Cisco IOS XE Intelligent Services, IOS XE Configuration Manual

Cisco IOS XE Intelligent Services Gateway Configuration
Release 2
Americas Headquarters
Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 USA http://www.cisco.com Tel: 408 526-4000
Fax: 408 527-0883
Guide
THE SPECIFICATIONS AND INFORMATION REGA RDING THE P RODUCTS IN TH IS MA NUAL ARE SUBJECT TO CHAN GE W ITHOUT NOT ICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILIT Y FOR THEIR APPLICAT ION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED W ARRANTY FO R THE ACCOMPA NYING PRODUCT ARE SET FO RTH IN THE IN FORMAT ION P ACKET TH AT S
HIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE
OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY. The Cisco implementation of TCP header compres
domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California. NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DO CUMENT FILES AND SOFTWARE OF THESE SUPPL IERS ARE PROVIDED “AS IS” WITH
AL
L FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WA RRANTIES, EXPRESSE D OR IMPLIED, INCLUDING, WITHOUT
LIM
ITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRI NGEMENT OR ARISING FROM A COURSE OF
DEALING, USAGE, OR TRADE PRACTICE. IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING,
W
ITHOUT LIMITATION, LOST P ROFITS OR LO SS OR DAMAGE TO DATA ARISIN G OUT OF THE USE OR INABILI TY TO USE THIS MA NUAL, EVEN I F CISCO
OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SU CH DAMA GES. CCDE, CCENT, CCSI, Cisco Eos, Cisco HealthPresence, Cisco IronPort, the Cisco logo, Cisco Nurse Connect, Cisco Pulse, Cisco SensorBase, Cisco StackPower,
Cis
co StadiumVision, Cisco TelePresence, Cisco Unified Computing System, Cisco WebEx, DCE, Flip Channels, Flip for Goo d, Fl Flip Video, Flip Video (Design), I nstant Broad band, and Welco me to the Human Network are trademarks; Changing the Way We Work, Live, Play, and Learn, Cisco Capital, Cis
co Capital (Design), Cisco:Financed (Stylized), Cisco Store, Flip Gift Card, and One Million Acts of G AsyncOS, Bringing the Meeting To You, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, CCVP, Cisco, the Cisco Certified Internetwork Expert logo, Cis
co IOS, Cisco Lumin, Cisco Nexus, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Collaboration Without Limitation, Co
ntinuum, EtherFast, EtherSwitch, Event Center, Explorer, Follow Me Browsing, GainMaker, iLYNX, IOS, iPhone, IronPort, the IronPort logo, Laser Link, LightStream, Linksys, MeetingPlace, MeetingPlace Chime Sound, MGX, Networkers, Networking Academy, PCNow, PIX, PowerKEY, PowerPanels, PowerTV, PowerTV (Design ), PowerVu, Prisma, ProConnect, ROSA, SenderBase, SMARTnet , Spectr um Expert, StackWise, WebEx, and t he WebEx logo are registered trade marks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or website are the propert between Cisco and any other company. (0910R)
Any Internet Protocol (IP) addresses u sed in this d ocument are not i document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.
Cisco IOS XE Intelligent Services Gateway Configuration Guide
© 2009 Cisco Systems, Inc. All rights reserved.
sion is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public
ip Mino, Flipshare (Design), Flip Ultra,
reen are service marks; and Access Registrar, Aironet, AllTouch,
y of their respective owners. The use of the word partner does not imply a partnershi p relati onshi p
ntended to be actual addresses. Any examples, command display output, and figures included in the
About Cisco IOS XE Software Documentation
Last Updated: December 1, 2009
This document describes the objectives, audience, conventions, and organization used in Cisco IOS XE software documentation. Also included are resources for obtaining technical assistance, additional documentation, and other information from Cisco. This document is organized into the following sections:
Documentation Objectives, page i
Audience, page i
Documentation Conventions, page ii
Documentation Organization, page iii
Additional Resources and Documentation Feedback, page x
Documentation Objectives
Cisco IOS XE documentation describe the tasks and commands available to configure and maintain Cisco networking devices.
Audience
The Cisco IOS XE documentation set is intended for users who conf igure and maintain Cisco netw orking devices (such as routers and switches) but who may not be familiar with the configuration and maintenance tasks, the relationship among tasks, or the Cisco IOS commands necessary to perform particular tasks. The Cisco IOS XE documentation set is also intended for those users experienced with Cisco IOS XE software who need to know about new features, new configuration options, and new software characteristics in the current Cisco IOS XE release.
i
Documentation Conventions
Documentation Conventions
In Cisco IOS XE documentation, the term router may be used to refer to various Cisco products; for example, routers, access servers, and switches. These and other networking devices that support Cisco IOS XE software are shown interchangeably in examples and are used only for illustrative purposes. An example that shows one product does not necessarily mean that other products are not supported.
This section contains the following topics:
Typographic Conventions, page ii
Command Syntax Conventions, page ii
Software Conventions, page iii
Reader Alert Conventions, page iii
Typographic Conventions
Cisco IOS XE documentation uses the following typographic conventions:
About Cisco IOS XE Software Documentation
Convention Description
^ or Ctrl Both the ^ symbol and Ctrl represent the Control (Ctrl) key on a keyboard. For
example, the key combination ^D or Ctrl-D means that you hold down the Control key while you press the D key. (Keys are indicated in capital letters but are not case sensitive.)
string A string is a nonquoted set of characters shown in italics. For example, when
setting a Simple Network Management Protocol (SNMP) community string to public, do not use quotation marks around the string; otherwise, the string will include the quotation marks.
Command Syntax Conventions
Cisco IOS XE documentation uses the following command syntax conventions:
Convention Description
bold Bold text indicates commands and keywords that you enter as shown.
italic Italic text indicates arguments for which you supply values. [x] Square brackets enclose an optional keyword or argument. ... An ellipsis (three consecutive nonbolded periods without spaces) after a syntax
element indicates that the element can be repeated.
| A vertical line, called a pipe, indicates a choice within a set of keywords
or arguments.
[x | y] Square brackets enclosing keywords or arguments separated by a pipe indicate an
optional choice.
{x | y} Braces enclosing keywords or arguments separated by a pipe indicate a
required choice.
[x {y | z}] Braces and a pipe within square brackets indicate a required choice within an
optional element.
ii
About Cisco IOS XE Software Documentation
Software Conventions
Cisco IOS XE software uses the following conventions:
Convention Description
Courier font
Bold Courier font
< > Angle brackets enclose text that is not displayed, such as a password. Angle
! An exclamation point at the beginning of a line indicates that the text that follows
[ ] Square brackets enclose default responses to system prompt s.
Reader Alert Conventions
Documentation Organization
Courier font is used for information that is displayed on a PC or terminal screen. Bold Courier font indicates text that the user must enter.
brackets also are used in contexts in which the italic font style is not supported; for example, ASCII text.
is a comment, not a line of code. An exclamation point is also displayed by the Cisco IOS XE software for certain processes.
Cisco IOS XE documentation uses the following conventions for reader alerts:
Caution Means reader be careful. In this situation, you might do something that could result in equipment
damage or loss of data.
Note Means reader take note. Notes contain helpful suggestions or references to material not covered in the
manual.
Timesaver Means the described action saves time. You can save time by performing the action described in the
paragraph.
Documentation Organization
This section describes the Cisco IOS XE documentation set, ho w it i s or gan ized, and ho w to access it on Cisco.com. Listed are configuration guides, command references, and supplementary references and resources that comprise the documentation set.
Cisco IOS XE Documentation Set, page iv
Cisco IOS XE Documentation on Cisco.com, page iv
Configuration Guides, Command References, and Supplementary Resources, page v
iii
Documentation Organization
Cisco IOS XE Documentation Set
The Cisco IOS XE documentation set consists of the following:
Release notes and caveats provide information about platform, technology, and feature support for
a release and describe severi ty 1 (catastrophic), seve rity 2 (severe), and se verity 3 (moderat e) defects in released Cisco IOS XE software. Review release notes before other documents to learn whethe r updates have been made to a feature.
Sets of configuration guides and command references organized by technology and published for
each standard Cisco IOS XE release.
Configuration guides—Compilations of documents that provide conceptual and task-oriented descriptions of Cisco IOS XE features.
Command references—Alphabe tical compilations of command pages that provide detailed information about the commands used in the Cisco IOS XE features and the processes that comprise the related configuration guides. For each technology, there is a single command reference that covers all Cisco IOS XE releases and that is updated at each standard release.
Command reference book for debug commands.
Lists of all the commands in a specific release and all commands that are new, modified, removed,
or replaced in the release.
About Cisco IOS XE Software Documentation
Reference book for system messages for all Cisco IOS XE releases.
Cisco IOS XE Documentation on Cisco.com
The following sections describe the documentation organization and how to access various document types.
Use Cisco Feature Navigator to find information about Cisco IOS XE software image support. T o access Cisco Feature Navigator, go to http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
New Features List
The New Features List for each release provides a list of all features in the release with hyperlinks to the feature guides in which they are documented.
Configuration Guides
Configuration guides are provided by technology and release and comprise a set of individual feature guides relevant to the release and technology.
Command References
Command reference books describe Cisco IOS XE commands that are supported in many different software releases and on many different platforms. The books are organized by technology. For information about all Cisco IOS XE commands, use the Command Lookup Tool at
http://tools.cisco.com/Support/CLILookup or the Cisco IOS Master Command List, All Releases, at http://www.cisco.com/en/US/docs/ios/mcl/allreleasemcl/all_book.html.
Cisco IOS XE Supplementary Documents and Resources
Supplementary documents and resources are listed in Table 2 on page x.
iv
About Cisco IOS XE Software Documentation
Documentation Organization
Configuration Guides, Command References, and Supplementary Resources
Ta ble 1 lists, in alphabetical order, Cisco IOS XE software configuration guides and
command references, including brief descriptions of the contents of the documents. The command references contain commands for both Cisco IOS software and Cisco IOS XE software, for all releases. The command references support many different software releases and platforms. Your Cisco IOS XE software release or platform may not support all these technologies.
Table 2 lists documents and resources that supplement the Cisco IOS XE software configuration guides
and command references. These supplementary resources include release notes and caveats; master command lists; new, modified, removed, and replaced command lists; system messages; and the debug command reference.
For additional information about configuring and operating specific networking devices, and to access Cisco IOS documentation, go to the Product/Technologies Support area of Cisco.com at the following location:
http://www.cisco.com/go/techdocs
Table 1 Cisco IOS XE Configuration Guides and Command References
Configuration Guide and Command Reference Titles Features/Protocols/Technologies
Cisco ASR 1000 Series Aggregation Services Routers
SIP and SPA Software Configuration Guide
Configuration and troubleshooting of SPA interface processors (SIPs) and shared port adapters (SP As) t hat are supported on t he Cisco ASR 1000 Series Router.
Cisco ASR 1000 Series Aggregation Services Routers
Software Configuration Guide
Cisco IOS XE Access Node Control Protocol
Configuration Guide
Cisco IOS Access Node Control Protocol
Overview of software functionality that is specific to the Cisco ASR 1000 Series Aggregation Services Routers.
Communication protocol between digital subscriber line access multiplexers (DSLAMs) and a broadband remote access server (BRAS).
Command Reference
Cisco IOS XE Asynchronous Transfer Mode
LAN ATM, multiprotocol over ATM (MPoA), and WAN ATM.
Configuration Guide
Cisco IOS Asynchronous Transfer Mode
Command Reference
Cisco IOS XE Broadband Access Aggr egation and DSL
PPP over Ethernet (PPPoE).
Configuration Guide
Cisco IOS Broadband Access Aggregation and DSL
Command Reference
Cisco IOS XE Carrier Ethernet Configuration Guide
Cisco IOS Carrier Ethernet Command Reference
IEEE 802.3ad Link Bundling; Link Aggregation Control Protocol (LACP) support for Eth ernet and Gigabit Ethernet links and EtherChannel bundles; LACP support for stateful switchover (SSO), in service software upgrade (ISSU), Cisco nonstop forwarding (NSF), and nonstop routing (NSR) on Gigabit EtherChannel bundles; and IEEE 802.3ad Link Aggregation MIB.
Cisco IOS XE Configuration Fundamentals
Configuration Guide
Cisco IOS Configuration Fundamentals
Autoinstall, Setup, Cisco IOS command- line inter face (CLI), Cisco IOS file system (IFS), Cisco IOS web browser user interface (UI), basic file transfer services, and file management.
Command Reference
v
About Cisco IOS XE Software Documentation
Documentation Organization
Table 1 Cisco IOS XE Configuration Guides and Command References (continued)
Configuration Guide and Command Reference Titles Features/Protocols/Technologies
Cisco IOS XE DECnet Configuration Guide
Cisco IOS DECnet Command Reference
Cisco IOS XE Dial Technologies Configuration Guide
Cisco IOS Dial Technologies Command Reference
Cisco IOS XE High Availability Configuration Guide
Cisco IOS High Availability Command Reference
Cisco IOS XE Intelligent Services Gateway
Configuration Guide
Cisco IOS Intelligent Services Gateway
Command Reference
Cisco IOS XE Interface and Hardware Component
Configuration Guide
Cisco IOS Interface and Hardware Component
Command Reference
Cisco IOS XE IP Addressing Services
Configuration Guide
Cisco IOS IP Addressing Services
Command Reference
Cisco IOS XE IP Application Services
Configuration Guide
Cisco IOS IP Application Services
Command Reference
Cisco IOS XE IP Multicast Configuration Guide
Cisco IOS IP Multicast Command Reference
Cisco IOS XE IP Routing: BFD Configuration Guide Bidirectional forwarding detection (BFD).
Cisco IOS XE IP Routing: BGP Configuration Guide
Cisco IOS IP Routing: BGP Command Reference
Cisco IOS XE IP Routing: EIGRP
Configuration Guide
DECnet protocol.
Asynchronous communications, dial backup, dial er technolog y, Multilink PPP (MLP), PPP, and virtual private dialup network (VPDN).
A variety of high availability (HA) features and technologies that are available for different network segments (from enterprise access to service provider core) to facilitate creation of end-to-end highly av ailable networks. Cisco IOS HA features and technologies can be categorized in three key areas: system-level resilienc y, network-level resiliency , an d embedded management for resiliency.
Subscriber identification, service and policy determination, session creation, session policy enforcement, session life-cycle management, accounting for access and service usage, and session state monitoring.
LAN interfaces, logical interfaces, serial interfaces, virtual interfaces, and interface configuration.
IP addressing, Address Resolution Protocol (ARP), Network Address Translation (NAT), Domain Name System (DNS), Dynamic Host Configuration Protocol (DHCP), and Next Hop Address Resolution Protocol (NHRP).
Enhanced Object Tracking (EOT), Gateway Load Balancing Protocol (GLBP), Hot Standby Router Protocol (HSRP), IP Services, TCP, Web Cache Communication Protocol (WCCP), User Datagram Protocol (UDP), and V irtual Router Redu ndancy Protocol (VRRP).
Protocol Independent Multicast (PIM) sparse mode (PIM-SM), bidirectional PIM (bidir-PIM), Source Specific Multicast (SSM), Multicast Source Discovery Protocol (MSDP), Internet Group Management Protocol (IGMP), and Multicast VPN (MVPN).
Border Gateway Protocol (BGP), multi protocol B GP, multiprotocol BGP extensions for IP multicast.
Enhanced Interior Gateway Routing Protocol (EIGRP).
Cisco IOS IP Routing: EIGRP Command Reference
Cisco IOS XE IP Routing: ISIS Configuration Guide
Cisco IOS IP Routing: ISIS Command Reference
vi
Intermediate System-to-Intermediate System (IS-IS).
About Cisco IOS XE Software Documentation
Table 1 Cisco IOS XE Configuration Guides and Command References (continued)
Configuration Guide and Command Reference Titles Features/Protocols/Technologies
Cisco IOS XE IP Routing: ODR Configuration Guide
Cisco IOS IP Routing: ODR Command Reference
Cisco IOS XE IP Routing: OSPF Configuration Guide
Cisco IOS IP Routing: OSPF Command Reference
Cisco IOS XE IP Routing: Protocol-Independent
Configuration Guide
Cisco IOS IP Routing: Protocol-Independent
Command Reference
Cisco IOS XE IP Routing: RIP Configuration Guide
Cisco IOS IP Routing: RIP Command Reference
Cisco IOS XE IP SLAs Configuration Guide
Cisco IOS IP SLAs Command Reference
Cisco IOS XE IP Switching Configuration Guide
Cisco IOS IP Switching Command Reference
Cisco IOS XE IPv6 Configuration Guide
Cisco IOS IPv6 Command Reference
Cisco IOS XE ISO CLNS Configuration Guide
Cisco IOS ISO CLNS Command Reference
Cisco IOS XE LAN Switching Configuration Guide
Cisco IOS LAN Switching Command Reference
Cisco IOS XE Multiprotocol Label Switching
Configuration Guide
Cisco IOS Multiprotocol Label Switching
Command Reference
Cisco IOS XE NetFlow Configuration Guide
Cisco IOS NetFlow Command Reference
Cisco IOS XE Network Management
Configuration Guide
Cisco IOS Network Management Command Reference
Cisco IOS XE Novell IPX Configuration Guide
On-Demand Routing (ODR).
Open Shortest Path First (OSPF).
IP routing protocol-independent features and commands. Generic policy-based routing (PBR) features and commands are included.
Routing Information Protocol (RIP).
Cisco IOS IP Service Level Agreements (IP SLAs).
Cisco Express Forwarding.
For a list of IPv6 features, protocols, and technolog ies, go to the IPv6 “Start Here” document at the following URL:
http://www.cisco.com/en/US/docs/ios/ios_xe/ipv6/configuratio n/guide/ip6-roadmap_xe.html
ISO Connectionless Network Service (CLNS).
VLANs and multilayer switching (MLS).
MPLS Label Distribution Protocol (LDP), MPLS Layer 2 VPNs, MPLS Layer 3 VPNs, MPLS Traffic Engineering (TE), and MPLS Embedded Management (EM) and MIBs.
Network traffic data analysis, aggregation caches, and export features.
Basic system management, system monitoring and logging, Cisco IOS Scripting with Tool Control Language (Tcl), Cisco networking services (CNS), Embedded Event Manager (EEM), Embedded Syslog Manager (ESM), HTTP, Remote Monitoring (RMON), and SNMP.
Novell Internetwork Packet Exchange (IPX) protocol.
Documentation Organization
Cisco IOS Novell IPX Command Reference
vii
About Cisco IOS XE Software Documentation
Documentation Organization
Table 1 Cisco IOS XE Configuration Guides and Command References (continued)
Configuration Guide and Command Reference Titles Features/Protocols/Technologies
Cisco IOS XE Quality of Service Solutions
Configuration Guide
Cisco IOS Quality of Service Solutions
Command Reference
Cisco IOS Security Command Reference Access control lists (ACLs); authentication, authorization, and
Cisco IOS XE Security Configuration Guide: Secure
Connectivity
Cisco IOS XE Security Configuration Guide: Securing
the Data Plane
Cisco IOS XE Security Configuration Guide: Securing
User Services
Cisco IOS XE Service Advertisement Framework
Configuration Guide
Class-based weighted fair queueing (CBWFQ), low latency queueing (LLQ), Modular Quality of Service (QoS) Command-Line Interface (CLI) (MQC), Network-Based Application Recognition (NBAR), priority queueing, Mult ilink PPP (MLP) for QoS, header compression, Resource Reservation Protocol (RSVP), weighted fair queueing (WFQ ), and weighted random early detection (WRED).
accounting (AAA); firewalls; IP security and encryption; neighbor router authentication; network access security; public key infrastructure (PKI); RADIUS; and TACACS+.
Internet Key Exchange (IKE) for IPsec VPNs; security for VPNs with IPsec; VPN availability features (reverse route injection, IPsec preferred peer, and real-time resolution for the IPsec tunnel peer); IPsec data plane features; IPsec management plane features; Public Key Infrastructure (PKI); Dynamic Multipoint VPN (DMVPN); Easy VPN; and Cisco Group Encrypted Transport VPN (GET VPN).
Access Control Lists (ACLs); Firewalls: Context-Based Access Control (CBAC) and Zone-Based Firew all; Cisco IOS Intrusio n Prevention System (IPS); Flexible Packet Matching; Unicast Reverse Path Forwarding (uRPF); Threat Information Distribution Protocol (TIDP) and TMS.
AAA (includes Network Admission Control [NAC]); Security Server Protocols (RADIUS and TACACS+); Secure Shell (SSH); Secure Access for Networking Devices (includes Autosecure and Role-Based CLI access); Lawful Intercept.
Cisco Service Advertisement Framework.
Cisco IOS Service Advertisement Framework
Command Reference
Cisco IOS XE VPDN Configuration Guide
Cisco IOS VPDN Command Reference
Cisco IOS XE Wide-Area Networking
Configuration Guide
Cisco IOS Wide-Area Networking
Command Reference
viii
Multihop by Dialed Number Identification Service (DNIS), timer and retry enhancements for L2TP and Layer 2 Forwarding (L2F), RADIUS Attribute 82 (tunnel assignment ID), shell-based authentication of VPDN users, and tunnel authentication via RADIUS on tunnel terminator.
Frame Relay; L2VPN Pseudowire Redundancy; and Media-Independent PPP and Multilink PPP.
About Cisco IOS XE Software Documentation
Table 1 Cisco IOS XE Configuration Guides and Command References (continued)
Configuration Guide and Command Reference Titles Features/Protocols/Technologies
Cisco Unified Border Element (Enterprise)
Configuration Guide
Cisco IOS Voice Command Reference
Cisco Unified Border Element (SP Edition)
Configuration Guide: Distributed Model
Cisco Unified Border Element (SP Edition)
Command Reference: Distributed Model
Cisco Unified Border Element (SP Edition)
Configuration Guide: Unified Model
Cisco Unified Border Element (SP Edition)
Command Reference: Unified Model
The Cisco Unified Border Element (Enterprise) on the Cisco ASR 1000 brings a scalable op tion for ente rprise customers. Running as a process on the Cisco ASR 1000 and utilizing the high-speed RTP packet processing path, the Cisco Unified Border Element (Enterprise) is used as an IP-to-IP gateway by enterprises and commercial cust omers to interconnect SIP and H.323 voice and video networks. The Cisco UBE (Enterprise) provides a network-to-network demarcation interface for signaling interworking, media interworking, address and port translations, billing, security, quality of service (QoS), and bandwidth management.
