PRESET

SEEK/MANU display

Title display

Reception band display

BAND

English

BAND

Touching this switches the reception band. Touching and holding this for 1 second or longer switches between the manual tuning mode and the seek tuning mode.

PS/AS

Touching this starts a preset scan. Touching and holding this for 2 seconds or longer starts an auto store. Touching this during the preset scan/auto scan ends the operation.

DISP

The display contents can be changed.

a/d (only in the simple operation display)

Touching these enables seek tuning or step tuning (in the manual tuning mode). Touching and holding these enables quick tuning (in the manual tuning mode).

● Simple operation display

Pressing and holding the [MODE] button for 2 seconds or longer switches the simple operation display.

a/d

FM1

SEEK

98.10

PRESET BAND DISPPS/AS

2:45

P.CH

Frequency display

The frequency currently being received is displayed. Touching or on the left slide button in the standard operation display allows you to perform seek tuning or manual tuning.

Preset No. display

Touching on the right slide button in the standard operation display selects a preset memory.

Title display

Displays the name of the broadcast channel currently being received.

Reception band display

AM: AM band name FM1: FM band name

PRESET

Touching this displays a preset memory No. list.

Listening to the radio

1. Press the [SRC] button to select the radio

mode. Each press of the [SRC] button switches the mode as follows:

Radio ➜ (DAB) ➜ CD/MP3 ➜ M.CATCHER ➜ (CD Changer) ➜ (DVD Changer) ➜ (TV) ➜ AUX ➜ Radio...

∗ The mode of equipment that is not

connected is not displayed.

2. Touch [BAND] to switch the reception band.

Each touch of [BAND] switches the reception band as follows:

FM1 ➜ FM2 ➜ FM3 ➜ AM (MW/LW) ➜ FM1...

Tuning

There are 3 types of tuning mode available, seek tuning, manual tuning and preset tuning.

Seek tuning

There are 2 types of seek tuning: DX SEEK and LOCAL SEEK.

DX SEEK can automatically tune in to receivable broadcast stations, while LOCAL SEEK can tune in to only broadcast stations with good reception sensitivity.

DXZ958RMC 17

Radio Operations

English

1. Touch [BAND] to select the desired band (FM or AM (MW, LW)).

2. Tune into a station. ∗ If "MANU" is displayed, touch and hold

[BAND] for 1 second or longer.

Automatic tuning is possible when "SEEK"

is displayed.

∗ If “TA” is lit in the display, TP stations are

automatically sought.

DX SEEK

When is touched on the frequency display, automatic tuning starts.

When the direction of higher frequencies; when is touched, the station is sought in the direction of lower frequencies.

∗ When seek tuning starts, “DX SEEK” appears

in the display.

LOCAL SEEK

When is touched on the frequency display, local seek tuning is carried out. Broadcast stations with good reception sensitivity are selected.

∗ When local seek starts, “LO SEEK” appears

in the display.

is touched, the station is sought in

1. Touch [PRESET]. The preset memory No. list is displayed.

2. Touch the preset memory No. ∗ In the standard operation display, preset

No. can also be tuned by touching

■ To cancel tuning

1. Touch [RTN].

Preset memory

A total of 24 preset positions (6-FM1, 6-FM2, 6FM3, 6-AM) exists to store individual radio stations in memory.

1. Touch [BAND] to switch the reception band.

2. Operate the frequency display to tune to a frequency to store.

3. Touch [PRESET]. The preset memory No. list is displayed.

4. Touch and hold the preset No. to store the station to for 2 seconds or longer. You will hear a long beep, and the station is stored in memory.

Manual tuning

There are 2 ways available: quick tuning and step tuning.

In the step tuning mode, the frequency changes 1 step at a time. In the quick tuning mode, you can quickly tune the desired frequency.

1. Touch and hold [BAND] for 1 second or longer if “SEEK” is displayed. Manual tuning is possible when “MANU” is displayed.

2. Operate the frequency display to tune to a frequency on which there is a broadcast.

● Step tuning

Touch

● Quick tuning

Touch on the frequency display. Tuning stops when you take your finger away from the panel.

on the frequency display.

Recalling a preset station

Recalling a preset station is a function for tuning pre-stored stations.

18 DXZ958RMC

Auto store

Auto store is a function for storing up to 6 stations that are automatically tuned in sequentially.

1. Touch and hold [PS/AS] for 2 seconds or longer. “A-STORE” is displayed. ∗ Stations with good reception are

automatically searched, and are stored to preset memory (No.1 to No.6) in order from the station having the lowest frequency.

Notes:

• When auto store is performed, stations stored to

memory so far are cleared.

• When there are fewer than 6 stations with good

reception in LOCAL SEEK, low frequencies are automatically returned to, and auto store is performed again by DX SEEK. If there are fewer than 6 stations even after auto store is performed twice, stations stored so far remain in memory.

• If auto store is performed in the FM bands, the

stations are stored in FM3 even if FM1 or FM2 was chosen for storing stations.

Preset scan

Preset scan is a function for receiving stations in the order that they are currently stored to preset No. so that broadcasts can be checked.

1. Touch [PS/AS]. “P-SCAN” is displayed. ∗ The currently stored stations are received

in order for 7 seconds or longer each. Stations with poor reception are skipped, and the next station is received.

■ To cancel preset scan

1. Touch [PS/AS]. “P-SCAN” display disappears and the stations that were being received when [PS/

AS] was touched are received next.

Radio Operations

English

DXZ958RMC 19

RDS Operations

English

RDS (Radio Data System)

This unit has a built-in RDS decoder system that supports broadcast stations transmitting RDS data.

This system can display the name of the broadcast station being received (PS), and can automatically switch to the broadcast station with the best reception as you move over long distances (AF switching).

If a traffic announcement or programme type is broadcasted from an RDS station, this broadcast is received no matter what mode you are in.

Also, if EON information is received, this information enables automatic switching of other preset stations on the same network and interruption of the station being received with traffic information from other stations (TP). This function is not available in some areas.

When using the RDS function, always set the radio to the FM mode.

• AF : Alternative Frequency

• PS : Programme Service Name

• PTY : Programme Type

• EON : Enhanced Other Network

• TP : Traffic Programme

• PI : Programme Identification

•TA : Traffic Announcement ∗ RDS interrupt does not function during AM

radio reception.

∗ When this unit receives the RDS signal,

and can read PS data, PS appears in the display.

AF function

The AF function switches to a different frequency on the same network in order to maintain optimum reception.

• The factory default setting is “ON”.

• When the AF function is ON, “AF” blinks in the display.

■ To switch the AF function ON/OFF

1. Press the [MODE] button.

2. Touch [AF].

“AF” goes off in the display. To switch the AF function ON, repeat steps 1 and 2. ∗ If the reception of the current broadcast

station deteriorates, “SEARCH” appears in the display, and the radio searches for the same programme on another frequency.

■ AF function between RDS and DAB

When the same programme is broadcasted by both RDS and DAB, and this function is ON, this unit automatically switches to receive the broadcast with the better reception.

• This function only operates when the DAH923 or DAH913 DAB unit (Optional) is connected.

• This factory default setting is “ON”.

1. Press the [ADJ] button to set to the adjust

mode.

2. Touch [TUNER].

3. Touch on the left of the display to

select “LINK ACT”.

ADJ TUNER

LINK ACT

20 DXZ958RMC

RTN

4. Touch

select "ON" or “OFF”.

ON:

AF switching between DAB and RDS is enabled.

OFF:

AF switching between DAB and RDS is disabled.

5. Press the [ADJ] button to return to the

original mode.

on the right of the display to

RDS Operations

English

REG (Regional programme) function

When the REG function is ON, the optimum regional station can be received. When this function is OFF, the optimum station for that region is received if the regional station area switches as you drive.

• The factory default setting is “OFF”.

Notes:

• This function is disabled when a national station such as BBC R2 is being received.

• The REG function ON/OFF setting is valid when the AF function is ON.

■ To switch the REG function ON/OFF

1. Press the [MODE] button.

2. Touch [REG].

“REG” lights in the display. To switch the REG function OFF, repeat steps 1 and 2.

Manually tuning a regional station in the same network

• This function is valid when the AF function is

ON.

• The operation differs according to the ON/

OFF setting of the REG function. When the REG function is ON, broadcasts having a perfectly matching PI code can be received. When the REG function is OFF, broadcasts of the same type of PI code can be received.

Notes:

• This function can be used when a regional broadcast of the same network is received.

• The PI code is a coding system that is unique to each broadcast station.

1. Touch [PRESET].

The preset memory No. list is displayed.

2. Touch the preset memory No. of the

broadcast to be received.

TA (Traffic Announcement)

When a traffic announcement broadcast starts in the TA standby mode, the traffic announcement broadcast is received as top priority regardless of the function mode so you can listen to it. Traffic programme (TP) automatic tuning is also possible.

• This function can only be used when “TP” is lit in the display. When “TP” is lit, this means that the RDS broadcast station being received has traffic announcement programmes.

■ To set the TA standby mode

If you press the [TA] button when only “TP” is lit in the display, “TP” and “TA” light in the display, and this unit is set to the TA standby mode until a traffic announcement is broadcast. When a traffic announcement broadcast starts, “TRA INFO” appears in the display. If you press the [TA] button while a traffic announcement broadcast is being received, the traffic announcement broadcast reception is cancelled and this unit enters the TA standby mode.

■ To cancel the TA standby mode

With “TP” and “TA ” lit in the display, press the [TA] button. “TA” in the display goes off and the TA standby mode is cancelled.

• If “TP” is not lit, pressing the [TA ] button searches for a TP station.

■ To search for a TP station

If you press the [TA] button when “TP” is not lit, “TA” in the display lights and this unit automatically receives a TP station.

Note:

• When a TP station cannot be received, “TP

SEEK” is displayed, and the search for the TP

station is continued. When the [TA] button is pressed again, “TA” and “TP SEEK” in the display go off, and the search for the TP station ends.

DXZ958RMC 21

RDS Operations

English

Auto store function for TP stations

You can automatically store up to 6 TP stations to preset memory. If the number of TPs that can be received is less than 6, broadcast stations already stored in memory are left without being overwritten.

1. Make sure that “TA” is displayed. If “TA” is not displayed, press the [TA] button to display “TA”.

2. Touch and hold [PS/AS] for 2 seconds or longer. “A-STORE” is displayed and the preset No. in the auto-store operation appears on the preset No. display.

• TP stations with good reception sensitivity are

stored to preset memory.

•Even if you select FM1 or FM2, a TP station is

stored to memory for FM3.

PTY

This function enables you to listen to a broadcast of the selected programme type even if this unit is in a function mode other than radio.

• The factory default setting is “OFF”.

• Some countries do not yet have PTY

broadcast.

• In the TA standby mode, a TP station has

priority over a PTY broadcast station.

■ To set the PTY standby mode

1. Press the [MODE] button.

2. Touch [PTY]. “PTY” lights in the display and the PTY standby mode is turned on. When the selected PTY broadcast starts, the PTY item name appears in the display.

■ To cancel the PTY standby mode

1. Press the [MODE] button.

2. Touch [PTY]. “PTY” goes off in the display and the PTY standby mode is cancelled.

■ To cancel a PTY interrupt broadcast

Press the [TA] button during the PTY interrupt broadcast. The PTY interrupt broadcast is cancelled and this unit returns to the PTY standby mode.

Selecting PTY

1. Press the [MODE] button.

2. Touch [PTY SELECT].

3. Touch select PTY. ∗ Below are the factory default settings

stored:

Preset number

P1 News News P2 Info Information P3 Pop M Pop Music P4 Sport Sport P5 Classics Serious Classical Music P6 Easy M Easy Listening Music

4. The PTY select mode is cancelled automatically 7 seconds after, or touch [RTN].

on the right of the display to

PTY item

ENGLISH Contents

PTY seek

1. Press the [MODE] button.

2. Touch [PTY SELECT].

3. Either touch on the right of the display, or touch [PTY-] / [PTY+]knob to select PTY.

4. Touch When is touched, this unit seeks a PTY broadcast moving up the frequencies, while when the frequencies. ∗ If no station with the selected PTY

broadcast can be received, this unit returns to the previous mode.

on the left of the display.

is touched it seeks moving down

22 DXZ958RMC

RDS Operations

PTY item

ENGLISH DEUTSCH SVENSKA FRANÇAIS Contents News Nachrich Nyheter Infos News Affairs Aktuell Aktuellt Magazine Today’s events Info Service Info Services Information Sport Sport Sport Sport Sports Educate Bildung Utbildn Educatif Education Drama Hör + Lit Teater Fiction Drama Culture Kultur Kultur Culture Culture Science Wissen Vetenskp Sciences Science Varied Unterh Underh Divers Variety Pop M PopPop M Pop Pop music Rock M Rock Rock M Rock Rock music Easy M U-Musik Lättlyss Chansons Easy music Light M L-Musik L klass M Cl Lég Light music Classics E-Musik Klassisk Classiq Classics Other M - - Musik Övrig m Autre M Other music Weather Wetter Väder Météo Weather Finance Wirtsch Ekonomi Economie Finance Children Kinder För barn Enfants For children Social Soziales Socialt Société Social Religion Religion Andligt Religion Religion Phone In Anruf Telefon Forum Phone in Tra vel Reise Resor Voyages Travel Leisure Freizeit Fritid Loisirs Leisure Jazz Jazz Jazz Jazz Jazz Country Country Country Country Country Nation M Landes M Nation m Ch pays Nation music Oldies Oldies Oldies Rétro Oldies Folk M Folklore Folkm Folklore Folk music Document Feature Dokument Document Documentaries

English

PTY preset memory

1. Press the [MODE] button.

2. Touch [PTY SELECT].

3. Touch [PTY-]/[PTY+] to select desired PTY. The 29 PTY types in the table below can be selected.

4. Touch [PRESET]. The PTY memory title list is displayed.

5. Touch and hold the preset No. to be stored for 2 seconds or longer. You will hear a long beep, and the selected PTY is stored to that preset channel memory.

