Casio EXILIM EX-ZR800 User Guide
Digital Camera
User’s Guide
E
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM
Website at http://www.exilim.com/
Accessories
As you unpack your camera, check to make sure that all accessories shown below
are included. If anything is missing, contact your original retailer.
Rechargeable lithium ion
battery (NP-130A)
Power cord
2
*
To attach the strap to the camera
USB-AC adaptor*
(AD-C54UG/AD-C53U)
Micro USB cable Basic Reference
Attach strap here.
1
Strap
*1 The type of USB-AC adaptor included varies according to the country or
geographic area where the camera is sold.
*2 A power cord is included with the AD-C53U USB-AC adapter. The shape of the
power cord plug varies according to the country or geographic area where the
camera is sold.
2
Read this first!
• The contents of this manual are subject to change without notice.
• The contents of this manual have been checked at each step of the production
process. Feel free to contact us if you notice anything that is questionable,
erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is
forbidden. Except for your own personal use, any other use of the contents of this
manual without the permission of CASIO COMPUTER CO., LTD. is forbidden
under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits suffered by you or any third party due to the use or malfunction of this
product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits caused by loss of memory contents due to malfunction, repair, or any other
reason.
• Note that the example screens and product illustrations shown in this User’s Guide
may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that
provides a pixel yield in excess of 99.99%. This means that some very small number
of pixels may not light or may remain lit at all times. This is due to the characteristics
of the liquid crystal panel, and does not indicate malfunction.
Take test shots
Before shooting your final image, shoot a test shot to ensure that the camera is
recording correctly.
3
Contents
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
]\
General Guide 9
]\
Monitor Screen Contents and How to Change Them 11
]\
Quick Start Basics 14
What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
] To load the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
] Charge the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . . 21
Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
] Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
] To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
] To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Turning the Camera On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Holding the Camera Correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
To shoot a snapshot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
] Selecting an Auto Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
] To shoot a snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Deleting Snapshots and Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
]\
Snapshot Tutorial 36
Selecting the Recording Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Using the Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer) . . 39
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . . 40
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Focus) . . 42
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ISO) . . 44
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . .(Make-up Level) . . 45
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift) . . 46
Using Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Flash) . . 47
Specifying the Metering Mode . . . . . . . . . . . . . . . . . . . . . . . . . (Metering) . . 49
Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
] Monitor Screen Information when Zooming . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
] Zooming with Super Resolution . . . . . . . . . . . . . . . . . . . . . . . . (Zoom (SR)) . . . 53
] Expanding the Zoom Range to Shoot Clearer Snapshots . (Multi SR Zoom). . . 54
Shooting a Burst of Images . . . . . . . . . . . . . . . . . . . . . . (High Speed CS) . . 54
4
Contents
Shooting with Artistic Effects . . . . . . . . . . . . . . . . . . . . . . . . (ART SHOT) . . 58
] Saving a Second Normal Image
When Shooting With HDR Art . . . . . . . . . . . . . . . . . . . .(Double (HDR Art)) . . . 60
Shooting with Triple Shot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
]\
Recording Movies 62
To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
] Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Recording a High-definition Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Recording a High Speed Movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Using Prerecord Movie . . . . . . . . . . . . . . . . . . . . . . . . (Prerecord (Movie)) . . 67
Recording a Time Lapse Movie . . . . . . . . . . . . . . . . . . . . . . (Time Lapse) . . 69
Recording a Movie for YouTube . . . . . . . . . . . . . . . . . . . . . (For YouTube) . . 71
Shooting a Snapshot while Shooting a Movie . . . . . (Snapshot In Movie) . . 72
]\
Using BEST SHOT 74
To shoot with BEST SHOT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Creating and Using Your Own Setups . . . . . . . . . . . . . (CUSTOM SHOT) . . 76
Shooting with High Speed Anti Shake . . . . . . . . . . . . . . . (HS Anti Shake) . . 77
Shooting Bright Images in the Dark without Flash . . . . . . (HS Night Shot) . . 78
Digitally Correcting for Overexposure and Underexposure . . . . . . (HDR) . . 79
