SERVICE BEFORE YOUR

PROVIDER’S CALLER DISPLAY

DISPLAY THIS

Synergy 2150

Digital cordless telephone and answering machine featuring DECT

YOU MUST SUBSCRIBE TO YOUR NETWORK

SYNERGY 2150 WILL

INFORMATION

User Guide

This equipment is not designed for making emergency telephone calls when the power fails.

Alternative arrangements should be made for access to emergency services.

This product is intended for connection to analogue public switched telephone networks

and private switchboards in the United Kingdom.

Please open this page for an ‘at a glance’ guide to your Synergy 2150.

Please open this page for a further ‘at a glance’guide to your Synergy 2150.

At a glance

Del

Scrolls up through the display.

Deletes numbers on the display before dialling.

Talk

Press to make and answer calls or to use in handsfree mode.

Power/Secrecy

Switches the handset on and off.

During a call, mutes your voice so your caller cannot hear you, and you can talk privately to someone else in the room.

Locks the keypad so you cannot press the buttons accidentally.

Synergy 2150

Options

Opens the set up menu.

Confirms setting you want.

Int

Lets you make an internal call or transfer a call.

Phonebook

Scrolls down through the display.

Displays the directory.

End

Press to end a call. Press to step back through options menu.

Keypad

LNR

Press to redial the last number called.

Inserts a Pause when storing a number in the memory.

Recall

Used to access some BT Select Services and when using your phone with a switchboard.

Base

Charging light

Comes on when the handset batteries are being charged and goes off when they are fully charged.

Synergy 2150

Charging

In use light*

Comes on when the line is in use. Flashes when a message has been left or a call has been logged.

*Will also flash in registration mode.

Display symbols

1. Indicates programming mode.

2. TAM on/off/messages (when flashing).

3. External line is in use.

4. Handset in use.

5. Indicates an internal call or when

transferring a call to another handset.

6. Secrecy feature is on. Your caller cannot hear you.

7. Battery status indicator.

8. Confirms active signal between

handset and base.

9. Handset loudspeaker.

10. Handset number.

11. A new call has been received.

In Use

Power light

Comes on while the

Power

mains power is switched on. Flashes to indicate Day/Time needs setting.

Page

Press to page the handset from the base.

INT

456 8

9 10 117

Int

645

Options

LNR

Del

Synergy 2150

–



MENU STRUCTURE

Call Screen

Only when TAM is answering

Play

Message

Message screen

Delete old

Memo

Caller ID

Phone book

View

Delete old

VIP

New entry

Save

Delete

VIP 1

VIP 2

Name:

Tel. number:

Change entry

Delete entry

Dial entry

Delete all

Notepad View

Save

HS setting Ext ringer

Int ringer

Key tone

Melody

Volume

Melody

Volume

Off

Language Deutsch

English

Francais

Dial mode

Flash time

Base ringer

Base setting

TAM settings

Waiting…

Base PIN:

ee next page

Italiano

Espanol

Select base Best base

Base 1-4

Show base Base name

Set new name

Off

Base 1-4

HS priority

Change PIN New PIN

PSTN prefix PSTN prefix

Call barring

Registration Base 1-4

Remove HS Handset 1-5

Network

Tone

Pulse

100MS

Others

Melody

Volume

No priority

Handset 1-5

number

PSTN

PBX

MENU STRUCTURE FOR THE ANSWERING MACHINE

Tam setting Speaker

Day/Time

TAM mode Ans/Record

Announce Ans/Record

Ring counts

Verbal

Remote PIN PIN: 0000

Volume 0123

Day: 1234567

Time: 00:00

Answer only

*TAM off

Answer only

246

off

Answering machine features

Play

Change

Delete

Play

Change

Delete

Handsfree

Skip backward

Delete (messages)

Play

Skip forward

Stop

Record memo

In this guide

At a glance 1 Key features 5 Introduction 7

Unpacking your Synergy 2150 8 For your records 8

Safety instructions 9 Setting up 10 Using your Synergy 2150 13

Making and receiving calls 13 Using the notepad 17 Using the phonebook 18

Using your Synergy 2150 answering machine 21

Message playback 26 Remote access 29 Remote access quick guide 30

BT Select Services 31

Using Caller display 31 Using VIP feature 33 Call waiting 33 Other services 34

Optional settings 35 Base station settings 37 Using additional handsets 41 Operating with additional

base stations 44 Connecting to a switchboard 45 Maintenance 47 Help 48 Technical information 50 Technical specification 51 Index 52

Hints and tips boxes

In this user guide, we’ve included helpful tips and

useful notes. They are shown in a white box like this.

Key features

Up to five handsets work from one base

You can make internal calls

between handsets, transfer an external caller to another handset and hold three way calls between two handsets and an external caller.

Make internal and external calls at the same time

With the maximum of five

handsets registered to the base station, your Synergy 2150 lets you use all of them together. One handset can be making an external call while

KEY FEATURES

the other four handsets are being used to make separate internal calls.

Enhanced call clarity

Highly advanced digital

technology (DECT) ensures much clearer calls than the older style phones.

20 name and number directory

Store up to 20 of your most

important or frequently dialled names and numbers in the phonebook. It’s then easy to display and dial numbers in the phonebook. Each handset has an individual directory.

Excellent handset range

Under ideal conditions you

can use your Synergy 2150 handset at up to 300 metres from the base station outside, or up to 50 metres inside.

Notepad

Saving you the need of a pen and paper, you can simply note down a phone number on your Synergy 2150 handset’s memory during a call. You can then look the number up later or add it to the phonebook.

minute recording capacity

Offers the benefits of digital recording.

Caller Display & Calls Log

Let’s you know who’s calling you before answering the telephone, allowing you to decide whether or not to answer the call.

Handsfree via handset

This function lets you keep your hands free, for example, to take notes. It also enables others in the same room to hear and join in the call.

Remote access

You can call your Synergy 2150 from another TouchTone telephone to switch it on or play back your messages.

Last 5 number redial

Display and redial any of the last five numbers called from your handset.

Keypad guard

This prevents accidental dialling while carrying the handset around.

KEY FEATURES

Introduction

Int

978

645

312

Options

LNR

Del

Synergy 2150

–



Your Synergy 2150 has been designed for ease of use and made to the high standards set by BT.

Please read the instructions carefully before use and retain this user guide for future reference.

DECT

By purchasing the Synergy 2150 you now own a product which combines the advantages of cordless operation with the performance of a high quality corded telephone. It complies with the Digitally Enhanced Cordless Telecommunications (DECT) standard and offers unparalleled quality and features.

Building up a phone system

INTRODUCTION

You can use up to 5 handsets with your Synergy 2150 base station without the need for additional wiring.

Synergy 2150

Del

Options

Int



–

312

645

978

LNR

Synergy 2150

Del

Options

Int



–

312

645

978

LNR

Synergy 2150

Charging

In Use

Power

Page

This user guide applies to both single and multiple handset systems. The internal call functions described in this guide apply only to Synergy 2150 base stations with more than one handset connected.

Important

If you wear a hearing aid, please

note that the Synergy 2150 works by

sending radio signals between the base

station and the handset. These signals

can interfere with hearing aids,

causing a humming noise.

Synergy 2150

Del

Options

Int



–

312

645

978

LNR

Synergy 2150

Del

Options

Int



–

312

645

978

LNR

Unpacking your Synergy 2150

If anything is missing, please contact your place of purchase immediately.

