Candy CWB 110 User Manual

Washing machine Instructions for use

CWB 110

Contents Page

Introduction 2
General delivery notes 4
Safety notes 4
Quick start 5
Description of controls 6
Programme Table 12
Programme selector 14
Detergent drawer 16
Detergents, washing aids and amounts to use 17
Useful advice for the user 19
The main wash 20
Cleaning and routine maintenance 22
Investigating malfunctions 23
Technical data 25
Setting up + installation 26

BEFORE SWITCHING ON THE APPLIANCE MAKE SURE
IT IS CORRECTLY INSTALLED AND THAT THE TRANSIT
BRACKETS ARE REMOVED AS SHOWN IN PAGE 26.

Introduction

Please read these instructions for use carefully and all other information enclosed with the
washing machine.
Keep all documentation in a safe place for future reference or for any future owners.

Note: this machine is solely for domestic use.

Notes on disposal

All packaging material used is environmentally-friendly and recyclable. Please help dispose of
the packaging via environmentally-friendly means.

Your supplier or local council will be able to give you
details of current means of disposal.

Valuable materials can be salvaged from an old appliance via scrap reprocessing.

Note: pull out the mains plug from any old appliance.
Cut the power cable and dispose of it, together with the
plug.

When disposing of an old washing machine, please ensure that the door lock is rendered
inoperable to prevent children shutting themselves in the appliance.

2 3

M) N.B!

If the appliance is installed on a carpeted floor ensure that the ventilation holes on the
base of the appliance are not obstructed.

N) If the appliance is not running properly or breaks down, switch it off, turn off the tap and do

not tamper with the appliance.
Consult only the Authorised Technical Support Service for possible repair and ask them to
use original spare parts.
Failure to comply with the above can compromise the safety of the appliance.

O) If the appliance’s power cable should ever need replacing, consult the Authorised

Technical Support Service

Quick start

Washing

- Open the door by using the button “A” (Fig. 1, page 6)

- Select laundry and put it in the machine

- Close the door

- Put detergent in the compartments as indicated in the programme guide in this instruction
manual

- Select programme

- Wait for the “STOP” indicator light to flash

Press additional function buttons (if required)

- Press the “Start/Pause” button (page 7)

- After few seconds the appliance starts working.

After washing

- The indicator light “STOP” will go on.

- Wait for the door lock to be released
(about 2 minutes after the programme has finished).
The “Door Security” indicator light will go out.

- Switch off the washing machine by turning the selector
to “OFF” position.

- Open the door and remove the laundry.

Ensure that the machine is correctly installed in line with the instructions found on page 26.

General delivery notes

Please check that the following items are delivered with the appliance:

- Instruction manual

- Certificate of guarantee

- Inlet hose

- Liquid detergent or liquid bleach compartment
Check that no damage has occurred during transit, and if so, call your nearest Authorised
Technical Support Service agent.

Safety notes

Note:
for cleaning or maintenance of the washing machine.

A) Pull out the plug
B) Turn off the tap
C) Candy equips all its appliances with earthing. Ensure that the mains supply is earthed,

and if it is not, seek assistance from a qualified person.

D) Do not touch the appliance when hands or feet are wet or damp. Do not use the appliance

with bare feet.

E) The use of adapters, multiple connectors and/or extensions is not recommended.

Note:
water temperature can reach 90°C during the wash cycle.

F) Check there is no water left in the drum before opening the door.
G) Do not allow children or unauthorised persons to use the appliance without supervision.
H) Do not pull the power cable or the appliance itself to remove the plug from the socket.
I) The appliance must not be exposed to weather conditions (rain, direct sun, etc...)
L) When moving the appliance never lift it by the controls or by the detergent drawer.

When in transit never rest the door against the trolley or transport the appliance without

the polystyrene base.

4 5

6

Description of controls

Door open button A
Door locked indicator light B
Start button C
Start Delay button D
Super rapid button E
Extra Rinse button F
Crease guard button G
Spin speed control H
Wash Temperature Control Knob I
“Time to end” indicator light L
Buttons indicator light M
Timer knob for wash programmes with OFF position N
Detergent drawer P

7

DOOR SECURITY indicator light

The “Door Security” indicator light is illuminated when the door is fully closed and the machine is ON.
When "Start/Pause" is pressed on the machine with the door closed the indicator will flash
momentarily and then illuminate.

If the door is not closed the indicator will continue to flash.

Aspecial safety device prevents the door from being opened immediately after the end of the cycle.
Wait for 2 minutes after the wash cycle has finished and the “Door Security” light has gone out
before opening the door. At the end of the cycle turn the programme selector to "OFF" .

B

NOTE: When the "Start/Pause" button has been pressed,
the appliance can take few seconds before it starts
working.

START/PAUSE button

When a programme is selecting, wait for the “STOP” indicator
light to flash before pressing the "Start/Pause" button.

Press to start the selected cycle (according to the selected cycle one indicator lights will go on) .

Changing the settings after the programmes has started (PAUSE)

The programme may be paused at any time during the wash cycle by holding down the
"Start/Pause" button for about two seconds. When the machine is in the paused mode, the
indicator light "Time to end" and option buttons will flash.
To restart the programme, press the "Start/Pause" button once again.
If you wish to add or remove items during washing, wait 2 minutes until the safety device
unlocks the door.
When you have carried out the manoeuvre, close the door, press "Start/Pause" button and
the appliance will continue working where it left off.

