Champion TUW-15 Service Manual

Champion

Fax:

910/661

-

1660

The Dishwashing Machine Specialists

Undercounter
Dishwasher

Technical Manual

Model TUW-15

Machine Serial No.

August, 1992 Manual P/N 111482

P.O. Box 4149
Winston-Salem, North Carolina 27115-4149

Champion Industries, Inc. 910/661 -1556

TABLE OF CONTENTS

WARRANTY SPECIFICATIONS 3
SCHEMATIC 4
ELECTRICAL PRECAUTION 5
INSTALLATION 6
OPERATING AND CLEANING 7
MAINTENANCE AND DESCALING 8
CHEMICAL SETTINGS 9
TIMING CHART 10
TROUBLE-SHOOTING 11

REPLACEMENT PARTS

DOOR COM PLETE 15
FRAME COVER 16
FRAME 17
SOLENOID FILL VALVE 19
VERTICAL PUMP 20
TANK 21
CONTROL BOX 23
CHEMICAL INJECTOR 25
BOOSTER TANK ASSEMBLY 26
DRAIN PUMP ASSEMBLY 27
DRAIN PUMP REPLACEMENT PARTS 28
FASTENER LIST 29

EFFECTIVE AT SERIAL NUMBER 1744 0508129

LIMITED WARRANTY

Champion Industries Inc. (herein referred to as Champion), P.O. Box 4149, Winston-Salem, North Carolina 27115, warrants machines,
and parts, as set out below.

Warranty of Machines: Champion warrants all new machines of its manufacture bearing the name

"Champion" and installed within the United States to be free from defects in material and workmanship for a period of one (1) year
after the date of installation or fifteen (15) months after the date of shipment by Champion, whichever occurs first. [See below for
special provisions relating to glasswashers.] The warranty registration card must be returned to Champion within ten (10) days after
installation. If warranty card is not returned to Champion within such period, the warranty will expire after one year from the date
of shipment.

Champion will not assume any responsibility for extra costs for installation in any area where there are jurisdictional
problems with local trades or unions.

If a defect in workmanship or material is found to exist within the warranty period. Champion, at its election, will either
repair or replace the defective machine or accept return of the machine for full credit; provided, however, as to
glasswashers. Champion's obligation with respect to labor associated wi th any repairs shall end (a) 120 days after
shipment, or (b) 90 days after installation, whichever occurs first. In the event that Champion elects to repair, the labor
and work to be performed in connection with the warranty shall be done during regular wo rking hours by a Champion
authorized service technician. Defective parts become the property of Champion. Use of replacement parts not authorized
by Champion will relieve Champion of all further liability in connection with its warranty. In no event will Champion's
warranty obligation exceed Champion's charge for the machine. The following are not covered by Champion's warranty:

a. Lighting of gas pilots or burners.
b. Cleaning of gas lines.
c. Replacement of fuses or resetting of overload breakers.
d. Adjustment of thermostats.
e. Adjustment of clutches.
f. Opening or closing of utility supply valves or switching of electrical supply current.
g. Cleaning of valves, strainers, screens, nozzles, or spray pipes.
h. Performance of regular maintenance and cleaning as outlined in operator's guide.

i. Damages resulting from water conditions, accidents, alterations, improper use, abuse,
tampering, improper installation, or failure to follow maintenance and operation procedures. j. Wear on Pulper
cutter blocks, pulse vanes, and auger brush.

Examples of the defects not covered by warranty include, but are not limited to: (1) Damage to the exterior or interior finish as a

result of the above, (2) Use with utility service other than that designated on the rating plate, (3) Improper connection to utility

service, (4) Inadequate or excessive water pressure, (5) Corrosion from chemicals dispensed in excess of recommended

concentrations, (6) Failure of electrical components due to connection of chemical dispensing equipment installed by others, (7)

Leaks or damage resulting from such leaks caused by the installer, including those at machine table connections or by connection

of chemical dispensing equipment installed by others, (8) Failure to comply with local building codes, (9) Damage caused by labor

dispute.

Warranty of Parts: Champion warrants all new machine parts produced or authorized by Champion to be free from defects in material

and workmanship for a period of 90 days from date of invoice. If any defect in material and workmanship is found to exist
within the warranty period Champion will replace the defective part without charge.

DISCLAIMER OF WARRANTIES AND LIMITATIONS OF LIABILITY. CHAMPION'S WARRANTY IS ONLY TO THE
EXTENT REFLECTED ABOVE. CHAMPION MAKES NO OTHER WARRANTIES. EXPRESS OR IMPLIED. INCLUDING,
BUT NOT LIMITED, TO ANY WARRANTY OF MERCHANTABILITY, OR FITNESS OF PURPOSE. CHAMPION SHALL
NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. THE REMEDIES SET OUT ABOVE ARE THE
EXCLUSIVE REMEDIES FOR ANY DEFECTS FOUND TO EXIST IN CHAMPION DISHWASHING MACHINES AND
CHAMPION PARTS, AND ALL OTHER REMEDIES ARE EXCLUDED. INCLUDING ANY LIABILITY FOR
INCIDENTALS OR CONSEQUENTIAL DAMAGES.

