Cisco Business 250 Series Switches Administration Guide

First Published: 2020-05-07

Last Modified: 2021-07-23

Americas Headquarters

Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 USA http://www.cisco.com Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

Get To Know Your Switch

This chapter contains the following sections:

Introduction

Thank you for purchasing the Cisco CBS Series Switch. The Cisco CBS Series Switches combine powerful network performance and reliability with a complete suite of network features that you need for a solid business network. These expandable Gigabit Ethernet switches, with Gigabit or 10-Gigabit uplinks, provide multiple management options, rich security capabilities, and Layer-3 static routing features far beyond those of an unmanaged or consumer-grade switch, at a lower cost than fully managed switches.

CHAPTER 1

• Introduction, on page 1

• Rack Mounting Switch, on page 2

• Wall Mounting a Switch, on page 3

• Power over Ethernet Considerations, on page 5

• Front Panel, on page 7

• Configuring Switches, on page 9

• Restoring Factory Default Settings, on page 11

• Navigation, on page 11

Before You Begin

Before you begin installing your device, ensure that the following items are available:

• RJ-45 Ethernet cables for connecting network devices. A category 6a and higher cable is required for 10G ports; a category 5e and higher cable is required for all other ports.

• Tools for installing the hardware.

• The rack-mount kit packed with the switch contains four rubber feet for desktop placement, and two brackets and twelve screws for rackmounting.

• If the supplied screws are lost, use replacement screws in the following size:

• Diameter of the screw head: 6.9 mm

• Length of face of screw head to base of screw: 5.9 mm

• Shaft diameter: 3.94 mm

Cisco Business 250 Series Switches Administration Guide

Rack Mounting Switch

Get To Know Your Switch

Warning

To prevent airflow restriction, allow clearance around the ventilation openings to be at least 3 inches (7.6 cm).

For CBS250-24T-4G, when rack-mounted, allow clearance above the switch to be at least: 1RU (1.75 inch/4.45cm)

• A computer to manage the device either via the console port or via the web-based interface. for web based interface the computer needs to support one of the following browsers:

• Microsoft Edge

• Firefox (version 82 or 81 or higher)

• Chrome (version 86 or 85 or higher)

• Safari over MAC (version 14.0 and higher)

Warning

Suitable for installation in information Technology Rooms in accordance with Article 645 of the national Electric Code and NFPA 75.

Rack Mounting Switch

You can mount the switches on any standard size, 19-inch (about 48 cm) wide rack. The switch requires 1 rack unit (RU) of space, which is 1.75 inches (44.45 mm) high.

Caution

For stability, load the rack from the bottom to the top, with the heaviest devices on the bottom. A top-heavy rack is likely to be unstable and might tip over.

To install the switch into a 19-inch standard chassis:

Step 1 Place one of the supplied brackets on the side of the switch so that the four holes of the brackets align to the screw holes,

and then use the four supplied screws to secure it.

Step 2 Repeat the previous step to attach the other bracket to the opposite side of the switch.

Step 3 After the brackets are securely attached, the switch is now ready to be installed into a standard 19-inch rack.

Note

Use supplied brackets to rack mount the switch.

Supplied rack mounting for switch models with front mounting position. The mounting ears do not sit flush to the front panel.

Cisco Business 250 Series Switches Administration Guide

Get To Know Your Switch

Wall Mounting a Switch

Supplied rack mounting for switch models with front mounting position. The mounting ears sit flush to the front panel.

Wall Mounting a Switch

You can mount the switches on a wall, using wall studs or to a firmly attached plywood mounting backboard.

Caution

Step 1 Attach a 19-inch bracket to one side of the switch.

Step 2 Repeat the previous step to attach the other bracket to the opposite side of the switch.

Read these instructions carefully before beginning installation. Failure to use the correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system.

Do not wall-mount the switch with its front panel facing up. Following safety regulations, wallmount the switch with its front panel facing down or to the side to prevent airflow restriction and to provide easier access to the cables.

To wall-mount a 24-port switch using brackets:

Cisco Business 250 Series Switches Administration Guide

Get To Know Your Switch

Wall Mount an 8 Port Switch

Step 3 After the brackets are securely attached, mount the switch with the front panel facing down. Make sure that the switch

is attached securely to wall studs or to a firmly attached plywood-mounting backboard. Wall-mounting a 24-port switch.

Wall-mounting a 24-port

Wall Mount an 8 Port Switch

To wall-mount a 8-port switch using mounting screws, follow these steps:

Step 1 Locate the screw template. The template is used to align the mounting screw holes.

Step 2 Position the screw template so that the edge that is marked as CABLE SIDE ENTRY faces toward the floor. Make sure

that the switch is attached securely to wall studs or to a firmly attached plywoodmounting backboard.

Step 3 Peel the adhesive strip off the bottom of the screw template.

Step 4 Attach the screw template to the wall.

Step 5 Use a 0.144-inch (3.7 mm) or a #27 drill bit to drill a 1/2-inch (12.7 mm) hole in the two screw template slots.

Step 6 Insert two screws in the slots on the screw template, and tighten them until they touch the top of the screw template.

Installing the mounting screws on the wall

Figure 3 Installing the mounting screws on the wall

Cisco Business 250 Series Switches Administration Guide

Get To Know Your Switch

Power over Ethernet Considerations

Step 7 Remove the screw template from the wall.

Step 8 Place the switch onto the mounting screws, and slide it down until it locks in place.Wall-mounting an 8-port switch

Figure 4 Wall-mounting an 8-port switch

Power over Ethernet Considerations

Some switches support PoE while others do not. The switch models that support PoE have a P in their model number, such as: CBSxxx-xxP-xx. If your switch is one of the Power over Ethernet (PoE) models, consider the following power requirement.

Cisco Business 250 Series Switches Administration Guide

Power over Ethernet Considerations

Get To Know Your Switch

Warning

The switch is to be connected only to PoE networks without routing to the outside plant.

Table 1: Switches with Power Over Ethernet

PoE PSE SupportPoE PD Chipset TypeDescriptionSKU Name

CBS250-8PP-D

AF/AT1*69208M8-Port Gigabit PoE Smart

Switch

CBS250-8PP-E-2G

AF/ATTPS23888-Port Gigabit PoE Smart

Switch

CBS250-8P-E-2G

AF/ATTPS23888-Port Gigabit PoE Smart

Switch

CBS250-8FP-E-2G

AF/ATTPS23888-Port Gigabit PoE Smart

Switch

CBS250-16P-2G

AF/AT2*TPS238816-Port Gigabit PoE

Smart Switch

CBS250-24PP-4G

AF/AT3*TPS238824-Port Gigabit PoE

Smart Switch

CBS250-24P-4G

AF/AT3*TPS238824-Port Gigabit PoE

Smart Switch

CBS250-24FP-4G

CBS250-48PP-4G

CBS250-48P-4G

CBS250-24P-4X

CBS250-24FP-4X

CBS250-48P-4X

AF/AT3*TPS238824-Port Gigabit PoE

Smart Switch

AF/AT6*TPS238848-Port Gigabit PoE

Smart Switch

AF/AT6*TPS238848-Port Gigabit PoE

Smart Switch

AF/AT3*TPS238824-Port Gigabit PoE Smart Switch with 10G Uplinks

AF/AT6*TPS238848-Port Gigabit PoE Smart Switch with 10G Uplinks

Cisco Business 250 Series Switches Administration Guide

Get To Know Your Switch

Front Panel

Caution

Front Panel

Consider the following when connecting a PoE switch. The PoE switches are PSE (Power Sourcing Equipment) that are capable of supplying DC power to attaching powered devices (PD). These devices include VoIP phones, IP cameras, and wireless access points. The PoE switches can detect and supply power to pre-standard legacy PoE PD. Due to the PoE legacy support, it is possible that a PoE switch acting as a PSE may mistakenly detect and supply power to an attaching PSE, including other PoE switches, as a legacy PD. Even though PoE switches are PSE, and as such should be powered by AC, they could be powered up as a legacy PD by another PSE due to false detection. When this happens, the PoE switch may not operate properly and may not be able to properly supply power to its attaching PDs.

To prevent false detection, you should disable PoE on the ports on the PoE switches that are used to connect to PSEs. You should also first power up a PSE device before connecting it to a PoE switch. When a device is being falsely detected as a PD, you should disconnect the device from the PoE port and power recycle the device with AC power before reconnecting its PoE ports.

The ports, LEDs, and Reset button are located on the front panel of the switch, as well as the following components:

Cisco Business 250 Series Model

Note

Models may differ within the CBS 250 series and this is just a representation of a model within the series.

• Console port with RJ-45 and mini-USB connectors. The console connects a serial cable to a computer serial port so that it can be configured using a terminal emulation program.

Note

Only certain models support this feature.

• USB Port—The USB port connects the switch to a USB device so that you can save and restore the configuration files, firmware images, and SYSLOG files through the connected USB device. The USB port supports the FAT32 file system.

• RJ-45 Ethernet Ports—The RJ-45 Ethernet ports connect network devices, such as computers, printers, and access points, to the switch.

• SFP+ Port (if present)—The small form-factor pluggable plus (SFP+) are connection points for modules so that the switch can link to other switches. These ports are also commonly referred to as mini 10GigaBit Interface Converter ports. The term SFP+ is used in this guide.

Cisco Business 250 Series Switches Administration Guide

Front Panel LEDs

Get To Know Your Switch

• The SFP+ ports (if present) are compatible with the following Cisco SFP 1G optical modules MGBSX1, MGBLX1, MGBLH1, MGBT1, as well as other brands.

• The SFP+ ports are compatible with the following Cisco SFP 1G optical modules MGBSX1, MGBLX1, MGBLH1, MGBT1, as well as other brands.

• The Cisco SFP+ Copper Cable modules that are supported in the Cisco switches are: SFP-H10GB-CU1M, SFP-H10GB-CU3M, and SFP-H10GB-CU5M.

• The LEDs of the corresponding RJ-45 port flash green to respond to the SFP interface traffic.

• Small form-factor pluggable (SFP) ports are connection points for modules, so the switch can link to other switches.

• Some SFP interfaces are shared with one other RJ-45 and SFP+ port, called a combo port. When the SFP is active, the adjacent RJ-45 port is disabled.

• Reset button is used to reset or reboot the switch. To reboot the switch, press the Reset button for less than 10 seconds.

• OOB Port (if present)—The Out of Band (OOB) port is a CPU Ethernet port that can be used only as a management interface. Bridging between the OOB port and the in-band Layer 2 interface is not supported. This does not appear on 250 devices.

• Multigigabit Ethernet Ports (if present) —Highlighted in blue, these ports support speeds up to 2.5 Gbps

• 60-Watt PoE Ports (if present) - The 60-Watt PoE port doubles the maximum PoE power delivered on

Front Panel LEDs

The following are the global LEDs found on the devices:

• System—(Green) The LED lights steady when the switch is powered on, and flashes when booting,

The following are per port LEDs:

• LINK/ACT—(Green) Located on the left of each port. The LED lights steady when a link between the

• SFP+ (if present)—(Green) Located on the right of a 10G port. The LED lights steady when a connection

or 5 Gbps on Cat5e cables. The maximum speed supported is printed on the blue shade under the port. Uplink ports on CBS350-8MGP-2X also support Multi-Gigabit speed. In this case, port speed can reach 10Gbps. Most of the cabling deployed worldwide is Cat5e, and previously limited to 1 Gbps at 100 meters. Cisco Multigigabit Ethernet enables speeds up to 2.5 or 5 Gbps on the same infrastructure without replacing a cable.

the port to 60W.

performing self-tests, or acquiring an IP address. If the LED flashes Amber, the switch has detected a hardware or firmware failure, and/or a configuration file error.

corresponding port and another device is detected, and flashes when the port is passing traffic.

is made through the shared port, and flashes when the port is passing traffic.

• Gigabit—(Green) Located on the right of the 1G port. The LED lights steady when another device is connected to the port, is powered on, and a 1000 Mbps link is established between the devices. When the LED is off, the connection speed is under 1000 Mbps or nothing is cabled to the port. (This feature is only available on certain models).

Cisco Business 250 Series Switches Administration Guide

Get To Know Your Switch

• PoE (if present)—(Amber) Located on the right of the port. The LED lights steady when power is being supplied to a device attached to the corresponding port. (This feature is only available on certain models).

Configuring Switches

The switch can be accessed and managed over your IP network using the web-based interface, or by using the switch’s command-line interface through the console port. Using the console port requires advanced user skills and is only supported on certain models.

The following table shows the default settings used when configuring your switch for the first time.

Configuring Switches

Default ValueParameter

ciscoUsername

ciscoPassword

192.168.1.254LAN IP

Configuring Your Switch Using the Web-based Interface

To access the switch with a web-based interface, you must know the IP address that the switch is using. The switch uses the factory default IP address of 192.168.1.254, with a subnet of /24. When the switch is using the factory default IP address, the System LED flashes continuously. When the switch is using a DHCP server-assigned IP address or an administrator has configured a static IP address, the System LED is a steady green (DHCP is enabled by default).

If you are managing the switch through a network connection and the switch IP address is changed, either by a DHCP server or manually, your access to the switch will be lost. You must enter the new IP address that the switch is using into your browser to use the web-based interface. If you are managing the switch through a console port connection, the link is retained.

To configure the switch using the web-based interface:

Step 1 Power on the computer and your switch.

Step 2 Connect the computer to any network port.

Step 3 Set up the IP configuration on your computer.

a) If the switch is using the default static IP address of 192.168.1.254/24, you must choose an IP address for the computer

in the range of 192.168.1.2 to 192.168.1.253 that is not already in use.

b) If the IP addresses will be assigned by DHCP, make sure that your DHCP server is running and can be reached from

the switch and the computer. You may need to disconnect and reconnect the devices for them to discover their new IP addresses from the DHCP server.

Note

Details on how to change the IP address on your computer depend upon the type of architecture and operating system that you are using. Use your computers local Help and Support functionality and search for “IP Addressing.”

Step 4 Open a web browser window.

Cisco Business 250 Series Switches Administration Guide

Get To Know Your Switch

Configuring Your Switch Using the Console Port

Step 5 Enter the switch IP address in the address bar and press Enter. For example, http://192.168.1.254.

Step 6 When the login page appears, choose the language that you prefer to use in the web-based interface and enter the username

and password.

The default username is cisco. The default password is cisco. Usernames and passwords are both case sensitive.

Step 7 Click Log In.

If this is the first time that you have logged on with the default username and password, the Change username and Password page opens. The rules for constructing a new password are displayed on the page.

Step 8 Enter a new username and password and confirm.

Note

Password complexity is enabled by default. The password must comply with the default complexity rules.

Step 9 Click Apply.

Caution

Make sure that any configuration changes made are saved before exiting from the web-based interface by clicking on the Save icon. Exiting before you save your configuration results in all changes being lost.

The Getting Started page opens. You are now ready to configure the switch. Refer to the Administration Guide or see the help pages for further information.

Configuring Your Switch Using the Console Port

To configure the switch using the console port, which is only supported on ceratin models, proceed with the following steps:

Step 1 Connect a computer to the switch console port using a Cisco console cable (purchased separately) or a cable with mini

USB connector.

Step 2 Start a console port utility such as HyperTerminal on the computer.

Step 3 Configure the utility with the following parameters:

• 115200 bits per second

• 8 data bits

• no parity

• 1 stop bit

• no flow control

Step 4 Enter a username and password. The default username is cisco, and the default password is cisco. Usernames and passwords

are both case sensitive.

If this is the first time that you have logged on with the default username and password, the following message appears:

Please change your username AND password from the default settings. Change of credentials

is required for better protection of your network.

Please note that new password must follow password complexity rules

Cisco Business 250 Series Switches Administration Guide

Get To Know Your Switch

Step 5 Set a new administrator username and password.

Restoring Factory Default Settings

Caution

You are now ready to configure the switch. See the CLI Guide for your switch.

Note

Console access also provides additional interfaces for debug access which are not available via the web interface. These debug access interfaces are intended to be used by a Cisco Support Team personnel, in cases where it is required to debug device’s behavior. These interfaces are password protected. The passwords are held by the Cisco support team. The device supports the following debug access interfaces:

Make sure that any configuration changes made are saved before exiting.

If you are not using DHCP on your network, set the IP address type on the switch to Static and change the static IP address and subnet mask to match your network topology. Failure to do so may result in multiple switches using the same factory default IP address of 192.168.1.254.

• U-BOOT access during boot sequence

• Linux Kernel access during boot sequence

• Run time debug modes - allows Cisco support team to view device settings and apply protocol and layer 1 debug commands and settings. The run time debug mode is accessible over telnet and SSH terminals in addition to console.

Restoring Factory Default Settings

To restore the switch to factory default settings, use the Reset button to reboot or reset the switch and do the

following:

• To reboot the switch, press and hold the Reset button for less than ten seconds.

• To restore the switch to its factory default settings:

• Disconnect the switch from the network or disable all DHCP servers on your network.

• With the power on, press and hold the Reset button for more than ten seconds.

Navigation

The navigation menu, located at the top right of each UI page, lists the device’s main features.You can access each feature’s UI pages using a series of cascading menus. To access an individual UI page, click the corresponding feature tab in the navigation menu to display a menu of subcategories. Select a subcategory and repeat this process until you see the desired page, and then select the page to display it in the main window.

Basic or Advanced Display Mode

The product supports many features, and therefore the WEB GUI includes hundreds of configuration and display pages. These pages are divided into the following display modes:

• Basic—Basic subset of configuration options are available. If you are missing some configuration option, select the Advanced mode in the device header.

Cisco Business 250 Series Switches Administration Guide

Basic or Advanced Display Mode

• Advanced—Full set of configuration options are available.

When the user switches from basic to advanced, the browser reloads the page. However, after reload, the user stays on the same page. When the user switches from advanced to basic, the browser reloads the page. If the page exists also on the basic mode, the user stays on the same page. If the page does not exist in the basic mode, the browser will load the first page of the folder which was used by the user. If the folder does not exist, the Getting Started page will be displayed.

If there is advanced configuration, and the page is loaded in basic mode, a page-level message will be displayed to the user (e.g. there are 2 radius server configured but in basic mode only a single server can be displayed, or there is 802.1X port authentication with time range configured but time range is not visible in basic mode). When switching from one mode to another, any configuration which was made on the page (without Apply) is deleted.

Get To Know Your Switch

Cisco Business 250 Series Switches Administration Guide

Getting Started

This chapter contains the following section:

• Getting Started, on page 13

Getting Started

This section will guide you on how to install and manage your device.

Click on Getting Started to access the page where you can use the various links and follow the on-screen

instructions to quickly configure your switch.

Basic or Advanced Display Mode

The switch's WEB GUI includes hundreds of configuration and display pages. These pages are divided into the following display modes:

• Basic—Basic subset of configuration options.

• Advanced—Full set of configuration options are available

CHAPTER 2

When switching from one mode to another, any configuration which was made on the page (without Apply) is deleted.

Initial Setup

TCP/UDP Services, on page 205Change Management Applications

and Services

IPv4 Interface, on page 161Change Device IP Address

VLAN Settings, on page 123Create VLAN

Port Settings, on page 103Configure Port Settings

Device Status

System Summary, on page 29System Summary

Interface, on page 32Port Statistics

Cisco Business 250 Series Switches Administration Guide

Getting Started

Statistics, on page 43RMON Statistics

RAM Memory, on page 47View Log

Quick Access

User Accounts, on page 50Change Device Password

Firmware Operations, on page 61Upgrade Device Software

File Operations, on page 64Backup Device Configuration

MAC-Based ACL, on page 223Create MAC-Based ACL

IPv4-based ACL, on page 225Create IP-Based ACL

QoS Properties, on page 235Configure QoS

SPAN , on page 38Configure SPAN

There are two hot links on the Getting Started page that take you to Cisco web pages for more information. Clicking on the Support link takes you to the device product support page, and clicking on the Forums link takes you to the Support Community page.