Shooting with a Blurred Background . . . . . . . . . . . (Blurred Background) . . 80
Shooting with Full Focus Macro . . . . . . . . . . . . . . . . (All-In-Focus Macro) . . 81
Using Continuous Shutter with Auto Focus . . . . . . . . . . . . . . . . . (AF-CS) . . 82
Shooting with Priority on Subject Faces . . . . . . . . . . . (HS Best Selection) . . 83
Shooting a Panorama Image . . . . . . . . . . . . . . . . . . . . .(Slide Panorama) . . 84
Shooting with a Super Wide Angle of View . . . . . . . . . . . . . . (Wide Shot) . . 86
Shooting Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Snapshot) . . 89
Shooting RAW Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Raw Image) . . 90
Using a TV Screen to Shoot Snapshots . . . . . . . . . . . . (HDMI TV Output) . . 91
]\
Advanced Settings (REC MENU) 93
Configuring Recording Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Triggering a Self-timer Operation with Motion . . . . . . . . .(Motion Shutter) . . 94
Repositioning the Motion Detection Area . . . . . . . . . . . . (Motion Position) . . 95
Assigning Functions to the Control Dial . . . . . . . . . . . . . . . . (Control Dial) . . 96
Assigning Functions to the [4] and [6] Keys . . . . . . . . . . . . . . . (L/R Key) . . 97
Saving a Second Normal Image When
Shooting With HDR Art . . . . . . . . . . . . . . . . . . . . . . . (Double (HDR ART)) . . 97
To select the snapshot image size . . . . . . . . . . . . . . . . . . . . (Image Size) . . 98
Specifying Snapshot Image Quality . . . . . . . . . . . . . . . . . (Image Quality) . 100
Movie Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . (Movie Quality) . 100
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ISO) . 101
Specifying the ISO Sensitivity Upper Limit . . . . . . . . . . . . (ISO High Limit) . 102
5
Contents
Zooming with Super Resolution . . . . . . . . . . . . . . . . . . . . . . .(Zoom (SR)) . 102
Specifying the Auto Focus Area . . . . . . . . . . . . . . . . . . . . . . . . . (AF Area) . 103
Reducing the Effects of Camera and Subject Movement . . . . (Anti Shake) . 104
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . 105
Shooting with Continuous Auto Focus . . . . . . . . . . . . . . (Continuous AF) . 105
Shooting with Face Detection . . . . . . . . . . . . . . . . . . . . . (Face Detection) . 106
Turning Digital Zoom On or Off . . . . . . . . . . . . . . . . . . . . . . (Digital Zoom) . 107
Reducing Wind Noise during Movie Recording . . . . . . . (Wind Noise Cut) . 107
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . .(Make-up Level) . 107
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift) . 108
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . 108
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Focus) . 108
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer) . 108
Specifying the Metering Mode . . . . . . . . . . . . . . . . . . . . . . . . . (Metering) . 108
Specifying Flash Intensity . . . . . . . . . . . . . . . . . . . . . . . . . (Flash Intensity) . 109
Controlling Image Sharpness . . . . . . . . . . . . . . . . . . . . . . . . . (Sharpness) . 109
Controlling Color Saturation . . . . . . . . . . . . . . . . . . . . . . . . . . (Saturation) . 109
Adjusting Image Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Contrast) . 109
Using the Auto Focus Assist Light . . . . . . . . . . . . . . . . . (AF Assist Light) . 110
Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Review) . 110
Using Icon Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Icon Help) . .111
Changing the Monitor Screen when Recording . . . . . . . . . (Shooting Info) . .111
Configuring Power On Default Settings . . . . . . . . . . . . . . . . . . . (Memory) . 113
]\
Viewing Snapshots and Movies 114
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Viewing a Panorama Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Viewing Continuous Shutter Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
] Deleting Continuous Shutter Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
] Dividing Up a CS Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
] Copying a CS Group Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Displaying the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Viewing Snapshots and Movies on a TV Screen. . . . . . . . . . . . . . . . . . . . . . 121
]\
Other Playback Functions (PLAY MENU) 124
Specifying the Control Dial Image Scroll Method . . . . . . . . . (Control Dial) . 124
Playing a Slideshow on the Camera . . . . . . . . . . . . . . . . . . . . (Slideshow) . 124
] Transferring Music from Your Computer to Camera Memory . . . . . . . . . . . . . . 126
Creating a Snapshot of Movie Frames . . . . . . . . . . . . . (MOTION PRINT) . 127
Editing a Movie on the Camera . . . . . . . . . . . . . . . . . . . . .(Movie Editing) . 127
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . 129
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . 129
6
Contents
Adjusting the Brightness of an Existing Snapshot . . . . . . . . . (Brightness) . 130
Selecting Images for Printing . . . . . . . . . . . . . . . . . . . . . . (DPOF Printing) . 130
Protecting a File Against Deletion . . . . . . . . . . . . . . . . . . . . . . . . . (Protect) . 130
Editing the Date and Time of an Image . . . . . . . . . . . . . . . . . (Date/Time) . 132
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Rotation) . 132
Resizing a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize) . 133
