Cisco Systems SLM248G4PS, SLM224G4PS User Manual

24-Port or 48-Port 10/100 +
4-Port Gigabit Smart Switch
with Resilient Clustering
Technology and PoE

USER GUIDE

BUSINESS SERIES

Model: SLM224G4PS, SLM248G4PS

About This Guide

Icon Descriptions

While reading through the User Guide you may see
various icons that call attention to specific items. Below is
a description of these icons:

NOTE: This check mark indicates that there is

a note of interest and is something that you
should pay special attention to while using the
product.

WARNING: This exclamation point indicates

that there is a caution or warning and it is
something that could damage your property or
product.

About This Guide

WEB: This globe icon indicates a noteworthy

website address or e-mail address.

Online Resources

Website addresses in this document are listed without
http:// in front of the address because most current web
browsers do not require it. If you use an older web browser,
you may have to add http:// in front of the web address.

Resource Website

Linksys www.linksys.com

Linksys International www.linksys.com/international

Glossary www.linksys.com/glossary

Network Security www.linksys.com/security

Copyright and Trademarks

Linksys is a registered trademark or
trademark of Cisco Systems, Inc. and/
or its affiliates in the U.S. and certain
other countries. Copyright © 2007
Cisco Systems, Inc. All rights reserved.
Other brands and product names are
trademarks or registered trademarks
of their respective holders.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

ii

Table of Contents

Chapter 1: Introduction 1

Chapter 2: Product Overview

SLM248G4PS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

SLM224G4PS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Chapter 3: Installation 5

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Pre-Installation Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Fast Ethernet Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Full-Duplex Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1000BASE-T Cable Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Positioning the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Placement Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Desktop Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Rack-Mount Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Uplinking the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Conguring Stack Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Reassigning a Slave Unit as the Master Unit . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Replacing a Stacked Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PB

2

Chapter 4: Conguration Using the Console Interface 9

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Using the HyperTerminal Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Using telnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

How to Use the Console Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Switch Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

System Conguration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Port Status Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Port Conguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

System Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Logout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Chapter 5: Conguration Using the Web-based Utility 17

Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Setup > Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Setup > Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

iii

Table of Contents

Setup > Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Setup > Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Setup > Stack Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Port Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Port Management > Port Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Port Management > Link Aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Port Management > LACP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Port Management > PoE Power Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

VLAN Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

VLAN Management > Create VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

VLAN Management > Port Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

VLAN Management > Port to VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

VLAN Management > VLAN to Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Statistics > RMON Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Statistics > RMON History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Statistics > RMON Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Statistics > RMON Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Statistics > Port Utilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Statistics > Interface Statistics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Security > 802.1x Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Security > Port Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Security > Storm Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Security > RADIUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

QoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

QoS > CoS Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

QoS > Queue Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

QoS > DSCP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

QoS > Bandwidth. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

QoS > Basic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Spanning Tree. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Spanning Tree > STP Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Spanning Tree > Global STP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Spanning Tree > STP Port Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Multicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Multicast > IGMP Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Multicast > Bridge Multicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Multicast > Bridge Multicast Forward All . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

SNMP > Global Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

SNMP > Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

SNMP > Group Prole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

iv

Table of Contents

SNMP > Group Membership. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

SNMP > Communities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

SNMP > Notication Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

SNMP > Notication Recipient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Admin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Admin > User Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Admin > Static Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Admin > Dynamic Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Admin > Port Mirroring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Admin > Cable Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Admin > Save Conguration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Admin > Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Admin > Reboot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Admin > Factory Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Admin > Logging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Admin > Server Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Admin > Memory Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Admin > Flash Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Logout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Appendix A: About Gigabit Ethernet and Fiber Optic Cabling 50

Gigabit Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Fiber Optic Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Appendix B: About Switch Stacking 51

Standalone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Stack Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Stack Building Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Normal (Self-Ordering) Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Manually Ordered Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Stack Resiliency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Advanced Stacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Unit IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Stack Units Startup Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

User Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Stacking Examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Replacing a Failed Stack Member in a Running Stack . . . . . . . . . . . . . . . . . . . .54

Stack Master Failure and Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Splitting a Stack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Merging Two Stacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Stacking Cable Failure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Inserting Too Many Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Standalone Unit Inserted into a Running Stack . . . . . . . . . . . . . . . . . . . . . . . .58

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

v

Table of Contents

Appendix C: Glossary 59

Appendix D: Specications 6

Appendix E: Warranty Information 6

Exclusions and Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

Obtaining Warranty Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

Appendix F: Regulatory Information 67

FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

Safety Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

Industry Canada Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

Avis d’ Industrie Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

User Information for Consumer Products Covered by EU Directive 2002/96/EC on Waste

Electric and Electronic Equipment (WEEE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

Appendix G: Contact Information 72

3

5

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

vi

Chapter 1

Chapter 1: Introduction

Thank you for choosing the Linksys 24/48-Port 10/100
+ 4-Port Gigabit Smart Switch with Resilient Clustering
Technology and PoE.

These switches allow you to expand your network
securely. User control is secured using 802.1x security
using a RADIUS authentication mechanism and can also
be controlled using MAC filtering.

For Wireless or VoIP deployments, the SLM224G4PS and
SLM248G4PS Switches support the IEEE802.3af standard
for Power over Ethernet (PoE), allowing you to attach PoE­enabled devices to your network. These devices need no
additional power cables or nearby power outlets, resulting
in simpler and less expensive installation. PoE support
also allows devices like cameras and Wireless Access Points
to be positioned in optimal locations, such as in ceilings
and walls—even outdoors.

