Bush LCD32F1080PS Instruction manual

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Issue 1 - 9/2/11

32” LCD TV

Installation & Operating Instructions - Please keep for future reference

529/8367

IMPORTANT - Please read these instructions fully before installing or operating

These instructions contain important information which will help you get the best from your television and ensure safe and correct installation and operation.

For any help concerning set up and use of your TV please call the

Customer Helpline: 0044

845 604 0105

Lines open: 9am - 8pm Monday to Saturday and 10am - 4pm Sunday

LCD32F1080PS

APPROVED

0345 604 0105

Contents

Contents 2 Contents 3-6

Preparation 4 Intended Use 4 Power source 4 Positioning the TV 4 Power cord and plug 4 Moisture and Water 5 Ventilation 5 Heat sources and Flames 5 Headphone Volume 5 Wall Mounting (optional) 5 LCD Screen 5 Cleaning 5 Batteries 5 Replacement Parts 6 Servicing 6 Taking out of service and storing 6 Connection to a Television Distribution System (Cable TV etc.) from Tuner 6 Symbols in this Instruction Book 6

Support 7 Getting Started 8-14 TV - Features 8 Viewing remote control - TV 9 Getting Started 10 Attaching the Stand 10 Getting Started 11 TV - Control buttons (left side) 11 Aerial connection 12 Power connection 12 Remote control - Inserting batteries 12 Wall Mounting 12 Switching the TV On and Off 12

Switching the TV On 12 Switching the TV Off 12

Operation using TV control buttons 13 Operation using Remote control buttons 13 Initial set up 14 General operation 14

Information Banner 14

Connections 15-19 Back connections explained 15 Left side connections explained 16 HDMI Connections 17 SCART Connections 17 VGA Connections 17 Side AV Connections 18 Using a Conditional Access Module 18 USB Connections 19 Basic Features 20-28 How to navigate menus - Selecting source 20 Electronic programme guide (EPG) 20 General Operation 21

Displaying Subtitles 21 Zoom Modes 21 Using Main Menu Screen 21

!"#$%&'(#%)*+,-./(0-)1-,,(#%2) 34

Source Settings 21 Audio Language 21

Basic Features 22 Navigating Channel List 22

Moving a Channel 22 Deleting a Channel 22 Renaming a Channel 22 Locking a Channel 22 Sorting Channel List 22

Language Settings 24

Other Functions and Features 25

Favourite Mode 25 Conditional Access 25 Setting Sleep Timer 25 Setting Programme Timers 25

Editing a Timer 25 Deleting a Timer 25 Picture Controls 26

!"#$%&'(#%)5(6,&'-)1-,,(#%2) 37

Operating Picture Settings Menu Items 26 Picture Settings Menu Items 26 PC Picture Settings Operation 26

Sound and Source Settings 27

!"#$%&'(#%)1")1-,,(#%2) 39

Sound Settings Menu Items 27

!"#$%&'(#%)1"&'6-)1-,,(#%2) 39

Other Controls 28

Operation 28 Other Settings Menu Items 28

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Contents

Advanced Features 29-32 Media Browser 29

Starting Media Browser 29

:-8(+);'"<2-')!"#$%&'+,("#) 3=

Operation 29 View Style 29 Slide Show Interval 29 Show Subtitle 29 Subtitle Language 29 Subtitle Position 29 Subtitle Font Size 29

>""?).)1@&AB-)8&'(#%)5C+DE+6F) 3=

Media Browser - continued 30

Viewing Videos via USB 30 Video Playback Screen 30 Subtitle Time Correction 30 Viewing Photos via USB 30 Displaying Photos in Slideshow Mode 30 Playing Music via USB 30

Setting the channels 31

Accessing Installation Menu 31 Automatic Channel Scan (Retune) 31 Manual Channel Scan 31 Analogue Fine Tune 31 First Time Installation 31 Clear Service List 31

Parental Control 32 Other Information 33-36 Teletext 33

Analogue Teletext 33

Digital Teletext (for the UK only) 33

!"#$%&$'(%)*+, -.

Other Information 35 Plug replacement - UK and Ireland only 35 Other Information 36 Product Support 37-42 Trouble shooting 37 Disposal information 38 Supported DVI Resolutions 38 Supported File Formats for USB Mode 39 AV and HDMI Signal Compatibility (Input Signal

Types) 39 PC Input Typical Display Modes 40

/#&*%(%)*,)0,%1")2('*(,(#21+,3,45, .6

Software Upgrade 42 Guarantee 43

Model number

BUSH DVB-T LCD32F1080PS

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Safety Information

IMPORTANT - Please read these instructions fully before installing or operating

Preparation

Place the device on a solid even surface. For ventilation, leave a free space of at least 10 cm all around the set. To prevent any fault and unsafe situations, do not place any objects on top of the set. Use this device in moderate climates.

