Canon EOS M6 User Guide

E
Advanced User Guide

Introduction

Before Starting to Shoot, Be Sure to Read the Following
To avoid shooting problems and accidents, rst read the “Handling
Precautions” (=31) and “Safety Instructions” (=28). Also, read this
manual carefully to ensure that you use the camera correctly.
Refer to This Manual while Using the Camera to Further Familiarize Yourself with the Camera
While reading this manual, take a few test shots and see how they come
out. You can then better understand the camera. Be sure to store this
manual safely, too, so that you can refer to it again when necessary.
Testing the Camera Before Use and Liability
After shooting, play images back and check whether they have been properly recorded. If the camera or memory card is faulty and the images cannot be recorded or downloaded to a computer, Canon cannot be held liable for any loss or inconvenience caused.
Copyrights
Copyright laws in some countries prohibit the unauthorized use of images recorded with the camera (or music/images with music transferred to the memory card) for purposes other than personal enjoyment. Also be aware that certain public performances, exhibitions, etc. may prohibit photography even for private enjoyment.
2

Item Check List

Before starting, check that all the following items are included with your camera. If anything is missing, contact your dealer.
Camera
(with body cap)
Battery Pack LP-E17
(with protective cover)
zThe camera does not come with a memory card (=11), interface cable, or HDMI
cable.
zFor details on the Advanced User Guide and Instruction Manuals, see “Instruction
Manuals” (=4).
zIf you purchased a Lens Kit, check that the lenses are included. zBe careful not to lose any of the above items.
zWhen you need Lens Instruction Manuals, download them from the Canon
website (=4).
zThe Lens Instruction Manuals (PDF les) are for lenses sold individually. Note
that when purchasing the Lens Kit, some of the accessories included with the lens may not match those listed in the Lens Instruction Manual.
Battery Charger
LC-E17/LC-E17E
Strap
3

Instruction Manuals

The Instruction Manual included with the camera provides basic instructions for the camera and Wi-Fi functions.
The Advanced User Guide (this PDF le), which provides complete instructions, can be downloaded from the Canon website to a computer or other device.
Downloading the Advanced User Guide/Instruction Manuals
The Advanced User Guide and Instruction Manuals for lenses and software (PDF les) can be downloaded from the Canon website to a computer or
other device.
zDownload site
Advanced User Guide/Supplemental Information
www.canon.com/icpd
Lens Instruction Manual
www.canon.com/icpd
Software Instruction Manual
www.canon.com/icpd
zTo view the PDF les, an Adobe PDF viewing software such as Adobe
Acrobat Reader DC (most recent version recommended) is required.
zAdobe Acrobat Reader DC can be downloaded for free from the Internet. zDouble-click the downloaded PDF le to open it. zTo learn how to use PDF viewing software, refer to the software’s Help section
or the like.
4
Instruction Manuals
Downloading the Advanced User Guide/Instruction Manuals Using QR Code
The Advanced User Guide and Instruction Manuals for lenses and software (PDF les) can be downloaded to a smartphone or tablet using the QR
code.
www.canon.com/icpd
zA software app is required to read the QR code. zSelect your country or region of residence, then download the Advanced User
Guide/Instruction Manuals.
zSelect [5: Manual/software URL] to display the QR code on the camera
screen.
5

Quick Start Guide

1
Insert the battery (=44).
zUpon purchase, charge the battery
to start using (=42).
2
3
4
(2)
Insert the card (=44).
zInsert the card with the label facing
the front of the camera.
Attach the lens (=51).
zAlign the white mount index on the
lens with the white mount index on
the camera to attach the lens.
zRemove the lens cap.
Prepare to shoot.
zPress (1) as you turn (2) slightly,
(1)
and then release (1).
zTurn (2) a little more until it clicks.
6
Quick Start Guide
5
6
7
8
Set the power switch to <1> (=49).
Set the focus mode switch to <AF>.
z<AF> stands for autofocus. z<MF> stands for manual focus.
Autofocus will not operate.
Set the Mode dial to <A> (=72).
zAll the necessary camera settings
will be set automatically.
Focus on the subject (=60).
z[p] (an AF point) appears over any
face detected.
zPress the shutter button halfway,
and the camera will focus on the subject.
7
Quick Start Guide
9
10
zTo view the images captured so far, see “Image Playback” (=306). zTo delete images, see “Erase Images” (=329).
Take the picture (=60).
zPress the shutter button completely
to take the picture.
Review the picture.
zThe image just captured will be
displayed for approx. 2 sec. on the
screen.
zTo display the image again, press
the <x> button (=306).
8

