ULTRA-2
ILLUSTRATED PARTS CATALOG
Designs, materials, weights, specifications, and dimensions for equipment or replacement parts
are subject to change without notice.
BUNN-O-MATIC CORPORATION
POST OFFICE BOX 3227
SPRINGFIELD, ILLINOIS 62708-3227
PHONE: (217) 529-6601 FAX: (217) 529-6644
32081.0004G 12/14 ©2013 Bunn-O-Matic Corporation
BUNN-O-MATIC COMMERCIAL PRODUCT WARRANTY
Bunn-O-Matic Corp. (“BUNN”) warrants equipment manufactured by it as follows:
1) Airpots, thermal carafes, decanters, GPR servers, iced tea/coffee dispensers, MCR/MCP/MCA single cup brewers, thermal servers and ThermoFresh® servers (mechanical and digital) 1 year parts and 1 year labor.
2) All other equipment - 2 years parts and 1 year labor plus added warranties as specified below:
a) Electronic circuit and/or control boards - parts and labor for 3 years.
b) Compressors on refrigeration equipment - 5 years parts and 1 year labor.
c) Grinding burrs on coffee grinding equipment to grind coffee to meet original factory screen sieve analysis - parts and
labor for 4 years or 40,000 pounds of coffee, whichever comes first.
These warranty periods run from the date of installation BUNN warrants that the equipment manufactured by it will be
commercially free of defects in material and workmanship existing at the time of manufacture and appearing within the
applicable warranty period. This warranty does not apply to any equipment, component or part that was not manufactured
by BUNN or that, in BUNN’s judgment, has been affected by misuse, neglect, alteration, improper installation or operation,
improper maintenance or repair, non periodic cleaning and descaling, equipment failures related to poor water quality,
damage or casualty. In addition, the warranty does not apply to replacement of items subject to normal use including but
not limited to user replaceable parts such as seals and gaskets. This warranty is conditioned on the Buyer 1) giving BUNN
prompt notice of any claim to be made under this warranty by telephone at (217) 529-6601 or by writing to Post Office Box
3227, Springfield, Illinois 62708-3227; 2) if requested by BUNN, shipping the defective equipment prepaid to an authorized
BUNN service location; and 3) receiving prior authorization from BUNN that the defective equipment is under warranty.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY OTHER WARRANTY, WRITTEN OR ORAL, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF EITHER MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. The agents, dealers or employees of BUNN are not authorized to make
modifications to this warranty or to make additional warranties that are binding on BUNN. Accordingly, statements by such
individuals, whether oral or written, do not constitute warranties and should not be relied upon.
If BUNN determines in its sole discretion that the equipment does not conform to the warranty, BUNN, at its exclusive option while the equipment is under warranty, shall either 1) provide at no charge replacement parts and/or labor (during the
applicable parts and labor warranty periods specified above) to repair the defective components, provided that this repair
is done by a BUNN Authorized Service Representative; or 2) shall replace the equipment or refund the purchase price for
the equipment.
THE BUYER’S REMEDY AGAINST BUNN FOR THE BREACH OF ANY OBLIGATION ARISING OUT OF THE SALE OF THIS
EQUIPMENT, WHETHER DERIVED FROM WARRANTY OR OTHERWISE, SHALL BE LIMITED, AT BUNN’S SOLE OPTION
AS SPECIFIED HEREIN, TO REPAIR, REPLACEMENT OR REFUND.
In no event shall BUNN be liable for any other damage or loss, including, but not limited to, lost profits, lost sales, loss of
use of equipment, claims of Buyer’s customers, cost of capital, cost of down time, cost of substitute equipment, facilities
or services, or any other special, incidental or consequential damages.
392, A Partner You Can Count On, Air Infusion, AutoPOD, AXIOM, BrewLOGIC, BrewMETER, Brew Better Not Bitter, BrewWISE, BrewWIZARD, BUNN Espress, BUNN Family Gourmet, BUNN Gourmet, BUNN Pour-O-Matic, BUNN, BUNN with
the stylized red line, BUNNlink, Bunn-OMatic, Bunn-O-Matic, BUNNserve, BUNNSERVE with the stylized wrench design,
Cool Froth, DBC, Dr. Brew stylized Dr. design, Dual, Easy Pour, EasyClear, EasyGard, FlavorGard, Gourmet Ice, Gourmet
Juice, High Intensity, iMIX, Infusion Series, Intellisteam, My Café, Phase Brew, PowerLogic, Quality Beverage Equipment
Worldwide, Respect Earth, Respect Earth with the stylized leaf and coffee cherry design, Safety-Fresh, savemycoffee.com,
Scale-Pro, Silver Series, Single, Smart Funnel, Smart Hopper, SmartWAVE, Soft Heat, SplashGard, The Mark of Quality in
Beverage Equipment Worldwide, ThermoFresh, Titan, trifecta, TRIFECTA (sylized logo), Velocity Brew, Air Brew, Beverage
Bar Creator, Beverage Profit Calculator, Brew better, not bitter., Build-A-Drink, BUNNSource, Coffee At Its Best, Cyclonic
Heating System, Daypart, Digital Brewer Control, Element, Milk Texturing Fusion, Nothing Brews Like a BUNN, Picture
Prompted Cleaning, Pouring Profits, Signature Series, Sure Tamp, Tea At Its Best, The Horizontal Red Line, Ultra are either
trademarks or registered trademarks of Bunn-O-Matic Corporation. The commercial trifecta® brewer housing configuration is a trademark of Bunn-O-Matic Corporation.
2
32081.4 031314
TABLE OF CONTENTS
Auger Drive and Cooling Drum .................................................................................................................................................. 20
Compressor and Mounting ............................................................................................................................................. 26, 28,30
Condenser and Fan Mounting .................................................................................................................................................... 24
Electrical and Operating Controls .............................................................................................................................................. 40
Frame, Panels and Drip Tray ........................................................................................................................................................ 4
Hopper, Cover and Faucet ............................................................................................................................................................ 8
Internal Liquid Autofill Kit (Optional) ......................................................................................................................................... 38
Numerical Index ........................................................................................................................................................................ 44