Operation tempera ture and oper ation humidity: 5ºC up to 45ºC, 85% rel. humidity max. (not blocking ventilation openings).

Intended Use

Th is devic e is used to rece ive and display TV programmmes.The different connection options make an additional expansion of the reception and display sources possible (various external devices). This device is only suitable for dry interior use. This appliance is intended solely for private domestic use and may not be used for industrial and commercial purposes. We exclude liability in principle, if the device is not used

+2)(#,-#8-8G)"')&#+&,@"'(H-8)0"8($6+,("#2)@+I-)E--#)

made. To operate your LCD TV in extreme ambient conditions may cause the damage of the device.

WARNING: Never let people (including children)

with physical, sensory or mental abilities or lack of experience and / or knowledge unsupervised use electrical device!

Childr en may not recogniz e dangers righ t! The swallowing of batteries can be fatal. Keep batteries always out of reach of small children. If a battery is swallowed, seek immediate medical attention. Keep

,@-)?+6F+%(#%)$C02)"&,)"A)'-+6@)"A)6@(C8'-#G),@-'-)(2)+)

risk of suffocation.

Power source

J)The TV should be operated only from a 220-240V

AC, 50 Hz outlet.

Warning: Do not leave your TV in standby or

operating mode when you leave your house.

/@-)C(%@,#(#%)B+2@)<(,@)+''"<@-+8)2D0E"CG)<(,@(#)

an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may

E-)"A)2&A$6(-#,)0+%#(,&8-),")6"#2,(,&,-)+)'(2F)"A)

electric shock of persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Positioning the TV

J)For ventilation, please leave a clear space of at

least 10cm all around the TV.

7,Do not block the ventilation openings. 7,Do not place the TV on sloping or unstable

surfaces, the TV may tip over.

J)To prevent damage to the TV, do not place any

objects on top of the TV.

J)Only use the TV in moderate climates.

Power cord and plug

J)The power cord plug should be easily accessible.

In case of storms and lightning, when going on holiday, or when the TV is not used for a long period of time disconnect the power cord from the mains power socket.

J)The mains plug is used to disconnect TV set from

the mains and therefore it must remain readily accessible.

7,Do not place the TV, furniture, etc. on the power

cord or pinch the cord.

J)Handle the power cord by the plug, do not unplug

the TV by pulling the power cord.

J)Never touch the power cord/plug with wet hands as

this could cause a short circuit or electric shock.

J)Never make a knot in the power cord or tie it with

other cords.

J)Power cords should be placed in such a way

that they are not likely to be stepped on or driven over.

J)K)8+0+%-8)?"<-')6"'8.?C&%)6+#)6+&2-)$'-)"')%(I-)

you an electric shock. When damaged it must be

'-?C+6-8G) ,@(2) 2@"&C8) "#CD) E-) 8"#-) ED) L&+C($-8)

personnel.

Accessories Included

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Safety Information

IMPORTANT - Please read these instructions fully before installing or operating

Moisture and Water

7,Do not use this TV in a humid or damp place (avoid

bathrooms, the sink in the kitchen, etc.

7,Do not expose this TV to rain or water, as this may

be dangerous.

7,Do not) ?C+6-)"EM-6,2) $CC-8) <(,@) C(L&(82G) 2&6@)+2)

B"<-')I+2-2G)"#),"?)"A),@-)/NO)KI"(8)A'"0)8'(??(#%)

or splashing.

J)If any solid object or liquid falls into the cabinet,

&#?C&%),@-) /N) +#8) @+I-) (,) 6@-6F-8) ED) L&+C($-8)

personnel before operating it any further.

Ventilation

J)The slots and openings on the TV set are intended

for ventilation and to ensure reliable operation.

J)To prevent overheating, these openings must not

be blocked or covered in anyway.

Heat sources and Flames

7,Do not expose the TV to direct sunlight or other

heat sources.

J)The TV should not be placed near to

"?-#) B+0-2) +#8) 2"&'6-2) "A) (#,-#2-)

heat such as an electric heater.

J)P#2&'-) ,@+,) #") "?-#) B+0-) 2"&'6-2G)

such as lighted candles, are placed on top of the TV.

Headphone Volume

J)Excessive sound pressure from earphones

and headphones can cause hearing loss, please take care.