About This Manual

Icons in this Manual
<6> : Indicates the Main dial. <5> : Indicates the Quick control dial. <W> <X> <Y> <Z> : Indicates the corresponding direction on the <V>
<5> : Indicates the control dial. <Q> <0> : Indicates the Quick Control/Setting button.
* : Indicates the duration (in * seconds) of the
y In addition to the above, the icons and symbols used on the camera’s buttons and
displayed on the screen are also used in this manual when discussing relevant operations and functionality.
(in page titles) : Functions only available in Creative Zone modes
M
*** : Reference page numbers for more information.
=
cross keys.
operation for the button you pressed, as timed after you release the button.
(<t>, <d>, <s>, <f>, or <a> mode) or for
movies recorded with manual exposure.
: Warning to prevent shooting problems.
: Supplemental information.
: Tips or advice for better shooting.
: Troubleshooting advice.
9
About This Manual
Basic Assumptions for Operational Instructions, Sample Photos
zBefore following any instructions, make sure the power switch is set to
<1> (=49).
zIt is assumed that all the menu settings and Custom Functions are set to
their defaults.
zThe illustrations in this manual show the camera attached with the
EF-M15-45mm f/3.5-6.3 IS STM lens as an example.
zThe sample photos displayed on the camera and used in this manual are
for instructional purposes only.
zIn references to using EF or EF-S lenses, it is assumed that a mount
adapter is used.
10

Compatible Cards

The following cards can be used with the camera regardless of capacity.
If the card is new or was previously formatted (initialized) by another camera or computer, format the card with this camera (=492).
zSD/SDHC/SDXC memory cards
UHS-II and UHS-I cards supported.
Cards that Can Record Movies
When recording movies, use a high-capacity card with ample performance (fast enough writing and reading speeds) for the movie recording size. For
details, see =581.
In this manual, “card” refers to SD memory cards, SDHC memory cards, and SDXC memory cards. * The camera does not come with a card for recording photos/
movies. Please purchase it separately.
11

Chapters

Introduction 2
Preparation and Basic Operations 41
Basic Zone 71
Creative Zone 105
Shooting 117
Flash Photography 285
Playback 303
Wireless Features 377
Set-up 483
Custom Functions / My Menu 527
Reference 551
12