Cropping a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Trimming) . 133
Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Copy) . 134
Dividing Up a Continuous Shutter Group . . . . . . . . . . . . . . (Divide Group) . 134
Combining CS Images into a Single Still Image . . . . . . . . (CS Multi Print) . 135
Editing a CS Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(CS Frame Edit) . 135
]\
Printing 136
Printing Snapshots. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Connecting Directly to a PictBridge Compatible Printer . . . . . . . . . . . . . . . . 136
Using DPOF to Specify Images to be Printed and
the Number of Copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . (DPOF Printing) . 138
]\
Using the Camera with a Computer 143
Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . 144
] Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . 144
] Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
] Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . 148
] Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Using an SD Memory Card with Built-in LAN . . . . . . . . . . . . . . . . . . . . . . . . 151
] Transferring Images with an Eye-Fi Card . . . . . . . . . . . . . . . . . . . (Eye-Fi). . 151
] Using a Smartphone to Play Back Images Stored on
a FlashAir Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (FlashAir). . 153
Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
]\
Other Settings (SETTING) 158
Enabling Power Saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ECO Mode) . 158
Adjusting Monitor Screen Brightness . . . . . . . . . . . . . . . . . . . . . . (Screen) . 158
Turning off Eye-Fi Card Communication . . . . . . . . . . . . . . . . . . . . (Eye-Fi) . 159
Configuring FlashAir Card Communication Settings . . . . . . . . . (FlashAir) . 159
Configuring Camera Sound Settings . . . . . . . . . . . . . . . . . . . . . (Sounds) . 159
Creating an Image Storage Folder . . . . . . . . . . . . . . . . . . (Create Folder) . 160
Time Stamping Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . .(Timestamp) . 160
Auto Image Orientation Detection and Rotation . . . . . . . . . . (Auto Rotate) . 161
Specifying the File Name Serial Number Generation Rule . . . . . (File No.) . 161
Configuring Sleep State Settings . . . . . . . . . . . . . . . . . . . . . . . . . . (Sleep) . 162
7
Contents
Configuring Auto Power Off Settings . . . . . . . . . . . . . . . (Auto Power Off) . 162
Configuring [r] Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(REC) . 163
Configuring [p] Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (PLAY) . 163
Disabling File Deletion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Delete Key) . 163
Configuring World Time Settings . . . . . . . . . . . . . . . . . . . . . (World Time) . 164
Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . 165
Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . 165
Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . 166
Configuring USB Protocol Settings . . . . . . . . . . . . . . . . . . . . . . . . . .(USB) . 166
Selecting the HDMI Terminal Output Method . . . . . . . . . . . (HDMI Output) . 166
Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . . (Format) . 167
Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . . (Reset) . 167
]\
Appendix 168
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Precautions During Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
] Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
] Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
] Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
] Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
] Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Number of Snapshots/Movie Recording Time . . . . . . . . . . . . . . . . . . . . . . . . 191
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
8
Contents
General Guide
The numbers in parentheses indicate the pages where each item is explained.
Front Back
1234675
bm
bl bn bo bp
bq
br
bk 89
Mode dial
1
(pages 28, 36, 62)
Zoom controller
2
(pages 29, 50, 120)
Shutter button
3
(pages 26, 28)
[Õ] (Continuous
4
Shutter) button (page 54)
[ON/OFF] (Power)
5
(pages 21, 26)
Flash (page 47)
6
Flash switch (page 47)
7
Front lamp
8
(pages 39, 110)
Lens
9
ckcl bt bs
cm
Microphones (page 63)
bk
Back lamp
bl
(pages 18, 20, 26, 29,
48)
[0] (Movie) button
bm
(page 62)
[r] (REC) button
bn
(page 26)
Strap hole (page 2)
bo
Terminal cover
bp
[USB] port
bq
(pages 17, 19)
[HDMI OUT]
br
HDMI output (micro)
(pages 91, 122)
[MENU] button
bs
(pages 62, 93)
[p] (PLAY) button
bt
(pages 26, 32)
[SET] button
ck
(pages 38, 62, 93)
Control dial
cl
([8][2][4][6])
(pages 10, 38, 62, 74,
93, 96)
Monitor screen
cm
(pages 11, 28)
9
General Guide
Bottom
Battery/memory card slots (pages 16, 24)
cn
Battery cover
co
Speaker
cp
Tripod hole
cq
Use this hole when attaching to a tripod.
cp cncq co
. Control Dial
In addition to using the up, down, left, and right buttons, you can also use the control
dial to perform operations.
• Depending on the function, certain operations cannot be performed using the
control dial.
Control dial
[8] [2] [4] [6] : Press the applicable button (up, down, left, right).
10
General Guide
Monitor Screen Contents and How to Change Them
The monitor screen uses various indicators, icons, and values to keep you informed
of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the
indicators and figures that can appear on the monitor screen in various modes.
They do not represent screens that actually appear on the camera.