Champion does not authorize any other person, including persons who deal in Champion dishwashing machines to change this warranty
or create any other obligation in connection with Champion Dishwashing Machines.

SCHEMATIC

WARNING WARNING WARNING

FAILURE TO FOLLOW PROPER INSTALLATION
INSTRUCTIONS MAY VOID WARRANTY

PLUMBING CONNECTIONS MUST BE MADE BEFORE POWER IS
CONNECTED TO THE MACHINE. DAMAGE TO THE BOOSTER
HEATER ELEMENTS WILL RESULT OTHERWISE.

PLUMBING

Water Supply: Con nect the machine to a 1/2 inch hot water line.
The minimum incoming water temperature and pressure is 140°F at 25 PSI.
The maximum incoming water temperature and pressure is 160°F at 90 PSI.
Drain: Connect to a 1/2 inch tailpiece in accordance with local plumbing codes.

THIS MACHINE SHOULD BE CONNECTED TO A 115/208 OR 120/240 VOLT
A.C. 4 WIRE, SINGLE PHASE SERVICE FUSED AT 50 AMPS.

FOLLOW THESE STEPS:

1. CONNECT NEUTRAL AND L1 WIRES, LEAVING L2 WIRE
TEMPORARILY DISCONNECTED.

2. a) PUSH "ON-OFF" SWITCH TO "ON-FILL" POSITION.
b) CLOSE DOOR AND TURN HANDLE.
c) PUSH "DE-LIME" SWITCH TO "DE-LIME" POSITION FOR

APPROXIMATELY 1 MINUTE. RETURN TO "OFF"
POSITION.

d) ALLOW MACHINE TO COMPLETE FILL CYCLE.

3. CONNECT THE L2 WIRE.

ELECTRICAL CONNECTIONS SHOULD BE MADE BY A
QUALIFIED ELECTRICIAN IN ACCORDANCE WITH LOCAL
ELECTRICAL CODES.

INSTALLATION PLUMBING

PREPARATION

The warewasher must be installed on a level, rigid surface. Allowance is to be made for water and drain
lines to the unit. When situated, the machine must be completely sealed to the floor using a good grade of
silicone sealant.
Area allowance Width 24" (610 mm)

Height 33-1/2" (851 mm)
Depth 23-1/2" (597 mm)

Remove the packing and dishware racks
from the interior of the warewasher.

WATER
Install a shut -off valve between the supply

and the dishwasher in an accessible
location. Connect the warewasher to the
hot water supply. The incoming water
temperature is

140° F (60° C) minimum and
160° F (71.1° C) maximum. Flow rate is

3.3 Imp. gal., 4 US gal. (13.6 L) per
minute.

Flow pressure:
Minimum 25 psi (172.5 kPa)

Maximum 95 psi (656 kPa)
DRAIN PUMP

Connect 1/2" (12.7 mm) flexhose to 1-1/2" (38 mm) drain piping as per local plumbing code. Drain should
not be in excess of 6 feet (1.56 m) above floor level or at a distance more than 40 feet (12.25 m) away for a
remote location.

ELECTRICAL
Have the heater switch and start switch in "OFF" position. The 500UT needs a six-foot (1.8 m) power cord

with a "U" ground parallel blade plug. Provide a 115/208 or 115/240 V, 60 Hz, A.C. 4-wire, single phase
service fused at 50 amps grounding receptacle in an accessible location within four feet of the warewasher.
This should be installed by a qualified electrician in accordance with the local electrical code specifications.

OPERATION

OPERATING INSTRUCTIONS

1. Be sure screen assemblies are in place.

2. Be sure there is detergent in the detergent container.

3. With door latch open, turn cycle switch to "ON-FILL" Close door, allow machine to fill automatically.

4. Pre-scrap all heavy soils from dishes before loading into machine.

5. Load pre-scrapped dishware into machine.

6. Close door and latch handle. Cycle will start.

7. When cycle light goes out, cycle is complete.

8. Open door, remove clean dishware.
NOTE: The door must be open for three (3) seconds for automatic cycle to reset before starting
another cycle.

9. After initial start -up each day, all other cycles are automatic-just load, close door and place door handle

in locked position to start cycle.