Emergency broadcast

If an emergency broadcast is received, all function mode operations are stopped, “ALARM” appears in the display, and the emergency broadcast can be heard.

■ To cancel an emergency broadcast

If you press the [TA] button, emergency broadcast reception is cancelled.

DXZ958RMC 23

RDS Operations

English

Switching the PTY display language

You can select one of 4 languages (English, German, Swedish or French) for the PTY displayed in the display.

• The factory default setting is “ENGLISH”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [TUNER].

3. Touch

select “LANGUAGE”.

on the left of the display to

ADJ TUNER

LANGUAGE

ENGLISH

RTN

4. Touch

select the desired language. ∗ Select one of ENGLISH, DEUTSCH

(German), SVENSKA (Swedish) or FRANÇAIS (French).

5. Press the [ADJ] button to return to the original mode.

on the right of the display to

Volume setting of TA, emergency broadcast (ALARM) and PTY

The volume for TA, ALARM and PTY interrupt broadcasts can be set during TA, ALARM or PTY interrupt broadcast.

• The factory default setting is “15”.

During a TA, ALARM or PTY interrupt broadcast, turn the [ROTARY] knob clockwise or counterclockwise to set the volume to the desired level (0 to 33).

• When the TA, ALARM or PTY interrupt

broadcast ends, the volume returns to the level that was active before the interrupt broadcast.

24 DXZ958RMC

CD/MP3/WMA Operations

English

Screen displays in the CD/ MP3 mode

● Standard operation display

The standard operation display appears by pressing the [SRC] button to select the CD/MP3 mode.

Track No. display

MP3 (WMA)

MP3

01 01

TRACK FOLDER

01:01

REC

Playing time display

● Simple operation display

Pressing and holding the [MODE] button for 2 seconds or longer switches the simple operation display.

TRACK

01:26

Playing time display Î00: 01: The playing time is displayed.

Track No. display If

track to play, or fast-forward or fast-rewind tracks.

Title display

The selected title is displayed.

Folder No. display (in the case of MP3/WMA)

Touching

REC (in the case of CD-DA)

Touching this records the track being played. Touching and holding this for 2 seconds or longer records all tracks in the disc. Touching this during recording cancels the recording process.

TOP

Touching this starts play from the track at the top of the disc or folder being played.

Title display

Folder No. display

Don tStop

2:45

DISPTOPREC

DISP

TOP

a/d

Don tStop

2:45

DISPTOPREC

is touched, you can select the

selects folders.

Touching this pauses or resumes play.

DISP

The display contents can be changed.

a/d (only in the simple operation display)

Touching these buttons selects the track to play. Touching and holding these buttons fastforwards or fast-rewinds tracks.

/ (Appears only in MP3/WMA discs/ MUSIC CATCHER mode and the simple operation display)

Touching these buttons selects the folder to play.

MP3/WMA

What is MP3?

MP3 is an audio compression method and classified into audio layer 3 of MPEG standards. This audio compression method has penetrated into PC users and become a standard format.

This MP3 features the original audio data compression to about 10 percent of its initial size with a high sound quality. This means about 10 music CDs can be recorded on a CD-R disc or CD-RW disc to allow a long listening time without having to change CDs.

What is WMA?

WMA is the abbreviation of Windows Media Audio, an audio file format developed by Microsoft Corporation.

Notes:

• If you play a file with DRM (Digital Rights

Management) for WMA remaining ON, no audio is output. (The DRM indicator blinks.)

• Windows Media™, and the Windows® logo are

trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.

● To disable DRM (Digital Rights

Management):

1. When using Windows Media Player 8, click

on TOOLS ➜ OPTIONS ➜ COPY MUSIC tab, then under COPY SETTINGS, unclick the check box for PROTECT CONTENT. Then, reconstruct files.

DXZ958RMC 25

CD/MP3/WMA Operations

English

2. When using Windows Media Player 9, click on TOOL ➜ OPTIONS ➜ MUSIC RECORD tab, then under Recording settings, unclick the Check box for RECORD PROTECTED MUSIC. Then, reconstruct files. Personally constructed WMA files are used at your own responsibility.

Precautions when creating MP3/WMA disc

● Usable sampling rates and bit rates:

1. MP3: Sampling rate 11.025 kHz-48 kHz, Bit rate: 8 kbps-320 kbps / VBR

2. WMA: Bit rate 48 kbps-192 kbps

● File extensions

1. Always add a file extension “.MP3” or “.WMA” to MP3 or WMA file by using single byte letters. If you add a file extension other than specified or forget to add the file extension, the file cannot be played.

2. Files without MP3/WMA data will not play. The indication “––:––” appears in the play time display if you attempt to play files without MP3/WMA data.

● Logical format (File system)

1. When writing MP3/WMA file on a CD-R disc or CD-RW disc, please select “ISO9660 level 1, 2 or JOLIET or Romeo” as the writing software format. Normal play may not be possible if the disc is recorded on another format.

2. The folder name and file name can be displayed as the title during MP3/WMA play but the title must be within 128 single byte alphabetical letters and numerals (including an extension).

3. Do not affix a name to a file inside a folder having the same name.

● Folder structure

1. A disc with a folder having more than 8 hierarchical levels will be impossible.

● Number of files or folders

1. Up to 255 files can be recognized per folder. Up to 500 files can be played.

2. Tracks are played in the order that they were recorded onto a disc. (Tracks might not always be played in the order displayed on the PC.)

3. Some noise may occur depending on the type of encoder software used while recording.

Multisession function

When a disc contains both CD-DA and MP3/ WMA type tracks mixedly, you can select which type of the recorded tracks to play.

● Default value is “CD”.

1. Press the [MODE] button.

2. Touch [Å]/[Î] to go to the next page.

3. Touch [MULTI SESS]. Each touch of [MULTI SESS] toggles the MULTI SESS display between “CD” (play CD-DA) or “MP3/WMA” (play MP3/WMA).

Disc

Mixed with CD and MP3/WMA type tracks

CD-DA

MP3/WMA disc

Note:

• When playing a CCCD (Copy Control CD), set the

setting to CD type. When this is set to MP3/WMA type, the CD cannot be played normally in some cases.

Setting

∗ The multi-session selection setting is

reflected the next time you load a CD.

Set to CD

Play CD

Play CD Play CD Play MP3/WMA

Set to MP3/WMA

Play MP3/WMA

Loading a CD

1. Press the [Q] button. The control panel opens.

2. Insert the disc into the CD SLOT. When the disc is loaded, the control panel automatically closes after several seconds, and play starts.

Notes:

•Never insert foreign objects into the CD SLOT.

• If the CD does not insert easily, there may be

another CD in the mechanism or the unit may require service.

• Discs not bearing the or mark and

CD-ROMs cannot be played by this unit.

• Some CDs recorded in the CD-R/CD-RW mode

may not be usable.

26 DXZ958RMC

CD/MP3/WMA Operations

English

Loading 8 cm compact discs

∗ No adapter is required to play an 8 cm CD. ∗ Insert the 8 cm CD into the center of the CD

SLOT.

Backup eject function

You can eject a disc by pressing the [Q] button even if the engine key or ACC is at the OFF position.

CAUTION

When the disc is ejected, press the [Q] button to close the control panel. If the control panel is left open, you will hear a double beep, and the control panel automatically closes.

1. Press the [Q] button. The control panel opens.

2. Press the [Q] button. The disc is ejected.

Note:

• Always close the SLOPING CONSOLE after

opening it or ejecting the CD.

CAUTION

• Be careful not to catch your hand or

fingers while closing the SLOPING CONSOLE.

• Do not try to put your hand or fingers in

the disc insertion slot. Also never insert foreign objects into the slot.

• Do not insert discs where adhesive comes

out from cellophane tape or a rental CD label, or discs with marks where cellophane tape or rental CD labels were removed. It may be impossible to extract these discs from the unit and they may cause the unit to break down.

Listening to a disc already loaded in the unit

1. Press the [SRC] button to select the CD/ MP3 mode. ∗ Play automatically starts when the mode

changes to the CD/MP3 mode.

Pausing play

1. Touch [ ].

■ To resume play

1. Touch [ ] again.

Selecting a track

When a CD-R/CD-RW recorded with an MP3 file or a WMA file is loaded, you can select only tracks recorded to the same folder by touching

on the track display.

1. To listen to the next track, touch on the track display.

2. To listen to the previous track, touch

twice on the track display. Touching touch

ahead to the track for the number of times you touched Touching

touch to the track for the number of times you touched

∗ If you touch

while the start of the track is being played, the track 2 tracks back is sometimes played.

plays the next track. If you

more times, the track advances

and that track is played.

plays the previous track. If you

more times, the track moves back

and that track is played.

twice on the track display

■ To select a folder

To select a different folder, touch

folder display on the right.

on the

Play list mode

This function allows you to play tracks, up to latest 5 time stamps, by reading the play list information written on the disc.

1. Press the [MODE] button.

2. Touch [Å]/[Î] to go to the next page.

3. Touch [PLAY LIST].

MODE

MULTI

SESS

MP3 WMA

PLAY

LIST

2 2

RTN

DXZ958RMC 27

CD/MP3/WMA Operations

English

The operation of selecting the play list or tracks in the play list is the same as that of selecting a folder or tracks in a folder. ∗ Play list play is possible only when there is

a file whose extension is “.M3U” on the CD-R/RW.

∗ Up to 5 play lists can be recognized, and

up to 255 files can be recognized per play list.

■ Stopping play of play list

1. Press the [MODE] button.

2. Touch [Å]/[Î] to go to the next page.

3. Touch [PLAY LIST].

Notes:

• The SCN/RPT/RDM functions cannot be used while in the play list mode.

• The title changes from folder name to play list name.

Top function

The top function resets the CD player to the first track of the disc.

1. Touch [TOP]. Play starts from the first track (track No.1).

Scan play

This function allows you to locate and play the first 10 seconds of all the tracks recorded on a disc.

1. Press the [MODE] button.

2. Touch [TRACK SCAN]. ∗ Scan play starts from the next track after

the track currently being played.

■ To cancel scan play

1. Press the [MODE] button.

Making a play list

1. Write desired tracks to a CD-R/RW, etc. Be sure to use alphanumeric/ASCII characters for all file names.

2. Make a play list by using a multimedia player, etc. and save the data. The file format must be M3U.

3. Again, write this play list to the CD-R/RW, etc.

Notes:

• When writing to a CD-R/RW, etc., be sure to use

alphanumeric/ASCII characters.

• Up to 5 layers can be recognized as a list. For

written play lists, latest 5 lists are recognized in the order in which they are written.

• When writing to a CD-R/RW, etc., turn off the Disc

At Once function.

• When adding a play list, it is recommended to

write it in the “Root” folder.

Fast-forward/fast-rewind

1. To fast-forward, touch on the track display.

2. To fast-rewind, touch on the track display.

Folder scan play

This function allows you to locate and play the first 10 seconds of the first track of all the folders recorders on a disc.

1. Press the [MODE] button.

2. Touch [FOLDER SCAN]. ∗ Folder scan play starts from the folder

following the folder that is playing.

■ To cancel folder scan play

1. Press the [MODE] button.

Repeat play

This function allows you to play the current track repeatedly.

1. Press the [MODE] button.

2. Touch [TRACK RPT].

■ To cancel repeat play

1. Press the [MODE] button.

Folder repeat play

This function allows you to play the current folder repeatedly.

1. Press the [MODE] button.

2. Touch [FOLDER RPT].

28 DXZ958RMC

■ To cancel folder repeat play

1. Press the [MODE] button.

Random play

This function allows you to play all tracks on the disc at random. When the disc contains 2 or more folders, all of the tracks in the folder are played at random, followed by all of the tracks in the next folder. This is repeated for all folders.

1. Press the [MODE] button.

2. Touch [TRACK RDM].

■ To cancel random play

1. Press the [MODE] button.

Folder random play

This function allows you to play all folders on the disc at random.

1. Press the [MODE] button.

2. Touch [FOLDER RDM].

CD/MP3/WMA Operations

English

■ To cancel folder random play

1. Press the [MODE] button.

MUSIC CATCHER

In the M.CATCHER mode, the files recorded in the built-in flash memory are played back. Operations for listening to a recording made using MUSIC CATCHER are the same as “CD/ MP3/WMA Operations”. For operations for recoding using MUSIC CATCHER, refer to the section “MUSIC CATCHER Operations”.

DXZ958RMC 29

MUSIC CATCHER Operations

English

The MUSIC CATCHER function allows you to record CD-DAs in the built-in flash memory.

REC MODE

TRACK

01:01

Don tStop

2:45

DISPTOPREC

REC

Setting a recording mode

MUSIC CATCHER can be switched between 2 recording modes:

• HQ (High Quality) MODE: about 266 minutes

• LP (Long Play) MODE: about 354 minutes

• The factory default setting is “HQ”.

1. Press the [MODE] button.

2. Touch [REC MODE] to select “HQ” or “LP”.

MODE

TRACK

SCAN

TRACK

RPT

TRACK

RDM

1 1

MULTI

SESS

MP3 WMA HQ

REC

MODE

RTN

Setting RDS interrupt during recording

The RDS or DAB interrupt function can be switched on or off during recording using MUSIC CATCHER.

∗ The factory default setting is “OFF”.

1. Press the [ADJ] button to switch to the adjust mode.

2. Touch [TUNER].

3. Touch

on the left of the display to

select “RDS-IN REC”.

