Bush LCD32F1080P Instruction Manual

LCD32F1080 P

COLOUR TV

I N S T R U C T I O N M A N U A L

Helpline no: 0845 604 0105

BUSH KAPAK-50138695.p65 17.11.2008, 16:321

English - 1 -

Features ............................................................... 3

Acc essories ......................................................... 3

Introduction ........................................................... 4

Preparation ........................................................... 4

Safety Precautions ............................................... 4

Power Source .................................................. 4

Power Cord ...................................................... 4

Moisture and Water .......................................... 4

Cleaning ............................................................ 4

Ventilation ......................................................... 5

Heat and Flames ............................................... 5

Lightning ........................................................... 5

Replacement Parts ............................................ 5

Servicing ........................................................... 5

Waste Disposal ................................................. 5

Information for Users in European Union

Countries .......................................................... 5

Disconnecting the Device ................................. 6

Headphone Volume ........................................... 6

Installation ......................................................... 6

LCD Screen ...................................................... 6

Warning ............................................................ 6

Overview of the Remote Control .......................... 7

LCD TV and Operating Buttons ............................ 8

Viewing the Connections ..................................... 9

Power Connection .............................................. 11

Aerial Connection ............................................... 11

Connecting the LCD TV to a PC .......................... 12

Connecting to a DVD Player ............................... 13

Using Side Connectors ....................................... 14

Connecting Other Equipment via Scart ............... 15

Input Selection .................................................... 15

Inserting Batteries in the Remote Control

Handset .............................................................. 16

Operating Range for the Remote Control ............ 16

Switching the TV On/Off .................................... 17

To Switch the TV On ...................................... 17

To Switch the TV Off ...................................... 17

Navigating the Menu System .............................. 17

Initial Settings ...................................................... 18

Basic Operations ................................................ 19

Operation with the Buttons on the TV ............ 19

Volume Setting ............................................ 19

Programme Selection .................................. 19

Entering Main Menu ..................................... 19

AV Mode ..................................................... 19

Operation with the Remote Control ................. 19

Volume Setting ............................................ 19

Programme Selection (Previous or Next

Programme)................................................. 19

Programme Selection (Direct Access) ........ 19

Everyday Operation ........................................... 20

Information Banner ......................................... 20

Electronic Programme Guide (EPG)................. 20

Displaying the Subtitles ................................... 21

Digital Teletext ................................................. 21

Over Air Download ......................................... 22

Widescreen .................................................... 22

IDTV Menu System ............................................. 22

Channel List .................................................... 22

Navigating the Entire Channel List ............... 23

Deleting the Channels in the Channel List ... 23

Renaming Channels .................................... 23

Adding Locks to Channels .......................... 24

Setting Favourites ....................................... 24

On Screen Help ........................................... 24

Installation ....................................................... 24

Add New Channels ..................................... 25

Automatic Search ................................. 25

Manual Search ...................................... 25

Configuration .................................................. 26

Audio Language.......................................... 26

Subtitle ........................................................ 27

Favourite Mode ........................................... 27

EPG Preference .......................................... 27

Receiver Upgrade ....................................... 27

Automatic Download (Automatic

Upgrade) ............................................... 27

Search for New Version (Manual

Upgrade) ............................................... 27

Parental Settings ......................................... 28

Timers ............................................................. 28

Language ........................................................ 29

TV Setup ......................................................... 29

Common Interface ........................................... 30

Menu System ...................................................... 31

Picture Menu ................................................... 31

Mode ........................................................... 31

Contrast/Brightness/Sharpness/Colour/Hue ..... 31

Colour Temp ................................................ 31

Noise Reduction .......................................... 31

Film Mode .................................................... 31

Store ........................................................... 31

Reset .......................................................... 31

Sound Menu.................................................... 32

Volume ........................................................ 32

Equalizer ..................................................... 32

Balance ....................................................... 32

Headphone.................................................. 32

Volume .................................................. 32

Balance ................................................. 32

Sound Mode ................................................ 32

AVL ............................................................. 32

Effect .......................................................... 32

Dynamic Bass ............................................. 33

3D Panorama............................................... 33

Subwo of er .................................................. 33

Store ........................................................... 33

Feature Menu.................................................. 33

Sleep Timer ................................................. 33

Contents

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:341

English - 2 -

Child Lock ................................................... 33

Language .................................................... 33

EXT-2 Out .................................................... 33

Default Zoom............................................... 34

Blue Background ......................................... 34

Menu Background ....................................... 34

Menu Timeout .............................................. 34

Teletext Language ....................................... 34

Install Menu ..................................................... 35

Program ...................................................... 35

Band ........................................................... 35

Channel....................................................... 35

Colour System............................................. 35

Sound System ............................................. 35

Fine Tune .................................................... 35

Search ........................................................ 35

VCR ............................................................ 35

Store Program ............................................. 35

Program Menu................................................. 36

Name .................................................... 36

Insert .................................................... 36

Delete ................................................... 36

APS (Auto Programming System) ......... 36

Country ....................................................... 36

Install Menu in AV Modes ............................ 37

Colour System ...................................... 37

VCR ...................................................... 37

Store Program ............................................. 37

Source Menu .................................................. 37

PC Mode Menu System ....................................... 38

Sound Menu.................................................... 38

Feature Menu.................................................. 38

PC Picture Menu.............................................. 38

PC Picture Position Menu ................................ 38

Autoposition ................................................ 38

H (Horizontal) Position ................................. 38

V (Vertical) Position .................................... 38

Dot Clock ..................................................... 38

Phase .......................................................... 38

Displaying TV Information ................................... 39

Mute Function ..................................................... 39

PIP (Picture-in-Picture) and PAP (Picture-and-

Picture) Modes ................................................... 39

Picture Mode Selection ....................................... 39

Freezing Picture ................................................. 39

Zoom Modes ....................................................... 39

Auto ............................................................ 39

Full .............................................................. 40

4:3 ............................................................... 40

Panoramic ................................................... 40

14:9 Zoom ................................................... 40

Cinema ........................................................ 40

16:9 Subtitle ................................................ 40

Teletext ............................................................... 41

Tips .................................................................... 42

Care of the Screen ......................................... 42

Image Persistence .......................................... 42

No Power ........................................................ 42

Poor Picture .................................................... 42

No Picture ....................................................... 42

Sound ............................................................. 42

Remote Control ............................................... 42

Input Sources ................................................. 42

CI Module ........................................................ 42

Appendix A: PC Input Typical Display Modes ...... 43

Appendix B: Main and PIP-PAP Picture

Combinations ...................................................... 44

Appendix C: AV and HDMI Signal Compatibility ... 45

Appendix D: Pin Specifications ........................... 46

Appendix E: Important Instruction ....................... 47

Specifications ..................................................... 48

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:342

English - 3 -

Features

• Remote controlled colour LCD TV.

• Fully integrated digital TV (DVB-T).

• It has two HDMI connectors for digital video

and audio. This connection is also designed

to accept high definition signals.

• Full HD (1920x1080).

• 100 programmes from VHF, UHF bands or

cable channels can be preset.

• It can tune cable channels.

• OSD menu system.

• It has 2 scart sockets for external devices

(such as video, video games, audio set, etc.).

• AV in .

• Stereo sound system (3D Panorama).

• Teletext, fastext, TOP text.

• Headphone connection.

• Automatic programming system.

• Forward or backward automatic tuning.

• Sleep timer.

• Child lock.

• Automatic sound mute when no transmission.

• NTSC playback.

• PIP / PAP functions.

• AVL (Automatic Volume Limiting).

• When no valid signal is detected, after 5

minutes the TV switches itself automatically

to standby mode.

• PLL (Frequency Search).

• PC input.

• Plug&Play for Windows 98, ME, 2000, XP, Vista.

• Audio line out.

Accessories

EXIT

/

GUIDE

WIDE

ABC DEF

GHI

JKL MNO

PQR

STU VWX YZ

M

P<P

OK

TV

DTV

AV

i

I-II

INFO

+

-

V

-

P

+

-/--

PP

0

1

2

3

4

5 6

7 8

9

PC

Remote Controller

Batteries

2 X AAA

Instruction Book

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:343

English - 4 -

Introduction

Than k you for choosi ng this

product. This manual will guide

you for the proper operation of

your TV. Before operating the TV,

please read this manual thoroughly.

Please do keep this manual in a safe place

for future references.

Preparation

For ventilation, leave a free space of at least

10 cm all around the set. To prevent any fault

and unsafe situations, please do not place

any objects on top of the set.

Use this device in moderate climates.

Safety Precautions

Please read the following recomme nded

safety precautions carefully for your safety.

Power Source

The TV set should be operated only from a

220-240 V AC, 50 Hz outlet. Ensure that you

sel ect the correct voltage setting for your

convenience.

Power Cord

Do not place the set, a piece of furniture, etc.

on the power cord (mains lead) or pinch the

cord. Handle the power cord by the plug. Do

not unplug the appliance by pulling from the

power cord and never touch the power cord

with wet hands as this could cause a short

circuit or electric shock. Never make a knot in

the cord or tie it with other cords. The power

cords should be placed in such a way that

they are not likely to be stepped on. A damaged

powe r cord can cause fire or give you an

electric shock. When it is damaged and needs

to be replaced, it should be done by qualified

personnel.

Moisture and Water

Do not use this device in

a hum id and damp

place (avo id t h e

bathroom, the sink in the

ki t chen , and nea r the

washing mac hine). Do

not expose this device to

rain or water, as this may be dangerous and

do not place objects filled with liquids, such

as flower vases, on top. Avoid from dripping

or splashing.

If any solid object or liquid falls into the cabinet,

unplug the TV and have it checked by qualified

personnel before operating it any further.

Cleaning

Before cleaning, unplug

the TV set from the wall

outlet. Do not use liquid or

aerosol cleaners. Use soft

and dry cloth.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:344

English - 5 -

Ventilation

The slots and openings on the TV set are

intended for ventilation and to ensure reliable

operati on. To preve nt ov erheatin g, these

openings must not be blocked or covered in

anyway.

Heat and Flames

The set should not be placed

near to open flames an d

sources of intense heat such as

an electric heater. Ensure that

no open flame sources, such as

lighted candles, are placed on top of the TV.

