ADMINISTRATION

GUIDE

Cisco Small Business

WAP551 Wireless-N Access Point with PoE

and

WAP561 Wireless-N Selectable-Band Access Point with PoE

Contents

Chapter 1: Getting Started 5

Starting the Web-Based Configuration Utility 5

Using the Access Point Setup Wizard 6

Getting Started 9

Window Navigation 10

Chapter 2: Status and Statistics 12

System Summary 12

Network Interfaces 14

Traffic Statistics 15

WorkGroup Bridge Transmit/Receive 16

Associated Clients 16

TSPEC Client Associations 18

TSPEC Status and Statistics 20

TSPEC AP Statistics 22

Radio Statistics 22

Email Alert Status 24

Log 24

Chapter 3: Administration 25

System Settings 26

User Accounts 26

Time Settings 28

Log Settings 30

Email Alert 32

HTTP/HTTPS Service 35

Management Access Control 37

Manage Firmware 38

Download/Backup Configuration File 40

Configuration Files Properties 42

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 1

Contents

Copy/Save Configuration 42

Reboot 43

Discovery—Bonjour 44

Packet Capture 44

Support Information 51

Chapter 4: LAN 52

Port Settings 52

VLAN and IPv4 Address Settings 53

IPv6 Addresses 54

IPv6 Tunnel 56

Chapter 5: Wireless 58

Radio 58

Rogue AP Detection 66

Networks 69

Scheduler 81

Scheduler Association 83

Bandwidth Utilization 83

MAC Filtering 84

WDS Bridge 85

WorkGroup Bridge 89

Quality of Service 92

WPS Setup 95

WPS Process 102

Chapter 6: System Security 105

RADIUS Server 105

802.1X Supplicant 107

Password Complexity 109

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 2

Contents

WPA-PSK Complexity 110

Chapter 7: Client Quality of Service 111

Client QoS Global Settings 111

ACL 111

Class Map 118

Policy Map 123

Client QoS Association 125

Client QoS Status 127

Chapter 8: Simple Network Management Protocol 129

General SNMP Settings 129

Groups 133

Users 135

Targets 136

Chapter 9: Captive Portal 138

Captive Portal Global Configuration 139

Instance Configuration 140

Instance Association 143

Web Portal Customization 143

Local Groups 147

Local Users 148

Authenticated Clients 149

Failed Authentication Clients 150

Chapter 10: Single Point Setup 152

Single Point Setup Overview 152

Access Points 157

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 3

Contents

Sessions 160

Channel Management 161

Wireless Neighborhood 165

Chapter A: Deauthentication Message Reason Codes 168

Deauthentication Reason Code Table 168

Appendix B: Where to Go From Here 170

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 4

Getting Started

This chapter provides an introduction to the Wireless Access Point (WAP) devices web-based configuration utility, and includes these topics:

• Starting the Web-Based Configuration Utility

• Using the Access Point Setup Wizard

• Getting Started

• Window Navigation

Starting the Web-Based Configuration Utility

This section describes system requirements and how to navigate the web-based configuration utility.

Supported Browsers

• Internet Explorer 7.0 or later

• Chrome 5.0 or later

• Firefox 3.0 or later

• Safari 3.0 or later

Browser Restrictions

• If you are using Internet Explorer 6, you cannot directly use an IPv6 address

to access the WAP device. You can, however, use the Domain Name System (DNS) server to create a domain name that contains the IPv6 address, and then use that domain name in the address bar in place of the IPv6 address.

• When using Internet Explorer 8, you can configure security settings from

Internet Explorer. Select Tools > Internet Options and then select the Security tab. Select Local Intranet and select Sites. Select Advanced and then select Add. Add the intranet address of the WAP device (http://<ip-

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 5

Getting Started

Using the Access Point Setup Wizard

• If you have multiple IPv6 interfaces on your management station, use the

By default, the web-based AP configuration utility logs out after 10 minutes of inactivity. See HTTP/HTTPS Service for instructions on changing the default timeout period.

To log out, click Logout in the top right corner of the web-based AP configuration utility.

address>) to the local intranet zone. The IP address can also be specified as the subnet IP address, so that all addresses in the subnet are added to the local intranet zone.

IPv6 global address instead of the IPv6 local address to access the WAP device from your browser.

Using the Access Point Setup Wizard

The first time that you log into the WAP device (or after it has been reset to the factory default settings), the Access Point Setup Wizard appears to help you perform initial configurations. Follow these steps to complete the wizard:

NOTE If you click Cancel to bypass the Wizard, the Change Password page appears. You

can then change the default password for logging in. For all other settings, the factory default configurations apply.

You must log in again after changing your password.

STEP 1 Click Next on the Welcome page of the Wizard. The Configure Device - IP

Address window appears.

STEP 2 Click Dynamic IP Address (DHCP) if you want the WAP device to receive an IP

address from a DHCP server. Or select Static IP Address to configure IP Address manually. For a description of these fields, see VLAN and IPv4 Address Settings.

STEP 3 Click Next. The Single Point Setup — Set a Cluster window appears. For a

description of Single Point Setup, see Single Point Setup.

STEP 4 To create a new Single Point Setup of WAP devices, select Create a New Cluster

and specify a New Cluster Name. When you configure your devices with the same cluster name and enable Single Point Setup mode on other WAP devices, they automatically join the group.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 6

Getting Started

Using the Access Point Setup Wizard

If you already have a cluster on your network, you can add this device to it by clicking Join an Existing Cluster, and then entering the Existing Cluster Name.

If you do not want this device to participate in a Single Point Setup at this time, click Do not Enable Single Point Setup.

(Optional) You can enter text in the AP Location field to note the physical location of the WAP device.

STEP 5 Click Next. The Configure Device - Set System Date and Time window appears.

STEP 6 Select your time zone, and then set the system time manually or set up the WAP

device to get its time from an NTP server. For a description of these options, see

Time Settings.

STEP 7 Click Next. The Enable Security - Set Password window appears.

STEP 8 Enter a New Password and enter it again in the Confirm Password text box. For

more information about passwords, see User Accounts.

NOTE You can uncheck the Password Complexity box if you wish to disable

the password security rules. However, we strongly recommend keeping the password security rules enabled.

STEP 9 Click Next. The Enable Security - Name Your Wireless Network window appears

for the Radio 1 interface.

NOTE For this window and the following two windows (Wireless Security

and VLAN ID), you configure these settings for the Radio 1 interface first. Then, for WAP561 devices, the windows repeat to enable you to configure these settings for Radio 2.

STEP 10 Enter a Network Name. This name serves as the SSID for the default wireless

network.

STEP 11 Click Next. The Enable Security - Secure Your Wireless Network window appears.

STEP 12 Choose a security encryption type and enter a security key. For a description of

these options, see System Security.

STEP 13 Click Next. The Wizard displays the Enable Security- Assign the VLAN ID For Your

Wireless Network window.

STEP 14 Enter a VLAN ID for traffic received on the wireless network.

It is suggested that you assign a different VLAN ID from the default (1) to wireless traffic, in order to segregate it from management traffic on VLAN 1.

STEP 15 Click Next.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 7

Getting Started

Using the Access Point Setup Wizard

STEP 16 For the WAP561 device, the Network Name, Wireless Security, and VLAN ID

pages show to enable configuring Radio 2. When finished with configuring Radio 2, click Next.

The Wizard displays the Enable Captive Portal - Create Your Guest Network window.

STEP 17 Select whether or not to set up an authentication method for guests on your

network, and click Next.

If you click No, skip to STEP 25.

If you click Yes , the Wizard displays the Enable Captive Portal - Name Your Guest Network window.

STEP 18 Specify a Guest Network Name for Radio 1. For the WAP561 device, select

whether the guest network uses Radio 1 or Radio 2.

STEP 19 Click Next. The Wizard displays the Enable Captive Portal - Secure Your Guest

Network window.

STEP 20 Choose a security encryption type for the guest network and enter a security key.

For a description of these options, see System Security.

STEP 21 Click Next. The Wizard displays the Enable Captive Portal - Assign the VLAN ID

window.

STEP 22 Specify a VLAN ID for the guest network. The guest network VLAN ID should be

different from the management VLAN ID.

STEP 23 Click Next. The Wizard displays the Enable Captive Portal - Enable Redirect URL

window.

STEP 24 Select Enable Redirect URL and specify a fully qualified domain name or IP

address in the Redirect URL field (including http://). If specified, guest network users are redirected to the specified URL after authenticating.

STEP 25 Click Next. The Wizard displays the Summary - Confirm Your Settings window.

STEP 26 Review the settings that you configured. Click Back to reconfigure one or more

settings. If you click Cancel, all settings are returned to the previous or default values.

STEP 27 If they are correct, click Submit. Your WAP setup settings are saved and a

confirmation window appears.

STEP 28 Click Finish. The Getting Started window appears.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 8

Getting Started

To simplify device configuration through quick navigation, the Getting Started page provides links for performing common tasks. The Getting Started page is the default window every time you log into the web-based AP configuration utility.

Links on the Getting Started Page

Category Link Name (on the Page) Linked Page

Initial Setup Run Setup Wizard Using the Access

Point Setup Wizard

Configure Radio Settings Radio

Configure Wireless Network Settings Networks

Device Status

Quick Access

Configure LAN Settings LAN

Run WPS WPS Setup

Configure Single Point Setup Single Point Setup

System Summary System Summary

Wireless Status Network Interfaces

Change Account Password User Accounts

Upgrade Device Firmware Manage Firmware

Backup/Restore Configuration Download/Backup

Configuration File

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 9

Getting Started

Window Navigation

This section describes the features of the web-based AP configuration utility.

The Configuration Utility header contains standard information and appears at the top on every page. It provides these buttons:

Buttons

Button Name Description

(User) The account name (Administrator or Guest) of the user

Log Out Click to log out of the web-based AP configuration utility.

logged into the WAP device. The factory default user name is cisco.

About Click to show the WAP device type and version number.

Help Click to show the online help. The online help is designed

to be viewed with browsers using UTF-8 encoding. If the online help shows errant characters, verify that the encoding settings on your browser are set to UTF-8.

A navigation pane, or main menu, is located on the left side of each page. The navigation pane is a list of the top-level features of the WAP devices. If a main menu item is preceded by an arrow, select to expand and display the submenu of each group. You can then select on the desired submenu item to open the associated page.

The table below describes the commonly used buttons that appear on various pages in the system.

Management Buttons

Button Name Description

Add Adds a new entry to the table or database.

Cancel Cancels the changes made to the page.

Clear All Clears all entries in the log table.

Delete Deletes an entry in a table. Select an entry first.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 10

Getting Started

Window Navigation

Management Buttons (Continued)

Button Name Description

Edit Edits or modifies an existing entry. Select an entry first.

Refresh Redisplays the current page with the latest data.

Save Saves the settings or configuration.

Update Updates the new information to the startup

configuration.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 11

Status and Statistics

This chapter describes how to display status and statistics and contains these topics:

• System Summary

• Network Interfaces

• Traffic Statistics

• WorkGroup Bridge Transmit/Receive

• Associated Clients

• TSPEC Client Associations

• TSPEC Status and Statistics

• TSPEC AP Statistics

• Radio Statistics

• Email Alert Status

• Log

System Summary

The System Summary page shows basic information such as the hardware model description, software version, and the time that has elapsed since the last reboot.

To view system information, select Status and Statistics > System Summary in the navigation pane. Or, select System Summary under Device Status on the Getting Started page.

The System Summary page shows this information:

• PID VID—The WAP hardware model and version.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 12

Status and Statistics

System Summary

• Serial Number—The serial number of the Cisco WAP device.

• Base MAC Address—The WAP MAC address.

• Firmware Version (Active Image)—The firmware version number of the

active image.

• Firmware MD5 Checksum (Active Image)—The checksum for the active

image.

• Firmware Version (Non-active)—The firmware version number of the

backup image.

• Firmware MD5 Checksum (Non-active)—The checksum for the backup

image.

• Host Name—A name assigned to the device.

• System Uptime—The time that has elapsed since the last reboot.

• System Time—The current system time.

•

The TCP/UDP Service table shows basic information about protocols and services operating on the WAP.

• Service—The name of the service, if available.

• Protocol—The underlying transport protocol that the service uses (TCP or

UDP).

• Local IP Address—The IP address, if any, of a remote device that is

connected to this service on the WAP device. All indicates that any IP address on the device can use this service.

• Local Port—The port number for the service.

• Remote IP Address—The IP address of a remote host, if any, that is using

this service. All indicates that the service is available to all remote hosts that access the system.

• Remote Port—The port number of any remote device communicating with

this service.

• Connection State—The state of the service. For UDP, only connections in

the Active or Established states appear in the table. The TCP states are:

- Listening—The service is listening for connection requests.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 13

Status and Statistics

Network Interfaces

- Active—A connection session is established and packets are being

- Established—A connection session is established between the WAP

- Time Wait—The closing sequence has been initiated and the WAP is

You can click Refresh to refresh the screen and show the most current information.

Network Interfaces

transmitted and received.

device and a server or client, depending on the role of each device with respect to this protocol.

waiting for a system-defined timeout period (typically 60 seconds) before closing the connection.

Use the Network Interfaces page to show configuration and status information about the wired and wireless interfaces. To show the Network Interfaces page, select Status and Statistics > Network Interface in the navigation pane.

The Network Interfaces page shows this information:

• LAN Status—These settings apply to the internal interface.

To change any of these settings, click the Edit link. After you click Edit, you are redirected to the VLAN and IPv4 Address Settings page. See VLAN and

IPv4 Address Settings for descriptions of these fields.

• Radio Status—These settings include the Wireless Radio mode (Enabled

or Disabled), the MAC address associated with the radio interface (or both radio interfaces for WAP561 devices), the 802.11 mode (a/b/g/n), and the channel used by the interface.

To change the wireless settings, click the Edit link. After you click Edit, you are redirected to the Radio page. See Radio for descriptions of these fields.

• Interface Status—This table lists status information for each Virtual Access

Point (VAP) and on each Wireless Distribution System (WDS) interface. On WAP561 devices, WLAN0 or WLAN1 precedes the VAP interface ID to indicate the associated radio interface. WLAN0 represents radio 1 and WLAN1 represents radio 2.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 14

Status and Statistics

Traf fic Statistics

You can click Refresh to refresh the screen and show the most current information.

Traffic Statistics

Use the Traffic Statistics page to view basic information about the WAP. It also provides a real-time display of transmit and receive statistics for the Ethernet interface, the Virtual Access Points (VAPs), and any WDS interfaces. All transmit and receive statistics reflect the totals since the WAP was last started. If you reboot the WAP, these figures indicate transmit and receive totals since the reboot.

If the VAP has been configured, the table lists the SSID, the administrative status (up or down), the MAC address of the radio interface, the VLAN ID, the name of any associated scheduler profile, and the current state (active or inactive). The state indicates whether the VAP is exchanging data with a client.

To show the Traffic Statistics page, select Status and Statistics > Traffic Statistics in the navigation pane.

The Traffic Statistics page shows summary data and statistics for traffic in each direction.

• Network Interface—Name of the Ethernet interface and each VAP and

WDS interface.

On WAP561 devices, WLAN0 and WLAN1 precede the VAP interface name to indicate the radio interface (WLAN0 represents radio 1 and WLAN1 represents radio 2).

• Tot al P ac ket s —The total packets sent (in Transmit table) or received (in

Received table) by this WAP device.

• Total Bytes—The total bytes sent (in Transmit table) or received (in

Received table) by this WAP device.

• Tot al D ro p p e d Pa cke t s—The total number of dropped packets sent (in

Transmit table) or received (in Received table) by this WAP device.

• Total Dropped Bytes—The total number of dropped bytes sent (in Transmit

table) or received (in Received table) by this WAP device.

• Errors—The total number of errors related to sending and receiving data on

this WAP device.

You can click Refresh to refresh the screen and show the most current information.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 15

Status and Statistics

WorkGroup Bridge Transmit/Receive

The WorkGroup Bridge Transmit/Receive page shows packet and byte counts for traffic between stations on a WorkGroup Bridge. For information on configuring WorkGroup Bridges, see WorkGroup Bridge.

To show the WorkGroup Bridge Transmit/Receive page, select Status and Statistics > WorkGroup Bridge in the navigation pane.

Each network interface that is configured as a WorkGroup Bridge interface shows these fields:

• Network Interface—Name of the Ethernet or VAP interface. On WAP561

devices, WLAN0 represents radio 1 and WLAN1 represents radio 2.

• Status and Statistics—Whether the interface is disconnected or is

administratively configured as up or down.

• VLAN ID—Virtual LAN (VLAN) ID. You can use VLANs to establish multiple

• Name (SSID)—Wireless network name. Also known as the SSID, this

Additional information appears for the transmit and receive direction for each WorkGroup Bridge interface:

• Tot al P ac ket s —The total number of packets bridged between the wired

• Total Bytes—The total number of bytes bridged between the wired clients

You can click Refresh to refresh the screen and show the most current information.

Associated Clients

internal and guest networks on the same WAP device. The VLAN ID is set on the VAP tab.

alphanumeric key uniquely identifies a wireless local area network. The SSID is set on the VAP tab.

clients in the WorkGroup Bridge and the wireless network.

in the WorkGroup Bridge and the wireless network.

You can use the Associated Clients page to view the client stations associated with a particular access point.

To show the Associated Clients page, select Status and Statistics > Associated Clients in the navigation pane.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 16

Status and Statistics

Associated Clients

The associated stations are shown along with information about packet traffic transmitted and received for each station.

• Total Number of Associated Clients—The total number of clients currently

associated with the WAP device.

• Network Interface—The VAP the client is associated with. On WAP561

devices, WLAN0 and WLAN1 precede the VAP interface name to indicate the radio interface (WLAN0 represents radio 1 and WLAN1 represents radio 2).

• Station—The MAC address of the associated wireless client.

• Status—The Authenticated and Associated Status shows the underlying

IEEE 802.11 authentication and association status, which is present no matter which type of security the client uses to connect to the WAP device. This status does not show IEEE 802.1X authentication or association status.