ADJ TUNER

4. Touch

RDS-IN REC

on the right of the display to

OFF

RTN

select “ON” or “OFF”.

● ON: When “ON” is selected, recording is suspended at the occurrence of an RDS interrupt during recording. (The output is switched to RDS audio.)

30 DXZ958RMC

● OFF: When “OFF” is selected, recording continues even at the occurrence of an RDS interrupt during recording. (RDS audio is not output.)

Notes:

• At the occurrence of an emergency broadcast (alarm interrupt), recording is suspended even when RDS interrupt is set to “OFF”.

• When TEL interrupt is set to “ON”, recording is suspended even when RDS interrupt is set to “OFF”. To avoid this, set the “TEL-SWITCH” setting to “OFF” or disconnect the cellular phone from the unit.

*For details on “Cellular phone interrupt setting”,

refer to the section “Common Operations” of each owner’s manual.

4. Press the [ADJ] button to return to the

original mode.

Notes on recording using MUSIC CATCHER:

• Recording operations are to be performed in

the CD/MP3/WMA mode.

• Recordable media are CD-DAs only.

• Discs (CD-R/CD-RW) created by copying on a

music recorder cannot be recorded.

• MP3/WMA discs cannot be recorded.

• Some CDs may show a subtractive time

indication in the area between tracks when they are played back. A between-tracks area is not recorded in such a CD.

• In recording using MUSIC CATCHER, some

amount of silent time is created between the tracks.

• If the disc contains some tracks that have been

already recorded, the other tracks are recorded.

•Folder and track names are added

automatically during recording. You can change folder names.

• If the disc contains some tracks previously

recorded, “INCLUDED” appears on the display.

• If there is no empty folder available, “FOLDER

FULL” appears on the display.

• When the memory capacity is used up,

“MEMORY FULL” appears on the display and recording is canceled.

• Recording cannot be performed during SCN,

RPT, and RDM. In such cases, “BUSY” appears on the display.

• When recording is canceled, the track that has

been recorded incompletely is deleted.

Recording operation (REC function)

Recording using MUSIC CATCHER is performed in the CD/MP3 mode and the following 2 recording modes are available: “TRACK REC” to record only one track currently being played back and “DISC REC” to record all tracks on the CD.

● TRACK REC

1. Press the [SRC] button to select the CD/MP3 mode.

2. Play back a track to be recorded, and touch [REC] to start recording.

The “T-REC” indicator lights on the display.

∗ When recording is complete, “REC DONE”

appears on the display.

● DISC REC

1. Press the [SRC] button to select the CD/MP3 mode.

2. Play back a CD to be recorded, and touch and hold [REC] for 2 seconds or longer to start recording.

The “D-REC” indicator lights on the display.

∗ When recording is complete, “REC DONE”

appears on the display.

Canceling recording

1. Touch [REC] to cancel the recording process.

The display shows “CANCELED” and then the playback of the CD continues.

Notes:

• Recording also can be canceled by pressing the

[SRC] or [Q] button.

• When recording is canceled, the track that has

been recorded incompletely is deleted.

MUSIC CATCHER Operations

3. Touch [Å]/[Î] to go to the next page.

4. Touch [TRACK ERASE], [FOLDER ERASE], or [ALL ERASE].

FOLDER ERASE ?

CANCEL

∗ The screen such as “FOLDER ERASE?”

appears.

5. Touch [OK] to erase.

∗ The “ERASING” message appears on the

display, and a track, a folder, or flash memory contents are erased.

Notes:

• When a selected track or folder is erased, the

approximate recordable time is shown (the recordable time shown varies according to the set recording mode).

• Do not turn off the power of the unit or switch the

operation mode during erasing recordings.

240:40 253:49

AVIL.

RTN

Remaining capacity of the memory

By touching [DISP] while in MUSIC CATCHER mode, the remaining capacity of the flash memory can be displayed as an approximate recordable time in “MM (minute): SS (second)” format. For example, “AVIL. 123:45”.

Note:

• The recordable time shown varies according to

the set recording mode.

English

Erasing operation (ERASE function)

MUSIC CATCHER has 3 different modes for erasing files from memory.

“TRACK ERASE”:erase only one track. “FOLDER ERASE”:erase the whole folder. “ALL ERASE”:erase all the contents of

the flash memory.

1. Press the [SRC] button to select the M.CATCHER mode.

2. Press the [MODE] button while playing music.

DXZ958RMC 31

Sound Adjustment

English

Adjustment items

You can adjust a sound effect or tone quality to your preference. A speaker system is selected in the speaker select procedure (cf. page 14) when this product is turned on for the first time.

The adjustment item depends on the speaker system.

● 3 WAY

Anti Distortion Filter (ADF) .................... Page 32

SETTING

Parametric Equalizer (P.EQ) .............. Page 33

Crossover (X-OVER) ........................ Page 34

Time Alignment (TIME ALIGN) ......... Page 35

Speaker Gain (SP GAIN) .................. Page 35

All Seat setting (ALL SEAT) ............. Page 36

Sub-woofer speaker volume

(SW VOLUME) ................................ Page 36

Bass setting (BASS) ............................ Page 37

Treble setting (TREBLE) ...................... Page 37

Balance (BALANCE) ............................. Page 37

● 2 WAY

Anti Distortion Filter (ADF) .................... Page 32

SETTING

Parametric Equalizer (P.EQ) .............. Page 33

Crossover (X-OVER) ........................ Page 34

Time Alignment (TIME ALIGN) ......... Page 35

Speaker Gain (SP GAIN) ................. Page 35

All Seat setting (ALL SEAT) .............. Page 36

Bass setting (BASS) ............................ Page 37

Treble setting (TREBLE) ....................... Page 37

Balance (BALANCE) ............................. Page 37

Fader (FADER)..................................... Page 37

● Dolby PLII

Anti Distortion Filter (ADF) .................... Page 32

Sub-woofer speaker volume

(SW VOLUME) ................................ Page 36

Center speaker volume

(CTR VOLUME) ............................... Page 36

Balance (BALANCE) ............................ Page 37

Fader (FADER)...................................... Page 37

Dolby mode (Dolby PL II) ...................... Page 40

Speaker Gain (SP GAIN) ..................... Page 40

Filter (FILTER) ...................................... Page 41

Music mode setting (PL II CONT) ......... Page 41

Delay time of the rear speakers

(PL II DELAY) .................................. Page 42

● NORMAL

Anti Distortion Filter (ADF) .................... Page 32

Sub-woofer speaker volume

(SW VOLUME) .................................. Page36

Bass setting (BASS) ............................. Page 37

Treble setting (TREBLE) ....................... Page 37

Balance (BALANCE) ............................. Page 37

Fader (FADER)...................................... Page 37

Virtual Space Enhancer (VSE) .............. Page 37

Parametric Equalizer (P.EQ) ................. Page 38

Filter (FILTER) ....................................... Page 41

Setting the ADF

• ADF is the abbreviation of Anti Distortion Filter.

The adopted “Liveliness Enhancement Filter” and “Sound Tone Compensation” functions allow well-modulated realistic playback without affecting the characteristics of the original sound tone.

This unit is provided with 4 types of sound tone effects stored in memory. Select the one you prefer.

ADF-1 : Suitable for genuine speakers ADF-2 : Suitable for separate speakers ADF-3 : Suitable for co-axial speakers USER : This setting can be adjusted by the

OFF : No sound effect

• The factory default setting is “OFF”.

Notes:

• As the volume changes when ADF is switched,

• On some speaker systems, sufficient effect

• When ADF is set to “USER”, “1”, “2” or “3”, the

1. Press the [SOUND] button.

2. Touch [ADF].

3. Touch on the right of the display to

user to his or her individual preference.

switch ADF with the volume and “SW VOLUME” (sub-woofer) and “CTR VOLUME” (center speaker) turned down as far as possible.

sometimes cannot be obtained. If this happens, adjust the volume.

VSE function and BASS/TREB function under EQ-SELECT are disabled.

SOUND

1 1

ADF

SETTING

OFF 0 0

VOLUME

BALANCE

RTN

select the ADF mode.

ADF MODE

ADF 1

RTN

∗ Select one of “USER”, “1”, “2”, “3”, or

“OFF”.

32 DXZ958RMC

4. To change the details of the ADF setting, press the [ADJ] button.

5. Touch

on the left of the display to select the desired item. Each touch of

switches the

adjustment item display as follows:

●Adjustment item (when USER is

selected in step 3)

BASS ➜ TREBLE ➜ COMP ➜ BASS...

●Adjustment item (when 1 to 3 is

selected in step 3)

LEVEL ➜ COMP ➜ LEVEL...

6. Touch

on the right of the display to adjust the item. ∗ “BASS” and “TREBLE” can be adjusted

within the range 1 to 13.

∗ “LEVEL” can be adjusted within the range -

3 to +3.

∗ Select either “ON” or “OFF” for “COMP”.

7. Press the [SOUND] button to return to the original mode.

SETTING items (only for 3 WAY and 2 WAY)

You can adjust the items listed in the SETTING section only when you selected “3 WAY” or “2 WAY” in “SPEAKER SELECT”. The items you can adjust are “P.EQ”, “X-OVER”, “TIME

ALIGN”, “SP GAIN”, and “ALL SEAT”.

SETTING–P.EQ

P.EQ (Parametric Equalizer) allows you to compensate the entire frequency level range in detail by smooth curve using frequency compensation matched to the type of your car.

“P.EQ” can be adjusted only when the “SPEAKER SELECT” is set to “3WAY” or “2WAY” and “EQ SELECT“ is set to “P.EQ” (cf. page 48).

• The factory default setting is “OFF”.

1. Press the [SOUND] button.

2. Touch [SETTING].

3. Touch [P.EQ].

SETTING

P.EQ X-OVER

OFF

PRESET

TIME

ALIGNSPGAIN

ALL

SEAT

RTN

Sound Adjustment

4. Touch [ON/OFF]. The P.EQ effect is toggled ON/OFF.

P.EQ MODE

FREQUENCY

LEFT

L/R

BAND

5. Touch [L/R] to select “LEFT” or “RIGHT”.

6. Touch [BAND]. ∗This item can be adjusted within the range

1 to 3.

7. Touch

on the left of the display to select the item. Each touch of

adjustment items as follows:

FREQUENCY ➜ Q ➜ GAIN ➜ FREQUENCY...

8. Touch

on the right of the display to adjust the setting. ∗ “FREQUENCY” can be adjusted within the

range 20Hz to 20kHz.

∗ “Q” can be adjusted within the range of 1,

3, 5, 7 and 20.

∗ “GAIN” can be adjusted within the range

-12dB to +12dB.

9. Repeat steps 5 to 8 to adjust the each setting. ∗ Touch and hold [L/R] for 2 seconds or

longer to copy the setting from one (left or right) to the other.

10. When you have finished adjusting each item, touch [RTN]. ∗ You can store the settings. For details, see

“Storing and recalling the SETTING adjustments” (page 36).

■ P.EQ adjustment

The settings that can be adjusted in the P.EQ menu are as follows. The center frequency, gain and Q curve can be stored to channel/band combinations.

For example, center frequency “250Hz”, gain “-8dB” and Q curve “3” can be stored to band 1 on the right channel.

LEFT/RIGHT (channel selection)

Selects the channel (left or right) to adjust.

BAND (band selection)

Selects the frequency band (1 to 3) to adjust. Set the center frequency (FREQUENCY), gain (GAIN) and Q curve (Q) for each frequency band.

500Hz

OFF

ON/OFF

RTN

switches the

English

DXZ958RMC 33

Sound Adjustment

English

FREQUENCY (center frequency selection)

Selects the frequency to be used as the center of the frequency band to be compensated from the range 20Hz to 20kHz. (1/3 octave steps, 31 points)

GAIN (gain adjustment)

Adjusts the gain (output level) within the range

-12dB to +12dB. (1dB steps, 25 points)

Q (Q curve selection)

Sets one of 1, 3, 5, 7, or 20 as the sharpness of the Q curve.

● Compensation

There is no need to compensate frequency characteristics if they are flat (no peaks or valleys) when you have measured the frequency characteristics with a measuring device. However, sometimes the frequency characteristics rise or fall in some places. If this happens, the frequency characteristics must be compensated. Create a frequency curve having characteristics that are opposite to the center frequency of parts where the characteristics rise and fall to cancel out these peaks and values, and make the frequency characteristics as flat as possible.

Making the frequency characteristics as flat as possible is called “compensation”.

On this unit, frequency characteristics can be compensated by P.EQ (Parametric Equalizer).

● Compensation of frequency characteristics

The figure below shows the relationship between the center frequency, gain and Q curve.

Level (dB)

Gain (G)

Q curve (Q)

Q =

3dB

Frequency curve

Center Frequency (F)

● Q curve

The Q curve becomes sharper when the numerical value is increased, and smoother when the numerical value is decreased.

Frequency (Hz)

Flat frequency characteristics can be made by selecting a Q curve opposite to that of the curve to be compensated.

Q curve : (Q)

Q curve : 20 Q curve : 1

SETTING–X-OVER

This function allows you to adjust the speaker setting such as cutoff frequencies or slope matched to the speakers you are using. (Crossover)

1. Press the [SOUND] button.

2. Touch [SETTING].

3. Touch [X-OVER].

X OVER MODE

LPF

REAR

4. Touch [SP] to select the desired speaker. Each touch of [SP] switches the adjustment items as follows:

HIGH ➜ MID ➜ SUB-W (in the case of 3WAY) ➜ REAR (in the case of 2WAY) ➜ HIGH...

5. Touch

on the left of the display to select the item. Each touch of

switches the

adjustment items as follows:

LPF* ➜ LPF SLOPE* ➜ HPF ➜ HPF SLOPE ➜ PHASE ➜ LPF...

