Overview of the Router

The Cisco 1900 Series Integrated Services Routers (ISRs) are modular routers with LAN and WAN connections that can be configured by means of interchangeable interface cards and internal service modules (ISMs). The series currently consists of the 1905, 1921, 1941, and 1941W (wireless) models. The 1941W is Wi-Fi CERTIFIED™ and 802.11a/b/g/n-compliant. The modular design of the routers provides flexibility, allowing you to configure your router according to your needs.

This ISR series has new slots that support next generation Enhanced High-Speed WAN Interface Cards (EHWICs), Internal Services Modules (ISMs, 1941 only), and 2 CompactFlash cards (1941 only). Universal serial bus (USB) ports are available for USB devices, and a USB mini Type-B serial console port is available in addition to the RJ-45 console connector.

This chapter provides an overview of the Cisco 1900 series routers and includes the following sections:

• Safety Warnings, page 1-1

• Chassis Views, page 1-2

• Hardware Features, page 1-6

• Interface Numbering, page 1-14

• Specifications, page 1-14

• Regulatory Compliance, page 1-18

Safety Warnings

Warning

IMPORTANT SAFETY INSTRUCTIONS

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. Use the statement number provided at the end of each warning to locate its translation in the translated safety warnings that accompanied this device.

Statement 1071

SAVE THESE INSTRUCTIONS

Ultimate disposal of this product should be handled according to all national laws and regulations.

Statement 1040

OL-19084-02

Cisco 1900 Series Hardware Installation

1-1

Chassis Views

Chapter 1 Overview of the Router

Warning

No user-serviceable parts inside. Do not open.

Only trained and qualified personnel should be allowed to install, replace, or service this equipment.

Statement 1030

Statement 1073

Safety Warnings for Finland, Norway and Sweden

Warning statement 1017 applies to the countries of Finland, Norway, and Sweden.

Warning

This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

Statement 1017

Chassis Views

This section contains views of the front and rear panels of Cisco 1900 series routers, showing the locations of the power and signal interfaces, the interface card slots, and the status indicators.

Figure 1-1 shows the front panel of the Cisco 1905 and Cisco 1921 router. Figure 1-2 shows the back

panel connectors on the Cisco 1905 and Cisco 1921 router. Figure 1-3 shows the front panel of a Cisco 1941 wireless router and Figure 1-4 shows the LEDs of the Cisco 1941 router. Figure 1-5 shows the back panel connectors on the Cisco 1941 router.

Caution Power off the router and the power over Ethernet (PoE) before installing an EHWIC in the Cisco 1905

and Cisco 1921 ISRs.

Cisco 1900 Series Hardware Installation

1-2

OL-19084-02

Chapter 1 Overview of the Router

Cisco 1900 Series

SYS

ACT POE

253707

1

2

3

Figure 1-1shows the front panel of the Cisco 1905 and Cisco 1921 router and LED names.

Figure 1-1 Front Panel of the Cisco 1905, and Cisco 1921 Router

1 SYS 2 ACT 3 PoE

1.Power over Ethernet (PoE) is available with optional external PoE power supply.

2. Power off the PoE before installing an EHWIC in the Cisco 1905 and Cisco 1921 ISRs.

Chassis Views

12

Caution Power off the PoE before installing an EHWIC in the Cisco 1905 and Cisco 1921 ISRs.

Figure 1-2 shows the back panel of the Cisco 1905 and Cisco 1921 with ports and LEDs.

Figure 1-2 Back Panel of the Cisco 1905 and Cisco 1921 Router (1921 shown)

1

EHWIC 1

FLASH

EHWIC (HWIC, WIC, or VWIC1) slots 0 and 1—slot 0 (Right), slot 1 (Left), or

1

double wide

2345

EHWIC 0

EN

161718

4

3

2

EN

CONSOLE

5 6

GE 0/1

AUX

S

L

S

L

GE 0/0

7

8

EN (Enable RJ-45 console)

2

9

BAUD

RESET

15

10

POE

53VDC 1.5A

11

12

13

3 RJ-45 serial console port 4 AUX port 5 GE 0/1 6 GE 0/0 7 S (Speed) 8 L (Link) 9 USB port—USB 2.0 Type-A port 10 KensingtonTM security slot 11 PoE

6

12 Ground connector 13 On/Off switch 14 Input power connection 15 Baud reset 16 USB serial port—USB 5-pin mini USB Type-B 17 EN (Enable USB console) 18 Flash

1. VWIC support is for data only.

2. Double-wide slot on the 1921 only.

3. The 1905 slot 0 (Right) comes with a permanently installed interface card. Only slot 1 (Left) is available.

14

Cisco 1921

100-240 V~ 50-60 Hz 1A

253708

OL-19084-02

Cisco 1900 Series Hardware Installation

1-3

Chassis Views

GHz

SYS ACT POE WLAN

2.4

5

1

2

3 4

250995

5

Cisco 1900 Series

Chapter 1 Overview of the Router

4. Only 1 EHWIC Gigabit Ethernet Switch can be installed in a 1905 or 1921.

5. See Module Support on Cisco’s Integrated Services Routers Generation 2 http://cisco.com/en/US/prod/collateral/routers/ps10538/aag_c07_563807.pdf for supported modules.

6. Power off the PoE before installing an EHWIC in the Cisco 1905 and Cisco 1921 ISRs.

Figure 1-3 shows the front panel of a Cisco 1941 wireless router with antennas mounted.

Note The Cisco 1905 comes with a permanently installed EHWIC in slot 0 (Right).

Figure 1-3 Front Panel of the Cisco 1941W Router

1

2

ACT POE WLAN

2.4

5

GHz

2 LEDs

2

Cisco 1900 Series

1 Antenna mounts

SYS

1

1. The antenna mounts are not available on the non-wireless models.

2. Some LEDs are not available on the non-wireless models.

Figure 1-4 shows the front panel of the Cisco 1941W (without antennas) with the LED names.

Figure 1-4 Cisco 1941 and Cisco 1941W Router LEDs

251372

Cisco 1900 Series Hardware Installation

1-4

OL-19084-02

Chapter 1 Overview of the Router

DO NOT REMOVE DURING NETWORK OPERATION DO NOT REMOVE DURING NETWORK OPERATION

273452

eHWIC 0

eHWIC 1

1516 38

7 6 5 4 2

2220

10111214

17 18 19 21

13

1

9

1 SYS 2 ACT 3 PoE 4 WLAN 5 2.4 or 5 GHz

Figure 1-5 shows the Cisco 1941 and 1941W back panel with ports and LEDs.

Figure 1-5 Back Panel of the Cisco 1941 and Cisco 1941W Router

Chassis Views

USB ports—two USB 2.0 Type-A ports (USB 0=Bottom)

1 3 GE 0/1 4 S (Speed) 5 RJ-45 serial console port 6 EN (Enable RJ-45 console)

USB serial port—USB 5-pin mini USB Type-B

7 9 HWIC slot 0 (EHWIC, HWIC, WIC, or

VWIC1)—single wide

2

11 CF 0 12 CompactFlash 0 13 HWIC slot 1 (EHWIC, HWIC, or

WIC)—double wide

4

15 CompactFlash 1 16 KensingtonTM security slot 17 On/Off switch 18 Input power connection 19 AUX port 20 S (Speed) 21 GE 0/0 22 L (Link)

1. VWIC support is for data only.

2. See Module Support on Cisco’s Integrated Services Routers Generation 2 http://cisco.com/en/US/prod/collateral/routers/ps10538/aag_c07_563807.pdf for supported modules.

3. Internal Service Module (ISM).

4. The double-wide slot can accommodate a single wide EHWIC, HWIC, WIC, or VWIC (data only), on the left side of the slot.