These are some points to keep in mind with regard to this field:

- If the WAP device security mode is None or Static WEP, the

authentication and association status of clients appears as expected; that is, if a client shows as authenticated to the WAP device, it is able to transmit and receive data. (The reason why is that Static WEP uses only IEEE 802.11 authentication.)

- If the WAP device uses IEEE 802.1X or WPA security, it is possible for a

client association to appear as authenticated (through IEEE 802.11 security) although it is not actually authenticated through the second layer of security.

• From Station/To Station—For the From Station, the counters indicate the

packets or bytes received by the wireless client. For the To Station, the counters indicate the number of packets and bytes transmitted from the WAP device to the wireless client.

- Packets—Number of packets received (transmitted) from the wireless

client.

- Bytes—Number of bytes received (transmitted) from the wireless client.

- Drop Packets—Number of packets dropped after being received

(transmitted).

- Drop Bytes—Number of bytes that dropped after being received

(transmitted).

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 17

Status and Statistics

TSPEC Client Associations

- TS Violate Packets (From Station)—Number of packets sent from a

client STA to the WAP device in excess of its active Traffic Stream (TS) uplink bandwidth, or for an access category requiring admission control to which the client STA has not been admitted.

- TS Violate Packets (To Station)—Number of packets sent from the

WAP device to a client STA in excess of its active TS downlink bandwidth, or for an access category requiring admission control to which the client STA has not been admitted.

• Up Time—The amount of time the client has been associated with the WAP

device.

You can click Refresh to refresh the screen and show the most current information.

TSPEC Client Associations

The TSPEC Client Associations page provides real-time information about the TSPEC client data transmitted and received by this access point. The tables on the TSPEC Client Associations page show voice and video packets transmitted and received since the association started, along with status information.

A TSPEC is a traffic specification that is sent from a QoS-capable wireless client to a WAP device requesting a certain amount of network access for the Traffic Stream (TS) it represents. A traffic stream is a collection of data packets identified by the wireless client as belonging to a particular user priority. An example of a voice traffic stream is a Wi-Fi CERTIFIED telephone handset that marks its codecgenerated data packets as voice priority traffic. An example of a video traffic stream is a video player application on a wireless laptop that prioritizes a video conference feed from a corporate server.

To view TSPEC client association statistics, select Status and Statistics > TSPEC Client Associations in the navigation pane.

The TSPEC Client Associations page shows this information:

Status and Statistics:

• Network Interface—Radio interface used by the client. On WAP561

devices, WLAN0 represents radio 1 and WLAN1 represents radio 2.

• SSID—Service set identifier associated with this TS client.

• Station—Client station MAC address.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 18

Status and Statistics

TSPEC Client Associations

• TS Identifier—TSPEC Traffic Session Identifier (range 0 to 7).

• Access Category—TS Access Category (voice or video).

• Direction—Traffic direction for this TS. Direction can be one of these

options:

- uplink—From client to device.

- downlink—From device to client.

- bidirectional

• User Priority—User Priority (UP) for this TS. The UP is sent with each

packet in the UP portion of the IP header. Typical values are as follows:

- 6 or 7 for voice

- 4 or 5 for video

The value may differ depending on other priority traffic sessions.

• Medium Time—Time that the TS traffic occupies the transmission medium.

• Excess Usage Events—Number of times that the client has exceeded the

medium time established for its TSPEC. Minor, infrequent violations are ignored.

• VAP MAC Address—Virtual Access Point MAC address.

Statistics:

• Network Interface—Radio interface used by the client.

• Station—Client station MAC address.

• TS Identifier—TSPEC Traffic Session Identifier (range 0 to 7).

• Access Category—TS Access Category (voice or video).

• Direction—The traffic direction for this TS. Direction can be one of these

options:

- uplink—From client to device.

- downlink—From device to client.

- bidirectional

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 19

Status and Statistics

TSPEC Status and Statistics

• From Station—Shows the number of packets and bytes received from the

wireless client and the number of packets and bytes that were dropped after being received.

- Packets—Number of packets in excess of an admitted TSPEC.

- Bytes—Number of bytes when no TSPEC has been established and

admission is required by the WAP device.

• To S ta ti on —The number of packets and bytes transmitted from the WAP

device to the wireless client and the number of packets and bytes that were dropped upon transmission.

- Packets—Number of packets in excess of an admitted TSPEC.

- Bytes—Number of bytes for which no TSPEC has been established

when admission is required by the WAP device.

You can click Refresh to refresh the screen and show the most current information.

TSPEC Status and Statistics

The TSPEC Status and Statistics page provides this information:

• Summary information about TSPEC sessions by radio.

• Summary information about TSPEC sessions by VAP.

• Real-time transmit and receive statistics for the radio interface and the

network interface(s).

All of the transmit and receive statistics shown are totals since the WAP device was last started. If you reboot the WAP device, these figures indicate transmit and receive totals since the reboot.

To view TSPEC status and statistics, select Status and Statistics > TSPEC Status and Statistics in the navigation pane.

The TSPEC Status and Statistics page provides this status information for the WLAN (Radio) and VAP interfaces:

• Network Interface—Name of the Radio or VAP interface. On WAP561

devices, WLAN0 represents radio 1 and WLAN1 represents radio 2.

• Access Category—Current Access Category associated with this Traffic

Stream (voice or video).

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 20

Status and Statistics

TSPEC Status and Statistics

• Status—Whether the TSPEC session is enabled (up) or not (down) for the

corresponding Access Category.

NOTE Status is a configuration status (it does not necessarily represent the

current session activity).

• Active Traffic Stream—Number of currently active TSPEC Traffic Streams

for this radio and Access Category.

• Traffic Stream Clients—Number of Traffic Stream clients associated with

this radio and Access Category.

• Medium Time Admitted—Time allocated for this Access Category over the

transmission medium to carry data. This value should be less than or equal to the maximum bandwidth allowed over the medium for this TS.

• Medium Time Unallocated—Time of unused bandwidth for this Access

Category.

These statistics appear separately for the transmit and receive paths on the wireless radio interface:

• Access Category—The Access Category associated with this Traffic

Stream (voice or video).

• Tot al P ac ket s —Total number of TS packets sent (in Transmit table) or

received (in Received table) by this Radio for the specified Access Category.

• Total Bytes—Total number of bytes received in the specified access

category.

These statistics appear separately for the transmit and receive paths on the network interfaces (VAPs):

• Total Voice Packets—Total number of TS voice packets sent (in Transmit

table) or received (in Received table) by this WAP device for this VAP.

• Total Voice Bytes—Total TS voice bytes sent (in Transmit table) or received

(in Received table) by this WAP device for this VAP.

• Total Video Packets—Total number of TS video packets sent (in Transmit

table) or received (in Received table) by this WAP device for this VAP.

• Total Video Bytes—Total TS video bytes sent (in Transmit table) or

received (in Received table) by this WAP device for this VAP.

You can click Refresh to refresh the screen and show the most current information.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 21

Status and Statistics

TSPEC AP Statistics

The TSPEC AP Statistics page provides information on the voice and video Traffic Streams accepted and rejected by the WAP device. To view the TSPEC AP Statistics page, select Status and Statistics > TSPEC AP Statistics in the navigation pane.

• TSPEC Statistics Summary for Voice ACM—The total number of

accepted and the total number of rejected voice traffic streams.

• TSPEC Statistics Summary for Video ACM—The total number of

accepted and the total number of rejected video traffic streams.

You can click Refresh to refresh the screen and show the most current information.

Radio Statistics

You can use the Radio Statistics page to show packet-level and byte-level statistics for each wireless radio interface. To view the Radio Statistics page, select Status and Statistics > Radio Statistics in the navigation pane.

For the WAP561 device, select the Radio for which you want to view statistics.

• Packets Received—Total packets received by the WAP device.

• Packets Transmitted—Total packets transmitted by the WAP device.

• Bytes Received—Total bytes received by the WAP device.

• Bytes Transmitted—Total bytes transmitted by the WAP device.

• Packets Receive Dropped—Number of packets received by the WAP

device that were dropped.

• Packets Transmit Dropped—Number of packets transmitted by the WAP

device that were dropped.

• Bytes Receive Dropped—Number of bytes received by the WAP device

that were dropped.

• Bytes Transmit Dropped—Number of bytes transmitted by the WAP

device that were dropped.

• Fragments Received—Number of fragmented frames received by the

WAP devic e.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 22

Status and Statistics

Radio Statistics

• Fragments Transmitted—Number of fragmented frames sent by the WAP

device.

• Multicast Frames Received—Count of MSDU frames received with the

multicast bit set in the destination MAC address.

• Multicast Frames Transmitted—Count of successfully transmitted MSDU

frames where the multicast bit was set in the destination MAC address.

• Duplicate Frame Count—Number of times a frame was received and the

Sequence Control field indicates it was a duplicate.

• Failed Transmit Count—Number of times an MSDU was not transmitted

successfully due to transmit attempts exceeding either the short retry limit or the long retry limit.

• FCS Error Count—Count of FCS errors detected in a received MPDU

frame.

• Transmit Retry Count—Number of times an MSDU is successfully

transmitted after one or more retries.

• ACK Failure Count—Count of ACK frames not received when expected.

• RTS Failure Count—Count of CTS frames not received in response to an

RTS frame.

• WEP Undecryptable Count—Number of frames discarded because they

could not be decrypted by the radio. Frames can be discarded because the frame was not encrypted, or it was encrypted with a privacy option not supported by the WAP device.

• RTS Success Count—Count of CTS frames received in response to an

RTS frame.

• Multiple Retry Count—Number of times an MSDU is successfully

transmitted after more than one retry.

• Frames Transmitted Count—Count of each successfully transmitted

MSDU.

You can click Refresh to refresh the screen and show the most current information.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 23

Status and Statistics

Email Alert Status

The Email Alert Status page provides information about the email alerts sent based on the syslog messages generated in the WAP device. To view the Email Alert Status page, select Status and Statistics > Email Alert Status in the navigation pane.

• Email Alert Status—The Email Alert configured status. The status is either

• Number of Emails Sent—The total number of emails sent. The range is an

• Number of Emails Failed—The total number of email failures. The range is

• Time Last Email Sent—The day, date, and time when the last email was

Enabled or Disabled. The default is Disabled.

unsigned integer of 32 bits. The default is 0.

an unsigned integer of 32 bits. The default is 0.

sent.

Log

You can click Refresh to show the most current information.

The Log page shows a list of system events that generated a log entry, such as login attempts and configuration changes. The log is cleared upon a reboot and can be cleared by an administrator. Up to 512 events can be shown. Older entries are removed from the list as needed to make room for new events.

To view the Log page, select Status and Statistics > Log in the navigation pane.

• Time Stamp—The system time when the event occurred.

• Severity—Whether the event is due to an error (err) or is informational (info).

• Service—The software component associated with the event.

• Description—A description of the event.

You can click Refresh to refresh the screen and show the most current information.

You can click Clear All to clear all entries from the log.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 24

Administration

This chapter describes how to configure global system settings and perform diagnostics.

It contains these topics:

• System Settings

• User Accounts

• Time Settings

• Log Settings

• Email Alert

• HTTP/HTTPS Service

• Management Access Control

• Manage Firmware

• Download/Backup Configuration File

• Configuration Files Properties

• Copy/Save Configuration

• Reboot

• Discovery—Bonjour

• Packet Capture

• Support Information

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 25

Administration

System Settings

The System Settings page enables you to configure information that identifies the WAP device within the network.

To configure system settings:

STEP 1 Select Administration > System Settings in the navigation pane.

STEP 2 Enter the parameters:

• Host Name—Administratively assigned name for the WAP device. By

convention, the name is the fully qualified domain name of the node. The default host name is wap concatenated with the last 6 hex digits of the MAC address of the WAP device. Host Name labels can contain only letters, digits and hyphens. Host Name labels cannot begin or end with a hyphen. No other symbols, punctuation characters, or blank spaces are permitted. The Host Name can be 1 to 63 characters long.

STEP 3 Click Save. The changes are saved to the Startup Configuration.

User Accounts

• System Contact—A contact person for the WAP device. The System

Contact can be 0 to 255 characters long and can include spaces and special characters.

• System Location—Description of the physical location of the WAP device.

The System Location can be 0 to 255 characters long and can include spaces and special characters.

One management user is configured on the WAP device by default:

• User Name: cisco

• Password: cisco

You can use the User Accounts page to configure up to four additional users and to change a user password.

To add a new user:

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 26

Administration

User Accounts

STEP 1 Select Administration > User Accounts in the navigation pane.

The User Account Table shows the currently configured users. The user cisco is preconfigured in the system to have Read/Write privileges.

All other users can have Read Only Access, but not Read/Write access.

STEP 2 Click Add. A new row of text boxes appears.

STEP 3 Check the box for the new user and select Edit.

STEP 4 Enter a User Name between 1 to 32 alphanumeric characters. Only numbers 0 to

9 and letters a to z (upper or lower) are allowed for user names.

STEP 5 Enter a New Password between 1 and 64 characters and then enter the same

password in the Confirm New Password text box.

As you enter a password, the number and color of vertical bars changes to indicate the password strength, as follows:

• Red—The password fails to meet the minimum complexity requirements.

• Orange—The password meets the minimum complexity requirements but

the password strength is weak.

• Green—The password is strong.

STEP 6 Click Save. The changes are saved to the Startup Configuration.

NOTE To delete a user, select the check box next to the user name and select Delete. To

save your deletion permanently, select Save when complete.

To change a user password:

STEP 1 Select Administration > User Accounts in the navigation pane.

The User Account Table shows the currently configured users. The user cisco is preconfigured in the system to have Read/Write privileges. The password for the user cisco can be changed.

STEP 2 Select the user to configure and click Edit.

STEP 3 Enter a New Password between 1 and 64 characters and then enter the same

password in the Confirm New Password text box.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 27

Administration

Time S et ting s

STEP 4 Click Save. The changes are saved to the Startup Configuration.

NOTE If you change your password, you must log in again to the system.

Time Settings

As you enter a password, the number and color of vertical bars changes to indicate the password strength, as follows:

• Red—The password fails to meet the minimum complexity requirements.

• Orange—The password meets the minimum complexity requirements but

the password strength is weak.

• Green—The password is strong.

A system clock provides a network-synchronized time-stamping service for software events such as message logs. You can configure the system clock manually or configure the WAP device as a Network Time Protocol (NTP) client that obtains the clock data from a server.

Use the Time Settings page to set the system time manually or to configure the system to acquire its time settings from a preconfigured NTP server. By default, the WAP device is configured to obtain its time from a predefined list of NTP servers.

The current system time appears at the top of the page, along with the System Clock Source option.

To use NTP to have the WAP device automatically acquire its time settings:

STEP 1 For the System Clock Source field, select Network Time Protocol (NTP).

STEP 2 Configure these parameters:

• NTP Server/IPv4/IPv6 Address Name—Specify the IPv4 address, IPv6

address, or hostname of an NTP server. A default NTP server is listed.

A hostname can consist of one or more labels, which are sets of up to 63 alphanumeric characters. If a hostname includes multiple labels, each is separated by a period (.). The entire series of labels and periods can be up to 253 characters long.

• Time Zone—Select the time zone for your location.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 28

Administration

Time S et ting s

STEP 3 Select Adjust Time for Daylight Savings if daylight savings time is applicable to

your time zone. When selected, configure these fields:

• Daylight Savings Start—Select the week, day, month, and time when

daylight savings time starts.

• Daylight Savings End—Select the week, day, month, and time when

daylight savings time ends.

• Daylight Savings Offset—Specify the number of minutes to move the clock

forward when daylight savings time begins and backward when it ends.

STEP 4 Click Save. The changes are saved to the Startup Configuration.

To manually configure the time settings:

STEP 1 For the System Clock Source field, select Manually.

STEP 2 Configure these parameters:

• System Date—Select the current month, day, and year date from the drop-

down lists.

• System Time—Select the current hour and minutes in 24-hour clock format,

such as 22:00:00 for 10 p.m.

• Time Zone—Select the time zone for your location.

STEP 3 Select Adjust Time for Daylight Savings if daylight savings time is applicable to

your time zone. When selected, configure these fields:

• Daylight Savings Start—Select the week, day, month, and time when

daylight savings time starts.

• Daylight Savings End—Select the week, day, month, and time when

daylight savings time ends.

• Daylight Savings Offset—Specify the number of minutes to move the clock

forward when daylight savings time begins and backward when it ends.

STEP 4 Click Save. The changes are saved to the Startup Configuration.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 29

Administration

Log Settings

CAUTION Enabling persistent logging can wear out the flash (nonvolatile) memory and

You can use the Log Settings page to enable log messages to be saved in permanent memory. You can also send logs to a remote host.

If the system unexpectedly reboots, log messages can be useful to diagnose the cause. However, log messages are erased when the system reboots unless you enable persistent logging.

degrade network performance. Only enable persistent logging to debug a problem. Make sure that you disable persistent logging after you finish debugging the problem.

To configure persistent logging:

STEP 1 Select Administration > Log Settings in the navigation pane.

STEP 2 Configure the parameters:

• Persistence—Click Enable to save system logs to nonvolatile memory so

that the logs are kept when the WAP device reboots. You can save up to 128 log messages in the nonvolatile memory. When the limit of 128 is reached, the oldest log message is overwritten by the newest message. Clear this field to save system logs to volatile memory. Logs in volatile memory are deleted when the system reboots.

• Severity—The minimum severity that an event must have for it to be written

to the log in nonvolatile memory. For example, if you specify 2 (critical), then critical, alert, and emergency events are logged to nonvolatile memory. Error messages with a severity level of 3 to 7 are written to volatile memory.

• Depth—The maximum number of messages, up to 512, that can be stored in

volatile memory. When the number you configure in this field is reached, the oldest log event is overwritten by the newest log event. Note that the maximum number of log messages that can be stored in nonvolatile memory (the persistent log) is 128, which is not configurable.

STEP 3 Click Save. The changes are saved to the Startup Configuration.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 30

Administration

Log Settings

The Kernel Log is a comprehensive list of system events (shown in the System Log) and kernel messages such as error conditions.

You cannot view kernel log messages directly from the web interface. You must first set up a remote log server to receive and capture logs. Then you can configure the WAP device to log to the remote log server.

