Calix GS4227E User Manual

NOTE: This Safety and Regulatory Statements Guide applies to all GigaSpire devices that may or may not include a Wi-Fi radio. Disregard

any statements made here if the feature or function is not present on any particular model.

Calix Safety and Regulatory Statements - GigaSpire

Before you Begin

IMPORTANT SAFETY INSTRUCTIONS

When using your equipment, basic safety precautions should always be followed to reduce the risk of fi re, electric shock, and injury to
persons, including the following:

• Read all the instructions listed here and/or in the user manual before you operate this device. Give attention to all safety precautions.
Retain the instructions for future reference.

• Always use caution when handling live electrical connections.

• Do not install electrical equipment in wet or damp conditions.

• Ensure that the power source for the system is adequately rated to assure safe operation and provides current overload protection.

• Do not allow anything to rest on the power cable, and do not place this product where people will stand or walk on the power cable.

• To avoid electric shock caused by over-voltage from the PSTN, DO NOT connect the POTS port on this unit directly to any external PSTN
line.

• Children: Do not allow children to play with the GigaSpire. It contains small parts that could become detached and create a choking
hazard.

• This unit must only be used with the certifi ed power adapter model inside the package, which complies with the requirement of a limited
power source.

• Installation of this device must be in accordance with national wiring codes and conform to local regulations and electrical codes.

• Do not use any accessories other than those approved by the manufacturer or your service provider. Use of non-original or non-approved
accessories may result in loss of performance, damage to the product, fi re, electric shock or injury, and may violate regulations. The
warranty does not cover product failures that have been caused by use of non-original or non-approved accessories.

• It is recommended that the customer install an AC surge protector in the AC outlet to which this device is connected. This is to avoid
damaging the device by local lightning strikes and other electrical surges.

• The minimum distance between the user and/or any bystander and the radiating structure of the transmitter varies based on the country
where it is deployed. For US deployments, 27 cm is the minimum distance while Canada requires a minimum of 33 cm.

• The pluggable external power supply provided with the unit should be mounted indoors. If other power supplies are employed, they
should be LISTED ITE with a Limited Power Source (LPS) output or LISTED with a National Electric Code (NEC) Class 2 output.

• All installation methods shall be in accordance with national and local regulations and practices. The wiring method should include the
use of Listed wire/cable acceptable for the application per the National Code, and should be one that an Authority Having Jurisdiction
(AHJ) can approve per the Code.

• For US products, no wiring to the product should be exposed in lengths beyond 140 feet, as the circuits should avoid exposure to acci­dental contact with lightning and power conductors in accordance with NEC Article 725-57 (NEC 2005). The installer should also consider
Articles 210, 240, 250, 770, and 810 of the NEC.

ENVIRONMENTAL CONDITIONS

• Maximum environmental values during use:

• Temperature: 0° C to +40° C (32° to 104° F), Humidity: 10% to 90% RH, non-condensing, -200 to 10,000 feet altitude.

REQUIRED SAFETY STATEMENTS

• Potentially Explosive Atmosphere: Do not use the GigaSpire in an area where a potentially explosive atmosphere exists.

• Atmosphère potentiellement explosive: N’utilisez pas le GigaSpire dans un endroit où existe une atmosphère potentiellement explosive.

• Intended Use: This product is classifi ed as telecommunication equipment not intended for direct purchase by the public.

• This product is designed and approved for use in an indoor location only.

CAUTION! Use of any controls, adjustments, or procedures other than those specifi ed herein may
result in hazardous radiation exposure.

!

• Utilisation prévue: Ce produit est classé comme équipement de télécommunication non destiné à l’achat direct par le public. Ce produit
est conçu et approuvé pour utilisation en intérieur uniquement.

MISE EN GUARDE ! L’utilisation de contrôles, réglages ou procédures autres que ceux spécifi és
dans ce manuel peut entraîner une exposition dangereuse à des rayonnements.

!

• Connect the power supply cord only to an AC power outlet that meets GigaSpire specifi cations.

• Never alter the AC power cord. If necessary, have the correct outlet installed by a qualifi ed electrician or call your service provider for
assistance.

