Chapter 1 - Setup
Introduction
Thank you for buying a Buffalo AirStation. The WZR-1750DHP AirStation is a dual-band wireless router with outstanding
performance and range. It combines speeds of 600 Mbps up to 1750 Mbps with a robust set of extra features like QoS,
wireless bridging, USB NAS, media server, and parental control. This manual will help you set it up and use it. If you’re
new to wireless networking, turn to chapter 2 to start configuring your wireless network.
For advanced users, use a wired Ethernet connection to access the AirStation’s settings:
• Default LAN-side IP address: 192.168.11.1
• Username: admin
• Default password: password
Diagrams and Layout
Front Panel
8
1 AOSS button
To initiate AOSS, hold down this button until the wireless LED flashes (about 1 second). Then, push or click the
AOSS button on your wireless client device to complete the connection. Both devices must be powered on for this
to work.
2 Wireless LED
(Access point/wireless bridge control switch set to “AP”)
On:
Wireless LAN is enabled or transmitting.
Double blinks:
AirStation is waiting for an AOSS or WPS security key.
Continuously blinking:
AOSS/WPS error; failed to exchange security keys.
Off:
Wireless LAN is disabled.
(Access point/wireless bridge control switch set to “WB”)
On:
Wireless LAN is enabled or transmitting.
Blinking:
Wireless LAN is enabled but not connected.
Off:
Wireless LAN is disabled.
Note:
The wireless LED will be blue for 5 GHz wireless connections or amber for 2.4 GHz wireless connections.
3 Internet access LED (Blue)
On:
Internet access is available.
Off:
Internet access is not available.
Router functionality is disabled.
4 Router LED (Blue)
On:
Router functionality is enabled.
Off:
Router functionality is disabled.
5 Buffalo LED (White or Red)
On (White):
Power is on.
Off:
Power is off.
On (Red)*:
Booting.
2 blinks (Red)**:
Flash ROM error.
3 blinks (Red)**:
Wired Ethernet LAN error.
4 blinks (Red)**:
Wireless LAN error.
9
5 blinks (Red)***:
IP address error.
9 blinks (Red)**:
System error.
Continuously blinking*:
Updating firmware, saving settings, or initializing settings.
* Never unplug the AC adapter while the Buffalo LED is blinking continuously.
** Turn off AirStation, wait for a few seconds, then turn it back on.
*** Because the network addresses of both the Internet port (WAN port) and the LAN port are the same, it is not possible
to establish communication. Change the LAN-side IP address of the AirStation.
Back Panel
1 Access Point/Wireless Bridge Control Switch
This switch changes between access point mode and wireless bridge mode.
AP - access point (or router) WB - wireless bridge
2 Mode button
If the switch above is in the “AP” position, this button switches the AirStation between router and access point
functionality. If the switch is in the “WB” position, the button has no effect.
3 USB Eject button
To dismount a USB hard drive, hold down this button until the USB LED flashes (about 3 seconds). The USB drive
can then be unplugged safely.
10
4 USB LED (Blue)
On:
A USB drive is connected.
Blinking:
The USB drive can be removed.
Note:
When this LED is blinking, the connected USB drive cannot be used. Remove the connected USB drive. If the LED
continues to blink even after the USB drive is removed, restart the AirStation. Do not remove the USB drive or turn
off the AirStation while the USB LED is on.
5 USB 3.0 Port
You can connect any USB 3.0 compatible devices (such as USB storage). Use the cable attached to the USB 3.0
device to connect.
6 USB 2.0 Port
You can connect any USB 2.0 compatible devices (such as USB printers).
7 LAN Port
Connect your computer, hub, or other Ethernet devices to these ports. This switching hub supports 10 Mbps, 100
Mbps, and 1000 Mbps connections.
8 LAN LED (Green)
On:
An Ethernet device is connected.
Blinking:
An Ethernet device is communicating.