Remote log server collection for WAP device syslog messages provides these features:

• Allows aggregation of syslog messages from multiple APs

• Stores a longer history of messages than is kept on a single WAP device

• Triggers scripted management operations and alerts

To specify a host on your network to serve as a remote log server:

STEP 1 Select Administration > Log Settings in the navigation pane.

STEP 2 Configure the parameters:

• Remote Log—Enables the WAP device to send log messages to a remote

host. When disabled, all log messages are kept on the local system.

• Server IPv4/IPv6 Address/Name—The IPv4 or IPv6 address, or the

hostname of the remote log server.

• UDP Port—The logical port number for the syslog process on the remote

host. The range is from 1 to 65535. The default port is 514.

Using the default port is recommended. If you choose to reconfigure the log port, make sure that the port number you assign to syslog is available for use.

STEP 3 Click Save. The changes are saved to the Startup Configuration.

If you enabled a Remote Log host, clicking Save activates remote logging. The WAP device sends its kernel messages real-time for display to the remote log server monitor, a specified kernel log file, or other storage, depending on your configurations.

If you disabled a Remote Log host, clicking Save disables remote logging.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 31

Administration

Email Alert

NOTE After new settings are saved, the corresponding processes may be stopped and

restarted. When this happens, the WAP device may lose connectivity. We recommend that you change WAP device settings when a loss of connectivity will least affect your wireless clients.

Use the email alert feature to send messages to the configured email addresses when particular system events occur.

The feature supports mail server configuration, message severity configuration, and up to three email address configurations to send urgent and non-urgent email alerts.

TIP Do not use your personal email address, which would unnecessarily expose your

personal email login credentials. Use a separate email account instead. Also be aware that many email accounts keep a copy of all sent messages by default. Anyone with access to this email account has access to the sent messages. Review your email settings to ensure that they are appropriate for the privacy policy of your business.

To configure the WAP device to send email alerts:

STEP 1 Select Administration > Email Alert in the navigation pane.

STEP 2 In the Global Configuration area, configure these parameters:

• Administrative Mode—Choose to enable the email alert feature globally.

• From Email Address—Enter the address to show as the sender of the email.

The address is a 255 character string with only printable characters. No address is configured by default.

• Log Duration—Choose the frequency at which scheduled messages are

sent. The range is from 30 to 1440 minutes. The default is 30 minutes.

• Scheduled Message Severity—Log messages of this severity level or

higher are grouped and sent to the configuration email address at the frequency specified by the Log Duration. Select from these values: None,

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 32

Administration

Email Alert

Emergency, Alert, Critical, Error, Warning, Notice, Info, and Debug. If set to None, then no scheduled severity messages are sent. The default severity is Warning.

• Urgent Message Severity—Log messages of this severity level or higher

are sent to the configured email address immediately. Select from these values: None, Emergency, Alert, Critical, Error, Warning, Notice, Info, and Debug. If set to None, then no urgent severity messages are sent. The default is Alert.

STEP 3 In the Mail Server Configuration area, configure these parameters:

• Server IPv4 Address/Name—Enter the IP address or hostname of the

outgoing SMTP server. (You can check with your email provider for the hostname.) The server address must be a valid IPv4 address or hostname. The IPv4 address should be in a form similar to xxx.xxx.xxx.xxx (192.0.2.10).

• Data Encryption—Enter the mode of security for the outbound email alert.

The alert can be sent using secure TLS protocol or the default Open protocol. Using secure TLSv1 protocol can prevent eavesdropping and tampering during the communication across the public network.

• Port—Enter the SMTP port number to use for outbound emails. The range is

a valid port number from 0 to 65535. The default port is 465. The port generally depends on the mode used by the email provider.

• Username—Enter the username for the email account that will be used to

send these emails. Typically (but not always) the username is the full email address including the domain (such as Name@example.com). The specified account will be used as the email address of the sender. The username can be from 1 to 64 alphanumeric characters.

• Password—Enter the password for the email account that will be used to

send these emails. The password can be from 1 to 64 characters.

STEP 4 Configure the email addresses and subject line.

• To E ma i l A d dr e s s 1/ 2/ 3—Enter up to three addresses to receive email

alerts. Each email address must be valid.

• Email Subject—Enter the text to appear in the email subject line. This can be

up to a 255 character alphanumeric string.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 33

Administration

Email Alert

STEP 5 Click Te s t Ma il to send a test email to validate the configured email account.

STEP 6 Click Save. The changes are saved to the Startup Configuration.

The following example shows how to fill in the Mail Server Configuration parameters:

Gmail Server IPv4 Address/Name = smtp.gmail.com Data Encryption = TLSv1 Port = 465 Username = Your full email address you can use to login to your email account associated with the above server Password = xxxxxxxx is a valid password of your valid email account To Email Address 1 = myemail@gmail.com

Windows Live Hotmail Windows Live Hotmail recommends the following settings: Data Encryption: TLSv1 SMTP Server: smtp.live.com SMTP Port: 587 Username: Your full email address, such as myName@hotmail.com or myName@myDomain.com Password: Your Windows Live account password

Yahoo! Mail Yahoo requires using a paid account for this type of service. Yahoo recommends the following settings: Data Encryption: TLSv1 SMTP Server: plus.smtp.mail.yahoo.com SMTP Port: 465 or 587 Username: Your email address, without the domain name such as myName (without @yahoo.com) Password: Your Yahoo account password

The following example shows a sample format of a general log email:

From: AP-192.168.2.10@mailserver.com Sent: Wednesday, September 09, 2009 11:16 AM To: administrator@mailserver.com Subject: log message from AP

TIME PriorityProcess Id Message Sep 8 03:48:25 info login[1457] root login on ttyp0 Sep 8 03:48:26 info mini_http-ssl[1175] Max concurrent connections of 20 reached

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 34

Administration

HTTP/HTTPS Service

Use the HTTP/HTTPS Service page to enable and configure web-based management connections. If HTTPS is used for secure management sessions, you also use the HTTP/HTTPS Service page to manage the required SSL certificates.

To configure HTTP and HTTP services:

STEP 1 Select Administration > HTTP/HTTPS Service in the navigation pane.

STEP 2 Configure these Global Settings:

• Maximum Sessions—The number of web sessions, including both HTTP

and HTTPS, that can be in use at the same time.

When a user logs on to the WAP device configuration utility, a session is created. This session is maintained until the user logs off or the Session Timeout expires. The range is from 1 to 10 sessions. The default is 5. If the maximum number of sessions is reached, the next user who attempts to log on to the configuration utility receives an error message about the session limit.

• Session Timeout—The maximum amount of time, in minutes, an inactive

user remains logged on to the WAP device configuration utility. When the configured timeout is reached, the user is automatically logged off. The range is from 1 to 60 minutes. The default is 10 minutes.

STEP 3 Configure HTTP and HTTPS services:

• HTTP Server—Enables access through HTTP. By default, HTTP access is

enabled. If you disable it, any current connections using that protocol are disconnected.

• HTTP Port—The logical port number to use for HTTP connections, from

1025 to 65535. The default port number for HTTP connections is the wellknown IANA port number 80.

• HTTPS Server—Enables access through secure HTTP. By default, HTTPS

access is enabled. If you disable it, any current connections using that protocol are disconnected.

• HTTPS Port—The logical port number to use for HTTP connections, from

1025 to 65535. The default port number for HTTP connections is the wellknown IANA port number 443.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 35

Administration

HTTP/HTTPS Service

STEP 4 Click Save. The changes are saved to the Startup Configuration.

• Redirect HTTP to HTTPS—Redirects management HTTP access attempts

on the HTTP port to the HTTPS port. This field is available only when HTTP access is disabled.

To use HTTPS services, the WAP device must have a valid SSL certificate. The WAP device can generate a certificate or you can download it from your network or from a TFTP server.

To generate the certificate with the WAP device, click Generate SSL Certificate. This should be done after the WAP device has acquired an IP address to ensure that the common name for the certificate matches the IP address of the WAP device. Generating a new SSL certificate restarts the secure web server. The secure connection does not work until the new certificate is accepted on the browser.

In the Certificate File Status area, you can view whether a certificate currently exists on the WAP device, and view this information about it:

• Certificate File Present

• Certificate Expiration Date

• Certificate Issuer Common Name

If an SSL certificate (with a .pem extension) exists on the WAP device, you can download it to your computer as a backup. In the Download SSL Certificate (From Device to PC) area, select HTTP or TFTP for the Download Method and click Download.

• If you select HTTP, you are prompted to confirm the download and then to

browse to the location to save the file on your network.

• If you select TFTP, additional fields appear to enable you to enter the File

Name to assign to the downloaded file, and enter the TFTP server address where the file will be downloaded.

You can also upload a certificate file (with a .pem extension) from your computer to the WAP device. In the Upload SSL Certificate (From PC to Device) area, select HTTP or TFTP for the Upload Method.

• For HTTP, browse to the network location, select the file, and click Upload.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 36

Administration

Management Access Control

• For TFTP, enter the File Name as it exists on the TFTP server and the TFTP

Server IPv4 Address, then click Upload. The filename cannot contain the

following characters: spaces, <, >, |, \, : , (, ), &, ; , #, ? , *, and two or more successive periods.

A confirmation appears when the upload was successful.

Management Access Control

You can create an access control list (ACL) that lists up to five IPv4 hosts and five IPv6 hosts that are authorized to access the WAP device configuration utility. If this feature is disabled, anyone can access the configuration utility from any network client by supplying the correct WAP device username and password.

If the management ACL is enabled, access through the web and SNMP is restricted to the specified IP hosts.

CAUTION Verify any IP address that you enter. If you enter an IP address that does not match

your Administrative computer, you will lose access to the configuration interface. It is highly recommend to give the Administrative computer a static IP address, so the address does not change over time.

To create an access list:

STEP 1 Select Administration > Management Access Control in the navigation pane.

STEP 2 Select Enable for the Management ACL Mode.

STEP 3 Enter up to five IPv4 and five IPv6 addresses that will be allowed access.

STEP 4 Verify the IP addresses are correct.

STEP 5 Click Save. The changes are saved to the Startup Configuration.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 37

Administration

Manage Firmware

The WAP device maintains two firmware images. One image is active and the other is inactive. If the active image fails to load during bootup, the inactive image is loaded and becomes the active image. You can also swap the primary and secondary images.

As new versions of the WAP device firmware become available, you can upgrade the firmware on your devices to take advantage of new features and enhancements. The WAP device uses a TFTP or HTTP client for firmware upgrades.

After you upload new firmware and the system reboots, the newly added firmware becomes the primary image. If the upgrade fails, the original firmware remains as the primary image.

NOTE When you upgrade the firmware, the access point retains the existing configuration

information.

Swapping the Firmware Image

To swap the firmware image running on the AP:

STEP 1 Select Administration > Manage Firmware in the navigation pane.

STEP 2 Click Swap Active Image.

A dialog box appears confirming the firmware image switch and subsequent reboot.

STEP 3 Click OK to proceed.

The process may take several minutes, during which time the access point is unavailable. Do not power down the access point while the image switch is in process. When the image switch is complete, the access point restarts. The AP resumes normal operation with the same configuration settings it had before the upgrade.

To upgrade the firmware on an access point using TFTP:

STEP 1 Select Administration > Manage Firmware in the navigation pane.

The Product ID (PID VID) and active and inactive firmware versions appear.

STEP 2 Select TFTP for Transfer Method.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 38

Administration

Manage Firmware

STEP 3 Enter a name (1 to 256 characters) for the image file in the Source File Name field,

including the path to the directory that contains the image to upload.

For example, to upload the ap_upgrade.tar image located in the /share/builds/ap directory, enter: /share/builds/ap/ap_upgrade.tar

The firmware upgrade file supplied must be a tar file. Do not attempt to use bin files or files of other formats for the upgrade; these types of files do not work.

The filename cannot contain the following items: spaces, <, >, |, \, : , (, ), &, ; , #, ? , *, and two or more successive periods.

STEP 4 Enter the TFTP Server IPv4 Address and click Upgrade.

Uploading the new software may take several minutes. Do not refresh the page or navigate to another page while uploading the new software, or the software upload is aborted. When the process is complete the access point restarts and resumes normal operation.

STEP 5 To verify that the firmware upgrade completed successfully, log into the user

interface and display the Upgrade Firmware page and view the active firmware version.

To upgrade using HTTP:

STEP 1 Select HTTP for Transfer Method.

STEP 2 If you know the name and path to the new file, enter it in the Source File Name

field. Otherwise, click the Browse button and locate the firmware image file on your network.

The firmware upgrade file supplied must be a tar file. Do not attempt to use bin files or files of other formats for the upgrade; these types of files do not work.

STEP 3 Click Upgrade to apply the new firmware image.

Uploading the new software may take several minutes. Do not refresh the page or navigate to another page while uploading the new software, or the software upload is aborted. When the process is complete, the access point restarts and resumes normal operation.

STEP 4 To verify that the firmware upgrade completed successfully, log into the user

interface, display the Upgrade Firmware page, and view the active firmware version.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 39

Administration

Download/Backup Configuration File

The WAP device configuration files are in XML format and contain all the information about the WAP device settings. You can back up (upload) the configuration files to a network host or TFTP server to manually edit the content or create backups. After you edit a backed-up configuration file, you can download it to the access point to modify the configuration.

The WAP device maintains these configuration files:

• Startup Configuration—The configuration file saved to flash memory.

• Backup Configuration—An additional configuration file saved on the WAP

device for use as a backup.

• Mirror Configuration—If the Startup Configuration is not modified for at

least 24 hours, it is automatically saved to a Mirror Configuration file. The Mirror Configuration file is a snapshot of a past Startup Configuration. The Mirror Configuration is preserved across factory resets, so it can be used to recover a system configuration after a factory reset by copying the Mirror Configuration to the Startup Configuration.

NOTE In addition to downloading and uploading these files to another system, you can

copy them to different file types on the WAP device. See Copy/Save

Configuration.

To back up (upload) the configuration file to a network host or TFTP server:

STEP 1 Select Administration > Download/Backup Configuration File in the navigation

pane.

STEP 2 Select Via TFTP or Via HTTP/HTTPS as the Transfer Method.

STEP 3 Select Backup (AP to PC) as the Save Action.

STEP 4 For a TFTP backup only, enter the Destination File Name with an .xml extension.

Also include the path where the file is to be placed on the server and then enter the TFTP Server IPv4 Address.

The filename cannot contain the following characters: spaces, <, >, |, \, : , (, ), &, ; , #, ? , *, and two or more successive periods.

STEP 5 For a TFTP backup only, enter the TFTP Server IPv4 Address.

STEP 6 Select which configuration file you want to back up:

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 40

Administration

Download/Backup Configuration File

• Startup Configuration—Configuration file type used when the WAP device

• Backup Configuration—Backup configuration file type saved on the WAP

• Mirror Configuration—If the Startup Configuration is not modified for at

STEP 7 Click Save to begin the backup. For HTTP backups, a window appears to enable

you to browse to the desired location for saving the file.

last booted. This does not include any configuration changes applied but not yet saved to the WAP device.

device.

You can download a file to the WAP device to update the configuration or to restore the WAP device to a previously backed-up configuration.

To download a configuration file to the WAP device:

STEP 1 Select Administration > Download/Backup Configuration File in the navigation

pane.

STEP 2 Select Via TFTP or Via HTTP/HTTPS as the Transfer Method.

STEP 3 Select Download (PC to AP) as the Save Action.

STEP 4 For a TFTP download only, enter the Source File Name with an .xml extension.

Include the path (where the file exists on the server) and enter the TFTP Server IPv4 Address.

The filename cannot contain the following characters: spaces, <, >, |, \, : , (, ), &, ; , #, ? , *, and two or more successive periods.

STEP 5 Select which configuration file on the WAP device that you want replaced with the

downloaded file: the Startup Configuration or the Backup Configuration.

If the downloaded file overwrites the Startup Configuration file, and the file passes a validity check, then the downloaded configuration takes effect the next time the WAP devic e reb oo ts.

STEP 6 Click Save to begin the upgrade or backup. For HTTP downloads, a window

appears to enable you to browse to select the file to download. When the download is finished, a window indicates success.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 41

Administration

Configuration Files Properties

CAUTION Ensure that power to the WAP device remains uninterrupted while the configuration

file is downloading. If a power failure occurs while downloading the configuration file, the file is lost and the process must be restarted.

Configuration Files Properties

The Configuration Files Properties page enables you to clear the Startup or Backup Configuration file. If you clear the Startup Configuration file, the Backup Configuration file becomes active the next time that you reboot the WAP device.

To delete the Startup Configuration or Backup Configuration file:

STEP 1 Select Administration > Configuration Files Properties in the navigation pane.

STEP 2 Select the Startup Configuration, or Backup Configuration file type.

STEP 3 Click Clear Files.

Copy/Save Configuration

The Copy/Save Configuration page enables you to copy files within the WAP device file system. For example, you can copy the Backup Configuration file to the Startup Configuration file type, so that it is used the next time you boot up the WAP devic e.

To copy a file to another file type:

STEP 1 Select Administration > Copy/Save Configuration in the navigation pane.

STEP 2 Select the Source File Name:

• Startup Configuration—Configuration file type used when the WAP device

last booted. This does not include any configuration changes applied but not yet saved to the WAP device.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 42

Administration

Reboot

• Backup Configuration—Backup configuration file type saved on the WAP

device.

• Mirror Configuration—If the Startup Configuration is not modified for at

STEP 3 For the Destination File Name, select the file type to be replaced with the file you

are copying.

STEP 4 Click Save to begin the copy process.

When complete, a window shows the message, Copy Operation Successful.

Reboot

You can use the Reboot page reboot the WAP device.

STEP 1 To reboot the WAP, select Administration > Reboot in the navigation pane.

STEP 2 Select one of these options:

• Reboot—Reboots the WAP using Startup Configuration.

• Reboot to Factory Default—Reboots the WAP using the factory default

configuration file. Any customized settings are lost.

A window appears to enable you to confirm or cancel the reboot. The current management session might be terminated.

STEP 3 Click OK to reboot.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 43

Administration

Discovery—Bonjour

Bonjour enables the WAP device and its services to be discovered by using multicast DNS (mDNS). Bonjour advertises services to the network and answers queries for the service types that it supports, simplifying network configuration in small business environments.

