HIGH POWEREDTECHNOLOGY
For easy reference while on the road, download the Pocket Guide from cardosystems.com/quick-guides/.
This is version 1.0 of the PACKTALK BOLD Manual. The latest version of the manuals in your preferred
language and various tutorials can be found at cardosystems.com/product-manuals/.
Register your PACKTALK BOLD
Registering your PACKTALK BOLD allows you to download software patches, enjoy new features that are
offered from time to time, and most importantly, assures smooth handling of any warranty issues you may have.
In the future, your registered PACKTALK BOLD may also be eligible for free product upgrades.
It's easy, just visit www.cardosystems.com/cardo-community and you'll be done in no time. Also, rest assured:
Cardo does not share your details with others.
Be SMART, register your PACKTALK BOLD.
2
CONTENTS
1. Introduction 4
2. Getting Started 5
2.1 Getting t o Know Your PACKTALK BOLD 5
2.2 Charging t he PACKTALK BOLD 5
2.3 Switching Your Unit On/Off 6
2.4 Using Your PACKT ALK bold 6
2.5 Pairing Your Unit to Bluetooth Devices 6
3. On the Road 8
3.1 Basic AUDI O Functions 8
3.2 Making and Receiving Phone Calls 8
3.2.1 Switching Between Two Calls on Two Mobile Phones 9
3.3 Streaming Music 9
3.4 Listening to FM Radio 9
3.5 Switching Music Sources 10
3.6 Voice Commands 10
4. Riding with Others 12
4.1 DMCIntercom 12
4.1.1 Setting Up and Usi ng DMC intercom Groups 12
4.1.2 Using DMC i ntercom 14
4.2 Bluetoot h I ntercom 16
4.2.1 Setting Up non-DMC Intercom Gr oups 16
4.2.2 Using the Bluetooth intercom 19
4.2.3 Resetting Bluetooth Intercom Pairing 19
4.3 Sharing Music and Radio 20
4.4 Switching between Intercom modes 20
5. Troubleshooting 22
5.1 Soft Reset 22
5.2 Reset Pairing 22
5.3 Reset to F act ory Settings 23
5.4 FAQ 23
6. Personalizing Your Device 24
6.1 Setting the Default Mobile Phone 25
6.2 Using Parallel Audio Streaming 25
6.3 Audio Source Priorities 26
Appendix A. PACKTALK BOLD LEDIndications 28
7. Glossary 30
8. Support 31
3
1. INTRODUCTION
Thank you for choosing the Cardo PACKTALK BOLD communication and entertainment system for motorcycle
helmets.
We wish you a great PACKTALK BOLD experience and encourage you to write to us at
support@cardosystems.com regarding any questions, suggestions or comments you may have.
If you have not yet installed the PACKTALK BOLD unit on your helmet, please install it as described in the
Installation Guide provided in the package.
And don't forget to register your PACKTALK BOLD at www.cardosystems.com/cardo-community.
4
2. GETTING STARTED
2.1 GETTING TO KNOW YOUR PACKTALK BOLD
2.2 CHARGING THE PACKTALK BOLD
Make sure that your PACKTALK BOLD battery is charged for at least 4 hours before initial use.
To charge the unit:
1. Using the supplied USB cable, connect your computer or wall charger to the USBport on your PACKTALK
BOLD.
● Charging with the wall charger is faster than via a computer USB port.
● Charging your unit switches it off automatically. To use your unit while it is being charged, switch it on.
(see Switching Your Unit On/Off on page 6).
While charging, the LED indicates the charging status as follows:
● Red LED on — charging
● Red LED off — charging complete
TIP: You can check the battery charge at any time by saying "Hey Cardo, battery status."
5
2.3 SWITCHING YOUR UNIT ON/OFF
To switch your PACKTALK BOLDon:
● Press both and for 1 second.
The speaker plays an ascending tone and a voice message greets you.
The LED confirms your PACKTALK BOLD is on:
● Normal and low battery — LED flashes blue three times, then green.
● Charging — LED flashes red and purple three times.
To switch your PACKTALK BOLDoff:
● Press both and .
The LED flashes red three times, confirming that your unit is switching off. The speaker plays a descending
tone and a voice message, "Goodbye".
2.4 USING YOUR PACKTALK BOLD
You can operate the various features of your PACKTALKBOLD in the following ways;:
● Press a button or combination of buttons on the unit.
● Use the Cardo Mobile App on your mobile device (once it is paired with the unit).
● Use automatic voice recognition (by saying a command, for example "Hey Cardo, Radio On").
You can also configure your unit by connecting it to a computer with the supplied USBcable and running the
Cardo Updater while your computer is connected to the Cardo Community website.
2.5 PAIRING YOUR UNIT TO BLUETOOTH DEVICES
Your PACKTALK BOLD has two Bluetooth channels for connection to Bluetooth devices such as mobile phones,
GPS devices, and Bluetooth music players with A2DP.