. Snapshot Recording (1 Shot)
Remaining snapshot memory capacity
2
13567
4
cn
cm
cl
ck
bt
bs
br
bq
Self-timer mode (page 39)
1
Face Detection (page 106)
2
Recording mode (page 28)
3
Image deterioration indicator/
4
Zoom (SR) indicator (page 52)
Remaining movie memory
5
capacity (page 62)
bp
6
(page 191)
8
Snapshot image size/Quality (pages 98, 100)
7
9
Movie quality (FHD/STD movie)
8
bk
(pages 62, 65)/
bl
Recording speed (high speed movie) (page 65)
bm
Focal distance
9
bn
(Converted to 35 mm film format.) (page 51)
bo
Anti Shake (page 104)
bk
Timestamp indicator (page 160)
bl
Histogram (page 111)
bm
AF Area (page 103)
bn
Date/Time (pages 21, 165)
bo
Focus frame (pages 29, 103)
bp
Battery level indicator (page 21)
bq
Metering mode (page 49)
br
Flash (page 47)
bs
Exposure compensation (page 46)
bt
Make-up level (page 45)
ck
ISO sensitivity (page 44)
cl
Focus mode (page 42)
cm
White balance (page 40)
cn
NOTE
• Depending on recording settings, the aperture, shutter speed, and ISO sensitivity
values may not appear on the monitor screen. These values will be red if the Auto
Exposure (AE) is not correct for some reason.
Monitor Screen Contents and How to Change Them
11
. Snapshot Recording (Burst Shooting)
Continuous Shutter (CS) speed (page 55)
5
6
7
5
6
7
8
1
Recording mode (page 28)
2
Remaining snapshot memory capacity
3
(page 191)
Allowable CS time/number of CS images
4
(page 55)
Remaining movie memory capacity (page 192)
5
Continuous Shutter mode (page 54)
6
Prerecord CS shots (page 56)
7
Maximum CS shots (page 55)
8
Snapshot recording mode (Snapshot In Movie)
1
(page 72)
Audio recording disabled (page 65)
2
Recording mode (page 62)
3
Movie recording time (page 62)
4
Remaining movie memory capacity (page 62)
5
Movie recording in progress (page 62)
6
Movie quality (FHD/STD movie)
7
(pages 62, 65)/
Recording speed (high speed movie) (page 65)
Remaining snapshot memory capacity
8
(page 191)
Folder name/file name (page 155)
4
Snapshot image quality (page 100)
5
Recording mode (page 28)
6
Histogram (page 111)
7
Date/time (page 165)
8
Metering mode (page 108)
9
White balance (page 129)
bk
Battery level indicator (page 21)
bl
Flash (page 47)
bm
Exposure compensation (page 46)
bn
Shutter speed
bo
Aperture value
bp
ISO sensitivity (page 44)
bq
Focal distance
br
(Converted to 35 mm film format.)
1243
8
7
6
. Movie Recording
5
42
1
3
8
. Snapshot Viewing
2413
br
bq
bp
bo
bn
bm
bk 9bl
File type
1
Protect indicator (page 130)
2
Snapshot image size (page 98)
3
Monitor Screen Contents and How to Change Them
12
. CS Image Viewing
Number of images in the group (page 116)
12
1
CS group icon (page 116)
2
. Movie Playback
No audio data available
3
4
1
Movie recording time (page 114)
2
Recording mode/Movie quality/speed
3
(pages 62, 65, 65)
YouTube (page 71)
4
1 2
. Configuring Monitor Screen Settings
Each press of [8] (DISP) will cycle through display settings that
display or hide on-screen information. You can configure separate
settings for the REC mode and PLAY mode.
REC mode
Information on Displays setting information.
Information off Hides setting information.
[8] (DISP)
PLAY mode
Information on
Information off No information displayed when shooting.
Displays settings when shooting, current date and time,
histogram (page 111), and other information.
Monitor Screen Contents and How to Change Them
13
Quick Start Basics
What you can do with your CASIO camera
Your CASIO camera is packed with a powerful selection of features and functions to
make recording of digital images easier, including the following main functions.
Time Lapse Movie
You can use this function to record movies of natural
events that occur over time, to speed up the flow of
traffic in a city scene, or to record other similar types of
movies.
*See page 69 for more information.
ART SHOT
A variety of artistic effects help to make even common,
ordinary subjects become more novel and exciting.
“ART SHOT” provides the following effects: HDR Art,
Toy Camera, Soft Focus, Light Tone, Pop, Sepia,
Monochrome, Miniature, Fisheye, Sparkling Shot.
*See page 58 for more information.
HS Night Shot
The camera shoots a series of images and then
merges them into a final image. The result is a bright
image, even if shot in the dark without a flash.
*See page 78 for more information.
