FI-SCHUKOMAT, SCHUKO® socket outlet (RCD) future® linear
Online-Catalogue 2019
FI-SCHUKOMAT
FI-SCHUKOMAT, SCHUKO® socket outlet (RCD)
with earth leakage circuit breaker
Shuttered.
DP cut off (P,N)
Without PE monitoring.
With connecting conductor and protection of downstream socket outlets.
Rated actuating current: 30 mA. Release time: ≤ 30 ms. Short-circuit strength: 3000 A (with 25 A GL fuse).
Current surge strength: 250 A (8/20) µs.
With fixing claws.
Rated frequency: 45-60 Hz.
Rated voltage: 230 V~,
Rated current: 16 A
Protection class (Device): IP 20, Temperature range (Device): -25 °C to 40 °C,
Connecting terminals approved in accordance with VDE 0620-1 as connectors. , Protective measure according
to VDE 0100; can be proven or checked using the Profitest 0100S testing device, for example., Increased shock
protection .
Order Code : 2CKA003116A0670
Article No. : 3120 EUCB-884
EAN: 4011395229866