To connect your unit to a Bluetooth device, you must first pair them. Once paired, they automatically recognize
each other whenever they are within range.
If you are pairing more than one device, Cardo recommends that you pair the mobile phone to channel 1, and
the additional device (such as GPS, music player or additional mobile phone) to channel 2.
If you are pairing the unit to more than one mobile phone, the phone paired with channel 1 is the default phone
for outgoing calls.
To pair Bluetooth channel 1 to a mobile phone:
1. Enable Bluetooth on the mobile phone.
2. On the unit in standby mode, press for 5 seconds.
The LED flashes red and blue.
3. On your mobile phone, search for Bluetooth devices.
6
4. When your PACKTALKBOLD appears in the list of available devices, select it.
If prompted for a PIN or Passkey, enter 0000 (four zeros).
The phone confirms that pairing has succeeded and the LED flashes purple for 2 seconds.
To pair Bluetooth channel 2 to another Bluetooth device:
1. Enable Bluetooth on the device (for example, your mobile phone, GPS device, or music player).
2. On the unit in standby mode, press for 5 seconds. The LED flashes red and blue.
3. Tap twice. The LED flashes red and green.
4. If you are pairing a GPS device, roll the control wheel inward.
The LED flashes slower.
5. On the device you are pairing, search for Bluetooth devices.
6. When your PACKTALKBOLD appears in the list of available devices, select it.
If prompted for a PIN or Passkey, enter 0000 (four zeros).
The device confirms that pairing has succeeded and the LED flashes purple for 2 seconds.
● If pairing is not completed within 2 minutes, the unit automatically returns to Standby.
● If you have paired two different mobile phones directly to your PACKTALK BOLD, set one as default for
making calls (see Setting the Default Mobile Phone on page 25).
● Not all Bluetooth mobile phones broadcast Bluetooth Stereo music (A2DP) even if the phone has an MP3
player function. Consult your mobile phone’s user manual for more information.
● Not all Bluetooth GPS devices allow connection to Bluetooth audio devices. Consult your GPS User
Manual for more information.
To cancel the pairing process:
● Press for 2 seconds.
The LED stops flashing red and blue/green.
To reset all Bluetooth device pairing:
1. Press for 5 seconds.
2. Press and for 2 seconds.
The LED flashes purple 5 times, confirming that pairing has been reset.
7
3. ON THE ROAD
PACKTALK BOLD makes it easy for you to receive phone calls and listen to music in a convenient and safe
manner.
3.1 BASIC AUDIO FUNCTIONS
The basic audio functions are the same whether you are listening to music, speaking on the intercom, or having a
phone conversation.
To turn the volume up:
● Roll the Control Wheel inward.
An increasingly louder tone is played on the speaker until you reach the maximum volume, as indicated by
the maximum volume tone.
To turn the volume down:
● Roll the Control Wheel outward.
An increasingly quieter tone is played on the speaker until you reach the minimum volume, as indicated by
the minimum volume tone.
To mute the microphone completely and lower the speaker volume to the minimal level:
● Roll the Control Wheel outward, then inward.
To unmute the microphone and raise the speaker volume to the previous level:
● Roll the Control Wheel in any direction.
An ascending tone is played on the speaker.
3.2 MAKING AND RECEIVING PHONE CALLS
You can use your mobile phone to make and receive phone calls while paired to your PACKTALK BOLD.
You can make a hands-free call using your mobile phone's voice dial option or using the Cardo speed dial or redial
last call options.
To make a phone call:
● To dial using your mobile phone's voice dial option, tap or say "Hey Siri" (if you are using an iOS device)
or "OK Google" (if you are using an Android device), then make your call as per the instructions for your
mobile device.
● To redial the last number called on your mobile device, tap twice or say "Hey Cardo, redial number."
● To dial your preset speed dial number, press and hold down for 2 seconds or say "Hey Cardo, speed
dial." (The speed dial number must be set in the Cardo Mobile App or community website prior to use.)
● If you connected two mobile phones to your unit, you cannot make an additional phone call from the other
phone while a phone call is already active.
● During Bluetooth intercom 3 or 4-way calls, riders that are connected on both channels A and B (see 3-
Way and 4-Way Bluetooth Intercom Calls on page 1) cannot receive phone calls.
8
To answer a call:
● Tap or or , or tap the Control Wheel, or say Answer.
To reject a call:
● Press or or for 2 seconds.
To ignore a call:
● Roll the Control Wheel outward, then inward, or say Ignore.
To end a call:
● Tap or , or tap the Control Wheel.
3.2.1 SWITCHING BETWEEN TWO CALLS ON TWO MOBILE PHONES
Your PACKTALK BOLD can toggle between two calls on two mobile phones when both mobile phones are paired
to your unit.
