Cisco ISR4331/K9 Product Data Sheet

Data Sheet

Cisco 4000 Family Integrated

Services Router

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 1 of 26

Table of Contents

Product Overview 3

Features and Benefits 3

Product Specifications 8

ISR 4000 Interfaces and Modules Support 19

Ordering Information 25

Warranty Information 25

Document History 26

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 2 of 26

Cisco® 4000 Family Integrated Services Routers (ISRs) form an Software Defined WAN platform that
delivers the performance, security, and convergence capabilities that today’s branch offices need.

Product Overview

The Cisco 4000 Family Integrated Services Router (ISR) revolutionizes WAN communications in the enterprise branch. With
new levels of built-in intelligent network capabilities and convergence, it specifically addresses the growing need for
application-aware networking in distributed enterprise sites. These locations tend to have lean IT resources. But they often also
have a growing need for direct communication with both private data centers and public clouds across diverse links, including
Multiprotocol Label Switching (MPLS) VPNs and the Internet.

The Cisco 4000 Family contains the following platforms: the 4461, 4451, 4431, 4351, 4331, 4321 and 4221 ISRs.

Figure 1.

Cisco 4000 Series Integrated Services Routers

Features and Benefits

Cisco 4000 Family ISRs provide you with Cisco® Software Defined WAN (SDWAN) software features and a converged
branch infrastructure. Along with superior throughput, these capabilities form the building blocks of next-generation
branch-office WAN solutions.

Cisco Software Defined WAN

Cisco SDWAN is a set of intelligent software services that allow you to reliably and securely connect users, devices, and
branch office locations across a diverse set of WAN transport links. SDWAN-enabled routers like the ISR 4000 dynamically
route traffic across the “best” link based on up-to-the-minute application and network conditions for great application
experiences. You get tight control over application performance, bandwidth usage, data privacy, and availability of your
WAN links - control that you need as your branches conduct greater volumes of mission-critical business.

Cisco Converged Branch Infrastructure

The Cisco 4000 Series ISRs consolidate many must-have IT functions, including network, compute, and storage resources.
The high-performance, integrated routers run multiple concurrent services, including encryption, traffic management,
and WAN optimization, without slowing your data throughput. And you can activate new services on demand through a
simple licensing change.

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 3 of 26

Business Requirement(s)

Feature/Solution

Performance

● Throughput

● Service reliability

● Concurrent software services at speeds up to 2 Gbps. Backplane architecture supports high-

bandwidth module-to-module communication at speeds up to 10 Gbps.

● A distributed multicore architecture with the industry’s first internal services plane.

● Remote installation of application-aware services, which run identically to their counterparts in

dedicated appliances.

Lower WAN expenditures

● Embedded SDWAN solution for creating lower-cost, business-class Internet connections.

Pay-as-you-grow

● Performance upgrade model

● Investment protection

● CapEx budget management

● Router capacity can be increased with a remote performance-on-demand license upgrade (no

hardware upgrade) for exceptional savings.

Superior and secure user application
experiences

● ISR-AX “Application Experience” software bundle with advanced routing and network monitoring

services.

● Dynamic Multipoint VPN (DMVPN), zone-based firewalls, Intrusion Prevention (Snort & Umbrella

Branch) and Content Management using Cisco Cloud Web security & OpenDNS protecting data,

Cisco Intent Based Networking and Digital Network Architecture (Cisco DNA)

The last few years has seen a rapid transformation and adoption of digital technologies. This puts pressure on the on the
Network teams supporting this changing infrastructure - especially when provisioning, managing, monitoring and
troubleshooting these diverse devices. Additionally innovations such as Software Defined WAN (SDWAN), Network
Function Virtualization (NFV), Open APIs and Cloud Management show great promise in transforming Organizations IT
networks. This transformation raises further questions and challenges for the IT teams.

The Cisco Digital Network Architecture (Cisco DNA) is an open, extensible, software-driven architecture that provides for
faster innovation, helping to generate deeper insights, and deliver exceptional experiences across many different
applications. Cisco DNA relies on intent-based networking, a revolutionary approach in networking that helps
organizations automate, simplify, and secure the network.

The intent-based Cisco DNA network is:

●

Informed by Context: Interprets every byte of data that flows across it, resulting in better security, more
customized experiences, and faster operations.

●

Powered by Intent: Translates your intent into the right network configuration, making it possible to manage and
provision multiple devices and things in minutes.

●

Driven by Intuition: Continually learns from the massive amounts of data flowing through it and turns that data
into actionable insight. Helps you solve issues before they become problems and learn from every incident.

Cisco DNA Center provides a centralized management dashboard across your entire network — the branch, campus, data
center, and cloud. Rather than relying on box-by-box management, you can design, provision, and set policy end-to-end
from the single Cisco DNA Center interface. This allows you to respond to organizational needs faster and to simplify day­to-day operations. Cisco DNA Analytics and Assurance and Cisco Network Data Platform (NDP) help you get the most
from your network by continuously collecting and putting insights into action. Cisco DNA is open, extensible, and
programmable at every layer. It integrates Cisco and third-party technology, open APIs, and a developer platform, to
support a rich ecosystem of network-enabled applications.

Table 1 breaks out many of the features and benefits of the Cisco 4000 Family that create a Software Define WAN
(SDWAN) and a converged branch infrastructure.

Table 1. Cisco 4000 Family ISR General Feature Highlights

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 4 of 26

Business Requirement(s)

Feature/Solution

providing authentication credentials, and transmissions not backhauled through the data center.

● Secure boot feature performs hardware-based authentication of the bootloader software to prevent

malicious or unintended software from booting on the system.

● Code signing verifies digital signatures of executables prior to loading to prevent execution of

altered or corrupted code.

● Hardware authentication protects against hardware counterfeiting by using an on-board tamper-

proof silicon, including field replaceable modules. If authentication fails, the module is not allowed
to boot.

IT consolidation, space savings, and
improved Total Cost of Ownership (TCO)

● Single converged branch platform integrates routing, switching, virtual server, storage, security,

unified communications, WAN optimization, and performance management tools.

Business continuity and increased
resiliency

● ISR 4400 Series models (4461, 4451, and 4431 ISRs) support dual integrated power supplies

for backup. The entire ISR 4000 Family supports optional power supply capable of
delivering additional PoE power to endpoints.

● Modular network interfaces with diverse connection options for load-balancing and network

resiliency.

● Modular interfaces with online removal and insertion (OIR) for module upgrades without network

disruption.

● Cisco Unified Survivable Remote Site Telephony (SRST), which serves as a resiliency complement to

Cisco Hosted Collaboration Solution (HCS), a Cisco cloud-based UC service.

● Support for multiple, diverse access links: T1/E1, T3/E3, Serial, xDSL, Gigabit and Ten-Gigabit

Ethernet.

Lower telephony costs with VoIP and rich
media experiences

● High-performance analog/digital gateway, allowing VoIP over less expensive Session Initiation

Protocol (SIP) trunks.

● Integrated IP PBX (Cisco Unified Communications Express) and Session Border Controller (Cisco

Unified Border Element, or CUBE).

Easier manageability and support

● Single, universal software image for all features and performance-on-demand licensing flexibility.

● No additional services and support needed for compute and storage.

● Supported by Cisco and third-party management tools, with programmability and automation.

Architectural Features

Benefits/Description

Multicore processors

● High-performance multicore processors support high-speed WAN connections. The data plane uses an

emulated Flow Processor (FP) that delivers Application-Specific Integrated Circuit (ASIC)-like performance
that does not degrade as services are added.

Embedded IP Security (IPsec) VPN
hardware acceleration

● Increases scalability. When combined with an optional Cisco IOS XE Software Security license, enables WAN

link security and VPN services.