Wall Mounting (optional)

J)To prevent injury, this TV must be securely attached

to the wall in accordance with the installation instructions (if the option is available).

LCD Screen

J)Occasionally, a few non-active pixels may appear

on the screen as a fixed blue, green or red point. Please note that this does not affect the performance of your product.

J)/+F-)6+'-)#",),")26'+,6@),@-)26'--#)<(,@)$#%-'#+(C2)

or other hard objects.

Cleaning

J)Before cleaning, unplug the TV from the wall

socket.

7,Do not use liquid or aerosol cleaners. Only use a

soft, dry cloth.

Batteries

Warning: Incorrect installation of

batteries may cause battery leakage and corrosion, resulting in damage to the remote control.

7,Do not mix old and new batteries, or

batteries of different types.

7,Do not 8(2?"2-)"A)E+,,-'(-2)(#)+)$'-O 7,Do not dispose of batteries with normal household

waste, take to a local recycling centre.

CAUTION: Insert the batteries / rechargeable

batteries in the correct polarity. Don´t try to recharge non rechargeable batteries and under no circumstances

,@'"<),@-0)(#,")$'-O)*+#%-') "A)-Q?C"2("#O)*")#",)&2-)

unequal batteries (old and new, Alkaline and carbon, etc.) simultaneously. If you will not use the device for a long time, remove the batteries and store the device in a dry and dust free place. Improper use of batteries may cause an explosion or leakage. If the batteries have leaked, use gloves and clean the appliance thoroughly with a dry cloth! Batteries should not be exposed to

@-+,G)2&6@)+2)2@(#-G)$'-)"'),@-)C(F-O

Accessories Included

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Warning: Risk of electric shock, do not attempt

to repair, service or modify this TV yourself. Contact the manufacturer, their approved service agent or the Customer Helpline: 0845 604 0105.

Taking out of service and storing

Unplug the TV from the mains and pack the TV in an appropriate cardboard box. Remove the batteries from the remote control and pack the remote control to the TV set.

NOTE: The TV set should be stored in a dry and

dust-free room.

Connection to a Television Distribution System (Cable TV etc.) from Tuner

Device connected to the protective earthing of the building installation through the mains connection or through other apparatus with a connection to protective earthing-and to a television distribution system using coaxial cable, may in some circumstances create a

$'-)@+H+'8O

Connection to a cable distribution system has therefore to be provided through a device providing electrical isolation below a certain frequency range (galvanic isolator, see EN 60728-11).

Safety Information

IMPORTANT - Please read these instructions fully before installing or operating

Symbols in this Instruction Book

The following symbols are used in the Instruction Book as a marker for restrictions and precautions and safety instructions. Note such information for security reasons.

WARNING

If you do not pay attention to such a marked warning, it can cause serious injury or death. Note these warnings strictly, in order to ensure a safe operation.

CAUTION

Such a precaution is marked, you should take up or note, to avoid injury or property damage. Note these instructions strictly, in order to ensure a safe operation.

IMPORTANT

Warnings on the appliance and restrictions are displayed like this. Read this information strictly in order to operate the system correctly and avoid damage.

NOTE: Information about the operation and

additional explanations are marked like this. To be aware of such information is recommended to ensure that the functions can be used optimally.

Accessories Included

Replacement Parts

When replacement parts are required, make sure that the service technician has used replacement parts,

<@(6@)+'-) 2?-6($-8)ED) ,@-) 0+#&A+6,&'-')"') @+I-),@-) 2+0-)2?-6($6+,("#2)+2),@-)"'(%(#+C)"#-O)R#+&,@"'(2-8) 2&E2,(,&,("#2)0+D)'-2&C,)(#)$'-G)-C-6,'(6+C)2@"6F)"')",@-')

hazards.

Servicing

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Support

The Argos Technical Helpline is here to help

Technical experts are available 7 days a week

7,!%1"8#,9#8",'*:,':;%$#,)*,+#((%*<,=",>)=2,:%<%('8,

equipment (image).

7,?=%:'*$#,)*,$)**#$(%*<,)(9#2,:#;%$#+,(),>)=2,

television such as a DVD player, Sky, home cinema system or a games console.

7,@2:#2,+"'2#,"'2(+A,%*$8=:%*<,(9'(,8)+(,2#1)(#,

control.

7,B*>,)(9#2,(#$9*%$'8,%++=#+,>)=,1'>,*##:,

assistance with.

Call us today: 0044 845 604 0105

Local call rates applies*

Lines open 9am-8pm Monday to Saturday and 10am-4pm Sunday.