Batteries should not be exposed to excessive

heat such as sunshine, fire or the like.

Lightning

In case of storm and lightning

or wh e n going on h o l i d a y,

disconnect the power cord from

the wall outlet.

Replacement Parts

When replacement parts are required, make

sure that the service technic ian has used

replacement parts, which are specified by the

manufacturer or have the same specifications

as th e o r i g i n a l on e . U n a u t h o r i z e d

substitutions may result in fire, electrical shock

or other hazards.

Servicing

Pleas e refer all servici ng to

qu a l ified per s onnel. Do no t

remove the cover yourself as

this may result in an electric

shock.

Waste Disposal

Instructions for waste disposal:

• Packaging and packaging aids are recyclable

and sho u l d p r incipally be r e c ycl e d.

Packaging materials, such as foil bag, must

be kept away from children.

• Batteries, including those which are heavy

metal-free, should not be disposed of with

household waste. Please dispose of used

battery in an environment friendly manner.

Find out about the legal regulations which

apply in your area.

• Cold cat hode fluo resc ent lamp in LCD

PANEL contains a small amount of mercury;

please follow the local laws or regulations

for disposal.

Information for Users in European
Union Countries

This symbol on the product or

on its packaging means that

your electrical and electronic

device should be disposed at

the e n d of its se r v i c e li f e

separately fr o m yo u r

household wastes. There are

separate collection systems for recycling in

EU.

For more information, please contact the local

authority or the dealer where you purchased

the product.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:345

English - 6 -

Disconnecting the Device

The mains plug is used to disconnect TV set

from the mains and therefore it must remain

readily operable.

Headphone Volume

Excessive sound pressure from

ear p hon es and he a d p h o n e s

can cause hearing loss.

Installation

To prevent injury, this device must be securely

attached to the wall in accordance with the

installation instructions when mounted to the

wall (if the option is available).

LCD Screen

The LCD panel is a very high technology

product wi t h about a m i l l i o n th i n film

transistors, giving you fine picture details.

Occasion ally, a few non-active pixels may

appear on the screen as a fixed blue, green

or red point. Please note that this does not

affect the performance of your product.

Warning

Do not leave your TV in standby or operating

mode when you leave your house.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:346

English - 7 -

Overview of the Remote Control

Standby

Yellow / Feature

Blue / Install

Previous programme

Cursor up

Cursor right

Cursor down

TV / DTV

Mono-Stereo / Dual I-II

Programme up/down

Numeric buttons

No function

Hold (in TXT mode) / PIP position

Update (in TXT mode) / PAP position

Index page

Reveal (in TXT mode) / PC

Green / Picture menu

Red / Sound menu

Menu

OK / Store

Cursor left

AV / Source

Info

Volume up/down

Mute

Personal preference

Time

Teletext

Mix (in TXT mode) / PIP mode

Expand (in TXT mode) / Image size

EXIT

/

GUIDE

WIDE

ABC

DEF

GHI

JKL MNO

PQR

STU

VWX

YZ

1

2

3

4

5

6
7

8

9

10111213141516

17181920212223242526272829

30

M

P<P

OK

TV

DTV

AV

i

I-II

INFO

+

-

V

-P+

-/--

PP

0

1

2

3

4

5 6

7 8

9

PC

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:347

English - 8 -

LCD TV and Operating Buttons

FRONT VIEW

REAR VIEW

SIDE VIEW

P/CH

MENU

TV/AV

TV/AV

button

MENU

button

Volume Up/

Volume Down buttons

Standby button

Programme Up/

Programme Down buttons

+

P/CH+TV/AV

MENU

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:348

English - 9 -

Viewing the Connections

HEIJKLMNO

A

G

B

C

D

F

RS-232 IN

P

This connector is for service use only..

Video Input is used for connecting video signals of external devices.

Connect the video cable between the VIDEO IN socket on the TV and the VIDEO OUT jack on

your device.

Audio Inputs are used for connecting audio signals of external devices.

Connect the audio cable between the AUDIO INPUTS on the TV and the AUDIO OUTPUT

jacks on your device.

Headphone jack is used for connecting an external headphone to the system.

Connect to the HEADPHONE jack to listen to the TV from headphones (optional).

Subwoofer Out is for connecting an external, active subwoofer to the set to give a much

deeper bass effect.

Use an appropriate RCA cable to connect the set to a subwoofer unit.

CI Slot and SPDIF Out. CI Slot is used for inserting a CI card. A CI card allows you to view all

the channels that you subscribe to. For more information, see “Common Interface” section. S/

PDIF Out is used for transferring digital audio signals. Use an RCA cable to transfer audio

signals to a device that has S/PDIF input.

PC Input is for connecting a personal computer to the TV set.

REAR VIEW

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:349

English - 10 -

Connect the PC cable between the

PC INPUT on the TV and the PC output on your PC.

PC Audio Inputs connects to audio jacks of your PC to enable PC audio.

Connect the PC audio cable between the PC AUDIO INPUTS on the TV and audio output of

your PC.

Audio Line Outs output audio signals to an external device such as an optional sound

system.

To connect the external speakers to your TV, use AUDIO LINE OUTS of the TV with an audio

cable.

Component Audio Inputs are used for connecting component audio.

Connect the audio cable between COMPONENT AUDIO INPUTS on the TV and audio outputs

of your device.

Component Video Inputs (YPbPr) are used for connecting component video.

You can connect the component video and audio sockets with a device that has component

output. Connect the component video cables between the

COMPONENT VIDEO INPUTS on

on the TV and the component video outputs of your device.

While connecting, be sure that the

letters on your TV, “

Y”, “Pb”, “Pr” correspond with your device’s connectors.

HDMI Inputs are for connecting a device that has an HDMI socket.

Your LCD Television is capable of displaying High Definition pictures from devices such as a

High Definition Satellite Receiver or DVD Player. These devices must be connected via the

HDMI sockets or Component Socket. These sockets can accept either 720p or 1080i signals.

Also, only HDMI modes accept 1080p signals. No sound connection is needed for an HDMI to

HDMI connection.

SCART 1 inputs or outputs for external devices.

Connect the

SCART cable between SCART sockets on TV and SCART socket on your external

device (such as a decoder, a VCR or a DVD player).

Note: If an external device is connected via the SCART sockets, the TV will automatically

switch to AV mode. If both sockets are employed at the sime time,

SCART 1 becomes

the preferential.

SCART 2 inputs or outputs for external devices.

RF Input connects to an antenna or a cable.

Note that if you use a decoder or a media recorder, you should connect the aerial cable

through the device to the television with an appropriate antenna cable, as shown in the

illustration below.

P

Control TV via serial cable

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3410

English - 11 -

Power Connection

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.

• After unpacking, allow the TV set to reach the ambient room temperature before you

connect the set to the mains.

• Plug the power cable to the mains socket outlet.

Aerial Connection

• Connect the aerial or cable TV plug to the AERIAL INPUT socket located at the rear of the TV.

Aerial Input

REAR VIEW

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3411

English - 12 -

Connecting the LCD TV to a PC

For displaying your computer’s screen image on your LCD TV, you can connect your computer

to the TV set.

• Power off both computer and display before making any connections.

• Use 15-pin D-sub display cable to connect a PC to the LCD TV.

• When done, switch to PC source. See, “

Input selection” section.

• Set the resolution that suits your viewing requirements.

PC audio cable

(not supplied)

to audio output

PC RGB cable

(not supplied)

to PC RGB output

PC audio

inputs

REAR VIEW

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3412

English - 13 -

Connecting to a DVD Player

If you want to connect a DVD player to your LCD TV, you can use connectors of the TV set. DVD

players may have different connectors. Please refer to your DVD player’s instruction book for

additional information. Power off both the TV and the device before making any connections.

Note: Cables shown in the illustration are not supplied.

• If your DVD player has an HDMI socket, you can connect via HDMI. When you connect to DVD

player as illustrated below, switch to HDMI source. See, “

Source menu” section.

• Most DVD players are connected through

COMPONENT SOCKETS. Use a component video

cable to connect video input. For enabling audio, use a component audio cable as illustrated

below. When done, switch to YPbPr source. See, “Input selection” section.

• You may also connect through the

SCART 1 or SCART 2. Use a SCART cable as shown

below.

Component

video

inputs

Component

audio

inputs

Component

audio
cable

Component

video
cable

SCART

cable

HDMI
cable

HDMI
inputs

SCART
sockets

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3413

English - 14 -

Using Side Connectors

You can connect a range of optional equipment to your LCD TV. Possible connections are

shown below.

Note that cables shown in the illustration are not supplied.

•

For connecting a camcorder, connect to the VIDEO IN socket and the AUDIO SOCKETS. Do

not connect the camcoder to

VIDEO IN socket at the sime time since it can cause noise in the

picture. For selecting the related source, see the section “

Input selection” in the following

parts.

• To connect external speakers, use an audio cable. Do not reverse the AUDIO LEFT and

AUDIO RIGHT jacks. Turn on the LCD TV and external speaker set after all connections are

made. Refer to your speaker set’s manual for further queries.

• To listen the sound from headphones, connect to the

HEADPHONE jack of theTV.

• For connecting a subwoofer, connect to the

SUBWOOFER OUT.

Headphone

Videocamera

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3414

English - 15 -

Connecting Other Equipment via Scart

Most devices support SCART connection. You can connect a; DVD recorder, a VCR or a decoder

to your LCD TV by using the

SCART sockets. Note that cables shown in the illustration are not

supplied.

Power off both the TV and the devices before making any connections.

For more information, refer to your device’s own instruction book.

SCART
sockets

VCR

DVD Recorder

Decoder

Input Selection

Once you have connected external systems to your TV, you can switch to different input sources.

• Press

AV button on your remote control for directly changing sources.

or,

• Select “Source” option from the main menu by using or button and press OK button.

Use then

or button to highlight an input and press OK button to select.

SOURCE : TV

TV

EXT - 1

EXT - 2

EXT - 3

EXT - 4

EXT - 5

TUNER

SCART

SCART

YPbPr

FAV

HDMI

EXT - 6

HDMI

PC

DTV

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3415

English - 16 -

Inserting Batteries in the
Remote Control Handset

• Remove the battery cover located on the back

of the handset by gently pulling backwards

from the indicated part.