9 Internet Port
10 Mbps, 100 Mbps, and 1000 Mbps connections are supported.
Note:
In wireless bridge mode or access point mode, the Internet port becomes a regular LAN port, for a total of 5 usable
LAN ports.
10 Internet LED (Green)
On:
The Internet port is connected.
Blinking:
The Internet port is transmitting data.
11 Power button
This button turns the power on and off.
It may take 20 to 30 seconds to complete shutdown.
12 DC connector
Connect the included AC adapter here.
11
Bottom
1 Reset button
To reset all settings, hold down this button until the Buffalo LED turns red (about 3 seconds). The power must be
on for this to work.
2 Setup card slot
This is the slot where the AirStation setup card is stored. The initial settings for the username, password, SSID, and
encryption type are provided on the card for logging into Settings .
Right Side
1 Mounting holes
Mounting holes are provided for mounting the AirStation to a wall. Use the supplied screws to mount to a wall.
12
Installation
Vertical Placement
Attach the stand as shown in the figure below.
Horizontal Placement
The same stand also allows horizontal placement. Install the stand as shown in the figure below.
13
Wall-Mounting
Attach to the wall with the supplied screws in the mounting holes as shown below.
14
How to Set Up AirStation for the First Time
Connect to a PC and Power On
To configure your AirStation, follow the procedure below.
1 Verify that you can connect to the internet without the AirStation, then turn off your modem and computer.
2 Unplug the LAN cable which connects your computer and modem.
3 Plug one end of the LAN cable into your modem and the other end to the AirStation’s Internet (WAN) port. Turn on
the modem.
15
4 Turn on the AirStation, then wait one minute.
Note:
If the power does not turn on when the AC adapter is connected, press the Power button on the rear of the
AirStation.
5 If using a wired LAN, connect the AirStation LAN port and computer using a LAN cable.
If using a wireless LAN, connect the computer to the wireless LAN as described in Chapter 3.
6 Once your computer has booted, the AirStation’s LEDs should be lit as described below:
Wireless On or blinking.
Internet access On.
Router On.
Buffalo White light on.
LAN On or blinking.
Internet On or blinking.
Note:
If the router LED is not lit, hold down the mode button for about 3 seconds to switch to router mode.
16
7 Launch a web browser. If the home screen is displayed, setup is complete.
If username and password fields are displayed, enter “admin” for the username and “password” for the password,
then click [Log In]. Step through the wizard to complete setup.
You’ve completed the initial setup of your AirStation.
Opening Settings
To configure the AirStation, log in to Settings as shown below.
1 Launch a web browser.
2 Enter the AirStation’s LAN-side IP address in the address field and press the Enter key.
Note:
• The AirStation’s default LAN-side IP address depends on the mode.
• In router mode: 192.168.11.1
• In access point mode: 192.168.11.100
• In Wireless bridge mode: 192.168.11.100
• If you changed the IP address of the AirStation, then use the new IP address.
3 Enter “admin” for the username and “password”for the password, then click [Log In].
Note:
If you forget your password, hold down the reset button to initialize all settings. Note that all other settings will also
revert to their default values.
17
4 This is the configuration interface, where most AirStation settings can be configured.
Connect Your Wireless Devices
For each wireless device that you want to connect to the network, use the device’s built-in software to search for
available networks. Find your SSID (the name of your wireless network) on the list of detected networks and select it.
Enter the passphrase for the network and you’ll be connected. Repeat for any additional wireless client devices that you
want to connect.
18
Chapter 2 - Settings
Settings lets you change advanced settings for the AirStation.
Easy Admin
Home
When you first open Settings, the Easy Admin page is shown. From this page you can easily configure common settings.
The examples below assume the AirStation is in router mode.
ParameterMeaning
WirelessDisplays current wireless status. Click the panel to configure wireless settings.
AOSS/WPSDisplays current AOSS/WPS status. Click the panel to run AOSS/WPS.
USB Storage
Guest Account
QoS
Web Filtering and
Parental Controls
Device Settings
Advanced SettingsClick the panel to configure advanced settings.
