INTRODUCTION
The Clarion DPX1000.2 is a full-featured two-channel amplifier that.
incorporates the following features:
• Digital Technology for high efficiency and high power output.
• Full frequency response with low distortion and exceptional signal to
noise performance
• Advanced circuit design that features bridgeable and mixed mode
operation for use in various systems, including those with satellite
speakers and/or subwoofers
• Variable low-pass electronic crossover with a 12dB or 24db per octave
slope and full adjustable range (from 55Hz to 550Hz) to aid in audio
system design
• Variable bass boost circuit to reinforce low frequency signals that may be
lost due to subwoofer box design
• Adjustable input level controls with ground loop isolation accepting a
wide range of input signals
• Remote turn-on with “soft start” muting to prevent turn on “thump”
• Pulse-width modulated (PWM) MOSFET power supply with low AM
RFI and protection circuits for overheating and speaker shorts
• 1-ohm load capability to drive a variety of speaker systems (stereo mode)
• Gold-plated input/output connectors
• Aluminum heat sink for efficient heat dissipation
• Low profile, compact size for space limited installations
• Wired remote Sub Level Control (BC2) included
• Full range or low pass output mode
• High level inputs
• Build in Subsonic filter
ABOUT THE MANUAL AND WARRANTY
To start enjoying your new Clarion two-channel amplifier, please read the
instructions listed in this manual. Keep all instructions for future reference.
Please fill out and send in the enclosed warranty card to protect your purchase
and aid in warranty service. Also, save your original sales receipt as proof of
purchase.
2
DPX1000.2 Power System Amplifier
INTRODUCTION
TABLE OF CONTENTS
Description • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 3
Input Connections and Audio Controls • • • • • • • • • • • • • • • • • • • • 4
Connections for Power and Speakers • • • • • • • • • • • • • • • • • • • • • 5
Applications • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 6
Installation • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 9
Mounting Precautions • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 9
Wiring Precautions • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 9
Setting the Gain • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 12
Setting the Crossover • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 12
Setting the Bass Boost • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 12
Final System Checks • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 13
Troubleshooting • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 13
Product Specs • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 14
Notes • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 15
DESCRIPTION
• The Clarion DPX1000.2 two-channel amplifier provides 250 watts x2 into a 4
ohm load, 450 watts x2 of power into a 2 ohm load. and 500 watts x2 into a 1
ohm load. This full featured model is an excellent choice for a variety of car
audio sound system configurations.
• The DPX1000.2 is Clarion’s first amplifier using Digital Technology
The DPX1000.2 uses an unregulated MOSFET power supply for superior
control of output wattage. A toroid-coil transformer yields maximum power
transfer with minimum heat loss. Careful attention to circuit design keeps AM
RFI at low levels, so you won’t hear unwanted noise when the level is cranked
up. Protection circuits safeguard the amplifier when overheating and speaker
shorts or improper load conditions occur.
• All connections and controls of the DPX1000.2 are on the end panels and are
easy to understand. We use gold-plated RCA and barrier connectors to ensure
the best electrical connection for your system. Included is a wired remote sub
level control (BC2) for adjusting the amplifier gain from the front of the
vehicle.
• Multimode operation is a unique feature that allows the DPX1000.2 to
maximize power output at different loads. In the regular mode (loads of 4 ohm
or 2 ohm stereo), the power output is 250 watts x2 into 4 ohms and 450 watts x
2 into 2 ohms. With a 1 ohm load, the power output will increase to 500 watts
x 2. This feature will accommodate various system configurations
Note: Activation of the 1 ohm mode will occur when the output load is 1 ohm.
The amplifier will shut down for 15 seconds and then turn back on in the 1
ohm mode. To reset this feature, the power connections must be disconnected
for 30 seconds and then reconnected.
OWNER'S MANUAL
3
DESCRIPTION
INPUT CONNECTIONS AND AUDIO CONTROLS
The front panel of the DPX1000.2 contains connections for RCA Inputs,
Speaker Level Inputs and Audio Controls as shown below.
The RCA Input Connections are gold-plated RCA Jacks and are labeled as
RIGHT and LEFT.
• Remote Sub level Control - This port is for the supplied remote gain control
that allows adjustment from a remote location .
• Subsonic Filter - This switch will activate the Subsonic Filter Circuit which
eliminates unwanted frequencies from 24Hz and below.
• Gain Control - This allows you to set the nominal operating level of the
amplifier. The amplifier ’s range, 250mV to 2.5V for RCA inputs or 500mV to
5V for speaker level inputs, can accommodate input levels from virtually any
brand of source unit.
