Cafina c5 Installation Manual

Download

OPERATING INSTRUCTIONS

c 5

Item no. : Cafina - 2954076

Item no. : Melitta SystemService - 2954082

OI c5 eng V9 / 18.08.2006 © Cafina / Melitta

OPERATING INSTRUCTIONS

RETAIN FOR FUTURE USE !

The copyright of these Operating Instructions, which are entrusted to the recipient personally, remains with the Cafina / Melitta company.

The content may not be disclosed or made available to any third party without the express consent of the Cafina / Melitta company.

These Operating Instructions must be read and applied by anyone performing work with or on the equipment described.

In particular, it is imperative that all such persons familiarise themselves with the safety instructions.

TABLE OF CONTENTS

1 Description

1.1 Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1

1.1.1 External parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1

1.1.2 Internal parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2

1.2 Mode of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.2 "Installed EF milk cooler" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.3 "External FC milk cooler" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.4 "Draw hot water" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.5 "Draw steam" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.6 "cw cup warmer" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.7 "Second coffee bean grinder" option . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.8 "Raised bean hopper" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.9 "Bean hopper lockable" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.10 "Milk level monitoring" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.11 "Raised feet" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.12 "Waste water container level monitoring" option . . . . . . . . . . . . . . . . 1 - 4

1.2.13 Shift function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.14 TWIN function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.15 Key cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.1 "user" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.2 "manager" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.3 "memory" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.4 "free vend" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.5 "vip" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.6 "external" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.7 "key lock" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.8 "engineer" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.3 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 6

1.3.1 Coffee maker types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 6

1.3.2 Machine identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 7

1.3.2.1 Switzerland . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 7

1.3.2.2 Export . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 7

1.3.3 Dimensions and weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 8

1.3.4 Filling data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 8

1.3.5 Operating performance data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 9

1.3.6 Environmental conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 9

1.3.6.1 Temperature and humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 9

1.3.6.2 Space requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 9

OI c5 eng V9 / 18.08.2006 i © Cafina / Melitta

TABLE OF CONTENTS

2 Safety instructions

2.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1

2.1.1 Warnings symbols used (depending on nationality) . . . . . . . . . . . . . 2 - 1

2.1.2 Places where warning symbols

are affixed (depending on nationality) . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1

2.1.3 Safety information in these Operating Instructions . . . . . . . . . . . . . . 2 - 1

2.2 Basic safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1.2 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1.3 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1.4 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.2 Specific hazards and instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 3

2.2.2.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 3

2.2.2.2 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5

2.2.2.3 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5

2.2.2.4 Key cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 6

2.2.3 Personal safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 6

2.3 Safety mechanisms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.3.1 Power switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.3.2 Pressure relief valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.4 Authorised persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.4.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.4.2 Areas of responsibility of personnel . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.4.2.1 Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.4.2.2 User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

2.4.2.3 Maintenance personnel (service technician) . . . . . . . . . . . . . . 2 - 8

2.4.3 Minimum training and qualifications of authorised personnel . . . . . . 2 - 8

2.4.3.1 Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

2.4.3.2 User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

2.4.3.3 Maintenance personnel (service technician) . . . . . . . . . . . . . . 2 - 8

2.5 Maintenance duty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

2.6 Availability of these Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

TABLE OF CONTENTS

3 Controls and indicators

3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 1

3.2 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 3

4 Initial start-up

4.1 Normal initial start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.1.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.1.2 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.1.3 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.2 Return to service after the machine

has been out of service for a limited time . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.2.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.2.2 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.2.3 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.3 Return to service after a fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2

4.3.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2

4.3.2 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2

4.3.3 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2

5Operation

5.1 Power supply connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

5.1.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

5.1.2 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

5.1.3 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

5.1.4 Temperature regulator unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2

5.1.4.1 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2

5.1.4.2 Brief description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2

5.1.4.3 Cooling operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2

5.1.4.4 Checking the desired milk temperature . . . . . . . . . . . . . . . . . . 5 - 3

5.1.4.5 Programming the desired milk temperature . . . . . . . . . . . . . . 5 - 3

5.2 Water connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

5.2.1 Water intake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

5.2.2 Water drainage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

5.3 Switching on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 5

5.3.1 Switching on the c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 5

5.3.2 Switching off the c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6

5.3.3 Switching the cw cup warmer on and off . . . . . . . . . . . . . . . . . . . . . . 5 - 8

OI c5 eng V9 / 18.08.2006 iii © Cafina / Melitta

TABLE OF CONTENTS

5.4 Dispensing of beverages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9

5.4.1 Dispensing normal coffee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9

5.4.1.1 General sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9

5.4.1.2 Dispensing a level 1 beverage . . . . . . . . . . . . . . . . . . . . . . . 5 - 10

5.4.1.3 Dispensing a level 2 beverage . . . . . . . . . . . . . . . . . . . . . . . 5 - 12

5.4.2 Dispensing decaffeinated coffee . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 14

5.4.3 Dispensing milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 15

5.4.4 Dispensing of hot water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 16

5.4.5 Drawing steam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 17

5.4.6 Frothing milk manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 18

5.5 Routine work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 19

5.5.1 Refilling fresh water canister . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 19

5.5.2 Emptying the waste water canister . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 19

5.5.3 Refill coffee beans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 20

5.5.4 Refill milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 22

5.5.5 Emptying the coffee dregs drawer . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 23

5.5.6 Cleaning the drip tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 24

5.6 System work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 25

5.6.1 Control panel and button layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 25

5.6.2 Structure of the functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 26

5.6.2.1 Overview and adjustment values . . . . . . . . . . . . . . . . . . . . . 5 - 26

5.6.3 Brief description of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.1 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.2 Daily counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.3 Total counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.4 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.5 Water quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.6 Coffee quantity ±1g . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.7 Flow period hot water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.8 Pre-infusion 1 milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.9 Pre-infusion 2 milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.10 Post-infusion milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.11 Flow period milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.12 Flow period steam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.13 Price . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.14 No charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.15 Time / date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

TABLE OF CONTENTS

5.6.4 Use of the functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 29

5.6.4.1 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 29

5.6.4.2 Daily counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 29

5.6.4.3 Total counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 30

5.6.4.4 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 31

5.6.4.5 Water quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 32

5.6.4.6 Coffee quantity ±1g . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 32

5.6.4.7 Flow period water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 33

5.6.4.8 Pre-infusion 1 milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 33

5.6.4.9 Pre-infusion 2 milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 34

5.6.4.10 Post-infusion milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 34

5.6.4.11 Flow period milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 35

5.6.4.12 Flow period steam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 35

5.6.4.13 Price . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 36

5.6.4.14 No charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 36

5.6.4.15 Time / date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 37

5.6.5 Resetting to initial installation default settings . . . . . . . . . . . . . . . . . 5 - 38

5.6.5.1 Coffee maker reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 38

6 Maintenance

6.1 Maintenance schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1

6.1.1 Intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1

6.1.1.1 Cleaning intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1

6.1.1.2 Intervals between services . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2

6.2 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2

6.2.1 Cleaning work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2

6.2.2 Cleaning procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 4

6.2.2.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 5

6.2.2.2 Installed EF milk cooler / external FC milk cooler . . . . . . . . . . 6 - 7

6.3 Maintenance log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 8

7 Troubleshooting

7.1 Fault display, troubleshooting and fault acknowledgement . . . . . . . . . . . . . 7 - 1

7.2 Checklist for fault diagnosis and troubleshooting . . . . . . . . . . . . . . . . . . . . . 7 - 2

7.2.1 Textual error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 2

7.2.2 Error messages displayed via diagnosis points (DP) . . . . . . . . . . . . . 7 - 6

OI c5 eng V9 / 18.08.2006 v © Cafina / Melitta

TABLE OF CONTENTS

8 Taking out of service and storage

8.1 Taking out of service for a

limited time / taking out of service for good . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 1

8.2 Storage for a limited period / permanent storage . . . . . . . . . . . . . . . . . . . . . 8 - 1

9 Packing and transportation

10 Disposal

11 Guarantee, consumables, spare parts, ordering procedure

12 "Service Technician" maintenance log

1 Description

1.1 Design

1.1.1 External parts

1 2 3 4

5 6 7 8

9 10

DESCRIPTION

1 Installed EF milk cooler

2 Bean hoppers 1 and 2

3 Temperature regulator unit

4 Filling chute with lid

5 Liquid crystal display

6 Control panel cover

7 Shift/Stop button

8 Beverage selection buttons

13 14

16 17

9 Hot water button

10 Steam tap

11 Beverage outlet, height-adjustable

12 Drip tray with drip grille

13 Steam outlet

14 Milk cooler door

15 c5 coffee maker

16 cw cup warmer

17 "Key card" slot

18 Coffee dregs drawer

19 Hot water outlet

20 Power switch for cw cup warmer

21 Cleaning container

22 COMBI-Tabs container

23 AMC powder bag

OI c5 eng V9 / 18.08.2006 1-1 © Cafina / Melitta

DESCRIPTION

1.1.2 Internal parts

1 Liquid crystal display

2 Shift/Stop button

3 Buttons [ + , - ]

4 Navigation buttons [ Y , Z , U , V ]

5 Milk level monitoring

6 Milk container

7 Milk intake lines

DESCRIPTION

1.2 Mode of operation

1.2.1 c5 coffee maker

The c5 coffee maker is a fully automatic coffee making machine which, in the basic version, can dispense pre-programmed coffee products through a height-adjustable product outlet into the container. The beverage required is selected via five beverage selection buttons.

The beverage selection buttons employ a click pushbutton design that provides both tactile and visual feedback. Large, illuminated product fields indicate the beverage currently selected.

A filling chute enables pre-ground, decaffeinated varieties of coffee to be processed.

The c5 coffee maker exhibits the latest marks of conformity, indicating that it satisfies the necessary certification standards.

1.2.2 "Installed EF milk cooler" option

The installed EF milk cooler consists of a compressor cooling unit, a separate pump system, a temperature regulator unit and a 6 litre capacity milk container.

The milk is automatically added to the relevant coffee products. The milk cooler door can be lockable.

1.2.3 "External FC milk cooler" option

The external FC milk cooler consists of an industry-standard refrigerator.

If the c5 coffee maker is fitted with an additional external FC milk cooler, the c5 coffee maker will contain an extra pump system for the automatic addition of milk into the relevant coffee products.

