Cisco SOHO 77H ADSL Router

Affordable Secure ADSL Router with the Power

of Cisco IOS

®

Manageability and Reliability

The Cisco SOHO 77H Router providesanaffordable, secure,multiuserdigital
subscriber line (DSL) access solution to small office/home office customers
while reducing deployment and operational costs for service providers.
Through the power of Cisco IOS
ADSL router provides superior manageability and reliability.

®

software technology, the Cisco SOHO 77H

Data Sheet

Figure 1

The Cisco SOHO 77H
ADSL Router

SOHO customers need affordable,
multiuser access on a single asymmetric
DSL (ADSL) line as well as business class
firewall security and reliability. Services
providers need to deploy and manage
intelligent customer premise equipment
(CPE) that supports SOHO customer’s
needs while keeping operational costs low.

The Cisco SOHO 77H router is ideal for
small offices or home offices and allows
userstosharea singleDSL lineand singleIP
address, providing:

• Affordable,multiuser accesswith 4port
Ethernet Hub

• Business Class Security with Stateful
Inspection Firewall

• Easy set up and deployment with
Web-based configuration

Because the Cisco SOHO 77H router is
based on Cisco IOS technology, service
providers can leverage their training and
investmentsin Cisco IOSsoftware toreduce
overall costs of doing business. With key
management and troubleshooting features,
serviceproviders cancost-effectively deploy
andremotely manage theCisco SOHO 77H
Router with the following advantages:

• Cisco IOS manageability, including
interactive diagnostics/debug features

• Familiar Cisco IOS command-line
interface (CLI)

• Proven reliability and industry leading
support

Benefits of Cisco SOHO 77H
ADSL Router

Affordable, Multiuser Access with a
Single DSL Line

The Cisco SOHO 77H ADSLrouter enables
service providersor businesses todeploy an
affordable, multiuser router thatis ideal for
sites that need fast, reliable access to the
Internet. Network Address Translation
(NAT) allows multiple users to share one
DSL line with a single IP address, and NAT
eliminates the need to readdress all PCs

All contents are Copyright © 1992–2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.

Cisco Systems, Inc.

Page 1 of 8

with private network addresses. Unlike a DSL modem, which allows only a single PC to connect to the Internet at a
time, theCisco SOHO 77HADSL routere allows multiplePCs to connect to the Internet simultaneously.The SOHO
77H router includes anintegrated four portEthernet hub toallow up tofour devices to connect directly to the router.

Figure 2

Cisco SOHO 77H Rear View

Figure 3

The Cisco SOHO 77H ADSL router is ideal for small office/home office environment, providing basic secure and reliable access to the Internet.

Small Office-Cisco SOHO 77H Home Office-Cisco SOHO 77H

Internet

Packet Filtering
Stateful Inspection
Firewall (ACLs)

Packet Filtering
Stateful Inspection
Firewall (ACLs)

Business Class Security with Stateful Inspection Firewall

With DSL’s always-on connection network security is essential. The Cisco SOHO 77H ADSL router enables service
providers to offer true business class security with a stateful inspection firewall that helps protect users from
unauthorized access from hackers allowing friendly traffic to pass through while stopping unwanted traffic at the
firewall. A stateful firewall denies or permits WAN traffic based on a session’s state, so requests from users behind
the firewall can be received, while preventing unauthorized access.

If an intruder attempts to gain access to the network through the SOHO 77H Router and is rejected the firewall
tracks the user through an audit trail. This audit trail can then help identify an attack in progress and locate an
intruder to prevent future attempts. In addition, the firewall uses NATto hide internal IP addresses from the outside
world to further keep the network secure.

Easy Set Up and Deployment

The Cisco SOHO 77H Router includes the Cisco Router Web Set up tool (CRWS), a web based configuration tool
that allows users to quickly self-install the router without knowledge of Cisco IOS software. Because CRWS is web
based, no additional software needs to be installed on a user’s PC. They simply point a browser to the router and
follow a few simple sets to quickly get the router up and running.

All contents are Copyright © 1992–2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.

Cisco Systems, Inc.

Page 2 of 8

Cisco Configuration Express allows service providers to order pre-configured SOHO 77H routers and have them
shipped directly to the customer site. End users simply enter user name and password to complete the installation.