Cisco Business 250 Series Switches Administration Guide

Dashboard

CHAPTER 3

Dashboard

This chapter contains the following section:

• Dashboard, on page 15

The dashboard is a collection of 8 squares, initially empty, that can be populated by various types of information. You can select a number of modules from the available modules and place them in this grid. You can also customize settings of the currently-displayed modules.When the dashboard loads, the modules you selected for the dashboard are loaded in their locations in the grid. The data in the modules is updated, in intervals depending on the module type.

When you open the dashboard, a wire frame view of the grid is displayed. To display modules that aren’t

currently being displayed, click Customize. Add modules by selecting a module from the list of modules on

the right and dragging and dropping it to any space in the grid.

The modules are divided into the following groups:

• Small Modules are modules that take up a single square.

• Large Modules take up two squares.

If you drag a module into a space currently occupied, the new module replaces the previous one. You can rearrange the placement of the modules in the grid by dragging a module from one occupied grid position to

another position. Only when you click Done are the modules populated by the relevant information. The title

bar of each module in the dashboard displays the title of the module and three buttons.

• Pencil — Opens configuration options (depending on the module).

• Refresh — Refreshes the information.

• X — Removes the module from the dashboard.

Cisco Business 250 Series Switches Administration Guide

Dashboard

Table 2: Small Modules

System Health

Resource Utilization

The System Health displays information about device health.

• Fan Status

• Yellow— A fan has failed and is backed up by a redundant fan.

• Green—Fan is operational.

• Red—Fan is faulty.

• Thermometer Status

• Green —Temperature is OK.

• Yellow—Temperature generates a warning.

• Red—Temperature is critical.

This module displays the utilization status in terms of a percentage of the various system resources as a bar chart

The resources monitored are:

• Multicast Groups—Percentage of Multicast groups that exist out of the maximum possible number that are permitted to be defined.

• MAC Address Table—Percentage of MAC Address table in use.

Identification

• TCAM—Percentage of TCAM used by QoS and ACL entries.

• CPU—Percentage of CPU being used.

This module displays basic information regarding the device. It displays the following fields:

• System Description—Displays description of the device.

• Host Name—Entered in the System Settings, on page 49 or default is used.

• Firmware Version—Current firmware version running on device.

• MAC Address—MAC address of the device.

• Serial Number—Serial number of the device.

• System Location (if configured)—Enter the physical location of the device.

• System Contact (if configured)—Enter the name of a contact person.

• Total Available Power (for PoE devices only)—Amount of power available to the device.

• Current Power Consumption (for PoE devices only)—Amount of power consumed by the device.

Cisco Business 250 Series Switches Administration Guide

Dashboard

PoE Utilization

Table 3: Large Modules

Latest Logs

This module displays a graphic representation of the PoE utilization status. For a standalone unit, this module displays a gauge with a dial of values from 0-100. The section of the dial from the traps threshold to 100 is red. In the middle of the gauge, the actual PoE utilization value is shown in watts.

Each bar represents the PoE utilization percentage value of the device on a scale of 0 to 100. If the PoE utilization is higher than the traps threshold, the bar is red. Otherwise the bar is green. When hovering on a bar, a tooltip appears showing the actual PoE utilization of the device in watts. Additional views can be selected in the configuration options (pencil icon in upper-right corner).

• Refresh Time—Select one of the displayed options.

• PoE Global Properties—Link to the Port Management > PoE > Properties page.

• PoE Port Settings—Link to the Port Management > PoE > Settings page.

Note

This section is only relevant for devices supporting PoE.

This module contains information about the five latest events logged by the system as SYSLOGs. The following configuration options (right-hand corner) are available:

• Severity Threshold—Described in Log Settings, on page 58.

• Refresh Time—Select one of the options displayed.

• View logs—Click to open RAM Memory, on page 47 .

Cisco Business 250 Series Switches Administration Guide

Dashboard

Suspended Interfaces

Port Utilization

This module displays interfaces that have been suspended in either device or table view. The view is selected in the configuration options

- Display Option (pencil icon in upper-right corner).

• Device View—In this view, the device is displayed. When units are connected in a stack, a drop-down selector enables the user to select the device to be viewed. All suspended ports in the device are shown as red.

• Table View—In this view, there is no need to select a specific stack unit. Information is displayed in table form as follows:

• Interface—Port or LAG that was suspended

• Suspension Reason—Reason interface was suspended

• Auto-recovery current status—Has auto recovery been enable for the feature that caused the suspension.

The following configuration options (right-hand corner) are available:

• Refresh Time—Select one of the options displayed

• Error Recovery Settings—Click to open Error Recovery Settings,

on page 106.

This section displays the port utilization on the device. The view is selected in the configuration options (pencil icon in upper-right corner).

• Display Mode—Device View - Displays the device Hovering over a port displays information about it.

• Display Mode—Chart View - A list of ports and how they are being used is displayed. For each port, the following port utilization information can be viewed.

• Tx—% (red)

• Rx—% (blue)

• Refresh Time—Select one of the displayed options.

• Interface Statistics—Link to the Status and Statistics> Interface.

Cisco Business 250 Series Switches Administration Guide

Dashboard

Traffic Errors

This modules displays the number of error packets of various types that are counted on the RMON statistics. The view is selected in the configuration options (pencil icon in upper-right corner).

• Display Mode - Device View

The device module mode displays a diagram of the device. All suspended ports in the device are shown as red.

Hovering over a suspended port displays a tooltip with the following information:

• Port name.

• If the port is a member of a LAG, the LAG identity of the port.

• Details of the last error logged on the port.

• Display Mode - Table View

• Interface—Name of port

• Last Traffic Error—Traffic error that occurred on a port and the last time the error occurred.

• Refresh Time—Select one of the refresh rates.

• Traffic Error Information—Click to link to the Statistics, on page

43.

Cisco Business 250 Series Switches Administration Guide

Dashboard

Cisco Business 250 Series Switches Administration Guide

CHAPTER 4

Configuration Wizards

This chapter contains the following sections:

• Getting Started Wizard, on page 21

• VLAN Configuration Wizard, on page 22

• ACL Configuration Wizard, on page 23

Getting Started Wizard

The Getting Started Wizard will assist you in the initial configuration of the device.

Step 1 In Configuration Wizards > GettingStarted Wizard, click Launch Wizard. Step 2 Click Launch Wizard and Next.

Step 3 Enter the fields in the General Information tab:

• System Location—Enter the physical location of the device.

• System Contact—Enter the name of a contact person.

• Host Name—Select the host name of this device. This is used in the prompt of CLI commands:

• Use Default—The default hostname (System Name) of these switches is: switch 123456, where 123456 represents the last three bytes of the device MAC address in hex format.

• User Defined—Enter the hostname. Use only letters, digits, and hyphens. Host names cannot begin or end with a hyphen. No other symbols, punctuation characters, or blank spaces are permitted (as specified in RFC1033, 1034, 1035).

Step 4 Click Next. Step 5 Enter the fields in the IP Settings tab:

• Interface—Select the IP interface for the system.

• IP Interface Source—Select one of the following options:

• DHCP—Select for the device to receive its IP address from a DHCP server.

• Static—Select to enter the IP address of the device manually.

Cisco Business 250 Series Switches Administration Guide

VLAN Configuration Wizard

• If you selected Static as the IP interface source, enter the following fields:

• IP Address—IP address of the interface.

• Network Mask—IP mask for this address.

• Administrative Default Gateway—Enter the default gateway IP address.

• DNS Server—Enter the IP address of the DNS server.

Step 6 Click Next

Step 7 Enter the fields in the User Account tab:

• Username—Enter a new user name between 0 and 20 characters. UTF-8 characters are not permitted.

• Password—Enter a password (UTF-8 characters are not permitted).

• Confirm Password—Enter the password again.

• Password Strength —Displays the strength of password.

Configuration Wizards

• Keep current username and password—Select to keep current username and password.

Step 8 Click Next

Step 9 Enter the fields in the Time Settings tab:

• Clock Source—Select one of the following:

• Manual Settings—Select to enter the device system time. If this is selected, enter the Date and Time.

• Default SNTP Servers—Select to use the default SNTP servers.

Note

• Manual SNTP Server—Select and enter the IP address of an SNTP server.

Step 10 Click Next to view a summary of configuration that you entered. Step 11 Click Apply to save the configuration data.

The default SNTP servers are defined by name, thus DNS must be configured and operational.

VLAN Configuration Wizard

The VLAN Configuration Wizard will assist you in configuring the VLANs. Each time you run this wizard, you can configure the port memberships in a single VLAN. To use the VLAN Configuration Wizard to configure your VLANs follow these steps:

Step 1 In Configuration Wizards > VLANConfiguration Wizard, click Launch Wizard. Step 2 Click Launch Wizard and Next.

Step 3 Select the ports that are to be configured as trunk port (by clicking with mouse on the required ports in the graphical

display). Ports that are already configured as Trunk ports are pre-selected.

Cisco Business 250 Series Switches Administration Guide

Configuration Wizards

ACL Configuration Wizard

Step 4 Click Next.

Step 5 Enter the fields:

• VLAN ID—Select the VLAN you want to configure. You can select either an existing VLAN or New VLAN.

• New VLAN ID—Enter the VLAN ID of a new VLAN.

• VLAN Name—Optionally, enter VLAN name.

Step 6 Select the trunk ports that are to be configured as untagged members of the VLAN (by clicking with mouse on the

required ports in the graphical display). The trunk ports that are not selected in this step becomes tagged members of the VLAN.

Step 7 Click Next.

Step 8 Select the ports are that to be the access ports of the VLAN. Access ports of a VLAN is untagged member of the VLAN.

(by clicking with mouse on the required ports in the graphical display).

Step 9 Click Next to see the summary of the information that you entered. Step 10 Click Apply.

ACL Configuration Wizard

The ACL Configuration Wizard will assist you when creating a new ACL, or editing an existing ACL. To add or modify an existing ACL, complete the following steps:

Step 1 In Configuration Wizards > ACL Configuration Wizard, click Launch Wizard. Step 2 To create a new ACL, click Next. To edit an existing ACL, choose it from the ACL drop-down list and then click Next.

Step 3 Enter the fields:

• ACL Name—Enter the name of a new ACL.

• ACL Type—Select the type of ACL: IPv4 or MAC.

Step 4 Click Next.

Step 5 Enter the fields:

• Action on match—Select one of the options:

• Permit Traffic—Forward packets that meet the ACL criteria.

• Deny Traffic—Drop packets that meet the ACL criteria.

• Shutdown Interface—Drop packets that meet the ACL criteria, and disable the port from where the packets received.

Step 6 For a MAC-based ACL, enter the fields:

Source MAC Address

Select Any if all source address are acceptable or User defined to enter a source address or range of source addresses.

Cisco Business 250 Series Switches Administration Guide

ACL Configuration Wizard

Configuration Wizards

Source MAC Value

Enter the MAC address to which the source MAC address is to be matched and its mask (if relevant).

Enter the mask to define a range of MAC addresses.Source MAC Wildcard

Mask

Destination MAC Address

Select Any if all destination addresses are acceptable or User defined to enter a destination address or a range of destination addresses.

Destination MAC Value

Enter the MAC address to which the destination MAC address is to be matched and its mask (if relevant).

Destination MAC Wildcard Mask

Enter the mask to define a range of MAC addresses. Note that this mask is different than in other uses, such as subnet mask. Here, setting a bit as 1 indicates don't care and 0 indicates to mask that value.

Note

If Time Range is selected, select the time range to be used.Time Range Name

Step 7 For a IPv4-based ACL, enter the fields:

Given a mask of 0000 0000 0000 0000 0000 0000 1111 1111 (which means that you match on the bits where there is 0 and don't match on the bits where there are 1's). You need to translate the 1's to a decimal integer and you write 0 for each four zeros. In this example since 1111 1111 = 255, the mask would be written: as 0.0.0.255.

Protocol

TCP/UDP

Source IP Address

Source IP Wildcard Mask

Select one of the following options to create an ACL based on a specific protocol:

• Any (IP)—Accept all IP protocols packets

• TCP—Accept Transmission Control Protocols packets

• UDP—Accept User Datagram Protocols packets

• ICMP—Accept ICMP Protocols packets

• IGMP—Accept IGMP Protocols packets

Select a port from the drop-down list.Source Port for TCP/UDP

Select a port from the drop-down list.Destination Port for

Select Any if all source address are acceptable or User defined to enter a source address or range of source addresses.

Enter the IP address to which the source IP address is to be matched.Source IP Value

Enter the mask to define a range of IP addresses. Note that this mask is different than in other uses, such as subnet mask. Here, setting a bit as 1 indicates don't care and 0 indicates to mask that value.

Enter the IP address to which the source IP address is to be matched.Destination IP Address

Cisco Business 250 Series Switches Administration Guide

Configuration Wizards

ACL Configuration Wizard

Destination IP Wildcard Mask

If Time Range is selected, select the time range to be used.Time Range Name

Step 8 Click Next.

Step 9 Confirm that you want the ACL and ACE to be created.

The details of the ACL rule are displayed. You can click Add another rule to this ACL to add another rule.

Step 10 Click Next and enter the ACL Binding information:

• Binding Type—Select one of the following options to bind the ACL:

• Physical interfaces only—Bind the ACL to a port. In this case, click a port or ports on which to bind the ACL.

• VLANs only—Bind the ACL to a VLAN. Enter the list of VLANs in the Enter the list of VLANs you want to bind the ACL to field.

• No binding—Do not bind the ACL.

Click Apply.

Cisco Business 250 Series Switches Administration Guide

ACL Configuration Wizard

Configuration Wizards

Cisco Business 250 Series Switches Administration Guide

Search

CHAPTER 5

Search

This chapter contains the following section:

• Search , on page 27

The search function helps the user to locate relevant GUI pages.

The search result for a keyword includes links to the relevant pages, and also links to the relevant help pages.

To access the search function, enter a key word and click on the magnifying glass icon.

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

This chapter contains the following sections:

• System Summary, on page 29

• CPU Utilization, on page 31

• Port Utilization, on page 32

• Interface, on page 32

• Etherlike, on page 33

• GVRP, on page 34

• 802.1X EAP, on page 35

• ACL, on page 36

• Hardware Resource Utilization, on page 36

• Health and Power, on page 37

• SPAN , on page 38

• Diagnostics, on page 40

• RMON, on page 43

• View Log, on page 47

CHAPTER 6

System Summary

The System Summary provides a preview of the device status, hardware, firmware version, general PoE status, and other system information.

To view the system information, click Status and Statistics > System Summary.

System Information

The System Information section provides a quick way to get information about your device. In this section, you will be able to see the following information:

• System Description—A description of the system.

• System Location—Physical location of the device. Click Edit to go System Settings, on page 49 to enter

this value.

• System Contact—Name of a contact person. Click Edit to go System Settings, on page 49 to enter this

value.

Cisco Business 250 Series Switches Administration Guide

Software Information

Status and Statistics

• Host Name—Name of the device. Click Edit to go System Settings, on page 49 to enter this value. By

default, the device host name is composed of the word switch concatenated with the three least significant bytes of the device MAC address (the six furthest right hexadecimal digits).

• System Object ID—Unique vendor identification of the network management subsystem contained in the entity (used in SNMP).

• System Uptime—Time that has elapsed since the last reboot.

Note

For the System Uptime, the time will reset after the switch has been up for 497 days (here the time shown is maximum of 497 days... So, if the switch never reboots, at 497 days, uptime will reset and start over.

• Current Time—Current system time.

• Base MAC Address—Device MAC address.

• Jumbo Frames—Jumbo frame support status. This support can be enabled or disabled by using the Port

Settings, on page 103.

Note

Software Information

The Software Information section provides a quick way get information on the software running on your device. In this section, you will be able to see the following:

• Firmware Version (Active Image)—Firmware version number of the active image.

• Firmware MD5 Checksum (Active Image)—MD5 checksum of the active image.

• Firmware Version (Non-active)—Firmware version number of the non-active image. If the system is in a stack, the version of the active unit is displayed.

• Firmware MD5 Checksum (Non-active)—MD5 checksum of the non-active image.

TCP/UDP Services Status

To reset the following fields, click Edit. The following settings will be displayed.

• HTTP Service—Whether HTTP is enabled/disabled.

• HTTPS Service—Whether HTTPS is enabled/disabled.

Jumbo frames support takes effect only after it is enabled, and after the device is rebooted.

• SNMP Service—Whether SNMP is enabled/disabled.

• Telnet Service—Whether Telnet is enabled/disabled.

• SSH Service—Whether SSH is enabled/disabled.

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

PoE Power Information on Device Supporting PoE

The PoE Power Information on Device Supporting PoE section provides a quick way to get PoE information on your device. In this section, the following will be displayed:

• PoE Power Information—Click on Detail to link you directly to the Properties, on page 111. This page shows the PoE power information.

• Maximum Available PoE Power (W)—Maximum available power that can be delivered by the switch.

• Total PoE Power Consumption (W)—Total PoE power delivered to connected PoE devices.

• PoE Power Mode—Port Limit or Class Limit.

The unit is displayed graphically, and hovering on a port displays its name.

The following information is displayed for each unit:

• Unit 1 (Active)—Device model ID.

• Serial Number—Serial number.

PoE Power Information on Device Supporting PoE

CPU Utilization

The device CPU handles the following types of traffic, in addition to end-user traffic handling the management interface:

• Management traffic

• Protocol traffic

• Snooping traffic

Excessive traffic burdens the CPU, and might prevent normal device operation. The device uses the Secure Core Technology (SCT) to ensure that the device receives and processes management and protocol traffic. SCT is enabled by default on the device and can’t be disabled.

To display CPU utilization, follow these steps:

Step 1 Click Status and Statistics > CPU Utilization.

The CPU Input Rate field displays the rate of input frames to the CPU per second. The window contains a graph displaying CPU utilization on the device. The Y axis is percentage of usage, and the X axis is the sample number.

Step 2 Check Enable to enable the CPU Utilization.

Step 3 Select the Refresh Rate (time period in seconds) that passes before the statistics are refreshed. A new sample is created

for each time period.

The window containing a graph displaying CPU utilization on the device is displayed.

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

Port Utilization

The Port Utilization page displays utilization of broadband (both incoming and outgoing) per port.

To display port utilization, follow these steps:

Step 1 Click Status and Statistics > Port Utilization. Step 2 Enter the Refresh Rate, which is the time period that passes before the interface Ethernet statistics are refreshed.

The following fields are displayed for each port:

• Interface—Name of port.

• Tx Utilization—Amount of bandwidth used by outgoing packets.

• Rx Utilization—Amount of bandwidth used by incoming packets.

To view a graph of historical utilization over time on the port, select a port and click View Interface History Graph. In addition to the above, the following field is displayed:

• Time Span—Select a unit of time. The graph displays the port utilization over this unit of time.

Interface

The Interface page displays traffic statistics per port. This page is useful for analyzing the amount of traffic that is both sent and received, and its dispersion (Unicast, Multicast, and Broadcast).

To display Ethernet statistics and/or set the refresh rate, follow these steps:

Step 1 Click Status and Statistics > Interface.

Step 2 To view statistics counters in table view or graphic view:

• Click Clear Interface Counters, to clear all counters.

• Click Refreshto refresh the counters.

• Click View All Interfaces Statistics to see all ports in table view.

• Click View Interface History Graph to display these results in graphic form. Select the Interface to view the the

statistics pertaining to that interface.

Step 3 Enter the parameters.

• Interface—Select the interface for which Ethernet statistics are to be displayed.

• Refresh Rate—Select the time period that passes before the interface Ethernet statistics are refreshed.

