Champion SSG M2 Installation Manual

LISTED

Waste Systems

Operation, Cleaning and Maintenance Manual

TRISYS

Model:

SSG M2
Slow Speed Grinder and
Centrifuge

Options:

Close-coupled and Remote Systems

3765 Champion Boulevard
Winston-Salem, NC 27105
[phone] Fax: [phone]
Toll-free: 1 [phone]

Issue Date: 8.22.17

Manual P/N 115808 rev. B

For machines beginning with S/N SG17040005 and above

2674 N. Service Road, Jordan Station
Ontario, Canada L0R 1S0
[phone] Fax: [phone]
Toll-free: 1 [phone]

Printed in the USA

National Service Department

In Canada: In the USA:

Toll-free: [phone] Toll-free: [phone]
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
email: [e-mail] email: [e-mail]

ATTENTION

The model no., serial no., voltage, Hz

and phase are needed to identify your

machine and to answer questions.

The machine data plate

is located on the right front corner

of the lower panel

Please have this information ready

if you call for service assistance.

COPYRIGHT © 2017 All rights reserved Printed in the USA

Product Registration

Two ways to
REGISTER YOUR PRODUCT and
ACTIVATE YOUR WARRANTY.

4:34 PM 44%

• Visit our website at www.championindustries.com and register your
product there.

• Use the fax form on the next page and fax to 1 800 661-1660.

PRODUCT REGISTRATION

Product Registration

BY FAX

COMPLETE THIS FORM AND FAX TO:

[phone] in the USA

1-[phone] in Canada

PRODUCT REGISTRATION CARD

Model

Date of Installation:
Company Name:

Address:
Telephone #: ( ) --­Contact:

Installation Company:
Address:
Telephone #:
Contact:

FAILURE TO REGISTER YOUR PRODUCT MAY VOID YOUR WARRANTY

(Street) Province Postal Code

Serial #

IMPORTANT IMPORTANT

Revision History

Revision History

We reserve the right to make changes to this manual without notice and without incurring any
liability by those changes. Equipment owners may request a revised manual, at no charge, by
calling 1 [phone] in the USA or by calling 1 [phone] in Canada.

Revision Revised Serial Number Revision
Date Pages Effectivity Description

4.11.17

8.22

.17

All SG17040005 Released First Edition

13

SG17040005

Revised drain procedure

i

LIMITED WARRANTY AGREEMENT (continued)

Warranty of Parts: The Company warrants all new machine parts produced or authorized by The
Company to be free from defects in material and workmanship for a period of 90 days from date of
invoice. If any defect in material and workmanship is found to exist within the warranty period The
Company will replace the defective part without charge.

DISCLAIMER OF WARRANTIES AND LIMITATIONS OF LIABILITY. THE COMPANY’S WARRANTY IS ONLY
TO THE EXTENT REFLECTED ABOVE. THE COMPANY MAKES NO OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED, TO ANY WARRANTY OF MERCHANTABILITY, OR FITNESS OF
PURPOSE. THE COMPANY SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. THE
REMEDIES SET OUT ABOVE ARE THE EXCLUSIVE REMEDIES FOR ANY DEFECTS FOUND TO EXIST IN THE
COMPANY’S WASTE PROCESSING MACHINES AND THE COMPANY’S PARTS, AND ALL OTHER REMEDIES
ARE EXCLUDED, INCLUDING ANY LIABILITY FOR INCIDENTALS OR CONSEQUENTIAL DAMAGES.

The Company does not authorize any other person, including persons who deal in Champion
dishwashing machines to change this warranty or create any other obligation in connection with
Champion, Trisys and Champion-Trisys machines.

AGREEMENT SIGNATURES

I acknowlege and agree that a I have read and understand this Limited Warranty Agreement. I
agree that the restrictions contained in this Limited Warranty Agreement are reasonable, proper and
necessitated by The Company’s legitimate interests and the legitimate interests of its subsidiaries and
affiliated entities. I acknowledge and agree that I am entering into this Limited Warranty Agreement
freely and with the intent to be bound by this Limited Warranty Agreement.