L (Link)

2

EN (Enable USB console)

8 10 ISM3 or WLAN

14 CF 1

OL-19084-02

Cisco 1900 Series Hardware Installation

1-5

Hardware Features

This section describes the basic features of Cisco 1900 series routers. It contains the following:

• Product Serial Number Location

• Built-In Interfaces, page 1-8

• Removable, Interchangeable, and Optional Modules, page 1-8

• Memory, page 1-9

• LED Indicators, page 1-10

• Chassis Ventilation, page 1-12

• Real-Time Clock, page 1-12

• Chassis Security, page 1-13

• Wireless LAN Connectivity, page 1-13

• Baud Reset Button

Chapter 1 Overview of the Router

Product Serial Number Location

The serial number and common language equipment identifier (CLEI) label for the Cisco 1905 and Cisco 1921 router is located on the rear of the chassis. (See Cisco 1905 and Cisco 1921 series routers is located on the bottom of the chassis. (See Figure 1-8.) The serial number label for the Cisco 1940 series routers is located on the rear of the chassis on a pull-out tab. (See

Figure 1-6 Serial Number and CLEI Location on Cisco 1905 and Cisco 1921 Routers

1 Common Language Equipment Identifier

1

(CLEI)

Figure 1-8.)

EHWIC 1

FLASH

EHWIC 0

EN

CONSOLE

Figure 1-6.) The product ID (PID) label for the

AUX

S

GE 0/1

L

POE

BAUD

S

GE 0/0

RESET

L

48VDC 1.67A

Cisco 1905

100-240 V~ 50-60 Hz 1A

253895

2

2 Serial Number (SN)

Cisco 1900 Series Hardware Installation

1-6

OL-19084-02

Chapter 1 Overview of the Router

DO NOT REMOVE DURING

NETWORK OPERATION

DO NOT REMOVE DURING

NETWORK OPERATION

251370

1

4

3

2

OVE DURING K OPERATION

Figure 1-7 PID and Compliance Label on Cisco 1905 and Cisco 1921 Routers

2

1

Hardware Features

100-240 V~ 50-60 Hz 1A

Cisco 1905

POE

48VDC 1.67A

RESET

BAUD

CONSOLE

GE 0/0

L

S

L

S

GE 0/1

EN

AUX

EN

FLASH

EHWIC 1 EHWIC 0

1 Product ID (PID) 2 Compliance label

Figure 1-8 Serial Number, PID/VID, and CLEI Number Location on Cisco 1940 Series Routers

253911

1 Product ID (PID) 2 Serial Number (SN) 3 Product ID/Version ID (PID/VID) 4 Common Language Equipment Identifier

OL-19084-02

Note The serial number for Cisco 1900 series routers is 11 characters long.

(CLEI)

Cisco 1900 Series Hardware Installation

1-7

Hardware Features

Cisco Product Identification Tool

The Cisco Product Identification (CPI) tool provides detailed illustrations and descriptions showing where to locate serial number labels on Cisco products. It includes the following features:

• A search option that allows browsing for models using a tree-structured product hierarchy

• A search field on the final results page making it easier to look up multiple products

• End-of-sale products are clearly identified in results lists

The tool streamlines the process of locating serial number labels and identifying products. Serial number information expedites the entitlement process and is important for access to support services.

The Cisco Product Identification tool can be accessed at the following URL:

http://tools.cisco.com/Support/CPI/index.do

Built-In Interfaces

Table describes the interfaces available on the Cisco 1900 series routers.

Chapter 1 Overview of the Router

Note Either the RJ-45 console port or USB console port may be used. They can not both be used at the same

time.

Ta b l e 1-1 Interfaces Available on the Cisco 1900 Series Routers

Interface Description

Gigabit Ethernet (GE) Two GE ports (RJ-45 connectors).

RJ-45 Console One console port (RJ-45 connector).

Auxiliary One auxiliary port (RJ-45 connectors).

USB console In addition to the RJ-45 Console port, the Cisco 1900 ISRs have a USB

5-pin mini Type-B port. When first connecting to this port, a USB driver must be installed. You will be prompted to install the driver. Simply follow the installation prompts to install the driver.

USB Two USB 2.0 Type-A compliant ports;1940 series. One USB 2.0 Type-A

compliant port; 1905 and1921.These ports are backward compatible with USB1.1 devices. The USB port provides connection for USB devices such as security tokens and flash memory.

Removable, Interchangeable, and Optional Modules

Some modules can be installed either by inserting them into slots on the chassis, or by opening the chassis and plugging them into connectors inside. The WLAN is factory installed.

• CompactFlash memory and enhanced high-speed WAN interface cards (EHWICs) fit into slots on

the Cisco 1940 series chassis, and can be installed or removed without opening the chassis.

• A connector inside the Cisco 1940 series chassis accommodates an optional field installable Internal

Service Module (ISM). See Installing and

Series ISRs

Upgrading Internal Modules and FRUs in Cisco 1900

Cisco 1900 Series Hardware Installation

1-8

OL-19084-02

Chapter 1 Overview of the Router

• The ISM connector inside the Cisco 1941W chassis accommodates an optional factory installed

wireless LAN card. The WLAN card is permanently installed in the ISM connector.

• Cisco 1940 series ISRs feature an optional upgrade to the internal power supply providing in-line

power (802.3af-compliant Power-over-Ethernet (PoE) and Cisco standard inline power) to optional integrated switch modules. The Cisco 1905, and Cisco 1921 have an external feed for PoE.(See

Figure 1-2.)

• There are no user-installable or replaceable modules on the Cisco 1905 or Cisco 1921 routers. The

chassis cover should never be removed.

Caution Power off the PoE before installing an EHWIC in the Cisco 1905 and Cisco 1921 ISRs.

Table 1-2 summarizes the optional modules:

Ta b l e 1-2 Summary of Cisco 1940 Series Removable and Interchangeable Modules

External Modules (In chassis slots) Internal Modules

CompactFlash

2 2 1

1. Only Advanced Capability CompactFlash (CF) purchased from Cisco operate in Cisco 1900 series ISRs. Legacy CF will not operate in these routers. When legacy CF is inserted, the following error message appears:

WARNING: Unsupported compact flash detected. Use of this card during normal operation can impact and severely degrade performance of the system. Please use supported compact flash cards only.

2. HWICs, WICs, and VWICs (data only) are supported.

3. Non wireless models only.

1

Enhanced High-Speed WAN Interface Cards (EHWICs)

Hardware Features

2

Internal Service Module (ISM)

3

Memory

OL-19084-02

Cisco 1900 series routers contain the following types of memory:

• DRAM—Stores the running configuration and routing tables and is used for packet buffering by the

network interfaces. Cisco

• Boot/NVRAM—Internal flash memory. Stores the bootstrap program (ROM monitor), the

IOS software executes from DRAM memory.

configuration register, and the startup configuration.

• Flash memory—External flash memory (1940 series only). Stores the operating system software

image.

Cisco 1900 Series Hardware Installation

1-9

Chapter 1 Overview of the Router

Hardware Features

Table 1-3 summarizes the memory options for Cisco 1900 series routers. The default memory numbers

for RAM represent the minimum usable memory. You can install additional RAM in multiples of the default amount, up to the maximum amount on the Cisco 1940 series ISRs. The Cisco 1905 and Cisco 1921 have factory installed, fixed memory modules and no expansion slots.

Ta b l e 1-3 Router Memory Specifications

DRAM 1940 Series 1905 1921

DRAM Type—Unregistered DIMM

(UDIMM)

DIMM sizes—512 MB, 1 GB, 2 GB

DIMM expansion slots—1

Default onboard memory—512 MB non ECC

Maximum memory—2.5 GB

Boot or NVRAM—Internal 16-MB flash memory.