DRAINING THE MACHINE

1. Turn the "ON-OFF" switch to "OFF-DRAIN" position.

2. Close the door.

3. Allow machine to automatically drain (approximately 1-1/2 minutes).

DAILY CLEANING INSTRUCTIONS

1. Drain machine.

2. Remove scrap screens assembly and screen support assembly.

3. Empty and clean scrap screens and screen support assembly.

IMPORTANT: Do not operate the warewasher with the screen assemblies covered with food
particles. Keep the screens clean. Pre -scraping or pre-flushing of dishware to remove heavy, loose

particles of food is recommended. Failure to keep screens clean will result in poor wash results and
could prevent proper draining during cycle.

4. Wipe down the interior of the unit with a mild soap solution, then wipe down with a clean cloth.

5. Replace the screen support and screens.

6. Close door, remove drip tray, clean and replace.

7. At the end of the work day, after completing steps 1 to 6, leave door partially open to allow the machine

wash tank to air-dry overnight.

NOTE: THE WASH TANK SHOULD BE LEFT EMPTIED
OVERNIGHT.

7

MAINTENANCE

DESCALING

Descaling the warewasher interior may be necessary in areas with hard water. General descaling can be
done by spraying a descaling chemical directly onto the scaled surface until the scale is removed, then
flushing with fresh water.

To descale the interior wash well proceed as follows:

1. With door latch open, set cycle switch to "ON-FILL" Close door and allow machine to fill
automatically with fresh hot water to the normal water level.

2. Open door and add descaler to wash well in the amount recommended by your chemical supplier.

(The usual amount is one to two cups.)

3. Close door to start a wash cycle and immediately set delime switch to "ON." Allow machine to run for
approximately 5 minutes, depending on scale conditions.

4. Set delime switch to "OFF" and allow machine to finish cycle.

5. Run an additional standard wash cycle to ensure that the machine has been entirely rinsed and flushed
of descaling chemical.

WARNING: Descaling chemicals are to be used with caution. Consult your chemical supplier for the
proper use and handling instructions.

Scheduled preventive maintenance practices will greatly increase the efficiency of your machine. A
machine that is well-maintained will not break down as frequently as one which receives only occasional
care. A small investment of a few minutes each day will pay you dividends in the form of many trouble-free
hours of faithful service.

The best maintenance you can give you dishwashing machine is to keep it Clean. By periodically cleaning
and flushing the machine, you can add greatly to its life expectancy. The components of a machine that
suffers from neglect will soon clog up and become inoperative.

SAFETY FEATURES

The warewasher will not operate with the door open. Close the door and turn the handle down until it
reaches the stop position.

CHEMICALS

CHEMICAL INJECTORS

NOTE: IT IS RECOMMENDED THAT A NON
CHLORINATED DETERGENT BE USED.

The built-in chemical injectors will provide accurate dispensing and reliable operation.
Flush the chemical lines once a week with fresh hot tap water to prevent chemical crystalization inside the

chemical tubing and possible damage to chemical pumps.
Place the chemical tubes in a container of hot water and flush thoroughly by holding the prime switch •ON."
Visually inspect the hoses for possible leaks. If any hoses are in need of repair, contact your authorized

service agent. Return the chemical feed lines to their proper chemical containers and reprime them with
chemical.

CHEMICAL SETTINGS

To adjust the chemical
concentration, do the following:

1. Remove the drip tray.

2. Remove the top left -hand screw
from the control box to allow the
front panel to hinge forward.

3. Rotate the cam set by pushing the top
of the cams slowly towards the back of
the warewasher until the locking
screws on the adjustable cams are
accessible.

4. Loosen the lock screw for the chemical to be adjusted and increase or decrease the cam gap as
desired. Increasing the gap in the cam increases the volume of chemical dispensed.

5. Tighten the locking screw sufficiently to ensure the cam will not move.

6. Replace the front panel mounting screw and the drip tray.

7. Operate the machine.

TROUBLE-SHOOTING

Check water line pressure. Ensure recommended flow

solenoid

1. WAREWASHER WILL NOT OPERATE

CAUSE REMEDY

1. Power cord not plugged into power outlet. 1. Plug into outlet.

2. No power. 2a. Check main cycle switch is in "ON" position.

3. Door not closed. 3. Ensure door is closed and door handle is

4. Door switch out of adjustment or defective. 4a. Reposition or replace door switch or replace

5. Cycle not resetting. 5a. Unlatch door handle for full 3 seconds to allow

b. Check electrical panel for blown fuse or tripped

circuit breaker.

c. Door opened between wash and rinse cycle.

Close door and allow machine to finish cycle.

turned down until it reaches stop position.
Check door locking cam is properly positioned
and secured to door handle shaft.

handle.

b. Replace homing timer switch if defective.

cycle timer to reset.
b. Replace homing cam switch.
c. If set screw on timer cam shaft assembly is

loose, tighten it.

2. WASH WELL UNDERFILLS

CAUSE REMEDY

Fill cam #5 on timer control shaft out of

1.

adjustment.

2.

Insufficient water pressure.

3.