Displays the status of USB storage connected to this product. Click the panel to
configure USB storage settings.
Displays current guest account status. Click the slider to turn guest account on or off.
Click the panel to configure guest account settings.
Displays current QoS status. Click the slider to turn QoS on or off. Click the panel to
configure priority control QoS.
Displays current content filter status. Click the slider to turn web filtering and parental
controls on or off. Click the panel to configure web filtering and parental controls.
Displays the number of devices connected to the network. Click the panel to check each
devices status.
19
Wireless
Configure basic wireless settings. This mode is available in router and access point mode only.
ParameterMeaning
2.4 GHz (11n/g/b)
5 GHz (11ac/n/a)
SSID 1Each SSID may contain up to 32 alphanumeric characters.
Encryption
Encryption Key
Channel
Bandwidth
You may enable or disable either wireless frequency range independently. If both
wireless radios are disabled, the AirStation will not communicate wirelessly.
The following types of encryption are available:
WPA2-PSK AES
WPA2 authentication with AES encryption is the best system available. Highly
recommended if all your wireless clients support it.
WPA-PSK AES
WPA authentication with AES encryption is an older system, but still secure.
WPA/WPA2-mixed PSK TKIP+AES
For maximum compatibility, this system allows any combination of WPA, WPA2, TKIP, and
AES. This encryption system works with most older clients but is not very secure.
No Encryption
No encryption means that anyone can log in to your wireless network, snoop on your
wireless traffic, and use your bandwidth. Not recommended for most users.
The encryption key is like the “password” for your wireless network. It may contain 8 to
63 case-sensitive alphanumeric characters (ASCII) or 64 hexadecimal characters (0-9 and
a-f, not case-sensitive).
For best results, select [Auto Channel]. The AirStation will seek and use the clearest
channel automatically. Alternately, you may choose a wireless channel manually.
In rural areas with little wireless traffic, a larger bandwidth setting may improve wireless
performance significantly. However, if you are in an urban area with much wireless traffic
and interference, the default bandwidth is recommended.
20
AOSS/WPS
The following window appears when you click the panel. Click [OK] to start AOSS/WPS.
USB Storage
Configure USB storage settings.
ParameterMeaning
Attached DriveThe names of USB devices connected to this product.
File SharingEnable or disable file sharing.
BitTorrentEnable or disable BitTorrent.
DLNAEnable or disable the media server.
WebAccessEnable or disable WebAccess.
BuffaloNAS.com Name
BuffaloNAS.com StatusIf the status shows [Registration failure], check your BuffaloNAS.com settings.
Username
Password
This name may contain 3 to 20 alphanumeric characters, hyphens (-) and underscores
(_). The AirStation will be registered by this name at BuffaloNAS.com.
The WebAccess username may contain up to 20 alphanumeric characters, hyphens (-),
underscores (_) and periods (.). Don’t use a symbol as the first character.
The WebAccess password may contain up to 20 alphanumeric characters, hyphens (-),
underscores (_) and periods (.). It should not be blank. Don’t use a symbol as the first
character.
21
Guest Account
Configure guest account settings. This mode is available in router and access point mode only.
ParameterMeaning
SSIDThe SSID for the guest account may contain up to 32 alphanumeric characters.
EncryptionSelect an encryption mode for the guest account.
Permitted Access TimeThis is the amount of time that guests will be permitted to access the Internet.
QoS
Configure QoS settings. This mode is available in router mode only.
ParameterMeaning
EnableEnable or disable QoS.
22
ParameterMeaning
Select a policy
Traffic Monitor
Select a policy for communication. Network bandwidth will be optimized for the
selected item.
You can check each item’s communication status.
: Priority
: Upload speed
: Download speed
Web Filtering and Parental Controls
Configure web filtering and parental controls. This mode is available in router mode only.
ParameterMeaning
Block Malicious SiteBlocks malware, phishing, and scam sites.