ACCEPTED AND AGREED:

BUYER

____________________________________
(Signature)

____________________________________________
(Printed Name and Title)

Dated:______________________________

Table of Contents

Table of Contents

Revision History ................................................................................................................ i

Limited Warranty
Safety Symbols

............................................................................................................. ii

................................................................................................................iv

Introduction ........................................................................................1

System Overview ....................................................................................... 1

System Components ................................................................................... 3

Loading Waste .......................................................................................... 4

Food Waste Feed Trough ............................................................................ 5

Grinder Access Door .................................................................................. 5

Emergency Stop Switch .............................................................................. 6

Start/Stop Sation ....................................................................................... 6

Digital Touchscreen Display ......................................................................... 7

Close-coupled Operation ..................................................................... 8

Filling ....................................................................................................... 8

Check Drain (if equipped) ........................................................................... 9

Run/Grind ................................................................................................ 9

Pause/Clean ........................................................................................... 10

Emergency Stop ...................................................................................... 10

Door Open ............................................................................................. 11

Motor Overload Alarms ............................................................................ 12

Cleaning ........................................................................................... 13

Maintenance ...................................................................................... 14

Maintenance Schedules ............................................................................ 14

Troubleshooting ....................................................................................... 15

iii

Table of Contents (continued)

Safety Symbols

The following symbols are used throughout this manual to alert the reader to important information.

WARNING:

Warnning statements indicate a condition or practice that can result in personal injury
or possible death.

CAUTION:

Caution statements indicate a condition or practice that can result in damage to the
machine or associated equipment.

DO NOT:

Do not statements indicate that a condition or practice will diminish the effective
operation of the machine.

OKAY:

Okay statements indicate that a condition or practice is correct and should be
followed.

NOTE:

Note statements highlight important information necessary for the operation of the
machine.

iv

This Page

Intentionally

Safety Symbols

Left Blank

v

System Overview

Waste Control System Overview

The system is designed to process food waste and food waste by-products (see the approved list
of wate on page 4), using a waste water trough, mechanical macerator, slurry transfer pump,
recirculation pump, and centrifuge waste water separator.

Main Control Panel an Centrifuge Control Panel System

1) Main Control Box

2) Remote Push Button Start/Stop Station

Slow Speed Grinder SSG M2:

1) SSG Drive, 5 HP

2) Slurry Pump, 3/4 HP

3) Recirculating Pump, 3/4 HP

3) Main PLC Control System

Centrifuge:

1) Drive Motor, 1.5 HP

2) Flush-down Solenoid Valve

Slurry Pump:

1) Drive Motor, 3/4HP

Recirculating Pump:

1) Drive Motor, 3/4HP

Waste Trough Water Piping:

1) Fresh Water

2) Gray Water (optional)

vi

Close-couple and Remote Introduction

Introduction

System Overview

The SSG waste handling system processes food waste scraped from dishes and deposited
into a trough (supplied by others). Waste is macerated in a slow speed grinder to produce a
slurry; the slurry is pumped to a centrifuge that extracts the water from the waste to produce a
semi-dry pulp. The pulp is discharged into a waste bin (supplied by others) and then
transported to a waste collection point (supplied by others).

There are two system configurations: close coupled and remote. Remote systems separate the
grinder from the centrifuge; close-coupled systems combine the grinder and centrifuge into a
single unit.

