Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP

Americas Headquarters

Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 USA http://www.cisco.com Tel: 408 526-4000

Fax: 408 527-0883

and SIP)

800 553-NETS (6387)

Common Phone Tasks

Softkey Definitions

View online help on the phone

Place a call Go off-hook before or

Redial a number Press Redial. Or press

Switch to the handset during a call

Switch to the speaker or headset during a call

Mute your phone Press .

Use your call logs Press to choose a

Edit a number Press EditDial, << or >>.

Hold/resume a call Press Hold or Resume.

Transfer a call to a new number

Place an intercom call Press intercom button,

Start a standard (ad hoc) conference call

Cisco, Cisco Systems, the Cisco logo, and the Cisco Systems logo are registered trademarks or trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries. All other trademarks

their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0903R)

mentioned in this document or Website are the property of

Press .

after dialing a number.

the Navigation button while on-hook to see your Placed Calls log.

Pick up the handset.

Press or , then hang up the handset.

call log. To dial, highlight a listing and go off-hook.

Press Tr ans fer, enter the number, then press

Tran sf er again.

enter a number if necessary, and speak after you hear the tone.

Press more > Confrn, dial the participant, then press Confrn again.

OL-19613-01

QUICK REFERENCE

Cisco Unified IP Phone 7962G and 7942G for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Softkey Definitions

Phone Screen Icons

Button Icons

Common Phone Tasks

AbbrDial Dial using a speed dial index

number

Answer Answer a call

Back Return to the previous Help topic

Barge Add yourself to a call on a shared

line

CallBack Receive notification when a busy

extension becomes available

Cancel Cancel an action or exit a screen

without applying changes

cBarge Add yourself to a call on a shared

line and establish a conference

CFwdALL Set up/cancel call forwarding

Clear Delete records or settings

Close Close the current window

ConfList View conference participants

Confrn Create a conference call

Delete Remove characters to the right of

the cursor when using EditDial

Details

(SCCP only)

Dial Dial a phone number

DirTrfr

(SCCP only)

DND Turn on/off Do Not Disturb

EditDial Edit a number in a call log

EndCall Disconnect the current call or the

Erase Reset settings to their defaults

Exit Return to the previous screen

Open the Details record for a multiparty call in the Missed Calls and Received Calls logs

Transfer two calls to each other

(DND)

current intercom call

GPickUp Answer a call that is ringing in

another group or on another line

iDivert Send or redirect a call to a voice

messaging system

Join Join together existing calls to

create a conference

Links View related Help topics

Main Display the Help main menu

MeetMe Host a Meet-Me conference call

more Display additional softkeys

New Call Make a new call

OPickUp Answer a call that is ringing in an

associated group

Park Store a call using Call Park

PickUp Answer a call that is ringing on

QRT Submit call problems to the

Redial Redial the most recently dialed

Remove Remove a conference participant

Resume Resume a call on hold

RmLstC Drop the last party added to a

Save Save the chosen settings

Search Search for a directory listing

Select Select a menu item or call

Tran sfer Transfer a call

Update Refresh content

VidMode (SCCP only)

<< Delete entered characters

>> Move through entered characters

another phone in your group

system administrator

number

conference call

Choose a video display mode

Phone Screen Icons

Call Forwarding enabled

Call on hold; remote call on hold

Connected call

Incoming call

Off-hook

On-hook

Shared line in use

Message waiting

Authenticated call

Encrypted call

BLF-monitored line is in-use

BLF-monitored line is idle

BLF-monitored line is ringing (BLF Pickup)

Speed-dial, call log, or directory listing (line status unknown)

Line in Do Not Disturb (BLF feature)

Intercom line in idle state

Intercom line in one-way audio call

Intercom line in two-way audio call

Handset in use

Headset in use

Speakerphone in use

Video enabled (SCCP only)

Feature assigned to button

Mobility assigned to button

Hold assigned to button

Conference assigned to button

Transfer assigned to button

Phone service URL assigned to button

URL entry in a call log is ready to edit (SIP only)

Option selected

Feature enabled

Button Icons

Messages

Services

Help

Directories

Settings

Volume

Speaker

Mute

Headset

Getting Started 1

Using this Guide 1 Finding Additional Information 2

Accessing Cisco Unified IP Phone 7900 Series eLearning Tutorials 2 Safety and Performance Information 2 Cisco Product Security Overview 3 Accessibility Features 3

Connecting Your Phone 4

An Overview of Your Phone 7

Understanding Buttons and Hardware 7 Understanding Lines and Calls 10

Understanding Line and Call Icons 11 Understanding Phone Screen Features 12

Cleaning the Phone Screen 12 Understanding Feature Buttons and Menus 13

Accessing the Help System on Your Phone 13 Understanding Feature Availability 14 Understanding SIP vs. SCCP 15

Basic Call Handling 16

Placing a Call—Basic Options 16 Placing a Call—Additional Options 17 Answering a Call 20 Ending a Call 21 Using Hold and Resume 22 Using Mute 23

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Switching Between Multiple Calls 23 Switching an In-Progress Call to Another Phone 24 Viewing Multiple Calls 24 Transferring Calls 25 Sending a Call to a Voice Message System 26 Forwarding Calls to Another Number 26 Using Do Not Disturb 27 Making Conference Calls 29

Using Conference Features 29

Using Conference 29 Using Join 30 Using cBarge 31 Using Meet-Me 31

Viewing or Removing Conference Participants 32

Placing or Receiving Intercom Calls 32

Advanced Call Handling 34

Speed Dialing 34 Picking Up a Redirected Call on Your Phone 35 Storing and Retrieving Parked Calls 37 Logging Out of Hunt Groups 38 Using a Shared Line 38

Understanding Shared Lines 38 Using Barge to Add Yourself to a Shared-Line Call 39

Understanding Barge Features 39 Using Barge Features 40

Preventing Others from Viewing or Barging a Shared-Line Call 41 Using BLF to Determine a Line State 42 Making and Receiving Secure Calls 43 Tracing Suspicious Calls 44 Prioritizing Critical Calls 44 Using Cisco Extension Mobility 46 Managing Business Calls Using a Single Phone Number 46

iv OL-19613-01

Using a Handset, Headset, and Speakerphone 49

Using a Handset 49 Using a Headset 49 Using a Speakerphone 50 Using AutoAnswer with a Headset or Speakerphone 51

Changing Phone Settings 52

Customizing Rings and Message Indicators 52 Customizing the Phone Screen 53

Using Call Logs and Directories 54

Using Call Logs 54 Directory Dialing 56

Using Corporate Directory on Your Phone 56 Using Personal Directory on Your Phone 57

Accessing Voice Messages 60

Using the User Options Web Pages 61

Accessing Your User Options Web Pages 61 Configuring Features and Services on the Web 62

Using Personal Directory on the Web 62

Using Your Personal Address Book on the Web 62 Configuring Fast Dials on the Web 63

Using the Address Book Synchronization Tool 64 Setting Up Speed Dials on the Web 65 Setting Up Phone Services on the Web 66 Controlling User Settings on the Web 67 Controlling Line Settings on the Web 68 Setting Up Phones and Access Lists for Mobile Connect 70 Using Cisco WebDialer 72

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Understanding Additional Configuration Options 74

Troubleshooting Your Phone 76

General Troubleshooting 76 Viewing Phone Administration Data 77 Using the Quality Reporting Tool 77

Cisco One-Year Limited Hardware Warranty Terms 78

Index 79

vi OL-19613-01

Getting Started

Using this Guide

This guide provides you with an overview of the features available on your phone. You can read it completely for a solid understanding of your phone’s capabilities, or refer to the table below for pointers to commonly used sections.

If you want to... Then...

Explore your phone on your own Press on the phone when you need assistance.

Review safety information See Safety and Performance Information, page 2.

Connect your phone See Connecting Your Phone, page 4.

Use your phone after it is installed Start with An Overview of Your Phone, page 7.

Learn what the button lights mean

Learn about the display See Understanding Phone Screen Features, page 12.

Make calls See Placing a Call—Basic Options, page 16.

Put calls on hold See Using Hold and Resume, page 22.

Mute calls See Using Mute, page 23.

Transfer calls See Transferring Calls, page 25.

Make conference calls See Making Conference Calls, page 29.

Set up speed dialing See Speed Dialing, page 34.

Share a phone number See Using a Shared Line, page 38.

Use your phone as a speakerphone

Change the ring volume or tone See Changing Phone Settings, page 52.

View your missed calls See Using Call Logs and Directories, page 54.

Listen to your voice messages See Accessing Voice Messages, page 60.

See softkey and icon definitions See the Quick Reference Card in the front of this guide.

See Understanding Buttons and Hardware, page 7.

See Using a Handset, Headset, and Speakerphone, page 49.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Finding Additional Information

You can access the most current Cisco Unified IP Phone documentation on the World Wide Web at this URL:

http://www.cisco.com/en/US/products/hw/phones/ps379/tsd_products_support_series_home.html

You can access the Cisco website at this URL:

http://www.cisco.com/

International Cisco websites can be accessed from this URL:

http://www.cisco.com/public/countries_languages.shtml

You can access the most current licensing information at this URL:

http://www.cisco.com/en/US/docs/voice_ip_comm/cuipph/all_models/openssl_license/7900_ssllic.htm l

Accessing Cisco Unified IP Phone 7900 Series eLearning Tutorials

(SCCP phones only.)

The Cisco Unified IP Phone 7900 Series eLearning tutorials use audio and animation to demonstrate basic calling features. You can access eLearning tutorials online (for several phone models) from your personal computer. Look for the eLearning tutorial (English only) for your phone model in the documentation list at the following location:

http://www.cisco.com/en/US/products/hw/phones/ps379/products_user_guide_list.html

Note Although a eLearning tutorials for the Cisco Unified IP Phone 7962G and 7942G are not

available, refer to the Cisco Unified IP Phone 7900 Series eLearning tutorials for an overview of the common IP phone features and functionality.

Safety and Performance Information

Refer to these sections for information about the impact of power outages and other devices on your Cisco Unified IP Phone.

Power Outage

Your accessibility to emergency service through the phone is dependent on the phone being powered. If there is an interruption in the power supply, Service and Emergency Calling Service dialing will not function until power is restored. In the case of a power failure or disruption, you may need to reset or reconfigure equipment before using the Service or Emergency Calling Service dialing.

2 OL-19613-01

Using External Devices

The following information applies when you use external devices with the Cisco Unified IP Phone:

Cisco recommends the use of good quality external devices (such as headsets) that are shielded against unwanted radio frequency (RF) and audio frequency (AF) signals.

Depending on the quality of these devices and their proximity to other devices such as mobile phones or two-way radios, some audio noise may still occur. In these cases, Cisco recommends that you take one or more of the following actions:

• Move the external device away from the source of the RF or AF signals.

• Route the external device cables away from the source of the RF or AF signals.

• Use shielded cables for the external device, or use cables with a better shield and connector.

• Shorten the length of the external device cable.

• Apply ferrites or other such devices on the cables for the external device.

Cisco cannot guarantee the performance of the system because Cisco has no control over the quality of external devices, cables, and connectors. The system will perform adequately when suitable devices are attached using good quality cables and connectors.

Caution In European Union countries, use only external headsets that are fully compliant with the

EMC Directive [89/336/EC].

Getting Started

Cisco Product Security Overview

This product contains cryptographic features and is subject to United States and local country laws governing import, export, transfer and use. Delivery of Cisco cryptographic products does not imply third-party authority to import, export, distribute or use encryption. Importers, exporters, distributors and users are responsible for compliance with U.S. and local country laws. By using this product you agree to comply with applicable laws and regulations. If you are unable to comply with U.S. and local laws, return this product immediately.

Further information regarding U.S. export regulations may be found at

http://www.access.gpo.gov/bis/ear/ear_data.html.

Accessibility Features

A list of accessibility features is available upon request. You can find more information about Cisco accessibility features at this URL:

www.cisco.com/go/accessibility

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

AUX

DC48V

10/100 SW 10/100 PC

185045

Connecting Your Phone

Your system administrator will likely connect your new Cisco Unified IP Phone to the corporate IP telephony network. If that is not the case, refer to the graphic and table below to connect your phone.

DC adaptor port (DC48V)

AC-to-DC power supply

AC power cord

Network port (10/100 SW)

Access port (10/100 PC)

4 OL-19613-01

Handset port

Headset port

Footstand button

Auxiliary port (AUX)

1 2 3

Connecting Your Phone

Adjusting the Footstand

To change the angle of the phone base, adjust the footstand while pressing the footstand button.

Adjusting the Handset Rest

Cisco recommends adjusting the handset rest, particularly when wall mounting the phone, as this will ensure that the receiver will not readily slip out of the cradle. See the table below for instructions.

Set the handset aside and pull the square plastic tab from the handset rest.

Rotate the tab 180 degrees.

Slide the tab back into the handset rest. An extension protrudes from the top of the rotated tab.

Return the handset to the handset rest.

Registering with TAPS

After your phone is connected to the network, your system administrator might ask you to auto-register your phone using TAPS (Tool for Auto-Registered Phones Support). TAPS might be used for a new phone or to replace an existing phone.

To register with TAPS, pick up the handset, enter the TAPS extension provided by your system administrator, and follow the voice prompts. You might need to enter your entire extension, including the area code. After your phone displays a confirmation message, hang up. The phone will re-start.

Using a Headset

You can use a wired headset, or you can use a wireless headset in conjunction with the wireless headset remote hookswitch control feature.

Headset Support

Although Cisco Systems performs limited internal testing of third-party headsets for use with the

Unified IP Phones, Cisco does not certify or support products from headset (or handset) vendors.

Cisco

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Cisco recommends the use of good quality external devices, for example, headsets that are screened against unwanted radio frequency (RF) and audio frequency (AF) signals. Depending on the quality of these devices and their proximity to other devices such as mobile phones and two-way radios, some audio noise or echo may still occur. An audible hum or buzz may be heard by either the remote party or by both the remote party and the Cisco Unified IP Phone user. Humming or buzzing sounds can be caused by a range of outside sources: for example, electric lights, electric motors, or large PC monitors.

Using External Devices, page 3 for more information.

See

Note In some cases, hum may be reduced or eliminated by using a local power cube or power

injector.

