User Guide
Explorer 8240C and 8300C
Digital Video Recorder with
Multi-Stream CableCARD Interface
POWER
AUX
INPUT
LIST
AUDIO VIDEOLR
GUIDE
INFO
EXIT
CH +
VOL +VOL -
CH - SELECT
Notice to Installers
The servicing instructions in this notice are for use by quali ed service personnel only. To reduce the risk of electric
shock, do not perform any servicing other than that contained in the operating instructions, unless you are quali ed
to do so.
Note to System Installer
For this apparatus, the coaxial cable shield/screen shall be
grounded as close as practical to the point of entry of the cable
into the building.For products sold in the US and Canada, this
reminder is provided to call the system installer's attention to
Article 820-93 and Article 820-100 of the NEC (or Canadian
Electrical Code Part 1), which provides guidelines for proper
grounding of the coaxial cable shield.
This symbol is intended to alert you that uninsulated voltage
within this product may have sufficient magnitude to cause
electric shock.Therefore, it is dangerous to make any kind of
contact with any inside part of this product.
Ce symbole a pour but d’alerter toute personne qu’un contact
avec une pièce interne de ce produit, sous tension et non isolée,
pourrait être suffisant pour provoquer un choc électrique. Il est
donc dangereux d’être en contact avec toute pièce interne de
ce produit.
CAUTION: To reduce the risk of electric shock, do not
remove cover (or back). No user-serviceable parts
inside. Refer servicing to qualified service personnel.
WARNING
TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
This symbol is intended to alert you of the presence
of important operating and maintenance (servicing)
instructions in the literature accompanying this product.
Ce symbole a pour but de vous avertir qu’une
documentation importante sur le fonctionnement et
l’entretien accompagne ce produit.
20070131 SysInstaller 820 US/Canada/Intl
ii
Contents
Important Safety Instructions.....................................................................................................iv
Welcome ...................................................................................................................................1
Safety First ................................................................................................................................ 1
For More Information .................................................................................................................1
Identify Your 8240C or 8300C .................................................................................................. 1
What’s On the Front Panel? ......................................................................................................2
What’s On the Back Panel? .......................................................................................................3
Connecting the DVR ..................................................................................................................4
Connections for a Standard-De nition TV and VCR ..................................................................5
View and Record Television Programming ................................................................................ 6
Performance Tips ...................................................................................................................... 7
Frequently Asked Questions .....................................................................................................7
Connecting to a Standard TV and Standard VCR ...................................................................... 8
Connecting to a Stereo TV and Stereo VCR ............................................................................. 9
Connecting to a Home Theater Receiver and Stereo TV ........................................................ 10
Connecting to an eSATA Hard Disk Drive (optional) ................................................................ 11
Index ....................................................................................................................................... 13
Compliance Information ............................................................................................ Back Cover
iii
IMPORTANT SAFETY INSTRUCTIONS
Read These Instructions
Keep These Instructions
Heed All Warnings
Follow All Instructions
Power Source Warning
A label on this product indicates the correct power source
for this product. Operate this product only from an electrical
outlet with the voltage and frequency indicated on the
product label. If you are uncertain of the type of power
supply to your home or business, consult your service
provider or your local power company.
Ground the Product
WARNING: Avoid electric shock and re
hazard! Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A
grounding-type plug has two blades and a third
grounding prong. The wide blade or the third
prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
If this product connects to coaxial cable wiring, be sure
the cable system is grounded (earthed). Grounding
provides some protection against voltage surges and
built-up static charges.
Antenna Lead In Wire
Ground Clamps
Electric Service
Equipment
NEC = National Electrical Code 1990
National Fire Protection Association
TO CATV INSTALLER
This reminder is provided to call the CATV system installer’s attention
to Article 820-40 of the National Electrical Code (NEC) that provides
guidelines for proper grounding, and in particular, specifies that the
cable ground shall be connected to the grounding system of the
building, as close to the point of entry as practical.
Antenna Discharge
Unit
(NEC Section 810-21)
Grounding
Conductors
(NEC Section 810-20)
Ground Clamps
Power Service
Grounding
Electrode System
(NEC Art 250, Part H)
WARNING: Avoid electric shock and re
hazard! Do not locate an outside antenna system
in the vicinity of overhead power lines or power
circuits. Touching power lines or circuits might
be fatal.
Protect the Product from Lightning
For added protection, unplug this apparatus during
lightning storms or when unused for long periods of time.