Close-Coupled System

Control Cabinet

Grinder

Slurry Pump

Centrifuge

Recirculating Pump

Fig.1

SSG M2 Close-coupled System

1

Close-coupled and Remote Introduction

Remote System

SSG

Control Cabinet

3

Remote

Centrifuge

4

2

Slow Speed Grinder

Waste Trough

1

Slurry Line

SSG

Rack Conveyor Dishwasher

Fig. 2

SSG Remote Waste System

Champion Rack Conveyor Dishwasher

2

System Components

Close-coupted and Remote Introduction

1

2

Green

START

Red

STOP

1

2

3

4

The waste trough flushing nozzles and the
system Start/Stop station may be located at
the opposite end of the SSG.

The waste Slow Speed Grinder (SSG) and
slurry pump are located in the dishroom but
may be separate. There is an Emergency
safety stop switch on the SSG access door.

The main system control panel is wall­mounted. It has a lighted digital touchscreen
and an emergency stop switch.

The centrifuge separates water
from waste and directs water to the drain.
The waste falls into a waste container
(supplied by others).

3

4

3

Close-coupled and Remote Introduction

Loading Waste

ATTENTION

THIS EQUIPMENT IS DESIGNED ONLY FOR FOOD WASTE REDUCTION.

(NAPKINS, PAPER TOWELS AND CARDBOARD ARE ACCEPT ABLE.)

ATENCIÓN

ESTE EQUIPO ES DISEÑADO SOLAMENTE PARA LA REDUCCIÓN

DE RESIDUOS DE ALIMENTOS.

(SERVILLETAS, TOALLAS DE PAPEL Y CARTÓN SON ACEPTABLES.)

! WARNING !

DO NOT LOAD FLATWARE, SERVICE WARE, PLASTICS, LARGE BONES,

RAW BONES, (SHELLS: CLAM, OYSTER, MUSSEL, SHRIMP, CRAB,

LOBSTER, SCALLOP, WALNUT, PEANUT, PECAN, ALMOND OR

ANY OTHER TYPE OF SHELL NOT LISTED), WOOD, RAGS.

DO NOT DUMP BULK QUANTITIES FROM TUBS ,GARBAGE CANS,

OR OTHER LARGE CONTAINERS DIRECTLY INTO THE MACHINE OR

FEED TROUGHS.

! ADVERTENCIA !

NO CARGUE PLATOS, CUBIERTOS, UTENSILIOS DE COCINA, PLÁSTICOS,

HUESOS GRANDES, HUESOS CRUDOS, CÁSCARAS O CARACOLES DE

(ALMEJA, OSTRA, MEJILLÓN, CAMARÓN, CANGREJO, LANGOSTA, VIEIRA,

NUEZ, MANÍ, NUEZ DE PACANA, ALMENDRA O CUALQUIER OTRO TIPO

DE CASCARA O CARACOL AUNQUE NO APARESCA EN ESTA LISTA),

MADERA O TRAPOS.

NO USE TINAS, CESTOS DE BASURA U OTROS ENVASES PARA

DESCARGAR GRANDES CANTIDADES DE RESIDUOS DE

ALIMENTOS DIRECTAMENTE EN LA MÁQUINA, O EN LA

ENTRADAS DE CANALES.

P/N 115802

4

Food Waste Feed Trough

Close-coupled and Remote Introduction

1. The waste trough carries acceptable food

waste and and paper products from
scrapping stations (supplied by others)
to the inlet of the grinder chamber.

2. The trough is equipped with flushing

nozzles designed to return water
pumped by a recirculation pump.

Flushing Nozzles

Fig. 3

Waste trough with flushing nozzles.

Grinder Access Door

1. The grinding chamber is protected by an access door mounted at the top of the chamber.

2. The door must be closed to run the machine. The machine will stop if the door is opened

and the red stop switch will begin to flash.

WARNING:

TThe grinder chamber has rotating blades that may cause serious INJURY or DEATH.
Keep hands and clothing clear of blades when power is on. Never bypass a safety
switch on this system.

Fig. 5

Fig. 4

Grinder Blades

Grinder Access Door

Continued on next page

5

Close-coupled and Remote Introduction

Emergency Stop Switch

1. The Emergency Stop Button is located on the front of the control cabinet above the

digital touchscreen display.