* This does not appear when the speaker is

selected to “HIGH” in step 4.

6. Touch

on the right of the display to adjust the setting.

●“LPF”

• The adjustment range of “MID” is

THROUGH, 630Hz to 10 kHz. (The factory default setting is “2kHz”.)

• The adjustment range of “SUB-W” (in the

case of 3WAY) or “REAR” (in the case of 2WAY) is THROUGH, 25Hz to 10 kHz. (The factory default setting is “80Hz”.)

80Hz

RTN

34 DXZ958RMC

●“HPF”

• The adjustment range of “HIGH” is 630Hz to 20 kHz. (The factory default setting is “2kHz”.)

• The adjustment range of “MID” is THROUGH, 25Hz to 10 kHz. (The factory default setting is “THROUGH”.)

• The adjustment range of “SUB-W” (in the case of 3WAY) or “REAR” (in the case of 2WAY) is THROUGH, 16Hz to 250 Hz. (The factory default setting is “THROUGH”.)

●“LPF SLOPE” and “HPF SLOPE”

• The adjustment range is -6dB/OCT,

-12dB/OCT, -18dB/OCT. (The factory default setting is “-12dB/OCT”.)

●“PHASE”

• The adjustment range is NORMAL/ REVERSE. (The factory default setting is “NORMAL”.)

7. Repeat steps 4 to 6 to adjust each setting.

8. Touch [RTN]. ∗ You can store the settings. For details, see

“Storing and recalling the SETTING

adjustments” (page 36).

SETTING–TIME ALIGN

The distance from the listener up to each speaker can be entered in 2.3 cm steps, and the time that the sound reaches the listener from each speaker can be adjusted. (Time alignment)

• The factory default setting is “0.0cm”.

1. Press the [SOUND] button.

2. Touch [SETTING].

3. Touch [TIME ALIGN].

TIME

ALIGN

HIGH L SP

4. Touch

on the left of the display to select the desired speaker. Each touch of adjustment items as follows:

HIGH L SP ➜ HIGH R SP ➜ MID L SP ➜ MID R SP ➜ SUB-W L SP*1 ➜ SUB-W R

➜ REAR L SP*2 ➜ REAR R SP*2 ➜

SP* HIGH L SP...

This is displayed when the “SPEAKER SELECT” is set to “3WAY”.

This is displayed when the “SPEAKER

SELECT” is set to “2WAY”.

0.0cm

RTN

switches the

Sound Adjustment

5. Touch adjust the setting. ∗ The adjustment range is 0cm to 501.4cm

in 2.3 cm steps.

6. Repeat steps 4 and 5 to adjust each item.

7. Touch [RTN]. ∗ You can store the settings. For details, see

“Storing and recalling the SETTING adjustments” (page 36).

on the right of the display to

SETTING–SP GAIN

This function allows you to adjust the speaker output level. Adjust so that the volumes that are output from each speaker are well-balanced. (Speaker gain)

1. Press the [SOUND] button.

2. Touch [SETTING].

3. Touch [SP GAIN].

SP GAIN MODE

HIGH L SP

4Touch

on the left of the display to select the desired speaker. ∗ Each touch of

adjustment items as follows:

HIGH L SP ➜ HIGH R SP ➜ MID L SP ➜ MID R SP ➜ SUB-W L SP*

➜ REAR L SP*2 ➜ REAR R SP*2 ➜

SP* HIGH L SP...

This is displayed when the “SPEAKER

SELECT” is set to “3WAY”.

This is displayed when the “SPEAKER

SELECT” is set to “2WAY”.

5. Touch on the right of the display to adjust the setting. ∗ The adjustment range is -20dB to 0dB.

6. Repeat steps 4 and 5 to adjust each item.

7. Touch [RTN]. ∗ You can store the settings. For details, see

“Storing and recalling the SETTING adjustments” (page 36).

0dB

RTN

switches the

➜ SUB-W R

DXZ958RMC 35

English

Sound Adjustment

English

SETTING–ALL SEAT

The setting of “TIME ALIGN” and “SP GAIN” temporarily returns to the factory default setting. When the setting that is adjusted for the driver's seat returns to the factory default setting, a sound suitable for all seats is provided.

1. Press the [SOUND] button.

2. Touch [SETTING].

3. Touch [ALL SEAT].

SETTING

P.EQ X-OVER

ON ALL

PRESET

TIME

ALIGNSPGAIN

ALL

SEAT

RTN

“ALL” appears on the display and the setting of “TIME ALIGN” and “SP GAIN” is set to the factory default setting.

■ To disable ALL SEAT setting

1. Touch [ALL SEAT] again.

Storing and recalling the SETTING adjustments

If your speaker system is “3 WAY” or “2 WAY”, you can store and recall up to three adjustments you have made to “P.EQ”, “X-OVER”, “TIME ALIGN”, “SP GAIN”.

1. Adjust one of the items in the SETTING.

2. Display the [SETTING] screen. ∗ To display this screen from the beginning,

press the [SOUND] button, then touch [SETTING].

3. Touch [PRESET].

SETTING

P.EQ X-OVER

OFF

PRESET

TIME

ALIGNSPGAIN

4. Touch one of [SAVE 1], [SAVE 2], and [SAVE 3].

LOAD1LOAD2LOAD3SAVE1SAVE2SAVE

SETTING PRESET

INITIAL

∗ If you touch [LOAD] or [INITIAL] before

touching [SAVE], the adjustments you have made will not be stored.

ALL

SEAT

RTN

■ To initialize the adjustments

You can initialize the adjustments for SETTING items.

1. Touch [SETTING].

2. Touch [INITIAL]. All the adjustments are initialized.

■ To recall the adjustments for

SETTING items

You can recall the stored adjustments for SETTING items.

1. Press the [SOUND] button.

2. Touch [SETTING].

3. Touch [PRESET].

SETTING

P.EQ X-OVER

OFF

PRESET

TIME

ALIGNSPGAIN

ALL

SEAT

RTN

4. Touch one of [LOAD 1], [LOAD 2], and [LOAD 3] to recall the stored adjustment.

Adjusting the sub-woofer/ center speaker

•“SW VOLUME” (sub-woofer) can be adjusted

only when the “SPEAKER SELECT” is set to “3WAY”, “Dolby PL II” or “NORMAL” and “SUB-WOOFER“ is set to “ON” (cf. page 48).

•“CTR VOLUME” (center speaker) can be

adjusted only when the “SPEAKER SELECT” is set to “Dolby PL II” and “CENTER-SP” is set to “ON” (cf. page 48).

• The factory default setting for SW VOLUME is

“0” and for CTR VOLUME is “0”.

1. Press the [SOUND] button.

2. Touch [SW VOLUME] or [CTR VOLUME].

SW VOLUME

RTN

∗ If you selected “Dolby PL II”, use [Å]/[Î]

to go to the next page.

3. Touch on the right of the display and adjust the item as desired. ∗ This item can be adjusted within the range

-5 to +5.

4. Press the [SOUND] button to return to the original mode.

36 DXZ958RMC

Sound Adjustment

English

Adjusting bass/treble

The bass/treble mode can be adjusted only when the “SPEAKER SELECT” is set to “3 WAY”, “2 WAY”, or “NORMAL” (cf. page 14) and “EQ SELECT” is set to “BASS/TREB” (cf. page

48).

• The factory default setting is “0”.

1. Press the [SOUND] button.

2. Touch [BASS] or [TREBLE].

BASS

RTN

3. Touch on the right of the display and adjust the item as desired. ∗ This item can be adjusted within the range

-6 to +6.

4. Press the [SOUND] button to return to the original mode.

Adjusting balance/fader

BALANCE:

Adjusts the volume balance between the left and right speakers.

FADER:

Adjusts the volume balance between the front and rear speakers.

• The factory default setting for BALANCE is “0”

and for FADER is “0”.

1. Press the [SOUND] button.

2. Touch [BALANCE] or [FADER].

BALANCE

RTN

3. Touch on the right of the display and adjust the item as desired. ∗ “BALANCE” can be adjusted within the

range L13 (left side emphasized) and R13 (right side emphasized).

∗ “FADER” can be adjusted within the range

R12 (rear side emphasized) and F12 (front side emphasized).

4. Press the [SOUND] button to return to the original mode.

Selecting the VSE menu

VSE (Virtual Space Enhancer) allows you to compensate the sound pressure balance inside your car so that the same sound effect can be obtained whichever seat you are sitting in as proved in compensation simulations.

• The factory default settings are “OFF” for VSE and “FLAT” for the VSE basic menu.

■ VSE basic menu

Six basic menus are pre-stored to this function. Select the basic menu to suit your preference.

1. Press the [SOUND] button.

2. Touch [VSE].

SOUND

1 2

OFF

VOLUME

RTN

BALANCE

P 1

PRESET

ADF VSE

OFF OFF OFF 0 0

P.E Q FILTER

3. Touch [ON/OFF].

The VSE effect is toggled ON/OFF.

VSE MODE

FLAT

PRESET

ON/OFF

When VSE is set to “OFF”, the VSE setting is not reflected on the music source. This completes the VSE setting. Press the [SOUND] button to return to the original mode.

4. Touch on the right of the display and

select one of the VSE basic menus.

VSE basic menus

No.

Function Name

1 FLAT

Description

Sound source flat equalizing

2 BASS BOOST Bass tones enhanced

3 HIGH BOOST

4IMPACT

5ACOUSTICAL

Mid and treble enhanced

Low and treble enhanced

Mid tones (human voice) enhanced

6 USER User preference

5. Press the [SOUND] button to return to the

original mode.

DXZ958RMC 37

Sound Adjustment

English

Adjusting/storing VSE (user memory)

Adjustment items

● DIFFUSE

Adjusts the deviation in diffused sound pressure.

● CAR WIDTH

Adjusts the deviation in sound pressure along the width of the car.

● CAR LENGTH

Adjusts the deviation in sound pressure along the length of the car.

1. Press the [SOUND] button.

2. Touch [VSE].

SOUND

1 2

OFF

ON/OFF

OFF

ON/OFF

VOLUME

RTN

ADF VSE

OFF OFF OFF 0 0

P.E Q FILTER

3. Touch [ON/OFF] to turn ON. The VSE effect is toggled ON/OFF.

VSE MODE

FLAT

PRESET

4. Touch on the right of the display and select one of the VSE basic menus.

5. Press the [ADJ] button.

6. Touch

on the left of the display and select [DIFFUSE], [CAR WIDTH], or [CAR LENGTH].

VSE EDIT

DIFFUSE

7. Touch on the right of the display to adjust the item. Each touch switches the value from 1 to 10.

8. Repeat steps 6 and 7 to adjust the desired item.

9. When you have finished adjusting each item, touch [RTN].

Notes:

• The screen displayed in step 3 appears, with the

title being accompanied by "✓" mark. Operation so far completes VSE adjustment. To

continue to store the adjustment value to the VSE

38 DXZ958RMC

BALANCE

P 1

PRESET

user menu, perform the following.

10. Touch [PRESET] to display the VSE menu list.

11. Touch and hold [USER] for 2 seconds or longer. You will hear a long beep, and the values you adjusted up to step 9 are stored to the VSE menu. If you hear a short beep, the adjustment values up to step 9 are discarded. Adjust these values again as required.

12. Press the [SOUND] button to return to the original mode.

Selecting the P.EQ menu

P.EQ (Parametric Equalizer) allows you to compensate the entire frequency level range in detail by smooth curve using frequency compensation matched to the type of your car. The P.EQ menu can be adjusted only when the “SPEAKER SELECT” is set to “NORMAL” (cf. page 14) and “EQ SELECT” is set to “P.EQ” (cf. page 48).

• The factory default setting for P.EQ is “OFF”

and for the P.EQ basic menu is “SEDAN-1”.

■ P.EQ basic menu

6 types of P.EQ basic menu are pre-stored to this function matched to the type of your car and the speaker mounting position. Select the basic menu to suit you car.

1. Press the [SOUND] button.

2. Touch [P.EQ].

SETTING

P.EQ X-OVER

OFF

PRESET

TIME

ALIGNSPGAIN

3. Touch [ON/OFF]. The P.EQ effect is toggled ON/OFF.

P.EQ MODE

SEDAN-1

PRESET

4. Touch on the right of the display and select one of the P.EQ menus.

OFF

ON/OFF

ALL

SEAT

RTN

P 1

PRESET

P.EQ basic menu

No. Display name

Speaker Mounting position

1 SEDAN-1 Front: Front door

Rear: Rear parcel

2 SEDAN-2 Front: Front door

Rear: Rear door

3 MINI VAN-1 Front: Front door

Rear: Luggage (side)

4 MINI VAN-2 Front: Front door

Rear: Rear door

5WAGON Front: Front door

Rear: Luggage (side)

6 USER User preference

5. Press the [SOUND] button to return to the original mode.

Adjusting/storing P.EQ (user memory)

1. Press the [SOUND] button.

2. Touch [P.EQ].

SETTING

P.EQ X-OVER

OFF

PRESET

TIME

ALIGNSPGAIN

3. Touch [ON/OFF] to turn ON. The P.EQ effect is toggled ON/OFF.

P.EQ MODE

SEDAN-1

PRESET

OFF

ON/OFF

ALL

SEAT

RTN

P 1

PRESET

Sound Adjustment

4. Touch on the right of the display and select one of the P.EQ menus.

5. Press the [ADJ] button.

6. Touch [F/R] to select [FRONT] or [REAR].

P.EQ EDIT

FREQUENCY

FRONT

F/R

BAND

7. Touch [BAND] to select the value to set. Each touch switches the value from 1 to 3.

8. Touch

on the left of the display and select each adjustment item. Each touch switches the adjustment item as follows:

●Adjustment items FREQUENCY ➜ Q ➜ GAIN ➜ FREQUENCY...