In addition to disconnecting the AC power from the wall
outlet, disconnect the signal inputs.
T15361
Outdoor Grounding System
If this product connects to an outdoor antenna or cable
system, be sure the antenna or cable system is grounded
(earthed). This provides some protection against voltage
surges and built-up static charges.
Article 810 of the National Electric Code (NEC) ANSI/NFPA
No. 70-1990, provides the following information:
• Grounding of the mast and supporting structure
• Grounding the lead-in wire to an antenna discharge unit
• Size of the grounding conductors
• Location of the antenna-discharge unit
• Connection to grounding electrodes
• Requirements for the grounding electrodes (see
the following antenna grounding diagram
as recommended by NEC ANSI/NFPA 70)
iv
Verify the Power Source from the On/O
Power Light
When the on/o power light is not illuminated, the apparatus
may still be connected to the power source. The light goes
out when the apparatus is turned o , regardless of whether
it is still plugged into an AC power source.
Eliminate AC Power/Mains Overloads
WARNING: Avoid electric shock and
re hazard! Do not overload AC power/mains,
outlets, extension cords, or integral convenience
receptacles. For products that require battery
power or other power sources to operate them,
refer to the operating instructions for those
products.
IMPORTANT SAFETY INSTRUCTIONS, continued
Prevent Power Cord Damage
Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the
point where the cord exits from the apparatus.
Provide Ventilation and Select a Location
• Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
• Do not place this apparatus on a bed, sofa, rug, or similar
surface.
• Do not place this apparatus on an unstable surface.
• Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampli ers) that produce heat.
• Do not install this apparatus in an enclosure, such as a
bookcase or rack, unless the installation provides proper
ventilation.
• Do not place entertainment devices (such as VCRs or
DVDs), lamps, books, vases with liquids, or other objects
on top of this product.
Operating Environment
This product is designed for operation indoors with a
temperature range from 32° to 104° F (0° to 40°C). Each
product should have adequate spacing on all sides so that
the cooling air vents on the chassis are not blocked.
Protect from Exposure to Moisture and
Foreign Objects
Do not use this apparatus near water.
WARNING: Avoid electric shock and re
hazard! Do not expose this product to liquids,
rain, or moisture.
WARNING: Avoid electric shock and re
hazard! Unplug this product before cleaning. Clean
only with a dry cloth. Do not use a liquid cleaner or
an aerosol cleaner. Do not use a magnetic/static
cleaning device (dust remover) to clean this product.
Accessories Warning
WARNING: Avoid electric shock and re
hazard! Only use attachments/accessories
specified by your service provider or the
manufacturer.
Service Warnings
WARNING: Avoid electric shock! Do not
open the cover of this product. Opening or
removing the cover may expose you to dangerous
voltages. If you open the cover, your warranty
will be void. This product contains no userserviceable parts. Refer all servicing to quali ed
service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as a power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
Check Product Safety
Upon completion of any service or repairs to this product,
the service technician must perform safety checks to
determine that this product is in proper operating condition.
Protect the Product when Moving It
Always disconnect the power source when moving
the apparatus or connecting or disconnecting cables.
WARNING: Avoid personal injury and
damage to this product! Use only with
the cart, stand, tripod, bracket, or table
speci ed by the manufacturer or sold with
the apparatus. When a cart is used, use
caution when moving the cart/ apparatus
combination to avoid injury from tip-over.
20110316_Cable_Safety
WARNING: Avoid electric shock and re
hazard! Never push objects through the openings
in this product. Foreign objects can cause
electrical shorts that can result in electric shock
or re.
v
Welcome
Watch TV on your terms.
®
The Explorer
provide a simple way to take control over your TV – and your life. You take control because these DVRs allow you
to decide what’s on TV and when. So there’s no more putting o the things you need to do, just because there’s a
show on TV you want to watch. Just think what a DVR can do for you:
• Never miss a minute of your favorite movie or the big game. Simply pause the live action and play again when
you’re ready. You can even rewind what you missed.
• Two of your favorite shows on at the same time? Simple. Just record one program while you watch the other.
You can even record two programs at the same time while watching a previously recorded program. Your VCR
can’t do that.
• Is your favorite sports team having an away game and you can’t go? Imagine being able to record it and watch it
at a more convenient time.
Don’t miss another minute of the TV shows you love!
Follow the instructions in this guide to install the 8240C or 8300C, to become familiar with the buttons on the front
panel, and to access your cable services. Then, enjoy the features of the 8240C or 8300C and change the way you
watch TV!