The Cisco Unified Border Element (SP Edit ion) is a sessi on border controller (SBC) that is VoIP-enabled and deployed at the edge of networks. For Cisco IOS XE Release 2.3 and earlier releases, Cisco Unified Border Element (SP Edition) is supported only in the distributed mode. Operating in the distributed mode, the SBC is a toolkit of functions that can be used to deploy and manage VoIP services, such as signaling interworking, network hiding, security, and quality of service.
The Cisco Unified Border Element (SP Edit ion) is a highly scalable, carrier-grade session border controller (SBC) that is designed for service providers and that is generally deployed at the border of the enterprise or SP networks to enable the easy deployment and management of VoIP services. Cisco Unified Border Element (SP Edition) is integrated into Cisco routing platforms and can use a large number of router functions to provide a very feature-rich and intelligent SBC application . Formerly known as Integrated Session Border Controller, Cisco Unified Border Element (SP Edition) provides a network-to-network demarcation interface for signaling interworking, media interworking, address and port translati ons, billing, security, quality of service, call admission control, and bandwidth manageme nt.
For Cisco IOS XE Release 2.4 and later releases, Cisco Unified Border Element (SP Edition) can operate in two modes or deployment models: unified and distributed. The configuration guide documents the features in the unified mode.
Documentation Organization
Table 2 lists documents and resources that supplement the Cisco IOS XE software configuration guides
and command references.
ix
About Cisco IOS XE Software Documentation
Additional Resources and Documentation Feedback
Table 2 Cisco IOS XE Software Supplementary Documents and Resources
Document Title or Resource Description
Cisco IOS Master Command List, All Releases Alphabetical list of all the commands documented in all
Cisco IOS XE software releases.
Cisco IOS Debug Command Reference Alphabetical list of debug commands including brief
descriptions of use, command syntax, and usage guidelines.
Cisco IOS XE system messages List of Cisco IOS XE system messages and descriptions. System
messages may indicate problems with your system, may be informational only, or may help diagnose problems with communications lines, internal hardware, or the system software.
Release notes and caveats Information about new and changed features, system
requirements, and other useful information about specific software releases; information about defects in specific Cisco IOS XE software releases.
MIBs Files used for network monitoring. To locate and download
MIBs for selected platforms, Cisco IOS XE software releases, and feature sets, use Cisco MIB Locator at the following URL:
http://www.cisco.com/go/mibs
RFCs Standards documents maintained by the Internet Engineering
T ask Force (IETF) that Ci sco IOS XE documentation references where applicable. The full text of referenced RFCs may be obtained at the following URL:
http://www.rfc-editor.org/
Additional Resources and Documentation Feedback
What’s New in Cisco Product Documentation is updated monthly and describes all new and revised
Cisco technical documentation. The What’s New in Cisco Product Documentation publication also provides information about obtaining the following resources:
Technical documentation
Cisco product security overview
Product alerts and field notices
Technical assistance
Cisco IOS XE software technical documentation includes embedd ed feedback forms where y ou can rate documents and provide suggestions for improvement. Your feedback helps us improve our documentation.
x
About Cisco IOS XE Software Documentation
CCDE, CCENT, CCSI, Cisco Eos, Cisco HealthPresence, Cisco IronPort, the Cisco logo, Cisco Nurse Connect, Cisco Pulse, Cisco SensorBase, Cisco StackPower, Cisco StadiumV ision, Cisco TelePresence, Cisco Unified Computing System, Cisco W e bEx, D CE, Flip Chann els, Fli p for Good, Flip Mino, Flipshare (Design), Flip Ultra, Fli p Video, Flip V i deo (Design), Instant Broadband, and Welcome to the Human Network are trademarks; Changing the Way We Work, Live, Play, and Learn, Cisco Capit al, C isco Capit al (D esign), Cis co:Finan ced (Styl ized), Cisco Stor e, Flip Gift Card, and One Million Acts of Green are service marks; and Access Registrar, Aironet, AllTouch, AsyncOS, Bringing the Meeting T o You, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, CCVP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Lumin, Cisco Nexus, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Collaboration Without Limitation, Cont inuum, E th erFast, EtherSwitch, Event Center, Explor er, Follow Me Browsi ng, Gain Mak er, iLYNX, IOS, iPhone, IronPort, the IronPort logo, Laser Link, LightStream, Linksys, MeetingPlace, MeetingPlace Chime Sound, MGX, Networkers, Networking Academy, PCNow, PIX, PowerKEY, PowerPanels, PowerTV, PowerTV (Design), PowerVu, Prisma, ProConnect, ROSA, SenderBase, SMARTnet, Spectrum Expert, StackWise, WebEx, and the WebEx logo are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0910R)
Any Internet Protocol (IP) addresses an d ph one nu mbers u sed in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network topology diagrams, and other fig ures included in the document are sho wn for illust rati v e purp oses only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional and coincidental.
© 2009 Cisco Systems, Inc. All rights reserved.
Additional Resources and Documentation Feedback
xi
Additional Resources and Documentation Feedback
About Cisco IOS XE Software Documentation
xii
Using the Command-Line Interface in Cisco IOS XE Software
Last Updated: December 1, 2009
This document provides basic information about the command-line interface (CLI) in Cisco IOS XE software and how you can use some of the CLI features. This document contains the follo wing sections:
Initially Configuring a Device, page i
Using the CLI, page ii
Saving Changes to a Configuration, page xii
Additional Information, page xii
For more information about using the CLI, see “Part 1: Using the Cisco IOS Command-Line Interface (CLI)” of the Cisco IOS XE Configuration Fundamentals Configuration Guide.
For information about the software documentation set, see the “About Cisco IOS XE Software
Documentation” document.
Initially Configuring a Device
Initially configuring a device varies by platform. For information about performing an initial configuration, see the hardware installation documentation that is provided with the orig inal packaging of the product or go to the Product Support area of Cisco.com at http://www.cisco.com/go/techdocs.
After you have performed the initial configuration and connected the device to your network, you can configure the device b y using the console port or a remote access method, such as Telnet or Secure Shell (SSH), to access the CLI or by using the configuration method provided on the device, such as Security Device Manager.
i
Using the CLI
Changing the Default Settings for a Console or AUX Port
There are only two settings that you can change on a console port or an AUX port:
Change the port speed with the config-register 0x command. Changing the port speed is not
Change the behavior of the port; for example, by adding a password or changing the timeout value.
Note The AUX port on the Route Processor (RP) installed in a Cisco ASR 1000 series router does not serve
any useful customer purpose and should be accessed only under the advisement of a customer support representative.
Using the CLI
This section describes the following topics:
Understanding Command Modes, page ii
Using the Interactive Help Feature, page v
Using the Command-Line Interface in Cisco IOS XE Software
recommended. The well-known default speed is 9600.
Understanding Command Syntax, page vi
Understanding Enable and Enable Secret Passwords, page viii
Using the Command History Feature, page viii
Abbreviating Commands, page ix
Using Aliases for CLI Commands, page ix
Using the no and default Forms of Commands, page x
Using the debug Command, page x
Filtering Output Using Output Modifiers, page xi
Understanding CLI Error Messages, page xi
Understanding Command Modes
The CLI command mode structure is hierarchical, and each mode supports a se t of specific commands. This section describes the most common of the many modes that exist.
Ta bl e 1 lists common command modes with associated CLI prompts, access and exit methods, and a
brief description of how each mode is used.
ii
Using the Command-Line Interface in Cisco IOS XE Software
Table 1 CLI Command Modes
Using the CLI
Command
Access Method Prompt Exit Method Mode Usage
Mode
User EXEC Log in.
Privileged EXEC
From user EXEC mode, issue the enable command.
Global configuration
From privileged EXEC mode, issue the
configure terminal
command.
Interface configuration
From global configuration mode, issue the interface command.
Line configuration
From global configuration mode, issue the line vty or line console command.
Router>
Router#
Router(config)#
Router(config-if)#
Router(config-line)#
Issue the logout or exit command.
Issue the disable command or the exit command to return to user EXEC mode.
Issue the exit command or the end command to return to privileged EXEC mode.
Issue the exit command to return to global configuration mode or the end command to return to privileged EXEC mode.
Issue the exit command to return to global configuration mode or the end command to return to privileged EXEC mode.
Change terminal settings.
Perform basic tests.
Display device status.
Issue show and debug
commands.
Copy images to the
device.
Reload the device.
Manage device
configuration files.
Manage device file
systems.
Configure the device.
Configure individual interfaces.
Configure individual terminal lines.
iii
Using the CLI
Table 1 CLI Command Modes (continued)
Using the Command-Line Interface in Cisco IOS XE Software
Command
Access Method Prompt Exit Method Mode Usage
Mode
ROM monitor From privileged EXEC
mode, issue the reload command. Press the Break key during the first 60 seconds while the system is booting.
Diagnostic The router boots or
enters diagnostic mode in the following scenarios. When a Cisco IOS XE process or processes fail, in most scenarios the router will reload.
A user-configured
access policy was configured using the transport-map command, which directed the user into diagnostic mode.
The router was
accessed using an RP auxiliary port.
A break signal
(Ctrl-C, Ctrl-Shift-6, or the send break
command) was entered, and the router was configured to enter diagnostic mode when the break signal was received.
rommon # >
The # symbol represents the line number and increments at each prompt.
Router(diag)#
Issue the continue command.
If a Cisco IOS XE process failure is the reason for entering diagnostic mode, the failure must be resolved and the router must be rebooted to exit diagnostic mode.
If the router is in diagnostic mode because of a transport-map configuration, access the router through another port or use a method that is configured to connect to the Cisco IOS XE CLI.
If the RP auxiliary port was used to access the router, use another port for access. Accessing the router through the auxiliary port is not useful for customer purposes.
Run as the default
operating mode when a valid image cannot be loaded.
Access the fall-back
procedure for loading an image when the device lacks a valid image and cannot be booted.
Perform password
recovery when a CTRL-Break sequence is issued within 60 seconds of a power-on or reload event.
Inspect various states on
the router, including the Cisco IOS XE state.
Replace or roll back the
configuration.
Provide methods of
restarting the Cisco IOS XE software or other processes.
Reboot hardware, such as
the entire router, an RP, an ESP , a SIP, a SP A, or other hardware components.
Transfer files into or off
of the router using remote access methods such as FTP, TFTP, and SCP.
iv
Using the Command-Line Interface in Cisco IOS XE Software
EXEC commands are not saved when the soft war e reboots. Co mmands that you i ssue in a configuration mode can be saved to the startup configuration. If you save the running configuration to the startup configuration, these commands will execute when the software is rebooted. Global configuration mode is the highest level of configuration mode. From global configuration mode, you can enter a variety of other configuration modes, including prot ocol-speci fic modes.
ROM monitor mode is a separate mode that is used when the software cannot load properly. If a valid software image is not found when the software boots or if the configuration file is corrupted at startup, the software might enter ROM monitor mode. Use the question symbol (?) to view the commands that you can use while the device is in ROM monitor mode.
rommon 1 > ? alias set and display aliases command boot boot up an external process confreg configuration register utility cont continue executing a downloaded image context display the context of a loaded image cookie display contents of cookie PROM in hex . . . rommon 2 >
Using the CLI
The following example sho ws ho w the command prompt changes to indicate a different command mode:
Router> enable Router# configure terminal Router(config)# interface ethernet 1/1 Router(config-if)# ethernet Router(config-line)# exit Router(config)# end Router#
Note A keyboard alternative to the end command is Ctrl-Z.
Using the Interactive Help Feature
The CLI includes an interactive Help feature. Table 2 describes how to use the Help feature.
Table 2 CLI Interactive Help Commands
Command Purpose
help Provides a brief description of the Help feature in any command mode. ? Lists all commands available for a particular command mode.
partial command? Provides a list of commands that begin with the character string (no
partial command<Tab> Completes a partial command name (no space between the command
command ? Lists the keywords, arguments, or both associated with the command
command keyword ? Lists the arguments that are associated with the keyword (space between
space between the command and the question mark).
and <Tab>).
(space between the command and the question mark).
the keyword and the question mark).
v
Using the CLI
Using the Command-Line Interface in Cisco IOS XE Software
The following examples show how to use the help commands:
help
Router> help Help may be requested at any point in a comma nd by entering a question mark '?'. If nothing
matches, the help list wil l be empty and you must backup unti l ent ering a '?' shows the available options.
Two styles of help are provided:
1. Full help is available wh en you are re ady to enter a c ommand argume nt (e.g. 'show ? ') and describes each possible argument.
2. Partial help is provided when an abbreviated argum ent is entered and you w ant to know what arguments match the input (e.g. 'show pr?'.)
?
Router# ? Exec commands: access-enable Create a temporary access-List entry access-profile Apply user-profile to interface access-template Create a temporary access-List entry alps ALPS exec commands archive manage archive files <snip>
partial command?
Router(config)# zo? zone zone-pair
partial command<Tab>
Router(config)# we<Tab> webvpn
command ?
Router(config-if)# pppoe ? enable Enable pppoe max-sessions Maximum PPPOE sessions
command keyword ?
Router(config-if)# pppoe enable ? group attach a BBA group <cr>
Understanding Command Syntax
Command syntax is the format in which a command should be entered in the CLI. Commands include the name of the command, keywords, and arguments. Keywords are alphanumeric strings that are used literally. Arguments are placeholders for values that a user must supply. Keywords and arguments may be required or optional.
Specific conventions convey information about syntax and command elements. Table 3 des cribes these conventions.
vi
Using the Command-Line Interface in Cisco IOS XE Software
Table 3 CLI Syntax Conventions
Symbol/Text Function Notes
< > (angle brackets) Indicate that the option is an
A.B.C.D. Indicates that you must enter a
WORD (all capital letters) Indicates that you must enter
LINE (all capital letters) Indicates that you must enter
<cr> (carriage return) Indicates the e n d o f t h e l i s t of
argument.
dotted decimal IP address.
one word.
more than one word.
available keywords and arguments, and also indicates when keywords and arguments are optional. When <cr> is the only option, you have reached the end of the branch or the end of the command if the command has only one branch.
Using the CLI
Sometimes arguments are disp laye d without angle brackets.
Angle brackets (< >) are not always used to indicate that an IP address is an argument.
Angle brackets (< >) are not always used to indicate that a WORD is an argument.
Angle brackets (< >) are not always used to indicate that a LINE is an argument.
The following examples show syntax conventions:
Router(config)# ethernet cfm domain ? WORD domain name
Router(config)# ethernet cfm domain dname ? level
Router(config)# ethernet cfm domain dname level ? <0-7> maintenance level number
Router(config)# ethernet cfm domain dname level 7 ? <cr>
Router(config)# snmp-server file-transfer access-group 10 ? protocol protocol options <cr>
Router(config)# logging host ? Hostname or A.B.C.D IP address of the syslog server ipv6 Configure IPv6 syslog server
vii
Using the Command-Line Interface in Cisco IOS XE Software
Using the CLI
Understanding Enable and Enable Secret Passwords
Some privileged EXEC commands are used for actions that impact the system, and it is recommended that you set a password for these commands to pre vent unauthorized use. Two types of passwords, enable (not encrypted) and enable secret (encrypted), can be set. The following commands set these passwords and are issued in global configuration mo de:
enable password
enable secret password
Using an enable secret password is recommended because it is encrypted and more secure than the enable password. When you use an enable secret password, text is encrypted (unreadable) before it is written to the config.text f ile. When you use an enable password, the text is written as entered (readable) to the config.text file.
Each type of password is case sensitiv e, can contai n from 1 to 25 uppercase and lo wercase alphanumeric characters, and can start with a number. Spaces are also valid password characters; for example, “two words” is a valid password. Leading spaces are ignored, but trailing spaces are recognized.
Note Both password commands have numeric keyw ords that are single inte ger v alues. If you choose a numb er
for the first character of your password follo wed by a space, the system will read the number as if it were the numeric keyword and not as part of your password.
When both passwords are set, the enable secret password takes precedence over the enable password. To remove a password, use the no form of the commands: no enable password or
no enable secret password. For more information about password recovery procedures for Cisco products, see
http://www.cisco.com/en/US/products/sw/iosswrel/ps1831/ products_tech_note09186a00801746e6.shtml.
Using the Command History Feature
The command history feature saves the commands that you enter during a session in a comman d history buffer. The default number of commands saved is 10, b ut the nu mber is configurable within the range of 0 to 256. This command history feature is particularly useful for recalling long or complex commands.
To change the number of commands saved in the history buffer for a terminal session, issue the terminal history size command:
Router# terminal history size num
A command history buffer is also available in line configuration mode with the same default and configuration options. To set the command history buffer size for a terminal session in line configuration mode, issue the history command:
Router(config-line)# history [size num]
viii
Using the Command-Line Interface in Cisco IOS XE Software
To recall commands from the history buffer, use the following methods:
Press Ctrl-P or the Up Arrow key—Recalls commands beginning with the most recent command.
Repeat the key sequence to recall successively older commands.
Press Ctrl-N or the Down Arrow key—Recalls the most recent commands in the history buf fer aft er
they have been recalled using Ctrl-P or the Up Arrow key. Repeat the key sequence to recall successively more recent commands.
Note The arrow keys function only on ANSI-compatible terminals such as the VT100.
Issue the show history command in user EXEC or privileged EXEC mode—Lists the most recent
commands that you entered. The number of commands that are displayed is determined by the setting of the terminal history size and history commands.
The command history feature is enabled by default. To disable this feature for a terminal session, issue the terminal no history command in user EXEC or privileged EXEC mode or the no history command in line configuration mode.
Using the CLI
Abbreviating Commands
Typing a complete command name is not always required for the command to execute. The CLI recognizes an abbreviated command when the abbreviation contains enough characters to uniquely identify the command. For example, the show version command can be abbreviated as sh ver. It cannot be abbreviated as s ver because s could mean show, set, or systat. The sh v abbreviation also is not valid because the show command has vrrp as a keyword in addition to ve rsion.
Using Aliases for CLI Commands
To save time and the repetition of entering the same command multiple times, you can use a command alias. An alias can be configured to do anything that can be done at the command line, but an alias cannot move between modes, type in passwords, or perform any interactive functions.
Ta ble 4 shows the default command aliases.
Table 4 Default Command Aliases
Command Alias Original Command
h help lo logout p ping s show u or un undebug w where
ix
Using the CLI
To create a command alias, issue the alias command in global configuration mode. The syntax of the command is alias mode command-alias original-command. Following are some examples:
Router(config)# alias exec prt partition—privileged EXEC mode
Router(config)# alias configure sb source-bridge—global configuration mode
Router(config)# alias interface rl rate-limit—interface configuration mode
To view both default and user-created aliases, issue the show alias command. For more information about the alias command, see
http://www.cisco.com/en/US/docs/ios/fundamentals/command/reference/cf_book.html.
Using the no and default Forms of Commands
Most configuration commands have a no form that is used to reset a command to its default value or disable a feature or function. For example, the ip routing command is enabled b y default. To disable this command, you would issue the no ip routing command. To re-enable IP routing, you would issue the ip routing command.
Configuration commands may also have a default form, which returns the command settings to their default values. For commands that are disabled b y def ault, u sing the default form has the same ef fect as using the no form of the command. For commands that are enabled by default and have default settings, the default form enables the command and returns the settings to their default values.
The no form is documented in the command pages of command references. The default form is generally documented in the command pages only when the default form performs a different function than the plain and no forms of the command. To see what default commands are available on your system, enter default ? in the appropriate command mode.
Using the Command-Line Interface in Cisco IOS XE Software
Using the debug Command
A debug command produces extensive output that helps you troubleshoot problems in your network. These commands are available for many features and functions within Cisco IOS XE software. Some debug commands are debug all, debug aaa accounting, and debug mpls packets. To use debug commands during a Telnet session with a device, you must first enter the terminal monitor command. To turn off debugging completely, you must enter the undebug all command.
For more information about debug commands, see the Cisco IOS Debug Command Reference at
http://www.cisco.com/en/US/docs/ios/debug/command/reference/db_book.html.
Caution Debugging is a high priority and high CPU utilization process that can render your dev ice unusable. Use
debug commands only to troubleshoot specific problems. The best times to run debugging are during periods of low network traffic and when few users are interacting with the network. Debugging during these periods decreases the likelihood that the debug command processing overhead will af fect network performance or user access or response times.
x
Using the Command-Line Interface in Cisco IOS XE Software
Filtering Output Using Output Modifiers
Many commands produce lengthy output that may use several screens to display. You can use output modifiers to filter this output to show only the information that you want to see.
The following three output modifiers are available:
begin regular-expression—Displays the first line in which a match of the regular e xpression is found
and all lines that follow.
include regular-expression—Displays all lines in which a match of the regular expression is found.
exclude regular-expression—Displays all lines except those in which a match of the regular
expression is found.
To use one of these output modifiers, type the command followed by the pipe symbol (|), the modifier, and the regular expression that you want to search for or filter. A regular expression is a case-sensitive alphanumeric pattern. It can be a single character or number, a phrase, or a more complex string.
The following example illustrates how to filter output of the show interface command to display only lines that include the expression “protocol.”
Router# show interface | include protocol
Using the CLI
FastEthernet0/0 is up, line protocol is up Serial4/0 is up, line protocol is up Serial4/1 is up, line protocol is up Serial4/2 is administratively down, line protocol is down Serial4/3 is administratively down, line protocol is down
Understanding CLI Error Messages
You may encounter some error messages while using the CLI. Table 5 shows the common CLI error messages.
Table 5 Common CLI Error Messages
Error Message Meaning How to Get Help
% Ambiguous command: “show con”
% Incomplete command. You did not enter all the
% Inv alid input detected at “^” marker.
You did not enter enough characters for the command to be recognized.
keywords or values required by the command.
You entered the command incorrectly. The caret (^) marks the point of the error.
Reenter the command followed by a space and a question mark (?). The keywords that you are allowed to enter for the command appear.
Reenter the command followed by a space and a question mark (?). The keywords that you are allowed to enter for the command appear.
Enter a question mark (?) to display all the commands that are available in this command mode. The keywords that you are allowed to enter for the command appear.