Introduction

Extensive QoS features makes the solution ideal for real­time applications like Voice and Video. The four priority
queues together with the Weighted Round Robin and
Strict Priority scheduling techniques facilitate efficient
co-existence of real-time traffic with data traffic allowing
them each to meet their QoS needs. Individual users or
applications can be prioritized above others using various
Class of Service options—by port, Layer 2 priority (802.1p),
and Layer 3 priority (TOS or DSCP). Intelligent Broadcast
and Multicast storm control minimize and contain the
effects of these types of traffic on regular traffic. IGMP
Snooping limits bandwidth-intensive video traffic to only
the requestors without flooding to all users. Incoming
traffic can be policed and outgoing traffic can be shaped
allowing you to control network access and traffic flow.

There are features that allow you to expand and grow your
network of switches. Link aggregation allows multiple
high-bandwidth trunks between switches to be set up.
This also provides a level of reliability in that the system
continues to operate if one of the links breaks. Spanning
Tree (STP) and Fast Link allow you to build a mesh of
switches increasing the availibility of the system.

The rich management functionality of the Smart Switches
with Resilient Clustering Technology includes SNMP,
RMON, Telnet, and HTTP Management options, allowing
you to flexibly integrate and manage these devices in your
network.

NOTE: Throughout this User Guide, the term

reset refers to cycling the power to the Switch;

that is, powering the Switch off, then on again.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

1

Chapter 2

Product Overview

Chapter 2: Product Overview

SLM248G4PS

Front Panel

The Switch LEDs and ports are located on the front panel.

Front Panel of the SLM248G4PS

System (Green/Amber) Lights up green to

indicate that the Switch is powered on.
Lights up amber while the Switch is performing a
system self-test. Blinks amber if the self-test fails.

LINK/ACT (1-12, 25-36) (Green/Amber) Lights

up green to indicate a functional 10/100 Mbps
network link through the corresponding port with
an attached device that does not support Power
over Ethernet (PoE). Lights up amber to indicate
a functional 10/100 Mbps network link through
the corresponding port with an attached PoE
device. Blinks green while the Switch is actively
sending or receiving data over that port.

LINK/ACT (13-24, 37-48) (Green) Lights up to

indicate a functional 10/100 Mbps network link
through the corresponding port with an attached
device. Blinks while the Switch is actively sending
or receiving data over that port.

G1-G4 (Green/Amber) Blinks green when the

Switch is actively sending or receiving data at
10/100 Mbps over the corresponding port (G1
through G4). Blinks yellow when the Switch is
actively sending or receiving data at 1000 Gbps
over the corresponding port (G1 through G4).

Stack (G1-G4) (Amber) Lights up to indicate

that the corresponding port (G1 through G4) is
linked to another switch. (Two of these LEDs will
be lit if switch stacking is properly configured.)

Ethernet 1-48 The Switch is equipped with 48

auto-sensing, Ethernet network ports, which
use RJ-45 connectors. The Fast Ethernet ports
support network speeds of 10 Mbps or 100 Mbps.
They can operate in half- and full-duplex modes.
Auto-sensing technology enables each port to
automatically detect the speed of the device
connected to it (10 Mbps or 100 Mbps), and
adjust its speed and duplex accordingly.

G1-G4

sensing Gigabit Ethernet network ports, which
use RJ-45 connectors. The Gigabit Ethernet ports
support network speeds of 10 Mbps, 100 Mbps, or
1000 Mbps. They can operate in half- and full-duplex
modes. Auto-sensing technology enables each port
to automatically detect the speed of the device
connected to it (10 Mbps, 100 Mbps, or 1000 Mbps),
and adjust its speed and duplex accordingly.

miniGBIC (1-2) The miniGBIC (gigabit interface

converter) port is a connection point for a
miniGBIC expansion module, so the Switch can
be uplinked via fiber to another switch. The
MiniGBIC port provides a link to a high-speed
network segment or individual workstation at
speeds of up to 1000 Mbps.

To establish a Gigabit Ethernet connection using
a miniGBIC port, you will need to install a MGBT1,
MGBSX1, or MGBLH1 Gigabit expansion module
and use Category 5e cabling or fiber optic cabling.

To establish a Fast Ethernet connection using a
miniGBIC port, you will need to install a MFEFX1
(100BASE-FX) or MFELX1 (100BASE-LX) 100SFP
Transceiver and use fiber optic cabling.

Stack ID Displays the S

the Switch is in stack mode.

Stack Master (Amber)

the stack Master during stack mode.

NOTE: On the SLM248G4PS, MiniGBIC ports are

shared with Gigabit Ethernet ports. If a miniGBIC
port is used, then the shared Gigabit Ethernet
port on the Switch cannot be used. The following
table defines the shared port mapping of the
SLM248G4PS Switch.

miniGBIC Port Gigabit Port

The Switch is equipped with 4 auto-

witch’s unit ID number if

Lights up if the switch is

SLM248G4PS Shared Port Mapping

miniGBIC 1 Port G3

miniGBIC 2 Port G4

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

2

Chapter 2

Product Overview

Back Panel

The Console port and power port are located on the back
panel of the Switch

CONSOLE The Console port is a serial port that

allows you to connect to a computer’s serial port
(for configuration purposes) using the provided
serial cable. You can use HyperTerminal to
manage the Switch using the console port.

