English
Setup Guide
Be sure to keep all user documentation
handy for future reference.
To obtain the latest version of this
manual visit the website at the URL
below.
http://world.casio.com/manual/projector/
Français
Guide d’installation
Conservez la documentation à portée
de main pour toute référence future.
Pour obtenir la toute dernière version de
ce manuel, consultez le site à l’adresse
suivante.
http://world.casio.com/manual/projector/
Español
Guía de configuración
Asegúrese de tener a mano toda la
documentación del usuario para
futuras consultas.
Para obtener la versión más reciente de
este manual, visite nuestro sitio web en
la siguiente URL.
http://world.casio.com/manual/projector/
• Some models covered by this User’s Guide may not be available
in certain geographic areas.
• Certains modèles couverts par ce mode d’emploi peuvent ne
pas être commercialisés dans certaines zones géographiques.
• Algunos modelos cubiertos por esta Guía del usuario pueden no
estar disponibles en determinadas áreas geográficas.
Contents
Safety Precautions .................................. EN-1
Operating Precautions ............................ EN-6
Quick Guide ............................................EN-11
Specifications .........................................EN-12
General Guide ........................................ EN-10
Unpacking
As you unpack the projector, check to make sure that all of the items listed below are present.
z DATA PROJECTOR
z Wireless remote control (YT-130)
z Test Batteries (AAA-size × 2)
z AC Power Cord
z RGB Cable
z Special AV Cable
z Carrying Bag
z Setup Guide
z “Read this first” Sheet
z Warranty
z Wireless adapter (Provided with USB models only.)
Projector Documentation and Software
The manuals for this projector can be downloaded from the CASIO website at the URL below.
http://world.casio.com/manual/projector/
Reference manual:
“User’s Guide” (UsersGuide.pdf)
Manuals for USB models:
“Network Function Guide”
The software for USB models can be downloaded from the CASIO website at the URL below.
http://www.casio-intl.com/support/download/
Software for USB models:
Network Connection, EZ-Converter FA
z The contents of this User’s Guide are subject to change without notice.
z Copying of this manual, either in part or its entirety, is forbidden. You are allowed to use this manual for your
own personal use. Any other use is forbidden without the permission of CASIO COMPUTER CO., LTD.
z CASIO COMPUTER CO., LTD. shall not be held liable for any lost profits or claims from third parties arising
out of the use of this product or this manual.
z CASIO COMPUTER CO., LTD. shall not be held liable for any loss or lost profits due to loss of data caused
by malfunction or maintenance of this product, or any other reason.
z The sample screens shown in this manual are for illustrative purposes only, and may not be exactly the
same as the screens actually produced by the product.
EN
Safety Precautions
Thank you for selecting this CASIO product. Be sure to read these “Safety Precautions” before trying to
use it. After reading this User’s Guide, keep it in a safe place for future reference.
About safety symbols
Various symbols are used in this User’s Guide and on the product itself to ensure safe use, and to
protect you and others against the risk of injury and against material damage. The meaning of each of the
symbols is explained below.
Danger
*
Warning
*
Caution
*
Icon Examples
A triangle indicates a situation against which you need to exercise caution. The example shown
’
here indicates you should take precaution against electric shock.
A circle with a line through it indicates information about an action that you should not perform.
The specific action is indicated by the figure inside the circle. The example shown here means
!
disassembly is prohibited.
A black circle indicates information about an action that you must perform. The specific action
is indicated by the figure inside the circle. The example shown here indicates you must unplug
$
the power cord from the power outlet.
This symbol indicates information that, if ignored or applied incorrectly,
creates the risk of death or serious personal injury.
This symbol indicates information that, if ignored or applied incorrectly, could
possibly create the risk of death or serious personal injury.
This symbol indicates information that, if ignored or applied incorrectly, could
possibly create the risk of personal injury or material damage.
Precautions During Use
Warning
*
● Adult supervision is required
whenever there are young children
present and especially when there is
the possibility of young children
coming into contact with the
projector.
● Smoke, odor, heat, and other
abnormalities
Should you ever notice smoke, strange
-
1.
2.
odor, or any other abnormality,
immediately stop using the projector.
Continued use creates the risk of fire and
electric shock. Immediately perform the
following steps.
Unplug the projector.
Contact your original dealer or authorized
CASIO service center.