Defective fill solenoid coil.

4.

Filter screen in the fill solenoid is plugged.

5.

Defective water fill switch on timer.

6.
Drain solenoid valve is leaking.

1. Reset fill cam to provide proper time to fill
to screen level.

2.
rate and pressure are provided. (25 psi /172.5 kPa
flow pressure)

3. Replace solenoid coil.

4. Clean the screen.

5. Replace the switch.

6. Clean debris from valve seat or replace drain
valve.

TROUBLE-SHOOTING

Screen assemblies and pump screen covered

Reset fill cam to provide proper

Cycle switch, or drain switch, or pump motor cam switch

Remove foreign matter from pump intake screen

ies and pump screen clean

gged at rear of control

3. WASH WELL OVERFILLS

CAUSE REMEDY

1.
with foreign matter preventing complete
removal of wash water during drain cycle.

2. Fill cam #5 on timer not set properly to fill to
top of screen assemblies.

3. Pump intake filter plugged with foreign matter. 3. Clean out wash well and pump intake

4. Drain solenoid valve blocked or not opening. 4. Clean obstruction or replace drain

5. Main drain piping blocked. 5. Have piping unplugged by plumber.

6. Drain pump not operation. 6. Repair or replace drain pump.

4. WASH WELL DO ES NOT DRAIN PROPERLY

1. Keep screen assemblies and pump
screen clean at all times.

2.
adjustment of water level (just above
scrap screens).

flter.

solenoid valve.

CAUSE REMEDY

1.
in control panel faulty.

2. Pump plugged with foreign matter. 2.

3. Defective pump impeller. 3. Replace the impeller.

4. Defective pump motor assembly. 4. Replace the pump motor assembly
Screen assemblies and pump screen

5.
covered with foreign matter preventing

wash water return to pump.

6. Main drain plugged. 6. Clear obstruction from drain.

1. Replace the defective switch.

and/or pump assy

5. Keep screen assembl
at all times.

7. Drain pump not operating. 7. Repair or replace.

8. Drain solenoid will not open.

9. Drain solenoid will not close.

10. Drain hose blocked or kinked 10. Replace hose.

8a. Solenoid coil defective. Replace
b. Solenoid power cord unplu

box. Replug.

c. Drain valve arm broken or disconnected.

Replace drain valve assembly.

9a. Drain mechanism jammed with soils. Clean.
b. See 8c.

5. WASH WELL CONTINUALLY FILLS WHEN UNIT IS NOT OPERATING

TROUBLE-SHOOTING

CAUSE

1. Dirt under seat of solenoid fill valve or worn seat.

2. Fill timer cam switch defective.

REMEDY

1. Clear seat of obstruction; replace solenoid valve
or install rebuild kit for solenoid valve if
necessary.

2. Replace fill timer cam switch.

6. WASH WATER BELOW MINIMUM RECOMMENDED TEMPERATURE (140°F / 60°C)

CAUSE REMEDY

1. Thermostat set too low.

2. Defective thermostat.

3. Defective wash tank heater,

4. Manual reset tripped on wash tank high limit
thermostat.

5. Water supply temperature from the hot water
tank too low. 140°F minimum required

1. Increase temperature by turning
thermostat control clockwise. (Located inside
control box.)

2. Replace thermostat.

3. Replace wash tank heater.

4. Push reset button on wash tank high limit
thermostat (located between heater
terminals).

5a. Hot water tank too small: replace with

properly sized tank.

b. Thermostat control on hot water tank set

too low. Adjust to correct setting.

c. Heater element in hot water tank defective.

7. CHEMICAL NOT FEEDING

CAUSE

1. No chemical in container.

2. Feed lines to and from chemical pump plugged.

3. Screen on feed line plugged.

4. Chemical feeder defective.

5. Defective chemical injector pump.

6. Chemical feeder system not plugged into rear of
control box.

7. Tubing kinked or split.

8. Worn chemical pump rotor.

9. Element tube split or loose hose clamps or ties.

REMEDY

1. Replace with full container.

2. Clear obstruction. Flush lines with hot water.

3. Clean.

4. Repair or replace feeder.

5. Repair or replace chemical injector pump.

6. Plug in.

7. Unkink or replace tubing.

8. Replace chemical pump rotor.

9. Replace element tube on chemical pump.

8. DISHES DO NOT WASH PROPERLY

CAUSE REMEDY

TROUBLE-SHOOTING

1. Improper concentrations or type of
detergent being used in wash well.
NOTE: Commercial grade must be
used.

1. Check with a qualified chemical sales
representative for proper concentration and type
of product to be used for local water conditions. Wash
well holds 7 qts. (8 L) of water when at
screen assembly level.

2.

Overloading of dishware in dishrack. 2. Space dishware in dishrack allowing room for water to

3.
Insufficient water in wash well.

circulate through dishware.

