Illustrated Parts List
Model Series
15C100
TYPE NUMBERS
0111 through 8939.
TABLE OF CONTENTS
Blower Housing/Shrouds 6............
Camshaft 2...........................
Carburetor 4..........................
Controls 5............................
Crankcase Cover 2....................
Crankshaft 2..........................
Cylinder 2............................
Cylinder Head 3.......................
Electric Starter 5......................
Exhaust System 6.....................
Flywheel 6............................
Fuel Supply 4.........................
Governor Spring 5....................
Ignition 5.............................
Kits/Gaskets -- Carburetor 4...........
Kits/Gaskets -- Engine 2...............
Kits/Gaskets -- Valves 3...............
Lubrication 2.........................
Piston Group 2.......................
Rewind Starter 5......................
FORM MS--3946--02/22/2010
15C100
All rights reserved. No part of this material may be reproduced or transmitted,
in any form or by any means, electronic or mechanical, including photocopying,
recording or by any information storage and retrieval system, without permission
in writing from Briggs & Stratton Corporation.
COPYRIGHT by BRIGGS & STRATTON CORPORATION
PRINTED IN U.S.A.
15C100
Not for
Reproduction
1319 WARNING LABEL
REQUIRED when replacing parts
with warning labels affixed.
1
616
615
552
718
2
3
15
1058 OPERATOR’S MANUAL
584
585
684
307A
307B
306A
307
998
15B
847
524
287
1330 REPAIR MANUAL
523
842
22
742
746
219
220
18A
18
415
20
1019 LABEL KIT
415
12
21
12
17
25
27
29B
32
26
28
27
3
12
7B
46
358B ENGINE GASKET SET
20
868
51
883A
993
598
24
20
21
16
146
741
1022
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3946--2 Assemblies include all parts shown in frames. 02/22/2010
2
15C100
Not for
Reproduction
383
5
36
40
33
238
7B
337
34
868
635
35
40
155
993
238
635A
45
122
51
1022
619
1026
13
1029
192
830
1034
7B
1095A VALVE GASKET SET
51
868
993
1022
1023
1022
914A
914B
914
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3946--3 Assemblies include all parts shown in frames. 02/22/2010
3
15C100
Not for
Reproduction
125A
127
51
98
97
633A
95
975
130
692
117
133
137
109C
127A
134
276
276
633
108
104
186
104
122
51
121 CARBURETOR OVERHAUL KIT
127
127A
977 CARBURETOR GASKET SET
137
118
51
365
276
134
137
122
51
276
633
633A
276
633
633A
972
957
190
957A
187
601
187A
601
187B
601
958
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3946--4 Assemblies include all parts shown in frames. 02/22/2010
4
15C100
Not for
Reproduction
222G
504
621
190
773
608A
55A
427
271A
668
813
1230
1211
503
442
1210
188
485
493B
222F
190
526
459
58
501
689
632
209
456
60B
597
188
1230
1119
1054
990
271
474A
892
347
270
990A
227
562
505
268
269
333
851
334
356C
356J
356L
65A
309A
930
697
356N
1403
578B
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3946--5 Assemblies include all parts shown in frames. 02/22/2010
5
15C100
Not for
Reproduction
1196A
731B
731A
363
1196
472C
1005A
493A
318
996
23
976
528
11B
1011
663
663
281A
604A
604B
564
1252
1251A
1070
455
332A
1036 EMISSIONS LABEL
304
65
1005
305
727
37
78
732
832D
836E
300E
613D
883A
1251B
1252A
832E
836E
676D
677A
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3946--6 Assemblies include all parts shown in frames. 02/22/2010
6
15C100
Not for
Reproduction
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1 794188 Cylinder Assembly
2 399269 Kit--Bushing/Seal
(Magneto Side)
3 K299819S Seal--Oil
(Magneto Side)
5 791720 Head--Cylinder
7B K∅791716 Gasket--Cylinder Head
11B 695745 Tube--Breather
12 K699485 Gasket--Crankcase
13 699482 Screw
(Cylinder Head)
15 691686 Plug--Oil Drain
15B 695757 Plug--Oil Drain
16 699445 Crankshaft
-- -- -- -- -- -- -- N o t e -- -- -- -- -791721 Crankshaft
Used on Type No(s).