Contents

Introduction 2
Item Check List ......................................................................................3
Instruction Manuals ................................................................................4
Quick Start Guide ...................................................................................6
About This Manual .................................................................................9
Compatible Cards ................................................................................11
Chapters...............................................................................................12
Contents ...............................................................................................13
Index to Features .................................................................................23
Safety Instructions ...............................................................................28
Handling Precautions ...........................................................................31
Part Names ..........................................................................................34
Preparation and Basic Operations 41
Charging the Battery ............................................................................42
Inserting/Removing the Battery and Card ............................................44
Using the Screen .................................................................................48
Turning on the Power ...........................................................................49
Attaching and Detaching a Lens ..........................................................51
Attaching and Detaching EF/EF-S Lenses ..........................................53
Using an Electronic Viewnder (Sold Separately) ................................56
Basic Operations ..................................................................................59
Menu Operations and Settings ............................................................64
Touch-Screen Operation ......................................................................68
Quick Control .......................................................................................69
13
Contents
Basic Zone 71
Scene Intelligent Auto/Hybrid Auto (Fully Automatic) ...........................72
Special Scene Mode (SCN) .................................................................80
Self Portrait Mode ................................................................................82
Portrait Mode........................................................................................83
Smooth Skin Mode ...............................................................................84
Landscape Mode .................................................................................85
Sports Mode .........................................................................................86
Panning Mode ......................................................................................87
Close-up Mode .....................................................................................89
Food Mode ...........................................................................................90
Night Portrait Mode ..............................................................................91
Handheld Night Scene Mode ...............................................................92
HDR Backlight Control Mode ...............................................................93
Cautions for the <SCN> Modes ...........................................................94
Creative Filters Mode ...........................................................................98
Creative Zone 105
Program AE Mode (P) ........................................................................106
Shutter-priority AE Mode (Tv).............................................................108
Aperture-priority AE Mode (Av) ..........................................................110
Manual Exposure Mode (M) ...............................................................11 2
Flexible-priority AE (Fv) ......................................................................114
14
Contents
Shooting 117
Still Photo Shooting 118
Tab Menus: Still Photo Shooting ........................................................11 9
Image Quality .....................................................................................124
Still Image Aspect Ratio .....................................................................127
Image Review Time............................................................................129
Lens Aberration Correction ................................................................130
Drive Mode .........................................................................................135
Self-Timer ...........................................................................................137
RAW Burst Mode ...............................................................................139
Exposure Compensation ....................................................................142
Auto Exposure Bracketing .................................................................143
ISO Speed Settings ...........................................................................145
Auto Lighting Optimizer ......................................................................151
Highlight Tone Priority ........................................................................152
Metering Mode ...................................................................................153
Metering Timer ...................................................................................155
Exposure Simulation ..........................................................................156
White Balance ....................................................................................157
White Balance Correction/Bracketing ................................................162
Color Space .......................................................................................164
Picture Style Selection .......................................................................165
Picture Style Customization ...............................................................168
Picture Style Registration ...................................................................171
Long Exposure Noise Reduction .......................................................173
15
Contents
High ISO Speed Noise Reduction ......................................................174
Dust Delete Data Acquisition .............................................................176
HDR Mode .........................................................................................178
Focus Bracketing ...............................................................................182
Touch Shutter .....................................................................................186
Shutter Release Method ....................................................................188
Interval Timer .....................................................................................189
Long (Bulb) Exposures ......................................................................192
Anti-icker Shooting ...........................................................................195
AF Operation ......................................................................................197
AF Method..........................................................................................200
Eye Detection AF ...............................................................................211
Continuous AF ...................................................................................213
Touch & Drag AF ................................................................................214
Manually Focusing with a Lens after AF ............................................216
AF-Assist Beam Firing .......................................................................217
Image Stabilization .............................................................................218
Exposure Lock (AE Lock) ..................................................................219
Manual Focus.....................................................................................220
MF Peaking (Outline Emphasis) ........................................................222
Focus Mode Switching .......................................................................223
Type of Digest Movie .........................................................................224
Remote Control Shooting ...................................................................225
General Still Photo Shooting Cautions ...............................................226
16
Contents
Movie Recording 229
Tab Menus: Movie Recording ............................................................230
Movie Mode........................................................................................234
HDR Movie Mode ...............................................................................241
Movie Recording Quality ....................................................................243
Sound Recording ...............................................................................250
Time-lapse Movies .............................................................................252
Video Snapshots ................................................................................263
Miniature Effect Movie .......................................................................268
Movie Digital IS ..................................................................................270
Auto Level for Movies ........................................................................272
Movie Servo AF ..................................................................................273
Other Menu Functions .......................................................................278
General Movie Recording Cautions ...................................................282
Flash Photography 285