8240C™ and 8300C™ Digital Video Recorders (DVR) with a Multi-Stream CableCARDTM (M-CardTM)
Safety First
Before using the DVR, read the Important Safety Instructions section of this guide.
For More Information
The consumer support website provides news and information about this product. For more information, please
refer to the following Web address:
http://www.cisco.com/web/consumer/support/index.html
Identify Your 8240C or 8300C
To nd the serial number for your 8240C or 8300C, look on the back for a label that is similar to the example shown
here. The serial number begins with “STB SN“ and is located beneath the bar code.
Serial Number
If your 8240C or 8300C requires troubleshooting in the future, your service provider may ask for this serial number.
Use the space provided here to record the serial number:
____________________________________________
STB SN: SABNFSRVG
eCM MAC: 001868C16907
STB RF MAC: 001868C16906
T15358
6
What’s on the Front Panel?
POWER
LIST
AUX
INPUT
AUDIO VIDEOLR
1 3 7 129
2 8 10 11
GUIDE
INFO
EXIT
456
CH +
VOL +VOL -
CH - SELECT
T15369
1 Power Turns the DVR on and o
2 Video and Connects to video and left/right (L/R) audio outputs of an external device to deliver the
Audio Input audio and video to a TV or other device.
Note: These connections are not available on the 8240C.
3 List Displays the list of recorded programs
4 Exit Exits menus, the on-screen guide, and program information
5 Info Displays a description of the selected program. This button is available from the on-screen
guide and while viewing a program
6 Guide Accesses on-screen services, such as the on-screen guide,
video-on-demand, or pay-per-view
7 IR Sensor Receives the infrared signal from the remote control
8 LED Display Displays the selected channel number and time of day. The LED also displays the following:
• Message (
• Power (
)
)
• RECORD
9 VOL + and VOL - Increases and decreases the volume
10 CH + and CH - Scrolls up and down through the channels
11 Select Provides access to your on-screen choices
12 USB Port Connects to external equipment, such as a keyboard or mouse (reserved for future use,
may not be available on all DVR models)
Note: This illustration may vary from the actual product.
7
What’s on the Back Panel?
CAUTION
RISK OF ELECTRIC SHOCK
AVIS:
RISQUE DE CHOC
ELECTRIQUE NE PAS OUVRIR
120 VAC
60HZ 5A
11
DO NOT OPEN
LISTED 14H1
CABLE EQUIP.
12
120 VAC
60HZ 80W
T15370
CATV CONVERTER
MADE IN MEXICO
CABLE
THIS DEVICE IS INTENDED TO BE ATTACHED
TO A RECEIVER THAT IS NOT USED TO
RECEIVE OVER-THE-AIR BROADCAST
SIGNALS. CONNECTION OF THIS DEVICE
CABLE
IN ANY OTHER FASHION MAY CAUSE
IN
HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS AND IS IN VIOLATION
OF THE FCC RULES, PART 15.
OUT
OUT 1 OUT 2
TV
DIGITAL
AUDIO OUT
1 4 7 10
MULTI-STREAM
A
U
L
D
IR
I
O
R
VIDEOVIDEO
S - VIDEO
OUT
652
8 9
eSATA
3
1 Cable In Connects to a coaxial cable that delivers the signal from your service provider
2 Cable Out Connects to a coaxial cable that sends analog audio and video signals to a TV or VCR.
These signals are standard-de nition TV (SDTV) video and stereo audio
3 Audio Out Connects to RCA cables that send analog audio signals (left and right) to the stereo
(LEFT and RIGHT) inputs on a TV
4 Video Out Connects to the video input of a TV or VCR
5 Digital Audio Connects to an RCA cable that sends a digital audio signal to a surround-sound receiver or
Out other digital audio device
6 Secondary Video Connects to either a VCR for archiving saved content from the DVR or connects to another
and Audio Out set of inputs (composite) on your TV
7 S-Video Out Connects to an S-Video cable that sends an S-Video signal to your TV or VCR. This signal
is standard de nition, but higher quality than other SDTV connections
8 IR (This connector reserved for future use)
9 Multi-Stream Slot for Multi-Stream CableCARD (M-Card) module for decrypting subscription digital
CableCARD channels. This DVR will not operate correctly without an M-Card module. Obtain an
M-Card module from your service provider
Note: Your service provider may provide this when you rst receive the DVR.
10 eSATA Connects to an external Serial ATA (eSATA) hard disk drive for expanded drive space.