For your records

Date of purchase:

Synergy 2150

●

handset.

Synergy 2150

●

base station.

Handset

●

Battery pack.

Plug mounted,

●

13 amp mains adaptor.

Telephone

●

line cord

Synergy 2150

Del

Options

Int



–

312

645

978

LNR

Synergy 2150

Charging

In Use

Power

Page

Place of purchase:

Serial number (on the underside of telephone base):

Purchase price:

For warranty purposes, proof of purchase is required, so please keep your receipt.

INTRODUCTION

Enter your Base Station PIN here

See pages 12 and 38 for more information.

Enter your remote access security PIN code here.

See page 26 for more information.

Belt clip

●

Safety instructions

Use only the approved battery pack supplied. Spare

batteries – Item Code: 871996 are available from BT Shops and the Synergy Helpline 0845 602 1041.

Do not try to use any other power supply except the one provided, otherwise you may permanently damage your Synergy 2150. It may also invalidate approval of this apparatus. To get a replacement Synergy 2150 base station power supply unit – Item Code 872073 – contact the Synergy Helpline 0845 602 1041.

There is a slight chance your phone could be damaged by

SAFETY INSTRUCTIONS

recommend that you unplug your Synergy 2150 from the mains power and telephone socket during storms.

Equally, the handset as well as any additional chargers you purchase can also become warm during charging. We advise against placing these products on antique, veneered or wooden surfaces as damage may occur.

expose the equipment or batteries to fire and water.

an electrical storm. We

The Synergy 2150 will produce a certain amount of heat during operation.

Do not use the Synergy 2150 in damp, humid conditions such as bathrooms. Do not

Do not dispose of used batteries with general household rubbish and do not

burn them.

Do not use the handsets in places where there are explosive hazards.

If you wear a hearing aid, please note that the Synergy

2150 works by sending radio signals between the base station and handset. These signals can interfere with hearing aids, causing a humming noise.

We advise that this product should not be used near emergency intensive care medical equipment and should not be used by individuals with pacemakers.

Synergy 2150 can interfere with other electrical equipment, e.g. answering machines, TV and radio sets, clock radio/alarms and computers if placed too close. It is recommended that you place your Synergy 2150 at least one metre away from such appliances to minimise any risk of interference.

Make sure you connect the power and telephone lines to the correct sockets in the base station.

Clean the handset and base station with a damp (not wet) cloth or antistatic wipe. Never use a dry cloth as this may cause a static shock. Never spray cleaning fluid directly onto the telephone.

Setting up

Follow these steps to set up your Synergy 2150 ready for use.

Plan the location of your Synergy 2150

Your Synergy 2150 works by sending and receiving radio signals between the base station and the handset.

The strength of the signal can depend on where you site the base station. Generally, the higher the base station is located the better. An upstairs room is ideal.

The following points should be considered:

• It should be within 3 metres of a power socket and phone socket otherwise extension cables will be required.

• Try to avoid locations near metallic obstructions or electrical appliances, such as TV sets, fridges, computers, fluorescent lights, radiators, metal pipes and metal window frames.

Connect the power cable

Plug the power cable into the power socket on your Synergy base station.

Plug the adaptor into the mains power supply and switch on. The power light comes on and starts to flash. This will continue flashing until the Day & Time are set (see page 22).

Install the rechargeable

battery in the handset

SETTING UP

Please note

The Synergy 2150 has a range of up to 300 metres outdoors and up to 50 metres indoors. It is possible that

the range may be affected by being near water (e.g. large ponds, lakes and the sea) as well as large metal

objects (e.g. radiators, metal partition

walls and steel girders).

The Synergy 2150 uses a nickel metal hydride (NiMH) battery pack supplied. Take care to connect the battery as shown and replace the battery cover.

Charge the handset battery

0-50%

(flashing)

50 -100%

100%

for at least 16 hours

Before you use your Synergy 2150 for the first time, it is important to have the handset battery fully charged. We recommend that you leave the Synergy 2150 on charge for at least 16 hours.

Place the handset on the base. The red charging light comes on. The handset should come pre-registered to the base station as HS1 and this is shown in the top right corner of the display.

The battery symbol is also shown. It flashes during charging. Once the handset is fully charged, the display shows a full battery symbol.

Battery levels

SETTING UP

Battery low warning.

If the handset battery symbol is empty and flashing, and you hear a warning beep every 10 seconds, you will need to recharge your handset before you can use it.

Battery performance

To keep your battery in the best condition, leave the handset off the base station for a few hours at a time (after the initial 16 hour charge).

After charging your Synergy handset for the first time, subsequent charging time for the battery is approximately 4-5 hours. Battery and case may become warm during charging. This is normal and not dangerous.

Note: Once the handset is fully

charged the red charging light will go off.

Under ideal conditions, the handset battery should give about 12 hours talktime (7 hours in handsfree mode) or 150 hours standby on a single charge.

Please note, however, that a new NiMH battery does not reach its full capacity until it has been in normal use for several days.

Please note that while the NiMH rechargeable battery can be expected to give years of service they do not last forever.

Their actual lifespan depends on how heavily they are used but over time, their capacity to recharge will begin to diminish and they will eventually need replacing.

Connect the telephone line cord

Synergy 2150

Charging

In Use

Power

Page

Int

978

645

312

+ –

Options

LNR

Del

Synergy 2150

to the Synergy 2150 base station

Plug the line cord into the line socket on your Synergy base station.

Connect the telephone line cord

Pre-set PINs

Your Synergy 2150 comes with a pre-set PIN which you will need to use to perform various functions on your phone.

Base station PIN is 0000 – used when adjusting base station settings and registration of new handsets.

Customer Helpline

0845 602 1041

SETTING UP

If you do not have modern phone sockets, call Freefone 0800 800 150 and ask for a BT engineer to come and fit the correct type. This is a chargeable service.

Your Synergy is now ready for use.

Using your Synergy 2150

Del

telephone

To switch your handset ON and OFF

USING YOUR PHONE

To lock and unlock the keypad

Press buttons in the order shown

Press and hold the POWER button until the display goes blank. The handset is now off.

Press the POWER button again. You hear two beeps. The display flashes Searching and then shows the standby screen.

This prevents you from accidentally operating the handset when you are carrying it around.

Press and release the

POWER button. Display shows

Keypad-lock.

Making and receiving calls

To make a call

Press the green TALK button. Display shows . You hear the dial tone.

DIAL

Enter the number you want and it is dialled.

To preview the number before you call.

Enter the number you want. It is shown on the screen but not dialled. If you make a mistake, you can change the number by pressing the DEL button to delete individual digits.

Press the TALK button to dial the number.

Press the POWER button again to unlock the keypad.

Please note

It is not possible to make emergency

calls when the keypad lock is on.

To end a call

Press the red END button.

Place the handset back on the base.

Call monitoring

Del

Options

Del

To receive a call

If you would like to listen to your caller on the handset but allow others to hear the call, you could turn the base loudspeaker speaker on.

Make your call and ensure that the L is displayed on the handset.

Display will flash

Loudspeaker.

Press the OPTIONS button to confirm.

Display will show Volume 0 1 2 3. 0 is off, 3 is loud.

Select the volume. (Settings always start at 2.)