2. Pushing the stop button will immediately stop the system and the red stop button will begin

to flash.

3. Pull and turn the button clockwise to reset so the the system may be restarted with the

green start button.

Fig. 6

Emergency Stop Switch

Start/Stop Station

1. The Start/Stop station usually is mounted near a scrapping station but can be mounted

on the close-coupled unit if desired.

2. The station includes a GREEN and RED pushbutton enclosed in a stainless steel box.

Fig. 7

Start/Stop Station

6

Digital Touchscreen Display

Control Cabinet

Close-coupled and Remote Introduction

Status Window

READY

RINSE SETPOINTS

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

Fig. 8

Digital Touchscreen Display

1. The touchscreen display is located on the main control cabinet for system control and

status messages.

2. Touching the buttons navigates from one screen to another. The machine status appears

in the top window (see "READY" in Fig 8.).

The operator screens include:

Setpoints:

Press the Rinse, slurry, and clean setpoints button to change system settings.

MANUAL CONTROL

Manual Control: Press to manually run the system components to test their opeation.

Inputs: Press to display inputs to the system PLC controller.

Outputs: Press to display outputs to the system PLC controller.

Default: Press to return a setpoint to the factory default.

Default is reserved for service.

7

Close-coupled Operation

Close-coupled - Normal Operation

FILLING

1. Ensure the grinder access door is closed and the Emergency stop button is off, and

a waste container is positioned under the centrifuge discharge.

2. Turn power ON at the main breaker or service disconnect switch.

3. The GREEN pushbutton will begin to flash and "READY" will appear in the Status

Window indicating the machine is ready to fill.

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

READY

4. Push the GREEN pushbutton.

5. "FILLING" appears in the Status Window and the machine begins to fill. The green

pushbutton continues to flash as the tank fills.

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

FILLING

CLEAN SETPOINTS OUTPUTS

6. When full, the Green button stops flashing and remains solid green.

The Status Window indicates "READY".

7. Press the GREEN start pushbutton to begin normal operation.

READY

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

8

Close-coupled Operation

CHECK DRAIN

1. During initial "FILLING" if the recirculation tank is not full within 10 minutes then

the fill operation will stop.

CHECK DRAIN

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

2. "CHECK DRAIN" will appear in the status window. The GREEN pushbutton

continues to flash.

3. To reset: Close the drains, then Push the GREEN pushbutton. "CHECK DRAIN" will

change to "FILLING". The machine will fill again until the machine is full.
The status window will display "READY".

RUN/GRIND

1. Press the solid green GREEN start button to begin the automatic cycle. The Status

window will disappear.

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

2. The grinder will run and food waste may be loaded into the waste trough.

Refer to page 4 for the proper waste loading procedures.

WARNING:

FAILURE TO FOLLOW THE LOADING WASTE INSTRUCTIONS, ON PAGE 4 WILL
VOID THE WARRANTY ON THE MACHINE.

3. The slurry pump will cycle on and off according to its program sending waste to the

centrifuge for dewatering. The centrifuge cycles on and off as well.

4. The recirculating pump sends water to the waste trough to flush waste down the trough.

9

Close-coupled Alarms

CLEAN/PAUSE

1. The system may be paused anytime during operation by pressing the RED pushbutton.

The display will indicate "CLEAN" as it begins a clean cycle .

CLEAN

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

2. The "CLEAN" cycle may be stopped by pressing the GREEN start button.

3. When the GREEN button is pressed the status window will disappear and the

machine will return to normal operation.

EMERGENCY STOP

1. Pushing the emergency stop switch located on the

front of the control cabinet will immediately
stop the machine.

2. The digital display indicates "E-STOP".

3. The RED stop pushbutton will flash and the

GREEN start pushbutton will go out. Both switches
are disabled until the emergency switch is reset.

