Page 1
Quick Guide
Read this guide rst.
Please read this guide before operating this product. After you finish reading the guide, store it in
a safe place for future reference.
Page 2
imagePRESS C800/C700/C60
Practical Features
Auto Gradation Adjustment for Various
Paper Types
The Auto Adjust Gradation function adjusts the gradation, density,
and color tone of images, and only requires you to scan the test
page. This function can be used for various weights of paper so that
a high quality print result can be obtained in different paper types.
"Adjustment for Image Quality and Finishing (Calibration)" in the
e-Manual
Achieve High Quality Color Reproduction
with Auto Color Tone Correction
Compared to the Auto Adjust Gradation function, which adjusts
CMYK, the Auto Correct Color Tone function adjusts mixed colors
that are expressed with multiple toner. By using these functions
together, you can perform the precise color adjustment.
"Adjustment for Image Quality and Finishing (Calibration)" in the
e-Manual
Optimum Print Result for Each Paper Type
Paper information, which includes the basis weight, finish, fixing, and
curl correction level, can be registered as the paper characteristics.
As the detailed information can be specified for each different paper
type, you can obtain the fine print result with considering the paper
characteristics. This function is also effective for improving paper
conveyance and print quality.
"Paper Type Management" in the e-Manual
Curl Correction for Stable Paper Conveyance
The machine constantly corrects the paper curl which occurs due
to the pressure applied when toner is fixed. Moreover, by correcting
the paper curl during outputting, the machine reduces the risk of
a paper jam, and achieves the stable paper conveyance. The curl
correction can be specified for each paper type you want to use.
"Adjustment for Image Quality and Finishing (Calibration)" in the
e-Manual
"Paper Type Management" in the e-Manual
Page 3
Easy Operation for Adjusting Image Position
You can adjust the image positions easily with this machine. All you
need is measuring marks on the test page and then entering the
measured values on the touch panel display. After that, the machine
will automatically adjust the image positions. You can make the
complicated adjustment easily by entering values for each edge of
front and back sides on a single screen.
"Paper Type Management" in the e-Manual
Quick Access to Frequently Used Settings
Different settings are required, depending on the printing purpose
or paper types, but accessing setting items located in various menus
every time is a quite complicated operation. In this case, register
frequently used settings in "Settings/Registration Shortcut" button.
You can directly access to the setting screen with this button and
save the effort to search necessary setting items.
"Settings/Registration" in the e-Manual
Alternative Settings for Your Needs,
"Productivity" or "Quality"
You can set a priority to either print productivity or image quality. For
instance, select "Productivity Priority" when printing a large number
of documents to achieve speedy printing. On the other hands, select
"Quality Priority" when printing documents which contain many
pictures to obtain precisely printed images. This function can be set
for each paper type to suit your various needs for printing.
"Settings/Registration" in the e-Manual
Page 4
Contents
Thank you for purchasing this Canon product. Please read this manual thoroughly before operating the machine
to familiarize yourself with its capabilities, and to make the most of its many functions. For more information on
the detailed settings for the functions, see the e-Manual. After reading this manual, store it in a safe place for future
reference.
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . 6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Maintenance and Inspections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Parts and Their Functions . . . . . . . . . . . . . . . . . . . . . . . . . 13
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Back View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Internal View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Control Panel (Upright Control Panel-D1) . . . . . . . . . . . . . . . . . . .16
Status Monitor/Cancel Screen . . . . . . . . . . . . . . . . . . . . 18
How to Turn ON the Main Power . . . . . . . . . . . . . . . . . . 19
Turning ON the Main Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Shutting Down the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Loading Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Available Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Registering Paper Types in the Paper Database . . . . . . . . . . . . . . 22
Loading Paper into the Paper Drawer . . . . . . . . . . . . . . . . . . . . . . . 23
Selecting Paper Types from the Paper Database . . . . . . . . . . . . .24
Cleaning and Maintenance . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning the Platen Glass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Cleaning the Original Scanning Area . . . . . . . . . . . . . . . . . . . . . . . .25
Cleaning the Feeder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Automatic Feeder Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Cleaning the Inside of the Main Unit . . . . . . . . . . . . . . . . . . . . . . . .27
Refreshing the Fixing Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Cleaning the Touch Panel Display . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Inspection of the Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Clearing Paper Jams and Staple Jams . . . . . . . . . . . . . . . . . . . . . . .32
Reducing the Frequency of Paper Jams . . . . . . . . . . . . . . . . . . . . .32
When an Error Message Is Displayed . . . . . . . . . . . . . . . . . . . . . . . .33
Contacting Your Local Authorized Canon Dealer . . . . . . . . . . . .34
If Memory Becomes Full . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
If the Main Power Does Not Turn ON . . . . . . . . . . . . . . . . . . . . . . . .35
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Symbols Used in This Manual
Indicates a warning concerning operations that may lead to death or injury to persons if not
WARNING
CAUTION
IMPORTANT
NOTE
OPTION
performed correctly. To use the machine safely, always pay attention to these warnings.
Indicates a caution concerning operations that may lead to injury to persons if not performed
correctly. To use the machine safely, always pay attention to these cautions.
Indicates operational requirements and restrictions. Be sure to read these items carefully to
operate the machine correctly, and avoid damage to the machine or property.
Indicates a clarification of an operation, or contains additional explanations for a procedure.
Reading these notes is highly recommended.
Indicates an optional product which can be used with this machine.
Page 5
Keys and Buttons Used in This Manual
Control Panel Keys: Key Icon (Key Name)
The followings are examples of how keys and
•
buttons are expressed in this manual.
Touch Panel Display Keys: [Key Name]
•
Buttons on Computer Operation Screens: [Button
[Copy]
[Close]
•
Name]
[OK], [Add], [Cancel]
Illustrations Used in This Manual
Illustrations used in this manual are those displayed when
the imagePRESS C800 has the following optional equipment
attached to it: the Duplex Color Image Reader Unit-H1, Upright
Control Panel-D1, and Output Tray-A1.
(Start) (Stop)
Manuals for the Machine
The manuals for this machine are divided as follows. Please refer to them for detailed information.
Printed manuals Manuals included in the accompanying CD-ROM
* The CD-ROM/DVD-ROM provided for this product may include manuals in PDF format. If you do not have access to Adobe Reader to
view the manuals in PDF format, try other programs such as PDF Preview developed by Vivid Document Imaging Technologies.
Quick Guide (This manual)
Describes the precautions for using the machine, parts names and functions, basic operations, and
specifications of the machine.
e-Manual
Describes all the functions of the machine. Also provided with a search function that is useful for finding
information.
Driver Installation Guide
Provides instructions on installing the drivers. The following installation guides are included in the same
CD-ROM as each driver.
Windows: Printer Driver Installation Guide, Color Network ScanGear 2 Installation Guide
Macintosh: Canon Printer Driver Guide
Page 6
Important Safety Instructions
These "Important Safety Instructions" are intended to prevent injury to user or other persons or destruction of
property. Please read these instructions thoroughly before operating the machine. Also, since it may result in
unexpected accidents or injuries, do not perform any operation unless otherwise specified in the manual. Improper
operation or use of this machine could result in personal injury and/or damage requiring extensive repair that may not
be covered under your Limited Warranty.
Installation
▀
Read the following installation precautions thoroughly to maintain a comfortable and safe working environment, in
areas of machine operation.
WARNING
Do not install the machine in locations where there
ar
e risks of a fir
•
A location wher
(i.e. by the walls, on the soft surface such as a bed,
sofa, or rug)
•
A damp or dusty location
•
A location exposed to direct sunlight
•
A location subject to high temperatures
•
A location near open flames
•
A location near alcohol, paint thinner, or other
flammable substances
CAUTION
Do not install the machine in unstable locations
Installing the machine in the following locations
my cause the machine t
personal injury.
•
An unsteady platform
•
A location subject to excessive vibrations
Do not remove the leveling feet
Do not remove the machine’s leveling feet after the
machine has been installed, as this ma
machine to fall or tip over, resulting in personal injury.
e or electrical shock
e the ventilation slots are blocked
o fall or tip over, resulting in
y cause the
ther
Warnings
O
•
D
o not place jewelry and other metal objects,
or containers filled with water or liquids on the
machine. If these items come into contact with a
high-voltage area inside the machine, it may result in
a fire or electrical shock.
•
Do not use the machine near any medical
equipment. Electric waves emitted from the machine
may interfere with medical equipment, which may
result in a malfunction or personal injury.
•
If objects are dropped or spilled inside the machine,
immediately turn OFF the main power switch, and
disconnect the power cord from the power outlet.
Then, contact your local authorized Canon dealer.
Avoid installing the machine at high altitudes of
about 3,000 meters abo
Machines with a hard disk may not operate properly
when used at high altitudes of about 3,000 meters
e sea level, or higher.
abov
ve sea level, or higher.
6
Page 7
IMPORTANT
Important Safety Instructions
Do not install the machine in the following locations
•
A location subjec
t to rapid changes in temperature
and humidity
•
A location near equipment that generates magnetic
waves or electromagnetic waves
•
A location where chemical reactions occur, such as a
laboratory
•
A location exposed to corrosive gas or toxic gas
•
A location where the floor may be warped due to
the weight of the machine, such as on a carpet
Avoid poorly ventilated locations
This machine generates a slight amount of ozone
. during normal use. Although sensitivity to ozone
etc
etc. may vary, this amount is not harmful. Ozone etc.
may be more noticeable during extended use or long
It is recommended that the room be appropriately
ventilated, sufficient to maintain a comfortable
working environment, in areas of machine operation.
In addition, do not install this machine where it
exhausts directly onto a person.
Do not install the machine in a location where
c
ondensation oc
If the room where the machine is installed is heated
rapidly, or the machine is mov
location to a hot, humid location, water droplets
(condensation) may form inside the machine. This
may result in paper jams, poor print quality, or a
malfunction. To prevent these problems, wait at
least two hours before using the machine in order to
adapt the machine to the ambient temperature and
humidity.
production runs, especially in poorly ventilated rooms.
Provide Adequate Installation Space
Provide enough space on each side of the machine for unrestricted operation.
curs
ed from a cool, dry
4" (100 mm) or more
When the Output Tray-A1, Duplex Color
Image Reader Unit-H1, and Upright
Control Panel-D1 are attached.
*1
76 7/8" (1,952 mm)
31 1/2" (800 mm) or more
60" (1,524 mm)
289 3/8" (7,349 mm)
When the Two-Knife Booklet Trimmer-A1, Booklet Trimmer-D1, Saddle
Finisher-AM2, Paper Folding Unit-F1, High Capacity Stacker-G1, Perfect
Binder-D1, Professional Puncher Integration Unit-C1, Professional
Puncher-B1, Document Insertion Unit-M1, Duplex Color Image Reader
Unit-H1, Upright Control Panel-D1, and Multi-drawer Paper Deck-B1 are
attached.
*2
*1 Make sure to provide at least 31 1/2" (800 mm) of space if you attach one or more of the following: Paper Folding Unit-F1, Professional
Puncher-B1, Document Insertion Unit-M1, Multi-drawer Paper Deck-B1, Perfect Binder-D1, or High Capacity Stacker-G1.
*2 Make sure to provide at least 4" (100 mm) of space if none of the Paper Folding Unit-F1, Professional Puncher-B1, Document Insertion
Unit-M1, Multi-drawer Paper Deck-B1, Perfect Binder-D1, or High Capacity Stacker-G1 is attached.
69 1/2" (1,765 mm)
7
Page 8
Power Supply
▀
Plug the machine into an outlet that is 208 V AC 20 A or greater.
WARNING
•
Do not use power supplies with voltages other than
those specified herein, as this may result in a fire or
electrical shock.
•
Do not use power cords other than the provided
power cord, as this may result in a fire or electrical
shock.
•
The provided power cord is intended for use with
this machine. Do not connect the power cord to
other devices.
•
Do not damage, modify, pull on, or excessively bend
the power cord. Also do not place heavy objects
on the power cord, as this could cause electrical
damage and result in a fire or electrical shock.
CAUTION
•
Do not connect any unauthorized optional products
to the outlet for connecting optional products, as
this could result in a fire or smoke.
IMPORTANT
•
Do not connect or disconnect the power plug with
wet hands, as this may result in electrical shock.
•
Do not connect the power cord to a multiplug
power strip, or do not use extension cords, as this
may cause a fire or electrical shock.
•
Do not bundle up or tie the power cord in a knot, as
this may result in a fire or electrical shock.
•
Insert the power plug completely into the power
outlet, as failure to do so may result in a fire or
electrical shock.
•
When there is thunder and lightning, disconnect the
power plug from the power outlet, as failure to do so
may result in a fire, malfunction, or electrical shock.
•
Install this machine near the power outlet and leave
sufficient space around the power plug so that it can
be unplugged easily in an emergency.
Power supply connection
•
D
o not connect the power cord to an uninterruptible
power source.
•
If the machine is connected to the power outlet with
multiple sockets, do not use the remaining sockets
to connect other devices.
•
It is recommended that the power outlet wired to an
indoor circuit breaker is used.
•
When disconnecting the power cord, wait at least 5
seconds before connecting the power cord again.
8
Other Precautions
Electrical noise and excessive voltage drop may cause
a malfunc
comput
tion or loss of data in the machine and
ers.
Page 9
Handling
▀
WARNING
Important Safety Instructions
•
If the machine makes strange noises, or gives off
smoke, heat, or strange smells, immediately turn
OFF the main power switch, and disconnect the
power cord from the power outlet. Then, contact
your local authorized Canon dealer. Continued use of
the machine in this condition may result in a fire or
electrical shock.
•
Do not attempt to disassemble or modify the
machine. There are high-temperature and highvoltage components inside the machine, and
contact with those components may result in a fire
or electrical shock.
•
If you are using a cardiac pacemaker and feel
abnormalities, please move away from the product
immediately. This product emits low level magnetic
flux.
CAUTION
•
Do not place heavy objects on the machine, as they
may fall or tip over, resulting in personal injury.
•
For your safety, disconnect the power cord when the
machine will not be used for an extended period of
time.
•
When opening and closing covers, be careful not to
get your hands caught, as this may result in personal
injury.
•
Keep your hands, hair, clothing, etc. away from
the rollers in the output area, as your hand, hair, or
clothing may get caught in the rollers which may
result in personal injury.