Platform Architecture

Table 2 lists the primary hardware architectural features and benefits of the Cisco 4000 Family. The routers run modular

Cisco IOS XE Software, widely deployed in the world’s most demanding networks. The software’s comprehensive

portfolio of services spans multiple technology areas, including security, WAN optimization, app and network Quality of
Service (QoS), and embedded management.

Table 2. Architectural Highlights

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 5 of 26

Architectural Features

Benefits/Description

Integrated Gigabit Ethernet ports

● The Cisco 4000 Family provides up to four built-in 10/100/1000 Ethernet ports for WAN or LAN.

● Based on the platform, some of the 10/100/1000 Ethernet ports can support Small Form-Factor Pluggable

(SFP)-based connectivity in addition to RJ-45 connections, enabling fiber or copper connectivity.

● Optionally, depending on the platform, up to 30W PoE+ can be enabled on two of the built-in front panel

Gigabit Ethernet interfaces to provide power to external devices such as fourth-generation (4G) LTE routers.

● An additional dedicated Gigabit Ethernet port is provided for device management

1

.

USB-based console access

● A mini type-B USB console port

1

supports management connectivity when traditional serial ports are not

available.

● Traditional console and auxiliary ports are also available

2

.

Optional integrated power supply
for distribution of PoE

● An optional upgrade to the internal power supply provides inline power (802.3af-compliant PoE or 802.3at-

compliant PoE+) to optional integrated switch modules.

● Redundant PoE conversion modules provide an additional layer of fault tolerance.

Optional integrated Redundant
Power Supply (RPS)

● For the ISR 4400 Series, power redundancy is available by installing an optional integrated RPS for

decreasing network downtime and protecting the network from power failures.

● Optional PoE boost mode increases total PoE capacity to up to 1000W.

Cisco Enhanced Services Module
(SM-X)

● Each service-module slot offers high data-throughput capability of up to 10 Gbps toward the system and up

to 1 Gbps to other module slots.

● Support for both single- and double-wide service modules provides flexibility in deployment options.

● An SM-X slot can be converted into a Network Interface Module (NIM) slot using an optional carrier card.

● Service modules support Online Insertion and Removal (OIR), avoiding network disruption when installing

new or replacement modules1.

Cisco Network Interface Modules
(NIMs)3

● Up to three integrated NIM slots on the Cisco 4000 Family allow for flexible configurations.

● Each NIM slot offers options of up to two 2Gbps connections. One towards the route processor and one for

direct module to module communication. The ISR 4221 has only one 1Gbps connection to the Route
Processor

● NIMs support OIR.

● Special NIMs add support Solid-State Drives (SSDs) and Hard Disk Drives (HDDs)

1

.

Cisco Integrated Services Card (ISC)
slot on motherboard

● Integrated Services Card natively supports the new Cisco High-Density Packet Voice Digital Signal Processor

Modules (PVDM4s), providing greater-density rich-media voice.

● Each Integrated Services Card slot connects to the system architecture through an up-to 2-Gbps link.

● Future modules can be hosted on the Integrated Services Card slot, improving system functions.

Flash memory support

● A single flash memory slot is available to support high-speed storage densities, upgradable to up to 32 GB.

The ISR4221 ships with a fixed 8GB Flash

● Two USB type A 2.0 ports provide capabilities for convenient storage

1

.

1

2

3

Not supported on ISR4221

ISR4221 supports shared Console & Auxiliary ports

Unified Communications (UC) and UC based NIM’s are not supported

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 6 of 26

Architectural Features

Benefits/Description

DRAM

● For the ISR 4400 Series, the default control-plane memory is 4 GB, upgradable to 16 GB to provide

additional scalability for control-plane features. The default data-plane memory is 2 GB.

● For the ISR 4300 Series, the default memory is 4 GB, upgradable to 16 GB (only 8GB for 4321) to provide

additional scalability.

● The ISR 4200 Series comes with 4GB Fixed DRAM

Operational Phase

Application

Description

Device staging and configuration

WebUI

● A GUI-based device-management tool for Cisco IOS and Cisco IOS XE Software-based

access routers. This tool simplifies routing, firewall, VPN, unified communications,
and WAN and LAN configuration through easy-to-use wizards.

Network-wide deployment,
configuration, monitoring, and
troubleshooting

Cisco Prime™
Infrastructure

● Offers comprehensive lifecycle management of wired and wireless access, campus,

and branch-office networks, rich visibility into end-user connectivity, and application
performance assurance.

● Provides wired lifecycle functions such as inventory, configuration, and image

management; automated deployment; compliance reporting; integrated best
practices; and reporting.

Staging, deployment, and changes
to configuration and image files

Cisco
Configuration
Engine

● A secure network management product that provides zero-touch image and

configuration distribution through centralized, template-based management.

Context-aware security
configuration and monitoring

Cisco Prime
Security Manager

● Management tool for configuring and managing context-aware security. The

application supports both single- and multi-device manager form factors.

● Provides the ability to write and enforce the granular context-aware security policies.

Cisco Wide Area Application
Service (WAAS) management

Cisco WAAS
Central Manager

● The management tool for the WAAS

1 4,

(WAN optimization and application
acceleration) integrated service. It provides a centralized mechanism for configuring
WAAS features, reporting, and monitoring.

Cisco IOS XE Software Embedded Management Capabilities

Feature

Description

Cisco IOS Embedded Event Manager (EEM)

● A distributed and customized approach to event detection and recovery.

● Offers the ability to monitor events and take informational, corrective, or any desired EEM action

when the monitored events occur or when a threshold is reached.

Cisco IOS XE IP Service-Level Agreements
(IP SLAs)

● Helps assure the performance of new business-critical IP applications as well as IP services that use

data and voice in an IP network.

SNMP, Remote Monitoring (RMON), syslog,
NetFlow, IP Flow Information Export (IPFix)

● Network monitoring and accounting tools.

4

Managing your Cisco ISR 4000 Family ISRs

The Cisco network management applications listed at the top of Table 3 are standalone products that can be purchased or
downloaded to manage your Cisco network devices. The applications are built specifically for the different operational

phases; select those that best fit your needs. Those management capabilities listed under the “Cisco IOS Software XE
Embedded Management” heading are directly integrated into the routers’ software operating system.

Table 3. Cisco DNA Center

It is suggested to use AppNav with an External WAAS device for the ISR4221

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 7 of 26

Technical
Specifications

Cisco 4461

Cisco 4451

Cisco 4431

Cisco 4351

Cisco 4331

Cisco 4321

Cisco 4221

Aggregate
Throughput
(Default)

1.5Gbps

1 Gbps

500 Mbps

200 Mbps

100 Mbps

50 Mbps

35Mbps

Aggregate
Throughput
(Performance
License)

3Gbps

2 Gbps

1 Gbps

400 Mbps

300 Mbps

100 Mbps

75 Mbps

Aggregate CEF
Only5
Throughput
(Boost License)

Over 7Gbps

Over 4Gbps

Over 4Gbps

Over 2Gbps

Over 2Gbps

1.5Gbps

1.2Gbps

Total onboard
WAN or LAN
10/100/1000 ports

4 4 4 3 3 2 2

Total onboard
WAN or LAN
10Gbps ports

2 - - - - - -

RJ-45-based
ports

4 4 4 3 2 2 2

SFP-based ports

4 4 4 3 2 1 1

5

Product Specifications

Table 4 lists the general product specifications for the Cisco 4000 Family routers.