0939, 1212, 1240,
1365, 8240, 8939.
795116 Crankshaft
Used on Type No(s).
0612, 0613, 0614,
0661, 0662, 0682,
0683.
797253 Crankshaft
Used on Type No(s).
0127, 0128, 0129,
0130, 0132.
17 692517 Bearing--Ball
18 699804 Cover--Crankcase
-- -- -- -- -- -- -- N o t e -- -- -- -- -699696 Cover--
Crankcase
Used on Type No(s).
0124, 0125, 0126,
0612, 0613, 0614,
0661, 0662, 0682,
0683.
18A 699672 Cover--Crankcase
20 K692550 Seal--Oil
(PTO Side)
21 281658S Cap--Oil Fill
22 699478 Screw
(Crankcase Cover/
Sump)
23 699516 Flywheel
24 222698S Key--Flywheel
25 791786 Piston Assembly
(Standard)
-- -- -- -- -- -- -- N o t e -- -- -- -- -791791 Piston
Assembly
(.020” Oversize)
26 791787 Ring Set
(Standard)
-- -- -- -- -- -- -- N o t e -- -- -- -- -791792 Ring Set
(.020” Oversize)
27 690975 Lock--Piston Pin
28 690229 Pin--Piston
29B 791783 Rod--Connecting
32 791784 Screw
(Connecting Rod)
33 499642 Valve--Exhaust
34 499641 Valve--Intake
35 691304
36
691304 Spring--Valve
37 699661 Guard--Flywheel
40 692194 Retainer--Valve
45 690977 Tappet--Valve
46 693404 Camshaft
51KzD∅791718 Gasket--Intake
55A 696710 Housing--Rewind
58 693389 Rope--Starter
60B 699334 Grip--Starter Rope
65 699228 Screw
65A 699851 Screw
Spring--Valve
(Intake)
(Exhaust)
Starter
(Cut To Required
Length)
(Rewind Starter)
(Rewind Starter)
78 699205 Screw
(Flywheel Guard)
95 691636 Screw
(Throttle Valve)
97 690024 Shaft--Throttle
98 398185 Kit--Idle Speed
104 D691242 Pin--Float Hinge
108 695807 Valve--Choke
109C 791954 Shaft--Choke
117 694176 Jet--Main
(Standard)
118 695042 Jet--Main
(High Altitude)
121 792006 Kit--Carburetor
Overhaul
122 D791717 Spacer--Carburetor
125A 794588 Carburetor
127 D694468 Plug--Welch
127A D691739 Plug--Welch
130 691181 Valve--Throttle
133 398187 Float--Carburetor
134 D398188 Kit--Needle/Seat
137 D
z693981 Gasket--Float Bowl
155 797442 Plate--Cylinder Head
(Metric)
(Used After Code Date
09061700).
-- -- -- -- -- -- -- N o t e -- -- -- -- -698214 Plate--Cylinder
Head
(SAE)
(Used Before Code
Date 09061800).
146 690979 Key--Timing
186 692317 Connector--Hose
187 791766 Line--Fuel
(Cut to Required
Length)
187A 791867 Line--Fuel
(Molded)
187B 791874 Line--Fuel
(Molded)
K Included in Engine Gasket Set--Ref. No.358.
D Included in Carburetor Overhaul Kit--Ref. No. 121.
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3946--7 Assemblies include all parts shown in frames. 02/22/2010
7
z Included in Carburetor Gasket Set--Ref. No. 977.
∅ Included in Valve Gasket Set--Ref. No 1095.