*Calls to Argos enquiry lines may attract a charge and set up fee from residential lines depending on your call plan/tariff. Mobile and other providers costs may vary, see www.bt.com/pricing for details.

For Security and training purposes, telephone calls to and from customer service centres maybe recorded and monitored. Calls from Republic of Ireland will attract international call charges.

0345 604 0105

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Getting Started

TV - Features

Accessories included

Optional Accessories

Wall mount bracket

NOTE:You should check the accessories after

pu r chasing. Make sure that eac h accesso r y is included.

J)Remote controlled colour LCD TV.

J)Fully integrated Terrestrial digital TV (MPEG4)

J)HDMI connectors for digital video and audio.

This connection is also designed to accept high

8-$#(,("#)2(%#+C2O

J)USB input.

J)1000 programmes (analogue+digital).

J)OSD menu system.

J)Integrated tuner MPEG4 compatible.

J)Scart socket for external devices (such as video,

video games, audio set, etc.).

J)Stereo sound system. (German+Nicam)

J)Teletext, fastext, TOP text.

J)Headphone connection.

J)Automatic programming system.

J)Forward or backward manual tuning.

J)Sleep timer / Child lock.

J)Automatic sound mute when no transmission.

J)NTSC playback.

J)AVL (Automatic Volume Limiting).

J)Auto power down.

J)PLL (Frequency Search).

J)PC input.

J)Plug&Play for Windows 98, ME, 2000, XP, Vista,

Windos 7.

J)Game Mode

Remote Control

Batteries: 2 x AAA

Instruction Book

Quick Start Guide

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Getting Started - TV

Viewing remote control - TV

SCREEN

LANG

SUBTITLE

PIP

RETURN

SOURCEFAV

PRESETSSLEEP

INFO

EPG

V+

V-P-

P+

uage (in DVB

AV / Source selection

Volume Up

Volume Down

Yellow button

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Getting Started

Attaching the Stand

1.)1,+#8)(2)?C+6-8)"#)+)B+,)2&'A+6-)S$%.1).

2. /")(#2,+CC) ,@-) /N) "#) ,@-) <+CCG) $'2,) "A) +CCG) A"",)

assembly should be removed. Unscrew the 4 screws that attach the foot assembly to the panel and

'-0"I-),@-)A"",)+22-0ECD)A'"0),@-)?+#-C)S$%O3TO

$%.1

$%.2

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Getting Started

TV - Control buttons

1. Standby ( ) button

Turns the TV on when in standby mode or turns the TV off into standby mode.

2. TV/AV button

Changes the operation of “Up” and “Down” buttons.

3. Programme Up/Down buttons

Moves up/down a channel.

4. Volume Up/Down buttons

Increases/decreases the volume.

NOTE: If you switch on your TV via PROGRAMME

UP/DOWN buttons on the remote control or on the TV set, the programme that you were watching last will be reselected.

NOTE:Press “ ” / “ ” buttons at the same

time to view main menu.

Standby-LCD

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Getting Started

Aerial connection

Connect the “aerial” or “cable TV” plug to AERIAL INPUT (ANT.) socket located on the back of the

/N)S$%O1).

Switching the TV On and Off

Switching the TV On

With power cord plug connected to the mains power socket, the TV is in ‘Standby’ mode.

To switch the TV on from standby mode:

Connect the power cord to the 220-240V AC 50 Hz. Then the standby LCD lights up. (The led will blink during the standby On/Off)

To switch on the TV from standby mode either:

a. Press the “

” button, P+ / P- or a numeric button on

the remote control.

b. Press the “

”, - or + button of the TV.

By either method the TV will switch on.

AAA/R3 x 2

Batteries

Switching the TV Off

Press the “ ” button on the remote control or press the “

” switch on the TV, the TV will switch to standby

mode.

To turn off the TV completely, remove the power cord plug from the mains power socket.

NOTE: When the TV is in standby mode, the

standby LCD can blink to indicate that features such as Standby Search, Over Air Download or Timer is active.

NOTE: If you switch on your TV via P +/- buttons on

the remote control or +/- on the TV set, the programme that you were watching last will be reselected.

HDM

SPDIF

Coax.OUT

HDM

SPDIF

Coax.OUT

$%O1

$%O2

Power connection

IMPORTANT :The TV set is designed to operate on

220-240V AC, 50 Hz.

Please note: After unpacking, allow the TV to reach ambient room temperature before connecting the TV to the mains power socket.

Connect the power cord plug to the mains power socket.

The LCD on the front of the TV then lights up, this indicates that the TV is in ‘Standby’ mode.

Remote control - Inserting batteries

Remove the battery cover on the back of the remote control, gently push down and pull backwards at the same time as shown.