Press the OPTIONS button to confirm.

Caller display

The Synergy 2150 can let you know who’s calling before you answer the telephone.

With BT’s Caller Display service, your Synergy base station receives caller information which is transmitted over the BT network, for more information, see page 31.

When the phone rings: the screen shows (without Caller Display).

Press the TALK button to answer the call

If the handset is on the base, simply pick it up and talk.

To use handsfree

This function lets you keep your hands free, for example, to take notes, or to dial a number. It also enables others in the same room to hear and join in the call.

Press to get a line. When making your call the

L is displayed on the handset. This has then established start of dialling.

Press and hold for 1 second. The handset loudspeaker

symbol will be displayed. You will now hear ringing or your caller on the handset speaker.

To change the volume. Display will show Volume

123. The number flashing is the current setting

Use to adjust the level, 1 is quiet, 3 is loud.

To confirm.

External

SETTING UP

LNR

Del

Options

To switch off:

LNR

Del

Press and hold for 1 second.

Secrecy

To adjust the earpiece volume

USING YOUR PHONE

The loudspeaker symbol will disappear from the display.

Press to end the call.

During a call you can adjust the volume of the handset receiver.

Press the UP and DOWN arrow buttons.

Display will show VOLUME 1 2 3.

The number flashing is the current setting.

Use the UP and DOWN arrow buttons until the display flashes at the desired volume level.

To confirm level.

This lets you talk to someone else close by without your caller hearing the conversation.

During your call: Press the SECRECY button.

Display shows

Mute

Your caller cannot hear you. To talk to your caller again.

To redial the last number

The last number called is displayed.

To dial the number.

To redial one of the last 5 numbers

The last number called is displayed.

and .

Please note

Once you have adjusted the earpiece

volume, to use other functions during

a call you must be out of earpiece

volume control.

The handset automatically times out

after approx 8 seconds, or press the

OPTIONS button to confirm level.

To scroll through the last 5 numbers. (Or keep pressing the REDIAL button).

To dial the number displayed.

Del

Options

Del

Options

Dialling mode

Del

Options

Del

Options

Del

Go to Tone

Your Synergy 2150 is preset to TONE dialling which most modern exchanges use. On some older exchanges or PBX’s it may be necessary to change the dialling mode to PULSE.

Until the display flashes BASE SETTING.

Enter the 4-digit base station

PIN PIN. Original setting 0000.

Until the display flashes DIAL MODE.

Until the display flashes PULSE.

To confirm.

If you are in the PULSE dialling mode then certain services accessed by tone dialling are not available.

During the call you can change to TONE by pressing the OPTIONS button.

Use the UP and DOWN arrows to scroll to the Go to Tone command and press the OPTIONS button.

Operation of your keypad after this will now be in TONE mode. When the call is completed you will revert to PULSE dialling.

Go back

If during a call you have selected a function using the

OPTIONS button, you can

revert back to a normal display without losing the caller if you select the option Go back.

USING YOUR PHONE

Use the UP and DOWN arrows to scroll to the Go Back command and press the OPTIONS button to confirm.

Options

Del

Options

Del

To use the recall button

Using the notepad

This is used when connected to certain switchboards and for some BT Select Services or those services available via your network provider. Refer to page 31 for more details.

Time break recall (TBR) is the method by which the exchange/PBX can be contacted and this is operated by the R (recall) button on the handset.

Your Synergy 2150 recall period is normally set to 100mS under the base setting menu Flash time. It should not normally be necessary to alter this value

USING YOUR PHONE

for use in the UK.

To exit the options menu at any time,

press the END button until the

display returns to standby.

You can store a telephone number in your Synergy 2150 notepad memory during a conversation.

To store a notepad number

Press the OPTIONS button. Until the display flashes

Notepad. The current notepad number

(if any) will be displayed.

KEYPAD

Enter the number you want to store. This will overwrite any existing number.

To save the number.

To view and dial a notepad number

Press the OPTIONS button. Until the display flashes

Notepad

Press the OPTIONS button. Until the display flashes

View

The notepad number is displayed.

To dial the number, if required.

To store a notepad number in

Options

Del

Options

Del

the phonebook

Using the phonebook

You must include a name to go with the number.

Until the display flashes

Notepad

Until the display flashes

Save

Display shows

ABC Use the keypad to enter the

Name:

name you want. The number is stored in the

phonebook.

Using the keypad to enter a name.

For example, to enter the name ANNE:

2ABC Press once to enter A.

Each time you have entered a letter wait for the cursor to move to the next space.

6MNO Press twice to enter N. 6MNO Press twice to enter N.

3DEF Press twice to enter E.

1 To insert a space. 0 To insert ‘&’.

You can store up to 20 of your most important or frequently dialled numbers in your Synergy’s phonebook.

Stored numbers can be up to 25 digits long and each one must have a name allocated to it. The maximum number of characters in the name field is 12.

To ensure that the Caller Display facility operates correctly you should always enter the full telephone number into the phone book, including the area code, for example 0845602641.

All entries in the phonebook are listed in alphabetical order.

To exit the options menu at any time,

press the button until the display

returns to standby.

USING YOUR PHONE

If you make a mistake, press the DEL button to delete the previous character or press the END button.

LNR

Options

Del

Options

Del

Options

Del

Options

To store a name and number in

Options

Del

the phonebook

To enter a pause in a stored number

Press the OPTIONS button. Until the display shows

Phone book

Until the display shows

New entry

Display shows

ABC Use the keypad to enter the

name you want.

For example, to enter the name ANNE:

2ABC Press once to enter A.

Each time you have entered a letter wait for the cursor to move to the next space.

6MNO Press three times to enter N. 6MNO Press twice to enter N.

3DEF Press twice to enter E.

USING YOUR PHONE

1 To insert a space. 0 To insert ‘&’.

Name:

When storing the number, press the REDIAL/PAUSE button at the point where you want to enter the Pause.

To edit an entry in the phonebook

Press the OPTIONS button. Until the display shows

Phone book.

Until the display shows Change entry.

Until the display shows the entry you want to change.

The name flashes.

ABC If required, enter a new name

to change it.

KEYPAD

If you make a mistake, press the DEL button to delete the previous character.

Display shows Tel. number:.

Enter the telephone number you want to store.

To confirm. You can now store another entry.

KEYPAD

To confirm the name. Display shows the phone number.

If required, enter a new number to change it.

To confirm the change.

Options

Del

Options

Del

Options

Del

Options

Del

Options

Del

To dial a number stored in the

Del

phonebook

To delete all entries from the phonebook

The first entry is displayed. Press to scroll through the

entries until the one you want is displayed.

To dial the number.

To delete an entry from the phonebook

Press the OPTIONS button. Until the display flashes

Phone book.

Until the display shows Delete entry.

Until the entry you want to delete flashes.

To confirm deletion.

Press the OPTIONS button. Until the display flashes

Phone book.

Until the display flashes

Delete all. Delete all?.

To confirm deletion.

To exit without deleting.

USING YOUR PHONE

Using your Synergy 2150

Options

Del

Options

answering machine

As soon as the base station is connected and fully charged, your answering machine is ready for use.

It comes with a pre-recorded answer/ record announcement: “Hello, your call

cannot be taken at the moment, so please leave your message after the tone”. You

can use this announcement or record one of your own (see page 24).