For more system error messages, see the System Messages for Cisco IOS XE document.
xi
Saving Changes to a Configuration
Saving Changes to a Configuration
T o sa ve changes that you made to the confi guration of a de vice, you must i ssue the copy running-conf ig startup-config command or the copy system:running-config nvram:startup-config comma nd. When
you issue these commands, the configuration changes that you made are saved to the startup configuration and saved when the software reloads or power to the device is turned off or interrupted. The following example shows the syntax of the copy running-config startup-config command:
Router# copy running-config startup-config Destination filename [startup-config]?
You press Enter to accept the startup-config filename (the default), or type a n ew f ilename and then press Enter to accept that name. The following outpu t is displayed indicating that the conf igurat ion was sa v ed:
Building configuration... [OK] Router#
On most platforms, the configuration is sa ved to NVRAM. On platforms with a Class A flash file system, the configuration is saved to the location specified by the CONFIG_FILE environment variable. The CONFIG_FILE variable defaults to NVRAM.
Using the Command-Line Interface in Cisco IOS XE Software
Additional Information
“Part 1: Using the Cisco IOS Command-Line Interface (CLI)” of the Cisco IOS XE Configuration
Fundamentals Configuration Guide
http://www.cisco.com/en/US/docs/ios/ios_xe/fundamentals/configuration/guide/2_xe/cf_xe_book. html
or “Using Cisco IOS XE Software” chapter of the Cisco ASR 1000 Series Aggregation Services Routers
Software Configuration Guide
http://www.cisco.com/en/US/docs/routers/asr1000/configuration/guide/chassis/Using_CLI.html
Cisco Product Support Resources
http://www.cisco.com/go/techdocs
Support area on Cisco.com (also search for documentation by task or product)
http://www.cisco.com/en/US/support/index.html
Software Download Center (downloads; tools; licensing, registration, advisory, and general
information) (requires Cisco.com user ID and password)
http://www.cisco.com/kobayashi/sw-center/
Error Message Decoder, a tool to help you research and resolve error messages for
Cisco IOS XE software
http://www.cisco.com/pcgi-bin/Support/Errordecoder/index.cgi
xii
Using the Command-Line Interface in Cisco IOS XE Software
Command Lookup Tool, a tool to help you find detailed descriptions of Cisco IOS XE commands
(requires Cisco.com user ID and password)
http://tools.cisco.com/Support/CLILookup
Output Interpreter, a troubleshooting tool that analyzes command output of supported
show commands
https://www.cisco.com/pcgi-bin/Support/OutputInterpreter/home.pl\
CCDE, CCENT, CCSI, Cisco Eos, Cisco HealthPresence, Cisco IronPort, the Cisco logo, Cisco Nurse Connect, Cisco Pulse, Cisco SensorBase, Cisco StackPower, Cisco StadiumV ision, Cisco TelePresence, Cisco Unified Computing System, Cisco W e bEx, D CE, Flip Chann els, Fli p for Good, Flip Mino, Flipshare (Design), Flip Ultra, Fli p Video, Flip V i deo (Design), Instant Broadband, and Welcome to the Human Network are trademarks; Changing the Way We Work, Live, Play, and Learn, Cisco Capit al, C isco Capit al (D esign), Cis co:Finan ced (Styl ized), Cisco Stor e, Flip Gift Card, and One Million Acts of Green are service marks; and Access Registrar, Aironet, AllTouch, AsyncOS, Bringing the Meeting T o You, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, CCVP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Lumin, Cisco Nexus, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Collaboration Without Limitation, Cont inuum, E th erFast, EtherSwitch, Event Center, Explor er, Follow Me Browsi ng, Gain Mak er, iLYNX, IOS, iPhone, IronPort, the IronPort logo, Laser Link, LightStream, Linksys, MeetingPlace, MeetingPlace Chime Sound, MGX, Networkers, Networking Academy, PCNow, PIX, PowerKEY, PowerPanels, PowerTV, PowerTV (Design), PowerVu, Prisma, ProConnect, ROSA, SenderBase, SMARTnet, Spectrum Expert, StackWise, WebEx, and the WebEx logo are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0910R)
Any Internet Protocol (IP) addresses an d ph one nu mbers u sed in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network topology diagrams, and other fig ures included in the document are sho wn for illust rati v e purp oses only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional and coincidental.
© 2009 Cisco Systems, Inc. All rights reserved.
Additional Information
xiii
Additional Information
Using the Command-Line Interface in Cisco IOS XE Software
xiv
Intelligent Services Gateway Features Roadmap
First Published: March 20, 2006 Last Updated: November 25, 2009
This feature roadmap lists the Cisco IOS XE features documented in the Cisco IOS XE Intelligent Services Gateway Configuration Guide and maps them to the documents in which they appear. The
roadmap is organized so that you can select your release train and see the features in that release. Find the feature name you are searching for and click on the URL in the “Where Documented” column to access the document containing that feature.
Feature and Release Support
Table 1 lists ISG feature support for Cisco IOS XE Release 2. Use Cisco Feature Navigator to find
information about platform support and software image support. Cisco Feature Navigator enables you to determine which Cisco IOS XE software images support a specific software release, feature set, or platform. To access Cisco Feature Navigator, go to http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
Note Table 1 lists only the Cisco IOS XE software release that introduced support for a given feature in a
given Cisco IOS XE software release train. Unless noted otherwise, subsequent re leases of t hat Cisco IOS software release train also support that feature.
Table 1 lists the most recent release of the software train first and the features in alphabetical order
within the release.
Americas Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Intelligent Services Gateway Features Roadmap
Table 1 Supported ISG Features in Cisco IOS XE Release 2
Release Feature Name Feature Description Where Documented
Cisco IOS XE Release 2.5
ISG:Session: Creation: Interface IP Session: L2
ISG IP interface sessions include all IP traffic received on a specific physical or virtual interface. IP interface sessions are provisioned through the CLI; that is, a
Configuring ISG Access for IP Subscriber
Sessions
session is created when the IP interface session commands are entered.
Cisco IOS XE Release 2.5
ISG:Session: Creation: Interface IP Session: L3
ISG IP interface sessions include all IP traffic received on a specific physical or virtual interface. IP interface sessions are provisioned through the CLI; that is, a
Configuring ISG Access
for IP Subscriber
Sessions
session is created when the IP interface session commands are entered.
Cisco IOS XE Release 2.5
ISG:Session: Multicast: Coexistence
This feature introduces the ability to host all the subscribers and services (data and multicast) on the same VLAN by enabling multicast and IP sessions to
Configuring ISG Access
for IP Subscriber
Sessions
coexist on the same subinterface.
Cisco IOS XE Release 2.5
ISG:Session: Static Session Creation
This feature enables administrator-initiated static IP sessions.
Configuring ISG Access
for IP Subscriber
Sessions
Cisco IOS XE Release 2.5
ISG:Instrumentation: DHCP Lease Query Support
The DHCP Lease Query transaction is a DHCP transaction with special message types that enable, among other things, clients to query DHCP servers
Configuring ISG Access
for IP Subscriber
Sessions
regarding the owner and th e lease-expiration-t ime of an IP address.
Cisco IOS XE Release 2.5
ISG:AAA Wireless Enhancements
This feature enhances ISG RADIUS proxy functionality to provide additional support for mobile
Configuring ISG as a
RADIUS Proxy
wireless environments. It includes changes to RADIUS attribute 31 processing.
Cisco IOS XE Release 2.5
ISG:Authentication: Radius Proxy WiMax
RADIUS proxy enhancements provide additional support for WiMax broadband environments.
Configuring ISG as a
RADIUS Proxy
Enhancements
Cisco IOS XE Release 2.5
Cisco IOS XE Release 2.5
ISG:Policy Control: Differentiated Initial Policy Control
This feature provides minimal or temporary network access to the subscribers when the RADIUS servers are down or cannot be accessed because of network issues.
ISG:Accounting: Prepaid ISG prepaid billing support allows ISG to check a
subscriber's available credit to determine whether to allow the subscriber access to a service and how long
Configuring ISG Control
Policies
Configuring ISG
Support for Prepaid
Billing
the access can last. ISG supports volume-based and time-based prepaid billing.
Cisco IOS XE Release 2.2
Cisco IOS XE Release 2.2
IP Subscriber Session CLI Updates
ISG:Accounting: Per Session, Service, and Flow
Some of the commands that are used to configure ISG IP subscriber sessions were modifi ed or replaced in this release.
ISG accounting provides a means to bill for account or service usage. ISG accounting uses the RADIUS protocol to facilitate interactio n between ISG and an
Configuring ISG Access
for IP Subscriber
Sessions
Configuring ISG
Accounting
external RADIUS-based AAA or mediation server.
2
Intelligent Services Gateway Features Roadmap
Table 1 Supported ISG Features in Cisco IOS XE Release 2
Release Feature Name Feature Description Where Documented
Cisco IOS XE Release 2.2
ISG:Accounting: Postpaid
ISG accounting provides a means to bill for account or service usage. ISG sends accounting start and stop
Configuring ISG
Accounting
records for sessions and services to an accounting server for postpaid billing. The accounting server interprets the records to generate bills.
Cisco IOS XE Release 2.2
ISG:Accounting: Tariff Switching
ISG accounting provides a means to bill for account or service usage. Where bi lling rates cha nge at f ixed tim es
Configuring ISG
Accounting
and sessions are active across the boundary at which the rates change, ISG will provides accounting data to the billing server indicating the boundary. Tariff switching can also be used between accounting methods, such as switching from prepaid billing to post paid billing.
Cisco IOS XE Release 2.2
ISG:Authentication: DHCP Option 82 Line ID
- AAA Authorization
This feature enhances ISG automatic subscriber logon by providing support for authorization on the basis of the circuit-Id and remote-Id.
Configuring ISG
Policies for Automatic
Subscriber Logon
Support
Cisco IOS XE Release 2.2
ISG:Flow Control: Flow Redirect
The ISG Layer 4 Redirect feature enables service providers to better control the user experience by allowing subscriber TCP or UDP packets to be
Redirecting Subscriber
Traffic Using ISG Layer
4 Redirect
redirected to specified servers for appropr iate handling. ISG Layer 4 redirection can be applied to individual subscriber sessions or flows.
Cisco IOS XE Release 2.2
Cisco IOS XE Release 2.2
ISG:Flow Control: QoS Control: Dynamic Rate Limiting
ISG:Instrumentation: Advanced Conditional Debugging
ISG can change the allowed bandwidth of a session or flow by dynamically applying rate-limiting policies.
ISG provides the ability to def ine various conditio ns for filtering debug output. Conditional debugging generates very specific and relevant information that can be used for session, flow, subscriber, and service
Configuring ISG
Network Forwarding
Policies
Troubleshooting ISG
with Session Monitoring
and Distributed
Conditional Debugging
diagnostics.
Cisco IOS XE Release 2.2
ISG:Instrumentation: Session and Flow Monitoring
ISG provides a mechanism for continuously monitor ing interface and CPU statistics. This feature introduces the
show interface monitor and show processes cpu monitor commands, which display statistics that are
Troubleshooting ISG
with Session Monitoring
and Distributed
Conditional Debugging
updated at specified intervals.
Cisco IOS XE Release 2.2
ISG:Network Interface: IP Routed, VRF-Aware MPLS
ISG supports several types of forwarding to connect subscriber sessions to networks. These connections can be to the Internet, corporate intranets, ISPs, or walled
Configuring ISG
Network Forwarding
Policies
gardens for content delivery. ISG supports both routed and MPLS-enabled interfaces for network access.
Cisco IOS XE Release 2.2
ISG:Network Interface: Tunneled (L2TP)
ISG supports several types of forwarding to connect subscriber sessions to networks. These connections can be to Internet, corporate Intranets, ISPs or walled
Configuring ISG
Network Forwarding
Policies
gardens for content delivery. ISG supports tunneled interfaces to networks.
3
Intelligent Services Gateway Features Roadmap
Table 1 Supported ISG Features in Cisco IOS XE Release 2
Release Feature Name Feature Description Where Documented
Cisco IOS XE Release 2.2
ISG:Policy Control: Cisco Policy Language
ISG control policies are a structured replacement for feature-specific configuration commands and allow
Configuring ISG Control
Policies
configurable functionality to be expressed in terms of an event, a condition, and an action. Control policies provide an intuitive and extensible framework, with a consistent set of CLI commands, for specifying system behavior. The ISG policy language is aligned with the Cisco Common Classification Policy Language (C3PL).
Cisco IOS XE Release 2.2
Cisco IOS XE Release 2.2
ISG:Policy Control: DHCP Proxy
ISG:Policy Control: ISG-SCE Control Bus
This feature enables ISG to dynamically interact with DHCP and apply policies that influence the IP addresses that DHCP assigns to subscribers.
This feature enables integration of an ISG device with an SCE device at the control plane level, allowing the
Configuring ISG Access
for IP Subscriber
Sessions
Configuring ISG
Integration with SCE
two devices to work as one when policies are applied to a subscriber session.
Cisco IOS XE Release 2.2
ISG:Policy Control: Multidimensional Identity per Session
ISG control policies provide a flexible way to collect pieces of subscriber identity during session establishment. Control policies also allow session
Configuring ISG Control
Policies
policy to be applied iteratively as more elements of identity become available to the system.
Cisco IOS XE Release 2.2
ISG:Policy Control: Policy: Domain Based (Auto-domain, Proxy)
ISG control policies manage the primary services and rules used to enforce particular contracts. Polices can be configured to interpret the domain as a request to
Configuring ISG Control
Policies
activate the service associated with that domain name, allowing users to automatically receive services in accordance with the domain that they are attempting to connect.
Cisco IOS XE Release 2.2
ISG:Policy Control: Policy: Triggers
ISG control policies can be configured with time-based, volume-based, and duration-based policy triggers.
Configuring ISG Control
Policies
Time-based triggers use an internal clock, allowing policies to be applied at specific times. Volume-based triggers are based on packet count; when the packet count reaches a specified value, the specified policy is applied. Duration-based triggers are based on an internal timer. Upon expiration of the timer, the specified policy is applied.
Cisco IOS XE Release 2.2
Cisco IOS XE Release 2.2
ISG:Policy Control: Policy Server: CoA
ISG:Policy Control: Policy Server: CoA ASCII Command Code Support
This feature provides ISG support for the RADIUS Change of Authorization (CoA) extension, which facilitates dynamic authorization.
This feature enables ISG to receive ASCII command codes for Account Logon, Account Logoff, Service Logon, Service Logoff, and Account Status queries and to perform the required functionality based on the
Enabling ISG to Interact
with External Policy
Servers
Cisco IOS ISG RADIUS
Interface Guide
command code.
4
Intelligent Services Gateway Features Roadmap
Table 1 Supported ISG Features in Cisco IOS XE Release 2
Release Feature Name Feature Description Where Documented
Cisco IOS XE Release 2.2
Cisco IOS XE Release 2.2
ISG:Policy Control: Policy Server: SSG-SESM Protocol
ISG:Policy Control: Service Profiles
ISG supports Cisco’s proprietary protocol to communicate with the SESM policy server.
ISG defines a service as a collection of policies that can be applied to any subscriber session. Services can be
Cisco SSG-to-ISG DSL Broadband Migration Guide
Configuring ISG Subscriber Services
configured on the router or on an external AAA server.
Cisco IOS XE Release 2.2
ISG:Policy Control: RADIUS Proxy Enhancement
The ISG RADIUS proxy feature enables ISG to serve as a proxy between a client device that uses RADIUS authentication and a AAA server. ISG RADIUS proxy
Configuring ISG as a RADIUS Proxy
functionality enables ISG to “sniff” (look at) the RADIUS packet flows and, upon successful authentication, transparently create a corresponding ISG session.
Cisco IOS XE Release 2.2
ISG:Policy Control: User Profiles
ISG user profiles specify services and functionality that should be applied to ISG sessions for the specified
Overview of ISG
subscriber. User profiles are defined on an external AAA server.
Cisco IOS XE Release 2.2
ISG:Session: Auth: PBHK
The ISG Port-Bundle Host Key feature serves as an in-band signaling mechanism for session identification
Configuring ISG
Port-Bundle Host Key
at external portals. TCP packets from subscribers are mapped to a local IP address for the ISG gateway and a range of ports. This mapping allows the portal to identify the ISG gateway from which the session originated.
Cisco IOS XE Release 2.2
ISG:Session: Auth: Single Sign-On
Single sign-on eliminates the need to authenticate a session more than once when a subscriber has access to
Overview of ISG
services provided by other devices in the administrative domain of the access or service provider.
Cisco IOS XE Release 2.2
ISG:Session: Authentication
ISG automatic subscriber logon enables another specified identifier to be used in place of the username in authorization requests. Enabling the AAA server to
Configuring ISG
Policies for Automatic
Subscriber Logon
authorize subscribers on the basis of a specified identifier allows subscriber profiles to be downloaded from the AAA server as soon as packets are received from subscribers.
Cisco IOS XE Release 2.2
ISG:Session: Creation: Interface IP Session: L2
ISG IP interface sessions include all IP traffic received on a specific physical or virtual interface. IP interface sessions are provisioned through the CLI; that is, a
Configuring ISG Access
for IP Subscriber
Sessions
session is created when the IP interface session commands are entered.
Cisco IOS XE Release 2.2
ISG:Session: Creation: Interface IP Session: L3
ISG IP interface sessions include all IP traffic received on a specific physical or virtual interface. IP interface sessions are provisioned through the CLI; that is, a
Configuring ISG Access
for IP Subscriber
Sessions
session is created when the IP interface session commands are entered.
5
Intelligent Services Gateway Features Roadmap
Table 1 Supported ISG Features in Cisco IOS XE Release 2
Release Feature Name Feature Description Where Documented
Cisco IOS XE Release 2.2
ISG:Session: Creation: IP Session: Protocol Event (DHCP)
Most ISG sessions are created upon detection of a data flow that cannot be affiliated with an already active session. An ISG can be configured to create an IP
Configuring ISG Access for IP Subscriber
Sessions
session upon receipt of the first DHCP DISCOVER packet received from a subscriber.
Cisco IOS XE Release 2.2
ISG:Session: Creation: IP Session: Subnet and Source IP: L2
The ISG session is the primary component used for associating services and policies across specific data flows. An IP subnet session is an ISG session that
Configuring ISG Access
for IP Subscriber
Sessions
includes any IP traffic from a single IP subnet. A source-IP-based session includes traffic from a single source IP address.
Cisco IOS XE Release 2.2
ISG: Session: Creation: IP Session: Subnet and Source IP: L3
The ISG session is the primary component used for associating services and policies across specific data flows. An IP subnet session is an ISG session that
Configuring ISG Access
for IP Subscriber
Sessions
includes any IP traffic from a single IP subnet. A source-IP-based session includes traffic from a single source IP address.
Cisco IOS XE Release 2.2
ISG:Session: Creation: P2P Session (PPPoE, PPPoXoX)
The ISG session is the primary context to which services and policies are associated across specific data flows. Point-to-point (P2P) sessions are established
Configuring ISG Access
for PPP Sessions
through a signaling protocol. ISG handles many variants of P2P encapsulation, such as PPP, PPPoE, and PPPoA.
Cisco IOS XE Release 2.2
ISG:Session: Lifecycle: Idle Timeout
The ISG idle timeout controls how long a connection can be idle before it is terminated.
Configuring ISG
Policies for
Session Maintenance
Cisco IOS XE Release 2.2
ISG:Session: Lifecycle: Packet of Disconnect (POD)
An ISG can be configured to interact wi th external policy servers. A policy server can use RADIUS Packet of Disconnect (POD) to manage the life cycle of any
Configuring ISG
Policies for
Session Maintenance
ISG session. The primary role of the POD message is to terminate an ISG session.
Cisco IOS XE Release 2.2
ISG:Session: VRF Transfer
The ISG session is the primary component used for associating services and policies with specific data flows. ISG sessions are associated with virtual routing
Configuring ISG Access
for IP Subscriber
Sessions
and forwarding instances when routing is required for the network service. ISG VRF transfer provides a means to dynamically switch an active session between virtual routing domains.
Cisco IOS XE Release 2.2
ISG:Session Protection and Resiliency: Keepalive—ARP, ICMP
This feature allows IP subscriber session health to be monitored by configuring keepalive messages using ARP or ICMP, depending upon the type of connection
Configuring ISG
Policies for
Session Maintenance
to be monitored.
Cisco IOS XE Release 2.2
Service Gateway Interface
The SGI implements a web services interface to access the policy, subscriber, and session management
Service Gateway
Interface
functionality of ISG.
6
Intelligent Services Gateway Features Roadmap
CCDE, CCENT, CCSI, CiscoEos, Cisco HealthPresence, Cisco IronPort, the Cisco logo, Cisco Nurse Connect, Cisco Pulse, Cisco SensorBase, Cisco StackPower, Cisco StadiumVision, Cisco TelePresence, Cisco Unified Computing System, Cisco WebEx, DCE, Flip Channels, Flip for Good, Flip Mino, Flipshare (Design), Flip Ultra, Fli p Video, Flip V i deo (Design), Instant Broadband, and Welcome to the Human Network are trademarks; Changing the Way We Work, Live, Play, and Learn, Cisco Capital, Cisco Capital (Design), Cisco:Financed (Stylized), Cisco Store, Flip Gift Card, and One Million Acts of Green are service marks; and Access Registrar, Aironet, AllTouch, AsyncOS, Bringing the Meeting T o You, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, CCVP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Lumin, Cisco Nexus, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Collabor ation Without Limitation, Continuum, EtherFast, EtherSwitch, Event Center, Explor er, Follow Me Browsi ng, Gain Mak er, iLYNX, IOS, iPhone, IronPort, the IronPort logo, Laser Link, LightStream, Linksys, MeetingPlace, MeetingPlace Chime Sound, MGX, Networkers, Networking Academy, PCNow, PIX, PowerKEY, PowerPanels, PowerTV, PowerTV (Design), PowerVu, Prisma, ProConnect, ROSA, SenderBase, SMARTnet, Spectrum Expert, StackWise, WebEx, and the WebEx logo are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0910R)
Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.
© 2006–2009 Cisco Systems, Inc. All rights reserved.
7
Intelligent Services Gateway Features Roadmap
8
Overview of ISG
First Published: March 20, 2006 Last Updated: March 2, 2009
Intelligent Services Gateway (ISG) is a Cisco IOS and Cisco IOS XE software feature set that provides a structured framework in which edge devices can deliver flexible and scalable services to subscribers. This document provides information about what ISG is, the benefits of ISG, and how to begin implementing it.
