Cherry JD-9000GB-1 Product Data Sheet

CHERRY DW 9000 SLIM

Rechargeable Wireless Desktop

1 / 3 © Cherry GmbH • Cherrystraße • 91275 Auerbach/OPf. • Germany
Tel [phone] • Fax [phone] • www.cherry.de • 2017-04-12

Models may vary from the image shown

Rechargeable designer desktop with many
extra features

The CHERRY DW 9000 SLIM desktop set stands out due to its
innovative functions, excellent workmanship and trendy, flat
design.

The mouse and keyboard can be connected using the 2.4 GHz
wireless USB receiver included with the set, or by Bluetooth®. You
can switch connection types in an instant using a switch on the
mouse or keyboard. This allows e.g. a laptop to be operated using
Bluetooth®, as well as allowing a PC to be operated using the same
desktop by means of a wireless connection with AES encryption.
The data are transferred using an AES-128 encryption in both
cases.

The CHERRY DW 9000 SLIM set features rechargeable lithium
batteries that allow you to work throughout the week. You can
then conveniently charge the mouse and keyboard using the micro
USB cable included with the set, even while you are working. To
ensure that the rechargeable batteries are still charged after a
holiday, use a switch to turn off the keyboard and mouse
altogether.

The keyboard contains an integrated metal plate, lending it an
optimal sturdiness and stability. Should you prefer a steeper angle
while typing, you can adjust the keyboard using the 4 rubber feet
included with the set. High stability is ensured by the metal plate,
which prevents bending and bounding when typing.

The use of high-quality scissor mechanisms with a low key stroke
ensures an ideal typing experience. Status LEDs integrated directly
in each key provide information on whether the CAPS LOCK,
SCROLL and NUM keys are activated. In addition, these keys flash
to warn that the battery charging status is low.

The 6 additional keys have proved to be extremely convenient and

practical: “Windows lock”, “Open browser”, “Quieter”, “Louder”,
“Mute” and “Open calculator”.

The mouse, which harmonizes with the keyboard perfectly, also

boasts a wide range of features. It fits ideally in the user’s hand

thanks to its rubber-coated side parts and a compact design. The
resolution can be set in three stages at the touch of a button: 600,
1000, 1600 dpi. A two-color status LED provides the user with
information on the battery status, the charging status, the selected
resolution or the connection status at all times. An extra-durable
mouse wheel with optical scanning and a magnetic storage feature
for the USB receiver are further details that ensure nothing is left
to be desired. The mouse is equally suitable for mobile and
stationary applications.

Key benefits

• Optionally connected using Bluetooth® or a 2.4 GHz wireless

unit – both with AES-128 encryption

• Lithium batteries in the mouse and keyboard can be recharged

via micro USB

• Status LEDs show low residual battery charge, charging status

and mouse resolution

• Additional status LEDs for the CAPS LOCK, NUM and SCROLL

keys

• Extra-small nano receiver for wireless operation

• 6 mouse buttons and a scroll wheel

• Precise sensor with three-level adjustable resolution up to

1,600 dpi

• Durable abrasion-proof laser inscription

• Solid metal plate in the keyboard for maximum stability

• Precise scissor mechanism for an ideal operating feeling

• Rubber feet for individual height adjustment

CHERRY DW 9000 SLIM

Rechargeable Wireless Desktop

2 / 3 © Cherry GmbH • Cherrystraße • 91275 Auerbach/OPf. • Germany
Tel [phone] • Fax [phone] • www.cherry.de • 2017-04-12

Technical Data

Layout (country or language):

Product dependant, see table "Models"

Housing color:

Product dependant, see table "Models"

Key color:

Product dependant, see table "Models"

Weight (product):

Keyboard: approx. 650 g
Mouse: approx. 90 g
Receiver: approx. 3 g

Total weight (with packaging):

approx. 1.000 g

Transmission range:

approx. 10 m

Frequency range:

26.957 MHz - 27.283 MHz (frequency)
Effective radiated power: max. 10 mW [EIRP]

Storage temperature:

-20 °C to 60 °C max 85% humidity

Operating temperature:

0 °C to 40 °C max 85% humidity

Current consumption:

Keyboard: typ. 4 mA
Mouse: typ. 13 mA
Receiver: typ. 28 mA

Interface:

Wireless, optionally using 2.4 GHz frequency (via USB receiver) or
Bluetooth® 4.0 - both with AES-128 encryption

Connection sockets:

• Micro USB port for charging cable

Product approvals:

cURus
CE
FCC
WHQL Win 10 64-bit
Bluetooth® SIG licensing

System requirements:

• For connection using Bluetooth®: Compatible device with

Bluetooth® 4.0 or higher

• For connection via USB: Free USB port (type A),

Windows 7, 8 or 10

Delivery volume:

• Keyboard

• Mouse

• Transport pouch

• Nano-USB transmission receiver

• 4 rubber feet

• USB-A/Micro-USB charging cable

• Manual

Dimensions product:

Keyboard: approx. 440 x 130 x 15 mm
Mouse: approx. 99 x 62,5 x 33,5 mm
Receiver: approx. 19 x 14,5 x 6,5 mm
Rubber feet: approx. 12 x 25 x 17 mm
Charging cable approx. 120 cm

Dimension packaging:

approx. 570 x 170 x 45 mm

Mouse:

• Scanning: Optical Sensor (PixArt)

• Resolution: 600 dpi / 1000 dpi / 1600 dpi (adjustable)

• Number of buttons: 6

• Function button Right/Left-click, Scroll wheel; Browser for;

Browser back, DPI-switch

• Mouse wheel design: Scroll wheel with key function

• Design: Symmetrical

• Power supply Rechargeable lithium-ion battery with 550 mAh

(permanently installed)

• Status LEDs LED for battery charge status, Bluetooth or

wireless connection (Bi-Color LED)

• Housing color: Product dependant, see table "Models"

• Key color: Product dependant, see table "Models"

Keyboard:

• Design: Chiclet-Layout with numeric block

• Key technology: SX

• Service life, standard key: > 10 million key operations

• Inscription technology: Laser

• Anti-slip feet 8 piece (18 x 4 mm)

• Power supply Rechargeable lithium-ion battery with 650 mAh

(permanently installed)

• Status LEDs CAPS LOCK, NUM and SCROLL keys, battery status

(via LED in keys) LED for battery charge status, Bluetooth or
wireless connection (Bi-Color LED)

• Number of Keys: Product dependant, see table "Models"

• Number of additional keys: 6

• Additional keys function: Windows Lock, Browser, Volume up,

Volume down, Mute, Calculator

Packaging unit:

Number of products in the master package: 10
Number of master packages per pallet: 16

Warranty:

2 years

Errors, technical changes and delivery possibilities excepted.
Technical information refers only to the specifications of the
products. Features may differ from the information provided.
