Casio EXILIM EX-ZR50 User Guide
Digital Camera
User’s Guide
EN
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM
Website at http://www.exilim.com/
Accessories
As you unpack your camera, check to make sure that all accessories shown below
are included. If anything is missing, contact your original retailer.
Rechargeable lithium ion
battery (NP-160)
Micro USB cable Strap
Basic Reference
USB-AC adaptor
(AD-C53U)
To attach the strap to the camera
Power cord*
Attach strap here.
* The shape of the power cord plug varies according to the country or geographic
area where the camera is sold.
2
Read this first!
• The contents of this manual are subject to change without notice.
• The contents of this manual have been checked at each step of the production
process. Feel free to contact us if you notice anything that is questionable,
erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is
forbidden. Except for your own personal use, any other use of the contents of this
manual without the permission of CASIO COMPUTER CO., LTD. is forbidden
under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits suffered by you or any third party due to the use or malfunction of this
product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits caused by loss of memory contents due to malfunction, repair, or any other
reason.
• Note that the example screens and product illustrations shown in this User’s Guide
may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that
provides a pixel yield in excess of 99.99%. This means that some very small number
of pixels may not light or may remain lit at all times. This is due to the characteristics
of the liquid crystal panel, and does not indicate malfunction.
Take test shots
Before shooting your final image, shoot a test shot to ensure that the camera is
recording correctly.
3
Contents
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
]\
General Guide 10
]\
Monitor Screen Contents and How to Change Them 11
]\
Quick Start Basics 15
What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Tilting the Monitor Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
] To load the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
] Charge the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . . 24
Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
] Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
] To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
] To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Turning the Camera On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Holding the Camera Correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
To shoot a snapshot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
] Selecting an Auto Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
] To shoot a snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Deleting Snapshots and Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
]\
Snapshot Tutorial 39
Selecting the Recording Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Using the Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer) . . 41
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . . 42
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Focus) . . 44
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ISO) . . 46
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . . . . (Make-up) . . 47
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift) . . 48
Using Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Flash) . . 49
Specifying the Metering Mode . . . . . . . . . . . . . . . . . . . . . . . . . (Metering) . . 51
Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
] Monitor Screen Information when Zooming . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
] Zooming with Super Resolution . . . . . . . . . . . . . . . . . . . . . . . . (Zoom (SR)) . . . 55
] Expanding the Zoom Range to Shoot Clearer Snapshots . (Multi SR Zoom). . . 56
4
Contents
Shooting a Burst of Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (CS) . . 56
] Shooting with High Speed CS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
] Shooting with Prerecord CS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
] Using Continuous Shutter with Auto Focus . . . . . . . . . . . . . . . . . . (AF CS) . . . 60
Triggering a Self-timer Operation with Motion . . . . . . . . . . . . (Handsfree) . . 61
] Configuring Handsfree Mode Settings . . . . . . . . . . . . . . . . . . . (Handsfree). . . 62
] Repositioning the Motion Detection Area . . . . . . . . . . . . . (Motion Position). . . 63
Shooting with Artistic Effects . . . . . . . . . . . . . . . . . . . . . . . . (ART SHOT) . . 64
] Saving a Second Normal Image When
Shooting With HDR Art . . . . . . . . . . . . . . . . . . . . . . . . .(Double (HDR Art)). . . 66
Shooting Three Versions of an Image with
Different Skin Tone Settings . . . . . . . . . . . . . . . . . . . . . . . (Make-up BKT) . . 67
]\
Recording Movies 68
To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
] Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Recording a High-definition Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Recording a High Speed Movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Using Prerecord Movie . . . . . . . . . . . . . . . . . . . . . . . . (Prerecord (Movie)) . . 73
Recording a Time Lapse Movie . . . . . . . . . . . . . . . . . . . . . . (Time Lapse) . . 75
Shooting a Snapshot while Shooting a Movie . . . . . (Snapshot In Movie) . . 78
]\
Using BEST SHOT 79
To shoot with BEST SHOT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . . . . (Make-up) . . 81