9. Touch

on the right of the display to adjust the items. ∗ “FREQUENCY” can be adjusted within the

range 20Hz to 20kHz.

∗ “Q” can be adjusted by choosing from 1, 3,

5, 7, or 20.

∗ “GAIN” can be adjusted within the range

-12dB to +12dB.

10. Repeat steps from 6 to 9 to adjust the desired item.

11. When you have finished adjusting each item, touch [RTN].

OFF

ON/OFF

250Hz

RTN

English

P.EQ basic menu setting values

No. (car type)

Channel

Parametric Equalizer Parameters (default)

Band 1 Band 2 Band 3

FQG F QG F QG

F: Center frequency, Q: Q curve, G: Gain (output level)

1Front 250 Hz 3 -8 dB 2 kHz 1 -4 dB 5 kHz 1 -4 dB (SEDAN-1) Rear 250 Hz 3 -10 dB 1.25 kHz 5 0 dB 8 kHz 5 0 dB 2Front 250 Hz 7 -10 dB 800 Hz 3 -4 dB 8 kHz 1 -5 dB (SEDAN-2) Rear 80 Hz 7 +3 dB 125 Hz 5 -12 dB 1.25 kHz 5 0 dB 3Front 125 Hz 5 -4 dB 1.25 kHz 3 -4 dB 2 kHz 7 +3 dB (MINI VAN-1) Rear 250 Hz 1 -6 dB 630 Hz 3 -4 dB 8 kHz 5 0 dB 4Front 250 Hz 3 -4 dB 1.25 Hz 3 -8 dB 80 Hz 3 +3 dB (MINI VAN-2) Rear 250 Hz 3 -8 dB 500 Hz 5 -5 dB 8 kHz 5 0 dB 5Front 250 Hz 3 -8 dB 1 kHz 3 -8 dB 10 kHz 1 -6 dB (WAGON) Rear 250 Hz 3 -8 dB 800 Hz 1 -8 dB 8 kHz 5 0 dB 6Front 500 Hz 1 0 dB 1 kHz 1 0 dB 5 kHz 1 0 dB (USER) Rear 500 Hz 1 0 dB 1 kHz 1 0 dB 5 kHz 1 0 dB

DXZ958RMC 39

Sound Adjustment

English

Notes:

• The screen displayed in step 3 appears, with the title being accompanied by “✓” mark.

Operation so far completes P.EQ adjustment. To continue to store the adjustment value to the P.EQ user menu, perform the following.

12. Touch [PRESET] to display the P.EQ menu

list.

13. Touch and hold [USER] for 2 seconds or

longer. You will hear a long beep, and the values you adjusted up to step 10 are stored to the P.EQ menu. If you hear a short beep, the adjustment values up to step 10 are discarded. Adjust these values again as required.

14. Press the [SOUND] button to return to the

original mode.

Dolby Pro Logic II

Dolby Pro Logic II is a matrix decoding technology in which updated digital matrix technology is applied and Dolby Pro Logic is further improved. Dolby Pro Logic II realizes excellent 5.1 channel reproduction of Dolby surround source as well as stereo sound sources such as CDs, thereby causing a surround channel to be full-ranged (20 Hz to 20 kHz) and become stereo. Therefore, you can enjoy any stereo sources with dynamic sound of

5.1 channel. The Music Mode or Matrix Mode

can be selected according to a source to be reproduced.

This product is manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.

Selecting the PL II menu (Dolby PL II)

This is available only when the speaker system is set to “Dolby PL II”. Select the MUSIC mode or the MATRIX mode matched the source you are to play as the Dolby Pro Logic II mode.

• The factory default setting is “MUSIC”.

■ MUSIC (music mode)

• This mode is suited for stereo sound sources such as CDs.

• Another adjustment mode (PL II CONT) that enables more detailed adjustment is also available because the sound field spreads differently depending on the state of the recorded music source. (See page 41)

■ MATRIX (matrix mode)

• This mode is suited for sound sources such as AM/FM radio.

1. Press the [SOUND] button.

2. Touch [Dolby PL II].

SOUND

1 2

FILTER FADER

GAIN

BALANCE

RTN

ADF

OFF

Dolby PL

MUSIC

The mode display is switched as follows:

MUSIC (music mode) ➜ MATRIX (matrix mode) ➜ MUSIC (music mode)...

3. Press the [SOUND] button to return to the

original mode. *For details on the volume adjustment of

the center speaker/sub-woofer, see page

36.

Adjusting the speaker gain level

Use the built-in test tone function so that the gain levels from all speakers become equal.

• The SP GAIN menu can be adjusted only when the Pro Logic II mode is set to “MUSIC” or “MATRIX”.

• The factory default setting is “0dB”.

1. Press the [SOUND] button.

2. Touch [SP GAIN].

SP GAIN MODE

FRONT - L

3. Touch

on the left of the display to select an item. Each touch switches the adjustment item as follows:

0dB

RTN

40 DXZ958RMC

●Adjustment items FRONT-L (Front left) ➜ CENTER*1 ➜ FRONT-R (Front right) ➜ SURROUND-R (Surround right) ➜ SURROUND-L (Surround left) ➜ SUB-WOOFER* FRONT-L...

“CENTER” is displayed only when

“CENTER-SP” (page 48) is set to “ON”.

“SUB-WOOFER” is displayed only when

“SUB-WOOFER” (page 48) is set to “ON”.

4. Touch adjust to the gain level.

•“SP-GAIN” can be adjusted within the

range -10dB to +10dB.

5. Repeat steps from 3 to 4 to adjust the desired item.

6. Press the [SOUND] button to return to the original mode.

on the right of the display to

➜

Adjusting the filter frequency

Filter frequency

You can set a filter frequency value best suited for your speakers.

• Depending on the settings for SPEAKER

SELECT, filters (HPF or SUB-W LPF) that can be adjusted differ. In the table below, “YES” refers to the item you can adjust while “NO” refers to the item you cannot adjust.

SPEAKER FILTER

SELECT HPF SUB-W LPF*

Dolby PL II No Yes

NORMAL Yes Yes

* This item can be adjusted only when “SUB-

WOOFER” is set to “ON”.

• The factory default setting for FILTER is

“THROUGH”.

Filter adjustment

● HPF (High-Pass Filter) adjustment

This filter cuts the signals under the selected frequency value. Each touch switches the frequency value as follows:

THROUGH ➜ 50Hz ➜ 80Hz ➜ 120Hz ➜ THROUGH...

Select the frequency that suits your speaker when you have installed speakers with smaller diameter. Set to “THROUGH” if you use speakers that can reproduce low frequency sound.

Sound Adjustment

● SUB-W LPF (Subwoofer Low-Pass Filter) adjustment

This filter cuts the signals above the selected frequency value. Each touch switches the frequency value as follows:

THROUGH ➜ 50Hz ➜ 80Hz ➜ 120Hz ➜ THROUGH...

Select the frequency that suits your subwoofer. Set to “THROUGH” if you use powered subwoofers with built-in low-pass filters.

1. Press the [SOUND] button.

2. Touch [FILTER].

3. Touch

select [HPF] or [SUB-W LPF].

4. Touch

select the frequency value.

• Select from THROUGH, 50Hz, 80Hz, or 120Hz.

5. Press the [SOUND] button to return to the original mode.

on the left of the display to

on the right of the display to

Setting the music mode

MUSIC mode

If you set Dolby Pro Logic II to “MUSIC”, you can further adjust the MUSIC mode in detail.

• This is available only when “MUSIC” has been

selected.

• The factory default settings are “NO” for

“PANORAMA”, “3” for “DIMENSION”, and “3” for “CTR WIDTH”.

Adjustment items

● PANORAMA (Panorama control setting)

Extends the front sound field image to rear speakers. Set to “YES” if you think the surround effect is not enough.

● DIMENSION (Dimension setting)

Shifts the sound field image to either front or rear. Set this item if the sound field image is weighted on either front or rear side. The center adjustment value is 3. Select from 0 to 2 for weighting on the rear side. Select from 4 to 6 for weighting on the front side.

● CTR WIDTH (Center width setting) *

Distributes a part of the center speaker sound to front speakers (left and right). By distributing the center sound to front speakers, the entire sound field image, and you can feel the natural broadening of the sound field image.

DXZ958RMC 41

English

Sound Adjustment

English

Set the value to “0” to reproduce all center sound from the center speaker. Set the value to “7” to distribute all center sound to left/right front speakers, just like a normal stereo system.

*“CTR WIDTH” is displayed only when

“CENTER-SP” is set to “ON”.

1. Press the [SOUND] button.

2. Touch [Å]/[Î] to go to the next page.

3. Touch [Dolby PL II CONT].

• The items to set are “PANORAMA”, “DIMENSION”, and “CTR WIDTH”.

4. Touch

select the item.

on the left of the display to

Dolby PL CONT

PANORAMA

RTN

4. Touching on the right of the display to adjust the delay time.

•“SRD-SP” can be adjusted within the

range 0ms to 15ms.

5. Press the [SOUND] button to return to the original mode.

5. Touch

adjust the values.

•For “PANORAMA”, select “YES” or “NO”.

•“DIMENSION” can be adjusted within the range 0 to 6.

•“CTR WIDTH” can be adjusted within the range 0 to 7.

6. Press the [SOUND] button to return to the original mode.

on the right of the display to

Adjusting the rear speaker delay time

Delay time

The time necessary for sound to travel from speakers to a listener differs depending on the speaker location or the car size. By adjusting the delay time of each speaker, you can hear the sound from the front speakers and the other speakers simultaneously.

• This item can be adjusted only when

“SPEAKER SELECT” is set to “Dolby PL II”.

• The factory default setting is “0ms”.

1. Press the [SOUND] button.

2. Touch [Å]/[Î] to go to the next page.

3. Touch [SRD DELAY].

SRD DELAY

SRD SP

0ms

42 DXZ958RMC

RTN

Common Operations

English

Screen display in the TITLE INPUT

The “TITLE INPUT” screen appears when you enter a title.

FONT display

a a-Z

FONT

MEMO

Title display

TITLE INPUT

Me I o d y

TEXT display

TEXT

RTN

FONT display

A: Capital alphabet letters a: Small alphabet letters 1: Numbers

U: Symbols

A¯: Umlaut

Title display

The currently entered title is displayed.

TEXT display

Touch

to select the character to enter.

Touching these buttons moves the cursor indicating input position.

RTN

Touching this cancels entry of titles, and returns the display to the original screen.

MEMO

Touching this stores the title that was input, and returns the display to the original screen.

Entering titles

You can give TV stations, CDs, and MUSIC MATCHER files a title up to 10 characters long. These titles can be displayed when broadcasts are received or when playing CDs.

The number of titles that can be entered is as follows:

Mode Number of titles

CD mode 50 titles TV mode 20 titles MUSIC CATCHER mode

64 titles (Only for folder names)

CD changer mode Number of titles

DCZ628 connected 100 titles CDC655Tz connected 100 titles CDC1255z connected 50 titles

1. Either receive the TV station, or play a CD or MUSIC CATCHER file for which you want to enter the title.

2. Touch [DISP].

3. Touch [INPUT].

DISPLAY EDIT

BGV

AVIL.

FOLDER00002

L-BLUE

208:43 SP/ANA COLOR

INPUT

RTN

TITLE

The TITLE INPUT screen appears.

4. Touch [

]/[ ] to move the cursor to indicate

the input position.

TITLE INPUT

A A-Z

FONT

MEMO

TEXT

RTN

∗ Up to ten characters can be input.

CAUTION

Pressing the reset button clears all user memories such as titles stored on this unit.

5. Touch

text. Each touch of text as follows:

Capital alphabet letters

(space) A B C D E F G H I J K L M N O P Q R S T U V W X Y Z

Small alphabet letters

a b c d e f g h i j k l m n o p q r s t u v w x y z

Numbers

0 1 2 3 4 5 6 7 8 9

Symbols

Umlaut

Å Ä Ë É E Ê Ï Æ Ø å ä ë é e ê ï ö ü æ ø

6. Touch

characters to enter.

7. Repeat steps 4 to 6 to enter the title.

8. Touch [MEMO]. You will hear a long beep, and the title is stored in memory.

on [FONT] to select the type of

switches the type of

on [TEXT] to determine the

DXZ958RMC 43

Common Operations

English

Clearing titles

1. Either receive the TV station, or play a CD or MUSIC CATCHER file whose title you want to clear.

2. Touch [DISP].

3. Touch [INPUT].

4. Touch and hold [RTN] for 2 seconds or longer to erase the title.

5. Touch [MEMO]. ∗ Erasing is performed by overwriting with a

blank title.

Cellular telephone mute

This unit requires special wiring to mute the audio signal automatically when a cellular telephone rings in the car.

∗ This function is not compatible with all cellular

telephones. Contact your local authorized Clarion dealer for information on proper installation and compatibility.

Changing settings

Selecting setting items

1. Press the [ADJ] button. The mode changes to the adjust mode.

1 1

APPEARANCE

RECENT

2. Touch [APPEARANCE], [SOUND], [TUNER], or [SETTING].

3. Touch

select the item to set.

4. When “ENT” is displayed at the right of the display, touch [ENT] to switch to the adjustment details display.

5. Touch

set the details.