Shooting With the Built-in Flash .........................................................286
Flash Function Settings .....................................................................291
Shooting With External Speedlites .....................................................302
Playback 303
Tab Menus: Playback .........................................................................304
Image Playback .................................................................................306
Magnied Image Display ....................................................................309
Index Display (Multiple-Image Display) ..............................................310
17
Contents
Movie Playback ..................................................................................3 11
Editing a Movie’s First and Last Scenes ............................................315
Frame Extraction ................................................................................317
Digest Movie Editing ..........................................................................319
Still Photo Extraction from RAW Burst Images ..................................321
Playback on a TV Set .........................................................................323
Protect Images ...................................................................................325
Rotate Images ....................................................................................328
Erase Images .....................................................................................329
Print Ordering .....................................................................................333
Photobook Set-up ..............................................................................337
Creative Filters ...................................................................................340
RAW Image Processing .....................................................................343
Creative Assist ...................................................................................349
Quick Control RAW Processing .........................................................351
Red-Eye Correction............................................................................352
Create Album .....................................................................................353
Cropping.............................................................................................356
Resizing .............................................................................................358
Rating .................................................................................................360
Slideshows .........................................................................................363
Set Image Search Conditions ............................................................365
Main Dial Browsing ............................................................................367
Playback Information Display .............................................................369
Highlight Alert .....................................................................................371
AF Point Display.................................................................................372
18
Contents
Playback Grid .....................................................................................373
View from Last Seen ..........................................................................374
Magnication (Approx.) ......................................................................375
Wireless Features 377
Tab Menus: Wireless Tab ...................................................................378
Selection of Wi-Fi/Bluetooth Connection ...........................................379
Connecting to a Smartphone .............................................................381
Connecting to a Computer via Wi-Fi ..................................................410
Connecting to a Printer via Wi-Fi .......................................................418
Sending Images to a Web Service .....................................................428
Wi-Fi Connection via Access Points ..................................................443
Connecting to a Wireless Remote Control .........................................448
Reconnecting via Wi-Fi ......................................................................451
Registering Multiple Connection Settings ..........................................453
Wi-Fi Settings .....................................................................................454
Bluetooth Settings ..............................................................................455
Changing the Nickname .....................................................................456
Geotagging Images with GPS Information from Other Devices .........457
Changing or Deleting Connection Settings ........................................460
Clearing Wireless Communication Settings to Default ......................462
View Info Screen ................................................................................463
Virtual Keyboard Operations ..............................................................464
Responding to Error Messages .........................................................465
Wireless Communication Function Notes ..........................................476
19
Contents
Security ..............................................................................................478
Checking Network Settings ................................................................479
Wireless Communication Status ........................................................480
Set-up 483
Tab Menus: Set-up .............................................................................484
Select Folder ......................................................................................486
File Numbering ...................................................................................488
Auto Rotate ........................................................................................491
Format Card .......................................................................................492
Mode Guide .......................................................................................494
Feature Guide ....................................................................................495
Eco Mode ...........................................................................................496
Power Saving .....................................................................................497
Display Brightness .............................................................................498
Date/Time/Zone .................................................................................499
Language ...........................................................................................502
Focus Mode Switch (AF/MF)..............................................................503
Video System .....................................................................................504
Sensor Cleaning ................................................................................505
Touch Control .....................................................................................509
Beeping ..............................................................................................510
HDMI Resolution ................................................................................5 11
HDMI HDR Output .............................................................................512
Shutter Button Function for Movies ....................................................513
Shooting Information Display .............................................................514
20
Contents
Display Performance ..........................................................................517
Viewnder Display Format .................................................................517
Display Settings .................................................................................518
Reverse Display .................................................................................519
Help Features.....................................................................................520
Custom Shooting Modes (C1/C2) ......................................................521
Reset Camera ....................................................................................522
Copyright Information .........................................................................523
Other Information ...............................................................................525
Custom Functions / My Menu 527
Tab Menus: Customization .................................................................528
Setting Custom Functions ..................................................................529
Custom Function Setting Items ..........................................................530
Clearing Custom Function Settings ...................................................544
Tab Menus: My Menu .........................................................................545
Registering My Menu .........................................................................546
Reference 551
Software .............................................................................................552
Importing Images to a Computer .......................................................554
In-Camera Charging ..........................................................................556
Household Power Outlet Accessory ...................................................557
Troubleshooting Guide .......................................................................558
21
Contents
Error Codes ........................................................................................577
Performance Data ..............................................................................578
Information Display ............................................................................585
Index ..................................................................................................598
22