Shooting with Triple Shot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Shooting with High Speed Anti Shake . . . . . . . . . . . . . . . (HS Anti Shake) . . 83
Shooting Bright Images in the Dark without Flash . . . . . . (HS Night Shot) . . 84
Digitally Correcting for Overexposure and Underexposure . . . . . . (HDR) . . 85
Shooting with a Blurred Background . . . . . . . . . . . (Blurred Background) . . 86
Shooting with Full Focus Macro . . . . . . . . . . . . . . . . (All-In-Focus Macro) . . 87
Shooting with Priority on Subject Faces . . . . . . . . . . . (HS Best Selection) . . 88
Shooting a Panorama Image . . . . . . . . . . . . . . . . . . . . .(Slide Panorama) . . 89
Shooting with a Super Wide Angle of View . . . . . . . . . . . . . . (Wide Shot) . . 91
Using a TV Screen to Shoot Snapshots . . . . . . . . . . . . (HDMI TV Output) . . 94
]\
Advanced Settings (REC MENU) 96
Configuring Recording Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Using a Smartphone as a Camera Remote Controller . (Remote Capture) . . 97
Configuring Handsfree Settings . . . . . . . . . . . . . . . . . . . . . . . (Handsfree) . . 97
Configuring Motion Position Settings . . . . . . . . . . . . . . . (Motion Position) . . 98
Assigning Functions to the [4] and [6] Keys . . . . . . . . . . . . . . . (L/R Key) . . 98
Assigning a Recording Function to
the Front Shutter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . (Front Shutter) . . 99
Shooting a Burst of Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (CS) . 100
5
Contents
To select the snapshot image size . . . . . . . . . . . . . . . . . . . . (Image Size) . 100
Specifying Snapshot Image Quality . . . . . . . . . . . . . . . . . (Image Quality) . 102
Movie Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . (Movie Quality) . 102
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ISO) . 104
Specifying the ISO Sensitivity Upper Limit . . . . . . . . . . . . (ISO High Limit) . 104
Reducing the Effects of Camera and Subject Movement . . . . (Anti Shake) . 105
Zooming with Super Resolution . . . . . . . . . . . . . . . . . . . . . . .(Zoom (SR)) . 106
Turning Digital Zoom On or Off . . . . . . . . . . . . . . . . . . . . . . (Digital Zoom) . 106
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Focus) . 106
Shooting with Face Detection . . . . . . . . . . . . . . . . . . . . . (Face Detection) . 107
Specifying the Auto Focus Area . . . . . . . . . . . . . . . . . . . . . . . . . (AF Area) . 108
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . . . . (Make-up) . 109
Shooting with Continuous Auto Focus . . . . . . . . . . . . . . (Continuous AF) . 109
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . 110
Saving a Second Normal Image When
Shooting With HDR Art . . . . . . . . . . . . . . . . . . . . . . . (Double (HDR ART)) . 110
Reducing Wind Noise during Movie Recording . . . . . . . (Wind Noise Cut) . 110
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift) . .111
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . .111
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer) . .111
Specifying the Metering Mode . . . . . . . . . . . . . . . . . . . . . . . . . (Metering) . .111
Specifying Flash Intensity . . . . . . . . . . . . . . . . . . . . . . . . . (Flash Intensity) . 112
Controlling Image Sharpness . . . . . . . . . . . . . . . . . . . . . . . . . (Sharpness) . 112
Controlling Color Saturation . . . . . . . . . . . . . . . . . . . . . . . . . . (Saturation) . 112
Adjusting Image Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Contrast) . 112
Using the Auto Focus Assist Light . . . . . . . . . . . . . . . . . (AF Assist Light) . 113
Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Review) . 113
Using Icon Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Icon Help) . 114
Changing the Monitor Screen when Recording . . . . . . . . . (Shooting Info) . 114
Configuring Power On Default Settings . . . . . . . . . . . . . . . . . . . (Memory) . 116
]\
Viewing Snapshots and Movies 117
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Viewing a Panorama Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Viewing Continuous Shutter Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
] Deleting Continuous Shutter Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
] Dividing Up a Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
] Copying a Group Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Displaying the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Viewing Snapshots and Movies on a TV Screen. . . . . . . . . . . . . . . . . . . . . . 125
6
Contents
]\
Other Playback Functions (PLAY MENU) 127
Assigning a Function to the Front Shutter Button . . . . . . . . (Front Shutter) . 127
Sending a Snapshot or Movie File from Camera Memory
to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Send to phone) . 128
Viewing Snapshots and Movies in Camera Memory
on a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (View on phone) . 128
Creating a Collage Image . . . . . . . . . . . . . . . . . . . . . . . . . (Quick Collage) . 128
Playing a Slideshow on the Camera . . . . . . . . . . . . . . . . . . . . (Slideshow) . 129
] Transferring Music from Your Computer to Camera Memory . . . . . . . . . . . . . . 131
Editing a Movie on the Camera . . . . . . . . . . . . . . . . . . . . .(Movie Editing) . 132
To merge two movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Movie Merge) . 134
Creating a Snapshot of Movie Frames . . . . . . . . . . . . . (MOTION PRINT) . 134
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . 135
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . 135
Adjusting the Brightness of an Existing Snapshot . . . . . . . . . (Brightness) . 136