Step 4 In the Receive Statistics section, the following stats are displayed:

• Total Bytes (Octets)—Octets received, including bad packets and FCS octets, but excluding framing bits.

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

• Unicast Packets—Good Unicast packets received.

• Multicast Packets—Good Multicast packets received.

• Broadcast Packets—Good Broadcast packets received.

• Packets with Errors—Packets with errors received.

Step 5 In the Transmit Statistics section, the following stats are displayed:

• Total Bytes (Octets)—Octets transmitted, including bad packets and FCS octets, but excluding framing bits.

• Unicast Packets—Good Unicast packets transmitted.

• Multicast Packets—Good Multicast packets transmitted.

• Broadcast Packets—Good Broadcast packets transmitted.

Etherlike

The Etherlike page displays statistics per port according to the Etherlike MIB standard definition. The refresh rate of the information can be selected. This page provides more detailed information regarding errors in the physical layer (Layer 1) that might disrupt traffic.

To view Etherlike Statistics and/or set the refresh rate follow these steps:

Step 1 Click Status and Statistics > Etherlike. Step 2 Enter the parameters.

• Interface-Select the specific interface for which Ethernet statistics are to be displayed.

• Refresh Rate-Select the amount of time that passes before the Etherlike statistics are refreshed.

The fields are displayed for the selected interface.

• Frame Check Sequence (FCS) Errors - Received frames that failed the CRC (cyclic redundancy checks).

• Single Collision Frames- Frames that involved in a single collision, but successfully transmitted.

• Late Collisions - Collisions that have been detected after the first 512 bits of data.

• Excessive Collisions - Transmissions rejected due to excessive collisions.

• Oversize Packets - Packets greater than 2000 octets received.

• Internal MAC Receive Errors - Frames rejected because of receiver errors.

• Pause Frames Received - Received flow control pause frames. This field is only supported XG ports. When the port speed is 1 G, the received pause frames counter is not operational.

• Pause Frames Transmitted - Number of pause frames transmitted.

Note

If one of the fields listed above shows a number of errors (not 0), a Last Up time is displayed.

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

GVRP

Step 3 To view statistics counters in table view, click View All Interfaces Statistics to see all ports in table view. You can also

click Refresh to refresh the stats or click Clear Interface Counters to clear the counters.

GVRP

The GARP VLAN Registration Protocol (GVRP) page displays the GVRP frames that are sent or received from a port. GVRP is a standards-based Layer 2 network protocol, for automatic configuration of VLAN information on switches. It is defined in the 802.1ak amendment to 802.1Q-2005. GVRP statistics for a port are only displayed if GVRP is enabled globally and on the port.

To view GVRP statistics and/or set the refresh rate, proceed as follows:

Step 1 Click Status and Statistics > GVRP.

Step 2 Enter the parameters.

Select the specific interface for which GVRP statistics are to be displayed.Interface

Refresh Rate

Received - Transmitted

Leave All

GVRP Error Statistics

Select the time period that passes before the GVRP page is refreshed. The Attribute Counter block displays the counters for various types of packets per interface. These are displayed for Received and Transmitted packets.

GVRP Join Empty packets received/transmitted.Join Empty

GVRP empty packets received/transmittedEmpty

GVRP Leave Empty packets received/transmitted.Leave Empty

GVRP Join In packets received/transmitted.Join In

GVRP Leave In packets received/transmitted.Leave In

GVRP Leave All packets received/transmitted. The GVRP Error Statistics section displays the GVRP error counters.

Invalid protocol ID errors.Invalid Protocol ID

Invalid attribute ID errors.Invalid Attribute Type

Invalid attribute value errors.Invalid Attribute Value

Invalid attribute length errors.Invalid Attribute Length

Invalid events.Invalid Event

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

Step 3 To clear statistics counters, click View All Interfaces Statistics to see all ports on a single page.

802.1X EAP

The 802.1x EAP page displays the Extensible Authentication Protocol (EAP) frames that are sent or received. To view the EAP Statistics and/or set the refresh rate, proceed as follows:

Step 1 Click Status and Statistics > 802.1x EAP.

Step 2 Select the Interface that is polled for statistics. Step 3 Select the Refresh Rate (time period) that passes before the EAP statistics are refreshed.

The values are displayed for the selected interface.

Valid EAPOL frames received on the port.EAPOL EAP Frames Received

Valid EAPOL start frames received on the port.EAPOL Start Frames Received

802.1X EAP

EAPOL Announcement Request Frames Received

EAPOL EAP Length Error Frames Received

Last EAPOL Frame Version

Last EAPOL Frame Source

EAPOL Logoff frames received on the port.EAPOL Logoff Frames Received

EAPOL Announcement frames received on the port.EAPOL Announcement Frames Received

EAPOL Announcement Request frames received on the port.

EAPOL invalid frames received on the port.EAPOL Invalid Frames Received

EAPOL frames with an invalid Packet Body Length received on this port.

EAP frames with unrecognized CKN received on this port.MKPDU Frames with unrecognized CKN Received

MKPDU invalid frames received on the port.MKPDU Invalid Frames Received

Protocol version number attached to the most recently received EAPOL frame.

Source MAC address attached to the most recently received EAPOL frame.

EAPOL EAP Supplicant frames transmitted on the port.EAPOL EAP Supplicant Frames Transmitted

EAPOL Start frames transmitted on the port.EAPOL Start Frames Transmitted

EAPOL Logoff frames transmitted on the port.EAPOL Logoff Frames Transmitted

EAPOL Announcement Request Frames Transmitted

EAPOL Announcement frames transmitted on the port.EAPOL Announcement Frames Transmitted

EAPOL Announcement Request frames transmitted on the port.

EAP Authenticator frames transmitted on the port.EAPOL EAP Authenticator Frames Transmitted

Cisco Business 250 Series Switches Administration Guide

ACL

Step 4 To clear statistics counters:

• Click Clear Interface Counters to clear the counters of all interfaces.

• Click Refreshto refresh the counters.

• Click View All Interfaces Statistics to view the counters of all interfaces.

ACL

When the ACL logging feature is enabled, an informational SYSLOG message is generated for packets that match ACL rules. To view the interfaces on which packets are forwarded or rejected based on ACLs, follow these steps:

Status and Statistics

MKA frames with no CKN transmitted on the port.EAPOL MKA Frames with No CKN Transmitted

Step 1 Click Status and Statistics > ACL.

Step 2 Select the Refresh Rate (time period in seconds) that passes before the page is refreshed. A new group of interfaces is

created for each time period.

The following information is displayed:

• Global Trapped Packet Counter—Number of packets trapped globally due to lack of resources.

• Trapped Packets - Port/LAG Based—The interfaces on which packets forwarded or rejected based on ACL rules.

• Trapped Packets - VLAN Based—The VLANs on which packets forwarded or rejected based on ACL rules.

Step 3 To clear statistics counters, click Clear Counters or click Refresh to refresh the counters.

Hardware Resource Utilization

This page displays the resources used by the device, such as Access Control Lists (ACL) and Quality of Service (QoS). Some applications allocate rules upon their initiation. Also, processes that initialize during the system boot use some of their rules during the startup process.

To view the hardware resource utilization, click Status andStatistics > Hardware Resource Utilization.

The following fields are displayed:

• IP Entries

• In Use—Number of TCAM entries used for IP rules.

• Maximum—Number of available TCAM entries that can be used for IP rules.

• ACL and QoS Rules

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

• In Use—Number of TCAM entries used for ACL and QoS rules

• Maximum—Number of available TCAM entries that can be used for ACL and QoS rules.

Health and Power

The Health and Power page monitors the temperature, power supply, and fan status on all relevant devices. The fans on the device vary based on the model.

Environmental Status

• Fan Status—Displays whether the fan is operating normally (OK) or not (Failure).

• Sensor Status—Displays whether the sensor is functional (OK) or not functional (Failure).

• Temperature—Displays one of the following options:

• OK—The temperature is below the warning threshold.

Health and Power

• Warning—The temperature is between the warning threshold to the critical threshold.

• Critical—Temperature is above the critical threshold.

• N/A—Not relevant.

Main Power Status

• Main Power Supply Status— Displays the main power supply status.

Power Savings

• Current Green Ethernet and Port Power Savings—Current amount of the power savings on all the ports.

• Cumulative Green Ethernet and Port Power Savings—Accumulative amount of the power savings on all the ports since the device was powered up.

• Projected Annual Green Ethernet and Port Power Savings—Projection of the amount of the power that will be saved on the device during one week. This value is calculated based on the savings that occurred during the previous week.

• Current PoE Power Savings (available for PoE SKUs only)—Current amount of the PoE power saved on ports that have PDs connected to them and on which PoE is not operational due to the Time Range feature.

• Cumulative PoE Power Savings (available for PoE SKUs only)—Cumulative amount of the PoE power, since the device was powered up, saved on ports which have PDs connected to them and to which PoE is not operational due to the Time Range feature.

• Projected Annual PoE Power Savings (available for PoE SKUs only)—Yearly projected amount of PoE power, since device was powered up, saved on ports that have PDs connected to them and to which PoE is not operational due to the Time Range feature. The projection is based on the savings during the previous week.

Cisco Business 250 Series Switches Administration Guide

SPAN

Health Table

• Unit No.—Displays the unit number in the stack.

• Fan Status— Displays the status of the fan.

• OK—Fan is operating normally.

• Failure—A fan is not operating correctly.

• N/A—Fan is not applicable for the specific model.

• Redundant Fan Status— Displays the redundant status of the fan:

• N/A—Redundant fan is not applicable for the specific model.

• Ready—Redundant fan is operational but not required.

• Active—One of the main fans is not working and this fan is replacing it.

Note

The Redundant Fan Status is only supported on certain SKUs.

Status and Statistics

SPAN

• Sensor Status—The following values are possible:

• OK—Sensor is functional.

• Failure—Sensor has a failure.

• Temperature—The options are:

• OK—The temperature is below the warning threshold.

• Warning—The temperature is between the warning threshold to the critical threshold.

• Critical—Temperature is above the critical threshold.

• N/A—Not relevant.

The SPAN feature, which is sometimes called port mirroring or port monitoring, selects network traffic for analysis by a network analyzer. The network analyzer can be a Cisco Switch Probe device or other Remote Monitoring (RMON) probes.

Port mirroring is used on a network device to send a copy of network packets, seen on a single device port, multiple device ports, or an entire VLAN, to a network monitoring connection on another port on the device. This is commonly used when monitoring of network traffic, such as for an intrusion-detection system, is required. A network analyzer, connected to the monitoring port, processes the data packets. A packet, which is received on a network port and assigned to a VLAN that is subject to mirroring, is mirrored to the analyzer port even if the packet was eventually trapped or discarded. Packets sent by the device are mirrored when Transmit (Tx) mirroring is activated.

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

Mirroring does not guarantee that all traffic from the source port(s) is received on the analyzer (destination) port. If more data is sent to the analyzer port than it can support, some data might be lost.

SPAN Session Destinations

A monitoring session consists of one or more source ports and a single destination ports. A destination port must be configured on the start and final devices. On the start device, this is the reflector port. On the final device, it is the analyzer port.

To add a destination port, follow these steps:

Step 1 Click Status and Statistics >SPAN > SPAN Session Destinations. Step 2 Click Add.

Step 3 Enter the following fields:

• Session ID—Select a session ID. This must match the session IDs of the source ports.

• Port—Select a port from the drop-down list.

SPAN Session Destinations

• Network Traffic—Select to enable that traffic other than monitored traffic is possible on the port.

Step 4 Click Apply.

SPAN Session Sources

In a single local SPAN or RSPAN session source, you can monitor the port traffic, such as received (Rx), transmitted (Tx), or bidirectional (both). The switch supports any number of source ports (up to the maximum number of available ports on the switch) and any number of source VLANs.

To configure the source ports to be mirrored, follow these steps:

Step 1 Click Status and Statistics > SPAN > SPAN Session Sources. Step 2 Click Add.

Step 3 Select the session number from Session ID. This must be the same for all source ports and the destination port. Step 4 In the Monitor Type field, select whether incoming, outgoing, or both types of traffic are mirrored.

• Rx and Tx—Port mirroring on both incoming and outgoing packets

• Rx—Port mirroring on incoming packets

• Tx—Port mirroring on outgoing packets

Step 5 Click Apply. The source interface for the mirroring is configured.

Cisco Business 250 Series Switches Administration Guide

Diagnostics

Copper Test

Status and Statistics

You can use diagnostics to test and verify the functionality of the hardware components of your system (chassis, supervisor engines, modules, and ASICs) while your device is connected to a live network. Diagnostics consists of packet-switching tests that test hardware components and verify the data path and control signals.

The Copper Test page displays the results of integrated cable tests performed on copper cables by the Virtual Cable Tester (VCT).

VCT performs two types of tests:

• Time Domain Reflectometry (TDR) technology tests the quality and characteristics of a copper cable attached to a port. Cables of up to 140 meters long can be tested. These results are displayed in the Test Results block of the Copper Test page.

• DSP-based tests are performed on active XG links to measure cable length. These results are displayed in the Advanced Information block of the Copper Test page. This test can run only when the link speed is 10G.

Preconditions to Running the Copper Test

Before running the test, do the following:

• (Mandatory) Disable Short Reach mode (see Properties, on page 116).

• (Optional) Disable EEE (see Properties, on page 116).

Use a CAT6a data cable when testing cables using (VCT).

The test results have an accuracy within an error range of +/- 10 for advanced Testing and +/-2 for basic testing.

Caution

Step 1 Click Status and Statistics > Diagnostics > Copper Test.

Step 2 Select the unit and port on which to run the test. Step 3 Click Copper Test.

Step 4 When the message appears, click OK to confirm that the link can go down or Cancel to abort the test. The following

fields are displayed in the Test Results block:

When a port is tested, it is set to the Down state and communications are interrupted. After the test, the port returns to the Up state. It is not recommended that you run the copper port test on a port you are using to run the web-based switch configuration utility, because communications with that device are disrupted.

To test copper cables attached to ports:, follow these steps

• Last Update—Time of the last test conducted on the port

• Test Results—Cable test results. Possible values are:

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

• Distance to Fault—Distance from the port to the location on the cable where the fault was discovered.

• Operational Port Status—Displays whether port is up or down.

The Advanced Information block (supported on some of the port types) contains thefollowing information, which is refreshed each time you enter the page:

• Cable Length—Provides an estimate for the length.

• Pair—Cable wire pair being tested.

• Status—Wire pair status. Red indicates fault and Green indicates status OK.

Optical Module Status

• OK—Cable passed the test.

• No Cable—Cable is not connected to the port.

• Open Cable—Cable is connected on only one side.

• Short Cable—Short circuit has occurred in the cable.

• Unknown Test Result—Error has occurred.

• Channel—Cable channel indicating whether the wires are straight or cross-over.

• Polarity—Indicates if automatic polarity detection and correction has been activated for the wire pair.

• Pair Skew—Difference in delay between wire pairs.

Optical Module Status

The Optical Module Status page displays the operating conditions reported by the SFP (Small Form-factor Pluggable) transceiver.

The following GE SFP (1000Mbps) transceivers are supported:

• MGBLH1: 1000BASE-LH SFP transceiver, for single-mode fiber, 1310 nm wavelength, supports up to 40 km.

• MGBLX1: 1000BASE-LX SFP transceiver, for single-mode fiber, 1310 nm wavelength, supports up to 10 km.

• MGBSX1:1000BASE-SX SFP transceiver, for multimode fiber, 850 nm wavelength, supports up to 550 m.

• MGBT1: 1000BASE-T SFP transceiver for category 5 copper wire, supports up to 100 m.

• GLC-SX-MMD - 1000BASE-SX short wavelength; with DOM

• GLC-LH-SMD - 1000BASE-LX/LH long-wavelength; with DOM

• GLC-BX-D - 1000BASE-BX10-D downstream bidirectional single fiber; with DOM

• GLC-BX-U - 1000BASE-BX10-U upstream bidirectional single fiber; with DOM

• GLC-TE - 1000BASE-T standard

Cisco Business 250 Series Switches Administration Guide

Tech-Support Information

Status and Statistics

The following XG SFP+ (10,000Mbps) transceivers are supported:

• Cisco SFP-10G-SR

• Cisco SFP-10G-LR

• Cisco SFP-10G-SR-S

• Cisco SFP-10G-LR-S

The following XG passive cables (Twinax/DAC) are supported:

• Cisco SFP-H10G-CU1M

• Cisco SFP-H10G-CU3M

• Cisco SFP-H10G-CU5M

To view the results of optical tests, click Status and Statistics > Diagnostics > Optical Module Status.

This page displays the following fields:

• Port—Port number on which the SFP is connected

• Description—Description of optical transceiver

• Serial Number—Serial number of optical transceiver

• PID—VLAN ID

• VID—ID of optical transceiver

• Temperature—Temperature (Celsius) at which the SFP is operating

• Voltage—SFPs operating voltage

• Current—SFPs current consumption

• Output Power—Transmitted optical power

• Input Power—Received optical power

• Transmitter Fault—Remote SFP reports signal loss. Values are True, False, and No Signal (N/S)

• Loss of Signal—Local SFP reports signal loss. Values are True and False

• Data Ready—SFP is operational. Values are True and False

Tech-Support Information

This page provides a detailed log of the device status. This is valuable when the technical support are trying to help a user with a problem, since it gives the output of many show commands (including debug command) in a single command.

To view technical support information useful for debugging purposes:

Step 1 Click Status and Statistics > Diagnostics > Tech-Support Information. Step 2 Click Generate.

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

RMON

Note

RMON

Generation of output from this command may take some time. When the information is generated, you can

copy it from the text box in the screen by clicking on Select tech-support data.

Remote Networking Monitoring (RMON) enables an SNMP agent in the device to proactively monitor traffic statistics over a given period and send traps to an SNMP manager. The local SNMP agent compares actual, real-time counters against predefined thresholds and generates alarms, without the need for polling by a central SNMP management platform. This is an effective mechanism for proactive management, provided that you have set the correct thresholds relative to your network’s base line.

RMON decreases the traffic between the manager and the device since the SNMP manager does not have to poll the device frequently for information, and enables the manager to get timely status reports, since the device reports events as they occur.

With this feature, you can perform the following actions:

• View the current statistics (from the time that the counter values cleared). You can also collect the values of these counters over a period of time, and then view the table of collected data, where each collected set is a single line of the History tab.

• Define interesting changes in counter values, such as “reached a certain number of late collisions” (defines the alarm), and then specify what action to perform when this event occurs (log, trap, or log and trap).

Statistics

The Statistics page displays detailed information regarding packet sizes and information regarding physical layer errors. The information is displayed according to the RMON standard. An oversized packet is defined as an Ethernet frame with the following criteria:

• Packet length is greater than MRU byte size.

• Collision event has not been detected.

• Late collision event has not been detected.

• Received (Rx) error event has not been detected.

• Packet has a valid CRC.

To view RMON statistics and/or set the refresh rate, complete the following:

Step 1 Click Status and Statistics > RMON > Statistics.

Step 2 Select the Interface for which Ethernet statistics are to be displayed.

Step 3 Select the Refresh Rate, which is the time period that passes before the interface statistics are refreshed.

The following statistics are displayed for the selected interface.

Cisco Business 250 Series Switches Administration Guide

Statistics

Status and Statistics

Bytes Received

Broadcast Packets Received

Fragments

Jabbers

Octets received, including bad packets and FCS octets, but excluding framing bits.

Packets dropped.Drop Events

Good packets received including Multicast and Broadcast packets.Packets Received

Good Broadcast packets received. This number does not include Multicast packets.