1. 256 MB cannot support net boot or warm upgrade functions. Net boot and warm upgrade require 512 MB of memory.

2. 512 MB activation requires memory licensing feature. See the Cisco IOS Software Activation Configuration Guide for details.

Type—D D R2

DIMM expansion slots—0

Default onboard memory—2561 MB non ECC

Maximum memory—512 MB

2

Boot or NVRAM—Internal 16 MB flash memory.

Type—DDR2

DIMM expansion slots—0

Default onboard memory—512

Maximum memory—512 MB

Boot or NVRAM—Internal 16 MB flash memory.

MB non ECC

LED Indicators

Table 1-4 summarizes the LED indicators that are located in the router bezel or chassis, but not on the

interface cards. Not all models have every LED.

Ta b l e 1-4 Summary of Cisco 1900 Series LED Indicators

LED Color Description Location

SYS Solid

Solid green indicates normal operation. Front panel

green

Blinking

System is booting or is in ROM monitor mode.

green

Amber System error.

Off Power is off or system board is faulty.

ACT Green Solid or blinking when any packets are transmitted or

Front panel received on any WAN or LAN, or when monitoring system activity.

PoE Green PoE is available. Front panel

Amber Power supply is not supplying PoE power.

Cisco 1900 Series Hardware Installation

1-10

OL-19084-02

Chapter 1 Overview of the Router

Table 1-4 Summary of Cisco 1900 Series LED Indicators (continued)

LED Color Description Location

WLAN

2.4GHz (Wireless Models)

WLAN 5GHz (Wireless Models)

WLAN Green

Hardware Features

Green On—Radio is connected, SSID1 is configured, signal is

being transmitted, and client is associated, but no data is being received or being transmitted.

Slow blinking—Radio is connected, SSID is configured, and beacons are being transmitted.

Fast blinking—Data is either being received or being transmitted.

Off—Radio is shut down, and no SSID is configured.

Green On—Radio is connected, SSID is configured, signal is being

transmitted, and client is associated, but no data is being received or being transmitted.

Slow blinking—Radio is connected, SSID is configured, and beacons are being transmitted.

Fast blinking—Data is either being received or being transmitted.

Off—Radio is shut down, and no SSID is configured.

Autonomous Mode

On—Wireless link is up.

Blinking—Ethernet link is up and data is either being received or being transmitted.

Front panel

Off—Wireless link is down.

Unified Mode

On—Ethernet link is up, wireless access point is communicating with LWAPP controller. Blinking—Ethernet link is up, wireless access point is not communicating with LWAPP controller.

Off—Ethernet link is down.

ISM/WLAN Green Initialized. Rear panel

Amber Initialized with error.

Flash (1905 and 1921 only)

Green Blinking means software is accessing the internal USB Flash

(eUSB2) device

Rear panel

Amber Initialized with error.

CF 1 Green Flash memory is busy.

Note Do not remove the CompactFlash memory card

Next to the CF1 slot

when this light is on.

Amber Initialized with error.

Blinking Green then

CompactFlash is ready for removal.

Note Remove the CompactFlash when the light turns off.

turns off

OL-19084-02

Cisco 1900 Series Hardware Installation

1-11

Hardware Features

Chapter 1 Overview of the Router

Table 1-4 Summary of Cisco 1900 Series LED Indicators (continued)

LED Color Description Location

CF 0 Green Flash memory is busy.

Note Do not remove the CompactFlash memory card

when this light is on.

Amber Initialized with error.

Blinking Green then

CompactFlash is ready for removal.

Note Remove the CompactFlash when the light turns off.

turns off

S (Speed) 1 blink +

GE port operating at 10 Mb/s. Rear panel

pause

2 blink +

GE port operating at 100 Mb/s.

pause

3 blink +

GE port operating at 1000 Mb/s.

pause

L (Link) Green GE link is established. Rear panel

Off No GE link is established.

EN (RJ-45

Green The RJ-45 console port is active. Rear panel,

console port)

EN (USB serial

Green The USB console port is active. Rear panel,

console port)

1. SSID = Service Set Identifier.

2. eUSB = embedded USB

Next to the

CF0 slot

next to the

console

port

next to the

USB

console

port

Chassis Ventilation

An internal fan provides chassis cooling. An onboard temperature sensor controls the fan speed. The fan is always on when power is applied to the router. Under most conditions, the fan operates at the slowest speed to conserve power and reduce fan noise. It operates at the higher speeds when necessary under conditions of higher ambient temperature. See the

Real-Time Clock

An internal real-time clock with battery backup provides the system software with time of day on system power up. This allows the system to verify the validity of the certification authority (CA) certificate. The Cisco

1900 series router has a lithium battery. This battery lasts the life of the router under the operating

environmental conditions specified for the router, and is not field-replaceable.

Cisco 1900 Series Hardware Installation

1-12

“Chassis Airflow Diagram” section on page 4-3.

OL-19084-02

Chapter 1 Overview of the Router

Note If the lithium battery in a Cisco 1900 ISR should fail, the router must be returned to Cisco for repair.

Although the battery is not intended to be field-replaceable, the following warning must be heeded:

Hardware Features

Warning

Dispose of used batteries according to the manufacturer’s instructions.

Chassis Security

The chassis of the router is constructed with a KensingtonTM security slot on the back panel. It can be secured to a desktop or other surface by using Kensington

Wireless LAN Connectivity

The embedded Wi-Fi CERTIFIED™, 802.11a/b/g/n-compliant wireless access point is preinstalled in the router as an optional feature. The Cisco 1900 series routers support both autonomous and unified features and network configurations.

The wireless access point does not have an external console port for connections. To configure the wireless device, you must use a console cable to connect a PC to the host router’s console port as described in command-line interface (CLI) to access the interface.

Table 1-5 describes the radios and antennas for the Cisco 1900 series wireless routers.

The 5-GHz radio incorporates an Unlicensed National Information Infrastructure (UNII) radio transceiver operating in the UNII 1, 2, 3, 5-GHz frequency bands.

Ta b l e 1-5 Wireless Device Radios and Antennas

Chapter 5, “Connecting to a Console Terminal or Modem,” and then use the Cisco IOS

Statement 1015

TM

lockdown equipment.

OL-19084-02

Radio

Radio Module Platform

Dual-band

802.11a/b/g/n radio module

Cisco 1900 series wireless

Band

2.4 GHz and 5 GHz

routers

1. Actual data rate is highly dependent on your wireless environment.

2. The antennas require some minor installation. They must be screwed onto the RP-TNC antenna connectors on the I/O side of the chassis. See the following document on Cisco.com for feature information:

http://cisco.com/en/US/products/ps5853/prod_installation_guide09186a00804399cd.html

Maximum Data Throughput

1

100 Mb/s per radio, up to 200 Mb/s total

Cisco 1900 Series Hardware Installation

Mode Antenna

Autonomous and unified

Three dual-band removable

2.4-GHz/5-GHz omnidirectional dipole RP-TNC antennas

2

1-13

Interface Numbering

Baud Reset Button

The Cisco 1905 and Cisco 1921 ISRs have a baud reset button on the back panel. When the button is pressed during power on, ROMMON resets the router to the default console port configuration. If the baud reset button is pressed for longer than 30 seconds, the router defaults to the read-only ROMMON image. The default console port configuration is 9600 control is set to none.

Interface Numbering

Each individual interface (port) on a Cisco 1900 series router is identified by a number. The Cisco 1900 series routers contains the following wide-area network (WAN) and local-area network (LAN) interface types:

• Two onboard Gigabit Ethernet (GE) LAN interfaces

• Two slots in which you can install WICs, VWICs (data only), and HWICs. The Cisco 1905 comes

with a factory installed EHWIC in the right slot.