To toggle between two calls on two mobile phones (without disconnecting either call):
● Tap twice.
To disconnect the current call and switch to the other call:
● Tap .
3.3 STREAMING MUSIC
You can stream music from your paired device to your PACKTALK BOLD.
To start music streaming from your paired device:
● Tap or say "Hey Cardo, music on."
To stop music streaming:
● Tap the Control Wheel or say "Hey Cardo, music off."
To skip to the next track (while streaming):
● Tap or say "Hey Cardo, next track."
To skip back to the previous track (while streaming):
● Tap twice or say "Hey Cardo, previous track."
To toggle between FM and ATDP music:
● Press for 2 seconds.
3.4 LISTENING TO FM RADIO
The PACKTALK BOLD is equipped with a built-in FM radio.
9
To turn on the FMradio:
● Tap twice or say "Hey Cardo, radio on."
When you switch on your FMradio, the station that was playing when you last switched off resumes playing.
To turn the FMradio off:
● Tap the Control Wheel or say "Hey Cardo, radio off."
To skip to the next station:
● Tap or say "Hey Cardo, next station."
To skip back to the previous station:
● Tap twice or say "Hey Cardo, previous station."
To scan for and select a station:
1. Press down the Control Wheel and simultaneously roll it inward.
The FMradio plays each station that it finds for several seconds.
2. When you hear a station you want to select, tap .
To store a scanned station in the active preset:
● Tap within 20 seconds of stopping the scan.
To toggle between FM and ATDP music:
● Press for 2 seconds.
3.5 SWITCHING MUSIC SOURCES
If two music (A2DP) audio sources are paired, PACKTALK BOLD uses the audio source from which you last
played music.
To switch to the other audio source:
1. Stop music (A2DP) playback from the current device (see Streaming Music on page 9).
2. Play music (A2DP) from the other device.
PACKTALK BOLD automatically remembers your last played device.
3.6 VOICE COMMANDS
You can use voice commands for hands-free operation of certain PACKTALK BOLD features. Voice commands
use voice recognition. You loudly say a command and PACKTALK BOLD performs the action. Voice commands
are available in various languages. English is the default language. You can change the language to another
available language.
PACKTALK BOLD uses the following predefined voice commands.
10
To ... Say ...
Turn on the radio "Hey Cardo, radio on"
Turn off the radio "Hey Cardo, radio off"
Skip to the next preset radio station "Hey Cardo, next station"
Skip to the previous preset radio station "Hey Cardo, previous station"
Turn on music "Hey Cardo, music on"
Turn off music "HeyCardo, music off"
Play the next music track "Hey Cardo, next track"
Play the previous music t rack "HeyCardo, previous track"
Raise volume "Hey Cardo, volume up"
Lower volume "Hey Cardo, volume down"
Mute audio "Hey Cardo, mute audio"
Unmute audio "Hey Cardo, unmute audio"
Call the default number (conf igurable) "Hey Cardo, speed dial"
Redial the last number "Hey Cardo, redial number"
Answer an incoming call "Answer"
Ignore an incoming call "Ignore"
Access Siri (when connected to an iOS device) "Hey Siri"
Access Google (when connected to an Android
device)
Check the batt ery status "Hey Cardo, battery status"
Open the call intercom "Hey Cardo, call intercom"
"OK Google"
11
4. RIDING WITH OTHERS
Your PACKTALK BOLD features two distinct intercom communication modes: the traditional Bluetooth protocol
and the Cardo's Dynamic Mesh Communications (DMC) technology.
DMC is the best way to communicate in a group. In DMC mode, you can instantly create or join a dynamicallyfluid network of up to 15 riders to communicate in full conference mode. Unlike Bluetooth, DMC allows anyone in
the group to roam freely, overtake each other or even leave the group altogether, without affecting the ongoing
conversations of the remaining fellow riders. You can also use the DMC intercom to communicate privately with
another rider.
Of course, you can still use Bluetooth to connect to devices, such as your smartphone or GPS, or to
communicate with riders with headsets that don't include DMC technology. For details, see Using the Bluetooth
Intercom.htm.
How Does DMC Work?
Anyone can start a new DMC group.
In DMC intercom mode, riders can join, leave, and rejoin existing DMC groups without affecting the ongoing
conversation among the other group members. If a group member goes out of range, the remaining riders are
automatically re-connected within split seconds to a closer group member, bypassing the absent or remote rider.
This way, all active riders remain connected to each other.
4.1 DMCINTERCOM
You can use the DMC intercom to speak with other riders in your DMC group. For more information on creating
DMC intercom groups, see Setting Up and Using DMC intercom Groups on page 12.
Using the DMC intercom, all riders in a group speak hands-free. A rider in a group performs no additional
operation to speak to or hear other riders in the group.
