Canon VCC STEP-UP 2014 BROCHURE

Canon: network surveillance solution

Network
Security
Cameras

2014

With a 70 year heritage and a focus on innovation, Canon offers network security cameras to monitor and protect your environment.
Canon network security cameras offer a wide choice of construction, field of view and resolutions, so you can select a model that’s best
suited for your applications. With best image quality in all lighting conditions and wide angles of view, these cameras ensure the evidence
is detailed and usable. All network cameras feature Canon’s distinctive advanced lens technology and leading edge functionality.

Key Technologies and Features

Image Quality

With the combination of high sensitivity CMOS sensors and advanced
DIGIC imaging processors, the fruit of Canon’s long years as a camera
manufacturer, our network security cameras offer superior image quality
with rich detail, low noise and faithful colour reproduction.

Powerful Image Processing

The dual image processors – DIGIC DV III and DIGIC NET II – enable
seamless capturing, processing, encoding and transmitting of images.*
The DIGIC DV III engine, also used in Canon’s Cinema EOS professional
movie cameras, allows exceptional video quality, low noise, smooth
gradations and vivid and accurate colour reproduction – even in low
light conditions. High streaming performance of DIGIC NET II allows
simultaneous streaming of 2x H.264 video in variable frame rates for
monitoring or recording.

* Dual image processors in VB-H and VB-S series

Class Leading Low Light Performance

Considering the importance of recognition ability for surveillance cameras,
noise reduction (NR) control and colour reproduction have been particularly
enhanced in Canon network cameras. As a result, while striking a balance
between noise, resolution and colour reproduction, colour is visible even in low
light conditions with excellent minimum luminance. The minimum subject
illumination is further improved by turning on Smart Shade Control / Auto SSC.

Competitor Network Camera

Canon Network Camera (VB-S900F)

SSC / Auto SSC

SSC (Smart Shade Control) is an extremely important function for security
purposes that maintains image sharpness when shadows are generated
by backlight or other causes. This function is further improved with Auto
SSC, which applies histogram analysis to shooting conditions such as
backlight scenes and automatically selects optimum exposure level.

Competitor Network Camera

Lens Design and Wide Angle Views

Thanks to Canon’s optic technology, the lenses deliver more light to
the camera’s sensors – achieving brighter and better defined images.
By optimally arranging high quality aspherical lenses, a superior lens
configuration is achieved that delivers low distortion and wide angle
of views in a very compact size.

Competitor Fixed 96° Wide-Angle Lens

Canon Network Camera With Auto SSC

Canon Fixed 95° Wide-Angle Lens
(VB-S31D / VB-S800D)

Intelligent Functions

Intelligent Functions aid operators in identifying alarming situations,
by analysing differences between different areas. It is possible to use
up to 15 functions in parallel on one camera. A choice of six different
Intelligent Functions include Moving Object Detection, Abandoned Object
Detection, Removed Object Detection, Camera Tampering Detection,
Passing Detection and Volume Detection. Detected activity can be set
to activate recording, uploading images to a server or sending an email
notification. By using an SD card you can backup recorded videos in case
of cable cut or the network going down.

Enhanced Compatibility with ONVIF v2.2 and Profile S compliance

Canon is a full member of ONVIF – the industry forum dedicated to the
development of a global IP-based physical security interface standard.
Compliance with the latest ONVIF v2.2 and Profile S makes it convenient
to create a solution with ONVIF-complaint video management software.
Canon also supports seamless integration through the use of the Canon
network camera SDK and HTTP protocol specification.

Easy and Flexible Installation

With multiple power supply options, it is easy to power the Canon network
cameras. The Camera Angle of View Setting Tool
the angle of the camera by watching the actual visual from a network
connected computer. Adjustments can be made intuitively by pressing the
pan/tilt buttons that appear on the adjustment window in the direction
you want to move the camera. Rotation and zoom can be adjusted using
the on-screen sliders, the range for which varies from camera to camera.

† The electronic adjustment functions of cameras with PTRZ installation are for adjusting the

camera after installation and do not possess the durability needed for regular operation.

†

can be used to adjust

POWER
TO YOUR
NEXT STEP

Let your next

step be image

quality even

when the lights

go down.