PAF Platform Assembly (Early Models) ..................................................................................................................................... 10
PAF Platform Assembly (Late Models) ...................................................................................................................................... 14
Solenoid and Coolant Piping ......................................................................................................................................... 32, 34, 36
Liquid Autofill (LAF CF) Kit ........................................................................................................................................................ 18
3
32081.4 050114
26
25
24
FRAME, PANELS AND DRIP TRAYS
2 1 2 3 28 10
ULTRA - 2
4
6
5
21
27
35
13
29
12
14
15
6 20 10 9 8 19 33 34 32 23 22 18 31 17 16
4
P2508
32081.4 050114
FRAME, PANELS AND DRIP TRAYS
ITEM PART NO. QTY. DESCRIPTION
1 27136.0002 1 Trim, Hopper/Drip Tray - WHI
27136.0003 1 Trim, Hopper/Drip Tray - BLK
02329.0000 2 Screw, Round Head - Locking #8-32 x .312"
2 27394.0000 3 Plug, Plastic - WHI
27394.0001 3 Plug, Nylon - BLK
3 32111.0000 1 Drip Tray, Left Hopper - WHI
32111.0001 1 Drip Tray, Left Hopper - BLK
32111.0002 1 Drip Tray, Right Hopper - WHI
32111.0003 1 Drip Tray, Right Hopper - BLK
01311.0001 8 Screw, Truss Head - Locking #8-32 x .25"
4 27058.0000 1 Corner, Right Rear - SST (without Filter Stop)
27058.0002 1 Corner, Right Rear - BLK (without Filter Stop)
27058.0010 1 Corner, Right Rear - SST (with Filter Stop)
27058.0014 1 Corner, Right Rear - BLK (with Filter Stop)
32580.0000 1 Screw, Hex Head #6-32 x .25"
5 36182.1004 1 Panel W/Decals, Right Side - SST
36182.1005 1 Panel W/Decals, Right Side - BLK
32580.0000 2 Screw, Hex Head #6-32 x .25"
6 27442.0000 2 Decal, Warning - Moving Parts
7 32082.0002 1 Schematic, Electrical 120V (ULTRA-2)
32082.0004* 1 Schematic, Electrical 100V (ULTRA-2B)
8 00986.0002 1 Decal, Warning - Electrical
9 29947.0000 1 Decal, Caution - Two Power Cords
10 29979.0000 1 Decal, Room Temperature
11 -------------- 2 Tube, Drain .375" I.D. x .50" O.D. x 10.50" (Order item 37)
12 32116.1000 1 Panel, Front - SST (Includes items 13,14 & 29)
32116.1001 1 Panel, Front - BLK (Includes items 13,14 & 29)
32580.0000 1 Screw, Hex Head #6 x .25"
02308.0000 2 Screw, Pan Head Serrated #8-32 x .375"
13 29967.1002 1 Gasket, Electronic Box
14 32126.1004 1 Membrane Switch - BLK
15 32068.0000 1 Cover, Lower Drip Tray - WHI
32068.0001 1 Cover, Lower Drip Tray - BLK
Each includes items
6,8,9,&10
Early Models
16 28086.0000 1 Drip Tray, Lower - WHI (Includes item 17)
28086.0001 1 Drip Tray, Lower - BLK (Includes item 17)
17 21437.1000 2 Strike Assy, Self Adhesive
18 21436.0000 2 Catch, Magnetic
(Continued)
5
32081.4 050114
26
25
24
FRAME, PANELS AND DRIP TRAYS
(Continued)
2 1 2 3 28 10
ULTRA - 2
4
6
5
21
27
35
13
29
12
14
15
6 20 10 9 8 19 33 34 32 23 22 18 31 17 16
6
P2508
32081.4 050114
FRAME, PANELS AND DRIP TRAYS
ITEM PART NO. QTY. DESCRIPTION
19 36182.1006 1 Panel W/Decals, Left Side - SST
36182.1007 1 Panel W/Decals, Left Side - BLK
32580.0000 2 Screw, Hex Head #6-32 x .25"
20 29373.0001 1 Decal, Coolant Charge
21 27058.0001 1 Corner, Left Rear - SST (without Filter Stop)
27058.0003 1 Corner, Left Rear - BLK (without Filter Stop)
27058.0011 1 Corner, Left Rear - SST (with Filter Stop)
27058.0015 1 Corner, Left Rear - BLK (with Filter Stop)
32580.0000 1 Screw, Hex Head #6 x .25"
22 26528.0000 4 Leg, Black Plastic - 4" Adj. (See item 36)
03354.0000 4 Leg, Black Plastic - 2.5" Adj. (See item 36)
23 03996.0000 4 Pad, Rubber - 4" Adj. Legs (See item 36)
03993.0000 4 Pad, Rubber - 2.5" Adj. Legs (See item 36)
24 32124.0000 1 Frame, Base (Models with AMERICOLD compressors)
32793.0000 1 Frame, Base (Models with EMBRACO compressors)
37906.0002 1 Frame, Base (Models with EMBRACO compressors - Internal Autofill Ready)
37906.0006 1 Frame, Base (Models with EMBRACO compressors)(Salt Air Resistant)
25 00927.0000 4 Clip, Spring
00927.0001 4 Clip, Spring (Salt Air Resistant)
26 27131.0000 1 Trim, Frame - Rear - SST
27131.0001 1 Trim, Frame - Rear - BLK
Each includes item 6
27 28098.0000 2 Fastener, Snap-in
28 29702.1000 2 Plunger Assy, Hopper Lock
29 29976.0000 1 Mount, Cable
30 29959.0001 1 Decal, Cleaning Instructions 120V (ULTRA-2)
29959.0002 1 Decal, Cleaning Instructions 230V (ULTRA-2A)
29959.8002 1 Decal, Cleaning Instructions Spanish 120V (ULTRA-2)
31 37883.0000 2 Cover, Hole (Internal Autofill Ready)
37883.0000 2 Cover, Hole (Internal Autofill Ready)(Salt Air Resistant)
01382.0000 4 Screw, Truss Head #6-32 x .38"
32 36187.0000 1 Vinyl Deflector
33 36188.0000 1 Bracket
34 20622.0005 1 Bushing
35 43136.0000 2 Bracket, Filter Stop SST
43136.0001 2 Bracket, Filter Stop BLK
43136.0002 2 Bracket, Filter Stop (Salt Air Resistant)
02335.0001 4 Screw, Hex #8 x .38"
36 13255.0003 - Leg Kit, 4" Adj. Legs (Includes 4 Legs and Pads)
13255.0006 - Leg Kit, 2.5" Adj. Legs (Includes 4 Legs and Pads)
Early Models
37 12421.1001 - Tube, Clear Vinyl (12" Long)
12421.1002 - Tube, Clear Vinyl (60" Long)
12421.1003 - Tube, Clear Vinyl (120" Long)
7
Not Illustrated
32081.4 121614
5
2
1
24
25
HOPPER, COVER AND FAUCET
ULTRA - 2
20
21
22
19
15
7
14
6
8
9
12
13
10
23
11
3
4
Early Models with Incandescent Bulbs
Optional For Crew
Serve Applications
17
18
MODELS w/Flat Lid
P2509
8
32081.4 031313
HOPPER, COVER AND FAUCET
ITEM PART NO. QTY. DESCRIPTION
- 32069.1000 2 Cover Assembly, Hopper, WHI (Includes items 1 thru 7)(Incandescent Bulb)
32069.1001 2 Cover Assembly, Hopper, BLK (Includes items 1 thru 7)(Incandescent Bulb)
47315.1000 2 Cover Assembly, Hopper, WHI (Includes items 1,2,5,6,7, and 24)(LED Lights)
47315.1001 2 Cover Assembly, Hopper, BLK (Includes items 1,2,5,6,7, and 24)(LED Lights)
1 32196.0000 2 Cover, Hopper - WHI
32196.0001 2 Cover, Hopper - BLK
01315.0000 4 Screw, Truss Head #8-32 x .38"
2 32105.0000 4 Insert, Hopper Lid Vent - WHI
32105.0001 4 Insert, Hopper Lid Vent - BLK
3 27446.0000 4 Lamp, T-5 Wedge Base
4 27445.1000 2 Lamp Holder/Socket Assy (Includes two of item 16)
32096.0001 4 Screw, Pan Head #2-56 x .50"
5 32266.0000 4 Insert, Hopper Display
6 32195.0000 2 Liner Assy, Hopper Cover
7 32267.1000 2 Cord Assy, Lamp (Includes two of item 16)
8 32190.1000 2 Hopper Assy. (Includes item 9)
32190.1001 2 Hopper Assy. (For Models with PAF) (Includes item 9)
32190.1003 2 Hopper Assy. (For Models Internal Autofill Ready or AFPO) (Includes item 9)
32190.1005 2 Hopper Assy. (For Models LAF CF) (Includes item 9)
9 32189.0000 2 Bushing, Auger Nose
10 32191.0000 2 Faucet - WHI
11 32265.0001 2 Handle, Faucet - BLK (Optional for Crew Serve Applications)