(A connected eSATA drive is not an archival device.) Check with your service provider for a
list of approved hard drive models for use with the DVR
11 AC Outlet Connects to the AC power cord from another device, such as a TV
12 AC Power Input Connects to the power cord to deliver power to the DVR
Note: This illustration may vary from the actual product.
8
Connecting the DVR
POWER
To connect your DVR to your entertainment devices, complete these steps.
Connect the coaxial cable that carries the signal from your service provider to the CABLE IN
connector on the back panel of the set-top.
1
Connect your SDTV to the DVR. Refer to the Connections for a Standard-De nition TV and
Standard VCR section on page 5.
2
Identify the additional
3
devices you will connect
to the DVR and TV. See
pages 8 through 11 and
the related user’s guides
for your devices for more
information.
VCR DVD Other
Home Theater External SATA Drive
4
5
6
Plug the DVR and the TV into an AC power source.
To provide some protection against voltage surges and built-up static charges that can be
caused by lightning storms and power outages, ground (earth) your electronic devices, such as
by plugging the set-top into a surge protector.
Do not turn on the DVR or TV yet.
It may take several minutes for the DVR to receive the latest software, programming, and service
information. Wait until you see one of the following displays on the front panel of the DVR that
indicates that the update is complete:
• Current time • Four dashes (- - - -)
Note: If four dashes are displayed, your DVR is not authorized. Call your service provider.
To begin watching TV, turn the TV ON, and press POWER on the front panel of
the DVR or press Power on the remote control.
7
9
Connections for a Standard-De nition TV and VCR
When using the DVR with an SDTV, you must make one of the following connections to view content. Some SDTVs
may not have all of these connections. In addition, you can make connections to a VCR to archive recordings to a
VCR tape. Refer to your TV and VCR user’s guide, and the cabling diagrams in this guide for more information.
Note: The labeling on your DVR model may vary from the labels shown in the following table.
Required Connections to an SDTV (choose one)
The Cable Out connection provides both a video and
an audio connection to an SDTV. See page 8 for an
example.
The Video Out connection provides video to a
standard de nition TV. The left and right audio outputs
provide stereo sound. See page 9 for an example.
The S-Video out connection provides optimal video
to a standard de nition TV. The left and right audio
outputs provide stereo sound.
S-Video Video Cable OutVCRStereo VCR
Optional Connection
The Cable Out connection provides both a video and
an audio connection to the VCR. See page 8 for an
example.
DVR
Connections
CABLE
OUT
Out 1
TV
VIDEO
OUT 1
L
R
S-VIDEO
OUT
DVR
Connections
CABLE
OUT
L
R
AUDIO 1
SDTV
Connections
CABLE/
ANTENNA
L
R
VIDEO
IN
AUDIO 1
S-VIDEO
IN
L
R
IN
IN
VCR
Connections
CABLE/
ANTENNA
For VCRs that have Video and Left and Right audio
connectors, you can use the OUT 2 connectors
(Video, Left, and Right) on the DVR. See page 9 for
an example.
10
OUT 2
VIDEO
R
L
L
R
VIDEOINAUDIO
IN
View and Record Television Programming
Access Services and Programs
Access cable services and programs by pressing the following keys on the remote control:
• Guide–Access the on-screen guide. The on-screen guide displays schedules of TV programs and other
services available from your service provider, such as video-on-demand and pay-per-view programs.
• Arrows–Select a program in the schedule.
• Info–Display a speci c program description (either from the on-screen guide or while viewing a program).
• Select–View a speci c program in the guide.
Record One Program While Watching Another
When two of your favorite programs are scheduled at the same time, you can
record one program on the built-in DVR while watching the other. Use the
DVR keys on the remote control to record programs or to play back recorded
programs.
Watch Two Programs at the Same Time
You do not need a special TV to watch two programs at the same time. Use
the picture-in-picture (PIP) keys on the remote control, and you will see a PIP
screen on your TV.
Avoid Screen Burn-In!
Images such as letterbox bars or side bars, bright closed-captioning
backgrounds, station logos, or any other stationary images may cause the
screen in your TV to age unevenly; this is known as screen burn-in. Refer to
the user’s guide that came with your TV for more information.
WARNING:
Avoid screen burn-in! Do not display the same xed images on your
HDTV screen for extended periods of time.
T10964
T10965
11
Performance Tips
If the DVR does not perform as expected, the following tips may help. If you need further assistance, contact your
service provider.