• To reduce the risk of damage to the electric cord, remove it from the outlet by holding onto the AC power adapter rather than the cord.

• Make sure the cord is positioned so that it will not be stepped on, tripped over, or otherwise subjected to damage or stress.

WARNING! Do not use any other power adapter except the one that accompanies this unit or a
power supply identifi ed in the list below. Use of another adapter could result in damage to the unit.

!

To prevent electrical shock, please do not open the cover. The following power adapter is qualifi ed
for use with this GigaSpire.

This GigaSpire must be powered by

Frecom F60-120500SPA or equivalent

UL Listed LPS power source rated at:

Input: 100-240 VAC, 50-60 Hz, 1.6A Max,

Output: Nominal 12 VDC, 5A Max, 60W Max

P/N 220-01099 Rev 12

www.calix.com

ALIMENTATION ÉLECTRIQUE

• Connectez le cordon d’alimentation uniquement à uneprise d’alimentation CA conforme aux spécifi cations GigaSpire.

• Ne modifi ez jamais le cordon d’alimentation CA. Si nécessaire, faites installer la bonne prise par un électricien qualifi é ou appelez votre
fournisseur de servicepour obtenir de l’aide.

• Pour réduire le risque d’endommager le cordon électrique, retirez-le de la prise en le tenant par la fi che moulée de l’adaptateur secteur
plutôt que par le cordon.

• Assurez-vous que le cordon est positionné de sorte qu’il ne puisse pas marcher dessus, trébucher ou subir

• d’autres dommages ou contraintes.

Attention ! N’utilisez pas d’autre adaptateursecteur que celui qui accompagne cet appareil ou une
alimentation électrique autre que celle identifi ée dans la liste ci-dessous. L’utilisation d’un autre adap-

!

tateur pourrait endommager l’appareil. Pour éviter les chocs électriques, n’ouvrez pas le couvercle.
L’adaptateur électrique suivant est qualifi é pour être utilisé avec le GigaSpire.

L’adaptateur électrique suivant est qualifi é

pour être utilisé avec le GigaSpire

Frecom F60-120500SPA ou une source d’alimentation équivalente certifi ée UL LPS de capacité:

Ce GigaSpire doit être alimenté par un adapteur

Entree: Input: 100-240 VAC, 50-60 Hz, 1.6A Max,

Sortie: Valeur nominale 12 VDC, 5A Max, 60W Max

Federal Communications Commission (FCC)

INTERFERENCE STATEMENT

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected.

• Consult the dealer or an experienced technician for help.

CAUTION: Any changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to

CAUTION: This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter except

ADDITIONAL CONSIDERATIONS

The country code selection is for non-US models only and is not available on any US models. Per FCC regulations, all Wi-Fi products
marketed in the US must be fi xed to US operational channels only.

RF FREQUENCY REQUIREMENTS

This device is for indoor use only when using all channels in the 5.150 GHz - 5.250 GHz and 5.725 GHz - 5.850 GHz frequency range. High
power radars are allocated as primary users of the 5.250 GHz - 5.350 GHz and 5.470 GHz - 5.725 GHz bands. These radar stations can
cause interference with and/or damage this device. It is restricted to indoor environment only.

FCC RADIATION EXPOSURE STATEMENT

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed
and operated with a minimum distance of 27cm between the radiator & your body.

operate this equipment.

in accordance with FCC multi-transmitter product procedures.

Industry Canada Requirements - English

The manufacturer declares that this product is in conformity with the requirements and other relevant provisions of the following Canadian
standards:

• CAN ICES-3 (B)/NMB-3(B)

• This device complies with ISED’s licence-exempt RSS standards. Operation is subject to the following two conditions:

(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired operation of the device.

CAUTION:

(i) The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to

co-channel mobile satellite systems;

(ii) The maximum antenna gain permitted for devices in the band 5725-5825 MHz shall comply with the e.i.r.p. limits specifi ed for

point-to-point and non-point-to-point operation as appropriate.

(iii) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5650-5850

MHz and that these radars could cause interference and/or damage to LE-LAN devices.

- 2 -