Triple Shot
Pressing the shutter button shoots a burst of three
images and stores them in memory. This feature is
great for making sure you don’t miss those special
moments when kids are around.
*See page 61 for more information.
B
14
Quick Start Basics
Blurred Background
This function analyzes a burst of consecutive images
and then blurs the background behind the main
subject. This creates an effect that really makes the
subject stand out, just like photographs taken with a
single-lens reflex camera.
*See page 80 for more information.
All-In-Focus Macro
All-In-Focus Macro shoots and analyzes a burst of
multiple images and combines them in a way that
produces an image in which everything is in focus:
from nearby objects to distant objects.
*See page 81 for more information.
Premium Auto Pro
Select Premium Auto Pro recording and the
camera automatically determines whether you
are shooting a subject or scenery, and other
conditions. Premium Auto Pro delivers higher
image quality than standard Auto.
*See page 28 for more information.
High Speed Movie
Movies can be recorded at up to 1000 frames per
second. This makes it possible to clearly view
phenomena that are invisible to the human eye, in
slow motion.
*See page 65 for more information.
FHD Movie Recording
You can record movies in high-quality FHD.
x
1080 pixels 30 fps)
(1920
*See page 65 for more information.
15
Quick Start Basics
First, charge the battery prior to use.
Note that the battery of a newly purchased camera is not charged. Perform the steps
below to load the battery into the camera and charge it.
• Your camera requires a special CASIO rechargeable lithium ion battery (NP-130A
or NP-130) for power. Never try to use any other type of battery.
To load the battery
1. Open the battery cover.
2. Load the battery.
With the CASIO logo on the battery
facing downwards (in the direction
of the lens), hold the stopper next
to the battery in the direction
indicated by the arrow as you slide
the battery into the camera. Press
the battery in until the stopper
secures it in place.
3. Close the battery cover.
Battery
OK
Stopper
NG
CASIO logo
16
Quick Start Basics
To replace the battery
1. Open the battery cover and
remove the current battery.
Stopper
2. Load a new battery.
Charge the Battery
You can use either of the two following methods to charge the camera’s battery.
• USB-AC adaptor
• USB connection to a computer (Using the included micro USB cable.)
. To charge with the USB-AC adaptor
The adaptor lets you charge the battery while it is loaded in the camera.
While the camera is turned off, connect in the sequence shown below.
Charging time: Approximately 240 minutes
[USB] port
USB-AC adaptor
(AD-C54UG)
2
1
Micro USB cable
(included with camera)
4
3
3
u mark of the small (micro
USB) connector facing the lens
side of the camera.
• When disconnecting the USB-AC adaptor from the camera, be sure to disconnect
from the camera first.
1
USB-AC adaptor
(AD-C53U)
2
Power cord
B
17
Quick Start Basics
IMPORTANT!
• A battery that has not been used for a long time, or ambient temperature extremes
can cause charging to take longer than normal. If charging takes longer than about
five hours, a timer will terminate it automatically, even if the battery is not fully
charged. This is indicated by the back lamp flashing red. If the battery has not been
used for a very long time, charging may be terminated automatically and the back
lamp may start flashing red after only about 60 minutes. In either case, disconnect
the USB cable from the camera and then reconnect it to resume charging.
• Make sure that you insert the cable connector into the [USB] port until you feel it
click securely into place. Failure to insert the connector fully can result in poor
communication or malfunction.
• Note that even while the connector is fully inserted, you
still will be able to see the metal part of the connector as
shown in the illustration.
• The USB-AC adaptor will become warm during charging.
This is normal and does not indicate malfunction.
• The shape of the power plug depends on each country or
geographic area.
Back Lamp Operation
Lamp Status Description
Back lamp
Lit Red Charging
Abnormal ambient temperature,
Flashing Red
USB-AC adaptor problem, or battery
problem (page 178)
Off Charging complete
18
Quick Start Basics
. To charge using a USB connection to a computer
USB connection lets you charge the battery while it is loaded in the camera.
While the camera is turned off, connect in the sequence shown below (
[USB] port
1, 2
Computer
(power turned on)
).
USB port
1
Micro USB cable
(included with camera)
u mark of the small (micro USB) connector facing the
lens side of the camera.
USB
2
• If the camera is on, press [ON/OFF] (Power) to turn it off before connecting it to
your computer.
IMPORTANT!
• The first time you connect the camera to your computer with the USB cable, an
error message may appear on your computer. If this happens, disconnect and then
reconnect the USB cable.
• A battery that has not been used for a long time, certain types of computers, and
connection conditions can cause charging to take more than approximately five
hours, which will trigger a timer that terminates charging automatically, even if the
battery is not fully charged. If this happens, disconnect and then reconnect the
USB cable to restart charging. To complete charging faster, use of the included
USB-AC adaptor is recommended.