E-STOP

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

4. To reset the Emergency stop switch: Pull the switch button out while turning clockwise.

The switch will lock in the up position.

Emergency Stop

Switch

5. The RED stop pushbutton will go out and the GREEN start button will flash. The status

bar will indicate the status before the E-Stop was pressed.

10

DOOR OPEN

1. Opening the access door at any time will activate

the "DOOR OPEN" alert.

2. Door open will appear in the display status bar.

3. The GREEN pushbutton switch

will go out as the RED pushbutton
begins to flash.

RINSE SETPOINTS MANUAL CONTROL

4. Close the access door to reset

the condition.

5. The RED pushbutton will go out

as the GREEN pushbutton begins
to flash. Push the GREEN pushbutton to return to normal operation.

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

Close-coupled Alarms

Access

Door

DOOR OPEN

11

Close-coupled Alarms

MOTOR OVERLOAD ALARMS

1. The motors are protected by motor overloads. In the event of an overload condition, the

system will stop and the faulty motor will appear in the status window.

2. The GREEN start pushbutton will go out as the RED stop pushbutton comes on.

Turn the main power to the machine off and drain the machine.

3. An authorized service repairman is required to fix the problem.

4. Below are the overload alarms:

GRINDER OL

GRINDER MOTOR OVERLOAD

SLURRY PUMP MOTOR
OVERLOAD

CENTRIFUGE MOTOR
OVERLOAD

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

SLURRY OL

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

CFUGE OL

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

12

RECIRCULATING PUMP
MOTOR OVERLOAD

CLEAN SETPOINTS OUTPUTS

RECIRC OL

RINSE SETPOINTS MANUAL CONTROL

SLURRY SETPOINTS INPUTS

CLEAN SETPOINTS OUTPUTS

Close-coupled Cleaning

CLEANING

1. The system must be thoroughly cleaned at the end of the day to prevent odors and ensure
the centrifuge and pumps remain in good working order. Refer to Fig. 9 below.

2. Push the RED stop button to initiate a "CLEAN" cycle (see PAUSE/CLEAN on page 9).

3. TURN POWER OFF AT THE MAIN BREAKER OR SERVICE DISCONNECT SWITCH.

4. Remove the tank covers and flush clean in a sink.

5. Open the Grinder Access Door and inspect for metal or other large debris and remove.

6. Only open the Recirculation Tank Drain Valve and drain the machine.

7. Flush the recirculation tank and grinder blades with fresh water to remove accumulated

soils. DO NOT HOSE THE EXTERIOR WITH WATER.

8. Scrub the interior and exterior of the machine using a plastic

bristle brush and mild detergent.

DO NOT CLEAN THE MACHINE WITH
A METAL SCRUB PAD OR BRUSH.

9. Reassemble the machine.

Recirculation
Tank Covers

Grinder
Access
Door

Fig.9

Close-coupled Cleaning

Drain
Valve

13

Close-coupled and Remote - Maintenance

Maintenance Schedules

Weekly - Turn power OFF before inspection.

1. Check water lines for leaks and tighten as needed.

2. Check the building drain for clogs.

3. Inspect the interior and exterior of the machine for loose or broken parts.

4. Inspect the float switches for free movement.

5. Check the centrifuge discharge hose for breaks and replace as needed.

6. Inspect the area around the system for accumulated debris and clean as required.

Monthly - Turn power OFF before inspection.

1. Perform all of the weekly checks listed above.

2. Open the grinder access door and inspect for obstructions.

3. Inspect the system piping for damaged or missing parts.

Monthly - Turn power ON before inspection.

1. Start and run the system normally. DO NOT LOAD WASTE INTO THE MACHINE.

2. Push the Emergency Stop Switch and check the operation of the E-STOP alarm per

the instructions on pg.10.

3. Open the grinder access door and check the DOOR OPEN alarm per the

instructions on pg.10.

Yearly - To be performed by an authorized service agent only.