■ To return to the original mode

1. Press the [ADJ] button again.

■ To call up the last operated item

1. Touch [RECENT].

ADJ

SETTINGSOUND

TUNER

RTN

on the left of the display to

on the right of the display to

44 DXZ958RMC

Common Operations

● Setting items

Main item Sub item

APPEARANCE MSG INFO

• Setting the message display ON/OFF (cf. page 46)

MSG INPUT

• Message information input (cf. page 46)

DIMMER IN

•Auto-dimmer setting (cf. page 46)

DMR LEVEL

• Setting the dimmer level (cf. page 47)

BRIGHT

• Adjusting the display brightness (cf. page 47)

BLINK LED

• Making the LED blink when DCP is removed (cf. page 47)

BEEP

• Setting beep (cf. page 47)

SCROLL SPD

• Adjusting the scroll speed (cf. page 48)

SRC ICON

• Setting the source icon display (cf. page 48)

SOUND EQ SELECT (When NORMAL, 3WAY or 2WAY is selected.)

• Setting P.EQ or BASS/TREBx (cf. page 48)

CENTER SP (When PL II is selected.)

• Setting center speaker ON/OFF (cf. page 48)

SUB WOOFER (When NORMAL, 3WAY or PL II is selected)

• Setting sub woofer speaker ON/OFF (cf. page 48)

AMP CANCEL

• Setting internal amplifier use ON/OFF (cf. page 49)

TUNER RDS-IN REC

• Setting the RDS/DAB interrupt while the MUSIC CATCHER function is in use. (cf. page 30)

LINK ACT

• Setting the AF function between RDS and DAB (cf. page 20)

LANGUAGE

• Setting the PTY screen language (cf. page 24)

TV AREA

• Setting the TV area (cf. page 58)

TV DIVER

• Setting TV diversity (cf. page 58)

SETTING AUX/TEL

• Setting AUX and TEL (cf. page 49)

AUX SENS

• Setting the portable audio (AUX) input level (cf. page 49)

TEL-SP

• Setting the car speaker output for the cellular phone (Optional TEL-002) (cf. page 49)

TEL-SWITCH

• Cellular phone interrupt setting (cf. page 50)

CALIBRATE

• Setting the auto-volume function (cf. page 50)

SYSTEM CHECK

•Performing a system check (cf. page 51)

CODEMATIC

• Setting security (cf. page 51)

SLIDE CONT

• Setting the slide direction of the slide buttons (cf. page 52)

English

DXZ958RMC 45

Common Operations

English

Displaying messages (MSG INFO)

This function allows you to display a message on the display when no operation is performed for more than 30 seconds.

• The factory default setting is “OFF”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [APPEARANCE].

3. Touch

on the left of the display to

select "MSG INFO".

ADJ APPEARANCE

MSG INFO OFF

RTN

4. Touch

on the right of the display to

select “ON” or “OFF”.

5. Press the [ADJ] button to return to the original mode.

Entering messages to display in message information (MSG INPUT)

• Up to 30 characters can be entered.

• The factory default setting is “Active MatriX

Control System”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [APPEARANCE].

3. Touch

select "MSG INPUT".

MSG INPUT

4. Touch [ENT]. The mode changes to the message entry mode.

5. Touch [ position.

FONT

on the left of the display to

ADJ-APPEARANCE

RTN

]/[ ] to determine the entry

MESSAGE INPUT

Active Mat

MEMO

RTN

[

ENT

A-

TEXT

6. Touch on [FONT] to select the type of text. Each touch of

switches the type of

text. For details, see page 43.

7. Touch

on [TEXT] to determine the

character to enter.

8. Repeat steps 5 to 7 to enter the message.

9. Touch [MEMO]. You will hear a long beep, and the message is stored in memory.

10. Press the [ADJ] button to return to the original mode.

Setting the auto-dimmer (DIMMER IN)

This function allows you to dim the lighting of the display matched to the illumination or the brightness inside your car.

Select either “AUTO” (interlocked to the brightness inside your car) or “ILLUMI” (interlocked to the illumination inside your car) as the auto-dimmer setting.

• When the auto-dimmer function is set to

“AUTO”, the brightness of the display is dimmed according to the brightness detected by this sensor.

• Set the dimmer setting at DMR LEVEL.

• The factory default setting is “AUTO”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [APPEARANCE].

3. Touch

select “DIMMER IN”.

]

D I MMER I N AUTO

4. Touch on the right of the display to select “AUTO ” or “ILLUMI”.

5. Press the [ADJ] button to return to the original mode.

on the left of the display to

ADJ APPEARANCE

RTN

46 DXZ958RMC

Common Operations

English

Setting the dimmer level (DMR LEVEL)

This function allows you to set how much the displayed is to be dimmed.

• The factory default setting is “3”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [APPEARANCE].

3. Touch

select “DMR LEVEL”.

DMR LEVEL 3

4. Touch

set the dimmer level. ∗ Select one of OFF (dimming OFF, bright),

1 (slightly dimmed) to 5 (dark).

5. Press the [ADJ] button to return to the original mode.

on the left of the display to

ADJ APPEARANCE

RTN

on the right of the display to

Adjusting the brightness of the display (BRIGHT)

You can adjust the brightness of the display to match the mounting angle of the unit.

• The factory default setting is “5”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [APPEARANCE].

3. Touch

select “BRIGHT”.

on the left of the display to

ADJ APPEARANCE

BRIGHT

Making the LED blink when DCP is removed (BLINK LED)

You can make the LED on this unit blink when the DCP is removed.

• The factory default setting is “OFF”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [APPEARANCE].

3. Touch select “BLINK LED”.

BL INK LED

4. Touch

select “ON” or “OFF”.

5. Press the [ADJ] button to return to the original mode.

on the left of the display to

ADJ APPEARANCE

OFF

RTN

on the right of the display to

Setting the beep for when buttons are operated (BEEP)

The short or long high-pitched tone you hear when a button is operated is called a “BEEP”.

• The factory default setting is “ON”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [APPEARANCE].

3. Touch select “BEEP”.

on the left of the display to

ADJ APPEARANCE

BEEP

OFF

RTN

4. Touch

adjust the brightness. ∗ This setting item can be adjusted within

the range 1 to 12.

Adjust this setting item while viewing how

the appearance of the display changes.

5. Press the [ADJ] button to return to the original mode.

on the right of the display to

4. Touch on the right of the display to select “ON” or “OFF”.

5. Press the [ADJ] button to return to the original mode.

DXZ958RMC 47

Common Operations

English

Adjusting the title scroll speed (SCROLL SPD)

This feature allows you to slow down the scroll speed when the scroll speed is too fast, making it difficult to view the screen.

• The factory default setting is “SPEED 1”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [APPEARANCE].

3. Touch

select “SCROLL SPD”.

SCROLL SPD

4. Touch

adjust the sensitivity. ∗ This setting item can be adjusted within

the range SPEED 1 to SPEED 4.

5. Press the [ADJ] button to return to the original mode.

on the left of the display to

ADJ APPEARANCE

RTN

on the right of the display to

Setting the source icon (SRC ICON)

You can change the source icon on the display.

• The factory default setting is “ICON”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [APPEARANCE].

3. Touch

select “SRC ICON”.

on the left of the display to

ADJ APPEARANCE

SRC

I CONI CON

RTN

Selecting the equalizer (EQ SELECT)

You can change the equalizer that adjusts the sound quality.

• The factory default setting is “P.EQ”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [SOUND].

3. Touch select [EQ SELECT].

4. Touch

select [EQ SELECT] or [BASS/TREB].

5. Press the [ADJ] button to return to the original mode.

on the left of the display to

ADJ SOUND

P.EQSELECT

RTN

on the right of the display to

Setting speakers ON/OFF (CENTER-SP/SUB-WOOFER)

Set the center speaker (CENTER-SP) and subwoofer (SUB-WOOFER) ON/OFF.

Be sure to set this setting to “OFF” when there is no center speaker or sub-woofer.

• The factory default setting is “ON” or “ST”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [SOUND].

3. Touch select “CENTER-SP” or “SUB-WOOFER”.

SUBSTWOOFER

on the left of the display to

ADJ SOUND

RTN

4. Touch

select “ICON” or “SPE/ANA”.

5. Press the [ADJ] button to return to the original mode.

on the right of the display to

48 DXZ958RMC

4. Touch on the right of the display to select "ON", "ST", "MONO", or "OFF".

5. Press the [ADJ] button to return to the original mode.

Setting internal amplifier use ON/OFF (AMP CANCEL)

Set internal amplifier use ON/OFF matched to whether or not an external amplifier is used.

Set AMP CANCEL to “ON” (internal amplifier use OFF) when an external amplifier is connected and the internal amplifier is not used.

• The factory default setting is “OFF” (internal amplifier used).

1. Press the [ADJ] button to set to the adjust

mode.

2. Touch [SOUND].

3. Touch

select “AMP CANCEL”.

AMP

4. Touch

select “ON” or “OFF”.

5. Press the [ADJ] button to return to the

original mode.

on the left of the display to

ADJ SOUND

OFFCANCEL

RTN

on the right of the display to

AUX function

This system has an external RCA input so you can listen to sounds and music from external devices connected to this unit.

Selecting AUX / TEL

You can listen to sound and music from external devices, or your telephone calls from the speakers when connected to this unit.

When TEL INT or External device is connected to this unit, you can select the TEL mode or AUX mode.

• The factory default setting is “AUX”.

1. Press the [ADJ] button to set to the adjust

mode.

2. Touch [SETTING].

3. Touch

select “AUX/TEL”.

on the left of the display to

ADJ SETTING

AUX/TEL

AUX

RTN

Common Operations

4. Touch on the right of the display to select “AUX” or “TEL”.

AUX:

The AUX/TEL input cable is for external Audio input.

TEL:

The AUX/TEL input cable is for cellular phone audio input.

5. Press the [ADJ] button to return to the original mode.

Setting the input level (AUX SENS) of portable audio (AUX mode)

This function allows you to set the input level of optional external devices connected to this unit.

• The factory default setting is “MID”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [SETTING].

3. Touch

select "AUX SENS".

4. Touch on the right of the display to set the input level. ∗ Select LOW, MID or HIGH.

Notes:

• When the input level is overloaded, “OVERLOAD”

appears. Adjust AUX SENS or the input level so that “OVERLOAD” disappears.

5. Press the [ADJ] button to return to the original mode.

on the left of the display to

ADJ SETTING

AUX

SENS

MID

RTN

Setting the car speaker output for the cellular phone (Optional TEL-002)

•To output telephone calls, set the cellular

phone.

• The factory default setting is “RIGHT”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [SETTING].

English

DXZ958RMC 49

Common Operations

English

3. Touch on the left of the display to select “TEL-SP”.

ADJ SETTING

TEL-SP

RIGHT

MUTE:

The sound from this unit is muted during telephone calls.

5. Press the [ADJ] button to return to the original mode.

RTN

4. Touch on the right of the display to select “LEFT” or “RIGHT”.

LEFT:

Telephone calls can be heard on the front left speaker connected to this unit.

RIGHT:

Telephone calls can be heard on the front right speaker connected to this unit.

5. Press the [ADJ] button to return to the original mode.

Cellular phone interrupt setting

If you connect this unit and your cellular phone with a unit (Optional, TEL-002), you can listen to your telephone calls on your car speakers.

• The factory default setting is “OFF”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [SETTING].

3. Touch

on the left of the display to

select “TEL-SWITCH”.

ADJ SETTING

TEL-SWITCH

OFF

RTN

4. Touch on the right of the display. Each time you touch, the setting changes in the following order:

OFF ➜ ON ➜ MUTE ➜ OFF...

OFF:

This unit continues normal operation even when the cellular phone is used.

Note:

• When connecting a hands-free kit, make sure

that the setting is ON to receive the telephone audio through the system.

ON:

You can listen to your telephone calls from the speakers connected to this unit. ∗ When listening to your calls on your car

speakers, you can adjust the volume by turning the [ROTARY] knob.

50 DXZ958RMC

Setting the auto-volume function (CALIBRATE/A-VOL SENS)

You can automatically change the volume to match your car's speed.

• The factory default setting is “LOW”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [SETTING].

3. Touch on the left of the display to select “CALIBRATE”.

ADJ SETTING

[

CALIBRATE

4. Accelerate to a speed of 50 km.

5. When you reach 50 km, touch [START]. Calibration is executed. After 2 seconds or longer, you will hear a long beep, and “SUCCESSFUL” will appear on the display. If you hear a short beep, this indicates that calibration failed. Repeat the procedure from step 4.

6. Next, adjust the sensitivity. Touch [SETTING].

7. Touch

on the left of the display to

select “A-VOL SENS”.

ADJ SETTING

A-VOL SENS

LOW

8. Touch on the right of the display. Each time you touch, the setting changes in the following order:

OFF (no change in volume) ➜ LOW (change in volume: small) ➜ MID-LOW ➜ MID ➜ MID-HIGH ➜ HIGH (change in volume: large) ...

9. Press the [ADJ] button to return to the original mode.

START

RTN

]

Performing a system check (SYSTEM CHECK)

This function allows you to perform a system check when an external equipment is connected to this unit or the “SPEAKER SELECT” is changed.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [SETTING].

3. Touch

select “SYSTEM CHECK”.

SYSTEM

4. Touch [START]. The confirmation display appears.

5. Touch [OK].

When the system check is complete, “SPEAKER SELECT” screen appears. Select the speaker system. For details on the speaker system, see “Selecting a speaker system” (cf. page 14). After this operation, the display returns to the original mode.

on the left of the display to

ADJ SETTING

CHECK

RTN

ADJ SETTING

CANCEL

[

START

]

Common Operations

2. Touch [SETTING].

3. Touch

select “CODEMATIC”.

CODEMAT I C

2 types of items are displayed for “CODEMATIC”, items for which “ON” or “OFF” is displayed at the right of the screen, and items for which “INPUT” is displayed at the right of the screen. Here, select the item for which “ON” or “OFF” is displayed at the right of the display.

4. Touch

select “ON” or “OFF”.

5. Touch select “CODEMATIC”.

CODEMATIC

Here, select the item for which “INPUT” is displayed at the right of the display.