Using the DMC intercom, you can also:
● Chat privately with another rider in your DMC group, see Chatting Privately on page 14
● Bridge a non-DMC passenger or rider, see Using DMC intercom on page 14
● Mute/unmute DMC intercom groups, see Muting/Unmuting DMC Intercom Groups on page 15
● Delete DMC intercom groups, see Deleting DMC intercom Groups on page 14
● Listen to music while in DMC intercom groups, see Background Audio Level and Audio Source Priorities on
page 15
● Switch between DMC intercom and Bluetooth intercom, see Switching between Intercom modes on page 20
4.1.1 SETTING UP AND USING DMC INTERCOM GROUPS
You can manage DMC intercom groups to suit your riding requirements, this includes creating groups, joining
groups, leaving and rejoining groups or changing your active group.
DMC intercom groups are created and deleted by a group creator. Each group can have up to 15 riders: one group
creator/admin and a maximum of 14 group members.
When creating a group, all members should be within 3 meters (10 feet) of the creator. The group continues
functioning even if the creator is no longer available.
If a rider's connection is lost, the rider remains part of the group and reconnects automatically once in range.
If you purchased the PACKTALKBOLD DUO, the package contains two units belonging to the same DMC
intercom group.
12
4.1.1.1 CREATING DMC INTERCOM GROUPS
When creating a DMC group, you must coordinate with the other riders who will be the group creator.
To create a DMC group:
1. Confirm your PACKTALK BOLD is in DMC intercom mode (LED flashes green slowly).
If your PACKTALKBOLD is not in DMC intercom mode, press and .
2. The group creator and all group members: Press for 5 seconds. The LED flashes green quickly.
3. Only the group creator: Tap . The LED flashes red and green quickly.
4. Other members can join the group within 2 minutes.
5. After each member joins successfully, the LEDs of the joined unit and the creator's unit flash purple.
After grouping is completed, the DMC intercom conference starts automatically.
4.1.1.2 JOINING DMC INTERCOM GROUPS
You can join or rejoin a DMC intercom group created by another rider.
If your DMC group connection is lost, you remain part of the group. Once in range of any other group member, you
automatically reconnect.
If your DMC group splits with some group members remaining in range of each other but not in range of all group
members, you can continue speaking with the members still in range. Once in range of any other group member,
you automatically reconnect.
If you join a new DMC group, you automatically leave your existing DMC group.
To join an existing DMC group:
1. Confirm your PACKTALK BOLD is in DMC intercom mode (LED flashes green slowly).
If your PACKTALKBOLD is not in DMC intercom mode, press and .
2. Both you and the group creator: Press for 5 seconds. The LED flashes green quickly.
3. Only the group creator: Tap . The LED flashes red and green quickly.
The color of the flashing LEDindicates whether you have been added to the group:
● Purple: You have successfully joined the group.
● Yellow: You cannot join the group because it has already reached the maximum number of riders.
● Red: Failed to join.
13
4.1.1.3 DELETING DMC INTERCOM GROUPS
If you delete a DMC intercom group, you must rejoin it if you want to connect to it again in the future.
To delete a DMC group:
1. Confirm your PACKTALK BOLD is in DMC intercom mode (LED flashes green slowly).
If your PACKTALKBOLD is not in DMC intercom mode, press and .
2. Press for 5 seconds. The LED flashes green quickly.
3. Press and for 2 seconds.
4.1.2 USING DMC INTERCOM
4.1.2.1 ADDING A NON-DMC PASSENGER
You can use the DMC bridging feature to add a non-DMC rider or passenger to the intercom group.
To bridge a non-DMC passenger/rider:
1. Verify that the passenger/rider is paired via Bluetooth to Channel A (see Setting Up non-DMC Intercom
Groups on page 16).
2. On your unit, press .
To disconnect the bridge:
● Press .
4.1.2.2 CHATTING PRIVATELY
You can chat privately with a specific member of your DMC group.
This option is also available using the Cardo mobile app.
To chat privately:
1. In the Mobile app, select the rider you want to speak with in private or pair with the rider's device on Bluetooth
channel B. (For details, see Pairing Your Unit to Bluetooth Devices on page 6.)
14
2. To start or stop a private chat, tap 2 times.
4.1.2.3 MUTING/UNMUTING DMC INTERCOM GROUPS
Muting the DMC intercom mutes your microphone and speaker. Unmuting the DMC intercom restores sound to
your microphone and speaker.
To mute/unmute the DMC group:
1. Confirm your PACKTALK BOLD is in DMC intercom mode (LED flashes green slowly).
If your PACKTALKBOLD is not in DMC intercom mode, press and .
2. On your unit, press the control wheel for 2 seconds.
4.1.2.4 BACKGROUND AUDIO LEVEL AND AUDIO SOURCE PRIORITIES
The PACKTALKBOLD can use parallel audio streaming to stream audio from two connected sources
simultaneously, so that you can listen to your music or the FM radio while holding a DMC intercom conversation.