1. Perform all Monthly Maintenance.

2. Check the operation of the motor overload alarms per page 11.

3. Evaluate all pump motor bearings and seals without disassembly.

4. Visually inspect the centrifuge (Contact factory before servicing).

5. Check the grinder for chipped/broken blades.

Lubrication -

1. Replace grinder gearcase grease every 15 years or 90,000 hours

whichever occurs first.

2. Use ~48 oz. of Mobiltemp 1 or equivalent in gearcase. Use

lithium grease on shaft seals.

14

Close-coupled and Remote - Maintenance

Troubleshooting

PROBLEM CAUSE SOLUTION

Grinder and/or centrifuge is
jammed and/or overloaded with
waste.

Will not come on. Main power OFF.

Low or no water in the recirculation
tank.

Recirculation tank overflows. Defective fill valve.

Fills constantly. Defective upper float.

Will not Drain. Drain valve(s) closed.

Green pushbutton flashing. Is machine filling with status window

Improper loading of waste and/or the
loading prohibited materials.

Green start button not pressed.

Water supply OFF.
Drain open
Lower float dirty.
Defective lower float.
Slurry pump is clogged.

Defective or dirty upper float.
Recirculation pump clogged or

defective.

Defective solenoid valve.

Building drain clogged.

display "FILLING"?

Follow the waste loading instructions on
pg. 4.

Contact service agent for repairs.

Turn power on at main breaker.
Press start button.

Open supply valve(s).
Close drain.
Turn off power and clean float.

Replace float.
Call service agent.

Repair or replace the valve.
Clean or replace float.
Contact service agent.

Turn off power and clean float.
Repair or replace float.

Open drain valve(s).
Clean drain lines.

Normal - push green button to
start.

Does status window display
"CLEAN".

Green pushbutton solid green, not
running.

Red pushbutton is flashing. Does status window display "E-Stop"

Red pushbutton is solid red. Does status window display "Cfuge

Waste pulp is too wet or water
is exiting the discharge chute.

Odor is detected around machine. Improper cleaning of machine.

Does status window display
"READY"?

Does status window display "Door
Open"?

OL", "Slurry OL", "Grinder OL", or
"Recirc OL"?

Food waste has insufficient mass.

Excess water in the system.

Improper cleaning of area around
machine.

Normal - push green button when status
window displays "READY"

Normal condition, push green
start button to start.

Normal condition - see pg. 10 to reset.
Normal condition - close the grinder

access door.

Motor overload has tripped - turn power
off and call service agent.

Add small pieces of cardboard to
grinder.

Contact service agent to adjust.

Clean machine and surrounding area.
Refer to cleaning instructions on pg. 13.

15

Blank Page

This Page

Intentionally

Left Blank

16

System Settings - Close-coupled and Remote

RINSE SETPOINTS

CAUTION:

Changing the rinse setpoints may cause the recirculation tank and/or the centrifuge
to overflow. Do not change these setpoints without factory authorization.

1. Touch the MAIN MENU - RINSE SETPOINTS button to access the rinse menu below.

The values shown are the default settings.

RINSE SETPOINTS

RINSE ON INTERVAL

RINSE OFF INTERVAL

BACK MAIN

0

60

2. The RINSE ON INTERVAL sets the time the centrifuge rinse is on during the slurry pump

operation. The rinse will come on when the slurry pump pauses.

3. The RINSE OFF INTERVAL sets the time the centrifuge rinse is off after the ON interval

time has elapsed.

4. For example, to change the Rinse On Interval, touch the 0 value, the setting keypad

appears. Pressing 20 and ENT, sets a new value and returns to the previous screen.

7

4

1

0

8

5

2

+/-

20

9

CLR

CAN

6

3

ENT

.