• If the battery has not been used for a very long time, charging may terminate
automatically and the back lamp may start flashing red or go out after only about
60 minutes. In either case, use of the USB-AC adaptor that comes with the camera
is recommended.
• If you turn on the camera while charging over a USB connection to a computer is in
progress, the camera will establish a USB connection with the computer. Though
charging normally should continue at this time, certain types of computers or
connection environments may stop charging if supply power is low. This will be
indicated by the camera’s back lamp lighting green.
• Charging is not performed while the connected computer is in the hibernate mode.
19
Quick Start Basics
Back Lamp Operation
Lamp Status Description
Lit Red,
(Lit/Flashing Amber)
Charging
Back lamp
Abnormal ambient temperature,
Flashing Red
charging taking abnormally long, or
battery problem (page 178)
Off, (Lit Green) Charging complete
• The information in parentheses in the above table shows the lamp status while the
camera is turned on during charging.
Other Charging Precautions
• With the two charging methods described above, you can charge the camera’s
battery (NP-130A or NP-130) without removing it from the camera. You also can
charge the battery using an optionally available charger unit (BC-130L). Never use
any other type of charger device. Attempting to use a different charger can result in
unexpected accident.
• This model can be charged only via from USB 2.0 specification USB port only.
• USB charging devices and power supply devices are subject to fixed standards.
Use of an inferior device or a device that is not up to standard can cause
malfunction and/or failure of your camera.
• Operation is not guaranteed in the case of a computer built or modified by you.
Even in the case of a commercially available computer, certain USB port
specifications may make it impossible to charge via the USB cable.
• A battery that is still warm immediately after normal use may not charge fully. Give
the battery time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of
this, it is recommended that you charge the battery immediately before you need to
use it.
• Charging the camera’s battery may cause interference with TV and radio reception.
If this happens, plug the USB-AC adaptor into an outlet that is further away from
the TV or radio.
• Actual charging time depends on current battery capacity and charging conditions.
• Do not use the USB-AC adaptor with any other device.
• Never use the power cord with another device.
• Use only the USB-AC adaptor and USB cable specified in this manual for charging.
Use of any other type of devices may result in improper charging.
20
Quick Start Basics
Checking Remaining Battery Power
As battery power is consumed, a battery indicator on the monitor screen indicates
remaining power as shown below.
Remaining Power High Low
Battery Indicator ***
Indicator Color White * White * Red * Red
indicates battery power is low. Charge the battery as soon as possible.
Recording is not possible when is indicated. Charge the battery immediately.
• The level shown by the battery indicator may change when you switch between the
REC mode and PLAY mode.
• Leaving the camera for about 30 days with no power supplied while the battery is
dead will cause its date and time settings to be cleared. A message telling you to
configure time and date settings will appear the next time you turn on the camera
after restoring power. When this happens, configure date and time settings (page
165).
• See page 197 for information about battery life and number of shots.
Battery Power Conservation Tips
• Entering the “ECO Mode” enables low-power operation (page 158).
• When you do not need to use the flash, select ? (Flash Off) for the flash setting
(page 47).
• Enable the Auto Power Off and the Sleep features to protect against wasting
battery power when you forget to turn off the camera (pages 162, 162).
• Select “Off” for “Continuous AF” (page 105).
Configuring Basic Settings the First Time You Turn On the Camera
The first time you load a battery into the camera, a screen appears for configuring the
display language, date, and time settings. Failure to set the date and time correctly
will cause the wrong date and time data to be recorded with images.
IMPORTANT!
• A screen for language selection will not appear in step 2 of the procedure below if
you purchased a camera intended for the Japanese market. To change the display
language from Japanese in this case, use the procedure under “Specifying the
Display Language (Language)” (page 166). Note that a version of this manual in
the language you select may not be included with a camera intended for the
Japanese market.
• Camera models sold in certain geographic areas may not support display language
selection.
21
Quick Start Basics
1. Press [ON/OFF] (Power) to turn on the
[ON/OFF] (Power)
camera.
2. Use [8], [2], [4], and [6] to select the
language you want and then press
[SET].
3. Use [8] and [2] to select a date style and then press [SET].
Example: July 10, 2015
YY/MM/DD
DD/MM/YY
MM/DD/YY
* 15/7/10
* 10/7/15
* 7/10/15
4. Set the date and the time.
Use [4] and [6] to select the setting you want to
change and then use [8] and [2] to change it.
To switch between 12-hour and 24-hour format, select
“24h” and then use [8] and [2] to change the setting.
5. After setting the date and time, use [4] and [6]
to select “Apply” and then press [SET].