For hot milk processing with integrated, fully automatic cleaning, the c5 coffee maker satisfies the HACCP hygiene requirements.

The patented, Automatic Coffeequality System (ACS) quality monitoring system continually monitors relevant parameters such as fineness of grind, coffee powder weighed-in quantity, infusion time and water temperature.

The piston system is optimally controlled via a Variable Pressure System (VPS).

The water supply can be directly connected to the water mains or to a water can.

1.2.4 "Draw hot water" option

It is possible to draw hot water in user-defined quantities by pressing a button.

1.2.5 "Draw steam" option

Steam can be drawn from the steam tap, and is continuously adjustable.

OI c5 eng V9 / 18.08.2006 1-3 © Cafina / Melitta

DESCRIPTION

1.2.6 "cw cup warmer" option

The autonomous cw cup warmer has three levels with built-in heating elements.

1.2.7 "Second coffee bean grinder" option

The second coffee bean grinder option allows a second variety of coffee to be used. Without this option, the second bean hopper is locked.

1.2.8 "Raised bean hopper" option

A higher been hopper (a unit) can be placed on top of the bean hopper(s) to increase the coffee bean capacitiy.

1.2.11 "Raised feet" option

To clean the area underneath the machines, all the machines can be fitted with raised feet.

1.2.12 "Waste water container level monitoring" option

If the c5 coffee maker is connected to fresh water and waste water cans, it is possible to monitor the level of the waste water can (see also section «5.2 Water connection, 5 - 4»). The level monitoring is coupled to the control system. The control system outputs level-specific information to the LCD.

1.2.13 Shift function

1.2.9 "Bean hopper lockable" option

Lockable versions of both the standard and raised bean hoppers are available.

1.2.10 "Milk level monitoring" option

Milk level monitoring is used in conjunction with the installed EF milk cooler. It is coupled to the c5 coffee maker control system.

Warnings on the LCD enable the user to keep an eye on the level of milk while the machine is in operation.

The five beverage selection buttons are allocated as standard at two levels with one pre-programmed beverage per level in each case.

The Shift function switches the beverage selection buttons to the second level and back again.

1.2.14 TWIN function

Normally, one pass of coffee grinding with subsequent infusion operation produces a single quantity of the selected coffee (coffee + milk) product.

With the TWIN function, one pass of coffee grinding with one subsequent infusion op- eration produces a double quantity of the selected coffee (coffee + milk) product.

The TWIN function has to be activated by the Technical Customer Service.

DESCRIPTION

1.2.15 Key cards

Key cards are needed to access the functions of the c5 coffee maker.

Functions such as switch on/switch off, counter readout or programming can only be used if one has the relevant authorised key card.

1.2.15.1 "user" key card

The "user" key card is the card of the person who operates the c5 coffee maker. This card can be configured as a multi-user card for up to six c5 coffee makers.

1.2.15.2 "manager" key card

The "manager" key card is the card of the person (manager), who uses this card to gain access to the higher-level functions. This card can be configured as a multi-user card for up to six c5 coffee makers.

1.2.15.3 "memory" key card

The "memory" key card contains all the system data for the c5 coffee maker, as it was configured at the time of (first) installation by the service technician.

The "memory" key card enables the coffee maker to be reset following an emergency.

1.2.15.4 "free vend" key card

The "free vend" key card enables beverages to be dispensed at no charge, using external billing modules.

1.2.15.5 "vip" key card

The "vip" key card enables the self-service mode to be enabled or disabled without having to delve into the programming of the c5 coffee maker.

1.2.15.6 "external" key card

The "external" key card enables external modules, such as coin-operation units or coin-checking devices, to be enabled or disabled without having to delve into the programming of the c5 coffee maker.

1.2.15.7 "key lock" key card

The "key lock" key card enables the control buttons to be locked or released without having to delve into the programming of the c5 coffee maker.

1.2.15.8 "engineer" key card

The "engineer" key card is reserved for the service technician. It allows the technician to access every area of the system software, read the statistical data and directly control hardware components for test purposes.

OI c5 eng V9 / 18.08.2006 1-5 © Cafina / Melitta

DESCRIPTION

1.3 Technical data

1.3.1 Coffee maker types

Description Standard

c5-1 XXX

c5 Office X

c5-1 W XXX X X

c5-1 C XXXXX X

c5-12 W X

c5-1 C EF XXXXX XX Optional

c5-12 C X

c5-12 C EF X

c5-1 C FC XXXXXX X

c5-12 C FC X

model

( 1 )

( 2 )

( 3 )

Shift

function

XXX Optional

XXX X

XXXX X

XXXX XX Optional

XXXX X X

TWIN

function

Hot water

outlet

Steam

out let

Separate hot

water outlet

Installed EF

milk cooler

Exter nal FC

milk cooler

monitoring

Mi lk le ve l

( 1 ) Hot water drawn through the coffee outlet

( 2 ) Coffee and hot water dispensed simultaneously

( 3 ) Coffee, hot water and steam dispensed simultaneously

Standard options

The following options can be used with every machine configuration:

- "cw cup warmer"

- "Bean hopper" (optionally lockable)

- "Second coffee bean grinder"

- "Raised bean hopper" (optionally lockable)

- "Raised feet"

The milk cooler door of the installed EF milk cooler is available in a lockable version.

DESCRIPTION

1.3.2 Machine identification

Position of identification plate

• c5 coffee maker

Switzerland and EU: Behind the coffee dregs drawer in the slide-in tray, at the top of the inside wall.

USA: On the front left-hand side.

• Installed EF milk cooler

Switzerland, EU: In the chill compartment at the top lefthand side of the inside wall.

• cw cup warmer

Switzerland, EU and USA: In the lower cup compartment at the top of the back wall.

1.3.2.1 Switzerland

CH-5502 HUNZENSCHWIL

Type

Instr. sheet Model year

Serial-No.

1.3.2.2 Export

CH-5502 HUNZENSCHWIL

Type

Water lowest level

Max. temperature

Max. overpressure

Heater power

Serial-No.

Model year

Through heater Boi ler

liters

°C

bar

Test overpressure and design comply with the Ordinance on Steam Boilers

OI c5 eng V9 / 18.08.2006 1-7 © Cafina / Melitta

DESCRIPTION

1.3.3 Dimensions and weights

Description Width [ mm ] Height [ mm ] Depth [ mm ] Weight [ kg ]

c5-1 450

c5 Of fice 450 49

c5-1 W 450 50

c5-1 C 450 50

c5-12 W 450 58

c5-1 C EF 700 90

c5-12 C 450 58

c5-12 C EF 700 94

c5-1 C FC 450 53

c5-12 C FC 450 61

cw 250 12

EF 250 26

Raised bean hopper 140

Raised feet 25.4 ( 1" )

680 600

50.8 ( 2" )

76.2 ( 3" )

101.6 ( 4" )

1.3.4 Filling data

Description Coffee

c5-1

c5 O ffice

c5-1 W

c5-1 C

c5-12 W

c5-1 C EF 6

c5-12 C

c5-12 C EF 6

c5-1 C FC

c5-12 C FC

Water intake

(fresh water container)

Water outlet

(waste water container)

cw Approx. 100 (mixed)

EF 6

Raised

bean hopper

beans:

first

bean

hopper

[ kg ]

1.4 1.4 8 20

+ 1.6 + 1.6

Cof fee beans:

second

bean

hopper

[ kg ]

Num ber

of cu ps whic h

ca n be

accommodated

Standard

size

Number

of cups which

can be

accommodated

Espresso

size

Refilling the

mi lk co ntainer

[ litres ]

Refilling the

canisters

[ litres ]

1.3.5 Operating performance data

DESCRIPTION

Description White coffee:

c5-1 2.3 kW = 170

c5 Off ice 2.3 k W = 17 0

c5-1 W 2.3 k W = 17 0

c5-1 C 6.0 kW = 20 0

c5-12 W 7.4 kW = 200 7.4 kW = 250 7.4 kW = 40

c5-1 C EF 6.1 kW = 200 6.1 kW = 250 6.1 kW = 200 6.1 kW = 30

c5-12 C 7.4 kW = 200 7.4 kW = 250 7.4 kW = 40

c5-12 C EF 6.1 kW = 200

c5-1 C FC 6.0 kW = 200 6.0 kW = 250 6.0 kW = 200 6.0 kW = 30

c5-12 C FC 7.4 kW = 200 7.4 kW = 250 7.4 kW = 200 7.4 kW = 40

c5 o utput [ kW ] = standard cups / h

3.4 kW = 200

3.6 kW = 170

7.5 kW = 200

1.3.6 Environmental conditions

Espresso:

c5 o utput [ kW ] =

Espressos / h

2.3 kW = 250

3.4 kW = 250

2.3 kW = 250

3.4 kW = 250

2.3 kW = 250

3.4 kW = 250

6.0 kW = 250

3.6 kW = 250

6.1 kW = 250

7.5 kW = 250

Cappuccino:

c5 outpu t [ kW ] =

Cappuccinos / h

6.1 kW = 200

7.5 kW = 200

Hot water:

c5 output [ kW ] =

litres / h

6.0 kW = 30

3.6 kW = 20

6.1 kW = 30

7.5 kW = 40

1.3.6.1 Temperature and humidity

 Operating and storage temperatures:

min. + 5 °C max. + 30 °C

 Operating and storage humidity:

max. 80 %

1.3.6.2 Space requirements

 Minimum space required for operation:

180 mm from the top edge of the bean hopper must be kept clear to allow for replenishment of beans.

OI c5 eng V9 / 18.08.2006 1-9 © Cafina / Melitta

DESCRIPTION

SAFETY INSTRUCTIONS

2 Safety instructions

2.1 Warnings

2.1.1 Warnings symbols used (depending on nationality)

The following warnings symbols may be affixed to the equipment.

Low voltage

• Warning of dangerous elec-

trical voltage.

• Electric shocks can lead to

serious injury or death.

• Only authorised technical

personnel may perform work on electrical installations.

• The technical safety instruc-

tions must be followed.

2.1.2 Places where warning symbols are affixed (depending on nationality)

NOTE

• The equipment comes sup-

plied with warning symbols (stickers) affixed wherever appropriate.

• If any of the warning sym-

bols should fall off during operation or following cleaning work, the operator must stick these warning symbols back again immediately.

2.1.3 Safety information in these Operating Instructions

• Unplug equipment before

carrying out any work on electrical installations.

Hot surface / hot internal components

• Warning of heat which could

lead to injury.