12 32193.0000 2 Spring, Faucet
13 32268.1000 1 Seal Kit (Includes 2 seals)
32268.1001 1 Seal Kit (Includes 1 seal)
14 27643.1000 2 Connector Assy (Includes Nut, Washer, Leads & Plug)
39967.0000 2 Washer, SST
01532.0001 2 Lockwasher, Internal-tooth .375"
15 32916.0002 2 Tether/Probe Kit (For Models with PAF)
39257.0000 2 Tether/Probe Kit (For Models Autofill Ready)
01393.0000 2 Screw, Truss Head #6 x .25"
16 03851.0000 4 Wire Nut (Not Illustrated)
17 29481.0001 1 Cover, Flat (Includes item 18)
18 00778.0000 1 Decal, BUNN
19 28776.0001 4 Plug (Two less used on Liquid Autofill with No Water lines)
24566.0000 4 Nut
20 28756.1000 4 Fitting, Quick Disconnect
21 28755.0003* 4 Tube, Norprene .25" ID x 1.25"
Internal Autofill
Ready Models
22 28770.0000 4 Elbow .25" Barb x .50" Barb
23 44614.1000 2 Handle (Low Level Access)
24 46331.0001 1 LED & Cord Assy
32096.0002 2 Screw, Pan Head #2-28 x .38"
25 38021.0000 1 Fitting, Quick Disconnect, .25" Male
42921.0000 1 Fitting, Quick Disconnect, .38" Male
9
32081.4 121614
PAF PLATFORM ASSEMBLY (Early Models)
ULTRA - 2
Early Models
33
31
32
2
15
8
6
5
4
3
16
30
1
10
11
12
7
16
17
9
29
18
13
14
26
28
20
23
19
21
22
24
25
27
10
P2517
32081.4 050114
PAF PLATFORM ASSEMBLY (Early Models)
ITEM PART NO. QTY. DESCRIPTION
- 29941.1000 1 Platform Assy. 120V SST (Includes items 1 thru 28 and 30 thru 34)
- 29941.1001 1 Platform Assy. 120V BLK (Includes items 1 thru 28 and 30 thru 34)
- 29941.1002 1 Platform Assy. 230V SST (Includes items 1 thru 34)
- 29941.1003 1 Platform Assy. 230V BLK (Includes items 1 thru 34)
1 29940.1000 1 Housing w/Decals SST (Includes item 16)
29940.1002 1 Housing w/Decals BLK (Includes items 16 and 30)
2 29591.0001 2 Guide Rail RH
01330.0000 4 Screw #10-32 x .38"
3 29591.0002 2 Guide Rail LH
01330.0000 4 Screw #10-32 x .38"
4 29724.0000 4 Roller
5 24457.0001 4 Shoulder Bolt
01522.0001 4 Washer
6 32632.0000 2 Latch (Early Models)
01311.0001 4 Screw, Truss Head Locking #8-32 x .25"
7 01666.0002 1 Bushing, Relief (120V)
05746.0000 1 Bushing, Relief (230V)
8 00906.0000 4 Nut
9 29742.0000 2 Retainer
10 29726.0000 2 Housing, Spring Contact
11 27788.0000 2 Spring
12 27748.0000 2 Pin
13 03628.0000 2 Receptacle 120V
32197.0000 2 Receptacle 230V
14 32104.0000 1 Relay, Lighting
01382.0000 2 Screw, Truss Head #6-32 x .38"
15 00707.0000 1 Bushing, Relief
16 29947.0000 1 Decal, Dual Power Cord
17 22126.0000 1 Rectifier
00908.0000 1 Nut #8-32
18 29844.0000* 1 Decal, Receptacle - PAF Only
29844.0001 1 Decal, Receptacle - PAFA Only
19 00908.0000 2 Nut, Grounding Stud
20 33524.0000 1 Latch, Support Rod
21 33527.0000 1 Washer
22 33525.0000 1 Guide
23 01521.0000 1 Washer
(Continued)
11
32081.4 050114
PAF PLATFORM ASSEMBLY (Early Models)
(Continued)
ULTRA - 2
Early Models
33
31
32
2
15
8
6
5
4
3
16
30
1
10
11
12
7
16
17
9
29
18
13
14
26
28
20
23
19
21
22
24
25
27
12
P2517
32081.4 050114
PAF PLATFORM ASSEMBLY (Early Models)
ITEM PART NO. QTY. DESCRIPTION
24 00617.0000 1 Cable Tie
25 22749.0000 1 Mounting Pad, Cable Tie
26 29943.1000 1 Cover, Bottom SST (120V)(Includes item 18)
29943.1001 1 Cover, Bottom BLK (120V)(Includes item 18)
29943.0002 1 Cover, Bottom SST (230V)
29943.0003 1 Cover, Bottom BLK (230V)
01315.0000 7 Screw, SST, Truss Head #8-32 x .38"
02322.0002 7 Screw, BLK, Truss Head #8-32 x .38"
27 29942.0000* 2 Bracket SST
29942.0001 2 Bracket BLK
01317.0000 4 Screw, Truss Head #8-32 x .50"
28 29936.0000 1 Rod, Support
29 29446.0001 1 EMI Filter (230V)
00908.0000 2 Nut #8-32
30 00986.0002 1 Decal, Electrical Warning
31 34573.0000* 2 Latch Bracket
32 01663.0000 2 Bushing, Snap
33 34575.0000* 2 Plate, Guide
01311.0001 4 Screw, Truss Head Locking #8-32 x .25"
34 20630.0007 1 Power Cord (120V)
28111.0005 1 Power Cord (230V)
32212.0001 1 Power Cord (230V EURO)
35 29948.0000 1 Harness, Main (120V)
29948.0001 1 Harness, Main (230V)
36 32267.1000 1 Lamp Cord (Includes item 34)
37 29763.0000 2 Resister, Probe Detector
38 03851.0000 2 Wire Nut
Not Illustrated
Late Models
13
32081.4 050114
PAF PLATFORM ASSEMBLY (Late Models)
ULTRA - 2
6
7
5
4
2
3
23
24
10 11 12 13 14
19
1
20
8
9
17
15
16
18
21
22
14
32081.4 050114
PAF PLATFORM ASSEMBLY (Late Models)
ITEM PART NO. QTY. DESCRIPTION
1 47237.0000 1 Cover SST (Includes item 23)
47237.0001 1 Cover BLK (Includes item 23)
2 29591.0001 2 Guide Rail RH
01330.0000 4 Screw #10-32 x .38"
3 29591.0002 2 Guide Rail LH
01330.0000 4 Screw #10-32 x .38"
4 29724.0000 4 Roller
5 24457.0001 4 Shoulder Bolt
01522.0001 4 Washer
6 47245.0000 2 Latch
01315.0000 6 Screw, Truss Head #8-32 x .38"
7 34575.0001 2 Plate, Retainer
02322.0002 4 Screw, Truss Head BLK #8-32 x .38"
8 00707.0000 1 Bushing, Relief (120V)
05746.0000 1 Bushing, Relief (230V)
9 03628.0000 2 Receptacle 120V
32197.0000 2 Receptacle 230V
10 00906.0000 4 Nut
11 29742.0000 2 Retainer
12 29726.0001 2 Housing, Spring Contact
13 27788.0000 2 Spring
14 27748.0000 2 Pin
15 32104.0000 1 Relay, Lighting
00973.0001 2 Nut, keps #6-32
16 47280.0001 1 Bushing, Relief
17 22126.0000 1 Rectifier
00973.0001 1 Nut, keps #6-32
18 29844.0000* 1 Decal, Receptacle - PAF Only
29844.0001 1 Decal, Receptacle - PAFA Only
19 00973.0001 4 Nut, Grounding Stud
20 29446.0009 1 EMI Filter (230V)
00973.0001 1 Nut, keps #6-32
21 47243.0000 1 Base, Housing SST (120V)(Includes item 18)
47243.0001 1 Base, Housing BLK (120V)(Includes item 18)
47243.0002 1 Base, Housing SST (230V)
47243.0003 1 Base, Housing BLK (230V)
01315.0000 10 Screw, SST, Truss Head #8-32 x .38"
02322.0002 10 Screw, BLK, Truss Head #8-32 x .38"
(Continued)
15
32081.4 050114
PAF PLATFORM ASSEMBLY (Late Models)
(Continued)
ULTRA - 2
6
7
5
4
2
3
23
10 11 12 13 14
19
24
1
20
8
9
17
15
16
18
21
22
16
32081.4 050114
PAF PLATFORM ASSEMBLY (Late Models)
ITEM PART NO. QTY. DESCRIPTION
22 47244.0000 1 Bracket, Support SST
47244.0001 1 Bracket, Support BLK
01315.0000 3 Screw, SST, Truss Head #8-32 x .38"
02322.0002 3 Screw, BLK, Truss Head #8-32 x .38"
01384.0002 1 Screw, Truss Head #8-32 x 2.0"
02314.0000 1 Screw, Pan Head .25-20 x 0.5"
23 29947.0000 1 Decal, Dual Power Cord
24 00986.0002 1 Decal, Electrical Warning
The following items are not illustrated
25 00617.0000 1 Cable Tie
26 20630.0007 1 Power Cord (120V)
33529.0011 1 Power Cord (230V)
27 29948.0000 1 Harness, Main (120V)
29948.0001 1 Harness, Main (230V)
28 32267.1000 1 Lamp Cord (Includes item 30)
29 29763.0000 2 Resister, Probe Detector
30 03851.0000 2 Wire Nut
17
32081.4 050114
LIQUID AUTOFILL (LAF CF) KIT
5 4 5 6 7
ULTRA - 2
27
5
28
5
19
25
24
23
21
Syrup Valve Assembly
16
17
18
8
9
5
10
5
11
22
20
26
1
2
3
15
14
13
12
Water Valve Assembly
18
P4222.50
32081.4 031313
LIQUID AUTOFILL (LAF CF) KIT
ITEM PART NO. QTY. DESCRIPTION
1 - - - - - - - - 2 Cover, Auger Motor (See AUGER DRIVE & COOLING DRUM)