Canon Inc
canon.com

Canon Europe
canon-europe.com

English Edition
© Canon Europa N.V. 2014

you can

Camera Type

Image Sensor

Video Resolution

Lens

Horizontal Viewing Angle

Day and Night Mode

Minimum Subject Illumination

Outdoor Rating

Video Compression Method

Max Frame Rate

Audio Support

Alarm Input / Output

Backlight Compensation

Video Streaming

Intelligent Functions

Memory Card Compatibility

Power Supply

Network Security

Dimensions (H x W x D)

Weight

ONVIF Compliance

VB-M700F VB-M600D VB-M600VE VB-M40/B VB-H710F VB-H610D VB-H610VE VB-H41/B VB-S900F VB-S800D VB-S31D VB-S30D

1.3 MP Network Cameras Full HD Network Cameras Ultra-compact Full HD Network Cameras

Fixed Box Indoor Fixed Dome

1/3 inch CMOS

with Primary Colour Filter

with Primary Colour Filter

Progressive scan

3x optical zoom lens

2.8 mm (wide) – 8.4 mm

3x optical zoom lens

2.8 mm (wide) – 8.4 mm

(telephoto)

f/1.2 – f/2.0

1/3 inch CMOS

Progressive scan

JPEG: 1280 x 960, 640 x 480, 320 x 240, 160 x 120

H.264: 1280 x 960, 640 x 480, 320 x 240

(telephoto)

f/1.2 – f/2.0

Outdoor Fixed Dome

(Vandal-resistant)

1/3 inch CMOS

with Primary Colour Filter

Progressive scan

3x optical zoom lens

2.8 mm (wide) – 8.4 mm
(telephoto)

f/1.2 – f/2.0

Pan Tilt Zoom Fixed Box Indoor Fixed Dome

1/3 inch CMOS

with Primary Colour Filter

Progressive scan

20x optical zoom lens with auto

focus 4x digital zoom 4.7 mm

(wide) – 94 mm (telephoto)

f/1.6 – f/3.5

1/3 inch CMOS

with Primary Colour Filter

Progressive scan

3x optical zoom lens

4x digital zoom 2.8 mm

(wide) – 8.4 mm (telephoto)

f/1.2 – f/2.0

with Primary Colour Filter

4x digital zoom 2.8 mm

(wide) – 8.4 mm (telephoto)

1/3 inch CMOS

Progressive scan

JPEG: 1920 x 1080, 960 x 540, 480 x 270, 320 x 240

H.264: 1920 x 1080, 960 x 540, 480 x 270

3x optical zoom lens

f/1.2 – f/2.0

102.5° (wide) – 34.2° (telephoto) 101.2° (wide) – 33.7° (telephoto) 101.2° (wide) – 33.7° (telephoto) 55.4° (wide) – 2.8° (telephoto) 112.6° (wide) – 36.7° (telephoto) 111.0° (wide) – 36.5° (telephoto) 111.0° (wide) – 36.5° (telephoto) 60.4° (wide) – 3.2° (telephoto) 96.0° 95.0° 95.0° 77.7° (wide) – 20.7° (telephoto)

Infrared Cut Filter Infrared Cut Filter Digital Night Mode

Day Mode: 0.25 lux (colour, f/1.2)

Night Mode: 0.008 lux

(mono, f/1.2)

1

1

Day Mode: 0.25 lux (colour, f/1.2)

Night Mode: 0.008 lux

(mono, f/1.2)

1

Day Mode: 0.25 lux (colour, f/1.2)

1

Night Mode: 0.008 lux

(mono, f/1.2)

1

Day Mode: 0.4 lux (colour, f/1.6)

1

Night Mode: 0.01 lux

(mono, f/1.6)

1

Day Mode: 0.3 lux (colour, f/1.2)1

1

Night Mode: 0.015 lux

(mono, f/1.2)

1

Day Mode: 0.3 lux (colour, f/1.2)1

Night Mode: 0.015 lux

(mono, f/1.2)

1

– – IP66 Rated – – – IP66 Rated – – – – –

H.264, JPEG H.264, JPEG H.264, JPEG

30 fps in all resolutions

2

30 fps in all resolutions

Two-way Two-way Microphone in / Line in x 1

2x Inputs / 2x Outputs 2x Inputs / 2x Outputs 1x Inputs / 1x Outputs

Smart Shade Control Smart Shade Control Auto Smart Shade Control

1x H.264 and 4 x JPEG streams 1x H.264 and 4 x JPEG streams 2x H.264 and 3 x JPEG streams