• Allow hot surfaces and components to cool before carrying out any work on these component parts.

• If necessary, wear heat-resistant gloves.

In these Operating Instructions, you will find the following three levels of safety information:

 Level 1

WARNING

• A warning refers to signifi-

cant hazards. Failure to follow the relevant safety instruction could lead to injury or death.

OI c5 eng V9 / 18.08.2006 2-1 © Cafina / Melitta

SAFETY INSTRUCTIONS

Depending on the type of danger, instead of STOP, one of the following symbols could be combined with the word WARNING.

WARNING

• Warning of electric shock.

WARNING

• Warning of heat.

 Level 2

CAUTION

• The CAUTION symbol

stresses important instructions. Failure to observe these instructions could lead to damage to the equipment or to other material assets.

2.2 Basic safety instructions

2.2.1 Proper use

2.2.1.1 General

Proper use includes, in addition to the specific provisions set out below, observing these Operating Instructions and complying with the supplier’s obligatory maintenance and repair instructions.

2.2.1.2 c5 coffee maker

The c5 coffee maker is used solely to dispense coffee products, coffee and milk combined products, hot water, steam and to heat and froth milk.

No other use of the c5 coffee maker will be deemed to be proper.

2.2.1.3 Installed EF milk cooler

The installed milk cooler is used exclusively to keep milk cold.

No other use of the installed EF milk cooler will be deemed to be proper.

 Level 3

NOTE

• Notes contain additional in-

formation aimed at raising the general level of safety and at lightening the user’s workload.

2.2.1.4 cw cup warmer

The cw cup warmer is intended solely to keep cups warm.

No other use of the cw cup warmer will be deemed to be proper.

2.2.2 Specific hazards and instructions

2.2.2.1 c5 coffee maker

WARNING

• Never insert either the

hands or any rod-shaped object into a bean hopper or into the filling chute while the c5 coffee maker is connected to the mains power supply.

• Only coffee beans may be

introduced to the bean hopper.

• Only ground coffee may be

introduced to the filling chute.

SAFETY INSTRUCTIONS

WARNING

• Hot air comes out from the

bottom of the steam outlet. There is a danger of scalding.

• The bottom of the steam pipe is hot after it has been giving off steam. There is a danger of burns.

• Hot liquid comes out from the bottom of the beverage outlet. There is a danger of scalding.

• Hot liquid comes out from the bottom of the hot water outlet. There is a danger of scalding.

WARNING

• When handling the combi-

nation cleaning tablets "COMBI-Tabs", the manufacturer’s warnings and instructions that are printed on the cleaning tablet container must be observed and complied with.

WARNING

• When handling the AMC

powder, the manufacturer’s warnings and instructions that are printed on the bag must be observed and complied with.

• The bottom of the hot water outlet is hot after it has been dispensing liquid. There is a danger of burns.

WARNING

• Never interfere with the

electricity supply connection or modify it. This could result in fatal injury.

• Never remove the screwmounted covers. There is a danger of fatal injury upon contact with live components.

OI c5 eng V9 / 18.08.2006 2-3 © Cafina / Melitta

SAFETY INSTRUCTIONS

NOTE

• Regardless of type configu-

ration, the c5 coffee maker should not be used in large kitchens.

• Electrical equipment which does not have adequate electro-magnetic protection should not be operated close to the c5 coffee maker or the installed EF milk cooler.

• The drip tray serves solely to collect drip water. It must not be used as a sink.

CAUTION

• Never interfere with the wa-

ter mains connection or modify it. There is a danger of flooding.

• The c5 coffee maker must be disconnected from the water supply after it has been switched off, e.g. for the overnight period of inactivity, i.e. it is imperative that the tap is closed.

CAUTION

• Never spray the c5 coffee

maker with a water hose during cleaning. There is a risk of damage.

• Always empty the coffee dregs drawer in the correct manner. There is a danger of overflow.

• Always insert the key card dry and in the correct position into the slot. Do not insert any foreign objects or chip cards for other systems into the slot. There is a risk of damage.

• Do not leave key card in the slot during operation.

• If the internal relieve pressure valve is actuated due to excessive pressure or temperature increase, switch the c5 coffee maker off immediately. Secure the c5 coffee maker against unintentional switching on and report to Customer Support.

• Only operate the c5 coffee maker in covered locations, avoid places where there is a risk of water splash. There is a risk of damage.

SAFETY INSTRUCTIONS

2.2.2.2 Installed EF milk cooler 2.2.2.3 cw cup warmer

WARNING

• Never interfere with the

electricity supply connection or modify it. This could result in fatal injury.

• Never remove the screwmounted covers. There is a danger of fatal injury upon contact with live components.

CAUTION

• Only use the milk container

supplied and always keep it clean. There is a hygiene risk.

• When refilling with milk, always use pre-cooled milk that is no hotter than 1 - 5 °C. There is a hygiene risk.

WARNING

• Never interfere with the

electricity supply connection or modify it. This could result in fatal injury.

• Always check that the power switch is working properly. The signal lamp must be illuminated.

• Never remove the screwmounted covers. There is a danger of fatal injury upon contact with live components.

WARNING

• The surfaces of the cup stor-

age area are heated. There is a danger of burns to the skin if touched for a prolonged period.

• When refilling with milk, cov-

er the lip seals on the inside of the milk cooler door with a cloth. If any milk is left in the lip seals, there is a hygiene risk.

• Always close the milk cooler door. There is a hygiene risk.

CAUTION

• Only operate the cw cup

warmer in covered locations, avoid places where there is a risk of water splash. There is a risk of damage.

• Never spray the cw cup warmer with a water hose during cleaning. There is a risk of damage.

OI c5 eng V9 / 18.08.2006 2-5 © Cafina / Melitta

SAFETY INSTRUCTIONS

2.2.2.4 Key cards

CAUTION

• Keep key cards dry, cool

and in the plastic pockets provided for this purpose. There is a risk of damage.

• Never put a key card on a hot surface or expose to direct sunlight. There is a risk of damage.

• Never put a key card down in an environment where there is a risk of water splash. There is a risk of damage.

• Always clean key cards including chip contacts with a clean, slightly moist cloth without using any household cleaner. There is a risk of damage.

• Never bend or fold a key card or use it as a tool. There is a risk of damage.

• In an environment that is likely to be electrostatic, always ensure that you have earthed yourself (e.g. by touching a radiator) before handling a key card. There is a risk of damage.

2.2.3 Personal safety

WARNING

If handled improperly, the equipment could cause serious or fatal injury.

Anyone using and maintaining the equipment must be trained in the correct handling of the equipment and must have read and understood the safety instructions in these Operating Instructions before starting to use or maintain the equipment.

WARNING

Never modify or remove any safety mechanisms.

Do not disable any safety mechanisms by modifying the equipment.

If there are any warning symbols affixed to the equipment (dependent on nationality), never remove these. Replace any lost or defective warnings symbols immediately.

WARNING

Never operate the equipment in a damaged condition.

Report any irregularities to your superior immediately, especially if they affect safety.

SAFETY INSTRUCTIONS

2.3 Safety mechanisms

As well as the warning symbols (dependent on nationality) affixed to the equipment, the equipment also has several active safety mechanisms.

2.3.1 Power switch

- c5 coffee maker power switch.

Activation with key card.

2.3.2 Pressure relief valve

The c5 coffee maker is equipped with internal pressure relief valves which monitor the flow heater pressure and the boiler pressure.

2.4 Authorised persons

2.4.1 General

Only persons who are authorised to do so may work on or with the equipment.

A person is deemed to be authorised if he/ she satisfies the minimum training and knowledge requirements listed in this chapter and has been assigned a fixed area of responsibility.

2.4.2 Areas of responsibility of

- cw cup warmer power switch (toggle

switch with integrated light)

personnel

2.4.2.1 Operator

As the most senior person from the legal point of view, the operator is responsible for the proper use of the equipment and for the training and deployment of authorised personnel.

He records the competencies and of authorised persons, including whether they have the authority to give orders, for his business.

His tasks include the following:

- He sets or resets the equipment to the beverages that are currently to be dispensed, if he wishes to dispense different beverages than those that the supplier configured upon delivery or installation of the equipment.

OI c5 eng V9 / 18.08.2006 2-7 © Cafina / Melitta

SAFETY INSTRUCTIONS

2.4.2.2 User

He is responsible for the following tasks:

- He adjusts the equipment to the beverages currently to be dispensed.

- He loads the equipment with the beverages to be handled.

- He starts the equipment up and monitors it.

- He cleans and services the equipment in accordance with the work described in chapters «6 Maintenance, 6 - 1» and «7 Troubleshooting, 7 - 1».

- He pinpoints problems and organises problem rectification.

2.4.2.3 Maintenance personnel

(service technician)

2.4.3.2 User

This is a person who has been instructed in how to use the equipment and is aware of the hazards that exist.

2.4.3.3 Maintenance personnel (service technician)

These are people who have completed specialist vocational training, are familiar with maintenance of the equipment and through their work they have acquired the skills needed.

Maintenance work on the mechanical and electrical aspects of the equipment may only be carried out by Customer Support.

2.5 Maintenance duty

He is responsible for the following tasks:

- He services and repairs the equipment in accordance with the work described in chapters «6 Maintenance, 6 - 1» and «7 Troubleshooting, 7 - 1».

- He takes the equipment apart, stores it and disposes of it.

2.4.3 Minimum training and

qualifications of authorised personnel

2.4.3.1 Operator

- He has a commercial background and

performs a managerial function.

- He has specialist experience in risk assessment and staff management.

- He has read and understood chapter «2 Safety instructions, 2 - 1».

The operator has an obligation to maintain and clean the equipment at regular intervals.

- to operate the equipment only in a fully operational and undamaged condition;

- to use only OEM consumables and spare parts;

- to test the security mechanisms to ensure that they are working properly following any maintenance or repair work (see section «2.3 Safety mechanisms, 2 - 7»).

2.6 Availability of these

Operating Instructions

A copy of these Operating Instructions in the vicinity of the equipment must be available to staff using the equipment at all times.

3 Controls and

indicators

3.1 Overview

CONTROLS AND INDICATORS

1 Steam tap, can be swivelled 90°

2 Product fields,

top line level 1, bottom line level 2

3 Control panel cover,

1 2

3 4

can be swivelled upwards, underneath it are the navigation and "+ / -" buttons.