• Insert two

AAA/R 03 or equival ent type

batteries inside. Place the batteries in the

right directions and replace the battery cover.

Note:Remove the batteries from the remote

control when it is not going to be used for a

long time. Otherwise the batteries may leak

and damage the handset.

Operating Range for the
Remote Control

• Point the top of the remote control toward

the LCD TV's remo te sen sor LED while

pressing a button.

30

30

EXIT

/

GUIDE

WIDE

ABC DEF

GHI

JKL MNO PQR

STU

VWX

YZ

M

P<P

OK

TV

DTV

AV

i

I-II

INFO

+

-

V

-

P

+

-/--

PP

0

1

2 3

4 5 6

7 8

9

PC

Remote range is approximately 7m/23ft.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3416

English - 17 -

Switching the TV On/Off

To Switch the TV On

• Connect the power cord to the 220-240V AC ,

50 Hz.

• Press STANDBY button. Then the standby

LED lights up.

• To switch on the TV from standby mode either:

• Press the

button, P+ / P- or a numeric

button on the remote control.

• Press the

-P/CH or P/CH+ button on the TV.

The TV will then switch on.

Note: If you switch on your TV via PROGRAM

UP/DOWN buttons on the remote control

or on the TV set, the programme that

you were watching last will be reselected.

To Switch the TV Off

• Press the button on the remote control or

STANDBY button on the TV, so the TV will

switch to standby mode.

• To power down the TV completely, unplug

the power cord from the mains socket.

Navigating the Menu System

For displaying
menu options

For navigation

To confirm choices

• Press M to display the main menu.

• Press or button to select an icon. Press

or OK button for more options.

• Use or button to highlight.

• Press or buttons to change the settings.

Press

OK to set as default.

• To exit the menu or return from sub-menu

screen, press

M.

Note: These explanations are valid for the

navigation of the whole menu system.

To select options that are explained in

the following parts, refer to “Navigating

the Menu System”.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3417

English - 18 -

Initial Settings

When the TV set is operated for the first time,

the IDTV turns on first.

Because this is the first time the TV is used, there

are no channels stored in the memory and the

following message appears on the screen:

Please ensure aerial is plugged in. Do you
want to start first time installation?

Yes

No

• To start installation process, select “Yes”,

to cancel select “No”.

• To select the “Yes” or “No” option, highlight

the item by using

or buttons and press

the

OK button.

The IDTV will automatically tune to the UHF

transmision channels 21 to 68, searching for

digital terrestrial TV broadcasts and displaying

the names of channels found. This process

wi l l ta k e ab o u t fi v e mi n u t e s . To cancel

searching, you can press the M button at any

time during the process.

MENU

BBC ONE
BBC TWO
BBC CHOICE

Searching UHF channels 30. Please wait. This will take a few minutes

Cancel search

AUTOMATIC SEARCH

Channels:

12 %

After Automatic Search is completed, the

following message asking for analogue channel

search appears on the screen:

Yes

Do you want to search for
analogue channels?

No

To seach for analogue channels, select “Yes”.

TV switches to the analogue TV mode. The

menu below is di s p l a y e d to sea r c h fo r

analo gue channels:

AUTO P ROGRA M

Country UK

Text language West

Select your Language, Country and Text

language

by using or and  /  buttons.

Press

OK button to continue. To cancel, press

the

BLUE button.

For more information on this process, see

“Install Menu” section.

NOTE: For proper functioning of digital teletext

in DTV mode, you should set

country

as UK in analogue AUTO PROGRAM.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3418

English - 19 -

Basic Operations

You can operate your TV using both the

remote control and onset buttons.

Operation with the Buttons on the TV

Volume Setting

• Press - button to decrease volume or

+ button to increase volume, so a volume

level scale (slider) will be displayed on the

screen.

Programme Selection

• Press P/ CH + button to select the next

programme or

P/CH - button to select the

previous programme.

Entering Main Menu

• Press the MENU button to enter main menu.

In the Main menu select sub-menu using

P/

CH -

or P/CH + buttons and enter the sub-

menu using

- or + buttons. To learn

the usage of the menus, refer to the menu

system sections.

AV Mode

• Press the TV/AV button at the control panel

on the the TV to switch your TV to AV modes.

Operation with the Remote Control

• The remote control of your TV is designed to

control all the functions of the model you

selected. The functions will be described in

accordance with the menu system of your

TV.

• Functions of the menu system are described

in the following sections.

Volume Setting

Press V + button to increase the volume.

Press

V - button to decrease the volume. A

volume level scale (slider) will be displayed

on the screen.

Programme Selection (Previous or
Next Programme)

• Press P - button to select the previous

programme.

• Pr e s s P + bu t t o n to se l e c t th e ne x t

programme.

Programme Selection (Direct Access)

•Press numeric buttons on the remote control

to select programmes between 0 and 9. The

TV will switch to the selected programme.

To select programmes between 10 - 999 (for

IDTV) or 10-99 (for analogue), press the

nu m eric bu tton s co nsecu t i vely (eg. fo r

programme 27, first press 2 and then 7).

When the pressing time is due for the second

numeric button, only the first digit programme

will be displayed. The limit of the delay time

is 3 seconds.

• Press directly the programme number to

reselect single digit programmes.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3419

English - 20 -

Everyday Operation

Press ing the

TV

DTV

button at any time

while watching televis ion programmes will

switch the TV set between the digital terrestrial

televi sion br o a d c a sting and it s n o r m a l

analogue broadcasting.

Information Banner

• Whenever you change channel, using the P-

/ P+ button or the numeric buttons, the TV

displays the broadcast picture along with an

information banner at the bottom of the

screen. This will remain on the screen for

approximately three seconds.

• Th e i n form ation banner c a n a l so be

displayed at any time while watching TV by

press ing the

button on the remote

control:

Now: 50/50
Next: Ace Lighting

1. BBC ONE

Signal Level:

13:15

09:25 - 11:00
11:00 - 11:25

• The information banner gives information

on th e c h a nne l selected and the

programmes on it. The name of the channel

is displaye d, along with its channel lis t

number and an indication of the strength of

the signal received.

Hi nt : No t a l l channe l s bro a d c a s t th e

programme data. If the name and time

of the programme are not avai lab le,

then “

No Information Available” will be

displayed in the information banner.

• Icons are also displayed in the information

banner and if this channel is a favourite

channel, favourite channel icon “ ” will

also be displayed.

If the selected channel is locked, you must

enter the correct four numeric code to view

the channe l . “

Enter Lock Ke y” will be

displayed on the screen in such a case:

Enter Lock Key

Electronic Programme Guide (EPG)

• Some, but not all, channels send information

about the current and next events.

• Please note that event information is updated

automatically. If there is no event information

data available in channels, only channel

names with

“No Information Available”

banner is displayed.

• Press

GUIDE button to view the EPG menu.

• In EPG menu, you can easily see the extended

help information by pressing

button.

• Press this button again to close this window.

• In the EPG menu, all channels are displayed.

Current channel is highlighted. Use

or

buttons to change cha nnels . Als o pr ess

GREEN/RED buttons to scroll up/down the

pages for the channels.

• If yo u hi g hlight an eve n t , short even t

description, extended event description, start

and end times of the event will be displayed

on the screen.

• If you press the OK button when a next event

is highlig hted, a reminder is set for the

highlighted programme and a clock appears

across the highlighted channel line.

Programme reminders can be set to signal

that a programme is about to start when you

are watch ing another channel. If you set

reminder for a programme, then you will be

asked for switching to that channel when the

reminder time is reached.

• Press the

M button to view the 7 day EPG.

• Press

or button to navigate in Channels

or Programmes.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3420

English - 21 -

• Press or button to navigate through the

channel and programme list.

Chuckle Vision 13:00-14:00

30. CBBC Channel 13:00 Chuckle Vision (Now)

40. BBC NEWS 24 14:00 Tracy Beaker

41. ITV News 14:55 Newsround

50. Four Text

800. BLUE/LEFT 1k...

801. CCIR17/1kHz...

ELECTRONIC PROGRAMME GUIDE(7 Day) Saturday 21/8 13:49

Channels Programmes on Saturday 21/8, 13:00 - 15:00

Triple bill. In the Ring/Romany Days/On the Radio: Paul and Barry
grapple with the world of wrestling; hunt for a mysterious Emperor's
underpants; and record their first pop song.

I

More

Change

Day

Navigate

Change Time

• With RED/GREEN buttons, you can change

the schedule time. By pressing

YELLOW/

BL U E

you ca n advance th e schedule

backward/forward of a day.

• If you press

button you can see the

detailed help information easily. Press

button again to exit help menu.

• The starting time for

EPG is the current time.

You can see the event information for the

next two hours. By pressing or button,

you can go to the next/previous hours while

Programmes list is highlighted.

• lf you press the

OK button when a next event is

highlighted, a reminder is set for the highlighted

programme and a clock appears on the screen.

• Programme reminders can be set to signal

that a programme is about to start when you

are watching another cha nnel. If you set

reminder for a programme, then you will be

asked for switching to that channel when the

reminder time is due.

Newsround 16:55-17:00

30. CBBC Channel 15:00 Even Stevens

40. BBC NEWS 24 15:50 Newsround Showbiz

41. ITV News 16:00 Basil Brush

50. Four Text 16:55 Newsround

51. BBCI

800. BLUE/LEFT 1k...

801. CCIR17/1kHz...

ELECTRONIC PROGRAMME GUIDE(7 Day) Saturday 21/8 13:51

Channels Programmes on Saturday 21/8, 15:00 - 17:00

CBBC joins the Newsround team, keeping you up to date on the latest
stories and events happening at home and abroad.

I

More

Change

DayNavigate

Change Time

Displaying the Subtitles

With digital terrestrial broadcasting (DVB-T),

some p r o g ra m mes a r e broadcast wi t h

subtitles. Subtitles can be displayed while

watching these programmes.

Press the

M button to display the main menu,

highlight the

Configuration line using or

button and press the OK button to display the

configuration menu.

Highlight the “Subtitle” item in configuration

menu and use

or button to set Subtitle to

Off or a language.