Moving Object Detection, Abandoned Object Detection, Removed Object Detection,

Camera Tampering Detection, Volume Detection

Moving Object Detection, Abandoned Object Detection, Removed Object Detection,

Camera Tampering Detection, Passing Detection, Volume Detection

SD / SDHC up to 32GB SD / SDHC / SDXC up to 128GB micro SD / SDHC / SDXC up to 64GB

PoE (IEEE802.3af compliant) / 12V DC / 24V AC / Canon PA-V17 (AC adapter) PoE (IEEE802.3af compliant) / 12V DC / 24V AC / Canon PA-V17 (AC adapter) PoE (IEEE802.3af compliant)

IPsec and Secure HTTP IPsec and Secure HTTP IPsec and Secure HTTP

65 x 80 x 192 mm (ϕ x H) ϕ186 x 140 mm (ϕ x H) ϕ180 x 147 mm (ϕx H) ϕ132 x 155 mm 65 x 80 x 192 mm (ϕ x H) ϕ186 x 140 mm (ϕ x H) ϕ180 x 147 mm (ϕ x H) ϕ132 x 155 mm 54 x 32 x 114 mm (ϕ x H) ϕ120 x 54 mm (ϕ x H) ϕ120 x 54 mm (ϕ x H) ϕ120 x 54 mm

700 g 1200 g 1910 g 1150 g 670 g 1200 g 1920 g 1140 g 180 g 240 g 270 g 270 g

ONVIF v1.02 ONVIF v2.2 and Profile S compliant ONVIF v2.2 and Profile S compliant

Outdoor Fixed Dome

(Vandal-resistant)

1/3 inch CMOS

with Primary Colour Filter

Progressive scan

3x optical zoom lens

4x digital zoom 2.8 mm

(wide) – 8.4 mm (telephoto)

f/1.2 – f/2.0

Day Mode: 0.3 lux (colour, f/1.2)1

Night Mode: 0.015 lux

(mono, f/1.2)

2

1

Pan Tilt Zoom Fixed Mini Box Fixed Minidome Pan Tilt Minidome Pan Tilt Zoom Minidome

1/3 inch CMOS

with Primary Colour Filter

Progressive scan

1/3 inch CMOS

with Primary Colour Filter

Progressive scan

1/3 inch CMOS

with Primary Colour Filter

Progressive scan

1/3 inch CMOS

with Primary Colour Filter

Progressive scan

with Primary Colour Filter

H.264, MJPEG: 1920 x 1080, 960 x 540, 480 x 270, 1280 x 720,

640 x 360, 320 x 180, 1280 x 960, 640 x 480, 320 x 240

20x optical zoom lens with auto

focus 12x digital zoom 4.7 mm

(wide) – 94 mm (telephoto)

f/1.6 – f/3.5

Day Mode: 0.4 lux (Colour, F/1.6)1

Night Mode: 0.02 lux

(Mono, F/1.6)

1

Fixed focal length lens

(4x digital zoom)

2.7 mm (wide)
f/1.6

Day Mode: 0.4 lux (colour, f/1.6)1

Digital Night Mode: 0.2 lux

(mono, f/1.6)

1

Fixed focal length lens

(4x digital zoom)

2.7 mm (wide)
f/1.6

Day Mode: 0.45 lux (colour, f/1.6)1

Digital Night Mode: 0.25 lux

(mono, f/1.6)

1

Fixed focal length lens

(4x digital zoom)

2.7 mm (wide)
f/1.6

Day Mode: 0.45 lux (colour, f/1.6)1

Digital Night Mode: 0.25 lux

(mono, f/1.6)

1

3.5x optical zoom lens with auto

focus (4x digital zoom) 2.25 mm

(wide) – 7.88 mm (telephoto)

Day Mode: 0.95 lux (colour, f/1.4)1

Digital Night Mode: 0.5 lux

30 fps in all resolutions, single stream2

H.264 (stream 1) (1920 x 1080) and H.264 (stream 2) (all sizes): 15 fps

Moving Object Detection, Abandoned Object Detection, Removed Object Detection,

Camera Tampering Detection, Passing Detection, Volume Detection

1/4.85 type CMOS

Progressive scan

f/1.4 – f/2.6

(mono, f/1.4)

1

Remote Setup - PTRZ

Zoom and Focus Pan, Tilt, Rotation, Zoom and Focus – Zoom and Focus Pan, Tilt, Rotation, Zoom and Focus – – – – –

1

1/30 seconds shutter speed, Smart Shade Control off, 50IRE 2 The frame rate may be reduced due to limitations of the viewer’s PC or network used and also the number of clients accessing the camera at the same time.