Good Multicast packets received.Multicast Packets Received

CRC and Align errors that have occurred.CRC & Align Errors

Undersized packets (less than 64 octets) received.Undersize Packets

Oversized packets (over 2000 octets) received.Oversize Packets

Fragments (packets with less than 64 octets, excluding framing bits, but including FCS octets) received.

Received packets that are longer than 1632 octets. This number excludes frame bits, but includes FCS octets that had either a bad FCS (Frame Check Sequence) with an integral number of octets (FCS Error) or a bad FCS with a non-integral octet (Alignment Error) number. A Jabber packet is defined as an Ethernet frame that satisfies the following criteria:

Collisions

Frames of 1024 Bytes or More

Note

If one of the fields above shows a number of errors (not 0), a Last Update time is displayed.

Step 4 To view counters in table view or graphic view:

• Click View All Interfaces Statistics to see all ports in table view.

• Click Graphic View to display these results in graphic form. In this view, you can select the Time Span for which

the results will be displayed and the type of statistic to be displayed.

Collisions received. If Jumbo frames are enabled, the threshold of Jabber frames is raised to the maximum size of Jumbo frames.

Frames, containing 64 bytes that were sent or received.Frames of 64 Bytes

Frames, containing 65-127 bytes that were sent or received.Frames of 65 to 127 Bytes

Frames, containing 128-255 bytes that were sent or received.Frames of 128 to 255 Bytes

Frames, containing 256-511 bytes that were sent or received.Frames of 256 to 511 Bytes

Frames, containing 512-1023 bytes that were sent or received.Frames of 512 to 1023 Bytes

Frames, containing 1024-2000 bytes, and Jumbo Frames, that were sent or received.

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

RMON History

The RMON feature enables monitoring statistics per interface.

The History page defines the sampling frequency, amount of samples to store and the port from which to gather the data. After the data is sampled and stored, it appears in the History Table page that can be viewed by clicking History Table.

To enter RMON control information, complete the following:

Step 1 Click Status and Statistics > RMON > History. The fields displayed on this page are defined in the Add RMON

History page, below. The only field is that is on this page and not defined in the Add page is:

• Current Number of Samples-RMON is allowed by the standard not to grant all requested samples, but rather to limit the number of samples per request. Therefore, this field represents the sample number granted to the request that is equal or less than the requested value.

Step 2 Click Add.

Step 3 Enter the parameters.

• New History Entry-Displays the number of the new History table entry.

• Source Interface-Select the type of interface from which the history samples are to be taken.

• Max No. of Samples to Keep-Enter the number of samples to store.

• Sampling Interval-Enter the time in seconds that samples are collected from the ports. The field range is 1-3600.

• Owner-Enter the RMON station or user that requested the RMON information.

Step 4 Click Apply. The entry is added to the History Control Table page, and the Running Configuration file is updated. Step 5 Click History Table to view the actual statistics.

RMON Events

You can control the occurrences that trigger an alarm and the type of notification that occurs. This is performed as follows:

• Events Page—Configures what happens when an alarm is triggered. This can be any combination of logs and traps.

• Alarms Page—Configures the occurrences that trigger an alarm.

To define RMON events, complete the following steps:

Step 1 Click Status and Statistics > RMON > Events. Step 2 Click Add.

Step 3 Enter the parameters.

• Event Entry—Displays the event entry index number for the new entry.

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

Alarms

• Community—Enter the SNMP community string to be included when traps are sent (optional).

• Description—Enter a name for the event. This name is used in the Add RMON Alarm page to attach an alarm to an event.

• Notification Type—Select the type of action that results from this event. Values are:

• None—No action occurs when the alarm goes off.

• Log (Event Log Table)—Add a log entry to the Event Log table when the alarm is triggered.

• Trap (SNMP Manager and Syslog Server)—Send a trap to the remote log server when the alarm goes off.

• Log and Trap—Add a log entry to the Event Log table and send a trap to the remote log server when the alarm goes off.

• Owner—Enter the device or user that defined the event.

Step 4 Click Apply. The RMON event is saved to the Running Configuration file. Step 5 Click EventLog Table to display the log of alarms that have occurred and that have been logged (see description below).

Alarms

RMON alarms provide a mechanism for setting thresholds and sampling intervals to generate exception events on counters or any other SNMP object counter maintained by the agent. Both the rising and falling thresholds must be configured in the alarm. After a rising threshold is crossed, no rising events are generated until the companion falling threshold is crossed. After a falling alarm is issued, the next alarm is issued when a rising threshold is crossed.

One or more alarms are bound to an event, which indicates the action to be taken when the alarm occurs.

Alarm counters can be monitored by either absolute values or changes (delta) in the counter values.

To enter RMON alarms, complete the following steps:

Step 1 Click Status and Statistics > RMON > Alarms.

All previously defined alarms are displayed. The fields are described in the Add RMON Alarm page below. In addition to those fields, the following field appears:

• Counter Value—Displays the value of the statistic during the last sampling period.

Step 2 Click Add.

Step 3 Enter the parameters.

Displays the alarm entry number.Alarm Entry

Select the type of interface for which RMON statistics are displayed.Interface

Select the MIB variable that indicates the type of occurrence measured.Counter Name

Cisco Business 250 Series Switches Administration Guide

Status and Statistics

View Log

Sample Type

Rising Event

Startup Alarm

Select the sampling method to generate an alarm. The options are:

• Absolute—If the threshold is crossed, an alarm is generated.

• Delta—Subtracts the last sampled value from the current value The difference in the values is compared to the threshold. If the threshold was crossed, an alarm is generated.

Enter the value that triggers the rising threshold alarm.Rising Threshold

Select an event to be performed when a rising event is triggered. Events are configured in the RMON Events, on page 45.

Enter the value that triggers the falling threshold alarm.Falling Threshold

Select an event to be performed when a falling event is triggered.Falling Event

Select the first event from which to start generation of alarms. Rising is defined by crossing the threshold from a low-value threshold to a higher-value threshold.

• Rising Alarm—A rising value triggers the rising threshold alarm.

• Falling Alarm—A falling value triggers the falling threshold alarm.

• Rising and Falling—Both rising and falling values trigger the alarm.

Enter the alarm interval time in seconds.Interval

Enter the name of the user or network management system that receives the alarm.Owner

Step 4 Click Apply. The RMON alarm is saved to the Running Configuration file.

View Log

The device can write to the following logs:

• Log in RAM (cleared during reboot).

• Log in Flash memory (cleared only upon user command).

You can configure the messages that are written to each log by severity, and a message can go to more than one log, including logs that reside on external SYSLOG servers.

RAM Memory

The RAM Memory page displays all messages that are saved in the RAM (cache) in chronological order. All entries are stored in the RAM log.

Pop-Up SYSLOG Notifications

Cisco Business 250 Series Switches Administration Guide

Flash Memory

Status and Statistics

When a new SYSLOG message is written to the RAM log file, a notification is displayed on the web GUI showing its contents. The web GUI polls the RAM log every 10 seconds. Syslog notifications pop-ups for all SYSLOGs created in the last 10 seconds appear at the bottom right of the screen.

If more than 7 pop-up notifications are displayed, a summary pop-up is displayed. This pop-up states how many SYSLOG notifications aren’t displayed. It also contains a button that enables closing all of the displayed pop-ups.

To view log entries, click Status and Statistics > ViewLog > RAM Memory.

The following are displayed at the top of the page:

• Alert Icon Blinking—Toggles between disable and enable.

• Pop-Up Syslog Notifications—Enables receiving pop-up SYSLOGs as described above.

• Current Logging Threshold—Specifies the levels of logging that are generated. This can be changed by clicking Edit by the field’s name.

This page contains the following fields for every log file:

• Log Index—Log entry number

Flash Memory

• Log Time—Time when message was generated.

• Severity—Event severity

• Description—Message text describing the event

To clear the log messages, click Clear Logs.

The Flash Memory page displays the messages that stored in the Flash memory, in chronological order. The minimum severity for logging is configured in the Log Settings, on page 58. Flash logs remain when the device is rebooted. You can clear the logs manually.

To view the Flash logs, click Status and Statistics > View Log > Flash Memory.

The Current Logging Threshold specifies the levels of logging that are generated. This can be changed by clicking Edit by the field’s name.

This page contains the following fields for each log file:

• Log Index—Log entry number

• Log Time—Time when message was generated.

• Severity—Event severity

• Description—Message text describing the event

To clear the messages, click Clear Logs. The messages are cleared.

Cisco Business 250 Series Switches Administration Guide

Administration

This chapter contains the following sections:

• System Settings, on page 49

• Console Settings , on page 50

• User Accounts, on page 50

• Idle Session Timeout, on page 51

• Time Settings, on page 52

• System Log, on page 58

• File Management, on page 61

• Cisco Business Dashboard Settings, on page 68

• Plug-n-Play (PNP), on page 70

• Reboot, on page 76

• Discovery Bonjour, on page 77

• Discovery - LLDP, on page 77

• Discovery - CDP, on page 92

• Locate Device, on page 98

• Ping, on page 99

• Traceroute, on page 100

CHAPTER 7

System Settings

The system setting page allows you customize the settings on your switch. You can configure the following:

Step 1 Click Administration > System Settings. Step 2 View or modify the system settings.

• System Description—Displays a description of the device.

• System Location—Enter the physical location of the device.

• System Contact—Enter the name of a contact person.

• Host Name—Select the host name of this device. This is used in the prompt of CLI commands:

• Use Default—The default hostname (System Name) of these switches is: switch123456, where 123456 represents the last three bytes of the device MAC address in hex format.

Cisco Business 250 Series Switches Administration Guide

Console Settings

• Custom Banner Settings—The following banners can be set:

Administration

• User Defined—Enter the hostname. Use only letters, digits, and hyphens. Host names can’t begin or end with a hyphen. No other symbols, punctuation characters, or blank spaces are permitted (as specified in RFC1033, 1034, 1035).

• Login Banner—Enter text to display on the Login page before login. Click Previewto view the results.

• Welcome Banner—Enter text to display on the Login page after login. Click Preview to view the results.

Note

Step 3 Click Apply to save the values in the Running Configuration file.

When you define a login banner from the web-based configuration utility, it also activates the banner for the CLI interfaces (Console, Telnet, and SSH).

The banner can contain up to 1000 characters. After 510 characters, press <Enter> to continue.

Console Settings

The console port speed can be set to one of the following speeds: 4800, 9600, 19200, 38400, 57600, and 115200 or to Auto Detection. If Auto Detection is selected, the device detects console speed automatically. When Auto Detection is not enabled, the console port speed is automatically set to the last speed that was set manually at (115,200 by default). When Auto Detection is enabled but the console baud-rate has not yet been discovered, the system uses speed 115,200 for displaying text (for example, the boot-up information). After Auto Detection is enabled in the Console Settings page, it can be activated by connecting the console to the device and pressing the Enter key twice. The device detects the baud rate automatically.

To enable Auto Detection or to manually set the baud rate of the console, follow these steps:

Step 1 Click Administration > Console Settings.

Step 2 Select one of the following options in the Console Port Baud Rate field:

• Auto Detection—The console baud rate is detected automatically.

• Static—Select one of the available speeds.

Step 3 Click Apply.

User Accounts

The User Accounts page enables entering additional users that are permitted to access to the device (read-only or read-write) or changing the passwords of existing users. A user accessing the device for the first time uses the cisco/cisco username and password. After providing the default credentials, you’re prompted to replace the default level 15 username and password, and you must provide a new username and password. The new password must comply with the password complexity rules.

Cisco Business 250 Series Switches Administration Guide

Administration

To add a new user, follow these steps:

Step 1 Click Administration > User Accounts. Step 2 In the Password Recovery Service, check Enable to enable password recovery. Step 3 Click Add to add a new user or click Edit to modify a user.

Step 4 Enter the parameters.

• User Name—Enter a new username from 0 through 20 characters. UTF-8 characters aren’t permitted.

• Password—Enter a password (UTF-8 characters aren’t permitted).

• Confirm Password—Enter the password again.

• Password Strength Meter—Displays the strength of password.

• User Level—Select the privilege level of the user.

• Read-Only CLI Access (1)—User can’t access the GUI, and can only access CLI commands that don’t change the device configuration.

Idle Session Timeout

• Read/Limited Write CLI Access (7)—User can’t access the GUI, and can only access some CLI commands

that change the device configuration. See the CLI Reference Guide for more information.

• Read/Write Management Access (15)—User can access the GUI, and can configure the device.

Step 5 Click Apply. The user is added to the Running Configuration file of the device.

Note

The password is stored in the configuration files as a non-recoverable hash using PasswordBased Key Derivation Function 2 (PBKDF2) with Secure Hash Algorithm, and SHA-512 as the hashing algorithm.

Idle Session Timeout

The Idle Session Timeout configures the time intervals that the management sessions can remain idle before they timeout.

To set the idle session timeout for various types of sessions, complete these steps:

Step 1 Click Administration > Idle Session Timeout.

Step 2 Select the timeout for the each type of session from the list.

• HTTP Session Timeout

• HTTPS Session Timeout

• Console Session Timeout

• Telnet Session Timeout

• SSH Session Timeout

Cisco Business 250 Series Switches Administration Guide

Time Settings

The default timeout value is 10 minutes. You must log in again to reestablish one of the chosen sessions.

Step 3 Click Apply to set the configuration settings on the device.

Time Settings

Synchronized system clocks provide a frame of reference between all devices on the network. Network time synchronization is critical because every aspect of managing, securing, planning, and debugging a network involves determining when events occur. Without synchronized clocks, accurately correlating log files between devices when tracking security breaches or network usage is impossible. Synchronized time also reduces confusion in shared file systems, as it is important for the modification times to be consistent, regardless of the machine on which the file systems reside. For these reasons, it is important that the time configured on all of the devices on the network is accurate.

Real Time Clock

Some devices have an internal self-sufficient Real Time Clock (RTC) component that keeps time even when the device is shut down and not connected to a power source.This internal clock is initialized during manufacturing and can be updated by the time features of the device when the software clock is set. When a device with a functional RTC component starts up, the system clock is set to the time and date of the RTC. The RTC component is updated whenever the system clock is changed - either dynamically by the Simple Network Time Protocol (SNTP), or manually.

Administration

Note

The device supports SNTP, and when enabled, the device dynamically synchronizes the device time with time from an SNTP server. The device operates only as an SNTP client, and cannot provide time services to other devices.

System Time

Use the System Time page to select the system time source. If the source is manual, you can enter the time here.

Caution

Step 1 Click Administration > Time Settings > System Time.

The following fields are displayed:

• Actual Time— Actual system time on the device.

• Last Synchronized Server—Address, stratum and type of the SNTP server from which system time was last taken.

If the system time is set manually and the device is rebooted, the manual time settings must be reentered.

To define system time, complete these steps:

Cisco Business 250 Series Switches Administration Guide

Administration

Step 2 Enter the following parameters:

• Clock Source Settings—Select the source used to set the system clock.

• Main Clock Source (SNTP Servers)—If this is enabled, the system time is obtained from an SNTP server. To use this feature, you must also configure a connection to an SNTP server in the SNTP Multicast/Anycast, on

page 55.

• Alternate Clock Source (PC via active HTTP/HTTPS sessions)— Check Enable to enable the date and time

from the configuring computer using the HTTP protocol.

System Time

Note

The Clock Source Setting must be set to either of the above for RIP MD5 authentication to work.

• Manual Settings—Set the date and time manually. The local time is used when there’s no alternate source of time, such as an SNTP server:

• Date—Enter the system date.

• Local Time—Enter the system time.

• Time Zone Settings—The local time is used via the DHCP server or Time Zone offset.

• Get Time Zone from DHCP—Select to enable dynamic configuration of the time zone and the DST from the DHCP server. Whether one or both of these parameters can be configured depends on the information found in the DHCP packet. If this option is enabled, DHCP client must be enabled on the device.

• Time Zone from DHCP—Displays the acronym of the time zone configured from the DHCP server. This acronym appears in the Actual Time field.

• Time Zone Offset—Select the difference in hours between Greenwich Mean Time (GMT) and the local time. For example, the Time Zone Offset for Paris is GMT +1, while the Time Zone Offset for New York is GMT – 5.

• Time Zone Acronym—Enter a name that represents this time zone. This acronym appears in the Actual Time field.

• Daylight Savings Settings—Select how DST is defined:

• Daylight Savings—Select to enable Daylight Saving Time.

• Time Set Offset—Enter the number of minutes offset from GMT ranging 1—1440. The default is 60.

• Daylight Savings Type—Click one of the following:

USA—DST is set according to the dates used in the USA.

European—DST is set according to the dates used by the European Union and other countries that use this standard.

By dates—DST is set manually, typically for a country other than the USA or a European country. Enter the parameters described below.

Recurring—DST occurs on the same date every year.

Selecting By Dates allows customization of the start and stop of DST:

• From—Day and time that DST starts.

• To—Day and time that DST ends.

Cisco Business 250 Series Switches Administration Guide

SNTP Unicast

Step 3 Selecting Recurring allows different customization of the start and stop of DST:

• From—Date when DST begins each year.

• Day—Day of the week on which DST begins every year.

• Week—Week within the month from which DST begins every year.

• Month—Month of the year in which DST begins every year.

• Time—The time at which DST begins every year.

• To—Date when DST ends each year. For example, DST ends locally every fourth Friday in October at 5:00 a.m.. The parameters are:

• Day—Day of the week on which DST ends every year.

• Week—Week within the month from which DST ends every year.

• Month—Month of the year in which DST ends every year.

• Time—The time at which DST ends every year.

Administration

Step 4 Click Apply. The system time values are written to the Running Configuration file.

SNTP Unicast

SNTP synchronizes a computer's system time with a server that has already been synchronized by a source such as a satellite receiver or modem. SNTP supports unicast, multicast and anycast operating modes. In unicast mode, the client sends a request to a dedicated server by referencing its unicast address.Up to 16 Unicast SNTP servers can be configured.

Note

The Main Clock Source (SNTP Servers) System Time, on page 52 must be enable for SNTP Client Unicast to operate.

To add a Unicast SNTP server, follow these steps:

Step 1 Click Administration > Time Settings > SNTP Unicast.

Step 2 Configure the following fields:

SNTP Client Unicast

Select to enable the device to use SNTP-predefined Unicast clients with Unicast SNTP servers.

IPv6 Source Interface

Cisco Business 250 Series Switches Administration Guide

Select the IPv4 interface used for communication with the SNTP server.IPv4 Source Interface

Select the IPv6 interface used for communication with the SNTP server.

Note

If the Auto option is selected, the system takes the source IP address from the IP address defined on the outgoing interface.

Administration

Step 3 Click Addto add a Unicast SNTP server.

SNTP Multicast/Anycast

Note

To remove all user-defined SNTP servers, click Restore Default Servers.

Step 4 Enter the following parameters:

IPv6 Address Type

SNTP Server IP Address/Name

Poll Interval

Select the SNTP server to be identified by its IP address or by name from the list.Server Definition

Select the version of the IP address: Version 6 or Version 4.IP Version

Select the IPv6 address type (if IPv6 is used). The options are:

• Link Local—The IPv6 address uniquely identifies hosts on a single network link. A link local address has a prefix of FE80, isn’t routable, and can be used for communication only on the local network. Only one link local address is supported. If a link local address exists on the interface, this entry replaces the address in the configuration.

• Global—The IPv6 address is a global Unicast IPV6 type that is visible and reachable from other networks.

Select the link local interface (if IPv6 Address Type Link Local is selected) from the list.Link Local Interface

Enter the SNTP server IP address or name. The format depends on which address type was selected.

Select to enable polling of the SNTP server for system time information. All NTP servers that are registered for polling are polled, and the clock is selected from the server with the lowest stratum level that is reachable. The server with the lowest stratum is considered to be the primary server. The server with the next lowest stratum is a secondary server, and so forth. If the primary server is down, the device polls all servers with the polling setting enabled, and selects a new primary server with the lowest stratum.