These environmental and hardware inconsistencies in the locations where Cisco Unified IP Phones are deployed means that there is not a single headset solution that is optimal for all environments.

Cisco recommends that customers test headsets in their intended environment to determine performance before making a purchasing decision and deploying en masse.

Audio Quality Subjective to the User

Beyond the physical, mechanical and technical performance, the audio portion of a headset must sound good to the user and to the party on the far end. Sound quality is subjective and Cisco cannot guarantee the performance of any headsets. However, a variety of headsets from leading headset manufacturers have been reported to perform well with Cisco Unified IP Phones. See manufacturer’s sites for details.

For information about wireless headsets that work in conjunction with the wireless headset remote hookswitch control feature, got to the following URL: http://www.cisco.com/pcgi-bin/ctdp/Search.pl

1. Choose IP Communications from the Enter Solution drop-down list box. The Select a Solution Category drop-down list box displays.

2. Choose IP Phone Headsets to see a list of Technology Development Program partners.

If you want to search for a particular Technology Development Program partner, enter the partner’s name in the Enter Company Name box.

6 OL-19613-01

101112131415

An Overview of Your Phone

The Cisco Unified IP Phone 7962G and 7942G are full-feature telephones that provide voice communication over the same data network that your personal computer uses, allowing you to place and receive phone calls, put calls on hold, speed dial numbers, transfer calls, make conference calls, and so on.

In addition to basic call-handling features, your phone can provide enhanced productivity features that extend your call-handling capabilities. Depending on configuration, your phone supports:

• Access to network data, XML applications, and web-based services.

• Online customizing of phone features and services from your Cisco Unified CM User Options web

pages.

• A comprehensive online help system that displays information on the phone screen.

Understanding Buttons and Hardware

You can use the graphics and table below to identify buttons and hardware on your phone.

Cisco Unified IP Phone 7962G

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Cisco Unified IP Phone 7942G

187004

101112131415

8 OL-19613-01

An Overview of Your Phone

Item Description For more information, see...

Programmable

buttons

Phone screen Shows phone features. Understanding Phone Screen

Footstand button Allows you to adjust the angle of the phone

Messages button Auto-dials your voice message service

Depending on configuration, programmable buttons provide access to:

• Phone lines and intercom lines (line buttons) and intercom lines

• Speed-dial numbers (speed-dial buttons, including the BLF speed-dial feature)

• Web-based services (for example, a Personal Address Book button)

• Call features (for example, a Privacy, Hold, or Transfer button)

Buttons illuminate to indicate status:

Green, steady—Active call or two-way intercom call

Green, flashing—Held call

Amber, steady—Privacy in use, one-way intercom call, DND active, or logged into Hunt Group

Amber, flashing—Incoming call or reverting call

Red, steady—Remote line in use (shared line or BLF status)

Red, flashing—Remote call on hold

base.

(varies by service).

• Understanding Phone

Screen Features, page 12

• Basic Call Handling,

page 16

• Speed Dialing, page 34

• Using a Shared Line,

page 38

• Using BLF to Determine a

Line State, page 42

• Using BLF to Determine a

Line State, page 42

• Placing or Receiving

Intercom Calls, page 32

Features, page 12

Adjusting the Footstand, page 5

Accessing Voice Messages, page 60

Directories button Opens/closes the Directories menu. Use it

to access call logs and directories.

Help button Activates the Help menu. Accessing the Help System on

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Using Call Logs, page 54

Your Phone, page 13

Item Description For more information, see...

Settings button Opens/closes the Settings menu. Use it to

control phone screen contrast and ring sounds.

Services button Opens/closes the Services menu. Using the User Options Web

Changing Phone Settings, page 52

Pages, page 61

Volume button Controls the handset, headset, and

speakerphone volume (off-hook) and the ringer volume (on-hook).

Speaker button Toggles the speakerphone on or off. When

the speakerphone is on, the button is lit.

Mute button Toggles the microphone on or off. When

the microphone is muted, the button is lit.

Headset button Toggles the headset on or off. When the

headset is on, the button is lit.

Navigation button Allows you to scroll through menus and

highlight items. When the phone is on-hook, displays phone numbers from your Placed Calls log.

Keypad Allows you to dial phone numbers, enter

letters, and choose menu items.

Softkey buttons Each activates a softkey option (displayed

on your phone screen).

Handset light strip Indicates an incoming call or new voice

message.

Using a Handset, Headset, and Speakerphone, page 49

Using Mute, page 23

Using a Handset, Headset, and Speakerphone, page 49

Using Call Logs, page 54

Basic Call Handling, page 16

Understanding Phone Screen Features, page 12

Accessing Voice Messages, page 60

Understanding Lines and Calls

To avoid confusion about lines and calls, refer to these descriptions:

Lines—Each line corresponds to a directory number or intercom number that others can use to call you. The Cisco 7942G supports one to two lines, depending on configuration. To see how many lines you have, look at the right side of your phone screen. You have as many lines as you have directory numbers and phone line icons:

Calls—Each line can support multiple calls. By default, your phone supports four connected calls per line, but your system administrator can adjust this number according to your needs. Only one call can be active at any time; other calls are automatically placed on hold.

10 OL-19613-01

Unified IP Phone 7962G supports one to six lines and the Cisco Unified IP Phone

Understanding Line and Call Icons

Your phone displays icons to help you determine the call and line state.

Icon Line or Call State Description

On-hook line No call activity on this line.

Off-hook line You are dialing a number or an outgoing call is ringing.

Connected call You are currently connected to the other party.

Ringing call An incoming call is ringing on one of your lines.

Call on hold You have put the call on hold. See Using Hold and Resume, page 22.

An Overview of Your Phone

Remote call on hold

Remote-in-use Another phone that shares your line has a connected call. See Using

Reverting call A holding call is reverting to your phone. See Using Hold and

Authenticated call

Encrypted call See Making and Receiving Secure Calls, page 43.

BLF- monitored line is idle

BLF- monitored line is in-use

BLF-monitored line is ringing (BLF Pickup)

Line in Do Not Disturb (BLF)

Idle Intercom line

One-way intercom call

Another phone that shares your line has put a call on hold. See Using

Hold and Resume, page 22

a Shared Line, page 38, for details.

Resume, page 22.

See Making and Receiving Secure Calls, page 43.

See Using BLF to Determine a Line State, page 42.

The intercom line is not in use. See Placing or Receiving Intercom

Calls, page 32.

The intercom line is sending or receiving one-way audio. See Placing

or Receiving Intercom Calls, page 32.

Two- way intercom call

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

The recipient pressed the intercom line to activate two-way audio with the caller. See

Placing or Receiving Intercom Calls, page 32.

186847

Understanding Phone Screen Features

This is what your main phone screen might look like with active calls and several feature menus open:

Primary phone

line

Programmable

button indicators

Softkey labels Each displays a softkey function. To activate a softkey, press the softkey button

Status line Displays audio mode icons, status information, and prompts.

Call activity

area

Phone tab Indicates call activity.

Feature tabs Each indicates an open feature menu. See Understanding Feature Buttons and

Displays the phone number (directory number) for your primary phone line. When several feature tabs are open, the phone number and the time and date alternate display in this area.

Programmable buttons can serve as phone line buttons, speed-dial buttons, phone service buttons or phone feature buttons. Icons and labels indicate how these buttons are configured. For an icon reference, see the Quick Reference Card at the front of this guide.

Displays current calls per line, including caller ID, call duration, and call state for the highlighted line (standard view). See

Icons” section on page 11, and Viewing Multiple Calls, page 24.

“Understanding Line and Call

“Phone Screen Icons” in

Menus, page 13.

Cleaning the Phone Screen

Use only a soft, dry cloth to wipe the phone screen. Do not use any liquids or powders on the phone, as they can contaminate phone components and cause failures.

12 OL-19613-01

Understanding Feature Buttons and Menus

Press a feature button to open or close a feature menu.

If you want to... Then...

Open or close a feature menu

Scroll through a list or menu

Go back one level in a feature menu

Switch among open feature menus

Press a feature button:

Messages

Services

Directories

Settings

Help

Press the Navigation button.

Press Exit. Pressing Exit from the top level of a menu, closes the menu.

Press a feature tab. Each feature menu has a corresponding tab. The tab is visible when the feature menu is open.

An Overview of Your Phone

Accessing the Help System on Your Phone

Your phone provides a comprehensive online help system. Help topics appear on the phone screen.

If you want to... Then...

View the main menu Press on your phone and wait a few seconds for the menu to display.

Main menu topics include:

• About Your Cisco Unified IP Phone—Details about your phone

• How do I...?—Procedures for common phone tasks

• Calling Features—Descriptions and procedures for calling features

• Help—Tips on using and accessing Help

Learn about a button or softkey

Learn about a menu item

Get help using Help Press twice quickly. Select the help topic you need.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Press , then quickly press a button or softkey.

Press , , or to display a feature menu. Highlight a menu item, then press twice quickly.

Understanding Feature Availability

Depending on your phone system configuration, features included in this Phone Guide might not be available to you or might work differently on your phone. Contact your support desk or system administrator for information about feature operation or availability.

You can access many features either by using a softkey or by pressing a line button. You can configure some features but your system administrator controls most of them.

Here are some details about using softkeys and line buttons to access features:

Feature Softkey Line Button Label and Icon

Call Back CallBack CallBack

Call Forward CFwdALL Forward All

Call Park Park Park

Call PickUp PickUp PickUp

Conference Confrn Conference

Conference List ConfList Conference List

Do Not Disturb DND Do Not Disturb or

Do Not Disturb

End Call EndCall End Call

Group Pickup GPickUp Group PickUp

Hold Hold Hold

Hunt Group HLog Hunt Group or

Hunt Group

Malicious Call Identification MCID Malicious Call ID

Meet Me Conferencing MeetMe MeetMe

Mobility Mobility Mobility

New Call New Call New Call

Other PickUp OPickUp Other PickUp

Quality Reporting Tool QRT Quality Reporting Tool

Redial Redial Redial

Remove Last Conference Party

Tra nsfer Tra nsfer Transf er

Video Mode Command VidMode Video

RmLstC Remove Last Participant

14 OL-19613-01

An Overview of Your Phone

Understanding SIP vs. SCCP

Your phone can be configured to work with one of two signaling protocols: SIP (Session Initiation Protocol) or SCCP (Skinny Call Control Protocol). Your system administrator determines this configuration.

Phone features can vary depending on the protocol. This Phone Guide indicates which features are protocol-specific. To learn which protocol your phone is using, you can ask your system administrator or you can choose

> Model Information > Call Control Protocol on your phone.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Basic Call Handling

You can perform basic call-handling tasks using a range of features and services. Feature availability can vary; see your system administrator for more information.

Placing a Call—Basic Options

Here are some easy ways to place a call on your Cisco Unified IP Phone.

If you want to... Then... For more information, see...

Place a call using the handset Pick up the handset and enter a number. An Overview of Your

Phone, page 7

Place a call using the speakerphone

Place a call using a headset Press and enter a number. Or if

Redial a number Press Redial to dial the last number, or

Place a call when another call is active (using the same line)

Dial from a call log 1. Choose > Missed Calls,

Press and enter a number. Using a Handset, Headset,

and Speakerphone, page 49

Using a Handset, Headset,

is lit, press New Call and enter a number.

press the Navigation button (with the phone idle) to see your Placed Calls.

1. Press Hold.

2. Press New Call.

3. Enter a number.

Received Calls, or Placed Calls.

2. Select the listing or scroll to it and go off-hook.

and Speakerphone, page 49

Using Call Logs, page 54

Using Hold and Resume, page 22

Using Call Logs, page 54

Tips

• You can dial on-hook, without a dial tone (pre-dial). To pre-dial, enter a number, then go off-hook by lifting the handset or pressing Dial,

• When you pre-dial, your phone tries to anticipate the number you are dialing by displaying matching numbers (if available) from your Placed Calls log. This is called Auto Dial. To call a number displayed with Auto Dial, press the number, or scroll to it and go off-hook.

• If you make a mistake while dialing, press << to erase digits.

16 OL-19613-01

, or .

Basic Call Handling

• If parties on a call hear a beep tone, the call might be monitored or recorded. Ask your system

administrator for more information.

• Your phone might be set up for international call logging, which is indicated by a “+” symbol on

the call logs, redial, or call directory entries. See your system administrator for more information.

Placing a Call—Additional Options

You can place calls using special features and services that might be available on your phone. See your system administrator for more information about these additional options.

For more information,

If you want to... Then...

Place a call while another call is active (using a different line)

Speed dial a number Do one of the following:

Dial from a corporate directory on the phone

Dial from a corporate directory on your personal computer using

WebDial er

Cisco

Use CallBack to receive notification when a busy or ringing extension is available

See if a line associated with a speed-dial, call record, or directory listing is busy before placing a call to that line

1. Press for the new line. The first call is automatically placed on hold.

2. Enter a number.

• Press (a speed-dial button).

• Use the Abbreviated Dial feature.

• Use the Fast Dial feature.

1. Choose > Corporate

Directory (exact name can vary).

2. Enter a name and press Search.

3. Highlight a listing and go off-hook.

1. Open a web browser and go to a

WebDialer-enabled corporate directory.

2. Click the number that you want to dial.

1. Press CallBack while listening to the busy tone or ring sound.

2. Hang up. Your phone alerts you when the line is free.

3. Place the call again.

Look for Busy Lamp Field indicators. Using BLF to Determine a

see...

Using Hold and Resume, page 22

Speed Dialing, page 34

Using Call Logs, page 54

Using Cisco WebDialer, page 72

Your system administrator

Line State, page 42

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

If you want to... Then...

Make a priority (precedence) call (SCCP phones only)

Dial from a Personal Address Book (PAB) entry

Place a call using a billing or tracking code

(SCCP phones only)

Place a call using your Cisco Extension Mobility profile

Make a call from a mobile phone using Mobile Voice Access

Enter the MLPP access number, then enter the phone number.

1. Choose > Personal Directory to log in.

2. Choose Personal Address Book and search for a listing.

1. Dial a number.

2. After the tone, enter a client matter

code (CMC) or a forced authorization code (FAC).