If

“Subtitle” is on and a language option is set,

pressing the

button causes the following

warning message display on the screen:

Interactive services cannot be used

while subtitles are on. Would you like

to turn subtitles off now?

NoYes

Digital Teletext

With digital terrestrial broadcasting (DVB-T),

in addition to pictures and sound, you can also

view digital teletext.

Digital teletext is sometimes broadcast at the

same time with the normal broadcasting.

• Press the

button.

• The digital teletext information appears.

• Operate it with the coloured buttons, / / /

buttons and OK button.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3421

English - 22 -

The operation method may differ depending

on the contents of the digital teletext.

Follow the instructions displayed on digital

teletext screen.

• When “

Press SELECT” button or similar

message appears on the screen, press the

OK button.

• When the

(Text) button is pressed, the

TV returns to television broadcasting.

• With digital terrestrial broadcasting (DVB-

T), in addition to digital teletext broadcasting

together with the normal broadcasting, there

are also channels with just di gital teletext

broadcasting.

• The aspect ratio when watching a channel

with just digital teletext broadcasting is the

same as the aspect ratio of the picture viewed

previously.

• When you press the

(Text) button again,

the digital teletext screen will be displayed.

Over Air Download

To ensure that your IDTV always has the most

up-to-date information, please ens ure that,

after use, it is set to standby mode. At 3 A.M.

each day, the IDTV automatically searches for

any updates which may be broadcast and will

download this to your IDTV automatically. This

operation will normally take approximately 30

second s.

If you want to perform this, you need to set

Automatic Download to

“Enabled” in Receiver

Upgrade setting.

Widescreen

Depending on the type of the broadcast being

transmitted, programmes can be viewed in a

number of formats. Press the WIDE button

repeatedly to select between

Auto, Full, 4:3,

Panoramic, 14:9 Zoom, Cinema

or 16 :9

Subtitle.

When Auto is selected, the format being

displayed is determined by the picture being

broadcast.

PLEASE NOTE: Menu s i z e chang e s

depending on th e

chosen image size.

IDTV Menu System

The IDTV menu can only be viewed when

watch ing di gita l ter res t rial broa d cast ing.

Press the

TV

DTV

button to turn IDTV on

while the TV is in analogue mode.

Press the M button. The menu below appears

on the screen:

Main Menu

Channel List

Installation

Configuration

Timers

Language

TV Setup

Common Interface

Channel List

Using the or button on the remote control,

make sure that the firs t item, Channel List, is

highlighted and press the OK button to display

the

Channel List.

The following operations can be performed

in this menu:

• Navigating the entire list of channels

• Deleting channels

• Renaming channels

• Adding locks to channels

• Setting favourites

Channel List is the place where the channels

are managed.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3422

English - 23 -

SELECT

i

SELECT

CHANNEL LIST 1 BBC ONE

1. BBC ONE

2. BBC TWO

3. ITV 8

4. Channel 4

5. BBC THREE

6. Teletext

7. BBC FOUR

8. Sky Travel

9. UKHistory

10. RTL

Select

Delete Edit Name Lock Favourites

Function

Select Channel Watch More

Navigating the Entire Channel List

Press or button for selecting the previous

or next channel. You can press

RED or GREEN

button to move page up or page down.

To watch a specific channel, highlight it using

or button and then press OK button, while

the “

Select” item on Channel List menu is

highlighted by using

or button.

Then the name and number of the selected

channel will be displayed in the top-left and

top-right of the channel display at the top-right

of the screen, respectively.

Deleting the Channels in the Channel
List

Press or button to select the channel

that will be deleted.

Press

or button to select the “Delete’’

item on Cha nne l Lis t menu. As seen on

Channel List menu, SELECT is displayed next

to

Delete item at the bottom of the screen to

indicate that you must press the

OK button to

delete the highlighted channel in the channel

list.

SELECT

i

SELECT

CHANNEL LIST 1 BBC ONE

1. BBC ONE

2. BBC TWO

3. ITV 8

4. Channel 4

5. BBC THREE

6. Teletext

7. BBC FOUR

8. Sky Travel

9. UKHistory

10. RTL

Select

Delete Edit Name Lock Favourites

Function

Select Channel Delete More

Press the OK button to delete the highlighted

channel in the channel list. Then the message

below appears on the screen:

The selected service will be permanently
deleted. Are you sure?

Yes No

Press or button to highlight the desired

option. If

OK button is pressed while “Yes” is

highlighted, th e h i g h l i g h t ed c h a n n e l i s

deleted. Selecting “No” cancels the deletion.

Renaming Channels

To rena me a specific channel, the channel

must be highlighted by pressing

or button.

Then highlight the

Edit Name item by pressing

or button as illustrated below. Press the

OK button to activate the rename feature.

SELECT

i

SELECT

CHANNEL LIST 1 BBC ONE

1. BBC ONE

2. BBC TWO

3. ITV 8

4. Channel 4

5. BBC THREE

6. Teletext

7. BBC FOUR

8. Sky Travel

9. UKHistory

10. RTL

Select

Delete Edit Name Lock Favourites

Function

Select Channel Edit Name More

Now pressing or button moves to the

previous/next character. Pressing

or

button toggles the current character, i.e., ‘b’

character becomes ‘a’ by and ‘c’ by .

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3423

English - 24 -

Pressing the numeric buttons ‘0...9’ replaces

the highlighted character with the characters

printed above the button one by one as the

button is pressed.

Press the

M button to cancel the editing or OK

button to save the new name.

Adding Locks to Channels

Channel locking provides a password-protected

access to channels selected by parents. In order

to lock a channel you should know the parental

lock password (default value is set to 0000 in

the factory and can only be changed from the

Configuration menu).

Select the channel to be locked by highlighting

it and select the Lock option by pressing or

button. When the OK button is pressed, a dialog

OSD asking for the password will be displayed.

SELECT

i

SELECT

CHANNEL LIST 1 BBC ONE

1. BBC ONE

2. BBC TWO

3. ITV 8

4. Channel 4

5. BBC THREE

6. Teletext

7. BBC FOUR

8. Sky Travel

9. UKHistory

10. RTL

Select

Delete Edit Name Lock Favourites

Function

Select Channel Lock/Unlock More

Enter Lock Key

Enter the password by using the numeric buttons

on the remote control. The lock icon “

” will now

be displayed next to the selected channel. Repeat

the same operation to cancel the lock.

Setting Favourites

You can set various channels as favourites

so th a t on l y the favo u r i te channe l s ar e

navi gat ed. To set a favou rite you should

highlight the

Favourites item at the bottom of

the Channel List menu.

Us e the

or bu tton to highlig h t the

“Favourites” item at the bottom of the screen

and then, in turn, highlight each channel you

want to add to the favourites list, using the

and buttons (or red/green buttons), and

press the

OK button.

A channel selected as a favourite appears in

the main channel list with a favourites icon (

)

against the channel name as illustrated below:

SELECT

i

SELECT

CHANNEL LIST 1 BBC ONE

1. BBC ONE

2. BBC TWO

3. ITV 8

4. Channel 4

5. BBC THREE

6. Teletext

7. BBC FOUR

8. Sky Travel

9. UKHistory

10. RTL

Select

Delete Edit Name Lock Favourites

Function

Select Channel Add/Remove... More

On Screen Help

For all menus, press the button to display

the help information about the menu functions.

For C h an n e l List me nu t h e following

message is displayed on the screen:

Press the SELECT button on your remote control to tune to the

highlighted channel.

Press MENU to exit this screen.

Installation

The Installation menu is mainly intended to

help you for creating a

Channel Table in the

most efficient way.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3424

English - 25 -

Main Menu

Channel List

Installation

Configuration

Timers

Language

TV Setup

Common Interface

This menu includes the following items:

• Add New Channels.

• First Time Installation.

Add New Channels

This tuning menu consists of two parts:

• Automatic Search

• Manual Search

Installation

Add New Channels

First Time Installation

Automatic Search

Manual Search

Automatic Search

Automatic search is started by pressing the

OK button in the auto-search pop up menu.

All the services will be searched and a channel

table will be created automatically.

All channels found are stored in a sorted form

with respect to their channel numbers. Some

services may not appear with the correct

channe l number. Thi s may occu r due to

missing information when the broadcaster

does not transmit any channel information.

Manual Search

In manual search, the number of the multiplex

is entered manually and only that multiplex is

searched for the channels. For every vali d

channel number, signal level, signal quality

and network name are shown at the bottom

of the screen.

In both manual and auto search, any existing

channel in the database is not re-stored to

avoid redundant duplicates of that channel.

First Time Installation

The user can use this item to load default

settings, which were loaded to the receiver at

the factory.

To install factory settings, highlight

“First Time

Installation”

menu and press the OK button.

Installation

Add New Channels

First Time Installation

Then you will be asked to confirm for deleting

all channels and settings:

Yes

Your previous digital channel list will be destroyed.
Are you sure you want to delete all digital channels
and settings for first time installation?

No

By selecting Yes and pressing the OK button,

the existing channel table will be deleted.

After factory settings are loaded, “First Time

Installation

” menu will be displayed:

Please ensure aerial is plugged in. Do you
want to start first time installation?

Yes

No

Press the OK button to start installation. After

search is complete d for digital channe ls, a

message as k i n g whether to se a r c h for

analogue channels appears on the screen:

Yes

Do you want to search for
analogue channels?

No

Press the OK button to search for analogue

channels. The following menu appears on

the screen for analogue channel search:

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3425

English - 26 -

AUTO P ROGRA M

Country UK

Text language West

Select your Language, Country and Text

language

by using or and  /  buttons.

Press

OK button to continue. To cancel, press

BLUE button. The following menu will be

displayed during the APS process:

APS is running...

Cancel

After APS is finalized, the programme table

will appear on the screen. In the programme

table you will see the programme numbers

and names assigned to the programmes.

If you do not accept the locations and/or the

programme names, you can change them in

the program table.

Configuration

Press the M button to display the main menu

and press the

button twi ce to highlight

Configuration. Then press the

OK button to

display the configuration menu. Press the

M

button to leave the menu screen.

