CH CALL
(without price)
TV-M420B (KX-504B)
TV-8700B (KX-514B)
FEB. 1996
TUNING
VHF
UHF
24
14
OFF VHF UHF
VOLUME
BRIGHT
5
30
6
40
50
7
11
60
13
69
CH
CH
EAR
EXT.ANT
AUDIO/
VIDEO
DC IN 12V
504030 60 69
VHF 2 4 5 6 7 11 13 CH
UHF 14
CH
TV-8700BTV-M420B
R
CONTENTS
SPECIFICATIONS ......................................................................................... 1
BLOCK DIAGRAM ........................................................................................ 2
PRINTED CIRCUIT BOARDS ....................................................................... 3
EXPLODED VIEW ......................................................................................... 7
ELECTRICAL PARTS LIST........................................................................... 9
MECHANICAL PARTS LIST ....................................................................... 15
IC AND TRANSISTOR LEAD IDENTIFICATION ........................................ 17
SCHEMATIC DIAGRAMS ........................................................................... 19
WAVEFORMS.............................................................................................. 21
SPECIFICATIONS
Item Specification
1. Reception channels VHF: 2 ~ 13 ch UHF: 14 ~ 69 ch
2. Power voltage DC 12.0 V
3. Power consumption TV-M420B: Approx. 6.7 W TV-8700B: Approx. 5.7 W
4. Current consumption TV-M420B: Approx. 558 mA TV-8700B: Approx. 475 mA
5. Battery life (with alkaline batteries) Approx. 9.0 hours (TV-8700B only)
Batteries : 4 × LR20 (D) size batteries (TV-8700B only)
6. Power supply Car adaptor : CA-K1200
AC adaptor : AD-K1200
Earphone jack : 3.5 ø mini
External power jack : 12.0 V DC IN
7. Connection terminals External antenna jack : 3.5 ø mini
Audio/Video jack : 3.5 ø mini
Diversity jack : 3.5 ø mini (TV-M420B only)
8. Screen size 4 inches
9. No. of picture element 153,360 (213 × 720) dots
TV-M420B : 104 mm (H) × 142 mm (W) × 41 mm (D)
10. Dimensions
TV-8700B : 104 mm (H) × 142 mm (W) × 74 mm (D)
TV-M420B : 354 g excluding batteries
11. Weight
TV-8700B : 445 g excluding batteries
AC adaptor : AD-K1200
Car adaptor : CA-K1200
12. Options
RF connector : CF-13
Antenna matching device : AS-35S
— 1 —
Antenna
BLOCK DIAGRAM
2 IC200
IF Amp.
Video
Sound
FM
AFT Circuit
AGC Circuit
Chroma Circuit
4 IC700
OSC
Display
Control
A/D Converter
Auto-tuning
Control
6 IC800
Det.
}
Display
Voltage
Generator
Power
Supply
1 TU
Tuner
5 IC500
Tuning
Voltage
Generator
VCC2 (3.95 V)
VCC7 (45 V)
VEE1 (-8 V)
VR800
Brightness
Control
1 — Tuner TU TEPU5-02
Selects a desired radio wave, and changes it to the video IF signal.
VR640
Volume
Control
3 IC600
Common
Driver
Speaker
Audio
Amp.
LCD
Segment
Driver
2 — Video, Sound, FM Det., AGC, Chroma circuit IC200 CST-2
Eliminates the carrier wave in the video IF signal, and picks up the video signal and the sound IF signal.
The sound signal is picked up from the sound IF signal by FM detection.
Generates the tricolor of red, green and blue from the video signal.
3 — Audio Amp. IC600 NJM386 (TV-M420B), NJM2070 (TV-M8700B)
Sound amplification.
4 — OSC, A/D Converter, Display / Auto-tuning Control : IC700 MSM6625-01 GSK-640E
Converts the color signal into digital signal.
Also generates the clock pulse for the display, and controls the display.
5 — Tuning Voltage Generator IC500 MSC1169MS-K
Generates the tuning voltage from the tuning pulse (TU) output of 4.
6 — Display Voltage Generator IC800 BA10358F
Generates the display voltages V0 ~ V4 from VEE1 and VCC7 outputs of the power supply.
— 2 —