•
In order to prevent burns, do not touch the fixing
transport unit and its surroundings and output area
when using the machine, as these areas are very hot
during use. Also, be careful when handling printed
paper as it may be hot especially during continuous
printing.
•
Paper that has just been output from the machine
may be hot. Be careful when removing or aligning
paper from the output tray. Touching paper right after
it is output may result in low-temperature burns.
•
Do not use highly flammable sprays near the
machine. If gas from these sprays comes into contact
with the electrical components inside the machine,
it may result in a fire or electrical shock.
•
When moving the machine, always turn OFF the
main power switch, disconnect the power plug from
the power outlet, and then unplug the interface
cable. Otherwise, the power cord or interface cable
may be damaged, resulting in a fire or electrical
shock.
•
Do not press down the feeder forcefully when using
the platen glass to make copies of thick books.
Doing so may damage the platen glass and result in
personal injury.
•
Be careful not to drop heavy object, such as a
dictionary, on the platen glass. Doing so may
damage the platen glass and result in personal injury.
•
There are high-voltage components inside the
machine. Do not touch the labeled component and
its surroundings when removing jammed paper or
inspecting the inside of the machine, as doing so
may result in an electrical shock.
•
Do not touch the finisher and its trays while the
machine is operating, when the optional finisher
is attached to the machine. Do not place your
hands near the rollers of the tray where stapling is
performed. Doing so may result in personal injury.
9
Page 10
Laser beam
The laser beam can be harmful to human bodies. Since
radiation emitted inside the pr
oduct is completely
confined within protective housings and external
covers, the laser beam cannot escape from the
machine during any phase of user operation. Read the
following remarks and instructions for safety.
•
Never open covers other than those instructed in the
manuals for this machine.
•
Do not remove the caution label which is attached
to the machine.
IMPORTANT
Controlling, adjusting, or operating the machine in
ways not mentioned in the manuals for this machine
may cause dangerous radiation to escape from the
machine. If the laser beam escapes from the machine,
exposure may cause serious damage to your eyes.
•
Follow the instructions in the caution label attached
to the machine.
•
Do not shake the machine or do not apply shock to
the machine.
•
Do not forcibly open and close covers and other
parts of the machine. Doing so may result in damage
to the machine.
•
During printing, do not turn OFF the main power,
open and close covers, or load and remove paper, in
order to prevent a paper jam.
•
Do not use this product for uses other than as a color
digital multitasking machine.
Transporting the machine
If you intend to move the machine over a long
distance, contac
t your local authorized Canon dealer
beforehand. Do not attempt to move the machine
yourself.
10
Page 11
Important Safety Instructions
Maintenance and Inspections
▀
Clean this machine regularly. The machine may not operate properly if dust accumulates. Make sure to read the
followings when cleaning the machine.
WARNING
•
When cleaning the machine, first turn OFF the main
power switch, then disconnect the power cord.
Failure to observe these steps may result in a fire or
electrical shock.
•
Clean the machine using a cloth which is wrung
after being damped in water. Do not use alcohol,
benzene, paint thinner, or other flammable
substances. Do not use tissue paper or paper towels.
If these substances come into contact with a highvoltage area inside the machine, it may result in a
fire, electrical shock, or generating of static electricity.
•
Disconnect the power cord from the power outlet
regularly, and clean the area around the base of
the power plug’s metal pins and the power outlet
with a dry cloth to ensure that all dust and grime is
CAUTION
•
If a paper jam occurs, follow the instructions
displayed on the touch panel display to remove any
jammed paper from inside the machine. Make sure
to remove any piece of paper inside the machine. Do
not insert your fingers into any parts not indicated
on the touch panel display, as doing so may result in
personal injury or burns.
removed. If the power cord is connected for a long
period of time in a damp, dusty, or smoky location,
dust can build up around the power plug and
become damp. This may cause a short circuit and
result in a fire.
•
Check the power cord and power plug regularly to
see if there are any excessive heat generation, rust,
deformation, scratches, or cracks. Using the power
cord and power plug under these conditions may
result in a fire or electrical shock.
•
When loading paper or removing jammed paper,
take care not to cut your hands or injure yourself on
the edges of the paper.
IMPORTANT
When removing jammed paper or replacing the toner
cartridge, take care not to allow the toner to come into
contact with your hands or clothing, as this will dirty
your hands or clothing. If toner gets onto your hands
or clothing, wash it off immediately with cold water.
Washing it off with warm water will set the toner, and
make it impossible to remove the toner stains.
11
Page 12
Consumables
▀
WARNING
•
If you accidentally spill or scatter toner, carefully
wipe up the loose toner with a damp, soft cloth and
avoid inhaling any toner dust. Do not use a vacuum
cleaner that is not equipped with safety measures
to prevent dust explosions to clean up loose toner.
Doing so may cause damage to the vacuum cleaner
or result in a dust explosion due to static discharge.
CAUTION
•
Be careful not to inhale toner. If toner is inhaled,
consult a physician immediately.
•
Be careful not to allow toner to get into your eyes
and mouth. If toner gets into your eyes or mouth,
wash them immediately with cold water and consult
a physician immediately.
•
Be careful not to allow toner to directly touch your
skin. If toner touches your skin, wash it away with
soap and water. If your skin still feels irritated after
washing it, consult a physician immediately.
•
Do not burn or throw toner cartridges in open
flames. Do not store toner cartridges in places
exposed to open flames.
•
Keep toner and other consumables out of the reach
of small children. If these items are ingested, consult
a physician immediately.
•
Do not dismantle the toner cartridge, as doing so
may cause toner to fly out.
IMPORTANT
When discarding used toner cartridges
Put the used toner cartridges into a bag to prevent the
emaining inside the cartridges from scattering,
toner r
and dispose of them in a location away from open
flames.
12
Page 13
Parts and Their Functions
This section provides you with the names and functions of all the parts of the machine. The keys and display on the
control panel are also described. Read this section to use the machine’s various functions smoothly.
"Optional Products" in the e-Manual
Front View
▀
123
5
1 USB Port (1)
Use to connect memory media to the machine via
USB.
2 Upright Control Panel-D1
Includes the keys, touch panel display, and
indicators required for operating the machine.
3 Main Power Switch
Press to the "|" side to turn ON the power.
4
4 Main Unit’s Right Cover
Open this cover when clearing a paper jam inside
the main unit.
5 Paper Drawer
Holds up to 550 sheets of paper (20 lb bond (80
2
g/m
)).
13
Page 14
Back View
▀
1
2
3
4
5
1 LAN Port
Use a LAN cable to connect the machine to a
network.
2 USB Port (2)
Use the USB port to connect external hard disks
and other devices to the machine.
3 USB Connector
Use a USB cable to connect the machine to a
computer.
4 Breaker
Detects excess current or leakage current.
5 Test Button
Press this button to test the circuit breaker.
14
Page 15
Internal View
▀
6
5
Parts and Their Functions
1
2
1 Toner Cartridge
This cartridge contains toner. Pull out this cartridge
when replacing it with a new one.
2 Front Cover
Open this cover to clear a paper jam in the
fixing transport unit.
3 Toner Replacement Cover
Open this cover to replace the toner cartridge.
4 Fixing Transport Unit
Pull the fixing transport unit out to clear a paper jam.
34
5 Waste Toner Container
Waste toner accumulates in this container. Pull out
this container when replacing it with a new one.
6 Left Cover on the Front Side
Open this cover to clear a paper jam or to replace
the waste toner container.
15
Page 16
Control Panel (Upright Control Panel-D1)
▀
12 34
19
18
17
1 Processing/Data Indicator
Blinks green when the machine is performing
operations, and maintains a steady green light
when received data is stored in memory.
2 Error Indicator
Blinks or lights if there is an error in the machine.
When the Error indicator blinks, follow the
instructions that appear on the touch panel display.
When the Error indicator maintains a steady red
light, contact your local authorized Canon dealer.
3 Settings/Registration key
Press to register and specify settings.
4 Energy Saver key
Press to set the Energy Saver mode or Sleep mode.
The mode activated after pressing the Energy
Saver key can be selected beforehand. This key
lights when the machine enters either mode. To
reactivate the machine, press this key again.
5
6
7
8
9
10111213141516
5 Counter Check key
Press to display the copy and print count totals.
6 Numeric keys
Press to enter numerical values.
7 Clear key
Press to clear entered values or characters.
8 Main Power Indicator
Lights when the main power is turned ON.
9 Edit Pen
Use when operating the touch panel display, such
as to enter characters.
10
Stop key
Press to stop a job in progress.
11
Start key
Press to start an operation, such as scanning or
copying.
16
Page 17
12
Reset key
Press to restore the standard settings of the
machine.
13
ID (Log In/Out) key
Press to log in/out when a login service such as
Department ID Management or SSO-H has been
set.
14
Touch Panel Display
The settings screen for each function is shown on
this display.
15
Brightness Adjustment Dial
Use to adjust the brightness of the touch panel
display.
16
Volume Settings key
Press to display the screen to specify the audible
tones for the fax function.
Parts and Their Functions
17
Status Monitor/Cancel key
Press to check the status of jobs or to cancel print
jobs. Also, press to check status of the machine,
such as checking the amount of paper remaining.
18
Quick Menu key
Press to retrieve favorite functions stored in Quick
Menu. Also, if you are using authentication, Quick
Menu set for each individual user can be displayed.
19
Main Menu key
Press to return to the Main Menu screen, such as
when you want to switch functions.
Setting the Energy Saver mode/Sleep mode to minimize energy consumption
You can save energy consumption by using the Energy Saver mode/Sleep mode when the machine is not
being used for a prolonged period of time, such as a lunch time. To use these modes, simply press
the control panel. If the machine is idle for a certain period of time, the machine will enter the Sleep mode
(Auto Sleep mode). For more information on the mode which activates after
information on the Auto Sleep mode, see the e-Manual.
"Basic Operations" > "Energy Saving Features" in the e-Manual
is pressed, and detailed
on
17
Page 18
Status Monitor/Cancel Screen
If you press , the Status Monitor/Cancel screen appears, and you can confirm the status of jobs and
consumables on this screen. By obtaining information, such as the completion time of the current job or the amount
of paper remaining, you can perform smooth printing operation without interruption.
Useful situations
•
When you want to know the completion time of jobs
•
When you want to check the amount of paper remaining for efficient paper loading
•
When you want to cancel a job which is registered by mistake
[Job] screen
The [Job] screen enables you to check the status of jobs in
the job list. On this screen, you can cancel a job in progress
and change the order of waiting jobs to print your job prior to
others.
[Paper] screen
You can check the paper information and the remaining
amount of paper in all paper sources. You can also specify the
paper type for each paper source in [Paper Settings].
[Toner/Other] screen
The remaining amount of toner is displayed in illustrations. You
can also check the remaining amount of staples, the amount of
punch waste, and the percentage of memory usage.
18
Page 19
How to Turn ON the Main Power
This section explains how to turn ON the main power.
Turning ON the Main Power
▀
Make sure that the power plug is firmly inserted into the power outlet, and the breaker is turned ON.
Open the main power switch cover.
1
Press the main power switch to the "|" side.
2
•
The main power indicator on the control panel lights.
IMPORTANT
If you want to turn ON the main power again, wait for at least 10 seconds after the main power and the main power
indicator are turned OFF. However, when [Quick Startup Settings for Main Power] is enabled, if you don’t wait more
than 20 seconds after the Main Power indicator is turned OFF, quick startup is not performed.
NOTE
The response of the keys and buttons may not be optimal immediately after turning ON the main power of the
machine.
Shutting Down the Machine
▀
Do not turn OFF the main power in the following situations
•
When using the I-Fax function
•
When the message <Backing up stored data from the Remote UI...> is displayed
•
When operating scan or print function
Open the main power switch cover.
1
Press the main power switch to the " " side.
2
•
The main power indicator on the control panel turns
OFF.
19
Page 20
Loading Paper
Load paper by following the procedure below. In this section, A4 custom size paper is used as an example.
Confirmation
Preparation
Operation
Registration
Confirm the paper types that can be loaded.
"Available Paper," on p. 20
Register all paper types you are going to use.
"Registering Paper Types in the Paper Database," on p. 22
Load paper in the paper drawer.
"Loading Paper into the Paper Drawer," on p. 23
Specify the loaded paper size and type for the paper drawer.
"Selecting Paper Types from the Paper Database," on p. 24
Available Paper
▀
This section describes the available paper for this machine. Paper that can be loaded differs, depending on the paper
sources. The following description includes the optional products as well as the standard paper drawers. The optional
products are indicated with
OPTION
icon.
OPTION
Stack Bypass-B1
POD Deck Lite-B1
OPTION
NOTE
Paper Drawer
Document Insertion Unit-M1
Multi-drawer Paper Deck-B1
OPTION
The optional Envelope Feeder Attachment is required to load envelopes, depending on the type of envelope.
"Basic Operations" > "Available Paper Stock" in the e-Manual
20
OPTION
Page 21
Loading Paper
Paper Drawer
Paper Capacity Upper, middle, and lower decks: 550 sheets (20 lb bond (80 g/m2)) each
Paper Type Thin 1 to 2, Plain 1 to 2, Heavy 1 to 4, Color, Recycled, Pre-Punched, Transparency, Clear Film, Tab, Bond,
Letterhead, Textured, Vellum, and Envelopes
Paper Size
Multi-drawer Paper Deck-B1
Paper Capacity Upper, middle, and lower decks: 2,000 sheets (20 lb bond (80 g/m2)) each
Paper Type Thin 1 to 2, Plain 1 to 2, Heavy 1 to 6, Color, Recycled, Pre-Punched, Transparency, Clear Film, Labels, Tab, Bond,
Paper Size
Document Insertion Unit-M1
Load paper you want to use as a cover of a booklet in the document insertion unit, such as coated paper.
Paper Capacity Upper and Lower trays: 200 sheets (20 lb bond (80 g/m2)) each
Paper Type Thin 1 to 2, Plain 1 to 2, Heavy 1 to 6, Color, Recycled, Pre-Punched, Tab, Bond, Letterhead, Coated, Textured, and
Paper Size
Stack Bypass-B1
Paper Capacity 100 sheets (20 lb bond (80 g/m2))
Paper Type Thin 1 to 2, Plain 1 to 2, Heavy 1 to 6, Color, Recycled, Pre-punched, Transparency, Clear Film, Labels, Tab, Bond,
Paper Size
POD Deck Lite-B1
Paper Capacity 3,500 sheets (20 lb bond (80 g/m2))
Paper Type Thin 1 to 2, Plain 1 to 2, Heavy 1 to 6, Color, Recycled, Pre-Punched, Transparency, Clear Film, Labels, Tab, Bond,
Paper Size
* For more information on paper that can be loaded, see "Specifications," on p. 36.