4 LCD,

text display on two lines

5 Filling chute with lid,

chute for "decaffeinated" coffee powder

6 Bean hopper cover

7 Shift/Stop button,

level change in dispensing of beverages, acknowledgement function in the programming

10 11

15 16 17

18 19

8 Beverage selection buttons,

dual assignment for dispensing of beverages, selection and modification function in the programming (only topmost and bottom-most beverage selection buttons)

9 Power switch for cw cup warmer

10 Hot water button

11 Pull-out coffee dregs drawer

12 Beverage outlet, height-adjustable

13 Drip grille

14 Milk cooler door

15 Digit light spot "setting mode"

16 Above: "Compressor" symbol,

below: digit light spot

17 Rocker switch

18 ENTER function

19 UP function

20 DOWN function

20 21

OI c5 eng V9 / 18.08.2006 3-1 © Cafina / Melitta

21 Display (3 digits)

CONTROLS AND INDICATORS

3.2 Operating modes

Operating mode (incl. sample display)

In operation In this condition, the c5 coffee maker is connected to the power supply

Select beverage

Out of order (de-energised)

Operation with critical problem

DPxx

Operation with non-critical problem

Select beverage Error coffee part DP16

Description

and water mains or to the canisters.

There are no restrictions on the dispensing of beverages.

In this condition the c5 coffee maker is disconnected from the power supply and water mains but is still connected to the canisters.

It is not possible to dispense any beverages.

In this condition, the c5 coffee maker is connected to the power supply and water mains or to the canisters.

It is not possible to dispense any beverages.

In this condition, the c5 coffee maker is connected to the power supply and water mains or to the canisters.

There are restrictions on the dispensing of beverages.

"Stand by" operation (switched off)

c5 12:10 14.06.2004

In this condition, the c5 coffee maker is connected to the power supply and water mains or to the canisters.

It is not possible to dispense any beverages.

INITIAL START-UP

4 Initial start-up

4.1 Normal initial start-up

4.1.1 c5 coffee maker

Normal initial start-up assumes that the c5 coffee maker is connected to the mains power supply.

Once the coffee bean level and the water connection have been checked, the c5 coffee maker can be switched on.

4.1.2 Installed EF milk cooler

Normal initial start-up assumes that the installed EF milk cooler (together with the c5 coffee maker) are connected to the mains.

Once the full milk container has been inserted, the installed EF milk container is ready for operation.

4.1.3 cw cup warmer

After the machine has been connected to the mains and the coffee bean level and water connection have been checked, the c5 coffee maker can be switched on. It is recommended carrying out the cleaning procedure described in section «6.2.2.1 c5 coffee maker, 6 - 5» immediately after switching on.

4.2.2 Installed EF milk cooler

Initial start-up after the machine has been out of service for a limited time assumes that the installed EF milk cooler (together with the c5 coffee maker) will normally have been disconnected from the mains. Once the machine has been connected to the mains power supply and the full milk container has been inserted, the installed EF milk cooler is switched on. It is recommended carrying out the cleaning procedure described in section «6.2.2.2 Installed EF milk cooler / external FC milk cooler, 6 - 7» immediately after switching on.

The machine is started up normally by pressing the power switch.

The cw cup warmer is ready for operation once it has been filled with cups.

4.2 Return to service after the machine has been out of service for a limited time

4.2.1 c5 coffee maker

Initial start-up after the machine has been out of service for a limited time assumes that the c5 coffee maker will normally have been disconnected from the mains.

4.2.3 cw cup warmer

If the plug for the cw cup warmer has been pulled out of the socket, it must be plugged into the socket first. To start the machine for the first time after it has been out of service for a limited time, press the power switch. The cup warmer is ready for operation once it has been filled with cups.

OI c5 eng V9 / 18.08.2006 4-1 © Cafina / Melitta

INITIAL START-UP

4.3 Return to service after a fault

4.3.1 c5 coffee maker

Normal initial start-up after a failure assumes that the c5 coffee maker has not been disconnected from the mains.

Before the c5 coffee maker can be operational again, the fault must have been cleared in accordance with chapter «7 Troubleshooting, 7 - 1».

4.3.2 Installed EF milk cooler

Normal initial start-up after a failure assumes that the installed EF milk cooler (together with the c5 coffee maker) have not been disconnected from the mains.

Before the installed EF milk cooler can be operational again, the fault must have been cleared in accordance with chapter «7 Troubleshooting, 7 - 1».

4.3.3 cw cup warmer

The cw cup warmer does not have any fault-monitoring software.

After a fault, the plug for the cw cup warmer must be re-inserted into the socket and the power switch activated.

OPERATION

5 Operation

5.1 Power supply connection

Connection to the power supply is a matter for the installation company and is taken for granted below.

5.1.1 c5 coffee maker

The c5 coffee maker is permanently connected to the power supply during normal operation.

Depending on the form of the power connection, the c5 coffee maker is disconnected from the power supply via power plug and socket or, in the case of a permanent connection, via a switch on the mains.

NOTE

• The c5 coffee maker does

not have a power switch of its own.

5.1.2 Installed EF milk cooler

The installed EF milk cooler is connected to the mains power supply via the c5 coffee maker.

If the coffee maker, having been connected to the mains, is then disconnected from the mains, the installed EF milk cooler will be deactivated accordingly.

NOTE

• The EF installed milk cooler

does not have a power switch of its own.

5.1.3 cw cup warmer

The cw cup warmer is connected to the power supply independently of the "c5 coffee maker / installed EF milk cooler" unit.

The cw cup warmer is connected to the power supply via the toggle switch and is switched off by this means.

NOTE

• The cw cup warmer has a

separate power switch.

OI c5 eng V9 / 18.08.2006 5-1 © Cafina / Melitta

OPERATION

5.1.4 Temperature regulator unit

5.1.4.1 Control panel

1 2 3

4 5

6 7

1 Digit light spot "setting mode"

2 Above: "Compressor" symbol,

below: digit light spot

3 Rocker switch

5.1.4.2 Brief description

The temperature regulator unit controls the compressor for the installed EF milk cooler. During operation, the display shows the approximate actual temperature of the milk in the milk container. The actual milk temperature is taken from the plate on which the milk container stands.

NOTE

• Pre-cooled milk that is no

hotter than 1 - 5 °C should be used. See also section «5.5.4 Refill milk, 5 - 22».

• The temperature indicator on the display shows the approximate actual temperature of the milk in the milk container, not the internal temperature of the installed EF milk cooler.

4 ENTER function

5 UP function

6 DOWN function

7 Display (3 digits)

5.1.4.3 Cooling operation

The digit light spot beneath the "Compressor" symbol is illuminated as long as the compressor is in operation.

NOTE

• The compressor is switched

on by the temperature regulator unit when the actual milk temperature is 2 °C above the setting for the desired milk temperature.

OPERATION

5.1.4.4 Checking the desired milk temperature

1. Press ENTER for approx. 2 seconds ...

- On the display, the word "SET" will appear.

2. Press ENTER a second time, but this time only briefly ...

- The digit light spot "Setting mode"

will flash for approx. 12 seconds.

- On the display, the desired milk tem-

perature will appear.

3. Press ENTER for approx. 2 seconds or wait until the digit light spot "Setting mode" stops flashing.

5.1.4.5 Programming the desired milk temperature

NOTE

• Alternative settings for the

desired milk temperature will be found in the separate specification for the temperature regulator unit.

1. Press ENTER for approx. 2 seconds ...

- On the display, the word "SET" will appear.

2. Press ENTER a second time, but this time only briefly ...

- The digit light spot "Setting mode"

will flash for approx. 12 seconds.

- On the display, the current desired

milk temperature will appear.

- To set the desired milk temperature,

press the UP / DOWN buttons as required.

NOTE

• Factory setting: 5 °C

• Adjustment range:

between 3 °C and 6 °C

3. Press ENTER for approx. 2 seconds or wait until the digit light spot "Setting mode" stops flashing.

- The desired milk temperature is now

set, and the approximate actual milk temperature is indicated on the display.

OI c5 eng V9 / 18.08.2006 5-3 © Cafina / Melitta

OPERATION

5.2 Water connection

Connection to the water mains is a matter for the installation company and is taken for granted below.

CAUTION

• It is not permissible to com-

bine a permanent connection to the mains water supply with the use of a waste water canister.

• Ideally, either "permanent connection to permanent connection" or "canister to canister" should be used as the connection type.

• The "Waste water container level monitoring" option can reduce the risk of overflows.

5.2.1 Water intake

The c5 coffee maker is supplied with water from ...

 ... the mains water supply, with perma-

nent connection to the pipe system.

 ... from a fresh water canister with de-

tachable hose coupling.

5.2.2 Water drainage

Water is drained from the c5 coffee maker ...

 ... into the waste water system, with

permanent connection to the pipe system.

 ... into a waste water canister fitted with

a cap with a hole in it.

 ... into a wastewater canister in combi-

nation with the "Waste water container level monitoring" option (hose is placed above the connection pipe).

5.3 Switching on and off

OPERATION

5.3.1 Switching on the c5 coffee maker

NOTE

• The c5 coffee maker has a

"standby" operating mode.

• The installed EF milk cooler

is set to "standby" or operating mode at the same time as the c5 coffee maker.

When the c5 coffee maker is switched on, it moves from "standby" to operating mode.

None of the product fields are lit up.

1. Turn on the tap.

2. Insert "user" / "manager" key card and

then remove.

NOTE

• Move steam and hot water

outlets to the vertical position.

• Close steam tap tightly.

• Pull beverage outlet right

down. Hot water and steam will come out.

3. This c5 coffee maker heats up. The second line flashes.

TURN ON prog. 86 °C act.

TURN ON Steam temp. too low

c5 10:25 14.06.2004

× Ø

4. After the c5 coffee maker has heated up, the "Refill milk" prompt will appear. You should now fill it up with milk, i.e. replenish with milk if the milk level is too low, or else insert the milk container.

Select beverage Refill milk

5. All five product fields are illuminated.

The c5 coffee maker is now ready to dispense beverages.

Select beverage

OI c5 eng V9 / 18.08.2006 5-5 © Cafina / Melitta

OPERATION

5.3.2 Switching off the c5 coffee maker

NOTE

• The c5 coffee maker has a

"standby" operating mode.

• The installed EF milk cooler

is set to "standby" or operating mode at the same time as the c5 coffee maker.

NOTE

• Details on the cleaning

procedure can be found in

sections «6.2.2.1 c5 coffee maker, 6 - 5» and «6.2.2.2 Installed EF milk cooler / external FC milk cooler, 6 - 7».