Selecting Images for Printing . . . . . . . . . . . . . . . . . . . . . . (DPOF Printing) . 136
Protecting a File Against Deletion . . . . . . . . . . . . . . . . . . . . . . . . . (Protect) . 137
Editing the Date and Time of an Image . . . . . . . . . . . . . . . . . (Date/Time) . 138
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Rotation) . 139
Resizing a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize) . 139
Cropping a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Trimming) . 140
Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Copy) . 140
Combining CS Images into a Single Still Image . . . . . . . . (CS Multi Print) . 141
Dividing Up a Continuous Shutter Group . . . . . . . . . . . . . . (Divide Group) . 141
Editing a CS Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Edit Group) . 141
]\
Establishing a Wireless LAN Connection 142
Wireless LAN Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Establishing a Connection between a Smartphone and Your Camera . . . . . 144
] Installing the EXILIM Remote App on Your Smartphone . . . . . . . . . . . . . . . . . 144
] Configuring Wireless LAN Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Using a Smartphone as a Camera Remote Controller . (Remote Capture) . 146
Sending the Currently Displayed Image to a Smartphone . . (Quick Send) . 148
] To assign the Quick Send function to the front shutter button . . . . . . . . . . . . . 148
] To send the displayed image to a smartphone . . . . . . . . . . . . . . . . . . . . . . . . . 149
Sending a Snapshot or Movie File from Camera Memory
to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . (Send Selected Image) . 150
Sending All Images Shot on the Current Day
to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Send New Images) . 152
Resizing Snapshots before Sending Them
to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize before send) . 153
Viewing Snapshots and Movies in Camera Memory
on a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (View on phone) . 154
7
Contents
]\
Printing 155
Printing Snapshots. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Using DPOF to Specify Images to be Printed and
the Number of Copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . (DPOF Printing) . 155
]\
Using the Camera with a Computer 160
Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . 161
] Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . 161
] Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
] Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . 165
] Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
]\
Other Settings (SETTING) 171
Enabling Power Saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ECO Mode) . 171
Adjusting Monitor Screen Brightness . . . . . . . . . . . . . . . . . . . . . . (Screen) . 171
Resizing Snapshots before Sending Them
to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize before send) . 172
Configuring Camera Sound Settings . . . . . . . . . . . . . . . . . . . . . (Sounds) . 172
Creating an Image Storage Folder . . . . . . . . . . . . . . . . . . (Create Folder) . 173
Time Stamping Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . .(Timestamp) . 173
Auto Image Orientation Detection and Rotation . . . . . . . . . . (Auto Rotate) . 174
Specifying the File Name Serial Number Generation Rule . . . . . (File No.) . 174
Configuring Sleep State Settings . . . . . . . . . . . . . . . . . . . . . . . . . . (Sleep) . 175
Configuring Auto Power Off Settings . . . . . . . . . . . . . . . (Auto Power Off) . 175
Specifying the Operation when the Monitor Screen is Tilted . (Screen Tilt) . 176
Configuring [p] Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (PLAY) . 176
Disabling File Deletion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Delete Key) . 176
Configuring World Time Settings . . . . . . . . . . . . . . . . . . . . . (World Time) . 177
Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . 178
Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . 178
Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . 179
Selecting the HDMI Terminal Output Method . . . . . . . . . . . (HDMI Output) . 179
Changing the Camera Password for
Wireless LAN Connection . . . . . . . . . . . . . . . . . . . . . . . (WLAN password) . 180
Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . . (Format) . 181
Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . . (Reset) . 181
8
Contents
]\
Appendix 182
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Precautions During Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
] Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
] Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
] Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
] Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
] Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Number of Snapshots/Movie Recording Time . . . . . . . . . . . . . . . . . . . . . . . . 208
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
9
Contents
General Guide
The numbers in parentheses indicate the pages where each item is explained.
Front Back
123
45 76
bl bn bo
bm
bp
bq
bk
[0] (Movie) button
1
(page 68)
Zoom controller
2
(pages 32, 52, 124)
Shutter button
3
(pages 29, 31)
[ON/OFF] (Power)
4
(pages 24, 29)
Flash (page 49)
5
Front lamp
6
(pages 41, 113)
Speaker
7
Lens
8
Microphone (page 69)
9
Bottom
co cmcn
9 8
btck bs br
cl
Front shutter button
bk
(pages 99, 127, 148)
[MODE] button
bl
(pages 31, 39, 68)
Back lamp
bm
(pages 21, 23, 29, 32,
49)
Strap hole (page 2)
bn
Terminal cover
bo
[HDMI OUT]
bp
HDMI output (micro)
(pages 94, 125)
[USB] port
bq
(pages 20, 22)
Tripod hole
cm
Use this hole when attaching to a tripod.