Table 4. Specifications of Cisco 4000 Family Integrated Services Routers

Using onboard Gigabit Ethernet Interfaces

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 8 of 26

Technical
Specifications

Cisco 4461

Cisco 4451

Cisco 4431

Cisco 4351

Cisco 4331

Cisco 4321

Cisco 4221

Enhanced
service-module
slots

3 2 0 2 1 0 0

Doublewide
service-module
slots

2

1 (assumes no
singlewide
SM-X modules
installed)

0

1 (assumes no
singlewide SM­X modules
installed)

0 0 0

NIM slots

3 3 3 3 2 2 2

OIR (all I/O
modules)

Yes

Yes

Yes

Yes

Yes

Yes

No

Onboard ISC slot

1 1 1 1 1 1 No

Default memory
double-data-rate
3 (DDR3) error­correction-code
(ECC) DRAM
(Combined
control/services/d
ata planes)

NA

NA

NA

4 GB

4 GB

4 GB

4GB

Maximum
memory DDR3
ECC DRAM
(Combined
control/services/d
ata planes)

NA

NA

NA

16 GB

16 GB

8 GB

4GB

Default memory
DDR3 ECC DRAM
(data plane)

4 GB

2 GB

2 GB

NA

NA

NA

NA

Maximum
memory DDR3
ECC DRAM (data
plane)

4 GB

2 GB

2 GB

NA

NA

NA

NA

Default memory
DDR3 ECC DRAM
(control/services
plane)

8 GB

4 GB

4 GB

NA

NA

NA

NA

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 9 of 26

Technical
Specifications

Cisco 4461

Cisco 4451

Cisco 4431

Cisco 4351

Cisco 4331

Cisco 4321

Cisco 4221

Maximum
memory DDR3
ECC DRAM
(control/services
plane)

32 GB

16 GB

16 GB

NA

NA

NA

NA

Default flash
memory

8 GB

8 GB

8 GB

4 GB

4 GB

4 GB

8GB

Maximum flash
memory

32 GB

32 GB

32 GB

16 GB

16 GB

8 GB

8GB

External USB 2.0
slots (type A)

2 2 2 2 1 1 1

USB console port

-type B mini (up
to 115.2 kbps)

1 1 1 1 1 1 0

Serial console
port - RJ45 (up to

115.2 kbps)

1 1 1 1 1 1 1 (combo
CON/AUX port)

Serial auxiliary
port - RJ45
(up to 115.2 kbps)

1 1 1 1 1 1 1 (combo
CON/AUX port)

Power-supply
options

Internal: AC,
DC and PoE

Internal: AC,
DC and PoE

Internal: AC,
DC, and PoE

Internal: AC, DC
and PoE

Internal: AC,DC
and PoE

External: AC
and PoE

External AC
only

Redundant
power supply

Internal: AC,
DC and PoE

Internal: AC,
DC and PoE

Internal: AC,
DC, and PoE

N/A

N/A

N/A

NA

Power Specifications

AC input voltage

100 to 240
VAC
autoranging

100 to 240
VAC
autoranging

100 to 240 VAC
autoranging

100 to 240 VAC
autoranging

100 to 240 VAC
autoranging

100 to 240 VAC
autoranging

100 to 240 VAC
autoranging

DC Input Voltage

Input Voltage

Input Current

48 – 60V

12A Max

48 – 60V

12A Max

48 – 60V

12A Max

NA

NA

24 – 60V

14 - 5A

NA

NA

NA

NA

AC input
frequency

47 to 63 Hz

47 to 63 Hz

47 to 63 Hz

47 to 63 Hz

47 to 63 Hz

47 to 63 Hz

47 to 63 Hz

AC input current
range, AC power
supply
(maximum)

7.1 to 3.0A

7.1 to 3.0A

3 to 1.3A

7.1 to 3.0A

3 to 1.3A

1.5 to 0.6A

1.5 to 0.6A

AC input surge
current

60 A peak
and less than
5 Arms per
half cycle

<50 A

60 A peak and
less than 5
Arms per half
cycle

60 A peak and
less than 12
Arms per half
cycle

60 A peak and
less than 5
Arms per half
cycle

90 A peak and
less than 3
Arms per half
cycle

90 A peak and
less than 3
Arms per half
cycle

Typical power (no

158

65

48

42

36

24

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 10 of 26

Technical
Specifications

Cisco 4461

Cisco 4451

Cisco 4431

Cisco 4351

Cisco 4331

Cisco 4321

Cisco 4221

modules) (watts)

Maximum power
with AC power
supply (watts)

1000W
(no PoE)

450 (no PoE)

250 (no PoE)

430

250

125

90

Maximum power
with DC power
supply (watts)

437 (no PoE)

437 (no PoE)

437 (no PoE)

437 (no PoE)

250 (no PoE)

Maximum power
with PoE power
supply (platform
only) (watts)

1000 with
PoE
redundant

1450 with
PoE boost no
redundancy

1000 with PoE
redundant

1450 with PoE
boost no
redundancy

500 with PoE
redundant

1000 with PoE
boost no
redundancy

990

530

260

NA (No PoE
Support)

Maximum
endpoint PoE
power available
from PoE power
supply (watts)

500 W with
optional
redundancy

500 W with
optional
redundancy

250 W with
optional
redundancy

500

250

120

NA (No PoE
Support)

Maximum
endpoint PoE
power capacity
with PoE boost
(watts)

950 W no
redundancy

950 W no
redundancy

500 W no
redundancy

N/A

N/A

N/A

NA (No PoE
Support)

Sizes and Weights

Dimensions
(H x W x D)

3.5 x 17.25 x

18.5 in

88.9 x

438.15 x

469.9 mm)

3.5 x 17.25 x

18.5 in

(88.9 x

438.15 x 469.9
mm)

1.73 x 17.25 x

19.97 in

(43.9 x 438.15
x 507.2 mm)

3.5 x 17.25 x

18.5 in

(88.9 x 438.15 x

469.9 mm)

1.75 x 17.25 x

17.25 in

(44.45 x 438.15
x 438.15 mm)

1.75 x 14.55 x

11.60 in

(44.55 x 369.57
x 294.64 mm)

1.72 x 12.7 x 10"

(43.7 x 322.6 x
254 mm)

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 11 of 26

Technical
Specifications

Cisco 4461

Cisco 4451

Cisco 4431

Cisco 4351

Cisco 4331

Cisco 4321

Cisco 4221

External Power
Supply
Dimensions

(H x W x D)

N/A

N/A

N/A

N/A

N/A

2.95 x 1.18 x

6.10 in

(75 x 30 x 155
mm)

37 x 73 x 152
mm (Phihong
mfg PN:
AA90U-120A­R)

36.5 x 67 x 155
mm (Delta mfg
PN: ADP90GR
BA)

Shipping Box
Dimensions

(H x W x D)

9.75 x 22.25 x
26 in

(24.76 x 56.51
x 66.04 mm)

9.75 x 22.25 x
26 in

(24.76 x 56.51
x 66.04 mm)

7.88 x 22.25 x

28.75 in

(200.2 x 565.1 x

730.25 mm)

9.75 x 22.25 x
26 in

(24.76 x 56.51 x

66.04 mm)

7.125 x 22.75 x

22.5 in

(180.98 x 577.85
x 571.5 mm)

7.0 x 21.5 x

16.125 in

(177.8 x 546.1 x

409.6 mm)

4.13 x 18.25 x

12.94"

(104.9 x 463.6 x

328.7 mm)

Rack height

3 Rack Units
(3RU)

2 Rack Units
(2RU)

1 Rack Units
(1RU)

2 Rack Units
(2RU)

1 Rack Unit
(1RU)

1 Rack Unit
(1RU)

1 Rack Unit
(1RU)

Rack-mount
19in. (48.3 cm)
EIA

Included

Included

Included

Included

Included

Included

Optional

Rack-mount 23in.
(58.4 cm) EIA

Optional

Optional

Optional

Optional

Optional

N/A

NA

Wall-mount

No

No

Yes

No

Yes

Mounting holes
under chassis

Yes

Weight with 1,
450-WAC power
supply (no
modules)

28.8 lb (13.1
kg)

N/A

28.8 lb (13.1 kg)