Finding Feature Information
For the latest feature information and caveats, see the release notes for your platform and software release. To find information about the features documented in this module, and to see a list of the releases in which each feature is supported, see the “Feature Information for th e Overview of ISG” section on page 9.
Use Cisco Feature Navigator to find information about platform support and Cisco IOS XE software image support. To access Cisco Feature Navigator, go to http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
Contents
Information About ISG, page 1
Additional References, page 8
Feature Information for the Overview of ISG, page 9
Information About ISG
This section contains the following concepts:
What Is ISG?, page 2
ISG Principles, page 3
Americas Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
© 2006–2009 Cisco Systems, Inc. All rights reserved.
Information About ISG
What Is ISG?
Overview of ISG
Benefits of ISG, page 6
Planning for ISG Implementation, page 6
ISG is a structured framework in which edge access devices can deliver flexible and scalable services to subscribers. ISG handles the following key aspects of subscriber management:
Subscriber identification
Service and policy determination
Session policy enforcement
Session life-cycle management
Accounting for access and service usage
Session state monitoring
In addition, ISG introduces a dynamic element to the provisioning and activation of services through control policies and Change of Authorization (CoA) extensions to the RADIUS protocol.
An ISG-enabled device may be deployed at the access edge and service edge of a network and is applicable to a range of subscriber network environments, such as digital subscriber line (DSL), public wireless LAN (PWLAN), and mobile wireless. Moreover, ISG has been designed to accommodate a flexible distribution o f subscriber and service information within a giv en solution. Figure 1 illustrates a typical DSL deployment for which service profi le data may be stored in an authentication, autho rization, and accounting (AAA) database and retrieved and cached on demand.
Figure 1 Sample Topology for a DSL Deployment
AAA
server
DSLAM
DSL
Policy server
Web
portal
ISG
DHCP server
Walled garden
Remote
access VPN
Internet
browsing
Internet
135148
It is also possible to define services directly on an ISG. In all cases, service activation may be triggered as a result of a locally defined control policy, user profile associations, or CoA commands from an external policy server or portal application.
2
Overview of ISG
ISG Principles
Fundamental to the ISG architecture is the provisioning of a common session layer at which the management of generic subscriber sessi ons is deco upled from t he technol ogy that is used to provide access to the edge device.
Within this session management layer, common methods are provided for the extraction of subscriber identity information and the determination and activation of services. These methods are described in the following sections:
Subscriber Sessions, page 3
Subscriber Access, page 4
Subscriber Identification, page 4
Subscriber Services, page 4
Policies, page 5
Dynamic Policy Updates, page 5
Subscriber Sessions
Information About ISG
An ISG subscriber session is a generic system context that is created for every subscriber who interacts with the edge device. A subscriber session is created on first interaction so that policies may be applied as early as possible. Such policies may facilitate the retrieval of subscriber identity information. All subscriber sessions are assigned a locally unique identifier that may subsequently be used to reference the session.
The session context is the basis for common handling at the session management layer, but the type of traffic that is encompassed in a session context may vary. Broadly, session types may be categorized as Layer 2 or Layer 3, depending on the packet types that are being handled by the session. For instance, a PPP session is a Layer 2 session in that it includes all packets transferred o ver a link that w as established using PPP negotiation. An IP session is Layer 3 because it includes all IP packets exchanged with a subscriber device at a single IP address. Whether a session is Layer 2 or Layer 3 will, to some extent, determine the type of polices that may be activated for the session.
ISG also provides flexibility in terms of how an IP session is defined for an interface. For example, on a particular interface, ISG can be provisioned to classify IP sessions on the basis of a single address (an IP session), a subnet (an IP subnet session), or the interface itself (an IP interface session), wherein all IP packets transferred over the interface are encompassed by the same session.
In a network deployment, ISG session types should be provisioned to represent individual subscriber entities. For example, a particular ISG interface may be directly conn ected to a subscriber household in which several subscriber devices with individual IP addresses are attached to a household LAN. If the plan is to model each LAN-attached device as a separate subscriber and apply different policies and services to each, the interface should be provisioned to expect IP sessions. However, if the household represents a single subscriber account, and common handling is required for all packets exchanged, the interface should be provisioned as an IP interface or subnet session.
3
Information About ISG
Subscriber Access
Under ISG, the provisioning and handling of specific access media and protocols is decoupled as far as possible from the functionality that is applicable to all session types. This model has the following benefits:
A common set of subscriber services may be use d on an ISG at wh ich heteroge neous subscr iber
networks are aggregated.
A common set of subscriber services may be used for multiple ISGs, even when the access
technology differs.
For a giv en subscriber , the access method may be altered (th rough prov isioning or roaming ) without
any need to change the service provisioning.
As new access protocols become available, they can be leveraged by existing edge deployments
without requiring changes to the service content; ne w access protocols pl ug into the ISG fr amew ork.
Subscriber Identification
A subscriber session is created when the first control protocol packet is received from the subscriber device. The control protocol will vary depending on the session type. If there is no control protocol, the session is signaled by the first data packet from the subscriber.
At session start, certain identity information is available, although typically not enough to completely identify the subscriber . Th rough the use of cont rol pol icies, the identit y informat ion a vailable at session start can be used to drive t he ex traction of furt her identity f rom the subscriber and d etermine ne w policy for the session. The following example illustrates how ISG might handle subscriber identity:
Overview of ISG
For an IP session, where session start is signaled by a DHCP protocol ev ent, a TCP redirection policy
Subscriber Services
An ISG service is a collection of policies applicable to a subscriber session. When a service is activ ated on a session, all policies contained within that service are activated on the session. Likewise, when a service is deactivated, all policies that are contained within the service are deactivated or removed from the session.
Services are useful for handling fix ed policy combinatio ns that are applicable to a number of subscribers. This application reduces duplication of persistent d ata and allo ws a group of poli cies to be acti v ated with a single action and a single reference.
A service may be defined on the edge device directly, through the command-line interface (CLI), or in an external repository and downloaded as required. A downloaded service definition is cached on the device for as long as it is active on one or more sessions.
A service may be activated in one of the following ways:
As a result of control policy execution
By receipt of a CoA service-logon command
By reference in a user profile, where the service is flagged for automatic activation
could be activated. This policy would facilitate the collection of a username and credential at an external web portal.
4
Overview of ISG
Policies
Information About ISG
Services primarily contain traffic policies. There are some restrictions regarding the policies that may be combined in a given service; for example, a service may not contain two traffic policies that specify a different nondefault traffic class unless they apply to different traffic directions (inbound versus outbound).
Where a service contains a network-forwarding policy, it is known as a primary service. Only one primary service may be active for a given session at any point in time; that is, primary services are mutually exclusive.
ISG introduces support for two basic policy types:
Traffic policies
Control policies
Traffic policies define the handling of data packets and consist of a traffic class, which defines the packet-based criteria for which the policy is applicable, and one or more traffic actions, which are functional instances that perform specific operations on a data stream and are often referred to as features. The traffic actions configured within a traffic policy are invoked for data packets that meet the criteria defined by the traffic class.
Network-forwarding policies are a specific type of traffic policy, for which the action is a network-forwarding action, such as to route packets using a specific virtual routing and forwarding instance (VRF) or to forward packets over a Layer 2 connection. Network-forwarding policies are “classless” in that it is not possible to refine the criteria for which the forwarding action is applicable.
Control policies define the handling of system e v ents and consist o f one or more contr ol policy rul es and a decision strategy that governs how the constituent policy rules are evaluated. A control policy rule consists of a control class (a flexible condition clause), an event for which the condition is evaluated, and one or more control actions. Control actions are general system functions, such as “authenticate” or “activate a service.”
Control policies may be activated on various targets, such as interfaces or ATM virtual circuits (VCs), and typically control the extraction and authentication of subscriber identity and the activation of services on sessions. Traffic policies may be activated only on sessions and are typically (though not always) applied through service activation.
Control policies are a structured replacement for feature-specific configuration commands and allow configurable functionality to be expressed in terms of an event, a condition, and an action. Control policies represent an intuitive and extensible framework for specifying system behavior. As additional functionality is added to the system, an administrator just has to learn what new events and actions can be included in a control policy, not a completely new set of configuration commands.
Dynamic Policy Updates
Traditionally, subscriber policy has been determined at one point only, at session establishment time, once the principal identity o f a subscrib er has be en authenticated. ISG introduces a dynamic policy model in which session policy may be altered at any time.
Session policy is evaluated at session start and may be reassessed whenever additional identity or service selection information is gleaned from the subscriber via the access protocol. In addition, policy may be updated for a session through the activation of control policies or by means of CoA commands from an external application. In the latter case, the external application may update policy as a result of administrator activity, back-end processing, or subscriber activity (such as service selection at a web portal).
5
Information About ISG
Benefits of ISG
Overview of ISG
ISG provides the following benefits:
A common system for session management across Cisco products and access technologies. New
access protocols, forwarding protocols, and feat ures may be plugged in with minimal impact and maximum potential for reuse.
Separation of the concerns of subscriber identification, service application, and subscriber access
and session type.
Flexible session definitions.
Flexible session detection.
Flexible, iterative approach to identification, service activation, and policy activation.
Different trust levels. Session authorization is not contingent on authentication.
Control policies. Control policies facilitate distrib uted polic y decisi on-making, reducin g round-trip
latency between the edge devi ce and policy serv er, and allow system event handling to be described in a consistent and intuitive manner.
Common policy model and language for control and traffic policy.
Provision for dynamic policy updates via CoA (through service activation or “policy push”).
Use of existing Cisco IOS infrastructure to provide session functionality.
Use of existing Cisco IOS infrastructure to track session state and life cycle.
Creation of a session context at first instance of subscriber interaction, thereby facilitating the
immediate application of policy to subscriber traffic.
Flexible distribution of service data.
Range of accounting options, including prepaid accounting, postpaid accounting, tariff switching
for prepaid and postpaid accounting, interim accounting, event-based accounting, and flow-based accounting.
Single sign-on services to an external application.
Flexible infrastructure in support of “equal-access” deployments, such as service-based Dynamic
Host Configuration Protocol (DHCP) pool and DHCP server determination, dynamic readdressing through DHCP, and VRF transfer.
Support for standard external interfaces, such as RADIUS and CoA.
Planning for ISG Implementation
ISG is very flexible and suppor ts a wide v ariety of fun ctionality. Before you begin to configure ISG, you should plan your system carefully . The fo llowing secti ons describe some of the important aspect s of your system that you should consider:
Trust Model, page 7
Subscriber Access Model, page 7
Single Sign-On Requirements, page 7
Network Forwarding, page 7
Service Packaging, page 8
Billing Model, page 8
6
Overview of ISG
Trust Model
Information About ISG
Trust levels are determined by the security needs of a particular application domain and the inherent security afforded by the subscriber network. In the following situations, it may not be necessary to authenticate subscriber identity:
When security is not considered paramount
When end-to-end security is provided in-band
When the subscriber network is intrinsically secure
Whether or not subscribers must be authenticated will influence the choice of access protocol. When authentication is not required, control policies may be used to determine authori zation and other session policy on the basis of subscriber identity.
Where authentication is considered necessary, the authenticated identity may be trusted:
For the duration of the session
Until a periodic reauthentication is instigated
Beyond the duration of a session; for example, for the lifetime of a subscription
For complete security, cryptographic methods may be used to secure the session (to the edge) following authentication, obviating the need for reauthentication. However, there are administrative and performance overheads associated with this practice.
Subscriber Access Model
The trust model will, to a large extent, determine the choice of access protocol. However, the access model will also depend on other factors such as the underlying media (for example, ATM versus Ethernet), type of endpoint (for example, PC, cell phone, PDA), mobility requirements, the system’s ability to influence the software installed on a subscriber device, and scalability requirements.
Single Sign-On Requirements
Where a subscriber will have access to services provided by other devices in the administrative domain of the access or service provider, is an additional authentication required, or should the identity of the subscriber be trusted? It may be necessary for the latte r device to query the access device to collect additional subscriber identity information and ascertain whether the subscriber has already been authenticated by the access device. The single sign-on facility is provided through the “session query” capability of CoA.
Network Forwarding
How should subscribers be given access to network services? Network forwarding options include the following:
Layer 2 connections; for example, a Layer 2 Tunneling Protocol (L2TP) tunnel to an L2TP netw ork
server (LNS)
Layer 3 connections, by associating all session packets with a particular VRF or routing domain
7
Additional References
Service Packaging
Billing Model
Overview of ISG
How should subscriber policies be organized into services, if at all? Some considerations for service packaging include the following:
Are certain policy combinations common to multiple subscribers?
Are shared policy combinations dependent on a particular forwarding domain?
Is it necessary for a subscriber to move between service domains?
Should services be defined on the de vice or in a remote repository? Ext ernally def ined services wi ll
be cached locally for as long as they are activated for one or more sessions.
How should subscribers be billed for service usage? Billing options include the following:
Billing by usage of time or volume
Billing at regular intervals (traditional postpaid)
Billing according to policies provisioned for the session
Billing according to the time of day (tariff switching)
Additional References
The following sections provide references related to ISG.
Related Documents
Related Topic Document Title
ISG commands Cisco IOS Intelligent Services Gateway Command Reference
Technical Assistance
Description Link
The Cisco Support website provides extensive online resources, including documentation and tools for troubleshooting and resolving technical issues with Cisco products and technologies.
To receive security and technical information about your products, you can subscribe to various services, such as the Product Alert Tool (accessed from Field Notices), the Cisco Technical Services Ne wsletter , and Really Simple Syndication (RSS) Feeds.
Access to most tools on the Cisco Support website requires a Cisco.com user ID and password.
http://www.cisco.com/techsupport
8
Overview of ISG
Feature Information for the Overview of ISG
Feature Information for the Overview of ISG
Table 1 lists the features in this module and provides links to specific configuration information. For
information about a feature in this technology that is not documented here, see the “Intelligent Services
Gateway Features Roadmap.”
Use Cisco Feature Navigator to find information about platform support and software image support. Cisco Feature Navigator enables you to determine which Cisco IOS XE software images support a specific software release, feature set, or platform. To access Cisco Feature Navigator, go to
http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
Note Table 1 list only the Cisco IOS XE software release that introduced support for a gi ven feature in a gi ven
Cisco IOS software release train. Unless noted otherwise, subsequent releases of that Cisco IOS XE software release train also support that feature.
Table 1 Feature Information for the Overview of ISG
Feature Name Releases Feature Configuration Information
ISG:Session: Auth: Single Sign-on Cisco IOS XE
Release 2.2.
Single sign-on eliminates the need to authenticate a session more than once when a subscriber has access to services provided by other devices in the administrative domain of the access or service provider.
The following section provides information about this feature:
Planning for ISG Implementation, page 6
CCDE, CCENT, CiscoEos, Cisco HealthPresence, the Cisco logo, CiscoLumin, CiscoNexus, CiscoStadiumVision, CiscoTelePresence, Cisco WebEx, DCE, and Welcome to the Human Network are trademarks; Changing the Way We Work, Live, Play, and Learn and Cisco Store are service marks; and Access Registrar, Aironet, AsyncOS, Bringing the Meeting To You, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, CCVP , Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Collaboration Without Limitation, EtherFast, EtherSwitch, Event Center, Fast Step, Follow Me Browsing, FormShare, GigaDrive, HomeLink, Internet Quotient, IOS, iPhone, iQuick Study, IronPort, the IronPortlogo, LightStream, Linksys, MediaTone, MeetingPlace, MeetingPlace Chime Sound, MGX, Networkers, Networking Academy, Network Registrar, PCNow, PIX, PowerPanels, ProConnect, ScriptShare, SenderBase, SMARTnet, Spectru m Expert, St ackWise, The Fastest W ay to Increase Your Internet Quotient, TransPath, W ebEx, and the WebEx logo are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0812R)
Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.
© 2006–2009 Cisco Systems, Inc. All rights reserved.
9
Feature Information for the Overview of ISG
Overview of ISG
10
Configuring ISG Control Policies
First Published: March 20, 2006 Last Updated: November 25, 2009
Intelligent Services Gateway (ISG) is a Cisco IOS XE software feature set that provides a structured framework in which edge devices can deliver flexible and scalable services to subscribers. ISG control policies are a means of defining the actions the syst em will take in response to specified conditions and events. A wide variety of system actions, conditions, and events can be combined using a consistent policy language, providing a flexible and precise way of configuring ISG. This module provides information about how to configure ISG control policies.
Finding Feature Information
For the latest feature information and caveats, see the release notes for your platform and software release. To find information about the features documented in this module, and to see a list of the releases in which each feature is supported, see the “Feature Information for ISG Control Policies” section on page 21.
Use Cisco Feature Navigator to find information about platform support and Cisco IOS XE software image support. To access Cisco Feature Navigator, go to http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
Contents
Prerequisites for Configuring ISG Control Policies, page 2
Restrictions for Configuring ISG Control Policies, page 2
Information About ISG Control Policies, page 2
How to Configure an ISG Control Policy, page 4
Configuration Examples for ISG Control Policies, page 15
Additional References, page 20
Feature Information for ISG Control Policies, page 21
Americas Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
© 2006–2009 Cisco Systems, Inc. All rights reserved.
Prerequisites for Configuring ISG Control Policies
Prerequisites for Configuring ISG Control Policies
For information about release and platform support, see the “Feature Information for ISG Control
Policies” section on page 21.
Authentication, authorization, and accounting (AAA) method lists must be configured prior to defi ning authentication and authorization actions.
Restrictions for Configuring ISG Control Policies
Control policies are activated for specific contexts, not directly on sessions. Control policies apply to all sessions hosted on the context.
Only one control policy map may be applied to a given context. Control policies can be defined only through the router’s command-line interface (CLI). Not all actions may be associated with all events. A new control class may not be inserted between existing control classes once a control policy map has
been defined.
Configuring ISG Control Policies
Information About ISG Control Policies
Before you configure ISG control policies, you should understand the following concepts:
Control Policies, page 2
Uses of Control Policies, page 3
Control Policies
Control policies define the actions that the system will take in response to specified events and conditions. For example, a control policy can be configured to au thenticate specif ic subscribers and then provide them with access to specific services.
A control policy is made of one or more control policy rules. A control policy rule is an association of a control class and one or more actions. The control class defines the conditions that must be met before the actions will be executed.
Three steps are involved in defining a control policy:
1. Create one or more control class maps.
A control class map specifies the conditions that must be met for a policy to be activated, and, optionally , the e v ent that causes the class to be e v aluated. A con trol class map may co ntain multip le conditions, each of which will ev aluate to either true or false. Match directives can be used to specify whether all, any, or none of the individual conditions must evaluate true in order for the class to evaluate true.
2. Create a control policy map.
A control policy map contains one or more control policy rules. A control policy rule associates a control class map with one or more actions. Actions are numbered and executed sequentially.
2
Configuring ISG Control Policies
3. Apply the control policy map.
Note Traffic policies are another type of policy used by ISG. Traffic policies define the handling of data
packets and are configured in service policy maps or service prof iles. For mo re information about t raf fic policies, see the “Configuring ISG Subscriber Services” module.
Information About ISG Control Policies
A control policy map is activated by applying it to a context. A control policy map can be applied to one or more of the following types of contexts. In the following list, the context types are listed in order of precedence. For example, a control policy map that is applied to a PVC takes precedence over a control policy map that is applied to an interface.
Virtual template
Subinterface
Interface
Global
In general, control policy maps that are applied to more specific contexts take precedence over policy maps applied to more general contexts.
Differentiated Initial Policy Control
Authentication failure for a subscriber may happen for an access-reject (which means a RADIUS server responded with a Reject) or due to an access request timeout (RADIUS server is unreachable).
Using ISG control policies, and actions configur ed for the 'radius-timeout' and 'access-reject' e vents, the system can distinguish between the different reasons for an authentication failure. Different events are thrown by the system (for example, a received authentication reject or an unavailable RADIUS server event). This allows the control policy to specify differen t actions fo r each type of authentication failure. For example, if the RADIUS server is down or unreachable, temporary access can be given to subscribers.
This feature is available only for IP-based sessions for subscriber authentication. This feature does not support the Point-to-Point Protocol over Ethernet (PPPoE) sessions.
Uses of Control Policies
Use control policies to configure an ISG to perform specific actions in response to specific events and conditions. For example, control policies could be used for the following purposes:
To activate a default service when a subscriber session is first detected
To sequence the gathering of subscriber identity, where a control protocol exists on the access side
T o determine how the system responds to an idle timeout or to a subscriber who has run out of credit
T o enable tr ansparent auto logon, which enab les authorization on the basis of an IP address or MAC
address
To configure the maximum amount of time a session can remain unauthenticated
To send periodic session state information to other devices
3
How to Configure an ISG Control Policy
How to Configure an ISG Control Policy
Perform the following tasks to configure an ISG control policy:
Configuring a Control Class Map, page 4 (required)
Configuring a Control Policy Map, page 8 (required)
Applying the Control Policy Map, page 12 (required)
Monitoring and Maintaining ISG Control Policies, page 15 (optional)
Configuring a Control Class Map
A control class map contains conditions that must be met for a control policy to be executed. A control class map can contain one or more conditions. Perform this task to configure a control class map.