The Power of Cisco IOS Software

Remote Management

The Cisco SOHO 77H Router incorporates the same Cisco IOS technologies used by service providers and
enterprises, allowing service providersto use existingknowledge of Cisco IOS softwareto reduce trainingcosts when
configuring, installing, and deploying Cisco SOHO 77H ADSL routers.

Additionally, Cisco IOS software provides many debug features that allow a service provider to remotely diagnose
network problems. For example, the ADSL loop analysis feature provides information gathered remotely to analyze
line quality and data transfer rates, including train speeds for upstream and downstream, bit error rate, margin,
chipset status, as well bits per frequency bin.

The Cisco SOHO 77H Series routers support centralized administration and management via Simple Network
Management Protocol (SNMP), HTTP,Telnet,or local management throughthe router consoleport. In addition, the
world-class support offered by the Cisco Technical Assistance Center (TAC) provides unparalleled support services.

Managed Network Services with Cisco IOS Software

Service providers can offersmall business andenterprise telecommuters managed network orInternet access withthe
Cisco SOHO 77H Router, providing service level agreement (SLAs) and guaranteed response times. SLAs can be a
critical requirementin serving the business market that isaccustomed to uninterrupted service with traditional WAN
services suchas T1 linesor Frame Relay. When deploying business serviceswith multiple Cisco SOHO77H Routers,
service providers can use tools to provision and monitor these services. The Cisco SOHO 77H Router supports the
SA Agent feature in Cisco IOS Software that enables the monitoring of SLAs all the way to the customer site.

Proven Reliability

Because Cisco SOHO 77H ADSL router is based on the same proven Cisco IOS technology used on 80 percent of
the Internet and because Cisco IOS software is the industry standard application for mission-critical enterprise
networks, SOHO customers can depend on them well into the future.

Table 1 Key Product Features and Benefits

Key Features Benefits

Affordable, Multiuser Access

NAT/PAT • Allows multiple users to share a single DSL line and one IP address

• Lets businesses and service providers conserve valuable IP address space

• Reduces time and costs by reducing IP address management

Integrated four port Ethernet Hub • Allows up to four devices to be connected directly to the router

Business Class Security

Statfeul Inspection Firewall • Offers internal users secure, per-application dynamic access control

(stateful inspection) for all traffic across perimeters

• Defends and protects router resources against denial-of-service attacks

• Checks packet headers, dropping suspicious packets

• Details transactions for reporting on a per-application, per-feature basis

All contents are Copyright © 1992–2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.

Cisco Systems, Inc.

Page 3 of 8

Table 1 Key Product Features and Benefits (Continued)

Key Features Benefits

NAT/PAT • Hides internal IP addresses from external networks

• Prevents certain denial-of-service attacks from outside networks on
internal hosts

Easy Set Up and Deployment

Cisco Router Web Set Up tool
(CRWS)

Web-Based Configuration • Provides an easy to set up configuration wizard that allows usersto easily

Configuration Express • Allows service providers to order pre-configured CPE and have it shipped

Color Coded Ports and Cables and
Quick-Start Reference Guide

Cisco IOS Management and Proven Reliability

Cisco IOS Interactive Debug Features • Allows service providers to remotely or locally diagnose network

Cisco IOS CLI • Allows customers to use existing knowledge of Cisco IOS CLI for easier

Cisco IOS Service Assurance Agent
(SAA)

Cisco IOS Easy IP • Enables true mobility-client IP addresses to be transparently configured

SNMP • Enables remote management and monitoring via SNMP, Telnet, or HTTP

• Provides an easy to set up configuration wizard that allows usersto easily
set up the router in minutes

set up the router in minutes

directly to the customer site

• Help users make proper connections

• Provides easy-to-follow installation instructions

problems in detail (for example, via Telnet or terminal connection into
the router)

installation and manageability without additional training

• Provides a way to measure statistics used in analyzing Service Level
Agreements (SLAs)

via the Cisco IOS Dynamic Host ConfigurationProtocol (DHCP) server each
time a client powers up

and local management via console port

Proven Technology • Offers technology thatis used throughout the backboneof the Internet and

World-Class Support • Helps customers keep their Cisco SOHO 77H series routers running

Table 2 Model Matrix

Hardware Specifications

Processor MPC 855T RISC
Processor Speed 50 MHz
DRAM Memory 16 MB
Flash Memory 8 MB
Ethernet 4 port 10 Mbps Hub
Console RJ-45

All contents are Copyright © 1992–2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.

in most enterprise networks

Cisco Systems, Inc.