Select the check box to enable authentication.Authentication

If authentication is enabled, select the value of the key ID.Authentication Key ID

Step 5 Click Apply. The STNP server is added, and you are returned to the main page.

SNTP Multicast/Anycast

Note

The Main Clock Source (SNTP Servers) System Time, on page 52 must be enable for SNTP Client Unicast to operate.

To enable receiving SNTP packets from all servers on the subnet and/or to enable transmitting time requests to SNTP servers, follow these steps:

Click Administration > Time Settings > SNTP Multicast/Anycast.

Cisco Business 250 Series Switches Administration Guide

SNTP Authentication

Select from the following options:

Administration

DescriptionOption

SNTP IPv4 Multicast Client Mode (Client Broadcast Reception)

SNTP IPv6 Multicast Client Mode (Client Broadcast Reception)

SNTP IPv4 Anycast Client Mode (Client Broadcast Transmission)

SNTP IPv6 Anycast Client Mode (Client Broadcast Transmission)

SNTP Authentication

SNTP clients can authenticate responses by using HMAC-MD5. An SNTP server is associated with a key. This is used as input together with the response itself to the MD5 function; the result of the MD5 is also included in the response packet. The SNTP Authentication page enables configuration of the authentication keys that are used when communicating with an SNTP server.

The authentication key is created on the SNTP server in a separate process that depends on the SNTP server type. Consult with the SNTP server system administrator for more information.

Select to receive system time IPv4 Multicast transmissions from any SNTP server on the subnet.

Select to receive system time IPv6 Multicast transmissions from any SNTP server on the subnet.

Select to transmit SNTP IPv4 synchronization packets requesting system time information. The packets are transmitted to all SNTP servers on the subnet.

Select to transmit SNTP IPv6 synchronization packets requesting system time information. The packets are transmitted to all SNTP servers on the subnet.

Step 1 Click Administration > Time Settings > SNTP Authentication. Step 2 Select SNTP Authentication to support authentication of an SNTP session between the device and an SNTP server. Step 3 Click Apply to update the device. Step 4 Click Add.

Step 5 Enter the following parameters:

• Authentication Key ID—Enter the number used to identify this SNTP authentication key internally.

• Authentication Key (Encrypted)—Enter the key used for authentication (up to eight characters) in encrypted format. The SNTP server must send this key for the device to synchronize to it.

• Authentication Key (Plaintext)—Enter the key used for authentication (up to eight characters) in plaintext format. The SNTP server must send this key for the device to synchronize to it.

• Trusted Key—Select to enable the device to receive synchronization information only from a SNTP server by using this authentication key.

Step 6 Click Apply. The SNTP Authentication parameters are written to the Running Configuration file.

Cisco Business 250 Series Switches Administration Guide

Administration

Time Range

Time ranges can be defined and associated with the following types of commands, so that they are applied only during that time range:

• Port Stat

• Time-Based PoE

There are two types of time ranges:

• Absolute—This type of time range begins on a specific date or immediately and ends on a specific date or extends infinitely. It is created in the Time Range pages. A periodic element can be added to it.

• Periodic—This type of time range contains a time range element that is added to an absolute range, and begins and ends on a periodic basis. It is defined in the Periodic Range pages.

If a time range includes both absolute and periodic ranges, the process associated with it is activated only if both absolute start time and the periodic time range have been reached. The process is deactivated when either of the time ranges are reached. The device supports a maximum of 20 absolute time ranges.

To ensure that the time range entries take effect at the desired times, the system time must be set.The time-range feature can be used for the following:

• Limit access of computers to the network during business hours (for example), after which the network ports are locked, and access to the rest of the network is blocked (see Configuring Ports and Configuring LAG Settings)

• Limit PoE operation to a specified period.

Add these descriptions for time range

Step 1 Click Administration > Time Settings > Time Range. Step 2 In the Time Range Table, click Add to add a new time range or Edit or Delete to edit or delete an existing one. Step 3 To add a new time range, click Add and configure the following:

• Time Range Name—Enter a name for your time range

• Absolute Starting Time—Select Immediate or enter a date and time.

• Absolute Ending Time—Select Infinite or enter a date and time

Step 4 Click Apply to apply the new time range settings.

Recurring Time Range

A recurring time element can be added to an absolute time range. This limits the operation to certain time periods within the absolute range.

To add a recurring time range element to an absolute time range:

Cisco Business 250 Series Switches Administration Guide

System Log

Step 1 Click Administration > Time Settings > Recurring Range.

The existing recurring time ranges are displayed (filtered per a specific, absolute time range.)

Step 2 Select the absolute time range to which to add the recurring range. Step 3 To add a new recurring time range, click Add.

Step 4 Enter the following fields:

• Recurring Starting Time—Enter the day of the week, and time that the Time Range begins.

• Recurring Ending Time—Enter the day of the week, and time that the Time Range ends.

Step 5 Click Apply.

System Log

Administration

Log Settings

This section describes the system logging, which enables the device to generate multiple independent logs. Each log is a set of messages describing system events.

The device generates the following local logs:

• Log sent to the console interface.

• Log written into a cyclical list of logged events in the RAM and erased when the device reboots.

• Log written to a cyclical log-file saved to the Flash memory and persists across reboots.

In addition, you can send messages to remote SYSLOG servers in the form of SNMP traps and SYSLOG messages.

You can select the events to be logged by severity level. Each log message has a severity level marked with the first letter of the severity level concatenated with a dash (-) on each side (except for Emergency that is indicated by the letter F). For example, the log message "%INIT-I-InitCompleted: … " has a severity level of I, meaning Informational.

The event severity levels are listed from the highest severity to the lowest severity, as follows:

• Emergency—System is not usable.

• Alert—Action is needed.

• Critical—System is in a critical condition.

• Error—System is in error condition.

• Warning—System warning has occurred.

• Notice—System is functioning properly, but a system notice has occurred.

• Informational—Device information.

Cisco Business 250 Series Switches Administration Guide

Administration

• Debug—Detailed information about an event.

You can select different severity levels for RAM and Flash logs. These logs are displayed in the RAM Memory,

on page 47 and Flash Memory, on page 48, respectively.

Selecting a severity level to be stored in a log causes all of the higher severity events to be automatically stored in the log. Lower severity events are not stored in the log. For example, if Warning is selected, all severity levels that are Warning and higher are stored in the log (Emergency, Alert, Critical, Error, and Warning). No events with severity level below Warning are stored (Notice, Informational, and Debug).

To set global log parameters, complete the following steps:

Step 1 Click Administration > System Log > Log Settings.

Step 2 Enter the parameters.

Select to enable message logging.Logging

Remote Logging Settings

Syslog Aggregator

Select to enable the aggregation of SYSLOG messages and traps. If enabled, identical and contiguous SYSLOG messages and traps are aggregated over the specified Max. Aggregation Time and sent in a single message. The aggregated messages are sent in the order of their arrival. Each message states the number of times it was aggregated.

Enter the interval of time that SYSLOG messages are aggregated.Max. Aggregation Time

Originator Identifier

Enables adding an origin identifier to SYSLOG messages. The options are:

• None—Do not include the origin identifier in SYSLOG messages.

• Hostname—Include the system host name in SYSLOG messages.

• IPv4 Address—Include the IPv4 address of the sending interface in SYSLOG messages.

• IPv6 Address—Include the IPv6 address of the sending interface in SYSLOG messages.

• User Defined—Enter a description to be included in SYSLOG messages.

Select the severity levels of the messages to be logged to the RAM.RAM Memory Logging

Select the severity levels of the messages to be logged to the Flash memory.Flash Memory Logging

Step 3 Click Apply. The Running Configuration file is updated.

Remote Logging Settings

The Remote Log Servers page enables defining remote SYSLOG servers to which log messages are sent. For each server, you can configure the severity of the messages that it receives.

To define SYSLOG servers, follow these steps:

Cisco Business 250 Series Switches Administration Guide

Remote Logging Settings

Step 1 Click Administration > System Log > Remote Log Servers.

Step 2 Enter the following fields:

• IPv4 Source Interface—Select the source interface whose IPv4 address will be used as the source IPv4 address of SYSLOG messages sent to SYSLOG servers.

• IPv6 Source Interface—Select the source interface whose IPv6 address will be used as the source IPv6 address of SYSLOG messages sent to SYSLOG servers.

Administration

Note

If the Auto option is selected, the system takes the source IP address from the IP address defined on the outgoing interface.

Information is described for each previously configured log server. The fields are described below in the Add page.

Step 3 Click Add.

Step 4 Enter the parameters.

IPv6 Address Type

Select whether to identify the remote log server by IP address or name.Server Definition

Select the supported IP format.IP Version

Select the IPv6 address type (if IPv6 is used). The options are:

• Link Local—The IPv6 address uniquely identifies hosts on a single network link. A link local address has a prefix of FE80::/10, isn’t routable, and can be used for communication only on the local network. Only one link local address is supported. If a link local address exists on the interface, this entry replaces the address in the configuration.

• Global—The IPv6 address is a global Unicast IPV6 type that is visible and reachable from other networks.

Select the link local interface (if IPv6 Address Type Link Local is selected) from the list.Link Local Interface

Enter the IP address or domain name of the log server.Log Server IP Address/Name

Enter the UDP port to which the log messages are sent.UDP Port

Facility

Select a facility value from which system logs are sent to the remote server. Only one facility value can be assigned to a server. If a second facility code is assigned, the first facility value is overridden.

Enter a server description.Description

Select the minimum level of system log messages to be sent to the server.Minimum Severity

Step 5 Click Apply. The Add Remote Log Server page closes, the SYSLOG server is added, and the Running Configuration

file is updated.

Cisco Business 250 Series Switches Administration Guide

Administration

File Management

A File Management System is an application that is used to store, arrange and access the files that are on your device.The system files are files that contain information, such as: configuration information or firmware images. Generally, every file under the flash://system/ folder is a system file. Various actions can be performed with these files, such as: selecting the firmware file from which the device boots, modifying various types of configuration files internally on the device, or copying files to or from an external device, such as an external server.

The following are some of the types of files are found on the device:

• Running Configuration—Contains the parameters currently being used by the device to operate. This file is modified when you change parameter values on the device. If the device is rebooted, the Running Configuration is lost. To preserve any changes you made to the device, you must save the Running Configuration to the Startup Configuration, or another file type.

• Startup Configuration—The parameter values that saved by copying another configuration (usually the Running Configuration) to the Startup Configuration. The Startup Configuration is retained in Flash and is preserved when the device is rebooted. At this time, the Startup Configuration is copied to RAM and identified as the Running Configuration.

File Management

• Mirror Configuration—A copy of the Startup Configuration, created by the device when the following conditions exist:

• The device has been operating continuously for 24 hours.

• No configuration changes have been made to the Running Configuration in the previous 24 hours.

• The Startup Configuration is identical to the Running Configuration.

Only the system can copy the Startup Configuration to the Mirror Configuration. However, you can copy from the Mirror Configuration to other file types or to another device.

• Backup Files—Manual copies of a files used for protection against system shutdown or for the maintenance of a specific operating state. For instance, you can copy the Mirror Configuration, Startup Configuration, or Running Configuration to a Backup file. The Backup exists in Flash or on a PC or USB drive and is preserved if the device is rebooted.

• Firmware—The program that controls the operations and functionality of the device. More commonly referred to as the image.

• Language File—The dictionary that enables the web-based configuration utility windows to be displayed in the selected language.

• Logging File—SYSLOG messages stored in Flash memory.

Firmware Operations

The Firmware Operations page can be used to:

• Update or backup the firmware image

• Swap the active image.

Cisco Business 250 Series Switches Administration Guide

Firmware Operations

The software images of the units in a stack must be identical to ensure proper stack operations. Stack units can be upgraded in any one of the following ways.

Step 1 Click Administration > File Management > Firmware Operations.

The following fields are displayed:

• Active Firmware File—Displays the current, active firmware file.

• Active Firmware Version—Displays the version of the current, active firmware file.

Step 2 Select the Operation Type from the following options:

• Update Firmware

• Backup Firmware

• Swap Image

Step 3 Select the Copy Method from the following options:

Administration

HTTP/HTTPS

For HTTP/HTTPS, enter the file name in the File Name field, or browse to locate and select the file.

USB

For USB, enter the file name in the File Name field, or browse to locate and select the file.

For TFTP, proceed with the TFTP Instructions below.TFTP

For SCP, proceed with the SCP Instructions below.SCP (File transfer via SSH)

TFTP Instructions

Configure the following if you selected the TFTP as your copy method for the firmware operations.

Server Definition

Select from the following options:

• By IP Address

• By Name

IP Version

Select from the following options:

• IP Version 6

• IP Version 4

IPv6 Address Type

Select from the following options:

• Link Local—A link local address has a prefix of FE80, is not routable, and can be used for communication only on the local network.

• Global—The IPv6 address is a global Unicast IPV6 type that is visible and reachable from other networks.

Cisco Business 250 Series Switches Administration Guide

Administration

Firmware Operations

Link Local Interface

If for the IPv6 address type, you selected Link Local, select the interface from the drop down list.

Enter the server IP address/name.Server IP Address/Name

Enter the name of the source (0 - 160 characters used)Source

SCP Instructions

Configure the following if you selected the SCP as your copy method for the firmware operations.

To enable SSH server authentication (which is disabled by default), click Edit .Remote SSH Server

Authentication

SSH Client Authentication

Select from the following:

• Use SSH Client System Credentials.

• Use SSH Client One-Time Credentials:

Enter the username if using the SSH Client One-Time Credentials option.Username

Enter the password if using the SSH Client One-Time Credentials option.Password

Server Definition

Select from the following options:

• By IP Address

IP Version

IPv6 Address Type

Link Local Interface

Select from the following options:

If for the IPv6 address type, you selected Link Local, select the interface from the drop down list.

Enter the server IP address/name.Server IP Address/Name

Enter the name of the source (0 - 160 characters used)Source

Step 4 Click Apply to save your settings.

• By Name

• Version 6

• Version 4

• Link Local—A link local address has a prefix of FE80, is not routable, and can be used for communication only on the local network.

• Global—The IPv6 address is a global Unicast IPV6 type that is visible and reachable from other networks.

Cisco Business 250 Series Switches Administration Guide

File Operations

Step 1 Click Administration > File Management > File Operations.

Step 2 Select the Operation Type from the following options:

• Update File

• Backup File

• Duplicate

Step 3 Select the Destination File Type from the following options:

• Running Configuration

• Startup Configuration

• Mirror Configuration

• Logging File

Administration

• Language File

• Dashboard Info File

Step 4 Select the Copy Method from the following options:

HTTP/HTTPS

For HTTP/HTTPS, enter the file name in the File Name field, or browse to locate and select the file.

USB

For USB, enter the file name in the File Name field, or browse to locate and select the file.

Internal Flash

For Internal File, enter the file name in the File name field or click on File Directory to browse and to locate. Sensitive Data Handling -Select the method in which the data should be handled. This applies only for file backup or duplication.

• Exclude - to exclude sensitive data

• Encrypt - to encrypt sensitive data

• Plaintext - to display sensitive data in plaintext.

For TFTP, proceed with the TFTP Instructions below.TFTP

For SCP, proceed with the SCP Instructions below.SCP (File transfer via SSH)

TFTP Instructions

Configure the following if you selected the TFTP as your update or backup method for the file operations.

Server Definition

Select from the following options:

• By IP Address

• By Name

Cisco Business 250 Series Switches Administration Guide

Administration

File Operations

IP Version

Select from the following options:

• IP Version 6

• IP Version 4

IPv6 Address Type

Select from the following options:

• Link Local—A link local address has a prefix of FE80, is not routable, and can be used for communication only on the local network.

• Global—The IPv6 address is a global Unicast IPV6 type that is visible and reachable from other networks.

Link Local Interface

If for the IPv6 address type, you selected Link Local, select the interface from the drop down list.

Enter the server IP address/name.Server IP Address/Name

Enter the name of the source (0 - 160 characters used)Source

SCP Instructions

Configure the following if you selected the SCP as your copy method for the file operations.

To enable SSH server authentication (which is disabled by default), click Edit .Remote SSH Server

Authentication

SSH Client Authentication

Server Definition

IP Version

IPv6 Address Type

Select from the following:

• Use SSH Client System Credentials:

• Use SSH Client One-Time Credentials:

Enter the username if using the SSH Client One-Time Credentials option.Username

Enter the password if using the SSH Client One-Time Credentials option.Password

Select from the following options:

• By IP Address

• By Name

Select from the following options:

• IP Version 6

• IP Version 4

Select from the following options:

• Link Local—A link local address has a prefix of FE80, is not routable, and can be used for communication only on the local network.

• Global—The IPv6 address is a global Unicast IPV6 type that is visible and reachable from other networks.

Cisco Business 250 Series Switches Administration Guide

File Directory

Administration

Link Local Interface

Step 5 In the File name section, click the Browse button to locate and select the file. Step 6 Click Apply.

If for the IPv6 address type, you selected Link Local, select the interface from the drop down list.

Enter the server IP address/name.Server IP Address/Name

Enter the name of the source (0 - 160 characters used)Source

File Directory

The File Directory page displays the system files existing in the system.

Step 1 Click Administration > File Management > File Directory.

Step 2 If required, enable Auto Mirror Configuration. This enables the automatic creation of mirror configuration files. When

disabling this feature, the mirror configuration file, if it exists, is deleted.

Step 3 Select the drive from which you want to display the files and directories. The following options are available:

• Flash—Display all files in the root directory of the management station.

• USB—Display files on the USB drive.

Step 4 Click Go to display the following fields:

• File Name—Type of system file or actual name of file depending on the file type.

• Permissions—Read/write permissions of the user for the file.

• Size—Size of file.

• Last Modified—Date and time that file was modified.

• Full Path—Path of file.

DHCP Auto Update

The Auto Configuration/Image Update feature provides a convenient method to automatically configure switches in a network and upgrade their firmware. This process enables the administrator to remotely ensure that the configuration and firmware of these devices in the network are up to date.

Step 1 Click Administration > File Management > DHCP Auto Update.

Step 2 Configure the following:

Cisco Business 250 Series Switches Administration Guide

Administration

DHCP Auto Update

Auto Configuration Via DHCP

Download Protocol

Image Auto Update via DHCP:

Download Protocol

Check to enable the autoconfiguration via DHCP. The Auto Configuration feature provides a convenient method to automatically configure switches in a network and upgrade their firmware.

Select the download protocol from the following opions:

• Auto By File Extension—(Default) Files with this extension are downloaded using SCP (over SSH), while files with other extensions are downloaded using TFTP.

• TFTP Only—The download is done through TFTP, regardless of the file extension of the configuration file name.

• SCP Only—The download is done through SCP (over SSH), regardless of the file extension of the configuration file name.

Check to enable image auto update via DHCP. The Image Auto Update feature provides a convenient method to automatically update switches in a network and upgrade their firmware.

Select the download protocol from the following options:

• Auto By File Extension—(Default) Files with this extension are downloaded using SCP (over SSH), while files with other extensions are downloaded using TFTP.

• TFTP Only—The download is done through TFTP, regardless of the file extension of the configuration file name.

Step 3 Select the SSH settings for SCP.

Remote SSH Server Authentication:

SSH Client Authentication

Backup Server Definition

IP Version

• SCP Only—The download is done through SCP (over SSH), regardless of the file extension of the configuration file name.

Click the link to navigate to the SSH Server Authentication page. There you can enable authentication of the SSH server to be used for the download and enter the trusted SSH server if required.

• Click on the System Credentialsto enter user credentials in the SSH User

Authentication page.