The WAP device advertises these service types:

• Cisco-specific device description (csco-sb)—This service enables clients

to discover Cisco WAP devices and other products deployed in small business networks.

• Management user interfaces—This service identifies the management

interfaces available on the WAP device (HTTP and SNMP).

When a Bonjour-enabled WAP device is attached to a network, any Bonjour client can discover and get access to the configuration utility without prior configuration.

A system administrator can use an installed Internet Explorer plug-in to discover the WAP device. The web-based configuration utility shows up as a tab in the browser.

Bonjour works in both IPv4 and IPv6 networks.

Bonjour is enabled by default. To change the administrative status:

STEP 1 Select Administration > Discovery - Bonjour in the navigation pane.

STEP 2 Click Enable to enable Bonjour or uncheck Enable to disable Bonjour.

STEP 3 Click Save. The changes are saved to the Startup Configuration.

Packet Capture

The wireless packet capture feature enables capturing and storing packets received and transmitted by the WAP device. The captured packets can then be analyzed by a network protocol analyzer, for troubleshooting or performance optimization. There are two methods of packet capture:

• Local capture method— Captured packets are stored in a file on the WAP

device. The WAP device can transfer the file to a TFTP server. The file is

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 44

Administration

Packet Capture

formatted in pcap format and can be examined using tools such as Wireshark and OmniPeek.

• Remote capture method—Captured packets are redirected in real time to

an external computer running the Wireshark tool.

The WAP device can capture these types of packets:

• 802.11 packets received and transmitted on radio interfaces. Packets

captured on radio interfaces include the 802.11 header.

• 802.3 packets received and transmitted on the Ethernet interface.

• 802.3 packets received and transmitted on the internal logical interfaces

such as VAPs and WDS interfaces.

Click Administration > Packet Capture to show the Packet Capture page. From the Packet Capture page you can:

• Configure packet capture parameters.

• Start a local or remote packet capture.

• View the current packet capture status.

• Download a packet capture file.

The Packet Capture Configuration area enables you to configure parameters and initiate a packet capture.

To configure packet capture settings:

STEP 1 Configure these parameters:

• Capture Beacons—Enables or disables the capturing of 802.11 beacons

detected or transmitted by the radio.

• Promiscuous Capture—Enables or disables promiscuous mode when the

capture is active.

In promiscuous mode, the radio receives all traffic on the channel, including traffic that is not destined to this WAP device. While the radio is operating in promiscuous mode, it continues serving associated clients. Packets not destined to the WAP device are not forwarded.

As soon as the capture is completed, the radio reverts to nonpromiscuous mode operation.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 45

Administration

Packet Capture

• Radio Client Filter—Enables or disables the WLAN client filter to capture

only frames that are transmitted to, or received from, a WLAN client with a specified MAC address.

• Client Filter MAC Address—Specifies the MAC address for WLAN client

filtering.

NOTE The MAC filter is active only when a capture is performed on an

802.11 interface.

• Packet Capture Method—Select one of these options:

- Local File—Captured packets are stored in a file on the WAP device.

- Remote—Captured packets are redirected in real time to an external

computer running the Wireshark tool.

STEP 2 Depending on the selected method, refer to the steps in the Local Packet Capture

or Remote Packet Capture section to continue.

NOTE Changes to packet capture configuration parameters take affect after packet

capture is restarted. Modifying the parameters while the packet capture is running does not affect the current packet capture session. To begin using new parameter values, an existing packet capture session must be stopped and restarted.

To initiate a local packet capture:

STEP 1 Ensure that Local File is selected for the Packet Capture Method.

STEP 2 Configure these parameters:

• Capture Interface—Enter a capture interface type for packet capture:

- radio1—802.11 traffic on Radio 1.

- radio2—802.11 traffic on Radio 2 (WAP561 only).

- eth0—802.3 traffic on the Ethernet port.

- VAP0 or WLAN0:VAP0—VAP0 traffic. For WAP561, this shows as

WLAN0:VAP0, where WLAN0 represents Radio 1.

- WLAN1:VAP0—VAP0 traffic on Radio 2 (for WAP561 devices only).

- VAP1 to VAP15, if configured—Traffic on the specified VAP. For WAP561,

the interface names are preceded by WLAN0: or WLAN1:, where WLAN0 represents Radio 1 and WLAN1 represents Radio 2.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 46

Administration

Packet Capture

- brtrunk—Linux bridge interface in the WAP device.

• Capture Duration—Enter the time duration in seconds for the capture. The

range is from 10 to 3600. The default is 60.

• Max Capture File Size—Enter the maximum allowed size for the capture file

in KB. The range is from 64 to 4096. The default is 1024.

STEP 3 Click Save. The changes are saved to the Startup Configuration.

STEP 4 Click Start Capture.

In Packet File Capture mode, the WAP device stores captured packets in the RAM file system. Upon activation, the packet capture proceeds until one of these events occurs:

• The capture time reaches the configured duration.

• The capture file reaches its maximum size.

• The administrator stops the capture.

The Packet Capture Status area of the page shows the status of a packet capture, if one is active on the WAP device.

• Current Capture Status—Whether packet capture is running or stopped.

• Packet Capture Time—Elapsed capture time.

• Packet Capture File Size—The current capture file size.

Click Refresh to show the latest data from the WAP device.

NOTE To stop a packet file capture, click Stop Capture.

The Remote Packet Capture feature enables you to specify a remote port as the destination for packet captures. This feature works in conjunction with the Wireshark network analyzer tool for Windows. A packet capture server runs on the WAP device and sends the captured packets through a TCP connection to the Wireshark tool. Wireshark is an open source tool and is available for free; it can be downloaded from http://www.wireshark.org.

A Microsoft Windows computer running the Wireshark tool allows you to display, log, and analyze captured traffic. The remote packet capture facility is a standard feature of the Wireshark tool for Windows. Linux version does not work with the WAP devic e.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 47

Administration

Packet Capture

When remote capture mode is in use, the WAP device does not store any captured data locally in its file system.

If a firewall is installed between the Wireshark computer and the WAP device, the traffic for these ports must be allowed to pass through the firewall. The firewall must also be configured to allow the Wireshark computer to initiate a TCP connection to the WAP device.

To initiate a remote capture on a WAP device:

STEP 1 Click Administration > Packet Capture.

STEP 2 Enable Promiscuous Capture.

STEP 3 For the Packet Capture Method, select Remote.

STEP 4 For the Remote Capture Port, use the default port (2002), or if you are using a

port other than the default, enter the desired port number used for connecting Wireshark to the WAP device. The port range is from 1025 to 65530.

STEP 5 If you want to save the settings for use at another time, click Save.

STEP 6 Click Start Capture.

To initiate the Wireshark network analyzer tool for Microsoft Windows:

STEP 1 On the same computer, initiate the Wireshark tool.

STEP 2 In the menu, select Capture > Options. A popup window appears.

STEP 3 At Interface, select Remote. A popup window appears.

STEP 4 At Host, enter the IP address of the WAP device.

STEP 5 At Port, enter the port number of the WAP. For example, enter 2002 if you used the

default, or enter the port number if you used a port other than the default.

STEP 6 Click OK.

STEP 7 Select the interface from which you need to capture packets. At the Wireshark

popup window, next to the IP address, there is a pull-down list for you to select the interfaces. The interface can be one of the following:

Linux bridge interface in the wap device

--rpcap://[192.168.1.220]:2002/brtrunk

Wired LAN interface

-- rpcap://[192.168.1.220]:2002/eth0 VAP0 traffic on radio 1

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 48

Administration

Packet Capture

-- rpcap://[192.168.1.220]:2002/wlan0

802.11 traffic

-- rpcap://[192.168.1.220]:2002/radio1

At WAP561, VAP1 ~ VAP7 traffic

-- rpcap://[ 192.168.1.220]:2002/wlan0vap1 ~ wlan0vap7

At WAP561, VAP1 ~ VAP3 traffic

-- rpcap://[ 192.168.1.220]:2002/wlan0vap1 ~ wlan0vap3

You can trace up to four interfaces on the WAP device at the same time. However, you must start a separate Wireshark session for each interface. To initiate additional remote capture sessions, repeat the Wireshark configuration steps; no configuration needs to be done on the WAP device.

NOTE The system uses four consecutive port numbers, starting with the configured port

for the remote packet capture sessions. Verify that you have four consecutive port numbers available. We recommend that if you do not use the default port, use a port number greater than 1024.

When you are capturing traffic on the radio interface, you can disable beacon capture, but other 802.11 control frames are still sent to Wireshark. You can set up a display filter to show only:

• Data frames in the trace

• Traffic on specific Basic Service Set IDs (BSSIDs)

• Traffic between two clients

Some examples of useful display filters are:

• Exclude beacons and ACK/RTS/CTS frames:

!(wlan.fc.type_subtype == 8 | | wlan.fc.type == 1)

• Data frames only:

wlan.fc.type == 2

• Traffic on a specific BSSID:

wlan.bssid == 00:02:bc:00:17:d0

• All traffic to and from a specific client:

wlan.addr == 00:00:e8:4e:5f:8e

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 49

Administration

Packet Capture

In remote capture mode, traffic is sent to the computer running Wireshark through one of the network interfaces. Depending on the location of the Wireshark tool, the traffic can be sent on an Ethernet interface or one of the radios. To avoid a traffic flood caused by tracing the packets, the WAP device automatically installs a capture filter to filter out all packets destined to the Wireshark application. For example, if the Wireshark IP port is configured to be 58000, then this capture filter is automatically installed on the WAP device:

not portrange 58000-58004

Due to performance and security issues, the packet capture mode is not saved in NVRAM on the WAP device; if the WAP device resets, the capture mode is disabled and then you must reenable it to resume capturing traffic. Packet capture parameters (other than mode) are saved in NVRAM.

Enabling the packet capture feature can create a security issue: Unauthorized clients may be able to connect to the WAP device and trace user data. The performance of the WAP device also is negatively impacted during packet capture, and this impact continues to a lesser extent even when there is no active Wireshark session. To minimize the performance impact on the WAP device during traffic capture, install capture filters to limit which traffic is sent to the Wireshark tool. When capturing 802.11 traffic, a large portion of the captured frames tends to be beacons (typically sent every 100 ms by all APs). Although Wireshark supports a display filter for beacon frames, it does not support a capture filter to prevent the WAP device from forwarding captured beacon packets to the Wireshark tool. To reduce the performance impact of capturing the 802.11 beacons, disable the capture beacons mode.

You can download a capture file by TFTP to a configured TFTP server, or by HTTP(S) to a computer. A capture is automatically stopped when the capture file download command is triggered.

Because the capture file is located in the RAM file system, it disappears if the WAP device is reset.

To download a packet capture file using TFTP:

STEP 1 Select Use TFTP to download the capture file.

STEP 2 Enter the TFTP Server Filename to download if different from the default. By

default, the captured packets are stored in the folder file /tmp/apcapture.pcap on the WAP device.

STEP 3 Specify a TFTP Server IPv4 Address in the field provided.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 50

Administration

Support Information

STEP 4 Click Download.

To download a packet capture file using HTTP:

STEP 1 Clear Use TFTP to download the captured file.

STEP 2 Click Download. A confirmation window appears.

STEP 3 Click OK. A dialog box displays that enables you to choose a network location to

save the file.

Support Information

The Support Information page enables you to download a text file that contains detailed configuration information about the AP. The file includes software and hardware version information, MAC and IP addresses, the administrative and operational status of features, user-configured settings, traffic statistics, and more. You can provide the text file to technical support personnel to assist them in troubleshooting problems.

To show the Support Information page, select Administration > Support Information in the navigation pane.

Click Download to generate the file based on current system settings. After a short pause, a window appears to enable you to save the file to your computer.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 51

LAN

This chapter describes how to configure the port, network, and clock settings of the WAP devices.

It includes these topics:

• Port Settings

• VLAN and IPv4 Address Settings

• IPv6 Addresses

• IPv6 Tunnel

Port Settings

STEP 1 Select LAN > Port Settings in the navigation area.

STEP 2 Enable or disable Auto Negotiation.

The Port Settings page enables you to view and configure settings for the port that physically connects the WAP device to a local area network.

To view and configure LAN settings:

The Operational Status area shows the type of port used for the LAN port and the Link characteristics, as configured in the Administrative Settings area. If the settings change through configuration or auto negotiation, you can click Refresh to show the latest settings.

• When enabled, the port negotiates with its link partner to set the fastest link

speed and duplex mode available.

• When disabled, you can manually configure the port speed and duplex

mode.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 52

LAN

VLAN and IPv4 Address Settings

STEP 3 If autonegotiation is disabled, select a Port Speed (10/100/1000 Mb/s) and the

duplex mode (Half- or Full-duplex).

STEP 4 Enable or disable the Green Ethernet Mode. When enabled, the WAP device

automatically enters a low-power mode when energy on the line is lost, and it resumes normal operation when energy is detected.

STEP 5 Click Save. The changes are saved to the Startup Configuration.

VLAN and IPv4 Address Settings

You can use the VLAN and IPv4 Address Settings page to configure settings for the LAN interface, including static or dynamic IPv4 address assignment.

To configure LAN settings:

STEP 1 Select LAN > VLAN and IPv4 Address in the navigation area.

The page shows Global Settings and IPv4 Settings. The Global Settings area shows the MAC address of the LAN interface port. This field is read-only.

STEP 2 Configure these Global Settings:

• Untagged VLAN—Enables or disables VLAN tagging. When enabled (the

default), all traffic is tagged with a VLAN ID.

By default all traffic on the access point uses VLAN 1, the default untagged VLAN. This means that all traffic is untagged until you disable the untagged VLAN, change the untagged traffic VLAN ID, or change the VLAN ID for a VAP or client using RADIUS.

• Untagged VLAN ID—Specifies a number between 1 and 4094 for the

untagged VLAN ID. The default is 1. Traffic on the VLAN that you specify in this field is not be tagged with a VLAN ID when forwarded to the network.

VLAN 1 is the both default untagged VLAN and the default management VLAN. If you want to segregate management traffic from the untagged VLAN traffic, configure the new VLAN ID at your router, and then use this new VLAN ID on your WAP device.

• Management VLAN ID—The VLAN associated with the IP address you use

to access the WAP device. Provide a number between 1 and 4094 for the Management VLAN ID. The default is 1.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 53

LAN

IPv6 Addresses

This VLAN is also the default untagged VLAN. If you already have a management VLAN configured on your network with a different VLAN ID, you must change the VLAN ID of the management VLAN on the WAP device.

STEP 3 Configure these IPv4 settings:

• Connection Type—By default, the DHCP client on the Cisco WAP551 and

WAP561 Access Point automatically broadcasts requests for network information. If you want to use a static IP address, you must disable the DHCP client and manually configure the IP address and other network information.

Select one of these values from the list:

- DHCP—The WAP device acquires its IP address from a DHCP server on

the LAN.

- Static IP—You manually configure the IPv4 address. The IPv4 address

should be in a form similar to xxx.xxx.xxx.xxx (192.0.2.10).

STEP 4 Click Save. The changes are saved to the Startup Configuration.

NOTE After new settings are saved, the corresponding processes may be stopped and

restarted. When this happens, the WAP device may lose connectivity. We recommend that you change WAP device settings when a loss of connectivity will least affect your wireless clients.

IPv6 Addresses

You can use the IPv6 Addresses page to configure the WAP device to use IPv6 addresses.

• Static IP Address, Subnet Mask, and Default Gateway—If you elected to

assign a static IP address, enter the IP information.

• Domain Name Servers—Select an option from the list:

- Dynamic—The WAP device acquires DNS server addresses from a

DHCP server on the LAN.

- Manual—You manually configure one or more DNS server addresses.

Enter up to two IP addresses in the text boxes.

To configure IPv6 address settings:

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 54

LAN

IPv6 Addresses

STEP 1 Select LAN > IPv6 Addresses in the navigation area.

STEP 2 Configure the following settings:

• IPv6 Connection Type—Choose how the WAP device obtains an IPv6

address:

- DHCPv6—The IPv6 address is assigned by a DHCPv6 server.

- Static IPv6—You manually configure the IPv6 address. The IPv6 address

should be in a form similar to xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx (2001:DB8::CAD5:7D91).

• IPv6 Administration Mode—Enables IPv6 management access.

• IPv6 Auto Configuration Administration Mode—Enables IPv6 automatic

address configuration on the WAP device.

When enabled, the WAP device learns its IPv6 addresses and gateway by processing the Router Advertisements received on the LAN port. The WAP device can have multiple autoconfigured IPv6 addresses.

• Static IPv6 Address—The static IPv6 address. The WAP device can have a

static IPv6 address even if addresses have already been configured automatically.

• Static IPv6 Address Prefix Length—The prefix length of the static address,

which is an integer in the range of 0 to 128. The default is 0.

• Static IPv6 Address Status—One of the following values appears:

- Operational—The IP address has been verified as unique on the LAN

and is usable on the interface.

- Te nt at iv e—The WAP device initiates a duplicate address detection

(DAD) process automatically when a static IP address is assigned. An IPv6 address is in the tentative state while it is being verified as unique on the network. While in this state, the IPv6 address cannot be used to transmit or receive ordinary traffic.

- Blank (no value)—No IP address is assigned or the assigned address is

not operational.

• IPv6 Autoconfigured Global Addresses—If the WAP device has been

assigned one or more IPv6 addresses automatically, the addresses are listed.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 55

LAN

IPv6 Tunnel

• IPv6 Link Local Address—The IPv6 address used by the local physical link.

The link local address is not configurable and is assigned by using the IPv6 Neighbor Discovery process.

• Default IPv6 Gateway—The statically configured default IPv6 gateway.

• IPv6 DNS Nameservers—Select one of the following values:

- Dynamic—The DNS name servers are learned dynamically through

DHCPv6.

- Manual—You specify up to two IPv6 DNS name servers in the fields

provided.

STEP 3 Click Save. The changes are saved to the Startup Configuration.

NOTE After new settings are saved, the corresponding processes may be stopped and

restarted. When this happens, the WAP device may lose connectivity. We recommend that you change WAP device settings when a loss of connectivity will least affect your wireless clients.