As well as recording incoming messages your Synergy 2150 can record memos for other users (see page 28) and allows you to skip through or delete your messages.

You can access your messages from any Synergy 2100 Additional handset or any external TouchTone telephone.

USING YOUR ANSWER MACHINE

You will need to set the day and time so that you will know when each message was received.

To set the base speaker volume

Press to open the main menu. Press until the display flashes

TAM setting. Press the OPTIONS button

to confirm. Waiting will flash for one second and then Speaker will flash.

Press to confirm Speaker Use to adjust the volume.

0 is off, 3 is loud. To confirm. You will then

hear the confirmation beeps.

Options

Del

Options

Please note

It is important to set the Day and

Time in preparation for using your

answering machine.

Please note

If your Synergy 2150 is disconnected

from the power, for example during

a power cut, when power is restored

the display will show Searching...

followed by the idle screen and the

green power light on the base

will flash.

You will not have lost your messages

but you will need to set the day and

time again.

Once this is completed the green

power light on the base will no

longer flash.

To set the day and time

Press to open the main menu. Press the UP and DOWN

arrows until the display flashes TAM Settings.

Press the OPTIONS button to confirm.

Press the UP and DOWN arrows until the display flashes Day/Time.

Press the OPTIONS button to confirm.

Display will show

Day: 1234567 Time: 00:00

Use to scroll through 1 Mon, 2 Tues, 3 Wed, 4 Thurs, 5 Fri, 6 Sat, 7 Sun or press the number on the keypad.

USING YOUR ANSWER MACHINE

Press the OPTIONS button to confirm.

Enter the time using the 24 hour clock. So for 14:52 type 1452 on the keypad.

Press the OPTIONS button to confirm.

You will then hear the confirmation beeps.

To select day/time prompts

Options

Del

Options

between messages

The day and time of a call is recorded when it is received. You can switch this on or off when you listen to your messages.

Press to open the main menu. Press until the display flashes

TAM setting. Press the OPTIONS button

to confirm. Waiting will flash for one second and then

Speaker will flash.

Answer only

Your Synergy 2150 will play a pre-recorded announcement but will not allow your caller to leave a message. However, you can record your own announcement if you wish.

Please note

An ✱beside one of the above

indicates which mode the answering

machine is currently in.

To switch the answering machine on/off and to set the answer mode

Press until Verbal is flashing.

To confirm. To select ON or OFF.

Your chosen option will flash. (✱indicates the current setting.)

USING YOUR ANSWER MACHINE

Press the OPTIONS button to confirm.

Setting the answer mode

Your Synergy 2150 has 2 answer modes.

Ans/record

Your Synergy 2150 has a pre-set announcement that allows your caller to leave a message, however, you can record your own announcement if you wish, see page 24.

Press to open the main menu. Press until the display flashes

TAM setting. Press the OPTIONS button

to confirm. Waiting will flash for one second and then Speaker will flash.

Press until the display flashes TAM mode.

Press to confirm. Press until your chosen

option flashes, ie:-

Ans/Record Ans Only Tam off.

Press to confirm. You will hear the confirmation beeps.

Please note

Indicates that the answering

machine is on.

Options

Del

To record your own announcement

Del

Options

Del

Options

Del Del

Options

Del

You can record an announcement of up to 3 minutes long to invite your caller to leave a message. A typical announcement for Ans/Record for example may be: “Hello, I cannot take

your call at the moment, so please leave a message after the tone”.

Press to open the main menu. Press until the display flashes

TAM setting. Press the OPTIONS button

to confirm. Waiting will flash for one second and then Speaker will flash.

Press until display flashes Announce.

Press the OPTIONS button to confirm.

To select Ans/record or Answer only.

Press the OPTIONS button to confirm.

Until change is displayed. Press the OPTIONS button.

You will then see Recording. You should record your message now.

Press to end recording.

Please note

If you are recording an announcement

using handsfree , you should make

the recording with the handset about 2 feet away from you for best results.

To delete an announcement

Press to open the main menu. Press until the display flashes

TAM setting. Press the OPTIONS button

to confirm. Waiting will flash for one second and then Speaker will flash.

Press until display flashes

Announce.

Press the OPTIONS button to confirm.

To select Ans/Record or

Answer only.

Press the OPTIONS button to confirm.

Until Delete is displayed. Display shows Delete?

Press to delete the announcement.

To exit and leave the current message saved.

USING YOUR ANSWER MACHINE

Your message will then play back automatically.

Press to return to the menu.

USING YOUR ANSWER MACHINE

Options

Del

Options

Del

Options

Please note

Deleting your own announcement

restores the original pre-recorded

message.

To adjust the number of rings before incoming calls are answered

You can select the number of rings from 2, 4 or 6 before incoming calls are answered.

Press to open the main menu. Press until the display flashes

TAM setting. Press the OPTIONS button

to confirm. Waiting will flash for one second and then Speaker will flash.

Until Ring counts is flashing.

Press the OPTIONS button to confirm.

Display shows Ring counts 2 4 6.

Until the number of rings you want is flashing.

Press to confirm.

Time saver

When the number of rings is set to 4, the Synergy 2150 will answer after 2 rings if new messages are left, and after 4 rings if there are no new messages. This is for use during remote access, see page 29,

To adjust the base speaker volume

When listening to your messages:

Press the

OPTIONS button

until display shows Volume

0 1 2 3

To select the volume. 0 is off, 1 is quiet and 3 is loud.

Press the OPTIONS button to confirm.

To turn the handset speaker on or off

When listening to your messages:

Press for 1 second. The indicates that the

loudspeaker is on.

If it is missing then the loudspeaker is off.

Del

Options

To adjust the handset speaker

Options

Del

Options

Del

volume

Memory full

When listening to your messages:

Display shows Volume123. To select the volume.

1 is quiet and 3 is loud. Press the OPTIONS button

to confirm.

To set your security PIN for remote access

Press the OPTIONS button. Until display flashes

TAM Setting.

Press the OPTIONS button to confirm.

Display will show Waiting for 1 second then Speaker will flash.

Until display flashes

Remote PIN.

Press the OPTIONS button to confirm.

Display shows PIN XXXX

(Your PIN.)

PIN Enter your new pin number.

Press the OPTIONS button to confirm.

Display flashes Remote PIN. Press to return to the menu.

For information on how to use remote access, see page 29.

Your Synergy 2150 has up to

minutes of recording time.

If a call arrives when the memory is full the display will show Memory full and the caller will hear that their message cannot be taken.

It is, therefore, advisable to delete your messages to create more space, see page 28.

Message playback

The following table provides a guide to the possible message indications you may see on your Synergy 2150 in certain situations.

For example, if you have new messages and the answering machine is on you will see the flashing in the display, New msg will be displayed on the LCD and the In Use light will flash on the base LED.

Answer Machine Message indications

Message

On/Off

status display LED

OFF

New

messages msg

Old

messages

New

messages msg

Old

messages

Icon

Flashing

Steady

No icon

LCD Base

New

Flashing

New Flashing

USING YOUR ANSWER MACHINE

Del

To play your messages

Options

Press the OPTIONS button. Until display flashes

Message. Press the OPTIONS button

to confirm. Waiting will be displayed

for one second and then:

This shows that message number one was recorded on Wednesday at 15.35 and is being played.

If you have selected Verbal on then you will hear the day and time of your messages.