2 43145.0000 2 Bracket, Support
00970.0000 8 Nut, Keps #8-32
3 43131.0000 2 Bracket, Cover Mounting
02308.0000 4 Screw, Pan Head Serrated #8-32 x .375"
4 38129.0017* 4 Hose, Braided .25" ID x 11.0" (Order item 29)
5 21275.0006 16 Clamp
6 43823.0000 2 Fitting
7 - - - - - - - - 2 Hopper (See HOPPER, COVER AND FAUCET)
8 43115.0000 2 Valve, Needle
9 45042.0000 2 Locknut
10 38129.0023* 2 Hose, Braided .25" ID x 1.75" (Order item 29)
11 43130.1001 2 Valve Assy, Water, 120V
43130.1003 2 Valve Assy, Water, 230V
01317.0000 4 Screw, Truss Head #8-32 x .50"
12 01085.0008 2 Valve, Solenoid
44945.0000 4 Screw
13 46341.0000 2 Fitting
14 42193.0000 2 CF Valve
15 43124.0000 2 Fitting
16 43907.0000 2 Bracket
17 00430.0001 2 Adapter
18 43122.0002 2 Fitting
19 43130.1002 2 Valve Assy, Syrup, 120V
43130.1004 2 Valve Assy, Syrup, 230V
01317.0000 4 Screw, Truss Head #8-32 x .50"
20 43128.0000 2 Valve, Solenoid
21 44011.0002 2 Switch, Pressure
22 46341.0000 2 Fitting
23 42193.0000 2 CF Valve
Includes items 12-18
Includes items 20-26
24 43941.1000 2 Orifice, .0465 BLK
43941.1001 2 Orifice, .0350 WHT
25 43124.0000 2 Fiting
26 43122.0002 2 Fitting
27 43121.0000 2 Fitting, Bulkhead
28 38129.0005* 2 Hose, Braided .25" ID x 2.25" (Order item 29)
29 38129.1000 - Hose, Braided .25" ID x 12.0" (Cut to required length)
30 43841.0000 2 Harness Valve Wiring 120V
43841.0001 2 Harness Valve Wiring 230V
19
Not Illustrated
32081.4 071713
AUGER DRIVE AND COOLING DRUM
3
1 5 2 6 7 8 4
ULTRA - 2
10
11
12
9
13
14
8
15
25
23 24
22
21
20
19
18
17
16
27
26
20
P2510
32081.4 060214
AUGER DRIVE AND COOLING DRUM
ITEM PART NO. QTY. DESCRIPTION
1 27231.0000 2 Cover, Auger Motor - WHI
27231.0001 2 Cover, Auger Motor - BLK
43118.0000 2 Cover, Auger Motor - WHI
43118.0001 2 Cover, Auger Motor - BLK
01317.0000 4 Screw, Truss Head #8-32 x .50"
2 27232.0000 2 Bracket, Auger Motor Mounting
27232.0003 2 Bracket, Auger Motor Mounting (Salt Air Resistant)
02308.0000 6 Screw, Pan Head Serrated #8-32 x .375"
3 28093.1000 2 Motor Assy, Auger (Includes items 6, 7 & 8) (120V)
28093.1003 2 Motor Assy, Auger (Includes items 6, 7 & 8) (230V)
01326.0002 6 Screw, Pan Head #10-32 x .375"
4 32108.0002 2 Bracket, Auger Motor/Cooling Drum Mounting
32108.0006 2 Bracket, Auger Motor/Cooling Drum Mounting (Salt Air Resistant)
01311.0001 8 Screw, Truss Head - Locking #8-32 x .25"
5 -------------- 2 Capacitor, Motor (See ELECTRICAL AND OPERATING CONTROLS)
01317.0000 2 Screw, Truss Head #8-32 x .50"
01501.0000 2 Washer #8
01511.0000 2 Lockwasher, Ext.-tooth #8
Models with
LAF CF
6 27179.0004* 1 Motor Assembly, Auger (120V)(Order item 3)
27179.0005* 1 Motor Assembly, Auger (230V)(Order item 3)
7 34836.0002 1 Pin, Drive .125" O.D. x .94"
8 27440.0001 2 Bearing, Torsion Spring
9 28081.0001 2 Shaft Assy, Auger Drive (Includes items 8, 10 thru 15) (Also use item 28)
10 27223.0000 2 Spring, Torsion
11 27228.0000 1 Snap Ring
12 11556.0001 1 Pin, Split .125" O.D. x .437"
13 27224.0000 1 Retainer, Torsion Spring
14 34836.0001 1 Pin, Split .125" O.D. x .75"
15 32449.0000 1 Shaft, Auger
16 32189.0000 2 Bushing, Auger - Front
17 32106.1000 2 Auger
18 26780.0000 2 Seal, Auger Shaft
19 37593.0000 2 Seal, Cooling Drum
20 26781.0000 2 Bushing, Auger Shaft
21 32079.0000 2 Seal, Cooling Drum/Hopper
(Continued)
21
32081.4 121614
AUGER DRIVE AND COOLING DRUM
(Continued)
3
1 5 2 6 7 8 4
ULTRA - 2
10
11
12
9
13
14
8
15
25
23 24
22
21
20
19
18
17
16
27
26
22
P2510
32081.4 060214
AUGER DRIVE AND COOLING DRUM
ITEM PART NO. QTY. DESCRIPTION
22 32092.0002 2 Drum Assy, Cooling - WHI (Incl. items 23 & 24)
32092.1003 2 Drum Assy, Cooling - BLK (Incl. items 23 & 24)
32092.0004 2 Drum Assy, Cooling - WHI (Incl. items 23 & 24)(Salt Air Resistant)
32092.0005 2 Drum Assy, Cooling - BLK (Incl. items 23 & 24)(Salt Air Resistant)
01377.0000 8 Screw, Flat Head #8-32 x .75"
23 42175.0002 1 Mount Assembly, Cooling Drum - WHI
42175.0003 1 Mount Assembly, Cooling Drum - BLK
24 -------------- 1 Drum, Cooling (Not Available. Order item 22)
25 -------------- - Temperature Sensor Assy (See ELECTRICAL AND OPERATING CONTROLS)
26 28027.0000 2 Support, Cooling Drum (For Shipping and Cooling Drum Adjustment)
27 28236.0000 2 Label, DO NOT LIFT HERE (For Shipping Only)
28 M2548.1001 - Lubricant, Krytox .50 oz (Not illustrated)
23
32081.4 031313
CONDENSER AND FAN MOUNTING
1 2 3 4
ULTRA - 2
5 6 7 8 9
Models w/MORRILL Fan
24
15 16 14
Models w/ELCO Fan
P2511
32081.4 031313
CONDENSER AND FAN MOUNTING
ITEM PART NO. QTY. DESCRIPTION
1 28122.0000 1 Filter, Air
2 26791.0000 1 Condenser Assy
26791.0001 1 Condenser Assy, Coated (Salt Air Resistant)
02308.0000 4 Screw, Pan Head Serrated #8-32 x .375"
3 32084.0000 1 Shroud, Condenser - Right Half
32084.0008 1 Shroud, Condenser - Right Half (Salt Air Resistant)
32084.0006 1 Shroud, Condenser - Right Half (Internal Autofill Ready)
32084.0005 1 Shroud, Condenser - Left Half
32084.0007 1 Shroud, Condenser - Left Half (Salt Air Resistant)
02332.0001 4 Screw, Hex Head Crimptite #6 x .25"
02308.0000 4 Screw, Pan Head Serrated #8-32 x .375"
4 29084.0000 1 Fan Assy, Condenser - 120V (Includes items 5 thru 9)
29084.0002 1 Fan Assy, Condenser - 120V (Includes items 5 thru 9)(Salt Air Resistant)
29084.0001 1 Fan Assy, Condenser - 230V (Includes items 5 thru 9)
02332.0002 3 Screw, Hex Head - Thread Cutting #6 x .375"
5 27257.0000 1 Speed Nut .25"-20
6 29159.0000 1 Blade, Condenser Fan - 230V HP
29159.0000 1 Blade, Condenser Fan - 115V HP
27220.0000 1 Blade, Condenser Fan - 115V
7 27258.0000 1 Silencer, Fan
8 27221.0000 1 Motor, Condenser Fan - 115V (Includes Leads and Terminals)
29160.0000 1 Motor, Condenser Fan - 115V HP (Includes Leads and Terminals)
29160.0001 1 Motor, Condenser Fan - 230V HP (Includes Leads and Terminals)
9 27219.0000 1 Shroud/Mount, Condenser Fan
27219.0001 1 Shroud/Mount, Condenser Fan (Salt Air Resistant)
27243.0000 3 Screw, Hex Head Thread Forming #8-32 x .437"
10 36329.0002 3 Cable Tie (Not Illustrated)
11 38278.0003* 1 Edging 1.00" (Order item 13)
12 38278.0016* 1 Edging 1.25" (Order item 13)
13 38278.1002 - Edging 36.0" (Use as required)
14 - - - - - - - - 1 Motor, Condenser Fan - 115V, 25W
- - - - - - - - 1 Motor, Condenser Fan - 115V, 34W
15 - - - - - - - - 1 Blade, Condenser Fan, Plastic
- - - - - - - - 1 Blade, Condenser Fan, Metal
16 - - - - - - - - 1 Shroud/Mount, Condenser Fan
Early Models. Order item 4
25
32081.4 121614
COMPRESSOR AND MOUNTING (EMBRACO)(Early Models)
1
ULTRA - 2
15
5
4
3
2
6 12 13 11 9 10
10
17
8
7
16
6
8
7
9
11
18
19
13
MODEL T-2155
26
MODEL T-2168
HP Models
P2553.60
32081.4 031313
COMPRESSOR AND MOUNTING (EMBRACO)(Early Models)
ITEM PART NO. QTY. DESCRIPTION
NOTE: Compressor part numbers are no longer available. Check with Bunn for substitute replacements.
