Thank you for purchasing the Clarion Product.
Please read this owner’s manual in its entirety before operating this equipment.
After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
Check the contents of the enclosed warranty card (ADB340MP only) and keep it carefully with this manual.
Contents |
|
|
1. |
FEATURES ..................................................................................................................................... |
2 |
2. |
PRECAUTIONS .............................................................................................................................. |
3 |
|
Flip Down Panel .............................................................................................................................. |
3 |
|
3” (8 cm) Compact Discs ................................................................................................................ |
3 |
|
Handling Compact Discs ................................................................................................................. |
4 |
|
Handling Cassette Tapes ................................................................................................................ |
4 |
3. |
CONTROLS .................................................................................................................................... |
5 |
4. |
NOMENCLATURE .......................................................................................................................... |
6 |
|
Names of the Buttons and their Functions ..................................................................................... |
6 |
|
Display Items ................................................................................................................................... |
7 |
|
LCD Screen ..................................................................................................................................... |
7 |
5. |
OPERATIONS ................................................................................................................................. |
8 |
|
Basic Operations ............................................................................................................................. |
8 |
|
Radio Operations .......................................................................................................................... |
10 |
|
CD/MP3 Operations ...................................................................................................................... |
12 |
|
Tape Operations ............................................................................................................................ |
15 |
|
Operations Common to Each Mode ............................................................................................. |
16 |
6. |
IN CASE OF DIFFICULTY ............................................................................................................ |
19 |
7. |
ERROR DISPLAYS ....................................................................................................................... |
20 |
8. |
SPECIFICATIONS ........................................................................................................................ |
20 |
1.FEATURES
■8-Times Oversampling Digital Filter and Dual 1-Bit D/A Converters
■Zero-Bit DetectorTM Mute Circuit
■Full Logec Tape Transport with True Function / Auto Reverse with Dual Azimuth Adjust
■® FM Reception System
■Capability to Read CD TEXT Data
■4 Pre-Programmed Graphic Equalizer Memories
■2-Channel RCA Line Level Output
2 ADZ625
2. PRECAUTIONS
1.When the inside of the car is very cold and the player is used soon after switching on the heater, moisture may form on the disc or the optical parts of the player and proper playback may not be possible. If moisture forms on the disc, wipe it off with a soft cloth. If moisture forms on the optical parts of the player,do not use the player for about one hour. The condensation will disappear naturally allowing normal operation.
2.Driving on extremely bumpy roads which cause severe vibration may cause the sound to skip.
3.This unit uses a precision mechanism. Even in the event that trouble arises, never open the case, disassemble the unit, or lubricate the rotating parts.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to consult the dealer or an experienced radio/TV technician for help.
CAUTION
USE OF CONTROLS, ADJUSTMENTS, OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN, MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
THE COMPACT DISC PLAYER SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONEEXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.
CHANGES OR MODIFICATIONS NOT EXPRESSLYAPPROVED BY THE MANUFACTURER FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
INFORMATION FOR USERS:
Flip Down Panel
This unit uses a flip-down structure that makes possible large-size display.
CAUTION
When opening and closing the FLIP DOWN PANEL, be careful not to catch your fingers. They could be injured.
1.Always use this unit with the FLIP DOWN PANEL closed.
2.Do not force operations or use this device abnormally when opening or closing the FLIP
DOWN PANEL.
3.Do not use the FLIP DOWN PANEL as a tray to place objects on when it is open.
4.When closing the FLIP DOWN PANEL, do not press the [OPEN] button.
5.Strong impacts to the operating or display section can cause damage or deformation.
6.If the FLIP DOWN PANEL does not open fully, gently open it with your hand.
3” (8 cm) Compact Discs
CAUTION
CHANGES OR MODIFICATIONS TO THIS PRODUCT NOT APPROVED BY THE MANUFACTURER WILL VOID THE WARRANTY AND WILL VIOLATE FCC APPROVAL.
MODEL
12V – GROUND
AM 530-1710kHz/FM 87.9- 107.9MHz
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS PRODUCTION COMPLIES WITH DHHS RULES 21 CFR
SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE.
CLARION CO., LTD.
50 KAMITODA, TODA-SHI, SAITAMA-KEN, JAPAN
MANUFACTURED:
3” (8 cm) disc can’t be played. Using an adapter and inserting them into this unit can cause damage, please do not insert by any means.
SERIAL No. |
Clarion Co., Ltd. |
Top View of Source Unit |
|
|
28A51690 |
|
3 |
PE-2652B |
MADE IN INDONESIA |
|
|
|
|
ADB340MP/ADB341MP |
Handling Compact Discs
Use only compact discs bearing the
or
mark.
Do not play heart-shaped, octagonal, or other specially shaped compact discs.
Some CDs recorded in CD-R/CD-RW mode may not be usable.
Handling
•Compared to ordinary music CDs, CD-R and CDRW discs are both easily affected by high temperature and humidity and some of CD-R and CD-RW discs may not be played. Therefore, do not leave them for a long time in the car.