Your messages will continue until all new messages have been played.

USING YOUR ANSWER MACHINE

New: 02 TOT:05 LSP:1

New is the number of new

messages received. TOT is the total number of

old and new messages. LSP is the current base

speaker setting. The loudspeaker icon

indicates that the handset loudspeaker is on.

Press the OPTIONS button The display flashes Play. Press the OPTIONS button

to confirm and play your messages.

01 Wed 15:35

To skip, play, pause and delete your messages

When listening to your messages use these buttons:

Press once to go to the start of the current message. Press twice to go back to the previous message.

Play/pause. During pause display will show Pause...

Skip to the next message. Delete the current message

on an individual basis. Record a memo. Stop.

To delete old messages

Del

Options

Del

Options

If you want to delete all of your messages:

Press the OPTIONS button. Display will flash

Message. Press the OPTIONS button

to confirm. Waiting will be displayed

for 1 second. Press the OPTIONS button. Display will flash Play. Until display flashes Delete

old. Press the OPTIONS button

to confirm. Display will show Delete

old?

To delete the messages.

To revert to the previous menu and not delete.

Press the OPTIONS button to confirm.

Display will flash Waiting. Press the OPTIONS button

to confirm. Display will flash Play. Until display flashes Memo. Press the OPTIONS button

to confirm. Recording... is displayed

and you will hear a long beep. You can now start recording your memo.

Press when you have finished recording.

To use Call Screening

You can let your Synergy 2150 answer an incoming call and hear the caller through the handset speaker. You can then decide whether to take the call.

Whilst the TAM is recording. Display shows Call Screen.

USING YOUR ANSWER MACHINE

To record a memo

You can record a memo up to 3 minutes long that can be played back as a normal message.

Press the OPTIONS button Display will flash

Message.

Press the OPTIONS button to confirm.

Display shows Screen. You will hear who is calling. To end screening.

Remote access

You can switch on and operate your answering machine from any other TouchTone telephone to play your messages and memos.

To keep your messages private, you will need to enter your 4-digit security PIN code before you can access your messages.

The pre-set security code is 0000 but it is advisable to change this, see page 26 to change your security code.

You can keep a record of the new number in the box printed in the front of this guide.

To turn answering machine on via remote access

Call your phone. After approx. 16 rings, the

telephone answer machine will answer and announce “Answer off ”.

Press the ✱button. You will be prompted to add

PIN your security code e.g. 0000.

You will hear “To play all messages, press 2”.

To switch on the answer machine in answer record mode, press the 8 button.

USING YOUR ANSWER MACHINE

Time Saver

If you have your ring count set to 4 rings, then you can tell if you have any new messages before the machine answers.

If the machine answers after 2 rings then you know you have new messages. If it gets to 3 rings, then you know there are no new messages and you can hang up, saving you the cost of a call.

To switch on the answer machine in answer only mode, press the 9 button.

–

Remote access quick guide

To listen to your messages remotely from an external telephone.

Call your answer machine and as you listen to the announcement press ✱.

When prompted, enter your remote access security PIN e.g. 0000.

If you incorrectly enter your security PIN three times you will be disconnected.

Press once to go to the start of the current message. Press twice to go back to the previous message.

Play/ pause. During pause display will show Pause...

Skip to the next message.

Delete the current message.

Record a memo or announcement.

Stop.

Turn the Synergy 2150 off.

USING YOUR ANSWER MACHINE

To select Memo.

To select Ans./record.

To select Answer only.

To select Ans./record.

To select Answer only.

BT Select Services

If you are connected to a digital exchange, you can subscribe to a range of BT Select Services. If you wish to subscribe to any of these services contact us on Freefone 0800 800 152 business, 150 residential, 8am to 6pm, Monday to Friday.

Using Caller Display

If you have subscribed to your network provider’s Caller Display service you will be able to see the caller’s number on the display (provided it is not withheld) prior to answering a call.

SELECT SERVICES

If you have not subscribed to Caller Display then please contact your network provider for details.

If a call is received and you have stored a name and number into your phonebook (see page 19) you will see both the name and number and your screen will look like this:

Please note

Caller Display information will

ONLY be saved if the call has NOT

been answered, or if the answering

machine has taken the call.

Caller Display information will not

be saved into the Call Log if the call

has been answered.

The following table provides a guide to the call indications you may see on your Synergy 2150.

For example, if you have a new call the

icon will be flashing on the display, new call will be displayed on the LCD (unless there are new messages when new msg is shown) and the In Use light will flash on the base LED.

Call indications

Call

status display LED

New calls Flashing New call Flashing

Icon

LCD Base

0876-42036523 John Brown

Old calls Steady

No calls

old or new

No icon

Please note

If there are both new messages and

new calls, New Msg will be shown

on the display.

Options

Del

Options

Del

Options

Please note

If someone has called several times

only the last day and time will be

recorded. The number of times the

caller has tried to contact you will be

shown on the right side of the screen.

Use to scroll through the calls.

Press to show the day and time of the call.

Up to 30 numbers can be stored in this way.

01 Call 04 04/02 0944

To view stored numbers

Press the OPTIONS button. Until display flashes

Caller ID.

Press the OPTIONS button to confirm.

Display will flash Waiting for 1 second and then View will flash.

Press the OPTIONS button to confirm.

The screen will show how many numbers have been stored.

NOTE: If no calls have been

received the screen will say Data Empty.

Please note

If a call is not answered, by the

answering machine or by a person,

the number will be stored in the

memory with the time and date of

the call.

To save a caller’s number into the phone book

When viewing your stored numbers:

To see the time and date of the call.

Display will flash Save. To confirm. Display will show Name:

and the telephone number.

ABC

Enter the caller’s name. To confirm. You will then

hear the confirmation beeps.

SELECT SERVICES

New 01 Total 01

The first caller will be displayed.

Del

Options

Del

Options

To delete old numbers

Del

Options

Until display flashes

Caller ID.

To confirm. Display will flash Waiting

for 1 second and then View will flash.

Until display flashes

Delete old.

To confirm. Display shows Delete old? To delete.

To cancel and return to the menu without deleting the numbers.

SELECT SERVICES

Using the VIP feature

This feature allows you to store two important numbers as VIPs. These could be, for example, your partner’s mobile number, a family or friend’s number.

To store a VIP number

Press the OPTIONS button. Press until Caller ID is

flashing. Press the OPTIONS button. Press until VIP is flashing. Press the OPTIONS button. Press until VIP 1 is flashing. Press the OPTIONS button.

123

Enter the telephone number. Follow exactly the same

procedure for VIP 2.

Call Waiting

If an incoming call arrives while you are already engaged on a telephone call, you will hear a soft beep every 5 seconds (this beep is not audible to the person you are speaking to).

Instead of the engaged tone, the second caller will hear an announcement to hold on as you are aware that there is a second call.

Used with Caller Display, when a VIP rings a different ring tone will be heard, alerting you that one of your VIPs is calling and their number will be displayed.

To use Call Waiting

Other services

You can answer the second call, without disconnecting your first caller, by pressing the CALL WAITING button. The first caller will be put on hold.

When you have spoken to the second caller you can return to the first caller by pressing the CALL WAITING button again. You can switch

back and forth between the two calls without disconnecting either if you wish.

If you wish to disconnect the first call press the END button after speaking to the first caller.