1 - - - - - - - - 1 Compressor Assy (Model T2155) 120V (No Longer Available)
- - - - - - - - 1 Compressor Assy, High Performance (Model T2168) 120V (No Longer Available)
- - - - - - - - 1 Compressor Assy, High Performance (Model T2168) 230V (No Longer Available)
2 32797.0000 4 Grommet, Compressor Mounting
3 32798.0000* 4 Sleeve, Compressor Mounting
4 34529.0000* 4 Washer, .281" I.D. x 1.0" O.D.
5 23700.0000 4 Nut, Hex Keps .25"-20
6 - - - - - - - - 1 Compressor (Not Available. Order item 1)
7 34254.0002 1 Overload Protector (Model T2155)(120V)
39136.0000 1 Overload Protector (Model T2168)(230V)
39819.0000 1 Overload Protector (Model T2168)(120V)
8 34253.0000 1 Retainer, Overload Protector (Model T2155, 120V & Model T2168, 230V)
39821.0000 1 Retainer, Overload Protector (Model T2168)(120V)
9 34252.0001 1 Cover, Compressor Terminal (Model T2155, 120V & Model T2168, 230V)
39818.0000 1 Cover, Compressor Terminal (Model T2168)(120V)
10 34251.0000 1 Retainer, Compressor Terminal Cover (Model T2155, 120V & Model T2168, 230V)
39820.0000 1 Retainer, Compressor Terminal Cover (Model T2168)(120V)
11 34255.0002 1 Relay, Compressor Start (Model T2155)(120V)
39137.0000 1 Relay, Compressor Start (Model T2168)(230V)
39833.0000 1 Relay, Compressor Start (Model T2168)(120V)
12 32799.0002 1 Bracket, Capacitor (Model T2155, 120V & Model T2168, 230V)
13 32795.0002 1 Capacitor, Run (Model T2155)(120V)
39152.0000 1 Capacitor, Run (Model T2168)(230V)
39804.0000 1 Capacitor, Run (Model T2168)(120V)
14 28651.0000 1 Label - R404A (Not illustrated)
15 - - - - - - - - 1 Eyebolt (Shipping Only)
- - - - - - - - 1 Tag, Eyebolt Shipping Notice (Not illustrated)
16 39142.0000 1 Screw M4 x 7mm
17 39885.0000 1 Gasket (Model T2168)(120V)
18 39788.0000 1 Bracket (Model T2168)(120V)
02335.0001 1 Screw, Hex #8 x .38" (Relay)
02308.0000 2 Screw, Pan Head Serrated #8-32 x .375" (Bracket)
19 39789.0000 1 Wiring Harness, Compressor (Model T2168)(120V)
33052.0000 1 Screw, Flat Head #10-32 x .50"
00971.0000 1 Nut, Keps #10-32
27
32081.4 090214
COMPRESSOR AND MOUNTING (EMBRACO)(Late Models)
1
ULTRA - 2
15
5
4
3
2
17
7
16
6
10
9
11
12
13
18
9
8
7
11
16
6
12
13
18
MODEL NT-2168 MODEL NT-2168
120V HP Models 230V HP Models
28
P4296.55
32081.4 031313
COMPRESSOR AND MOUNTING (EMBRACO)(Late Models)
ITEM PART NO. QTY. DESCRIPTION
NOTE: Check compressor data plate for Model Number prior to ordering replacement parts.
1 35980.1004 1 Compressor Assy (Model NT2168) 120V (Incl. items 2, 3, 6 - 18)
35980.0008 1 Compressor Assy (Model NT2168) 120V (Incl. items 2, 3, 6 - 18)(Salt Air Resistant)
35980.1005 1 Compressor Assy (Model NT2168) 230V (Incl. items 2, 3, 6 - 18)
2 32797.0000 4 Grommet, Compressor Mounting
3 32798.0000* 4 Sleeve, Compressor Mounting
4 34529.0000* 4 Washer, .281" I.D. x 1.0" O.D.
5 23700.0000 4 Nut, Hex Keps .25"-20
6 - - - - - - - - 1 Compressor (Not Available. Order item 1)
7 39819.0004 1 Overload Protector (Model NT2168)(120V)
39819.0005 1 Overload Protector (Model NT2168)(230V)
8 38821.0005 1 Retainer, Overload Protector (Model NT2168)(230V)
9 39818.0001 1 Cover, Compressor Terminal (Model NT2168)(120V)
39818.0002 1 Cover, Compressor Terminal (Model NT2168)(230V)
10 39820.0001 1 Retainer, Compressor Terminal Cover (Model NT2168)(120V)
11 39833.0004 1 Relay, Compressor Start (Model NT2168)(120V)
39833.0005 1 Relay, Compressor Start (Model NT2168)(230V)
12 44820.0004 1 Capacitor, Run (Model NT2168)(120V)
44820.0005 1 Capacitor, Run (Model NT2168)(230V)
13 39804.0004 1 Capacitor, Start (Model NT2168)(120V)
39804.0005 1 Capacitor, Start (Model NT2168)(230V)
14 28651.0000 1 Label - R404A (Not illustrated)
15 - - - - - - - - 1 Eyebolt (Shipping Only)
- - - - - - - - 1 Tag, Eyebolt Shipping Notice (Not illustrated)
16 45282.0000 1 Screw M3.5 x 7mm (120V)
17 39885.0001 1 Gasket (Model NT2168)(120V)
18 39788.0002 1 Bracket (Model NT2168)(120V & 230V)
39788.0003 1 Bracket (Model NT2168)(120V & 230V) (Salt Air Resistant)
02308.0000 2 Screw, Pan Head Serrated #8-32 x .375"
29
32081.4 121614
COMPRESSOR AND MOUNTING (AMERICOLD)
R404A
R404A
ULTRA - 2
19
5
4
3
1
2
14
7 15 8 16 6
9 10 11 12
7 15 8 16 6
17 12
13 9 10 11 18
120V MODELS
30
230V MODELS
P2512
32081.4 031313
COMPRESSOR AND MOUNTING (AMERICOLD)
ITEM PART NO. QTY. DESCRIPTION
NOTE: Compressors and related parts are no longer available. No substitutes are available.
1 - - - - - - - - 1 Compressor Assy 120V (No Longer Available)
- - - - - - - - 1 Compressor Assy 230V (No Longer Available)
2 -------------- 4 Grommet, Compressor Mounting
Order item 20
3 -------------- 4 Sleeve, Compressor Mounting
4 34529.0000* 4 Washer, .281" I.D. x 1.0" O.D.