Index to Features

Power
zCharging the battery (=42)
zBattery level (=50)
zEco mode (=496)
zPower saving (=497)
Cards
zFormatting (=492)
zCards compatible with movie
recording (=581)
Lens
zAttaching (=51, =53)
zDetaching (=52, =55)
zReleasing shutter without lens
(=543)
Basic Settings
zDate/Time/Zone (=499)
zLanguage (=502)
zBeeper (=510)
zClear all camera settings (=522)
zCopyright information (=523)
Screen
zTilting (=48)
zTouch control (=68)
zFeature guide (=495)
zBrightness (=498)
zElectronic level (=514)
zHelp (=520)
AF
zAF operation (=197)
zAF method (=200)
zAF point selection (=205)
zEye Detection AF (=211)
zContinuous AF (=213)
zTouch & drag AF (=214)
zElectronic manual focus (=216)
zAF-assist beam (=217)
zManual focusing (=220)
zMF peaking settings (=222)
Metering
zMetering mode (=153)
Drive
zMaximum burst (=126)
zDrive mode (=135)
zSelf-timer (=137)
23
Index to Features
Image Recording Settings
zCreating/Selecting a folder
(=486)
zFile numbering (=488)
Image Quality
zImage quality (=124)
zStill image aspect ratio (=127)
zLens aberration correction
(=130)
zISO speed (still photos) (=145)
zAuto Lighting Optimizer (=151)
zHighlight tone priority (=152)
zWhite balance (=157)
zColor space (=164)
zPicture Style (=165)
zNoise reduction for long exposures
(=173)
zNoise reduction for high ISO
speeds (=174)
zAnti-icker shooting (=195)
Shooting
zShooting mode (=36)
zQuick Control (=69)
zCreative Assist (=78)
zCreative lters (=98)
zDepth-of-eld preview (=111)
zRAW burst mode (=139)
zHDR mode (=178)
zFocus bracketing (=182)
zTouch shutter (=186)
zInterval timer (=189)
zBulb timer (=193)
zMagnied view (=207)
zRemote control (=225)
zRemote switch (=225)
zShooting information display
(=514)
zGrid display (=515)
zError codes (=577)
24
Index to Features
Exposure
zExposure compensation with
M+ISO Auto (=113)
zExposure compensation (=142)
zAEB (=143)
zExposure simulation (=156)
zAE lock (=219)
zSafety shift (=533)
Flash
zBuilt-in ash (=286)
zFlash exposure compensation
(=288)
zFE lock (=289)
zBuilt-in ash function settings
(=294)
zExternal ash function settings
(=296)
zExternal ash custom function
(=300)
zExternal ash (=302)
Movie Recording
zAutoexposure recording (=234)
zManual exposure recording
(=236)
zHDR movie (=241)
zMovie recording size (=243)
zSound recording (=250)
zWind lter (=250)
zAttenuator (=251)
zMicrophone (=251)
zTime-lapse movie (=252)
zVideo snapshot (=263)
zMovie Servo AF (=273)
zMovie Servo AF track sensitivity
(=275)
zMovie Servo AF speed (=276)
zRemote control shooting (=278)
zISO speed (movie) (=279)
zHDMI output (=280)
zAuto slow shutter (=281)
25
Index to Features
Playback
zImage review time (=129)
zSingle-image display (=306)
zTouch playback (=308)
zMagnied view (=309)
zIndex display (=310)
zMovie playback (=311)
zEditing a movie’s rst and last
scenes (=315)
zFrame Grab (4K) (=317)
zStill photo extraction (RAW burst
images) (=321)
zViewing images on a television
(=323)
zProtect (=325)
zImage rotation (=328)
zErasing (=329)
zRating (=360)
zSlide show (=363)
zSetting image search conditions
(=365)
zImage browsing (Jump display)
(=367)
zPlayback information display
(=369)
zHighlight alert (=371)
zAF point display (=372)
zGrid display (=373)
zHDMI resolution (=511)
zHDR output (=512)
zShooting information display
(=590)
Image Editing
zCreative lters (=340)
zRAW image processing (=343)
zRed-eye correction (=352)
zVideo snapshot album (=353)
zCropping JPEGs (=356)
zResizing JPEGs (=358)
Print Ordering
zPrint order (DPOF) (=333)
zPhotobook Set-up (=337)
Customization
zCustom shooting mode (=521)
zCustom Functions (C.Fn) (=528)
zCustom button operations
(=537)
zCustom dial operations (=542)
zMy Menu (=546)
26
Index to Features
Sensor Cleaning and Dust Reduction
zDust Delete Data Acquisition
(=176)
zSensor cleaning (=505)
zManual sensor cleaning (=507)
Software
zDownloading and Installing
(=552)
zSoftware Instruction Manuals
(=553)
Wireless Features
zConnect to smartphones (=381)
zAuto send images to smartphones
(=396)
zRemote control (EOS Utility)
(=410)
zAuto send images to computers
(=415)
zPrint from Wi-Fi printers (=418)
zUpload to Web service (=428)
zConnect to Wireless Remote
(=448)
zGeotagging Images (=457)
zClear wireless settings (=462)
27