POWER The Power port is where you connect

the AC power.

.

Back Panel of the SLM248G4PS

SLM224G4PS

Front Panel

The Switch’s LEDs and ports are located on the front panel.

Front Panel of the SLM224G4PS

Stack (G1-G4) (Amber) Lights up to indicate

that the corresponding port (G1 through G4) is
linked to another switch. (Two of these LEDs will
be lit if switch stacking is properly configured.)

Ethernet 1-24 The Switch is equipped with 24

auto-sensing, Ethernet network ports, which
use RJ-45 connectors. The Fast Ethernet ports
support network speeds of 10 Mbps or 100 Mbps.
They can operate in half- and full-duplex modes.
Auto-sensing technology enables each port to
automatically detect the speed of the device
connected to it (10 Mbps or 100 Mbps), and
adjust its speed and duplex accordingly.

G1-G4

sensing Gigabit Ethernet network ports, which
use RJ-45 connectors. The Gigabit Ethernet ports
support network speeds of 10 Mbps, 100 Mbps, or
1000 Mbps. They can operate in half- and full-duplex
modes. Auto-sensing technology enables each port
to automatically detect the speed of the device
connected to it (10 Mbps, 100 Mbps, or 1000 Mbps),
and adjust its speed and duplex accordingly.

miniGBIC (1-2) The miniGBIC (gigabit interface

converter) port is a connection point for a
miniGBIC expansion module, so the Switch can
be uplinked via fiber to another switch. The
MiniGBIC port provides a link to a high-speed
network segment or individual workstation at
speeds of up to 1000 Mbps.

The Switch is equipped with 4 auto-

System (Green/Amber) Lights up green to

indicate that the Switch is powered on.
Lights up amber while the Switch is performing a
system self-test. Blinks amber if the self-test fails.

LINK/ACT (1-24) (Green) Lights up to indicate

a functional 10/100 Mbps network link through
the corresponding port (1 through 24) with
an attached device. Blinks while the Switch is
actively sending or receiving data over that port.

Power over Ethernet (1-6, 13-18)

up to indicate that power is being supplied to an
attached powered device on the corresponding
port (1 through 6, or 13 through 18).

LINK/ACT (G1-G4) (Green) Blinks when the

Switch is actively sending or receiving data over
the corresponding port (G1 through G4).

1000M (G1-G4) (Yellow)

functional 1 Gbps connection on the corresponding
port (G1 through G4) with an attached device.

(Amber) Lights

Lights up to indicate a

To establish a Gigabit Ethernet connection using
a miniGBIC port, you will need to install a MGBT1,
MGBSX1, or MGBLH1 Gigabit expansion module
and use Category 5e cabling or fiber optic cabling.

To establish a Fast Ethernet connection using a
miniGBIC port, you will need to install a MFEFX1
(100BASE-FX) or MFELX1 (100BASE-LX) 100SFP
Transceiver and use fiber optic cabling.

Stack ID Displays the S

the Switch is in stack mode.

Stack Master (Amber)

the stack Master during stack mode.

NOTE:

shared with standard ports. If a miniGBIC port is
used, then the shared standard port on the Switch
cannot be used. The following table defines the
shared port mapping of the SLM224G4PS Switch.

On the SLM224G4PS, MiniGBIC ports are

witch’s unit ID number if

Lights up if the switch is

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

3

Chapter 2

SLM224G4PS Shared Port Mapping

miniGBIC Port Standard Port

miniGBIC 1 G3

miniGBIC 2 G4

Back Panel

The Console port and power port are located on the back
panel of the Switch.

Back Panel of the SLM224G4PS

CONSOLE The Console port is a serial port that

allows you to connect to a computer’s serial port
(for configuration purposes) using the provided
serial cable. You can use HyperTerminal to
manage the Switch using the console port.

POWER The Power port is where you connect

the AC power.

Product Overview

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

4

Chapter 3

Installation

Chapter 3: Installation

Overview

This chapter will explain how to connect network devices
to the Switch. The following diagram shows a typical
network configuration.

Cable/DSL

Internet

When you connect your network devices, make sure you
do not exceed the maximum cabling distances, which are
listed in the following table:

Modem Router Wireless Access Point Server

10/100/1000

Desktop

Typical Network Configuration for the SLM248G4PS

Maximum Cabling Distances

From To Maximum Distance

Switch Switch or Hub 100 meters (328 feet)

10/100

Notebook

Uplink via Fiber to

Switch

Pre-Installation Considerations

Fast Ethernet Considerations

If you are using the Switch for Fast Ethernet (100 Mbps)
applications, you must observe the following guidelines:

Full-Duplex Considerations

The Switch provides full-duplex support for its RJ-45
ports. Full-duplex operation allows data to be sent and
received simultaneously, doubling a port’s potential data
throughput. If you will be using the Switch in full-duplex
mode, the maximum cable length using Category 5 cable
is 328 feet (100 meters).

1000BASE-T Cable Requirements

All Category 5 UTP cables that are used for 100BASE-TX
connections should also work for 1000BASE-T, providing
that all four wire pairs are connected. However, it is
recommended that for all critical connections, or any
new cable installations, Category 5e (enhanced Category

5) or Category 6 cable should be used. The Category
5e specification includes test parameters that are only
recommendations for Category 5. Therefore, the first
step in preparing existing Category 5 cabling for running
1000BASE-T is a simple test of the cable installation to be
sure that it complies with the IEEE 802.3ab standards.