1. Before using Mobile Voice Access to make a call, obtain your Mobile Voice Access number and End user PIN from your system administrator.

2. Dial your assigned Mobile Voice access number.

3. Enter your mobile phone number (if requested) and PIN.

4. Press 1 to make a call to an enterprise IP phone.

5. Dial a desktop phone number other than your desktop phone number.

For more information, see...

Prioritizing Critical Calls, page 44

Using Personal Directory on Your Phone, page 57

Your system administrator

Using Cisco Extension Mobility, page 46

18 OL-19613-01

If you want to... Then...

Place a call using Fast Dial

Note Before using this option, your

1. Press the Fast Dial line button.

2. Scroll to or press the index number

to find and select an entry.

The system dials the specified number.

Place a call using your PAB

Note Before using this option, your

system administrator must configure this feature and assign a service URL to the line button. Contact your system administrator for more information.

Basic Call Handling

For more information, see...

Configuring Fast Dials on the Web, page 63

Using Your Personal Address Book on the Web, page 62

Configuring Fast Dials on the Web, page 63

Using Your Personal Address Book on the Web, page 62

1. Press the PAB line button.

2. Access the contact and select the

number.

The system dials the specified number.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Answering a Call

You can answer a call by lifting the handset, or you can use other options if they are available on your phone.

If you want to... Then... For more information, see...

Answer with a wired headset Press , if unlit. Or, if is already

lit, press Answer or (flashing).

Note The ringing line is automatically

selected. Ask your system administrator about options to always select the primary line.

If you are using a wireless headset, refer to the wireless headset documentation.

Answer with the speakerphone

Switch from a connected call to answer a new call

Answer using call waiting Press Answer. Using Hold and Resume,

Send a call to a voice message system

Auto-connect calls Use AutoAnswer. Using AutoAnswer with a

Retrieve a parked call on another phone

Use your phone to answer a call ringing elsewhere

Press , Answer, or (flashing).

Note The ringing line is automatically

selected. Ask your system administrator about options to always select the primary line.

Press Answer, or if the call is ringing on a different line, press

Press iDivert. Sending a Call to a Voice

Use Call Park or Directed Call Park. Storing and Retrieving

Use Call Pickup. Picking Up a Redirected

(flashing).

Using a Handset, Headset, and Speakerphone, page 49

Using Hold and Resume, page 22

page 22

Message System, page 26

Headset or Speakerphone, page 51

Parked Calls, page 37

Call on Your Phone, page 35

20 OL-19613-01

Basic Call Handling

If you want to... Then... For more information, see...

Answer a priority call (SCCP phones only)

Answer a call on your mobile phone or other remote destination

Hang up the current call and press Answer.

Set up Mobile Connect and answer your phone.

When you enable Mobile Connect:

• Your desktop and remote

destinations receive calls simultaneously.

• When you answer the call on your

desktop phone, the remote destinations stop ringing, are disconnected, and display a missed call message.

• When you answer the call on one

remote destination, the other remote destinations stop ringing, are disconnected, and a missed call message is shown on the other remote destinations.

Prioritizing Critical Calls, page 44

Using Cisco Extension Mobility, page 46

Tip

If parties on a call hear a beep tone, the call might be monitored or recorded. Ask your system administrator for more information.

Ending a Call

To end a call, hang up. Here are some more details.

If you want to... Then...

Hang up while using the handset Return the handset to its cradle. Or press EndCall.

Hang up while using a wired headset Press . If you want to keep headset mode activate, press

EndCall.

If you are using a wireless headset, refer to the wireless headset documentation.

Hang up while using the speakerphone Press or EndCall.

Hang up one call but preserve another call on the same line

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Press EndCall. If necessary, remove the call from hold first.

Using Hold and Resume

You can hold and resume calls. When you put a call on hold, the Hold icon appears on the right in the call information area and the corresponding line button flashes green . With a shared line, when you place a call on hold, the line button flashes green and the phone displays the hold icon. When another phone places a call on hold, the line button flashes red hold icon .

If the Hold Reversion feature is enabled for your phone, a call that you put on hold reverts back to ringing after a certain period of time. The 'reverting' call remains on hold until you resume it or until Hold Reversion times out.

Your phone indicates the presence of a reverting call by:

• Alerting you at intervals with a single ring (or flash or beep, depending on your phone line setting).

• Briefly displaying a “Hold Reversion” message in the status bar at the bottom of the phone screen.

• Displaying the animated Hold Reversion icon next to the caller ID for the held call.

• Displaying a flashing amber line button (depending on the line state).

If you want to... Then...

Put a call on hold 1. Make sure the call you want to put on hold is highlighted.

2. Press Hold.

Remove a call from hold on the current line

Remove a call from hold on a different line

1. Make sure that the appropriate call is highlighted.

2. Press Resume.

1. Press the appropriate line button: or (flashing). Doing so might

cause a held call to resume automatically:

• If there is a reverting call on the line, that call will resume.

• If there is more than one reverting call on the line, the oldest

reverting call will resume.

• If a non-reverting held call is the only call on the line, it will resume.

2. If necessary, scroll to the appropriate call and press Resume.

and the phone displays the remote

Tips

• Engaging the Hold feature typically generates music or a beeping tone.

• If you receive an alert for an incoming call and a reverting call at the same time, by default your

phone will shift the focus of the phone screen to display the incoming call. Your system administrator can change this focus priority setting.

• If you use a shared line, Hold Reversion rings only on the phone that put the call on hold, not on the other phones that share the line.

22 OL-19613-01

• The duration between Hold Reversion alerts is determined by your system administrator.

Basic Call Handling

Using Mute

With Mute enabled, you can hear other parties on a call but they cannot hear you. You can use Mute with the handset, speakerphone, or a headset.

If you want to... Then...

Toggle Microphone on Press .

Toggle Microphone off Press .

Switching Between Multiple Calls

You can switch between multiple calls on one or more lines. If the call that you want to switch to is not automatically highlighted, use the Navigation button to scroll to it.

If you want to... Then...

Switch between connected calls on one line

Switch between connected calls on different lines

Switch from a connected call to answer a ringing call

1. Make sure the call that you want to switch to is highlighted.

2. Press Resume.

Any active call is placed on hold and the selected call is resumed.

Press for the line that you are switching to.

If a single call is holding on the line, the call automatically resumes. If multiple calls are holding, highlight the appropriate call and press Resume.

Press Answer, or if the call is ringing on a different line press (flashing). Any active call is placed on hold and the selected call is resumed.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Switching an In-Progress Call to Another Phone

You can switch in-progress calls between the desktop phone and your mobile phone or other remote destination.

If you want to... Then...

Switch an in-progress call on your desktop phone to a mobile phone

Switch an in-progress call from a mobile phone to your desktop phone

1. Press the Mobility softkey and select Send call to mobile.

2. Answer the in-progress call on your mobile phone.

The desktop phone line button turns red and handset icons and the calling party number appear on the phone display. You cannot use same phone line for any other calls, but if your desk phone supports multiple lines, you can use another line to make or receive calls.

1. Hang up the call on your mobile phone to disconnect the mobile phone, but not the call.

2. Press Resume on your desk phone within 4 seconds and start talking on the desk phone.

Viewing Multiple Calls

Understanding how multiple calls are displayed on your phone can help you organize your call-handling efforts.

In standard viewing mode, your phone displays calls as follows for the highlighted line:

• Calls with the highest precedence and longest duration display at the top of the list.

• Calls of a similar type are grouped together. For example, calls that you have interacted with are

grouped near the top, and calls on hold are grouped last.

You can use these additional methods to view multiple calls on multiple lines:

If you want to... Then...

View calls on another line

Switch to call overview mode

24 OL-19613-01

1. Press .

2. Immediately press the line button .

Press for the highlighted line.

The phone switches to call overview mode, displaying one call per line. The displayed call is either the active call or the held call with the longest duration.

To return to standard viewing mode, press , then immediately press the line button.

Basic Call Handling

Transferring Calls

Transfer redirects a connected call. The target is the number to which you want to transfer the call.

If you want to... Then...

Transfer a call without talking to the transfer recipient

Talk to the transfer recipient before transferring a call (consult transfer)

Transfer two current calls to each other (direct transfer) without staying on the line (SCCP phones only)

Redirect a call to a voice message system

1. From an active call, press Transfer.

2. Enter the target number.

3. Press Tran sfer again to complete the transfer or EndCall to cancel.

Note If your phone has on-hook transfer enabled, complete the transfer

by hanging up.

1. From an active call, press Tr ansfer.

2. Enter the target number.

3. Wait for the transfer recipient to answer.

4. Press Trans fe r again to complete the transfer or EndCall to cancel.

Note If your phone has on-hook transfer enabled, complete the transfer

by hanging up.

1. Scroll to highlight any call on the line.

2. Press Select.

3. Repeat this process for the second call.

4. With one of the selected calls highlighted, press DirTrfr. (To

display DirTrfr, you might need to press more.)

The two calls connect to each other and drop you from the call.

Note If you want to stay on the line with the callers, use Join instead.

Press iDivert. For more information, see Sending a Call to a Voice

Message System, page 26.

Tips

• If your phone has on-hook transfer enabled, complete the call by hanging up.

• If on-hook transfer is not enabled on your phone, hanging up without pressing Tr ansfer again

places the call on hold.

• You cannot use Trans fer to redirect a call on hold. Press Resume to remove the call from hold before transferring it.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Sending a Call to a Voice Message System

You can use iDivert to send an active, ringing, or on-hold call to your voice message system. Depending on the type of call and your phone configuration, you can also use iDivert to send the call to another party's voice message system.

• If the call was originally sent to someone else's phone, iDivert allows you to redirect the call either to your own voice message system or to the original called party’s voice message system. Your system administrator must make this option available to you.

• If the call was sent to you directly (not transferred or forwarded to you), or if your phone does not support the option described above, using iDivert redirects the call to your voice message system.

If you want to... Then...

Send an active, ringing, or on-hold call to a voice message system

Press iDivert. One of two things occurs:

• The call is transferred to your voice message system.

• Your phone screen displays a menu that allows you to

choose between your voice message system or the voice message system of the original called party. Choose an option to redirect the call.

Tip

If your phone displays a menu that disappears before you make your selection, you can press iDivert again to re-display the menu. You can also ask your system administrator to configure a longer timeout value.

Forwarding Calls to Another Number

You can use the call forwarding features to redirect incoming calls from your phone to another number.

Your system administrator might allow you to choose from two types of call forwarding features:

• Unconditional call forwarding (Call Forward All)—Applies to all calls that you receive.

• Conditional call forwarding (Call Forward No Answer, Call Forward Busy, Call Forward No

Coverage)—Applies to certain calls that you receive, according to conditions.

You can access Call Forward All on your phone or from your User Options web pages; conditional call forwarding features are accessible only from your User Options web pages. Your system administrator determines which call forwarding features are available to you.

26 OL-19613-01

If you want to... Then...

Set up Call Forward All on your primary line

Cancel Call Forward All on your primary line

Verify that Call Forward All is enabled on your primary line

Set up or cancel call forwarding remotely, or for a non-primary line

Press CFwdALL or Forward All and enter a target phone number.

Press CFwdALL or Forward All.

Look for:

• The call forward icon above your primary phone number: .

• The call forwarding target number in the status line.

1. Log in to your User Options web pages. (See Accessing Your

User Options Web Pages, page 61.)

2. Access your call forwarding settings (See Controlling Line

Settings on the Web, page 68.)

Note When call forwarding is enabled for any line other than the

Basic Call Handling

primary line, your phone does not provide you with any confirmation that calls are being forwarded. Instead, you must confirm your settings in the User Options web pages.

Tips

• Enter the call forward target number exactly as you would dial it from your phone. For example, enter an access code or the area code, if necessary.

• You can forward your calls to a traditional analog phone or to another IP phone, although your system administrator might restrict the call forwarding feature to numbers within your company.

• Call forwarding is phone line specific. If a call reaches you on a line where call forwarding is not enabled, the call will ring as usual.

• Your system administrator can enable a call forward override feature that allows the person receiving your forwarded calls to reach you. With override enabled, a call placed from the target phone to your phone is not forwarded, but rings through.

• Your phone may reject your attempt to set up Call Forward All directly on the phone if the target number that you enter would create a call forwarding loop or would exceed the maximum number of links permitted in a call forwarding chain.

Using Do Not Disturb

You can use the Do Not Disturb (DND) feature to turn off only the ringer on your phone or to turn off all audible and visual notifications of incoming calls. Your system administrator enables DND for your phone.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

When DND and Call Forward All are both enabled on your phone, calls are forwarded and the caller does not hear a busy tone.

DND interaction with other types of calls includes:

• DND does not affect intercom calls or non-intercom priority calls.

• If both DND and auto-answer are enabled, only intercom calls will be auto-answered.

If you want to... Then...

Turn on DND Press DND or Do Not Disturb .

“Do Not Disturb” displays on the phone, the DND lights, and the ring tone is turned off.

Turn off DND Press DND or Do Not Disturb .

Customize DND settings If your system administrator configured DND settings to appear

on the User Options page, follow these steps:

1. Log in to your User Options web pages. See Accessing Your

User Options Web Pages, page 61.

2. From the drop-down menu, choose User Options > Device.

3. Set the following options:

–

Do Not Disturb—Set to enable/disable DND.

–

DND Option—Choose either Call Reject (to turn off all audible and visual notifications) or Ringer Off (to turn off only the ringer).

–

DND Incoming Call Alert (applies to either DND option set)—Set the alert to beep only, flash only, disable the alert, or choose “None” (to use the “Alert” setting configured by your system administrator).

Tips

• When DND is active, DND blocking is applied to all the lines on your phone.

• When DND and Call Forward All are both enabled on your phone, Call Forward All takes

precedence on incoming calls. That is, calls will be forwarded and the caller will not hear a busy tone.

• Intercom and Multilevel Precedence and Preemption (MLPP), park reversion and hold reversion all override DND.

• Your system administrator enables the DND feature on your phone.

28 OL-19613-01

Basic Call Handling

Making Conference Calls

Your Cisco Unified IP Phone allows you to talk simultaneously with multiple parties in a conference call.

Using Conference Features

You can create a conference in various ways, depending on your needs and the features that are available on your phone.