Safety Instructions

Be sure to read these instructions in order to operate the product safely. Follow these instructions to prevent injury or harm to the operator of the
product or others.
WARNING
zKeep the product out of the reach of young children.
A strap wrapped around a person’s neck may result in strangulation. The parts or provided items of cameras or accessories are dangerous if swallowed. If swallowed, seek immediate medical assistance. The battery is dangerous if swallowed. If swallowed, seek immediate medical
assistance.
z Use only power sources specied in this instruction manual for use with the product. zDo not disassemble or modify the product. zDo not expose the product to strong shocks or vibration. zDo not touch any exposed internal parts. zStop using the product in any case of unusual circumstances such as the presence
of smoke or a strange smell.
zDo not use organic solvents such as alcohol, benzine or paint thinner to clean the
product.
z Do not get the product wet. Do not insert foreign objects or liquids into the product. zDo not use the product where ammable gases may be present.
This may cause electric shock, explosion or re.
zDo not leave a lens or a camera with a lens attached, exposed without the lens cap
attached.
The lens may concentrate the light and cause re.
zDo not touch the product connected to a power outlet during lightning storms.
This may cause electric shock.
zObserve the following instructions when using commercially available batteries or
provided battery packs.
Use batteries/battery packs only with their specied product.
Do not heat batteries/battery packs or expose them to re.
Do not charge batteries/battery packs using non-authorized battery chargers.
Do not expose the terminals to dirt or let them come into contact with metallic pins
or other metal objects.
Do not use leaking batteries/battery packs.
When disposing of batteries/battery packs, insulate the terminals with tape or other means.
This may cause electric shock, explosion or re. If a battery/battery pack leaks and the material contacts your skin or clothing, ush the exposed area thoroughly with running water. In case of eye contact, ush thoroughly with copious amounts of clean running water and seek
immediate medical assistance.
28
Denotes the risk of serious injury or death.
:
Safety Instructions
zObserve the following instructions when using a battery charger or AC adapter.
Periodically remove any dust buildup from the power plug and power outlet using a
dry cloth.
Do not plug in or unplug the product with wet hands.
Do not use the product if the power plug is not fully inserted into the power outlet.
Do not expose the power plug and terminals to dirt or let them come into contact
with metallic pins or other metal objects.
zDo not touch the battery charger or AC adapter connected to a power outlet during
lightning storms.
zDo not place heavy objects on the power cord. Do not damage, break or modify the
power cord.
zDo not wrap the product in cloth or other materials when in use or shortly after use
when the product is still warm in temperature.
zDo not unplug the product by pulling the power cord. zDo not leave the product connected to a power source for long periods of time. zDo not charge batteries/battery packs at temperatures outside the range of 5–40 °C
(41–104 °F).
This may cause electric shock, explosion or re.
zDo not allow the product to maintain contact with the same area of skin for extended
periods of time during use.
This may result in low-temperature contact burns, including skin redness and blistering, even if the product does not feel hot. The use of a tripod or similar equipment is recommended when using the product in hot places and for people with circulation problems or less sensitive skin.
zFollow any indications to turn off the product in places where its use is forbidden.
Not doing so may cause other equipment to malfunction due to the effect of electromagnetic waves and even result in accidents.
29
Safety Instructions
CAUTION:
zDo not re the ash near the eyes.
Denotes the risk of injury.
It may hurt the eyes.
zDo not look at the screen or through the viewnder for prolonged periods of time.
This may induce symptoms similar to motion sickness. In such a case, stop using the product immediately and rest for a while before resuming use.
zFlash emits high temperatures when red. Keep ngers, any other part of your body,
and objects away from the ash unit while taking pictures.
This may cause burns or malfunction of the ash.
zDo not leave the product in places exposed to extremely high or low temperatures.
The product may become extremely hot/cold and cause burns or injury when
touched.
zStrap is intended for use on the body only. Hanging the strap with any product
attached on a hook or other object may damage the product. Also, do not shake the product or expose the product to strong impacts.
zDo not apply strong pressure on the lens or allow an object to hit it.
This may cause injury or damage to the product.
zOnly mount the product on a tripod that is sufciently sturdy. zDo not carry the product when it is mounted on a tripod.
This may cause injury or may result in an accident.
zDo not touch any parts inside the product.
This may cause injury.
zIf any abnormal skin reaction or irritation occurs during or following the use of this
product, refrain from further use and get medical advice/attention.
30
Loading...
+ 576 hidden pages