5 23700.0000 4 Nut, Hex Keps .25”-20
6 -------------- 1 Compressor (Not Available. Order item 1)
7 27641.0000 1 Cap, Access Valve (Procure Locally)
8 27551.0000 1 Valve Assy, Access (Includes items 7 & 15) (Requires brazing to Install)
9 27407.0000 1 Overload Protector (120V)
27407.0001 1 Overload Protector (230V)
10 27403.0000 1 Retainer, Overload Protector (120V)
11 27408.0000 1 Cover, Compressor Terminal
12 32095.0000 1 Retainer, Compressor Terminal Cover (120V)
27404.0000 1 Retainer, Compressor Terminal Cover (230V)
13 02335.0001 1 Screw, Hex Head Crimptite #8 x .375"
14 32094.0000 1 Relay, Compressor Start (120V)
15 27642.0000 1 Valve Core, .25"
16 28651.0000 1 Label - R404A
17 27406.0002 1 Starter, Motor (230V)
18 27405.0001 1 Capacitor, Run (230V)
02332.0002 Screw, Hex Crimptite #6 x .375"
19 - - - - - - - - 1 Eyebolt (Shipping Only)
- - - - - - - - 1 Tag, Eyebolt Shipping Notice (Not illustrated)
20 27613.0000 1 Kit, Compressor Mounting (Includes 4 each of item 2 & 3)
31
32081.4 090214
SOLENOID AND COOLANT PIPING (EMBRACO-100V & 120V)
1 2 3 4 5 6
ULTRA - 2
15
15
16
13
12
11
16
18
19
17 14 10 8 7 9
32
P2552
32081.4 031313
SOLENOID AND COOLANT PIPING (EMBRACO-100V & 120V)
ITEM PART NO. QTY. DESCRIPTION
1 -------------- 1 Condenser (See Condenser and Fan Mounting)
2 32088.0000 1 Tube .375" O.D. Accumulator to Left Cooling Drum (Requires brazing to install)
3 27607.1000 1 Tube .093" O.D. Solenoid to Left Cooling Drum (Requires brazing to install)
27607.1001 1 Tube .093" O.D. Solenoid to Right Cooling Drum (Requires brazing to install)
4 32087.0000 1 Tube .375" O.D. Accumulator to Right Cooling Drum (Requires brazing to install)
5 28925.0000 2 Adapter, Reducing (Requires brazing to install)(Early Models)
6 -------------- 2 Cooling Drum (See Auger Drive and Cooling Drum)
7 32113.0000 1 Bracket, Solenoid Mounting
32113.0000 1 Bracket, Solenoid Mounting (Salt Air Resistant)
02308.0000 1 Screw, Pan Head Serrated #8-32 x .375"
8 32133.0000 2 Solenoid Assy (120V)
32133.0002 2 Solenoid Assy (100V)
02332.0001 2 Screw, Crimptite #6 x .25"
9 -------------- 1 Compressor (See Compressor and Mounting)
10 32256.0000 1 Dryer Assembly (Requires brazing to install)
11 34257.0000 1 Tube .312" O.D. Accumulator to Compressor (Requires brazing to install)
12 34258.0000 1 Tube .250" O.D. Condenser to Compressor (Requires brazing to install)
13 34211.0000* 1 Tube, Condenser to Dryer (Includes items 15 & 16) (Requires brazing to install)
14 32257.0000 1 Accumulator, Suction (Requires brazing to install)
15 27641.0000 2 Cap, Valve Access
16 27642.0000 2 Valve Core
17 27411.0000 1 Cup, Condensate
18 28645.0000 1 Valve, Access (Includes items 15 & 16) (Requires brazing to install)
19 34256.0000 2 Tube, Spacer (Requires brazing to install)
20 M2316.1000 - Insulation, Tube .375" I.D. x 6 ft LG (As Required)
21 00617.0000 8 Tie, BLK Nylon 3.90" LG (As Required)
22 36329.0002 7 Cable Tie
Not Illustrated
33
32081.4 121614
SOLENOID AND COOLANT PIPING (EMBRACO-230V)
1 2 3 4 6
ULTRA - 2
15
16
13
12
11
19
5
18
16
15
17 14 10 8 7 9
34
P3459
32081.4 031313
SOLENOID AND COOLANT PIPING (EMBRACO-230V)
ITEM PART NO. QTY. DESCRIPTION
1 -------------- 1 Condenser (See Condenser and Fan Mounting)
2 32088.0000 1 Tube .375" O.D. Accumulator to Left Cooling Drum (Requires brazing to install)
3 27607.1000 1 Tube .093" O.D. Solenoid to Left Cooling Drum (Requires brazing to install)
27607.1001 1 Tube .093" O.D. Solenoid to Right Cooling Drum (Requires brazing to install)
4 32087.0000 1 Tube .375" O.D. Accumulator to Right Cooling Drum (Requires brazing to install)
5 44053.0000 2 Tube, Access Port (Requires brazing to install)
6 -------------- 2 Cooling Drum (See Auger Drive and Cooling Drum)
7 32113.0000 1 Bracket, Solenoid Mounting
02308.0000 1 Screw, Pan Head Serrated #8-32 x .375"
8 32133.0001 2 Solenoid Assy (230V)
02332.0001 2 Screw, Crimptite #6 x .25"
9 -------------- 1 Compressor (See Compressor and Mounting)
10 32256.0000 1 Dryer Assembly (Requires brazing to install)
11 36198.0000 1 Tube .312" O.D. Accumulator to Compressor (Requires brazing to install)
12 36196.0000 1 Tube .250" O.D. Condenser to Compressor (Requires brazing to install)
13 34211.0000* 1 Tube, Condenser to Dryer (Includes items 15 & 16) (Requires brazing to install)
14 32257.0000 1 Accumulator, Suction (Requires brazing to install)
15 27641.0000 2 Cap, Valve Access
16 27642.0000 2 Valve Core
17 27411.0000 1 Cup, Condensate
18 28645.0000 1 Valve, Access (Includes items 15 & 16) (Requires brazing to install)
19 34256.0000 1 Tube, Spacer (Requires brazing to install)
20 M2316.1000 - Insulation, Tube .375" I.D. x 6 ft LG (As Required)
21 00617.0000 8 Tie, BLK Nylon 3.90" LG (As Required)
22 36329.0002 7 Cable Tie
Not Illustrated
35
32081.4 031313
SOLENOID AND COOLANT PIPING (AMERICOLD)
1 2 3 4 5 6
ULTRA - 2
15
16
13
12
14
13
Early Models
17 11 10 8 7 9
36
P2513
32081.4 031313
SOLENOID AND COOLANT PIPING (AMERICOLD)
ITEM PART NO. QTY. DESCRIPTION
NOTE: Compressors and related parts are no longer available. No substitutes are available.
1 -------------- 1 Condenser (See Condenser and Fan Mounting)
2 32088.0000 1 Tube .375" O.D. Accumulator to Left Cooling Drum (Requires brazing to install)
3 27607.1000 1 Tube .093" O.D. Solenoid to Left Cooling Drum (Requires brazing to install)
27607.1001 1 Tube .093" O.D. Solenoid to Right Cooling Drum (Requires brazing to install)
4 32087.0000 1 Tube .375" O.D. Accumulator to Right Cooling Drum (Requires brazing to install)
5 28925.0000 2 Adapter, Reducing (Requires brazing to install)(Early Models)
6 -------------- 2 Cooling Drum (See Auger Drive and Cooling Drum)
7 32113.0000 1 Bracket, Solenoid Mounting
02308.0000 1 Screw, Pan Head Serrated #8-32 x .375"
8 32133.0000 2 Solenoid Assy (120V)
32133.0001 2 Solenoid Assy (230V)
02332.0001 2 Screw, Crimptite #6 x .25"
9 -------------- 1 Compressor (See Compressor and Mounting)
10 32256.0000 1 Dryer Assembly (Requires brazing to install)
11 32086.0001 1 Tube .312" O.D. Accumulator to Compressor (Requires brazing to install)
12 32085.0001 1 Tube .250" O.D. Condenser to Compressor (Requires brazing to install)
13 - - - - - - - - 1 Tube, Condenser to Dryer (Early Models) (Requires brazing to install)
34211.0000* 1 Tube, Condenser to Dryer (Late Models) (Includes items 15 & 16)
(Requires brazing to install)
14 32257.0000 1 Accumulator, Suction (Requires brazing to install)
15 27641.0000 1 Cap, Valve Access
16 27642.0000 1 Valve Core
17 27411.0000 1 Cup, Condensate
18 M2316.1000 - Insulation, Tube .375" I.D. x 6 ft LG (As Required)
19 00617.0000 8 Tie, BLK Nylon 3.90" LG (As Required)
20 36329.0002 7 Cable Tie
Not Illustrated
37
32081.4 090214
INTERNAL LIQUID AUTOFILL KIT (Optional)
11 2 12
To Hopper
ULTRA - 2
1
2
3
4
11
5
6
7
8
13
14
10
9
38
P3458
32081.4 031313
INTERNAL LIQUID AUTOFILL KIT (Optional)
ITEM PART NO. QTY. DESCRIPTION
Quantities listed below are for one solenoid only. Two to four may required.