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom Size (4" x 5 7/8" to 13" x 19 1/4"
(100 mm x 148 mm to 330.2 mm x 487.7 mm)), and Envelopes
OPTION
Letterhead, Coated, Textured, and Vellum
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, and Custom Size (5 1/2" x 7 1/8" to 13"
x 19 1/4" (139.7 mm x 182 mm to 330.2 mm x 487.7 mm))
Vellum
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, and Custom Size (7 1/8" x 7 1/8" to 13" x 19
1/4" (182 mm x 182 mm to 330.2 mm x 487.7 mm))
OPTION
Letterhead, Coated, Textured, Vellum, and Envelopes
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom Size (4" x 5 7/8" to 13" x 19 1/4"
(100 mm x 148 mm to 330.2 mm x 487.7 mm)), and Envelopes
Letterhead, Coated, Textured, Vellum, and Envelopes
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom Size (5 1/2" x 5 7/8" to 13" x 19
1/4" (139.7 mm x 148 mm to 330.2 mm x 487.7 mm)), and Envelopes
OPTION
OPTION
21
Page 22
Registering Paper Types in the Paper Database
▀
Register all paper types you are going to use with this machine. You can register paper types by selecting paper types
from the Paper Database.
NOTE
If you load paper which is already registered in the machine, such as plain or recycled paper, this step is not necessary.
Proceed to the next step "Loading Paper into the Paper Drawer".
Press (Settings/Registration).
1
Press [Preferences] [Paper Settings] [Paper Type Management Settings].
2
Press [Paper Database].
3
Select the paper type from the list press [OK].
4
Confirm that the selected paper type is displayed in
5
the <Paper Type Management Settings> screen
press [OK].
•
If the desired paper type is not listed in the Paper Database,
select and duplicate a paper type that closely matches the
characteristics of the desired paper type, and then change
the necessary settings.
"Paper Type Management" in the e-Manual
22
Page 23
Loading Paper into the Paper Drawer
▀
Open the paper drawer.
1
•
Gently pull out the paper drawer until it stops.
Adjust the position of the paper drawer guides.
2
•
Slide each guide while squeezing it on the top to align for the
desired paper size.
Load the paper stack into the paper drawer.
3
1
Load the paper stack against the right wall of the paper drawer.
2
Gently push the paper drawer back into the machine until it clicks
into place in the closed position.
Loading Paper
NOTE
•
Make sure to fan the paper stack, and align the edges before loading paper.
•
Curled paper must be straightened out prior to use.
•
Make sure that the height of the paper stack does not exceed the loading limit mark (
•
When loading pre-punched paper, transparencies/clear film, tab paper, and envelopes, make sure to load paper in
an appropriate orientation as the paper orientation differs, depending on the paper source.
"Maintenance" > "Loading Paper" in the e-Manual
).
23
Page 24
Selecting Paper Types from the Paper Database
▀
Select the loaded paper type from the Paper Database.
Press (Settings/Registration).
1
Press [Preferences] [Paper Settings] [Paper Settings].
2
Select the paper source in which you loaded paper
3
press [Set].
•
If you load paper other than standard paper, select [Custom
Size] or [Envelope].
Select the loaded paper type from the list press
4
[OK].
24
Confirm that the selected paper type is displayed in
5
<Details of Selected Paper> press [OK].
Page 25
Cleaning and Maintenance
For optimum operation of the machine, we recommend to clean and check the machine regularly.
Cleaning the Platen Glass
▀
If originals cannot be scanned properly, follow the cleaning procedure below. Clean with a cloth which is wrung after
being dampened in water, and then clean with a soft and dry cloth. Use the provided glass cleaning cloth for simple
cleaning.
Clean the Platen Glass.
1
•
Clean the platen glass and the underside of the feeder.
Cleaning the Original Scanning Area
▀
If originals which are fed from the feeder cannot be scanned properly, follow the procedure below.
Press (Settings/Registration).
1
Press [Adjustment/Maintenance] [Maintenance] [Original Scanning Area Cleaning
2
Method].
Follow the cleaning instructions on the touch panel display.
3
25
Page 26
Cleaning the Feeder
▀
If originals which are fed from the feeder become dirty, follow the cleaning procedure below. Clean with a cloth which
is wrung after being dampened in water, and then clean with a soft and dry cloth. Use the provided glass cleaning
cloth for simple cleaning.
Clean the original scanning area.
1
•
Open the feeder and clean the original scanning area (thin glass
strip).
Open the covers.
2
1
Pull the lever above the feeder, and open the cover.
1
2
2
Open the inside cover.
Clean the original scanning area of the feeder.
3
Close the covers.
4
1
Close the inside cover.
1
2
2
Close the cover.
26
Page 27
Automatic Feeder Cleaning
▀
If originals which are fed from the feeder become dirty, follow the procedure below.
Place 10 sheets of blank paper into the feeder.
1
•
Use LTR plain paper.
Press (Settings/Registration).
2
Press [Adjustment/Maintenance] [Maintenance] [Clean Feeder].
3
Press [Start].
4
Cleaning and Maintenance
Cleaning the Inside of the Main Unit
▀
If output paper becomes dirty, follow the procedure below.
Press (Settings/Registration).
1
Press [Adjustment/Maintenance] [Maintenance] [Clean Inside Main Unit].
2
Press [Start].
3
NOTE
•
Similarly perform [Adjustment/Maintenance] [Maintenance] [Clean Wire] and [Adjustment/Maintenance]
[Maintenance] [Clean Roller].
•
Paper may be cleaned by performing [Adjustment/Maintenance] [Maintenance] [Clean Belt]. After loading
three or more sheets of plain paper into the upper paper drawer of the main unit, perform the above procedure.
27
Page 28
Refreshing the Fixing Belt
▀
If streaks appear on the output paper, or gloss unevenness occurs in the high density area of the printed heavy paper,
follow the procedure below.
Press (Settings/Registration).
1
Press [Adjustment/Maintenance] [Maintenance] [Refresh Fixing Belt].
2
Press [Start].
3
NOTE
The fixing belt is refreshed automatically every several sheets of paper is printed. You can adjust the refresh frequency
and time in [Fixing Roller Auto Refresh Level].
Cleaning the Touch Panel Display
▀
Wipe the touch panel display with a cloth dampened in water
or a mild cleaning agent, and then wipe with a soft, dry cloth.
28
Page 29
Cleaning and Maintenance
Inspection of the Breaker
▀
This machine has a breaker that detects excess current or leakage current. Make sure to test the breaker once a month
by following the procedure below.
Turn OFF the main power.
1
•
Make sure that the main power is turned OFF, before inspecting
the breaker.
Push the test button located on the rear of the machine.
2
•
Push the test button with the tip of a ball-point pen or a similar
object. Briefly push the test button.
Confirm that the breaker lever is switched to the OFF
3
position.
•
If the breaker lever is not switched to the OFF position, repeat
step 2. If the breaker lever is not switched to the OFF position,
despite carrying out the above procedure two or three times,
contact your local authorized Canon dealer.
Switch the breaker lever to ON.
4
Turn ON the main power.
5
29
Page 30
Consumables
The following consumables are available for this machine. For more information, contact your local authorized Canon
dealer. For information on using and storing consumables, see "Consumables," on p. 12.
Recommended Paper
In addition to plain paper, other types of paper stock are available, such as recycled paper, color paper, transparencies/
clear film (recommended for this machine), vellums, and labels. For high-quality printouts, use paper recommended by
Canon.
Toner
If a message prompting you to replace the toner cartridge appears on the touch panel display, replace the used toner
cartridge with a new one. For information on how to replace the toner cartridge, see the e-Manual. For optimum print
quality, using Canon genuine toner is recommended.
"Maintenance" > "Replacing the Toner Cartridge" in the e-Manual
Supported Canon Genuine Toner
Canon imagePRESS Toner T01 Black
Canon imagePRESS Toner T01 Cyan
Canon imagePRESS Toner T01 Magenta
Canon imagePRESS Toner T01 Yellow
Black Toner Cartridge Cyan, Magenta, or Yellow Toner Cartridge
Be careful of counterfeit toners
Please be aware that there are counterfeit Canon toners in the marketplace. Use of counterfeit toner may
result in poor print quality or machine performance. Canon is not responsible for any malfunction, accident
or damage caused by the use of counterfeit toner. For more information, see canon.com/counterfeit.
Waste Toner Container
The waste toner is accumulated in the waste toner container, and when the container is nearly full, a message
prompting you to replace the container appears on the touch panel display. For information on how to replace the
waste toner container, see the e-Manual. Your local authorized Canon dealer will dispose of the used waste toner
container.
"Maintenance" > "Replacing the Waste Toner Container" in the e-Manual
30
Page 31
Staple Cartridge for the Stapler Unit
The Staple-N1/Staple-J1 can be attached to the Finisher-AM1/
Saddle Finisher-AM2/Staple Finisher-T1/Booklet Finisher-T1 for
stapling. For information on how to replace the staple cartridge,
see the e-Manual.
"Maintenance" > "Replacing the Staple Cartridge (For
Optional Products)" > "Replacing the Staple Cartridge in the
Stapler Unit (Finisher-AM1/Saddle Finisher-AM2)", "Replacing
the Staple Cartridge in the Stapler Unit (Staple Finisher-T1/
Booklet Finisher-T1)" in the e-Manual.
Staple Cartridge for the Saddle Stitcher Unit
The Staple-P1/Staple Cartridge-D2/Staple Cartridge-D3 can be
attached to the Saddle Finisher-AM2/Booklet Finisher-T1 for
saddle stitching. For information on how to replace the staple
cartridge, see the e-Manual.
"Maintenance" > "Replacing the Staple Cartridge (For
Optional Products)" > "Replacing the Staple Cartridge in the
Saddle Stitcher Unit (Saddle Finisher-AM2)", "Replacing the
Staple Case in the Saddle Stitcher Unit (Booklet Finisher-T1)"
in the e-Manual.
Staple-N1
Staple-P1
Consumables
Staple-J1
Staple Cartridge-D2
Staple Cartridge-D3
Genuine Supplies
Canon has developed and manufactured Toner, Parts, and Supplies specifically for use in this machine.
For optimal print quality and for optimal machine performance and productivity, we recommend that you use
Genuine Canon Toner, Parts, and Supplies.
Contact your Canon Authorized Dealer or Service Provider for Genuine Canon Supplies.
31
Page 32
Troubleshooting
This section explains how to solve problems when paper jam occurs frequently or error messages are displayed. For
information on the detailed procedures and precautions, see the e-Manual.
"Problem Solving" in the e-Manual
Clearing Paper Jams and Staple Jams
▀
If a paper jam or staple jam occurs, follow the instructions displayed on the touch panel display to clear the jam. If you
press [Close], you can continue operations, such as scanning originals, even if the jammed paper is not removed.
Paper Jam screen
The location of a paper jam is displayed with
animations.
Reducing the Frequency of Paper Jams
▀
If paper jams occur frequently, the following reasons may be the cause.
Staple Jam screen
The location of a staple jam and procedures for
clearing the jam are displayed.
There are torn pieces of paper left inside the machine.
As a result of pulling jammed paper out by force, torn pieces of paper may be left inside the machine.
Remove all of the torn pieces.
Paper which does not match with the setting is loaded.
Make sure that the paper loaded in the paper drawer matches the paper size and type registered in [Paper
Settings] in [Preferences].
"Selecting Paper Types from the Paper Database," on p. 24
Paper jams occur frequently only when using the specific custom paper.
The paper information may be registered incorrectly.
Confirm the paper information settings for the paper you are using.
"Paper Type Management" in the e-Manual
32
Page 33
When an Error Message Is Displayed
▀
If a malfunction occurs and the machine cannot operate
normally, a screen shown on the right appears. If the machine
cannot operate normally after turning the main power OFF
and then ON, contact your local authorized Canon dealer.
"Contacting Your Local Authorized Canon Dealer," on p. 34
If a key for the Limited Functions mode is
displayed:
If [Limited Functions Mode] is displayed, you can temporally
set the Limited Functions mode to continue to use some
functions.
"Problem Solving" > "Service Call Message" in the e-Manual
Troubleshooting
If a message is displayed on the bottom of the
screen:
If an error message appears on the bottom of the screen,
printing and scanning functions are restricted, but some
functions may still be available.
"Problem Solving" > "Service Call Message" in the e-Manual
33
Page 34
Contacting Your Local Authorized Canon Dealer
▀
If you cannot operate the machine normally after turning the main power OFF and then ON, contact your local
authorized Canon dealer by following the procedure below.
Note the error code.
1
•
Write down the error code "EXXXXX-XXXX".
Turn OFF the main power.
2
•
Press the main power switch to the "
" side.
Remove the power plug from the power outlet.
3
Confirm the product name, and contact your local authorized Canon dealer.
4
34
Page 35
Troubleshooting
If Memory Becomes Full
▀
If memory becomes full during scanning, the following messages appear on the touch panel display. Follow the
procedures on the screen, and then delete unnecessary files stored in the Mail Box and Fax/I-Fax Inbox to make more
memory available.
Scanning will be canceled because the memory is full. Do you want to print (send, store)* the scanned pages?
* A part of the message differs, depending on the function used.
[Yes]: A job for the pages scanned into memory is processed. After processing the job, scan the remaining pages.
[No]: A job for the pages scanned into memory is canceled. Scan the whole pages again.
Scanning will be canceled because the memory is full. Wait a moment, then try again.
[OK]: Scan the whole pages again after the current operation is complete.
Could not perform the operation because the memory is full.
[OK]: Delete unnecessary data from memory, and then scan the whole pages again.
If the Main Power Does Not Turn ON
▀
If the machine cannot operate when the main power is turned
ON, check the breaker. If the breaker is switched to the OFF
position, do not attempt to turn ON the breaker yourself, and
be sure to contact your local authorized Canon dealer.