15C100
Not for
Reproduction
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
188 699479 Screw
(Control Bracket)
190 699220 Screw
(Fuel Tank)
192 797440 Adjuster--Rocker Arm
(Metric)
(Used After Code Date
09061700).
-- -- -- -- -- -- -- N o t e -- -- -- -- -694543 Adjuster--
Rocker Arm
(SAE)
(Used Before Code
Date 09061800).
209 692571 Spring--Governor
-- -- -- -- -- -- -- N o t e -- -- -- -- -691278 Spring--
Governor
Used on Type No(s).
0124, 0125, 0126,
0127, 0128, 0129,
0130, 0132.
219 693578 Gear--Governor
220 691724 Washer
(Governor Gear)
222F 793100 Bracket--Control
222G 793109 Bracket--Control
227 692573 Lever--Governor
Control
238 691300 Cap--Valve
268 691025 Control Wire Casing
(Cut to Required
Length)
269 691026 Control Wire
(Cut to Required
Length)
270 691027 Nut
(Control Wire Casing)
271 691028 Lever--Control
271A 698038 Lever--Control
z271716 Washer--Sealing
276 D
281A 793122 Panel--Control
-- -- -- -- -- -- -- N o t e -- -- -- -- -793133 Panel--Control
Used on Type No(s).
0124, 0125, 0126,
0127, 0128, 0129,
0130, 0132.
287 699629 Screw
(Dipstick Tube)
300E 796422 Muffler
(Used After Code Date
08113000).
-- -- -- -- -- -- -- N o t e -- -- -- -- -791940 Muffler
(Used Before Code
Date 08120100).
304 699598 Housing--Blower
305 699481 Screw
(Blower Housing)
306A 695710 Shield--Cylinder
307 699483 Screw
(Cylinder Shield)
307A 699234 Screw
(Cylinder Shield)
307B 790557 Screw
(Cylinder Shield)
309A 793667 Motor--Starter
Used on Type No(s).
0112, 0114, 0116,
0117, 0120, 0122,
0124, 0126, 0127,
0129, 0131, 0612,
0613, 0614, 0661,
0662, 0682, 0683,
0939, 1235, 1240,
1365, 8240, 8365,
8939.
-- -- -- -- -- -- -- N o t e -- -- -- -- -699786 Motor--Starter
Used on Type No(s).
0111, 0113, 0118,
0121, 0123, 0125,
0128, 0130, 0132,
1212.
318 690370 Screw
(Mounting Bracket)
332A 792723 Nut
(Flywheel)
333 695711 Armature--Magneto
334 699477 Screw
(Magneto Armature)
337 491055S Plug--Spark
(Resistor)
-- -- -- -- -- -- -- N o t e -- -- -- -- -691043 Plug--Spark
(EMS)
347 698338 Switch--Rocker
-- -- -- -- -- -- -- N o t e -- -- -- -- -691995 Switch--Rocker
Used on Type No(s).
0612.
356C 695630 Wire--Stop
356J 692603 Wire--Stop
356L 790552 Wire--Stop
358B 791797 Set--Engine Gasket
356N 794819 Wire--Stop
363 19203 Puller--Flywheel
365 699484 Screw
(Carburetor)
383 19374S Wrench--Spark Plug
415 693463 Plug
427 798458 Nut
(Control Bracket)
(Metric)
-- -- -- -- -- -- -- N o t e -- -- -- -- -694255
(Control
(SAE)
442 790282 Screw
(Starter Strap)
455 692591 Cup--Flywheel
456 692299 Plate--Pawl Friction
459 281505S Pawl--Rachet
472C 791948 Knob--Choke Shaft
Nut
Bracket)
K Included in Engine Gasket Set--Ref. No.358.
D Included in Carburetor Overhaul Kit--Ref. No. 121.
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3946--8 Assemblies include all parts shown in frames. 02/22/2010
8
z Included in Carburetor Gasket Set--Ref. No. 977.
∅ Included in Valve Gasket Set--Ref. No 1095.