Chapter 1 Overview of the Router

baud, 8 data bits, 1 stop bit, no parity, and flow

The numbering format for the slots is interface-type 0/slot-number/interface-number. Tab le 1-6 summarizes the interface numbering. See Figure 1-5 to identify the slot numbers.

Ta b l e 1-6 Interface Numbering

Slot Number Slot Type Slot Numbering Range

Onboard Ports 10/100/1000 Ethernet 0/0 and 0/1

Slot 0 EHWIC/HWIC/WIC 0/0/0 to 0/0/0 (single-wide)

Slot 1 EHWIC/WIC/VWIC 0/1/0 to 0/1/0 (single or double-wide)

Note On the Cisco 1900 series router, the numbering format for configuring an async interface is 0/slot/port. To

configure the line associated with an async interface, simply use the interface number to specify the async line. For example, line 0/0/0 specifies the line associated with interface serial 0/0/0 on a WIC-2A/S in slot 0. Similarly, line 0/1/1 specifies the line associated with interface async 0/1/1 on a WIC-2AM in slot 1.

Specifications

Table 1-7 lists the specifications for Cisco 1905 and Cisco 1921 series routers. Tab l e 1-8 lists the

specifications for Cisco 1940 series routers.

Ta b l e 1-7 Cisco 1905 and 1921 Series Router Specifications

Description Specification Physical

Dimensions without rubber feet (H x W x D)

Cisco 1900 Series Hardware Installation

1-14

1

1.75 in x 13.5 in x 11.5 in (4.4 cm x 34.3 x 29.2 cm), 1 RU2 height

OL-19084-02

Chapter 1 Overview of the Router

Specifications

Table 1-7 Cisco 1905 and 1921 Series Router Specifications

1

Description Specification

Rack-mount 19 in. (48.3 cm)

Optional

EIA

Weight (no modules installed) Approximately 12 lbs

Weight with PoE 12.8 lbs

Maximum Weight-Fully

14 lbs

Configured

Power

AC input power

• Input voltage 100 to 240 VAC, autoranging

• Frequency 47 to 63 Hz

• Input current (max) 1.5 to 0.6 A

• Typical power (no modules) 25 W

• Power (max) with AC 60 W

• Power (max) with PoE

70 W

(platform only)

• Maximum PoE device

80 W power capacity with PoE power supply

• Surge current <50 A

Ports

Console One RJ-45 connector and one USB mini Type B, USB 2.0

compliant. Baud rates: 1200, 2400, 4800, 9600, 19200, 38400,

57600, and 115200.

Auxiliary ports RJ-45 connector. Baud rates: 1200, 2400, 4800, 9600, 19200,

38400, 57600, and 115200.

USB port One USB Type A, USB 2.0 compliant, 2.5 W (500 mA) max.

10/100/1000 Gigabit Ethernet Two RJ-45 connectors (GE0/GE1), Auto-MDIX

4

Environmental

Operating humidity 10 to 85% RH

Operating temperature - up to

32 to 104°F (0 to 40°C)

5906 ft (1800 m) elevation

Operating temperature - up to

32 - 77°F (0 - 25°C)

9843 ft (3000 m) elevation

Operating altitude maximum 10,000 ft (3000 m)

Transportation and Storage Environment

Nonoperating temperature –40 to 158°F (–40 to 70°C)

Nonoperating humidity 5 to 95% RH

Nonoperating altitude 15,000 ft (4570 m)

Acoustic

3

OL-19084-02

Cisco 1900 Series Hardware Installation

1-15

Specifications

Chapter 1 Overview of the Router

Table 1-7 Cisco 1905 and 1921 Series Router Specifications

Description Specification

Sound Pressure (Typ/Max) 32.9/58.3 dBa

Sound Power (Typ/Max) 41.9/67.2 dBA

Regulatory

Electromagnetic compatibility (EMC)

47 CFR, Part 15 ICES-003 Class A EN55022 Class A CISPR22 Class A AS/NZS 3548 Class A VCCI V-3 EN 300-386 EN 61000 (Immunity) EN 55024, CISPR 24 EN50082-1

For detailed compliance information, see the Regulatory

Compliance and Safety Information for Cisco 1900 Series Routers

document.

Safety compliance UL 60950-1

CAN/CSA C22.2 No. 60950-1 EN 60950-1 AS/NZS 60950-1 IEC 60950-1

For detailed compliance information, see the Regulatory

Compliance and Safety Information for Cisco 1900 Series Routers

document.

Telecom TIA/EIA/IS-968

CS-03 ANSI T1.101 IEEE 802.3 RTTE Directive

1

1. Refer to the Cisco 1900 Series Integrated Services Routers Data Sheet for additional information.

2. Rack unit (RU

3. 480 Mb/s individually, bandwidth is shared when both are used.

4. Auto-MDIX=auto media-dependent interface cross over.

Ta b l e 1-8 Cisco 1940 Series Router Specifications

Description Specification Physical

Dimensions without rubber feet (H x W x D)

Cisco 1900 Series Hardware Installation

1-16

For detailed compliance information, see the Regulatory

Compliance and Safety Information for Cisco 1900 Series Routers

document.

1

3.5 x 13.5 x 11.5 in. (8.9 x 34.3 x 29.2 cm), 2 RU2 height

OL-19084-02

Chapter 1 Overview of the Router

Specifications

Table 1-8 Cisco 1940 Series Router Specifications

1

Description Specification

Rack-mount 19 in. (48.3 cm)

Included

EIA

Weight (no modules installed) Approximately 12 lbs

Weight with PoE 12.8 lbs

Maximum Weight-Fully

14.0 lbs

Configured

Power

AC input power

• Input voltage 100 to 240 VAC, autoranging

• Frequency 47 to 63 Hz

• Input current (max) 1.5 to 0.6 A

• Typical power (no modules) 35 W

• Power (max) with AC 110 W

• Power (max) with PoE

110 W (platform only)

• Maximum PoE device

80 W power capacity with PoE power supply

• Surge current <50 A

Power consumption 110 W maximum platform only

Ports

Console One RJ-45 connector and one USB mini Type B, USB 2.0

compliant. Baud rates: 1200, 2400, 4800, 9600, 19200, 38400,

57600, and 115200.

Auxiliary ports RJ-45 connector. Baud rates: 1200, 2400, 4800, 9600, 19200,

38400, 57600, and 115200.

USB ports Two USB Type A, USB 2.0 compliant, 2.5 W (500 mA) max.

10/100/1000 Gigabit Ethernet Two RJ-45 connectors (GE0/GE1), Auto-MDIX

4

Environmental

Operating humidity 10 to 85% RH

Operating temperature - up to

32 to 104°F (0 to 40°C)

5906 ft (1800 m) elevation

Operating temperature - up to

32 - 77°F (0 - 25°C)

9843 ft (3000 m) elevation

Operating altitude maximum 10,000 ft (3000 m)

Transportation and Storage Environment

Nonoperating temperature –40 to 158°F (–40 to 70°C)

Nonoperating humidity 5 to 95% RH

Nonoperating altitude 15,000 ft (4570 m)

3

OL-19084-02

Cisco 1900 Series Hardware Installation

1-17

Regulatory Compliance

Chapter 1 Overview of the Router

Table 1-8 Cisco 1940 Series Router Specifications

Description Specification Acoustic

Sound Pressure (Typ/Max) 26/46

Sound Power (Typ/Max) 36/55 dBA

Regulatory

Electromagnetic compatibility (EMC)

47 CFR, Part 15 ICES-003 Class A EN55022 Class A CISPR22 Class A AS/NZS 3548 Class A VCCI V-3 CNS 13438 EN 300-386 EN 61000 (Immunity) EN 55024, CISPR 24 EN50082-1

For detailed compliance information, see the Regulatory

Compliance and Safety Information for Cisco 1900 Series Routers

document.