CANCELLING THE PROGRAMME
To cancel the programme the programme selector should be rotated to the "OFF" position.

C

Fig. 1

Door open button

Important:
a special safety device prevents the door from opening at the end of the wash/spin cycle. at
the end of the spin phase wait up to 2 minutes before opening the door.

A

C

D

E

P

I

G

F

N

B

A

H

L

M

8

SUPER RAPID button

Pressing this button reduces the time of the wash programme by a maximum of 50 minutes
depending on the programme and the temperature selected. The "Super Rapid" button can
be used for washing loads of 1 to 5,5 kg. This option may only be utilised on COTTONS and

SYNTHETICS programmes.

E

START DELAY BUTTON

Appliance start time can be set with this button, delaying the star by 3, 6 or 9 hours.
Proceed as follow to set a delayed start:
Select a programme (“STOP” indicator light blinks)
Press Start Delay button (each time the button is pressed the start will be delayed by 3, 6 or
9 hours respectively and the corresponding light will blink).
Press START to commence the Start Delay operation (the indicator light associated with the
selected Start Delay time stops blinking and remains ON).
At the end of the required time delay the programme will start.

To cancel the Start Delay function :
press the Start Delay button until the indicator lights will be off (The STOP light blinks) and
the programme can be started manually using the START button or switch off the appliance
by turning the programme selector to off position.

D

9

EXTRA RINSE BUTTON

Thanks to the new electronic system, acting on the button is possible to effect a new special
rinse cycle. The addition of a lot of more water and the new action combined of cycles of
rotation of the drum with load and unloading of water, allow to get laundry perfectly rinsed.
This function has been studied for the people with delicate and sensitive skin, for which also a
least residue of detergent can cause irritations or allergies.
It advises to also use this function for the children items and in case of washings of very dirty
items, for which it is due to use a lot of detergent, or in the washing of towelling items whose
fibers mostly have the tendency to hold the detergent.
This button is not available in the Wool/Hand wash programmes.

F

The option buttons should be selected before pressing
the "Start/Pause" button.

G

CREASE GUARD button

Press the button to select or deselect this function.
The Crease Guard function minimizes creases as much as possible with a uniquely designed
anti-crease system that is tailored to specific fabrics.

MIXED FABRICS - the water is gradually cooled throughout the final two rinses with no
spinning and then a delicate spin assures the maximum relaxation of the fabrics.

DELICATE FABRICS – final two rinses with no spinning and then the fabrics are left in water
until it is time to unload. When you are ready to unload, press the "Crease Guard" button –
this will drain.

WOOLLENS/HAND WASH – after the final rinse the fabrics are left in water until it is time to
unload and the button indicator blinking.

When you are ready to unload, press the "Crease Guard" button, this will drain and spin
ready for emptying.

If you do not want to spin the clothes and activate drain only:

- Turn the programme selector to the "OFF" position;

- Select programme drain only ;

- Switch on the appliance again by pressing the "Start/Pause" button.

PROGRAMME selector with "OFF" position

Rotates in both directions.
The machine is turned on by selecting a
programme via the programme selector.
This status will be indicated by the
"STOP" indicator light flashing, this light
will continue to flash until the machine
has started or the machine is returned to
the "OFF" position.

Press the "Start/Pause" button to start the selected cycle.
Once a programme is selected the programme selector remains stationary on the selected

programme till cycle ends.
Switch off the washing machine by turning the selector to "OFF".

Note:
The programme selector must be returned to the "OFF" position
at the end of each cycle or when starting a subsequent wash
cycle prior to the next programme being selected and started.

N

11

Buttons indicator light

The indicator light around the option buttons will light when specific options are selected.

M

TIME TO END indicator light

In order to manage your time better, this washing machine features an indicator light system
that keeps you constantly informed on the remaining cycle time.

Indicator light START:

Remaining time above 60 minutes.

Indicator light 60:

Remaining time less than 60 minutes.

Indicator light 30:

Remaining time less than 30 minutes.

Indicator light 15:

Remaining time less than 15 minutes.

Indicator light STOP:

End of the programme.

L

10

WASH TEMPERATURE CONTROL KNOB

ROTATES IN BOTH DIRECTIONS

With this device it is possible to reduce, but no increase
washing cycle temperature.
The table of programmes indicate the maximum temperature
advised for each type of wash.

WARNING: THIS TEMPERATURE MUST NEVER BE
EXCEEDED

I

VARIABLE SPIN SPEED selector

Can be turned in either direction

The spin stage plays a very important role in preparing the
laundry for efficient drying and your model offers maximum
flexibility to suit all your requirements.
The selector can be turned to reduce the maximum spin
speed, right up to eliminating the spin completely (position ).
In programmes for mixed fibres, synthetics and delicates,
the washing machine automatically lowers the spin speed.
In order not to damage fabrics, it is not possible to increase this spin speeds.

Note: this model is fitted with an electronic device that
checks the load is balanced correctly. If the load is slightly
unbalanced the machine will re-balance it automatically to carry
out the normal spin.
If, after several attempts, balance is not restored, a reduced spin
speed will be used.
If loads are seriously unbalanced the spin stage will be cancelled.
This helps limit vibration, reduce noise output and improve the
washing machine’s lifespan.

H
