BT DIVERSE 5300 ADDITIONAL User Manual

User Guide

BT DIVERSE 5300

ADDITIONAL HANDSET AND CHARGER

This equipment is not designed for making emergency telephone calls when the power fails. Alternative arrangements should be made for access to emergency services.

FOR SMS

TEXT MESSAGING

YOU MUST SUBSCRIBE

TO A CALLER DISPLAY SERVICE

AND YOU MUST NOT WITHHOLD

YOUR TELEPHONE NUMBER.

A QUARTERLY FEE IS PAYABLE.

Please open this page for an ‘At a glance’ guide to your BT Diverse 5300.

abc

def

ghi

jkl

mno

tuv

wxyz

pqrs

➤

INT MENU

At a glance

Microphone

Hash/Keyguard

Hold down to switch the keypad guard on and of f.

Extra Directory

Used to store an additional 10 names and numbers.

Keypad

Red phone

Press to end a call, return the display to idle or turn the power on and off.

Display

Displays the status of your handset.

Handsfree

Use to answer calls or make a call in handsfree mode.

Green phone

For making and answering calls.

Recall

Press for use with switchboards and certain Network Services or press and hold to enter a pause.

Calls list

Lets you access your lists – calls and SMS.

Right hand side

Takes you into the redial list.

Left hand side

Allows you to make an internal call.

Right hand side

Takes you into the menu options.

Left hand side

Lets you set the alarm clock.

Star/bell

Switches the handset ringer on and off.

One button

As well as being the number one button hold down to access your Voice Mail ser vice.

Directory

Used to store numbers and names in the directory.

BT Diverse Helpline – 08457 908 070

Charger

Contact points

Display option buttons

The OPTION buttons allow you to select options within each menu that are shown on the display.

Press the right side of the button to confirm (OK) menu selection.

Press the left side of the button for and right side of the button for when going through the menu options.

Handset display

When in IDLE SCREEN mode and the clock has been set.

Charger underside

Power socket

INT

BT Diverse Helpline – 08457 908 070

In this guide

At a glance 1

Main menu structure 4

Messages 5

Quick guide to handset settings 6

Quick guide to handset display icons 7

Introduction 8

Unpacking your BT Diverse 5300 8 For your records 8

Safety information 9

Setting up 10

Using the telephone 15

Making and ending calls 15 Handsfree 16 Using the directory 17 Character map 18 VIP ringing 19 Redial 22 Secrecy 23 Paging and internal calls 23

Caller Display and other BT Calling Features 26

Caller Display 26 Calls list 26 Call Waiting 29 Other BT Calling Features 29

Additional features 32

Voice Mail 32

Handset settings 34

Alarm clock 36 Appointment call 37 Walk and talk 41 Room monitor 42

Help 45

General information 47

Guarantee 47 BT Accessories and

Replacement Items 47

Technical information 48

Index 49

Hints and tips boxes

In this user guide, we’ve included helpful tips and impor tant notes. They are shown in boxes like this.

Helpline

If you experience any dif ficulties with your BT Diverse 5300, please call the BT Diverse Helpline on 08457 908 070.

Please refer to the separate Using SMS User Guide for instructions on using the SMS functionality.

BT Diverse Helpline – 08457 908 070

Menu structure

Please note that you will only see all the below menu options if you are registered to a BT Diverse 5310 base station.

SMS Write message

Incoming

Outgoing

Settings Service Centres Service Centre 1 ->

Service Centre 5

SMS Mailboxes SMS > 1-3

Notify Number

Notify Type Missed Calls

Select Services Withhold Number

For All Calls Call Divert All Calls

No Answer

When Busy

Call Waiting On

Off

Cancel Ringback

Additional Features Room Monitor Call Internal

Call External

Level

Walk and Talk

Calender/Clock Set Appointment Enter Date

Enter Time

Enter Text

Alarm Clock Enter Alarm Time

Date/Time

Time Mode 12 Hour

24 Hour

Audio Settings Earpiece Volume

Handsfree Volume

Ringer Volume

Ringer Melody External Calls

Internal Calls

Appointment

Alarm Clock

All Ringer Tones

Advisory Tones Key Tones

Battery Low On

During Call

Confirmation Tone

BT Diverse Helpline – 08457 908 070

Messages

Press to get to your Mailbox and access your text messages, voicemail and Calls list.

The following functions are available:

Note

If your handset is registered to a BT Diverse 5350 answering machine base, you will have additional menu’s in Voice Mail. Please refer to your BT Diverse 5350 guide to see what fur ther menus are now available.