3a. Re-adjust fill cam to bring level jus t above screen

assemblies.

b. Check line flow rate and pressure.

4. Wash arms not turning. 4. Remove obstruction such as cutlery, or clean spray

nozzles and spray arm support.

5. Pump not operating. 5. Ensure that snap-type electrical connector for pump is

secure.

6. Defective or worn pump impeller. 6. Replace the impeller.

7. Defective pump motor assembly. 7. Replace the pump motor assembly.

8.

Wash water temperat ure too low.

8a. Must not be less than 140° F (60° C) and not

higher than 160° F (71.1° C) for best wash results.
b. Check wash tank heater thermostat is properly set.
c. Wash tank thermostat is defective. Replace.
d. Booster not providing 180° F water. Check booster for

proper temperature.
e. If capacity insufficient, install the correct size hot water

tank to provide 140°F/60°C constantly.

9.

Worn spray arm support. 9. Loss of wash water pressure due to worn spray arm

support. Replace spray arm support.

10. Pump intake or scrap screens blocked. 10. Clean pump intake screen and scrap screens.

11. Lime scale build-up inside wash tank. 11. Descale warewasher regularly using the proper
descaling chemical. Contact your chemical supplier for

the proper product and use directions.

12.

Rinse water below 180°F (82°C)
minimum required temperature for
proper sanitation.

12a. Heater elements defective. Replace elements (located

on front of booster tank).

b. Thermostat improperly set. Adjust.
c. Thermostat tripped or defective. Reset by

pushing button in on high limit switch, or replace if
defective.

d. High temperature cut -off thermostat defective.

Replace.

e. No power to booster. Check circuit breaker OR

check for loose connection OR check for broken wire
at terminal block.

REPLACEMENT PARTS

PART NUMBER ITEM NO. DESCRIPTION QTY/PER
0700308 1 DOOR WELDED ASSY 1

0501922 2 DOOR HANDLE 1
0503715 3 DOOR EXTENSION SPRING 2
0307358 4 DOOR CAM 1
0501413 5 #10-32 x 3/8 RH SS MC SCREW 1

REPLACEMENT PARTS

FRAME COVER

PART NUMBER ITEM NO. DESCRIPTION QTY/PER
0708104 1 FRAME ASSEMBLY WELDED 1

0300304 2 TOP PANEL 1
0307568 3 LH SIDE PANEL 1
0307569 4 RH SIDE PANEL 1
0308114 5 GLIDE FOOT 4
0307573 6 FRONT PANEL 1
0503716 7 GROMMET 1

REPLACEMENT PARTS

FRAME

PART NUMBER ITEM NO. DESCRIPTION QTY/PER
0708104 1 FRAME ASSEMBLY WELDED 1
0300067 2 DOOR STOP 2
0300069 3 HINGE BAR 2
0502618 4 3/8 MPT x 1/2 COUPLER 1
0705502 5 DRIP TRAY SUPPORT ASSEMBLY 1
0705479 6 DRIP TRAY ASSEMBLY 1
0300065 7 VALVE SUPPORT 1
0503713 8 REDUCING ELBOW 1/2 FPT x 3/8 MPT 1
0504952 9 115 V FILL SOLENOID VALVE, 3 GPM 1
0505235 10 COIL 155V, 60 HZ 1
0505229 11 SOLENOID GUIDE 1
0502811

0502809 14 DIAPHRAGM 1
0502803 16 SCREEN 1
0502808 17 FLOW WASHER, 3 GPM 1
0306208 18 CABLE CLAMP 1
0307373 19 CABLE CLAMP BRACKET 1
0300203 20 CLAMP 1
0708106 21 CONNECTION BOX 1
0305096 22 THERMOMETER ADJUST BRACKET 1
0503656 23 HEYCO CABLE CLAMP 1
0705544 24 TERMINAL BLOCK 1
107417 25 1/2 ID RUBBER HOSE 5-FT
0300164 26 WATER INLET TUBE 1
0503656 27 3/8 GROMMET 1
0300084 NS NUT PLATE 8-32 TAP 1
0505506 NS FILL VALVE HARNESS 1

12 SPRING 1
13 PLUNGER 1

FILL VALVE REPAIR KIT 1

REPLACEMENT PARTS

REPLACEMENT PARTS

INLET PLUMBING

PART NUMBER ITEM NO. DESCRIPTION QTY/PER
0300203 NS INLET PLUMBING CLAMP 1
0504952 1 230V 60HZ SOLENOID FILL VALVE 2
0505235 2 COIL - 230V 60HZ 1
0306208 3 CABLE CLAMP COVER 1
0700899 4 CABLE CLAMP ASSY 1
0505229 5 SOLENOID GUIDE 1
0502811 6 DIAPHRAGM KIT 1
0502808 7 FLOW WASHER 1
0502807 8 WASHER 1
0502804 9 WASHER 1
0502803 10 SCREEN 1

PART

VERTICAL PUMP

NO.