Insert two AAA/R3 or equivalent type batteries. Ensure the batteries are inserted the correct way and replace ,@-)E+,,-'D)6"I-')S$%O2).

NOTE: When the remote control is not going to

be used for long periods of time, the batteries should be removed. Otherwise the remote control may be damaged, caused by battery leakage and corrosion.

Wall Mounting

When wall mounting please ensure you use a compatible wall mount (not supplied). This TV conforms to the VESA

0"&#,(#%)2?-6($6+,("#2)+#8)(2)UVV)Q)3VV00O

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Getting Started

Operation using TV control buttons

The main menu OSD (On Screen Display) cannot be displayed using the TV control buttons.

The “

”/“ ” buttons will function as volume up/down as default. Even if you set other functions for these buttons, the “ ”/“ ” buttons will return to volume control after a short while.

Volume Setting

Press “

” button to decrease volume or “ ”

button to increase volume, so a volume level scale (slider) will be displayed on the screen.

Programme Selection

Press “P/CH +” bu t ton to sele c t the next programme or “P/CH -” button to select the previous programme.

AV Mode

Hold the TV/AV button for a few seconds, the “Source” OSD will be displayed.

Operation using Remote control buttons

The remote control is designed to control all the functions of the model you selected.

Volume Setting

Press “V +” button to increase the volume. Press “V -” button to decrease the volume. A volume level scale (slider) will be displayed on the screen.

Prog r a m me Selection (Previous o r Next Programme)

Press P- button to select the previous programme. Press P+ button to select the next programme.

Programme Selection (Direct Access)

Press number buttons on the remote control to select programmes between 0 and 9. The TV will switch to the selected programme.

To select programmes between 10-500 (IDTV) or 10-199 (analogue), press the number buttons consecutively.

SCREEN

LANG

RETURN

SOURCEFAV

PRESETSSLEEP

INFO

EPG

V+

V-P-

P+

PIP

SUBTITLE

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

Getting Started

Initial set up

W@-#),&'#-8)"#)A"'),@-)$'2,) ,(0-G) C+#%&+%-) 2-C-6,("#)) 0-22+%-) (2) 8(2?C+D-8) S$%.1). Press the “

” or “

” button to highlight the required language, press OK button to select. “First Time Installation” appears. Use“

” or “ ” button to set the required country, and press

“

” button to select “Teletext Language”. Use “ ” or

“

” button to set the “Teletext Language” and select

“Scan Encrypted” using “

” or “ ” button. Set “Scan

Encrypted” using “

” or “ )X)E&,,"#)S$%O2).

Press OK button on the remote control to continue and the 6"#$'0+,("#)26'--#)<(CC)E-)8(2?C+D-8)"#),@-)26'--#)S$%O3).To start automatic select Yes (to cancel select No), highlight the item required using the “

” or “ ” button and press

OK)E&,,"#),")2-C-6,O)/@-)2-+'6@)<(CC)2,+',)S$%.4).

I M P O RTA N T: D o n o t turn of f the TV while

“First Time Installation” is in operation.

After all the available stations are stored, Channel List will be displayed on the screen. If LCN (*) is available in your country, a message appears on the screen which asks you if you want to sort the channels according to LCN. In some countries, the order of the channels is arranged automatically by the broadcaster. This is called logical channel number (LCN). If the selected country has LCN support, the channels will be enumerated one by one, beginning from number 1. You cannot move any programme to a position after the last saved one. If you try to do this, both programmes will change their places. If LCN support is not available, you can move the channels as you wish.

Press OK button to quit channel list and watch TV.

(*) LCN is the Logical Channel Number system that organizes available broadcasts in accordance with a recognizable channel sequence.

Information Banner

Whenever you change channel using the P-/P+ buttons or the numeric buttons, the TV displays the broadcast picture along with an information banner at the bottom of the screen. The information banner can be displayed at any time while watching TV by pressing the INFO E&,,"#)"#),@-)'-0",-)6"#,'"C)S$%.5).

Hint: Not all channels broadcast the programme data. If the name and time of the programme are not available, then information banner will be displayed with blanks.

If the selected channel is locked, you must enter the correct four-digit numeric code to view the channel (default code is 0000). “Enter PIN” will be displayed on the screen in such a case.

Source Selection

Press the SOURCE button on the remote control for switching between the sources.

S$%.1)

S$%.2)

S$%.3)

S$%.4)

S$%.5)

For any help concerning set up and use of your TV please call the Customer Helpline: 0044 845 604 0105

+ 30 hidden pages