35
Page 36
Specifications
Specifications are subject to change without notice for product improvement or future release.
For more information on the specifications of the following optional equipment, consult the relevant guide.
•
High Capacity Stacker-G1
•
Booklet Trimmer-D1
•
Two-Knife Booklet Trimmer-A1
•
Perfect Binder-D1
•
Professional Puncher-B1
Main Unit
▀
Item Specifications
Name Canon imagePRESS C800/C700/C60
Type Reader
Color Supported Full Color
Resolution for Writing 2,400 dpi x 2,400 dpi
Paper Weight/Type Paper Drawer 1, 2, 3:
Paper Sizes Paper Drawer 1, 2, 3:
Warm-Up Time After powering ON
-Printer Separated, Console type
Weight:
14 lb bond to 80 lb cover (52 g/m
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb
bond (64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)),
Plain 2 (25 lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy 1 (29 lb bond to 34
lb bond (106 g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150
g/m2)), Heavy 3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover
to 80 lb cover (181 g/m2 to 220 g/m2)), Color, Recycled, Pre-Punched, Transparency,
Clear Film, Tab, Bond, Letterhead, Textured *1 , Vellum, and Envelopes
* The printing conditions may vary, depending on the paper type. For more information on paper types, see
e-Manual > Basic Operations.
*1 Textured paper that is 221 g/m2 or more in weight cannot be used.
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom
Size (4" x 5 7/8" to 13" x 19 1/4" (100 mm x 148 mm to 330.2 mm x 487.7 mm)), and
Envelopes*1*
*1 The following envelope types can be used:
Standard Paper Size : Nagagata 3, Yougatanaga 3, Kakugata 2, No. 10(COM10), ISO-C5, DL, and Monarch
Custom Paper Size : 6" x 9", 9" x 12", and 10" x 13"
2
The following envelope types can be used without the Envelope Feeder Attachment-F1.
*
Kakugata 2, ISO-C5, 9" x 12", and 10" x 13"
6 minutes
If [Quick Startup Settings for Main Power] is set to 'On', it takes 7 seconds until the key
operation on the touch panel display is available after turning ON the main power of the
machine. Depending on the situations, the machine does not startup quickly.
Returning from the Sleep mode
6 minutes
* At a room temperature of 68°F in all above cases.
* Activation time may vary, depending on the environment and conditions under which the machine is being used.
2
Envelopes whose size is between 4" x 5 7/8" to 13" x 19 1/4" (100 mm x 148 mm to 330.2 mm
x 487.7 mm) can also be fed, however, image may not be printed correctly on the envelops.
2
to 220 g/m2)
36
Page 37
Item Specifications
First Copy Time Full color
imagePRESS C800/C700/C60: 7.7 seconds*
Black-and-White:
imagePRESS C800/C700/C60: 6.9 seconds*
*1 When "Color Priority" is selected.
2
*
When "Black & White Priority" is selected.
Copy Speed* Direct (sheets/minute)
<Full Color>
13" x 19" 38 33 30
12 5/8" x 17 3/4" 40 35 32
12" x 18" 40 35 32
11" x 17" 40 35 32
LGL 46 4 1 36
LTR 80 70 60
LTRR 66 58 52
STMTR 80 70 60
<Black-and-White>
13" x 19" 38 33 30
12 5/8" x 17 3/4" 40 35 32
12" x 18" 40 35 32
11" x 17" 40 35 32
LGL 46 4 1 36
LTR 80 70 60
LTRR 66 58 52
STMTR 80 70 60
The copy speed may vary, depending on the settings for paper type, paper size, and the
sending method.
When continuously copying, adjustments for machine temperature or image quality may
cause machine operations to pause or become slow.
* Except when paper is fed from the Stack Bypass-B1.
Margin Top: 1/8" (4.0 mm)
Left and Right: 1/8" (2.5 mm)
Bottom: 1/8" (4.0 mm)
Specifications
1
2
imagePRESS C800 imagePRESS C700 imagePRESS C60
37
Page 38
Item Specifications
Paper Feeding System/Capacity Paper Drawer 1, 2, 3:
2
550 sheets x 3 cassettes (20 lb bond (80 g/m
))
Multiple Copies 1 to 9,999 sheets
Power Source 208 V AC, 60 Hz, 20 A
Power Consumption Maximum Power Consumption:
3,520 W or less
Power Consumption:
When in the Sleep mode:
1 Wh
When the main power switch is turned OFF:
[Quick Startup Settings for Main Power] is set to 'OFF' : 0.5 Wh
[Quick Startup Settings for Main Power] is set to 'ON' : 1.0 Wh
* The power consumption may vary, depending on the environment and conditions under which the machine is
being used.
Memory Capacity Standard: 3.5 GB (1.5+2 GB)
Hard Disk Capacity Standard: 1 TB (Used space: 1 TB)
* The hard disk capacity is subject to change in future release.
Dimensions (H x W x D) 56 1/8" *1 x 60 1/4" *2 x 36 3/4" (1,424 mm x 1,530 mm x 934 mm)
(when the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached.)
1
To the top of the Upright Control Panel-D1 in the standard position.
*
2
To the right edge of the Upright Control Panel-D1 in the standard position.
*
Weight (Including the toner bottle, the
Approximately 697 lb (316 kg)
Duplex Color Image Reader Unit-H1 and the
Upright Control Panel-D1)
Installation Space (W x D) 76 7/8" x 36 3/4" (1,952 mm x 934 mm)
(when the Output Tray-A1, the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached)
Duplex Color Image Reader Unit-H1
▀
Item Specifications
Type Printer separated, Stream feed (Feeder), No stream (Reader)
Resolution for Reading 600 dpi x 600 dpi
Number of Tones 256
Acceptable Originals Sheet, book, three dimensional object (up to 4.4 lb (2kg))
Size and Weight of Originals Size:
11" x 17", LGL, LTR, LTRR, STMT, and STMTR
Weight:
1-sided scanning:
2
13 lb bond to 80 lb cover (50 g/m
to 220 g/m2)
2-sided scanning:
13 lb bond to 80 lb cover (50 g/m2 to 220 g/m2) (Black and White Original)
17 lb bond to 80 lb cover (64 g/m2 to 220 g/m2) (Color Original)
38
Page 39
Item Specifications
Magnification Regular paper size:
Same Ratio:
ect
Dir
Reduction:
1 : 0.78 (LGL LTR)
1 : 0.73 (11" x 17" LGL, 11" x 15" LTR)
1 : 0.64 (11" x 17" LTR)
1 : 0.50 (11" x 17"STMT)
1 : 0.25
Enlargement:
1 : 1.21 (LGL 11" x 17")
1 : 1.29 (LTR 11" x 17")
1 : 2.00 (STMT 11" x 17")
1 : 4.00
Copy Ratio:
25% to 400% (in 1% increments)
Original Feeding Mechanism Automatic Document Feeder
2
Original Tray Capacity 300 sheets (20 lb bond (80 g/m
Original Scanning Speed Copying:
1-sided scanning:
120 sheets/minute*
70 sheets/minute (LTR in Full Color at 600 dpi)
2-sided scanning:
60 sheets/minute (120 pages)*1 (LTR in Black-and-White at 600 dpi)
35 sheets/minute (70 pages) (LTR in Full Color at 600 dpi)
Scanning:
1-sided scanning:
120 sheets/minute (LTR in Black-and-White/Full Color at 300 dpi)
2-sided scanning:
100 sheets/minute (200 pages)*1 (LTR in Black-and-White at 300 dpi)
70 sheets/minute (140 pages) (LTR in Full Color at 300 dpi)
*1 When "Speed Priority" is selected.
* The scanning speed may vary, depending on the scanning mode and original type.
Power Source From the main unit
Dimensions (H x W x D) 7 1/8" x 24 7/8" x 23 3/4" (179 mm x 633 mm x 603 mm) (feeder and reader)
Weight Approximately 59.3 lb (26.9 kg) (feeder and reader)
))
1
(LTR in Black-and-White at 600 dpi)
Specifications
39
Page 40
POD Deck Lite-B1
▀
Item Specifications
Paper Size / Weight / Type Size:
13" x 19", 12 5/8" x 17 11/16"
(5 1/2" x 5 7/8" to 13" x 19 1/4" (139.7 mm x 148 mm to 330.2 mm x 487.7 mm))*1, and
Envelopes*2*
*1 Custom paper sizes which are smaller than 5 1/2" x 7 1/8" (139.7 mm x 182 mm) can be used only if they are
standard paper sizes.
*2 The following envelope types can be used:
Standard Paper Size : Nagagata 3, Yougatanaga 3, Kakugata 2, No. 10(COM10), ISO-C5, DL, and Monarch
Custom Paper Size : 6" x 9", 9" x 12", and 10" x 13"
3
10" x 13" can be used without the Envelope Feeder Attachment-G1
*
Weight:
14 lb bond to 110 lb cover (52 g/m2 to 300 g/m2)
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2
(25 lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond
(106 g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)),
Heavy 3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80
lb cover (181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256
g/m2)), Heavy 6 (140 lb index to 110 lb cover (257 g/m2 to 300 g/m2)), Color, Recycled,
Pre-Punched, Transparency, Clear Film, Labels, Tab, Bond, Letterhead, Coated, Textured,
Vellum, and Envelopes
Paper Deck Capacity 3,500 sheets (20 lb bond (80 g/m
Power Source / Maximum Power
Consumption
Dimensions (H x W x D)
* 168 lb (76 kg)
Weight
Installation Space Including the Main Unit
*
(W x D)
* I ncluding the POD Deck Lite Attachment Kit-A1.
* 22 3/8" x 28 1/4" x 22 1/2" (568 mm x 717 mm x 572 mm)
120-127 V AC, 60 Hz, 2.2 A/480 W or less
80 5/8" x 36 3/4" (2,049 mm x 934 mm)
(When the Output Tray-A1, the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached)
3
, 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom Size
2
))
Multi-drawer Paper Deck-B1
▀
Item Specifications
Paper Size / Weight / Type Size:
40
13" x 19", 12 5/8" x 17 11/16"
Size (5 1/2" x 7 1/8" to 13" x 19 1/4" (139.7 mm x 182 mm to 330.2 mm x 487.7 mm))
Weight:
14 lb bond to 110 lb cover (52 g/m2 to 300 g/m2)
, 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, and Custom
Page 41
Item Specifications
Paper Size / Weight / Type Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2
(25 lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond
(106 g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)),
Heavy 3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80
lb cover (181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256
g/m2)), Heavy 6 (140 lb index to 110 lb cover (257 g/m2 to 300 g/m2)), Color, Recycled,
Pre-Punched, Transparency, Clear Film, Labels, Tab, Bond, Letterhead, Coated, Textured,
and Vellum
Paper Deck Capacity 2,000 sheets x 3 paper decks (20 lb bond (80 g/m
Power Source/Maximum Power
Consumption
Dimensions (H x W x D) 41" x 37 3/8" x 31 3/8" (1,040 mm x 950 mm x 797 mm)
Weight Approximately 342 lb (155 kg)
Installation Space Including the Main Unit
(W x D)
120-127 V AC, 60 Hz, 3.1 A/880 W or less
89 7/8" x 36 3/4" (2,282 mm x 934 mm)
(when the Output Tray-A1, the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached)
2
to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
2
))
Specifications
Stack Bypass-B1
▀
Item Specifications
Paper Size / Weight / Type Size:
13" x 19", 12 5/8" x 17 11/16"
Size (4" x 5 7/8" to 13" x 19 1/4" (100 mm x 148 mm to 330.2 mm x 487.7 mm)), and
Envelopes*
* The following envelope types can be used:
Standard Paper Size: Nagagata 3, Yougatanaga 3, Kakugata 2, No. 10(COM10), ISO-C5, DL, and Monarch
Custom Paper Size: 6" x 9", 9" x 12", and 10" x 13"
Weight:
14 lb bond to 110 lb cover (52 g/m2 to 300 g/m2)
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2
(25 lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond
(106 g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)),
Heavy 3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80
lb cover (181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256
g/m2)), Heavy 6 (140 lb index to 110 lb cover (257 g/m2 to 300 g/m2)), Color, Recycled,
Pre-punched, Transparency, Clear Film, Labels, Tab, Bond, Letterhead, Coated, Textured,
Vellum, and Envelopes
Paper Capacity 100 sheets (20 lb bond (80 g/m
, 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom
2
to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
2
))
41
Page 42
Stack Bypass Alignment Tray-C1
▀
Item Specifications
Paper Size / Weight / Type See "Specifications" of the "Stack Bypass-B1," on p. 41.
Paper Capacit
Weight 2.4 lb (1.1 kg)
▀
Item Specifications
Paper Size LTR/A4
Paper Capacit
Weight 0.2 lb (0.1 kg)
▀
Item Specifications
Acceptable Envelopes Standard Paper Size:
Loading Limit (Height) 50 sheets
Weight 0.1 lb (30 g)
y See "Specifications" of the "Stack Bypass-B1," on p. 41.
If the basis weight of the paper is below 156 g/m
parallel to the feeding direction is shorter than A4R or LTRR, the amount of skew correction
applied to the paper will not change even if the Stack Bypass Alignment Tray-C1 is attached.
Tab Feeding Attachment-F1
y 2 3/8" (60 mm) in height (or 300 to 400 sheets)
Envelope Feeder Attachment-F1
Nagagata 3, Y
Custom Paper Size:
6" x 9"
ougatanaga 3, No. 10(COM10), DL, and Monarch
2
(42 lb bond), or the side of the paper
Envelope Feeder Attachment-G1
▀
Item Specifications
Acceptable Envelopes Standard Paper Size:
Nagagata 3, Y
Custom Paper Size:
6" x 9" and 9" x 12"
Loading Limit (Height) Nagagata 3*
Yougatanaga 3, Kakugata 2*2, 6" x 9", 9" x 12", No. 10(COM10), ISO-C5, and DL
Monarch
*1 Up to 4" (100 mm) when you are using a side seam envelope.
2
Up to 1 3/4" (45 mm) when you are using a side seam envelope.