Main Menu

Channel List

Installation

Configuration

Timers

Language

TV Setup

Common Interface

Th e vari o u s co n f igurat i o n functio n s ar e

displayed in a list, along with a quarter-screen

image of the currently selected channel. You

can sel ect a function by highlig hti ng the

corresponding menu line using the

or

button. Configuration menu will look like this:

i

CONFIGURATION

Audio Language
Subtitle
Favourite Mode
EPG Preference
Receiver Upgrade

Parental Settings

English
Off
Off
Now&Next
V.1.5

Change Default Audio Language

More

Audio Language

Digita l terre stria l televis ion channels can

broadcast simultaneous soundtracks in more

than one la nguage. This function selec ts

which language soundtrack you will hear

when switching to a channel broadcasting with

the multiple soundtracks.

Highlight the

Audio Language line in the

Configuration menu and use the or

button to cycle through the language options.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3426

English - 27 -

Subtitle

Digi tal terre stria l televis ion channels can

broadcast subtitles displayed on the screen

for hard-of-hearing peo ple. This func tio n

selects the desired subtitle language and

ena bles the autom atic displ ay of subtitles

whenever subtitle information is broadcast.

Highlight the Subtitle line in the Configuration

menu and use the

or button to cycle

through

“Off” and language options.

Favourite Mode

This function enables or disables the favourite

channel list mode.

Use

or button to turn on/off favourite

mode. If the

“Favourite Mode” is on; while in

normal operating mode, pressing

P+ and P-

but t o n s wi l l on l y na v i g a te through the

channels that were previously define d as

favourites in the channel list.

EPG Preference

Digi tal terre stria l televis ion channels can

broadcas t simultaneous Next&Now and 7-

Day electronic programme.

Highlight the

EPG Preference line in the

Configuration menu and use the or

button to select Next&Now or 7-Day.

Receiver Upgrade

Th e IDTV can b e up gra d ed via t h e

configuration menu, entered from the main

menu.

In the con figur ation me nu, hi ghlig h t the

“Receiver Upgrade” item by pressing or

button and press the OK button to start

upgrade process.

There are two options for receiver software to

be upgraded:

automatic and manual.

i

CONFIGURATION

Audio Language
Subtitle
Favourite Mode
EPG Preference
Receiver Upgrade

Parental Settings

English
Off
Off
Now&Next
V.1.5

Exit

More

Automatic Download
Search for New Version

Enabled

MENU

Automatic Download (Automatic Upgrade)

Au tomat i c Down l oad can be enab l e d or

disabled by pressing

or button. If it is

enabled, t he n t h e r e are t w o wa y s for

automatic upgrade:

• The first one is checking the existence of a

new software every time the IDTV goes to

standby.

• The second one is being activated at 03:00

A.M. every night, provided that the IDTV is left

in standby mode.

• Both automatic upgrade methods result in

standby mode either the upgraded or not.

If the automatic upgrade is set to “

Disabled”

then this function will not work.

Search for New Version (Manual Upgrade)

Manual upgrade starts if the “Search for New

Version”

item is highlighted by using or

button and activated by pressing the OK button.

After

“Search for New Version” is activated,

the IDTV tunes to each frequency that have

been stored in its database and looks for the

new sof t w a r e. During th is process, th e

following OSD is displayed:

Software Upgrade

Searching for upgrade. Please wait, or
press MENU to cancel.

Search Progress:

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3427

English - 28 -

Parental Settings

Some channels broadcast material which you

do not want younger members of the family to

watch. Any channel can be ‘locked’ so that it cannot

be selected for viewing unless a four-digit PIN

code is entered. In this way, any channel not

suitable for younger viewers can be prohibited.

This function enables or disables the menu

protection system and allows the PIN code to

be changed.

Use

or button to highlight Parental

Settings

option. Press the OK button to enter

Parental Settings menu. A dialog box asking

for the lock key is displayed:

Enter Lock Key

There is only one key which is set to “0000”

initially. Enter lock key. If wrong lock key is

entered, the following message is displayed

and the TV then returns to the previous menu:

Wrong Lock Key

If it is correct, the Parental Settings menu will

be displayed including the following items:

Menu Lock

Installation

Set Lock Key

Here, you can set/reset locking for the main

menu or the ins tal lat ion menu to restrict

access. If the menu lock is disabled, there

will be free access to the menu system. Also

in this menu you can change the lock key and

set/change parental lock mode.

Disabled: All menus are unlocked.

Main Menu: Main menu is accessible only with

the correct lock key. So the user

cannot add, delete, rename, or

move the channels and cann ot

set the timers.

Installation: Installation menu is locked, so

the user cannot add channels.

Note: Changes will be updated after exiting

configuration menu.

Timers

You can set a timer to switch the TV to any

channel without your intervention. This is also

useful for recording the programmes when

you are out.

Display the main menu by pressing the M

button. Highlight the Timers line by pressing

or button and press the OK button to

display the Timer menu:

Main Menu

Channel List

Installation

Configuration

Timers

Language

TV Setup

Common Interface

Up to five separate timer events can be set

and each is displayed in the Timer screen,

showing the event number, the channel to be

selected, the start time, end time, date and

the mode - whether that event is active (and

will be acted on) or not.

SELECT

i

MENU

TIMER MENU

No Channel Name Start End Date Mode

1. ITV 1 20:00 21:00 12/05/2005 Active

2. BBC ONE 00:00 00:00 01/01/2005 Inactive

3. BBC ONE 00:00 00:00 01/01/2005 Inactive

4. BBC ONE 00:00 00:00 01/01/2005 Inactive

5. BBC ONE 00:00 00:00 01/01/2005 Inactive

6. BBC ONE 00:00 00:00 01/01/2005 Inactive

Toggle Mode

Exit

Edit Timer More

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3428

English - 29 -

• To set an event, highlight its mode button

using the

or button and press the OK

button to display the timer entry window.

Name:

Start:
End:
Date:
Mode:

3. ITV 1
00:00
00:00
03/06/2005
Once

• Here the five sett ing s cons istin g of the

channel name, start time, end time, date and

frequency mode can be set. You can move

freely between each setting using the

or

buttons.

• The channel name is set using the

or

butto n to disp l a y the c h a n n e l w h i c h

broadcasts the programme.

• The start time, end time and date are each

set with the numeric buttons on the remote

control in 24-hour format.

• The frequency mode determines how often

the receiver operates this event and is set

with the

or button to be either Once,

Daily, or Weekly.

If an invalid number for the start or end times

or the date is entered, “Entered time is not

va l i d ”

me ssage appears on th e m e n u

screen.

If timer action occurs while the TV is being

watched, the TV switche s to the selected

channel. When timer expires, the TV switches

back to the channel which it is switched from.

Selected digital channel will be output via

Scart-2. You should connect your VCR to Scart-

2 for recording digital broadcasts.

Language

Some programmes are broadcast in two or

more languages s im u l ta n eo u s l y. The

langu age thus can be selected from the

Language menu.

• Press the

M button to display the main menu

and use

or butto n to highlig ht the

Language line and press the

OK button:

Main Menu

Channel List

Installation

Configuration

Timers

Language

TV Setup

Common Interface

• Use the or button to highlig ht the

soundtrack language required and press the

OK button. Normal viewing, with the required

language soundtrack, can be resumed by

pressing the M button.

Languages

English

TV Setup

You can use this item to display the TV functions.

Th e d i g i t a l TV Se t u p me nu screen is

accessed from the main menu. Press the

M

button to display the main menu and use

or button to highlight “TV Setup”, press the

OK button to display TV Setup menu screen.

Main Menu

Channel List

Installation

Configuration

Timers

Language

TV Setup

Common Interface

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3429

English - 30 -

You can find detailed information for all menu

items in “Analogue TV Menu System” section.

Common Interface

• Press the M button to display the main menu

and use the

or button to highlight the

“Common Interface” line and press the OK

button:

Main Menu

Channel List

Installation

Configuration

Timers

Language

TV Setup

Common Interface

It is required to subscribe to a pay channel

company to view the pay channels of the digital

terrestrial broadcasting.

Obtain the Conditional Access Module (CAM)

and the viewing card by subscribing to a pay

channel company, then insert those to the TV

using the following procedure.

• Switch off the TV and unplug from the mains.

• Insert the CAM and then the viewing card to

the slot that is located in the terminal cover

at the left-hand side of the TV (from front

view).

• The CAM should be correctly inserted, it is

impossible to insert fully if reversed. The

CAM or the TV terminal may be damaged if

the CAM is forcefully inserted.

• Connect the TV to the mains supply, switch

on and then wait for few moments until the

card is activated.

• Some CAMs may require the following set

up. Please set the CAM by entering the IDTV

menu, Common Interface then pressing the

OK button. (C A M set u p menu is not

displayed when it is not required.)

• To see the viewing contract information: enter

IDTV; press the

M button, then highlight

Common Interface and press the OK button.

• When no module is inserted, “

No Common

Interfac e module detected

” messa ge

appears on the screen.

• Refer to the module instruction manual for

details of the settings.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3430

English - 31 -

Menu System

Picture Menu

Mode Dyn amic

Contrast 63

Brightness 63

Sharpness 31

Colour 99

Colour Temp Normal

Noise Reduction Low

Store

Film Mode Off

Reset


NO SIGNAL

Mode

For your viewing requirements, you can set

the related

mode option.

Press

or button to select Mode. Press

or button to choose from one of these

options:

Cinema, Dynamic and Natural.

Contrast/Brightness/Sharpness/Colour/
Hue

Press or button to select the desired

option. Press



/  button to set the level.

Note: Hue option can only be visible when

the TV receives an NTSC signal.

Colour Temp

Press or button to select Colour Temp.

Press



/  to choo se from one of these

options:

Cool, Normal and Warm.

Note:

• Setting

Cool option gives white colours a

slight blue stress.

• Setting Warm option gives white colours a

slight red stress.

• For normal colours, select Normal option.

Noise Reduction

If the broadcast signal is weak and the picture

is noisy, use

Noise Reductio n setting to

reduce the noise amount.

Pres s or b u t t o n to se l ec t N o i s e

Reduction

. Press  /  to choose from one of

these options:

Low, Medium, High or Off.

Film Mode

Films are recorded at a different number of

fr a m es per sec o n d to norm a l te l evisi o n

programmes .

Press

or button to select Film Mode.

Press



/  button to set this feature On or Off.

Turn this feature on when you are watching

films to see the fast motion scenes clearly.