SUMMARY STEPS
1. enable
2. configure terminal
3. class-map type control [match-all | match-any | match-none] class-map-name
Configuring ISG Control Policies
4. available {authen-statu s | authenticated-domain | authenticated-username | dnis | media |
mlp-negotiated | nas-port | no-username | protocol | service-name | source-ip-address | timer | tunnel-name | unauthenticated-domain | unauthenticated-username}
5. greater-than [not] nas-port {[adapter adapter-number] [channel channel-number] [ipaddr
ip-address] [port port-number] [shelf shelf-number] [slot slot-number] [sub-interface sub-interface-number] [type interface-type] [vci vci-number] [vlan vlan-id] [vpi vpi-number]}
6. greater-than-or-equal [not] nas-port {[adapter adapter-number] [channel channel-number]
[ipaddr ip-address] [port port-number] [shelf shelf-number] [slot slot-number] [sub-interface sub-interface-number] [type interface-type] [vci vci-number] [vlan vlan-id] [vpi vpi-number]}
7. less-than [not] nas-port {[adapter adapter-number] [channel channel-number] [ipaddr
ip-address] [port port-number] [shelf shelf-number] [slot slot-number] [sub-interface sub-interface-number] [type interface-type] [vci vci-number] [vlan vlan-id] [vpi vpi-number]}
8. less-than-or-equal [not] nas-port {[adapter adapter-number] [channel channel-number] [ipaddr
ip-address] [port port-number] [shelf shelf-number] [slot slot-number] [sub-interface sub-interface-number] [type interface-type] [vci vci-number] [vlan vlan-id] [vpi vpi-number]}
9. match authen-status {authenticated | unauthenticated}
10. match authenticated-domain {domain-n ame | regexp regular-expression}
11. match authenticated-username {username | regexp regular-expression}
12. match dnis {dnis | regexp regular-expression}
13. match media {async | atm | ether | ip | isdn | mpls | serial}
14. match mlp-negotiated {no | yes}
15. match nas-port {adapter adapter-number | channel channel-number | circuit-id name | ipaddr
ip-address | port port-number | remote-id name | shelf shelf-number | slot slot-numbe r | sub-interface sub-interface-number | type {asy nc | atm | basic-rate | enm | ether | fxo | fxs | none | primary-rate | synch | vlan | vty} | vci vci-number | vlan vlan-id | vpi vpi-number}
4
Configuring ISG Control Policies
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
How to Configure an ISG Control Policy
16. match no-username {no | yes}
17. match protocol {atom | ip | pdsn | ppp | vpdn}
18. match service-name {se rvice-name | regexp regular-expression}
19. match source-ip-address ip-address subnet-mask
20. ma tch timer {timer-name | regexp regular-expression}
21. match tunnel-name {tunnel-name | regexp regular-expression}
22. match unauthenticated-domain {domain-name | regexp regular-expression}
23. match unauthenticated-username {username | regexp regular-expression}
24. match vrf {vrf-name | regexp regular-expression}
Enables privileged EXEC mode.
Enter your password if prompted.
Enters global configuration mode.
Step 3
Step 4
Step 5
Example:
Router# configure terminal
class-map type control [match-all | match-any | match-none] class-map-name
Example:
Router(config)# class-map type control match-all class1
available {authen-status | authenticated-domain | authenticated-username | dnis | media |
mlp-negotiated | nas-port | no-username | protocol | service-name | source-ip-address | timer | tunnel-name | unauthenticated-domain | unauthenticated-username}
Example:
Router(config-control-classmap)# available nas-port
greater-than [not] nas-port {[adapter adapter-number] [channel channel-number] [ipaddr ip-address] [port port-number] [shelf
shelf-number] [slot slot-number] [sub-interface sub-interface-number] [type interface-type] [vci vci-number] [vlan vlan-id] [vpi vpi-number]}
Creates or modifies a control class map, which defines the conditions under which the actions of a control policy map will be executed and enters control class-map configuratio n mode.
(Optional) Enters control class map mode. Creates a condition that evaluates true if the specified subscriber identifier is locally available.
(Optional) Creates a condition that evaluates true if the subscriber network access server (NAS) port identifier is greater than the specified value.
Example:
Router(config-control-classmap)# greater-than nas-port type atm vpi 200 vci 100
5
How to Configure an ISG Control Policy
Command or Action Purpose
Step 6
greater-than-or-equal [not] nas-port {[adapter
adapter-number] [channel channel-number] [ipaddr ip-address] [port port-number] [shelf
shelf-number] [slot slot-number] [sub-interface sub-interface-number] [type interface-type] [vci vci-number] [vlan vlan-id] [vpi vpi-number]}
Example:
Router(config-control-classmap)# greater-than-or-equal nas-port vlan 10
Step 7
Step 8
less-than [not] nas-port {[adapter
adapter-number] [channel channel-number] [ipaddr ip-address] [port port-number] [shelf
shelf-number] [slot slot-number] [sub-interface sub-interface-number] [type interface-type] [vci vci-number] [vlan vlan-id] [vpi vpi-number]}
Router(config-control-classmap)# less-than nas-port type atm vpi 200 vci 105
less-than-or-equal [not] nas-port {[adapter adapter-number] [channel channel-number ] [ipaddr ip-address] [port port-number] [shelf
shelf-number] [slot slot-number] [sub-interface sub-interface-number] [type interface-type] [vci vci-number] [vlan vlan-id] [vpi vpi-number]}
Configuring ISG Control Policies
(Optional) Creates a condition that evaluates true if the specified subscriber NAS port identifier is greater than or equal to the specified value.
(Optional) Creates a condition that evaluates true if the specified subscriber NAS port identifier is less than the specified value.
(Optional) Creates a condition that evaluates true if the specified subscriber NAS port iden tifier is less than or equal to the specified value.
Step 9
Step 10
Step 11
Example:
Router(config-control-classmap)# less-than-or-equal nas-port ipaddr 10.10.10.10
match authen-status {authenticated | unauthenticated}
Example:
Router(config-control-classmap)# match authen-status authenticated
match authenticated-domain {domain-name | regexp regular-expression}
Example:
Router(config-control-classmap)# match authenticated-domain cisco.com
match authenticated-username {username | regexp regular-expression}
Example:
Router(config-control-classmap)# match authenticated-username regexp "admin@.*com"
(Optional) Creates a condition that evaluates true if a subscriber’s authentication status matches the specified authentication status.
(Optional) Creates a condition that evaluates true if a subscriber’s authenticated domain matches the specified domain.
(Optional) Creates a condition that evaluates true if a subscriber’s authenticated username matches the specified username.
6
Configuring ISG Control Policies
Command or Action Purpose
Step 12
match dnis {dnis | regexp regular-expression}
Example:
Router(config-control-classmap)# match dnis reg-exp 5551212
Step 13
match media {async | atm | ether | ip | isdn | mpls | serial}
Example:
Router(config-control-classmap)# match media atm
Step 14
match mlp-negotiated {no | yes}
Example:
Router(config-control-classmap)# match mlp-negotiated yes
Step 15
match nas-port {adapter adapter-number | channel channel-number | circuit-id name | ipaddr ip-address | port port-number | remote-id name | shelf shelf-number | slot
slot-number | sub-interface sub-interface-number | type {async | atm |
basic-rate | enm | ether | fxo | fxs | none | primary-rate | synch | vlan | vty} | vci vci-number | vlan vlan-id | vpi vpi-number}
How to Configure an ISG Control Policy
(Optional) Creates a condition that evaluates true if a subscriber’s Dialed Number Identification Service number (DNIS number, also referred to as called-party number) matches the specified DNIS number.
(Optional) Creates a condition that evaluates true if a subscriber’s access media type matches the specified media type.
(Optional) Creates a condition that evaluates true or false depending on whether the subscriber’s session was established using multilink PPP negotiation.
If the yes keyword is used, the condition e valuates true
if the subscriber’s session was established using multilink PPP negotiation.
(Optional) Creates a condition that evaluates true if a subscriber’s NAS port identifier matches the specified value.
Step 16
Step 17
Step 18
Example:
Router(config-control-classmap)# match nas-port type ether slot 3
match no-username {no | yes}
Example:
Router(config-control-classmap)# match no-username yes
match protocol {atom | ip | pdsn | ppp | vpdn}
Example:
Router(config-control-classmap)# match protocol ip
match service-name {service-name | regexp regular-expression}
Example:
Router(config-control-classmap)# match service-name service1
(Optional) Creates a condition that evaluates true or false depending on whether or not a subscriber’s username is available.
If the yes keyword is used, the condition e valuates true
if the subscriber’s username is not available.
(Optional) Creates a condition that evaluates true if a subscriber’s access protocol type matches the specified protocol type.
(Optional) Creates a condition that evaluates true if the service name associated with a subscriber matches the specified service name.
7
How to Configure an ISG Control Policy
Command or Action Purpose
Step 19
match source-ip-address ip-address subnet-mask
Example:
Router(config-control-classmap)# match source-ip-address 10.10.10.10 255.255.255.255
Step 20
match timer {timer-name | regexp regular-expression}
Example:
Router(config-control-classmap)# match timer TIMERA
Step 21
match tunnel-name {tunnel-name | regexp regular-expression}
Example:
Router(config-control-classmap)# match tunnel-name regexp L.*
Step 22
match unauthenticated-domain {domain-name | regexp regular-expression}
Example:
Router(config-control-classmap)# match unauthenticated-domain example.com
Step 23
match unauthenticated-username {username | regexp regular-expression}
Example:
Router(config-control-classmap)# match unauthenticated-username regexp examplename1
Step 24
match vrf {vrf-name | regexp regular-expression}
Example:
Router(config-control-classmap)# match vrf regexp examplename2
Configuring ISG Control Policies
(Optional) Creates a condition that evaluates true if a subscriber’s source IP address matches the specified IP address.
(Optional) Creates a condition that evaluates true upon expiry of a specified policy timer.
(Optional) Creates a condition that evaluates true if a subscriber’s virtual private dialup network (VPDN) tunnel name matches the specified tunnel name.
(Optional) Creates a condition that evaluates true if a subscriber’s unauthenticated domain name matches the specified domain name.
(Optional) Creates a condition that evaluates true if a subscriber’s unauthenticated username matches the specified username.
(Optional) Creates a condition that evaluates true if a subscriber’s VPN routing and forwarding (VRF) matches the specified VRF.
Configuring a Control Policy Map
A control policy map contains one o r more cont rol policy rules that associate a control class with one or more actions. Perform this task to configure a control policy map.
Note The actions that can be configured in a policy rule depend on the type of event that is specified by the
class type control command. For example, if the account-logoff event is specif ied, the on ly act ion that can be configured in that policy rule is service. The procedure in this section shows all actions that can be configured in a policy map.
8
Configuring ISG Control Policies
Default Method Lists
If you specify the default method list for any of the contr ol policy actions, the def ault list will not appear in the output of the show running-config command. For example, if you configure the following command:
Router(config-control-policymap-class-control)# 1 authenticate aaa list default
the following will display in the output for the show running-config command:
1 authenticate
Named method lists will display in the show running-config command output.
SUMMARY STEPS
1. enable
2. configure terminal
3. policy-map type control policy-map-name
4. class type control {control-class-name | always} [event {access-reject | account-logoff |
How to Configure an ISG Control Policy
account-logon | acct-notification | credit-exhausted | dummy-event | quota-depleted | radius-timeout | service-failed | service-start | service-stop | session-default-service | session-restart | session-service-found | session-start | timed-policy-expiry}]
5. action-number authenticate aaa list list-name
6. action-number authorize [aaa list list-na me] [password password] [upon network-service-found
{continue | stop}] identifier {authenticated-domain | authenticated-username | auto-detect | circuit-id [plus remote-id] | dnis | mac-address | nas-port | remote-id [plus circuit-id] | source-ip-address | tunnel-name | unauthenticated-domain | unauthenticated-username | vendor-class-id}
7. action-number collect [aaa list list-name] identifier {authen-status | authenticated-domain |
authenticated-username | dnis | mac-address | media | mlp-negotiated | nas-port | no-username | protocol | service-name | source-ip-address | timer | tunnel-name | unauthenticated-domain | unauthenticated-username | vrf}
8. action-number if upon network-service-found {continue | stop}
9. action-number proxy accounting aaa list {list-name | default}
10. ac tion-num ber service [disconnect | local | vpdn]
11. ac tion-num ber service-policy type control policy-map-name
12. ac tion-num ber service-policy type service [unapply] [aaa list list-name] {name service-name |
identifier {authenticated-domain | authenticated-username | dnis | nas-port | tunnel-name | unauthenticated-domain | unauthenticated-username}}
13. ac tion-num ber set name identifier {authen-status | authenticated-domain |
authenticated-username | dnis | mac-address | media | mlp-negotiated | nas-port | no-username | protocol | service-name | source-ip-address | timer | tunnel-name | unauthenticated-domain | unauthenticated-username | vrf}
14. ac tion-num ber set-timer name-of-timer minutes
15. ac tion-num ber substitute name matching-pattern pattern-string
16. end
9
How to Configure an ISG Control Policy
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
policy-map type control policy-map-name
Example:
Router(config)# policy-map type control MY-POLICY
Step 4
class type control {control-class-name | always} [event {access-reject | account-logoff | account-logon | acct-notification | credit-exhausted | dummy-event | quota-depleted | radius-timeout | service-failed | service-start | service-stop | session-default-service | session-restart | session-service-found | session-start | timed-policy-expiry}]
Configuring ISG Control Policies
Enables privileged EXEC mode.
Enter your password if prompted.
Enters global configuration mode.
Creates or modifies a control policy map, which is used to define a control policy and enters control policy-map configuration mode.
Specifies a control class for which actions may be configured and enters control policy-map class configuration mode.
A policy rule for which the control cl ass is always will
always be treated as the lowest priority rule within the control policy map.
Step 5
Step 6
Example:
Router(config-control-policymap)# class type control always event session-start
action-number authenticate aaa list list-name
Example:
Router(config-control-policymap-class-control)# 1 authenticate aaa list LIST1
action-number authorize [aaa list list-name] [password password] [upon network-service-found {continue | stop}] identifier {authenticated-domain | authenticated-username | auto-detect | circuit-id [plus remote-id] |
dnis | mac-address | nas-port | remote-id [plus circuit-id] | source-ip-address | tunnel-name | unauthenticated-domain | unauthenticated-username | vendor-class-id}
Example:
Router(config-control-policymap-class-control)# 1 authorize identifier source-ip-address
(Optional) Initiates an authentication request.
(Optional) Initiates a request for authorization on the basis of the specified identifier.
10
Configuring ISG Control Policies
Command or Action Purpose
Step 7
action-number collect [aaa list list-name] identifier {authen-status | authenticated-domain | authenticated-username | dnis | mac-address | media | mlp-negotiated | nas-port | no-username | protocol | service-name | source-ip-address | timer | tunnel-name | unauthenticated-domain | unauthenticated-username | vrf}
Example:
Router(config-control-policymap-class-control)# 1 collect identifier authen-status
Step 8
action-number if upon network-service-found {continue | stop}
Example:
Router(config-control-policymap-class-control)# 2 if upon network-service-found stop
Step 9
action-number proxy accounting aaa list {list-name | default}
How to Configure an ISG Control Policy
(Optional) Collects the specified subscriber identifier from the access protocol.
(Optional) Specifies whether the system should continue processing policy rules once the subscriber’s network service has been identified.
(Optional) Specifies the list that the request should be proxied to.
Step 10
Step 11
Step 12
Example:
Router(config-control-policymap-class-control)# 1 proxy accounting aaa list default
action-number service [disconnect | local | vpdn]
Example:
Router(config-control-policymap-class-control)# 3 service disconnect
action-number service-policy type control policy-map-name
Example:
Router(config-control-policymap-class-control)# 4 service-policy type control domainBasedAccess
action-number service-policy type service [unapply] [aaa list list-name] {name service-name | identifier {authenticated-domain | authenticated-username | dnis | nas-port |
tunnel-name | unauthenticated-domain | unauthenticated-username}}
Example:
Router(config-control-policymap-class-control)# 1 service-policy type service aaa list LISTA name REDIRECT
(Optional) Specifies a network service type for PPP sessions.
(Optional) Nests the specified control policy map within a parent control policy map.
(Optional) Activates an ISG service.
Specifying an identifier instead of a service name will
activate a service that has the same name as the specified identifier.
11
How to Configure an ISG Control Policy
Command or Action Purpose
Step 13
action-number set name identifier {authen-status | authenticated-domain |
authenticated-username | dnis | mac-address | media | mlp-negotiated | nas-port | no-username | protocol | service-name | source-ip-address | timer | tunnel-name | unauthenticated-domain | unauthenticated-username | vrf}
Example:
Router(config-control-policymap-class-control)# 1 set APJ identifier authen-status
Step 14
action-number set-timer name-of-timer minutes
Example:
Router(config-control-policymap-class-control)# 1 set-timer TIMERA 5
Step 15
action-number substitute name matching-pattern pattern-string
Configuring ISG Control Policies
(Optional) Sets a variable name.
(Optional) Starts a named policy timer.
Expiration of the timer generates the event
timed-policy-expiry.
(Optional) Substitutes a matching pattern in variable content by a rewrite pattern.
Example:
Router(config-control-policymap-class-control)# 1 substitute TPK SUBA SUBB
Step 16
end
(Optional) Ends the current configuration session and returns to privileged EXEC mode.
Example:
Router(config-control-policymap-class-control)# end
Applying the Control Policy Map
A control policy map must be activ ated b y applying it to a conte xt. Perform one or more of the follo wing tasks to apply a control policy to a context:
Applying a Control Policy Map Globally on the Router, page 12
Applying an ISG Control Policy Map to an Interface or Subinterface, page 13
Applying an ISG Control Policy Map to a Virtual Template, page 14
Applying a Control Policy Map Globally on the Router
Perform this task to apply a control policy globally.
SUMMARY STEPS
1. enable
2. configure terminal
3. service-policy type control policy-map-name
12
Configuring ISG Control Policies
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
service-policy type control policy-map-name
Example:
Router(config)# service-policy type control policy1
How to Configure an ISG Control Policy
Enables privileged EXEC mode.
Enter your password if prompted.
Enters global configuration mode.
Applies a control policy.
Applying an ISG Control Policy Map to an Interface or Subinterface
Perform this task to apply an ISG control policy to an interface or subinterface.
SUMMARY STEPS
1. enable
2. configure terminal
3. interface type number [.subinterface number]
4. service-policy type control policy-map-name
DETAILED STEPS
Command or Action Purpose
Step 1
Step 2
enable
Example:
Router> enable configure terminal
Example:
Router# configure terminal
Enables privileged EXEC mode.
Enter your password if prompted.
Enters global configuration mode.
13
How to Configure an ISG Control Policy
Command or Action Purpose
Step 3
interface type number[.subinterface-number]
Specifies an interface and enters interface configuration mode.
Example:
Router(config)# interface gigabitethernet 0/0/1.1
Step 4
service-policy type control policy-map-name
Applies a control policy.
Example:
Router(config-if)# service-policy type control policy1
Applying an ISG Control Policy Map to a Virtual Template
Perform this task to apply an ISG control policy map to a virtual template.
SUMMARY STEPS
Configuring ISG Control Policies
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
interface virtual-template number
Example:
Router(config)# interface virtual-template0
Step 4
service-policy type control policy-map-name
1. enable
2. configure terminal
3. interface virtual-template number
4. service-policy type control policy-map-name
Enables privileged EXEC mode.
Enter your password if prompted.
Enters global configuration mode.
Creates a virtual template interface and enters interface configuration mode.
Applies a control policy.
Example:
Router(config-if)# service-policy type control policy1
14
Configuring ISG Control Policies
Monitoring and Maintaining ISG Control Policies
Optionally, you can perform this task to monitor and maintain ISG control policy operation. Steps can be performed in any order.
SUMMARY STEPS
1. enable
2. show class-map type control
3. show policy-map type control
4. clear class-map control
5. clear policy-map control
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Enables privileged EXEC mode.
Configuration Examples for ISG Control Policies
Step 2
Step 3
Step 4
Step 5
Example:
Router> enable
show class-map type control
Example:
Router# show class-map type control
show policy-map type control
Example:
Router# show policy-map type control
clear class-map control
Example:
Router# clear class-map control
clear policy-map control
Example:
Router# clear policy-map control
Enter your password if prompted.
Displays information about ISG control class maps.
The display includes statistics on the number of times a
particular class has been eval uated and what the results were.
Displays information about ISG control policy maps.
The display includes statistics on the number of times
each policy rule within the policy map has been executed.
Clears the control class map counters.
Clears the control policy map counters.
Configuration Examples for ISG Control Policies
This section contains the following examples of ISG control policies:
Control Policy for Layer 2 Access and Service Provisioning: Example, page 16
Verifying a Control Policy: Examples, page 16
Control Policy for Restricting Access on the Basis of Interface and Access Media: Example, page 19
Control Policies for Automatic Subscriber Login: Example, page 20
15
Configuring ISG Control Policies
Configuration Examples for ISG Control Policies
Control Policy for Layer 2 Access and Service Provisioning: Example
The following example shows how to configure a control policy that produces the following results:
VPDN forwarding is applied to anyone dialing in from “example1.com”.
Access to locally terminated Layer 3 network resources is provided to anyone dialing in from
“example2.com”.
Anyone else is barred.
username user1@example1.com password 0 lab username user2@example2.com password 0 lab username user3@example3.com password 0 lab ! class-map type control match-all MY-FORWARDING-USERS match unauthenticated-domain example1.com ! class-map type control match-all MY-LOCAL-USERS match unauthenticated-domain example2.com ! policy-map type control MY-POLICY class type control MY-FORWARDING-USERS event session-start 1 service local ! class type control MY-LOCAL-USERS event session-start 1 service local ! class type control always event session-start 2 service disconnect ! ! policy-map type control ppp-users class type control always event session-start 1 collect identifier unauthenticated-domain 2 service-policy type control MY-POLICY !