• Conference—Allows you to create a standard (ad hoc) conference by calling each participant. Use

the Confrn softkey or the Conference button. Conference is available on most phones.

• Join—Allows you to create a standard (ad hoc) conference by combining existing calls. Use the

Join softkey or button.

• cBarge—Allows you to create a standard (ad hoc) conference by adding yourself to a call on a

shared line. Press a line button or use the cBarge softkey or button. cBarge is available only on phones that use shared lines.

• Meet-Me—Allows you to create or join a conference by calling a conference number. Use the

MeetMe softkey or button.

Using Conference

Conference allows you to call each participant. Conference is available on most phones.

If you want to... Then...

Create a conference 1. From a connected call, press Confrn or Conference. (You may

need to press the more softkey to see Confrn.)

2. Enter the participant’s phone number.

3. Wait for the call to connect.

4. Press Confrn or Conference again to add the participant to your

call.

5. Repeat to add additional participants.

Add new participants to an existing conference

See a list of participants or remove participants

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Repeat the steps listed above.

Your system administrator determines whether non-initiators of a conference can add or remove participants.

See Viewing or Removing Conference Participants, page 32.

Using Join

Join allows you to combine two or more existing calls to create a conference in which you are a participant.

If you want to... Then...

Create a conference by joining together existing calls that are on a single phone line

Create a conference by joining together existing calls that are on multiple phone lines

See a list of participants or remove participants

1. From an active call, highlight another call that you want to include in the conference and press Select.

Selected calls display this icon .

2. Repeat this step for each call that you want to add.

3. Press Join. (You may need to press the more softkey to see Join.)

1. From an active call, press Join. (You may need to press the more

softkey to see Join.)

2. Press the green flashing line button for the call(s) that you want to include in the conference.

One of the following occurs:

• The calls are joined.

• A window opens on your phone screen prompting you to select

the call(s) that you want to join. Highlight the call(s) and press Select, then press Join to complete the action.

Note If your phone does not support Join for calls on multiple lines,

transfer the calls to a single line before using Join.

Press ConfList or Conference List. (You may need to press the more softkey first.) See

page 32.

Viewing or Removing Conference Participants,

Tips

• If you frequently join more than two parties into a single conference, you might find it useful to first select the calls that you want to join, then press Join to complete the action.

• When Join completes, caller ID changes to “Conference.”

• You may be able to combine multiple conference calls by using the Join or DirTrfr softkeys. Check

with your system administrator to see whether this feature is available to you.

30 OL-19613-01

Basic Call Handling

Using cBarge

You can create a conference by using cBarge to add yourself to a call on a shared line.

If you want to... Then...

Create a conference by barging a call on a shared line

See a list of participants or remove participants

Press the line button for the shared line.

In some cases, you must highlight the call and press cBarge to complete the action.

See Using Barge to Add Yourself to a Shared-Line Call, page 39 for more information.

See Viewing or Removing Conference Participants, page 32.

Using Meet-Me

Meet-Me conferencing allows you to start or join a conference by calling the conference number.

If you want to... Then...

Start a Meet-Me conference 1. Obtain a Meet-Me phone number from your system administrator.

2. Distribute the number to participants.

3. When you are ready to start the meeting, go off-hook to get a dial

tone, then press MeetMe.

4. Dial the Meet-Me conference number.

Participants can now join the conference by dialing in.

Note Participants hear a busy tone if they call the conference before the

initiator has joined. In this case, participants must call back.

Join a Meet-Me conference Dial the Meet-Me conference number (provided by the conference

initiator).

Note You will hear a busy tone if you call the conference before the

initiator has joined. In this case, try your call again.

End a Meet-Me conference All participants must hang up.

The conference does not automatically end when the conference initiator disconnects.

Tip

If you call a secure Meet-Me conference number from a non-secure phone, your phone displays the message, “Device Not Authorized.” For more information, see

page 43.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Making and Receiving Secure Calls,

Viewing or Removing Conference Participants

During a standard (ad hoc) conference, you can view a list of participants and remove participants.

View a list of conference participants

Get an updated list of conference participants

See who initiated the conference

Remove any conference participant

Drop the last participant added to the conference

Verify that a conference call is secure

Verify that a participant is calling from a secure phone

Add more participants See Using Conference, page 29.

Press ConfList or Conference List.

Participants are listed in the order in which they join the conference with the most recent additions at the top.

While viewing the conference list, press Update.

While viewing the conference list, locate the participant listed at the bottom of the list with an asterisk (*) next to the name.

While viewing the conference list, highlight the participant’s name and press Remove.

While viewing the conference list, press RMLstC or Remove Last Participant.

Look for the or icon after “Conference” on the phone screen.

Look for the or icon beside the participant’s name on the phone screen.

Placing or Receiving Intercom Calls

You can make an intercom call to a target phone that auto-answers the call in speakerphone mode with mute activated. The one-way intercom call allows you to deliver a short message to the recipient. If the recipient’s handset or headset is in use, the audio is sent to the device that is in use. Any current call activity that your recipient is engaged in continues simultaneously.

The target destination receives an intercom-alert tone and can then choose to:

• Listen to the caller with your microphone muted (you can hear the caller but the caller cannot hear you).

• End the intercom call by pressing the EndCall softkey with the intercom call in focus. Do this if you do not want to hear the message.

• Talk to the caller by pressing the active intercom button, and use either the handset, headset or speaker. The intercom call becomes a two-way connection so that you can converse with the caller.

When using the intercom feature, be aware of the following:

• From an intercom line, you can only dial other intercom lines.

• You can use only one intercom line at a time.

• When your active call is being monitored or recorded, you cannot receive or place intercom calls.

32 OL-19613-01

Basic Call Handling

• You cannot place an intercom call on hold.

Note If you log into your desk phone every day using your Extension Mobility profile, make sure

that your system administrator configures your Extension Mobility profile to include the intercom feature.

If you want to... Then...

Place an intercom call to a preconfigured intercom target

Place an intercom call to any intercom number

Press (intercom target line) and, after you hear the intercom-alert tone, begin speaking.

Press (an intercom line). Enter the intercom target number or press a speed-dial number for your target. After you hear the intercom-alert tone, begin speaking.

Receive an intercom call When you hear the intercom-alert tone, handle the call in one of these

ways:

• Listen to the message in one-way audio.

• Speak to the caller by pressing (active intercom line).

• Press EndCall with the intercom call in focus.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Advanced Call Handling

Advanced call-handling tasks involve special features that your system administrator might configure for your phone depending on your call-handling needs and work environment.

Speed Dialing

Speed dialing allows you to enter an index number, press a button, or select a phone screen item to place a call. Depending on configuration, your phone can support several speed-dial features:

• Speed-dial buttons

• Abbreviated Dialing

• Fast Dials

Note • To set up speed-dial buttons and Abbreviated Dial, you must access your User Options

web pages. See

• To set up Fast Dials, you must access the Personal Directory feature. See Using Personal

Directory on Your Phone, page 57.

• Alternately, your system administrator can configure speed-dial features for you.

Accessing Your User Options Web Pages, page 61.

If you want to... Then...

Use speed-dial buttons

Use Abbreviated Dialing (On-hook)

34 OL-19613-01

1. Set up speed-dial buttons. See Setting Up Speed Dials on the Web, page 65.

2. To place a call, press (a speed-dial button).

Note If your phone supports the Busy Lamp Field (BLF) speed-dial feature, you can

see if the speed-dial number is busy before dialing. See

Determine a Line State, page 42.

1. Set up Abbreviated Dialing codes. See Setting Up Speed Dials on the Web,

page 65.

2. To place a call, enter the Abbreviated Dialing code and press AbbrDial.

Using BLF to

Advanced Call Handling

If you want to... Then...

Use Abbreviated Dialing (Off-hook)

Use Fast Dial 1. Create a Personal Address B ook entry and assign a Fast Dials code. See Using

1. Pick up the handset.

2. Press the AbbrDial softkey and enter the abbreviated dial code using the

keypad.

3. Press the AbbrDial softkey again.

To use Off-hook Abbreviated Dialing to conference a call:

1. Press the Confrn softkey. The user will hear dialtone.

2. Follow steps 2 and 3 above.

3. Press the Confrn softkey again.

To use Off-hook Abbreviated Dialing to transfer a call:

1. Press the Tr ansfer softkey. The user will hear dialtone.

2. Follow steps 2 and 3 above.

3. Press the Tr ansfer softkey again.

To use Off-hook Abbreviated Dialing while a call is on hold:

1. Press the NewCall softkey.

2. Follow steps 2 and 3 above.

Your Personal Address Book on the Web, page 62.

2. To place a call, access the Fast Dial service on your phone. See Using Personal

Directory on Your Phone, page 57.

Picking Up a Redirected Call on Your Phone

Call PickUp allows you to answer a call that is ringing on a coworker’s phone by redirecting the call to your phone. You might use Call PickUp if you share call-handling with coworkers.

If you want to... Then...

Answer a call that is ringing on another extension within your call pickup group

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

1. Press the PickUp softkey or button. (You might have to go

off-hook to display the softkey.)

If your phone supports auto-pickup, you are now connected to the call.

2. If the call rings, press Answer to connect to the call.

If you want to... Then...

Answer a call that is ringing on another extension outside of your call pickup group

Answer a call that is ringing on another extension in your group or in an associated group

Answer a call that is ringing on a particular extension (line number)

1. Press the GPickUp softkey or the Group PickUp button. (You might have to go off-hook to display the softkey.)

2. Enter the group pickup number.

If your phone supports auto-pickup, you are now connected to the call.

3. If the call rings, press Answer to connect to the call.

1. Press the OPickUp softkey or the Other PickUp button.

(You might have to go off-hook to display the softkey.)

If your phone supports auto-pickup, you are now connected to the call.

2. If the call rings, press Answer to connect to the call.

1. Press the GPickUp softkey or the Group PickUp button.

(You might have to go off-hook to display the softkey.)

2. Enter the line number with the call that you want to pick up. For example, if the call that you want to pick up is ringing on line 12345, enter 12345.

If your phone supports auto-pickup, you are now connected to the call.

3. If the call rings, press Answer to connect to the call.

Tips

• If multiple calls are available for pick up, your phone picks up the oldest call first (the call that has been ringing for the longest time).

• If you press GPickUp or Group PickUp and enter a line number, your phone picks up the ringing call on that particular line (if available).

• If you have multiple lines and want to pick up the call on a non-primary line, first press for the desired line, then press a Call PickUp softkey or button.

• Depending on how your phone is configured, you might receive an audio and/or visual alert about a call to your pickup group.

• If you use the BLF Pickup feature on your phone, see Using BLF to Determine a Line State,

page 42.

36 OL-19613-01

Advanced Call Handling

Storing and Retrieving Parked Calls

You can park a call when you want to store the call so that you or someone else can retrieve it from another phone in the Cisco Unified Communications Manager system (for example, a phone at a coworker’s desk or in a conference room).

You can park a call by using these methods:

• Call Park—Use the Park softkey to store the call. Your phone displays the call park number where the system stored your call. You must record this number and then use the same number to retrieve the call.

• Directed Call Park—Use the Trans fe r softkey to direct the call to an available directed call park number that you dial or speed dial. To retrieve the call from a directed call park number, dial the park retrieval prefix, then dial or speed dial the same directed call park number. You can use a Directed Call Park button to speed dial the directed call park number and to monitor whether a directed call park number is occupied or available.

If you want to... Then...

Store an active call using Call Park

Retrieve a parked call Enter the call park number from any Cisco Unified IP Phone in your

Direct and store an active call at a directed call park number

Retrieve a parked call from a directed call park number

1. During a call, press Park. (You may need to press the more softkey to see Park.)

2. Note the call park number displayed on your phone screen.

3. Hang up.

network to connect to the call.

1. During a call, press Tr an sfer.

2. Press the Directed Call Park with the park-unoccupied icon to

speed dial the directed call park number.

A Directed Call Park (flashing) with park-occupied icon indicates the directed call park number is not available.

3. Press Tr ansfe r again to finish storing the call.

From any Cisco Unified IP Phone in your network, enter the park retrieval prefix and dial the directed call park number. Or after entering the park retrieval prefix, press the

(flashing) with to connect to the call.

Tips

• You have a limited time to retrieve a parked call before it reverts to ringing at the original number. See your system administrator for details.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

• Your system administrator can assign Directed Call Park buttons to available line buttons on your

Cisco Unified IP Phone 7962G that has a Cisco Unified IP Phone Expansion Module (the Cisco Unified IP Phone 7942G does not support the Cisco Unified IP Phone Expansion Module).

• You can dial directed call park numbers if you do not have Directed Call Park buttons. However, you will not be able to see the status of the directed call park number.

Logging Out of Hunt Groups

If your organization receives a large number of incoming calls, you might be a member of a hunt group. A hunt group includes a series of directory numbers that share the incoming call load. When the first directory number in the hunt group is busy, the system hunts for the next available directory number in the group and directs the call to that phone.

When you are away from your phone, you can prevent hunt group calls from ringing your phone by logging out of hunt groups.

If you want to... Then...

Log out of hunt groups to temporarily block hunt group calls

Press HLog or Hunt Group. Your phone screen displays, “Logged

out of Hunt Group.”

Press HLog or Hunt Group. When logged in, the Hunt Group button

is lit.

Tip

Logging out of hunt groups does not prevent non-hunt group calls from ringing your phone.

Using a Shared Line

Your system administrator might ask you to use a shared line if you:

• Have multiple phones and want one phone number

• Share call-handling tasks with coworkers

• Handle calls on behalf of a manager

Understanding Shared Lines

Remote-in-Use Icon

The Remote-in-Use icon appears when another phone that shares your line has a connected call. You can place and receive calls as usual on the shared line, even when the Remote-in-Use icon appears.

38 OL-19613-01

Advanced Call Handling

Sharing Call Information and Barging

Phones that share a line each display information about calls that are placed and received on the shared line. This information might include caller ID and call duration. (See the exceptions.)

When call information is visible in this way, you and coworkers who share a line can add yourselves to calls using either Barge or cBarge. See

Using Barge to Add Yourself to a Shared-Line Call, page 39.