1 37931.0000 1 Tube
2 21275.0006 4 Clamp .41 - .50"
3 32745.0028* 1 Hose .25" ID x 1.0"
4 37933.0000 1 Solenoid, Syrup Valve 120V
37933.0001 1 Solenoid, Syrup Valve 230V
37933.0002 1 Solenoid, Syrup Valve 100V
5 37958.0000 1 Locknut
6 37878.0000 1 Bracket, Autofill
01311.0001 1 Screw, Truss Head #8-32 x .25" Locking
02332.0001 1 Screw, Hex Head #6 x .25"
7 33149.0000 1 Gasket
8 35174.0003 1 Fitting .375" Barb x .375" Flare
9 01663.0000 1 Bushing, Snap
10 07070.0000 1 Bushing, Snap
11 32745.0027* 1 Hose .25" ID x 55.0"
12 38021.0000 1 Coupling .25" Barb
42921.0000 1 Coupling .38" Barb (For Models using .38" ID hose)
13 21275.0003 1 Clamp .57 - .70"
14 12422.0011 1 Clamp .40-.45" ID
39
32081.4 031313
ELECTRICAL AND OPERATING CONTROLS
1 3 2 4
ULTRA - 2
5
6
7
18
14 15 13
9
8
16
10 11 17 12
40
P2514
32081.4 031313
ELECTRICAL AND OPERATING CONTROLS
ITEM PART NO. QTY. DESCRIPTION
1 27178.0000 2 Capacitor, Auger Motor 370 VAC (120V)
27178.0001 2 Capacitor, Auger Motor 500 VAC (230V)
2 38708.1000 2 Circuit Board, Torque Sensor (120/230V)
02308.0000 2 Screw, Pan Head Serrated #8-32 x .375"
02360.0000 2 Washer, .188" I.D. x .75" O.D.
3 27246.1000 2 Temperature Sensor (Includes Connector)
4 00604.0000 2 Clip
01317.0003 2 Screw, Truss Head Locking #8-32 x .375"
5 32104.0000 1 Relay, Lighting
01382.0000 2 Screw, Truss Head #6-32 x .38"
6 27181.0000 1 Circuit Breaker, 5 amp
7 37711.0000 1 Relay, 120V (ULTRA-2)
37711.0001 1 Relay, 230V (ULTRA-2A)
02308.0000 2 Screw, Pan Head Serrated #8-32 x .375"
8 27644.1002 1 Transformer, 120V 60 Hz
27644.1004 1 Transformer, 230V 50/60 Hz
27644.1005 1 Transformer, 115V (Spanish Models)
00970.0000 2 Nut, Keps #8-32
9 29446.0006 1 EMI Filter (ULTRA-2A only)
00970.0000 2 Nut, Keps #8-32
10 32121.0000 1 Box, Electronic Control
00973.0000 3 Nut, Keps #6-32
11 32097.1000 1 Memory Clock Board 120V
32097.1001 1 Memory Clock Board 230V
24544.0000 1 Screw, Pan Head #8-18
12 44039.1000 1 Circuit Board Assy, Bilingual, Main 120V
44039.1008 1 Circuit Board Assy, Bilingual, Main 230V
24544.0000 4 Screw, Pan Head #8-18
13 05746.1000 1 Bushing, Strain Relief
14 32269.0000 1 Probe, Thermister
15 29421.0001 1 Clamp, Worm Drive
16 28860.0003 1 Transformer, 230V (Early Models)
02308.0000 2 Screw, Pan Head Serrated #8-32 x .375"
00970.0000 2 Nut, Keps #8-32
17 38983.1001 1 Circuit Board, Autofill (Models with LAF & CF Refill Systems)
18 40770.0000 1 Resistor (230V)
(Continued)
41
32081.4 090214
ELECTRICAL AND OPERATING CONTROLS
(Continued)
1 3 2 4
ULTRA - 2
5
6
7
18
9
14 15 13
8
16
10 11 17 12
42
P2514
32081.4 031313
ELECTRICAL AND OPERATING CONTROLS
ITEM PART NO. QTY. DESCRIPTION
The following items are not illustrated:
19 32263.0000 1 Harness, Main (120V)
32263.0001 1 Harness, Main (230V)
32263.0005 1 Harness, Main (Autofill Ready Models with T2168 Compressor)
32263.0006 1 Harness, Main (Autofill Ready Models with NT2168 Compressor)
32263.0007 1 Harness, Main (Autofill Ready Models with NT2168 Compressor)(Salt Air Resistant)
00970.0000 1 Nut, Keps #8-32 (Grounding)
20 32163.0000 1 Harness, Membrane Switch to Electronic Control
32163.0001 1 Harness, Membrane Switch to Electronic Control (Salt Air Resistant)
21 20630.0009 1 Power Cord 120V
38074.0028 1 Power Cord 230V
42749.0001 1 Power Cord 230V (KETI units)
22 37962.0000 1 Harness, Autofill Circuit Board to Syrup Valves (Models with Internal Autofill Option)
37962.0001 1 Harness, Autofill Circuit to CF Valves 120V
37962.0002 1 Harness, Autofill Circuit to CF Valves 230V
23 40432.0000 1 Jumper, WHI EMI Filter (230V)
24 40432.0001 1 Jumper, BLK EMI Filter (230V)
Models with LAF CF
25 40432.0002 1 Jumper, Compressor (230V)(Early Models)
43
32081.4 121614
NUMERICAL INDEX
PART NO. PAGE NO.
00430.0001......................... 19
00604.0000......................... 41
00617.0000..... 13,17,33,35,37
00707.0000.................... 11,15
00778.0000........................... 9
00906.0000.................... 11,15
00908.0000.................... 11,13
00927.0000........................... 7
00927.0001........................... 7
00970.0000............... 19,41,43
00971.0000......................... 27
00973.0000......................... 41
00973.0001......................... 15
00986.0002................. 5,13,17
01085.0008......................... 19
01311.0001....... 5,11,13,21,39
01315.0000................. 9,15,17
01317.0000............... 13,19,21
01317.0003......................... 41
01326.0002......................... 21
01330.0000.................... 11,15
01377.0000......................... 23
01382.0000.................... 11,41
01382.0000........................... 7
01384.0002......................... 17
01393.0000........................... 9
01501.0000......................... 21
01511.0000......................... 21
01521.0000......................... 11
01522.0001.................... 11,15
01532.0001........................... 9
01663.0000.................... 13,39
01666.0002.. 5,11,19,21,25,27
02308.0000..... 29,33,35,37,41
02314.0000......................... 17
02322.0002............... 13,15,17
02329.0000........................... 5
02332.0001..... 25,33,35,37,39
02332.0002.................... 25,31
02335.0001................. 7,27,31
02360.0000......................... 41
03354.0000........................... 7
03628.0000.................... 11,15
03851.0000................. 9,13,17
03993.0000........................... 7
03996.0000........................... 7
05746.0000.................... 11,15
05746.1000......................... 41
07070.0000......................... 39
11556.0001......................... 21
12421.1001........................... 7
12421.1002........................... 7
12421.1003........................... 7
12422.0011......................... 39
13255.0003........................... 7
13255.0006........................... 7
20622.0005........................... 7
20630.0007.................... 13,17
20630.0009......................... 43
21275.0003......................... 39
21275.0006.................... 19,39
21436.0000........................... 5
21437.1000........................... 5
22126.0000.................... 11,15
22749.0000......................... 13
23700.0000............... 27,29,31
24457.0001.................... 11,15
24544.0000......................... 41
24566.0000........................... 9
26528.0000........................... 7
26780.0000......................... 21
26781.0000......................... 21
26791.0000......................... 25
26791.0001......................... 25
27058.0000........................... 5
27058.0001........................... 7
27058.0002........................... 5
27058.0003........................... 7
27058.0010........................... 5
27058.0011........................... 7
27058.0014........................... 5
27058.0015........................... 7
27131.0000........................... 7
27131.0001........................... 7
27136.0002........................... 5
27136.0003........................... 5
27178.0000......................... 41
27178.0001......................... 41
27179.0004......................... 21
27179.0005......................... 21
27181.0000......................... 41
27219.0000......................... 25
27219.0001......................... 25
27220.0000......................... 25
27221.0000......................... 25
27223.0000......................... 21
27224.0000......................... 21
27228.0000......................... 21
27231.0000......................... 21
27231.0001......................... 21
27232.0000......................... 21
27232.0003......................... 21
27243.0000......................... 25
27246.1000......................... 41
27257.0000......................... 25
27258.0000......................... 25
27394.0000........................... 5
27394.0001........................... 5
27403.0000......................... 31
27404.0000......................... 31
27405.0001......................... 31
27406.0002......................... 31
27407.0000......................... 31
27407.0001......................... 31
27408.0000......................... 31
27411.0000............... 33,35,37
27440.0001......................... 21
27442.0000........................... 5
27445.1000........................... 9
27446.0000........................... 9
27551.0000......................... 31
27607.1000............... 33,35,37
27607.1001............... 33,35,37
27613.0000......................... 31
27641.0000.......... 31,33,35,37
27642.0000.......... 31,33,35,37
27643.1000........................... 9
27644.1002......................... 41
27644.1004......................... 41
27644.1005......................... 41
27748.0000.................... 11,15
27788.0000.................... 11,15
28027.0000......................... 23
28081.0001......................... 21
28086.0000........................... 5
28086.0001........................... 5
28093.1000......................... 21
28093.1003......................... 21
28098.0000........................... 7
28111.0005......................... 13
28122.0000......................... 25
28236.0000......................... 23
28645.0000.................... 33,35
28651.0000............... 27,29,31
28755.0003........................... 9
28756.1000........................... 9
28770.0000........................... 9
28776.0001........................... 9
28860.0003......................... 41
28925.0000.................... 33,37
29084.0000......................... 25
29084.0001......................... 25
29084.0002......................... 25
29159.0000......................... 25
29160.0000......................... 25
29160.0001......................... 25
29373.0001........................... 7
29421.0001......................... 41
29446.0001......................... 13
29446.0006......................... 41
29446.0009......................... 15
29481.0001........................... 9
PART NO. PAGE NO. PART NO. PAGE NO. PART NO. PAGE NO.