*
Weight Approximately 3.3 lb (1.5 kg)
1
6 3/8" (160 mm)
4" (100 mm)
2 3/4" (70 mm)
42
ougatanaga 3, Kakugata 2, No. 10(COM10), ISO-C5, DL, and Monarch
Page 43
Document Insertion Unit-M1
▀
Item Specifications
Paper Size/Weight/Type Size:
13" x 19", 12 5/8" x 17 11/16"
1/8" x 7 1/8" to 13" x 19 1/4" (182 mm x 182 mm to 330.2 mm x 487.7 mm))
Weight:
14 lb bond to 110 lb cover (52 g/m2 to 300 g/m2)
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2 (25
lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond (106
g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)), Heavy
3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80 lb cover
(181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256 g/m2)),
Heavy 6 (140 lb index to 110 lb cover (257 g/m2 to 300 g/m2)), Color, Recycled, Pre-
Punched, Tab, Bond, Letterhead, Coated, Textured, and Vellum
Paper Capacity Upper/Lower Tray: 200 sheets (20 lb bond (80 g/m
Power Source/Maximum Power
Consumption
Dimensions (H x W x D) 55 3/8" x 29 3/8" x 31 1/4" (1,407 mm x 746 mm x 793 mm)
Weight Approximately 134 lb (61 kg)
Installation Space Including the Main Unit
(W x D)
100-240 V AC, 50/60 Hz, 1.0 A/120 W or less
105 3/8" x 36 3/4" (2,676 mm x 934 mm)
(when the Duplex Color Image Reader Unit-H1, the Upright Control Panel-D1, and the Finisher-AM1 (or the Saddle
Finisher-AM2) are attached)
, 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, and Custom Size (7
2
)) x 2
Specifications
Paper Folding Unit-F1
▀
Item Specifications
Paper Size / Weight / Type Size:
old:
Z-F
LTRR, LGL, and 11" x 17"
C-Fold:
LTRR
Accordion Z-Fold:
LTRR
Double Parallel Fold:
LTRR and LGL
Half Fold:
LTRR
43
Page 44
Item Specifications
Paper Size / Weight / Type Weight:
old:
Z-F
14 lb bond to 28 lb bond (52 g/m2 to 105 g/m2)
C-Fold:
14 lb bond to 28 lb bond (52 g/m2 to 105 g/m2)
Accordion Z-Fold:
14 lb bond to 28 lb bond (52 g/m2 to 105 g/m2)
Double Parallel Fold:
14 lb bond to 24 lb bond (52 g/m2 to 90 g/m2)
Half Fold:
14 lb bond to 28 lb bond (52 g/m2 to 105 g/m2)
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2 (25
lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Color, Recycled, and Coated
Power Source/Maximum Power
Consumption
Dimensions (H x W x D) 46 7/8" x 13 1/4" x 31 1/4" (1,190 mm x 336 mm x 793 mm)
Weight Approximately 157 lb (71 kg)
Installation Space Including the Main Unit
(W x D)
From the finisher/150 W or less
105 3/8" x 36 3/4" (2,676 mm x 934 mm)
(when the Duplex Color Image Reader Unit-H1, the Upright Control Panel-D1, the Finisher-AM1 (or the Saddle
Finisher-AM2) are attached)
Output Tray-A1
▀
Item Specifications
Paper Size/Weight/Type Size:
13" x 19", 12 5/8" x 17 11/16"
(4" x 5 7/8" to 13" x 19 1/4" (100 mm x 148 mm to 330.2 mm x 487.7 mm)), and Envelopes
Weight:
14 lb bond to 110 lb cover (52 g/m2 to 300 g/m2)
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2
(25 lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond
(106 g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)),
Heavy 3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80
lb cover (181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256
g/m2)), Heavy 6 (140 lb index to 110 lb cover (257 g/m2 to 300 g/m2)), Color, Recycled,
Pre-Punched, Transparency, Clear Film, Labels, Tab, Bond, Letterhead, Coated, Textured,
Vellum, and Envelopes
Paper Capacity 1-side : 250 sheets (20 lb bond (80 g/m
2-side : 250 sheets (20 lb bond (80 g/m2))
Dimensions (H x W x D) 6 7/8" x 16 5/8" x 15" (175 mm x 422 mm x 382 mm)
, 12" x 18" , 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom Size
2
))
44
Page 45
Item Specifications
Weight Approximately 2.6 lb (1.2 kg)
Installation Space I
Main Unit (W x D)
Finisher-AM1
▀
Item Specifications
Paper Size/Weight/Type Size:
Capacity Per Tray*
ncluding the
1
76 7/8" x 36 3/4" (1,952 mm x 934 mm)
(when the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached)
13" x 19", 12 5/8" x 17 11/16"
(4" x 5 7/8" to 13" x 19 1/4" (100 mm x 148 mm to 330.2 mm x 487.7 mm)), and Envelopes
Weight:
14 lb bond to 110 lb cover (52 g/m2 to 300 g/m2)
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2
(25 lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond
(106 g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)),
Heavy 3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80
lb cover (181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256
g/m2)), Heavy 6 (140 lb index to 110 lb cover (257 g/m2 to 300 g/m2)), Color, Recycled,
Pre-Punched, Transparency, Clear Film, Labels, Tab, Bond, Letterhead, Coated, Textured,
Vellum, and Envelopes
No Collating/Collate/Group mode
Tray A:
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, and STMTR:
1,000 sheets (or 5 3/4" (147 mm) in height)
Tray B:
If the High Volume Stack Mode is set to 'Off':
LTR and EXEC:
2,000 sheets (or 11 1/4" (285 mm) in height)
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, and LTRR:
1,000 sheets (or 5 3/4" (147 mm) in height)
If the High Volume Stack Mode is set to 'On':
(The maximum stack volume may vary, depending on the paper type.)
LTR and EXEC:
4,000 sheets (or 19 1/4" (490 mm) in height)
LTRR:
2,000 sheets (or 11 1/4" (285 mm) in height)
11" x 17" and LGL:
1,500 sheets (or 8 1/2" (216 mm) in height)
13" x 19", 12 5/8" x 17 11/16", and 12" x 18":
1,000 sheets (or 5 3/4" (147 mm) in height)
Specifications
, 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom Size
45
Page 46
Item Specifications
Capacity Per Tray*
Max. Stapling Capacity/Available Staple Size When the standard staple cartridge is attached
1
Staple mode
Tray B:
LTR, and EXEC:
3,000 sheets/200 sets (or 16 5/8" (423 mm) in height)
LTRR:
2,000 sheets/200 sets (or 11 1/4" (285 mm) in height)
11" x 17" and LGL:
1,500 sheets/200 sets (or 8 1/2" (216 mm) in height)
No Collating/Collate/Group mode with different paper sizes
Tray A:
1,000 sheets (or 5 3/4" (147 mm) in height)
Tray B*2:
If the High Volume Stack Mode is set to 'Off':
LTR and EXEC:
2,000 sheets (or 11 1/4" (285 mm) in height)
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, and LTRR:
1,000 sheets (or 5 3/4" (147 mm) in height)
If the High Volume Stack Mode is set to 'On':
(The maximum stack volume may vary, depending on the paper type.)
LTR and EXEC:
4,000 sheets (or 19 1/4" (490 mm) in height)
LTRR:
2,000 sheets (or 11 1/4" (285 mm) in height)
11" x 17" and LGL:
1,500 sheets (or 8 1/2" (216 mm) in height)
13" x 19", 12 5/8" x 17 11/16", and 12" x 18":
1,000 sheets (or 5 3/4" (147 mm) in height)
Z-Fold mode (when the Paper Folding Unit-F1 is attached.)
Tray A, Tray B: 30 sheets or 10 sheets/1 set
Half Fold (when the Paper Folding Unit-F1 is attached.)
Tray A, Tray B: 50 sheets
*1 To stack 2,000 sheets or more LTR paper, use Tray B first, and then use Tray A for outputting paper.
2
If the capacity values of the different paper sizes are different, the smallest value is applied to the Tray B capacity.
*
(The maximum stapling capacity may vary, depending on the paper type and weight.)
LTR and EXEC:
100 sheets (20 lb bond (80 g/m2)) or below 1/2" (11 mm) in height, 98 sheets (20 lb bond
(80 g/m2)) + 2 sheets (140 lb index (256 g/m2))
11" x 17", LGL, and LTRR:
50 sheets (20 lb bond (80 g/m2)) or below 1/4" (5.5 mm) in height, 48 sheets (20 lb bond
(80 g/m2)) + 2 sheets (140 lb index (256 g/m2))
Corner Stapling:
11" x 17", LGL, LTR, LTRR, EXEC, and Custom Size (8 1/4" x 7 1/8" to 11 3/4" x 17" (210 mm x
182 mm to 297 mm x 432 mm))
Double Stapling:
11" x 17", LGL, LTR, LTRR, EXEC, and Custom Size (7 1/8" x 7 1/8" to 11 3/4" x 17" (182 mm x
182 mm to 297 mm x 432 mm))
46
Page 47
Item Specifications
Power Source/Maximum Power
Consumption
Dimensions (H x W x D) 48 3/4" x 31 1/2" x 31 1/4" (1,239 mm x 800 mm x 792 mm)
Weight Approximately 287 lb (130 kg)
Installation Space Including the Main Unit
(W x D)
Staple Finisher-T1
▀
Item Specifications
Paper Size/Weight/Type Size:
Capacity Per Tray No Collating mode
V AC, 50/60 Hz, 8 A/500 W or less
120-240
92" x 36 3/4" (2,335 mm x 934 mm)
(when the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached)
13" x 19", 12 5/8" x 17 11/16"
(4" x 5 7/8" to 13" x 19 1/4" (100 mm x 148 mm to 330.2 mm x 487.7 mm)), and Envelopes
Weight:
Tray A:
14 lb bond to 140 lb index (52 g/m2 to 256 g/m2)
Tray B, Tray C:
14 lb bond to 110 lb cover (52 g/m2 to 300 g/m2)
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2
(25 lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond
(106 g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)),
Heavy 3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80
lb cover (181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256
g/m2)), Heavy 6 (140 lb index to 110 lb cover (257 g/m2 to 300 g/m2)), Color, Recycled,
Pre-Punched, Transparency, Clear Film, Labels, Tab, Bond, Letterhead, Coated, Textured,
Vellum, and Envelopes
Tray A:
LTR, STMTR, and EXEC:
250 sheets (or 1 3/4" (43 mm) in height)
13" x 19", 12 5/8" x 17 3/4", 12" x 18", 11" x 17", LGL, and LTRR:
125 sheets (or 7/8" (21 mm) in height)
Tray B:
LTR, STMTR, and EXEC:
1,300 sheets (or 7 3/8" (188 mm) in height) *
13" x 19", 12 5/8" x 17 3/4", 12" x 18", 11" x 17", LGL, and LTRR:
650 sheets (or 3 3/4" (96 mm) in height)
Tray C:
LTR:
2,450 sheets (or 13 5/8" (347 mm) in height) *
STMTR, and EXEC:
1,700 sheets (or 9 5/8" (243 mm) in height) *
13" x 19", 12 5/8" x 17 3/4", 12" x 18", 11" x 17", LGL, and LTRR:
650 sheets (or 3 3/4" (96 mm) in height)
, 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom Size
1
1
1
Specifications
47
Page 48
Item Specifications
Capacity Per Tray Collate, Group mode
y B:
Tra
LTR and EXEC:
1,300 sheets (or 7 3/8" (188 mm) in height) *
1
11" x 17", LGL, and LTRR:
650 sheets (or 3 3/4" (96 mm) in height)
Tray C:
LTR and EXEC:
1,700 sheets (or 9 5/8" (243 mm) in height) *
1
11" x 17", LGL, and LTRR:
650 sheets (or 3 3/4" (96 mm) in height)
Staple mode
Tray B, Tray C:
LTR and EXEC:
1,300 sheets/100 sets (or 7 3/8" (188 mm) in height) *
11" x 17", LGL, and LTRR:
650 sheets/50 sets (or 3 3/4" (96 mm) in height)
No Collating/Collate/Group mode with different paper sizes
Tray B, Tray C:
650 sheets (or 3 3/4" (96 mm) in height)
Staple mode with different paper sizes
Tray B, Tray C:
650 sheets/50 sets (or 3 3/4" (96 mm) in height)
*1 Up to 650 sheets (or 3 3/4” (96 mm in height) when thin paper or custom paper lighter than 16 lb bond (59 g/m2)
is selected.
Max. Stapling Capacity/Available Staple Size When the standard staple cartridge is attached
(The maximum stapling capacity may vary, depending on the paper type and weight.)
LTR and EXEC:
50 sheets (20 lb bond (80 g/m2))
11" x 17", LGL, and LTRR:
30 sheets (20 lb bond (80 g/m2))
Corner Staple mode/Double Staple mode:
11" x 17", LGL, LTR, LTRR, and EXEC
Power Source/Maximum Power
From the main unit/385 W or less
Consumption
Dimensions (H x W x D) 44 1/8” x 25 3/8” x 25 7/8”(1,121 mm x 644 mm x 656 mm)
Weight Approximately 106 lb (48 kg)
Installation Space Including the Main Unit
(W x D)
85 3/4" x 36 3/4" (2,179 mm x 934 mm)
(When the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached)
90 1/4" x 36 3/4" (2,291 mm x 934 mm)
(When the Puncher, the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached)
1
48
Page 49
Saddle Finisher-AM2
▀
Item Specifications
Paper Size/Weight/Type Size:
13" x 19", 12 5/8" x 17 11/16"
(4" x 5 7/8" to 13" x 19 1/4" (100 mm x 148 mm to 330.2 mm x 487.7 mm)), and Envelopes
Weight:
14 lb bond to 110 lb cover (52 g/m2 to 300 g/m2)
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2
(25 lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond
(106 g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)),
Heavy 3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80
lb cover (181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256
g/m2)), Heavy 6 (140 lb index to 110 lb cover (257 g/m2 to 300 g/m2)), Color, Recycled,
Pre-Punched, Transparency, Clear Film, Labels, Tab, Bond, Letterhead, Coated, Textured,
Vellum, and Envelopes
Capacity Per Tray*
1
No Collating/Collate/Group mode
Tray A:
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, and STMTR:
1,000 sheets (or 5 3/4" (147 mm) in height)
Tray B:
If the High Volume Stack Mode is set to 'Off':
LTR and EXEC:
2,000 sheets (or 11 1/4" (285 mm) in height)
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, and LTRR:
1,000 sheets (or 5 3/4" (147 mm) in height)
If the High Volume Stack Mode is set to 'On':
(The maximum stack volume may vary, depending on the paper type.)