N/A

N/A

NA

Weight with 1
1,000-WAC
power supply+ 1
PoE power
module (no other
modules)

30.6 lb
(13.9 kg)

N/A

29.0 lb (13.2 kg)

N/A

N/A

NA

Weight with AC
PS (no modules)

N/A

18.5 lb (8.4 kg)

N/A

13.5 lb (6.2 kg)

7.7 lb (3.5 kg) +

1.2 lb (0.66 kg)
external PS

7.1 lb (3.22kg)

Weight with DC
PS (no modules)

28.8lb (13.1kg)

28.8lb (13.1kg)

28.8lb (13.1kg)

13.5 lb (6.2 kg)

Weight with AC
PS with POE (no
modules)

N/A

18.6 lb (8.4 kg)

N/A

14.1 lb (6.4 kg)

N/A

NA

Typical weight
(fully loaded with
modules)

42.7 lb
(19.4 kg)

22.4 lb (10.2 kg)

37.7 lb (17.1 kg)

16.1 lb (7.3 kg)

9.14 lb (4.2 kg)
+ 1.2 lb
(0.66 kg)
external PS

8.11 lb (3.68kg)

Packaging

6.4 lb (2.9 kg)

5.9 lb (2.7 kg)

6.4 lb (2.9 kg)

4.6 lb (2.1 kg)

2.2 lb (1 kg)

1.28 lb (0.58kg)

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 12 of 26

Technical
Specifications

Cisco 4461

Cisco 4451

Cisco 4431

Cisco 4351

Cisco 4331

Cisco 4321

Cisco 4221

Weight

Airflow

I/O side to
bezel side

I/O side to
bezel side

I/O side to
bezel side

I/O side to
bezel side

I/O side to
bezel side

Right I/O side to
Left I/O side

I/O side to
bezel side

MTBF (Hours)

480770

480770

512970

566310

587250

593270

593270

Environmental Specifications

Operating Conditions

Temperature

32 to 104ºF
(0 to 40ºC)

32 to 104ºF
(0 to 40ºC)

32 to 104ºF
(0 to 40ºC)

32 to 104ºF

(0 to 40ºC)

32 to 104ºF

(0 to 40ºC)

32 to 104ºF

(0 to 40ºC)

32 to 104ºF

(0 to 40ºC)

Altitude

(China)

0 – 6,560 ft.

(0 – 2,000 m)

0 – 6,560 ft.

(0 – 2,000 m)

0 – 6,560 ft.

(0 – 2,000 m)

0 – 6,560 ft.

(0 – 2,000 m)

0 – 6,560 ft.

(0 – 2,000 m)

0 – 6,560 ft.

(0 – 2,000 m)

0 – 6,560 ft.

(0 – 2,000 m)

Altitude

(Rest of the
world)

0 – 10,000 ft.

(0 – 3,050 m)

0 – 10,000 ft.

(0 – 3,050 m)

0 – 10,000 ft.

(0 – 3,050 m)

0 – 10,000 ft.

(0 – 3,050 m)

0 – 10,000 ft.

(0 – 3,050 m)

0 – 10,000 ft.

(0 – 3,050 m)

0 – 10,000 ft.

(0 – 3,050 m)

Short Term
Temperature
upto 6560ft per
NEBS GR-63­CORE

NA

NA

NA

NA

32° to 131°

(0° to 55° C)

(for ISR4331-DC
version)

NA

NA

Relative humidity

5% to 85%

5% to 85%

5% to 85%

5% to 85%

5% to 85%

5% to 85%

5% to 85%

Short-term
humidity

5% to 90%,
not to exceed

0.024 kg
water/kg of
dry air

5% to 90%,
not to exceed

0.024 kg
water/kg of
dry air

5% to 90%, not
to exceed 0.024
kg water/kg of
dry air

5% to 90%, not
to exceed 0.024
kg water/kg of
dry air

5% to 90%, not
to exceed 0.024
kg water/kg of
dry air

5% to 90%, not
to exceed 0.024
kg water/kg of
dry air

5% to 90%, not
to exceed 0.024
kg water/kg of
dry air

Acoustics:

Sound pressure

(Typical/
maximum)

50.6/73.1 dBA

50.6/73.1 dBA

54.3/79.1 dBA

50.6/73.1 dBA

52.8/74.8 dBA

24.2/51.9 dBA

28.5/53 dBA

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 13 of 26

Technical
Specifications

Cisco 4461

Cisco 4451

Cisco 4431

Cisco 4351

Cisco 4331

Cisco 4321

Cisco 4221

Acoustics:

Sound power

(Typical/
maximum)

58.2/78.8
dBA

58.2/78.8 dBA

57.2/80.8 dBA

58.2/78.8 dBA

61.2/81.6 dBA

31.9/59.9 dBA

41 / 68 dBA

Nonoperating Conditions

Temperature

-40 to 158ºF
(-40 to 70ºC)

-40 to 158ºF
(-40 to 70ºC)

-40 to 158ºF
(-40 to 70ºC)

-40 to 158ºF
(-40 to 70ºC)

-40 to 158ºF
(-40 to 70ºC)

-40 to 158ºF
(-40 to 70ºC)

-40 to 158ºF
(-40 to 70ºC)

Relative humidity

5% to 95%

5% to 95%

5% to 95%

5% to 95%

5% to 95%

5% to 95%

5% to 95%

Altitude

15,584 ft
(4750m)

15,584 ft
(4750m)

15,584 ft
(4750m)

15,584 ft
(4750m)

15,584 ft
(4750m)

15,584 ft
(4750m)

15,584 ft
(4750m)

Regulatory and Compliance

Safety

UL 60950-1

CAN/CSA
C22.2 No.
60950-1

EN 60950-1

AS/NZS
60950-1

IEC 60950-1

UL 60950-1

CAN/CSA
C22.2 No.
60950-1

EN 60950-1

AS/NZS
60950-1

IEC 60950-1

UL 60950-1

CAN/CSA C22.2
No. 60950-1

EN 60950-1

AS/NZS 60950­1

IEC 60950-1

UL 60950-1

CAN/CSA C22.2
No. 60950-1

EN 60950-1

AS/NZS 60950­1

IEC 60950-1

UL 60950-1

CAN/CSA C22.2
No. 60950-1

EN 60950-1

AS/NZS 60950­1

IEC 60950-1

UL 60950-1

CAN/CSA C22.2
No. 60950-1

EN 60950-1

AS/NZS 60950­1

IEC 60950-1

UL 60950-1

CAN/CSA C22.2
No. 60950-1

EN 60950-1

AS/NZS 60950­1

IEC 60950-1

EMC

47 CFR, Part
15

ICES-003
Class A

EN55032
Class A

CISPR32
Class A

AS/NZS
CISPR 32
Class A

VCCI V-3

CNS 13438

EN 300-386

EN 61000
(Immunity)

EN 55024,
CISPR 24

KN22, KN24

47 CFR, Part 15

ICES-003 Class
A

EN55032 Class
A

CISPR32 Class
A

AS/NZS CISPR
32 Class A

VCCI V-3

CNS 13438

EN 300-386

EN 61000
(Immunity)

EN 55024,
CISPR 24

KN22, KN24

47 CFR, Part 15

ICES-003 Class
A

EN55032 Class
A

CISPR32 Class
A

AS/NZS CISPR
32 Class A

VCCI V-3

CNS 13438

EN 300-386

EN 61000
(Immunity)

EN 55024,
CISPR 24

KN22, KN24

47 CFR, Part 15

ICES-003 Class
A

EN55032 Class
A

CISPR32 Class
A

AS/NZS CISPR
32 Class A

VCCI V-3

CNS 13438

EN 300-386

EN 61000
(Immunity)