If you make a mistake configuring display language, date, or time settings with the
above procedure, refer to the following pages for information about how to correct
the settings.
– Display language: page 166
– Date and time: page 165
NOTE
• Each country controls its local time offset and the use of summer time, and so they
are subject to change.
• Removing the battery from the camera too soon after configuring time and date
settings for the first time can cause the settings to be reset to their factory defaults.
Do not remove the battery for at least 24 hours after configuring settings.
22
Quick Start Basics
Preparing a Memory Card
Though the camera has built-in memory that can be used to store images and
movies, you probably will want to purchase a commercially available memory card for
greater capacity. The camera does not come with a memory card. Images recorded
while a memory card is loaded are saved to the memory card. When no memory card
is loaded, images are saved to built-in memory.
• For information about memory card capacities, see page 191.
Supported Memory Cards
– SD Memory Card
– SDHC Memory Card
– SDXC Memory Card
Use one of the above types of memory card.
• The above are supported memory card types as of June 2013.
• This camera supports use of SD memory cards of the following types and
capacities: SD memory cards up to 2GB, SDHC memory cards from 2GB up to
32GB, SDXC memory cards from 32GB up to 2TB. Note that the ability to use any
particular card with this camera, even if it satisfies the above capacity and type
requirements, is not guaranteed.
• This camera supports use of Eye-Fi cards and FlashAir cards.
. Memory Card Handling Precautions
Certain types of cards can slow down processing speeds, and even can make it
impossible to store High Quality movies correctly. Also, use of certain types of
memory cards slows down data transfer and increases the time it takes to record
movie data, which can result in movie frames being dropped. The Y indicator on the
monitor screen turns yellow to indicate that frames are being dropped. In order to
avoid problems such as these, use of an Ultra High Speed Type SD memory card is
recommended. Note, however that CASIO makes no guarantees about the operation
of any Ultra High Speed Type SD memory card used with this camera.
23
Quick Start Basics
To load a memory card
1. Press [ON/OFF] (Power) to turn off
the camera and then open the
battery cover.
2. Load a memory card.
Positioning the memory card so its front
is facing upwards (towards the monitor
screen side of the camera), slide it into
the card slot all the way in until you hear
it click securely into place.
Front
Front Back
3. Close the battery cover.
IMPORTANT!
• Never insert anything besides a supported memory card (page 23) into the memory
card slot.
• Should water or any foreign object ever get into the card slot, immediately turn off
the camera, remove the battery, and contact your retailer or nearest CASIO
authorized service center.
24
Quick Start Basics
To replace the memory card
Press the memory card and then release it.
This will cause it to pop out of the memory
card slot slightly. Pull the card out the rest
of the way and then insert another one.
• Never remove a card from the camera
while the back lamp is flashing green.
Doing so can cause the image save
operation to fail and even damage the
memory card.
To format (initialize) a new memory card
Format a memory card on the camera before using it for the first time.
IMPORTANT!
• Formatting a memory card that already has snapshots or other files on it, will delete
its contents. Normally you do not need to format a memory card again. However, if
storing to a card has slowed down or if you notice any other abnormality, re-format
the card.
• Be sure to use the camera to format a memory card. Formatting a card on a
computer will result in a non-SD standard format, which can greatly slow down
processing time and cause compatibility, performance, and other problems.
• Before formatting a new Eye-Fi card to use it for the first time, copy the Eye-Fi
install file from the card to your computer.
• Formatting a FlashAir card with the camera will delete files on the card that are
required for communication. For details about formatting, see the instructions that
come with the FlashAir card.
1. Turn on the camera and press [MENU].
2. Press [4], use [8] and [2] to select the “
¥
SETTING” tab, and then
press [6].
3. Use [8] and [2] to select “Format” and then press [SET].
4. Use [8] and [2] to select “Format” and then press [SET].
5. Use [8] and [2] to select “Yes” and then press [SET].
25
Quick Start Basics
Turning the Camera On and Off
. To turn power on
Pressing [ON/OFF] (Power) enters the REC mode so
you can record images. Pressing [p] (PLAY) while
in the REC mode enters the PLAY mode, which you
can use to view snapshots and movies (pages 32,
114).
• You also can turn on the camera by pressing [p]
(PLAY).
•Pressing [r] (REC) or the shutter button while in
the PLAY mode returns to the REC mode.
• Take care to ensure that nothing is restricting or
coming into contact with the lens as it extends.
Holding the lens with your hand so it cannot
extend creates the risk of malfunction.
• About 10 seconds after you press [p] (PLAY) to
enter the PLAY mode, the lens will retract into the
camera.
• The Sleep function or Auto Power Off (pages 162,
162) will turn off power automatically if you do not
perform any operation for a preset amount of time.