Battery cover
cn
Battery/memory card slots (pages 19, 27)
co
[MENU] button
br
(pages 68, 96)
[p] (PLAY) button
bs
(pages 29, 35)
[SET] button
bt
(pages 40, 68, 96)
Control button
ck
([8][2][4][6])
(pages 40, 68, 79, 96)
Monitor screen
cl
(pages 11, 31)
10
General Guide
Monitor Screen Contents and How to Change Them
The monitor screen uses various indicators, icons, and values to keep you informed
of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the
indicators and figures that can appear on the monitor screen in various modes.
They do not represent screens that actually appear on the camera.
. Snapshot Recording (1 Shot)
Remaining snapshot memory capacity
2
13567
4
co
cn
cm
cl
ck
bt
bs
br
Self-timer mode (page 41)
1
Face Detection (page 107)
2
Recording mode (page 31)
3
Image deterioration indicator/
4
Zoom (SR) indicator (page 54)
Remaining movie memory
5
capacity (page 68)
bq bp
6
(page 208)
8
Snapshot image size/Quality (pages 100, 102)
7
9
Movie quality (FHD/STD movie)
8
bk
(pages 68, 71)/
bl
Recording speed (high speed movie) (page 71)
bm
Focal distance
9
bn
(Converted to 35 mm film format.) (page 53)
bo
Anti Shake (page 105)
bk
Timestamp indicator (page 173)
bl
Histogram (page 114)
bm
Front shutter button function (page 99)
bn
Date/Time (pages 24, 178)
bo
AF Area (page 108)
bp
Focus frame (pages 32, 108)
bq
Battery level indicator (page 24)
br
Metering mode (page 51)
bs
Flash (page 49)
bt
Exposure compensation (page 48)
ck
Make-up (page 47)
cl
ISO sensitivity (page 46)
cm
Focus mode (page 44)
cn
White balance (page 42)
co
NOTE
• Depending on recording settings, the aperture, shutter speed, and ISO sensitivity
values may not appear on the monitor screen. These values will be red if the Auto
Exposure (AE) is not correct for some reason.
Monitor Screen Contents and How to Change Them
11
. Snapshot Recording (Burst Shooting)
Continuous Shutter (CS) speed (page 56)
5
6
7
1
Recording mode (page 31)
2
Remaining snapshot memory capacity
3
(page 208)
Allowable CS time*/number of CS images
4
(page 56)
* It is not displayed while shooting with
Prerecord CS.
Remaining movie memory capacity (page 209)
5
Continuous Shutter mode (page 56)
6
Prerecord CS shots (page 58)
7
Maximum CS shots (page 56)
8
Snapshot recording mode (Snapshot In Movie)
1
(page 78)
Audio recording disabled (page 71)
2
Recording mode (page 68)
3
Movie recording time (page 68)
4
Remaining movie memory capacity (page 68)
5
Movie recording in progress (page 68)
6
Movie quality (FHD/STD movie)
7
(pages 68, 71)/
Recording speed (high speed movie) (page 71)
Remaining snapshot memory capacity
8
(page 208)
1243
8
7
6
. Movie Recording
42
1
3
8
5
Monitor Screen Contents and How to Change Them
12
. Snapshot Viewing
2413
bt
bs
br
bq
bp
bo
bm blbn bk
File type
1
Protect indicator (page 137)
2
Snapshot image size
3
(page 100)
Folder name/file name
4
(page 168)
Snapshot image quality
5
(page 102)
. CS Image Viewing
12
Recording mode (page 31)
6
Histogram (page 114)
7
5
Front shutter button function (page 127)
8
6
Wireless LAN connection status
9
(pages 149, 151)
7
Date/time (page 178)
bk
8
Metering mode (page 51)
bl
9
White balance (page 135)
bm
Battery level indicator (page 24)
bn
Flash (page 49)
bo
Exposure compensation (page 48)
bp
Shutter speed
bq
Aperture value
br
ISO sensitivity (page 46)
bs
Focal distance
bt
(Converted to 35 mm film format.)
Number of images in the group (page 119)
1
Group icon (page 119)
2
. Movie Playback
1 2
4
3
No audio data available
1
Movie recording time (page 117)
2
Movie quality (FHD/STD movie)
3
(pages 68, 71)/
Recording speed (high speed movie) (page 71)
Interval (page 75)
4
Displayed for movie recorded with Time Lapse.