Safety compliance UL 60950-1

CAN/CSA C22.2 No. 60950-1 EN 60950-1 AS/NZS 60950-1 IEC 60950-1

For detailed compliance information, see the Regulatory

Compliance and Safety Information for Cisco 1900 Series Routers

document.

Telecom TIA/EIA/IS-968

CS-03 ANSI T1.101 ITU-T G.823, G.824 IEEE 802.3 RTTE Directive

1

1. Refer to the Cisco 1900 Series Integrated Services Routers Data Sheet for additional information.

2. Rack unit (RU

3. 480 Mb/s individually, bandwidth is shared when both are used.

4. Auto-MDIX=auto media-dependent interface cross over.

Regulatory Compliance

For compliance information, refer to the Regulatory Compliance and Safety Information for Cisco 1900

Series Routers document.

Cisco 1900 Series Hardware Installation

1-18

For detailed compliance information, see the Regulatory

Compliance and Safety Information for Cisco 1900 Series Routers

document.

OL-19084-02

CHAP T E R

2

Preparing for Router Installation

This chapter describes the site requirements and equipment needed to install your Cisco 1900 series integrated services router. It includes the following sections:

• Safety Recommendations, page 2-1

• General Site Requirements, page 2-3

• Network Cabling Specifications, page 2-5

• Console and Auxiliary Port Considerations, page 2-5

• Preparing to Connect to a Network, page 2-7

• Inspecting the Router, page 2-10

• Installation Checklist, page 2-11

• Site Log, page 2-13

• Inspecting the Router, page 2-10

• Required Tools and Equipment for Installation and Maintenance, page 2-13

Note To see translations of the warnings that appear in this publication, refer to the Regulatory Compliance

and Safety Information for Cisco 1900 Series Routers document that accompanies your router.

Safety Recommendations

Follow these guidelines to ensure general safety:

• Keep the chassis area clear and dust-free during and after installation.

• If you remove the chassis cover, put it in a safe place.

• Keep tools and chassis components away from walk areas.

• Do not wear loose clothing that could get caught in the chassis. Fasten your tie or scarf, and roll up

your sleeves.

• Wear safety glasses when working under conditions that might be hazardous to your eyes.

• Do not perform any action that creates a hazard to people or makes the equipment unsafe.

Warning

OL-19084-02

Read the installation instructions before connecting the system to the power source.

Statement 1004

Cisco 1900 Series Hardware Installation

2-1

Safety Recommendations

Chapter 2 Preparing for Router Installation

Warning

Blank faceplates and cover panels serve three important functions: they prevent exposure to hazardous voltages and currents inside the chassis; they contain electromagnetic interference (EMI) that might disrupt other equipment; and they direct the flow of cooling air through the chassis. Do not operate the system unless all cards, faceplates, front covers, and rear covers are in place.

1029

Warning

To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the handles on modules (such as power supplies, fans, or cards); these types of handles are not designed to support the weight of the unit.

Warning

Ultimate disposal of this product should be handled according to all national laws and regulations.

Statement 1040

Safety with Electricity

Follow these guidelines when working on equipment powered by electricity.

Warning

Do not work on the system or connect or disconnect cables during periods of lightning activity.

Statement 1001

Statement

Statement 1032

Warning

Read the installation instructions before connecting the system to the power source.

Statement 1004

When installing or replacing the unit, the ground connection must always be made first and disconnected last.

• Locate the emergency power-off switch in the room in which you are working. Then, if an electrical

Statement 1046

accident occurs, you can quickly turn off the power.

• Disconnect all power before doing the following:

–

Installing or removing a chassis

–

Working near power supplies

–

Removing the top cover of a chassis

• Look carefully for possible hazards in your work area, such as moist floors, ungrounded power

extension cables, frayed power cords, and missing safety grounds.

• Do not work alone if hazardous conditions exist.

• Never assume that power is disconnected from a circuit. Always check.

• Never open the enclosure of the router’s internal power supply.

• If an electrical accident occurs, proceed as follows:

–

Use caution; do not become a victim yourself.

–

Turn off power to the device.

Cisco 1900 Series Hardware Installation

2-2

OL-19084-02

Chapter 2 Preparing for Router Installation

–

If possible, send another person to get medical aid. Otherwise, assess the victim’s condition and then call for help.

–

Determine whether the person needs rescue breathing or external cardiac compressions; then take appropriate action.

In addition, use the following guidelines when working with any equipment that is disconnected from a power source, but is still connected to telephone wiring or other network cabling:

• Never install telephone wiring during a lightning storm.

• Never install telephone jacks in wet locations unless the jack is specifically designed for it.

• Never touch uninsulated telephone wires or terminals unless the telephone line is disconnected at

the network interface.

• Use caution when installing or modifying telephone lines.

Preventing Electrostatic Discharge Damage

Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. ESD can occur if electronic printed circuit cards are improperly handled and can cause complete or intermittent failures. Always follow ESD prevention procedures when removing and replacing modules:

• Ensure that the router chassis is electrically connected to earth ground.

General Site Requirements

• Wear an ESD-preventive wrist strap, ensuring that it makes good skin contact. Connect the clip to

an unpainted surface of the chassis frame to channel unwanted ESD voltages safely to ground. To guard against ESD damage and shocks, the wrist strap and cord must operate effectively.

• If no wrist strap is available, ground yourself by touching a metal part of the chassis.

Caution For the safety of your equipment, periodically check the resistance value of the antistatic strap. It should

be between 1 and 10 megohms (Mohm).

General Site Requirements

This section describes the requirements that your site must meet for safe installation and operation of your router. Ensure that the site is properly prepared before beginning installation. If you are experiencing shutdowns or unusually high errors with your existing equipment, this section can also help you isolate the cause of failures and prevent future problems.

OL-19084-02

Cisco 1900 Series Hardware Installation

2-3

General Site Requirements

Power Supply Considerations

Check the power at your site to ensure that you are receiving “clean” power (free of spikes and noise). Install a power conditioner if necessary.

Chapter 2 Preparing for Router Installation

Warning

The device is designed for connection to TN and IT power systems.

The AC power supply includes the following features:

• Autoselects either 110 V or 220 V operation.

• All units include a 6-foot (1.8-meter) electrical power cord. (A label near the power cord indicates

Site Environment

The Cisco 1900 series router is designed for placement on a desktop, rack-mounted or wall mounted.

The location of your router is an extremely important consideration for proper operation. Equipment placed too close together, inadequate ventilation, and inaccessible panels can cause malfunctions and shutdowns, and can also make maintenance difficult. Plan for access to both front and back panels of the router.

When planning your site layout and equipment locations, remember the precautions described in the

“Site Configuration” section on page 2-4 to help avoid equipment failures and reduce the possibility of

environmentally caused shutdowns. If you are currently experiencing shutdowns or an unusually high number of errors with your existing equipment, these precautions may help you isolate the cause of the failures and prevent future problems.

Statement 1007

the correct voltage, frequency, current draw, and power dissipation for the unit.)

Site Configuration

The following precautions will help you plan an acceptable operating environment for your router and will help you avoid environmentally caused equipment failures:

• Make sure that the room where your router operates has adequate circulation. Electrical equipment

generates heat. Without adequate circulation, ambient air temperature may not cool equipment to acceptable operating temperatures. See the

• Always follow the ESD-prevention procedures described in the “Preventing Electrostatic Discharge

Damage” section on page 2-3 to avoid damage to equipment. Damage from static discharge can

cause immediate or intermittent equipment failure.