15C100
Not for
Reproduction
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
474A 793640 Alternator
-- -- -- -- -- -- -- N o t e -- -- -- -- -791743 Alternator
Used on Type No(s).
0117, 0118, 0123,
0126, 0127, 0130,
0612.
793118 Alternator
Used on Type No(s).
0613, 0614, 0661,
0662, 0682, 0683.
797090 Alternator
Used on Type No(s).
0120, 0121, 0122,
0124, 0125, 0128,
0129, 0132.
698314 Alternator
Used on Type No(s).
0131.
485 695755 Knob--Control
493A 695744 Bracket--Mounting
493B 691177 Bracket--Mounting
501 698315 Regulator
503 796239 Strap--Starter
504 694254 Washer Set--Friction
505 691251 Nut
(Governor Control
Lever)
523 798469 Dipstick
(Used After Code Date
10022100).
-- -- -- -- -- -- -- N o t e -- -- -- -- -790546 Dipstick
(Used Before Code
Date 10022200).
524 281370S Seal--Dipstick Tube
526 690297 Screw
(Regulator)
528 793006 Hose--Primer
552 692346 Bushing--Governor
Crank
562 691119 Bolt
(Governor Control
Lever)
564 699854 Screw
(Control Cover)
578B 791956 Wire Assembly
584 791759 Cover--Breather
Passage
585 791760 Gasket--Breather
Passage
597 691696 Screw
(Pawl Friction Plate)
598 220624 Shim--End Play
601 791850 Clamp--Hose
604A 793134 Cover--Control
604B 790473 Cover--Control
608A 699335 Starter--Rewind
613D 699209 Screw
(Muffler)
615 692576 Retainer--Governor
Shaft
616 692547 Crank--Governor
619 699481 Screw
(Cylinder Head Plate)
621 692310 Switch--Stop
632 692653 Spring/Link--
Mechanical Governor
633
D
z693867 Seal--Choke/Throttle
Shaft
633A Dz691321 Seal--Choke/Throttle
Shaft
635 692076 Boot--Spark Plug
635A 692927 Boot--Sparkplug
663 699854 Screw
(Control Panel)
668 694257 Spacer
676D 794213 Deflector--Muffler
677A 699776 Screw
(Muffler Deflector)
684 791761 Screw
(Breather Passage
Cover)
689 691855 Spring--Friction
692 690572 Spring--Detent
697 793567 Screw
(Starter Motor)
718 690959 Pin--Locating
727 698039 Cover--Starter Drive
731A 794589 Hood--Snow
731B 793643 Hood--Snow
-- -- -- -- -- -- -- N o t e -- -- -- -- -798183 Hood--Snow
Used on Type No(s).
0132.
732 699200 Screw
(Starter Drive Cover)
741 695087 Gear--Timing
742 692564 Retainer--E Ring
746 790278 Gear--Idler
773 694258 Retainer
813 690635 Clamp
830 797441 Stud--Rocker Arm
(Metric)
(Used After Code Date
09061700).
-- -- -- -- -- -- -- N o t e -- -- -- -- -694544 Stud--Rocker
Arm
(SAE)
(Used Before Code
Date 09061800).
832D 793193 Guard--Muffler
832E 797003 Guard--Muffler
836E 699854 Screw
(Muffler Guard)
842 691031 Seal--O Ring
(Dipstick Tube)
847 798468 Dipstick/Tube
Assembly
(Used After Code Date
10022100).
-- -- -- -- -- -- -- N o t e -- -- -- -- -790545 Dipstick/Tube
Assembly
(Used Before Code
Date 10022200).
K Included in Engine Gasket Set--Ref. No.358.
D Included in Carburetor Overhaul Kit--Ref. No. 121.
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3946--9 Assemblies include all parts shown in frames. 02/22/2010
9
z Included in Carburetor Gasket Set--Ref. No. 977.
∅ Included in Valve Gasket Set--Ref. No 1095.