Verifying a Control Policy: Examples
The following examp les show sample output generated from the configuration in the Control Policy for
Layer 2 Access and Service Provisioning: Example:
Router# show users
Line User Host(s) Idle Location * 0 con 0 idle 00:00:00
Interface User Mode Idle Peer Address Vi1.1 user1@xyz.com PPPoE - 10.1.126.14 Vi1.2 user2@abc.com PPPoE - 10.1.126.15
Router# show subscriber session
Current Subscriber Information: Total sessions 2
Uniq ID Interface State Service Identifier Up-time 2022 Vi1.1 authen Local Term user1@xyz.com 00:08:41 2023 Vi1.2 authen Local Term user2@abc.com 00:08:40
MCP_BBA_8#show subscriber session MCP_BBA_8#show subscriber session uid 2022 detailed
16
Configuring ISG Control Policies
Unique Session ID: 2022 Identifier: user1@xyz.com SIP subscriber access type(s): PPPoE/PPP Current SIP options: Req Fwding/Req Fwded Session Up-time: 00:08:57, Last Changed: 00:08:57 Interface: Virtual-Access1.1
Policy information: Context 2C655DF0: Handle A2070D8D AAA_id 00007DE8: Flow_handle 0 Authentication status: authen Downloaded User profile, excluding services: service-type 2 [Framed] Framed-Protocol 1 [PPP] timeout 720 (0x2D0) ssg-account-info ''QU;10000;D;20000'' Downloaded User profile, including services: service-type 2 [Framed] Framed-Protocol 1 [PPP] timeout 720 (0x2D0) ssg-account-info ''QU;10000;D;20000'' Config history for session (recent to oldest): Access-type: PPP Client: SM Policy event: Process Config Connecting Profile name: apply-config-only, 3 references service-type 2 [Framed] Framed-Protocol 1 [PPP] timeout 720 (0x2D0) ssg-account-info ''QU;10000;D;20000'' Rules, actions and conditions executed: subscriber rule-map ppp-users condition always event session-start 1 collect identifier unauthenticated-domain 2 service-policy type control MY-POLICY subscriber condition-map match-all MY-FORWARDING-USERS match identifier unauthenticated-domain xyz.com [TRUE] subscriber rule-map MY-POLICY condition MY-FORWARDING-USERS event session-start 1 service local subscriber rule-map ppp-users condition always event session-start 2 service-policy type control MY-POLICY
Configuration Examples for ISG Control Policies
Session inbound features: Feature: Policing Upstream Params: Average rate = 10000, Normal burst = 1875, Excess burst = 3750 Config level = Per-user
Session outbound features: Feature: Policing Dnstream Params: Average rate = 20000, Normal burst = 3750, Excess burst = 7500 Config level = Per-user
Non-datapath features: Feature: Session Timeout Timeout value is 720 seconds Time remaining is 00:02:56 Configuration sources associated with this session: Interface: Virtual-Template1, Active Time = 00:09:03
Router# show subscriber session uid 2023 detailed
17
Configuration Examples for ISG Control Policies
Unique Session ID: 2023 Identifier: user2@abc.com SIP subscriber access type(s): PPPoE/PPP Current SIP options: Req Fwding/Req Fwded Session Up-time: 00:09:17, Last Changed: 00:09:17 Interface: Virtual-Access1.2
Policy information: Context 2C656120: Handle F4070D8E AAA_id 00007DE9: Flow_handle 0 Authentication status: authen Downloaded User profile, excluding services: service-type 2 [Framed] Framed-Protocol 1 [PPP] timeout 720 (0x2D0) ssg-account-info ''QU;10000;D;20000'' Downloaded User profile, including services: service-type 2 [Framed] Framed-Protocol 1 [PPP] timeout 720 (0x2D0) ssg-account-info ''QU;10000;D;20000'' Config history for session (recent to oldest): Access-type: PPP Client: SM Policy event: Process Config Connecting Profile name: apply-config-only, 3 references service-type 2 [Framed] Framed-Protocol 1 [PPP] timeout 720 (0x2D0) ssg-account-info ''QU;10000;D;20000'' Rules, actions and conditions executed: subscriber rule-map ppp-users condition always event session-start 1 collect identifier unauthenticated-domain 2 service-policy type control MY-POLICY subscriber condition-map match-all MY-FORWARDING-USERS match identifier unauthenticated-domain xyz.com [FALSE] subscriber rule-map MY-POLICY condition MY-FORWARDING-USERS event session-start subscriber condition-map match-all MY-LOCAL-USERS match identifier unauthenticated-domain abc.com [TRUE] subscriber rule-map MY-POLICY condition MY-LOCAL-USERS event session-start 1 service local subscriber rule-map ppp-users condition always event session-start 2 service-policy type control MY-POLICY
Configuring ISG Control Policies
Session inbound features: Feature: Policing Upstream Params: Average rate = 10000, Normal burst = 1875, Excess burst = 3750 Config level = Per-user
Session outbound features: Feature: Policing Dnstream Params: Average rate = 20000, Normal burst = 3750, Excess burst = 7500 Config level = Per-user
Non-datapath features: Feature: Session Timeout Timeout value is 720 seconds
18
Configuring ISG Control Policies
Configuration Examples for ISG Control Policies
Time remaining is 00:02:40 Configuration sources associated with this session: Interface: Virtual-Template1, Active Time = 00:09:19
Control Policy for Restricting Access on the Basis of Interface and Access Media: Example
This example shows how to configure a contr ol policy to allow access only to users who enter the router from a particular interface and access type. In this case, only PPPoE users will be allowed; everyone else is barred.
The first condition class map “MATCHING-USERS” evaluates true only if all of the lines within it also evaluate true; however, within “MATCHING-USERS” is a nested class map (second condition), “NOT-ATM”. This nested class map represents a subcondition that must also evaluate to true. Note that the class map “NOT-ATM” specifies “match-none”. This means that “NO T-ATM” evaluates to true only if every condition line within it evaluates to false.
The third condition specifies matching on the NAS port associated wi th this su bscriber. Specifically, only subscribers that arrive on a Gigabit Ethernet interface and on slot 3 will evaluate to true.
! Configure the control class maps. class-map type control match-all MATCHING-USERS
class type control NOT-ATM match media ether
match nas-port type ether slot 3 ! class-map type control match-none NOT-ATM
match media atm !
If the conditions in the class map “MATCHING-USERS” evaluate to true, the fi rst action to be ex ecuted is to authenticate the user. If authentication is successful, the service named “service1” will be downloaded and applied. Finally, a Layer 3 service is provided.
If “MA TCHING-USERS” is not ev aluated as true, the “always” class will apply, which results in barring anyone who does not match “MATCHING-USERS”.
! Configure the control policy map. policy-map type control my-pppoe-rule
class type control MATCHING-USERS event session-start
1 authenticate aaa list XYZ 2 service-policy type service service1 3 service local
!
class type control always
1 service disconnect ! ! Apply the control policy to an interface. interface gigabitethernet3/0/0
service-policy type control my-pppoe-rule
Finally, the policy is associated with an interface.
19
Additional References
Control Policies for Automatic Subscriber Login: Example
In the following example, if the client is from the a subnet, automatic subscriber login is applied and an authorization request is sent to the list TALLIST with the subscriber’s sou rce IP address as the username. If the authorization request is successful, any automatic acti vation services specif ied in the returned user profile are activated for the session and the execution of rules within the control policy stops. If the authorization is not successful, the rule execu tion proceeds, and the subscriber is redirected to the polic y server to log in. If the subscriber does not log in within five minutes, the session is disconnected.
interface GigabitEthernet0/0/0
service-policy type control RULEA
aaa authentication login TALLIST group radius aaa authentication login LOCAL local access-list 100 permit ip any any
class-map type traffic match-any all-traffic
match access-group input 100 match access-group output 100
policy-map type service redirectprofile
class type traffic all-traffic
redirect to ip 10.0.0.148 port 8080
Configuring ISG Control Policies
class-map type control match-all CONDA
match source-ip-address 209.165.201.1 255.255.255.0 ! class-map type control match-all CONDF
match timer TIMERB
match authen-status unauthenticated
policy-map type control RULEA
class type control CONDA event session-start
1 authorize aaa list TAL_LIST password cisco identifier source-ip-address 2 apply aaa list LOCAL service redirectprofile 3 set-timer TIMERB 5 minutes
class type control CONDF event timed-policy-expiry
1 service disconnect
Additional References
The following sections provide references related to ISG control policies.
Related Documents
Related Topic Document Title
ISG commands Cisco IOS Intelligent Services Gateway Command Reference Traffic Policies The “Configuring ISG Subscriber Services” module.
20
Configuring ISG Control Policies
MIBs
MIB MIBs Link
No new or modified MIBs are supported by this feature.
T o locate and do wnload MIBs for selected platforms, Cisco IOS XE releases, and feature sets, use Cisco M IB Locator found at the following URL:
http://www.cisco.com/go/mibs
Technical Assistance
Description Link
The Cisco Support website provides extensive online resources, including documentation and tools for troubleshooting and resolving technical issues with Cisco products and technologies.
To receive security and technical information about your products, you can subscribe to various services, such as the Product Alert Tool (accessed from Field Notices), the Cisco Technical Services Ne wsletter , and Really Simple Syndication (RSS) Feeds.
http://www.cisco.com/techsupport
Feature Information for ISG Control Policies
Access to most tools on the Cisco Support website requires a Cisco.com user ID and password.
Feature Information for ISG Control Policies
Table 1 lists the features in this module and provides links to specific configuration information. For
information about a feature in this technology that is not documented here, see the “Intelligent Services
Gateway Features Roadmap.”
Use Cisco Feature Navigator to find information about platform support and software image support. Cisco Feature Navigator enables you to determine which Cisco IOS XE software images support a specific software release, feature set, or platform. To access Cisco Feature Navigator, go to
http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
Note Table 1 lists only the Cisco IOS XE s oftware release that introduced support for a given feature in a
given Cisco IOS XE software release train. Unless noted othe rwise, su bsequent releases of that Cisco IOS XE software release train also support that feature.
21
Feature Information for ISG Control Policies
Table 1 Feature Information for ISG Control Policies
Feature Name Releases Feature Configuration Information
ISG: Policy Control: Policy: Domain Based (Autodomain, Proxy)
Cisco IOS XE Release 2.2
ISG control policies manage the primary services and rules used to enforce particular contracts. These policies include programmable interfaces to dynamic triggers and conditional logic to be applied to flows within a session, or other characteristics of a session, upon meeting the policy criteria. Policies can be configured to interpret the domain as a request to activate the service associated with that domain name, allowing users to automatically receive services in accordance with the domain to which they are attempting to connect.
The following sections provide mo re information about this feature:
Information About ISG Control Policies, page 2
How to Configure an ISG Control Policy, page 4
ISG: Policy Control: Policy: Triggers Cisco IOS XE
Release 2.2
ISG control policies can be configured with time-based, volume-based, and duration-based policy triggers. Time-based triggers use an inte rnal clock, allowing policies to be applied at specific times. Volume-based triggers are based on packet count; when the packet count reaches a specified value, the specified policy is applied. Duration-based triggers are based on an internal timer. Upon expiration of the timer , the specif ied policy is applied.
Configuring ISG Control Policies
ISG: Policy Control: Multidimension al Identity per Session
Cisco IOS XE Release 2.2
The following sections provide mo re information about this feature:
Information About ISG Control Policies, page 2
How to Configure an ISG Control Policy, page 4
ISG control policies provide a flexible way to collect pieces of subscriber identity information during session establishment. Control policies also allow session polic y to be applied iteratively as more elements of identity information become available to the system.
The following sections provide mo re information about this feature:
Information About ISG Control Policies, page 2
How to Configure an ISG Control Policy, page 4
22
Configuring ISG Control Policies
Feature Information for ISG Control Policies
Table 1 Feature Information for ISG Control Policies (continued)
Feature Name Releases Feature Configuration Information
ISG: Policy Control: Cisco Policy Language Cisco IOS XE
Release 2.2
ISG control policies are a structured replacement for feature-specific configuration commands and allow configurable functionality to be expressed in terms of an event, a condition, and an action. Control policies provide an intuitive and extensi ble frame w ork, wit h a consistent set of CLI commands, for specifying system behavior.
The following sections provide mo re information about this feature:
Information About ISG Control Policies, page 2
How to Configure an ISG Control Policy, page 4
ISG: Policy Control: Differentiated Initial Policy Control
Cisco IOS XE Release 2.5.0
This features provides the ability to distinguish RADIUS authentication rejects from RADIUS server unavailability. It allows minimal or temporary network access to the subscribers when the RADIUS servers are down or cannot be accessed because of network problems or when an authentication reject is received for a subscriber.
In Cisco IOS Release 12.2(33)XNE, support was added for the Cisco 10000 Series Routers.
The following sections provides more information about this feature:
Information About ISG Control Policies, page 2
How to Configure an ISG Control Policy, page 4
The following command was introduced or modified: class type control.
CCDE, CCENT, CCSI, CiscoEos, Cisco HealthPresence, Cisco IronPort, the Cisco logo, Cisco Nurse Connect, Cisco Pulse, Cisco SensorBase, Cisco StackPower, Cisco StadiumVision, Cisco TelePresence, Cisco Unified Computing System, Cisco WebEx, DCE, Flip Channels, Flip for Good, Flip Mino, Flipshare (Design), Flip Ultra, Fli p Video, Flip V i deo (Design), Instant Broadband, and Welcome to the Human Network are trademarks; Changing the Way We Work, Live, Play, and Learn, Cisco Capital, Cisco Capital (Design), Cisco:Financed (Stylized), Cisco Store, Flip Gift Card, and One Million Acts of Green are service marks; and Access Registrar, Aironet, AllTouch, AsyncOS, Bringing the Meeting T o You, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, CCVP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Lumin, Cisco Nexus, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Collabor ation Without Limitation, Continuum, EtherFast, EtherSwitch, Event Center, Explor er, Follow Me Browsi ng, Gain Mak er, iLYNX, IOS, iPhone, IronPort, the IronPort logo, Laser Link, LightStream, Linksys, MeetingPlace, MeetingPlace Chime Sound, MGX, Networkers, Networking Academy, PCNow, PIX, PowerKEY, PowerPanels, PowerTV, PowerTV (Design), PowerVu, Prisma, ProConnect, ROSA, SenderBase, SMARTnet, Spectrum Expert, StackWise, WebEx, and the WebEx logo are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0910R)
Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.
© 2006–2009 Cisco Systems, Inc. All rights reserved.
23
Feature Information for ISG Control Policies
Configuring ISG Control Policies
24
Configuring ISG Access for PPP Sessions
First Published: March 20, 2006 Last Updated: March 2, 2009
Intelligent Services Gateway (ISG) is a Cisco IOS and Cisco IOS XE software feature set that provides a structured framework in which edge devices can deliver flexible and scalable services to subscribers. This document provides information about how to configure ISG access for PPP subscribers.
Finding Feature Information
For the latest feature information and caveats, see the release notes for your platform and software release. To find information about the features documented in this module, and to see a list of the releases in which each feature is supported, see the “Feature Information for ISG Access for PPP Sessions” section on
page 13.
Use Cisco Feature Navigator to find information about platform support and Cisco IOS XE software image support. To access Cisco Feature Navigator, go to http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
Contents
Prerequisites for ISG Access for PPP Sessions, page 2
Restrictions for ISG Access for PPP Sessions, page 2
Information About Configuring ISG Access for PPP Sessions, page 2
How to Configure ISG Access for PPP Sessions Using Control Policies, page 4
Configuration Examples for ISG Access for PPP Sessions, page 9
Additional References, page 12
Feature Information for ISG Access for PPP Sessions, page 13
Americas Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
© 2009 Cisco Systems, Inc. All rights reserved.
Prerequisites for ISG Access for PPP Sessions
Prerequisites for ISG Access for PPP Sessions
For information about release and platform support, see the “Feature Information for ISG Access for PPP
Sessions” section on page 13.
The specific access protocol that is being used must be provisioned on the interface. If local PPP authentication is required, the ppp authentication command must be configured on the
interface or virtual template. The tasks and examples in this document assume that you know how to configure and use ISG control
policies. See the module “Configuring ISG Control Policies” for information about how configure control policies.
Restrictions for ISG Access for PPP Sessions
In Cisco IOS XE, SSO and ISSU are not supported for the following features on ISG PPP sessions:
Port-Bundle Host Key
Configuring ISG Access for PPP Sessions
Layer 4 Redirect
Traffic C l ass
Accounting
Information About Configuring ISG Access for PPP Sessions
Before you configure access for PPP sessions, you should understand the following concepts:
Overview of ISG Access for PPP Sessions, page 2
ISG Subscriber IP Address Management for PPP Sessions, page 3
VRF Transfer for PPP Sessions, page 3
Default Policy for ISG Access for PPP Sessions, page 3
Overview of ISG Access for PPP Sessions
Layer 2 sessions are established by means of control protocols that operate between the peer entities and the ISG device. Typically, Layer 2 sessions are encapsulated to isolate them from other session s on the same physical media.
Although the system provides defa ult handling f or Layer 2 session s, you may w ant to conf igur e policies to forward or locally terminate the prot ocol or to locally authenticate su bscribers on the b asis of identity data that is collected from the access protocol. ISG control policies can be configured to extract identity and credentials of peer entities from access protocols. This mechanism allows services to be pro visioned for Layer 2 sessions on the basis of any identity pertaining to the session, whether explicitly provided via the protocol or native to the underlying media or access port.
ISG supports the following Layer 2 access protocols:
PPP
PPP over Ethernet (PPPoE)
2
Configuring ISG Access for PPP Sessions
Information About Configuring ISG Access for PPP Sessions
Layer 2 Tunnel Protocol (L2TP)
ISG Subscriber IP Address Management for PPP Sessions
ISG subscriber IP address management applies to IP sessions or Layer 2 (PPP) sessions that are terminated locally.
For a subscriber to be routable within a given IP service domain, the subscriber must present a domain-specific IP address to the network. If a subscriber transfers between IP service domains (which includes any private domain managed by the access provider), the IP address presented to the network must change to reflect the ne w domai n. For locally terminated PPP session s, ISG suppor ts the follo wi ng methods of IP address assignment:
IP address in a user profile
IP subnet in a user profile
Named address pool in a user profile
Local address pools
Standard methods of IP address management for PPP (see the Cisco IOS XE Dial Technologies
Configuration Guide for information about IP address management support for PPP sessions)
When a locally terminated PPP session is transferred from one VRF to another VRF, the peer IP address is renegotiated using IPCP.
VRF Transfer for PPP Sessions
VRF transfer enables an ISG subscriber session to move from one VRF to another following selection of a new primary service. Once a PPP session comes up with the IP address from the network access point (NAP), the subscriber can access a web portal and choose a service provider. On VRF transfers in PPP sessions, ISG must reassign the IP address from the new domain to the PPP session. In PPP sessions, the IP address is reassigned by IPCP renegotiation.
Without PPP renegotiation, VRF transfer is not supported for PPP sessions.
Default Policy for ISG Access for PPP Sessions
ISG provides default handling of Layer 2 sessions in the absence of a configured control policy. If the vpdn enable command is configured and a domain name is specified in the username (e.g., user@domain) or a Dialed Number Identification Service (DNIS) number has been provided, the system will perform authorization on the basis of this information. If virtual private dial-up network (VPDN) tunnel information is found, the session will be forwarded for handling at an L2TP network server (LNS). If authentication is required by the remote LNS, the ppp authentication command must be configured at the PPP interface or virtual template. If the vpdn authen-before-forward command is configured, the system will attempt to authenticate the PPP session locally before for warding it on to the LNS.
If tunnel information is not found for the domain name or DNIS or the vpdn enable command is not configured, Stack Group Bidding Protocol (SGBP) a uthorization will be attempted (if SGBP is configured). If no authorization information is located using SGBP, the PPP session will be terminated
3
Configuring ISG Access for PPP Sessions
How to Configure ISG Access for PPP Sessions Using Control Policies
locally. Local termination means that the PPP session will be established between the peer and the ISG device, and the IP payload will be routed. In the latter case, authentication will occur only if the ppp authentication command is configured on the PPP interface or virtual template.
If an ISG control policy is defined for the session-start event, that policy will override the default handling.
How to Configure ISG Access for PPP Sessions Using Control Policies
To configure ISG Layer 2 access, perform the following steps:
1. Decide how you want Layer 2 session handling to be influenced by subscriber identity. Do you want
to forward the protocol or terminate it locally? Do you want to authenticate subscribers locally?
2. Configure control policies to provide Layer 2 session handling. See the module “Configuring ISG
Control Policies” for information about how configure control policies. See the “Configuration Examples for ISG Access for PPP Sessions” section on page 9 for an example of a control policy
for Layer 2 access.
3. Enable ISG VRF transfer for PPP sessions.
4. Verify and troubleshoot the configuration as needed.
This section contains the following tasks:
Enabling ISG VRF Transfer for PPP Sessions, page 4
Troubleshooting ISG Access for PPP Sessions, page 7
Enabling ISG VRF Transfer for PPP Sessions
VRF transfer enables an ISG subscriber session to move from one VRF to another following selection of a new primary service. This procedure contains the following sections:
Prerequisites, page 4
Specifying a VRF in a Service Policy Map, page 5
Verifying VRF Transfer for PPP Sessions
Prerequisites
This procedure assumes that you have configured support for PPP sessions by configuring a virtual template and method of IP address allocation. Note that the original VRF, loopback interface, and IP address pool must be specified in a virtual template rather than in a user profile in ord er for VRF transfer to work. For information about how to configure virtual templates and support for PPP sessions, see the
Cisco IOS XE Dial Technologies Configuration Guide.
4
Configuring ISG Access for PPP Sessions
Specifying a VRF in a Service Policy Map
VRF transfer occurs when a new primary service is activated for a session, causing the session to transfer from one VRF to another. Services can be configured in service profiles on an external AAA server or they can be configured on the ISG device in service policy maps. Perform this task to configure a VRF in a service policy map on the ISG device.
SUMMARY STEPS
1. enable
2. configure terminal
3. policy-map type service policy-map-name
4. ip vrf forwarding name-of-vrf
5. sg-service-type primary
6. sg-service-group service-group-name
DETAILED STEPS
How to Configure ISG Access for PPP Sessions Using Control Policies
Step 1
Step 2
Step 3
Step 4
Command or Action Purpose
enable
Enables privileged EXEC mode.
Enter your password if prompted.
Example:
Router> enable configure terminal
Enters global configuration mode.
Example:
Router# configure terminal policy-map type service policy-map-name
Creates or modifies a service policy map, which is used to define an ISG service, and enters service policy-map
Example:
Router(config)# policy-map type service service1
ip vrf forwarding name-of-vrf
configuration mode.
Associates the service with a VRF.
Example:
Router(config-service-policymap)# ip vrf forwarding blue
5
How to Configure ISG Access for PPP Sessions Using Control Policies
Command or Action Purpose
Step 5
sg-service-type primary
Example:
Router(config-service-policymap)# sg-service-type primary
Step 6
sg-service-group service-group-name
Example:
Router(config-service-policymap)# sg-service-group group1
Verifying VRF Transfer for PPP Sessions
Perform this task to verify VRF transfer for PPP sessions. All of the show steps are optional and may be performed in any order.
Configuring ISG Access for PPP Sessions
Defines the service as a primary service.
A primary service is a service that contains a
network-forwarding policy. A primary service must be defined as a primary service by using the sg-service-type primary command. Any service that is not a primary service is defined as a secondary service by defau lt .
(Optional) Associates an ISG service with a service group.
A service group is a grouping of services that may be
active simultaneously for a given session. Typically, a service group includes one primary s ervice and o ne or more secondary services.
SUMMARY STEPS
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Step 2
show subscriber session all
Example:
Router# show subscriber session all
1. enable
2. show subscriber session all
3. show idmgr {service key session-handle session-handle service-key service | session key
{domainip-vrf ip-address ip-address vrf-id vrf-id | ip-address ip-address | mac-address mac-address | nativeip-vrf ip-address ip-address vrf-id vrf-id | portbundle ip ip-address bundle bundle-number | session-handle session-handle}}
4. show ip route [vrf vrf-name]
Enables privileged EXEC mode.