• Make sure that the chassis cover and module back panels are secure. All empty interface card slots

must have filler panels installed. The chassis is designed to allow cooling air to flow within it, through specially designed cooling slots. A chassis with uncovered openings creates air leaks, which may interrupt and reduce the flow of air across internal components.

“Chassis Airflow Diagram” section on page 4-3.

Cisco 1900 Series Hardware Installation

2-4

OL-19084-02

Chapter 2 Preparing for Router Installation

Wireless LAN Considerations

Wireless communication is dependent upon the propagation of radio waves. Many environmental factors influence radio waves. The Cisco Multiband Swivel-Mount Dipole Antenna document Installation Notes section describes factors affecting this. Prior to determining a location for the router it is advisable you review these factors.

http://www.cisco.com/en/US/docs/routers/access/wireless/hardware/notes/antdip.html#wp1009743

The type of antenna used with your wireless router and its location greatly impact the quality of wireless connections to the router. Cisco 1900 series wireless routers are compatible with three different antenna types—swivel-mount dipole antennas that mounts on the back panel of the router, a wall-mount antenna, and a ceiling-mount antenna.

For more information about antenna coverage and optimal usage, see the following documents:

• Cisco Multiband Swivel-Mount Dipole Antenna

• Cisco Multiband Diversity Omnidirectional Ceiling-Mount Antenna

Network Cabling Specifications

The following sections describe the cables needed to install your Cisco 1900 series ISR in the following sections:

• Console and Auxiliary Port Considerations, page 2-5

• Preparing to Connect to a Network, page 2-7

For cable connection procedures, see the “Cable Connection Procedures for Cisco 1900 Series Routers” document.

Console and Auxiliary Port Considerations

The router includes USB, asynchronous serial and auxiliary ports. The console and auxiliary ports provide access to the router either locally using a console terminal connected to the console port, or remotely, using a modem connected to the auxiliary port. This section provides important cabling information to consider before connecting the router to a console terminal or modem.

The main difference between the console and auxiliary ports is that the auxiliary port supports flow control, whereas the console port does not. Flow control paces the transmission of data between a sending device and a receiving device. Flow control ensures that the receiving device can absorb the data sent to it before the sending device sends more. When the buffers on the receiving device are full, a message is sent to the sending device to suspend transmission until the data in the buffers has been processed. Because the auxiliary port supports flow control, it is ideally suited for use with the high-speed transmissions of a modem. Console terminals send data at slower speeds than modems; therefore, the console port is ideally suited for use with console terminals.

Console Port Connections

The router has an EIA/TIA-232 asynchronous serial console port (RJ-45) and at least one USB Type-A

2.0 compliant ports. See

OL-19084-02

Tabl e 1-1 on page 1-8 for a list of ports.

Cisco 1900 Series Hardware Installation

2-5

Console and Auxiliary Port Considerations

EIA/TIA-232 Port

Depending on the cable and the adapter used, this port will appear as a data terminal equipment (DTE) or data communications equipment (DCE) device at the end of the cable.

For connection to a PC running terminal emulation software, your router is provided with an RJ-45-to-DB-9 cable.

To connect the router to an ASCII terminal, use the RJ-45-to-DB-9 cable and a DB-9-to-DB-25 adapter (provided).

The default parameters for the console port are 9600 baud, 8 data bits, no parity, and 1 stop bit. The console port does not support mode control. For detailed information about installing a console terminal, see the

Connection Procedures for Cisco 1900 Series Routers” document.

For cable and port pinouts, refer to the online document Cisco Modular Access Router Cable

Specifications. This document is located on Cisco.com.

USB Serial Console

The USB serial console port connects directly to the USB connector of a PC using a USB Type A to 5-pin mini Type-B cable. The USB Console supports full speed (12Mb/s) operation. The console port does not support hardware flow control.

The default parameters for the console port are 9600 baud, 8 data bits, no parity, and 1 stop bit. The console port does not support mode control. For detailed information about installing a console terminal, see the

Connection Procedures for Cisco 1900 Series Routers” document.

Chapter 2 Preparing for Router Installation

“Connecting to the Console Port with Microsoft Windows” section on page 5-4 of the “Cable

For operation with Microsoft Windows, the Cisco Windows USB Console Driver must be installed on any PC connected to the Console port. If it is not installed, prompts guide you through a simple installation process.

The Cisco Windows USB Console Driver allows plugging and unplugging the USB cable from the console port without affecting Windows HyperTerminal operations. No special drivers are needed for Mac OS X or Linux.

Only one console port can be active at a time. When a cable is plugged into the USB console port the RJ

45 port becomes inactive. Conversely, when the USB cable is removed from the USB port the RJ 45

port becomes active.

Baud rates for the USB console port are 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps.

Note 4-pin mini Type-B connectors are easily confused with 5-pin mini Type-B connectors. They are

not compatible Only the 5-pin mini Type-B can be used.

USB Console OS Compatibility

• Windows 2000, Windows XP 32- and 64-bit, Windows Vista 32- and 64-bit

• Mac OS X version 10.5.4

• Redhat / Fedora Core 10 with kernel 2.6.27.5-117

• Ubuntu 8.10 with kernel 2.6.27-11

• Debian 5.0 with kernel 2.6

• Suse 11.1 with kernel 2.6.27.7-9

Cisco 1900 Series Hardware Installation

2-6

OL-19084-02

Chapter 2 Preparing for Router Installation

Auxiliary Port Connections

The router has an EIA/TIA-232 asynchronous serial auxiliary port (RJ-45) that supports flow control. Depending on the cable and the adapter used, this port will appear as a DTE or DCE device at the end of the cable.

For connection to a modem, your router is provided with an RJ-45-to-DB-9 cable and a DB-9-to-DB-25 adapter.

For detailed information about connecting devices to the auxiliary port, see the “Connecting to the

Auxiliary Port” section on page 5-9.

For cable and port pinouts, refer to the Cisco Modular Access Router Cable Specifications document on Cisco.com.

Preparing to Connect to a Network

When setting up your router, consider distance limitations and potential electromagnetic interference (EMI) as defined by the applicable local and international regulations.

The following sections describe network connection considerations for several types of network interfaces:

• Ethernet Connections, page 2-7

Preparing to Connect to a Network

• Serial Connections, page 2-7

• ISDN BRI Connections, page 2-9

• CSU/DSU Connections, page 2-10

Refer to the following online documents for more information about network connections and interfaces:

• Cisco Modular Access Router Cable Specifications

Ethernet Connections

The IEEE has established Ethernet as standard IEEE 802.3. The Cisco 1941 Ethernet implementations are as follows:

• 1000BASE-T—1000 Mb/s full-duplex transmission over a Category 5 or better unshielded

twisted-pair (UTP) cable. Supports the Ethernet maximum length of 328 feet (100 meters).

• 100BASE-T—100 Mb/s full-duplex transmission over a Category 5 or better unshielded

twisted-pair (UTP) cable. Supports the Ethernet maximum length of 328 feet (100 meters).

• 10BASE-T—10 Mb/s full-duplex transmission over a Category 5 or better unshielded twisted-pair

(UTP) cable. Supports the Ethernet maximum length of 328 feet (100 meters).

Refer to the Cisco Modular Access Router Cable Specifications online document for information about Ethernet cables, connectors, and pinouts. This document is available online.

Serial Connections

Serial connections are provided by serial WAN interface cards (WICs). For more information on WICs, refer to

OL-19084-02

Cisco.com. This document can be accessed online.