Monitor Screen Contents and How to Change Them
13
. Configuring Monitor Screen Settings
Each press of [8] (DISP) will cycle through display settings that
display or hide on-screen information. You can configure separate
settings for the REC mode and PLAY mode.
REC mode
Information on Displays setting information.
Information off Hides setting information.
PLAY mode
Information on
Displays settings when shooting, current date and time,
histogram (page 114), and other information.
Information off No information displayed when shooting.
[8] (DISP)
Monitor Screen Contents and How to Change Them
14
Quick Start Basics
What you can do with your CASIO camera
Your CASIO camera is packed with a powerful selection of features and functions to
make recording of digital images easier, including the following main functions.
Tiltable Monitor Screen
The camera’s monitor screen can be tiled upwards
up to 180 degrees. This makes it easy to compose
180 degrees
self-portraits and to shoot from low angles.
*See page 17 for more information.
Handsfree Self-portraits
You can control operation of the self-timer from a
distance by waving your hand, which makes it easier to
shoot self-portraits from a distance.
*See page 61 for more information.
Time Lapse Movie
You can use this function to record movies of natural
events that occur over time, to speed up the flow of
traffic in a city scene, or to record other similar types of
movies.
*See page 75 for more information.
Make-up Bracketing (Make-up BKT)
Make-up Bracketing (Make-up BKT) lets you shoot three
versions of the same image with the press of the shutter
button, each with a different Skin Tone setting.
*See page 67 for more information.
ART SHOT
A variety of artistic effects help to make even common,
ordinary subjects become more novel and exciting.
“ART SHOT” provides the following effects: HDR Art,
Toy Camera, Soft Focus, Light Tone, Pop, Sepia,
Monochrome, Miniature, Fisheye, Sparkling Shot,
Crystal Ball, ART SHOT Bracketing.
*See page 64 for more information.
15
Quick Start Basics
Triple Shot
Pressing the shutter button shoots a burst of three
images and stores them in memory. This feature is
great for making sure you don’t miss those special
moments when kids are around.
*See page 82 for more information.
Premium Auto Pro
Select Premium Auto Pro recording and the
camera automatically determines whether you
are shooting a subject or scenery, and other
conditions. Premium Auto Pro delivers higher
image quality than standard Auto.
*See page 31 for more information.
Quick Collage
This function can be used to combine multiple snapshots into
a single collage image.
*See page 128 for more information.
Wireless LAN Connection
Turns your smartphone into a camera remote
controller and allows you to send images recorded with
your camera to your smartphone.
*See page 142 for more information.
16
Quick Start Basics
Tilting the Monitor Screen
The monitor screen can be tilted upwards up to 180 degrees.
. Tilting the Monitor Screen
As shown in the illustration, you can tilt the
monitor screen by opening it from the bottom.
. Returning the Monitor Screen to Its
Normal Position
You can return the monitor screen to its normal
position by holding the bottom of the monitor
screen and rotate it.
IMPORTANT!
• Under factory default settings, the camera will turn on automatically whenever the
monitor screen is tilted. See page 176 for information about configuring the camera
so it does not turn on when the monitor screen is tilted upwards.
• When returning the monitor screen to the back of the camera, take care so you do
not catch your fingers between the bottom of the monitor screen and the camera.
• Do not subject the monitor screen to strong impact. Doing so can damage it.
NOTE
• Be sure to return the monitor screen to its normal position to the back of the
camera when you are not using it.
180 degrees
17
Quick Start Basics
. What you can do with the camera...
Shoot self-portraits
You can position the monitor screen so it
faces in the same direction as the lens,
for easy composition of self-portraits. You
can also use a stand on the back of the
camera to keep the camera upright when
placed on a tabletop or other surface.
Low-angle shots High-angle shots
The tilt angle of the monitor screen can
be adjusted for each composition of
images from various low angles.
By holding the camera upside down, you
can angle the monitor screen in a way
that allows you to shoot from high
angles. In this case, the camera will
automatically rotate on-screen
information and the displayed image
180 degrees.
18
Quick Start Basics
First, charge the battery prior to use.
Note that the battery of a newly purchased camera is not charged. Perform the steps
below to load the battery into the camera and charge it.
• Your camera requires a special CASIO rechargeable lithium ion battery (NP-160)
for power. Never try to use any other type of battery.