6. Touch [INPUT]. The Touch Code display appears.

7. Enter the touch code. ∗ Touch [1] to [4] at the bottom of the display

at random. You can also repeatedly touch the same number.

on the left of the display to

ADJ SETTING

OFF

RTN

on the right of the display to

on the left of the display to

ADJ SETTING

RTN

CODE MATIC

English

INPUT

Using the security function (CODEMATIC)

This function prevents persons who do not know the touch sequence from easily operating this unit. The Touch Code display appears when DCP is attached and the power is turned ON with “CODEMATIC” set to “ON”.

If you touch the display in this screen in the preset order, “SUCCESSFUL” is displayed and the power is turned OFF.

When the power is next turned ON, the Touch Code display does not appear, and the main display in the radio mode or CD mode is displayed.

• The factory default setting is “OFF”.

1. Press the [ADJ] button to set to the adjust mode.

1234

When you touch 4 times, and 4 indicators light, you will hear a long beep, and the original mode is returned to.

■ To cancel CODEMATIC

If you have forgotten the touch order, either touch [4], [1], [3] and then [2] in that order, or press [SCN] on the remote control unit.

DXZ958RMC 51

Common Operations

English

Setting the slide direction of the slide buttons (SLIDE CONT)

This function allows you to set the direction of the left and right slide buttons.

• The factory default setting is “UP ➜ +”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [SETTING].

3. Touch

select “SLIDE CONT”.

SLIDE

4. Touch

select “UP ➜ +” or “DOWN ➜ +”.

5. Press the [ADJ] button to return to the original mode.

on the left of the display to

ADJ SETTING

CONT UP

on the right of the display to

RTN

52 DXZ958RMC

7. OPERATIONS OF ACCESSORIES

CD Changer Operations

English

CD changer

When an optional CD changer is connected through the CeNET cable, this unit can control CD changer operations. This unit can be connected to a total of 2 CeNET-wired CD changers.

■ When 2 CD changers are connected

Press the [SRC] button to select the changer connected to this unit. (Each press of the [SRC] button switches the changer.)

• If the CD changer does not contain a

magazine, “NO MAGAZINE” is displayed, and if the magazine does not contain a CD, “NO DISC” is displayed.

• For details on the title display, see “Switching

the title display” (cf. page 16).

Screen displays in the changer mode

● Standard operation display

The standard operation display appears by pressing the [SRC] button to select changer modes.

Track No. display

TRACK

03:09

Title display

TELL ME

2:45

DISP

Disc No. display

DISC

Playing time display Î00:01: The playing time is displayed.

Track No. display

Touching

allows you to select the track to play, or fast-forward/fast-rewind tracks.

Title display

The selected title is displayed.

Disc No. display

Touching

selects discs.

Touching this pauses or resumes play.

DISP

The display contents can be changed.

a/d (only in the simple operation display)

Touching these selects the track to play. Touching and holding these fast-forwards/fastrewinds tracks.

/ (only in the simple operation

display)

Touching these buttons selects the disc to play.

CAUTION

CD-ROM discs cannot be played from every CD changer. This depends on the model.

Note:

• Some CDs recorded in the CD-R/CD-RW mode

may not be usable.

Playing time

DISP

display

● Simple operation display

Pressing and holding [MODE] button for 2 seconds or longer switches the simple operation display.

a/d

03:29

TELL ME

2:45

DISP

DISC

TRACK

DXZ958RMC 53

CD Changer Operations

English

Selecting the changer mode

1. Press the [SRC] button to select the changer mode. ∗ Each time you press the [SRC] button, the

display switches as follows:

Radio ➜ (DAB) ➜ CD/MP3 ➜ M. CATCHER ➜ (CD changer) ➜ (DVD changer) ➜ (TV) ➜ AUX ➜ Radio...

∗ The mode of equipment that is not

connected is not displayed.

Play starts automatically when the mode

changes to the changer mode.

Pausing play

1. Touch [s].

■ To resume play

1. Touch [s] again.

Selecting a CD

1. Touch on the disc No. display to select a disc. Play starts. ∗ If magazine does not contain the disc you

selected, the No. for that disc is not displayed.

Selecting a track

1. To listen to the next track, touch on the track display.

2. To listen to the previous track, touch twice on the track display. Touching touch ahead to the track for the number of times you touched Touching touch more times, the track moves back to the track for the number of times you touched ∗ If you touch twice on the track display

while the start of the track is being played, the track 2 tracks back is sometimes played.

plays the next track. If you

more times, the track advances

and that track is played.

plays the previous track. If you

and that track is played.

Fast-forward/fast-rewind

1. To fast-forward, touch on the track display.

2. To fast-rewind, touch on the track display.

Scan play

Scan play locates and plays the first 10 seconds of each track on a disc automatically. This function continues on the disc until it is canceled.

The scan play function is useful when you want to select a desired track.

1. Press the [MODE] button.

2. Touch [TRACK-SCAN]. ∗ Scan play starts from the next track after

the track currently being played.

■ To cancel scan play

1. Press the [MODE] button.

Disc scan play

Disc scan play locates and plays the first 10 seconds of the first track on each disc in the currently selected changer. This function continues automatically until it is canceled.

Disc scan play is useful when you want to select a desired disc.

1. Press the [MODE] button.

2. Touch [DISC SCAN]. ∗ Disc scan play starts from the next disc

after the disc currently being played.

■ To cancel disc scan play

1. Press the [MODE] button.

Repeat play

Repeat play continuously plays the current track. This function continues automatically until it is canceled.

1. Press the [MODE] button.

2. Touch [TRACK RPT].

■ To cancel repeat play

1. Press the [MODE] button.

54 DXZ958RMC

Disc repeat play

After all the tracks on the current disc have been played, disc repeat play automatically replays the current disc over from the first track. This function continues automatically until it is canceled.

1. Press the [MODE] button.

2. Touch [DISC RPT].

■ To cancel disc repeat play

1. Press the [MODE] button.

Random play

Random play selects and plays individual tracks on the disc in no particular order. This function continues automatically until it is canceled.

1. Press the [MODE] button.

2. Touch [TRACK RDM].

■ To cancel random play

1. Press the [MODE] button.

Disc random play

The disc random play selects and plays individual tracks or discs automatically in no particular order. This function continues automatically until it is canceled.

1. Press the [MODE] button.

2. Touch [DISC RDM].

■ To cancel disc random play

1. Press the [MODE] button.

CD Changer Operations

English

DXZ958RMC 55

TV Operations

English

TV tuner function

When an optional TV tuner is connected through the CeNET cable, this unit controls all TV tuner functions. To watch TV, you need a TV tuner and a monitor.

Screen displays in the TV mode

● Standard operation display

The standard operation display appears by pressing the [SRC] button to select the TV mode.

Channel display

Title display

3ch

MANU

PRESET BAND PS AS

PRESET

SEEK/MANU

BAND

indicator

● Simple operation display

Pressing and holding the [MODE] button for 2 seconds or longer switches the simple operation display.

a/d

MANU

3ch

PRESET BAND PS AS

Channel display 3ch: The channel currently being received is

displayed. Touching

or in the standard operation display allows you to perform seek tuning or manual tuning.

Title display

The name of the station currently being received is displayed.

VTR : In video mode Touching these switches the display.

Reception band display

TV1

2:45

DISP

PS/AS

TV1

2:45

DISP

Preset No. display

P.C H

DISP

P.C H

Reception band display TV1 : Band name

Preset No. display

Touching on the right slide button in the standard operation display selects a preset memory. Touching [PRESET] displays the preset memory number list.

PS/AS

Touching this starts a preset scan. Touching and holding this for 2 seconds or longer starts an auto store. Touching this during the preset scan/auto scan ends the operation.

BAND

Touching this switches the reception band. Touching and holding this for 1 second or longer toggles between the manual tuning mode and the seek tuning mode.

a/d (only in the simple operation display)

Touching these buttons enables seek tuning or step tuning (in the manual tuning mode). Touch and holding these buttons enables quick tuning (in manual tuning mode).

DISP

The display contents can be changed.

Selecting the TV mode

1. Press the [SRC] button to select the TV mode. Each press of the [SRC] button switches the mode as follows:

Radio ➜ (DAB) ➜ CD/MP3 ➜ M. CATCHER ➜ (CD changer) ➜ (DVD changer) ➜ (TV) ➜ AUX ➜ Radio...

∗ The mode of equipment that is not

connected is not displayed.

Switching the reception band

1. Touch [BAND] to switch the reception band. Each touch of [BAND] switches the reception band.

TV1 ➜ TV2 ➜ TV1...

56 DXZ958RMC

TV Operations

English

Seek tuning

Seek tuning is a function for automatically tuning stations with good reception.

1. Touch and hold [BAND] for 1 second or longer while “MANU” is displayed. Automatic tuning is possible when “SEEK” is displayed.

2. Touch “SEEK UP/SEEK DOWN” is displayed, and tuning starts. Tuning automatically stops at stations with good reception.

on the channel display.

■ To cancel tuning

1. Touch on the channel display again.

Manual tuning

There are 2 ways available: quick tuning and step tuning.

In the step tuning mode, the frequency changes 1 step at a time. In the quick tuning mode, you can quickly tune the desired frequency.

1. Touch and hold [BAND] for 1 second or longer if “SEEK” is displayed. Manual tuning is possible when “MANU” is displayed.

2. Operate the channel display to tune to a channel on which there is a broadcast.

● Step tuning

Touch on the channel display.

● Quick tuning

Touch stops when you take your finger away from the panel.

on the channel display. Tuning

Preset memory

A total of 12 TV stations can be stored (6-TV1 and 6-TV2). This allows you to select your favorite TV stations and store them in memory for later recall.

1. Touch [BAND] to switch the reception band.

2. Operate the channel display to select the station to store to.

3. Touch [PRESET]. The preset memory No. list is displayed.

4. Touch and hold the preset No. to store for 2 seconds or longer. You will hear a long beep, and the station is stored in memory.

Auto store

Auto store selects 6 TV stations automatically and stores each one into preset memory.

1. Touch and hold [PS/AS] for 2 seconds or longer. “A-STORE” appears on the display. ∗ Stations with good reception are

automatically searched, and are stored to preset memory (No.1 to No.6) in order from the station having the lowest frequency.

Notes:

• When auto store is performed, stations stored to

memory so far are cleared.

• When there are fewer than 6 stations with good

reception, low frequencies are automatically returned to, and auto store is performed again. If there are fewer than 6 stations even after auto store is performed twice, stations stored so far remain in memory.

Recalling a preset station

This function allows the user to select a preset station.

1. Touch [PRESET]. The preset memory No. list is displayed.

2. Touch the preset memory No. ∗ The station can also be tuned by touching

in the standard operation display.

■ To cancel tuning

1. Touch [RTN].

Preset scan

Preset scan is a function for receiving stations in the order that they are currently stored to preset No. so that broadcasts can be checked.

1. Touch [PS/AS]. “P-SCAN” appears on the display. ∗ The currently stored stations are received

in order for 7 seconds or longer each. Stations with poor reception are skipped, and the next station is received.

DXZ958RMC 57

TV Operations

English

■ To cancel the preset scan

1. Touch [PS/AS]. “P-SCAN” disappears, and the stations that were being received when [PS/AS] was touched are received next.

Watching a video

The TV tuner has a VTR input terminal to which 1 external device can be connected. Connect a 12 V video cassette player (VCP) or video cassette recorder (VCR) to the TV tuner input terminal.

1. Press the [MODE] button.

2. Touch [TV/VTR]. ∗ Every time you touch this, the function

switches between TV and VTR.

Setting the TV area (TV AREA)

When you select the TV area (TV reception area), the TV tuner area setting changes.

• The factory default setting is “GERMANY”.

1. Press the [ADJ] button to set the adjust mode.

2. Touch [TUNER].

3. Touch

select “TV AREA”.

on the left of the display to

ADJ TUNER

TV AREA

GERMANY

3. Touch on the left of the display to select [TV DIVER].

ADJ TUNER

TV DIVER

4. Touch on the right of the display to select [ON] or [OFF].

5. Press the [ADJ] button to return to the original mode.

RTN

4. Touch

select the area.

5. Press the [ADJ] button to return to the previous mode.

on the right of the display to

Setting the TV Diver

You can change the reception setting for the TV antenna connected to the TV tuner.

• Set this item to “OFF” when a TV diversity

antenna is not in use.

• The factory default setting is “ON”.

1. Press the [ADJ] button to set to the adjust mode.

2. Touch [TUNER].

58 DXZ958RMC

Digital Radio / DAB Operations

English

DAB control function

When a CeNET cable is used to connect a DAB (Optional, DAH913 or DAH923), all functions can be operated.

Listening to the DAB station

1. Press the [SRC] button to select the DAB mode.

Notes:

• The display shown in the normal reception mode

and the preset reception mode is the same as that when a DAB station is received.

• The number of programmes and broadcasting

times depend on the DAB station.

• When the strength of DAB signals is weak, audio

output is muted.

Seek tuning

1. Press the [SRC] button to select the DAB mode.

2. Touch and hold [BAND] for 1 second or longer if “MANU” is displayed. Seek tuning is possible when “SEEK” is displayed.

3. Touch on the left of the display. “DAB” lights up in the display when the main unit receives a DAB station. ∗ The main unit stops the seek tuning when

it cannot find a DAB station. The display returns to the original mode.

Manual tuning

1. Press the [SRC] button to select the DAB mode.

2. Touch and hold [BAND] for 1 second or longer if “SEEK” is displayed. Manual tuning is possible when “MANU” is displayed.

3. Touch on the left of the display to tune the station. ∗ If no operation is performed for more than

7 seconds, manual tuning is cancelled and the display returns to the seek turning mode.