• Bass Boost Control- The amplifier also features a “high-Q” (i.e. narrow
frequency band) Bass Boost circuit. It acts much like an equalizer, with
adjustable gain (from 0 to +15dB) fixed at 45Hz. Use this feature to tune lowfrequency audio response to compensate for a less than ideal subwoofer
enclosure design. The added boost produces rich, full bass tones that are
normally difficult to reproduce in the car audio environment. Note: If Bass
Boost is undesired, set Bass Boost to 0dB.
Low-pass Filter Controls
• Frequency (Hz) Selection Control - The crossover frequency is fully
adjustable between 55Hz and 550Hz for a wide range of crossover points. Use
4
DPX1000.2 Power System Amplifier
CONNECTIONS
12345678 9 10
1 Speaker Level Inputs
2 RCA Input Jacks
3 Remote Sub level Connector
4 Gain Control
5 Subsonic Filter Selection Switch
6 Bass Boost Control
7 Freq (Hz) Selection Control
8 X-Over Slope Select Switch
9 Output Select Switch
0 Input Select Switch
Figure 1-
this feature, along with your speaker manufacturer’s recommended crossover
frequencies, to quickly design a more advanced system
• X-Over Slope Switch - This switch will change the X-Over between a 12db
and 24dB per octave slope. The steep crossover slope keeps midrange tones out
of the subwoofer and thereby eliminates an unnatural “nasal” tone quality in
the audio system.
• Output Mode Switch - This switch is to change the output between lowpass
and fullrange. If lowpass is selected, the lowpass filter controls will control
the crossover frequency.
• Input Mode Switch - This switch allows you to set the input mode. Stereo
input allows full left and right stereo operation. Right (bridged) input allows
single channel input for bridged operation. This is especially useful in highpowered systems when using one amplifier for each subwoofer/speaker. L + R
(sum mono) allows a stereo input to be summed into a mono output.
• Speaker Level Inputs - These provide connections for a high-level stereo
source. In addition, these connections are provided for installations where the
source unit’s RCA outputs are unavailable.
WARNING:When using the speaker (high-level) inputs, the Black wire must
be grounded at the Radio. Failure to do this will result in noise and improper
operation.
CONNECTIONS FOR POWER AND SPEAKERS
The rear panel of the DPX1000.2 contains power and speaker connections as
shown below.
OWNER'S MANUAL
5
CONNECTIONS
1 2
3 4 5
1 Left Speaker Output
2 Right Speaker Output
3 Ground Input
4 Remote Turn-on Input
5 Battery + 12v Input
Figure 2-
APPLICATIONS
The Clarion DPX1000.2 2-channel car audio amplifier can be used in a variety
of system applications. Here are some examples to help plan your own
installation.
Bridged- Mono Subwoofer System
6
DPX1000.2 Power System Amplifier
APPLICATIONS
Figure 3 - In this application the amplifier is bridged for mono operation to
drive a subwoofer. Minimum load in the bridged mode is 2 ohms.
Set X-Over Mode to Lowpass and
adjust FREQ to speaker specifications.
2-Channel Full-Range, Satellite, or Subwoofer Stereo System
OWNER'S MANUAL
7
APPLICATIONS
L Full Range
L Subwoofer R Subwoofer
L Satellite R Satellite
R Full Range
2-way Passive
Crossover
2-way Passive
Crossover
Set Ampz Mode as shown.
Set Amp Mode as shown;
adjust FREQ to speaker
specifications.
Set Amp Mode as shown;
adjust FREQ to speaker
specifications.
Figure 4 - In this application, the amplifier is used in stereo and drives two
full-range (or satellite or subwoofer) speakers. NOTE: A passive crossover
must be used with satellite speakers. Minimum load in the stereo mode is 1
ohms.
(Set INPUT SELECT Switch to STEREO)
Mixed-Mode Satellite and Subwoofer System
8
DPX1000.2 Power System Amplifier
APPLICATIONS
Subwoofer 4 ohms
CC
L
L Speaker R Speaker
+
-
+
+
-
-
Set amp mode switch to fullrange.
FREQ (hz)
80
100
125
150
200
L (mH)
8.0
6.4
5.1
4.2
3.2
C (uF)
497
398
318
265
199
NOTE: Chart values based on 4 ohm speakers.
Figure 5 - The amplifier can be configured for a mixed-mode operation. The
table provides component values to create a 6dB per octave crossover at
specified frequencies. Use components that have a +
5% tolerance and
capacitors rated at 100V. NOTE: Choose the same frequency for both LP and
HP crossovers. Do not overlap frequencies, as this may damage the amplifier.