The handset will then ring. Press the TALK button again and continue with the second caller.

• Call my bill

• Call Barring

• Call Diversion

• Charge Advice

• Reminder Calls

• Three-way Calling

• Call Return 1471 For more information about these

Select Services, call BT on Freefone 0800 800 150 for residential or 152 for business. If you are not on the BT network, please ask your telecommunications supplier for information on their services.

SELECT SERVICES

The second caller will only be charged for their call from the moment you answer and not while they are waiting for your initial contact.

Optional Settings

Options

Del

Options

Del

Options

Del

Options

Del

Options

Del

Options

To adjust the handset ringer volume

optional settings

The volume levels range from 0-5 where 0 is off and

5 = maximum. The pre-set

level is 3. You can also set the handset

to ring at different volumes for external calls and internal calls (i.e. calls from other handsets registered to the base station).

Press the OPTIONS button. Until display flashes

HS setting. Press the OPTIONS button To select either Ext. ringer

(to set the ring volume for external calls) or Int. ringer (to set the ring volume for internal calls).

Press the OPTIONS button Until the display flashes

Volume. Press the OPTIONS button To hear and switch between

volume settings 0-5. To confirm the setting

displayed.

To exit the options menu at any time,

press the END button until the

display returns to standby.

To adjust the handset ringer melody

You can choose from 6 melodies. The pre-set melody is 4.

You can also set different melodies for external calls and internal calls (i.e. calls from other handsets registered to the base station)

Press the OPTIONS button. Until display flashes

HS setting. Press the OPTIONS button

to confirm. To select either Ext. ringer

(to set the ring melody for external calls) or

Int.ringer

(to set the ring melody for internal calls).

Press the OPTIONS button Until the display flashes

Melody. Press the OPTIONS button

to confirm.

Options

Del

Options

Del

Options

Del

Options

Del

Options

Del

Options

Del

To hear and switch between

Del

Options

the different melodies 1-6. Press the OPTIONS button

to confirm the setting displayed.

To switch the keytones off and on

When you press a button on the handset, you hear a beep. You can switch these beeps off.

To set a different language for the display

You can set the options of ‘English’, ‘Francais’, ‘Deutsch’, ’Italiano’ or ‘Espanol’.

Until the display flashes HS setting.

Until the display flashes Language.

Until the display flashes HS setting.

Until the display flashes Key tone.

Until the display flashes ON or OFF.

To confirm the setting displayed.

To scroll through the options,

Deutsch, English, Francais, Italiano or Espanol until the required

language flashes.

Please note

The current language

setting is indicated by an ✱ before

the country’s language.

To select the language displayed.

optional settings

Base station settings

Options

Del

Options

Del

Options

Del

Options

Del

Options

Del

Options

Del

Options

Del

To adjust the base ringer melody

You can use your handset to change the melody.

Until the display flashes

Base setting

PIN Enter the 4-digit base station

PIN. Original setting 0000.

Until the display flashes

BASE STATION SETTINGS

Base ringer

Until the display flashes

Melody

To hear and select the choice of melody you want 1-6. The original setting is 4.

To confirm the selection displayed. You hear a confirmation ring.

To adjust the base ringer volume

You can use your handset to change the melody. The settings range from

0-5, where 0 = off and

5 = maximum.

Until the display flashes

Base setting

PIN Enter the 4-digit base station

PIN. Original setting 0000.

Until the display flashes

Base ringer

Until the display flashes

Volume

To hear and select the volume you want 0-5. The original setting is 3.

To confirm the selection displayed. You hear a confirmation ring.

To set the handset priority

Options

Del

Options

Del

Options

Del

To change the base station PIN

If you are using more than one handset on your base station, you can select one handset to ring before all the others. You can then set the number of rings it will make before the other handsets start ringing.

Until the display flashes

Base setting

PIN Enter the 4-digit base station

PIN. Original setting 0000.

To scroll through and select

HS Priority

. To confirm. To scroll through the options:

No priority

- all handsets

ring at the same time.

Handset 1-5

- the selected

handset rings first.

If you change your base station PIN, keep a record of the new number by writing it in the space provided on page 8.

Until the display flashes

Base setting

PIN Enter the 4-digit base station

PIN. Original setting 0000.

Until the display flashes

Change PIN

Enter the new 4-digit PIN you

want. To confirm new PIN. Display

shows Retype.

PIN Re-enter the new PIN.

To confirm the setting.

BASE STATION SETTINGS

KEYPAD

To confirm the displayed setting. Display flashes

Ring (1-99)

Enter the number of rings you want the selected handset to ring before the other handsets.

To confirm.

To set call barring

Options

Del

Options

Del

Options

Del

Options

Del

Options

Del

You can bar calls with up to five different prefixes, making it impossible to dial out if a telephone number is preceded by one of these prefixes. This could be an international dialling code or a premium rate service. You can also specify individual handsets on which you want to set call barring.

To select which base station you want your handset to use

Until the display shows

Select base

To scroll through the options:

Best base

= your handset will automatically select the base station with the strongest reception.

Base 1-4

= you can select

a specific base to use.

Until the display flashes

Base setting

PIN Enter the 4-digit base station

PIN. Original setting 0000.

Until the display flashes

BASE STATION SETTINGS

KEYPAD

Call barring

. The display flashes Enter the prefix number to

be barred. (If you are barring international calls, enter 00).

Display shows HS. Enter the handset number(s)

1-5 you want calls to be

barred from. To confirm. You hear a

confirmation ring. Repeat the steps above to

enter up to five separate barred prefixes.

To confirm.

To display the base station name on your handset

Your handset can display the name of the base station to which it is currently registered.

NO:

Until the display shows

Show base

Until the display shows

Base name

Until the display shows

To confirm the setting.

To change the base station name

Options

Del

Options

Del

Options

Del

If you choose to display the base station name on your handset (see above), you can give each base a different name. For example, ‘Office’ or ‘Home’.

Until the display shows

Show base

Until the display shows

Set new name

Until the base name you wish to change is flashed on the display.

ABC Use the keypad to enter the

new base station name. To confirm the setting. See page 18 for details of

how to enter letters.

BASE STATION SETTINGS

Using additional handsets

Options

Page

Options

Del

Registering an additional Synergy handset with the base station or de-registering a handset.

As well as your original handset, you can register up to a further 4 additional handsets to your Synergy 2150 base station.

The system allows internal calls between two handsets while a third is making an external call.

Each additional handset you purchase must be registered with the base station.

Please note

Remember to charge the batteries of

new handsets for at least 16 hours.

When switched on, a new additional

ADDITIONAL HANDSETS

handset will display Not SUB.

This tells you that the handset is not

yet registered with the base station.

To register a handset

At the base station:

Press the

PAGE button and

hold for at least 10 seconds, until you hear the validation tone, then release the button.

The In Use LED on the base will flash repeatedly. You must register the handset in the next 10 minutes.

At the handset:

Until the display flashes

Registration

Press to display the available base station names

BASE 1-4

If your handset is already registered to another base, then the display shows next to the base name.

When a free base station number is displayed. Display then shows

Searching

the base station number. When the handset has

detected the base station signal, it gives a confirmation ring. You are asked to enter the base station PIN.

PIN Enter the 4-digit base

station PIN. The pre-set PIN is 0000. (To change the PIN, see page 38.)

The LED will stop flashing (unless there are new messages).