Positioning the Switch

Before you choose a location for the Switch, observe the
following guidelines:

Make sure that the Switch is accessible and that the

Hub† Hub 5 meters (16.4 feet)

Switch or Hub† Computer 100 meters (328 feet)

A hub refers to any type of 100 Mbps hub. A 10 Mbps hub connected

†

to another 10 Mbps hub can span up to 100 meters (328 feet).

•

cables can be connected easily.

Keep cabling away from sources of electrical noise,

•

power lines, and fluorescent lighting fixtures.

Position the Switch away from water and moisture

•

sources.

To ensure adequate air flow around the Switch, be

•

sure to provide a minimum clearance of two inches
(50 mm).

Do not stack free-standing Switches more than four

•

units high.

Placement Options

There are two ways to physically install the Switch, either
set the Switch on its four rubber feet for desktop placement
or mount the switch in a standard-sized, 19-inch wide, 1U­high rack for rack-mount placement.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

5

Chapter 3

Installation

Desktop Placement

Attach the rubber feet to the recessed areas on the

•

bottom of the Switch.

Place the Switch on a desktop near an AC power source.

•

Keep enough ventilation space for the switch and

•

check the environmental restrictions mentioned in the
Specifications Appendix as you are placing the Switch.

Connect the Switch to network devices according to

•

the Hardware Installation instructions below.

Attaching the Switch’s Rubber Feet

Rack-Mount Placement

To rack-mount the Switch in any standard 19-inch wide,
1U-high rack, follow the instructions described below.

Place the Switch on a hard flat surface with the front

1.
panel facing you.

Attach a rack–mount bracket to one side of the Switch

2.
with the supplied screws and secure the bracket
tightly.

Attaching the Brackets

Follow the same steps to attach the other bracket to

3.
the opposite side.

After the brackets are attached to the Switch, use

4.
suitable screws to securely attach the brackets to any
standard 19-inch rack.

When rack-mounting the Switch, please observe the
following guidelines

Elevated Operating Ambient If installed in a closed

•

or multi-unit rack assembly, the operating ambient
temperature of the rack environment may be greater
than room ambient. Therefore, consideration should
be given to installing the equipment in an environment
compatible with the maximum ambient temperature
(Tma) specified by the manufacturer.

Reduced Air Flow Installation of the equipment

•

in a rack should be such that the amount of air flow
required for safe operation of the equipment is not
compromised.

Mechanical Loading Mounting of the equipment in

•

the rack should be such that a hazardous condition is
not achieved due to uneven mechanical loading.

Circuit Overloading Consideration should be given

•

to the connection of the equipment to the supply
circuit and the effect that overloading of the circuits
might have on overcurrent protection and supply
wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing
this concern.

Reliable Earthing Reliable earthing of rack-mounted

•

equipment should be maintained. Particular attention
should be given to supply connections other than
direct connections to the branch circuit (e.g. use of
power strips).

Mounting in Rack

Connect the Switch to network devices according to

5.
the Hardware Installation instructions below.

Hardware Installation

To connect network devices to the Switch, follow these
instructions:

Make sure all the devices you will connect to the Switch

1.
are powered off.

For a 10/100 Mbps device:

2.

Connect a Category 5 Ethernet network cable to

•

one of the numbered ports on the Switch.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

6

Chapter 3

Installation

For a 1000 Mbps device:

Connect a Category 5e Ethernet network cable to

•

port G1, G2, G3, or G4 on the Switch.

For a 10/100 Mbps PoE device:

SLM248G4PS: Connect a Category 5e Ethernet

•

network cable to one of ports 1-12 or ports 25-36
on the Switch.

SLM224G4PS: Connect a Category 5e Ethernet

•

network cable to one of ports 1-6 or ports 13-18 on
the Switch.

Connect the other end of the network cable to a PC or

3.
other network device.

Repeat steps 2 and 3 to connect additional devices.

4.

If a 802.3af-compliant PoE device is connected to one
of the Switch’s PoE ports, the Switch will automatically
supply the required power to the device.

If you are using a miniGBIC port, then connect a

5.
miniGBIC module to a miniGBIC port. For more detailed
instructions, refer to “Uplinking the Switch“.

Connect the supplied power cord to the Switch’s

6.
power port, and plug the other end into an electrical
outlet. When connecting power, always use a surge
protector.

IMPORTANT: Make sure you use the power

cord that is supplied with the Switch. Use of a
different power cord could damage the Switch.

Power on the devices connected to the Switch. Each

7.
active port’s corresponding LED will light up on the
Switch.

Uplinking the Switch

Ethernet Ports Shared with miniGBIC Ports

Switch

SLM248G4PS G3 G4

SLM224G4PS G3 G4

To establish a Gigabit Ethernet connection using a miniGBIC
port, you will need to install a MGBT1, MGBSX1, or MGBLH1
Gigabit expansion module and use Category 5e cabling or
fiber optic cabling.

To establish a Fast Ethernet connection using a miniGBIC
port, you will need to install a MFEFX1 (100BASE-FX) or
MFELX1 (100BASE-LX) 100SFP Transceiver and use fiber
optic cabling.