Cisco 1900 Series Hardware Installation

2-7

Preparing to Connect to a Network

Before you connect a device to a serial port, you need to know the following:

• Type of device—data terminal equipment (DTE) or data communications equipment (DCE)—that

you are connecting to the synchronous serial interface

• Type of connector—male or female—that is required for connecting to the device

• Signaling standard that is required by the device

Configuring Serial Connections

The serial ports on the serial WICs use DB-60 connectors. Serial ports can be configured as DTEs or DCEs, depending on the serial cable used.

Serial DTE or DCE Devices

A device that communicates over a synchronous serial interface is either a DTE or DCE device. A DCE device provides a clock signal that paces the communications between the device and the router. A DTE device does not provide a clock signal. DTE devices usually connect to DCE devices. The documentation for the device should indicate whether it is a DTE or DCE device. (Some devices have a jumper that allows you to select either DTE mode or DCE mode.) devices.

Chapter 2 Preparing for Router Installation

Tabl e 2-1 lists typical DTE and DCE

Ta b l e 2-1 Typical DTE and DCE Devices

Device Type Gender Typical Devices

DTE Male

DCE Female

1. If pins protrude from the base of the connector, the connector is male.

2. If the connector has holes to accept pins, the connector is female.

Signaling Standards Supported

The synchronous serial ports available for the router support the following signaling standards: EIA/TIA-232, EIA/TIA-449, V.35, X.21, and EIA-530. You can order a Cisco DB-60 shielded serial transition cable that has the appropriate connector for the standard you specify. The documentation for the device that you want to connect should indicate the standard used for that device. The router end of the shielded serial transition cable has a DB-60 connector, which connects to the DB-60 port on a serial WIC. The other end of the serial transition cable is available with a connector appropriate for the standard that you specify.

The synchronous serial port can be configured as DTE or DCE, depending on the attached cable (except EIA-530, which is DTE only). To order a shielded cable, contact customer service. See the

Documentation and Submitting a Service Request” section on page -xvi.

1

2

• Ter m i n a l

• PC

• Modem

• CSU/DSU

• Multiplexer

“Obtaining

Note All serial ports configured as DTE require external clocking from a channel service unit/data service unit

(CSU/DSU) or other DCE device.

Cisco 1900 Series Hardware Installation

2-8

OL-19084-02

Chapter 2 Preparing for Router Installation

Although we do not recommend manufacturing your own serial cables (because of the small size of the pins on the DB-60 serial connector), cable pinouts are provided in the

Cable Specifications.

Transmission Speeds and Distance Limitations

Serial signals can travel a limited distance at any given bit rate; generally, the slower the data rate, the greater the distance. All serial signals are subject to distance limits, beyond which a signal is significantly degraded or is completely lost.

Table 2-2 lists the recommended maximum speeds and distances for each serial interface type; however,

you might get good results at speeds and distances greater than those listed, if you understand the electrical problems that might arise and can compensate for them. For instance, the recommended maximum rate for V.35 is 2

Ta b l e 2-2 Serial Signal Transmission Speeds and Distances

Distance for EIA/TIA-232

Rate (bps) Feet Meters Feet Meters Feet Meters

2400 200 60 4100 1250 16.4 5

4800 100 30 2050 625 16.4 5

9600 50 15 1025 312 16.4 5

19200 25 7.6 513 156 16.4 5

38400 12 3.7 256 78 16.4 5

56000 8.6 2.6 102 31 16.4 5

1544000 (T1) — — 50 15 16.4 5

Mbps, but 4 Mbps is commonly used.

Distance for EIA/TIA-449, X.21, V.35, and EIA-530

Preparing to Connect to a Network

Cisco Modular Access Router

Distance for USB

Balanced drivers allow EIA/TIA-449 signals to travel greater distances than EIA/TIA-232 signals. Typically, EIA/TIA-449 and EIA-530 can support a 2-Mbps rate, and V.35 can support a 4-Mbps rate.

Asynchronous/Synchronous Serial Module Baud Rates

The following baud-rate limitations apply to the slow-speed serial interfaces in the asynchronous/synchronous serial modules:

• Asynchronous interface—Maximum baud rate is 115.2 kbps.

• Synchronous interface—Maximum baud rate is 128 kbps, full-duplex.

ISDN BRI Connections

The BRI WICs provide Integrated Services Digital Network (ISDN) Basic Rate Interface (BRI) connections. BRI WICs are available with either an S/T interface that requires an external Network Termination 1 (NT1), or a U interface that has a built-in NT1. You can install the BRI WICs in any available WIC slots in the chassis.

OL-19084-02

Cisco 1900 Series Hardware Installation

2-9

Inspecting the Router

Chapter 2 Preparing for Router Installation

Warning

The ISDN connection is regarded as a source of voltage that should be inaccessible to user contact. Do not attempt to tamper with or open any public telephone operator (PTO)-provided equipment or connection hardware. Any hardwired connection (other than by a nonremovable, connect-one-time-only plug) must be made only by PTO staff or suitably trained engineers.

Statement 23

Hazardous network voltages are present in WAN ports regardless of whether power to the unit is OFF or ON. To avoid electric shock, use caution when working near WAN ports. When detaching cables, detach the end away from the unit first.

Use a BRI cable (not included) to connect the BRI WIC directly to an ISDN. Ta b le 2-3 lists the specifications for ISDN BRI cables. For information about pinouts, refer to the Cisco Modular Access

Router Cable Specifications online document, which is located on Cisco.com.

Ta b l e 2-3 ISDN BRI Cable Specifications

Specification High-Capacitance Cable Low-Capacitance Cable

Resistance (at 96 kHz) 160 ohms/km 160 ohms/km

Capacitance (at 1 kHz) 120 nF1/km

Impedance (at 96 kHz) 75 ohms 150 ohms

Wire diameter 0.024 in (0.6 mm) 0.024 in (0.6 mm)

Distance limitation 32.8 ft (10 m) 32.8 ft (10 m)

1. nF = nanofarad

Statement 1026

30 nF/km

For more information on BRI WICs, refer to Cisco.com.

CSU/DSU Connections

CSU/DSU WICs are available that provide switched 56-kbps connections, or full or fractionalized T1 connections.

For more information on CSU/DSU WICs, refer to Cisco.com.

Inspecting the Router

Do not unpack the router until you are ready to install it. If the final installation site will not be ready for some time, keep the chassis in its shipping container to prevent accidental damage. When you are ready to install the router, proceed with unpacking it.

The router, cables, publications, and any optional equipment that you ordered may be shipped in more than one container.

Inspect all items for shipping damage. If anything appears to be damaged, or if you encounter problems installing or configuring your router, contact customer service. Warranty, service, and support information is in the quick start guide that shipped with your router.

Cisco 1900 Series Hardware Installation

2-10

OL-19084-02

Chapter 2 Preparing for Router Installation

Installation Checklist

The sample installation checklist lists items and procedures for installing a new router. Make a copy of this checklist, and mark each item when you complete it. Include a copy of the checklist for each router in your Site Log (described in the

Installation Checklist

“Site Log” section on page 2-13).

OL-19084-02

Cisco 1900 Series Hardware Installation

2-11

Installation Checklist

Chapter 2 Preparing for Router Installation

Installation Checklist for Site_____________________________________________

Router Name_______________________________________________________

Task Verified by Date

Installation Checklist copied

Background information placed in Site Log

Site power voltages verified

Installation site power check completed

Required tools available

Additional equipment available

Router received

Router quick start guide received

Cisco Regulatory Compliance and Safety Information Roadmap document received

Product registration card received

Chassis components verified

Initial electrical connections established

ASCII terminal (for local configuration) or modem

Signal distance limits verified

Startup sequence steps completed

Initial operation verified

Software image verified

(for remote configuration) available

Cisco 1900 Series Hardware Installation

2-12

OL-19084-02

Chapter 2 Preparing for Router Installation

Site Log

The Site Log is a record of all actions related to the router. Keep it in an accessible place near the chassis so that anyone who performs tasks has easy access to it. Use the Installation Checklist to verify steps in installation and maintenance of the router. Site Log entries might include the following information:

• Installation progress—Make a copy of the Installation Checklist, and insert it into the Site Log.