INSTALLATION
This section lists Mounting and Wiring Precautions for installing the Clarion
DPX1000.2. These safeguards provide enough detail to successfully complete
an installation. If you do not have the necessary skills, Clarion recommends
consulting your authorized Clarion dealer for installation.
MOUNTING PRECAUTIONS
Although the Clarion DPX1000.2 incorporate heat sinks and protection circuits,
mounting the amplifier in a tight space without any air movement can still
damage internal circuitry over time. Choose a site that provides adequate
ventilation around the amplifier. For easy system set-up, mount the amplifier
so the front panel controls will be accessible after installation.
In addition, observe the following precautions:
1. For the most efficient cooling, mount the amplifier so cool air runs along the
length of the fins rather than across them. Remember, any moving air will
dissipate heat.
2. Mount the amplifier on a rigid surface. Avoid mounting to subwoofer
enclosures or areas prone to vibration. Do not install the amplifier on plastic or
other combustible materials.
3. Prior to drilling, make sure proposed mounting holes will not cut into the
fuel tank, fuel lines, brake lines (under chassis) or electrical wiring.
WIRING PRECAUTIONS
Read all wiring precautions. If you are not sure of the connections, contact
your authorized Clarion dealer.
1. Before installation, make sure the source unit Power switch is in the OFF
position.
2. Disconnect the negative (-) lead of the battery before making any power
connections.
3. When making connections, be sure that each connection is clean and secure.
Insulate final connections with electrical tape or shrink tubing. Failure to do so
may damage your equipment.
4. A secure clean ground connection is critical to the performance of your
Clarion amplifier. Use the shortest ground wire possible snd securely connect
to the car chassis to minimize resistance and avoid noise problems.
OWNER'S MANUAL
9
INSTALLATION
5. Add an external fuse on the amplifier ’s positive (+) power lead and connect
it as close as possible to the vehicle’s (+) battery terminal. Use a rating that
equals the total current consumption at full output of all amplifier in the
system. Adding an external fuse will protect the electrical system from short
circuits that can cause a fire.
6. Refer to Figure 6 when making electrical connections. Connect the
amplifier’s positive (+) lead via a fuse directly to the positive (+) terminal on
the battery. Do not connect this wire to the car ’s fuse panel. Use red-insulated
10-gauge (or larger) wire for the amplifier’s positive (+) power lead and the
same-gauge black-insulated wire for the ground.
7. When replacing the amplifier’s fuse, always use one having the same current
rating. Substituting a higher-rated fuse or a slow-blow type can result in serious
damage to the amplifier.
8. Never ground the speakers to the vehicle chassis or body.
9. Make sure that your vehicle’s electrical system (alternator, battery, etc.) is
capable of handling the additional load. If you are planning a multi-amplifier
system, you may need to add a second battery and possibly upgrade the
alternator with a higher-output rated model. Consult your authorized Clarion
dealer for recommendations.
10. To avoid noise problems, run the amplifier’s positive (+) power lead along
one side of the vehicle to the battery. Run the remote turn-on wire and RCA
audio cables down the center, and route the speaker wires along the remaining
side. If wires must cross, run them perpendicular to each other.
11. When creating passage holes for the power wire, use grommets to eliminate
any sharp edges created during drilling. This will protect the wire from being
nicked and causing a short circuit.
12. Extra cable can cause signal loss and act as an “antenna” for noise. Use
only high-quality RCA cables that are no longer than necessary to make a
direct connection with the source unit or equalizer.
10
DPX1000.2 Power System Amplifier
WIRING
OWNER'S MANUAL
11
WIRING
BATTERY
+
-
F
U
S
E
Remote Turn-on
Chasis Groung
(Bare Metal)
Left Speaker +
Right Speaker +
Right Speaker -
Left Speaker -
Figure 6. - Electrical connections for the DPX1000.2
SETTING THE GAIN
After completing the installation, follow these steps to set the Gain Control and
then perform the Final System Checks.
1. Turn the Gain Control all the way counter-clockwise.
2. Turn the vehicle’s Ignition Switch to the ON position. Then turn the
ON/OFF Switch on the source units to the ON position. Set all Tone or
Equalization Controls to “flat” positions and turn Loudness off.
Note: If the system uses an equalizer, set its frequency controls to “flat”
positions.
3. Play a CD or Tape and set the Volume Control at 75% of full level.
4. Slowly increase the Gain Control. Stop when you hear a slight distortion of
audio.