IPv6 Tunnel

The WAP551 and WAP561 devices support the Intra-Site Automatic Tunnel Addressing Protocol (ISATAP). ISATAP enables the WAP device to transmit IPv6 packets encapsulated within IPv4 packets over the LAN. The protocol enables the WAP device to communicate with remote IPv6-capable hosts even when the LAN that connects them does not support IPv6.

The WAP device acts as an ISATAP client. An ISATAP enabled host or router must reside on the LAN. The IP address or hostname of the router is configured on the WAP device (by default, it is isatap). If configured as a hostname, the WAP device communicates with a DNS server to resolve the name into one or more ISATAP router addresses. The WAP device then sends solicit messages to the router(s). When an ISATAP-enabled router replies with an advertisement message, the WAP device and router establish the tunnel. The tunnel interface is assigned a link-local and a global IPv6 address, which serve as virtual IPv6 interfaces on the IPv4 network.

When IPv6 hosts initiate communication with the WAP device connected via the ISATAP router, the IPv6 packets are encapsulated into IPv4 packets by the ISATAP router.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 56

LAN

IPv6 Tunnel

To configure an IPv6 tunnel using ISATAP:

STEP 1 Select LAN > IPv6 Tunnel in the navigation area.

STEP 2 Configure the following parameters:

• ISATAP Status—Enables or disables the administrative mode of ISATAP on

the WAP device.

• ISATAP Capable Host—The IP address or DNS name of the ISATAP router.

The default value is isatap.

• ISATAP Query Interval—Specifies how often the WAP device should send

queries to the DNS server to attempt to resolve the ISATAP host name into an IP address. The WAP sends DNS queries only when the IP address of an ISATAP router is unknown. The valid range is 120 to 3600 seconds.

• ISATAP Solicitation Interval—Specifies how often the WAP should send

router solicitation messages to the ISATAP router(s) it learns about through the DNS query messages. The WAP sends router solicitation messages only when there is no active ISATAP router. The valid range is 120 to 3600 seconds.

STEP 3 Click Save. The settings are saved to the Startup Configuration.

When the tunnel is established, the ISATAP IPv6 Link Local Address and ISATAP IPv6 Global Address show on the page. These are the virtual IPv6 interface addresses to the IPv4 network.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 57

Wireless

This chapter describes how to configure properties of the wireless radio operation.

It includes these topics:

• Radio

• Rogue AP Detection

• Networks

• Scheduler

• Scheduler Association

Radio

• Bandwidth Utilization

• MAC Filtering

• WDS Bridge

• WorkGroup Bridge

• Quality of Service

• WPS Setup

• WPS Process

Radio settings directly control the behavior of the radio in the WAP device and its interaction with the physical medium; that is, how and what type of signal the WAP device emits.

To configure radio settings:

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 58

Wireless

Radio

STEP 1 Select Wireless > Radio in the navigation pane.

STEP 2 In the Global Settings area, configure the TSPEC Violation Interval, which is the

time interval in seconds for the WAP device to report associated clients that do not adhere to mandatory admission control procedures. The reporting occurs through the system log and SNMP traps. Enter a time from 0 to 900 seconds. The default is 300 seconds.

STEP 3 For WAP561 devices, select the Radio interface to configure (Radio 1 or Radio 2).

STEP 4 In the Basic Settings area, configure these settings:

NOTE Local regulations may prohibit the use of certain radio modes. Not all

modes are available in all countries. Also, for the dual-radio WAP561, Radio 1 supports either the 2.4 GHz (the default selection) or 5 GHz band, but Radio 2 supports the 5 GHz band only. The single radio on the WAP551 device supports either band.

• Radio—Turns on or off the radio interface. By default, the radio is off.

• MAC Address—The Media Access Control (MAC) address for the interface.

The MAC address is assigned by the manufacturer and cannot be changed.

• Mode—The IEEE 802.11 standard and frequency the radio uses. For each

radio, select one of the available modes:

- 802.11a—Only 802.11a clients can connect to the WAP device.

- 802.11b/g—802.11b and 802.11g clients can connect to the WAP device.

- 802.11a/n—802.11a clients and 802.11n clients operating in the 5-GHz

frequency can connect to the WAP device.

- 802.11b/g/n (default)—802.11b, 802.11g, and 802.11n clients operating in

the 2.4-GHz frequency can connect to the WAP device.

- 5 GHz 802.11n—Only 802.11n clients operating in the 5-GHz frequency

can connect to the WAP device.

- 2.4 GHz 802.11n—Only 802.11n clients operating in the 2.4-GHz

frequency can connect to the WAP device.

• Channel Bandwidth—The 802.11n specification allows a coexisting 20/

40 MHz channel in addition to the legacy 20 MHz channel available with other modes. The 20/40 MHz channel enables higher data rates but leaves fewer channels available for use by other 2.4 GHz and 5 GHz devices.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 59

Wireless

Radio

By default, when the radio mode includes 802.11n, the channel bandwidth is set to 20/40 MHz to enable both channel widths. Set the field to 20 MHz to restrict the use of the channel bandwidth to a 20 MHz channel.

• Primary Channel (802.11n modes with 20/40 MHz bandwidth only)—A

40 MHz channel can be considered to consist of two 20 MHz channels that are contiguous in the frequency domain. These two 20 MHz channels are often referred to as the Primary and Secondary channels. The Primary Channel is used for 802.11n clients that support only a 20 MHz channel bandwidth and for legacy clients.

Select one of these options:

- Upper—Sets the Primary Channel as the upper 20 MHz channel in the

40 MHz band.

- Lower—Sets the Primary Channel as the lower 20 MHz channel in the

40 MHz band. Lower is the default selection.

• Channel—The portion of the radio spectrum the radio uses for transmitting

and receiving.

The range of available channels is determined by the mode of the radio interface and the country code setting. If you select Auto for the channel setting, the WAP device scans available channels and selects a channel where the least amount of traffic is detected.

Each mode offers a number of channels, depending on how the spectrum is licensed by national and transnational authorities such as the Federal Communications Commission (FCC) or the International Telecommunication Union (ITU-R).

STEP 5 In the Advanced Settings area, configure these settings:

• Short Guard Interval Supported—This field is available only if the selected

radio mode includes 802.11n.

The guard interval is the dead time, in nanoseconds, between OFDM symbols. The guard interval prevents Inter-Symbol and Inter-Carrier Interference (ISI, ICI). The 802.11n mode allows for a reduction in this guard interval from the a and g definition of 800 nanoseconds to 400 nanoseconds. Reducing the guard interval can yield a 10 percent improvement in data throughput.

The client with which the WAP device is communicating must also support the short guard interval.

Select one of these options:

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 60

Wireless

Radio

- Ye s—The WAP device transmits data using a 400-nanosecond guard

Interval when communicating with clients that also support the short guard interval. Yes is the default selection.

- No—The WAP device transmits data using an 800-nanosecond guard

interval.

• Protection—The protection feature contains rules to guarantee that 802.11

transmissions do not cause interference with legacy stations or applications. By default, protection is enabled (Auto). With protection enabled, protection is invoked if legacy devices are within range of the WAP device.

You can disable protection (Off); however, legacy clients or WAP devices within range can be affected by 802.11n transmissions. Protection is also available when the mode is 802.11b/g. When protection is enabled in this mode, it protects 802.11b clients and WAP devices from 802.11g transmissions.

NOTE This setting does not affect the ability of the client to associate with

the WAP device.

• Beacon Interval—The interval between the transmission of beacon frames.

The WAP device transmits these at regular intervals to announce the existence of the wireless network. The default behavior is to send a beacon frame once every 100 milliseconds (or 10 per second).

Enter an integer from 20 to 2000 milliseconds. The default is 100 milliseconds.

• DTIM Period—The Delivery Traffic Information Map (DTIM) period. Enter an

integer from 1 to 255 beacons. The default is 2 beacons.

The DTIM message is an element included in some Beacon frames. It indicates which client stations, currently sleeping in low-power mode, have data buffered on the WAP device awaiting pickup.

The DTIM period that you specify indicates how often the clients served by this WAP device should check for buffered data still on the WAP device awaiting pickup.

The measurement is in beacons. For example, if you set this field to 1, clients check for buffered data on the WAP device at every beacon. If you set this field to 10, clients check on every 10th beacon.

• Fragmentation Threshold—The frame size threshold in bytes. The valid

integer must be even and in the range of 256 to 2346. The default is 2346.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 61

Wireless

Radio

The fragmentation threshold is a way of limiting the size of packets (frames) transmitted over the network. If a packet exceeds the fragmentation threshold you set, the fragmentation function is activated and the packet is sent as multiple 802.11 frames.

If the packet being transmitted is equal to or less than the threshold, fragmentation is not used. Setting the threshold to the largest value (2,346 bytes, which is the default) effectively disables fragmentation.

Fragmentation involves more overhead both because of the extra work of dividing up and reassembling of frames it requires, and because it increases message traffic on the network. However, fragmentation can help improve network performance and reliability if properly configured.

Sending smaller frames (by using lower fragmentation threshold) might help with some interference problems; for example, with microwave ovens.

By default, fragmentation is off. We recommend not using fragmentation unless you suspect radio interference. The additional headers applied to each fragment increase the overhead on the network and can greatly reduce throughput.

• RTS Threshold—The Request to Send (RTS) Threshold value. The valid

integer range must be from 0 to 2347. The default is 2347 octets.

The RTS threshold indicates the number of octets in an MPDU, below which an RTS/CTS handshake is not performed.

Changing the RTS threshold can help control traffic flow through the WAP device, especially one with a lot of clients. If you specify a low threshold value, RTS packets are sent more frequently, which consumes more bandwidth and reduces the throughput of the packet. However, sending more RTS packets can help the network recover from interference or collisions that might occur on a busy network, or on a network experiencing electromagnetic interference.

• Maximum Associated Clients—The maximum number of stations allowed

to access each radio of this WAP device at any one time. You can enter an integer between 0 and 200. The default is 200 stations.Therefore, the singleradio WAP551 device can support up to 200 clients, whereas the dual-radio WAP561 device can support up to 400 clients total.

• Transmit Power—A percentage value for the transmit power level for this

WAP devic e.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 62

Wireless

Radio

The default value of 100 percent can be more cost-efficient than a lower percentage because it gives the WAP device a maximum broadcast range and reduces the number of access points needed.

To increase the capacity of the network, place WAP devices closer together and reduce the value of the transmit power. This helps reduce overlap and interference among access points. A lower transmit power setting can also keep your network more secure because weaker wireless signals are less likely to propagate outside of the physical location of your network.

Some channel ranges and country code combinations have relatively low maximum transmit power. When attempting to set the transmit power to the lower ranges (for example, 25% or 12%), the expected drop in power may not occur, because certain power amplifiers have minimum transmit power requirements.

• Fixed Multicast Rate—The transmission rate in Mbps for broadcast and

multicast packets. This setting can be useful in an environment where wireless multicast video streaming occurs, provided the wireless clients are capable of handling the configured rate.

When Auto is selected, the WAP device chooses the best rate for the associated clients. The range of valid values is determined by the configured radio mode.

• Legacy Rate Sets—Rates are expressed in megabits per second.

Supported Rate Sets indicate rates that the WAP device supports. You can check multiple rates (check a box to select or deselect a rate). The WAP device automatically chooses the most efficient rate based on factors such as error rates and the distance of client stations from the WAP device.

Basic Rate Sets indicate rates that the WAP device advertises to the network for the purposes of setting up communication with other access points and client stations on the network. It is generally more efficient to have a WAP device broadcast a subset of its supported rate sets.

• MCS (Data Rate) Settings—The Modulation and Coding Scheme (MCS)

index values that the WAP device advertises. MCS can enhance throughput for 802.11n wireless clients.

Check the box below the MCS index number to enable it or uncheck it to disable the index. You cannot disable all indexes at the same time.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 63

Wireless

Radio

The WAP device supports MCS indexes 0 to 23. MSC index 23 allows for a maximum transmission rate of 450 Mbps. If no MCS index is selected, the radio operates at MCS index 0, which allows for a maximum transmission rate of 15 Mbps.

The MCS settings can be configured only if the radio mode includes 802.11n support.

• Broadcast/Multicast Rate Limiting—Multicast and broadcast rate limiting

can improve overall network performance by limiting the number of packets transmitted across the network.

By default, the Multicast/Broadcast Rate Limiting option is disabled. Until you enable Multicast/Broadcast Rate Limiting, these fields are disabled:

- Rate Limit—The rate limit for multicast and broadcast traffic. The limit

should be greater than 1, but less than 50 packets per second. Any traffic that falls below this rate limit will always conform and be transmitted to the appropriate destination. The default and maximum rate limit setting is 50 packets per second.

- Rate Limit Burst—An amount of traffic, measured in bytes, which is

allowed to pass as a temporary burst even if it is above the defined maximum rate. The default and maximum rate limit burst setting is 75 packets per second.

• TSPEC Mode—Regulates the overall TSPEC mode on the WAP device. By

default, TSPEC mode is off. The options are:

- On—The WAP device handles TSPEC requests according to the TSPEC

settings you configure on the Radio page. Use this setting if the WAP device handles traffic from QoS-capable devices, such as a Wi-Fi CERTIFIED phone.

- Off—The WAP device ignores TSPEC requests from client stations. Use

this setting if you do not want to use TSPEC to give QoS-capable devices priority for time-sensitive traffic.

• TSPEC Voice ACM Mode—Regulates mandatory admission control (ACM)

for the voice access category. By default, TSPEC Voice ACM mode is off. The options are:

- On—A station is required to send a TSPEC request for bandwidth to the

WAP device before sending or receiving a voice traffic stream. The WAP device responds with the result of the request, which includes the allotted medium time if the TSPEC was admitted.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 64

Wireless

Radio

- Off—A station can send and receive voice priority traffic without

requiring an admitted TSPEC; the WAP device ignores voice TSPEC requests from client stations.

• TSPEC Voice ACM Limit—The upper limit on the amount of traffic the WAP

device attempts to transmit on the wireless medium using a voice AC to gain access. The default limit is 20 percent of total traffic.

• TSPEC Video ACM Mode —Regulates mandatory admission control for the

video access category. By default, TSPEC Video ACM mode is off. The options are:

- On — A station is required to send a TSPEC request for bandwidth to the

WAP device before sending or receiving a video traffic stream. The WAP device responds with the result of the request, which includes the allotted medium time if the TSPEC was admitted.

- Off — A station can send and receive video priority traffic without

requiring an admitted TSPEC; the WAP device ignores video TSPEC requests from client stations.

• TSPEC Video ACM Limit—The upper limit on the amount of traffic that the

WAP device attempts to transmit on the wireless medium using a video AC to gain access. The default limit is 15 percent of total traffic.

• TSPEC AP Inactivity Timeout—The amount of time for a WAP device to

detect a downlink traffic specification as idle before deleting it. The valid integer range is from 0 to 120 seconds and the default is 30 seconds.

• TSPEC Station Inactivity Timeout—The amount of time for a WAP device

to detect an uplink traffic specification as idle before deleting it. The valid integer range is from 0 to 120 seconds and the default is 30 seconds.

• TSPEC Legacy WMM Queue Map Mode—Enables or disables the

intermixing of legacy traffic on queues operating as ACM. By default, this mode is off.

STEP 6 Click Save. The changes are saved to the Startup Configuration.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 65

Wireless

Rogue AP Detection

CAUTION After new settings are saved, the corresponding processes may be stopped and

restarted. When this happens, the WAP device may lose connectivity. We recommend that you change WAP device settings when a loss of connectivity will least affect your wireless clients.

Rogue AP Detection

A Rogue AP is an access point that has been installed on a secure network without explicit authorization from a system administrator. Rogue access points pose a security threat because anyone with access to the premises can ignorantly or maliciously install an inexpensive wireless WAP device that can potentially allow unauthorized parties to access the network.

The WAP device performs an RF scan on all channels on each radio to detect all APs in the vicinity of the network. If rogue APs are detected, they are shown on the Rogue AP Detection page. If an AP listed as a rogue is legitimate, you can add it to the Known AP List.

NOTE The Detected Rogue AP List and Trusted AP List provide information that you can

use to take further action. The AP does not have any control over rogue APs on the lists and cannot apply any security policies to APs detected through the RF scan.

When AP detection is enabled, the radio periodically switches from its operating channel to scan other channels within the same band.

Rogue AP detection can be enabled and disabled. To enable the radio to collect information about rogue APs, click Enable next to AP Detection for Radio 1 (or Radio 2 for WAP561 devices) and then click Save.

Information about detected and trusted rogue access points appears. You can click Refresh to refresh the screen and show the most current information:

• Action—If the AP is in the Detected Rogue AP List, you can click Trust to

move the AP to the Trusted AP List.

If the AP is in the Trusted AP list, you can click Untrust to move the AP to the Detected Rogue AP List.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 66

Wireless

Rogue AP Detection

NOTE The Detected Rogue AP List and Trusted AP List provide information.

The WAP device does not have any control over the APs on the list and cannot apply any security policies to APs detected through the RF scan.

• MAC Address—The MAC address of the rogue AP.

• Beacon Interval—The beacon interval used by the rogue AP.

Beacon frames are transmitted by an AP at regular intervals to announce the existence of the wireless network. The default behavior is to send a beacon frame once every 100 milliseconds (or 10 per second).

NOTE The Beacon Interval is set on the Radio page.

• Type—The t ype of de vice :

- AP indicates the rogue device is an AP that supports the IEEE 802.11

Wireless Networking Framework in Infrastructure Mode.

- Ad hoc indicates a rogue station running in Ad hoc mode. Stations set to

Ad hoc mode communicate with each other directly, without the use of a traditional AP. Ad hoc mode is an IEEE 802.11 Wireless Networking Framework also referred to as peer-to-peer mode or an Independent Basic Service Set (IBSS).

• SSID—The Service Set Identifier (SSID) for the WAP device.

The SSID is an alphanumeric string of up to 32 characters that uniquely identifies a wireless local area network. It is also referred to as the Network Name.

• Privacy—Indicates whether there is any security on the rogue device:

- Off indicates that the Security mode on the rogue device is set to None

(no security).