. To turn off the camera
Press [ON/OFF] (Power).
NOTE
• You also can configure the camera to turn on or off when you press [r] (REC)
(page 163).
• The camera can be configured so power turns off when [p] (PLAY) is pressed
(page 163).
[ON/OFF] (Power)
Shutter button
Back lamp
[p] (PLAY)
[r] (REC)
26
Quick Start Basics
Holding the Camera Correctly
Your images will not come out
clearly if you move the camera
when you press the shutter
button. When pressing the
shutter button, be sure to hold
the camera as shown in the
illustration, and keep it still by
pressing your arms firmly
against your sides as you shoot.
Holding the camera still,
carefully press the shutter button
and take care to avoid all
movement as the shutter
releases and for a few moments after it releases. This is especially important when
available lighting is low, which slows down the shutter speed.
NOTE
• Take care that your fingers and the strap do not
cover any of the areas indicated in the illustration.
• To protect against accidentally dropping the
camera, attach the wrist strap and make sure it is
around your fingers or wrist while you are
operating the camera.
• Never swing the camera around by its strap.
• The supplied strap is intended for use with this
camera only. Never use it for any other purpose.
• When the “Auto Rotate” setting is turned on, the
camera will detect whether it is being held
vertically or horizontally when a snapshot image is
shot. When you display an image shot with the camera held vertically, the image is
rotated automatically 90 degrees when displayed on the monitor screen (page
161).
Horizontal Vertical
Hold the camera so the flash is above the lens.
Flash
Front lamp
Lens
27
Quick Start Basics
To shoot a snapshot
Selecting an Auto Recording Mode
You can select one of two auto recording modes (Program Auto or Premium Auto
Pro) according to your digital imaging needs.
Setting
P
Program
Auto
Ÿ
Premium
Auto Pro
REC Screen
Icon Display
Description
This is the standard Auto recording mode.
With Premium Auto Pro recording, the camera
automatically determines whether you are shooting a
subject or scenery, and other conditions. Premium
Auto Pro recording delivers higher image quality than
Program Auto recording.
• It also requires more power (and runs down the
battery quicker) than Program Auto.
1. Press [ON/OFF] (Power) to turn on the camera.
The camera will enter the REC mode.
• If the camera is in the PLAY mode, press [r] (REC) or the shutter button.
2. Align the mode dial with [P] (Program Auto) or [Ÿ] (Premium Auto
Pro) to select Auto recording mode.
Remaining Snapshot Memory
Capacity (page 191)
Auto recording mode icon
Monitor screen
[r] (REC)
28
[ON/OFF] (Power)
Shutter button
Mode dial
Quick Start Basics
To shoot a snapshot
1. Point the camera at the subject.
If you are shooting with Premium Auto Pro, text will
appear at the bottom of the monitor screen describing the
type of shot the camera has detected.
• You can zoom the image, if you want.
Appears when the
camera detects it is
stationary on a tripod.
Zoom controller
If the camera decides that it needs to shoot a series of images with Continuous Shutter
(CS), it will display “Š”. Take care to avoid any camera and subject movement until
shooting of all of the CS images is complete.
w Wide Angle z Telephoto
2. Half-press the shutter button to
focus the image.
When focus is complete, the camera
will beep, the back lamp will light
green, and the focus frame will turn
green.
Half-press
Press lightly
until the
button stops.
Beep, beep (Image is in focus.)
When you half-press the shutter button, the
camera automatically adjusts exposure and
focuses on the subject it is currently pointed at.
Mastering how much pressure is required for a
half-press and a full-press of the shutter button
is an important technique for good-looking
images.
29
Back lamp
Focus frame
Quick Start Basics
3. Continuing to keep the camera still,
press the shutter button the rest of
the way down.
This records the snapshot.
Full-press
Snap (Image is recorded.)
Recording a Movie
Press [0] (Movie) to start movie recording. Press
[0] (Movie) again to stop movie recording. See the
following pages for details.
Standard movie (STD movie): page 62
High-definition movie (FHD movie): page 65
High speed movie (HS movie): page 65
[0] (Movie)
. If the image does not focus...
If the focus frame stays red and the back lamp is flashing green, it means that the
image is not in focus (because the subject is too close, etc.). Re-point the camera at
the subject and try to focus again.
. Shooting with Auto
If the subject is not in the center of the frame...
“Focus lock” (page 43) is the name of a technique you can use when you want to
shoot an image in which the subject to be focused on is not within the focus frame in
the center of the screen.
To track the movement of a moving subject
Half-press the shutter button to follow and focus automatically on a moving subject.
See “O Tracking” (page 103) for more information.
30
Quick Start Basics
Loading...