SETTING THE
CROSSOVER
The Clarion DPX1000.2 features a fully adjustable crossover. To set the
crossover, follow these steps.
1. Using the Amp Mode Switch, select the desired mode - Low Pass, or Full
Range.
Note: Fullrange selection will disable x-over adjustments.
2. Using the Freq (Hz) Control, select the desired frequency.
SETTING
THE BASS BOOST
1. Initially set the Bass Boost control to its full left position (i.e. 0dB).
2. Listen to a variety of music styles (e.g. Rock, Rap, etc.) and slowly increase
the Bass Boost control until a noticeable increase in low bass response is
perceived.
3. Slowly adjust the Bass Boost control (up or down) to realize the best bass
response.
CAUTION: If you hear a “pop” (due to speaker over-excursion), lower the
Bass Boost to prevent speaker damage. If the system sounds muddy and
distorted (due to amplifier clipping), lower Bass Boost to avoid shutdown from
overheating.
12
DPX1000.2 Power System Amplifier
SETTING THE GAIN
FINAL SYSTEM CHECKS
1. Start the engine and turn on the source unit. After a two-second delay,
slowly increase the Volume Control and listen to the audio. If you hear any
noise, static, distortion or no sound at all, check the connections, and also refer
to Troubleshooting. Depending on your system design, the levels may become
quite loud even at low Volume Control settings. Until you get an “audio feel”
of the system’s power, use care when adjusting controls.
2. Turn the Balance Controls to their extreme positions and listen to the results.
Audio imaging should match control settings (audio from the left speaker when
balance is left).
3. Increase the volume and verify that the amplifier reproduces audio (at full
frequencies) without distortion. If you hear distortion, check the connections
and verify that the Gain Control is set correctly. Another possibility is
damaged speakers or under-powered speakers. Once again refer to
Troubleshooting for additional help.
TROUBLESHOOTING
Problem
No Audio.
Solution
Low or no remote turn-on voltage. Check remote connections at amplifier and
source unit.
Blown amplifier fuse. Replace with new fast-blow fuse (same rating).
Power wires not connected. Check battery and ground wiring at amplifier; also
check battery connections.
Speaker leads shorted. Check speaker continuity to ground, it should not show
a common ground.
Speakers not connected or are blown. Check speaker connections at amplifier,
measure coil impedance.
Problem
Audio cycles on and off.
Solution
Thermal protection circuits are shutting amplifier off. Check location for
adequate ventilation; consult an authorized Clarion Audio Dealer.
Problem
Distorted audio.
Solution
Gain is not set properly, or damaged speaker cones. Review Setting Gain;
inspect each speaker cone for signs of damage (i.e. frozen cone, burning smell,
etc.)
OWNER'S MANUAL
13
TROUBLESHOOTING
PUT TITLE HERE
DPX1000.2 Power System Amplifier
Problem
Audio lacks punch.
Solution
Speakers wired incorrectly, which causes cancellation of bass frequencies.
Check polarity of wires from amplifier to each speaker as defined by the
system design.
Problem
Amplifier fuse keeps blowing.
Solution
Incorrect wiring or short circuit. Review Installation and check all wiring
connections.
Problem
Whining or ticking noise in the audio with engine on.
Solution
Amplifier is picking up alternator noise or radiated noise. Turn down input
gain; move audio cables away from power wires. Check power and ground
connections on amplifier; install an in-line noise filter on source unit’s power
wire; check alternator and/or voltage regulator; test for weak battery or add
water to battery
PRODUCT SPECS
DPX1000.2
14
TROUBLESHOOTING
Frequency Response
Signal Noise Ratio
THD
Input Sensitivity Low Level
Input Sensitivity Speaker Level
Max. Power Output
Cont. Power Output
2-Ohm Stereo Output
Bridged Power
Dimensions
Current Consumption at output @ max power
20Hz ~ 20kHz
>95db
.2% all channels driven
250mV ~ 2.5 V
500mV - 5V
500 watts x 2 @1 ohm
250 watts x 2 into 4 ohms @ <1% THD
450 watts x 2 into 2 ohms @ <1% THD
1000 watts x 1 into 2 ohms @ <1% THD
2 1/8” H x 8 1/4” W x 14” L
86A @ 1000 Watts
NOTES
OWNER'S MANUAL
15
NOTES
661 W. Redondo Beach Blvd.
Gardena, CA 90247
1-800-GO-CLARION
www.clarion-usa.com
DPX1000.2-10 Rev.1 (02/01)
Loading...