REPLACEMENT PARTS

ITEM

DESCRIPTION QTY/PER

NO.

0504910
0501659
0501431
0501425
0707619
0502704
0502703
0502744
0502705
0501457

VERTICAL PUMP & MOTOR ASSEMBLY 1
1 SPRAY ARM PIVOT 1
2 #8-32 x 1-1/8 RH SS SCREW 4
3 #8-32 x 5/8 RH SS SCREW 4
4 PUMP SERVICE KIT 1
5 IMPELLER 1
6 •O" RING SEAL 1
7 PROPELLER/ROTATING SEAL 1
8 SEAL/MOUNTING PLATE ASSY 1
9 10-32 x 7/8 HEX HD BOLT 4

TANK

REPLACEMENT PARTS

PART NUMBER ITEM NO. DESCRIPTION QTY/PER

0708105 1 TANK ASSEMBLY WELDED 1
0503717 2 DOOR SIDE GASKET 19" LONG 2
0501882 3 DOOR TOP GASKET 20-5/8" LONG 1
0503727 NS DOOR SWITCH HARNESS 1
0300132 5 DOOR SWITCH INSULATION 2
0501382 6 DOOR SWITCH 1
0300074 7 NUT PLATE 1
0300073 8 SWITCH PLATE 1
0705487 9 RH & LH SCREEN FRAME ASSEMBLY 2
0700079 10 LH TRAY SLIDE ASSEMBLY 1
0700080 NS RH TRAY SLIDE ASSEMBLY 1
0700311 12 VENT COVER ASSEMBLY 2
0704892 13 MOTOR GUARD SCREEN 1
0703373 14 SPRING CLIP ASSEMBLY 1
0700006 15 OVERFLOW COVER 1
0501836 16 HEATER "0" RING 1
0504601 17 HEATER 1200 W, 240V 500HT/UT 1
0501650 18 THERMOSTAT REDUCER 1
0501881 19 WASH PUMP GASKET 1
0501896 20 THERMOMETER SEAL 1
0305097 21 HEATER BOX 1
0300061 22 HEATER COVER 1
0504602 23 THERMOMETER 2" DIAL, 12" STEM 1
0503574 NS STRAIN RELIEF BUSHING, SMALL 1
0301684 25 BOTTOM SPRAYARM LOCK NUT 1
0705486
0705049 26 BOTTOM SPRAYARM 1
0501563 27 #8 x 3/8" TH SLOT TYPE "A" 2
0505044 28 BOTTOM SPRAYARM SUPPORT 1
0707602 29 SCREEN SUPPORT ASSEMBLY 1
0504910 30 VERTICAL PUMP AND MOTOR ASSY, 115 V, 60 HZ 1
0305495 31 CONNECTION TUBE 1
0503679 32 7/16 SS GEAR-TYPE HOSE CLAMP 2
0306618 33 DRAIN VALVE, REWORKED 1
0705041 34 TOP MANIFOLD ASSEMBLY 1
0305051 35 MANIFOLD CLIP 2

LOWER SPRAYARM ASSEMBLY 1

TANK

REPLACEMENT PARTS

PART NUMBER ITEM NO. DESCRIPTION QTY/PER

0705507
0705047 36 UPPER SPRAYARM 1
0505043 37 UPPER SPRAYARM SUPPORT 1
0501563 NS #8 x 3/8 TH SLOT 1
0505042 38 UPPER SPRAYARM PIVOT 1
0505485 39 STEAM GASKET 2
0507098 40 WASH TANK LIMIT THERMOSTAT 1
0305067 NS RH SCREEN SUPPORT 1
0507097 NS HEATER HARNESS 1

UPPER SPRAYARM COMP. 1

REPLACEMENT PARTS

CONTROL BOX

PART NUMBER ITEM NO. DESCRIPTION QTY/PER

0708108
0705524 1 CONTROL BOX BOTTOM ASSEMBLY 1
0503747 2 RED NEON LAMP, 115V 1
0503765 3 AMBER NEON LAMP, 240 V 1
0503749 4 11 POINT TERMINAL BLOCK 1
0501361 5 DPDT ROCKER SWITCH 20 AMP 2
0300108 6 RH TIMER SUPPORT 1