● Malfunction
Immediately stop using the projector if
-
1.
2.
3.
EN-1
the screen appears abnormal, or if any
other abnormal operation occurs even
though you are operating the projector
correctly. Continued use creates the risk
of fire and electric shock. Immediately
perform the following steps.
Turn off the projector.
Unplug the projector.
Contact your original dealer or authorized
CASIO service center.
Safety Precautions
● Power cord
Misuse of the power cord creates the risk
+
• Be sure to use only the accessories that come
• Make sure that you use a power source with the
• Do not overload a power outlet with too many
• Do not locate the power cord near a stove.
• Do not use the power cord that comes with the
• Do not share the outlet supplying power to the
• Never use the power cord while it is still bundled
• Use a conveniently located power outlet that you
-
• Never place heavy objects on the power cord
• Make sure the power cord is not pinched
• Never try to modify the power cord, allow it to
• Do not twist the power cord or pull on it.
"
• When using this projector in the country where
-
of fire and electric shock.
Make sure that you always observe the
following precautions.
with the projector.
same voltage as that specified for the projector.
devices.
projector with any other device.
projector with other devices. If you are using an
extension cord, make sure that the ampere rating
of the extension cord is compatible with the
power consumption value of this projector.
together.
can reach easily when you need to unplug the
projector.
A damaged power cord creates the risk
of fire and electric shock.
Make sure that you always observe the
following precautions.
and never expose it to heat.
between the wall and the rack or table where the
projector is located, and never cover the power
cord with a cushion or other object.
become damaged, or subject it to excessive
bending.
Never touch the power cord or plug while
your hands are wet.
Doing so creates the risk of electric
shock.
you purchased it, be sure to use the power cord
that came with it. Whenever using the projector
in another country, be sure to purchase and use
a power cord that is rated for the voltage of that
country. Also make sure that you are aware of
the Safety Standards that apply in that country.
When going out, make sure the projector
is in a location away from pets and other
animals, and unplug the power plug from
the power outlet. A power cord damaged
by chewing can cause shorts, and
creates the risk of fire.
● Water and foreign matter
Never allow water to get on the projector.
+
%
%
1.
2.
3.
● Disassembly and modification
!
Be sure to leave all internal inspection, adjustment,
and repair up to your original dealer or authorized
CASIO service center.
● Dropping and impact
-
1.
2.
3.
Water creates the risk of fire and electric
shock.
Never place a vase or any other container
of water on top of the projector. Water
creates the risk of fire and electric shock.
Water or other liquid, or foreign matter
(metal, etc.) getting into the projector
creates the risk of fire and electric shock.
Should anything get inside the projector,
immediately perform the following steps.
Turn off the projector.
Unplug the projector.
Contact your original dealer or authorized
CASIO service center.
Never try to take the projector apart or
modify it in any way. The projector
contains a large number of high-voltage
components that create the risk of
electric shock and burn injury. Also, note
that problems caused by unauthorized
projector disassembly or modification are
not covered by the warranty and are not
eligible for repair by CASIO.
Continued use of the projector after it has
been damaged by dropping or other
mistreatment creates the risk of fire and
electric shock. Immediately perform the
following steps.
Turn off the projector.
Unplug the projector.
Contact your original dealer or authorized
CASIO service center.
EN-2
Safety Precautions
● Disposal by burning
Never try to dispose of the projector by
-
burning it. Doing so can cause an
explosion, which creates the risk of fire
and personal injury.
● Projector light emission
• Never look directly into the lens, intake
-
vents, or exhaust vents while the light is
on. When turning on the projector, check
to make sure that no one is looking
directly into its lens, intake vents, or
exhaust vents. The strong light emitted
by the projector creates the risk of eye
damage.
• Do not attempt to use a magnifying
glass, mirror, or other similar object to
bend or reflect the projector’s light, and
never hold or place such object in the
path of the projector’s light. Refracted or
reflected light can shine into a person’s
eyes and create the risk of eye damage.
● Blocking the vents
Never allow the vents to become
-
• Allow at least 30cm (11.8 inches) between the
• Do not insert the projector into any space where
• Never cover the projector with a blanket or any
• Locate the projector on a firm, flat surface during
• Never stand the projector up on either end during
blocked. Doing so causes internal heat
build up, which creates the risk of fire and
breakdown of the projector. Touching the
projector while it is hot creates the risk of
burn injury. Make sure that you always
observe the following precautions.
projector and walls.
air circulation is poor.
similar item.
use. Never use the projector while it is on a
carpet, blanket, towel, seat cushion, or other
pliable surface.
use.