When the c5 coffee maker is switched off, it moves from operating mode to "standby" mode.

It can be switched off in the following ways, provided that "yes" is selected.

OFF after cleaning? [1]yes [5]no

 No beverages have been dispensed

since the last switch-on:

The c5 coffee maker goes straight to "standby" mode without the cleaning procedure.

 Only coffee or only milk beverages

have been dispensed since the last switch-on:

CAUTION

• Waste water canister almost

or completely full?

• Depending on the cleaning

procedure, the throughput of water may be high. If the waste water canister has little remaining capacity, it could overflow.

• Check waste water canister

prior to switching off the machine!

The c5 coffee maker runs through the relevant cleaning procedure and then goes to "standby" mode.

 Both coffee and milk beverages have

been dispensed since the last switchon:

The c5 coffee maker runs through the full cleaning procedure and then goes to "standby" mode.

OPERATION

We now describe as an example how the machine is switched off after both coffee and milk beverages have been dispensed in the operating mode.

NOTE

Coffee system: Only use combi-

•

nation cleaning tablets "COMBITabs".

• Get out two combination cleaning

tablets "COMBI-Tabs" or one combination cleaning tablet "COMBI-Tabs" and a AMC powder bag.

• Get the cleaning container.

1. Insert "user" / "manager" key card and

then remove.

2. Before switching off, the cleaning process starts up. (For details, see also section «6.2.2 Cleaning procedure, 6 - 4»).

Tell the c5 coffee maker to switch off after the cleaning process.

OFF after cleaning? [1]yes [5]no

For "yes", press the topmost beverage selection button [ ].

3. You will now be prompted to empty the coffee dregs drawer.

Empty drawer!

Select beverage

× Ø

Pull out the coffee dregs drawer so that you can empty it. The following message appears ...

Drawer missing!

Push the empty coffee dregs drawer back in. The following message appears ...

Drawer emptied Please confirm (

4. Now press the Shift/Stop button [ ] on the control panel.

)

OI c5 eng V9 / 18.08.2006 5-7 © Cafina / Melitta

OPERATION

Now empty the milk, i.e. replace the milk container with the empty cleaning container (into which you have placed one combination cleaning tablet "COMBI-Tabs" or the content of a AMC powder bag). Leave the milk cooler door open.

Insert the cleaning container

Please confirm (

)

5. Now press the Shift/Stop button [ ] on the control panel.

The following message appears during the rinse operation ...

8. When the cleaning process has finished, the following message appears ...

c5 12:10 14.06.2004

Take the cleaning container out of the installed EF milk cooler.

The c5 coffee maker is switched off.

9. Turn off the tap.

5.3.3 Switching the cw cup

warmer on and off

The cw cup warmer is switched on and off via the illuminated toggle switch.

Rinsing

The cover of the filling chute folds open. Now insert the other combination cleaning tablet "COMBI-Tabs" in the filling chute.

Put cleaning agent in Please confirm (

)

6. Now press the Shift/Stop button [ ] on the control panel.

7. The following message appears ...

Cleaning

NOTE

• The cw cup warmer does

not have a "standby" mode. It is always switched to full heat output.

Cleaning milk

OPERATION

5.4 Dispensing of bever-

ages

5.4.1 Dispensing normal coffee

The following description of how to dispense beverages assumes the following allocation to the beverage selection buttons:

Product fields from top to bottom ...

Espresso [ ] Ristretto

Coffee Cream [ ] Coffee Special

Cappuccino [ ] Macchiatto

Cup of [ ] cold milk

Hot milk [ ] Decaffeinated

5.4.1.1 General sequence

1. Push the beverage outlet upwards.

2. Place coffee cup(s) under the bever-

age outlet.

3. Push the beverage outlet downwards until the coffee cup(s) can be removed without having to push the beverage outlet upwards again.

4. When this message is displayed, the coffee maker is ready to dispense beverages ...

Select beverage

5. Decide your beverage dispensing strategy.

Level assignment ...

Level 1 ....... [ ]

Level 2 .......

Reference products ...

NOTE

* after the product in the display means "reference product from bean hopper 1".

** after the product in the display means "reference product from bean hopper 2".

Stopping the product flow ...

NOTE

• The TWIN function can only

be used if it has been activated by Customer Support!

 Level 1 beverage

 Level 2 beverage

 One cup from a single infusion oper-

ation

 More than one cup from a single in-

fusion operation

 Two cups from a single, combined

infusion operation (TWIN function)

 Several cups (two each) from a sin-

gle, combined infusion operation (TWIN function)

6. Dispense the beverages.

You can interrupt the flow of beverage at any time by pressing the Shift/Stop button [ ], if this has been configured on the control side.

OI c5 eng V9 / 18.08.2006 5-9 © Cafina / Melitta

OPERATION

5.4.1.2 Dispensing a level 1 beverage

 You want to dispense a single shot

of the same beverage.

Dispensing information:

 One grinding operation per shot.

 One infusion operation per shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press beverage selection button Espresso / Ristretto [ ] once.

The following message appears ...

1 Espresso**

 You want to dispense multiple shots

of the same beverage (no TWIN function).

Dispensing information:

 One grinding operation per shot.

 One infusion operation per shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press beverage selection button Espresso / Ristretto [ ] five times

at two-second intervals, for example. The following message appears ...

5 Espresso**

2. Preparation of the beverage is initiated.

3. The beverage is dispensed.

2. Preparation of the beverage is initiated.

3. The beverages are dispensed continu-

ously.

OPERATION

 You want to dispense a double shot

of the same beverage (with TWIN function).

Dispensing information:

 One grinding operation per double

shot

 One infusion operation per double

shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press beverage selection button Espresso / Ristretto [ ] twice in

quick succession. The following message appears ...

 You want to dispense more than one

double shot of the same beverage (with TWIN function).

Dispensing information:

 One grinding operation per double

shot

 One infusion operation per double

shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press beverage selection button Espresso / Ristretto [ ] four times

in quick succession, for example. The following message appears ...

2 Espresso

2. Preparation of the beverage is initiated.

3. The two beverages are dispensed.

4 Espresso

2. Preparation of the beverage is initiated.

3. The two double beverages are dis-

pensed continuously.

OI c5 eng V9 / 18.08.2006 5-11 © Cafina / Melitta

OPERATION

5.4.1.3 Dispensing a level 2 beverage

 You want to dispense a single shot

of the same beverage.

Dispensing information:

 One grinding operation per shot.

 One infusion operation per shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press the Shift/Stop button [ ] on the control panel. The following message appears ...

 You want to dispense more than one

double shot of the same beverage (no TWIN function).

Dispensing information:

 One grinding operation per double

shot

 One infusion operation per double

shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press the Shift/Stop button [ ] on the control panel. The following message appears ...

Select beverage

An acoustic signal is heard. If no beverage selection button is pressed within 5 seconds, then the beverage selection will revert to level 1.

2. Press beverage selection button Espresso / Ristretto [ ] once.

The following message appears ...

1 Ristretto

3. Preparation of the beverage is initiated.

Select beverage

An acoustic signal is heard. If no beverage selection button is pressed within 5 seconds, then the beverage selection will revert to level 1.

2. Press beverage selection button Espresso / Ristretto [ ] five times

at two-second intervals, for example. The following message appears ...

5 Ristretto

3. Preparation of the beverage is initiated.

4. The beverage is dispensed.

4. The beverages are dispensed continu-

ously.

OPERATION

 You want to dispense a double shot

of the same beverage (with TWIN function).

Dispensing information:

 One grinding operation per double

shot

 One infusion operation per double

shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press the Shift/Stop button [ ] on the control panel. The following message appears ...

 You want to dispense more than one

double shot of the same beverage (with TWIN function).

Dispensing information:

 One grinding operation per double

shot

 One infusion operation per double

shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press the Shift/Stop button [ ] on the control panel. The following message appears ...

Select beverage

An acoustic signal is heard. If no beverage selection button is pressed within 5 seconds, then the beverage selection will revert to level 1.

2. Press beverage selection button Espresso / Ristretto [ ] twice in

quick succession. The following message appears ...

2 Ristretto

3. Preparation of the beverage is initiated.

Select beverage

An acoustic signal is heard. If no beverage selection button is pressed within 5 seconds, then the beverage selection will revert to level 1.

2. Press beverage selection button Espresso / Ristretto [ ] four times

in quick succession. The following message appears ...

4 Ristretto

3. Preparation of the beverage is initiated.

4. The two beverages are dispensed.

4. The two double beverages are dis-

pensed continuously.

OI c5 eng V9 / 18.08.2006 5-13 © Cafina / Melitta

OPERATION

5.4.2 Dispensing decaffeinated coffee

As well as the nine pre-programmed beverages, which can be dispensed using the beverage selection buttons, it is also possible to dispense a tenth beverage.

This tenth product is assigned for the purposes of beverage dispensing to one overriding product from the range of beverage selection buttons.

This tenth product has to be in powder form and is inserted into the filling chute using the measuring spoon.

CAUTION

"Powder form" is understood to

•

mean coffee ground from coffee beans. Different forms of coffee or other powder products than coffee must not be used.

(For an overview see also section «5.4.1.1 General sequence, 5 - 9».)

1. When this message is displayed, the

coffee maker is ready to dispense beverages ...

3. Press beverage selection button Hot milk / Decaffeinated [ ] once.

The following message appears ...

Please wait

4. Shortly afterwards the following message appears ...

Put coffee in

The lid of the filling chute opens.

5. Shortly afterwards the following message appears ...

Select beverage

The lid of the filling chute remains open for approx. 20 seconds.

Select beverage

2. Press the Shift/Stop button [ ] on the control panel. The following message appears ...

Select beverage

An acoustic signal is heard. If no beverage selection button is pressed within 5 seconds, then the beverage selection will revert to level 1.

6. Put pre-prepared powder from the

measuring beaker filled up to the line into the filling chute.

7. For example, press beverage selection

button Espresso / Ristretto [ ] once. The following message appears ...

1 Espresso**

8. Preparation of the beverage is initiated.

9. The beverage is dispensed.

OPERATION

5.4.3 Dispensing milk

Depending on the configuration of the c5 coffee maker, it is possible to dispense cold or hot milk either manually or in portions.

A milk beverage selection button can only be allocated the functions of "manual" or "portion".

 Manual dispensing of milk

Keep the beverage selection button pressed down until the desired quantity of milk has been dispensed.