Store

Press or button to select Store. Press



or OK button to store the settings. “Stored”

will be displayed on the screen.

Reset

Press or button to select Reset. Press



/  or OK button to reset the picture modes to

factory default settings.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3431

English - 32 -

Sound Menu

Volume 1 5

Equalizer

Balance 0

Headphone

Sound Mode Mono

AVL On

Effect Off

Dynamic Bass Off

3D Panorama O ff

Store

SOUND

Subwoofer Off

Volume

Press or button to select Volume. Press



/  button to change the level of the Volume.

Equalizer

Press or button to select Equalizer. Press



/  or OK button to enter equalizer menu.

In equalizer menu the sound mode can be

changed to

User, Music, Movie, Speech, Flat

and Concert by pressing  /  button. Select

the desired frequency by

or button and

increase or decrease the frequency gain by

pressing  /  button.

Press the

M button to return to the previous

menu.

No te : E q u a l i zer me n u se t t i n g s can b e

changed only when the

Equalizer Mode

is in User.

Balance

This setting is used for emphasizing left or

right speaker balance.

Press or button to select Balance. Press



/  button to change the level of the balance.

Balance level can be adjusted between

-32

and + 32.

Headphone

Press or button to select Headphone. Press



button to view the hedphone menu.

Headphone sub-menu options are described

below:

Volume

Press or button to select Volume. Press



button to increase headphone volume level.

Pr e s s



but t o n to decrease he a d p h one

volume level. Headphone volume level can

be adjusted between 0 and 63.

Balance

Press or button to select Balance. Press



button to increase balance to the right. Press



button to decrease balance to the left.

Balance level can be adjusted between -32

and +32.

Press the

M button to return to the previous

menu.

Sound Mode

Press or button to select Sound Mode.

Using



/  button, you can select Mono,

Stereo, Dual I or Dual II mode, only if the

selected channel supports that mode.

AVL

Automatic Volume Limiting (AVL) function adjusts

the sound to obtain fixed output level between

progra mmes (For instance, volume level of

advertisement s tend to be louder than

programmes).

Press

or button to select AVLVL. Press  /



button to set the AVL as On or Off.

Effect

If you are watching a mono broadcast, set

Effect on to obtain a better sound effect which

will be more stereo-like. If the current sound

system is stereo, switching this effect on will

give a more spatial effect.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3432

English - 33 -

Press or button to select Effect. Press

/ 

button to set Effect as On or Off.

Dynamic Bass

Dynamic Bass is used to increase bass effect

of the TV set.

Press

or button to select Dynamic Bass.

Use



/  button set Dynamic bass to Low,

High or Off. It is not recommended to select

High while listening at high volume levels.

3D Panorama

This feature is used to create the impression

that sound is coming from around the room

instead of from the speakers of the TV set.

Press

or button to select 3D Panorama. Use



/  button to set 3D Panaroma as On or Off.

Subwoofer

It is possible to connect an external, active

subwoofer to the TV set to give a much deeper

bass effect.

Press

or button to select Subwoofer.

Subwoofer can be set to

On or Off.

Dynamic Bass is not available if

Subwoofer

is set to On.

Set

Subwoofer to On when you connect an

external subwoofer to the set.

Store

Press or button to select Store.

Press



or OK button to store the settings.

“

Stored” will be displayed on the screen.

Feature Menu

Sleep Timer Off

Child Lock Off

Language English

Ext-2 Out TV

Default Zoom Full

Blue Background On

Menu Backgroun d Translucent

Menu Timeout 60 sec

Teletext La nguage West

FEAUTURE

Sleep Timer

Press or button to select Sleep Timer.

Use



/  button to set the Sleep Timer.

The timer can be programmed between

Off

and 120 minutes in steps of 10 minutes.

If

Sleep Timer is activated, at the end of the

selected time, the TV goes automatically to

standby mode.

Child Lock

Press or button to select Child Lock.

Use



/  button to set the Child Lock On or

Off. When On is selected, the TV can only be

controlled by the remote control handset. In

this case the control panel buttons (except for

the

STANDBY button) will not work.

Hence, if one of those buttons is pressed,

“Child Lock On” will be displayed on the

screen when the menu screen is not visible.

Language

Press or button to select Language. Use



/  button to select the Language.

EXT-2 Out

Use this setting to define Ext-2 signal output.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3433

English - 34 -

Press or button to select Ext-2 Out. Use



/  button to set Ext-2 Out to TV/DTV, EXT1,

EXT3, EXT4, EXT5, EXT6

or PC.

Note:

• Only audio output is available for EXT-3,

EXT5, EXT-6.The other options have both

audio and video outputs.

• If you connect a device to EXT-1, when you

switch to a different source or activate PIP/

PAP functions while in DTV mode, there

will be no output from

EXT-1 Out.

• For copying from a DVD or VCR device, you

should set desired option for

EXT-2 output. If

you plug your device to

EXT-1, you will copy

the picture that comes from the tuner.

Default Zoom

While zoom mode is set as AUTO, the TV will

set the zoom mode in accordance with the

signal of the broadcast. If there is no WSS or

aspect ratio information, the TV will then use

this setting to adopt.

Press

or button to select Default Zoom.

You can set

Default Zoom to Full, Panoramic,

4:3

or 14:9 Zoom by pressing  /  button.

Blue Background

If the signal is weak or ab sent, the TV will

automatically change to a blue screen. To

enable this, set Blue Background to On.

By press ing

or button , select Blue

Background.

Press  /  button to set Blue

Background

as On or Off.

Menu Background

Pres s or b utto n t o select Menu

Ba ck g ro und .

You ca n ch a nge menu

background to

Translucent or Opaque by

pressing



/  button.

Menu Timeout

To set a specific display timeout for menu

screens, set a value for this option.

Press or button to select Menu Timeout.

Use

/ button to change menu timeout to

15 sec, 30 sec or 60 sec.

Teletext Language

Pr ess or bu tton to selec t Telet ext

Language

. Use / button to change

Teletext Language to West, East, Turk/Gre,

Cyrillic or A ra b i c . Text la n g u a g e

combinations are given below.

TEXT LANGUAGE LANGUAGE

TEXT LANGUAGE LANGUAGE

ENGLISH ENGLISH
FRENCH FRENCH
SWEDISH SWEDISH
FINNISH FINNISH
DANISH DANISH
CZECH GERMAN
SLOVAK DUTCH
GERMAN SPANISH
DUTCH PORTUGUESE
SPANISH ITALIAN
PORTUGUESE HUNGARIAN
ITALIAN TURKISH
HUNGARIAN GREEK
ICELANDIC ICELANDIC
FRENCH ENGLISH
SWEDISH CZECH
FINNISH SLOVAKYA
DANISH GERMAN
CZECH DUTCH
SLOVAK RUSSIAN
GERMAN LITHUANIAN
DUTCH LETTISH
ITALIAN UKRANIAN
HUNGARIAN ESTONIAN
POLISH ENGLISH
SLOVENIAN FRENCH
CROATIAN ARABIC
ROMANIAN HEBREW

West Turk/Gre

East

Cyrillic

Arabic

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3434

English - 35 -

Install Menu

Program 1

Band S

Channel 36

Colour System AUTO

Sound System BG

Fine Tune 0

Search 423.25

VCR Off

Store Program

INSTALL

Program

Press or button to select Program. Use

/ button to select the program number..

You can also ent e r a num b e r using th e

numeric buttons on the remote control. There

are 100 program storage between 0 and 99.

Band

Band can be selected either C or S. Press

/ button to select Band.

Channel

Channel can be changed by / button or

numeric buttons.

Colour System

Press or button to select Colour System.

Use

/ button to change the colour system

to

PAL, SECAM or AUTO.

If sound system is set to

I, SECAM will not be

available for the colour system settings.

Note:In AV modes, you can choose NTSC

3.58, NTSC 4.43 or PAL60 as well.

Sound System

Press or button to select Sound System.

Press

/ button to change the soun d

system to

BG, I, DK, L or LP.

Fine Tune

Press or button to select Fine Tune. Press

/ button to adjust the tuning.

Search

Press or button to select Search. Use

/ button to start program searching. You can

also enter the desired frequency using the

nu m e ric button s w h i l e S e a r c h i t em i s

highlighted.

VCR

This item can be seen in all modes except for

PC, YPbPr and HDMI.

If you want to watch a VCR source from one of

these modes, then it will be better to set

VCR

mo d e On. To do this, wh ile the item is

highlighted, press the



/  buttons to set it On.

If you want to watch a

DVD, then you must set

this item as

Off.

Store Program

Press or button to select Store Program.

Press

or OK button to store the settings.

“

Program Stored” will be displayed on the

screen.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3435

English - 36 -

Program Menu

PROGRAM

Name

Delete

Insert

APS

01 S-16

02 S-16

03 ARD

04 BBC1

05 D

06 CH4

07 BBC2

08 C06

09 C09

10 C10

11 C-12

12 C-21

13 C-23

14 C-43

15 C-55

16 C-57

17 C-64

18 C-68

19 S-20

20 S-20

21 S-20

22 S-33

23 S-34

24 S-35

25 S-36

26 S-40

27 -----

28 -----

29 -----

30 -----

By moving the cursor in four directions you

can reach 20 programmes in the same page.

You can scroll the pages up or down by

pressing the navigation buttons to see all the

programmes in TV mode (except for the AV

modes). B y cu r s or ac t i o n , pr o g r a m m e

selection is done automatically.

Name

To change the name of a programme, select

the programme and press the

RED button.

The first letter of the selected name will be

highlighted. Press

or button to change

that letter and

/ button to select the other

letters. By pressing the

RED button, you can

store the name.

Insert

Select the programme which you want to insert

by navigat ion button s. Press the

GRE EN

bu tton. By navi g a t ion but t ons mov e the

selected p r o g r a m m e to t h e de c i d e d

programm e space and press the GREEN

button again.

Delete

To delete a programme, press the YELLOW

button. Pressing the YELLOW button again

erases the selected progr amm e fr om the

prog ramme l ist, a nd t h e f o l l o w i n g

programmes shift one line up.