PACKTALK BOLD automatically manages your music and FM radio volume while using DMC intercom.
PACKTALK BOLD also automatically manages DMC intercom volume with mobile phone calls and GPS. For
more information on background audio level and audio source priorities, see Using Parallel Audio Streaming on
page 25.
15
4.2 BLUETOOTH INTERCOM
To connect your unit to another unit with a Bluetooth intercom, such as a Cardo Bluetooth unit or other Bluetoothenabled devices, you must first pair their channels. Once paired, the units automatically recognize each other
whenever they are in range (line of sight up to 1.6 km / 5,200 ft subject to terrain).
● Pairing a channel replaces any existing paired unit on that channel with the new unit.
● If you purchased the PACKTALK BOLD DUO, the retail package contains two pre-paired units in DMC
mode.
● The Intercom range with other models is limited to the distance of the unit with the shorter range.
4.2.1 SETTING UP NON-DMC INTERCOM GROUPS
DMC is always the best way to connect a group of riders. If you happen to ride with a group of riders that do not
have DMC devices (such as Bluetooth communicators by Cardo or by other brands), you can switch your unit to
Bluetooth mode and create or join a non-DMC group. The participating riders are connected in a chain with a
maximum total of four riders.
To set up a Cardo non-DMC group:
1. Confirm your unit is in Standby Bluetooth intercom mode (LED flashes blue slowly).
If your unit is not in Bluetooth intercom mode, tap and . For more information see, Switching between
Intercom modes on page 20.
2. To initiate 2-way pairing:
● On your unit, press for 5 seconds to enter pairing mode.
The LED flashes red.
● The following announcement is heard: Rider A pairing.
Bluetooth intercom pairing needs to be initiated on the other device.
The unit confirms that pairing has succeeded.
3. To add a 3rd rider:
● Press for 5 seconds. The LED flashes red.
● Tap 2 times. The LEDflashes blue.
The following announcement is heard: Rider B pairing.
16
Bluetooth intercom pairing needs to be initiated on the other device.
4. To add a 4th rider, Rider 1 or Rider 2 connects to the additional rider.
Bluetooth intercom pairing needs to be initiated on the other device.
To pair a non-Cardo Bluetooth intercom group unit:
1. Confirm your unit is in Standby Bluetooth intercom mode (LED flashes blue slowly).
If your unit is not in Bluetooth intercom mode, tap and . For more information see, Switching between
Intercom modes on page 20.
2. To initiate 2-way pairing:
● On your unit, press for 5 seconds.
The LED flashes red.
● Tap to activate the Cardo gateway.
The LED flashes red and blue.
Bluetooth intercom pairing needs to be initiated on the other device.
● The unit confirms that pairing has succeeded.
3. To add a 3rd rider:
● Press for 5 seconds.
The LED flashes red.
● Tap 2 times. The LEDflashes blue.
17
● Tap . The LED flashes red and blue.
Bluetooth intercom pairing needs to be initiated on the other device.
4. To add a 4th rider, Rider 1 or Rider 2 connects to the additional rider.
Bluetooth intercom pairing needs to be initiated on the other device.
● To cancel the pairing process, press for 2 seconds. The LED stops flashing.
● If pairing is not completed within 2 minutes, the unit automatically returns to Standby.
18
4.2.2 USING THE BLUETOOTH INTERCOM
4.2.2.1 STARTING/ENDING BLUETOOTH INTERCOM CALLS
To start or end communication with Rider 1:
● : Press .
To start or end communication with Rider 2:
● : Press twice.
To initiate a 4-way Bluetooth Conference:
4.2.2.2 RECEIVING BLUETOOTH INTERCOM CALLS
If another paired unit calls you via Bluetooth intercom, the call begins instantly.
4.2.3 RESETTING BLUETOOTH INTERCOM PAIRING
Resetting Bluetooth intercom pairing also resets all Bluetooth device pairing.
To reset Bluetooth intercom pairing:
1. Press for 5 seconds.
2. When the LED flashes red, press and for 2 seconds.
The LED flashes purple 5 times slowly, confirming that pairing has been reset.
19
4.3 SHARING MUSIC AND RADIO
You can share music and FMradio with a passenger or other rider. Music sharing is more suitable for
rider/passenger combinations, whereas FM radio is also intended for rider/rider combinations.
● You can share music only in Bluetooth intercom mode.
● Music and radio can be shared with only one passenger/rider.
● Bluetooth intercom calls are disabled when sharing music.
● FM radio sharing opens a Bluetooth intercom call automatically.
● If you paired your unit to two mobile phones, music will be shared from the mobile phone through which
you last played music.
● When sharing FM radio, either passenger/rider can change station while the Bluetooth intercom call
remains open.