 Dispensing a portion of milk

Keep the beverage selection button pressed down and wait until the programmed quantity of milk has been dispensed.

An example of how a portion of hot milk is dispensed is now described.

1. Push the beverage outlet upwards.

2. Place milk jug under the beverage out-

let.

3. Push the beverage outlet downwards until the milk jug can be removed without having to push the beverage outlet upwards again.

4. When this message is displayed, the coffee maker is ready to dispense beverages ...

Select beverage

NOTE

• Replenishment of milk is not

allowed while "milk" is being dispensed.

• The first portion of milk should not be used ...

- if no milk has been

dispensed for over four hours.

- immediately after the

machine has been started up (c5 coffee maker / installed EF milk cooler).

- in the morning, if the milk

was in the installed EF milk cooler overnight.

5. Press beverage selection button Hot milk / Decaffeinated [ ] once.

The following message appears ...

1 Port. hot milk

6. Preparation of the beverage is initiated.

7. The beverage is dispensed.

NOTE

• Pressing the beverage se- lection button Hot milk / Decaffeinated [ ] while

the beverage is being dispensed stops the flow of beverage.

OI c5 eng V9 / 18.08.2006 5-15 © Cafina / Melitta

OPERATION

5.4.4 Dispensing of hot water

CAUTION

• Hot water outlet is hot.

• Danger of burns and scald-

ing.

• Be careful when touching the hot water outlet.

Depending on the configuration of the c5 coffee maker, it is possible to dispense hot water either manually or in portions.

The hot water button can only be allocated the functions of "manual" or "portion".

 Manual drawing of hot water

Keep the hot water button [ ] pressed down until the desired quantity of hot water has been dispensed.

An example of how a portion of hot milk is drawn is now described.

1. Rotate hot water outlet to the vertical position.

2. Place cup under hot water outlet.

3. When this message is displayed, the

coffee maker is ready to dispense beverages ...

Select beverage

4. Press hot water button [ ] once. The following message appears ...

1 Hot water

 Drawing a portion of hot water

Keep the hot water button [ ] pressed down and wait until the programmed quantity of hot water has been dispensed.

5. Preparation of the beverage is initiated.

6. The beverage is dispensed.

NOTE

• Pressing the hot water but-

ton [ ] while the beverage is being dispensed stops the flow of beverage.

OPERATION

5.4.5 Drawing steam

CAUTION

• Steam outlet is hot.

• Danger of burns and scald-

ing.

• Be careful when touching the hot steam outlet.

The steam is used to heat up cold and preheated drinks.

The steam tap [ ] can be rotated up to 90° max.

Operational status of steam tap:

- Steam tap closed [ ]

- Steam tap open to the maximum possible [ ]

4. Rotate the steam outlet forwards and dip it into the drink that is to be heated.

With larger receptacles, moved the steam outlet together with the receptacles towards the c5 coffee maker and then place the receptacle on the drip grille.

5. Rotate steam tap [ ] downwards in a controlled way and keep it in this position until the drink has reached the desired temperature.

If necessary, move the receptacle upwards and sideways during the heating operation.

6. Once the heating operation has finished, rotate the steam tap [ ] right back into its normal position.

7. Pull receptacle forwards and put aside.

8. Wipe steam outlet clean with a moist

cloth.

1. Rotate hot water outlet to the vertical

position.

2. Rotate steam tap [ ] slightly down- wards so as to allow the condensed water that is still in the steam outlet to run off into the drip tray.

Keep the steam tap [ ] rotated until only steam comes out of the nozzle.

3. Rotate the steam tap [ ] until it is right back in position.

9. Rotate hot water outlet to the vertical position.

10. Rotate steam tap [ ] slightly down- wards so as to allow the residual fluid that is still in the steam outlet to run off into the drip tray.

OI c5 eng V9 / 18.08.2006 5-17 © Cafina / Melitta

OPERATION

5.4.6 Frothing milk manually

CAUTION

• Beware hot steam outlet

and/or splash from hot milk.

• Danger of burns and scalding.

• Be careful when touching the hot steam outlet. Observe distance between end of steam nozzle and surface of liquid.

NOTE

• The milk used should be

cool so as to comply with the hygiene regulations.

1. Align steam outlet vertically.

2. Rotate steam tap [ ] slightly down-

wards so as to allow the condensed water that is still in the steam outlet to run off into the drip tray.

3. Rotate steam outlet forwards and dip the end of the steam nozzle into the drink to be frothed right down to the bottom of the receptacle.

4. Rotate the steam tap [ ] down- wards in a controlled way.

At the same time lower the receptacle so that the end of the steam nozzle is just above the surface of the liquid.

During the frothing operation, watch the formation of froth and continually adjust the distance between the "end of the steam nozzle and the surface of the liquid" (this will differ according to the physical properties of the steam nozzle).

Steam can be used to froth milk.

The steam tap [ ] can be rotated up to 90°.

Operational status of steam tap:

- Steam tap closed [ ]

- Steam tap open to the maximum possible [ ]

5. When the desired degree of froth has been achieved, rotate the steam tap [ ] back into its normal position (closed) to terminate the operation.

6. Pull receptacle forwards and put aside.

7. Wipe steam outlet clean with a moist

cloth.

8. Align steam outlet vertically.

9. Rotate steam tap [ ] slightly down-

wards so as to allow the residual fluid that is still in the steam outlet to run off into the drip tray.

OPERATION

5.5 Routine work

5.5.1 Refilling fresh water canister

The fresh water canister (20 litres) must be refilled at least once a day with cold, thoroughly hygienic mains water.

NOTE

• Never refill completely de-

calcified fresh water.

• Always take care to correct-

ly connect the rapid action coupling of the water line that runs between the fresh water canister and the c5 coffee maker.

• Fresh water pipe must not

have any kinks in it.

1. If the option "Waste water container level monitoring" option has been selected, the following message will appear when the canister is full ...

Select beverage Waste water full

NOTE

• It will not be possible to dis-

pense any further beverages using the c5 coffee maker until the waste water canister has been emptied.

2. Empty the waste water canister immediately. The following message appears ...

5.5.2 Emptying the waste water canister

The waste water canister (10 litres) must be emptied and thoroughly rinsed at least once a day.

NOTE

• Always take care to ensure

that the waste water hose is pushed down through the hole in the cap of the waste water canister to a sufficient depth.

• If the option "Waste water

container level monitoring" was selected during installation, take care to ensure that the waste water hose fits snugly and sufficiently far on the connection pipe.

Waste water emptied Please confirm (

)

Press Shift/Stop button [ ].

3. The following message appears ...

Select beverage

4. You can now dispense beverages as required.

• Waste water hose must not have any kinks in it.

OI c5 eng V9 / 18.08.2006 5-19 © Cafina / Melitta

OPERATION

5.5.3 Refill coffee beans

The bean hoppers are monitored as regards coffee bean content. If a bean hopper becomes empty, this is displayed for the relevant bean hopper during the dispensing of a beverage.

NOTE

• The description which fol-

lows applies by analogy to the bean hopper 2.

In the example below, bean hopper 1 is empty. The associated reference product is "Coffee cream*".

1. Beverage selection key Coffee cream / Coffee Special [ ] has been

pressed once. The following message appears ...

3. Press beverage selection button Coffee cream / Coffee Special [ ]

again.

NOTE

• Do not press the Shift/Stop

button or insert any key card.

4. If bean hopper 2 is also empty, the following message will appear briefly ...

1 Coffee cream* Bean hopper 2 empty

5. Preparation of the beverage is initiated.

6. The beverage is dispensed.

1 Coffee cream* Bean hopper 1 empty

2. Pour coffee beans into bean hopper 1 up to about 2 cm below the bean hopper rim.

The position of bean hopper 1 is visible on the inside of the bean hopper cover.

OPERATION

In the example below, bean hopper 1 is empty. The associated reference product is "Coffee cream*".

The Shift/Stop button was pressed by mistake.

1. Beverage selection key Coffee cream / Coffee Special [ ] has been

pressed once. The following message appears ...

1 Coffee cream* Bean hopper 1 empty

2. The Shift/Stop button [ ] was pressed by mistake.

3. The following message appears ...

4. Pour coffee beans into bean hopper 1

up to about 2 cm below the bean hopper rim.

The position of bean hopper 1 is visible on the inside of the bean hopper cover.

5. Insert "user" / "manager" key card. The following message appears ...

Fault confirmed

6. Remove "user" / "manager" key card. The following message appears ...

Select beverage

Select beverage Bean hopper 1 empty

According to the illuminated product fields, only the beverages served by bean hopper 2 and also pure milk beverages are available for selection using the relevant beverage selection buttons.

As before, there are no restrictions on the drawing of hot water and steam.

According to the illuminated product fields, all the products are now available for selection via the associated beverage selection buttons.

7. Select beverage.

8. Preparation of the beverage is initiated.

9. The beverage is dispensed.

OI c5 eng V9 / 18.08.2006 5-21 © Cafina / Melitta

OPERATION

5.5.4 Refill milk

The description of the procedure below applies to both the installed EF milk cooler and the external FC milk cooler.

 The installed EF milk cooler can option-

ally be fitted with a milk level monitoring system.

NOTE

The milk container for the in-

•

stalled EF milk cooler holds approx. six litres of milk.

• If the installed EF milk cooler is

fitted with milk level monitoring, then this will be activated when the milk supply in the milk container has dropped to about 1 litre or when the milk container is not in the installed EF milk cooler.

• When replenishing the milk

supply, always cover the lip seals of the milk cooler door of the installed EF milk cooler.

• The milk used to replenish

the milk container must be pre-cooled, i.e. it must not be any hotter than 1 - 5 °C. If hotter milk is used, the milk will overheat when "milky coffee" beverages are dispensed, insufficient froth will be created and it will not be possible to comply with the hygiene regulations.

CAUTION

• If the milk container is emp-

ty:

the addition of steam instead of milk to beverages can result in splashing of hot liquid, causing scalds.

• Replenish the milk supply immediately.

1. The following message indicates that there is either no milk or insufficient milk or else that the milk container itself is not inside the installed EF milk cooler ...

Select beverage Refill milk

2. Replenish milk supply. This will result in the following message ...

Select beverage

3. Pull beverage outlet right down.

4. Open control panel cover and press the

[ V ] button.

• If the milk container is empty

when the machine comes to dispense beverages that include milk, the c5 coffee maker will dispense steam instead of milk.

Please wait

A little milk will be released to fill the lines.