EN 55024,
CISPR 24

KN22, KN24

47 CFR, Part 15

ICES-003 Class
A

EN55032 Class
A

CISPR32 Class
A

AS/NZS CISPR
32 Class A

VCCI V-3

CNS 13438

EN 300-386

EN 61000
(Immunity)

EN 55024,
CISPR 24

KN22, KN24

EN 50121-1

EN61000-6-4

EN 50121-4

ICES-003 Class
A

EN55032 Class
A

CISPR32 Class
A

AS/NZS CISPR
32 Class A

VCCI V-3

CNS 13438

EN 300-386

EN 61000
(Immunity)

EN 55024,
CISPR 24

KN22, KN24

ICES-003 Class
A

EN55032 Class
A

CISPR32 Class
A

AS/NZS CISPR
32 Class A

VCCI V-3

CNS 13438

EN 300-386

EN 61000
(Immunity)

EN 55024,
CISPR 24

KN22, KN24

Telecom

T1

IC CS­03:2004

T1

IC CS-03:2004

TIA-968-

TIA-968-B

CS-03

ANSI T1.101

TIA-968-B

CS-03

ANSI T1.101

TIA-968-B

CS-03

ANSI T1.101

TIA-968-B

CS-03

ANSI T1.101

TIA-968-B

CS-03

ANSI T1.101

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 14 of 26

Technical
Specifications

Cisco 4461

Cisco 4451

Cisco 4431

Cisco 4351

Cisco 4331

Cisco 4321

Cisco 4221

TIA-968­B:2009

HKTA
2028:2010

HKTA
2017:2010

HKTA 2015:
2006

G.703:2001

ID0002:2007

IS6100:2004

DSPR Gray
Book:2000

DSPR
Technical
Condition:
2004

E1

AS/ACIF
S016: 2001

AS/ACIF
S038: 2001

G.703:2001

TBR 4:1995

TBR 12:1993

TBR 13:1996

RRA 2009-38

(RRL 2005-

96)

IDA TS
DLCN:2011

IDA TS ISDN
PRA:2005

IS6100: 2004

PTC
220:2008

Ethernet

IEEE 802.3

ANSA X3.263

B:2009

HKTA
2028:2010

HKTA
2017:2010

HKTA 2015:
2006

G.703:2001

ID0002:2007

IS6100:2004

DSPR Gray
Book:2000

DSPR
Technical
Condition:
2004

E1

AS/ACIF S016:
2001

AS/ACIF S038:
2001

G.703:2001

TBR 4:1995

TBR 12:1993

TBR 13:1996

RRA 2009-38

(RRL 2005-96)

IDA TS
DLCN:2011

IDA TS ISDN
PRA:2005

IS6100: 2004

PTC 220:2008

Ethernet

IEEE 802.3

ANSA X3.263

ITU-T G.823,
G.824

IEEE 802.3

RTTE Directive

Homologation
requirements
vary by country
and interface
type. For
specific country
information,
refer to the
online
approvals data
base at:

https://www.cis
cofax.com/.

ITU-T G.823,
G.824

IEEE 802.3

RTTE Directive

Homologation
requirements
vary by country
and interface
type. For
specific country
information,
refer to the
online
approvals data
base at:

https://www.cis
cofax.com/.

ITU-T G.823,
G.824

IEEE 802.3

RTTE Directive

Homologation
requirements
vary by country
and interface
type. For
specific country
information,
refer to the
online
approvals data
base at:

https://www.cis
cofax.com/.

ITU-T G.823,
G.824

IEEE 802.3

RTTE Directive

Homologation
requirements
vary by country
and interface
type. For
specific country
information,
refer to the
online
approvals data
base at:

https://www.cis
cofax.com/.

ITU-T G.823,
G.824

IEEE 802.3

RTTE Directive

Homologation
requirements
vary by country
and interface
type. For
specific country
information,
refer to the
online
approvals data
base at:

https://www.cis
cofax.com/.

Cisco IOS XE Software

Protocols

IPv4, IPv6, static routes, Routing Information Protocol Versions 1 and 2 (RIP and RIPv2), Open Shortest Path First
(OSPF), Enhanced IGRP (EIGRP), Border Gateway Protocol (BGP), BGP Router Reflector, Intermediate System-to­Intermediate System (IS-IS), Multicast Internet Group Management Protocol Version 3 (IGMPv3), Protocol Independent

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 15 of 26

Technical
Specifications

Cisco 4461

Cisco 4451

Cisco 4431

Cisco 4351

Cisco 4331

Cisco 4321

Cisco 4221

Multicast sparse mode (PIM SM), PIM Source Specific Multicast (SSM), RSVP, CDP, ERSPAN, IPSLA, Call Home, EEM,
IKE, ACL, EVC, DHCP, FR, DNS, LISP, OTV6, HSRP, RADIUS, AAA, AVC, Distance Vector Multicast Routing Protocol
(DVMRP), IPv4-to-IPv6 Multicast, MPLS, Layer 2 and Layer 3 VPN, IP sec, Layer 2 Tunneling Protocol Version 3
(L2TPv3), Bidirectional Forwarding Detection (BFD), IEEE802.1ag, and IEEE802.3ah

Encapsulations

Generic routing encapsulation (GRE), Ethernet, 802.1q VLAN, Point-to-Point Protocol (PPP), Multilink Point-to-Point
Protocol (MLPPP), Frame Relay, Multilink Frame Relay (MLFR) (FR.15 and FR.16), High-Level Data Link Control (HDLC),
Serial (RS-232, RS-449, X.21, V.35, and EIA-530), and PPP over Ethernet (PPPoE)

Traffic
management

QoS, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Hierarchical QoS,
Policy-Based Routing (PBR), Performance Routing, and NBAR.

Cryptographic
Algorithms

Encryption: DES, 3DES, AES-128 or AES-256 (in CBC and GCM modes); Authentication: RSA (748/1024/2048 bit),
ECDSA (256/384 bit); Integrity: MD5, SHA, SHA-256, SHA-384, SHA-512

6

Services plane: Enabling the Branch-in-a-Box

All Cisco ISR 4000 routers contain processing cores built-in as standard to allow full-featured services to run on-board.
This includes the full-featured Cisco WAAS engine that provides application acceleration and highly responsive virtual
desktop experience. The technology is known as Cisco Service Containers and it uses a standard hypervisor to allow x64
based applications to run.

The 4000 series routers can be fitted with Solid State Drives (SSD) and server cards for local storage and computing
capability. The Cisco UCS-E server cards are available with 8-core Intel Xeon processors with up to 48GB of high speed
DDR3 memory and three drives built in offering RAID 0, 1 and 5. This immense amount of compute power can eliminate
the need for any dedicated servers at branch sites. UCS-E cards can be configured and managed using VMware vCenter
and pooled with Data Center compute resources.

Supported only on the 4451 for Bandwidths <100Mbps

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 16 of 26

Software Subscription through Cisco DNA Licensing

The ISR4000 series supports software based subscription using Cisco DNA based licensing. Three Cisco DNA based
software subscription licenses are available for the WAN portfolio: Cisco DNA Essentials, Cisco DNA Advantage and Cisco
ONE Advantage allowing customers to have a single unified solution that spans across the ISR4000 series routers and its
ASR1000 and ISR1000 counterparts

The license tiers are structured to support the growth in business needs enabling the customer to move from basic
functionality using the Cisco DNA Essentials to full-functionality with the Cisco DNA Advantage and expanding that to
include WAN Optimization and Analytics on the Cisco ONE Advantage. This provides complete flexibility to move the
same license across end-points based on growing network and security requirements, growth in bandwidth based on user
and application growth at the sites as also the ability to change the management of the platform from on-prem to cloud

or vice-versa.

