Canon 0571C005 Instruction manual
• Get closer and fill the frame with your subject
• High-performance focusing for photos and movies
• Stay informed, with a built-in lens information display
• Superb image quality from an advanced optical
design
• Compact design you can take everywhere
Product Range
EF 70-300mm F/4-5.6 IS II USM
EF 70-200mm f/4L USM
EF 75-300mm f/4-5.6 III
EF 75-300mm f/4-5.6 III USM
EF-S 55-250mm f/4-5.6 IS STM
EF 70-300mm F/4-5.6 IS II USM
EF 70-200mm f/4L USM
EF 70-200mm f/4L IS USM
EF 70-300mm f/4-5.6L IS USM
EF 70-300mm F/4-5.6 IS II USM
EF-S 55-250mm f/4-5.6 IS STM
Superb performance when
shooting from a distance
Get closer and capture the detail
of distant subjects. Ideal for
outdoor sports and wildlife
photography whatever EOS
camera you shoot with.
EF 70-300mm F/4-5.6 IS II USM
Technical Specifications
Canon Inc.
canon.com
Canon Europe
canon-europe.com
English Edition
Canon Europa NV 2016
Optical Features/Specifications
Angle of view (horzntl, vertl, diagnl) 29º - 6º 50',19º 30' - 4º 35',34º - 8º 15'
Lens construction (elements/groups) 17/12
No. of diaphragm blades 9
Minimum aperture
1
32 – 45
Closest focussing distance (m) 1.2
Maximum magnification (x) 0.25 (at 300 mm)
Distance Information Yes
Image stabilizer 4-stops
AF actuator Nano USM
Physical Specifications
Filter diameter (mm) 67
Max. diameter x length (mm) 80 x 145.5
Weight (g) 710
Accessories
Lens cap E-67II
Lens hood ET-74B
Lens case/pouch LP1222
Rear cap Lens Dust Cap E
Magnification with Extension Tube EF12 II 0.25 - 0.17
Magnification with Extension Tube EF25 II 0.47 - 0.38
Extender Compatibility Not Compatible
Get closer and capture the detail of distant subjects. Ideal
for outdoor sports and wildlife photography whatever EOS
camera you shoot with.
Sales Start Date: November 2016
Product Details:
Product Name Mercury Code EAN Code Recommended Retail Price
EF 70-300mm F/4-5.6 IS II USM 0571C005AA 4549292037708 <Please fill in RRP>
Measurement / Logistic Information:
Product Name Mercury Code Pack
type
Pack description Quantity
per pack
Length
(mm)
Width
(mm)
Height
(mm)
Net Weight
(kg)
Gross
Weight (kg)
EF 70-300mm F/4-5.6 IS II USM 0571C005AA EA Each 1 137 137 247 0.734 1.0172
CT Carton 6 432 294 286 6.10 7.03
EP Euro Pallet 108 1200 800 1008 137
Layers per Pallet 3
Cartons per Layer 6
Lens Hood ET-74B 0578C001AA EA Each 1 99 84 101 0.057 0.092
CT Carton 24 445 296 243 2.2 1 2.77
EP Euro Pallet 576 1200 800 1122 76.50
Layers per Pallet 4
Cartons per Layer 6
What’s in the box?
• EF 70-300mm F/4-5.6 IS II USM
• Lens cap E-67II
• Lens dust cap E
• Instruction Manual
• Warranty card
Superb performance when shooting
from a distance
Footnotes
[1]
Minimum aperture if using 1/3 stop increments
Optional Accessories :
Product Name Mercury Code EAN Code Recommended Retail Price
Lens Hood ET-74B 0578C001AA 4549292037746 <Please fill in RRP>