No Picture
• Verify that the power to your TV is turned on.
• If the DVR is plugged into a wall switch, verify the wall switch is in the ON position.
Note: You should avoid plugging the DVR into an outlet that is controlled by a wall switch.
• Verify that all cables are properly connected.
• Verify that the M-Card module is installed.
• If your system includes a VCR or stereo, verify that you have properly connected them to the DVR.
• Verify that the TV is set to the proper input channel.
No Color
• Verify that the current TV program is broadcast in color.
• Adjust the TV color controls.
No Sound
• If your setup includes a VCR or stereo, verify that you have properly connected it to the DVR.
• Verify that the volume is turned up.
• Verify that the mute function is not engaged.
Automatic Software Updates
A message appears on the TV screen when the DVR and the M-Card module are receiving software updates.
In addition, download information also appears on the front panel of the DVR during these updates. Wait for the
current time to display on the front panel before continuing. When the time appears, the update is complete.
Frequently Asked Questions
Where Are the Connection Diagrams?
The diagrams are on pages 8 through 11 of this guide. The diagrams show examples of common ways to connect
the DVR to your other electronic devices. However, these diagrams do not show every possible combination of
devices. Refer to the user’s guides that came with your other electronic devices for further information.
What Cables Do I Need?
The required cables are shown in the connection diagrams in this guide. Some of the cables and adaptors shown in
the diagrams may not be included with the DVR.
12
Connecting to a Standard TV
WARNING:
Electric shock hazard! Unplug all electronic devices before connecting or disconnecting any device
cables to the DVR.
Explorer DVR
CAUTION
RISK OF ELECTRIC SHOCK
AVIS:
RISQUE DE CHOC
ELECTRIQUE NE PAS OUVRIR
120 VAC
60HZ 5A
DO NOT OPEN
LISTED 14H1
CABLE EQUIP.
120 VAC
60HZ 80W
CATV CONVERTER
MADE IN MEXICO
Cable Input
THIS DEVICE IS INTENDED TO BE ATTACHED
TO A RECEIVER THAT IS NOT USED TO
RECEIVE OVER-THE-AIR BROADCAST
SIGNALS. CONNECTION OF THIS DEVICE
CABLE
IN ANY OTHER FASHION MAY CAUSE
IN
HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS AND IS IN VIOLATION
OF THE FCC RULES, PART 15.
LEFT
AUDIO
CABLE
OUT
OUT 1 OUT 2
TV
DIGITAL
AUDIO OUT
MULTI-STREAM
A
U
L
D
IR
I
O
R
VIDEOVIDEO
S - VIDEO
OUT
eSATA
Standard TV
INOUT
INOUT
VIDEO
CABLE/
ANTENNA
INOUT
RIGHT
Connecting to a Standard TV and Standard VCR
WARNING:
Electric shock hazard! Unplug all electronic devices before connecting or disconnecting any device
cables to the DVR.
Explorer DVR
T15371
THIS DEVICE IS INTENDED TO BE ATTACHED
TO A RECEIVER THAT IS NOT USED TO
RECEIVE OVER-THE-AIR BROADCAST
SIGNALS. CONNECTION OF THIS DEVICE
CABLE
IN ANY OTHER FASHION MAY CAUSE
IN
HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS AND IS IN VIOLATION
OF THE FCC RULES, PART 15.
CATV CONVERTER
MADE IN MEXICO
Cable Input
Standard TV
LEFT
AUDIO
RIGHT
CABLE
OUT
OUT 1 OUT 2
TV
DIGITAL
AUDIO OUT
MULTI-STREAM
A
U
L
D
IR
I
O
R
VIDEOVIDEO
S - VIDEO
OUT
eSATA
CAUTION
RISK OF ELECTRIC SHOCK
AVIS:
RISQUE DE CHOC
ELECTRIQUE NE PAS OUVRIR
120 VAC
60HZ 5A
DO NOT OPEN
LISTED 14H1
CABLE EQUIP.
120 VAC
60HZ 80W
VCR
OUT TO TVIN FROM ANT.
INOUT
INOUT
VIDEO
CABLE/
ANTENNA
INOUT
T15372
13
Connecting to a Stereo TV
Explorer DVR
CABLE
CABLE
IN
CATV CONVERTER
MADE IN MEXICO
Cable Input
WARNING:
Electric shock hazard! Unplug
all electronic devices before
THIS DEVICE IS INTENDED TO BE ATTACHED
TO A RECEIVER THAT IS NOT USED TO
RECEIVE OVER-THE-AIR BROADCAST
SIGNALS. CONNECTION OF THIS DEVICE
IN ANY OTHER FASHION MAY CAUSE
HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS AND IS IN VIOLATION
OF THE FCC RULES, PART 15.