Block Malicious and
Adult Sites
Block Malicious, Adult,
and Other Non-Family
Friendly Sites
I agree to Norton’s
Terms of Service
Norton ConnectSafe must be activated by customer. Use of Norton ConnectSafe is subject to the Terms of Service found
at https://dns.norton.com/dnsweb/terms.do
.
Blocks malware, phishing, and sites that contain sexually explicit content.
Blocks malware, phishing, and scam sites, sites that contain sexually explicit material,
mature content, abortion, alcohol, crime, cult, drugs, gambling, hate, sexual orientation,
suicide, tobacco, and violence.
Parental controls are provided by Symantec Corporation. To enable, you must accept the
terms of service.
23
Device Settings
Check the status of each device connected to the network. This mode is available in router mode only.
ParameterMeaning
Displays the IP address of each device connected to this product.
Displays uploading and downloading speed of each device connected to this product.
Displays the devices connected to the AirStation.
Click the appropriate icon to open each device’s settings.
Click the icon to send a Wake-on-LAN packet to the device.
24
Advanced Settings
Internet
Configure the WAN-side port (“Internet port”).
Internet -> Internet (Router Mode Only)
ParameterMeaning
Method of Acquiring IP
Address
Default GatewayConfigure an IP address for the default gateway.
DNS Name Server
Address
Internet MAC Address
MTU Size of Internet
Port
Specify how the WAN-side IP address is obtained.
Specify an IP address for the DNS server.
You may use the default MAC address or specify one manually.
Note:
Configuring an improper MAC address may make the AirStation unusable. Do not
change the MAC address unless you know what you’re doing!
Configure the MTU value of the Internet port. Values of 578 to 1500 bytes may be
entered.
25
PPPoE
Configure PPPoE settings.
Internet -> PPPoE (Router Mode Only)
ParameterMeaning
Default PPPoE
Connection
IP Unnumbered PPPoE
Connection
PPPoE Connection ListEdit PPPoE destination. You can register up to 5 sessions.
Edit Connection ListClick this button to edit destination settings.
If you have registered multiple connection destinations in the [PPPoE Connection List],
connection destinations selected here have priority.
Select the destination from the [PPPoE Connection List] which is used when [Use IP
Unnumbered] is chosen for the method of acquiring IP address.
26
This is displayed when [Edit Connection List] is clicked.
Name of Connection
Enter the name to identify the connected destination. You may enter up to 32
alphanumerical characters and symbols.
Username
Enter the username specified by your ISP for PPPoE certification. You may enter up to 64
alphanumerical characters and symbols.
Password
Enter the password specified by your ISP for PPPoE certification. You may enter up to 64
alphanumerical characters and symbols.
Service Name
Fill in this field only if your ISP specifies a service name. Leave blank otherwise. You may
enter up to 64 alphanumerical characters and symbols.
Connection Type
PPPoE Connection
Preferred ConnectionsDisplays information you have set regarding to the connection destination route.
Edit Preferred
Connections
Preferred PPPoE
Connection
Specifies the timing for the AirStation to connect to your provider.
Automatic Disconnection
Set time to disconnect after communication is stopped when the connection method is
set to [Connection on Demand] or [Manual]. You can enter up to 1440 minutes.
Authentication
Configure an authentication method with a provider.
MTU Size
Configure the MTU size for PPPoE. Values of 578 to 1492 bytes may be entered.
MRU Size
Configure MRU (maximum receive unit) for PPPoE. Values of 578 to 1492 may be
entered.
Keepalive
If keepalive is enabled, the AirStation will issue an LCP echo request once a minute in
order to maintain the connection with the PPPoE. If the server does not respond for
more than 6 minutes, the line is recognized as disconnected and the AirStation will
terminate the connection. Disabled by default.
Click to edit the connection destination route settings.
Click [Edit Preferred Connections] to display.
Name
The destination to connect by PPPoE if [Destination Address] and [Source Address]
match. Select the destination registered to the PPPoE Connection List.