To load the battery
1. Open the battery cover.
2. Load the battery.
With the CASIO logo on the battery
facing upwards (in the direction of
the lens), hold the stopper next to
the battery in the direction
indicated by the arrow as you slide
the battery into the camera. Press
the battery in until the stopper
secures it in place.
3. Close the battery cover.
Stopper
OK
CASIO logo
NG
Battery
19
Quick Start Basics
To replace the battery
1. Open the battery cover and
remove the current battery.
Stopper
2. Load a new battery.
Charge the Battery
You can use either of the two following methods to charge the camera’s battery.
• USB-AC adaptor
• USB connection to a computer (Using the included micro USB cable.)
. To charge with the USB-AC adaptor
The adaptor lets you charge the battery while it is loaded in the camera.
While the camera is turned off, connect in the sequence shown below.
Charging time: Approximately 160 minutes
[USB] port
Micro USB cable
(included with camera)
4
u mark of the small (micro USB) connector
facing the monitor screen side of the camera.
1
USB-AC adaptor
(AD-C53U)
2
3
Power cord
• When disconnecting the USB-AC adaptor from the camera, be sure to disconnect
from the camera first.
20
Quick Start Basics
IMPORTANT!
• A battery that has not been used for a long time, or ambient temperature extremes
can cause charging to take longer than normal. If charging takes longer than about
five hours, a timer will terminate it automatically, even if the battery is not fully
charged. This is indicated by the back lamp flashing red. If the battery has not been
used for a very long time, charging may be terminated automatically and the back
lamp may start flashing red after only about 60 minutes. In either case, disconnect
the USB cable from the camera and then reconnect it to resume charging.
• Make sure that you insert the cable connector into the [USB] port until you feel it
click securely into place. Failure to insert the connector fully can result in poor
communication or malfunction.
• Note that even while the connector is fully inserted, you
still will be able to see the metal part of the connector as
shown in the illustration.
• Pressing [ON/OFF] (Power) while the USB-AC adaptor is
connected to the camera will turn on the camera with
power being supplied by the battery. Because of this,
charging will stop.
• The USB-AC adaptor will become warm during charging.
This is normal and does not indicate malfunction.
• The shape of the power plug depends on each country or geographic area.
Back Lamp Operation
Lamp Status Description
Back lamp
Lit Red Charging
Abnormal ambient temperature,
Flashing Red
USB-AC adaptor problem, or battery
problem (page 195)
Off Charging complete
21
Quick Start Basics
. To charge using a USB connection to a computer
USB connection lets you charge the battery while it is loaded in the camera.
While the camera is turned off, connect in the sequence shown below (
[USB] port
1, 2
Computer
(power turned on)
).
USB port
1
Micro USB cable
(included with camera)
u mark of the small (micro USB) connector facing the
monitor screen side of the camera.
USB
2
• If the camera is on, press [ON/OFF] (Power) to turn it off before connecting it to
your computer.
IMPORTANT!
• The first time you connect the camera to your computer with the USB cable, an
error message may appear on your computer. If this happens, disconnect and then
reconnect the USB cable.
• A battery that has not been used for a long time, certain types of computers, and
connection conditions can cause charging to take more than approximately five
hours, which will trigger a timer that terminates charging automatically, even if the
battery is not fully charged. If this happens, disconnect and then reconnect the
USB cable to restart charging. To complete charging faster, use of the included
USB-AC adaptor is recommended.
• If the battery has not been used for a very long time, charging may terminate
automatically and the back lamp may start flashing red or go out after only about
60 minutes. In either case, use of the USB-AC adaptor that comes with the camera
is recommended.
• If you turn on the camera while charging over a USB connection to a computer is in
progress, the camera will establish a USB connection with the computer. Though
charging normally should continue at this time, certain types of computers or
connection environments may stop charging if supply power is low. This will be
indicated by the camera’s back lamp lighting green.
• Charging is not performed while the connected computer is in the hibernate mode.
22
Quick Start Basics
Back Lamp Operation
Lamp Status Description
Lit Red,
(Lit/Flashing Amber)
Charging
Back lamp
Abnormal ambient temperature,
Flashing Red
charging taking abnormally long, or
battery problem (page 195)
Off, (Lit Green) Charging complete
• The information in parentheses in the above table shows the lamp status while the
camera is turned on during charging.
Other Charging Precautions
• With the two charging methods described above, you can charge the camera’s
battery (NP-160) without removing it from the camera. You also can charge the
battery using an optionally available charger unit (BC-110L). Never use any other
type of charger device. Attempting to use a different charger can result in
unexpected accident.
• This model can be charged only via from USB 2.0 specification USB port only.