● When you stop sharing FM radio, the Bluetooth intercom call remains open and the FM radio continues to
play independently on each passenger/rider's unit.
● When you stop sharing music, the music continues to play on your unit only.
To start/stop sharing:
1. Confirm your PACKTALK BOLD is in Bluetooth intercom mode (blue LED flashes slowly).
If your PACKTALK BOLD is not in Bluetooth intercom mode, press and .
2. Start playing music or the FM radio.
3. Press for 2 seconds to start sharing on Channel A (by default).
To manually select the channel on which to share music or radio:
1. Start playing music or the FM radio.
2. Start a Bluetooth intercom call on either channel (A or B).
3. Press for 2 seconds.
To stop sharing:
● Press for 2 seconds.
4.4 SWITCHING BETWEEN INTERCOM MODES
Your PACKTALKBOLD unit can work in only one intercom mode at a time.
The current intercom mode is indicated by the color of the LED:
● When in DMC intercom mode, the LED flashes green at approximately 4-second intervals.
● When in Bluetooth intercom mode, the LEDflashes blue at approximately 4-second intervals.
20
To switch between intercom modes:
● On your unit, press and .
The color of the flashing LED changes and a voice message indicates the current intercom mode.
21
5. TROUBLESHOOTING
5.1 SOFT RESET
If your PACKTALK BOLD stops responding, reset it in one of these ways:
● Turning it off and then on again (see Getting Started on page 5).
● Using the supplied USB cable, connect your unit to the computer or wall charger for 30 seconds.
5.2 RESET PAIRING
This option deletes all paired units and devices.
To reset mobile device pairing:
1. Confirm your unit is in Standby Bluetooth intercom mode (LED flashes blue slowly).
If your unit is not in Bluetooth intercom mode, tap and . For more information see, Switching between
Intercom modes on page 20.
2. While in standby mode, press for 5 seconds.
3. Press and for 2 seconds.
The LED flashes purple 5 times slowly, confirming that pairing has been reset.
To reset intercom pairing:
1. Confirm your unit is in Standby Bluetooth intercom mode (LED flashes blue slowly).
If your unit is not in Bluetooth intercom mode, tap and . For more information see, Switching between
Intercom modes on page 20.
2. While in standby mode, press for 5 seconds.
3. Press and for 2 seconds.
The LED flashes purple 5 times slowly, confirming that pairing has been reset.
To reset DMC group pairing:
1. Confirm your PACKTALK BOLD is in DMC intercom mode (LED flashes green slowly).
If your PACKTALKBOLD is not in DMC intercom mode, press and .
2. While in standby mode, press for 5 seconds.
3. Press and for 2 seconds.
The LED flashes purple 5 times slowly, confirming that pairing has been reset.
22
5.3 RESET TO FACTORY SETTINGS
This option deletes all paired units, devices and all configuration settings.
To perform a factory reset through the unit:
1. Check that your PACKTALK BOLD is in Standby mode (see PACKTALK BOLD LEDIndications on page
28).
2. Simultaneously press + + for 5 seconds.
The LED flashes purple 5 times slowly, confirming that pairing has been reset.
5.4 FAQ
Additional answers to common problems can be found at www.cardosystems.com/faqs.
23
6. PERSONALIZING YOUR DEVICE
Get the most out of your PACKTALK BOLD by changing the settings and customizing your unit according to your
own personal preferences, using either of the following methods:
● Cardo Mobile App on iOS or Android devices.
● Cardo Community on Windows / Mac - minimum requirements - Windows® 7 / Mac OS X 10.8
● Unit buttons.
Cardo recommends you customize your settings before going out on the road. You can adjust any of these
settings as required after experiencing them under road conditions.
Object
AGC sensitivit y
(Off/Low/ Medium/ High)
Default
Value
Medium AGC automatically adjusts speaker
volume according to ambient noise and
Description
riding speed. For example, when set to
Low, higher ambient noise will cause the
volume increase to kick in at a higher
level.
Audio priority
(A2DP/Bluetooth
intercom)
Background Audio
Level
Bluetooth
intercom
Priority of audio source playing through
speakers. Either music is not interrupted
by an intercom call, or vice-versa.
N/A Sets the background audio volume when
parallel audio streaming is on (see
Parallel audio streaming in Bluetooth
mode (Enable/Disable) below).
Bluetooth friendly
name
Create, join or leave a
group of
passengers/riders
Download the latest
firmware upgrade
PACKTALK
BOLD
Sets the name that appears on your
phone while pairing and in the Cardo app.
Empty DMC intercom groups. For more
information, see Setting Up and Using
DMC intercom Groups on page 12.
N/A Stay up-to-date by downloading software
updates whenever a new version is
available.
FMBand According to
Your Region
Intercom Mode
(DMC/Bluetooth)
DMC
Intercom
Language According to
Your Region
If you are in Japan, select Japan.