Page 4 of 8

Table 2 Model Matrix (Continued)

Hardware Specifications

LEDs 7
Support for Kensington-Style

Physical Lock
Crossover Hub Switch Yes
Power Supply Universal 100 - 240 VAC

Yes

Table 3 Cisco SOHO 77H Router Software Feature Set

Software Feature Sets—Basic Protocols/Features IP/FW Image

LAN

Transparent Bridging X
IP X

Routing

RIP, RIPv2 X
PAP, CHAP, Local Password X

Security

Stateful Inspection Firewall X

Ease of Use and Deployment

Web based Configuration X
Easy IP Phase I and II X

Management

Web based management tool X
SNMP, Telnet, Console Port X
Service Assurance Agent X
TFTP Client and Server X

QoS

CBR, UBR, VBR-nrt, Per VC Shaping X

Address Conservation

NAT Many to One (PAT) X
IPCP Address Negotiation X
DHCP Client Address Negotiation X

Note:

plain old telephone service (POTS) splitter connected between the line and phones, fax machines, or modems, to provide filtering
of the high-frequency ADSL signal to avoid interference between the voice and the ADSL service.

All contents are Copyright © 1992–2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.

Ordinary circuit-switched telephone service can be supported on the same copper pair as ADSL by using micro filters or

Cisco Systems, Inc.

Page 5 of 8

Table 4 Cisco SOHO and 800 Series—DSLAM Interoperability

Alcatel

DSLAM

Chipset

Cisco 826

Cisco 827H

Cisco 828

Cisco SOHO 76

Cisco SOHO 77H

Cisco SOHO 78

ASAM
1000

AME
ADSL

Alcatel 7300 Cisco 6x60/6015 ECI

AME
ADSL

GSI
G.SHDSL

ADI
ADSL

XX–– P (ext) –PP–
XX–X* X –PP–

––P– – X––R
XX–– P (ext) –PP–
XX–X* X –PP–

––P– – X––R

GSI
ADSL

GSI
G.SHDSL

ADI 918
ADSL

ADI 930
ADSL

Metalink
G.SHDSL

DSLAM

Chipset

Cisco 826

Cisco 827H

Cisco 828

Cisco SOHO 76

Cisco SOHO 77H

Cisco SOHO 78

Legend

In progress

P

P (ext)

In progress

Supported

X

On roadmap

R

No plan/not supported

–

Needs external attenuator

*

TDB, testing required

?

Siemens
Xpresslink 2.0

TI ADSL GSI

G.SHDSL

Fujitsu/Westell

AME
ADSL

GSI
G.SHDSL

Marconi
DSLAM AXH600

AME
ADSL

Metalink
G.SHDSL

Lucent Stinger

AME
ADSL

GSI
ADSL

P – – ?R
P –P–R –?R

– R–P– R––
P –––– –?R
P –P–R –?R

– R–P– R––

All contents are Copyright © 1992–2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.

Cisco Systems, Inc.

Page 6 of 8

Regulatory and Standards Compliance

Supported RFCs

• RFC 2516 Point-to-Point Protocol (PPP) over
Ethernet

• RFC 2364 Point-to-Point Protocol (PPP) over
ATM PVCs

• RFC 2684 (formerly 1483) Multiprotocol
ATM encapsulation

• RFC 1577 Classical IP over ATM

• RFC 1213 MIB II for IP

• RFC 1695 AToM MIB for ATM

• RFC 1058 RIP1, RIP1-compatible

• RFC 1389 RIP2

• RFC 2131, 2132 DHCP server

• RFC 1542, 2132 Bootp and DHCP relay agent

• RFC 2132 DHCP client

• RFC 1974 Data compression of up to 4:1
(STACTMLZS)

• RFC 1144 Van Jacobson TCP header compression

• RFC 1631 Network renumbering

• RFC 1334, 1994 User authentication (PAP/CHAP)
with PPP

• RFC 1631, 2663 IP Network Address Translation
(NAT)