Enter your password if prompted.
Displays information pertaining to the service chosen b y the subscriber.
6
Configuring ISG Access for PPP Sessions
Command or Action Purpose
Step 3
show idmgr {service key session-handle session-handle service-key service | session key {domainip-vrf ip-address ip-address vrf-id
vrf-id | ip-address ip-address | mac-address mac-address | nativeip-vrf ip-address ip-address vrf-id vrf-id | portbundle ip ip-address bundle bundle-number | session-handle session-handle}}
Example:
Router# show idmgr session key ip-address
10.0.0.1
Step 4
show ip route [vrf vrf-name]
Example:
Router# show ip route
How to Configure ISG Access for PPP Sessions Using Control Policies
Displays information related to ISG session and service identity.
Displays the current state of the routing table.
Troubleshooting ISG Access for PPP Sessions
The commands in this task can be used to monitor and troubleshoot Layer 2 sessions. All of these commands are optional and do not need to be entered in a particular order.
SUMMARY STEPS
1. enable
2. show subscriber session detailed
3. debug condition
4. debug subscriber packet [event | full | detail]
5. debug subscriber error
6. debug subscriber event
7. debug subscriber fsm
8. debug ppp {packet | negotiation | error | authentication | subscriber switch}
DETAILED STEPS
Command or Action Purpose
Step 1
Step 2
enable
Example:
Router> enable
show subscriber session detailed
Enables privileged EXEC mode.
Enter your password if prompted.
Displays information about ISG subscriber sessions.
Example:
Router# show subscriber session detailed
7
How to Configure ISG Access for PPP Sessions Using Control Policies
Command or Action Purpose
Step 3
debug condition condition
Example:
Router# debug condition username user5@isp.com
Step 4
debug subscriber packet [event | full | detail]
Example:
Router# debug subscriber packet event
Step 5
debug subscriber error
Example:
Router# debug subscriber error
Step 6
debug subscriber event
Configuring ISG Access for PPP Sessions
Filters debug output on the basis of the specified condition.
Note See the module “Troubleshooting ISG with Session
Monitoring and Distributed Conditional Debugging” for information about conditional
debugging.
Displays diagnostic information about packets during Subscriber Service Switch (SSS) call setup.
Displays diagnostic information about errors that can occur during SSS call setup.
Displays diagnostic information about SSS call setup events.
Step 7
Step 8
Example:
Router# debug subscriber event
debug subscriber fsm
Example:
Router# debug subscriber fsm
debug ppp {packet | negotiation | error | authentication | subscriber switch}
Example:
Router# debug ppp packet
Displays diagnostic information about the SSS call setup state.
Displays information on traffic and exchanges in an internetwork that is imple menting the PP P.
8
Configuring ISG Access for PPP Sessions
Example
In the following example, the output of the debug subscriber packet detail command is filtered on the basis of the username “cpe6_1@isp.com”:
Router# debug condition username cpe6_1@isp.com
Condition 1 set
Router# show debug
Condition 1: username cpe6_1@isp.com (0 flags triggered)
Router# debug subscriber packet detail
SSS packet detail debugging is on
Router# show debug
SSS:
SSS packet detail debugging is on
Condition 1: username cpe6_1@isp.com (0 flags triggered)
Configuration Examples for ISG Access for PPP Sessions
Router#
Configuration Examples for ISG Access for PPP Sessions
This section contains the following examples:
Configuring ISG Access for PPP Sessions: Example, page 9
VRF Transfer for PPP Sessions Using IPCP Renegotiation: Example, page 11
Configuring ISG Access for PPP Sessions: Example
The following example shows the configuration of an ISG policy that provides services to PPP subscribers. This example configures ISG to perform the following actions:
PPP local termination
ISG will provide local termination by activating the service “ispa” for subscribers matching the domain “ispa”. The system will authenticate the subscriber using method-list “list1”. For local termination services, the global VRF is applied by default unless another VRF is specified in the service profile, on the interface, or in the virtual template.
PPP authentication before forwarding
ISG will locally authenticate subscribers matching domain “isp b” before forw arding the session s to an LNS. (Sessions are forwarded to an LNS because service policy map “ispb” specifies a VPDN group). The system will authenticate the subscribers using method-list “list2”.
PPP forwarding without local authentication
ISG will forward sessions to an LNS without local authentication for subscribers matching domain “ispc”.
PPP domain exclusion
9
Configuration Examples for ISG Access for PPP Sessions
ISG will deny service to and disconnect the session for subscribers matching domain “ispd”.
PPP domain-based service activation
For subscribers matching all other domains, ISG will activate a service that has the same name as the specified domain.
Configure control class maps, which define the conditions that must be met before a control policy rule will be executed.
class-map type control match-all PPP_SESSION match protocol ppp
class-map type control match-all NAS_PORT_CONDITION class type control match identifier name PPP_SESSION less-than identifier nas-port type atm vpi 200 vci 100
class-map type control match-all ISPA match unauthenticated-domain ispa
class-map type control match-all ISPB match unauthenticated-domain ispb
class-map type control match-all ISPC match unauthenticated-domain ispc
class-map type control match-all ISPD match unauthenticated-domain ispd
Define the top-level control policy map.
policy-map type control L2_ACCESS
Configuring ISG Access for PPP Sessions
Define a control policy rule that activates a forwarding service on the basis of the ATM VPI/VCI on which the call came in.
class type control NAS_PORT_CONDITION event session-start
1 service-policy type service xconnect
Define a control policy rule that collects the domain name from the protocol. The domain name is available from a structured user name (e.g., user@domain).
class type control PPP_SESSION event session-start
1 collect identifier unauthenticated-domain 2 service-policy type control DOMAIN_BASED_ACCESS
Define the nested control policy.
policy-map type control DOMAIN_BASED_ACCESS
Define a control policy rule that provides local termination by activating the service “ispa”.
class type control ISPA event session-start
1 authenticate aaa list list1 2 service-policy type service ispa
Define a control policy rule that configures the system to authenticate the subscriber locally before activating service “ispb”. The service “ispb” specifies forwarding the session to an LNS.
class type control ISPB event session-start
1 authenticate aaa list list2 2 service-policy type service ispb
Define a control policy rule that activates service “ispc”, which specifies forwarding.
class type control ISPC event session-start
10
Configuring ISG Access for PPP Sessions
1 service-policy type service ispc
Define a control policy rule that results in session disconnection for subscribers that match service “ispd”.
class type control ISPD event session-start
service disconnect
Define a control policy rule that defines the default for all other domains, which is to activate a service having the same name as the specified domain.
class type control always event session-start
service-policy type service identifier unauthenticated-domain
Configure the service policy maps.
policy-map type service xconnect service vpdn group 1
policy-map type service ispa service local ip vrf forwarding red
policy-map type service ispb service vpdn group 2
policy-map type service ispc service vpdn group 3
Apply the control policy map globally.
service-policy type control L2_ACCESS
Configuration Examples for ISG Access for PPP Sessions
VRF Transfer for PPP Sessions Using IPCP Renegotiation: Example
The following example shows a configuration that uses PPPoE to establish a session, and the RADIUS service profile that is created to associate the VRF. In this example, when a PPP session initially comes up, it belongs to the default rout ing table, and the IP address i s assigned from the def ault IP ad dress pool “DEF-POOL”. When the subscriber selects the “ISP-RED” service, ISG downloads the “ISP- RED” service profile and applies it to the session. The PPP session is then transferred to VRF “RED”. IPCP renegotiation occurs between the client d evice and the ISG device, and the subscriber is assigned a new IP address from the pool “POOL-RED”.
ip vrf RED
rd 1:1
interface Loopback0 ip address 10.0.0.1 255.255.255.0
interface Loopback1 ip address 20.0.0.1 255.255.255.0
ip vrf forwarding RED ! interface GigabitEthernet0/0/0 pppoe enable
interface Virtual-Template1 ip unnumbered Loopback0 service-policy control RULE2 peer default ip address pool DEF-POOL ppp authentication chap
11
Additional References
ip local pool DEF-POOL 172.16.5.1 172.16.5.250 ip local pool POOL-RED 172.20.5.1 172.20.5.250
Service profile for ISP RED
Cisco-AVpair = ip:vrf-id=RED Cisco-AVpair = "ip:ip-unnumbered=loopback 1" Cisco-AVpair = ip:addr-pool=POOL-RED Cisco-AVpair = subscriber:sg-service-type=primary Cisco-AVpair = subscriber:sg-service-group=RED-GROUP Cisco-SSG-Service-Info = IPPPOE-RED Cisco-SSG-Service-Info = R10.1.1.0;255.255.255.0 Framed-Protocol = PPP Service-Type = Framed
Additional References
The following sections provide references related to ISG access for PPP sessions.
Configuring ISG Access for PPP Sessions
Related Documents
Related Topic Document Title
ISG commands Cisco IOS Intelligent Services Gateway Command Reference AAA configuration tasks The “Authentication, Authorization, and Accounting (AAA)”
section in the Cisco IOS XE Security Configuration Guide AAA commands Cisco IOS Security Command Reference PPP configuration tasks The “PPP Configuration” section of the Ci sco IOS XE Dial Services
Configuration Guide
PPP commands Cisco IOS Dial Services Command Reference
12
Configuring ISG Access for PPP Sessions
Feature Information for ISG Access for PPP Sessions
Technical Assistance
Description Link
The Cisco Support website provides extensive online resources, including documentation and tools for troubleshooting and resolving technical issues with Cisco products and technologies.
To receive security and technical information about your products, you can subscribe to various services, such as the Product Alert Tool (accessed from Field Notices), the Cisco Technical Services Ne wsletter , and Really Simple Syndication (RSS) Feeds.
Access to most tools on the Cisco Support website requires a Cisco.com user ID and password.
http://www.cisco.com/public/support/tac/home.shtml
Feature Information for ISG Access for PPP Sessions
Table 1 lists the features in this module and provides links to specific configuration information. For
information about a feature in this technology that is not documented here, see the “Intelligent Services
Gateway Features Roadmap.”
Use Cisco Feature Navigator to find information about platform support and software image support. Cisco Feature Navigator enables you to determine which Cisco IOS XE software images support a specific software release, feature set, or platform. To access Cisco Feature Navigator, go to
http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
Note Table 1 lists only the Cisco IOS XE s oftware release that introduced support for a given feature in a
given Cisco IOS XE software release train. Unless noted othe rwise, su bsequent releases of that Cisco IOS XE software release train also support that feature.
Table 1 Feature Information for ISG Layer 2 Access
Feature Name Releases Feature Configuration Information
ISG:Session: Creation: P2P Session (PPPoE, PPPoXoX)
Cisco IOS XE Release 2.2
The ISG session is the primary context to which services and policies are associated across specific data flows. Point-to-point (P2P) sessions are established through a signaling protocol. ISG handles many variants of P2P encapsulation, such as PPP, PPPoE and PPPoA.
The following sections provide information about this feature:
Information About Configuring ISG Access for PPP
Sessions, page 2
How to Configure ISG Access for PPP Sessions
Using Control Policies, page 4
13
Feature Information for ISG Access for PPP Sessions
CCDE, CCENT, CiscoEos, Cisco HealthPresence, the Cisco logo, Cisco Lumin, Cisco Nexus, Cisco StadiumVision, Cisco TelePresence, Cisco WebEx, DCE, and Welcome to the Human Network are trademarks; Changing the Way We Work, Live, Play, and Learn and Cisco Store are service marks; and Access Registrar, Aironet, AsyncOS, Bringing the Meeting To You, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, CCVP , Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Collaboration Without Limitation, EtherFast, EtherSwitch, Event Center, Fast Step, Follow Me Browsing, FormShare, GigaDrive, HomeLink, Internet Quotient, IOS, iPhone, iQuick Study, IronPort, the IronPort logo, LightStream, Link sys , Medi aTone, MeetingPlace, MeetingPlace Chime Sound, MGX, Networkers, Networking Academy, Network Registrar, PCNow, PIX, PowerPanels, ProConnect, ScriptShare, SenderBase, SMARTnet, Spectru m Expert, St ackWise, The Fastest W ay to Increase Your Internet Quotient, TransPath, W ebEx, and th e WebEx logo are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0812R)
Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.
© 2006–2009 Cisco Systems, Inc. All rights reserved.
Configuring ISG Access for PPP Sessions
14
Configuring ISG Access for IP Subscriber Sessions
First Published: December 5, 2006 Last Updated: November 25, 2009
Intelligent Services Gateway (ISG) is a Cisco IOS XE software feature set that provides a structured framework in which edge de v ices can deli v er fle xible and scalable services to subscribers. ISG supports IP sessions for subscribers who connect to ISG from routed, Layer 2 or Layer 3 access networks. This module describes how to configure ISG to bring up IP subscriber sessions, manage subscriber IP addressing, and configure dynamic Virtual Private Network (VPN) selection.
Note This document assumes that Network Address Translation is pe rformed on a Layer 3 g ate way other than
the ISG.
Finding Feature Information
For the latest feature information and caveats, see the release notes for your platform and software release. To find information about the features documented in this module, and to see a list of the releases in which each feature is supported, see the “Feature Information for ISG Access for IP Subscriber Sessions”
section on page 40.
Use Cisco Feature Navigator to find information about platform support and Cisco IOS XE software image support. To access Cisco Feature Navigator, go to http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
Contents
Prerequisites for ISG Access for IP Subscriber Sessions, page 2
Restrictions for ISG Access for IP Subscriber Sessions, page 2
Information About ISG Access for IP Subscriber Sessions, page 3
How to Configure ISG for IP Subscriber Sessions, page 13
Americas Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
© 2009 Cisco Systems, Inc. All rights reserved.
Configuring ISG Access for IP Subscriber Sessions
Prerequisites for ISG Access for IP Subscriber Sessions
Configuration Examples for ISG Access for IP Subscriber Sessions, page 34
Additional References, page 38
Feature Information for ISG Access for IP Subscriber Sessions, page 40
Prerequisites for ISG Access for IP Subscriber Sessions
For information about release and platfor m requiremen ts, s ee the “Feature Information for ISG Access for
IP Subscriber Sessions” section on page 40.
Dynamic Host Configuration Protocol (DHCP) server must support the DHCP lease protocol.
Restrictions for ISG Access for IP Subscriber Sessions
Overlapping IP Address Restrictions
Overlapping IP addresses in the same virtual routing and forwarding (VRF) instance are not supported. Overlapping IP subscribers in different VRFs are not supported on the same interface for static IP
subscriber sessions and routed IP subscriber sessions. Overlappin g IP subscrib er s in different VRFs are supported on the same interface for Layer 2 connecte d Dynamic H ost Configuration Proto col (DHCP) subscriber sessions.
IP Subnet Session Restrictions
IP subnet sessions are not supported on an interface configured with the ip subscriber l2-connected command. IP subnet sessions are supported only when the ip subscriber routed command is conf igured on the interface.
ISG DHCP Restrictions
ISG cannot relay DHCP requests when a Layer 3 DHCP relay agent is between the ISG device and subscriber devices.
Dynamic VPN Selection Restrictions
Dynamic VPN selection is not supported for IP subnet sessions and subscribers coming in on nonglob al VRF interfaces.
Dynamic VPN selection is not supported for subscribers with a static VPN configuration on the access interface.
Dynamic VPN selection with address reassignment is not supported for routed IP subscriber sessions that are initiated by DHCP . IP addresses of routed IP subscribers must be routable in the access network. Because Internet service provider (ISP) or VRF-owned priv ate addresses could o verlap or be unroutabl e in the network between subscribers and the ISG device, it is not possible to assi gn IP addresses to tho se subscribers.
General IP Session Restrictions
Packet of Disconnect (PoD) is not supported for IP subscriber sessions. IP subscriber sessions are not supported on ambiguous IEEE 802.1QinQ (QinQ) or IEEE 802.1Q
(Dot1Q) subinterfaces.
2
Configuring ISG Access for IP Subscriber Sessions
IP subscriber sessions are not supported on interfaces that receive multiprotocol label swit ching (MPLS) packets.
Modular quality of service (QoS) command-line interface (CLI) based (MQC) shaping and queueing is supported in the egress direction in the default class for IP subscriber sessions.
ISG IP subscriber functionality is not supported on the following types of access interfaces:
Gigabit EtherChannel (Port Channel)
Generic routing encapsulation (GRE)
PPP (virtual-template)
Layer 2 Tunnel Protocol (L2TP)
ISG IP interface sessions are not supported. Interface statistics are not generated for ISG multiservice interfaces. Stateful switchover (SSO) and In Service Software Upgrade (ISSU) are not supported for ISG IP
subscriber sessions or traffic class sessions. Upon switchover, an IP session must be re-created or restarted (for DHCP sessions) when the session becomes active again.
SSO and ISSU are not supported for any features on IP subscriber sessions or traffic class sessions.
Information About ISG Access for IP Subscriber Sessions
Information About ISG Access for IP Subscriber Sessions
Before you configure ISG access for subscriber sessions, you should understand the following concepts:
Types of IP Subscriber Sessions, page 3
IP Subscriber Connectivity, page 5
IP Subscriber Session Initiation, page 6
IP Subscriber Addressing, page 6
IP Subscriber Identity, page 8
VPN Connectivity and Services for IP Subscribers, page 10
IP Session Termination, page 12
IP Session Recovery for DHCP-Initiated IP Sessions, page 13
Default Services for IP Subscriber Sessions, page 13
Types of IP Subscriber Sessions
ISG supports the following types of IP subscriber sessions on Cisco IOS XE software:
IP Sessions, page 4
IP Interface Sessions, page 4
IP Subnet Sessions, page 4
3
Information About ISG Access for IP Subscriber Sessions
IP Sessions
An IP session includes all the traffic that is associated with a single subscriber IP address. If the IP address is not unique to the system, other distinguishing characteristics such as a VRF or MAC address form part of the identity of the session. ISG can be configured to create IP sessions upon receipt of DHCP packets, packets with unclassified IP or MAC addresses, or RADIUS packets. See the “IP Subscriber
Session Initiation” section on page 6 for more information.
IP sessions may be hosted for a connected subscriber de vice (one routing hop from the ISG) or one that is more than one hop from the gateway.
IP Interface Sessions
An IP interface session includes all IP traffic received on a specific physical or virtual interface. IP interface sessions are provisioned through the CLI; that is, a session is created when the IP interface session commands are entered, and the session is continuous, even when the interface is shut down. By default, IP interface sessions come up in the state “unauthenticated” with full network access.
IP interface sessions might be used in situations in which a subscriber i s represented by an interface (with the exception of PPP) and communicates using more than one IP address. For example, a subscriber using routed bridge encapsulation (RBE) access might have a dedicated ATM virtual circuit (VC) to home customer premises equipment (CPE) that is hosting a number of PCs.
Configuring ISG Access for IP Subscriber Sessions
IP Subnet Sessions
An IP subnet session represents all the traff ic that is associated with a single IP subnet. IP subnet sessions are used to apply uniform edge processing to packets associated with a particular IP subnet. When an IP subnet session is configured, ISG treats the subnet as a single subscriber, which means that ISG features and functionality are applied to the subnet traffic as an aggregate.
IP subnet sessions are supported for routed IP subscriber traffic. IP subnet sessions are created the same way as IP sessions, except that when a subscriber is authorized
or authenticated and the Framed-IP-Netmask attribute is present in the user or service profile, ISG converts the source-IP-based session into a subnet session with the subnet value in the Framed-IP-Netmask attribute.
Note Where an ingress interface ma ps to a single subnet, the subnet might be accommoda ted with an IP
interface session. However, if the ISG is more than one hop away from a subscriber, and there is the possibility that multiple subnets are accessible through the same interface, IP subnet sessions may be defined to distinguish the traffic and apply appropriate edge functionality to each subnet.
Coexistence of Multicast and IP sessions
The ISG Session Multicast Coexistence feature introduces the ability to host all the subscribers and services (data and multicast) on the same VLAN by enabling multicast and IP sessions to coe xist on th e same subinterface for Cisco ASR 10000 Series Aggregation Routers. ISG IP sessions are supported on nonaccess-type subinterfaces. In the case of an existing session or even when no session exists, this support helps the multicast traffic to pass through the interfaces configured for the IP sessions in both upstream and downstream directions without creating a session.
4
Configuring ISG Access for IP Subscriber Sessions
IP Subscriber Connectivity
IP subscribers connect to ISG through either Layer 2 connected access networks or routed access networks. The following sections describe these types of IP subscriber connectivity:
Layer 2 Connected Access Networks
Routed Access Networks
Layer 2 Connected Access Networks
Layer 2 connected subscribers are either directly attached to the physical interfaces of an ISG or connected to an ISG through a Layer 2 access network, such as a bridged or a switched netw ork. Layer 3 forwarding is either absent or not used to direct subscriber traffic in the Layer 2 access network. IP addresses of the subscribers may or may not be on the same subnet as the Layer 2 connected physi cal interfaces. Figure 1 shows an example of a Layer 2 connected access network.
Figure 1 Layer 2 Connected Access Network
Information About ISG Access for IP Subscriber Sessions
IP subscriber
IP subscriber
Routed Access Networks
Routed subscriber traffic is routed through a Layer 3 access network with at least one transit router before reaching the ISG. IP addresses of the subscribers are at least routable in the Layer 3 access network. Layer 3 access networks contain a single routing domain and therefore do not support overlapping IP addresses. Figure 2 shows an example of a routed access network.
Bridged/switched
access network
Core network
ISG
230024
5
Information About ISG Access for IP Subscriber Sessions
Figure 2 Routed Access Network
Configuring ISG Access for IP Subscriber Sessions
access network
IP subscriber
IP subscriber
IP Subscriber Session Initiation
ISG can be configured to allow one or more of the following events to signal the start of an IP session or IP subnet session on an interface:
DHCP DISCOVER packet
If the following conditions are met, receipt of a DHCP DISCOVER packet will trigger the creation of an IP session:
The ISG serves as a DHCP relay or server for new IP address assignments.
Subscribers are configured for DHCP.
The DHCP DISCOVER packet is the first DHCP request received from the subscriber.
Unclassified source IP address
Routed
Core network
ISG
230025
For routed IP subscribers, a new IP session is triggered by the appearance of an IP packet with an unclassified source IP address (which means that an IP session does not yet e xist for that IP addr ess).