OUT
Stereo
TV
OUT 1 OUT 2
TV
DIGITAL
AUDIO OUT
LEFT
AUDIO 2
RIGHT
LEFT
AUDIO 1
MULTI-STREAM
A
U
L
D
IR
I
O
R
VIDEOVIDEO
INOUT
S - VIDEO
OUT
VIDEO 2
INOUT
INOUT
CABLE/
ANTENNA
INOUT
VIDEO 1
INOUT
INOUT
connecting or disconnecting
any device cables to the DVR.
RIGHT
Connecting to a Stereo TV and Stereo VCR
eSATA
CAUTION
RISK OF ELECTRIC SHOCK
AVIS:
RISQUE DE CHOC
ELECTRIQUE NE PAS OUVRIR
120 VAC
60HZ 5A
DO NOT OPEN
LISTED 14H1
CABLE EQUIP.
120 VAC
60HZ 80W
T15373
WARNING:
Electric shock hazard! Unplug all electronic devices before connecting or disconnecting any device
cables to the DVR.
Explorer DVR
CAUTION
RISK OF ELECTRIC SHOCK
AVIS:
RISQUE DE CHOC
ELECTRIQUE NE PAS OUVRIR
120 VAC
60HZ 5A
DO NOT OPEN
LISTED 14H1
CABLE EQUIP.
120 VAC
60HZ 80W
CATV CONVERTER
MADE IN MEXICO
THIS DEVICE IS INTENDED TO BE ATTACHED
TO A RECEIVER THAT IS NOT USED TO
RECEIVE OVER-THE-AIR BROADCAST
SIGNALS. CONNECTION OF THIS DEVICE
CABLE
IN ANY OTHER FASHION MAY CAUSE
IN
HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS AND IS IN VIOLATION
OF THE FCC RULES, PART 15.
CABLE
OUT
OUT 1 OUT 2
TV
DIGITAL
AUDIO OUT
MULTI-STREAM
A
U
L
D
IR
I
O
R
VIDEOVIDEO
S - VIDEO
OUT
eSATA
Cable Input
Stereo TV
Stereo
VCR
RL
AUDIO
VIDEO
IN
IN
Note: This connection allows for
archiving to your VCR and for watching
VCR tapes on your TV. You may also
VIDEO
OUT
AUDIO
OUT
RF IN
RL
RF OUT
LEFT
AUDIO 2
RIGHT
LEFT
AUDIO 1
INOUT
VIDEO 2
INOUT
INOUT
CABLE/
ANTENNA
INOUT
VIDEO 1
INOUT
INOUT
choose to connect OUT 1 from the DVR
directly to your TV, so that you may watch live channels
RIGHT
on your TV during any archive-to-VCR process.
T15374
14
Connecting to a Home Theater Receiver and Stereo TV
WARNING:
Electric shock hazard! Unplug all electronic devices before connecting or disconnecting any device
cables to the DVR.
Explorer DVR
CATV CONVERTER
MADE IN MEXICO
Cable Input
CABLE
IN
Home
Theater
Receiver
THIS DEVICE IS INTENDED TO BE ATTACHED
TO A RECEIVER THAT IS NOT USED TO
RECEIVE OVER-THE-AIR BROADCAST
SIGNALS. CONNECTION OF THIS DEVICE
IN ANY OTHER FASHION MAY CAUSE
HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS AND IS IN VIOLATION
OF THE FCC RULES, PART 15.
DIGITAL
AUDIO
1
2
3
4
Stereo
CABLE
OUT
TV/CABLE
S-VIDEO
VIDEO
L
AUDIO
R
TV
OUT 1 OUT 2
TV
DIGITAL
AUDIO OUT
DVD
S-VIDEO
VIDEO
L
AUDIO
R
LEFT
INOUT
AUDIO 2
INOUT
RIGHT
LEFT
INOUT
AUDIO 1
INOUT
VIDEOVIDEO
A
U
L
D
I
O
R
S-VIDEO
VIDEO
AUDIO
OUT
MULTI-STREAM
VIDEO 1
L
R
VIDEO 2
VIDEO 1
IR
S - VIDEO
OUT
S-VIDEO
VIDEO
AUDIO
OUT
INOUT
INOUT
COMPONENT VIDEO
L
1
R
CABLE/
ANTENNA
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS:
RISQUE DE CHOC
ELECTRIQUE NE PAS OUVRIR
120 VAC
120 VAC
60HZ 5A
eSATA
Y
Y
PB
PB
PR
PR
2
MONITOR
Y
S-VIDEO
PB
OUT
PR
VIDEO OUT
OUTIN
LISTED 14H1
CABLE EQUIP.