Privacy section for

Privacy

If you do not want coworkers who share your line to see information about your calls, enable the Privacy feature. Doing so also prevents coworkers from barging your calls. See

Viewing or Barging a Shared-Line Call, page 41.

Note The maximum number of calls that a shared line supports can vary by phone.

Preventing Others from

Using Barge to Add Yourself to a Shared-Line Call

You can use barge features (cBarge or Barge) to add yourself to calls on your shared line. (Calls must be non-private calls. See

Understanding Shared Lines, page 38.)

Understanding Barge Features

cBarge and Barge

Depending on how your phone is configured, you can add yourself to a non-private call on a shared line using either cBarge or Barge:

• cBarge converts the call into a standard conference, allowing you to add new participants. (See

Making Conference Calls, page 29 for information about standard conferences.)

• Barge allows you to add yourself to the call but does not convert the call into a conference or allow

you to add new participants.

Single-button and Multi-touch Barge

Your system administrator determines whether the barge feature on your phone (cBarge or Barge) operates as a single-button or multi-touch feature.

• Single button barge allows you to press a line button to barge a call (if only one call is on the line).

• Multi-touch barge allows you to view call information before barging.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Using Barge Features

The table below describes how to use barge features (cBarge or Barge) to add yourself to a call on a shared line.

If you want to... Then...

See if the shared line is in use

Add yourself to a call on a shared line

View conference participants (if you used cBarge)

Tips

• When you barge a call, other parties might hear a beep tone announcing your presence. With cBarge, other parties hear a brief audio interruption and the phone screen changes to display conference details.

• When you leave a call that you have barged, other parties hear a beep-beep tone.

• If a phone that is using the shared line has Privacy enabled, call information and barge softkeys

will not appear on the other phones that share the line.

• If a phone that is using the shared line has Privacy disabled and it is configured with Private Line Automated Ringdown (PLAR), the barge and cBarge features will still be available.

• You will be disconnected from a call that you have joined using Barge if the call is put on hold, transferred, or turned into a conference call.

Look for the remote-in-use icon next to a red line button .

Press the red line button for the shared line.

One of the following occurs:

• You are added to the call.

• A window opens on your phone screen prompting you to select the call

that you want to barge. Press Barge or cBarge to complete the action. (You may need to press the more softkey to display Barge or cBarge.)

See Viewing or Removing Conference Participants, page 32.

40 OL-19613-01

Advanced Call Handling

Preventing Others from Viewing or Barging a Shared-Line Call

If you share a phone line, you can use the Privacy feature to prevent others who share the line from viewing or barging (adding themselves to) your calls.

If you want to... Then...

Prevent others from viewing or barging calls on a shared line

Allow others to view or barge calls on a shared line

Tips

• If the phone that shares your line has Privacy enabled, you can make and receive calls using the

shared line as usual.

• The Privacy feature applies to all shared lines on your phone. Consequently, if you have multiple

shared lines and Privacy is enabled, coworkers will not be able to view or barge calls on any of your shared lines.

1. Press Private .

2. To verify that Privacy is on, look for the Privacy-enabled

icon

1. Press Private .

2. To verify that Privacy is off, look for the Privacy-disabled

icon

next to an amber line button .

next to an unlit line button .

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Using BLF to Determine a Line State

Busy Lamp Field features (BLF) allow you to view the state of a phone line that is associated with a speed-dial button, call log, or directory listing on your phone. If you use BLF Pickup, you can answer a ringing call for the line that you are monitoring. Your system administrator determines which BLF features are configured for your phone.

If you want to... Then...

See the state of a line listed in a call log or directory

Look for one of these indicators next to the line number:

Line is in-use.

Line is idle.

BLF indicator unavailable for this line.

Line is in Do Not Disturb state.

See the state of a speed-dial line

Use BLF Pickup to answer a call ringing on a coworker’s phone

Look for one of these indicators next to the line number:

+ Line is in-use.

+ Line is idle.

BLF indicator unavailable for this line.

+ Line is in Do Not Disturb state.

+ (flashing)—Line is ringing (BLF Pickup only).

Press the BLF Pickup button while the line is ringing.

The call is redirected to the next available line on your phone. (If you want to specify a line, first press a line button, then press the BLF button.)

If your phone supports auto-pickup, the call connects automatically. Otherwise, the call rings on your phone for you to answer.

Note If you press the BLF Pickup button when the monitored line is not

ringing, your phone will speed dial the line number.

Tips

• Your phone might play an audible indicator to alert you when a call is ringing on the monitored line (BLF Pickup only).

• BLF Pickup answers the oldest ringing call first (if the line that you are monitoring has more than one ringing call).

42 OL-19613-01

Advanced Call Handling

Making and Receiving Secure Calls

Depending on how your system administrator has configured your phone system, your phone might support making and receiving secure calls.

Your phone is capable of supporting these types of calls:

• Authenticated call—The identities of all phones participating in the call have been verified.

• Encrypted call—The phone is receiving and transmitting encrypted audio (your conversation)

within the Cisco IP network. Encrypted calls are also authenticated.

• Protected call—The phone is receiving and transmitting encrypted audio (your conversation) with

another phone. A protected call provides a similar level of security as an encrypted call, but adds additional security. If the call is protected at both ends, a security tone plays at the beginning of the conversation. Some features, such as conference calling, shared lines, Extension Mobility, and join across lines are not available when protected calling is configured. Protected calls are not authenticated.

• Non-secure call—At least one of the participating phones or the connection does not support these

security features, or the phones cannot be verified.

If you want to... Then...

Check the security level of a call or conference

Look for a security icon in the top right corner of the call activity area, next to the call duration timer:

Authenticated call or conference

Encrypted call or conference

Non-secure call or conference

Verify that the phone on the other end of the connection is also secure

Determine if secure calls can be made in your company

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Look for the encrypted lock icon and listen for a security tone at the beginning of the call.

When encrypted calling is configured on your phone, the lock icon is displayed. However, the conversation is protected only when the security tone plays at the beginning of a call, indicating that the call is protected on both ends of the call. If your call is connected to a non-protected phone, the secure tone is not played.

Contact your system administrator.

Note There are interactions, restrictions, and limitations that affect how security features work on

your phone. For more information, ask your system administrator.

Tracing Suspicious Calls

If you are receiving suspicious or malicious calls, your system administrator can add the Malicious Call Identification (MCID) feature to your phone. This feature enables you to identify an active call as suspicious, which initiates a series of automated tracking and notification messages.

If you want to... Then...

Notify your system administrator about a suspicious or harassing call

Press MCID or Malicious Call ID.

Your phone plays a tone and displays the message, “MCID successful”.

Prioritizing Critical Calls

(SCCP phones only.)

In some specialized environments, such as military or government offices, you might need to make and receive urgent or critical calls. If you have the need for this specialized call handling, your system administrator can add Multilevel Precedence and Preemption (MLPP) to your phone.

Keep these terms in mind:

• Precedence indicates the priority associated with a call.

• Preemption is the process of ending an existing, lower priority call while accepting a higher

priority call that is sent to your phone.

If you... Then...

Want to choose a priority (precedence) level for an outgoing call

Want to make a priority (precedence) call

Hear a special ring (faster than usual) or special call waiting tone

44 OL-19613-01

Contact your system administrator for a list of corresponding precedence numbers for calls.

Enter the MLPP access number (provided by your system administrator) followed by the phone number.

You are receiving a priority (precedence) call. An MLPP icon on your phone screen indicates the priority level of the call.

Advanced Call Handling

If you... Then...

Want to view priority level of a call Look for an MLPP icon on your phone screen:

Priority call

Medium priority (immediate) call

High priority (flash) call

Highest priority (flash override) or Executive Override call

Higher priority calls are displayed at the top of your call list. If you do not see an MLPP icon, the priority level of the call is normal (routine).

Want to accept a higher-priority call Answer the call as usual. If necessary, end an active call first.

Hear a continuous tone interrupting your call

You or the other party are receiving a call that must preempt the current call. Hang up immediately to allow the higher priority call to ring through.

Tips

• When you make or receive an MLPP-enabled call, you will hear special ring tones and call waiting

tones that differ from the standard tones.

• If you enter an invalid MLPP access number, a verbal announcement will alert you of the error.

• An MLPP-enabled call retains its priority and preemptive status when you:

–

Put the call on hold

–

Transfer the call

–

Add the call to a three-way conference

–

Answer the call using PickUp

• MLPP overrides the Do Not Disturb (DND) feature.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Using Cisco Extension Mobility

Cisco Extension Mobility (EM) allows you to temporarily configure a Cisco Unified IP Phone as your own. Once you log in to EM, the phone adopts your user profile, including your phone lines, features, established services, and web-based settings. Your system administrator must configure EM for you.

If you want to... Then...

2. Enter your user ID and PIN (provided by your system administrator).

3. If prompted, select a device profile.

Log out of EM 1. Choose > EM Service (name can vary).

2. When prompted to log out, press Yes.

Tips

• EM automatically logs you out after a certain amount of time. Your system administrator establishes this time limit.

• Changes that you make to your EM profile from your User Options web pages take effect immediately if you are logged in to EM on the phone; otherwise, changes take effect the next time you log in.

• Changes that you make to the phone from your User Options web pages take effect immediately if you are logged out of EM; otherwise, changes take effect after you log out.

• Local settings controlled by the phone are not maintained in your EM profile.

Managing Business Calls Using a Single Phone Number

With Mobile Connect and Mobile Voice Access installed, you can use your mobile phone to handle calls associated with your desktop phone number.

If you want to... Then...

Configure Mobile Connect Use the User Options web pages to set up remote destinations and

create access lists to allow or block calls from specific phone numbers from being passed to the remote destinations. See

and Access Lists for Mobile Connect, page 70.

Answer a call using your mobile phone

Switch an in-progress call between your desk phone and a mobile phone

46 OL-19613-01

See Answering a Call, page 20.

See Switching an In-Progress Call to Another Phone, page 24.

Setting Up Phones

If you want to... Then...

Put a call that has been picked up on your mobile phone on hold

1. Press the Enterprise Hold (name may vary) softkey.

The other party is placed on hold.

2. On your mobile phone, press the Resume (name may vary) softkey. See

Connect to Mobile Voice Access

Turn on Mobile Connect from your mobile phone

1. From any phone, dial your assigned Mobile Voice Access number.

2. Enter the number you are calling from, if prompted, and your PIN.

1. Dial your assigned Mobile Voice access number.

2. Enter your mobile phone number (if requested) and PIN.

3. Press 2 to activate Mobile Connect.

4. Choose whether to turn Mobile Connect on for all configured

phones or just one:

–

Make a call from your

See Placing a Call—Additional Options, page 17.

mobile phone

Turn off Mobile Connect from your mobile phone

1. Dial your assigned Mobile Voice Access number.

2. Enter your mobile phone number (if requested) and PIN.

3. Press 3 to disable Mobile Connect.

4. Choose whether to turn off Mobile Connect for all configured

phones or just one:

–

Turn on or off Mobile Connect access to all your remote destinations from your desk phone

1. Press Mobility to display the current remote destination status (Enabled or Disabled).

2. Press Select to change the status.

3. Press Exit.

Advanced Call Handling

Switching an In-Progress Call to Another Phone, page 24.

All phones—Enter 2.

One phone—Enter 1 and then the remote destination you want to add, followed by #.

All phones—Enter 2.

One phone—Enter 1 and then the remote destination you want to add, followed by #.

Tips

• When calling Mobile Voice Access, you must enter the number you are calling and your PIN if any of the following is true:

–

The number you are calling from is not one of your remote destinations.

–

The number is blocked by you or your carrier (shown as “Unknown Number”).

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

–

The number is not accurately matched in the Cisco Unified Communications Manager database; for example, if your number is 510-666-9999, but it is listed as 666-9999 in the database, or your number is 408-999-6666, but it is entered as 1-408-999-6666 in the database.

• If you incorrectly enter any requested information (such as mobile phone number or PIN) three times in a row, the Mobile Voice Access call disconnects, and you are locked out for a period of time. Contact your system administrator if you need assistance.

48 OL-19613-01

Using a Handset, Headset, and Speakerphone

You can use your phone with these audio devices: a handset, headset, or speakerphone.

The phone is off-hook when the handset is lifted or another audio device is in use.

The phone is on-hook when the handset is in its cradle and other audio devices are not in use.

Using a Handset

If you want to... Then...

Use the handset Lift it to go off-hook; replace it to go on-hook.

The ringing line is automatically selected. Ask your system administrator about options to always select the primary line.

Switch to the speakerphone or headset during a call

Adjust the volume level for a call

Press or , then hang up the handset.

Press during a call or after invoking a dial tone.

Press Save to preserve the volume level for future calls.

Using a Headset

Your phone supports four- or six-wire headset jacks for wired headsets, and also supports wireless headsets. For information about purchasing headsets, see

You can use a headset with all of the controls on your phone, including and .

However, if you use a wireless headset, refer to the wireless headset documentation for information.

If you want to... Then...

Toggle headset mode on and off Press .

Switch to a handset Lift the handset.

Adjust the volume level for a call

If you use AutoAnswer, see Using AutoAnswer with a Headset or Speakerphone, page 51.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Press during a call or after invoking a dial tone.

Press Save to preserve the volume level for future calls.

Using a Headset, page 5.

Using a Wireless Headset

Refer to the wireless headset documentation for information about using the wireless headset’s remote features. Also, check with your system administrator to be sure your phone is enabled to use a wireless headset with the wireless headset remote hookswitch control feature.

Using Wideband with your Headset

If you use a headset that supports wideband, you might experience improved audio sensitivity if you enable the wideband setting on your phone (this setting is disabled by default). To access the setting, choose

If the Wideband Headset setting shows as dimmed, then this setting is not user controllable.

Check with your system administrator to be sure your phone system is configured to use wideband. If the system is not configured for wideband, you may not detect any additional audio sensitivity even when using a wideband headset. To learn more about your headset, refer to the headset documentation or ask your system administrator for assistance.

> User Preferences > Audio Preferences > Wideband Headset.

Using a Speakerphone

Many of the actions you can take to dial a number or answer a call will automatically trigger speakerphone mode, assuming that the handset is in its cradle and

is not lit.

If you want to... Then...