● Projector cabinet
Never open the projector’s cabinet.
’
Doing so creates the risk of electric
shock.
● Cleaning
Before cleaning the projector, be sure to
$
turn it off and unplug it from the power
outlet. Failure to do so creates the risk of
electric shock.
● Exhaust vents
The exhaust vents become very hot while the
projector is running. Never touch them. Doing so
creates the risk of burn injury. The areas near the
exhaust vents also become quite hot. Never locate
objects made of plastic or other heat-sensitive
materials near or under the projector. Doing so
creates the risk of deformation and discoloration of
the object.
● Lens cover
Be sure to remove the lens cover before turning on
the projector. Never leave the lens cover attached
while the projector is in use.
● Location
Never locate the projector in any of the following
types of locations. Doing so creates the risk of fire
and electric shock.
• Near an area subject to strong vibration
• An area subject to large amounts of moisture or
dust
• In a kitchen or other area exposed to oil smoke
• Near a heater, on a heated carpet, or in an area
exposed to direct sunlight
• An area subject to temperature extremes
(Operating temperature range is 5°C to 35°C
(41°F to 95°F)).
● Heavy objects
Never place heavy objects on the projector or
climb on top of the projector. Doing so creates the
risk of fire and electric shock.
● Water
Never locate the projector in a bathroom or
anywhere else there is the chance that it will be
splashed with water.
● Unstable location
Never place the projector on an unstable
-
surface or on a high shelf. Doing so can
cause it to fall, creating the risk of
personal injury.
EN-3
Safety Precautions
● Using the projector on a base with
casters
Whenever using the projector on a base that has
casters, make sure that you lock the casters when
not moving the base.
● Lightening
During a lightening storm, do not touch the plug of
the projector’s power cord.
● Remote controller
Never try to take the remote controller
!
+
● Radio waves emitted by the wireless
-
-
• If you are using a pace maker or any other
apart or modify it in any way. Doing so
creates the risk of electric shock, burn
injury, and other personal injury. Be sure
to leave all internal inspection,
adjustment, and repair up to your original
dealer or authorized CASIO service
center.
Never allow the remote controller to
become wet. Water creates the risk of fire
and electric shock.
adapter (which is provided with some
projector models)
Never use this product inside of an
aircraft or medical facility, or in any other
location where use of such devices is
prohibited. Radio waves can have an
effect on the operation of electronic
equipment and medical equipment, and
cause accidents.
Do not use this product in the vicinity of
high-precision electronic instruments or
electronic devices that handle weak radio
signals. Radio waves can have an effect
on the operation of such equipment, and
cause accidents.
electronic medical device, be sure to consult
your physician or device manufacturer before
using this product.
Caution
*
● Power cord
Misuse of the power cord creates the risk
-
• When unplugging the power cord, always grasp
• Insert the plug into the power outlet as far as it
• After using the projector, unplug it from the
• Unplug the projector from the power outlet if you
• At least once a year, unplug the power plug and
• Never use detergent to clean the power cord,
• Before moving the projector, be sure to turn it off
● Backup of important data
+
● During projection, make sure there is
An object in front of the lens creates the risk of fire.
● Lens effect
Never have an aquarium or any other object that
produces a lens effect in front of the projector
while the light source unit is on. Such an object
creates the risk of fire.
● Lens
Never touch the lens with your hand.
● Wireless adapter (provided with some
-
of fire and electric shock. Make sure that
you always observe the following
precautions.
the plug, and do not pull on the power cord.
will go.
power outlet.
do not plan to use it for a long time.
use a dry cloth or vacuum cleaner to clear dust
from the area around the prongs of the power
plug.
especially the power plug and jack.
and unplug it from the power outlet first.
Be sure to keep separate written records
of all data stored in projector memory.
Memory data can be lost due to
breakdown, maintenance, etc.
nothing in front of the lens blocking
the light.
projector models)
Keep the wireless adapter out of the
reach of small children. Accidental
swallowing of a wireless adapter can
interfere with proper breathing and create
a life-threatening situation.