Otherwise, select Worldwide.
DMC intercom and Bluetooth intercom.
Voice announcements and voice-assisted
menus language (see "Spoken Status
Announcements" below).
Mobile priorit y Mobile 1 If you paired your unit to two mobile
phones, you must set one of them as the
default phone for outgoing calls.
Parallel audio
streaming in Bluetoot h
mode (Enable/Disable)
Disable You can hear two audio sources
simultaneously. For example, hear GPS
while listening to music.
Note: Parallel audio streaming may not
work properly with some iOS devices (i.e.,
music player or GPS navigator) due to
connected device limitations.
Cardo Mobile App
(iOS/Android)
ü ü
ü ü
ü û
ü ü
ü û
û ü
ü ü
ü û
ü ü
ü û
ü ü
Cardo
Community
24
Object
RDS (Enable/Disable) Disable Radio Data System allows the radio to
Set speed dial numbers Empty Pre-set phone numbers for automatic
Set the 6 F M radio
presets
Spoken Status
Announcements
(Enable/Disable)
Default
Value
automatically retune to the strongest
frequency available for the FM station you
are listening to when the signal becomes
too weak.
dialing.
107.5 Pre-set FM radio stations.
Enable Voice announcements inform you to
whom or to what device you are
connected.
Description
Cardo Mobile App
(iOS/Android)
ü ü
ü ü
ü ü
ü ü
Cardo
Community
AGC and voice control performance vary based on environmental conditions, including riding speed, helmet
type and ambient noise. For improved voice control performance, minimize the wind impact on the microphone
by closing the visor and using the large microphone sponge.
6.1 SETTING THE DEFAULT MOBILE PHONE
If you paired your unit to two mobile phones, you must set one of them as the default phone for outgoing calls.
If you do not set a default phone, the phone that you first paired with your unit is automatically set as the
default phone.
To set the default phone:
● During a mobile call, press for 5 seconds.
6.2 USING PARALLEL AUDIO STREAMING
With parallel audio streaming, you can hear GPS instructions during a mobile or Bluetooth intercom call, or while
listening to other audio sources, such as music or FM radio.
25
Parallel audio streaming may not work properly with some iOS devices (i.e., music player or GPS navigator)
due to connected device limitations.
Your PACKTALK BOLD sets the various audio sources to either foreground (volume remains the same) or
background (volume reduced) as described in the following table:
Mobile Phone 1/2 GPS Intercom 1 Intercom 2 Music FM Radio
Foreground Foreground
Foreground
1
If you add an intercom call to a mobile phone call creating a conference call, the volume for both audio sources is
1
Foreground Foreground
Foreground Background
Foreground Background
Foreground
Foreground Background
Foreground Background
Foreground
1
2,3
Foreground
2,3
Foreground
Background
4
Foreground
the same.
2
If you make two intercom calls simultaneously creating an intercom conference call, the volume for both audio
sources is the same.
3
If you make two intercom calls simultaneously creating an intercom conference call, you cannot hear the mobile
phone or GPS.
4
If you play music only, the music volume is not reduced.
5
If you play the FMradio only, the FM radio volume is not reduced.
5
In some cases, parallel audio streaming may not work properly due to connected device limitations (music
player or GPS navigator). For more information, see FAQ on page 23.
Cardo recommends that during a 3-way or 4-way Bluetooth intercom conference call, the rider who is
connected to only one intercom call listens for mobile phone and GPS announcements.
You cannot use music sharing for voice audio with riders during parallel audio streaming.
Music can be streamed in the background during an active DMC intercom call.
You can configure parallel audio streaming via the Cardo app or the Cardo Community.
6.3 AUDIO SOURCE PRIORITIES
If Parallel Audio Streaming is disabled, PACKTALKBOLD manages the audio sources you hear through the
speakers according to the following audio source priorities.
26
Priority Audio Source
Higher Priority
↑
Lower Priority
1
Phone calls and GPS temporarily mute DMC intercom, but group members remain part of the DMC intercom
Mobile phone, GPS device instructions
Intercom (DMC and Bluetooth modes) or Music
Music or Intercom (DMC and Bluetooth modes)
FM Radio
1
2
3
group.
2
When audio priority is set to Intercom, you cannot hear navigation app or SMS messages from your phone
during an ongoing intercom call.
3
When audio priority is set to A2DP (music), the intercom is disabled while listening to music (via A2DP). A rider
calling you by intercom hears a sound indicating you are not available.
Intercom modes all have the same priority, so ongoing intercom calls will not be interrupted by any other
intercom call.
If you paired your unit to two mobile phones (see Setting the Default Mobile Phone on page 25), music will be
shared from the mobile phone through which you last played music.
27
APPENDIX A. PACKTALK BOLD LEDINDICATIONS
Your PACKTALK BOLD operates in various modes. Each mode consists of a group of features currently
available for your use. For example, when PACKTALK BOLD plays music, it will be in music playing mode,
enabling features related to playing music such as skipping to the next and previous tracks.