Toggle speakerphone mode on or off

Switch to a handset Lift the handset.

Adjust the volume level for a call

50 OL-19613-01

Press .

Press during a call or after invoking a dial tone.

Press Save to preserve the volume level for future calls.

Using a Handset, Headset, and Speakerphone

Using AutoAnswer with a Headset or Speakerphone

When AutoAnswer is enabled, your phone answers incoming calls automatically after a few rings. Your system administrator configures AutoAnswer to use either the speakerphone or a headset. You might use AutoAnswer if you receive a high volume of incoming calls.

If you... Then...

Use AutoAnswer with a headset

Use AutoAnswer with the speakerphone

Keep headset mode active (in other words, keep illuminated), even when you are not on a call.

To keep headset mode active, do the following:

• Press EndCall to hang up.

• Press New Call or Dial to place new calls.

If your phone is set up to use AutoAnswer in headset mode, calls are automatically answered only if

Otherwise, calls ring normally and you must manually answer them.

Keep the handset in the cradle and headset mode inactive ( unlit).

Otherwise, calls ring normally and you must manually answer them.

is illuminated.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Changing Phone Settings

You can customize your Cisco Unified IP Phone by adjusting the ring tone, background image, and other settings.

Customizing Rings and Message Indicators

You can customize how your phone indicates an incoming call and a new voice mail message. You can also adjust the ringer volume for your phone.

If you want to... Then...

Change the ring tone per line

Change the ring pattern per line (flash-only, ring once, beep-only, etc.)

Adjust the volume level for the phone ringer

Change the way that the voice message light on your handset works

1. Choose > User Preferences > Rings.

2. Choose a phone line or the default ring setting.

3. Choose a ring tone to play a sample of it.

4. Press Select and Save to set the ring tone, or press Cancel.

1. Log in to your User Options web pages. (See Accessing Your User

Options Web Pages, page 61.)

2. Access your call ring pattern settings. (See Controlling Line

Settings on the Web, page 68.)

Note Before you can access this setting, your system administrator might

need to enable it for you.

Press while the handset is in the cradle and the headset and speakerphone buttons are off. The new ringer volume is saved automatically.

1. Log in to your User Options web pages. (See Accessing Your User

Options Web Pages, page 61.)

2. Access your message indicator settings. (See Controlling Line

Settings on the Web, page 68.)

Note Typically, the default system policy is to indicate a new voice

message by displaying a steady light on the handset light strip.

52 OL-19613-01

Customizing the Phone Screen

You can adjust the characteristics of your phone screen.

If you want to... Then...

Change the phone screen contrast

Change the background image

Change the language on your screen

Change the line text label

Adjust contrast for your Cisco Unified IP Phone Expansion Module

1. Choose > User Preferences > Contrast.

2. To make adjustments, press Up, Down or .

3. Press Save, or press Cancel.

Note If you accidentally save a very light or very dark contrast and cannot

see the phone screen display:

Press and then press 1, 4 on the keypad.

Next, press to change the contrast until you can see the phone screen display, and then press Save.

1. Choose > User Preferences > Background Images.

2. Scroll through available images and press Select to choose an image.

3. Press Preview to see a larger view of the background image.

4. Press Exit to return to the selection menu.

5. Press Save to accept the image or press Cancel.

Note If you do not see a selection of images, then this option has not been

enabled on your system.

1. Log in to your User Options web pages. (See Accessing Your User

Options Web Pages, page 61.)

2. Access your user settings. (See Controlling User Settings on the Web,

page 67.)

1. Log in to your User Options web pages. (See Accessing Your User

Options Web Pages, page 61.)

2. Access your line label settings. (See Controlling Line Settings on the

Web, page 68.)

1. Choose > User Preferences > Contrast.

2. To make adjustments, press Up, Down or .

3. Press Save, or press Cancel.

Note The Cisco Unified IP Phone 7942G does not support the Cisco Unified

IP Phone Expansion Module.

Changing Phone Settings

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Using Call Logs and Directories

This section describes how you can use call logs and directories. To access both features, use the Directories button

Using Call Logs

Your phone maintains call logs. Call logs contain records of your missed, placed, and received calls.

Your phone administrator determines whether missed calls are logged in your missed calls directory for a given line appearance on your phone.

If you want to... Then...

View your call logs Choose > Missed Calls, Placed Calls, or Received Calls. Each stores

Display details for a single call record

Erase all call records in all logs

Erase all call records in a single log

Erase a single call record 1. Choose > Missed Calls, Placed Calls, or Received Calls.

up to 100 records.

1. Choose > Missed Calls, Placed Calls, or Received Calls.

2. Highlight a call record.

3. Press Details. Doing so displays information such as called number,

calling number, time of day, and call duration (for placed and received calls only).

Press , then press Clear.

1. Choose > Missed Calls, Placed Calls, or Received Calls.

2. Highlight a call record.

3. Press Clear. (You may need to press the more softkey to display

Clear.)

2. Highlight a call record.

3. Press Delete.

54 OL-19613-01

If you want to... Then...

Dial from a call log (while not on another call)

1. Choose > Missed Calls, Placed Calls, or Received Calls.

2. Highlight a call record.

Note If the Details softkey appears, the call is the primary entry of a

3. If you need to edit the displayed number, press EditDial followed by

<< or >>. To delete the number, press EditDial followed by Delete. (You may need to press the more softkey to display Delete.)

4. Go off-hook to place the call.

Dial from a call log (while connected to another call)

1. Choose > Missed Calls, Placed Calls, or Received Calls.

2. Highlight a call record.

Note If the Details softkey appears, the call is the primary entry of a

3. If you need to edit the displayed number, press EditDial followed by

<< or >>. To delete the number, press EditDial followed by Delete. (You may need to press the more softkey to display Delete.)

4. Press Dial.

5. Choose a menu item to handle the original call:

• Hold—Puts the first call on hold and dials the second.

• Trans fer—Transfers the first party to the second and drops you from

the call. (Press Transfe r again after dialing to complete the action.)

• Conference—Creates a conference call with all parties, including you. (Press Confrn or Conference again after dialing to complete the action.)

• EndCall—Disconnects the first call and dials the second.

See if the line in the call log is busy before placing

Look for Busy Lamp Field indicators. See Using BLF to Determine a Line

State, page 42.

a call to that line

Place a call from a URL entry in a call log (SIP phones only)

1. Choose > Missed Calls, Placed Calls, or Received Calls.

2. Highlight the URL entry that you want to dial.

3. If you need to edit the entry, press EditDial.

4. The icon appears to indicate that you can begin editing

characters in the URL entry.

5. Press Dial.

multiparty call. See the

multiparty call. See the Tips section below.

Tips section below.

Using Call Logs and Directories

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Tips

• (SCCP and SIP phones) Your phone might be set up for international call logging, which is indicated by a “+” symbol on the call logs, redial, or call directory entries. See your system administrator for more information.

• (SCCP phones only) To view the complete call record of a multiparty call (for example, of call that has been forwarded or transferred to you), highlight the call record and press Details. The Details record shows two entries for each missed or received multiparty call. The entries are listed in reverse chronological order:

–

The first logged entry is the name/number of the last completed call of a multiparty call received on your phone.

–

The second logged entry is the name/number of the first completed call of a multiparty call received on your phone.

Directory Dialing

Depending on configuration, your phone can provide corporate and personal directory features:

• Corporate Directory—Corporate contacts that you can access on your phone. Your system administrator sets up and maintains your Corporate Directory.

• Personal Directory—If available, personal contacts and associated speed-dial codes that you can configure and access from your phone and User Options web pages. Personal Directory is comprised of Personal Address Book (PAB) and Fast Dials:

–

PAB is a directory of your personal contacts.

–

Fast Dials allows you to assign codes to PAB entries for quick dialing.

Using Corporate Directory on Your Phone

You can use a corporate directory to place calls to coworkers.

If you want to... Then...

Dial from a corporate directory (while not on another call)

56 OL-19613-01

1. Choose > Corporate Directory (exact name can vary).

2. User your keypad to enter a full or partial name and press Search.

3. To dial, select the listing, or scroll to the listing and go off-hook.

Using Call Logs and Directories

If you want to... Then...

Dial from a corporate directory (while on another call)

See if the phone line in the directory is busy

1. Choose > Corporate Directory (exact name can vary).

2. User your keypad to enter a full or partial name and press Search.

3. Scroll to a listing and press Dial.

4. Choose a menu item to handle the original call:

• Hold—Puts the first call on hold and dials the second.

• Trans fer—Transfers the first party to the second and drops you

from the call. (Press Transfer again after dialing to complete the action.)

• Conference—Creates a conference call with all parties, including you. (Press Confrn or Conference again after dialing to complete the action.)

• EndCall—Disconnects the first call and dials the second.

Look for Busy Lamp Field (BLF) indicators. See Using BLF to Determine a

Line State, page 42.

Tip

Use the numbers on your keypad to enter characters on your phone screen. Use the Navigation button on your phone to move between input fields.

Using Personal Directory on Your Phone

The Personal Directory feature set contains your Personal Address Book (PAB) and Fast Dials. This section describes how to set up and use Personal Directory on your phone. Alternately, see

Personal Directory on the Web, page 62.

If you want to... Then...

Access Personal Directory (for PAB and Fast Dial codes)

Search for a PAB entry

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

1. Choose > Personal Directory (exact name can vary).

2. Enter your Cisco Unified Communications Manager user ID and PIN,

then press Submit.

1. Access Personal Directory, then choose Personal Address Book.

2. Enter search criteria and press Submit.

3. You can choose Previous or Next to move through listings.

4. Highlight the PAB listing that you want and press Select.

Using

If you want to... Then...

Dial from a PAB entry

Delete a PAB entry 1. Search for a listing.

Edit a PAB entry 1. Search for a listing.

Add a new PAB entry 1. Access Personal Directory, then choose Personal Address Book.

Assign a Fast Dial code to a PAB entry

Add a new Fast Dial code (not using a PAB entry)

Search for Fast Dial codes

1. Search for a listing.

2. Highlight the listing and press Select.

3. Press Dial. (You may need to press the more softkey to see Dial.)

2. Highlight the listing and press Select.

3. Press Edit.

4. Press Delete.

5. Choose OK to confirm the deletion.

2. Highlight the listing and press Select.

3. Press Edit to modify a name or email address.

4. If necessary, choose Phones to modify a phone number.

5. Press Update.

2. Access the Search page by choosing Submit. (You do not need to input

search information first.)

3. Press New.

4. Use your phone keypad to enter a name and e-mail information.

5. Choose Phones and use the keypad to enter phone numbers. Be sure to

include any necessary access codes such as a 9 or 1.

6. Choose Submit to add the entry to the database.

1. Search for a PAB entry.

2. Highlight the listing and press Select.

3. Press Fast Dial.

4. Highlight the number that you want to dial and press Select.

5. Highlight any unassigned Fast Dial code that you want to assign to the

number and press Select.

1. Choose > Personal Directory > Personal Fast Dials.

2. Highlight a Fast Dial code that is unassigned and press Assign.

3. Enter a phone number.

4. Press Update.

1. Choose > Personal Directory > Personal Fast Dials.

2. Choose Next to move through listings.

58 OL-19613-01

Using Call Logs and Directories

If you want to... Then...

Place a call using a Fast Dial code

Delete a Fast Dial code

Log out of Personal Directory

1. Search for a Fast Dial code.

2. Press Dial.

1. Search for a Fast Dial code.

2. Highlight the listing you want and press Remove.

3. Press Remove again.

1. Choose > Personal Directory (exact name can vary).

2. Choose Log out.

3. Press OK.

Tips

• Your system administrator can provide you with the user ID and PIN that you need to log in to Personal Directory.

• Personal Directory automatically logs you out after a certain amount of time. This time limit can vary. Ask your system administrator for more information.

• Use the numbers on your keypad to enter characters on your phone screen. Use the Navigation button on your phone to move between input fields.

• Your phone might be set up for international call logging, which is indicated by a “+” symbol on the call logs, redial, or call directory entries. See your system administrator for more information.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Accessing Voice Messages

To access voice messages, use the Messages button

Note Your company determines the voice message service that your phone system uses. For the most

accurate and detailed information, refer to the documentation that came with your voice message system.

If you want to... Then...

Set up and personalize your voice message service

Check for your new voice messages

Press and follow the voice instructions.

If a menu appears on your screen, choose an appropriate menu item.

Look for:

• A steady red light on your handset. (This indicator can vary. See

Customizing Rings and Message Indicators, page 52.)

• A flashing message waiting icon and text message on your phone screen.

Note The red light and message waiting icon display only when you have a

voice message on your primary line, even if you receive voice messages on other lines.

Listen for:

• A stutter tone from your handset, headset, or speakerphone when you place a call.

Note The stutter tone is line-specific. You hear it only when using the line

with the waiting messages.

Listen to your voice messages or access the voice messages menu

Send a call to a voice message system

60 OL-19613-01

Press .

Depending on your voice message service, doing so either auto-dials the message service or provides a menu on your screen.

When you connect to a voice message service, the line that has a voice message is selected by default. If more than one line has a voice mail, then the first available line is selected. Ask your system administrator about options to always connect to the voice message service on the primary line.

Press iDivert. For more information, see Sending a Call to a Voice Message

System, page 26.

Using the User Options Web Pages

Your Cisco Unified IP Phone is a network device that can share information with other network devices in your company, including your personal computer. You can use your computer to log in to your Cisco Unified CM User Options web pages, where you can control features, settings, and services for your Cisco Unified IP Phone. For example, you can set up speed-dial buttons from your

Options web pages.

User

Accessing Your User Options Web Pages

This section describes how to log in and select a phone device.

If you want to... Then do this...

Select a device after logging in

Select a configuration option after logging in

1. Obtain a User Options URL, user ID, and default password from your system administrator.

2. Open a web browser on your computer, enter the URL, and log on.

3. If prompted to accept security settings, click Yes or Install Certificate.

The Cisco Unified Communications Manager User Options main web page displays. From this page you can choose User Options to access User Settings, Directory features, a Personal Address Book, and Fast Dials.

Or, to access phone-specific options, select a device (see below).

1. After you have logged in to your User Options web pages, choose User Options > Device.

The Device Configuration page displays.