EN-4
Safety Precautions
Battery Precautions
Danger
*
Should liquid leaking from an alkaline
battery get into the eyes, immediately take
+
the following steps.
Do not rub the eyes! Wash the eyes with clean
1.
water.
Contact a physician immediately. Failure to
2.
take immediate action can lead to loss of
eyesight.
Warning
*
Misuse of batteries can cause them to leak and
stain the area around them, or to explode, creating
the risk of fire and personal injury. Make sure that
you always observe the following precautions.
• Never try to take batteries apart and do
-
+
Misuse of batteries can cause them to leak and
stain the area around them, or to explode, creating
the risk of fire and personal injury. Make sure that
you always observe the following precaution.
-
not allow them to become shorted.
• Never expose batteries to heat or throw
them into fire.
• Never mix old batteries and new ones.
• Never mix batteries of different types.
• Never try to charge batteries.
• Take care that batteries are oriented
correctly when you load them.
Caution
*
• Use only the type of batteries that is
specified for the remote controller.
Lens Cover
Warning
*
The lens cover of this Data Projector uses
+
-
Other
Allowing dust to build up inside the projector by
not cleaning it for long periods creates the risk of
fire and accident, and can cause loss of projection
luminosity. Contact your original dealer or
authorized CASIO service center once a year about
having the interior of the projector cleaned. Note
that you will be charged for cleaning.
● Be sure to follow all applicable local
a magnetic attachment. Because of this,
it should not be used in the vicinity of
anyone wearing a pacemaker or any
other electric medical device. Should any
problem arise, move the lens cover away
from the person experiencing the
problem and consult a physician.
Caution
*
Keep the lens cover away from floppy
disks, magnetic cards, magnetic tapes,
prepaid cards, checks, and any other
media that uses magnetic recording. The
lens cover can corrupt data recorded on
magnetic media.
Caution
*
laws and regulations, and do not
dismantle the projector when
disposing of it.
● Dead batteries
Be sure to remove batteries from the remote
controller as soon as they go dead.
• Remove batteries from the remote
+
● Disposing of batteries
Make sure that you dispose of used batteries in
accordance with the rules and regulations in your
local area.
controller if you do not plan to use it for a
long time.
EN-5
Operating Precautions
About the Light Source Unit
z The projector’s light source unit uses a laser and LED.
z The life of the light source unit is rated at approximately 20,000 hours. The actual life will depend on
use conditions, the settings configured on the setup menu, and differences between each individual
light source unit.
z The light source unit is warranted for the period noted on the warranty certificate or for 6,000 hours,
whichever comes first.
z The failure of the light source unit to light or a noticeable drop in light source unit brightness indicates
the end of the light source unit’s life. Contact your original dealer or authorized CASIO service center
for replacement. Note that problems caused by unauthorized projector disassembly or modification
are not covered by the warranty and are not eligible for repair by CASIO.
Laser Precautions
This projector is a Class 1 laser device that conforms with IEC 60825-1.
z This projector has a built-in laser module. Disassembly or modification is very dangerous and should
never be attempted.
z Any operation or adjustment not specifically instructed by the user’s guide creates the risk of
hazardous laser radiation exposure.
EN-6
Bottom
Operating Precautions
Vent Outlets
• Vent outlets become very hot during projection. Never touch vents or allow them to become blocked.
• Do not insert foreign objects.
Bottom
Projector Light Emission
• Never look directly into the lens while the light is on.
EN-7
Operating Precautions
Other Precautions
This projector is made of precision components. Failure to observe the following precautions can result
in inability to correctly save data and malfunction.
● Never use or store the projector in the following locations. Doing so creates the
risk of malfunction of and damage to the projector.
z Locations subjected to electrostatic charge
z Locations subjected to temperature extremes
z Locations where there is extreme moisture
z Locations subjected to sudden temperature changes
z Locations where there is a lot of dust
z On a shaky, slanted, or otherwise unstable surface
z Locations where there is the danger of getting wet
z Locations where there are large amounts of oil smoke or other smoke
● Avoid using the projector under the following conditions. Such conditions
create the risk of malfunction of and damage to the projector.
z Avoid areas subject to temperature extremes (operating temperature range is 5°C to 35°C (41°F to
95°F)).
z Never place heavy objects on the projector or climb on top of the projector.
z Never insert or allow foreign objects to drop into the projector.
z Never place a vase or any other container of water on top of the projector.