Safety

• FCC Part 68

• UL 1950/ CSA 950-95, Third Edition

• IEC 950: Second Edition with Amendments 1, 2, 3,
and 4

• EN60950: 1992 with Amendments 1, 2, 3, and 4

• CSO3, Canadian Telecom requirements

• AS/NZS 3260:1996 with Amendments1, 2, 3, and 4

• ETSI 300-047

• TS 001 with Amendment 1

• EMI

• AS/NRZ 3548:1992 Class B

• CFR 47 Part 15 Class B

• EN60555-2 Class B

• EN55022 Class B

• VCCI Class II

• ICES-003, Issue 2, Class B, April 1997

• IEC 1000-3-2

Immunity

• IEC 1000-4-2 (EN61000-4-2)

• IEC 1000-4-3 (ENV50140)

• IEC 1000-4-4 (EN61000-4-4)

ADSL Specifications

Alcatel DynaMiTe ADSL Chipset

• T1.413 ANSI ADSL DMT issue 2

• G.992.1 TU G.DMT support

Physical Specifications

Dimensions and Weight Specifications

• Dimensions (H x W x D):

2.0 x 9.7 x 8.5 in. (5.1 x 24.6 x 21.6 cm)

• Weight:

1.48lb (0.67kg)

Environmental Operating Ranges

• Operating tempurature:
32 to 104ºF (0 to 40ºC)

All contents are Copyright © 1992–2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.

Cisco Systems, Inc.

Page 7 of 8

Corporate Headquarters

Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
www.cisco.com
Tel: [phone]

800 553-NETS (6387)

Fax: [phone]

European Headquarters

Cisco Systems Europe
11 Rue Camille Desmoulins
92782 Issy-les-Moulineaux
Cedex 9
France
www-europe.cisco.com
Tel: [phone]
Fax: [phone]

Cisco Systems has more than 200 offices in the following countries and regions. Addresses, phone numbers, and fax numbers are listed on the

Cisco Web site at www.cisco.com/go/offices

Argentina • Australia • Austria • Belgium • Brazil • Bulgaria • Canada • Chile • China PRC • Colombia • Costa Rica • Croatia
Czech Republic • Denmark • Dubai, UAE • Finland • France • Germany • Greece • Hong Kong SAR • Hungary • India • Indonesia • Ireland
Israel • Italy • Japan • Korea • Luxembourg • Malaysia • Mexico • The Netherlands • New Zealand • Norway • Peru • Philippines • Poland
Portugal • Puerto Rico • Romania • Russia • Saudi Arabia • Scotland • Singapore • Slovakia • Slovenia • South Africa • Spain • Sweden
Switzerland • Taiwan • Thailand • Turkey • Ukraine • United Kingdom • United States • Venezuela • Vietnam • Zimbabwe

All contents are Copyright ©1992–2002,CiscoSystems,Inc.Allrightsreserved.CCIP,theCiscoPowered Network mark, the Cisco Systems Verified logo, Cisco Unity, Follow Me Browsing, FormShare, Internet Quotient,
iQ Breakthrough, iQ Expertise, iQ FastTrack, the iQ logo, iQ Net Readiness Scorecard, Networking Academy, ScriptShare, SMARTnet, TransPath, and Voice LAN are trademarks of Cisco Systems, Inc.; Changing the
Way We Work, Live, Play, and Learn, Discover All That’s Possible, The Fastest Way to Increase Your Internet Quotient, and iQuick Study are service marks of Cisco Systems, Inc.; and Aironet, ASIST, BPX, Catalyst,
CCDA, CCDP, CCIE, CCNA, CCNP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, the Cisco IOS logo, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Empowering the
Internet Generation, Enterprise/Solver, EtherChannel, EtherSwitch, Fast Step, GigaStack, IOS, IP/TV, LightStream, MGX, MICA, the Networkers logo, Network Registrar, Packet, PIX, Post-Routing, Pre-Routing,
RateMUX, Registrar, SlideCast, StrataView Plus, Stratm, SwitchProbe, TeleRouter, and VCO are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries.

All other trademarks mentioned in this document or Web site are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.
(0203R) 05/02 LDI-4014c

Americas Headquarters

Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
www.cisco.com
Tel: [phone]
Fax: [phone]

Asia Pacific Headquarters

Cisco Systems, Inc.
Capital Tower
168 Robinson Road
#22-01 to #29-01
Singapore 068912
www.cisco.com
Tel: [phone]
Fax: [phone]