The hardware installation is complete. Proceed to
“Chapter 5: Configuration Using the Web-based Utility”,
for directions on how to set up the Switch.

Port Shared with

miniGBIC1

Port Shared with

miniGBIC2

Configuring Stack Mode

The SLM224G4PS and SLM248G4PS Switches can operate
in either standalone mode or stack mode. In standalone
mode, the switch operates independently of other
switches. In stack mode, multiple Stackable Switches are
connected together to effectively form a single switch.
The default operating mode is stack mode.

A Switch stack can contain any combination of
SLM224G4PS and SLM248G4PS units, with the following
limits:

SLM224G4PS only: Maximum of 6 units

•

SLM248G4PS only: Maximum of 4 units

•

SLM224G4PS and SLM248G4PS: Maximum of 192

•

10/100 ports (total among all switches)

To uplink the Switch using a 1000 Mbps Ethernet port,
connect one end of a Cat 5e (or better) Ethernet network
cable to a Gigabit port, then connect the other end of the
cable into the peripheral device’s uplink port. MDI/MDIX
will automatically detect the speed and cable type.

To uplink the Switch using the miniGBIC port, connect
a miniGBIC module to a miniGBIC port whose shared
Ethernet port is not being used (a miniGBIC port and its
shared Ethernet port cannot be used at the same time).
The following table shows which Ethernet ports are shared
with the miniGBIC ports.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

Each switch in a stack is assigned a unique unit number.
These numbers indicate the switch’s status in the stack:

Unit 1: The switch is the Master unit. The master handles

•

the management functions for the entire stack.

Unit 2: The switch is the Backup Master unit. The backup

•

master automatically becomes the new master if the
master fails.

Unit 3, 4, 5, 6: The switch is a Slave unit. (Depending on

•

the switch models used, 5 and 6 may not be valid.)

The Switches are connected together using a pair of Gigabit
ports on each Switch: G1 and G2, G3 and G4, or miniGBIC1
and miniGBIC2. Linksys recommends using Gigabit ports
G1 and G2 (the default stacking ports). Connections are
made using Category 5e Ethernet network cables.

To set up a stack with six switches, follow these steps:

7

Chapter 3

Connect one end of a Category 5e Ethernet network

1.
cable to port G1 on Unit 1.

Connect the cable’s other end to port G2 on Unit 2.

2.

Connect one end of a Category 5e Ethernet network

3.
cable to port G1 on Unit 2.

Connect the cable’s other end to port G2 on Unit 3.

4.

Connect one end of a Category 5e Ethernet network

5.
cable to port G1 on Unit 3.

Connect the cable’s other end to port G2 on Unit 4.

6.

Connect one end of a Category 5e Ethernet network

7.
cable to port G1 on Unit 4.

Connect the cable’s other end to port G2 on Unit

8.

Connect one end of a Category 5e Ethernet network

9.
cable to port G1 on Unit 5.

Connect the cable’s other end to port G2 on Unit 6.

10.

Connect one end of a Category 5e Ethernet network

11.
cable to port G1 on Unit 6.

Connect the cable’s other end to port G2 on Unit 1.

12.

Installation

Connect Unit 2 to Unit 3

Connect port G1 on Unit 3 to port G2 on Unit 1.

5.

3.

For a stack with less than 6 switches, the steps are similar
except that port G1 of the last switch in the stack must be
connected back to port G2 of the first switch in the stack.

The following is an example of setting up a stacked
configuration using three SLM248G4PS switches.

Connect port G1 on Unit 1 to port G2 on Unit 2.

1.

Connect Unit 1 to Unit 2

Connect port G1 on Unit 2 to port G2 on Unit 3.

2.

Connect Unit 3 to Unit 1

For detailed information on switch stacking, refer to
“Appendix B: About Switch Stacking.”

For more information on stack configuration using the
Console Interface, refer to “Stack Configuration” and
“System Mode” in “Chapter 4: Configuration Using the
Console Interface” .

For more information on stack configuration using the
Web-based Utility, refer to “Setup > Stack Management”
in “Chapter 5: Configuration Using the Web-based Utility”.

Reassigning a Slave Unit as the Master Unit

You can reassign a slave unit so that it becomes the master
unit. To do this, you swap their unit numbers. For example,
to make slave unit 5 be the master, you change the master’s
unit number from 1 to 5 and the slave’s unit number from
5 to 1. To change the unit numbers, you can use either the
Web-based utility or the console interface.

The following describes the procedure for changing a
slave unit into the master unit. In this example, unit 5 is
made the master unit.

Swap the unit numbers. That is, change the unit

1.
number of the current master from 1 to 5, and change
the unit number of slave unit 5 from 5 to 1. (The order
in which these are performed is not significant.)

Power off the new unit 5 (the former master unit).

2.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

8

Chapter 4

Chapter 4:
Configuration Using the

Configuration Using the Console Interface

Set the serial port settings as follows, then click OK.

5.

Bits per Second: 38400

Databits: 8

Console Interface

Overview

The Switch features a menu-driven console interface that
lets you perform basic switch configuration and easily
manage your network. To use the console interface, you
either run the HyperTerminal application to configure a
serial connection through the Switch’s console port, or
run a telnet session over an Ethernet connection.