0504956 ' 7 25 RPH 115V TIMER MOTOR 1

0705087 8 CONTROL BOX REAR ASSEMBLY 1
0501379 9 15 AMP TIMER SWITCH 10
0501479 10 1/4 OD x 1/8 x 1/16 FLAT FIBER WASHER 12
0503740 11 TIMER STUD, 4-1/4' LONG 2
0505605 12 TIMER PIN, 3-1/4" LONG 1
0503664 13 •E' RETAINER RING, 3/16 SHAFT 2
0305084 14 CONTROL BOX COVER 1
0300053 15 ADJUSTABLE DETERGENT CAM 1
0503735 16 ADJUSTING SPACER 1
0501507 17 5/16 LOCKWASHER INT -TOOTH CRS 1
0501543 18 5/16-24 JAM NUT, SS 1
0503701 19 TIMER SHAFT BEARING 1
0300099 20 LH TIMER SUPPORT 1
0503573 21 SWITCH INSULATION, LARGE 2
0501358 22 WASH PUMP START RELAY 1
0708107 23 CONTROL BOX FRONT ASSEMBLY 1
0300096 24 THERMOSTAT SUPPORT 1
0501380 25 VARIABLE THERMOMETER 1
0300052 26 DETERGENT CAM 1
0300237 27 ADJUSTABLE CAM 2
0305069 28 CHEMICAL FILL CAM 1
0301672 29 CAM SPACER 4
0305072 30 DRAIN CAM, WASH PUMP REVERSE CAM 2
0308382 31 WASH PUMP CAM 1
0300124 32 HOMING CAM 1
0501397 33 #6-40 x 3/16 SOCK SET CUP PT 2
0501369 34 SPRING RETURN ROCKER SWITCH 1

CONTROL BOX ASSEMBLY 1

CONTROL BOX

REPLACEMENT PARTS

PART NUMBER ITEM NO.

0503737 35 TIMER SHAFT 1
0508112 NS CONTROL BOX HARNESS 1
0305068 37 FILL VALVE, AUTO FILL & DRAIN CAM 2
0503647 NS STRAIN RELIEF BUSHING, MEDIUM 1
0505530 NS WASH PUMP HARNESS 1
0505514 NS CAM ADJUSTMENT LABEL 1

0508130 NS UT SCHEMATIC 1

DESCRIPTION QTY/PER

CHEMICAL INJECTOR ASSEMBLY

REPLACEMENT PARTS

PART NUMBER ITEM NO.

0705611
0305089 1 PUMP COVER 1
0705092 2 PUMP HOUSING ASSEMBLY 1
0706635 3 45 CC ELEMENT TUBE ASSEMBLY 1
0503574 4 STRAIN RELIEF BUSHING, SMALL 1
0503756 5 RINSE-AID PUMP MOTOR, INJECTOR UNIT 115 \/

0707142 6 ROTOR 1
0503757 7 DETERGENT PUMP DRIVE MOTOR, 115 V, 60 HZ 1
0503754 8 MASTERFLEX PUMP C/W HARDWARE 1
0503755 9 DETERGENT PUMP HOSE 7 FT.
0304883 10 ELBOW HOSE SPACER 2
0502644 11 1/4- HOSE BARB ELBOW 2
0502718 8A BEARING 2
0502715 8B SPINDLE C/W ROTOR 1
0502713 8C PUMP HEAD 2
0503301 NS COVER WARNING LABEL 1
0503592 NS EARTH LABEL 1
0503694 NS SANITIZER LABEL 1
0503695 NS DETERGENT LA BEL 1
0505518 NS CHEMICAL INJECTOR HARNESS 1
0503575 NS .125 BUTT CONNECTOR INSULATION 2
0503758 NS CLOSED END CONNECTOR 1
0501472 NS #10 L FLAT WASHER, BRASS 2
0501518 NS 5-1/2" NYLON TIE 2

CHEMICAL INJECTOR ASSEMBLY 1

(OPT. ON LITTLE CAESAR'S ONLY)

DESCRIPTION QTY/ PER

1

REPLACEMENT PARTS

PART NUMBER ITEM DESCRIPTION QTY/PER

0705520
0705065 1 BOOSTER TANK WELDED 1
0707243 2 END COVER 1
0707480 3 HEATER ASSY. 2
0507315 4 240-V, 3000-W HEATER 2
0503588 5 •O" RING 1/8' x 1-3/8" SILICONE 2
0503647 6 STRAIN RELIEF BUSHING 1
0504953 7 BOOSTER THERMOSTAT 1
0507095 8 BOOSTER LIMIT THERMOSTAT 1

107417 9 1/2- ID RUBBER HOUSE (OUTLET) 5'
0300164 10 WATER INLET TUBE 1
0502665 11 INLET LINE 1/2- BRAIDED TUBING 16"
0307716 12 BOOSTER THERMOSTAT BRACKET 1
0507096 NS BOOSTER TANK HARNESS 1
0503679 NS 7/16 S.S. GEAR-TYPE CLAMP 1

BOOSTER TANK COMPLETE 1

DRAIN PUMP ASSEMBLY

DESCRIPTION

REPLACEMENT PARTS

PART NUMBER ITEM NO.