APS (Auto Programming System)

When you press the BLUE button for starting

automatic tuning,

Auto Programming System

menu will appear on the screen:

PROGRAM

Country Germa ny

Country

Press or button to select your country. If

you want to exit from A.P.S. function, press the

BLUE button.

When you press

OK or RED button for starting

automatic tuning, all stored programmes will

be erased and the TV will search for available

channels. During the search, the following

OSD will be displayed:

APS is running...

Cancel

Whenever you press the BLUE button, APS

function stops and

Program Table appears

on the screen.

If you wait until the end of APS, Program Table

will be displayed with the programmes found

and located.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3436

English - 37 -

Install Menu in AV Modes

The following screen appears in the install

menu when the TV is in AV modes. Note that

limited options will be available. Switch to TV

mod e for viewing complete version of the

Install menu.

Colour System AUTO

VCR Off

Store Program

INSTALL

Colour System

Press or button to select Colour System.

Use

/ button to change the colour system

to

PAL, SECAM, PAL 60, NTSC 4,43, NTSC 3,58

or AUTO.

VCR

Press or button to select VCR. Use /

button to set the VCR as On or Off.

Store Program

Press or button to select Store Program.

Press

or OK button to store the settings.

“

Program Stored” will be displayed on the

screen.

Source Menu

Press or button and select the sixth icon.

Then press

or OK button. Source menu

appears on the screen:

SOURCE : TV

TV

EXT - 1

EXT - 2

EXT - 3

EXT - 4

EXT - 5

TUNER

SCART

SCART

YPbPr

FAV

HDMI

EXT - 6

HDMI

PC

DTV

In sou r c e menu, hi g h l i g h t a so u rce by

pressing

or button and switch to that

mode by pressing

or OK button. Source

options are;

TV, EXT-1, EXT-2, EXT-3, EXT-4,

EXT-5, EXT-6, PC or DTV.

Note: Once you have connected optional

equipment systems to your TV, you

should select the required input to view

pictures from that source.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3437

English - 38 -

PC Mode Menu System

See “Connecting the LCD TV to a PC” section

for connecting a PC to the TV set.

For switching to

PC source, press AV button on

your remote control and select

PC input. You can

also use

“Source” menu to switch to PC mode.

No te t h a t PC mo d e menu se t t ings ar e

available only while the TV is in PC source.

Sound Menu

The items in thi s menu are des cribed at

“Sound Menu” section explained in “Analogue

TV Menu System”.

Feature Menu

Feature menu settings are identical to the

settings explained in “

Feature Menu” section

in “Analogue TV Menu System”.

PC Picture Menu

For adjusting PC picture items, do the following:

Press

or button to select the second

icon.

PC Picture menu appears on the screen.

Br i g h t n e s s , Co n trast and C o l o u r

Tem p e r ature

se t t i ng s in th is me n u ar e

identic al to settings defined in TV picture

menu under “Analogue TV Menu System”.

PC Picture Position Menu

Select the first icon by pressing or button.

Press then



or OK button. PC Picture Position

menu appears on the screen:

Autopositio n

H Position 9

V Position 50

Dot Clock 100

Phase 31

Autoposition

If you shift the picture horizontally or vertically

to an unwanted position, use this item to put

the picture into correct place automatically.

This setting therefore automatically optimizes

the display.

Select Autoposition item by using

or

buttons. Press OK button.

Warni n g :Auto posi t i on ad j u s tm e n t

recommended to be done with the

full scree n image for the proper

adjus tment.

H (Horizontal) Position

This item shifts the image horizontally to right

hand side or left hand side of the screen.

Select H Position item by using or button.

Use

/ button to adjust the value.

V (Vertical) Position

This item shifts the image vertically towards

the top or bottom of the screen.

Select V Position item by using or button.

Use

/ button to adjust the value.

Dot Clock

Do t C l o c k a d j u s t m e n t s c o r r e c t t h e

interference that appear as vertical banding

in d ot i n t e nsi ve pr e sentations like

spreadsheets or paragraphs or text in smaller

fonts.

Sele ct

Dot Cl ock item by using or

buttons. Use / button to adjust the value.

Phase

De pen ding on the re s o l u t i o n and sc a n

frequency that you input to the TV set, you may

see a hazy or noisy picture on the screen. In

such a case you can use this item to get a

clear picture by trial and error method.

Select

Phase item by using or buttons.

Use



/  button to adjust the value.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3438

English - 39 -

Displaying TV Information

Programme Number, Programme Name,

Sound Indicator

and Zoom Mode information

is displayed on the screen when a new

pro g r a m m e is entered or butto n is

presse d.

Mute Function

Press button to disa ble sound. Mute

indicator will be displayed in the upper side

of the screen.

To cancel mute, there are two alternatives; the

first one is pressing the

button and the

second one is increasing the volume level.

PIP (Picture-in-Picture) and PAP
(Picture-and-Picture) Modes

Press the button to switch to PIP mode.

At PIP Mode, a small picture (PIP picture) is

displayed on the main picture. There are 1

size and 4 positions (upper left, upper right,

bottom left and bottom right) available for the

PIP window. You can use

button to change

the PIP positi on. Aspect Ratio of the PIP

window is fixed and 4:3.

When PIP Mode is entered, the default active

window is the PIP wind ow and the active

window is indicated by a white frame around

it. The active window can be change d by

pressing



/  button. The status info OSD

belongs to active window. The place of the

status OSDs are same for both windows.

Press the

button again to exit the PIP mode.

Press the

button to switch to PAP mode.

At PAP Mode, two pictures with equal sizes

are displayed on the screen. Aspect Ratios of

the windows are fixed.

When you switch to PAP Mode, Main window

in PIP Mode is displayed on the right side of

the sc r e e n . Th e ac t i v e win d ow can be

changed by pressing



/  button.

Press the

button again to exit the PAP mode.

Source restrictions of PAP Mode are same as

in PIP Mode. It is not possible to show 2

different channels from the TV tuner at the

same time.

NOTE: In all HDMI modes, PIP and PAP are

not visible. In YPbPr 1080i, PIP is not

vis ib le.

NOTE: See Appendix B for all PIP/PAT modes.

Picture Mode Selection

By pressi ng PP button, you can chang e

Picture Mode settings in accordance with

your viewing requirements.

Freezing Picture

You can freeze the picture on the screen.

Press the

OK button to freeze picture. Press

again to quit freeze mode.

Zoom Modes

You can change the aspect ratio of the TV for

viewing the picture in different zoom modes.

Press

/WIDE button to directly change the

zoom mode.

Available zoom modes are listed below.

Note: In YPBPR and HDMI modes, while in

720 and 1080 resolutions,

Full 1 and Full

2

modes will also be visible.

Auto

Whe n a WSS (Wide Scree n Signall ing)

signal, which shows the aspect ratio of the

picture, is included in the broadcast signal or

the signal from an external device, the TV

au tomati c a lly cha n ges the

ZOOM mode

according to the

WSS signal.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3439

English - 40 -

• When the AUTO mode does not function

correctly due to poor

WSS signal quality or

when you want to change the

ZOOM mode,

change to another

ZOOM mode manually.

Full

This uniformly stretches the left and right sides

of a normal picture (4:3 aspect ratio) to fill the

wide TV screen.

• For 16:9 aspect ratio pictures that have been

squeezed into a normal picture (4:3 aspect

ratio), use the

Full mode to restore the picture

to its original shape.

4:3

Use to view a normal picture (4:3 aspect ratio)

as this is its original size.

Panoramic

This stretches the left and right sides of a

normal picture (4:3 aspect ratio) to fill the

screen, without making the picture appear

unnat ural.

The top and bottom of the picture are slightly

cut off.

14:9 Zoom

This zooms up the wide picture (14:9 aspect

ratio) to the upper and lower limits of the

screen.

Cinema

This zooms up the wide picture (16:9 aspect

ratio) to the full screen.

16:9 Subtitle

This zooms up the wide picture (16:9 aspect

ratio) with subtitles to the full screen.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3440

English - 41 -

Teletext

Teletext system transmits information such as

news, sports and weather on your TV. Note

that if the signal becomes insufficient, some

text errors may occur or the teletext mode may

be quitted.

Teletext function buttons are listed below:

Teletext On/Off / PAT mode

Activates teletext mode when pressed once.

Pressing this button again will split the screen

into two windows, one displaying the teletext

and the other displaying the current channel.

Pressing again will quit the teletext mode.

Index

Selects the teletext index page.

Mix

Places the teletext screen over the programme.

Expand

Press once to enlarge top half of the page,

press again to enlarge the bottom half of the

page. Press again to revert back to normal

size.

Reveal

Shows hidden information (e.g. solutions of

games).

Hold

Holds a text page when convenient. Press again to

resume.

Subcode Pages / Time

Selects subcode pages if available when the

teletext is activated. W hen the teletext is not

activated, displays time info if the programme

has teletext transmission.

P+ / P- and numbers (0-9)

Press to select a page.

Note: Most TV stations use code 100 for their

index pages.

Coloured Buttons

(RED/GREEN/YELLOW/BLUE)

Your TV supports both FASTEXT and TOP text

systems. W hen these systems are available,

the pages are divided into groups or topics.

When FASTEXT system is available, sections

in a teletext page will become colour-coded

and can be selected by pressing the coloured

buttons. Press a coloured button that corresponds

with your needs.

The coloured writi ngs will appear, showing

you which coloured buttons to use when TOP

text

transmission is present. Pressing P - or

P + co m m a nds wil l re q uest the ne xt or

previous page respectively.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3441

English - 42 -

Tips

Care of the Screen

Clean the screen with a slightly damp, soft

cloth. Do not use abrasive solvents as they

may damag e the coati ng layer of the TV

screen.

For your safety, unplug the mains plug when

cleaning the set. When moving the TV, hold it

properly from the bottom part.

Image Persistence

Please note that ghosting may occur while

displ aying a persi stent image . LCD TVs’

image persistence may disappear after a short

time. Try turning off the TV for a while.

To avoid this, do not leave the screen in still

picture for extended periods.

No Power

If your TV system has no power, please check

the main power cable and connection to the

mains socket outlet.

Poor Picture

Have you selected the correct TV system? Is

your TV set or house aerial located too close

to a non-earthed audio equipme nt or neon

lights, etc.?