2. If you have multiple devices assigned to you, choose the appropriate device (phone model, Extension Mobility profile, or Remote Destination profile) from the Name drop-down menu.

Note Toolbar buttons located at the top of the Device Configuration page are

specific to the selected device type.

1. After you have logged in to your User Options web pages, choose User Options to access User Settings, Directory, Personal Address Book, Fast

Dials, and Mobility Settings.

2. To return to the Device Configuration page from another page, choose User Options > Device.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Configuring Features and Services on the Web

The topics in this section describe how to configure features and services from your User Options web pages after logging in. See

Using Personal Directory on the Web

The Personal Directory feature set that you can access on your computer consists of:

• A Personal Address Book (PAB)

• Fast Dials

• Cisco Unified Communications Manager Address Book Synchronizer

Note You can also access PAB and Fast Dials from your phone. See Using Personal Directory on

Your Phone, page 57.

Using Your Personal Address Book on the Web

This section describes how to use your PAB from your User Options web pages.

Accessing Your User Options Web Pages, page 61.

If you want to... Then do this after you log in...

Add a new PAB entry 1. Choose User Options > Personal Address Book.

2. Click Add New.

3. Enter information for the entry.

4. Click Save.

Search for a PAB entry 1. Choose User Options > Personal Address Book.

2. Specify search information and click Find.

Edit a PAB entry 1. Search for a PAB entry.

2. Click a name or nickname.

3. Edit the entry as needed and click Save.

62 OL-19613-01

If you want to... Then do this after you log in...

Delete a PAB entry 1. Search for a PAB entry.

2. Select one or more entries.

3. Click Delete Selected.

Assign a line button for PAB

Note Before you can assign a line button for PAB, your system

administrator must configure the phone to display services. Contact your system administrator for more information.

1. Choose User Options > Device.

2. Click Service URL.

3. Choose the Personal Address Book service from the Button

drop-down list box.

4. Enter a phone label for the button.

5. Click Save.

6. Click Reset and then click Restart to refresh the phone

configuration.

You can now press the line button to access PAB codes.

Using the User Options Web Pages

Configuring Fast Dials on the Web

This section describes how to assign Fast Dials from your User Options web pages.

If you want to... Then do this after you log in...

Assign a Fast Dial code to a PAB entry

Assign a Fast Dial code to a phone number (without using a PAB entry)

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

1. Create a PAB entry. See Using Your Personal Address Book on the

Web, page 62.

2. Choose User Options > Fast Dials.

3. Click Add New.

4. Use the Search Options area to find the appropriate PAB entry.

5. Click a phone number in the Search Results area.

6. Change the Fast Dial code, if desired.

7. Click Save.

1. Choose User Options > Fast Dials.

2. Click Add New.

3. Change the Fast Dial code, if desired.

4. Enter a phone number.

5. Click Save.

If you want to... Then do this after you log in...

Search for a Fast Dial entry

Edit a Fast Dial phone number

Delete a Fast Dial entry 1. Search for a Fast Dial.

Assign a line button for Fast Dial

1. Choose User Options > Fast Dials.

2. Specify search information and click Find.

1. Choose User Options > Fast Dials.

2. Search for the Fast Dial entry that you want to edit.

3. Click on a component of the entry.

4. Change the phone number.

5. Click Save.

2. Select one or more entries.

3. Click Delete Selected.

Note Before you can assign a line button for Fast Dial, your system

administrator must configure the phone to display services. Contact your system administrator for more information.

1. Choose User Options > Device.

2. Click Service URL.

3. Choose the Fast Dial service from the Button drop-down list box.

4. Enter a phone label for the button.

5. Click Save.

6. Click Reset and then click Restart to refresh the phone configuration.

You can now press the line button to access Fast Dial codes.

Tips

• You can create up to 500 Fast Dial and PAB entries.

• You can create a new Fast Dial entry without using a PAB entry. Such Fast Dial entries are labeled

“raw” in the User Options web pages and do not display a configurable text label.

Using the Address Book Synchronization Tool

You can use the Address Book Synchronization Tool (TABSynch) to synchronize your existing Microsoft Windows Address Book (if applicable) with your PAB. Entries from your Microsoft Windows Address Book will then be accessible on your Cisco Unified IP Phone and User pages. Your system administrator can give you access to TABSynch and provide detailed instructions.

64 OL-19613-01

Options web

Using the User Options Web Pages

Setting Up Speed Dials on the Web

Depending on configuration, your phone can support several speed-dial features:

• Speed-dial buttons

• Abbreviated Dialing

• Fast Dials

Note For help using speed-dial features, see Speed Dialing, page 34.

If you want to... Then do this after you log in...

Set up speed-dial buttons

Set up Abbreviated Dialing

Set up Fast Dials See Configuring Fast Dials on the Web, page 63.

1. Choose User Options > Device.

2. Choose a phone from the Name drop-down menu.

3. Click Speed Dials.

4. Enter a number and label for a speed-dial button (programmable button)

on your phone.

5. Click Save.

Note Your phone uses the ASCII Label field.

1. Choose User Options > Device.

2. Choose a phone from the Name drop-down menu.

3. Click Speed Dials.

4. Enter a number and label for an Abbreviated Dialing code.

5. Click Save.

You can also set up Fast Dials on your phone. See Using Personal Directory on

Your Phone, page 57.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Setting Up Phone Services on the Web

Phone services can include special phone features, network data, and web-based information (such as stock quotes and movie listings). You must first subscribe to a phone service before accessing it on your phone.

If you want to... Then do this after you log in...

Subscribe to a service 1. Choose User Options > Device.

2. Choose a phone from the Name drop-down menu.

3. Click Phone Services.

4. Click Add New.

5. Choose a service from the drop-down list and click Next.

6. Change the service label and/or enter additional service information, if

available (optional).

7. Click Save.

Search for services 1. Select a device.

2. Click Phone Services.

3. Click Find.

Change or end services 1. Search for services.

2. Select one or more entries.

3. Click Delete Selected.

Change a service name 1. Search for services.

2. Click on the service name.

3. Change the information and click Save.

66 OL-19613-01

If you want to... Then do this after you log in...

Add a service to an available programmable phone button

Access a service on your phone

1. Choose User Options > Device.

2. Choose a phone from the Name drop-down menu.

3. Click Service URL.

Note If you do not see this option, ask your system administrator to

configure a service URL button for your phone.

4. Choose a service from the Button Service drop-down list.

5. If you want to rename the service, edit the label fields.

Note Your phone uses the ASCII Label field if the phone does not support

double-byte character sets.

6. Click Save.

7. Click Reset to reset your phone (necessary to see the new button label

on your phone).

Choose ( ) > Services.

Using the User Options Web Pages

Controlling User Settings on the Web

User settings include your password, PIN, and language (locale) settings.

If you want to... Then do this after you log in...

Change your password 1. Choose User Options > User Settings.

2. In the Browser Password area, enter information.

3. Click Save.

Change your PIN 1. Choose User Options > User Settings.

2. In the Phone PIN area, enter information.

3. Click Save.

Change the language (locale) for your User

Change the language (locale) for your phone screen

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Options web pages

1. Choose User Options > User Settings.

2. In the User Locale area, choose an item from the Locale

drop-down list.

3. Click Save.

1. Choose User Options > User Settings.

2. Choose an item from the User Locale drop-down list.

3. Click Save.

Tip

Your PIN and password allow you to access different features and services. For example, use your PIN to log in to Cisco Extension Mobility or Personal Directory on your phone. Use your password to log in to your User Options web pages and Cisco WebDialer on your personal computer. For more information, ask your system administrator.

Controlling Line Settings on the Web

Line settings affect a specific phone line (directory number) on your phone. Line settings can include call-forwarding, voice message indicators, ring patterns, and line labels.

You can set up other line settings directly on your phone:

• Set up call forwarding for your primary phone line—see Forwarding Calls to Another Number,

page 26.

• Change rings, display, and other phone-model specific settings—see Changing Phone Settings,

page 52.

If you want to... Then do this after you log in...

Set up call forwarding per line

Change the voice message indicator (lamp) setting per line

1. Choose User Options > Device.

2. Choose a phone from the Name drop-down menu.

3. Click Line Settings.

4. If you have more than one directory number (line) assigned to your

phone, choose a line from the Line drop-down menu.

5. In the Incoming Call Forwarding area, choose call forwarding settings for various conditions.

6. Click Save.

1. Choose User Options > Device.

2. Choose a phone from the Name drop-down menu.

3. Click Line Settings.

4. If you have more than one directory number (line) assigned to your

phone, choose a line from the Line drop-down menu.

5. In the Message Waiting Lamp area, choose from various settings.

Note Typically, the default message waiting setting prompts your phone to

display a steady red light from the handset light strip to indicate a new voice message.

6. Click Save.

68 OL-19613-01

If you want to... Then do this after you log in...

Change the audible voice message indicator setting per line

1. Choose User Options > Device.

2. Choose a phone from the Name drop-down menu.

3. Click Line Settings.

4. If you have more than one directory number (line) assigned to your

phone, choose a line from the Line drop-down menu.

5. In the Audible Message Waiting Indicator area, choose from various settings.

Note Typically, the default message waiting setting prompts your phone to

display a steady red light from the handset light strip to indicate a new voice message.

6. Click Save.

Change or create a line text label that appears on your phone screen

1. Choose User Options > Device.

2. Choose a phone from the Name drop-down menu.

3. Click Line Settings.

4. If you have more than one directory number (line) assigned to your

phone, choose a line from the Line drop-down menu.

5. In the Line Text Label area, enter a text label.

6. Click Save.

Note Your phone uses the ASCII Label field if the phone does not support

double-byte character sets.

Using the User Options Web Pages

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Setting Up Phones and Access Lists for Mobile Connect

When using Cisco Mobile Connect, you must add your mobile phone and other phones that you want to use to make and receive calls using the same directory numbers as your desk phone. These phones are called remote destinations. You can also define access lists to restrict or allow calls from certain numbers to be sent to your mobile phone.

If you want to... Then do this after you log in...

Create an access list 1. Choose User Options > Mobility Settings > Access Lists.

2. Click Add New.

3. Enter a name to identify the access list and a description (optional).

4. Choose whether the access list will allow or block specified calls.

5. Click Save.

6. Click Add Member to add phone numbers or filters to the list.

7. Select an option from the Filter Mask drop-down list box. You can filter

a directory number, calls with restricted caller ID (Not Available), or calls with anonymous caller ID (Private).

8. If you select a directory number from the Filter Mask drop-down list box, enter a phone number or filter in the DN Mask field. You can use the following wild cards to define a filter:

–

X (upper or lower case)—Matches a single digit. For example, 408555123X matches any number between 4085551230 and

4085551239.

–

!—Matches any number of digits. For example, 408! matches any number starts with 408.

–

#—Used as a single digit for exact match.

9. To add this member to the access list, click Save.

10. To save the access list, click Save.

70 OL-19613-01

If you want to... Then do this after you log in...

Add a new remote destination

1. Choose User Options > Mobility Settings > Remote Destinations.

2. Click Add New.

3. Enter the following information:

–

Name—Enter a name for the mobile (or other) phone.

–

Destination Number—Enter your mobile phone number.

4. Select your remote destination profile from the drop-down list box. Your remote destination profile contains the settings that apply to remote destinations that you create.

5. Select the Mobile Phone check box to allow your remote destination to accept a call sent from your desktop phone.

6. Select the Enable Mobile Connect check box to allow your remote destination to ring simultaneously with your desktop phone.

7. Choose one of the following options in the Ring Schedule area:

–

All the time—Choose this option if you do not want to impose day and time restrictions on ringing the remote destination.

–

As specified below—Choose this option and select from the following items to set up a ring schedule based on day and time:

• Select a check box for each day of the week you want to allow calls to ring the remote destination.

• For each day, select All Day or select the beginning and ending times from the drop-down lists.

• Select the time zone from the drop-down list box.

8. Choose one of the following ringing options:

–

Always ring this destination.

–

Ring this destination only if the caller is in the allowed access list that you select.

–

Do not ring this destination if the caller is in the blocked access list that you select.

Note The ring schedule drop-down list boxes include only the access lists that

you have created.

Using the User Options Web Pages

9. Click Save.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Using Cisco WebDialer

Cisco WebDialer allows you to make calls on your Cisco Unified IP Phone to directory contacts by clicking items in a web browser. Your system administrator must configure this feature for you.

If you want to... Then...

Use WebDialer with your User Options directory

Use WebDialer with another online corporate directory (not your User Options directory)

1. L og in to you r Use r Opti ons w eb pag es. S ee Accessing Your User Options

Web Pages, page 61.

2. Choose User Options > Directory and search for a coworker.

3. Click the number that you want to dial.

4. If this is your first time using WebDialer, set up preferences on the Make

Call page.

5. Click Dial. (See the last row in this table to learn how to suppress this page in the future, if desired.)

The call is now placed on your phone.

6. To end a call, click Hangup or hang up from your phone.

1. Log in to a WebDialer-enabled corporate directory and search for

coworkers.

2. Click the number that you want to dial.

3. When prompted, enter your user ID and password.

4. If this is your first time using WebDialer, set up preferences on the Make

Call page.

5. Click Dial. (See the last row in this table to learn how to suppress this page in the future, if desired.)

The call is now placed on your phone.

6. To end a call, click Hangup or hang up from your phone.

72 OL-19613-01

Using the User Options Web Pages

If you want to... Then...

Log out of WebDialer Click the logout icon in the Make Call or Hang Up page.

Set up, view, or change WebDialer preferences

Access the Make Call page.

The Make Call page appears the first time that you use WebDialer (after you click the number that you want to dial.)

The Make Call page contains the following options:

• Preferred language—Determines the language used for WebDialer

settings and prompts.

• Use preferred device—Identifies the Cisco Unified IP Phone (Calling

device) and directory number (Calling line) that you will use to place WebDialer calls. If you have one phone with a single line, the appropriate phone and line are automatically selected. Otherwise, choose a phone and/or line. If you have more than one phone, it will be specified by device type and MAC address. (To display the MAC address on your phone, choose

> Network Configuration > MAC Address.)