• USB charging devices and power supply devices are subject to fixed standards.
Use of an inferior device or a device that is not up to standard can cause
malfunction and/or failure of your camera.
• Operation is not guaranteed in the case of a computer built or modified by you.
Even in the case of a commercially available computer, certain USB port
specifications may make it impossible to charge via the USB cable.
• A battery that is still warm immediately after normal use may not charge fully. Give
the battery time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of
this, it is recommended that you charge the battery immediately before you need to
use it.
• Charging the camera’s battery may cause interference with TV and radio reception.
If this happens, plug the USB-AC adaptor into an outlet that is further away from
the TV or radio.
• Actual charging time depends on current battery capacity and charging conditions.
• Do not use the USB-AC adaptor with any other device.
• Never use the power cord with another device.
• Use only the USB-AC adaptor and USB cable specified in this manual for charging.
Use of any other type of devices may result in improper charging.
23
Quick Start Basics
Checking Remaining Battery Power
As battery power is consumed, a battery indicator on the monitor screen indicates
remaining power as shown below.
Remaining Power High Low
Battery Indicator ***
Indicator Color White * White * Red * Red
indicates battery power is low. Charge the battery as soon as possible.
Recording is not possible when is indicated. Charge the battery immediately.
• The level shown by the battery indicator may change when you switch between the
REC mode and PLAY mode.
• Leaving the camera for about 20 days with no power supplied while the battery is
dead will cause its date and time settings to be cleared. A message telling you to
configure time and date settings will appear the next time you turn on the camera
after restoring power. When this happens, configure date and time settings (page
178).
• See page 213 for information about battery life and number of shots.
Battery Power Conservation Tips
• Entering the “ECO Mode” enables low-power operation (page 171).
• When you do not need to use the flash, select ? (Flash Off) for the flash setting
(page 49).
• Enable the Auto Power Off and the Sleep features to protect against wasting
battery power when you forget to turn off the camera (pages 175, 175).
• Select “Off” for “Continuous AF” (page 109).
Configuring Basic Settings the First Time You Turn On the Camera
The first time you load a battery into the camera, a screen appears for configuring the
display language, date, and time settings. Failure to set the date and time correctly
will cause the wrong date and time data to be recorded with images.
IMPORTANT!
• A screen for language selection will not appear in step 2 of the procedure below if
you purchased a camera intended for the Japanese market. To change the display
language from Japanese in this case, use the procedure under “Specifying the
Display Language (Language)” (page 179). Note that a version of this manual in
the language you select may not be included with a camera intended for the
Japanese market.
• Camera models sold in certain geographic areas may not support display language
selection.
24
Quick Start Basics
1. Press [ON/OFF] (Power) to turn on the
[ON/OFF] (Power)
camera.
2. Use [8] and [2] to select the language
you want and then press [SET].
3. Use [8] and [2] to select a date style and then press [SET].
Example: July 10, 2015
YY/MM/DD
DD/MM/YY
MM/DD/YY
* 15/7/10
* 10/7/15
* 7/10/15
4. Set the date and the time.
Use [4] and [6] to select the setting you want to
change and then use [8] and [2] to change it.
To switch between 12-hour and 24-hour format, select
“24h” and then use [8] and [2] to change the setting.
5. After setting the date and time, use [4] and [6]
to select “Apply” and then press [SET].
If you make a mistake configuring display language, date, or time settings with the
above procedure, refer to the following pages for information about how to correct
the settings.
– Display language: page 179
– Date and time: page 178
NOTE
• Each country controls its local time offset and the use of summer time, and so they
are subject to change.
• Removing the battery from the camera too soon after configuring time and date
settings for the first time can cause the settings to be reset to their factory defaults.
Do not remove the battery for at least 24 hours after configuring settings.
25
Quick Start Basics
Preparing a Memory Card
Though the camera has built-in memory that can be used to store images and
movies, you probably will want to purchase a commercially available memory card for
greater capacity. The camera does not come with a memory card. Images recorded
while a memory card is loaded are saved to the memory card. When no memory card
is loaded, images are saved to built-in memory.
• For information about memory card capacities, see page 208.
Supported Memory Cards
– SD Memory Card
– SDHC Memory Card
– SDXC Memory Card
Use one of the above types of memory card.
• The above are supported memory card types as of July 2014.
• This camera supports use of SD memory cards of the following types and
capacities: SD memory cards up to 2GB, SDHC memory cards from 2GB up to
32GB, SDXC memory cards from 32GB up to 2TB. Note that the ability to use any
particular card with this camera, even if it satisfies the above capacity and type
requirements, is not guaranteed.