60HZ 80W
RIGHT
T15375
15
Connecting to an eSATA Hard Disk Drive (optional)
Complete the following steps to install an eSATA drive.
1. Make sure that both the DVR and the eSATA drive are unplugged from power.
2. Connect the data cable for the eSATA drive to the DVR.
3. Plug in power to the eSATA drive.
4. Plug in the power cord, and then turn on the DVR.
5. Follow the on-screen instructions. One of the following situations occurs:
• If it is a new drive or one used on another device, the system displays a message and asks you to format the
drive
• If the drive is formatted and is functioning properly with this DVR, a con rmation message appears and states
that the drive is working.
Explorer DVR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS:
RISQUE DE CHOC
ELECTRIQUE NE PAS OUVRIR
120 VAC
60HZ 5A
LISTED 14H1
CABLE EQUIP.
To
Wall Outlet
120 VAC
60HZ 80W
CATV CONVERTER
MADE IN MEXICO
Cable Input
WARNING:
THIS DEVICE IS INTENDED TO BE ATTACHED
TO A RECEIVER THAT IS NOT USED TO
RECEIVE OVER-THE-AIR BROADCAST
SIGNALS. CONNECTION OF THIS DEVICE
CABLE
IN ANY OTHER FASHION MAY CAUSE
IN
HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS AND IS IN VIOLATION
OF THE FCC RULES, PART 15.
CABLE
OUT
OUT 1 OUT 2
TV
DIGITAL
AUDIO OUT
A
U
L
D
I
O
R
VIDEOVIDEO
MULTI-STREAM
IR
S - VIDEO
OUT
External SATA
eSATA
Unswitched
Hard Disk Drive
eSATA
Electric shock hazard! Unplug
all electronic devices before
connecting or disconnecting
any device cables to the DVR.
To Unswitched
Wall Outlet
T15376
How the eSATA Drive Works with Your DVR
An eSATA drive is an extension of the internal hard drive of the DVR; it is not an archival device. Programs recorded
to the eSATA drive can be played back on the DVR originally connected to the eSATA drive. For instance, you
cannot record programs to the eSATA drive, remove the drive, and then connect it to a computer or a di erent DVR
for playing back programs.
Some programs will record to the internal drive of the DVR and some will record to the eSATA drive, depending on
the space available. The DVR selects the drive that has the most free space and records the program to that drive.
A program is not split between the internal and eSATA drives.
Recommendations for the eSATA Drive
Contact your cable service provider for a list of approved eSATA hard disk drives. At a minimum, your eSATA drive
should have these capabilities:
• External SATA Connector - SATA II: Cable and Connector, Revision 1.0 (www.sata-io.org for more information)
• Drive Speed: 7200 RPM (5400 RPM without Multi-Room
• Capacity: Only one eSATA drive can be connected to the DVR. The DVR does not support a separate port
multiplier.
• eSATA Drive Power: The eSATA drive should power on when plugged in and should not be controlled by switch.
16
TM
DVR); 133 Mbps
Connecting to an eSATA Hard Disk Drive (optional), continued
Guidelines for Using the eSATA Hard Disk Drive
The eSATA hard disk drive requires continuous power. If the eSATA drive loses power while the DVR is plugged in,
the DVR may stop current recordings or not provide enough space for future recordings. Follow these guidelines for
using the eSATA drive:
• Do not plug in the power cord for the eSATA drive to a switched outlet or to the AC outlet on the DVR.
• Do not turn o , disconnect, or unplug the eSATA drive while the DVR is plugged in.
Disconnecting the eSATA Hard Disk Drive
Complete the following steps to disconnect the eSATA drive safely.
1. Make sure that the DVR is powered o .
2. Disconnect the power cord from the DVR and wait for at least 10 seconds.
3. Disconnect the power cord and data cable from the eSATA drive.
Note: If you improperly disconnect your eSATA drive, you will receive an error message and you will be required to
restart the DVR upon reconnecting.