Events are considered to occur whenever you operate a feature and when PACKTALK BOLD responds. For
example, turning on music is an event.
PACKTALK BOLD's current mode is indicated by the unit LEDs. You also hear voice announcements on your
unit for mode changes and events.
The following table shows LEDindications for modes and events according to the current battery state.
LED Flashing Battery State Mode or Event
Blue For 2 seconds Normal ● Rider B connected
● Set voice control to enabled
Blue Fast (three times) Normal
Low Battery
Charging
Blue Fast (repeating fast) Normal,
Low Battery
Charging
Blue Slow (repeated at 3-second intervals) Normal ● Standby
Blue Slow twice (repeated at 3-second
Normal ● Incoming/outgoing call (intercom or
intervals)
Green Fast twice (repeated at 1-second
intervals)
Normal or
Low Battery
Green Fast (repeating) Normal or
Low Battery
Purple For 2 seconds Normal
Low Battery
Charging
Purple Slow (5 times) Normal
Low Battery
Purple/Red Purple twice slowly, then red Charging ● Incoming/outgoing call (intercom or
Purple/Red Slow purple and red (repeating) Charging ● Standby
Red Slow twice (repeated at 3-second
Low Battery ● Incoming/outgoing call (intercom or
intervals)
Red For 2 seconds Normal or
Low Battery
Red Fast (repeated at 3-second intervals) Low Battery ● Standby DMC intercom
Red Fast (repeated at 3-second intervals) Low Battery ● Standby
Red Fast (repeating fast) Normal
Low Battery
Charging
Red Fast (3 times) Normal
Low Battery
Charging
● Power on
● Pairing intercom rider B
mobile)
● Audio active (intercom, FM, A2DP, GPS)
● Active DMC intercom call
● Pairing DMC intercom
● Mobile pairing successful
● Mobile connected
● Reset pairing
mobile)
● Audio active (intercom, FM, A2DP, GPS)
mobile)
● Audio active (intercom, FM, A2DP, GPS)
● DMC intercom pairing failed
● Pairing intercom rider A
● Power off
28
LED Flashing Battery State Mode or Event
Red For 2 seconds Normal
Low Battery
● Rider A connected
● Set voice control to disabled
Charging
Red Remains on Charging ● Off
Red/Blue Alternating fast Normal
● Pairing Mobile 1
Low Battery
Charging
Red/Blue Alternating slow Normal
● Pairing GPS 1
Low Battery
Red/Green Alternating fast Normal
● Pairing Mobile 2
Low Battery
Charging
Red/Green Alternating slow Normal,
● Pairing GPS 2
Low Battery
Yellow For 2 seconds Normal
Low Battery
Charging
● Intercom call attempted without
microphone or audio kit connected.
● DMC intercom pairing successful
29
7. GLOSSARY
Term/Abbreviation Description
A2DP Advanced Audio Distribution Profile (for music). A protocol for playing
music over Bluetooth.
AGC sensitivit y AGC (Automatic Gain Control) automatically adjusts speaker volume and
microphone sensitivity according to ambient noise and riding speed.
Device Mobile phone, GPS or music player.
DMC Dynamic Mesh Communications.
Intercom Mode (DMC/Bluetooth) DMC intercom or Bluetooth intercom.
Language Voice announcements and voice commands language.
Unit Cardo or non-Cardo Bluetooth Communication system.
Voice control Voice activation (by saying a word or phrase) of certain features for
hands-free operation.
Voice control sensitivity Adjusts your microphone sensitivity for voice activation while you are
riding.
30
8. SUPPORT
For additional information:
: www.cardosystems.com
* support@cardosystems.com
( USA and Canada: 1-800-488-0363 / International: +49 89 450 36819
To avoid potential problems and to receive our support and warranty coverage, we strongly recommend buying
our products only from authorized Cardo dealers.
Your favorite brick-and-mortar store is always your best bet. Unauthorized online resellers and online auction
sites such as eBay are not among Cardo’s authorized dealers, and purchasing our products from such sites
will be at your own risk. Cardo strives to provide quality products and exceptional customer service. We
select dealers who share that vision. Buying grey market items from unauthorized online dealers is
counterproductive and also adversely affects unsuspecting online consumers who may be purchasing used,
counterfeit or defective products or devices whose warranties are void. Protect your investment by purchasing
genuine Cardo and scala rider® products only from authorized dealers.
© 2018 Cardo Systems
All rights reserved. Cardo, the Cardo logo and other Cardo marks are owned by Cardo and may be registered. All
other trademarks are the property of their respective owners. Cardo Systems assumes no responsibility for any
errors that may appear in this document. Information contained herein is subject to change without notice.
31
Loading...