RINSE SETPOINTS

RINSE ON INTERVAL

RINSE OFF INTERVAL

20

60

BACK MAIN

5. Touch BACK to go back one screen or MAIN to return to the main menu.

17

System Settings - Close-coupled and Remote

SLURRY SETPOINTS

NOTE:

Slurry setpoints control the cycling of the slurry pump. The default settings are 12
seconds pump run and 2 seconds pump off. This cycling keeps the pump flow
unobstructed. The centrifuge automatically rinses during the slurry pump off interval.

1. Touch the SLURRY SETPOINTS button to access the rinse menu below.

The values shown are the default settings.

2. TIME and FLOAT are factory settings; do not change. The buttons appear blue when

properly set ON.

SLURRY SETPOINTS

SLURRY ON INTERVAL

SLURRY OFF INTERVAL

FLOATTIME

BACK MAIN

12

2

3. The SLURRY ON INTERVAL sets the time the slurry pump is on during the machine

automatic cycle. The rinse will come on when the slurry pump pauses.

4. The SLURRY OFF INTERVAL sets the time the slurry pump is off after the ON interval

time has elapsed.

7

4

1

0

8

5

2

+/-

5. To change a setting: touch the desired number displayed, 12 is touched in the example

above. Enter the new value, 20 in the example and press ENT to enter the new value.
The slurry pump will now run for 20 seconds and pause for 2 seconds.

20

9

CLR

CAN

6

3

ENT

.

SLURRY SETPOINTS

SLURRY ON INTERVAL

SLURRY OFF INTERVAL

20

2

BACK MAIN

18

NOTE:

The slurry pump will cyle ON and OFF for three cycles and then reverse direction for
1 second. The pump will continue this pattern continuously.

System Settings - Close-coupled and Remote

CLEAN SETPOINTS

NOTE:

Clean setpoints control the run time of the slurry pump and centrifuge during the
CLEAN cycle (see Clean/Pause on page 10). This cycling flushes the slurry pump
and centrifuge whenvere the stop pushbutton is pressed during normal operation.

1. Touch the CLEAN SETPOINTS button to access the CLEAN menu below.

2. Touching the DEFAULT button changes the settings to 540 seconds and 600 seconds.

The factory settings are 54 seconds for the slurry pump 60 seconds for the centrifuge.

3.

DEFAULT

CLEAN SETPOINTS

SLURRY CNTFG

540 600

MAIN BACK

4. The SLURRY button sets the time the slurry pump runs during the automatic CLEAN cycle.

The centrifuge runs and rinses after the slurry pump stops.

5. The SLURRY OFF INTERVAL sets the time the slurry pump is off after the ON interval

time has elapsed.

7

4

1

0

8

5

2

+/-

6. To change a setting: touch the desired number displayed, 54 is touched in the example

above. Enter the new value, 55 in the example and press ENT to enter the new value.
The slurry pump will now run for 55 seconds and centrifuge will run for 60 seconds.

55

9

CLR

CAN

6

3

ENT

.

DEFAULT

CLEAN SETPOINTS

SLURRY CNTFG

54 60

MAIN BACK

19

System Settings - Close-coupled and Remote

MANUAL CONTROL

1. The manual control screen allows testing of the major components in the system to ensure

they operate correctly.

2. Touch each button to run that component. It will operate as long as the button is pressed.

RECIRC

SLURRY RINSE VALVE

GRINDER FWD

MANUAL CONTROL

CENTRIFUGE SLURRY REV

FILL VALVE

GRINDER REV

BACK MAIN

3. Push BACK to go back one screen or touch MAIN to return to the main menu.

INPUTS

INPUTS

I/00 BLFSWU

I/01 BLFSWL

I/02 GRNDOL

I/03 SLUROL

I/04 CENTOL

I/05 STOP

I/06 START

I/07 DSS

1/10 PWFSWL

I/00 PWFSWJ

I/01 E-STOP

I/02 RECFSWL

I/03 RECFSWU

OUTPUTS

BACK MAIN

20