- On indicates that the rogue device has some security in place.

NOTE You can use the Networks page to configure security on the AP.

• WPA—Whether WPA security is on or off for the rogue AP.

• Band—The IEEE 802.11 mode being used on the rogue AP. (For example,

IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.)

The number shown indicates the mode:

- 2.4 indicates IEEE 802.11b, 802.11g, or 802.11n mode (or a combination

of the modes).

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 67

Wireless

Rogue AP Detection

- 5 indicates IEEE 802.11a or 802.11n mode (or both modes).

• Channel—The channel on which the rogue AP is currently broadcasting.

The channel defines the portion of the radio spectrum that the radio uses for transmitting and receiving.

NOTE You can use the Radio page to set the channel.

• Rate—The rate in megabits per second at which the rogue AP is currently

transmitting.

The current rate is always one of the rates shown in Supported Rates.

• Signal—The strength of the radio signal emitting from the rogue AP. If you

hover the mouse pointer over the bars, a number representing the strength in decibels (dB) appears.

• Beacons—The total number of beacons received from the rogue AP since it

was first discovered.

• Last Beacon—The date and time of the last beacon received from the

rogue AP.

• Rates—Supported and basic (advertised) rate sets for the rogue AP. Rates

are shown in megabits per second (Mbps).

All Supported Rates are listed, with Basic Rates shown in bold. Rate sets are configured on the Radio page.

To create a Trusted AP List and save it to a file:

STEP 1 In the Detected Rogue AP List, click Trust for APs that are known to you. The

Trusted APs move to the Trusted AP List.

STEP 2 In the Download/Backup Trusted AP List area, select Backup (AP to PC).

STEP 3 Click Save.

The list contains the MAC addresses of all APs that have been added to the Known AP List. By default, the filename is Rogue2.cfg. You can use a text editor or web browser to open the file and view its contents.

You can import a list of known APs from a saved list. The list might be acquired from another AP or created from a text file. If the MAC address of an AP appears in the Trusted AP List, it is not detected as a rogue.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 68

Wireless

Networks

To import an AP list from a file, use these steps:

STEP 1 In the Download/Backup Trusted AP List area, select Download (PC to AP).

STEP 2 Click Browse and choose the file to import.

The file that you import must be a plain-text file with a .txt or .cfg extension. Entries in the file are MAC addresses in hexadecimal format with each octet separated by colons, for example 00:11:22:33:44:55. You must separate entries with a single space. For the AP to accept the file, it must contain only MAC addresses.

STEP 3 Choose whether to replace the existing Trusted AP List or add the entries in the

imported file to the Trusted AP List.

a. Select Replace to import the list and replace the contents of the Known AP

List.

b. Select Merge to import the list and add the APs in the imported file to the APs

currently shown in the Known AP List.

Networks

STEP 4 Click Save.

When the import is complete, the screen refreshes and the MAC addresses of the APs in the imported file appear in the Known AP List.

Virtual Access Points (VAPs) segment the wireless LAN into multiple broadcast domains that are the wireless equivalent of Ethernet VLANs. VAPs simulate multiple access points in one physical WAP device. The WAP device supports up to 16 VAPs.

Each VAP can be independently enabled or disabled, with the exception of VAP0. VAP0 is the physical radio interface and remains enabled as long as the radio is enabled. To disable operation of VAP0, the radio itself must be disabled.

Each VAP is identified by a user-configured Service Set Identifier (SSID). Multiple VAPs cannot have the same SSID name. SSID broadcasts can be enabled or disabled independently on each VAP. SSID broadcast is enabled by default.

The default SSID for VAP0 is ciscosb. Every additional VAP created has a blank SSID name. The SSIDs for all VAPs can be configured to other values.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 69

Wireless

Networks

The SSID can be any alphanumeric, case-sensitive entry from 2 to 32 characters. The printable characters plus the space (ASCII 0x20) are allowed, but these six characters are not:

?, ", $, [, \, ], and +.

The allowable characters are:

ASCII 0x20, 0x21, 0x23, 0x25 through 0x2A, 0x2C through 0x3E, 0x40 through 0x5A, 0x5E through 0x7E.

In addition, these three characters cannot be the first character:

!, #, and ; (ASCII 0x21, 0x23, and 0x3B, respectively).

Trailing and leading spaces (ASCII 0x20) are not permitted.

NOTE This means that spaces are allowed within the SSID, but not as the first or last

character, and the period "." (ASCII 0x2E) is also allowed.

Each VAP is associated with a VLAN, which is identified by a VLAN ID (VID). A VID can be any value from 1 to 4094, inclusive. The WAP551 and WAP561 devices support 17 active VLANs (16 for WLAN plus one management VLAN).

By default, the VID assigned to the configuration utility for the WAP device is 1, which is also the default untagged VID. If the management VID is the same as the VID assigned to a VAP, then the WLAN clients associated with this specific VAP can administer the WAP device. If needed, an access control list (ACL) can be created to disable administration from WLAN clients.

To configure VAPs:

STEP 1 Select Wireless > Networks in the navigation pane.

STEP 2 For WAP561 devices, select the Radio interface on which you want to configure

VAP s (Radio 1 or Radio 2).

STEP 3 Select the Enabled check box for the VAP you want to configure.

—Or—

If VAP0 is the only VAP configured on the system, and you want to add a VAP, click

Add. Then, select the VAP and click Edit.

STEP 4 Configure the parameters:

• VLAN ID—The VID of the VLAN to associate with the VAP.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 70

Wireless

Networks

CAUTION Be sure to enter a VLAN ID that is properly configured on the network. Network

problems can result if the VAP associates wireless clients with an improperly configured VLAN. When a wireless client connects to the WAP device by using this VAP, the WAP device tags all traffic from the wireless client with the VLAN ID you enter in this field, unless you enter the port VLAN ID or use a RADIUS server to assign a wireless client to a VLAN. The range for the VLAN ID is from 1 to 4094.

NOTE If you change the VLAN ID to a different ID than the current

management VLAN ID, WLAN clients associated with this specific VAP cannot administer the device. Verify the configuration of the untagged and management VLAN IDs on the LAN page. For more information, see VLAN

and IPv4 Address Settings.

• SSID Name—A name for the wireless network. The SSID is an alphanumeric

string of up to 32 characters. Choose a unique SSID for each VAP.

NOTE If you are connected as a wireless client to the same WAP device that

you are administering, resetting the SSID will cause you to lose connectivity to the WAP device. You need to reconnect to the new SSID after you save this new setting.

• Broadcast SSID—Enables and disables the broadcast of the SSID.

Specify whether to allow the WAP device to broadcast the SSID in its beacon frames. The Broadcast SSID parameter is enabled by default. When the VAP does not broadcast its SSID, the network name is not shown in the list of available networks on a client station. Instead, you must enter the exact network name manually into the wireless connection utility on the client so that it can connect.

Disabling the broadcast SSID is sufficient to prevent clients from accidentally connecting to your network, but it does not prevent even the simplest of attempts by a hacker to connect or monitor unencrypted traffic. Suppressing the SSID broadcast offers a very minimal level of protection on an otherwise exposed network (such as a guest network) where the priority is to make it easy for clients to get a connection and where no sensitive information is available.

• Security—The type of authentication required for access to the VAP:

- None

- Static WEP

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 71

Wireless

Networks

- Dynamic WEP

- WPA Personal

- WPA Enterprise

If you select a security mode other than None, additional fields appear.

NOTE We recommend using WPA Personal or WPA Enterprise as the

authentication type as it provides stronger security protection. Use Static WEP or Dynamic WEP only for legacy wireless computers or devices that do not support WPA Personal/Enterprise. If you need to set security as Static WEP or Dynamic WEP, configure Radio as 802.11a or 802.11b/g mode (see

Radio). The 802.11n mode restricts the use of Static or Dynamic WEP as the

security mode.

• MAC Filtering—Specifies whether the stations that can access this VAP are

restricted to a configured global list of MAC addresses. You can select one of these types of MAC filtering:

- Disabled—Do not use MAC filtering.

- Local—Use the MAC Authentication list that you configure on the MAC

Filtering page.

- RADIUS—Use the MAC Authentication list on an external R ADIUS server.

• Channel Isolation—Enables and disables station isolation.

- When disabled, wireless clients can communicate with one another

normally by sending traffic through the WAP device.

- When enabled, the WAP device blocks communication between

wireless clients on the same VAP. The WAP device still allows data traffic between its wireless clients and wired devices on the network, across a WDS link, and with other wireless clients associated with a different VAP, but not among wireless clients.

STEP 5 Click Save. The changes are saved to the Startup Configuration.

CAUTION After new settings are saved, the corresponding processes may be stopped and

restarted. When this happens, the WAP device may lose connectivity. We recommend that you change WAP device settings when a loss of connectivity will least affect your wireless clients.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 72

Wireless

Networks

NOTE To delete a VAP, select the VAP and click Delete. To save your deletion permanently,

click Save when complete.

These sections describe the security settings that you configure, depending on your selection in the Security list on the Networks page.

If you select None as your security mode, no additional security settings are configurable on the WAP device. This mode means that any data transferred to and from the WAP device is not encrypted. This security mode can be useful during initial network configuration or for problem solving, but it is not recommended for regular use on the internal network because it is not secure.

Wired Equivalent Privacy (WEP) is a data encryption protocol for 802.11 wireless networks. All wireless stations and access points on the network are configured with a static 64-bit (40-bit secret key + 24-bit initialization vector (IV)) or 128-bit (104-bit secret key + 24-bit IV) Shared Key for data encryption.

Static WEP is not the most secure mode available, but it offers more protection than setting the security mode to None (Plain-text), as it does prevent an outsider from easily sniffing out unencrypted wireless traffic.

WEP encrypts data moving across the wireless network based on a static key. (The encryption algorithm is a stream cipher called RC4.)

These parameters configure Static WEP:

• Transfer Key Index—A key index list. Key indexes 1 through 4 are available.

The default is1.

The Transfer Key Index indicates which WEP key the WAP device uses to encrypt the data it transmits.

• Key Length—The length of the key. Select one:

- 64 bits

- 128 bits

• Key Type—The key type. Select one:

- ASCII

- Hex

• WEP Keys—You can specify up to four WEP keys. In each text box, enter a

string of characters for each key. The keys you enter depend on the key type selected:

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 73

Wireless

Networks

- ASCII—Includes uppercase and lowercase alphabetic letters, the

numeric digits, and special symbols such as @ and #.

- Hex—Includes digits 0 to 9 and the letters A to F.

Use the same number of characters for each key as specified in the Characters Required field. These are the RC4 WEP keys shared with the stations using the WAP device.

Each client station must be configured to use one of these same WEP keys in the same slot as specified on the WAP device.

• Characters Required—The number of characters you enter into the WEP

Key fields is determined by the key length and key type you select. For example, if you use 128-bit ASCII keys, you must enter 26 characters in the WEP key. The number of characters required updates automatically based on how you set the key length and key type.

• 802.1X Authentication—The authentication algorithm defines the method

used to determine whether a client station is allowed to associate with WAP device when static WEP is the security mode.

Specify the authentication algorithm you want to use by choosing one of these options:

- Open System authentication allows any client station to associate with

the WAP device whether that client station has the correct WEP key or not. This algorithm is also used in plaintext, IEEE 802.1X, and WPA modes. When the authentication algorithm is set to Open System, any client can associate with the WAP device.

NOTE Just because a client station is allowed to associate does not

ensure it can exchange traffic with an WAP device. A station must have the correct WEP key to be able to successfully access and decrypt data from the WAP device, and to transmit readable data to the WAP device.

- Shared Key authentication requires the client station to have the correct

WEP key in order to associate with the WAP device. When the authentication algorithm is set to Shared Key, a station with an incorrect WEP key cannot associate with the WAP device.

- Both Open System and Shared Key. When you select both

authentication algorithms, client stations configured to use WEP in shared key mode must have a valid WEP key in order to associate with the WAP device. Also, client stations configured to use WEP as an open system (shared key mode not enabled) can associate with the WAP device even if they do not have the correct WEP key.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 74

Wireless

Networks

If you use Static WEP, these rules apply:

• All client stations must have the Wireless LAN (WLAN) security set to WEP,

and all clients must have one of the WEP keys specified on the WAP device in order to decode AP-to-station data transmissions.

• The WAP device must have all keys used by clients for station-to-AP

transmit so that it can decode the station transmissions.

• The same key must occupy the same slot on all nodes (AP and clients). For

example, if the WAP device defines abc123 key as WEP key 3, then the client stations must define that same string as WEP key 3.

• Client stations can use different keys to transmit data to the access point.

(Or they can all use the same key, but using the same key is less secure because it means one station can decrypt the data being sent by another.)

• On some wireless client software, you can configure multiple WEP keys and

define a client station transfer key index, and then set the stations to encrypt the data they transmit using different keys. This ensures that neighboring access points cannot decode other access point transmissions.

• You cannot mix 64-bit and 128-bit WEP keys between the access point and

its client stations.

Dynamic WEP refers to the combination of 802.1x technology and the Extensible Authentication Protocol (EAP). With Dynamic WEP security, WEP keys are changed dynamically.

EAP messages are sent over an IEEE 802.11 wireless network using a protocol called EAP Encapsulation Over LANs (EAPOL). IEEE 802.1X provides dynamically generated keys that are periodically refreshed. An RC4 stream cipher is used to encrypt the frame body and cyclic redundancy checking (CRC) of each 802.11 frame.

This mode requires the use of an external RADIUS server to authenticate users. The WAP device requires a RADIUS server that supports EAP, such as the Microsoft Internet Authentication Server. To work with Microsoft Windows clients, the authentication server must support Protected EAP (PEAP) and MSCHAP V2.

You can use any of a variety of authentication methods that the IEEE 802.1X mode supports, including certificates, Kerberos, and public key authentication. You must configure the client stations to use the same authentication method the WAP device uses.

These parameters configure Dynamic WEP:

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 75

Wireless

Networks

• Use Global RADIUS Server Settings—By default, each VAP uses the

global RADIUS settings that you define for the WAP device (see RADIUS

Server). However, you can configure each VAP to use a different set of

RADIUS servers.

To use the global RADIUS server settings, ensure that the check box is selected.

To use a separate RADIUS server for the VAP, uncheck the check box and enter the RADIUS server IP address and key in these fields:

• Server IP Address Type—The IP version that the RADIUS server uses.

You can toggle between the address types to configure IPv4 and IPv6 global RADIUS address settings, but the WAP device contacts only the RADIUS server or servers for the address type you select in this field.

• Server IP Address 1 or Server IPv6 Address 1—The address for the

primary RADIUS server for this VAP.

When the first wireless client tries to authenticate with the WAP device, the WAP device sends an authentication request to the primary server. If the primary server responds to the authentication request, the WAP device continues to use this RADIUS server as the primary server, and authentication requests are sent to the address you specify.

The IPv4 address should be in a form similar to xxx.xxx.xxx.xxx (192.0.2.10). The IPv6 address should be in a form similar to xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx (2001:DB8::CAD5:7D91).

• Server IP Address 2 to 4 or Server IPv6 Address 2 to 4—Up to three IPv4

or IPv6 backup RADIUS server addresses.

If authentication fails with the primary server, each configured backup server is tried in sequence.

• Key—The shared secret key that the WAP device uses to authenticate to

the primary RADIUS server.

You can use up to 63 standard alphanumeric and special characters. The key is case sensitive and must match the key configured on the RADIUS server. The text you enter is shown as asterisks.

• Key 2 to Key 4—The RADIUS key associated with the configured backup

RADIUS servers. The server at Server IP (IPv6) Address 2 uses Key 2, the server at Server IP (IPv6) Address 3 uses Key 3, and so on.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 76

Wireless

Networks

• Enable RADIUS Accounting—Enables tracking and measuring of the

resources a particular user has consumed, such as system time, amount of data transmitted and received, and so on.

If you enable RADIUS accounting, it is enabled for the primary RADIUS server and all backup servers.

• Active Server—Enables administratively selecting the active RADIUS

server, rather than having the WAP device attempt to contact each configured server in sequence and choose the first server that is up.

• Broadcast Key Refresh Rate—The interval at which the broadcast (group)

key is refreshed for clients associated with this VAP.

The default is 300. The valid range is from 0 to 86400 seconds. A value of 0 indicates that the broadcast key is not refreshed.

• Session Key Refresh Rate—The interval at which the WAP device

refreshes session (unicast) keys for each client associated with the VAP.

The valid range is from 0 to 86400 seconds. A value of 0 indicates that the broadcast key is not refreshed.

WPA Personal is a Wi-Fi Alliance IEEE 802.11i standard, which includes AES-CCMP and TKIP encryption. The Personal version of WPA uses a pre-shared key (PSK) instead of using IEEE 802.1X and EAP as is used in the Enterprise WPA security mode. The PSK is used for an initial check of credentials only. WPA Personal is also referred to as WPA-PSK.

This security mode is backwards-compatible for wireless clients that support the original WPA.

These parameters configure WPA Personal:

• WPA Versions—The types of client stations you want to support:

- WPA—The network has client stations that support the original WPA

and none that support the newer WPA2.

- WPA2—All client stations on the network support WPA2. This protocol

version provides the best security per the IEEE 802.11i standard.

If the network has a mix of clients, some of which support WPA2 and others which support only the original WPA, select both of the check boxes. This lets both WPA and WPA2 client stations associate and authenticate, but uses the more robust WPA2 for clients who support it. This WPA configuration allows more interoperability in place of some security.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 77

Wireless

Networks

• Cipher Suites—The cipher suite you want to use:

- TKIP

- CCMP (AES)

You can select either or both. Both TKIP and AES clients can associate with the WAP device. WPA clients must have one of these keys to be able to associate with the WAP device:

- A valid TKIP key

- A valid AES-CCMP key

Clients not configured to use WPA Personal are not able to associate with the WAP device.

• Key—The shared secret key for WPA Personal security. Enter a string of at

least 8 characters to a maximum of 63 characters. Acceptable characters include uppercase and lowercase alphabetic letters, the numeric digits, and special symbols such as @ and #.