Cisco DNA Licenses are supported for all ISR4000 platforms using the Cisco DNA Center, the controller and analytics
platform at the heart of Cisco’s intent-based network. For more information on the Cisco DNA Center and supported
platforms, please refer to https://www.cisco.com/c/en/us/products/cloud-systems-management/dna-center/index.html

Enterprise NFV on ISR4000

Built to reduce costs without compromising vital network services, the UCS E-Series router-integrated branch blade
servers provide support for a Virtualization-ready and Application-centric platform that can be seamlessly integrated on
the ISR4000 platform. Customers can now install virtualized applications on the ISR4000 routers through the Cisco®
Enterprise NFV Infrastructure Software (NFVIS) – a virtualization infrastructure that integrates full VM lifecycle
management, monitoring, device programmability, and service chaining in a single, installable package. For more
information on Enterprise NFV and NFVIS, please refer to the link at https://www.cisco.com/c/en/us/solutions/enterprise-

networks/enterprise-network-functions-virtualization-nfv/index.html#~stickynav=2

Support for DC Power

ISR4000 platforms support both DC and AC Power Supplies as options. Specifically, the ISR 4331 has two separate
product SKU’s – the ISR4331/K9 and the ISR4331-DC/K9 which support AC and DC Power respectively, The ISR4400 can
independently support an AC or a DC Power supply on the same chassis. While the 4300 supports between 24V and
60Vdc, the 4400 supports between 48V and 60Vdc. The 4331 provides for upto 250W of power rating while the 4400
provides upto 437W. It is important to note that when DC Power supplies are installed on the router, PoE based modules
may not be used.

More details about the DC Power supplies and its capabilities can be found at the below url

https://www.cisco.com/c/en/us/td/docs/routers/access/4400/hardware/installation/guide4400­4300/C4400_isr/FRUs_Modules.html#49534

Product Performance and Scalability

The Cisco 4000 Family is built on a multicore CPU architecture. It runs modular Cisco IOS XE Software, which allows the
platform to use to full advantage a distributed multicore architecture. The architecture of the Cisco 4000 separates
control- and data-plane operations and integrates an industry-first services plane. This design delivers full-featured
integrated services up to Layer 7 at high performance with the ability to deliver application-aware network services while
maintaining a stable platform and a high level of performance during periods of heavy network traffic.

The ISR 4000 consists of 3 series of Routers – the ISR 4400 series, the 4300 series and ISR 4200 series whose performance
levels maybe represented by the chart below

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 17 of 26

Common for the new 4000 Family is that all platforms come with fixed maximum performance levels. One fixed base
performance level is delivered as factory default with an optional performance-on-demand license to increase the base
forwarding throughput. This scenario enables deployment in high-speed WAN environments through performance-on­demand licensing to double or, for one of the platforms, triple the router capacity without any hardware upgrades.

All 4000 platforms have their fixed performance levels set well within actual capacity, with the result that performance
does not necessarily degrade when a service is added to the configuration. This setup provides a deterministic
performance, eliminating a network administrator’s guesswork when planning for new services.

For a more detailed document on ISR 4000 Series Performance and Platform Scalability, please refer to the Performance
Whitepaper at https://www.cisco.com/c/en/us/products/collateral/routers/4000-series-integrated-services-routers-

isr/white-paper-c11-734550.html

ISR 4000 Boost License

In addition to the Performance License, customers may now order a Booster (or Boost) License that allows the router to
perform between five or more times than that of the throughput with Performance License. In contrast to the
deterministic performance described above, in the Booster mode, the router does not provide the deterministic level of
performance as provided when operating with the default license or with the Performance license.

The Boost License provides a license tier above the Performance License allowing customers to completely remove the
ISR4000’s performance limiters. This will make the ISR 4000 platforms perform at entirely new performance levels,
allowing for 4+ Gbps of IP Routing (CEF) performance on the 4400 series ISRs. For deployments using encryption, IPSec
throughput with AES 256 increases to 250Mbps on the lowest platform up to 10Gbps on the ISR4461.

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 18 of 26

ISR 4000 Interfaces and Modules Support

The Cisco 4000 Series Integrated Services Routers (ISRs) are modular routers with LAN and WAN connectivity. The
routers provide for Network Interface Module (NIM) slots and Enhanced service module (SM-X) slots offering a rich set of
Modules, such as LAN, WAN and Wireless Interfaces plus a range of Compute engines for embedded services

For the complete list of supported modules on the ISR4000 Series refer to the Interfaces and Modules sheet at

https://www.cisco.com/c/en/us/products/routers/4000-series-integrated-services-routers-isr/relevant-interfaces-and­modules.html.

Software defined WAN with the ISR4000 Series

The ISR 4000 series is optimized for the Software Defined WAN (SD-WAN). For enterprises this means that business
critical applications run faster, with more reliability and reduced Operational Expenditure (OpEx). The SDWAN achieves
this by making all branches and Data Centers have the ability to monitor, control, move and report on streams of
application data such as specific web (HTTP) traffic for example. The ISR 4000 series has deep packet inspection
capability and can accurately identify and control thousands of different applications including custom in-house
enterprise applications.

The entire SD-WAN implementation on the ISR4000 is maybe implemented by managing the end device either from the
Cloud or On-Premise through ascending levels of throughput based licenses. All licenses that support SD-WAN, whether
On-Premise or on Cloud are all enabled using Subscription Licenses. These subscription licenses enable all customers to
seamlessly transition between On-Premise and Cloud management as needed. The license tiers are structured to support
the growth in business needs through simple subscriptions that help simplify the journey to intent-based networking for
the WAN.

The SDWAN subscriptions are aligned across three subscription licenses of Cisco DNA Essentials, DNA Advantage and
Cisco DNA Premier, each expanding functionally. The Cisco DNA Essentials covers all types of connectivity & router life
cycle management, support for Network & application visibility coupled with basic premise and transport security. The
Cisco DNA Advantage provides for Advanced WAN topologies, Application aware policies supported by enhanced
network security. The Cisco DNA Premier provides for Cloud connectivity with unlimited segmentation, Advanced
Application optimization & Network Analytics, secured by advanced threat protection

For more information on Cisco SDWAN please refer to https://www.cisco.com/c/en/us/products/software/one-wan-

subscription/index.html

The benefits are immense;

1. Business-critical applications no longer have to contend each other or with traffic that should be served on best

effort basis.

2. The Enterprise network becomes more reliable because multiple paths can be used.

3. Costs are greatly reduced because dual MPLS links can be replaced with a mix of MPLS and Internet.

4. The time to bring up new remote sites is dramatically reduced because the SD-WAN supports rapidly deployed

DSL and 3G/4G LTE connections as easily as MPLS.

5. Security is assured across these connections using a zero-touch secure VPN technology used by governments and

finance organizations worldwide.

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 19 of 26

From a platform perspective, the ISR 4000 series has

1. Separated control and data planes for Denial of Service (DoS) attack prevention and Intrusion Prevention System

(IPS) and firewall capability built-in.

2. SaaS applications can have content locally cached. The caching is automatic and peers directly with Akamai

technology to obtain intelligence.

3. Application performance speed is greatly increased using in-built application acceleration technology that can

locally cache at a byte-level.