Using the HyperTerminal Application

To access the console interface using HyperTerminal:

Click the Start button.

1.

Select All Programs > Accessories > Communications

2.
> HyperTerminal.

Start > All Programs > Accessories > Communications > HyperTerminal

Enter a name for this connection. Select an icon for the

3.
application, then click OK.

Parity: None

Stop bits: 1

Flow control: None

HyperTerminal Properties Screen

The Login screen appears. Proceed to the “Login”

6.
section below.

Using telnet

In addition to using HyperTerminal to operate the console
interface through the Switch’s console port, you can also
use a telnet session to operate the console interface
through an Ethernet connection.

Click Start, then select All Programs > Accessories >

1.
Command Prompt to open a command prompt.

At the prompt, enter telnet 192.168.1.254, then press

2.
Enter.

The Login screen appears. Proceed to the “Login”

3.
section below.

HyperTerminal Connection Description Screen

Select a port to communicate with the switch. Select

4.
COM1 or COM2.

HyperTerminal Connect To Screen

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

9

Chapter 4

Configuration Using the Console Interface

How to Use the Console Interface

The Console Interface consists of a hierarchical series of
menu screens and settings screens. Each menu displays
a list of options. Selecting an option brings up a settings
screen where you can configure the relevant settings.

To select a menu option, either press the number of the
option in the list (for example, press 5 to select Help from
the Main Menu), or use the arrow keys to move up or down
the list until the option is highlighted, then press Enter.

The lower portion of each settings screen lists the actions
and navigation keys. The actions (Edit, Save, Quit) allow
you to make changes to the settings. The navigation keys
(Arrow Keys, Tab, Backspace, Space, Esc) allow you to
highlight and select different items within the screen.

To change a setting, highlight Edit, then press Enter. Use
the arrow keys to highlight the setting to be changed,
then enter its new value (or press Space to toggle through
the list of values). To save your changes and remain in the
settings screen, highlight Save, then press Enter. To return
to the previous screen, highlight Quit, then press Enter.
To cancel all changes and return to the previous screen,
press Esc, then select Quit.

Switch Main Menu

After successful login, the Main Menu screen appears. This
screen displays six menu choices: System Configuration
Menu, Port Status, Port Configuration, System Mode, Help,
and Log Out.

Main Menu

System Configuration Menu

Login

The console interface starts by displaying the Login screen.
The first time you open the console interface, use the
default username admin and leave the password blank,
then press the Enter key. You can set a password later
from the User and Password Settings screen.

Console Login Screen

If you are using HyperTerminal, enter the username and
password at the prompts. Then press Enter to log in.

If you are using telnet, use the arrow keys to select Edit
and press Enter. Enter the username and password in the
respective fields. Then press Esc to return to the Login
screen. Use the arrow keys to select Execute and press
Enter to complete the login process.

System Configuration Menu

The System Configuration Menu provides the following
options:

System Information

1.

Management Settings

2.

User and Password Settings

3.

Security Settings

4.

IP Configuration

5.

File Management

6.

Restore System Default Settings

7.

Reboot System

8.

Stack Configuration

9.

0. Back to Main Menu

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

10

Chapter 4

System Information

From the System Information screen you can check current
firmware versions and other general switch information.

System Information

Versions

Configuration Using the Console Interface

General System Information

Management Settings

The Management Settings screen displays the Serial Port
Configuration option.

The Versions screen displays version-related information
for each switch in the system.

Versions

Unit The unit number of the switch, from 1 to 6.

Status The status of the switch, either master or slave.

Software Version The version number of the software .

Boot Version The version number of the boot file.

Hardware Version The Switch’s current hardware setup.

General System Information

Management Settings

Serial Port Configuration

The Serial Port Configuration screen displays the current
baud rate setting. To change the baud rate, select Edit,
then use the spacebar to toggle through the different
baud rates. Use the Save action to set the new baud rate.

The General System Information screen displays the System
Description, System Up Time, System MAC Address, System
Contact, System Name and System Location.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

Serial Port Configuration

11

Chapter 4

Configuration Using the Console Interface

User & Password Settings

The User & Password Settings screen displays all the user
accounts defined on the system.

User & Password Settings

The default account is admin. You cannot edit this account
(its user name and password cannot be changed). For
security purposes, Linksys recommends creating at least
one user account with a unique user name and password.
You can create up to five user accounts total.

(When you create your first user account, it will appear as
though you are editing the admin account; however, you
are only
The admin account is not overwritten or deleted.)

Once you have created a user account, you can edit it
(change the user name and/or password) or delete it. If the
system contains only one user account and you delete that
account, the original admin account will reappear in its
place. This is because the system must always have at least
one account.

replacing the admin account with the new account.

Security Settings

The IP Configuration screen displays one option: Disable
Active Management Access Profile.

Security Settings

Selecting this option will prompt you to confirm that you
want to disable the active management access profile.

NOTE: This setting has no effect when

Management Access Rules are not defined.

IP Configuration

The IP Configuration screen displays three menu choices:
IP Address Settings, HTTP Configuration, and Network
Configuration.

To add a new user, use the arrow keys to select Edit,
press Enter, then enter the new account’s user name and
password in the Username and Password columns, and
re-enter the password in the Password Again column to
confirm the password.

To delete an existing user account, use the arrow keys to
select Edit, press Enter, then delete the user name in the
Username column.