The display shows the normal standby setting when the registration process is completed.

✱

and

Options

Int

Del

Options

Del

The handset is automatically registered with the next available handset number. This number is shown on the display as

HS 2, 3, 4

or 5.

Please note

If the registration process fails, the

handset display shows Not SUB and

you should begin the process again.

To de-register a handset

Press buttons in the order shown

To call another handset

Press the INT button. Display shows the INT symbol and

Internal

Enter the handset number you want. Display shows the number and the called handset rings.

Press the END button to end the call.

To transfer an external call to another handset

You can use your handset to de-register another handset from a base station. You cannot de-register the handset you are using from the base station you are using.

Until display flashes Base setting.

PIN Enter the 4-digit base station

PIN, the pre-set PIN is 0000.

Until the display shows

Remove HS

Until the handset number you want to de-register is flashing.

To confirm. You will hear a confirmation

tone and the display will return to Remove HS.

KEYPAD

Your caller is put on hold and you hear the dialling tone.

Enter the handset number to which you want to transfer the call. When the handset is answered

The call is transferred. If the handset is not

answered, press the INT button to speak to the caller again.

ADDITIONAL HANDSETS

To hold a three-way conversation

Int

You can talk to one external call and another internal caller at the same time on your Synergy handset.

During a call with an external caller:

Your caller is put on hold and you hear a tone.

KEYPAD

Enter the handset number to which you want to transfer the call. When the handset is answered.

Press and hold the #button for a few seconds until the display clears. You can now start your three-way conversations.

ADDITIONAL HANDSETS

Operating with additional

Page

base stations

You can use up to five handsets on each Synergy 2150 base station, and up to four base stations with your handset to build up a comprehensive cordless telephone system.

The handset supplied with each base station is already registered as HS1.

To register your handset to another base station

You can register a handset with up to 3 other base stations.

Follow the same steps shown on page 41, ensuring that you select a base station that is free i.e. one that has no ✱ against it.

Press and hold the PAGE button on the base station you want to register your handset to. It sends a unique signal and your handset will automatically accept it as the next base station.

In this way when selecting your base station to operate from, the handset will automatically display your new base name, once it has established connection, e.g. name Base 1 as Home and Base 2 as Office.

Please note

When registering handsets to another

manufacturer’s base, the assigned

handset number may not appear in

the handset display.

To find out the handset number,

press INT then 1 to call handset 1.

Then look at the display on handset 1

to see your handset number.

ADDITIONAL BASE STATIONS

To avoid confusion you may wish to allocate a different name from your original base. This can be done by following the steps on page 40.

Connecting to a switchboard

Options

Del

Options

Del

Options

Del

Options

Del

Options

Del

Options

Del

When connecting your Synergy 2150 to a switchboard/PBX, you may need to change the dialling mode from TONE to PULSE.

To change the dialling mode

The dialling mode is set to TONE when the product is supplied.

To change to PULSE.

Until display flashes

setting

SWITCHBOARD

PIN Enter the 4-digit base station

PIN. Original setting 0000.

Until the display flashes Dial mode.

Until the display flashes

Pulse.

Base

To change the network connection

When connected to some switchboards/PBX’s you may encounter higher than normal speech levels. If this is the case you can alter the network setting from PSTN to PBX which would reduce the levels to normal.

Until the display flashes Base setting.

PIN Enter the 4-digit base station

PIN. Original setting 0000.

Until the display flashes Network.

Until PBX is flashing.

To confirm setting.

To confirm the setting.

To enter a PSTN pre-fix code

Options

Del

Options

Del

With some switchboards it may be helpful to dial a pause after entering the PSTN pre-fix code eg: 9,11 etc. to enable you to get an outside line. However, your Synergy 2150 can enter a pause automatically for you.

Please note

Each time you dial out on

a PSTN number you must

still dial the pre-fix code i.e. you will still have to

dial the pre-fix code 9,11 etc.

to enable an outside line to

be established.

The numbers held in the

directory must also have the

PSTN pre-fix code to gain an outside line with some

switchboards.

Please note

Each time the PSTN pre-fix code is

dialled a pause will automatically be

inserted before the telephone

number is dialled.

SWITCHBOARD

Until the display flashes

Base setting

PIN Enter the 4-digit base station

PIN. Original setting 0000.

Until the display flashes

KEYPAD

PSTN prefix

Enter the pre-fix number

after which you want the pause to be inserted. This can be up to 5 digits.

To confirm the setting.

Maintenance

General

Simply clean your Synergy 2150 with a damp cloth (not wet) or an antistatic wipe. Never use a dry cloth as this may cause a static shock.

Service

Within guarantee

If you experience a problem with your Synergy 2150 you should contact the Synergy Helpline on 0845 602 1041. Calls are charged at local call rates. If the problem is not remedied, you will

MAINTENANCE

be advised to contact your original point of purchase.

Some retailers offer extended warranty schemes for cover outside the initial 12-month period. Please ask them for details.

Outside warranty

If your Synergy 2150 needs repair after the warranty period has ended, contact the Synergy Helpline on

0845 602 1041 for information on

our recommended repair agents.

If you have to return your Synergy 2150

Pack the unit securely, preferably in the original packaging. All parts must be returned including the mains power adaptor. We cannot take responsibility for goods damaged in transit.

Help

Emergency calls

The emergency services can be

contacted in the UK by dialling 999

or 112 which is valid in any countr y

that is a member of the European

community.

Please note

If your Synergy 2150 is connected to

a switchboard/PBX, you may have

to dial an access number before 999 to

contact the emergency services. Some

switchboards cannot dial out during

a power failure.

The Synergy 2150 will not work

when the power fails. Alternative

arrangements should be made for

access to emergency services.

Replacing the handset battery

After a time, you may find that the handset battery is running out of charge more quickly. This is a standard sign of wear and the battery will need replacing.

Spare batteries (Item Code 871996) are available from BT Shops or contact the Synergy 2150 Helpline

0845 602 1041.

Do not immerse batteries in water or throw them into a fire, or dispose of them with ordinary domestic refuse.

BT accepts no responsibility for damage caused to your Synergy handset by using any other type of battery.

No display appears

The battery may be flat or dead. Recharge or replace the battery.

No dial tone

Is the telephone line cord plugged into the phone socket?

Check that the base station is connected to the mains power and switched on.

You cannot link up with the base station

If the display shows Not SUB, the handset must be registered with the Synergy 2150 base station. See page 41.

Is the display flashing ? The mains power cable may not be

connected at the base or switched on. Are you in range of the base station? Battery could be low or flat. If using more than one base station,

check that you are connected to the correct base. See page 39.

No ring on the handset or base station

The ringer volume may be switched to silent. To adjust the ringer volume on the handset, see page 35, on the base station, see page 37.

Check that that the base station is plugged into the phone socket.

HELP

Check that that the base station is plugged into the mains power and switched on.

Buzzing noise on my radio, TV, computer or hearing aid

Sometimes, your Synergy 2150 can interfere with other electrical equipment if it is placed too close.

It is recommended that you place your Synergy 2150 and other Synergy handsets at least one metre away from such appliances to avoid any risk of interference.

The charger does not appear to be working

Check that:

• the power adaptor is properly plugged in to the charger

• your handset has slotted correctly into the charger

HELP

• the battery is correctly fitted into the handset

If you are still experiencing difficulty,

call the Synergy 2150 Helpline

0845 602 1041.