LTR and EXEC:
4,000 sheets (or 19 1/4" (490 mm) in height)
LTRR:
2,000 sheets (or 11 1/4" (285 mm) in height)
11" x 17" and LGL:
1,500 sheets (or 8 1/2" (216 mm) in height)
13" x 19", 12 5/8" x 17 11/16", and 12" x 18":
1,000 sheets (or 5 3/4" (147 mm) in height)
Staple mode
Tray B:
LTR, and EXEC:
3,000 sheets/200 sets (or 16 5/8" (423 mm) in height)
LTRR:
2,000 sheets/200 sets (or 11 1/4" (285 mm) in height)
11" x 17" and LGL:
1,500 sheets/200 sets (or 8 1/2" (216 mm) in height)
Specifications
, 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom Size
49
Page 50
Item Specifications
Capacity Per Tray*
1
No Collating/Collate/Group mode with different paper sizes
Tray A:
1,000 sheets (or 5 3/4" (147 mm) in height)
Tray B*2:
If the High Volume Stack Mode is set to 'Off':
LTR and EXEC:
2,000 sheets (or 11 1/4" (285 mm) in height)
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, and LTRR:
1,000 sheets (or 5 3/4" (147 mm) in height)
If the High Volume Stack Mode is set to 'On':
(The maximum stack volume may vary, depending on the paper type.)
LTR and EXEC:
4,000 sheets (or 19 1/4" (490 mm) in height)
LTRR:
2,000 sheets (or 11 1/4" (285 mm) in height)
11" x 17" and LGL:
1,500 sheets (or 8 1/2" (216 mm) in height)
13" x 19", 12 5/8" x 17 11/16", and 12" x 18":
1,000 sheets (or 5 3/4" (147 mm) in height)
Z-Fold mode (when the Paper Folding Unit-F1 is attached)
Tray A, Tray B: 30 sheets or 10 sheets/1 set
Half Fold (when the Paper Folding Unit-F1 is attached)
Tray A, Tray B: 50 sheets
*1 To stack 2,000 sheets or more LTR paper, use Tray B first, and then use Tray A for outputting paper.
2
If the capacity values of the different paper sizes are different, the smallest value is applied to the Tray B capacity.
*
Max. Stapling Capacity/Available Staple Size When the standard staple cartridge is attached
(The maximum stapling capacity may vary, depending on the paper type and weight.)
LTR and EXEC:
100 sheets (20 lb bond (80 g/m2)) or below 1/2" (11 mm) in height, 98 sheets (20 lb bond
(80 g/m2)) + 2 sheets (140 lb index (256 g/m2))
11" x 17", LGL, and LTRR:
50 sheets (20 lb bond (80 g/m2)) or below 1/4" (5.5 mm) in height, 48 sheets (20 lb bond
(80 g/m2)) + 2 sheets (140 lb index (256 g/m2))
Corner Stapling:
11" x 17", LGL, LTR, LTRR, EXEC, and Custom Size (8 1/4" x 7 1/8" to 11 3/4" x 17" (210 mm x
182 mm to 297 mm x 432 mm))
Double Stapling:
11" x 17", LGL, LTR, LTRR, EXEC, and Custom Size (7 1/8" x 7 1/8" to 11 3/4" x 17" (182 mm x
182 mm to 297 mm x 432 mm))
50
Page 51
Item Specifications
Available Saddle Stitch Capacity/Size Saddle Stitch:
25 sheets (20 lb bond (80 g/m
Saddle Folding:
5 sheets (20 lb bond (80 g/m2))
Size:
13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL, LTRR, and Custom Size (8 1/4" x 11"
to 13" x 19 1/4" (210 mm x 279.4 mm to 330.2 mm x 487.7 mm)
Cover Weight:
Requires the paper weight of the main document (more than 17 lb bond (64 g/m2)) or
more.
* Available Saddle Stitch capacity may vary, depending on the paper type and weight.
Power Source/Maximum Power
Consumption
Dimensions (H x W x D) 48 3/4" x 31 1/2" x 31 1/4" (1,239 mm x 800 mm x 792 mm)
Weight Approximately 397 lb (180 kg)
Installation Space Including the Main Unit
(W x D)
120-240 V AC, 50/60 Hz, 8 A/500 W or less
92" x 36 3/4" (2,335 mm x 934 mm)
(when the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached)
2
)) (including 1 cover sheet)
Specifications
Booklet Finisher-T1
▀
Item Specifications
Paper Size/Weight/Type Size:
13" x 19", 12 5/8" x 17 11/16"
(4" x 5 7/8" to 13" x 19 1/4" (100 mm x 148 mm to 330.2 mm x 487.7 mm)), and Envelopes
Weight:
Tray A:
14 lb bond to 140 lb index (52 g/m2 to 256 g/m2)
Tray B, Tray C:
14 lb bond to 110 lb cover (52 g/m2 to 300 g/m2)
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2
(25 lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond
2
(106 g/m
Heavy 3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80
lb cover (181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256
g/m2)), Heavy 6 (140 lb index to 110 lb cover (257 g/m2 to 300 g/m2)), Color, Recycled,
Pre-Punched, Transparency, Clear Film, Labels, Tab, Bond, Letterhead, Coated, Textured,
Vellum, and Envelopes
, 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC, STMTR, Custom Size
to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)),
51
Page 52
Item Specifications
Capacity Per Tray No Collating mode
y A:
Tra
LTR, STMTR, and EXEC:
250 sheets (or 1 3/4" (43 mm) in height)
13" x 19", 12 5/8" x 17 3/4", 12" x 18", 11" x 17", LGL, and LTRR:
125 sheets (or 7/8" (21 mm) in height)
Tray B:
LTR, STMTR, and EXEC:
1,300 sheets (or 7 3/8" (188 mm) in height) *
13" x 19", 12 5/8" x 17 3/4", 12" x 18", 11" x 17", LGL, and LTRR:
650 sheets (or 3 3/4" (96 mm) in height)
Tray C:
LTR:
2,450 sheets (or 13 5/8" (347 mm) in height) *
STMTR, and EXEC:
1,700 sheets (or 9 5/8" (243 mm) in height) *
13" x 19", 12 5/8" x 17 3/4", 12" x 18", 11" x 17", LGL, and LTRR:
650 sheets (or 3 3/4" (96 mm) in height)
Collate, Group mode
Tray B:
LTR and EXEC:
1,300 sheets (or 7 3/8" (188 mm) in height) *
11" x 17", LGL, and LTRR:
650 sheets (or 3 3/4" (96 mm) in height)
Tray C:
LTR and EXEC:
1,700 sheets (or 9 5/8" (243 mm) in height) *
11" x 17", LGL, and LTRR:
650 sheets (or 3 3/4" (96 mm) in height)
Staple mode
Tray B, Tray C:
LTR and EXEC:
1,300 sheets/100 sets (or 7 3/8" (188 mm) in height) *
11" x 17", LGL, and LTRR:
650 sheets/50 sets (or 3 3/4" (96 mm) in height)
No Collating/Collate/Group mode with different paper sizes
Tray B, Tray C:
650 sheets (or 3 3/4" (96 mm) in height)
Staple mode with different paper sizes
Tray B, Tray C:
650 sheets/50 sets (or 3 3/4" (96 mm) in height)
Saddle Stitch mode
1 to 5 sheets/25 sets, 6 to 10 sheets/15 sets, 11 to 16 sheets/10 sets
*1 Up to 650 sheets (or 3 3/4” (96 mm in height) when thin paper or custom paper lighter than 16 lb bond (59 g/m2)
is selected.
1
1
1
1
1
1
52
Page 53
Item Specifications
Max. Stapling Capacity/Available Staple Size When the standard staple cartridge is attached:
he maximum stapling capacity may vary, depending on the paper type and weight.)
(T
LTR and EXEC:
50 sheets (20 lb bond (80 g/m2))
11" x 17", LGL, and LTRR:
30 sheets (20 lb bond (80 g/m2))
Corner Staple mode/Double Staple mode:
11" x 17", LGL, LTR, LTRR, and EXEC
Available Saddle Stitch Capacity/Size Saddle Stitch:
16 sheets (including 1 cover sheet 140 lb index (256 g/m
Saddle Folding:
1 sheet (16 lb bond to 140 lb index (60 g/m2 to 256 g/m2))
Size:
12” x 18”, 11” x 17”, LGL, and LTRR
Cover Weight:
Requires the paper weight of the main document (16 lb bond to 140 lb index (60 g/m2 to
256 g/m2)) or more.
* Available Saddle Stitch capacity may vary, depending on the paper type and weight.
Power Source/Maximum Power
Consumption
Dimensions (H x W x D) 44 1/8” x 25 1/2” x 25 7/8” (1,121 mm x 646 mm x 656 mm)
Weight Approximately 158.7 lb (72 kg)
Installation Space Including the Main Unit
(W x D)
From the main unit/385 W or less
85 7/8" x 36 3/4" (2,181 mm x 934 mm)
(When the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached)
90 1/4" x 36 3/4" (2,293 mm x 934 mm)
(When the Puncher, the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached)
Specifications
2
)) (20 lb bond (80 g/m2))
53
Page 54
Puncher Unit-BS1 / Puncher Unit-BT1
▀
Item Specifications
Paper Size/Weight/Type Size:
Puncher Unit
Two Holes:
Three Holes:
Puncher Unit-BT1:
Two Holes:
Four Holes:
Weight:
14 lb bond to 110 lb cover (52 g/m2 to 300 g/m2)*
* The maximum weight for coated paper is 110 lb index (209g/m2).
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2 (25
lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond (106
g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)), Heavy
3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80 lb cover
(181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256 g/m2)),
Heavy 6 (140 lb index to 110 lb cover (257 g/m2 to 300 g/m2)), Color, Recycled, Tab, Bond,
Letterhead, Coated, and Textured
Punch Hole Quantity, Hole Diameter Puncher Unit-BS1
Two or Three Holes: 3/8" (8 mm)
Puncher Unit-BT1
Two or Four Holes: 1/4" (6.5 mm)
Distance between Punch Holes Puncher Unit-BS1
Two Holes: 2 3/4" (70 mm)
Three Holes: 4 1/4" (108 mm)
Puncher Unit-BT1
Two Holes: 3 1/8" (80 mm)
Four Holes: 3 1/8" (80 mm)
Punch Waste Tray Capacity Approximately 6,000 sheets (20 lb bond (80 g/m
* The figure may differ depending on the surrounding environment, paper type, and paper weight.
Power Source From the finisher
Dimensions (H x W x D) Inside the finisher
Weight Approximately 6.7 lb (3.0 kg)
-BS1:
LGL, LTRR, and Custom Size (7 1/8" x 7 1/8" to 11 3/4" x 17" (182 mm x 182 mm to
297 mm x 432 mm))
11" x 17", LTR, EXEC, and Custom Size (9 1/2" x 7 1/8" to 11 3/4" x 17" (240 mm x 182
mm to 297 mm x 432 mm))
LGL, LTRR, and Custom Size (7 1/8" x 7 1/8" to 11 3/4" x 17" (182 mm x 182 mm to
297 mm x 432 mm))
11" x 17", LTR, EXEC, and Custom Size (10 1/8" x 7 1/8" to 11 3/4" x 17" (257mm x 182
mm to 297 mm x 432 mm))
2
))
54
Page 55
External 2/3 Hole Puncher-C1
▀
Item Specifications
Paper Size/Weight/Type Size:
2 Holes:
TRR
LGL and L
3 Holes:
11” x 17” and LTR
Weight:
14 lb bond to 140 lb index (52 g/m2 to 256 g/m2)
Type:
Thin 2 (14 lb bond to 16 lb bond (52 g/m2 to 63 g/m2)), Thin 1 (17 lb bond to 20 lb bond
(64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond (80 g/m2 to 90 g/m2)), Plain 2 (25
lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1 (29 lb bond to 34 lb bond (106
g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond (129 g/m2 to 150 g/m2)), Heavy
3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)), Heavy 4 (67 lb cover to 80 lb cover
(181 g/m2 to 220 g/m2)), Heavy 5 (82 lb cover to 140 lb index (221 g/m2 to 256 g/m2)),
Color, Recycled, Tab, Bond, Letterhead, Coated, and Textured
Punch Hole Quantity, Hole Diameter Two holes:
6.5 mm (1/4”)
Three holes:
8 mm (3/8”)
Distance between Punch Holes Two holes:
70 mm (2 3/4”)
Three holes:
108 mm (4 1/4”)
2
Punch Waste Tray Capacity Approximately 10,000 sheets (20 lb bond (80 g/m
Power Source From the main unit
Dimensions (H x W x D) 32 1/2” x 4 1/4” x 24 1/4” (825 mm x 107 mm x 615 mm)
Weight Approximately 17lb (7.7 kg)
Installation Space Including the Main Unit
(W x D)
90 1/4" x 36 3/4" (2,293 mm x 934 mm)
(When the Booklet Finisher-T1, the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are
attached)
))
Specifications
55
Page 56
Professional Puncher Integration Unit-C1
▀
Item Specifications
Paper Size/Weight/Type Size:
LTR
eight:
W
Plain: 20 lb bond to 80 lb cover (75 g/m2 to 216 g/m2)
Coated: 44.4 lb cover to 80 lb cover (120 g/m2 to 216 g/m2)
Type:
Thin 1 (17 lb bond to 20 lb bond (64 g/m2 to 79 g/m2)), Plain 1 (20 lb bond to 24 lb bond
(80 g/m2 to 90 g/m2)), Plain 2 (25 lb bond to 28 lb bond (91 g/m2 to 105 g/m2)), Heavy1
(29 lb bond to 34 lb bond (106 g/m2 to 128 g/m2)), Heavy 2 (35 lb bond to 40 lb bond
(129 g/m2 to 150 g/m2)), Heavy 3 (40 lb bond to 66 lb cover (151 g/m2 to 180 g/m2)),
Heavy 4 (67 lb cover to 80 lb cover (181 g/m2 to 220 g/m2)), Color, Recycled, Tab, Bond,
Letterhead, Coated, and Textured
Power Source 120-127 V AC, 60 Hz, 5.5 A
Maximum Power Consumption 130 W or less
Dimensions (H x W x D) 41" x 9 7/8" x 31 1/4" (1,040 mm x 250 mm x 792 mm)
Weight Approximately 88.2lb (40 kg)
Copy Card Reader-F1
▀
Item Specifications
Available Cards Magnetic
Card Readout M
Magnetic Card Reading Direction Inserting Direction
Store/Replay Replay
Power Source From the main unit
Dimensions (H x W x D) 1 5/8" x 3 1/2" x 3 3/4" (40 mm x 88 mm x 96 mm)
Weight Approximately 7.1 oz (200 g)
ethod Magnetic readout
(excluding the attachment kit and cable)
(including the attachment kit and cable)
Send Function
▀
•
Scan Features
Item Specifications
Communication Protocol FTP (TCP/IP), SMB (TCP/IP), WebDAV
mat TIFF, JPEG, PDF, XPS, OOXML (PowerPoint)
Data For
Resolution 100 x 100 dpi, 150 x 150 dpi, 200 x 100 dpi, 200 x 200 dpi, 200 x 400 dpi, 300 x 300 dpi, 400 x
400 dpi, 600 x 600 dpi
System Environment Windows Server 2003 R2 SP2, Windows Vista SP2, Windows Server 2008 SP2, Windows Server
2008/R2, Windows 7, Windows 8, Windows Server 2012, Mac OS X 10.6.x, Mac OS 10.7.x*
Mac OS 10.8.x*1, Red Hat Linux 9
*1 Available on FTP and WebDAV
56
1
,
Page 57
Specifications
Item Specifications
Interface 1000BASE-T, 100BASE-TX, 10BASE-T
ode Automatic-Color Select (Full Color/Grayscale), Automatic-Color Select (Full Color/Black-and-
Color M
White), Full Color, Grayscale, Black-and-White
Original Type Text, Text/Photo, Photo
Other Preview, Browse Windows (SMB) File Server
Optional PDF / XPS / OOXML Functions PDF
Compact, Trace and Smooth, Limited Color, Encryption, OCR, Device Signature, User
Signature, Optimization for Web*
XPS
Compact, OCR, Device Signature, User Signature
OOXML
PowerPoint, Word, OCR
*1 PDF files optimized for Web viewing.
