Candy CY2104-16S User Manual
W.MACHINE/WASHER-DRYER
31000970 CY2104-16S
Service Manual
31000970 CY2104-16S 0512 (17/03/2005)
Ricambio
Part No.
Piece
Ref. Descrizione - Description - Beschreibung - Descripcion
2 Programs disc 41014633 0648 (01/12/2006)
2 Programs disc 41015946 0648 (01/12/2006)
14h Therm/potent. knob spring 41013044 0648 (01/12/2006)
15 Cam disc 91602569 0648 (01/12/2006)
19a Button 0/1 41013656
31 Control panel 41015446
32 Dispenser drawer front 41014566
40 Insert 41013917
47 Table top front frame 91602091
48 R/H side frame 91601694
48a L/H side frame 91601695
49 Top rear frame 91601681
51 Work top 90489680
E-Teil
Pieza
Inizio
Beginning
Debut
Begin
Inicio
Fine
Ending
Fin
End
Fin
60 Hinge 91700102
62 Door surround 41013807
65a Door catch with spring service pack 49005361
67 Glass door with frame 41014742
67d Counter ring 41013808
76 Cabinet assy 41003254
77 Rear panel 90481367
78 Socle 41006148
79 Rear foot 90481375
80 Front foot 91671122
94d Filter w/knob without screw 41004157
97c Stopper x drain/recycle pump 91941774
97d Filt hous w/filter cartridge 49002227
101 Dispenser drawer 41000142 0648 (01/12/2006)
101 Dispenser drawer 41021547 0648 (01/12/2006)
103 Rack 91602943 0648 (01/12/2006)
109 Dispenser bottom section assy 91671224
109b Dispenser bottom section 41021545 0648 (01/12/2006)
110 Dispenser top section 41021549 0648 (01/12/2006)
Copyright 2007 Gias S.r.L.
31000970 CY2104-16S 0512 (17/03/2005)
Ricambio
Part No.
Piece
Ref. Descrizione - Description - Beschreibung - Descripcion
112 Distribution connecting rod 92884212 0648 (01/12/2006)
113 Lever 91602939 0648 (01/12/2006)
114 Driving lever 41000950 0648 (01/12/2006)
114a Hose clip 92470061
116 Cam 92621614 0648 (01/12/2006)
118 Spring 92483148 0648 (01/12/2006)
131 Hose clip 90249756
132 Valve hose cold water 90482365 0648 (01/12/2006)
132 Valve hose cold water 41021552 0648 (01/12/2006)
134 Solenoid valve 90450750 0648 (01/12/2006)
134 Solenoid valve 41021555 0648 (01/12/2006)
138 Drain hose 92693373
138a Drain house elbow 92689587
E-Teil
Pieza
Inizio
Beginning
Debut
Begin
Inicio
Fine
Ending
Fin
End
Fin
138b Hose clamp 92895051
142 Fill hose 92250869
151b Motorized selector 22 settings 41003735 0648 (01/12/2006)
151g selector 22 settings 41014503 0648 (01/12/2006)
153 Pressure switch 41008943 0541 (03/10/2005)
153 Pressure switch 41016044 0541 (03/10/2005)
157 Harness 41014812 0648 (01/12/2006)
157 Harness 41022622 0648 (01/12/2006)
157u 16 Way flat cable 41012505
161d Drain/recycle pump complete 41005956
162 Door safety device 91201208 0527 (01/07/2005)
162 Door safety device 41016879 0527 (01/07/2005)
164 Anti jamming filter radio 91212795 0648 (01/12/2006)
164 Anti jamming filter radio 91200098 0648 (01/12/2006)
202 Drum 91750615
203 Tub 41005500
204a Front flange 41006951
205 Drum shaft assy 92994862
211 Bolt 92419498
213a Spring 92436781
215 Tub gasket 92131689
Copyright 2007 Gias S.r.L.