Cisco Security Solutions for the ISR4000 Series

Cisco WAN MACsec,

Cisco routers support a wide-range of ever enhancing security features on the ISR4000 routers. Cisco WAN MACsec is
supported on the ISR4000 series routers using the NIM-2GE-CU-SFP module. WAN MACsec provides a line-rate network
encryption solution over Layer 2 Ethernet transport services and can be leveraged outside campus networks, whether it
be over Metro Ethernet transport or Data Center Interconnect (DCI) links. MACsec also secures WAN connections that are
leveraging Ethernet as the link-layer media. For more information refer to the whitepaper at

https://www.cisco.com/c/dam/en/us/td/docs/solutions/CVD/Aug2016/WP-WAN-MACsecDep-Aug2016.pdf

Cisco Encrypted Threat Analytics

The rapid rise in encrypted traffic is changing the threat landscape. As more businesses become digital, a significant
number of services and applications are using encryption as the primary method of securing information. Encrypted
Threat Analytics (ETA) is a functionality that allows customers to do cryptographic assessments and identify malware
communications in encrypted traffic through passive monitoring. Using information about events that occur inside of a
flow or intraflow telemetry to identify malware communication in encrypted traffic means Encrypted Traffic Analytics can
maintain the integrity of the encrypted flow without the need for bulk decryption. For more information and platform
support refer to https://www.cisco.com/c/dam/en/us/solutions/collateral/enterprise-networks/enterprise-network-

security/nb-09-encrytd-traf-anlytcs-wp-cte-en.pdf

Cisco Snort IPS and Cisco Umbrella Branch

Cisco® Snort® IPS for Cisco 4000 Series Integrated Services Routers (ISRs) offers a lightweight threat defense solution that
uses industry-recognized Snort open-source Intrusion Prevention System (IPS) technology. It is perfect for customers who
are looking for a cost-effective solution that provides one box for both advanced routing capabilities and integrated
threat defense security to help comply with regulatory requirements.

Cisco Umbrella Branch is a cloud-delivered security service for the Cisco Integrated Services Router (ISR). It provides the
first layer of defense against threats at branch offices. And it offers the simplest, fastest way to protect every device on
your branch network. You gain visibility and enforcement at the DNS layer, so you can block requests to malicious
domains and IPs before a connection is ever made.

When enabling MACsec, you will need to procure the Security and HSEC licenses to stay within the limits of federal export
control regulations. When customers wish to enable ETA, the Security (SEC) license needs to be enabled. Enabling Snort
needs a Security (SEC) license and a signature subscription license. Enabling Cisco Umbrella Branch needs an Umbrella
Branch license and a subscription license.

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 20 of 26

7

Reducing Operational Costs using Cisco ISR

Support for Data Modelling

Enterprises and Service Providers (SP’s) wish to drive down the operational cost (opex) of their networks and increase the
agility and speed with which they deliver new services furthered by investments in Software Defined Networking (SDN)
and Network Function Virtualization (NFV). Cisco routers provide support for Netconf and YANG data-modelling with
increasing model coverage in successive releases

Software Maintenance Upgrades (SMU)

The ISR4000 routers now support Software Maintenance Upgrades (SMU)7. The Software Maintenance Upgrade (SMU) is
a package that can be installed on a system to provide a patch fix or security resolution to a released image. An SMU
package is provided on a per release and per component basis and is specific to the platform. An SMU is an independent
and self-sufficient package and it does not have any prerequisites or dependencies. Please refer to

https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/config-mgmt/configuration/xe-16-6/config-mgmt-xe-16-6-book/cm­smu.html for additional details

Network Plug and Play

Network Plug and Play helps automate the onboarding of new devices on your network by applying configuration
settings without manual intervention. With the ease of a centrally managed controller, it reduces the time a new device
takes to join your network and become functional. For more information on Plug and Play (PnP), please refer to

https://www.cisco.com/c/en/us/td/docs/solutions/Enterprise/Plug-and-Play/release/notes/pnp-connect-release­notes.html

Cisco IOS Software Licensing and Packaging

Universal IOS XE and XE-SDWAN Image

A single Cisco IOS XE Universal image encompassing all functions is delivered with the platform. Advanced features can
be enabled by simply activating a software license on the Universal image. Technology packages and feature licenses,
enabled through right-to-use licenses, simplify software delivery and decrease the operational costs of deploying new
features.

Beginning IOS version 16.9.1, SDWAN support is provided for IOS image on the ISR4000 series router. The SDWAN
features are provisioned through a separate image, the XE-SDWAN image. While the Universal IOS-XE image provides
for routing features, the XE-SDWAN image provides support for OnPrem or Cloud based Software Defined WAN
solutions. Unified Communications for XE-SDWAN will be supported in upcoming releases

When ordering an ISR router, a customer may choose either of IOS-XE or XE-SDWAN image. With IOS-XE image,
customers may opt for subscription based licensing or for perpetual licensing. With XE-SDWAN image, customers may
order only subscription licensing. Refer to Cisco DNA Ordering Guide at

https://www.cisco.com/c/dam/en/us/products/collateral/cloud-systems-management/dna-center/nb-09-dna-1-x­ordering-guide-cte-en-latest.pdf.

Supported from IOS-XE16.6.1 for all ISR4000 and ASR1000 series routers

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 21 of 26

8

9

Four major technology licenses are available on the Cisco 4000 Family and use the IOS-XE image; these licenses can be
activated through the Cisco software activation process identified at https://www.cisco.com/go/sa. The following licenses
are available:

●

IP Base: This technology package is available as default.

●

Application Experience (APPX): This license includes data and application performance features.

●

Unified Communications (UC)8: This license includes voice features.

●

Security (SEC) or Security with No Payload Encryption (SEC-NPE): This license includes features for securing
network infrastructure.

The Cisco 4000 Series has a performance-on-demand license to increase the base forwarding throughput with no
hardware changes. Also present is the High Security (HSEC) license, which removes the curtailment enforced by the U.S.
government export restrictions on the encrypted tunnel count and encrypted throughput. The HSECK9 license is a
separately required license for a feature to have full crypto functionality. Without the HSECK9 license, only 1000 secure
tunnels and 2509 Mbps of crypto bandwidth would be available.

For additional information and details about Cisco IOS Software licensing and packaging on the Cisco 4000 Family, please
visit https://www.cisco.com/c/en/us/td/docs/routers/access/4400/software/configuration/guide/isr4400swcfg.pdf.

IOS-XE provides support for both perpetual and subscription licensing. Subscription Licensing with support for Cisco DNA
Center is offered using the 3-Licenses of Cisco DNA Essentials, Cisco DNA Advantage and Cisco DNA Premier in-line with
similar licenses that provide support on the XE-SDWAN side. Please refer to Cisco DNA Ordering Gide at:

https://www.cisco.com/c/dam/en/us/products/collateral/cloud-systems-management/dna-center/nb-09-dna-1-x­ordering-guide-cte-en-latest.pdf.

Software Defined Networks maybe provisioned through three major licenses on the Cisco 4000 Family; these licenses can
be activated through the Cisco software activation process identified at https://www.cisco.com/go/sa using the Cisco
DNA Center or through the vManage management portal. The XE-SDWAN image provides for its own licensing schema
through the Cisco DNA Licensing

The following licenses are available:

●

Cisco DNA Essentials covers all types of connectivity & router life cycle management, support for Network &
application visibility coupled with basic premise and transport security

●

Cisco DNA Advantage provides for Advanced WAN topologies, Application aware policies supported by enhanced
network security

●

The Cisco DNA Premier provides for Cloud connectivity with unlimited segmentation, Advanced Application

optimization & Network Analytics, secured by advanced threat protection
For more information please refer to https://www.cisco.com/c/dam/en/us/products/collateral/software/dna-software-

routing-subscription.pdf

Unified Communications is not supported by ISR4221

The change to 250Mbps was achieved in the IOS-XE version 16.8.1 pursuant to revised Federal regulations

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 22 of 26

Bundles

Features

Application Experience with Voice (AXV)

AX + Voice

Voice with Security (VSEC)

Voice + Security

Application Experience (AX)

IP Base + Security + advanced networking protocols: L2TPv3, BFD, MPLS, VRF, VXLAN10
(Bandwidth <100Mbps)

Application Experience: PfRv3, WAAS with AppNav, NBAR2, AVC, IP SLA

Hybrid Cloud Connectivity: LISP, OTV (for Bandwidth <100Mbps), VPLS, EoMPLS

Intelligent Web Caching: Akamai Connect

Voice (V)

IP Base + Unified Communications: CME, SRST, CUBE

Security (SEC)

IP Base + Advanced Security: Zone Based Firewall, IPSec VPN, EZVPN, DMVPN, FlexVPN

10

Smart Software Licensing Support for IOS-XE

IOS-XE supports Smart Licensing beginning with image version 16.6.1 and Device Led Conversion with image version

16.9.1. Smart Software licensing is a simplified license management system that delivers visibility into customer license
ownership and consumption. Licenses are managed through a central Cisco Smart License cloud portal (CSSM). The cloud
portal maintains an account of what the customer has bought and what they are using, thus alerting the customer if they
go out of compliance. Customers can determine what licenses they own and how they are being used. Customers benefit
from being able to pool available licenses thus providing for a more straightforward license usage across like-platforms,
thus decreasing operational costs.