Select from the following options:

• By IP Address

• By Name

Select from the following options:

• IP Version 6

• IP Version 4

Cisco Business 250 Series Switches Administration Guide

Cisco Business Dashboard Settings

Administration

IPv6 Address Type

Link Local Interface

IP Address

Note

Step 4 Click Apply to save your settings.

DHCP Auto Configuration / Image is operational only when the IP Address configuration is dynamic.

Select from the following options:

• Link Local—A link local address has a prefix of FE80, is not routable, and can be used for communication only on the local network.

• Global—The IPv6 address is a global Unicast IPV6 type that is visible and reachable from other networks.

If for the IPv6 address type, you selected Link Local, select the interface from the drop down list.

Enter the name of the backup configuration file.Backup Server IP Address/Name

Enter the name of the backup configuration file (0 - 160 characters used)Backup Configuration File Name

Enter the name of backup indirect image file (0 - 160 characters used).Backup Indirect Image File Name

The address of the last auto configuration/image server IP address is displayed.Last Auto Configuration / Image Server

The name of the last auto configuration file is displayed.Last Auto Configuration File Name

Cisco Business Dashboard Settings

Cisco Business Dashboard helps you monitor and manage your Cisco 100 to 500 Series network with the use of the Cisco Business Dashboard Manager. The Cisco Business Dashboard Manager is an add-on that automatically discovers your network, and allows you to configure and monitor all supported Cisco 100 to 500 Series devices such as Cisco switches, routers, and wireless access points.

Cisco Business Dashboard Manager is a distributed application which is comprised of two separate components or applications: one or more Probes referred to as Cisco Business Dashboard Probe and a single Manager called Cisco Business Dashboard Manager. An instance of Cisco Business Dashboard Probe is installed at each site in the network, performs network discovery and communicates directly with each Cisco device.

Note

For detailed instructions on how to setup the Cisco Business Dashboard Manager and Probe, please consult the Cisco Business Dashboard Quick Start Guide.

https://cisco.com/go/cbd-docs

Complete the following steps on the switch graphical user interface (GUI) to enable a Probe connection to a Dashboard, configure the Organization and Network name, and other information required to allow connection to the Dashboard:

Step 1 Click Administration > Cisco Business Dashboard Settings.

Cisco Business 250 Series Switches Administration Guide

Administration

Step 2 Configure the following:

Cisco Business Dashboard Settings

Check to enable the Cisco Business Dashboard Probe operation.Probe Operation

Displays the status of the Cisco Business Dashboard probe.Probe Status

Displays the version of the Cisco Business Dashboard probe.Probe Version

Logging Threshold

Dashboard Definition

Select one of the following options (Information, Debug, Warning, or Error) from the drop-down list to limit the level of messages logged by the Cisco Business Dashboard probe agent. Only messages with the specified level or higherwill be logged.

Check to enable. This logs all communication and events between all modules.All Module Logging

Check to enable. This logs all communication between the Probe and Mnager.Call Home Logging

Check to enable. This logs the device discovery events and topology discovery.Discovery Logging

Check to enable. This logs the message translation between northbound and southbound.Services Logging

Check to enable. This logs the core system process not covered by any of the other logs.System Logging

Check to enable. This logs the communication between the Manager and the Probe.Northbound Logging

Check to enable. This logs the low level communication between the Probe and devices.Southbound Logging

Check to enable.Dashboard Connection

Displays the status of the Cisco Business Dashboard Manager.Dashboard Status

Enter the organization name of the Cisco Business Dashboard Probe running on the device.Organization Name

Enter the site name of the Cisco Business Dashboard Probe.Network Name

Define the address of the Cisco Business Dashboard. Select one of the following:

Dashboard Port

Access

Key ID

Access Key

Secret

• By IP address - this option requires you to enter a valid IP address to the IP Address/Name field.

• By Name- this option requires you to enter a hostname to the IP Address/Name field.

Enter the name of IP address of the Cisco Business Dashboard.IP Address/Name

Specify one of the following TCP ports to connect to the Dashboard.

• Use Default (443).

• User Defined (Range: 1-65535). This option is available only if a valid address is entered in the Dashboard Address field.

Specify the key ID to be used for the initial authentication between the Cisco Business Dashboard Probe running on the device and the Cisco Business Dashboard.

Specify the secret to use for authentication. It can be Encrypted or in Plaintext format. The Plaintext format is specified as an alphanumeric string without white-spaces (up to 160 chars). The Key ID and Secret settings must be set together.

Cisco Business 250 Series Switches Administration Guide

Plug-n-Play (PNP)

Step 3 Click Apply to save the setting to the running configuration.

Administration

Note

Reset Connection Reset Connection button - click to disconnect the current connection with the Dashboard, flush the Cisco Business

Dashboard Probe cached data, and then attempt to reconnect to the Dashboard. A confirmation message is displayed before the operation starts. This control is enabled only if the Dashboard Connection and Probe Operation are enabled.

Note

Many factors affect the number of network devices and clients that the Cisco Business Dashboard Probe on a switch can manage. We recommend that a probe on a switch manage no more than 15 network devices (switches, routers, and wireless access points) and no more than 150 connected clients. If your network is more complex, we recommend that you use other platforms for the Cisco Business Dashboard Probe. For more information about Cisco Business Dashboard, go to

www.cisco.com/go/findit.

The fields Organization Name, Network Name, Dashboard Address, Key ID cannot be modified if Dashboard Connection setting is enabled. To modify any of these settings clear the Dashboard Connection check box,

click Apply, and redo steps 2-4 above.

If it is required to clear the Cisco Probe database – use the following CLI Command: clear Cisco Business Dashboard probe database.

Plug-n-Play (PNP)

Installation of new networking devices or replacement of devices can be expensive, time-consuming and error-prone when performed manually. Typically, new devices are first sent to a central staging facility where the devices are unboxed, connected to a staging network, updated with the right licenses, configurations and images; then packaged and shipped to the actual installation location. After these processes are completed, experts must travel to the installation locations to perform the installation. Even in scenarios where the devices are installed in the NOC/Data Center itself, there may not be enough experts for the sheer number of devices. All these issues contribute to delays in deployment and add to the operational costs.

Connecting to PNP Server

To allow the switch to connect to the PnP server, a discovery process takes place, in which the switch discovers the PNP server address/url. There are multiple discovery methods, and they are executed by the switch according to the sequence detailed below. If a PnP server is discovered by a certain method, the discovery process is completed and the rest of the methods are not executed:

1. User configured address - the PnP server url or IP address are specified by the user.

2. Address received from DHCP response option 43 - the PnP server url or IP address are received as part

of option 43 in the DHCP response

3. DNS resolution of hostname "pnpserver" - the PnP server IP addressed is obtained via DNS server

resolution of hostname “pnpserver”.

4. Cisco Plug and Play Connect - a redirection service that allows full “out of the box” PNP server discovery

which runs over HTTPs.

The switch contacts the redirection service using the FQDN “devicehelper.cisco.com”.

Cisco Business 250 Series Switches Administration Guide

Administration

Plug-n-Play (PNP)

Cisco PnP Connect Prerequisites

To allow Cisco Plug and Play Connect operation, the user needs to create devices and controller profiles in Plug and Play Connect (navigate to https://software.cisco.com and click the PnP Connect link). Note that a Cisco Smart Account is required to use PnP Connect. To create or update a Smart Account, see the Administration section of https://software.cisco.com.

In addition, the following prerequisites are required to be met on the switch itself:

• The PNP server was not discovered by the other discovery methods

• The device is able to successfully resolve the name devicehelper.cisco.com (either static configuration or using DNS server)

• System time was set using one of the following methods

• Time was updated by an SNTP server

• Clock was set manually by user

• Time was preserved across resets by Real Time Clock (RTC).

CA-Signed Certificate based Authentication

Cisco distributes certificates signed by a signing authorities in .tar file format and signs the bundle with Cisco Certificate Authority (CA) signature. This certificate bundle is provided by Cisco infoSec for public downloads on cisco.com.

Note

If the PNP server discovery is based on Cisco PnP Connect, the trustpool is downloaded from following:

http://www.cisco.com/security/pki/trs/ios_core.p7b.

If the PNP server discovery is based on DHCP option 43, use the “T<Trust pool CA bundle URL>;” parameter in DHCP option 43 to provide the URL for downloading the trust pool. The certificates from this bundle can be installed on the Cisco device for server-side validation during SSL handshake. It is assumed that the server uses a certificate, which is signed by one of the CA that is available in the bundle.

The PnP agent uses the built-in PKI capability to validate the certificate bundle. As the bundle is signed by Cisco CA, the agent is capable of identifying a bundle that is tampered before installing the certificates on the device. After the integrity of the bundle is ensured by the agent, the agent installs the certificates on the device. After the certificates are installed on the device, the PnP agent initiates an HTTPs connection to the server without any additional steps from the server.

Note

The device also supports a built in certificate bundle which is installed as part of the bootup process. this bundle can be used to validate PNP server. If a Bundle is downloaded based on Cisco PnP Connect information then the certificates from the downloaded bundle are installed and the certificates based on the built in bundle are un-installed.

Cisco Business 250 Series Switches Administration Guide

Plug-n-Play (PNP)

Note

Administration

In addition to validating PNP certificate based on installed CA certificate the PNP Agent also validates that the certificate's Common Name/Subject Alternate Name (CN/SAN) matches the hostname/IP address of the PNP server. If they don't match validation of certificate is rejected.

Cisco PnP DHCP Option 43 Usage Guidelines

DHCP option 43 is a vendor specific identifier which is one of the methods that can be used by the PnP agent to locate and connect to the PnP server (see Cisco Plug-n-Play for more information).

The following provides Information on configuration of Option 43 to allow proper configuration on DHCP server.

Option 43 includes the following fields/parameters:

<DHCP-typecode><feature-opcode><version><debug-option>;<arglist>

The <arglist> parameter should use the following syntax:

B<IPaddress type>;I<IPaddress>;J<Port>;K<Transportprotocol>;T<Trust poolCA bundleURL>;Z<SNTP server IP address>

The following table details the description and usage of option 43 fields

DescriptionParameter

DHCP sub-option type. The DHCP sub-option type for PnP is 5.DHCP-typecode

Feature-opcode

Feature operation code – can be either Active (A) or Passive (P). The feature operation code for PnP is Active (A) which implies that PnP agent initiates a connection to the PnP server. If the PnP server cannot be reached, PnP agent retries until it makes a connection.

Version of template to be used by PnP agent. Must be 1.Version

Debug-option

Turns ON or OFF the debug messages during the processing of the DHCP Option 43:

D – debug option is ON ; N – debug option is OFF.

Transport protocol to be used between PnP agent and PnP server:

4 - HTTP or 5 – HTTPS.

IP address type of PnP server IP address specified with the letter code

‘I’:

1 - host , 2- IPv4 , 3 - IPv6

IP address or hostname of PnP server. If hostname is specified, DNS related options must be present in the DHCP server to allow for successful use of hostname.

Cisco Business 250 Series Switches Administration Guide

Administration

PNP Settings

DescriptionParameter

URL of trust pool CA bundle. You can get the CA bundle from a Cisco Business Dashboard, or from a TFTP server.

• When using Cisco Business Dashboard, use the following URL format:

http://CBD IP address or domain

name/ca/trustpool/CA_bundle_name

• When using TFTP Server, use the following URL format:

tftp://tftp server IP/CA_bundle_name

SNTP server IP address. You must sync the clock before configuring a trust pool.

Note

The switch clock is considered synchronized if it was updated by any SNTP server supported by the switch (by default, userconfigured or in Z parameter) or set manually by the user. This parameter is required when using trust pool security if the switch can not reach any other SNTP server. For example, for an out-of-thebox switch with factory default configuration but no Internet connectivity to reach the default SNTP servers.

Port number http=80 https=443J

Examples for Option 43 usage:

• The following format is used for PnP connection setup using HTTP:

option 43 ascii 5A1N;K4;B2;I10.10.10.3;J80

• The following format is used for PnP connection setup on top of HTTPS, directly using a trust pool. HTTPS can be used when the trust pool CA bundle is downloaded from a Cisco Business Dashboard and the Cisco Business Dashboard server certificate was issued by a 3rd party (not self signed). In the example below “10.10.10.3” is the Cisco Business Dashboard IP address. Optionally, you can specify a domain name:

option 43 ascii

5A1N;K5;B2;I10.10.10.3;Thttp://10.10.10.3/ca/trustpool/ios.p7b;Z10.75.166.1

PNP Settings

To configure PNP settings, follow these steps:

Step 1 Click Administration > PNP > PNP Settings.

Step 2 Configure PNP by entering information in the following fields:

Check to enable.PNP State

Cisco Business 250 Series Switches Administration Guide

PNP Settings

Administration

PNP Transport / Settings Definition

IP Version

Select one of the following options for locating configuration information, regarding the transport protocol to use, the PNP server address and the TCP port to use:

• Default Settings—If this option is selected, the PNP settings are then taken from DHCP option 43. If settings aren’t received from DHCP option 43, the following default values are used: default transport protocol HTTP, DNS name "pnpserver" for PNP server and the port related to HTTP. If the “pnpserver” name is not resolved by DNS, then Cisco Plug and Play Connect service is used, using DNS name “devicehelper.cisco.com”. When selecting the Default Settings option, all fields in PNP Transport section are grayed out. If both PNP agent and DHCP Auto Configuration/Image Update are enabled on device - in case he DHCP reply includes, in addition to option 43, options related to config or image file name, then device ignores received option 43.

• Manual Settings—Manually set the TCP port and server settings to use for PNP transport.

Select the transport protocol, HTTP or HTTPS.Transport Protocol

Number of the TCP port. This is entered automatically by the system: 80 for HTTP.TCP Port

Select whether to specify the PNP server By IP address or By name.Server Definition

Select the supported IP format.

• Version 6—IPv6

Server IPv6 Address Type

PNP User / User Definition

• Version 4—IPv4

Select one of the following options, if the IP version type is IPv6:

• Global—The IPv6 address is a global Unicast IPV6 type that is visible and reachable from other networks.

If the source IPv6 address type is Link Local, select from where it is received.Link Local Interface

Enter the IP address or domain name of the PNP server.Server IP Address/Name

User information to be sent in PNP packets sent to the server. Select one of the following options:

• Default Settings—When selecting this option, the PNP username and password settings are taken from DHCP option 43. If this option is selected the username and password fields are grayed out.

• Manual Settings—Select to manually configure PNP username and password.

Username to be entered in the PNP packets.User Name

Cisco Business 250 Series Switches Administration Guide

Administration

PNP Session

Password in either Encrypted or Plaintext form.Password

PNP Behavior Settings/Reconnection

If you select User Defined, set the interval (in seconds) before attempting to reconnect the session after the connection is lost.

Interval

Discovery Timeout

Specifies the time to wait, in seconds, before attempting discovery again after a discovery of the PNP server failed.

Timeout Exponential Factor

Value that triggers the discovery attempt exponentially. By multiplying the previous timeout value by an exponential value and applying the result as timeout (if value is smaller than max timeout value).

Maximum value of timeout. Must be greater than the Discovery Timeout value.Max Discovery Timeout

Watchdog Timeout

Interval of time to wait for a reply from a PnP or file server during an active PNP session (for example during a file download process).

Step 3 Click Apply. The parameters are copied to the Running Configuration file.

Click Display Sensitive Data as Plaintext to display the password if it’s encrypted.

PNP Session

The PNP Session screen displays the value of the PNP parameters currently in effect. The source of the parameter is displayed in parenthesis where relevant.

To display information about PNP parameters, follow these steps:

Click Administration > PNP > PNP Session.

The following fields are displayed:

• Administrative Status—Whether PNP is enabled or not.

• Operational Status—Is PNP operational.

• PNP Agent State—Indicates whether there’s an active PNP session. The possible values are Discovery Wait; Discovery; Not Ready; Disabled; Session; Session Wait.

• Transport Protocol– Displays the PNP agent session information.

• TCP Port—TCP port of the PNP session

• Server IP Address—IP address of PNP server

• Username—Username to be sent in PNP packets.

• Password MD5—Password to be sent in PNP packets.

• Session Interval Timeout—Session Interval timeout configured (appears only when PNP Agent State is waiting).

Cisco Business 250 Series Switches Administration Guide

Reboot

• Remaining Timeout—Value of remaining timeout.

Note

Click the Resume button to immediately take the PnP agent out of the waiting state, in the following way:

• If the agent is in the Discovery Waiting state, it’s set to the Discovery state.

• If the agent is in the PnP Session Waiting state, it’s set to the PnP Session state.

Some configuration changes, such as enabling jumbo frame support, require the system to be rebooted before they take effect. However, rebooting the device deletes the Running Configuration, so it’s critical to save the Running Configuration as the Startup Configuration before rebooting. Clicking Apply doesn’t save the configuration to the Startup Configuration. section.

Administration

To reboot the device, follow these steps:

Step 1 Click Administration > Reboot. Step 2 Click Reboot to reboot the device.

• Reboot—Reboots the device. Since any unsaved information in the Running Configuration is discarded at reboot,

you must click Saveto preserve the current configuration across the boot process. If the Save option isn’t displayed,

the Running Configuration matches the Startup Configuration and no action is necessary.

The following options are available:

• Immediate—Reboot immediately.

• Date—Enter the date (month/day) and time (hour and minutes) of the schedule reboot. This schedules a reload of the software to take place at the specified time (using a 24-hour clock).

Note

• Click Cancel Reboot to cancel a scheduled reboot.

• In—Reboot within the specified number of hours and minutes The maximum amount of time that can pass is 24 days.

• Restore to Factory Defaults—Reboots the device by using the factory default configuration. This process erases all except the Active Image, Inactive Image, Mirror configuration and Localization files.

This option can only be used if the system time has either been set manually or by SNTP.

• Clear Startup Configuration File—Check to clear the startup configuration on the device for the next time it boots up.

Cisco Business 250 Series Switches Administration Guide

Administration

Discovery Bonjour

As a Bonjour client, the device broadcasts Bonjour Discovery protocol packets to directly connected IP subnets. The device can be discovered by a network management system or other third-party applications. By default, Bonjour is enabled on the Management VLAN.

To configure Bonjour, follow these steps:

Step 1 Click Administration > Discovery - Bonjour. Step 2 Select Enable to enable Bonjour Discovery globally. Step 3 To enable Bonjour on a specific interface, click Add.

Step 4 Select and configure the interface. Step 5 Click Apply to update the Running Configuration file.

Discovery Bonjour

Note

Step 6 Click Delete to disable Bonjour on an interface.

When Bonjour is enabled, it sends Bonjour Discovery packets to interfaces with IP addresses associated with Bonjour on the Bonjour Discovery Interface Control table.

Discovery - LLDP

LLDP is a protocol that enables network managers to troubleshoot and enhance network management in multi-vendor environments. LLDP standardizes methods for network devices to advertise themselves to other systems, and to store discovered information. LLDP enables a device to advertise its identification, configuration, and capabilities to neighboring devices that then store the data in a Management Information Base (MIB).

LDP is a link layer protocol. By default, the device terminates and processes all incoming LLDP packets as required by the protocol. This section describes how to configure LLDP and covers the following topics:

Properties

The Properties page enables entering LLDP general parameters, such as enabling/disabling the feature globally and setting timers. To enter LLDP properties, proceed as follows:

Step 1 Click Administration > Discovery - LLDP > Properties. Step 2 Enter the parameters.

Select to enable LLDP on the device (enabled by default).LLDP Status

LLDP Frames Handling

If LLDP isn’t enabled, select one of the following options:

• Filtering—Delete the packet.