•New discs may have some roughness around the edges. If such discs
are used, the player may not work or the sound may skip. Use a ball-point pen or the like to remove any roughness from the edge of the disc.
•Never stick labels on the surface of the compact disc or mark the surface with a pencil or pen.
•Never play a compact disc with any cellophane tape or other glue on it or with peeling off marks. If you try to play such a compact disc, you may not be able to get it back out of the CD player or it may damage the CD player.
•Do not use compact discs that have large scratches, are misshapen, cracked, etc. Use of such discs may cause misoperation or damage.
•To remove a compact disc from its storage case, press down on the center of the case and lift the disc out, holding it carefully by the edges.
•Do not use commercially available CD protection sheets or discs equipped with stabilizers, etc. These may damage the disc or cause breakdown of the internal mechanism.
Storage
•Do not expose compact discs to direct sunlight or any heat source.
•Do not expose compact discs to excess humidity or dust.
•Do not expose compact discs to direct heat from heaters.
Cleaning
•To remove fingermarks and dust, use a soft cloth and wipe in a straight line from the center of the compact disc to the circumference.
•Do not use any solvents, such as commercially available cleaners, anti-static spray or thinner to clean compact discs.
•After using special compact disc cleaner, let the compact disc dry off well before playing it.
Handling Cassette Tapes
Using any of the following types of cassette tapes can cause malfunctions.
•Cassette tapes with low recording levels
•Cassette tapes in which the unrecorded section between songs is shorter than 4 seconds
•Cassette tapes with noise or the like recorded between songs
•Cassette tapes on which there are long unrecorded sections in the middle of a song
Handling precautions
•Slack in the tape can cause malfunctions. In particular for prerecorded
cassette tapes and 90-
minute tapes, take up any slack in the tape before inserting it into the cassette player.
•Avoid using cassettes of 120 minutes or longer. (Such cassettes have extremely thin tape, so the tape can become stretched or cut.)
•Periodically play a cleaning cassette in the player to clean the head.
•Keep magnets, screwdrivers, and other iron and steel and magnetic items away from both cassette tapes and the tape head in the player.
•Do not oil the cassette mechanism.
•Do not use any cassette tapes with peeling labels or deformed cases. Such cassette tapes can cause breakdowns.
•When not using the player, always take the cassette out of the mechanism. Exposing a cassette to direct sunlight, extreme temperatures, or high humidity can damage the cassette.
Be sure to unfold and read the next page. Veuillez dé plier et vous ré fé rer à la page suivante.
Cerció rese de desplegar y de leer la pá gina siguiente.
ADB340MP/ADB341MP 4
3. CONTROLS/LES COMMANDES/CONTROLES/
Source unit / Appareil pilote / Unidad fuente /
|
|
|
[TITLE] |
[RPT] |
[CD SLOT] |
|
[RDM] |
|
[CD EJECT] |
||
[OPEN] |
|
|
|
[SCN] |
|
|
|
[FNC] |
|
|
[EQ] |
[BND] |
|
|
[SPE/ANA] |
[PRESET] |
|
|
[VOLUME] |
[MEMO] |
|
|
[A-M] |
[DISP] |
|
|
[ISR] |
|
|
[ |
] |
[MUTE] |
[ |
], [ |
] |
With the FLIP DOWN PANEL opened / Avec la CONSOLE RABATTABLE ouverte / Con el PAÍNEL ABATÍBLE abierto. /
[TAPE SLOT]
[TAPE EJECT]
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: Veuillez dé plier cette page et vous ré fé rer aux sché mas quand vous lisez chaque chapitre.
Nota: Cuando lea los capítulos, despliegue esta pá gina y consulte los diagramas.
4. NOMENCLATURE
Note:
• Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold).
Names of the Buttons and their Functions
[OPEN]
• Press to open the Flip down panel.
[RPT] button
•Plays repeatedly while in the CD/MP3 mode.
•In the tape mode, enables repeat play.
•When held depressed for one second or more, enables blank-skip mode.
•Press and hold for 1 second or longer to perform folder repeat play while in the MP3 mode, or BLS while in the tape mode.
[CD SLOT]
• CD insertion slot.
[TITLE] button
•Use the button to input a title in the CD/MP3 mode.
•Press and hold the button for 1 second or longer to enter the adjust mode.
[RDM] button
•Performs random play while in the CD/MP3 mode.
•Press and hold for 1 second or longer to perform folder ramdom play while in the MP3 mode.
[CD EJECT] button
•Ejecting a CD.
•Press and hold the button for more than 10 seconds to reset this unit.
[EQ] button
•Press to select EQ menu.
•Press and hold for 1 second or longer to set EQ effects to ON/OFF.
[SPE/ANA] button
• Press to change the spectrum analyzer display.
[VOLUME] knob
•Adjust the volume by turning the knob clockwise or counterclockwise.
•Use the knob to perform various settings.
[A-M] button
•Press and hold the button for 1 second or longer to turn on or off the MAGNA BASS EXTEND.