17
Index
A
AC
Outlet iv, 3, 11
Power input 3
B
Back panel 3
Burn-in of screen 6
C
CableCard
Cable Out, connector 3
Compliance, FCC and Canadian EMI Back Cover
Connectors
See also Front panel; Back panel
required for SDTV 5
VCR 5
Connecting the DVR to other devices;
Home Theater 10
Standard TV 8
Stereo TV 9, 10
VCR 8, 10
eSATA drive 11, 12
Consumer support 1
Controls. See Front panel
D
Dashes display 4
Diagrams. See Connecting the DVR
to other devices
Digital Video Recorder. See DVR, What is it?
Display, LED 2
DVR, What is it 1
E
eSATA 3, 11-12
External hard disk drive. See eSATA
3, 7
F
FAQs 7
FCC compliance Back Cover
Frequently Asked Questions. See FAQs
Front panel 2
H
Hard disk drive, external. See eSATA
Home theater system connection 10
I
IR Sensor 2
K
Keys. See Front panel; Back panel
L
LED Display 2
M
M-Card. See Multi-Stream CableCARD
Multi-Stream CableCARD 3, 7
P
Performance tips. See Troubleshooting.
Doesn’t display 7
No color 7
No sound 7
Picture-in-picture. See PIP
PIP 6
Ports. See Connectors
Product information 1
Programming, viewing 6
R
Record programs 1, 6
Remote control 6
RGB connector. See PrPbY
18
Index, continued
S
S-Video 5
Safety ii, iv-v, 7
Screen burn-in 6
SD mode 5
SDTV connections 5
Serial number, locating 1
Set-top. See Welcome
Software updates 7
Sound, troubleshooting 7
Standard TV 5, 8
Support, consumer 1
T
Time display 4
Troubleshooting 7
TV
programming 6
recording 6
U
Updating, software 7
USB port 2
V
VCR connection 5, 8, 9
View programs 6
W
Watch TV 1, 6
Web access to product information 1
Welcome 1
19
FCC Compliance
United States FCC Compliance
This device has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
such interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy. If not
installed and used in accordance with the instructions, it may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment OFF and ON, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna, if applicable.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit di erent from
that to which the receiver is connected.
• Consult the cable company or an experienced radio/television
technician for help.
Any changes or modi cations not expressly approved by Cisco
Systems, Inc., could void the user’s authority to operate the
equipment.
The information shown in the FCC Declaration of Conformity
paragraph below is a requirement of the FCC and is intended to
supply you with information regarding the FCC approval of this
device. The phone numbers listed are for FCC-related questions
only and not intended for questions regarding the connection
or operation for this device. Please contact your cable service
provider for any questions you may have regarding the operation
or installation of this device.
Explorer 8240C and 8300C
Digital Video Recorder
Models: 8240C and 8300C
Manufactured by: Cisco Systems, Inc.
5030 Sugarloaf Parkway
Lawrenceville, Georgia 30044 USA
Telephone: 678 277-1120
Canada EMI Regulation
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la class B est conforme à la norme
NMB-003 du Canada.
20060628FDC
Software and Firmware Use
The software described in this document is protected by copyright
law and furnished to you under a license agreement. You may
only use or copy this software in accordance with the terms of
your license agreement.
The rmware in this equipment is protected by copyright law.
You may only use the rmware in the equipment in which it is
provided. Any reproduction or distribution of this rmware, or any
portion of it, without our express written consent is prohibited.
Disclaimer
Cisco Systems, Inc. assumes no responsibility for errors or
omissions that may appear in this guide. We reserve the right to
change this guide at any time without notice.
Declaration of Conformity
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
1) the device may not cause harmful interference, and 2)
the device must accept any interference received, including
interference that may cause undesired operation.
Cisco Systems, Inc. 678 277-1120
5030 Sugarloaf Parkway, Box 465447 800 722-2009
Lawrenceville, GA 30042 www.cisco.com
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its a liates in the U.S. and other countries. A listing of Cisco’s trademarks
can be found at www.cisco.com/go/trademarks.
CableCARD and M-Card are trademarks of Cable Television Laboratories, Inc.
Manufactured under license from Dolby Laboratories. Dolby is a trademark of Dolby Laboratories.
HDMI, the HDMI logo, and High-De nition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other
countries.
Other third party trademarks mentioned are the property of their respective owners.
The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1009R)
© 2007. 2010, 2012 Cisco and/or its a liates. All rights reserved.
June 2012 Part Number 4015426 Rev C
Loading...