15C100
Not for
Reproduction
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
851 493880S Terminal--Spark Plug
868 K∅692044 Seal--Valve
883A K691893 Gasket--Exhaust
892 791944 Switch--Key
-- -- -- -- -- -- -- N o t e -- -- -- -- -798182 Switch--Key
Used on Type No(s).
0132.
914 699481 Screw
(Rocker Cover)
(Bottom)
914A 797444 Screw
(Rocker Cover)
(Top)(Metric)
(Used After Code Date
09061700).
-- -- -- -- -- -- -- N o t e -- -- -- -- -692557 Screw
(Rocker Cover)
(Top)(SAE)
(Used Before Code
Date 09061800).
914B 797444 Screw
(Rocker Cover)
(Center)(Metric)
(Used After Code Date
09061700).
-- -- -- -- -- -- -- N o t e -- -- -- -- -697551 Screw
(Rocker Cover)
(Center)(SAE)
(Used Before Code
Date 09061800).
930 696709 Guard--Rewind
957 792647 Cap--Fuel Tank
(Fresh Start)
-- -- -- -- -- -- -- N o t e -- -- -- -- -795027 Cap--Fuel
Tank
(Text Free)
957A 698109 Cap--Fuel Tank
958 698180 Valve--Fuel Shut Off
(Plastic)
972 694260 Tank--Fuel
(Plastic)
975 493640 Bowl--Float
976 793382 Primer--Carburetor
977 792007 Gasket Set--Carburetor
990 695756 Key--Set
990A 798177 Key--Set
993 K∅694088 Gasket--Cylinder Head
Plate
996 794687 Shield--Carburetor
998 696683 Pipe--Oil
(4” Long)
-- -- -- -- -- -- -- N o t e -- -- -- -- -792928 Pipe--Oil
(2 1/2” Long)
794701 Pipe--Oil
(5” Long)
1005 692592 Fan--Flywheel
1005A 794273 Fan--Flywheel
1011 794544 Tube--Vent
1019 791811 Kit--Label
1022 K∅691890 Gasket--Rocker Cover
1023 499924 Cover--Rocker Arm
1026 790287 Rod--Push
1029 797443 Arm--Rocker
(Metric)
(Used After Code Date
09061700).
-- -- -- -- -- -- -- N o t e -- -- -- -- -691230 Arm--Rocker
(SAE)
(Used
Before Code
Date 09061800).
1034 691343 Guide--Push Rod
1036 Label--Emissions
(Available From An
Authorized Briggs &
Stratton Sevice
Dealer)
1054 280275 Tie--Cable
1058 277104 Operator’s Manual
-- -- -- -- -- -- -- N o t e -- -- -- -- -279128 Operator’s-
Manual
Used on Type No(s).
0132.
1070 699201 Screw
(Flywheel Fan)
1095A 791798 Gasket Set--Valve
1119 699772 Screw
(Alternator)
1196 696692 Screw
(Snow Hood)
1196A 699854 Screw
(Snow Hood)
1210 498144 Pulley/Spring
Assembly
(Pulley)
1211 498144 Pulley/Spring
Assembly
(Spring)
1230 699847 Screw
(Control Bracket)
1251A 796421 Shield--Snow
(Used After Code Date
08113000).
-- -- -- -- -- -- -- N o t e -- -- -- -- -790555 Shield--
Snow
(Used Before Code
Date 08120100).
1251B 790556 Shield--Snow
1252 699629 Screw
(Snow Shield)
1252A 699491 Screw
(Snow Shield)
1319 794467 Label--Warning
1330 272147 Repair Manual
1403 699481 Screw
(Wire Assembly)
K Included in Engine Gasket Set--Ref. No.358.
D Included in Carburetor Overhaul Kit--Ref. No. 121.
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3946--10 Assemblies include all parts shown in frames. 02/22/2010
10
z Included in Carburetor Gasket Set--Ref. No. 977.
∅ Included in Valve Gasket Set--Ref. No 1095.
Not for
Reproduction
Not for
Reproduction
Loading...