To save your changes, press Esc, use the arrow keys to
select Save, then press Enter.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

IP Configuration

12

Chapter 4

Configuration Using the Console Interface

IP Address Settings

The IP Address Settings screen allows you to set the IP
information for the Switch.

IP Address Configuration

IP Address This sets the Switch’s IP Address. The default

setting is 192.168.1.254. If you change the IP address,
verify that the address you enter is correct and does not
conflict with another device on the network.

Subnet Mask This combined with the IP Address defines

the Switch’s network address.

Default Gateway This defines the IP Address for the

default gateway of the network.

Network Configuration

The Network Configuration screen offers a choice of two
tests, Ping and TraceRoute.

Network Configuration

Ping The Ping screen displays the IP address of the

location you want to contact.

Management VLAN This is the ID number of the

Management VLAN.

DHCP Client The status of the DHCP client is displayed.

If you want the Switch to be a DHCP client, then select
ENABLE. If you want to assign an static IP address to the
Switch, then enter the IP settings and select DISABLE.

HTTP

The HTTP screen allows you to set the Hyper Text Transfer
Protocol server (web server) information for the Switch.

HTTP

HTTP Server Enable or disable the Switch’s HTTP server

function.

HTTP Server port Set the TCP port that HTTP packets are

sent and received from.

Ping

Select Edit to change the IP address, and select Execute
to begin the ping test.

After the ping test is complete, the Ping screen displays
the IP address, status, and statistics of the ping test.

TraceRoute The TraceRoute screen displays the IP address

of the address whose route you want to trace.

TraceRoute

Select Edit to change the IP address, and select Execute
to begin the traceroute test.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

13

Chapter 4

Configuration Using the Console Interface

After the traceroute test is complete, the TraceRoute
screen displays the IP address, status, and statistics of the
traceroute test.

File Management

The File Management screen allows you to upload or
download files, such as the startup configuration, boot, or
image file, using a TFTP server.

File Management

Source File Specify the location of the file to transfer.

Select one of the following:

TFTP If the file is located on a TFTP server.

•

Restore System Default Settings

To restore the Switch back to the factory default settings,
select Restore System Default Settings and press Enter.
A prompt appears in the lower part of the screen asking
you to confirm the requested action. Press Y to continue
or N to cancel the action.

Restore Default

Reboot System

If you want to restart the Switch, select Reboot System
and press Enter. When you are prompted to confirm the
action, press Y to continue or N to cancel the action.

Image If the file is a software code file.

•

Startup-config If the file is a configuration file.

•

Destination File Specify where the file is to be transferred.

Select one of the following:

TFTP If the file is to be uploaded to a TFTP server.

•

Image If the file is to be downloaded as a software

•

code file.

Startup-config If the file is a configuration file

•

Boot If the file is a boot file.

•

File Name Enter the name of the file to be uploaded or

downloaded.

IP Address Enter the IP address of the TFTP server that

will transfer the file.

Select Edit to change the settings. When your changes
are complete, press Esc to return to the Action menu, and
select Execute to upload or download the designated file.
If you are downloading a new boot image, please follow
these steps:

Download the new boot code. DO NOT RESET THE

1.
DEVICE!

Reboot System

Stack Configuration

The Stack Configuration screen displays information about
the switch stack and allows you to change those settings.

Download the new software image.

2.

Reset the device now.

3.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

Stack Configuration

14

Chapter 4

Configuration Using the Console Interface

Unit The unit number of the switch, from 1 to 6.

MAC Address The MAC address of the switch.

Software The version number of the software that runs

the switch.

Uplink The ID number of the switch that has an uplink

connection to this switch.

Downlink The ID number of the switch that has a

downlink connection from this switch.

Status The status of the switch, either master or slave.

ID After Reset The ID number that the Switch will have

after the next system reset. Values are Auto or 1 to 6.

Back to Main Menu

Select Back to Main Menu to exit the System Configuration
Menu and return to the Main Menu screen.

Port Status Menu

The Port Status Menu displays three options: Port Status,
PoE Status, and Back to Main Menu.

PoE Status

The PoE Status screen displays the following status
information for each of the switch’s PoE ports: port number,
port status, power allocation, and power consumption.
This screen is read-only; to change a port’s PoE settings,
use the Port Configuration screen.

PoE Status

Port Configuration

The Port Configuration Menu displays three options: Port
Settings, PoE Settings, and Back to Main Menu.

Port Status Menu

Port Status

The Port Status screen displays the following status
information for each of the switch’s ports: port number,
port status, link status, speed and duplex mode, and flow
control status. This screen is read-only; to change a port’s
settings, use the Port Configuration screen.

Port Status

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

Port Configuration

The Port Configuration screen allows you to change a
port’s settings. You can enable or disable a port, or set
its auto-negotiation status, speed and duplex mode, and
flow control status.

Port Configuration Menu

Port Configuration

15

Chapter 4

Configuration Using the Console Interface

PoE Settings

The PoE Settingsscreen allows you to change a PoE port’s
PoE settings. You can set a PoE port’s priority, or enable or
disable PoE on a PoE port.

PoE Settings

System Mode

The System Mode screen displays information about the
system mode:

Help

The Help screen explains how to navigate the various
screens of the console interface.

Help

Logout

Select Logout to log out of the console interface.

System Mode

Current System Mode This is always set to Layer 2.