Mountains or high buildings can cause double

pictures or ghost images. Sometimes you can

improve the picture quality by changing the

direction of the aerial.

Is th e picture or teletext unrecognisable?

Ch eck if you h a v e entered th e correct

frequency.

The picture quality may degrade when two

peripherals are connected to the TV at the

same time. In such a case, disconnect one of

the peripherals.

No Picture

Is the aerial connected properly? Are the plugs

connected tightly to the aerial socket? Is the

aerial cable damaged? Are suitable plugs

used to connect the aerial? If you are in doubt,

consult your dealer.

No Picture means that your TV is not receiving

a transmission. Have you selected the correct

button on the remote control? Try once more.

Sound

You can not hear any sound. Did you perhaps

interrupt the sound, pressing the

button?

Sound is coming fro m on l y on e of the

speakers. Is the balance set to one extreme?

See

Sound menu.

Remote Control

Your TV no longer responds to the remote

control. Perhaps the batteries are exhausted.

If so you can still use the local buttons at the

bottom of the TV.

Input Sources

If you cann ot select an input source, it is

possible that no device is connected.

Check the AV cables and connections if you

have tried to connect a device.

CI Module

If you are experiencing a problem with the CI

module, it is possible that CI module is not

proper ly inserted. Remove the CI card and

then reinsert.

If the problem persists, it is possible that your

CI module is not recognized. Try inserting a

different CI module.

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3442

English - 43 -

Appendix A: PC Input Typical Display Modes

The display has a maximum PC resolution of 1360 x 768, frequency range of 56-85 Hz.

The following table is an illustration of some of the typical video display modes.

Your TV may not support different resolutions. Supported resolution modes are listed below.

If you switch your PC to an unsupported mode, a warning OSD will appear on the screen.

M ode Re solution Frequenc y

Horizontal Vertical Hor.(kHz) Ver.(Hz)

1

640 480 31,5 60

2

640 480 37,9 72

3

640 480 37,5 75

4

800 600 35,2 56

5

800 600 37,9 60

6

800 600 48,1 72

7

800 600 46,9 75

8

800 600 53,7 85

9

1024 768 48,4 60

10

1024 768 56,5 70

11

1024 768 60 75

12

1280 1024 64 60

13

1280 768 47,8 60

14

1360 768 47,7 60

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3443

English - 44 -

Appendix B: Main and PIP-PAP Picture Combinations

MAIN

EXT-1 EXT-1 EXT-2 EXT-2 EXT-3 EX T-4 EXT-5 EXT-6

CVBS RGB CVBS RGB YPBPR CVBS HDM I HD MI

PIP,PAP

O

EXT-1 O
CVBS

EXT-1 O
RGB

EXT-2 O
CVBS

EXT-2 O
RGB
EXT-3 X
YPBPR

EXT-4 O
CVBS

EXT-5 X
HDMI

EXT-6 X X X X X X X
HDMI

PC X X X X X X X X

(X: Not available, O : Available)

* DTV PIP-PAP options are the same as t he TUNER input. TV and DTV cannot be in PIP-PAP mode together.

Depending on the TV model, available source combinations may differ.

X X XX X X X

O O OO O O O

X X XX X X X

O O OO O O X

X O OO O O O

O O OO X O O

O O OO O X O

N

O

P

I

P

&

P

A

P

A

V

A

I

L

A

B

L

E

I

F

M

A

I

N

I

S

A

V

-

5

N

O

P

I

P

&

P

A

P

A

V

A

I

L

A

B

L

E

I

F

M

A

I

N

I

S

A

V

-

6

O

X

Main and PIP, PAP picture combinations

TUNER

PC

TUNER /

DTV *

O O O O O O

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3444

English - 45 -

Appendix C: AV and HDMI Signal Compatibility

Source Available

O
O
O
O
O
O

X
X

480I 60Hz

O

480P 60Hz

O

576I 50Hz

O

576P 50Hz

O

720P 50Hz

O

720P 60Hz

O

1080I 50Hz

O

1080I 60Hz

O
O
O

480I 60Hz

O

480P 60Hz

O

576I 50Hz

O

576P 50Hz

O

720P 60Hz

O

720P 50Hz

O

1080I 60Hz

O

1080I 60Hz

O

1080P 50Hz

O

1080P 60Hz

O

Supported Signals

EXT-1

(SCART 1)

PAL 50/60

NTSC 60

RGB 50
RGB 60

EXT-2

(SCART-2)

PAL 50/60

NTSC 60
S-VHS 50
S-VHS 60

EXT-3

(YPbPr)

EXT-4

(FAV)

PAL 50/60

NTSC 60

HDMI1
HDMI2

Note

: In some cases a signal on the LCD TV may not be displayed properly. The problem

may be an inconsistency with standards from the source equipment (DVD, Set-top box, etc…).

If you do expereince such a problem please contact your dealer and also the manufacturer
of the source equipment.

(X: Not Available, O: Available)

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3445

English - 46 -

Signal Input

PC RGB Terminal (D-sub 15-pin connector)

Pin Input signal

1 R
2 G or sync on green
3 B
4 No connection
5 No connection
6 R.GND
7 G.GND
8 B.GND

9 No connection
10 GND
11 No connection
12 [SDA]
13 H.sync or H/V composite sync
14 V.sync. [V.CLK]
15 [SCL]

• When different kinds of input signals are

simultaneously input to the monitor via a graphics

board or the like, the monitor will automatically

select the signals in the following priority order:

Sync signal type Priority

H/V separate sync. 1

H/V composite s ync. 2

sync.on Green * 3

• Even in the case of the recommended

signals shown on the following page,

there may be instances when correct

display is not possible. In this case, use

H/V separate sync, H/V composite sync.

HDMI connector pin specifications

Pin Input signal Pin Input signal

1 TMDS Data2+ 11 TMDS Clock Shield
2 TMDS Data2 Shield 12 TMDS Clock­3 TMDS Data 2- 13 CEC
4 TMDS Data 1+ 14 Reserved (N.C. on device)
5 TMDS Data1 Shield 15 SCL
6 TMDS Data1- 16 SDA
7 TMDS Data0+ 17 DDC/CED Ground
8 TMDS Data0 Shield 18 +5V Power
9 TMDS Data0- 19 Hot Plug Detect

10 TMDS Clock+

SCART connector pin specifications

Pin Input signal Pi n Input signal

1 AUDIO OUT (RIGHT) 12 Not us ed
2 AUDIO IN (RIGHT) 13 RGB-R GND
3 AUDIO OUT (LEFT/MONO) 14 GND
4 AUDIO GND 15 RGB-R / S.V HS CHROMINANCE IN
5 RGB-B GND 16 BLANKING SIGNAL
6 AUDIO IN (LEFT/MONO) 17 COMPOSITE VIDEO GND
7 RGB-B IN 18 BLANKING SIGNAL GND
8 AUDIO / RGB SW ITCH / 16:9 19 COMPOSITE VIDEO OUT

9 RGB-G GND 20 COMPOSITE VIDEO / S.VHS LUMINANCE IN
10 Not used 21 GND / SHIELD (CHASSIS)
11 RGB-G IN

Appendix D: Pin Specifications

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3446

English - 47 -

CAUTION

TO PREVENT ELECTRIC SHOCK DISCONNECT FROM THE MAINS BEFORE

REMOVING COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

SAFETY PRECAUTION

THIS DEVICE MUST BE DISCONNECTED FROM THE MAINS WHEN NOT IN USE. DO

NOT ALLOW THIS UNIT TO BE EXPOSED TO RAIN OR MOISTURE.

MAINS (AC) OPERATION

The wires in the mains lead are coloured in accordance with the following code :

IMPORTANT

As the colours of the wires in the mains lead of this appliance may not correspond

with the coloured markings identifying the terminals in your plug, proceed as follows:

The Green and Yellow coloured wire must be connected to the terminal which is

marked with the letter E, or by the earth symbol, or with Green or Green and Yellow

colors.

The Blue or Black coloured wire must be connected to the terminal which is marked

with the letter N or black colour.

The Brown or Red coloured wire must be connected to the terminal which is marked

with the letter L or Red colour.

For continued protection against risk of fire, replace only with a fuse with the same

type and rating. (ASTA approved 5A 250VAC fuse).

Appendix E: Important Instruction

For your own safety read following instruction carefully before attempting to connect this unit to

the mains supply.

BLUE
(Neutral)

BROWN
(Live)

FUSE

GREEN

&

YELLOW

(Earth)

(if there is

earth cable)

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3447

English - 48 -

Specifications

TV BROADCASTING

PAL/SECAM B/G D/K K' I/I' L/L'

RECEIVING CHANNELS

VHF (BAND I/III)

UHF (BAND U)

HYPERBAND

CABLE TV (S1-S20/ S21-S41)

NUMBER OF PRESET CHANNELS

100

CHANNEL INDICATOR

On Screen Display

RF AERIAL INPUT

75 Ohm (unbalanced)

OPERATING VOLTAGE

220-240V AC , 50 Hz.

AUDIO

3D Panorama

AUDIO OUTPUT POWER (W

RMS.

) (10% THD)

2 x 8

POWER CONSUMPTION (W)

180 W

<1 W (Stand-by)

PANEL

16:9 display, 32” Screen Size

DIMENSIONS (mm)

Weight (kg)

With foot

Without foo t

D L H

DIMENSIONS (mm)

210
120

804
804

602

16,1
14,5

560

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3448

English - 49 -

ARGOS

Product Guarantee

This product is guaranteed against manufacturing defects for a period of

1 Year

This does not cover the product where the fault is due to misuse, abuse, use in

contravention of the instructions, or where the product has been the subject of

unauthorised modifications or alterations, or has been the subject of

commercial use

In the event of a problem with the product within the guarantee period please

return it to your nearest Argos store

If the item is shown to have had an inherent defect present at the time of sale,

the store will provide you with a replacement

Your statutory rights remain unaffected

Guarantor; Home Retail Group

489 - 499 Avebury Boulevard

Central Milton Keynes

MK9 2NW

ENG-32761-1205UK-32 INCH 17MB26 UK IDTV-(WO SVHS-ECO PIP)(3D PANORAMA)-50138695.p6519.11.2008, 08:3449

BUSH KAPAK-50138695.p65 17.11.2008, 16:322