While customers can purchase existing SKU’s, they must mandatorily create a Smart Account when implementing Smart
Licensing. One or more Virtual Accounts maybe created under the Smart Account to enable the organization to logically
segregate the purchased licenses. Device Led Conversion (DLC) allows the customer to convert all existing PAK and RTU
licenses on the router into a Smart License. For more information, refer to the link at

https://www.cisco.com/c/en/us/products/software/smart-accounts/software-licensing.html.

Cisco ISR 4000 Bundles

Cisco ISR 4000 is available is several attractive bundles. The AX bundles integrate Cisco Wide Area Application Services
(WAAS), Security (SEC), and Data (DATA) licenses into a single bundle that is simple to order, configure, and deploy. For
customers who are also interested in voice along with all of these features, AXV presents an attractive option. See Table 6
for details.

Table 5. Cisco ISR 4000 Feature Bundles

Note: ISR4221/K9 does not support UC (Voice), hence no V, VSEC, AXV bundles for ISR4221/K9

More information on ISR AX bundles is available at https://www.cisco.com/go/ax.

A pay-as-you-grow licensing model lets you increase the performance level for the platforms from the base level to a
higher level. So you can purchase at an attractive entry-level price point and increase the performance level as your
business demand grows. Table 7 describes the performance licenses.

Supported only on the ISR4451

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 23 of 26

Platform

Performance-on-Demand License

Features

ISR4461

FL-4460-PERF-K9

Increases the performance from base performance 1.5 Gbps to 3 Gbps

ISR4451

FL-44-PERF-K9

Increases the performance from base performance 1 Gbps to 2 Gbps

ISR4431

FL-44-PERF-K9

Increases the performance from base performance 500 Mbps to 1 Gbps

ISR4351

FL-4350-PERF-K9

Increases the performance from base performance 200 Mbps to 400 Mbps

ISR4331

FL-4330-PERF-K9

Increases the performance from base performance 100 Mbps to 300 Mbps

ISR4321

FL-4320-PERF-K9

Increases the performance from base performance 50 Mbps to 100 Mbps

ISR4221

FL-4220-PERF-K9

Increases the performance from base performance 35 Mbps to 75 Mbps

Part number

Description

FL-4220-BOOST-K9 (=)

Booster Performance License for 4220 Series Router

FL-4320-BOOST-K9 (=)

Booster Performance License for 4320 Series Router

FL-4330-BOOST-K9 (=)

Booster Performance License for 4330 Series Router

FL-4350-BOOST-K9 (=)

Booster Performance License for 4350 Series Router

FL-4430-BOOST-K9 (=)

Booster Performance License for 4430 Series Router

FL-44-BOOST-K9 (=)

Booster Performance License for 4450 Series Router

FL-4460-BOOST-K9 (=)

Booster Performance License for 4460 Series Router

Table 6. Cisco ISR 4000 Performance Licenses

Table 7. Cisco ISR 4000 Booster (boost) Performance Licenses

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 24 of 26

Product Name

Product Description

ISR4461/K9

Cisco ISR 4461 with 4 onboard GE, 3 NIM slots, 1 ISC slot, 3 SM slots, 8 GB Flash Memory default, 2 GB DRAM default
(data plane), 4 GB DRAM default (control plane)

ISR4451-X/K9

ISR 4451 with 4 onboard GE, 3 NIM slots, 1 ISC slot, 2 SM slots, 8 GB Flash Memory default, 2 GB DRAM default (data
plane), 4 GB DRAM default (control plane)

ISR4431/K9

ISR 4431 with 4 onboard GE, 3 NIM slots, 1 ISC slot, 8GB Flash Memory default, 2 GB DRAM default (data plane), 4 GB
DRAM default (control plane)

ISR4351/K9

ISR 4351 with 3 onboard GE, 3 NIM slots, 1 ISC slot, 2 SM slots, 4 GB Flash Memory default, 4 GB DRAM default

ISR4331/K9

ISR 4331 with 3 onboard GE, 2 NIM slots, 1 ISC slot, 1 SM slots, 4 GB Flash Memory default, 4 GB DRAM default

ISR4321/K9

ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default

ISR4221/K9

ISR 4221 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 8 GB Flash Memory default, 4 GB DRAM default

Ordering Information

The Cisco ISR 4000 Family is orderable and shipping. To place an order, refer to Table 8 below and visit the Cisco Ordering

Home Page.

Table 8. Cisco ISR 4000 Series Ordering Information

For additional product numbers, including the Cisco 4000 Family bundle offerings, please contact your local Cisco account
representative. To place an order, visit the Cisco Ordering Home Page. To download software, visit the Cisco Software

Center.

Integrated Services Router Migration Options

The Cisco ISR 4000 Family is included in the standard Cisco Technology Migration Program (TMP). Refer to

https://www.cisco.com/go/tmp and contact your local Cisco account representative for program details.

Warranty Information

The Cisco ISR 4000 Series Integrated Services Routers have a 90-day limited liability warranty.

Cisco and Partner Services for the Branch Office

Services from Cisco and our certified partners help you transform the branch-office experience and accelerate business
innovation and growth. We have the expertise to create a clear, replicable, optimized branch-office footprint across
technologies. Planning and design services align technology with your business goals and can increase deployment
efficiency. Technical services help you improve operational efficiency, save money, and mitigate risk. Optimization
services help you continuously improve performance and succeed with new technologies. For more information, please
visit https://www.cisco.com/go/services.

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 25 of 26

New or revised topic

Described In

Date

Change 4461 from 2RU to 3RU

Sizing Section

December 4, 2018

Added 4461 and SD-WAN

November 13, 2018

Added support for Cisco SD-WAN with IOS XE SD-WAN, 16.9.1 software release.
Added Encrypted Traffic Analytics as well as Boost Performance Licensing support
information.

Ordering Information

August 8, 2018
Added new ISR 4000 Series model, the ISR 4221. Updated all related modules,

memory, licenses and bundles support related to the ISR 4221.

Features and Benefits

August 23, 2017

Printed in USAs C78-732542-21 12/18

Cisco SMARTnet® technical support for the Cisco ISR 4000 Family is available on a one-time or annual contract basis.
Support options range from help-desk assistance to proactive, onsite consultation. All support contracts include:

●

Major Cisco IOS Software updates for protocol, security, bandwidth, and feature improvements

●

Full access rights to Cisco.com technical libraries for technical assistance, electronic commerce, and product

information

●

Access 24 hours a day to the industry’s largest dedicated technical support staff

Cisco Capital

Flexible payment solutions to help you achieve your objectives

Cisco Capital makes it easier to get the right technology to achieve your objectives, enable business transformation and
help you stay competitive. We can help you reduce the total cost of ownership, conserve capital, and accelerate growth.
In more than 100 countries, our flexible payment solutions can help you acquire hardware, software, services and
complementary third-party equipment in easy, predictable payments. Learn more.

For More Information

For more information about the Cisco ISR 4000 Family, visit https://www.cisco.com/go/ISR4K or contact your local Cisco
account representative.

Document History

© 2018 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 26 of 26