● Whenever setting the projector down or performing any operation that involves
moving or reorienting it, take care that you do not pinch your fingers under the
projector.
● Never leave dead batteries inside the remote controller for a long time.
Dead batteries can leak, which leads to malfunction of and damage to the remote controller. Be sure to
replace the batteries at least once every one year, no matter how much you use the remote controller
during that time.
● Clean with a soft, dry cloth.
When very dirty, use a soft cloth that has been dampened in a weak solution of water and a mild neutral
detergent. Wring all excess water from the cloth before wiping. Never use thinner, benzine, or any other
volatile agent to clean the projector. Doing so can remove its markings and cause staining of the case.
● Missing Screen Dots
Though this projector is manufactured using the most advanced digital technology available today, some
of the dots on the screen may be missing. This is normal, and does not indicate malfunction.
● Never subject the projector to strong impact while it is projecting.
If the projector is accidentally subjected to strong impact, the projection image will momentarily go
blank. The image will reappear after some time, but it may be the wrong color or it may be accompanied
by an error message.
If the projected image is the wrong color, re-select the current input source. If this does not return the
projected image to its proper color, turn projector power off and then back on again.
If the image reappears with an error message, correct the problem in accordance with the indicator
explanations under “Error Indicators and Warning Messages” in the User’s Guide.
EN-8
Operating Precautions
● Keystone Correction and Image Quality
Performing keystone correction causes the image to be compressed before it is projected. This can
result distortion of the image or a loss of image quality. If this happens, change orientation of the
projector and/or screen so it conforms as much as possible to the illustration under “Setting Up the
Projector” in the User’s Guide.
If image quality is the highest priority, turn off auto keystone correction and position the projector so it is
pointed straight at the screen.
z Even if your projector is still within the warranty period, you will be charged for repair if a problem is
due to running the projector non-stop for very long periods (like 24 hours) or if the projector was set up
and used without following the “Setup Precautions” in the User’s Guide.
z Use under high ambient temperature or in environments subjected to large amounts of dust, oil
smoke, tobacco smoke, or other types of smoke can shorten the replacement cycles and require more
frequent replacement of the optical engine and other components. Note that you are charged for such
replacement. For details about replacement cycles and fees, contact an authorized CASIO service
center.
Precaution when Handling the Projector after Use
The projector’s exhaust vents and the area around the vents
become very hot during operation, and will still be hot immediately
after turning off the projector. Because of this, you should hold the
sides of the projector as shown in the illustration whenever
moving it.
Stowing the Projector in the Carrying Bag
Make sure the projector is no longer warm before stowing it in the carrying bag.
Cleaning the Projector
z Periodically clean the projector exterior, lens, intake vents and exhaust vents on a regular basis.
z When cleaning the lens, do not apply undue force and take care to avoid damaging it.
z Dust and dirt tend to collect around the intake vents. Because of this, you should use a vacuum
cleaner to clean away accumulated dust and dirt periodically.
z Continued use of the projector after dust has accumulated around the intake vents can cause
overheating of internal components and lead to malfunction.
z Certain operating conditions also can cause dirt and dust to accumulate around the projector’s
exhaust vents. If this happens, use the same procedure as that described above to clean the exhaust
vents.
EN-9
General Guide
CLASS 1 LASER PRODUCT
Intake vents
Control panel
Indicators
Brightness sensor[P] (Power) key
Remote control signal receiverExhaust vents
Release button Front foot
Rear feet
Intake vents
Lens cover
(Magnetic attachment to projector)
Projection lens
Control Panel and Indicators
LIGHT indicator
POWER/STANDBY indicator
[P] (Power) key
TEMP indicator [FOCUS] key
[INPUT] key
[ZOOM] key
[AUTO] key
EN-10
[ENTER] key
[MENU] key
[ESC] key
Cursor keys (q/w/U/I)
Quick Guide
This section explains the operational flow up to the point that projection is started.
For more individual operations, see the User’s Guide (UsersGuide.pdf).
1. Load batteries into the remote controller.
☞ “To load remote controller batteries” (User’s Guide)
2. Place the projector onto a table, desk, or stand that is level and firm, making sure
that you allow enough room around it.