. Memory Card Handling Precautions
Certain types of cards can slow down processing speeds, and even can make it
impossible to store High Quality movies correctly. Also, use of certain types of
memory cards slows down data transfer and increases the time it takes to record
movie data, which can result in movie frames being dropped. The Y indicator on the
monitor screen turns yellow to indicate that frames are being dropped. In order to
avoid problems such as these, use of an Ultra High Speed Type SD memory card is
recommended. Note, however that CASIO makes no guarantees about the operation
of any Ultra High Speed Type SD memory card used with this camera.
26
Quick Start Basics
To load a memory card
1. Press [ON/OFF] (Power) to turn off
the camera and then open the
battery cover.
2. Load a memory card.
Positioning the memory card so its front
is facing upwards (towards the lens side
of the camera), slide it into the card slot
all the way in until you hear it click
securely into place.
Front
Front Back
3. Close the battery cover.
IMPORTANT!
• Never insert anything besides a supported memory card (page 26) into the memory
card slot.
• Should water or any foreign object ever get into the card slot, immediately turn off
the camera, remove the battery, and contact your retailer or nearest CASIO
authorized service center.
27
Quick Start Basics
To replace the memory card
Press the memory card and then release it.
This will cause it to pop out of the memory
card slot slightly. Pull the card out the rest
of the way and then insert another one.
• Never remove a card from the camera
while the back lamp is flashing green.
Doing so can cause the image save
operation to fail and even damage the
memory card.
To format (initialize) a new memory card
Format a memory card on the camera before using it for the first time.
IMPORTANT!
• Formatting a memory card that already has snapshots or other files on it, will delete
its contents. Normally you do not need to format a memory card again. However, if
storing to a card has slowed down or if you notice any other abnormality, re-format
the card.
• Be sure to use the camera to format a memory card. Formatting a card on a
computer will result in a non-SD standard format, which can greatly slow down
processing time and cause compatibility, performance, and other problems.
1. Turn on the camera and press [MENU].
2. Press [4], use [8] and [2] to select the “
press [6].
¥
SETTING” tab, and then
3. Use [8] and [2] to select “Format” and then press [SET].
4. Use [8] and [2] to select “Format” and then press [SET].
5. Use [8] and [2] to select “Yes” and then press [SET].
28
Quick Start Basics
Turning the Camera On and Off
. To turn power on
Pressing [ON/OFF] (Power) enters the REC mode so
you can record images. Pressing [p] (PLAY) while
in the REC mode enters the PLAY mode, which you
can use to view snapshots and movies (pages 35,
117).
• You also can turn on the camera by pressing [p]
(PLAY).
• Pressing the shutter button while in the PLAY
mode returns to the REC mode.
• Take care to ensure that nothing is restricting or
coming into contact with the lens as it extends.
Holding the lens with your hand so it cannot
extend creates the risk of malfunction.
• About 10 seconds after you press [p] (PLAY) to
enter the PLAY mode, the lens will retract into the
camera.
• The Sleep function (page 175) or Auto Power Off
(page 175) will turn off power automatically if you
do not perform any operation for a preset amount
of time.
. To turn off the camera
Press [ON/OFF] (Power).
NOTE
• The camera can be configured so power turns off when [p] (PLAY) is pressed
(page 176).
[ON/OFF] (Power)
Shutter button
Back lamp
[p] (PLAY)
29
Quick Start Basics
Holding the Camera Correctly
Your images will not come out
clearly if you move the camera
when you press the shutter
button. When pressing the
shutter button, be sure to hold
the camera as shown in the
illustration, and keep it still by
pressing your arms firmly
against your sides as you shoot.
Holding the camera still,
carefully press the shutter button
and take care to avoid all
movement as the shutter
releases and for a few moments after it releases. This is especially important when
available lighting is low, which slows down the shutter speed.
NOTE
• Take care that your fingers and the strap do not
cover any of the areas indicated in the illustration.
• To protect against accidentally dropping the
camera, attach the wrist strap and make sure it is
around your fingers or wrist while you are
operating the camera.
• Never swing the camera around by its strap.
• The supplied strap is intended for use with this
camera only. Never use it for any other purpose.
• Shooting an image while the camera’s “Auto
Rotate” setting is “On” will cause the playback
image to be rotated automatically to the orientation
the camera was in when the image was recorded (page 174).
Horizontal Vertical
Hold the camera so the flash is above the lens.
Flash
Front lamp
Lens
30
Quick Start Basics
Loading...