Unclassified source MAC address
For Layer 2 connected IP subscribers, a new I P session is triggered by the appearance of an IP packet with an unclassified source MAC address (which means that an IP session does not yet e xist for that MAC address).
RADIUS Access-Request packet
For routed or Layer 2 connected access, a new IP session is triggered by the appearance of a RADIUS Access-Request packet when ISG is serving as a RADIUS proxy.
IP Subscriber Addressing
The following sections provide information about how ISG handles IP addressing for IP subscribers:
Methods of ISG Subscriber IP Address Assignment
Public and Private IP Addresses
Overlapping IP Addresses
ISG Subscriber IP Address Assignment Using DHCP
6
Configuring ISG Access for IP Subscriber Sessions
Methods of ISG Subscriber IP Address Assignment
IP subscribers either have IP addresses configured statically or obtain IP addresses dynamically throug h some network protocol that has the ability to assign IP addresses. For a subscriber to be routable within a given IP service domain, the subscriber must pr esent a domain-specif ic IP address to the network. If a subscriber transfers between IP service domains (which include any private domain managed by the access provider), the IP address presented to the network must change to reflect th e new domain.
The following sections describe the methods of IP address assignment that ISG supports for each type of Layer 3 session:
IP Interface Sessions
IP Sessions
IP Subnet Sessions
IP Interface Sessions
For IP interface sessions, ISG is not inv olv ed in (or aw are of) the assignment of subscriber IP addresses.
IP Sessions
Information About ISG Access for IP Subscriber Sessions
IP Subnet Sessions
For IP sessions, ISG supports the following methods of IP address assignment:
Static IP addresses
If a subscriber’s static IP address is configured correctly for the service domain, ISG does not have to be involved in the assignment of an IP address for the subscriber.
DHCP
If DHCP is being used to assign IP addresses, and the IP address that is assigned by DHCP is correct for the service domain, ISG does not have to be involved in the assignment of an IP address for the subscriber.
If the IP address that is assigned by DHCP is not correct for the service domain, or if the domain changes because of a VRF transfer, ISG can be configured to influence the DHCP IP address assignment.
The following conditions must be met in order for ISG to influence DHCP IP address assignment:
The subscriber must be Layer 2 connected.
The ISG device must be in the path of DHCP requests by serving as a DHCP server or relay.
Subscribers must not have statically configured IP addresses.
For deployments that support it, DHCP is the recommended method of IP address assignment.
For IP subnet sessions, the IP subnet is specified in the user profile.
Public and Private IP Addresses
No matter how an IP subscriber is assigned an IP address, the IP address falls in either the public or the private IP address category. If an IP subs criber is assigned with a private IP address and the subscriber has to reach the Internet, a Layer 3 gateway, such as ISG or a firewall, between the subscriber and the Internet must perform network address translation (NAT) for the subscriber’s private IP address.
7
Information About ISG Access for IP Subscriber Sessions
When the access network is a Layer 2 connected network, a subscriber IP address can be either native or foreign to an access interface. A native subscriber IP address is one that belongs to the subnet provisioned on the access interface. A foreign subscriber IP address is one that does not belong to the subnet provisioned on the access interface. A foreign subscriber IP address could result when a retail ISP assigns an IP address to the IP subscriber from its own IP address allotment, which is different from the wholesale ISPs, or when an IP subscriber with a static IP address that is native in the home access network roams to a foreign access network. To support IP subscribers with foreign IP addresses, ISG must be able to respond to Address Resolution Protocol (ARP) requests that originate from foreign IP addresses with a MAC address of the ISG itself. Because the access network is Layer 2 connecte d, ISG maintains an adjacency to every subscriber.
When the access network is a routed network, a subscriber IP address must be routable in the access network; otherwise, subscriber traffic will never be able to reach ISG. ISG may not have an adjacency for each subscriber in this case, but rather an adjacency of the next hop toward a subscriber. The next hop is determined by the routing process on ISG.
Overlapping IP Addresses
When an access network is deployed without VPN capability, the IP address space in the access network is shared among all IP subscribers. When the IP addresses are assigned dynamically, care must be taken to ensure that these addresses do not overlap. In cases where overlapping IP addresses are assigned to IP subscribers intentionally , th e access network should use a Laye r 2 separation mechanism to dif feren tiate the IP address spaces. For example, the access network may put each IP address space in a different VLAN.
In cases in which the access network serves both local IP subscribers and roaming users, the static pri vate IP address of a roaming subscriber may overlap the native private IP address of another subscriber. For example, a public wireless hot spot that generally assigns dynamic IP addresses might want to provide access to occasional roaming users with statically configured IP addresses. To support this special overlapping condition, all IP subscribers must be in a Layer 2 connected access network in which overlapping MAC addresses do not exist. In this case, IP subscribers can be distinguished using MAC addresses.
Configuring ISG Access for IP Subscriber Sessions
ISG Subscriber IP Address Assignment Using DHCP
When ISG is in the path of DHCP requests (as either a DHCP server or a DHCP relay), ISG can influence the IP address pool and DHCP server that are used to assign subscriber IP addresses. To enable ISG to influence the IP addresses assigned to subscri bers, a ssoci ate a DHCP a ddress pool class with an address domain. The DHCP address pool class must also be configured in a service policy map, service profile, or user profile that is associated with a subscriber. Whe n a DHCP request is received from a subscriber, DHCP uses the address pool class that is associated with the subscriber to determine which DHCP address pool should be used to service the request. As a result, on a per-request basis, an IP address is provided by the local DHCP server or relayed to a remote DHCP server that is defined in the selected pool.
IP Subscriber Identity
IP subscriber identity is closely related to IP session initiat ion because ISG must uniquely iden tify an IP subscriber at the moment that it creates the IP session. However, the need to identify an IP subscriber goes beyond the session initiation phase. The following sections describe how ISG uniquely identifies IP subscribers:
8
Configuring ISG Access for IP Subscriber Sessions
Routed IP Subscriber Identity
MAC Address as Secondary Identity
DHCP Lease Query Support
Layer 2 Connected IP Subscriber Identity
Routed IP Subscriber Identity
If the access network is a routed network, subscriber IP addresses can be used to uniquely identify IP subscribers because by definition subscriber IP addresses are at least routable in the access network.
When using a subscriber IP address as the identifier, ISG assumes that the subscriber IP address is unique. If the access network is deployed with Layer 3 load balancing, redundancy, or asymmetric routing, ISG also assumes that IP tr affic from the same IP subscriber may arrive at different access interfaces. To support this type of deployment, ISG assumes a single IP address space for all the access interfaces connecting to the same access network.
If there is a requirement to support several IP address spaces over a single physical access network, the access network must use some Layer 2 encapsulation to create a separate logical access network for each IP address space. In this case, ISG can still have a single IP address space for all the logical access interfaces that connect to a logical access network.
When subscriber IP addresses are private IP addresses, the access network must be able to route such subscriber traffic. If the subscriber traffic is destined to the Internet, NAT must be performed.
Information About ISG Access for IP Subscriber Sessions
For routed IP subscribers, the subscriber IP address serves as the key for an IP session. ISG associates IP traffic with an IP session as follows:
In the upstream direction, the source IP address of an IP packet is used to identify the IP session.
The source IP address is the subscriber IP address.
In the downstream direction, the destination IP address of an IP packet is used to identify the IP
session. The destination IP address is the subs criber IP address.
If the IP subscriber is a VPN user, the subscriber IP address must be routable in both the global routing table and the VPN routing table on the ISG.
In the case of an IP subnet subscriber, a subscriber IP address is defined as an IP prefix address instead of a /32 IP host address. This IP prefix covers a range of IP addresses used by end users but represents a single logical IP subscriber from the ISG point of view . In th is deployment, all end users share the same connectivity and services provided by the ISG.
T o normalize the classificati on of IP subscribers that have dif ferent network masks, ISG uses the netw ork mask in conjunction with the subscriber IP address for routed IP subscribers.
MAC Address as Secondary Identity
You must configure the collect identif i er mac-addr ess command at the start of a session. This instructs the ISG devices to store the MAC address as part of the session identifiers. For routed IP subscriber sessions, the MAC address is collected from the DHCP server using the DHCP Lease Query Protocol. For information about conf iguri ng the com mand, see the “Con fig uring ISG Control Poli cies” module in the Cisco IOS ISG Configuration Guide.
9
Information About ISG Access for IP Subscriber Sessions
DHCP Lease Query Support
The DHCP Lease Query message is a DHCP message type transmitted from a DHCP relay agent to a DHCP server. A DHCP Lease Query aware relay agent sends the location of an IP endpoint to the DHCP Lease Query message.
The DHCP Lease Query transaction is a DHCP transaction with special message types that enable clients to query DHCP servers regarding the owner and the lease expiration time of an IP address. For information about configuring DHCP server for Lease Query, see the “Configuring a DHCP Server IP
Address” section on page 28.
Layer 2 Connected IP Subscriber Identity
A Layer 2 connected access network is capabl e of providing IP connectivity to IP subscrib ers with foreign and overlapping IP addresses, in addition to IP subscribers with native IP addresses. Because subscriber IP addresses might not be unique in such an access network, ISG uses the subscriber MAC address to identify Layer 2 connected IP subscribers, regardless of what kind of IP address a subscriber has.
Traffic that comes from IP subscribers with private or overlapping IP addresses and that is destined to the Internet is subject to NAT.
Configuring ISG Access for IP Subscriber Sessions
For Layer 2 connected IP subscribers, both the subscriber MAC address (unique within a VLAN) and the IP address serve as the keys for the IP session, but they are used in different directions:
In the upstream direction, the VLAN ID and source MA C address of an IP packet are used to identify
the IP session.
In the downstream direction, both the destination IP address and the VLAN ID of an IP packet are
used to identify the IP subscriber context.
VPN Connectivity and Services for IP Subscribers
The following sections provide informatio n about VPN connectivity and services for ISG IP subscribers:
Subscriber VPN Membership
VPN Addressing
VPN IP Subscriber Identity
Service Model for VRF Transfers
Benefits of Dynamic VPN Selection
Subscriber VPN Membership
Depending on deployment requirements, an IP subscriber may or may not have VPN service. If an IP subscriber does have VPN service, the subscriber may belong to only one VPN domain at any time. An IP subscriber is associated with a VPN domain in one of the following ways:
Static VPN assignment—The VPN IP subscriber belongs to a static VPN domain. Whenever the IP
subscriber connects to ISG, the IP subscriber is placed in the preassigned VPN domain.
Dynamic VPN selection—The VPN IP subscriber can choose and switch among different VPN
domains through dynamic service logon. Whenever a new VPN domain is selected, VPN services of the current VPN domain must be removed before VPN services of the new VPN domain can be applied to the IP subscriber.
10
Configuring ISG Access for IP Subscriber Sessions
Dynamic VPN selection can be initiated through automatic service logon, where the VRF is downloaded and applied to the subscriber session at session start, or through subscriber service selection at a web portal, in which case the subscriber is transferred to the VRF that corresponds to the selected service.
VPN Addressing
When a subscriber session is transferred from one VPN domain to another, it is effectively entering a new addressing domain that may or may not overlap the subscriber’s previous domain. The subscriber’s network-facing address must be altered accordin gly so that packets can be corre ctly routed back from within the service domain.
A VRF transfer is necessary when a subscriber’s identity and subscribed services cannot be determined without interaction with a web portal. A local routing context is required, at least initially, so that IP packets may be routed to and from the portal server. Following portal-based service selection, the subscriber would typically have to be transferred into the VRF associated with the selected service domain. Following a VRF transfer, the subscriber must also receive an address that is routable in this new domain.
If ISG is adjacent to the subscriber device and serves as a DHCP relay or server, DHCP can be used to assign domain-specific addresses to subscribers.
In order for VRF transfers to be supported, it is strongly recommended that DHCP be configured with short initial leases, this is because existing subscriber addresses can only be altered once the current lease has expired. Subscribers will not have access to the selected domain before the next DHCP renew request is received. Using short initial lease times minimizes the interval between a VRF change and a DHCP renewal. If long lease times are used, an out-of-band method of initiating IP address change should be implemented.
Information About ISG Access for IP Subscriber Sessions
When DHCP can be used to assign a new address at the subscriber device, subnet-based VRF selection can be used to bring about the transfer. Subnet-based VRF selection (also known as VRF autoclassify) is a feature that selects the VRF at the ingress port on the basis of the source IP subnet address.
Service providers and orga nizations have allocated pub lic IP address blocks that are not overlapping by nature. Therefore, when they are assigned public IP addresses, VPN IP subscribers have no overlapping IP addresses. When VPN IP subscribers of different VPN domains have private IP addresses assigned, they are likely to have overlapping addresses in the access network.
An access network is a single IP address space when there is no Layer 2 encapsulatio n separ a ting VP N IP subscribers of different VPN domains. Therefore, ISG must be able to handle overlapping IP addresses when deploying VPN IP subscribers. IP connectivi ty for VPN IP subscribers with ov erlapping IP addresses is possible only when they are connected to ISG through a Layer 2 connected access network.
VPN IP Subscriber Identity
ISG identifies VPN IP subscribers in the same way that it identifies non-VPN IP subscribers. Upstream IP traffic is defined as the subscriber IP traffic traveling from the access network to the VPN (overlaid on top of the service provider core network). Downstream IP traffic is defined as the subscriber IP traffic traveling from the VPN to the access network.
11
Information About ISG Access for IP Subscriber Sessions
Service Model for VRF Transfers
A primary service is a service that contains a network-forwarding policy (such as a VRF) in its service definition. Only one primary service at a time can be activated for a session. A secondary service is any service that does not contain a network-forwarding policy.
When a subscriber for whom a primary service has already been activated tries to select another primary service, ISG will deactivate all current services (including the current primary service) and activate the new primary service, and hence switch the VRF.
When a subscriber for whom a primary service has already been activated tries to select a secondary service, the action taken by ISG depends on whether the secondary service is part of a service group. A service group is a grouping of services that may be simulta neously active for a given session. Typically, a service group includes one primary service and one or more secondary services. Table 1 describes the action that ISG will take when a subscriber selects a secondary service.
Table 1 ISG Activation Policy for Secondary Services
Primary Service Characteristics Secondary Service Characteristics Resulting Behavior at ISG
Primary service with no service group attribute
Primary service with service group attribute
Configuring ISG Access for IP Subscriber Sessions
Secondary service with service group
Secondary service with no service group
Secondary service with different service group
Secondary service with same service group
Secondary service with no service group
Do not bring up the secondary service.
Bring up the secondary service.
Do not bring up the secondary service.
Bring up the secondary service.
Bring up the secondary service.
Benefits of Dynamic VPN Selection
The need for switching of a subscriber session be tween rout ing and forwarding domains (al so called network services) occurs frequently in markets where so-called equal access networking must be supported. Equal access networking is often mandated by regulatory rules stating that an access provider should allow service providers equal access to a retail subscriber network. ISG dynamic VPN selection facilitates equal access networking by allowing subscribers to transfer between network services.
IP Session Termination
An IP session may be terminated in one of the following ways:
DHCP Lease Expiry or DHCP Release from client
If DHCP is used to detect a new session, its departure may also be signaled by a DHCP event.
Application stop
An application command that is used to terminate a session. The application stop command is typically used to terminate a session when a subscriber initiates an account logoff from a web portal. An application stop may also result from the actions of an administrator, such as action taken in response to rogue behavior from a subscriber.
12
Configuring ISG Access for IP Subscriber Sessions
Idle timeout and session timeout
Idle timeouts and session timeouts can be used to detect or impose termination of an IP session.
Control policy
A control policy containing the “service disconnect” action can be used to terminate a session.
IP Session Recovery for DHCP-Initiated IP Sessions
When an IP session is terminated (for example, by account logoff or session timeout) or lost (for example, by router reload), the client may continue to hold an unexpired DHCP lease. When this happens, ISG performs a session restart to prevent the client’s IP connection from being stuck until the DHCP lease expires. A control policy can be configured to define the actions that ISG will take when the session restart event occurs. If a policy is not defined, a default policy will take effect. The default policy causes ISG to disconnect the session after 60 seconds following a session restart and is the equivalent of the following configuration:
policy-map type control GLOBAL
class type control always event session-restart
1 service disconnect delay 60
How to Configure ISG for IP Subscriber Sessions
This default policy appears in the output for the show subscriber policy rules command as follows:
Rule: internal-rule-session-restart
Class-map: always event session-restart
Action: 1 service disconnect delay 60 Executed: 0
Default Services for IP Subscriber Sessions
Newly created IP sessions may require a default service to allow subsequent subscriber packets to be processed appropriately; for example, to permit or force TCP packets to a captive portal where menu-driven authentication and service selection can be performed. A default service policy map or service profile may be configured for IP sessions to redirect traffic, enable port-bundle host-key functionality for session identification, or enable transparent autologon. A default service would also likely include a network service, which allows subscribers to access a web portal for authentication and service selection.
How to Configure ISG for IP Subscriber Sessions
Perform the following tasks to configure ISG Layer 3 access:
Creating ISG Sessions for IP Subscribers, page 13 (required)
Assigning ISG Subscriber IP Addresses Using DHCP, page 24 (required)
Configuring ISG Dynamic VPN Selection, page 29 (required)
Creating ISG Sessions for IP Subscribers
An ISG device creates IP sessions for IP traffic on subscriber -side interfaces. The following tasks enable IP sessions and indicate how sessions will be identified:
13
How to Configure ISG for IP Subscriber Sessions
Creating IP Subscriber Sessions for Routed ISG Subscrib ers, page 14 (required)
Creating IP Subscriber Sessions for Layer 2 Connected ISG Subscribers, page 15 (required)
Creating ISG IP Interface Sessions, page 17 (required)
Creating an ISG Static Session, page 18 (required)
Creating ISG IP Subnet Sessions, page 19 (required)
Configuring IP Session Recovery for DHCP-Initiated IP Sessions, page 20 (required)
Verifying ISG IP Subscriber Sessions, page 22 (optional)
Clearing ISG IP Subscriber Sessions, page 23 (optional)
Troubleshooting Tips, page 24 (optional)
Creating IP Subscriber Sessions for Routed ISG Subscribers
Routed IP subscribers are subscribers that are routed through a Layer 3 access network with at least one transit router before reaching the ISG. Perform this task to conf igure ISG to create IP sessions for routed IP subscribers.
Configuring ISG Access for IP Subscriber Sessions
SUMMARY STEPS
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
interface type number
1. enable
2. configure terminal
3. interface type number
4. ip subscriber routed
5. initiator {dhcp [class-aware] | radius-proxy | unclassified ip-address}
6. end
Enables privileged EXEC mode.
Enter your password if prompted.
Enters global configuration mode.
Specifies an interface and enters interface configuration mode.
Example:
Router(config)# interface gigabitethernet 0/0/0
Step 4
ip subscriber routed
Example:
Router(config-if)# ip subscriber routed
14
Specifies the type of IP subscriber to be hosted on the interface, and enters ISG IP subscriber configuration mode.
Configuring ISG Access for IP Subscriber Sessions
Command or Action Purpose
Step 5
initiator {dhcp [class-aware] | radius-proxy | unclassified ip-address}
Example:
Router(config-subscriber)# initiator dhcp
Step 6
end
How to Configure ISG for IP Subscriber Sessions
Configures ISG to create an IP subscriber session upon receipt of the specified packet type.
dhcp—ISG will initiate an IP session upon receipt of a
DHCP DISCOVER packet. The class-aware keyword allows ISG to influence the IP address assigned by DHCP by providing DHCP with a class name.
radius-proxy—ISG will initiate an IP session upon
receipt of a RADIUS Access-Request packet.
unclassified ip-address—ISG will initiate an IP
session upon receipt of the first IP packet with an unclassified IP source address.
This command can be entered more than once to
specify more than one method of IP session initiation.
Note If the ISG device serves as either a DHCP relay or
DHCP server in the assignment of client IP addresses, ISG must be configured to initiate IP sessions upon receipt of DHCP DISCOVER packets. In other words, the initiator dhcp command must be configured instead of the
initiator unclassified ip or initiator unclassified mac command.
(Optional) Returns to privileged EXEC mode.
Example:
Router(config-subscriber)# end
Creating IP Subscriber Sessions for Layer 2 Connected ISG Subscribers
Layer 2 connected subscribers are either directly attached to the physical interfaces of an ISG or connected to an ISG through a Layer 2 access network, such as a bridged network or a switched network. Perform this task to configure ISG to create IP sessions for Layer 2 connected IP subscribers.
SUMMARY STEPS
1. enable
2. configure terminal
3. interface type number
4. ip subscriber l2-connected
5. initiator {dhcp [class-aware] | radius-proxy | unclassified mac-address}
6. end
15
How to Configure ISG for IP Subscriber Sessions
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
interface type number
Example:
Router(config)# interface gigabitethernet 0/0/0
Step 4
ip subscriber l2-connected
Example:
Router(config-if)# ip subscriber l2-connected
Step 5
initiator {dhcp [class-aware] | radius-proxy | unclassified mac-address}
Example:
Router(config-subscriber)# initiator unclassified mac-address
Configuring ISG Access for IP Subscriber Sessions
Enables privileged EXEC mode.
Enter your password if prompted.
Enters global configuration mode.
Specifies an interface and enters interface configuration mode.
Specifies the type of IP subscriber to be hosted on the interface, and enters ISG IP subscriber configuration mode.
Note It is recommended that IP sessions for Layer 2
connected subscribers be configured using the ip subscriber l2-connected command. However, the ip subscriber routed command could also be used
if subscriber IP addresses are routable in the access domain.
Configures ISG to create an IP subscriber session upon receipt of the specified packet type.
dhcp—ISG initiates an IP session upon receipt of a
DHCP DISCOVER packet. The class-aware keyword allows ISG to influence the IP address assigned by DHCP by providing DHCP with a class name.
16
radius-proxy—ISG initiates an IP session upon recei pt
of a RADIUS packet.
unclassified mac-address—ISG will initiate an IP
session upon receipt of the first IP packet with an unclassified MAC source address.
This command can be entered more than once to
specify more than one method of IP session initiation.
Note If the ISG device serves as either a DHCP relay or
DHCP server in the assignment of client IP addresses, ISG must be configured to initiate IP sessions upon receipt of DHCP DISCOVER packets. In other words, the initiator dhcp command must be configured instead of the
initiator unclassified ip or initiator unclassified mac command.
Loading...