☞ “Setting Up the Projector”, “Setup Precautions” (User’s Guide)
z Also, be sure to read the “Safety Precautions” (page EN-1) and the “Operating Precautions” (page
EN-6).
3. Referring to the illustration on page EN-10, adjust the vertical angle of the projector.
1 Lift up the front of the projector and press the release button. This causes the front foot to drop
from the bottom of the projector.
2 While holding down the release button, raise and lower the front of the projector. When the front
foot is the height you want, release the release button. The front foot will lock at that position.
3 Make fine adjustments to the horizontal tilt of the projector by rotating the rear feet.
4. Use the supplied power cord to plug the projector into a power outlet.
5. Connect the projector to an image output device and then turn on the device.
☞ “Connecting Projector Cables” (User’s Guide)
6. Remove the projector lens cover.
7. Press the [P] (Power) key to turn on the projector.
z The first time you turn on the projector, a “Language” window will appear in the center of the
projection screen. Select the language you want.
8. Use the [INPUT] key to select the input source.
☞ “Selecting the Input Source” (User’s Guide)
9. On the remote controller, use the [ZOOM +] and [ZOOM –] keys to adjust the
projected image size.
10.
On the remote controller, use the [FOCUS e] and [FOCUS r] keys to adjust image
focus.
11.
After you finish projecting, press the [P] (Power) key.
z This will cause a power down confirmation message to appear. Press the [P] (Power) key again
to turn off the projector.
NOTE
z This product is also designed for IT power distribution system with phase-to-phase voltage 230V.
If you run into problems...
If you experience any problems while operating the projector or if you suspect that the projector is not
operating properly, refer to the “Troubleshooting” section in the User’s Guide (UsersGuide.pdf).
EN-11
Specifications
Model Name XJ-A142/XJ-A147 XJ-A242/XJ-A247 XJ-A252/XJ-A257
Display system DLP® chip × 1, DLP® system
Display Chip Chip Size XGA 0.55 inches
Number of Pixels 786,432
Projection Lens 2X power zoom, power focus
Light Source Laser and LED
Projected Image Size 15 to 300 inches 18 to 300 inches
Projection
Distance
Gamut Full color (16.77 million colors)
Brightness 2500 lumens 3000 lumens
Contrast Ratio (Full White / Black) 1800:1
Scanning
Frequencies
Display
Resolution
Terminals RGB input COMPUTER terminal: RGB 15-pin mini D-Sub × 1
Wireless Support *
Speaker 1W × 1, Monaural
Operating Temperature 5 to 35°C (41 to 95°F)
Operating Humidity 20 to 80% (non-condensation)
60 inches 1.70 to 3.36 meters
100 inches 2.86 to 5.61 meters
Minimum
Projection
Distance
Horizontal 15 to 91 kHz
Vertical 50 to 85 Hz
RGB Signal Native: 1024 × 768 Native: 1280 × 800
Component Signal Maximum: 1920 × 1080 (HDTV 1080P)
HDMI Signal Maximum: 1920 × 1080 (HDTV 1080P)
Video Signal NTSC, PAL, PAL-N, PAL-M, PAL60, SECAM
Component Input
Digital Video Input HDMI input terminal: HDMI type A terminal × 1
Analog Video Input
Audio (Stereo)
Input and Output
USB Host USB type A × 1 (XJ-A147, XJ-A247, XJ-A257 only)
USB Device Micro-USB type B × 1 (back of projector)
Control Terminal RS-232C
1
(Aspect ratio: 4:3)
(1024 × 768)
F 2.29-3.09 / f 15.9-30.8
(5.6 to 11 feet)
(9.4 to 18.4 feet)
0.84 meters (2.8 feet)
Maximum: 1600 × 1200 (UXGA) resizing
Used for both RGB input and component (YCbCr/YPbPr)
HDCP support, audio signal support
AV terminal: 3.5 mm mini jack × 1
Used for both video input and audio input/output.
(XJ-A147, XJ-A247, XJ-A257 only)
Micro-USB type B × 1 (side of projector): For logo data
(Requires separately available YK-60 converter cable.)