• Flooding—Forward the packet to all VLAN members

Cisco Business 250 Series Switches Administration Guide

Port Settings

Notification Interval

Administration

Enter the rate in seconds at which LLDP advertisement updates are sent, or use the default.TLV Advertise Interval

Enter the minimum time interval between SNMP notifications.Topology Change SNMP

Hold Multiplier

Enter the amount of time that LLDP packets are held before the packets are discarded, measured in multiples of the TLV Advertise Interval. For example, if the TLV Advertise Interval is 30 seconds, and the Hold Multiplier is 4, then the LLDP packets are discarded after 120 seconds.

Reinitializing Delay

Enter the time interval in seconds that passes between disabling and reinitializing LLDP, following an LLDP enable/disable cycle.

Transmit Delay

Enter the amount of time in seconds that passes between successive LLDP frame transmissions, due to changes in the LLDP local systems MIB.

Chassis ID Advertisement

Select one of the following options for advertisement in the LLDP messages:

• MAC Address—Advertise the MAC address of the device.

• Host Name—Advertise the host name of the device.

Step 3 In the LED-MED Properties Fast Start Repeat Count field, enter the number of times LLDP packets are sent when the

LLDP-MED Fast Start mechanism is initialized. This occurs when a new endpoint device links to the device. For a description of LLDP MED, refer to the LLDP MED Network Policy section.

Step 4 Click Apply. The LLDP properties are added to the Running Configuration file.

Port Settings

The LLDP Port Settings page enables LLDP and SNMP notification per port. The LLDP-MED TLVs can be configured in the LLDP MED Port Settings, on page 81.

To define the LLDP port settings, follow these steps:

Step 1 Click Administration > Discovery - LLDP > Port Settings.

This page contains the port LLDP information.

Step 2 Select a port and click Edit. Step 3 Configure the following fields:

Select the port to edit.Interface

Administrative Status

Select the LLDP publishing option for the port.

• Tx Only—Publishes but doesn’t discover.

• Rx Only—Discovers but doesn’t publish.

• Tx & Rx—Publishes and discovers.

• Disable—Indicates that LLDP is disabled on the port.

Cisco Business 250 Series Switches Administration Guide

Administration

Port Settings

Select Enable to send notifications to SNMP notification recipients.SNMP Notification

Available/Selected Optional TLVs

Select the options to be published by the device:

• Port Description—Information about the port.

• System Name—System's assigned name.

• System Description—Description of the network entity.

• System Capabilities—Primary functions of the device, and whether these functions are enabled on the device.

• 802.3 MAC-PHY—Duplex and bit rate capability and the current duplex and bit rate settings of the sending device.

• 802.3 power via MDI—Maximum power transmitted via MDI

• 802.3 Link Aggregation—Whether the link (associated with the port on which the LLDP PDU is transmitted) can be aggregated.

• 802.3 Maximum Frame Size—Maximum frame size capability of the MAC/PHY implementation

• 4-Wire Power via MDI—(relevant to PoE ports supporting 60W PoE) Proprietary Cisco TLV defined to support power over Ethernet that allows for 60 watts power (standard support is up to 30 watts).

Management Address Optional TLV

Advertisement Mode

IP Address

Selected Protocol IDs

Select one of the following ways to advertise the IP management address of the device:

• Auto Advertise—Specifies that the software automatically chooses a management address to advertise from all the IP addresses of the device. In case of multiple IP addresses, the software chooses the lowest IP address among the dynamic IP addresses. If there are no dynamic addresses, the software chooses the lowest IP address among the static IP addresses.

• None—Select this option if no advertisement mode is desired.

• Manual Advertise—Select this option and the management IP address to be advertised.

If Manual Advertise was selected, select the Management IP address from the addresses provided.

Select to advertise the PVID in the TLV.PVID

Select which VLANs will be advertised.VLAN ID

Select which protocols will be advertised.Protocol IDs

Select the protocols to be used in the Protocols IDs box and move them to the Selected Protocols ID box.

Cisco Business 250 Series Switches Administration Guide

Administration

LLDP MED Network Policy

Step 4 Enter the relevant information, and click Apply. The port settings are written to the Running Configuration file.

LLDP MED Network Policy

The LLDP-MED network policy is a related set of configuration settings for a specific real-time application such as voice, or video. A network policy, if configured, can be included in the outgoing LLDP packets to the attached LLDP media endpoint device. The media endpoint device must send its traffic as specified in the network policy it receives. For example, a policy can be created for VoIP traffic that instructs VoIP phone to:

• Send voice traffic on VLAN 10 as tagged packet and with 802.1p priority 5.

• Send voice traffic with DSCP 46.

Network policies are associated with ports by using the LLDP MED Port Settings, on page 81. An administrator can manually configure one or more network policies and the interfaces where the policies are to be sent. It is the administrator's responsibility to manually create the VLANs and their port memberships according to the network policies and their associated interfaces.

In addition, an administrator can instruct the device to automatically generate and advertise a network policy for voice application based on the voice VLAN maintained by the device. Refer the Auto Voice VLAN section for details on how the device maintains its voice VLAN.

To define an LLDP MED network policy, follow these steps:

Step 1 Click Administration > Discovery - LLDP > LLDP MED Network Policy.

This page contains previously-created network policies.

Step 2 Select Autofor LLDP-MED Network Policy for Voice Application if the device is to automatically generate and advertise

a network policy for voice application based on the voice VLAN maintained by the device.

Note

When this box is checked, you may not manually configure a voice network policy.

Step 3 Click Apply to add this setting to the Running Configuration file. Step 4 To define a new policy, click Add.

Step 5 Enter the values:

• Network Policy Number—Select the number of the policy to be created.

• Application—Select the type of application (type of traffic) for which the network policy is being defined.

• VLAN ID—Enter the VLAN ID to which the traffic must be sent.

• VLAN Type—Select whether the traffic is Tagged or Untagged.

• User Priority—Select the traffic priority applied to traffic defined by this network policy. This is the CoS value.

• DSCP Value—Select the DSCP value to associate with application data sent by neighbors. This value informs them how they must mark the application traffic they send to the device.

Step 6 Click Apply. The network policy is defined.

Cisco Business 250 Series Switches Administration Guide

Administration

LLDP MED Port Settings

Note

You must manually configure the interfaces to include the desired manually-defined network policies for the outgoing LLDP packets using the LLDP MED Port Settings.

LLDP MED Port Settings

The LLDP MED Port Settings page enables configuration of the LLDP-MED TLVs. Network policies are configured using the LLDP MED Network Policy page.

Note

If LLDP-MED Network Policy for Voice Application is Auto and Auto Voice VLAN is in operation, then the device automatically generates an LLDP-MED Network Policy for Voice Application for all the LLDP ports. LLDP-MED enabled and are members of the voice VLAN.

To configure LLDP MED on each port, proceed as follows:

Step 1 Click Administration > Discovery - LLDP > LLDP MED Port Settings.

This page displays the following LLDP MED settings for all ports :

• User-Defined Network Policy—Policies are defined for types of traffic in LLDP MED Network Policy, on page

80. The following information is displayed for the policy on the port:

• Active—Is the type of traffic active on the port.

• Application—Type of traffic for which the policy is defined.

• Location—Whether Location TLV is transmitted.

• PoE—Whether PoE-PSE TLV is transmitted.

• Inventory—Whether Inventory TLV is transmitted.

Step 2 The message at the top of the page indicates whether the generation of the LLDP MED Network Policy for the voice

application is automatic or not. Click on the link to change the mode.

Step 3 To associate additional LLDP MED TLV and/or one or more user-defined LLDP MED Network Policies to a port, select

it, and click Edit.

Step 4 Enter the parameters:

• Interface—Select the interface to configure.

• LLDP MED Status—Enable/disable LLDP MED on this port.

• SNMP Notification—Select whether SNMP notification is sent on a per-port basis when an end station that supports MED is discovered.

• Selected Optional TLVs—Select the TLVs that can be published by the device by moving them from the Available Optional TLVs list to the Selected Optional TLVs list.

Cisco Business 250 Series Switches Administration Guide

LLDP Port Status

• Selected Network Policies—Select the LLDP MED policies to be published by LLDP by moving them from the

Administration

Available Network Policies list to the Selected Network Policies list. To include one or more user-defined network

policies in the advertisement, you must also select Network Policy from the Available Optional TLVs.

Note

The following fields must be entered in hexadecimal characters in the exact data format that is defined in the LLDP-MED standard (ANSI-TIA-1057_final_for_publication.pdf):

• Location Coordinate—Enter the coordinate location to be published by LLDP.

• Location Civic Address—Enter the civic address to be published by LLDP.

• Location ECS ELIN—Enter the Emergency Call Service (ECS) ELIN location to be published by LLDP.

Step 5 Click Apply. The LLDP MED port settings are written to the Running Configuration file.

LLDP Port Status

The LLDP Port Status page contains the LLDP global information for every port.

Step 1 To view the LLDP port status, click Administration > Discovery - LLDP > LLDP PortStatus.

Information for all ports is displayed.

Step 2 Select a specific port and click LLDP Local Information Detail to see the details of the LLDP and LLDP-MED TLVs

sent out to the port.

Step 3 Select a specific port and click LLDP Neighbor Information Detail to see the details of the LLDP and LLDP-MED

TLVs received from the port.

LLDP Port Status Global Information

• Chassis ID Subtype—Type of chassis ID (for example, MAC address).

• Chassis ID—Identifier of chassis. Where the chassis ID subtype is a MAC address, the MAC address of the device appears.

• System Name—Name of device.

• System Description—Description of the device (in alpha-numeric format).

• Supported System Capabilities—Primary functions of the device, such as Bridge, WLAN AP, or Router.

• Enabled System Capabilities—Primary enabled function(s) of the device.

• Port ID Subtype—Type of the port identifier that is shown.

LLDP Port Status Table

• Interface—Port identifier.

• LLDP Status—LLDP publishing option.

• LLDP MED Status—Enabled or disabled.

Cisco Business 250 Series Switches Administration Guide

Administration

• Local PoE ((Power Type, Power Source, Power Priority, Power Value)—Local PoE information advertised.

• Remote PoE (Power Type, Power Source, Power Priority, Power Value)—PoE information advertised by the neighbor.

• # of neighbors—Number of neighbors discovered.

• Neighbor capability of 1st device—Displays the primary functions of the neighbor; for example: Bridge or Router.

LLDP Local Information

To view the LLDP local port status advertised on a port, follow these steps:

Step 1 Click Administration > Discovery - LLDP > LLDP Local Information. Step 2 Select the interface and port for which the LLDP local information is to be displayed.

LLDP Local Information

The LLDP Local Information page contains the following fields:

Global

• Chassis ID Subtype—Type of chassis ID. (For example, the MAC address.)

• Chassis ID—Identifier of chassis. Where the chassis ID subtype is a MAC address, the MAC address of the device appears.

• System Name—Name of device.

• System Description—Description of the device (in alpha-numeric format).

• Supported System Capabilities—Primary functions of the device, such as Bridge, WLAN AP, or Router.

• Enabled System Capabilities—Primary enabled function(s) of the device.

• Port ID Subtype—Type of the port identifier that is shown.

• Port ID—Identifier of port.

• Port Description—Information about the port, including manufacturer, product name and hardware/software version.

Management Address

• IPv4 Address—IPv4 returned address most appropriate for management use.

• IPv6 Global Address—IPv6 returned global address most appropriate for management use.

• IPv6 Link Local Address—IPv6 returned link local address most appropriate for management use.

MAC/PHY Details

• Auto-Negotiation Supported—Port speed auto-negotiation support status. The possible values are True and False.

• Auto-Negotiation Enabled—Port speed auto-negotiation active status. The possible values are True and False.

• Auto-Negotiation Advertised Capabilities—Port speed auto-negotiation capabilities, for example, 1000BASE-T half duplex mode, 100BASE-TX full duplex mode.

Cisco Business 250 Series Switches Administration Guide

LLDP Local Information

• Operational MAU Type—Medium Attachment Unit (MAU) type. The MAU performs physical layer functions, including digital data conversion from the Ethernet interfaces’ collision detection and bit injection into the network; for example, 100BASE-TX full duplex mode.

802.3 Details

• 802.3 Maximum Frame Size - The maximum supported IEEE 802.3 frame size.

802.3 Link Aggregation

• Aggregation Capability—Indicates whether the interface can be aggregated.

• Aggregation Status—Indicates whether the interface is aggregated.

• Aggregation Port ID—Advertised aggregated interface ID.

802.3 Energy Efficient Ethernet (EEE)

• Local Tx—Indicates the local link partner’s reflection of the remote link partner’s Tx value.

• Local Rx—Indicates the local link partner’s reflection of the remote link partner’s Rx value.

Administration

• Remote Tx Echo—Indicates the time (in micro seconds) that the transmitting link partner waits before it starts transmitting data after leaving Low Power Idle (LPI mode).

• Remote Rx Echo—Indicates the time (in micro seconds) that the receiving link partner requests that the transmitting link partner waits before transmission of data following Low Power Idle (LPI mode).

802.3 Power via MDI

• MDI Power Support Port Class—Advertised power support port class.

• PSE MDI Power Support—Indicates if MDI power is supported on the port.

• PSE MDI Power State—Indicates if MDI power is enabled on the port.

• PSE Power Pair Control Ability—Indicates if power pair control is supported on the port.

• PSE Power Pair—Power pair control type supported on the port.

• PSE Power Class—Advertised power class of the port.

• Power Type—Type of pod device connected to the port.

• Power Source—Port power source.

• Power Priority—Port power priority

• PD Requested Power Value—Amount of power allocated by the PSE to the PD.

• PSE Allocated Power Value—Amount of power allocated to the sourcing equipment (PSE).

4-Wire Power via MDI

• 4-Pair PoE Supported—Indicates system and port support enabling the 4-pair wire (true only for specific ports that have this HW ability).

• Spare Pair Detection/Classification Required—Indicates that the 4-pair wire is needed.

• PD Spare Pair Desired State—Indicates a pod device requesting to enable the 4-pair ability.

Cisco Business 250 Series Switches Administration Guide

Administration

MED Details

LLDP Local Information

• PD Spare Pair Operational State—Indicates if the 4-pair ability is enabled or disabled.

• Capabilities Supported—MED capabilities enabled on the port.

• Current Capabilities—MED TLVs advertised by the port.

• Device Class—LLDP-MED endpoint device class. The possible device classes are:

• Endpoint Class 1—Indicates a generic endpoint class, offering basic LLDP services.

• Endpoint Class 2—Indicates a media endpoint class, offering media streaming capabilities as well as all Class 1 features.

• Endpoint Class 3—Indicates a communications device class, offering all Class 1 and Class 2 features plus location, 911, Layer 2 switch support and device information management capabilities.

• PoE Device Type—Port PoE type, for example, PD/PSE.

• PoE Power Source—Port’s power source.

• PoE Power Priority—Port’s power priority.

• PoE Power Value—Port’s power value.

• Hardware Revision –Hardware version.

• Firmware Revision—Firmware version.

• Software Revision—Software version.

• Serial Number—Device serial number.

• Manufacturer Name—Device manufacturer name.

• Model Name—Device model name.

• Asset ID—Asset ID.

Location Information

Enter the following data structures in hexadecimal as described in section 10.2.4 of the ANSI-TIA-1057 standard:

• Civic—Civic or street address.

• Coordinates—Location map coordinates—latitude, longitude, and altitude.

• ECS ELIN—Device’s Emergency Call Service (ECS) Emergency Location Identification Number (ELIN).

Network Policy Table

• Application Type—Network policy application type, for example, Voice.

• VLAN ID—VLAN ID for which the network policy is defined.

• VLAN Type—VLAN type, Tagged or Untagged, for which the network policy is defined.

• User Priority—Network policy user priority.

Cisco Business 250 Series Switches Administration Guide

LLDP Neighbor Information

• DSCP—Network policy DSCP.

LLDP Neighbor Information

The LLDP Neighbor Information page contains information that was received from neighboring devices. After timeout (based on the value received from the neighbor Time To Live TLV during which no LLDP PDU was received from a neighbor), the information is deleted.

To view the LLDP neighbors information, follow these steps:

Step 1 Click Administration > Discovery - LLDP > LLDP Neighbor Information.

Step 2 Select the interface for which LLDP neighbor information is to be displayed.

This page displays the following fields for the selected interface:

• Local Port—Number of the local port to which the neighbor is connected.

Administration

• Chassis ID Subtype—Type of chassis ID (for example, MAC address).

• Chassis ID—Identifier of the 802 LAN neighboring device's chassis.

• Port ID Subtype—Type of the port identifier that is shown.

• Port ID—Identifier of port.

• System Name—Published name of the device.

• Time to Live—Time interval (in seconds) after which the information for this neighbor is deleted.

Step 3 Select a local port, and click Details.

The LLDP Neighbor Information page contains the following fields:

Port Details

• Local Port—Port number.

• MSAP Entry—Device Media Service Access Point (MSAP) entry number.

Basic Details

• Chassis ID Subtype—Type of chassis ID (for example, MAC address).

• Chassis ID—Identifier of the 802 LAN neighboring device chassis.

• Port ID Subtype—Type of the port identifier that is shown.

• Port ID—Identifier of port.

• Port Description—Information about the port, including manufacturer, product name and hardware/software version.

• System Name—Name of system that is published.

Cisco Business 250 Series Switches Administration Guide

Administration

Management Address Table

MAC/PHY Details

LLDP Neighbor Information

• System Description—Description of the network entity (in alpha-numeric format). This includes the system name and versions of the hardware, operating system, and networking software supported by the device. The value equals the sysDescr object.

• Supported System Capabilities—Primary functions of the device. The capabilities are indicated by two octets. Bits 0 through 7 indicate Other, Repeater, Bridge, WLAN AP, Router, Telephone, DOCSIS cable device, and station, respectively. Bits 8 through 15 are reserved.

• Enabled System Capabilities—Primary enabled function(s) of the device.

• Address Subtype—Managed address subtype; for example, MAC or IPv4.

• Address—Managed address.

• Interface Subtype—Port subtype.

• Interface Number—Port number.

• Auto-Negotiation Supported—Port speed auto-negotiation support status. The possible values are True and False.

• Auto-Negotiation Enabled—Port speed auto-negotiation active status. The possible values are True and False.

• Auto-Negotiation Advertised Capabilities—Port speed auto-negotiation capabilities, for example, 1000BASE-T half duplex mode, 100BASE-TX full duplex mode.

802.3 Power via MDI

• MDI Power Support Port Class—Advertised power support port class.

• PSE MDI Power Support—Indicates if MDI power is supported on the port.

• PSE MDI Power State—Indicates if MDI power is enabled on the port.

• PSE Power Pair Control Ability—Indicates if power pair control is supported on the port.

• PSE Power Pair—Power pair control type supported on the port.

• PSE Power Class—Advertised power class of the port.

• Power Type—Type of pod device connected to the port.

• Power Source— Port power source.

• Power Priority—Port power priority.

• PD Requested Power Value—Amount of power requested by the pod device.

• PSE Allocated Power Value—Amount of power allocated by the PSE to the PD.

4-Wire Power via MDI

Cisco Business 250 Series Switches Administration Guide

LLDP Neighbor Information

• 4-Pair PoE Supported—Indicates system and port support enabling the 4-pair wire (true only for specific ports that have this HW ability).

• Spare Pair Detection/Classification Required—Indicates that the 4-pair wire is needed.

• PD Spare Pair Desired State—Indicates a pod device requesting to enable the 4-pair ability.

• PD Spare Pair Operational State—Indicates if the 4-pair ability is enabled or disabled.

802.3 Details

• 802.3 Maximum Frame Size—Advertised maximum frame size that is supported on the port.

802.3 Link Aggregation

• Aggregation Capability—Indicates if the port can be aggregated.

• Aggregation Status—Indicates if the port is currently aggregated.

• Aggregation Port ID—Advertised aggregated port ID.