Please note

In the event of a mains power failure,

date/time stamp will need to be reset.

Are you using the correct power adaptor? Synergy 2150 base station power supply is Item Code 872073.

Cannot adjust the option in the base station

Is someone else making changes via another handset?

Have you pressed the OPTIONS button to confirm your selection?

If you are still experiencing difficulty, call the Synergy 2150 Helpline on

0845 602 1041.

Have you pressed the OPTIONS button to confirm your selection?

Technical information

Environment

Your Synergy 2150 should be kept free of dust, moisture, high temperature, vibration and should not be exposed to direct sunlight. Do not stand it on carpets or other surfaces which generate fibres or place it in locations which prevent the free flow of air over its surfaces.

Warning

The apparatus is designed to be

operated in a normal office or domestic

environment where the relative

humidity does not exceed 75%.

It should not be used in bathrooms

or near water.

If the power fails

Alternative arrangements should be made for access to emergency services.

How many phones can you have?

All items of telephone equipment have a Ringer Equivalence Number (REN), which is used to calculate the number of items which may be connected to any one telephone line. The Synergy 2150 has a REN of 1. Any other instrument provided by BT may be assumed to have a REN of 1 unless otherwise stated. A total REN of 4 is allowed.

Connection to the BT telephone network

Synergy 2150 is fully approved for connection to the BT network provided it is used according to the instructions in this guide. The telephone lines must provide Multi-frequency (Touch Tone) dialling capabilities.

It may be connected to Direct Exchange Lines and switchboards (PBXs) with new plan (plug and socket) arrangements.

Connecting to switchboards

Synergy 2150 is only approved for use with a compatible switchboard including those which do not provide secondary proceed indication.

If you would like a list of suitable switchboards, contact BT on 154.

If you do not have a compatible switchboard, it cannot be guaranteed that the product will operate correctly under all possible conditions of connection. If you have any difficulties, contact BT on 154.

Generally, Synergy 2150 can be connected to any switchboard where a simple modern telephone can be used to make and receive calls. Synergy 2150 is suitable for connection to switchboards which return secondary proceed indication.

TECHNICAL INFORMATION

Technical specification

Standard DECT, GAP Number of channels 120 duplex channels Radio frequency range 1880 MHz to 1900 MHz Duplex method Time-division multiplexing. 10 ms frame length Channel spacing 1728 kHz Bit rate 1152 kbit/s Modulation GFSK Voice coding 32 kbit/s Transmitted power 10 mW, average output per channel Range Up to 300 metres outdoors (uninterrupted line

of sight) Up to 50 metres in buildings

Power supply Base station 230 V/50 Hz (AC adaptor)

TECHNICAL SPECIFICATION

Power consumption base station 3.6 VA Operating time, mobile unit Standby: up to 150 hours

(with fully charged battery) Phone in use: Up to 12 hours

Handsfree: Up to 7 hours talktime.

Permitted ambient conditions 0˚C to 55˚C – Handset; 5˚C to 45˚C for operation (maximum) Base; 15% to 90% rel. humidity

Permitted storage temperature –10˚C to +60˚C Signalling method DTMF and PULSE Signal key function Timed Break Recall Base station dimensions 120mm x 126mm x 60mm (L x W x H) Handset dimensions 151mm x 46mm x 30mm (L x W x H) Weight Base station: 175g

Handset: 115g (with battery)

Index

Answering machine

answer mode 23 base speaker volume 21 call monitoring 14 call screening 28 delete announcement 24 delete old messages 28 handset speaker on/off 25 handset speaker volume 26 memory full 26 number of rings 25

on/off 23 play messages 27 record memo 28 record own annoucement 24 remote access 29 save caller’s number into

phonebook 32 security PIN 26 select day/time prompts 23 set day and time 22 time saver 25, 29 view stored numbers 32 VIP feature 33

At a glance 1, 2

Base station

additional 44 change base station name 40 handset display 39 melody 37 PIN number 12, 38 priority, handset 38 register handset 41

ringer volume 37 select which base station 39

Batteries

charging 11 helpline 49 installing 10 levels 11 low warning 11 performance 11 replacing 48

Building up a phone system 7

Call barring 39

Call monitoring 14 Call screening 28 Call waiting 33 Caller display 31 Calls

end 13 handsfree 14 make 13 receive 14 redial 15 secrecy 15 three-way calling 43 transfer 42

Cleaning 47

DECT 7

Delete

announcement 24 old messages 28

old numbers 33 Dialling mode 16, 45

change 45 pulse 16 tone 16

Display symbols 2

End a call 13 Go back option 16

Guarantee 47

Handset

additional 41 call another handset 42 de-register 42 display which base station 39 earpiece volume 15 keytones 36 melody 35 menu 3

INDEX

monitor 14 on/off 13 register 41 ringer volume 35 ringer priorities 38 three-way call 43 transfer external call 42 transfer 42

Handsfree 14 Help 48 Helpline 49

Introduction 7 Key features 5, 6

Keypad lock/unlock 13

Language display 36

Lock keypad 13 Location 10

Mains adaptor 10

Maintenance 47 Make a call 13 Melody

base station 37

handset 35 Memory full 26 Menu 3

Notepad

dial a number 17

store a number 17

store in phonebook 18

view a number 17 Number of rings 25

Optional settings 35

On/Off

answering machine 23

handset 13

handset speaker 26 Pause 19

Phonebook 18

delete 20

delete all 20

dial a number 20

edit an entry 19

pause 19

store a name and number 19 Phone system – building up 7 PIN

base station 12, 38

pre-set 12

remote access 26 Play messages 27 Power socket 10

Power cable 10

Tone dialling 16

Recall 16, 17

Receive a call 14 Record

memo 28

own announcement 24 Redial 15 Remote access 29 Remote access PIN 26 REN (Ringer Equivalence Number) Returning your Synergy 2150 47

Safety instructions 9

Secrecy 15 Security PIN for remote access 26 Select services 31

caller display 31

VIP feature 33

call waiting 33 Service 47

Unpacking 8

Unlock keypad 13

VIP 33

Volume

earpiece 15 handset ringer 35 handset speaker volume 26 base station ringer 37

Warranty 47

INDEX

Setting up 10 Switchboard 45

dialling mode 45

connecting 45, 49

PSTN pre-fix code 46 Switch handset on/off 13

Technical information 50

Telephone socket 12 Technical specification 51 Telephone line cord 12 Three-way conversation 43 Time saver 25

Offices worldwide

The telecommunications services described in this publication are subject to availability and may be modified from time to time. Services and equipment are provided subject to British Telecommunications plc’s respective standard conditions of contract. Nothing in this publication forms any part of any contract.

Touchtone™ is a registered trade mark of British Telecommunications plc in the UK.

© British Telecommunications plc 2000. Registered Office: 81 Newgate Street, London EC1A 7AJ. Registered in England No. 1800000. Designed by: The Art & Design Partnership Limited. Printed in China. Synergy 2150. Issue 1 (5/00) 7

Printed on paper which meets international environmental standards.

CE compliant to 89/336/EEC (EMC Directive) & 73/23/EEC (Low Voltage Directive)

APPROVED for connection to

telecommunication systems specified in

the instructions for use subject to the

conditions set out in them

610384

BT Synergy 2150 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