IEEE 802.11b/g/n compatible
(XJ-A147, XJ-A247, XJ-A257 only)
WXGA 0.65 inches
(Aspect ratio: 16:10)
1,024,000
(1280 × 800)
1.43 to 2.84 meters (4.7 to 9.3 feet)
2.41 to 4.75 meters (7.9 to 15.6 feet)
input.
registration
EN-12
Specifications
Model Name XJ-A142/XJ-A147 XJ-A242/XJ-A247 XJ-A252/XJ-A257
Operating Altitude 0 to 3,000 meters (0 to 10,000 feet) above sea level
Power Requirements 100 to 240V AC, 50/60Hz
Power Consumption (100 to 240V)
Eco Level 1 when Eco Mode is “On” 115W 120W
Eco Level 5 when Eco Mode is “On” 70W 75W
When “Bright” is selected for Eco
Off Mode.
When “Normal” is selected for Eco
Off Mode.
Standby Power
Consumption
Approximate Dimensions 297 (W) × 210 (D) × 43 (H) mm (11.7" × 8.3" × 1.7")
Approximate Weight 2.3kg (5.1lbs)
*1 With connection of provided wireless adapter to USB-A port on the back of the projector.
Specifications are subject to change without notice.
100 to 120V 0.14W
220 to 240 V 0.23W
155W 165W
125W 135W
(Including projections)
EN-13
Specifications
GPL and LGPL (for USB port model users)
(1) This product uses software (This Software) that comes under the GNU General Public License
(GPL) and GNU Lesser General Public License (LGPL). In accordance with the GPL and LGPL, the
source code of This Software is open source code. Anyone who wishes to view the open source
code can do so by downloading it from the CASIO Projector download site. Whenever copying,
modifying, or distributing This Software, be sure to do so in accordance with the terms and
conditions of the GPL and LGPL.
(2) This Software is provided “as is” without expressed or implied warranty of any kind. However, this
disclaimer does not affect the terms and conditions of the warranty of the product itself (including
malfunctions due to This Software).
(3) The full text of the GPL and LGPL that covers this software can be found at the back of the “User’s
Guide”. The “User’s Guide” for this projector is included with the files that you download from the
website whose URL is provided on the cover of this manual.
z DLP is a registered trademark of Texas Instruments Incorporated of the United States.
z Microsoft, Windows, Windows Vista, and PowerPoint are registered trademarks or trademarks of Microsoft
Corporation in the United States and other countries.
z HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of
HDMI Licensing, LLC.
z Apple and Macintosh are registered trademarks of Apple Inc. of the United States.
z Adobe and Reader are registered trademarks of Adobe Systems Incorporated.
z XGA is a registered trademark of IBM Corporation of the United States.
z Other company and product names may be registered trademarks or trademarks of their respective
owners.
EN-14
GUIDELINES LAID DOWN BY FCC RULES FOR USE OF THIS UNIT IN THE U.S.A. (not
applicable to other areas).
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communication. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
z Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
Proper connectors must be used for connection to host computer and/or peripherals in order to meet
FCC emission limits.
Connector cable.... XJ-A142/XJ-A147/XJ-A242/XJ-A247/XJ-A252/XJ-A257 unit to PC
Model Number: XJ-A142/XJ-A147/XJ-A242/XJ-A247/XJ-A252/XJ-A257
Trade Name: CASIO COMPUTER CO., LTD.
Responsible party: CASIO AMERICA, INC.
Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801
Telephone number: 973-361-5400
This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Declaration of Conformity
FCC Information
This device, Wireless LAN USB Adapter, complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received; including interference that may cause undesired operation.
Federal Communications Commission (FCC) Statement
This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user authority to operate the
equipment.
Tested to comply with FCC standard. FOR HOME OR OFFICE USE.
FCC RF Radiation Exposure Statement:
1. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment,
under 47 CFR 2.1093 paragraph (d)(2).
2. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The Wireless LAN USB Adapter has been tested to the FCC exposure requirements (Specific Absorption
Rate).
XJ-A142/XJ-A147/XJ-A242/XJ-A247/XJ-A252/XJ-A257
FOR CALIFORNIA USA ONLY
Perchlorate Material – special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Manufacturer:
CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan
Responsible within the European Union:
CASIO EUROPE GmbH
Casio-Platz 1, 22848 Norderstedt, Germany
RJA530264-002
Printed in Japan
Imprimé au Japon
MA1403-A
Loading...