Destination Address
When communicating to this address, the AirStation will communicate with [Name].
Source Address
When communicating from this address, the AirStation will communicate with [Name].
27
Dynamic DNS
Configure dynamic DNS settings. Many settings are only available when the appropriate dynamic DNS service is
enabled.
Internet -> Dynamic DNS (Router Mode Only)
ParameterMeaning
Dynamic DNS ServiceSelect a provider (DynDNS or TZO) for dynamic DNS.
Username
Password
Hostname
Email Address
TZO Key
Domain Name
IP Address Update
Period
Internet-side IP Address
Domain Name
StatusDisplay the status of the dynamic DNS service.
Enter the dynamic DNS username. You may enter up to 64 alphanumerical characters
and symbols.
Enter the dynamic DNS password. You may enter up to 64 alphanumerical characters
and symbols.
Enter the dynamic DNS hostname. You may enter up to 255 alphanumerical characters,
hyphens, and periods.
Enter the email address which is registered to the dynamic DNS service. You may enter
up to 64 alphanumerical characters and symbols.
Enter the TZO Key which is registered to the dynamic DNS service. You may enter up to
64 alphanumerical characters and symbols.
Enter the domain name which is registered to the dynamic DNS service. You may enter
up to 255 alphanumerical characters, hyphens, and periods.
Specifies the period to notify the dynamic DNS service provider of the current IP
address. For DynDNS, set it between 0 and 35 days. For TZO, set it between 0 and 99
days. If 0 (zero) days is set, no periodic update is performed.
The WAN-side IP address of the AirStation’s Internet port. This address is sent to the
dynamic DNS service provider.
The domain name assigned by the dynamic DNS service provider. The AirStation can be
accessed from the Internet using this domain name.
28
PPTP
Configure the VPN server.
Internet -> PPTP (Router Mode Only)
ParameterMeaning
PPTP ServerEnable to use a PPTP server.
Authentication TypeSelect the authentication method for PPTP connection.
Server IP AddressSelect the server IP address.
Client IP AddressSelect the IP address range.
DNS Server IP AddressChoose the IP address for the DNS server.
WINS Server IP AddressChoose the IP address for the WINS server.
MTU/MRU Value
Edit PPTP User ListClick to edit user information.
Add New user
Advanced Settings
PPTP User ListDisplays the PPTP connection user information.
Configure MTU (maximum transmission unit) / MRU (maximum receive unit) between
578 and 1500 which is used during transmission on PPTP.
Click [Edit PPTP User List] to display.
Username
Enter the username to connect to the PPTP server. You may enter up to 16
alphanumerical characters and symbols.
Password
Enter the password to connect to the PPTP server. You may enter up to 16
alphanumerical characters and symbols.
Method of Acquiring IP Address
Select the method to be used to assign the IP address is assigned to the PPTP client.
29
NAT
Configure network address translation settings. This enables LAN-side devices to communicate with the Internet.
Internet -> NAT (Router Mode Only)
ParameterMeaning
Address TranslationEnable to use network address translation.
LAN
Configure LAN-side and DHCP server settings.
LAN -> LAN
ParameterMeaning
LAN-side IP Address
DHCP ServerEnable or disable the DHCP server, which assigns LAN-side IP addresses automatically.
DHCP IP Address Pool
LAN-side IP Address (For
IP Unnumbered)
Advanced SettingsCheck [Display] to display DHCP server advanced settings options.
Lease Period
By default, the LAN-side IP address is 192.168.11.1 with subnet mask 255.255.255.0. You
may change it here.
Configure the range of IP addresses to be assigned by the DHCP server and IP addresses
to be excluded from that range. Values from 1-256 may be entered.
Set an IP unnumbered LAN-side IP address.
Note:
A PC with a normal LAN-side IP address and a PC with an IP unnumbered IP address
cannot communicate each other.
Set the effective period of an IP address assigned by the DHCP server. Up to 999 hours
may be entered.
30
Loading...
+ 77 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