• Key Strength Meter—The WAP device checks the key against complexity

criteria such as how many different types of characters (uppercase and lowercase alphabetic letters, numbers, and special characters) are used and how long the string is. If the WPA-PSK complexity check feature is enabled, the key is not accepted unless it meets the minimum criteria. See

WPA-PSK Complexity for information on configuring the complexity check.

• Broadcast Key Refresh Rate—The interval at which the broadcast (group)

key is refreshed for clients associated with this VAP. The default is 300 seconds and the valid range is from 0 to 86400 seconds. A value of 0 indicates that the broadcast key is not refreshed.

WPA Enterprise with RADIUS is an implementation of the Wi-Fi Alliance IEEE

802.11i standard, which includes CCMP (AES), and TKIP encryption. The Enterprise mode requires the use of a RADIUS server to authenticate users.

This security mode is backwards-compatible with wireless clients that support the original WPA.

These parameters configure WPA Enterprise:

• WPA Versions—The types of client stations to be supported:

- WPA—If all client stations on the network support the original WPA but

none support the newer WPA2, and then select WPA.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 78

Wireless

Networks

- WPA2—If all client stations on the network support WPA2, we suggest

using WPA2 which provides the best security per the IEEE 802.11i standard.

- WPA and WPA2—If you have a mix of clients, some of which support

WPA2 and others which support only the original WPA, select both WPA and WPA2. This setting lets both WPA and WPA2 client stations associate and authenticate, but uses the more robust WPA2 for clients who support it. This WPA configuration allows more interoperability, in place of some security.

• Enable pre-authentication—If for WPA Versions you select only WPA2 or

both WPA and WPA2, you can enable pre-authentication for WPA2 clients.

Click Enable pre-authentication if you want WPA2 wireless clients to send pre-authentication packets. The pre-authentication information is relayed from the WAP device that the client is currently using to the target WAP device. Enabling this feature can help speed up authentication for roaming clients who connect to multiple APs.

This option does not apply if you selected WPA for WPA Versions because the original WPA does not support this feature.

• Cipher Suites—The cipher suite you want to use:

- TKIP

- CCMP (AES)

- TKIP and CCMP (AES)

By default both TKIP and CCMP are selected. When both TKIP and CCMP are selected, client stations configured to use WPA with RADIUS must have one of these addresses and keys:

- A valid TKIP RADIUS IP address and RADIUS Key

- A valid CCMP (AES) IP address and RADIUS Key

• Use Global RADIUS Server Settings—By default, each VAP uses the

global RADIUS settings that you define for the WAP device (see RADIUS

Server). However, you can configure each VAP to use a different set of

RADIUS servers.

To use the global RADIUS server settings, make sure the check box is selected.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 79

Wireless

Networks

To use a separate RADIUS server for the VAP, uncheck the box and enter the RADIUS server IP address and key in these fields:

• Server IP Address Type—The IP version that the RADIUS server uses.

• Server IP Address 1 or Server IPv6 Address 1—The address for the

primary RADIUS server for this VAP.

If IPv4 is selected as the Server IP Address Type, enter the IP address of the RADIUS server that all VAPs use by default, for example, 192.168.10.23. If IPv6 is selected, enter the IPv6 address of the primary global RADIUS server, for example, 2001:DB8:1234::abcd.

• Server IP Address 2 to 4 or Server IPv6 Address 2 to 4—Up to three IPv4

and/or IPv6 addresses to use as the backup RADIUS servers for this VAP.

If authentication fails with the primary server, each configured backup server is tried in sequence.

• Key 1—The shared secret key for the global RADIUS server. You can use up

to 63 standard alphanumeric and special characters. The key is case sensitive, and you must configure the same key on the WAP device and on your RADIUS server. The text you enter is shown as asterisks to prevent others from seeing the RADIUS key as you type.

• Key 2 to Key 4—The RADIUS key associated with the configured backup

RADIUS servers. The server at Server IP (IPv6) Address 2 uses Key 2, the server at Server IP (IPv6) Address 3 uses Key 3, and so on.

• Enable RADIUS Accounting—Tracks and measures the resources a

particular user has consumed such as system time, amount of data transmitted and received, and so on.

If you enable RADIUS accounting, it is enabled for the primary RADIUS server and all backup servers.

• Active Server—Enables the administrative selection of the active RADIUS

server, rather than having the WAP device attempt to contact each configured server in sequence and choose the first server that is up.

Broadcast Key Refresh Rate—The interval at which the broadcast (group) key is refreshed for clients associated with this VAP.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 80

Wireless

Scheduler

The default is 300 seconds. The valid range is from 0 to 86400 seconds. A value of 0 indicates that the broadcast key is not refreshed.

• Session Key Refresh Rate—The interval at which the WAP device

refreshes session (unicast) keys for each client associated with the VAP.

The valid range is from 0 to 86400 seconds. A value of 0 indicates that the session key is not refreshed.

The Radio and VAP Scheduler allows you to configure a rule with a specific time interval for VAPs or radios to be operational, which automates the enabling or disabling of the VAPs and radio.

One way you can use this feature is to schedule the radio to operate only during the office working hours in order to achieve security and reduce power consumption. You can also use the Scheduler to allow access to VAPs for wireless clients only during specific times of day.

The WAP device supports up to 16 profiles. Only valid rules are added to the profile. Up to 16 rules are grouped together to form a scheduling profile. Periodic time entries belonging to the same profile cannot overlap.

You can create up to 16 scheduler profile names. By default, no profiles are created.

To view Scheduler status and add a Scheduler profile:

STEP 1 Select Wireless > Scheduler in the navigation pane.

STEP 2 Ensure that the Administrative Mode is enabled. By default it is disabled.

The Scheduler Operational Status area indicates the current operation status of the Scheduler:

• Status—The operational status of the Scheduler. The range is Up or Down.

The default is Down.

• Reason—The reason for the scheduler operational status. Possible values

are:

- IsActive—The scheduler is administratively enabled.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 81

Wireless

Scheduler

- Administrative Mode is disabled—Operational status is down because

global configuration is disabled.

STEP 3 To add a profile, enter a profile name in the Scheduler Profile Configuration text

box and click Add. The profile name can be up to 32 alphanumeric characters.

You can configure up to 16 rules for a profile. Each rule specifies the start time, end time and day (or days) of the week the radio or VAP can be operational. The rules are periodic in nature and are repeated every week. A valid rule must contain all of the parameters (days of the week, hour, and minute) for the start time and the end time. Rules cannot conflict; for example, you can configure one rule to start on each weekday and another to start on each weekend day, but you cannot configure one rule to begin daily and another rule to begin on weekends.

To configure a rule for a profile:

STEP 1 Select the profile from the Select a Profile Name list.

STEP 2 Click Add Rule.

The new rule shows in the rule table.

STEP 3 Check the box next to the Profile Name and click Edit.

STEP 4 From the Day of the Week menu, select the recurring schedule for the rule. You

can configure the rule to occur daily, each weekday, each weekend day (Saturday and Sunday), or any single day of the week.

STEP 5 Set the start and end times:

• Start Time—The time when the radio or VAP is operationally enabled. The

time is in HH:MM 24-hour format. The range is <00-23>:<00-59>. The default is 00:00.

• End Time—The time when the radio or VAP is operationally disabled. The

time is in HH:MM 24-hour format. The range is <00-23>:<00-59>. The default is 00:00.

STEP 6 Click Save. The changes are saved to the Startup Configuration.

NOTE A Scheduler profile must be associated with a radio interface or a VAP interface to

be in effect. See the Scheduler Association page.

NOTE To delete a rule, select the profile from the Profile Name column and click Delete.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 82

Wireless

Scheduler Association

The Scheduler profiles need to be associated with the WLAN interface or a VAP interface to be effective. By default, there are no Scheduler profiles created, and no profile is associated with any radio or VAP.

Only one Scheduler profile can be associated with the WLAN interface or each VAP. A single profile can be associated with multiple VAPs. If the Scheduler profile associated with a VAP or the WLAN interface is deleted, then the association is removed.

To associate a Scheduler profile with the WLAN interface or a VAP:

STEP 1 Select Wireless > Scheduler Association in the navigation pane. For WAP561

devices, select the Radio interface on which you want to associate a scheduler profile (Radio 1 or Radio 2).

STEP 2 For the WLAN interface or a VAP, select the profile from the Profile Name list.

The Interface Operational Status column shows whether the interface is currently enabled or disabled.

STEP 3 Click Save. The changes are saved to the Startup Configuration.

Bandwidth Utilization

Use the Bandwidth Utilization page to configure how much of the radio bandwidth can be used before the WAP device stops allowing new client associations. This feature is enabled by default.

To change bandwidth utilization settings:

STEP 1 Select Wireless > Bandwidth Utilization in the navigation pane.

STEP 2 Click Enable to enable Bandwidth Utilization, or uncheck Enable to disable

bandwidth utilization.

STEP 3 If bandwidth utilization is enabled, in the Maximum Utilization Threshold box,

enter the percentage of network bandwidth utilization allowed on the radio before the WAP device stops accepting new client associations.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 83

Wireless

MAC Filtering

STEP 4 Click Save. The changes are saved to the Startup Configuration.

NOTE After new settings are saved, the corresponding processes may be stopped and

MAC Filtering

The valid integer range is from 0 to 100 percent. The default is 70 percent. When set to 0, all new associations are allowed regardless of the utilization rate.

restarted. When this happens, the WAP device may lose connectivity. We recommend that you change WAP device settings when a loss of connectivity will least affect your wireless clients.

Media Access Control (MAC) filtering can be used to exclude or allow only listed client stations to authenticate with the access point. MAC authentication is enabled and disabled per VAP on the Networks page. Depending on how the VAP is configured, the WAP device may refer to a MAC filter list stored on an external RADlUS server, or may refer a MAC filter list stored locally on the WAP device.

The WAP device supports one local MAC filter list only; that is, the same list applies to all VAPs that are enabled to use the local list. The filter can be configured to grant access only to the MAC addresses on the list, or to deny access only to addresses on the list.

Up to 512 MAC addresses can be added to the filter list.

To configure MAC filtering:

STEP 1 Select Wireless > MAC Filtering in the navigation pane.

STEP 2 Select how the WAP device uses the filter list:

• Allow only stations in the list—Any station that is not in the Stations List is

denied access to the network through the WAP device.

• Block all stations in list—Only the stations that appear in the list are denied

access to the network through the WAP device. All other stations are permitted access.

NOTE The filter setting also applies to the MAC filtering list stored on the

RADIUS server, if one exists.

STEP 3 In the MAC Address field, enter the MAC address to allow or block and click Add.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 84

Wireless

WDS Bridge

The MAC address appears in the Stations List.

STEP 4 Continue entering MAC addresses until the list is complete, and then click Save.

The changes are saved to the Startup Configuration.

NOTE To remove a MAC address from the Stations List, select it and then click Remove.

NOTE After new settings are saved, the corresponding processes may be stopped and

restarted. When this happens, the WAP device may lose connectivity. We recommend that you change WAP device settings when a loss of connectivity will least affect your wireless clients.

If one or more VAPs are configured to use a MAC filter stored on a RADIUS authentication server, you must configure the station list on the RADIUS server. The format for the list is described in this table:

WDS Bridge

RADIUS Server Attribute

User-Name (1) MAC address of the client station. Valid Ethernet MAC

User-Password (2) A fixed global password used to

The Wireless Distribution System (WDS) allows you to connect multiple WAP551 and WAP561 devices. With WDS, access points communicate with one another without wires. This capability is critical in providing a seamless experience for roaming clients and for managing multiple wireless networks. It can also simplify the network infrastructure by reducing the amount of cabling required. You can configure the WAP device in point-to-point or point-to-multipoint bridge mode based on the number of links to connect.

In the point-to-point mode, the WAP device accepts client associations and communicates with wireless clients and other repeaters. The WAP device forwards all traffic meant for the other network over the tunnel that is established between the access points. The bridge does not add to the hop count. It functions as a simple OSI Layer 2 network device.

Description Value

address.

NOPASSWORD

look up a client MAC entry.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 85

Wireless

WDS Bridge

In the point-to-multipoint bridge mode, one WAP device acts as the common link between multiple access points. In this mode, the central WAP device accepts client associations and communicates with the clients and other repeaters. All other access points associate only with the central WAP device that forwards the packets to the appropriate wireless bridge for routing purposes.

The WAP device can also act as a repeater. In this mode, the WAP device serves as a connection between two WAP devices that might be too far apart to be within cell range. When acting as a repeater, the WAP device does not have a wired connection to the LAN and repeats signals by using the wireless connection. No special configuration is required for the WAP device to function as a repeater, and there are no repeater mode settings. Wireless clients can still connect to an WAP device that is operating as a repeater.

Before you configure WDS on the WAP device, note these guidelines:

• WDS only works with Cisco WAP551 and Cisco WAP561 devices.

• All Cisco WAP devices participating in a WDS link must have the following

identical settings:

- Radio

- IEEE 802.11 Mode

- Channel Bandwidth

- Channel (Auto is not recommended)

NOTE When operating bridging in the 802.11n 2.4 GHz band, set the Channel

Bandwidth to 20 MHz, rather than the default 20/40 MHz. In the 2.4 GHz 20/40 MHz band, the operating bandwidth can change from 40 MHz to 20 MHz if any 20 MHz WAP devices are detected in the area. The mismatched channel bandwidth can cause the link to disconnect.

See Radio (Basic Settings) for information on configuring these settings.

• When using WDS, be sure to configure WDS on both WAP devices

participating in the WDS link.

• You can have only one WDS link between any pair of WAP devices. That is,

a remote MAC address may appear only once on the WDS page for a particular WAP device.

To configure a WDS bridge:

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 86

Wireless

WDS Bridge

STEP 1 Select Wireless > WDS Bridge in the navigation pane.

STEP 2 Select Enable for Spanning Tree Mode. When enabled, STP helps prevent

switching loops. STP is recommended if you configure WDS links.For WAP561 devices, select Radio 1 or Radio 2 for each WDS link that you configure.

STEP 3 Select Enable for WDS Interface.

STEP 4 Configure the remaining parameters:

• Remote MAC Address—Specifies the MAC address of the destination WAP

device; that is, the WAP device on the other end of the WDS link to which data is sent or handed-off and from which data is received.

TIP You can find the MAC address on the Status and Statistics > Network

Interface page.

• Encryption—The type of encryption to use on the WDS link; it does not have

to match the VAP you are bridging. The WDS Encryption settings are unique to the WDS bridge. The options are none, WEP, and WPA Personal.

If you are unconcerned about security issues on the WDS link, you may decide not to set any type of encryption. Alternatively, if you have security concerns you can choose between Static WEP and WPA Personal. In WPA Personal mode, the WAP device uses WPA2-PSK with CCMP (AES) encryption over the WDS link. See WEP on WDS Links or WPA/PSK on WDS Links following this procedure for more information about encryption options.

STEP 5 Repeat these steps for up to three additional WDS interfaces.

STEP 6 Click Save. The changes are saved to the Startup Configuration.

STEP 7 Replicate this procedure on the other device or devices connecting to the bridge.

TIP You can verify that the bridge link is up by going to the Status and Statistics

> Network Interface page. In the Interface Status table, the WLAN0:WDS(x) status should state Up.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 87

Wireless

WDS Bridge

CAUTION After new settings are saved, the corresponding processes may be stopped and

restarted. When this happens, the WAP device may lose connectivity. We recommend that you change WAP device settings when a loss of connectivity will least affect your wireless clients.

These additional fields appear when you select WEP as the encryption type.

• Key Length—If WEP is enabled, specify the length of the WEP key as

64 bits or 128 bits.

• Key Type—If WEP is enabled, specify the WEP key type: ASCII or Hex.

• WEP Key—If you selected ASCII, enter any combination of 0 to 9, a to z,

and A to Z. If you selected Hex, enter hexadecimal digits (any combination of 0 to 9 and a to f or A to F). These are the RC4 encryption keys shared with the stations using the WAP device.

Note that the required number of characters is indicated to the right of the field and changes based on your selections in the Key Type and Key Length fields.

These additional fields appear when you select WPA/PSK as the encryption type.

• WDS ID—Enter an appropriate name for the new WDS link you have

created. It is important that the same WDS ID is also entered at the other end of the WDS link. If this WDS ID is not the same for both WAP devices on the WDS link, they will not be able to communicate and exchange data.

The WDS ID can be any alphanumeric combination.

• Key—Enter a unique shared key for the WDS bridge. This unique shared

key must also be entered for the WAP device at the other end of the WDS link. If this key is not the same for both WAPs, they will not be able to communicate and exchange data.

The WPA-PSK key is a string of at least 8 characters to a maximum of 63 characters. Acceptable characters include uppercase and lowercase alphabetic letters, the numeric digits, and special symbols such as @ and #.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 88

Wireless

WorkGroup Bridge

The WAP device WorkGroup Bridge feature enables the WAP device to extend the accessibility of a remote network. In WorkGroup Bridge mode, the WAP device acts as a wireless station (STA) on the wireless LAN. It can bridge traffic between a remote wired network or associated wireless clients and the wireless LAN that is connected using the WorkGroup Bridge mode.

The WorkGroup Bridge feature enables support for STA-mode and AP-mode operation simultaneously. The WAP device can operate in one Basic Service Set (BSS) as an STA device while operating on another BSS as a WAP device. When WorkGroup Bridge mode is enabled, the WAP device supports only one BSS for wireless clients that associate with it, and another BSS with which the WAP device associates as a wireless client.

It is recommended that WorkGroup Bridge mode be used only when the WDS bridge feature cannot be operational with a peer WAP device. WDS is a better solution and is preferred over the WorkGroup Bridge solution. Use WDS if you are bridging Cisco WAP121, WAP321, WAP551, and WAP561 devices. If you are not, then consider WorkGroup Bridge. When the WorkGroup Bridge feature is enabled, the VAP configurations are not applied; only the WorkGroup Bridge configuration is applied.

NOTE The WDS feature does not work when the WorkGroup Bridge mode is enabled on

the WAP device.

In WorkGroup Bridge mode, the BSS managed by the WAP device while operating in WAP device mode is referred to as the access point interface, and associated STAs as downstream STAs. The BSS managed by the other WAP device (that is, the one to which the WAP device associates as an STA) is referred to as the infrastructure client interface, and the other WAP device is referred as the upstream AP.