29591.0001.................... 11,15
29591.0002.................... 11,15
29702.1000........................... 7
29724.0000.................... 11,15
29726.0000......................... 11
29726.0001......................... 15
29742.0000.................... 11,15
29763.0000.................... 13,17
29844.0000.................... 11,15
29844.0001.................... 11,15
29936.0000......................... 13
29940.1000......................... 11
29940.1002......................... 11
29941.1000......................... 11
29941.1001......................... 11
29941.1002......................... 11
29941.1003......................... 11
29942.0000......................... 13
29942.0001......................... 13
29943.0002......................... 13
29943.0003......................... 13
29943.1000......................... 13
29943.1001......................... 13
29947.0000.................... 11,17
29947.0000........................... 5
29948.0000.................... 13,17
29948.0001.................... 13,17
29959.0001........................... 7
29959.0002........................... 7
29959.8002........................... 7
29967.1002........................... 5
29976.0000........................... 7
29979.0000........................... 5
32068.0000........................... 5
32068.0001........................... 5
32069.1000........................... 9
32069.1001........................... 9
32079.0000......................... 21
32082.0002........................... 5
32082.0004........................... 5
32084.0000......................... 25
32084.0005......................... 25
32084.0006......................... 25
32084.0007......................... 25
32084.0008......................... 25
32085.0001......................... 37
32086.0001......................... 37
32087.0000............... 33,35,37
32088.0000............... 33,35,37
32092.0002......................... 23
32092.0004......................... 23
32092.0005......................... 23
32092.1003......................... 23
32094.0000......................... 31
44
32081.4 121614
NUMERICAL INDEX
PART NO. PAGE NO. PART NO. PAGE NO. PART NO. PAGE NO. PART NO. PAGE NO.
32095.0000......................... 31
32096.0001........................... 9
32096.0002........................... 9
32097.1000......................... 41
32097.1001......................... 41
32104.0000............... 11,15,41
32105.0000........................... 9
32105.0001........................... 9
32106.1000......................... 21
32108.0002......................... 21
32108.0006......................... 21
32111.0000........................... 5
32111.0001........................... 5
32111.0002........................... 5
32111.0003........................... 5
32113.0000............... 33,35,37
32113.0002......................... 33
32116.1000........................... 5
32116.1001........................... 5
32121.0000......................... 41
32124.0000........................... 7
32126.1004........................... 5
32133.0000.................... 33,37
32133.0001.................... 35,37
32133.0002......................... 33
32163.0000......................... 43
32163.0001......................... 43
32189.0000...................... 9,21
32190.1000........................... 9
32190.1001........................... 9
32190.1003........................... 9
32190.1005........................... 9
32191.0000........................... 9
32193.0000........................... 9
32195.0000........................... 9
32196.0000........................... 9
32196.0001........................... 9
32197.0000.................... 11,15
32212.0001......................... 13
32256.0000............... 33,35,37
32257.0000............... 33,35,37
32263.0000......................... 43
32263.0001......................... 43
32263.0005......................... 43
32263.0006......................... 43
32263.0007......................... 43
32265.0001........................... 9
32266.0000........................... 9
32267.1000.................... 13,17
32267.1000........................... 9
32268.1000........................... 9
32268.1001........................... 9
32269.0000......................... 41
32449.0000......................... 21
32580.0000........................... 5
32580.0000........................ 5,7
32632.0000......................... 11
32745.0027......................... 39
32745.0028......................... 39
32793.0000........................... 7
32795.0002......................... 27
32797.0000.................... 27,29
32798.0000.................... 27,29
32799.0002......................... 27
32916.0002........................... 9
33052.0000......................... 27
33149.0000......................... 39
33524.0000......................... 11
33525.0000......................... 11
33527.0000......................... 11
33529.0011......................... 17
34211.0000............... 33,35,37
34251.0000......................... 27
34252.0001......................... 27
34253.0000......................... 27
34254.0002......................... 27
34255.0002......................... 27
34256.0000.................... 33,35
34257.0000......................... 33
34258.0000......................... 33
34529.0000............... 27,29,31
34573.0000......................... 13
34575.0000......................... 13
34575.0001......................... 15
34836.0001......................... 21
34836.0002......................... 21
35174.0003......................... 39
35980.0008......................... 29
35980.1004......................... 29
35980.1005......................... 29
36182.1004........................... 5
36182.1005........................... 5
36182.1006........................... 7
36182.1007........................... 7
36187.0000........................... 7
36188.0000........................... 7
36196.0000......................... 35
36198.0000......................... 35
36329.0002.......... 25,33,35,37
37593.0000......................... 21
37711.0000......................... 41
37711.0001......................... 41
37878.0000......................... 39
37883.0000........................... 7
37883.0002........................... 7
37906.0002........................... 7
37906.0006........................... 7
37931.0000......................... 39
37933.0000......................... 39
37933.0001......................... 39
37933.0002......................... 39
37958.0000......................... 39
37962.0000......................... 43
37962.0001......................... 43
37962.0002......................... 43
38021.0000...................... 9,39
38074.0028......................... 43
38129.0005......................... 19
38129.0017......................... 19
38129.0023......................... 19
38129.1000......................... 19
38278.0003......................... 25
38278.0016......................... 25
38278.1002......................... 25
38708.1000......................... 41
38821.0005......................... 29
38983.1001......................... 41
39136.0000......................... 27
39137.0000......................... 27
39142.0000......................... 27
39152.0000......................... 27
39257.0000........................... 9
39788.0000......................... 27
39788.0002......................... 29
39788.0003......................... 29
39789.0000......................... 27
39804.0000......................... 27
39804.0004......................... 29
39804.0005......................... 29
39818.0000......................... 27
39818.0001......................... 29
39818.0002......................... 29
39819.0000......................... 27
39819.0004......................... 29
39819.0005......................... 29
39820.0000......................... 27
39820.0001......................... 29
39821.0000......................... 27
39833.0000......................... 27
39833.0004......................... 29
39833.0005......................... 29
39885.0000......................... 27
39885.0001......................... 29
39967.0000........................... 9
40432.0000......................... 43
40432.0001......................... 43
40432.0002......................... 43
40770.0000......................... 41
42175.0002......................... 23
42175.0003......................... 23
42193.0000......................... 19
42749.0001......................... 43
42921.0000...................... 9,39
43115.0000......................... 19
43118.0000......................... 21
43118.0001......................... 21
43121.0000......................... 19
43122.0002......................... 19
43124.0000......................... 19
43128.0000......................... 19
43130.1001......................... 19
43130.1002......................... 19
43130.1003......................... 19
43130.1004......................... 19
43131.0000......................... 19
43136.0000........................... 7
43136.0001........................... 7
43136.0002........................... 7
43145.0000......................... 19
43823.0000......................... 19
43841.0000......................... 19
43841.0001......................... 19
43907.0000......................... 19
43941.1000......................... 19
43941.1001......................... 19
44011.0002......................... 19
44039.1000......................... 41
44039.1008......................... 41
44053.0000......................... 35
44614.1000........................... 9
44820.0004......................... 29
44820.0005......................... 29
44945.0000......................... 19
45042.0000......................... 19
45282.0000......................... 29
46331.0001........................... 9
46341.0000......................... 19
47237.0000......................... 15
47237.0001......................... 15
47243.0000......................... 15
47243.0001......................... 15
47243.0002......................... 15
47243.0003......................... 15
47244.0000......................... 17
47244.0001......................... 17
47245.0000......................... 15
47280.0001......................... 15
47315.1000........................... 9
47315.1001........................... 9
M2316.1001 ....................... 33
M2316.1000 ....................... 35
M2316.1000 ....................... 37
M2548.1001 ....................... 23
45
32081.4 121614
Loading...