5. You can now dispense beverages as required.

OPERATION

5.5.5 Emptying the coffee dregs drawer

Once an infusion operation is complete, empty the resulting block of coffee dregs into the coffee dregs drawer.

Monitoring of how full the coffee dregs drawer is is based on adding up the weight of the individual blocks of coffee dregs discarded.

NOTE

• The coffee dregs drawer is

full to capacity when it contains a weight of 0.7 kg.

When this occurs, the message "Empty drawer!" is displayed.

• The coffee dregs drawer is

80 % full when it contains a weight of 0.56 kg.

When this occurs, the message "Drawer nearly full!" is displayed.

1. The following displays indicate how full the coffee dregs drawer is ...

... Coffee dregs drawer 80 % full.

1 Coffee cream* Drawer nearly full!

... Coffee dregs drawer 100 % full.

Select beverage Empty drawer!

2. Push the beverage outlet all the way up.

3. Pull out coffee dregs drawer. The following message appears ...

Select beverage Drawer missing!

CAUTION

• If the coffee dregs drawer

overflows, this will cause serious dirt accumulation inside the c5 coffee maker.

• Always empty coffee dregs drawer correctly when the c5 coffee maker is switched

on.

4. Empty coffee dregs drawer, clean with

warm water (not with hot water from the c5 coffee maker) and dry.

5. Push coffee dregs drawer in. The following message appears ...

Drawer emptied Please confirm (

)

Press Shift/Stop button [ ].

6. The following message appears ...

Select beverage

7. You can now dispense beverages as required.

OI c5 eng V9 / 18.08.2006 5-23 © Cafina / Melitta

OPERATION

5.5.6 Cleaning the drip tray

The drip grille and drip tray must be cleaned at regular intervals.

1. Press the drip grille at the back right or back left corner downwards a little.

2. Remove drip grille and clean.

3. Clean drip tray and clean out the drain

holes if they are blocked.

4. Place the drip grille in the correct position on the drip tray, i.e. with the transverse rods underneath.

OPERATION

5.6 System work

5.6.1 Control panel and button

layout

 Navigation button [ V ]

- One level down in the structure

 Navigation button [ Z ]

- One position horizontally to the right in the structure

 Navigation button [ Y ]

- One position horizontally to the left in the structure

 Shift/Stop button [ ]

- Not allocated

 [ + ] button

- Used to raise the adjustment value in predefined steps

- Used to enter "Yes"

 [ – ] button

- Used to lower the adjustment value in predefined steps

- Used to enter "No"

 [ ] button (no. invisible)

 Liquid crystal display

- Displays information on the corresponding function.

 Navigation button [ U ]

- One level higher in the structure

- Used to confirm queries / or adjustment values

- 1 = "Yes" in response to textual questions

- 2 to 4 unallocated

- 5 = "No" in response to textual questions

Cards

Card handling:

1. Insert key card.

2. Wait until LCD display changes.

3. Remove key card.

 "user" key card

- Insertion of the card has the effect of switching the c5 coffee machine on or off

- Insertion of the card has the effect of granting access to basic functions

 "manager" key card

- Insertion of the card has the effect of granting access to advanced functions

- Insertion of the card after the adjustment values have been changed has the effect of confirming the new settings

OI c5 eng V9 / 18.08.2006 5-25 © Cafina / Melitta

OPERATION

5.6.2 Structure of the functions

5.6.2.1 Overview and adjustment values

Access with the "user" key card

User menu Function Setting In steps of ...

Cleaning - OFF after cleaning ?

- Clean coffee ?

- Clean milk ?

Daily counter - Coffee total

- Other products

Access with the "manager" key card

Manager menu Function Setting In steps of ...

Cleaning - OFF after cleaning ?

- Clean coffee ?

- Clean milk ?

Daily counter - Coffee total

- Other products

- Reset counter

Total counter - Coffee total

- Tea total

- Steam total

- Milk total

Functions - E XTERNA L

- Self-service

- ON / OFF timer

- Memoswitch

- Milk

- Disable buttons

Water quantity - Coffee products 0-995 ml ± 0.5 ml

Coff. quant. ±1g - Coffee products ± 1 g ± 0.1 g

Flow period water - Hot water products 0.4 - 120 s ± 0.2 s

Pre-infusion 1 milk - Milk / coffee products 0.0 - 50 s ± 0.5 s

Pre-infusion 2 milk - Milk / coffee products 0.0 - 50 s ± 0.5 s

Post-infusion milk - Milk / coffee products 0.0 - 50 s ± 0.5 s

Flow period milk - Milk products 0.4 - 120 s ± 0.2 s

Flow period steam - Steam products 0.4 - 120 s ± 0.2 s

Price - For all products 0.00 - 25.00 ± 0.10

No charge - For all products Yes / No -

Time / date - Hours

- Minutes

- Day

- Month

- Year

(1)yes / (5) no (1)yes / (5) no (1)yes / (5) no

0 - 100.000 0 - 100.000

(1)yes / (5) no (1)yes / (5) no (1)yes / (5) no

0 - 100.000 0 - 100.000

yes / no

0 - 1.000.000 0 - 1.000.000 0 - 1.000.000 0 - 1.000.000

yes / no yes / no yes / no yes / no yes / no yes / no

HH: MM DD. MM.

OPERATION

5.6.3 Brief description of functions

5.6.3.1 Cleaning

 OFF after cleaning?

Specifies whether the c5 coffee maker will switch off after the individual cleaning procedures are complete or remain in operation.

 Clean coffee?

Specifies whether the cleaning procedure will apply to the coffee system.

 Clean milk?

Specifies whether the cleaning procedure will apply to the milk system.

5.6.3.2 Daily counter

5.6.3.4 Functions

 EXTERNAL

Addition and removal of external modules such as coin-operation units or coin-checking devices (analogous to "external" key card) etc.

 Self-service

Switches c5 coffee maker to self-service operation (analogous to "vip" key card).

The products intended can be dispensed directly.

 ON / OFF timer

Sets c5 coffee maker to automatic switching on and off.

The switch-on/switch-off times must have been previously specified.

[i] The daily counters must not be used for

billing purposes as different counting methods are used. Billing will only be correct with a registration system.

 With "user" key card

Queries the current counter status for all products. Deletion of counters is not possible.

 With "manager" key card

Queries the current counter status for all products. Deletion of counters is generally possible.

5.6.3.3 Total counter

[i] The total counters must not be used for

billing purposes as different counting methods are used. Billing will only be correct with a registration system.

 Memoswitch

The c5 coffee maker can take note of the usage behaviour of the user up to a point and simplify operation.

 Milk

Addition and removal of the installed EF milk cooler.

 Disable buttons

Locking and release of the control buttons on the c5 coffee maker (analogous to "key lock" key card).

5.6.3.5 Water quantity

 Every individual coffee product

The water quantity can be altered in predefined steps.

 Coffee / Tea / Steam / Milk

Queries the current counter status for specified products.

Deletion of counters is not possible.

OI c5 eng V9 / 18.08.2006 5-27 © Cafina / Melitta

OPERATION

5.6.3.6 Coffee quantity ±1g

 Every individual coffee product

The powder quantity can be altered in predefined steps.

5.6.3.7 Flow period hot water

 Hot water beverages

The flow time can be altered in predefined steps.

5.6.3.8 Pre-infusion 1 milk

 Every "coffee-milk" beverage

The milk flow time can be altered in predefined steps.

Coffee is then added.

5.6.3.9 Pre-infusion 2 milk

 Every "coffee-milk" beverage

5.6.3.11 Flow period milk

 Cold milk

The flow time can be altered in predefined steps.

 Hot milk

The flow time can be altered in predefined steps.

5.6.3.12 Flow period steam

 "Steam button" option

The flow time can be altered in predefined steps.

5.6.3.13 Price

 Every beverage

Allows a price to be stored for every beverage, e.g. for a connected, external billing system.

The milk flow time can be altered in predefined steps.

Coffee is then added.

5.6.3.10 Post-infusion milk

 Every "coffee-milk" beverage

The milk flow time can be altered in predefined steps.

Coffee is output first.

5.6.3.14 No charge

 Every beverage

Allows a price to be stored for every beverage, e.g. for a connected, external billing system.

5.6.3.15 Time / date

 Time

Used to set the time in the format "12:34".

 Date

Used to set the date in the format "Wednesday 16.06.2004".

OPERATION

5.6.4 Use of the functions

5.6.4.1 Cleaning

 Card: "user" key card

1. Insert / remove card

OFF after cleaning? (1)yes (5)no

2. [ ] button (5)

Clean coffee? (1)yes (5)no

3. [ ] button (1)

Clean milk? (1)yes (5)no

4. [ ] button (1)

5. Start of cleaning procedure

 Card: "manager" key card

1. Insert / remove card

2. 1 x [ Z ] button

Daily counter

3. 1 x [ V ] button

Coffee total 25

4. [ Z ] or [ Y ] button

Other beverages yy

5. [ Z ] or [ Y ] button

Reset counter no

6. 1 x [ + ] button

5.6.4.2 Daily counter

 Card: "user" key card

1. Insert / remove card

2. 1 x [ Z ] button

Daily counter

3. 1 x [ V ] button

Coffee total 25

4. [ Z ] or [ Y ] button

Other beverages yy

5. Insert / remove card

Select beverage

Reset counter yes

7. 1 x [ U ]

Daily counter

8. Insert / remove card

Select beverage

OI c5 eng V9 / 18.08.2006 5-29 © Cafina / Melitta

OPERATION

5.6.4.3 Total counter

 Card: "manager" key card

1. Insert / remove card

2. 2 x [ Z ] button

Total counter

3. 1 x [ V ] button

Coffee total 130

4. 1 x [ Z ] button

Tea total 25

5. 1 x [ Z ] button

Steam total 15

6. 1 x [ Z ] button

Milk total 10

7. 1 x [ U ] button

Total counter

8. Insert / remove card

Select beverage

OPERATION

5.6.4.4 Functions

NOTE

• Only those functions which

have a grey background (activated) can be altered.