System Mode The system mode, either Stack or

Standalone. This cannot be changed.

Stacking Mode after Reset This indicates the mode,

Stack or Standalone, that the system will be in following
the next system reset. The default mode is Stack.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

16

Chapter 5

Configuration Using the Web-based Utility

Chapter 5: Configuration Using the Web-based Utility

This chapter describes the features included in the Web­based Utility. All features shown in this chapter, unless
specifically identified, are included in the all of Stackable
Switches. Unique features for specific Switches are noted.

NOTE: The web-based utility is optimized for

a screen resolution of 1024 x 768. Internet
Explorer version 5.5 or above is required.

To use the utility, open your web browser, enter
http://192.168.1.254 in the Address field, then press Enter.

Address Bar

Each time you log in, the web-based utility first displays
the Setup tab’s Summary screen. To access another screen,
you first select the appropriate category from among
the 11 tabs that appear at the top of the screen: Setup,

Port Management, VLAN Management, Statistics,
Security, QoS, Spanning Tree, Multicast, SNMP, Admin,

and Logout. Then, select the desired screen from the list
directly below the tab names.

Setup

The Setup tab contains the Summary, Zoom, Network
Settings, Time, and Stack Management screens.

Setup > Summary

The Summary screen displays a summary of Switch
information. The settings shown cannot be modified
from the Summary screen; however, many of them can be
modified from the Setup tab’s Network Settings screen.

NOTE: The default IP address is 192.168.1.254.

If you have changed the IP address or are using
DHCP to assign it, enter the new IP address
instead. The computer you use for configuration
should be on the same subnet as the Switch.

The Login screen appears. Enter admin in the Username
field and enter the password in the Password field. If this is
the first time you are using the utility, leave the Password
blank. Then press OK to log in. The Setup tab’s Summary
screen appears.

(After you have completed your first login, f
purposes it is recommended that you set a password at
a later time. For detailed information on changing the
password, refer to section “Admin > User Authentication.”

or security

Setup > Summary

The Summary screen has two sections: Device Information
and System Information. These are described below.

Device Information

)

System Name Displays the name of the Switch, if one has

been entered on the Setup tab’s Network Settings screen.

IP Address The IP address assigned to the Switch. The

Switch’s default IP address is 192.168.1.254. This setting
can be configured from the Setup tab’s Network Settings
screen.

Subnet Mask The Subnet Mask assigned to the Switch.

The default is 255.255.255.0. This setting can be
configured from the Setup tab’s Network Settings screen.

DNS Server The IP address of your ISP’s server that

translates the names of websites into IP addresses. This
setting can be configured from the Setup tab’s Network
Settings screen.

Login Screen

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

17

Chapter 5

Configuration Using the Web-based Utility

Default Gateway The IP address (default 0.0.0.0) of the

gateway router between the Switch and management
stations on other network segments. This setting can be
configured from the Setup tab’s Network Settings screen.

NOTE: The Default Gateway cannot be

configured if the system IP address is set to

192.168.1.254. (The system IP Address is set
using Setup > Network Settings.)

Address Mode Specifies whether the Switch’s IP address

is Static or dynamically assigned using DHCP (Dynamic
Host Configuration Protocol). This setting can be
configured from the Setup tab’s Network Settings screen.
The default setting is Static.

Base MAC Address Displays the Switch’s MAC address.

Jumbo Frame This setting enables or disables Jumbo

frames on the Switch. A maximum packet size of 9 KB is
supported. Jumbo frames allow data to be transmitted
using fewer frames, providing lower overhead, quicker
processing time, and fewer interruptions. Select either
Enable or Disable (default).

Setup > Zoom

The Zoom screen depicts the status of all the ports in the
system. This screen displays a front-panel view of each
Switch. The color of each switch port indicates its status:

Green This port has a connection.

Gray This port has no connection.

Orange The administrator has closed down this port.

Setup > Zoom

NOTE: The Jumbo Frame feature functions only

on the Gigabit ports (G1-G4).

Switch Mode After Reset This setting specifies the

system mode following a system reset. Select either
Standalone or Stackable (default).

System Information

Model Name Displays the model name of the Switch.

Hardware Version

Boot Version Displays the current boot version.

Firmware Version Displays the current software version

System Location Displays the location of the system if it

has been defined. This setting can be configured from the
Setup tab’s Network Settings screen.

System Contact The name of the administrator appears

here, if one has been defined. This setting can be configured
from the Setup tab’s Network Settings screen.

System Up Time Displays the length of time that has

elapsed since the Switch was last reset.

Current Time Displays the current time. This setting can

be configured from the Setup tab’s Time screen.

Displays the current hardware version.

Clicking on a port displays the Port Configuration screen.

NOTE: The port colors in the Zoom screen are

not related to the colors of the port LEDs. The
port LEDs display different status information,
as described in “Chapter 2: Overview.”

Setup > Network Settings

Setup > Network Settings

The Network Settings screen allows you to edit the
following information.

Click Save Settings to save your changes. Click Cancel

Changes to cancel your changes.

24/48-Port 10/100 + 4-Port Gigabit Smart Switch with Resilient Clustering Technology and PoE

Identification

System Name Specifies the name of the Switch. Enter the

name into the text field provided. By default, the system
name is LS-SLM224G4POE or LS-SLM248G4POE.

18