Switching programmes

1. Press the [SRC] button to select the DAB mode.

2. Touch on the left of the display to switch programmes in the DAB station.

Note:

• The programme name may be the same

depending on the DAB programme.

Programme scan

This function scans through each receivable programme in a DAB station being received for 10 seconds sequentially. This is useful when you want to search for a desired programme.

1. Press the [SRC] button to select the DAB mode.

2. Touch [S-SCAN]. “S-SCAN” lights up and this unit starts scanning each programme for 10 seconds sequentially. Each time the main unit scans, the programme name is shown in the display.

3. To stop programme scan when a desired programme is tuned in touch [S-SCAN].

Manual memory

The main unit has a manual memory function for DAB programmes. Up to 18 programmes (6 programmes each) can be preset to the preset buttons.

[M1], [M2] and [M3]

1. Press the [SRC] button to select the DAB mode.

2. Touch [BAND] to select any one shown above.

3. Touch [PRESET]. The preset memory No. list is displayed.

4Touch and hold the preset No. to be stored

for 2 seconds or longer. You will hear a long beep, and the station is stored to memory. If you hear a short beep, the station is not stored to memory. Repeat the procedure from step 1.

Note:

• Interrupt programmes (PTY or INFO) cannot be

written to manual memory.

DXZ958RMC 59

Digital Radio / DAB Operations

English

Recalling a preset programme

1. Press the [SRC] button to select the DAB mode.

2. Touch [BAND]. Each touch of [BAND] changes the display in the following order:

M1 ➜ M2 ➜ M3 ➜ M1...

3. Touch recall a preset programme.

on the right of the display to

AF function

The AF function switches to a different frequency on the same network in order to maintain optimum reception.

• The factory default setting is “ON”.

• If the reception of the current broadcast

station deteriorates, “SEARCH” appears in the display and the radio searches for the same programme on another frequency.

•For details on the “AF function”(cf. page 20) ,

refer to the section “RDS operation” of the respective owner's manual.

● To switch the AF function ON

● To switch the AF function OFF

● AF function between RDS and DAB

When the same programme is broadcast by both RDS and DAB, and this function is ON, the main unit automatically switches to receive the broadcast with the better reception.

TA (Traffic Announcement)

When a traffic announcement broadcast starts in the TA standby mode, the traffic announcement broadcast is received as top priority regardless of the function mode. Traffic programme (TP) automatic tuning is also possible.

• This function can only be used when “TP” is lit

in the display. When “TP” is lit, this means that the DAB or RDS broadcast station being received has traffic announcement programmes.

•For details on “TA ” (cf. page 21), refer to the

section “RDS operation” of the respective owner's manual.

● To set the TA standby mode

● To cancel the TA standby mode

● To search for a TP station

Notes:

• If a TP station is not received, the main unit stops the search operation.

•“TP” may be lit in the display when a TP broadcast is transmitted from an RDS station. In this case, press the [TA] button to perform TP seek tuning. Press the [TA] button again to return to the previous mode.

INFO (Announcement)

In the INFO standby mode, when the selected announcement programme starts, the main unit automatically switches to the selected announcement programme.

● To set the INFO standby mode

If you press and hold the [TA] button for 1 second or longer, “INFO” lights in the display and the main unit is set to the INFO standby mode until the selected announcement is broadcast.

When the selected announcement broadcast starts, the announcement item appears in the display. If you press and hold the [TA] button for 1 second or longer while the selected announcement broadcast is being received, reception of the selected announcement broadcast is cancelled and the main unit enters the INFO standby mode.

● To cancel the INFO standby mode

To cancel the INFO standby mode, press and hold the [TA] button for 1 second or longer.

● Information select

This is a function for selecting INFORMATION ON or OFF in the Information interrupt mode.

You can set ON for up to 6 information items. You can select any of the 6 items below:

INFORMATION item

ENGLISH Contents

Tr avel Transport flash Warning Warning / Service News News flash Weather Area weather flash Event Event announcement Special Special event

60 DXZ958RMC

1. Press the [MODE] button.

2. Touch [INFO SELECT] to enter the “INFO SELECT” mode.

3. Touch on the left of the display to select an information item. You can select any of 6 items:

Tra vel ➜ Warning ➜ News ➜ Weather ➜ Event ➜ Special ➜ Travel...

4. Touch select “ON” or “OFF”.

5. Touch [RTN].

on the right of the display to

PTY

This function enables you to listen to the selected programme type regardless of the function mode.

• One common PTY can be selected for DAB or

RDS.

• Of DAB PTY and RDS PTY, the PTY which is

received earlier takes priority over the other.

• PTY broadcasts are not yet available in all

countries.

• In the INFO standby mode, INFO stations

have priority over PTY stations.

• In the TA standby mode, TP stations have

priority over PTY stations.

•For details on “PTY”(cf. page 22) , refer to the

section “RDS operation” of the respective owner's manual.

● To set the PTY standby mode

● To cancel the PTY standby mode

● To cancel a PTY interrupt broadcast

● To select PTY

● PTY seek

● PTY preset memory

Digital Radio / DAB Operations

Switching the PTY and INFO display language

You can select one of 4 languages (English, German, Swedish or French) for the PTY and INFO shown in the display.

• The factory default setting is “ENGLISH”.

•For details on “Switching the PTY display language” (cf. page 24), refer to the section “RDS operation” of the respective owner's manual.

Volume setting of TA, INFO, emergency broadcast (ALARM) and PTY

The volume for TA, INFO, ALARM and PTY interrupt broadcasts can be set during TA, INFO, ALARM and PTY interrupt broadcasts. Perform the following operation depending on the connected model.

• The factory default setting is “15”.

During a TA, INFO, ALARM or PTY interrupt broadcasts, turn the [ROTARY] knob clockwise or counterclockwise to set the volume to a desired level (0 to 33).

• When the TA, INFO, ALARM or PTY interrupt broadcast ends, the volume returns to the level that was active before the interrupt broadcast.

English

Emergency broadcast

When an emergency broadcast is received, all function mode operations are stopped, “ALARM” appears in the display, and the emergency broadcast can be heard.

•For details on “Emergency broadcast” (cf. page 23), refer to the section “RDS operation” of the respective owner's manual.

● To cancel an emergency broadcast

DXZ958RMC 61

English

8. IN CASE OF DIFFICULTY

Problem

Power does not turn on. (No sound is produced.)

No audio when operating the unit with amplifiers.

Nothing happens when buttons are pressed.

General

Display is not accurate.

No sound heard.

Sound skips or is noisy.

CD/MP3/WMA

Sound is cut or skipped. Noise is generated or noise is mixed with sound.

Cause

Fuse is blown.

Incorrect wiring.

Amplifier turn-on lead is shorted to ground or excessive current is required.

The microprocessor has malfunctioned due to noise, etc.

DCP or main unit connectors are dirty.

The speaker protection circuit is operating.

There is a disc other than a compact disc or foreign matter already in place.

MP3/WMA files are absent in a disc.

Files are not recognized as an MP3/WMA file.

File system is not correct.

Disc is dirty.

Disc is heavily scratched or warped.

MP3/WMA files are not encoded properly.

Measure

Replace with a fuse of the same amperage. If the fuse blows again, consult your store of purchase.

Consult your store of purchase.

Tu rn the unit off and check each wire for a possible short. If the amplifier turn-on lead shorts out, cover it with insulation such as tape.

Tu rn off the power, then remove the DCP by referencing "Removing the DCP" (cf. page 10). Press the reset button for about 2 seconds with a thin rod.

Wipe the dirt off with a soft cloth moistened with cleaning alcohol.

1. Check the speaker connection.

2. Turn down sound volume. Function can also be restored by turning the power off and on again.

3. If the sound is muted again, consult your store of purchase.

With the SLOPING CONSOLE open, press and hold the [Q] button for 3 seconds or longer. The foreign matter is forcibly ejected.

Write MP3/WMA files onto the disc properly.

Use MP3/WMA files encoded properly.

Use ISO9660 level 1, 2 or JOLIET or Romeo file system.

Clean the disc with a soft cloth.

Replace with a disc with no scratches.

Use MP3/WMA files encoded properly.

Reset button

62 DXZ958RMC

English

Problem

Sound is bad directly after power is turned on.

Wrong filename

Play list play is

CD/MP3/WMA

not performed.

Cause Measure

Water droplets may form on the internal lens when the car is parked in a humid place.

File system is not correct.

File name or extension is not correct.

Let dry for about 1 hour with the power on.

Use ISO9660 level 1, 2 or JOLIET or Romeo file system.

Use alphanumeric/ASCII characters for MP3/WMA file name. Use “.M3U” for the file extension of a play list.

DXZ958RMC 63

English

9. ERROR DISPLAYS

If an error occurs, one of the following displays is displayed. Ta ke the measures described below to eliminate the problem.

Error Display Measure

ERROR 2

ERROR 3

ERROR 6

CD/MP3/WMA

ERROR 7

ERROR 8

ERROR 9

M.CATCHER

ERROR 2

ERROR 3

CD changer

ERROR 6

ERROR 2

ERROR 3

A DISC is caught inside the CD deck and is not ejected.

A DISC cannot be played due to scratches, etc.

A DISC is loaded upside-down inside the CD deck and does not play.

The format of the flash memory is damaged.

There is a failure with the flash memory.

An error during recording, scratch on the disc, or error due to sound skips

A DISC inside the CD changer is not loaded.

A DISC inside the CD changer cannot be played due to scratches, etc.

A DISC inside the CD changer cannot be played because it is loaded upside-down.

A DISC inside the DVD changer cannot be played.

A DISC cannot be played due to scratches, etc.

Cause

This is a failure of CD deck’s mechanism and consult your store of purchase.

Replace with a non-scratched, non-warped-disc.

Eject the disc then reload it properly.

Execute ALL ERASE on the flash memory, and the problem is solved.

Tu rn POWER/ACC off and then turn it on again, and the problem is solved.

Tu rn POWER/ACC off and then turn it on again, or eject the CD. The problem is solved.

This is a failure of CD changer’s mechanism and consult your store of purchase.

Replace with a non-scratched, non-warped disc.

Eject the disc then reload it properly.

This is a failure of DVD mechanism and consult your store of purchase.

Retry or replace with a non-scratched, nonwarped-disc.

ERROR 6

DVD changer

ERROR P

ERROR R

AMP GUARD

General

A DISC inside the DVD changer cannot be played because it is loaded upside-down.

Parental level error

Region code error

The speaker protection circuit is operating. During this operation, if any volume operation is performed, the display shows “AMP GUARD”. “AMP GUARD” sometimes functions when special test signals are used.

Eject the disc then reload it properly

Set the correct Parental level.

Eject the disc and replace correct region code disc.

1. Tur n down sound volume. Function can also be restored by turning the power off and on again. (Speaker volume is reduced automatically when the speaker protection circuit operates).

2. If the sound is muted again, consult our service department.

If an error display other than the ones described above appears, press the reset button. If the problem persists, turn off the power and consult your store of purchase.

64 DXZ958RMC

10. SPECIFICATIONS

English

Radio section

Tuning System: PLL synthesizer tuner Receiving Frequencies:

FM : 87.5 to 108 MHz (0.05 MHz steps) MW : 531 to 1602 kHz (9 kHz steps) LW : 153 to 279 kHz (3 kHz steps)

CD Player

System:

Compact disc digital audio system

Usable Discs:

Compact disc

Frequency Response (±1 dB):

5 Hz to 20 kHz

Signal to Noise Ratio (1 kHz):

100 dB

Dynamic Range (1 kHz):

96 dB

Harmonic Distortion:

0.005%

MC mode

HQ:

Approximately 266 minutes, 66 tracks (4 minutes for each)

LP:

Approximately 354 minutes, 88 tracks (4 minutes for each)

Audio

Output Power:

4 × 31 W (DIN 45324, +B=14.4 V)

Continuous Average Power Output:

18 W × 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD

Bass Control Action (50 Hz):

±12 dB

Treble Control Action (12.5 kHz):

±12 dB

Line Output Level (CD 1 kHz):

4 V/F 2ch + 4V/R 2ch 4 V/SUB WOOFER 2ch

General

Power Supply Voltage:

14.4 V DC (10.8 to 15.6 V allowable), negative ground

Current Consumption:

Less than 15 A, 3A

Speaker Impedance:

4 Ω (4 Ω to 8 Ω allowable)

Weight / Main unit:

1.7 kg

Weight / Remote control unit:

40 g (including battery)

Dimensions / Main unit:

178 (W) × 50 (H) × 160 (D) mm

Dimensions / Remote control unit:

44 (W) × 113 (H) × 13 (D) mm

Note:

• Specifications and design are subject to change without notice for further improvement.

DXZ958RMC 65

2005/1 (Abe·Abe)

Clarion Co., Ltd.

Printed in China / Imprimé en Chine / Gedruckt in China / Stampato in Cina

Gedrukt in China / Impreso en China / Tryckt i Kina / Impresso na China

PE-2743E

280-8180-00

Clarion DXZ958RMC User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1. PRECAUTIONS

Sloping Console

Handling Compact Discs

2. CONTROLS

3. NOMENCLATURE

Names of the Buttons and their Functions

Operations when External Equipment is Connected to this Unit

Touch Panel Buttons

Touch Panel Operations

4. DCP

5. REMOTE CONTROL

Inserting the Battery

Functions of the Remote Control Unit Buttons

6. OPERATIONS

Basic Operations

Radio Operations

RDS Operations

CD/MP3/WMA Operations

MUSIC CATCHER Operations

Sound Adjustment

Common Operations

7. OPERATIONS OF ACCESSORIES

CD Changer Operations

TV Operations

Digital Radio / DAB Operations

8. IN CASE OF DIFFICULTY

9. ERROR DISPLAYS

10. SPECIFICATIONS