•
E-Mail and I-Fax Features
Item Specifications
Communication Protocol SMTP, POP3
ommunication Mode Simple, Full
I-Fax C
Resolution For Sending E-mail
100 x 100 dpi, 150 x 150 dpi, 200 x 100 dpi, 200 x 200 dpi, 200 x 400 dpi, 300 x 300 dpi,
400 x 400 dpi, 600 x 600 dpi
For Sending I-Fax (Black-and-White)
200 x 100 dpi, 200 x 200 dpi, 200 x 400 dpi*
1
dpi*
For Sending I-Fax (Color)
100 x 100 dpi*1, 200 x 200 dpi*1, 300 x 300 dpi*1, 400 x 400 dpi*1, 600 x 600 dpi*
Format E-mail
TIFF, JPEG, PDF, XPS, OOXML (PowerPoint)
I-Fax (Black-and-White)
TIFF (MH, MR*1, MMR*1)
I-Fax (Color)
TIFF (Profile-C)*
Original Size E-mail
11" x 17", LGL, LTR, LTRR, STMT, STMTR
I-Fax
11" x 17", LGL*2, LTR, LTRR, STMT*2, STMTR*
Server Software Microsoft Exchange 2003 SP2, Microsoft Exchange 2007 SP2, Sendmail 8.14.4, Lotus Domino
R7.0
Other Searches a destination via the LDAP Server, Preview
1
1
, PDF/A-1b, Policy Applied
1
, 300 x 300 dpi*1, 400 x 400 dpi*1, 600 x 600
2
1
57
Page 58
Item Specifications
Optional PDF / XPS / OOXML Functions
(E-mail only)
*1 Available after setting RX conditions of the destination.
2
Sent as LTR.
*
3
PDF files optimized for Web viewing.
*
Network Environment
▀
•
Hardware Specifications
Item Specifications
Network Interface 10Base-T/100Base-TX/1000Base-T (RJ-45)
•
Software Specifications
TCP / IP Frame type : Ethernet II
IPX / SPX Frame type: Ethernet II/Ethernet 802.2/Ethernet 802.3/Ethernet SNAP/Auto Detect
AppleTalk Frame type: Ethernet SNAP
PDF
t, Trace and Smooth, Limited Color, Encryption, OCR, Device Signature, User
Compac
Signature, Optimization for Web*3, PDF/A-1b, Policy Applied
XPS
Compact, OCR, Device Signature, User Signature
OOXML
PowerPoint, Word, OCR
Protocol Supported
int applications: LPD/Raw/IPP/IPPS/FTP/WSD/SMB
Pr
Print applications: Bindery PServer/NDS PServer/RPrinter/NPrinter
Print applications: PAP (Printer Access Protocol)
Printer Settings
▀
•
Software Specifications
Item Specifications
Command Language PCL5e, PCL6, PostScript 3
Resident Fonts PCL: 93 Scalable f
PS: 136 Scalable fonts
Printable Area PCL5e, PCL6:
Reduced to 1/6" (4.23 mm) from the top, bottom, left, and right edges of the paper.
PostScript 3*:
Reduced to 1/6" (4 mm) from the top, bottom, left, and right edges of the paper.
* With 12 5/8" x 17 11/16" size paper, you cannot print in the areas 3/8" (10 mm) from the top, bottom, left, and
right edges of the paper.
58
onts, 2 OCR fonts, and 10 Bitmap fonts
Page 59
Product Name
Safety regulations require the product’s name to be registered. In some regions where this product is sold, the following name(s) in
parenthesis may be registered instead.
imagePRESS C800/C700/C60 (F163000)
FCC (Federal Communications Commission) Users in the U.S.A.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules, and the limits for an ISM equipment, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate, radio frequency energy and, if not installed and used in accordance with the Operator’s Manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
If this equipment does cause harmful interference to other equipment, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
•
Increase the separation between the equipment and other equipment.
•
Connect the equipment into an outlet on a circuit different from that to which the other equipment is connected.
•
Consult the dealer for help.
Use of shielded cables are required to comply with Class A limits in Subpart B of Part 15 of the FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If you make such changes or
modifications, you could be required to stop operation of the equipment.
If your equipment malfunctions, please contact your local authorized Canon dealer from whom you purchased the equipment (if
under warranty), or with whom you have a servicing contract. If you are not sure who to contact, and have both purchased and are
using the equipment in the U.S.A., please refer to the “SUPPORT” page on Canon U.S.A.’s Web site (http://www.usa.canon.com).
Laser Safety
This product complies with 21 CFR Chapter 1 Subchapter J as
a Class I laser product under the U.S. Department of Health
and Human Services (DHHS) Radiation Performance Standard
according to the Radiation Control for Health and Safety Act of
1968. Also, this product is certified as a Class 1 laser product under
IEC60825-1: 2007. This means that the product does not produce
hazardous laser radiation.
Since radiation emitted inside the product is completely confined
within protective housings and external covers, the laser beam
cannot escape from the machine during any phase of user
operation. Do not remove protective housings or external covers,
except as directed by the equipment’s manual.
CAUTION
Use of controls, adjustments, or performance of procedures other than those specified in the manuals for this machine may result in
hazardous radiation exposure.
59
Page 60
International ENERGY STAR Program
As an ENERGY STAR® Partner, Canon USA, Inc. has determined that this machine meets the
international ENERGY STAR Program for energy efficiency.
The International ENERGY STAR Office Equipment Program is an international program that
promotes energy saving through the use of computers and other office equipment. The program
backs the development and dissemination of products with functions that effectively reduce
energy consumption. It is an open system in which business proprietors can participate voluntarily.
The targeted products are office equipment, such as computers, displays, printers, facsimiles, and
copiers. The standards and logos are uniform among participating nations.
IPv6 Ready Logo
The protocol stack included in this machine has obtained the IPv6 Ready Logo Phase-1 established
by the IPv6 Forum.
Information Security Standard (IEEE 2600)
This machine is compliant with IEEE Std 2600™ - 2008 (hereinafter referred to as IEEE 2600), a global information security standard for
multifunction peripherals and printers, and is able to achieve the security requirements defined in IEEE 2600.*
For information on how this machine meets the security requirements defined in IEEE 2600, see e-Manual > Security > IEEE 2600
Security Standard.
* IEEE 2600.1 CC Authentication has not been obtained for this machine by itself.
Copyright
Copyright CANON INC. 2014
No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including
photocopying and recording, or by any information storage or retrieval system without the prior written permission of Canon Inc.
This product includes software and/or software modules that are licensed by Canon Inc. or its licensors from third parties. Use and
distribution of this software and/or software modules are subject to conditions (a) through (d) below.
(a)
Copyright (C) 1999, 2000, 2002 Aladdin Enterprises. All rights reserved.
(b)
UFST: Copyright © 1989 - 1996, 1997, 2003, 2004, 2008, all rights reserved, by Monotype Imaging Inc.
(c)
Copyright © Unpublished Work of Novell, Inc. All Rights Reserved.
(d)
Portions of this software are copyright © 2007 The FreeType Project (www.freetype.org). All rights reserved.
60
Page 61
Disclaimers
The information in this document is subject to change without notice.
CANON INC. MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, EITHER EXPRESS OR IMPLIED, EXCEPT AS
PROVIDED HEREIN, INCLUDING WITHOUT LIMITATION, THEREOF, WARRANTIES AS TO MARKETABILITY, MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE OR USE, OR NON-INFRINGEMENT. CANON INC. SHALL NOT BE LIABLE FOR ANY DIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM THE USE OF THIS MATERIAL.
The following applies in California, USA only:
The battery included with your product contains Perchlorate Material and may require special handling.
See http://www.dtsc.ca.gov/hazardouswaste/perchlorate/ for details.
Legal Limitations on the Usage of Your Product and the Use of Images
Using your product to scan, print or otherwise reproduce certain documents, and the use of such images as scanned, printed or
otherwise reproduced by your product, may be prohibited by law and may result in criminal and/or civil liability. A non-exhaustive
list of these documents is set forth below. This list is intended to be a guide only. If you are uncertain about the legality of using
your product to scan, print or otherwise reproduce any particular document, and/or of the use of the images scanned, printed or
otherwise reproduced, you should consult in advance with your legal advisor for guidance.
•
Paper Money
•
Money Orders
•
Certificates of Deposit
•
Postage Stamps (canceled or uncanceled)
•
Identifying Badges or Insignias
•
Selective Service or Draft Papers
•
Checks or Drafts Issued by Governmental Agencies• Stock Certificates
•
Motor Vehicle Licenses and Certificates of Title
•
Travelers Checks
•
Food Stamps
•
Passports
•
Immigration Papers
•
Internal Revenue Stamps (canceled or uncanceled)
•
Bonds or Other Certificates of Indebtedness
•
Copyrighted Works/Works of Art without Permission of Copyright Owner
61
Page 62
Trademarks
"MEAP" is a trademark of CANON Inc., referring to an "application platform" for Canon multifunction and single function printers.
This product contains the Universal Font Scaling Technology or UFST® under license from Monotype Imaging, Inc. UFST® is a
trademark of Monotype Imaging, Inc. registered in the United States Patent and Trademark Office and may be registered in certain
jurisdictions.
Apple, AppleTalk, EtherTalk, LocalTalk, Mac, Macintosh, Mac OS, and Safari are trademarks of Apple Inc., registered in the U.S. and other
countries.
Microsoft, Windows, Windows Vista, Windows Server, Internet Explorer, Excel and PowerPoint are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
Adobe, PostScript, and the PostScript logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the
United States and/or other countries.
Copyright © 2007 -08 Adobe Systems Incorporated. All rights reserved.
Protected by U.S. Patents 5,737,599; 5,781,785; 5,819,301; 5,929,866; 5,943,063; 6,073,148; 6,515,763; 6,639,593; 6,754,382; 7,046,403;
7,213,269; 7,242,415; Patents pending in the U.S. and other countries.
All instances of the name PostScript in the text are references to the PostScript language as defined by Adobe Systems Incorporated
unless otherwise stated. The name PostScript also is used as a product trademark for Adobe Systems' implementation of the
PostScript language interpreter.
Except as otherwise stated, any reference to a "PostScript printing device," "PostScript display device," or similar item refers to a
printing device, display device or item (respectively) that contains PostScript technology created or licensed by Adobe Systems
Incorporated and not to devices or items that purport to be merely compatible with the PostScript language.
Adobe, the Adobe logo, PostScript, the PostScript logo, and PostScript 3 are either registered trademarks or trademarks of Adobe
Systems Incorporated in the United States and/or other countries.
Linux is a registered trademark of Linus Torvalds. Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
All other trademarks are the property of their respective owners.
62
Page 63
The PDF logo is a trademark or registered trademark of Adobe Systems Incorporated in the United States and other countries.
Copyright © 2008 Adobe Systems Incorporated. All rights reserved.
Protected by U.S. Patents 6,185,684; 6,205,549; 7,213,269; 7,272,628; 7,278,168; Patents pending in the U.S. and other countries.
All instances of the name PostScript in the text are references to the PostScript language as defined by Adobe Systems Incorporated
unless otherwise stated. The name PostScript also is used as a product trademark for Adobe Systems' implementation of the
PostScript language interpreter.
Except as otherwise stated, any reference to a "PostScript printing device," "PostScript display device," or similar item refers to a
printing device, display device or item (respectively) that contains PostScript technology created or licensed by Adobe Systems
Incorporated and not to devices or items that purport to be merely compatible with the PostScript language.
Adobe, the Adobe logo, Adobe LiveCycle® Policy Server, PostScript, the PostScript Logo, and PostScript 3 are either registered
trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.
All other trademarks are the property of their respective owners.
Other product and company names herein may be the trademarks of their respective owners.
63
Page 64
CANON imagePRESS C800/C700 SERIES LIMITED WARRANTY
Canon U.S.A., Inc. or Canon Canada Inc. (as applicable, "Canon") warrants the imagePRESS C800/C700Series product and Canon brand
options designed for use with the imagePRESS product (collectively the "Product") to be free from defects in workmanship and materials
under normal use and service for a period of 90 days after delivery to the original purchaser ("Purchaser") or 180,000 prints or copies (or a
combination of both), whichever comes first. During such warranty period, Canon shall replace, without charge, any defective part with a
new or comparable rebuilt part. This warranty shall not extend to consumables such as paper, chemicals, and toner as to which there shall
be no warranty or replacement. Warranty replacement shall not extend the original warranty period of the Product.