Record the pertinent information as each procedure is completed.

• Upgrade and maintenance procedures—Use the Site Log as a record of ongoing router maintenance

and expansion history. A Site Log might include the following events:

–

Site Log

Installation of network modules

Removal or replacement of network modules and other upgrades

Configuration changes

Maintenance schedules and requirements

Maintenance procedures performed

Intermittent problems

–

Comments and notes

Required Tools and Equipment for Installation and Maintenance

You need the following tools and equipment for installing and upgrading the router and its components:

• ESD-preventive cord and wrist strap

• Number 2 Phillips screwdriver for installing or removing modules, and a flat-blade screwdriver for

removing CompactFlash cover, upgrading memory, or other components: small, 3/16-inch (0.48 centimeter) and medium, 1/4-inch (0.63 centimeter).

• A 1/4-inch (0.63 centimeter) nut driver

• Wire crimper

• AWG 14 wire for connecting the router chassis to earth ground

In addition, depending on the type of modules you plan to use, you might need the following equipment to connect a port to an external network:

• Cables for connection to WAN and LAN ports (dependent on configuration)

Note For more information on cable specifications, refer to the online document Cisco Modular

Access Router Cable Specifications, which is located on Cisco.com.

• Ethernet hub or PC with a network interface card for connection to Ethernet (LAN) ports

• Console terminal (an ASCII terminal or a PC running terminal emulation software) configured for

9600 baud, 8 data bits, no parity, and 1 stop bit

• Modem for connection to the auxiliary port for remote administrative access

• Data service unit (DSU) or channel service unit/data service unit (CSU/DSU) as appropriate for

serial interfaces

• External CSU for any CT1/PRI modules without a built-in CSU

OL-19084-02

Cisco 1900 Series Hardware Installation

2-13

Required Tools and Equipment for Installation and Maintenance

• NT1 device for ISDN BRI S/T interfaces (if not supplied by your service provider)

Chapter 2 Preparing for Router Installation

Cisco 1900 Series Hardware Installation

2-14

OL-19084-02

CHAP T E R

Cable Information and Specifications for Cisco 1900 Series Routers

This document gives cable information and specifications for the console port, auxiliary port, and network ports on your Cisco 1900 series integrated services router. It contains the following sections:

• Console and Auxiliary Port Considerations, page 3-1

• Preparing to Connect to a Network, page 3-3

For cable connection procedures, see the “Cable Connection Procedures for Cisco 1900 Series Routers” document.

Console and Auxiliary Port Considerations

The router includes USB, asynchronous serial and auxiliary ports. The console and auxiliary ports provide access to the router either locally using a console terminal connected to the console port, or remotely, using a modem connected to the auxiliary port. This section provides important cabling information to consider before connecting the router to a console terminal or modem.

3

The main difference between the console and auxiliary ports is that the auxiliary port supports flow control, whereas the console port does not. Flow control paces the transmission of data between a sending device and a receiving device. Flow control ensures that the receiving device can absorb the data sent to it before the sending device sends more. When the buffers on the receiving device are full, a message is sent to the sending device to suspend transmission until the data in the buffers has been processed. Because the auxiliary port supports flow control, it is ideally suited for use with the high-speed transmissions of a modem. Console terminals send data at slower speeds than modems; therefore, the console port is ideally suited for use with console terminals.

Console Port Connections

The router has an EIA/TIA-232 asynchronous serial console port (RJ-45) and two USB Type-A 2.0 compliant ports.

EIA/TIA-232 Port

Depending on the cable and the adapter used, this port will appear as a data terminal equipment (DTE) or data communications equipment (DCE) device at the end of the cable.

OL-19084-01

Cisco 1900 Series Hardware Installation

3-1

Console and Auxiliary Port Considerations

For connection to a PC running terminal emulation software, your router is provided with an RJ-45-to-DB-9 cable.

To connect the router to an ASCII terminal, use the RJ-45-to-DB-9 cable and a DB-9-to-DB-25 adapter (provided).

The default parameters for the console port are 9600 baud, 8 data bits, no parity, and 1 stop bit. The console port does not support mode control. For detailed information about installing a console terminal, see the

Connection Procedures for Cisco 1900 Series Routers” document.

For cable and port pinouts, refer to the online document Cisco Modular Access Router Cable

Specifications. This document is located on Cisco.com.

USB Serial Console

The USB serial console port connects directly to the USB connector of a PC using a USB Type A to 5-pin mini Type-B cable. The USB Console supports full speed (12Mb/s) operation. The console port does not support hardware flow control.

The default parameters for the console port are 9600 baud, 8 data bits, no parity, and 1 stop bit. The console port does not support mode control. For detailed information about installing a console terminal, see the

Connection Procedures for Cisco 1900 Series Routers” document.

For operation with Microsoft Windows, the Cisco Windows USB Console Driver must be installed on any PC connected to the Console port. If it is not installed, prompts guide you through a simple installation process.

The Cisco Windows USB Console Driver allows plugging and unplugging the USB cable from the console port without affecting Windows HyperTerminal operations. No special drivers are needed for Mac OS X or Linux.

Chapter 3 Cable Information and Specifications for Cisco 1900 Series Routers

“Connecting to the Console Port with Microsoft Windows” section on page 5-4 of the “Cable

Only one console port can be active at a time. When a cable is plugged into the USB console port the RJ

45 port becomes inactive. Conversely, when the USB cable is removed from the USB port the RJ 45

port becomes active.

Baud rates for the USB console port are 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps.

Note 4-pin mini Type-B connectors are easily confused with 5-pin mini Type-B connectors. They are

not compatible Only the 5-pin mini Type-B can be used.

USB Console OS Compatibility

• Windows 2000, Windows XP 32- and 64-bit, Windows Vista 32- and 64-bit

• Mac OS X version 10.5.4

• Redhat / Fedora Core 10 with kernel 2.6.27.5-117

• Ubuntu 8.10 with kernel 2.6.27-11

• Debian 5.0 with kernel 2.6

• Suse 11.1 with kernel 2.6.27.7-9

Cisco 1900 Series Hardware Installation

3-2

OL-19084-01

Chapter 3 Cable Information and Specifications for Cisco 1900 Series Routers

Auxiliary Port Connections

The router has an EIA/TIA-232 asynchronous serial auxiliary port (RJ-45) that supports flow control. Depending on the cable and the adapter used, this port will appear as a DTE or DCE device at the end of the cable.

For connection to a modem, your router is provided with an RJ-45-to-DB-9 cable and a DB-9-to-DB-25 adapter.

For detailed information about connecting devices to the auxiliary port, see the “Connecting to the

Auxiliary Port” section on page 5-9.

For cable and port pinouts, refer to the Cisco Modular Access Router Cable Specifications document on Cisco.com.

Preparing to Connect to a Network

When setting up your router, consider distance limitations and potential electromagnetic interference (EMI) as defined by the applicable local and international regulations.

The following sections describe network connection considerations for several types of network interfaces:

• Ethernet Connections, page 3-3

Preparing to Connect to a Network

• Serial Connections, page 3-3

• ISDN BRI Connections, page 3-5

• CSU/DSU Connections, page 3-6