802.3 Energy Efficient Ethernet (EEE)

Administration

• Remote Tx—Indicates the time (in micro seconds) that the transmitting link partner waits before it starts transmitting data after leaving Low Power Idle (LPI mode).

• Remote Rx—Indicates the time (in micro seconds) that the receiving link partner requests that the transmitting link partner waits before transmission of data following Low Power Idle (LPI mode).

• Local Tx Echo—Indicates the local link partner’s reflection of the remote link partner’s Tx value.

• Local Rx Echo—Indicates the local link partner’s reflection of the remote link partner’s Rx value.

MED Details

• Capabilities Supported—MED capabilities enabled on the port.

• Current Capabilities—MED TLVs advertised by the port.

• Device Class—LLDP-MED endpoint device class. The possible device classes are:

• Endpoint Class 1—Indicates a generic endpoint class, offering basic LLDP services.

• Endpoint Class 2—Indicates a media endpoint class, offering media streaming capabilities as well as all Class 1 features.

• Endpoint Class 3—Indicates a communications device class, offering all Class 1 and Class 2 features plus location, 911, Layer 2 switch support and device information management capabilities.

• PoE Device Type—Port PoE type, for example, PD/PSE.

• PoE Power Source—Port’s power source.

• PoE Power Priority—Port’s power priority.

• PoE Power Value—Port’s power value.

• Hardware Revision –Hardware version.

• Firmware Revision—Firmware version.

Cisco Business 250 Series Switches Administration Guide

Administration

802.1 VLAN and Protocol

PPVID Table

LLDP Neighbor Information

• Software Revision—Software version.

• Serial Number—Device serial number.

• Manufacturer Name—Device manufacturer name.

• Model Name—Device model name.

• Asset ID—Asset ID.

• PVID—Advertised port VLAN ID.

• VID—Protocol VLAN ID.

• Supported—Supported Port and Protocol VLAN IDs.

• Enabled—Enabled Port and Protocol VLAN IDs.

VLAN ID Table

• VID—Port and Protocol VLAN ID.

• VLAN Name—Advertised VLAN names.

Protocol ID Table

• Protocol ID—Advertised protocol IDs.

Location Information

Enter the following data structures in hexadecimal as described in section 10.2.4 of the ANSI-TIA-1057 standard:

• Civic—Civic or street address.

• Coordinates—Location map coordinates—latitude, longitude, and altitude.

• ECS ELIN—Device’s Emergency Call Service (ECS) Emergency Location Identification Number (ELIN).

• Unknown—Unknown location information.

Network Policy Table

• Application Type—Network policy application type, for example, Voice.

• VLAN ID—VLAN ID for which the network policy is defined.

• VLAN Type—VLAN type, Tagged or Untagged, for which the network policy is defined.

• User Priority—Network policy user priority.

• DSCP—Network policy DSCP.

Cisco Business 250 Series Switches Administration Guide

LLDP Statistics

The LLDP Statistics page displays LLDP statistical information per port.

To view the LLDP statistics, follow these steps:

Step 1 Click Administration > Discovery - LLDP > LLDP Statistics.

For each port, the fields are displayed:

• Interface—Identifier of interface.

• Tx Frames (Total)—Number of transmitted frames.

• Rx Frames

• Total—Number of received frames

• Discarded—Total number of received frames that discarded

• Errors—Total number of received frames with errors

Administration

• Rx TLVs

• Discarded—Total number of received TLVs that discarded

• Unrecognized—Total number of received TLVs that unrecognized.

• Neighbor's Information Deletion Count—Number of neighbor ageouts on the interface.

Step 2 Click Refresh to view the latest statistics.

LLDP Overloading

LLDP adds information as LLDP and LLDP-MED TLVs into the LLDP packets. LLDP overload occurs when the total amount of information to be included in an LLDP packet exceeds the maximum PDU size supported by an interface.

The LLDP Overloading page displays the number of bytes of LLDP/LLDP-MED information, the number of available bytes, and the overloading status of every interface.

To view LLDP overloading information:

Step 1 Click Administration > Discovery - LLDP > LLDP Overloading.

In the LLDP Overloading Table, the following information is displayed for each port:

• Interface—Port identifier.

• Total Bytes In-Use—Total number of bytes of LLDP information in each packet

• Available Bytes Left—Total amount of available bytes left for other LLDP information in each packet.

• Status—Whether TLVs are being transmitted or if they are overloaded.

Cisco Business 250 Series Switches Administration Guide

Administration

Step 2 To view the overloading details for a port, select it and click Details.

This page contains the following information for each TLV sent on the port:

• LLDP Mandatory TLVs

• Size (Bytes)—Total mandatory TLV byte size

• Status—If the mandatory TLV group is being transmitted, or if the TLV group was overloaded.

• LLDP MED Capabilities

• Size (Bytes)—Total LLDP MED capabilities packets byte size

• Status—If the LLDP MED capabilities packets sent, or if they overloaded.

• LLDP MED Location

• Size (Bytes)—Total LLDP MED location packets byte size

• Status—If the LLDP MED locations packets sent, or if they overloaded.

LLDP Overloading

• LLDP MED Network Policy

• Size (Bytes)—Total LLDP MED network policies packets byte size

• Status—If the LLDP MED network policies packets sent, or if they overloaded.

• LLDP MED Extended Power via MDI

• Size (Bytes)—Total LLDP MED extended power via MDI packets byte size.

• Status—If the LLDP MED extended power via MDI packets sent, or if they overloaded.

• 802.3 TLVs

• Size (Bytes)—Total LLDP MED 802.3 TLVs packets byte size.

• Status—If the LLDP MED 802.3 TLVs packets sent, or if they overloaded.

• LLDP Optional TLVs

• Size (Bytes)—Total LLDP MED optional TLVs packets byte size.

• Status—If the LLDP MED optional TLVs packets sent, or if they overloaded.

• LLDP MED Inventory

• Size (Bytes)—Total LLDP MED inventory TLVs packets byte size.

• Status—If the LLDP MED inventory packets sent, or if they overloaded.

• Total

• Total (Bytes)—Total number of bytes of LLDP information in each packet.

Cisco Business 250 Series Switches Administration Guide

Discovery - CDP

• Available Bytes Left—Total number of available bytes left to send for additional LLDP information in each packet.

Discovery - CDP

Cisco Discovery Protocol is a Layer 2, media-independent, and network-independent protocol that networking applications use to learn about nearby, directly connected devices. Cisco Discovery Protocol is enabled by default. Each device configured for Cisco Discovery Protocol advertises at least one address at which the device can receive messages and sends periodic advertisements (messages) to the well-known multicast address 01:00:0C:CC:CC:CC. Devices discover each other by listening at that address. They also listen to messages to learn when interfaces on other devices are up or go down.

Advertisements contain time-to-live information, which indicates the length of time a receiving device should hold Cisco Discovery Protocol information before discarding it. Advertisements supported and configured in Cisco software are sent, by default, every 60 seconds on interfaces that support Subnetwork Access Protocol (SNAP) headers. Cisco devices never forward Cisco Discovery Protocol packets. Cisco devices that support Cisco Discovery Protocol store the information received in a table. Information in this table is refreshed every time an advertisement is received, and information about a device is discarded after three advertisements from that device are missed.

Administration

This section describes how to configure CDP.

Properties

Similar to LLDP, the Cisco Discovery Protocol (CDP) is a link layer protocol for directlyconnected neighbors to advertise themselves and their capabilities to each other. Unlike LLDP, CDP is a Cisco proprietary protocol.To configure the CDP properties, complete the following steps:

Step 1 Click Administration > Discovery - CDP > Properties.

Step 2 Enter the parameters.

Select to enable CDP on the device.CDP Status

CDP Frames Handling

CDP Voice VLAN Advertisement

CDP Mandatory TLVs Validation

If CDP is not enabled, select the action to be taken if a packet that matches the selected criteria is received:

Select to enable the device to advertise the voice VLAN in CDP on all of the ports that are CDP enabled, and are member of the voice VLAN. The voice VLAN is configured in the Properties, on page 128.

If selected, incoming CDP packets not containing the mandatory TLVs are discarded and the invalid error counter is incremented.

Select the version of CDP to use.CDP Version

Cisco Business 250 Series Switches Administration Guide

Administration

Interface Settings

CDP Hold Time

CDP Transmission Rate

Device ID Format

Source Interface

Amount of time that CDP packets are held before the packets are discarded, measured in multiples of the TLV Advertise Interval. For example, if the TLV Advertise Interval is 30 seconds, and the Hold Multiplier is 4, then the LLDP packets are discarded after 120 seconds. The following options are possible:

• Use Default—Use the default time (180 seconds)

• User Defined—Enter the time in seconds.

The rate in seconds at which CDP advertisement updates are sent. The following options are possible:

• Use Default—Use the default rate (60 seconds)

• User Defined—Enter the rate in seconds.

Select the format of the device ID (MAC address or serial number). The following options are possible:

• Use Default—Use the default rate (60 seconds)

• User Defined—Enter the rate in seconds.

IP address to be used in the TLV of the frames. The following options are possible:

• Use Default—Use the IP address of the outgoing interface.

• User Defined—Use the IP address of the interface (in the Interface field) in the address TLV.

IF User Defined was selected for Source Interface, select the interface.Interface

Syslog Voice VLAN Mismatch

Check to send a SYSLOG message when a voice VLAN mismatch is detected. This means that the voice VLAN information in the incoming frame does not match what the local device is advertising.

Syslog Native VLAN Mismatch

Check to send a SYSLOG message when a native VLAN mismatch is detected. This means that the native VLAN information in the incoming frame does not match what the local device is advertising.

Syslog Duplex Mismatch

Check to send a SYSLOG message when duplex information is mismatched. This means that the duplex information in the incoming frame does not match what the local device is advertising.

Step 3 Click Apply. The LLDP properties are defined.

Interface Settings

The Interface Settings page enables you to enable/disable CDP per port. By setting these properties, it’s possible to select the types of information to be provided to devices that support the LLDP protocol.

The LLDP-MED TLVs to be advertised can be selected in the LLDP MED Port Settings, on page 81.

Cisco Business 250 Series Switches Administration Guide

CDP Local Information

To define the CDP interface settings:

Step 1 Click Administration > Discovery - CDP > Interface Settings.

This page displays the following CDP information for each interface.

• CDP Status—CDP publishing option for the port.

• Reporting Conflicts with CDP Neighbors—Status of the reporting options that are enabled/disabled in the Edit page (Voice VLAN/Native VLAN/Duplex).

• No. of Neighbors—Number of neighbors detected.

The bottom of the page has four buttons:

• Copy Settings—Select to copy a configuration from one port to another.

• Edit—Fields explained in Step 2 below.

• CDP Local Information Details—Takes you to the CDP Local Information, on page 94 .

• CDP Neighbor Information Details—Takes you to the CDP Neighbors Information, on page 96.

Administration

Step 2 Select a port and click Edit.

This page provides the following fields:

• Interface—Select the interface to be defined.

• CDP Status—Select to enable/disable the CDP publishing option for the port.

Note

The next three fields are operational when the device has been set up to send traps to the management station.

• Syslog Voice VLAN Mismatch—Select to enable sending a SYSLOG message when a voice VLAN mismatch is detected. This means that the voice VLAN information in the incoming frame doesn’t match what the local device is advertising.

• Syslog Native VLAN Mismatch—Select to enable sending a SYSLOG message when a native VLAN mismatch is detected. This means that the native VLAN information in the incoming frame doesn’t match what the local device is advertising.

• Syslog Duplex Mismatch—Select to enable sending a SYSLOG message when duplex information mismatch is detected. This means that the duplex information in the incoming frame doesn’t match what the local device is advertising.

Step 3 Enter the relevant information, and click Apply. The port settings are written to the Running Configuration.

CDP Local Information

To view information that is advertised by the CDP protocol about the local device:

Click Administration > Discovery - CDP > CDP Local Information. The following fields are displayed:

Cisco Business 250 Series Switches Administration Guide

Administration

CDP Local Information

Number of the local port.Interface

Displays whether CDP is enabled or not.CDP State

Device ID TLV

Appliance TLV

• Device ID Type—Type of the device ID advertised in the device ID TLV

• Device ID—Device ID advertised in the device ID TLV

System Name—System name of the device.System Name TLV

Address1-3—IP addresses (advertised in the device address TLV).Address TLV

Port ID—Identifier of port advertised in the port TLV.Port TLV

Identifier of port advertised in the port TLV.Port ID

Capabilities—Capabilities advertised in the port TLV).Capabilities TLV

Version—Information about the software release on which the device is running.Version TLV

Platform—Identifier of platform advertised in the platform TLV.Platform TLV

Native VLAN—The native VLAN identifier advertised in the native VLAN TLV.Native VLAN TLV

Duplex—Whether port is half or full-duplex advertised in the full/half duplex TLV.Full/Half Duplex TLV

• Appliance ID—Type of device attached to port advertised in the appliance TLV

• Appliance VLAN ID—VLAN on the device used by the appliance, for instance if the appliance is an IP phone, this is the voice VLAN.

Extended Trust TLV

CoS for Untrusted Ports TLV

Extended Trust—Enabled indicates that the port is trusted, and the packets received are marked. In this case, packets received on such a port aren’t re-marked. Disabled indicates that the port isn’t trusted in which case, the following field is relevant.

CoS for Untrusted Ports—If Extended Trust is disabled on the port, this field displays the Layer 2 CoS value, meaning, an 802.1D/802.1p priority value. This is the COS value with which all packets received on an untrusted port are remarked by the device.

Cisco Business 250 Series Switches Administration Guide

CDP Neighbors Information

Administration

Power Available TLV

4-Wire Power via MDI TLV

• Request ID—Last power request ID received echoes the Request-ID field last received in a Power Requested TLV. It’s 0 if no Power Requested TLV was received since the interface last transitioned to Up.

• Power Management ID—Value incremented by 1 (or 2, to avoid 0) each time any one of the following events occurs:

Available-Power or Management Power Level change

A Power Requested TLV is received with a Request-ID that is different from the last-received set.

The interface transitions to Down.

• Available Power—Amount of power consumed by port

• Management Power Level—Displays the supplier's request to the pod device for its Power Consumption TLV. The device always displays “No Preference” in this field.

Displays whether this TLV is supported.

• 4-Pair PoE Supported—Displays whether PoE is supported.

• Spare Pair Detection/Classification Required—Displays whether this classification is required.

• PD Spare Pair Desired State—Displays the PD spare pair desired state.

• PD Spare Pair Operational State—Displays the PSE spare pair state.

CDP Neighbors Information

The CDP Neighbors Information page displays CDP information received from neighboring devices.

Information is deleted, after timeout (based on the value received from Time To Live TLV during which no CDP PDU was received).

To view the CDP neighbors information, proceed as follows:

Step 1 Click Administration > Discovery - CDP > CDP Neighbor Information. Step 2 To select a filter, check the Filter checkbox, select a Local interface, and click Go.

The filter is applied on the list, and Clear Filter is activated to enable stopping the filter.

The CDP Neighbor Information page contains the following fields for the link partner (neighbor):

Neighbors device ID.Device ID

Neighbors system name.System Name

Number of the local port to which the neighbor is connected.Local Interface

CDP protocol version.Advertisement Version

Cisco Business 250 Series Switches Administration Guide

Administration

Time interval (in seconds) after which the information for this neighbor is deleted.Time to Live

Capabilities advertised by neighbor.Capabilities

Information from Platform TLV of neighbor.Platform

Outgoing interface of the neighbor.Neighbor Interface

Step 3 Select a device, and click Details.

This page contains the following fields about the neighbor (actual field display depends on what the neighbor is advertising):

Neighbors device ID.Device ID

Neighbors system name.System Name

Number of the local port to which the neighbor is connected.Local Interface

CDP protocol version.Advertisement Version

Time interval (in seconds) after which the information for this neighbor is deleted.Time to Live (sec)

CDP Neighbors Information

Power Request

Capabilities advertised by neighbor.Capabilities

Information from Platform TLV of neighbor.Platform

Outgoing interface of the neighbor.Neighbor Interface

Neighbors native VLAN.Native VLAN

Whether neighbors interface is half or full-duplex.Duplex

Neighbors addresses.Addresses

Amount of power consumed by neighbor on the interface.Power Drawn

Neighbors software version.Version

Power requested by PD that is connected to the port.

• Power Request List—Each PD may send a list (up to 3) of supported power levels.

Shown if a PSE is connected to the port.Power Available

Note

Disconnects on the Clear Table button all connected devices if from CDP, and if Auto Smartport is enabled change all port types to default.

Cisco Business 250 Series Switches Administration Guide

CDP Statistics

The CDP Statistics page displays information regarding CDP frames that sent or received from a port. CDP packets are received from devices attached to the switches interfaces, and are used for the Smartport feature.

To view CDP statistics, follow these steps:

Step 1 Click Administration > Discovery - CDP > CDP Statistics.

The following fields are displayed for every interface:

Packets Received/Packets Transmitted:

• Version 1—Number of CDP version 1 packets received/transmitted.

• Version 2—Number of CDP version 2 packets received/transmitted.

• Total—Total number of CDP packets received/transmitted.

CDP Error Statistics:

• Illegal Checksum—Number of packets received with illegal checksum value.

Administration

• Other Errors—Number of packets received with errors other than illegal checksums.

• Neighbors Over Maximum—Number of times that packet information couldn’t be stored in cache because of lack of room.

Step 2 To clear all counters on all interfaces, click ClearAll Interface Counters. To clear all counters on an interface, select

it and click Clear Interface Counters.

Locate Device

This feature enables flashing all network port LEDs on a specific device in the network to locate the device physically. This feature is useful for locating a device within a room with many interconnected devices. When this feature is activated, all network port LEDs on the device flash for a configured duration (one minute by default).

Step 1 Click Administration > Locate Device.

Step 2 Enter values in the following fields:

• Duration—Enter for how long (in seconds) the port’s LEDs flash.

• Remaining Time—This field is only displayed if the feature is currently activated. It displays the remaining time during which the LED flashes.

Step 3 Click Start to activate the feature.

Cisco Business 250 Series Switches Administration Guide

Cisco CBS250-8P-E-2G, CBS250-16P-2G Manual [EN]

Specifications and Main Features

Frequently Asked Questions

User Manual

Cisco Business 250 Series Switches Administration Guide

Get To Know Your Switch

Introduction

Rack Mounting Switch

Wall Mounting a Switch

Wall Mount an 8 Port Switch

Power over Ethernet Considerations

Front Panel

Front Panel LEDs

Configuring Switches

Configuring Your Switch Using the Web-based Interface

Configuring Your Switch Using the Console Port

Restoring Factory Default Settings

Navigation

Basic or Advanced Display Mode

Getting Started

Getting Started

Dashboard

Dashboard

Configuration Wizards

Getting Started Wizard

VLAN Configuration Wizard

ACL Configuration Wizard

Search

Search

Status and Statistics

System Summary

System Information

Software Information

TCP/UDP Services Status

PoE Power Information on Device Supporting PoE

CPU Utilization

Port Utilization

Interface

Etherlike

GVRP

802.1X EAP

Hardware Resource Utilization

Health and Power

SPAN

SPAN Session Destinations

SPAN Session Sources

Diagnostics

Copper Test

Optical Module Status

Tech-Support Information

RMON

Statistics

RMON History

RMON Events

Alarms

View Log

RAM Memory

Flash Memory

Administration

System Settings

Console Settings

User Accounts

Idle Session Timeout

Time Settings

System Time

SNTP Unicast

SNTP Multicast/Anycast

SNTP Authentication

Time Range

Recurring Time Range

System Log

Log Settings

Remote Logging Settings

File Management

Firmware Operations

File Operations

File Directory

DHCP Auto Update

Cisco Business Dashboard Settings

Plug-n-Play (PNP)