•Use the button to switch to the audio mode (bass/mid/treble, balance/fader adjustment)
[ISR] button
•Recalls ISR radio station in memory.
Press and hold for 1 seconds or longer: Stores current station into ISR memory (radio mode only).
[
] button
•Plays or pauses a CD/TAPE while in the CD/ MP3 or TAPE mode.
•After selecting various setting options, press this button to confirm the settings.
[ |
], [ |
] buttons |
•Selects a station while in the radio mode or selects a track when listening to a CD. These buttons are used to make various settings.
[MUTE] button
• Turns mute on and off.
[DISP] button
•Switches the display indication (Main display, sub display, clock display).
•Press and hold for 1 second or longer to switch the CD title.
[MEMO] button
•Use to change and store items in preset memory.
[PRESET] knob
•Stores a station into memory or recall it directly while in the radio mode.
•In EQ mode, use to select menu.
•In adjust modes, use to select items for adjustment.
•Selects a Folder while in the MP3 playback.
[BND] button
•Switches the band, or seek tuning or manual tuning while in the radio mode.
•Plays a first track while in the CD/MP3 mode.
•In tape mode, changes the side played (direction of tape travel).
[FNC] button
•Press the button to turn on the power.
Press and hold the button for 1 second or longer to turn off the power.
•Switches the operation mode among the radio mode, etc.
5 |
ADB340MP/ADB341MP |
6 |
ADB340MP/ADB341MP |
[SCN] button
•Performs preset scan while in the radio mode. When the button is pressed and held, auto store is performed.
•Performs scan play for 10 seconds for each track while in the CD/MP3 and tape mode.
•Press and hold for 1 second or longer to perform folder scan play while in the MP3 mode.
[TAPE SLOT]
• Cassette tape insertion slot.
[TAPE EJECT] button
• Ejecting a tape.
Display Items
: EQ indication |
Spectrum analyger display |
||||||||||||||||||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||||||||||||||
|
|
|
|
: MP3 indication |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
: BLS (Blank skip) indication |
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
: Manual indication |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
: Stereo indication |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
: Folder scan / Folder repeat / |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Folder random indication |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
: Scan indication |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
: Repeat indication |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
: Random indication |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
: Mute indication
: MAGNA BASS EXTEND indication
Operation status indication
•The frequency, Title, play time, CT(clock), etc. are displayed.
Preset channel indication (1 to 6)
Function mode indication
•The names of modes being selected, etc. are displayed.
LCD Screen
In extreme cold, the screen movement may slow down and the screen may darken, but this is normal.
The screen will recover when it returns to normal temperature.
ADB340MP/ADB341MP 7
5. OPERATIONS
Basic Operations |
Note: Be sure to read this chapter referring to the front diagrams of |
chapter “3. CONTROLS” on page 5 (unfold). |
CAUTION
Be sure to lower the volume before switching off the unit power or the ignition key. The unit remembers its last volume setting. If you switch the power off with the volume up, when you switch the power back on, the sudden loud volume may hurt your hearing and damage the unit.
The clock is displayed when the ignition key is turned to the ACC (accessory) or IGN (igni- tion-on) position even when the unit power is off. In some cars, the clock may momentarily disappear when the ignition key is turned to the START position. The clock will reappear after the engine has started and the ignition key is released to the IGN (ignitionon) position.
Turning on/off the power
Notes:
•Be careful about using this unit for a long time without running the engine. If you drain the car’s battery too far, you may not be able to start the engine and this can reduce the service life of the battery.
1.Press the [FNC] button.
2.The illumination and display on the unit light up. The unit automatically remembers its last operation mode and will automatically switch to display that mode.
3.Press and hold the [FNC] button for 1 second or longer to turn off the power for the unit.
Selecting a mode
1.Press the [FNC] button to change the mode of operation.
2.Each time you press the [FNC] button, the mode of operation changes in the following order:
Radio mode CD mode Tape mode
AUX mode Radio mode...
Mute
Turning the volume down quickly.
Press the [MUTE] button.
Each time the button is pressed the Mute turns
ON or OFF.
When it’s ON, the “MUTE” indicator blinks.
Switching the display
Press the [DISP] button to select the desired display.
Each time you press the [DISP] button, the display switches in the following order:
In Tuner source
Frequency Clock Frequency...
In CD source
Clock Track Number & Track Time Clock...
In Tape source
Playback direction & Current status Current status Clock Playback direction & Current status...
Once selected, the preferred display becomes the display default. When a function adjustment such as volume is made, the screen will momentarily switch to that function’s display, then revert back to the preferred display several seconds after the adjustment.
When you have entered a title in a CD, it appears in the main display. If you have not entered a title, “NO-TITL” appears in the title display instead. For information on how to enter a title, refer to the subsection “Entering titles”in the “Operations Common to Each Mode”.
Adjusting the volume
Turning the [VOLUME] knob clockwise to increase the volume, or turning the [VOLUME] knob counterclockwise to decrease the volume.
The volume level is from 0 (minimum) to 35 (maximum).
8 ADB340MP/ADB341MP
Loading...