Note If you have an Extension Mobility profile, you can select your Extension

Mobility logged-in device from the Calling device menu.

• Do not display call confirmation—If selected, prompts WebDialer to

suppress the Make Call page. This page appears by default after you click a phone number in a WebDialer-enabled online directory.

• Disable Auto Close—If selected, the call window does not close

automatically after fifteen seconds.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Understanding Additional Configuration Options

Your system administrator can configure your phone to use specific button and softkey templates along with special services and features, if appropriate. This table provides an overview of some configuration options that you might want to discuss with your phone system administrator based on your calling needs or work environment.

Note You can locate Phone Guides and other documents listed in this table on the web:

http://www.cisco.com/en/US/products/hw/phones/ps379/tsd_products_support_series_home. html

If you... Then... For more information...

Need to handle more calls on your phone line

Need more than one phone line

Need more speed-dial buttons

Ask your system administrator to configure your line to support more calls.

Ask your system administrator to configure one or more additional directory numbers for you.

First make sure that you are using all of your currently available speed-dial buttons.

If you need additional speed-dial buttons, try using Abbreviated Dialing or subscribing to the Fast Dial service.

Another option is to attach a

Unified IP Phone Expansion

Cisco Module to your Cisco Unified IP Phone 7962G.

Talk to your system administrator or phone support team.

See:

• Speed Dialing, page 34

• Cisco Unified IP Phone

Expansion Module 7914 Phone Guide.

• Cisco Unified IP Phone Expansion Module 7915 Phone Guide.

• Cisco Unified IP Phone Expansion Module 7916 Phone Guide.

Note The Cisco Unified IP Phone

7942G does not support the Cisco Unified IP Phone Expansion Module.

74 OL-19613-01

Understanding Additional Configuration Options

If you... Then... For more information...

Work with (or work as) an administrative assistant

Want to use one extension for several phones

Share phones or office space with coworkers

Answer calls frequently or handle calls on someone’s behalf

Need to make video calls (SCCP phones only)

Determine the state of a phone line associated with a speed-dial button, call log, or directory listing on your phone

Want to temporarily apply your phone number and settings to a shared

Unified IP Phone

Cisco

Consider using:

• Cisco Unified Communications Manager Assistant

• A shared line

Request a shared line. This allows you to use one extension for your desk phone and lab phone, for example.

Consider using:

• Call Park to store and retrieve calls without using the transfer feature

• Call Pickup to answer calls ringing on another phone

• A shared line to view or join coworkers’ calls

• Cisco Extension Mobility to apply your phone number and user profile to a shared

Unified IP Phone

Cisco

Ask your system administrator to set up the AutoAnswer feature for your phone.

Consider using Cisco Unified Video Advantage, which enables you to make video calls using your Cisco Unified

Phone, your personal computer,

IP and an external video camera.

Ask your administrator to set up the Busy Lamp Field (BLF) feature for your phone.

Ask your system administrator about the Cisco Extension Mobility Service.

See:

• Using a Shared Line, page 38

• Cisco Unified

Communications Manager Assistant User Guide

See Using a Shared Line, page 38.

Ask your system administrator about these features and see:

• Advanced Call Handling,

page 34

• Using a Shared Line, page 38

• Using Cisco Extension

Mobility, page 46

See Using AutoAnswer with a

Headset or Speakerphone, page 51.

Contact your system administrator for additional assistance and see the Cisco

Unified Video Advantage Quick Start Guide and User Guide.

See Using BLF to Determine a Line

State, page 42.

See Using Cisco Extension

Mobility, page 46.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Troubleshooting Your Phone

This section provides troubleshooting information for your Cisco Unified IP Phone.

General Troubleshooting

This section provides information to help you troubleshoot general problems with your phone. For more information, see your system administrator.

Symptom Explanation

You cannot hear a dial tone or complete a call

The Settings button is unresponsive

The softkey that you want to use does not appear

Barge fails and results in a fast busy tone

You are disconnected from a call that you joined using Barge

CallBack fails The other party might have call forwarding enabled.

The phone shows an error message when you attempt to set up Call Forward All

One or more of the following factors might apply:

• You must log into the Extension Mobility service.

• You must enter a client matter code (CMC) or forced authorization

code (FAC) after dialing a number. (SCCP phones only)

• Your phone has time-of-day restrictions that prevent you from using some features during certain hours of the day.

Your system administrator might have disabled on your phone.

One or more of the following factors might apply:

• You must press more to reveal additional softkeys.

• You must change the line state (for example, go off-hook or have a

connected call).

• Your phone is not configured to support the feature associated with that softkey.

You cannot barge an encrypted call if the phone you are using is not configured for encryption. When your barge attempt fails for this reason, your phone plays a fast busy tone.

You will be disconnected from a call that you have joined using Barge if the call is put on hold, transferred, or turned into a conference call.

Your phone may reject your attempt to set up Call Forward All directly on the phone if the target number that you enter would create a Call Forward All loop or would exceed the maximum number of links permitted in a Call Forward All chain (also known as maximum hop count). Ask your system administrator for details.

76 OL-19613-01

Troubleshooting Your Phone

Viewing Phone Administration Data

Your system administrator might ask you to access administration data on your phone for troubleshooting purposes.

If you are asked to... Then...

Access network configuration data

Access status data Choose > Status and select the status item that you want to view.

Access phone model information

Access phone call and voice quality information

Choose > Network Configuration and select the network configuration item that you want to view.

Choose > Model Information.

Choose > Status > Call Statistics.

Using the Quality Reporting Tool

Your system administrator may temporarily configure your phone with the Quality Reporting Tool (QRT) to troubleshoot performance problems. You can press QRT or Quality Reporting Tool to submit information to your system administrator. Depending on configuration, use the QRT to:

• Immediately report an audio problem on a current call.

• Select a general problem from a list of categories and choose reason codes.

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

Cisco One-Year Limited Hardware Warranty Terms

There are special terms applicable to your hardware warranty and various services that you can use during the warranty period. Your formal Warranty Statement, including the warranties and license agreements applicable to Cisco software, is available on Cisco.com at the following URL:

http://www.cisco.com/en/US/docs/general/warranty/English/1Y1DEN__.html

78 OL-19613-01

Index

Abbreviated Dialing 65 Abbreviated Dialing (Off-hook) 35 Address Book Synchronization Tool 64 answering calls, options for 20 ASCII label field support 65 audible message waiting indicator 60 audio problems 77 audio, quality of 6 authenticated calls 43 Auto Dial 16 AutoAnswer 51

barge

and privacy 41 and shared lines 38

using 39 BLF 42 BLF Pickup 42 Busy Lamp Field

see BLF 42 button 33

call activity area, viewing 12 call forwarding 26

configuring from web page 68

call logs

dialing from a URL entry in 55 erasing 54

viewing and dialing from 54 call park 37 call pickup, using 35 call waiting 20 caller ID 12 call-handling, advanced 34 call-handling, basic 16 calls

answering 20

barging 39

blocking 27

compared to lines 10

conference features for 29

ending 21

forwarding 26, 68

handling multiple 23

holding and resuming 22

icons for 11

maximum per line 10

multiple parties on 29

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

multiple, switching between 23 muting 23 parking 37 placing 16 prioritizing 44 redirecting while ringing 35 reporting problems with 77 secure 43 storing and retrieving 37 transferring 25 using DND 27 viewing 12, 23 viewing multiple 24

Cisco Unified Communications Manager

Address Book Synchronizer

Cisco Unified IP Phone

adjusting height of 5 connecting 4 description of 7 feature configuration for 14, 74 illustration of 7 online help for 13 registering 5 securing handset rest 5 web-based services for 61

Cisco Unified IP Phone Expansion Module

7914

53, 74

Cisco Unified IP Phone Expansion Module

7915

Cisco Unified Video Advantage 75 Cisco WebDialer 72 Client Matter Code 18 CMC 18 conference calls

Meet-Me 31 types of 29

configuration

options 74

corporate directory

dialing from web page with 17 using from web page 72 using on phone 17

customization

messages 60

Details softkey, viewing multiparty calls with

55, 56

device configuration page 61 dialing, options for 16 direct transfer 25 directed call park 37 directory

corporate 56 dialing from web page with 17 personal 56 using from web page 72

using on phone 17, 54 divert calls to voice message system 26, 60 DND 27 Do Not Disturb 27

encrypted calls 43 ending a call, options for 21 Extension Mobility

80 OL-19613-01

extension numbers, viewing 12

FAC 18 Fast Dial service

dialing with 18

Fast Dials

configuring from web page 63

feature buttons

help 9 messages 9 services 10

settings 10 feature menus, using 14 features, availability of 14, 74 footstand

adjusting 5

button, identifying 9 Forced Authorization Code 18 forwarding calls, options for 26

GPickUp 36 group call pickup, using 36

securing in cradle 5

using 49 hanging up, options for 21 headset

answering calls with 20

audio quality 6

button, identifying 10

hanging up with 21

mode 49 headset performance, general 5 help button, description of 9 help, using 13 hold

and switching calls 23

and transferring 25

using 22 hold reversion indicators, reverting calls 22 hunt groups, logging out 38

icons

for call states 11

for lines 11 idle 11 installing, Cisco Unified IP Phone 4 intercom calls 32 intercom line 11, 33 international call logging 17, 56, 59

handset

light strip 10

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

keypad

description of 10

language (locale) settings 67 line buttons, identifying 9 lines

and call forwarding 68 and call states 11 description of 10 icons 11 ring patterns for 68 text label for 68 using BLF 42 viewing 12 voice message indicator setting for 68

logging out of hunt groups 38

Mobile Voice Access 46 multiparty calls

identifying in call logs 55

viewing details of 55, 56 multiple calls, handling 23 mute button, description of 10 mute, using 23

navigation button, description of 10 network configuration data, locating 76

on-hook dialing 16 online help, using 13 OPickUp 36 other call pickup, using 36

Malicious Call Identification (MCID), using 44 Meet-Me conferences 31 menus, using 14 messages

indicator for 52, 60

listening to 60 messages button, description of 9 missed calls, records of 54 MLPP, using 44 Mobile Connect 46 mobile connect

access to remote destinations 47

enabling 71

82 OL-19613-01

PAB 56

using from web page 62 park retrieval prefix 37 password, changing 67 Personal Address Book

See PAB 57 Personal Address Book (PAB)

dialing from 18 Personal Address Book,see PAB Personal Directory

using from web page 62

phone lines

buttons for 9 description of 10 viewing 12

phone screen

adjusting contrast of 53 changing language of 53 cleaning 12 features of 12

phone services

configuring

see also User Options web pages PickUp 35 PIN, changing 67 placed calls, records of 54 placing calls, options for 16 prioritizing calls 44 privacy

and shared lines 38

using 41 programmable buttons

description of 9

labels for 12

QRT 77 QRT, using 77 Quality Reporting Tool 77

received calls, records of 54

redial 16 remote destination 46

ring schedule 71

turn off access 47 Remote-in-Use icon for shared lines 38 resume, using 22 ring patterns, changing 68 ring schedule for remote destinations 71 ringer

customizing 52

indicator for 10

safety, warnings 2 secure calls 43 security

levels of 43

making and receiving secure calls 43

verifying non-secure calls 43 services button, description of 10 services,subscribing to 66 settings button, description of 10 settings, customizing 52 shared lines

and Remote-in-Use icon 38

description of 38

with barge 39

with privacy 41 softkey buttons

description of 10

labels for 12 speakerphone

Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 7.1(2) (SCCP and SIP)

answering calls with 20 button, identifying 10 hanging up with 21 mode 49

speed dial 34

buttons, identifying 9 configuring 65 labels 12, 65

using 17 status data, locating 76 status line, viewing 12 subscriptions, for phone services 66 suspicious calls, tracing 44 switching calls 23, 46

Tabs, phone and feature 12 TABSynch 64 TAPS, using 5 telephony features

audible message waiting indicator 60 text, entering on phone 14 Tool for Auto-Registered Phones Support 5 transferring, options for 25 troubleshooting 76

Cisco Systems CP7962G User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Common Phone Tasks

Softkey Definitions

QUICK REFERENCE

Phone Screen Icons

Button Icons

Contents

Getting Started

Using this Guide

Finding Additional Information

Accessing Cisco Unified IP Phone 7900 Series eLearning Tutorials

Safety and Performance Information

Cisco Product Security Overview

Accessibility Features

Connecting Your Phone

An Overview of Your Phone

Understanding Buttons and Hardware

Understanding Lines and Calls

Understanding Line and Call Icons

Understanding Phone Screen Features

Cleaning the Phone Screen

Understanding Feature Buttons and Menus

Accessing the Help System on Your Phone

Understanding Feature Availability

Understanding SIP vs. SCCP

Basic Call Handling

Answering a Call

Ending a Call

Using Hold and Resume

Using Mute

Switching Between Multiple Calls

Switching an In-Progress Call to Another Phone

Viewing Multiple Calls

Transferring Calls

Sending a Call to a Voice Message System

Forwarding Calls to Another Number

Using Do Not Disturb

Making Conference Calls

Using Conference Features

Using Conference

Using Join

Using cBarge

Using Meet-Me

Viewing or Removing Conference Participants

Placing or Receiving Intercom Calls

Advanced Call Handling

Speed Dialing

Picking Up a Redirected Call on Your Phone

Storing and Retrieving Parked Calls

Logging Out of Hunt Groups

Using a Shared Line

Understanding Shared Lines

Using Barge to Add Yourself to a Shared-Line Call

Understanding Barge Features

Using Barge Features

Preventing Others from Viewing or Barging a Shared-Line Call

Using BLF to Determine a Line State

Making and Receiving Secure Calls

Tracing Suspicious Calls

Prioritizing Critical Calls

Using Cisco Extension Mobility

Managing Business Calls Using a Single Phone Number

Using a Handset, Headset, and Speakerphone

Using a Handset

Using a Headset

Using a Speakerphone

Using AutoAnswer with a Headset or Speakerphone

Changing Phone Settings

Customizing Rings and Message Indicators

Customizing the Phone Screen

Using Call Logs and Directories

Using Call Logs

Directory Dialing

Using Corporate Directory on Your Phone

Using Personal Directory on Your Phone

Accessing Voice Messages

Using the User Options Web Pages