C35065 1 DRAIN PUMP 1
0508139 2 COUPLING 1/2x1/2NPTF 1
0508140 3 ELBOW 1/2 HOSE x 1/2 NPTM 1
0508141 4 ADAPTOR 1/2 HOSE X 3/4 NPTM 1
0502665 5 1/2" BRAIDED HOSE 1
0508128 6 TEE 1/2 HB x 1/2 HB x 1/2 NPTM 1
0508127 7 CHECK VALVE 1/2 NPTF x 1/2 NPTF 1
0508126 8 CLOSE NIPPLE 1/2 NPT x 1/2 NPTM 1
0508125 9 ADAPTOR 1-1/2 NPTM x 1/2 NPTF 1
0508124 10 ADAPTOR TAILPIECE 1-1/2 COUPF x 1-1/2 NPTF 1
0501833 11 1 /2" HOSE C/W COUPLING 10 FT
0308119 NS PUMP HOLD-DOWN STRAP 1

QTY/PER

REPLACEMENT PARTS

DRAIN PUMP PARTS

DRAIN PUMP PARTS

PART NUMBER ITEM NO. DESCRIPTION QTY/PER

0508368 1 VOLUTE 3/4 NPT 1
0508369 2 IMPELLER, NYLON 1
0508370 3 GASKET

MOUNT SCREWS #10-24 x 1-5/8" LARGE 3

SERVICE INSTRUCTIONS

MAKE CERTAIN THAT THE UNIT IS DISCONNECTED FROM THE POWER
SOURCE BEFORE ATTEMPTING TO SERVICE OR REMOVE ANY
COMPONENT!

1. This unit is permanently lubricated. Oiling is not required. Do not, in any case, open the sealed portion of
the unit or remove housing screws.

2. Periodic cleaning of the pump parts will prolong the LIFE and EFFICIENCY of the pump. Refer to the above
picture for the assembly and disassembly of the pumping head.

3. First remove the three screws on the left. (Do NOT remove other screws which may be exposed.)

4. Lightly clean any corrosion or debris which may clog the impeller. Use a brush and penetrating oil and
lightly scrape to remove encrusted material.

5. Turn the impeller by hand to make sure it turns freely. If it is rotating, install parts in reverse order in which
they were removed.

6. If it does not rotate, if pump is tripping circuit breakers, or not operating properly after cleaning, return to an
authorized service agent. DO NOT attempt repairs yourself.

7. Be certain power cord is in good condition and contains no nicks or cuts.

REPLACEMENT PARTS

FASTENERS

PART NUMBER DESCRIPTION
0501397 6-40 x 3/16 SET SCREW
0501403 10-32 x 3/4 RH BRASS SCREW
0501404 10-32 x 3/8 RH BRASS SCREW
0501406 8-32 x 1/2 RH SLOT SS SCREW
0501408 8-32 x 1/4 TRUSS SLOT SS SCREW
0501412 10-32 x 3/8 TRUSS SLOT SS SCREW
0501413 10-32 x 3/8 RH HD SS SCREW
0501415 SS RH 10-32 x 5/8 SCREW
0501418 SS RH 1/4-20 x 1/2 SCREW
0501419 1/4-20 X 1/2 HEX HD SS BOLT
0501424 SS HH 1/4-20 BOLT
0501425 SS RH 8-32 x 5/8 SCREW
0501436 SS RH 4-40x1/4 SCREW
0501441 TYPE 23 10-32 x 5/16 SCREW
0501450 SS NIBS 6-32 x 1/4 SCREW
0501463 RH 8-32 X 1 SCREW
0501472 #10 BRASS FLAT WASHER
0501476 SS FLAT 1/4 WASHER
0501479 FIBER FLAT WASHER
0501493 #10 EXTERNAL TOOTH LOCKWASHER
0501496 LOCK WASHER, EXTERNAL TOOTH 5/16
0501497 #8 SPLIT LOCKWASHER
0501501 1/4 SPLIT LOCKWASHER
0501518 5" PLASTIC HOSE TIE
0501519 4" PLASTIC HOSE TIE
0501533 10-32 BRASS HEX NUT
0501539 1/4-20 SS HEX NUT
0501549 KEPS NUT 4-40
0501563 SS TH 8-32 x 3/8 SCREW
0501565 SS TH 10-32 3/8 SCREW
0503679 7/16 GEAR TYPE CLAMP
0503723 6-32x1 RH SS SCREW
0503724 SS HH 5/16-18 BOLT
0503743 PLASTIC TIE, 5"
0503745 RH 8-32 x 3/16 SCREW
0504911 PH 8 5/16 SCREW
0504941 ALUMINUM POP RIVET 5/32
0506589 6-32 x 7/8 PAN SS SCREW
0502665 BRAIDED HOSE
0503755 CHEMICAL TUBING
0506591 DETERGENT TUBING

29