This limited warranty shall only apply if the Product is used in conjunction with compatible computers, peripheral equipment and software.
Canon shall have no responsibility for such items except for compatible Canon brand peripheral equipment covered by a separate warranty
("Separate Warranty"). Repairs of such Canon brand peripheral equipment shall be governed by the terms of the Separate Warranty.
Non-Canon brand equipment that may be distributed with the Product is sold "AS IS" and without warranty of any kind by Canon, including any
implied warranty regarding merchantability or fitness for a particular purpose, and all such warranties are disclaimed. The sole warranty, if any,
with respect to such non-Canon brand items is given by the supplier or producer thereof. For further information on software, see below.
This warranty shall be void and of no force and effect if the Product is damaged as a result of (a) abuse, neglect, mishandli ng, alteration,
electric current fluctuation or accident, (b) improper use, including failure to follow operating or maintenance instructions or environmental
conditions prescribed in Canon's operator's manual or other documentation, (c) installation or repair by other than authorized service
representatives qualified by Canon who are acting in accordance with Canon's service bulletins, (d) use of supplies or parts (other than those
distributed by Canon) which damage the Product or cause abnormally frequent service calls or service problems, or (e) use of th e Product with
non-compatible computers, peripheral equipment or software, including the use of the Product in any system configuration not recommended
in any manual distributed with the Product. Nor does this warranty extend to any Product on which the original identification marks or serial
numbers have been defaced, removed, or altered.
ANY SOFTWARE THAT IS DISTRIBUTED WITH THE PRODUCT AND HAS AN ASSOCIATED END USER AGREEMENT IS LICENSED,
WARRANTED AND PROVIDED ACCORDING TO THE TERMS OF THAT AGREEMENT, INCLUDING ANY LIMITATIONS AND
DISCLAIMERS THEREIN. SUCH SOFTWARE IS SOLD WITHOUT WARRANTY OF ANY KIND BY CANON. PLEASE CONTACT CANON
IMMEDIATELY IF YOU HAVE NOT RECEIVED A COPY OF THE SOFTWARE SUPPLIER'S END USER AGREEMENT. CANON
RECOMMENDS THAT DATA STORED ON THE PRODUCT' S HARD DISK DRIVE BE DUPLICATE D OR BACKED UP TO PREVENT ITS
LOSS IN THE EVENT OF FAILURE OR OTHER MALFUNCTION OF THE HARD DISK DRIVE.
THE ABOVE WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES AND CONDITIONS, EXPRESS OR IMPLIED, INCLUDING ANY
IMPLIED WARRA NTIES AND CONDITIONS REGARDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
RELATING TO THE USE OR PERFORMANCE OF A PRODUCT OR ANY ASSOCIATED COMPONENT, AND ALL SUCH OTHER
WARRANTIES AND CONDITIONS ARE DISCLAIMED. NO OTHER EXPRESS WARRANTY, CONDITION OR GUARANTY, EXCEPT AS
MENTIONED ABOVE, GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THE PRODUCT SHALL BIND CANON
ANY SUPPLIER OR ANY AUTHORIZED SERVICE PROVIDER. NO WARRANTY IS GIVEN ON ANY USED PRODUCT.
THE SOFTWARE EMBEDDED IN THE PRODUCT AND USED TO CONTROL ITS FEATURES IS OWNED BY CANON INC. AND/OR
OTHER THIRD PARTIES AND IS LICENSED UNDER THE THIRD PARTY SOFTWARE TERMS AND CONDITIONS STATED
ELSEWHERE IN THIS MANUAL. ANY DEFECT IN SUCH EMBEDDED SOFTWARE THAT MATERIALLY IMPAIRS A FEATURE OF THE
PRODUCT DOCUMENTED IN THIS USER MANUAL WILL BE COVERED BY THE ABOVE WARRANTY THAT THE PRODUCT IS FREE
FROM DEFECTS IN MATERIAL AND WORKMANSHIP; NO OTHER WARRANTY APPLIES TO THIS SOFTWARE, AND ALL DISCLAIMER
AND LIMITATION PROVISIONS AS SET FORTH BELOW APPLY TO THIS SOFTWARE.
NEITHER CANON OR ITS SUPPLIERS NOR ANY AUTHORIZED SERVICE PROVIDER SHALL BE LIABLE FOR PERSONAL INJURY OR
PROPERTY DAMAGE (UNLESS CAUSED SOLELY AND DIRECTLY BY THE NEGLIGENCE OF CANON OR ANY AUTHORIZED
SERVICE PROVIDER), LOSS OF REVENUE OR PROFIT, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, EXPENDITURES
FOR SUBSTITUTE EQUIPMENT OR SERVICES, LOSS OR CORRUPTION OF DATA, INCLUDING, WITHOUT LIMITATION, DATA
STORED ON THE PRODUCT'S HARD DISK DRIVE, STORAGE CHARGES OR OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THE PRODUCT, REGARDLESS OF THE LEGAL THEORY ON
WHICH THE CLAIM IS BASED AND EVEN IF CANON OR ITS SUPPLIERS OR ANY AUTHORIZED SERVICE PROVIDER HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST CANON OR ITS SUPPLIERS
OR ANY AUTHORIZED SERVICE PROVIDER BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT CAUSING
THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, THE PURCHASER ASSUMES ALL RISKS AND LIABILITY FOR
LOSS, DAMAGE OR INJURY TO PERSONS AND PROPERTY OF THE PURCHASER OR OTHERS ARISING OUT OF THE POSSESSION,
USE, MISUSE, OR INABILITY TO USE THE PRODUCT NOT CAUSED SOLELY AND DIRECTLY BY THE NEGLIGENCE OF CANON OR
ANY AUTHORIZED SERVICE PROVIDER. THIS WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THE PRODUCT AND STATES SUCH PURCHASER'S EXCLUSIVE REMEDY.
CONDITIONS OF WARRANTY
Defective parts must be returned to Canon or an Authorized Service Provider with all necessary documentation and will become the property
of Canon.
THIS WARRANTY APPLIES TO PRODUCTS SOLD AND USED IN THE U.S.A. AND CANADA ONLY.
64
Page 65
CANON imagePRESS C60 SERIES LIMITED WARRANTY
w
A
Canon U.S.A., Inc. or Canon Canada Inc. (as applicable, "Canon") warrants the imagePRESS C60 product and Canon brand options
designed for use with the imagePRESS product (collectively the "Product") to be free from defects in workmanship and materials under
normal use and service for a period of 90 days after delivery to the original purchaser ("Purchaser") or 90,000 prints or copies (or a
combination of both), whichever comes first. During such warranty period, Canon shall replace, without charge, any defective part with a
new or comparable rebuilt part. This warranty shall not extend to consumables such as paper, chemicals, and toner as to which there shall
be no warranty or replacement. Warranty replacement shall not extend the original warranty period of the Product.
This limited warranty shall only apply if the Product is used in conjunction with compatible computers, peripheral equipment and software.
Canon shall have no responsibility for such items except for compatible Canon brand peripheral equipment covered by a separate warranty
("Separate Warranty"). Repairs of such Canon brand peripheral equipment shall be governed by the terms of the Separate Warranty.
Non-Canon brand equipment that may be distributed with the Product is sold "AS IS" and without warranty of any kind by Canon, including any
implied warranty regarding merchantability or fitness for a particular purpose, and all such warranties are disclaimed. The sole warranty, if any,
ith respect to such non-Canon brand items is given by the supplier or producer thereof. For further information on software, see below.
This warranty shall be void and of no force and effect if the Product is damaged as a result of (a) abuse, neglect, mishandling, alteration,
electric current fluctuation or accident, (b) improper use, including failure to follow operating or maintenance instructions or environmental
conditions prescribed in Canon's operator's manual or other documentation, (c) installation or repair by other than authorized service
representatives qualified by Canon who are acting in accordance with Canon's service bulletins, (d) use of supplies or parts (other than those
distributed by Canon) which damage the Product or cause abnormally frequent service calls or service problems, or (e) use of the Product with
non-compatible computers, peripheral equipment or software, including the use of the Product in any system configuration not recommended
in any manual distributed with the Product. Nor does this warranty extend to any Product on which the original identification marks or serial
numbers have been defaced, removed, or altered.
NY SOFTWARE THAT IS DISTRIBUTED WITH THE PRODUCT AND HAS AN ASSOCIATED END USER AGREEMENT IS LICENSED,
WARRANTED AND PROVIDED ACCORDING TO THE TERMS OF THAT AGREEMENT, INCLUDING ANY LIMITATIONS AND
DISCLAIMERS THEREIN. SUCH SOFTWARE IS SOLD WITHOUT WARRANTY OF ANY KIND BY CANON. PLEASE CONTACT CANON
IMMEDIATELY IF YOU HAVE NOT RECEIVED A COPY OF THE SOFTWARE SUPPLIER'S END USER AGREEMENT. CANON
RECOMMENDS THAT DATA STORED ON THE PRODUCT'S HARD DISK DRIVE BE DUPLICATED OR BACKED UP TO PREVENT ITS
LOSS IN THE EVENT OF FAILURE OR OTHER MALFUNCTION OF THE HARD DISK DRIVE.
THE ABOVE WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES AND CONDITIONS, EXPRESS OR IMPLIED, INCLUDING ANY
IMPLIED WARRA NTIES AND CONDITIONS REGARDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
RELATING TO THE USE OR PERFORMANCE OF A PRODUCT OR ANY ASSOCIATED COMPONENT, AND ALL SUCH OTHER
WARRANTIES AND CONDITIONS ARE DISCLAIMED. NO OTHER EXPRESS WARRANTY, CONDITION OR GUARANTY, EXCEPT AS
MENTIONED ABOVE, GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THE PRODUCT SHALL BIND CANON
ANY SUPPLIER OR ANY AUTHORIZED SERVICE PROVIDER. NO WARRANTY IS GIVEN ON ANY USED PRODUCT.
THE SOFTWARE EMBEDDED IN THE PRODUCT AND USED TO CONTROL ITS FEATURES IS OWNED BY CANON INC. AND/OR
OTHER THIRD PARTIES AND IS LICENSED UNDER THE THIRD PARTY SOFTWARE TERMS AND CONDITIONS STATED
ELSEWHERE IN THIS MANUAL. ANY DEFECT IN SUCH EMBEDDED SOFTWARE THAT MATERIALLY IMPAIRS A FEATURE OF THE
PRODUCT DOCUMENTED IN THIS USER MANUAL WILL BE COVERED BY THE ABOVE WARRANTY THAT THE PRODUCT IS FREE
FROM DEFECTS IN MATERIAL AND WORKMANSHIP; NO OTHER WARRANTY APPLIES TO THIS SOFTWARE, AND ALL DISCLAIMER
AND LIMITATION PROVISIONS AS SET FORTH BELOW APPLY TO THIS SOFTWARE.
NEITHER CANON OR ITS SUPPLIERS NOR ANY AUTHORIZED SERVICE PROVIDER SHALL BE LIABLE FOR PERSONAL INJURY OR
PROPERTY DAMAGE (UNLESS CAUSED SOLELY AND DIRECTLY BY THE NEGLIGENCE OF CANON OR ANY AUTHORIZED
SERVICE PROVIDER), LOSS OF REVENUE OR PROFIT, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, EXPENDITURES
FOR SUBSTITUTE EQUIPMENT OR SERVICES, LOSS OR CORRUPTION OF DATA, INCLUDING, WITHOUT LIMITATION, DATA
STORED ON THE PRODUCT'S HARD DISK DRIVE, STORAGE CHARGES OR OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THE PRODUCT, REGARDLESS OF THE LEGAL THEORY ON
WHICH THE CLAIM IS BASED AND EVEN IF CANON OR ITS SUPPLIERS OR ANY AUTHORIZED SERVICE PROVIDER HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST CANON OR ITS SUPPLIERS
OR ANY AUTHORIZED SERVICE PROVIDER BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT CAUSING
THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, THE PURCHASER ASSUMES ALL RISKS AND LIABILITY FOR
LOSS, DAMAGE OR INJURY TO PERSONS AND PROPERTY OF THE PURCHASER OR OTHERS ARISING OUT OF THE POSSESSION,
USE, MISUSE, OR INABILITY TO USE THE PRODUCT NOT CAUSED SOLELY AND DIRECTLY BY THE NEGLIGENCE OF CANON OR
ANY AUTHORIZED SERVICE PROVIDER. THIS WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THE PRODUCT AND STATES SUCH PURCHASER'S EXCLUSIVE REMEDY.
CONDITIONS OF WARRANTY
Defective parts must be returned to Canon or an Authorized Service Provider with all necessary documentation and will become the property
of Canon.
THIS WARRANTY APPLIES TO PRODUCTS SOLD AND USED IN THE U.S.A. AND CANADA ONLY.
65
Page 66
66
Page 67
Page 68
CANON INC.
30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan
CANON U.S.A., INC.
One Canon Park, Melville, NY 11747, U.S.A.
CANON CANADA INC.
6390 Dixie Road Mississauga, Ontario L5T 1P7, Canada
CANON EUROPA N.V.
Bovenkerkerweg 59, 1185 XB Amstelveen, The Netherlands
(See http://www.canon-europe.com/ for details on your regional dealer)
CANON LATIN AMERICA, INC.
One Canon Park, Melville, NY 11747, U.S.A.
CANON AUSTRALIA PTY. LTD
Building A, The Park Estate, 5 Talavera Road, Macquarie Park, NSW 2113, Australia
CANON CHINA CO., LTD
15F Jinbao Building No.89 Jinbao Street, Dongcheng District, Beijing 100005, China
CANON SINGAPORE PTE. LTD.
1 HarbourFront Avenue #04-01 Keppel Bay Tower, Singapore 098632
CANON HONGKONG CO., LTD
19/F., The Metropolis Tower, 10 Metropolis Drive, Hunghom, Kowloon, Hong Kong
FT6-1038 (000) XXXXXXXXXX Copyright CANON INC. 2014 PRINTED IN CHINA
Loading...