 Card: "manager" key card

1. Insert / remove card

2. 3 x [ Z ] button

Functions

3. 1 x [ V ] button

EXTERNAL no

1 x [ Z ] button

Self-service no

4. 1 x [ + ] button

EXTERNAL yes

1 x [ + ] button

Self-service yes

1 x [ + ] button

ON / OFF timer yes

1 x [ + ] button

Memoswitch yes

1 x [ + ] button

Milk yes

1 x [ + ] button

1 x [ Z ] button

ON / OFF timer no

1 x [ Z ] button

Memoswitch no

1 x [ Z ] button

Milk no

1 x [ Z ] button

Disable buttons no

Disable buttons yes

5. 1 x [ U ]

Functions

6. Insert / remove card

Select beverage

OI c5 eng V9 / 18.08.2006 5-31 © Cafina / Melitta

OPERATION

5.6.4.5 Water quantity

 Card: "manager" key card

1. Insert / remove card

2. 4 x [ Z ] button

Water quantity

3. 1 x [ V ] button

Espresso** 11 Water quantity 40 ml

4. e.g. 1 x [ – ] button

Espresso** 11 Water quantity 35 ml

5. e.g. 2 x [ + ] button

Espresso** 11 Water quantity 45 ml

5.6.4.6 Coffee quantity ±1g

 Card: "manager" key card

1. Insert / remove card

2. 5 x [ Z ] button

Coff. quant. ±1g

3. 1 x [ V ] button

Espresso** 11 Coffee quantity 8.5 g

4. e.g. 1 x [ – ] button

Espresso** 11 Coffee quantity 8.4 g

5. e.g. 2 x [ + ] button

Espresso** 11 Coffee quantity 8.6 g

6. 1 x [ U ]

Water quantity

7. 1 x [ V ] button

Espresso** 11 Water quantity 45 ml

8. [ Z ] or [ Y ] button

Other beverages xx Text yyy ml

9. 1 x [ U ]

Water quantity

10. Insert / remove card

Select beverage

6. 1 x [ U ]

Coff. quant. ±1g

7. 1 x [ V ] button

Espresso** 11 Coffee quantity 8.6 g

8. [ Z ] or [ Y ] button

Other beverages xx Text y.y g

9. 1 x [ U ]

Coff. quant. ±1g

10. Insert / remove card

Select beverage

OPERATION

5.6.4.7 Flow period water

 Card: "manager" key card

1. Insert / remove card

2. 6 x [ Z ] button

Flow period water

3. 1 x [ V ] button

Hot water 01 Flow period water\6.0s

4. e.g. 1 x [ – ] button

Hot water 01 Flow period water\5.8s

5. e.g. 2 x [ + ] button

Hot water 01 Flow period water\6.2s

5.6.4.8 Pre-infusion 1 milk

 Card: "manager" key card

1. Insert / remove card

2. 7 x [ Z ] button

Pre-infusion 1 milk

3. 1 x [ V ] button

Espresso** 11 Pre-inf. 1 milk 0.0s

4. 2 x [ Z ] button

Cappuccino 13 Pre-inf. 1 milk 1.5s

5. e.g. 1 x [ – ] button

Cappuccino 13 Pre-inf. 1 milk 1.0s

6. 1 x [ U ]

Flow period water

7. Insert / remove card

Select beverage

6. e.g. 2 x [ + ] button

Cappuccino 13 Pre-inf. 1 milk 2.0s

7. 1 x [ U ]

Pre-infusion 1 milk

8. Insert / remove card

Select beverage

OI c5 eng V9 / 18.08.2006 5-33 © Cafina / Melitta

OPERATION

5.6.4.9 Pre-infusion 2 milk

 Card: "manager" key card

1. Insert / remove card

2. 7 x [ Y ] button

Pre-infusion 2 milk

3. 1 x [ V ] button

Espresso** 11 Pre-inf. 2 milk 0.0s

4. 2 x [ Z ] button

Cappuccino 13 Pre-inf. 2 milk 10.0s

5. e.g. 1 x [ – ] button

Cappuccino 13 Pre-inf. 2 milk 9.5s

5.6.4.10 Post-infusion milk

 Card: "manager" key card

1. Insert / remove card

2. 6 x [ Y ] button

Post-infusion milk

3. 1 x [ V ] button

Espresso** 11 Post-infusion milk0.0s

4. 2 x [ Z ] button

Cappuccino 13 Post-infusion milk1.0s

5. e.g. 1 x [ – ] button

Cappuccino 13 Post-infusion milk0.5s

6. e.g. 2 x [ + ] button

Cappuccino 13 Pre-inf. 2 milk 10.5s

7. 1 x [ U ]

Pre-infusion 2 milk

8. Insert / remove card

Select beverage

6. e.g. 2 x [ + ] button

Cappuccino 13 Post-infusion milk1.5s

7. 1 x [ U ]

Post-infusion milk

8. Insert / remove card

Select beverage

OPERATION

5.6.4.11 Flow period milk

 Card: "manager" key card

1. Insert / remove card

2. 5 x [ Y ] button

Flow period milk

3. 1 x [ V ] button

Port. hot milk 15 Flow period milk 25.0s

1 x [ Z ] button

Port. cold milk 24 Flow period milk 25.0s

4. e.g. 1 x [ – ] button ]

Port. hot milk 15 Flow period milk 24.5s

5.6.4.12 Flow period steam

 Card: "manager" key card

1. Insert / remove card

2. 4 x [ Y ] button

Flow period steam

3. 1 x [ V ] button

**** 02 Flow period steam15.0s

4. e.g. 1 x [ – ] button

**** 02 Flow period steam14.8s

5. e.g. 2 x [ + ] button

**** 02 Flow period steam15.2s

Cold milk port. 24 Flow period milk 24.5s

5. e.g. 2 x [ + ] button

Port. hot milk 15 Flow period milk 25.5s

Cold milk port. 24 Flow period milk 25.5s

6. 1 x [ U ]

Flow period milk

7. Insert / remove card

Select beverage

6. 1 x [ U ]

Flow period steam

7. Insert / remove card

Select beverage

OI c5 eng V9 / 18.08.2006 5-35 © Cafina / Melitta

OPERATION

5.6.4.13 Price

 Card: "manager" key card

1. Insert / remove card

2. 3 x [ Y ] button

Price

3. 1 x [ V ] button

Hot water 01 Price 2.00

4. e.g. 1 x [ – ] button

Hot water 01 Price 1.90

5. e.g. 2 x [ + ] button

Hot water 01 Price 2.10

5.6.4.14 No charge

 Card: "manager" key card

1. Insert / remove card

2. 2 x [ Y ] button

No charge

3. 1 x [ V ] button

Hot water 01 No charge no

4. 1 x [ + ] button

Hot water 01 No charge yes

5. [ Z ] or [ Y ] button

Other beverages xx Text Text

6. 1 x [ U ]

Price

7. Insert / remove card

Select beverage

6. 1 x [ + ] button

Other beverages xx Text y es

7. 1 x [ U ]

No charge

8. Insert / remove card

Select beverage

OPERATION

5.6.4.15 Time / date

 Card: "manager" key card

1. Insert / remove card

2. 1 x [ Y ] button

Time / date

3. 1 x [ V ] button

Time / date Hours 14:20

4. e.g. 1 x [ + ] button

Time / date Hours 15:20

5. 1 x [ Z ] button

Time / date Minutes 15:20

8. e.g. 1 x [ + ] button

Time / date Day Friday 18.06.2004

9. 1 x [ Z ] button

Time / date Month Friday 18.06.2004

10. e.g. 1 x [ + ] button

Time / date Month Sunday 18.07.2004

11. 1 x [ Z ] button

Time / date Month Sunday 18.07.2004

12. e.g. 1 x [ + ] button

Time / date Month Monday 18.07.2005

6. e.g. 5 x [ + ] button

Time / date Minutes 15:25

7. 1 x [ Z ] button

Time / date Day Thursday 17.06.2004

13. 1 x [ U ] button

Time / date

14. Insert / remove card

Select beverage

After switching off the c5 coffee maker, a message like this appears ...

c5 15:35 18.07.2005

OI c5 eng V9 / 18.08.2006 5-37 © Cafina / Melitta

OPERATION

5.6.5 Resetting to initial installation default settings

5.6.5.1 Coffee maker reset

This function is used to reset the c5 coffee maker software to the default settings that applied upon first installation.

The c5 coffee maker reads in from the "memory" key card all the data which the service technician wrote to the card ("memory" key card) last time.

NOTE

• All the software modifica-

tions which have been made to the functions using the "manager" key card are lost when machine is reset!

• Empty the waste water can-

ister and fill the fresh water canister prior to activating the coffee maker reset so as to accommodate the higher water throughput that this causes.

2. Insert card ("memory" key card)

3. To connect c5 coffee maker to the

mains power supply:

 insert plug

 set separate power switch to ON

4. The following message appears ...

Read memory card (+) 14:45 17.06.2004

5. 1 x [ + ] button

Reading memory card 14:45 17.06.2004

Remove card 14:45 17.06.2004

6. Remove card ("memory" key card)

c5 15:45 17.06.2004

 Card: "memory" key card

 Card: "user" key card

1. To disconnect c5 coffee maker from

the mains power supply.

 pull out the plug

 set separate power switch to OFF

7. Insert / remove card ("user" key card)

Calibration 14:45 17.06.2004

Please wait 14:45 17.06.2004

TURN ON Text

8. Coffee maker reset is complete

Select beverage

MAINTENANCE

6 Maintenance

This chapter deals exclusively with preventive maintenance of the equipment. In case of problems, please consult chapter «7 Troubleshooting, 7 - 1».

6.1 Maintenance schedule

6.1.1 Intervals

6.1.1.1 Cleaning intervals

Cleaning area Daily Weekly Monthly

Cover of beverage outlet

Waste water canister

External / internal "EF / FC"

External / internal cup warmer

Outside of c5 coffee maker

Control buttons and steam tap

Steam outlet

Filling chute with lid

Bean hopper

Fresh water canister

Hot water outlet

Coffee dregs drawer

Liquid crystal display

Milk container “EF / FC”

Milk hoses "EF / FC"

Recess for coffee dregs drawer

Beverage outlet



Cleaning procedure "EF / FC"  (2 x)

Cleaning procedure c5 coffee maker

Area underneath the equipment (c5 / EF / cw)

Drip grille

Drip tray

 (1 x)



MAINTENANCE

6.1.1.2 Intervals between services

The c5 coffee maker is designed for a maximum of 100,000 cups per year.

The built-in safety mechanisms (relieve pressure valves) must be checked once a year to ensure that they are working properly. We recommend that this check is carried out during an (A) service of the whole system.

- "A" service

An "A" service of the whole system is required every 50,000 cups or no later than one year since the last "A" service. The following display message indicates the need for maintenance:

Select beverage Maintenance Coffee

Contact Customer Support.