The devices connected to the wired interface of the WAP device, as well as the downstream stations associated with the access point interface of the device, can access the network connected by the infrastructure client interface. To allow the bridging of packets, the VLAN configuration for the access point interface and wired interface should match that of the infrastructure client interface.

WorkGroup Bridge mode can be used as range extender to enable the BSS to provide access to remote or hard-to-reach networks. A single-radio can be configured to forward packets from associated STAs to another WAP device in the same ESS, without using WDS.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 89

Wireless

WorkGroup Bridge

Before you configure WorkGroup Bridge on the WAP device, note these guidelines:

• All WAP devices participating in WorkGroup Bridge must have the following

identical settings:

- Radio

- IEEE 802.11 Mode

- Channel Bandwidth

- Channel (Auto is not recommended)

See Radio (Basic Settings) for information on configuring these settings.

• WorkGroup Bridge mode currently supports only IPv4 traffic.

• WorkGroup Bridge mode is not supported across a Single Point Setup.

• It is not recommended to associate another AP to the downstream interface

of the WAP device operating in WorkGroup Bridge mode; that is, the chaining or cascading of APs is not supported.

To configure WorkGroup Bridge mode:

STEP 1 Select Wireless > WorkGroup Bridge in the navigation pane.

STEP 2 Select Enable for the WorkGroup Bridge Mode.

STEP 3 For WAP561 devices, select the radio interface on which to configure WorkGroup

Bridge mode (Radio 1 or Radio 2).

STEP 4 Configure these parameters for the Infrastructure Client Interface (upstream):

• SSID—The SSID of the BSS.

NOTE There is an arrow next to SSID for SSID Scanning; this feature is

disabled by default, and is enabled only if AP Detection is enabled in Rogue AP Detection (which is also disabled by default).

• Security—The type of security to use for authenticating as a client station

on the upstream WAP device. Choices are:

- None

- Static WEP

- WPA Personal

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 90

Wireless

WorkGroup Bridge

- WPA Enterprise

• VLAN ID—The VLAN associated with the BSS.

NOTE The Infrastructure Client Interface will be associated with the

upstream WAP device with the configured credentials. The WAP device may obtain its IP address from a DHCP server on the upstream link. Alternatively, you can assign a static IP address. The Connection Status field indicates whether the WAP is connected to the upstream WAP device. You can click the Refresh button at the top of the page to view the latest connection status.

STEP 5 Configure the following additional fields for the Access Point Interface:

• Status—Select Enable for the Access Point Interface.

• SSID—The SSID for the Access Point Interface does not need to be the

same as the Infrastructure Client SSID. However, if attempting to support a roaming type of scenario, the SSID and security must be the same.

• SSID Broadcast—Select if you want the downstream SSID to be broadcast.

SSID Broadcast is enabled by default.

• Security—The type of security to use for authenticating. Choices are:

- None

- Static WEP

- WPA Personal

• MAC Filtering—Select one of these options:

- Disabled—The set of clients in the APs BSS that can access the

upstream network is not restricted to the clients specified in a MAC address list.

- Local—The set of clients in the APs BSS that can access the upstream

network is restricted to the clients specified in a locally defined MAC address list.

- RADIUS—The set of clients in the APs BSS that can access the upstream

network is restricted to the clients specified in a MAC address list on a RADIUS server.

If you select Local or RADIUS, see MAC Filtering for instructions on creating the MAC filter list.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 91

Wireless

Quality of Service

• VLAN ID—Configure the Access Point Interface with the same VLAN ID as

STEP 6 Click Save. The changes are saved to the Startup Configuration.

The associated downstream clients now have connectivity to the upstream network.

Quality of Service

The quality of service (QoS) settings provide you with the ability to configure transmission queues for optimized throughput and better performance when handling differentiated wireless traffic, such as Voice-over-IP (VoIP), other types of audio, video, streaming media, and traditional IP data.

advertised on the Infrastructure Client Interface.

To configure QoS on the WAP device, you set parameters on the transmission queues for different types of wireless traffic and specify minimum and maximum wait times (through contention windows) for transmission.

WAP Enhanced Distributed Channel Access (EDCA) parameters affect traffic flowing from the WAP device to the client station.

Station EDCA parameters affect traffic flowing from the client station to the WAP device.

In normal use, the default values for the WAP device and station EDCA should not need to be changed. Changing these values affects the QoS provided.

To configure WAP device and Station EDCA parameters:

STEP 1 Select Wireless > QoS in the navigation pane.For WAP561 devices, select the

radio interface on which to configure QoS settings (Radio 1 or Radio 2).

STEP 2 Select an option from the EDCA Template list:

• WFA Defaults—Populates the WAP device and Station EDCA parameters

with WiFi Alliance default values, which are best for general, mixed traffic.

• Optimized for Voice—Populates the WAP device and Station EDCA

parameters with values that are best for voice traffic.

• Custom—Enables you to choose custom EDCA parameters.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 92

Wireless

Quality of Service

These four queues are defined for different types of data transmitted from WAPto-station. If you choose a Custom template, the parameters that define the queues are configurable; otherwise, they are set to predefined values appropriate to your selection. The four queues are:

• Data 0 (Voice)—High priority queue, minimum delay. Time-sensitive data

such as VoIP and streaming media are automatically sent to this queue.

• Data 1 (Video)—High priority queue, minimum delay. Time-sensitive video

data is automatically sent to this queue.

• Data 2 (Best Effort)—Medium priority queue, medium throughput and delay.

Most traditional IP data is sent to this queue.

• Data 3 (Background)—Lowest priority queue, high throughput. Bulk data that

requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example).

STEP 3 Configure the following EDCA and Station EDCA parameters:

NOTE These parameters are configurable only if you selected Custom in the

previous step.

• Arbitration Inter-Frame Space—A wait time for data frames. The wait time

is measured in slots. Valid values for AIFS are 1 through 255.

• Minimum Contention Window—An input to the algorithm that determines

the initial random backoff wait time (window) for retry of a transmission.

This value is the upper limit (in milliseconds) of a range from which the initial random backoff wait time is determined.

The first random number generated is a number between 0 and the number specified here.

If the first random backoff wait time expires before the data frame is sent, a retry counter is incremented and the random backoff value (window) is doubled. Doubling continues until the size of the random backoff value reaches the number defined in the Maximum Contention Window.

Valid values are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1023. This value must be lower than the value for the Maximum Contention Window.

• Maximum Contention Window—The upper limit (in milliseconds) for the

doubling of the random backoff value. This doubling continues until either the data frame is sent or the Maximum Contention Window size is reached.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 93

Wireless

Quality of Service

After the Maximum Contention Window size is reached, retries continue until a maximum number of retries allowed is reached.

Valid values are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1023. This value must be higher than the value for the Minimum Contention Window.

• Maximum Burst (WAP only)—A WAP EDCA parameter that applies only to

traffic flowing from the WAP to the client station.

This value specifies (in milliseconds) the maximum burst length allowed for packet bursts on the wireless network. A packet burst is a collection of multiple frames transmitted without header information. The decreased overhead results in higher throughput and better performance.

Valid values are 0.0 through 999.

• Wi-Fi MultiMedia (WMM)—Select Enable to enable Wi-Fi MultiMedia

(WMM) extensions. This field is enabled by default. With WMM enabled, QoS prioritization and coordination of wireless medium access is on. With WMM enabled, QoS settings on the WAP device control downstream traffic flowing from the WAP device to client station (AP EDCA parameters) and the upstream traffic flowing from the station to the AP (station EDCA parameters).

Disabling WMM deactivates QoS control of station EDCA parameters on upstream traffic flowing from the station to the WAP device. With WMM disabled, you can still set some parameters on the downstream traffic flowing from the WAP device to the client station (AP EDCA parameters).

• TXOP Limit (Station only)—The TXOP Limit is a station EDCA parameter and

only applies to traffic flowing from the client station to the WAP device. The Transmi ssion O ppor tunity (T XOP ) is an inter val of tim e, in millis econds , when a WME client station has the right to initiate transmissions onto the wireless medium (WM) towards the WAP device. The TXOP Limit maximum value is

65535.

STEP 4 Configure the following additional settings:

• No Acknowledgement—Select Enable to specify that the WAP device

should not acknowledge frames with QosNoAck as the service class value.

• Unscheduled Automatic Power Save Delivery—Select Enable to enable

APSD, which is a power management method. APSD is recommended if VoIP phones access the network through the WAP device.

STEP 5 Click Save. The changes are saved to the Startup Configuration.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 94

Wireless

WPS Setup

CAUTION After new settings are saved, the corresponding processes may be stopped and

WPS Setup

restarted. When this happens, the WAP device may lose connectivity. We recommend that you change WAP device settings when a loss of connectivity will least affect your wireless clients.

This section describes the Wi-Fi Protected Setup (WPS) protocol and its configuration on the WAP device.

WPS is a standard that enables simple establishment of wireless networks without compromising network security. It relieves both the wireless client users and the WAP device administrators from having to know network names, keys, and various other cryptographic configuration options.

WPS facilitates network setup by allowing the administrator to use a push button or PIN to establish wireless networks, which avoids the manual entry of network names (SSIDs) and wireless security parameters:

• Push button: The WPS button is either on the product or a clickable button

on the user interface.

• Personal Identification Number (PIN): The PIN can be viewed in the

product user interface.

WPS maintains network security by requiring both the users of new client devices and WLAN administrators to have either physical access to their respective devices or secure remote access to these devices.

These are typical scenarios for using WPS:

• A user wishes to enroll a client station on a WPS-enabled WLAN. (The

enrolling client device may detect the network, and prompt the user to enroll, although this is not necessary.) The user triggers the enrollment by pushing a button on the client device. The WAP device's administrator then pushes a button on the WAP device. During a brief exchange of WPS protocol messages, the WAP device supplies the new client with a new security configuration through Extensible Authentication Protocol (EAP).

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 95

Wireless

WPS Setup

The two devices disassociate, and then reassociate and authenticate with the new settings.

• A user wishes to enroll a client station on a WPS-enabled WLAN by

supplying the WAP device administrator with the PIN of the client device. The administrator enters this PIN in the configuration utility of the WAP device and triggers the device enrollment. The new enrollee and the WAP device exchange WPS messages, including a new security configuration, disassociate, reassociate, and authenticate.

• A WAP device administrator purchases a new WAP device that has been

certified by the Wi-Fi Alliance to be compliant with WPS version 2.0, and wishes to add the WAP device to an existing (wired or wireless) network. The administrator turns on the WAP device, and then accesses a network host that supports the WPS registration protocol. The administrator enters the PIN of the WAP device in the configuration utility of this external registrar, and triggers the WPS registration process. (On a wired LAN, the WPS protocol messages are transported through Universal Plug and Play, or UPnP, protocol.) The host registers the WAP as a new network device and configures the WAP with new security settings.

• A WAP device administrator has just added a new WAP device to an

existing (wireless or wired) network through WPS, and wishes to grant network access to a new client device. The device is enrolled through either the PIN or Push-Button Control (PBC) methods described above, but this time the device enrolls with the external registrar, with the WAP device acting solely as a proxy.

• A wireless device that does not support WPS must join the WPS-enabled

WLAN. The administrator, who cannot use WPS in this case, instead manually configures the device with the SSID, public shared key, and cryptography modes of the WPS-enabled WAP device. The device joins the network.

The PIN is either an eight-digit number that uses its last digit as a checksum value, or a four-digit number with no checksum. Each of these numbers may contain leading zeroes.

The WPS standard assigns specific roles to the various components in its architecture:

• Enrollee—A device that can join the wireless network.

• AP—A device that provides wireless access to the network.

• Registrar—An entity that issues security credentials to enrollees and

configures APs.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 96

Wireless

WPS Setup

The WAP devices act as AP devices and support a built-in registrar. They do not function as an enrollee.

The administrator can enable or disable WPS on only one VAP. WPS is operational only if this VAP meets these conditions:

• The WAP device is configured to broadcast the VAP SSID.

• MAC address filtering is disabled on the VAP.

• WEP encryption is disabled on the VAP.

• The VAP is configured to use either WPA-Personal security or none. If

WPA2-PSK encryption mode is enabled, then a valid pre-shared key (PSK) must be configured and CCMP (AES) encryption must be enabled.

• The VAP is operationally enabled.

WPS is operationally disabled on the VAP if any of these conditions are not met.

NOTE Disabling WPS on a VAP does not cause disassociation of any clients previously

authenticated through WPS on that VAP.

It is not necessary for the WAP devices to handle the registration of clients on the network themselves. The WAP device can either use its built-in registrar, or act as a proxy for an external registrar. The external registrar may be accessed through the wired or wireless LAN. An external registrar may also configure the SSID, encryption mode, and public shared key of a WPS-enabled BSS. This capability is very useful for out-of-box deployments; that is, when an administrator simply attaches a new WAP device to a LAN for the first time.

If the WAP device is using a built-in registrar, it enrolls new clients using the configuration of the VAP associated with the WPS service, whether this configuration was configured directly on the WAP device or acquired by an external registrar through WPS.

Push-button Control

The WAP device enrolls 802.11 clients through WPS by one of two methods: the Push-Button Control (PBC) method, or the Personal Identification Number (PIN) method.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 97

Wireless

WPS Setup

The PBC method is when the user of a prospective client pushes a button on the enrolling device, and the administrator of the WAP device with an enabled built-in registrar pushes a similar (hardware or software) button. This sequence begins the enrollment process, and the client device joins the network. Although the Cisco WAP devices do not support an actual hardware button, the administrator can initiate the enrollment for a particular VAP using a software button in the webbased configuration utility.

NOTE There is no defined order in which the buttons on the client device and WAP device

must be pressed. Either device can initiate the enrollment. However, if the software button on the WAP device is pressed, and no client attempts to enroll after 120 seconds, the WAP device terminates the pending WPS enrollment transaction.

PIN Control

A client may also enroll with a registrar by using a PIN. For example, the WAP device administrator may start an enrollment transaction for a particular VAP by entering the PIN of a client. When the client detects the WPS-enabled device, the user can then supply its PIN to the WAP device to continue the enrollment process. After the WPS protocol has completed, the client securely joins the network. The client can also initiate this process.

As with the PBC method, if the WAP device begins the enrollment transaction and no client attempts to enroll after 120 seconds, the WAP device terminates the pending transaction.

Although the WAP device supports a built-in registrar for WPS, its use is optional. After an external registrar has configured the WAP device, the WAP device acts as a proxy for that external registrar, regardless if the built-in registrar of the WAP device is enabled (it is enabled by default).

Each WAP device stores a WPS-compatible device PIN in nonvolatile RAM. WPS requires this PIN if an administrator wants to allow an unconfigured WAP device (that is, one with only factory defaults, including WPS being enabled on a VAP) to join a network. In this scenario, the administrator obtains the PIN value from the configuration utility of the WAP device.

The administrator may wish to change the PIN if network integrity has been compromised in some way. The WAP device provides a method for generating a new PIN and storing this value in NVRAM. If the value in NVRAM is corrupted, erased, or missing, a new PIN is generated by the WAP device and stored in NVRAM.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 98

Wireless

WPS Setup

The PIN method of enrollment is potentially vulnerable by way of brute force attacks. A network intruder could try to pose as an external registrar on the wireless LAN and attempt to derive the PIN value of the WAP device by exhaustively applying WPS-compliant PINs. To address this vulnerability, in the event that a registrar fails to supply a correct PIN in three attempts within 60 seconds, the WAP device prohibits any further attempts by an external registrar to register with the WAP device on the WPS-enabled VAP for 60 seconds. The lockdown duration increases upon subsequent failures, up to a maximum of 64 minutes. The WAP devices registration functionality goes into permanent lockdown after the 10th consecutive failed attempt. Reset the device to restart the registration functionality.

However, wireless client stations may enroll with the WAP device's built-in registrar, if enabled, during this lockdown period. The WAP device also continues to provide proxy services for enrollment requests to external registrars.

The WAP device has an additional security features for protecting its device PIN. After the WAP device has completed registration with an external registrar, and the resulting WPS transaction has concluded, the device PIN is automatically regenerated.

The WPS protocol can configure the following parameters for a WPS-enabled VAP on a WAP device:

• Network SSID

• Key management options (WPA-PSK, or WPA-PSK and WPA2-PSK)

• Cryptography options (CCMP/AES, or TKIP and CCMP/AES)

• Network (public shared) key

If a VAP is enabled for WPS, these configuration parameters are subject to change, and are persistent between reboots of the WAP device.

The WAP device supports registration with WPS External Registrars (ER) on the wired and wireless LAN. On the WLAN, external registrars advertise their capabilities within WPS-specific Information Elements (IEs) of their beacon frames; on the wired LAN, external registrars announce their presence through UPnP.

WPS v2.0 does not require registration with an ER through the user interface. The administrator can register the WAP device with an ER by:

STEP 1 Entering the ER PIN on the WAP device.

STEP 2 Entering the WAP device PIN on the user interface of the ER.

Cisco Small Business WAP551 and WAP561 Wireless-N Access Point 99

Cisco Systems WAP561AK9 User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual

Getting Started

Starting the Web-Based Configuration Utility

Using the Access Point Setup Wizard

Getting Started

Window Navigation

Status and Statistics

System Summary

Network Interfaces

Traf fic Statistics

WorkGroup Bridge Transmit/Receive

Associated Clients

TSPEC Client Associations

TSPEC Status and Statistics

TSPEC AP Statistics

Radio Statistics

Email Alert Status

Administration

System Settings

User Accounts

Time S et ting s

Log Settings

Email Alert

HTTP/HTTPS Service

Management Access Control

Manage Firmware

Download/Backup Configuration File

Configuration Files Properties

Copy/Save Configuration

Reboot

STEP 1 Select Administration > Discovery - Bonjour in the navigation pane.

Packet Capture

Support Information

Port Settings

VLAN and IPv4 Address Settings

IPv6 Addresses

IPv6 Tunnel

Wireless

Radio

Rogue AP Detection

Networks

Scheduler

Scheduler Association

Bandwidth Utilization

MAC Filtering

WDS Bridge

WorkGroup Bridge

Quality of Service

WPS Setup