SMS

Network Mailbox

Calls List Delete entry

Copy to directory

Date and time

Status

Delete list

Handset Settings Auto Answer

Language

Select base

Reset Handset

Base Settings System-PIN

Base Reset

Additional Features Dialling mode Tone

Pulse

Tone-Earth

Recall 80 ms

800 ms

Repeater Mode

Listening in System – PIN

Voice Mail Set Key 1 Network Mailbox

BT Diverse Helpline – 08457 908 070

Quick guide to handset settings

Switch the handset OFF/ON: Hold down. (default is ON)

Switch Keyguard

Hold down.

on/off

Switch handset

Hold down.

ringer off Make a call or . Redial a number to scroll through the list to dial.

Copy a displayed

to display Copy to directory add name

number in the redial

display shows Save entry .

list to the directory

Dial from the

to name or number you want to dial .

directory Dial from Calls list to display Calls List to display the number you want .

Adjust handsfree volume whilst in Display shows Volume to decrease/incr ease volume . handsfree mode

Adjust earpiece

display shows Volume to decr ease/increase volume .

volume Make internal call then select handset and click on . Call all handsets to Call All .

Transfer call to

then select handset and click on .When user answers press .

another handset

Put caller on hold

then select handset and click on . When finished press .

while you make

Back will be selected press .

an internal call Set date and time to display Calendar/Clock to display Date/Time

enter date enter time . Select am/pm .

➤

OK OK

Int

OK OK OK

Page

BT Diverse Helpline – 08457 908 070

Quick guide to handset display icons

Redial, lists up to the last 10 dialled number.

Flashes to indicate new messages (e.g Calls or SMS).

For calling other handsets.

Opens the menu.

Shows the status of the handset battery.

Scroll through the menu.

Confirms the function displayed.

Scroll left and right when entering numbers or messages.

Deletes numbers/characters (from left to right).

Ringer off.

Handset locked.

Shows the number of the handset and is displayed in top left hand corner.

Appears when the time and date is set, allows access to Calendar/Clock functionality.

INT



eg. 1

If anything is missing, please contact your place of purchase immediately.

One BT Diverse 5300 charger

One BT Diverse 5300 handset

One power supply for the charger

Two AAA rechargeable batteries

One belt clip

Batter y compartment cover

BT Diverse Helpline – 08457 908 070

INTRODUCTION

Introduction

Unpacking your BT Diverse 5300

For guarantee purposes proof of purchase is required so please keep your receipt.

For your records

Date of purchase:

Place of purchase:

BT Diverse Helpline – 08457 908 070

SAFETY INFORMATION

Safety information

General

Only use the power supply included with the product. Using an unauthorised power supply will invalidate your guarantee and may damage the telephone. Power supply number is C39280-Z4-C478.

For the handset use only AAA 1.2V Nickel Metal Hydride (NiMH) rechargeable batteries with a minimum capacity of 700 mAh. Never use other batteries or conventional alkaline batteries. They could lead to a short circuit or destroy the battery casing. Batteries and accessories are available from www.withandwithoutwires.com or call 0870 240 5522.

If the Keyguard is switched on, it is NOT possible to make calls, including emergency numbers (999/112).

Do not open the charger or handset (other than to change batteries). This could expose you to high voltages or other risks.

Radio signals transmitted between the handset and base may cause interfer ence to hearing aids.

This product should not be used near emergency/intensive care medical equipment and should not be used by people with pacemakers.

Never dispose of batteries in a fire. There is a serious risk of explosion and/or the release of highly toxic chemicals.

Cleaning

Simply clean the charger and handset with a damp (not wet) cloth, or an anti-static wipe. Never use household polish as this will damage the product. Never use a dr y cloth as this may cause a static shock.

Environmental

Do not expose to direct sunlight. The product may heat up when the

batteries are being recharged. This is normal. However, we recommend that you do not place the product on antique/veneered wood to avoid damage.

Do not stand your product on carpets or other surfaces which generate fibr es, or place it in locations preventing the free flow of air over its surfaces.

Do not submerge any par t of your product in water and do not use it in damp or humid conditions, such as bathrooms.

Do not expose your product to fire, explosive or other hazardous conditions.

There is a slight chance that your phone could be damaged by an electrical storm. We recommend that you unplug the power and telephone line cord during an electrical storm.

BT Diverse Helpline – 08457 908 070

SETTING UP

Plan the location

Situate your product close enough to a mains power socket so that the cable will reach.

Make sure it is at least 1 metre away from other electrical products to avoid interference.

Do not situate the product in the bathroom or other humid areas.

IMPORTANT

Please note that your handset is NOT registered to a base station. The BT Diverse 5300 handset will be easily registered once you complete the steps 1 to 3 below.

2 Plug the power supply unit

into the wall socket

Setting up

1 Connect the charger

Plug the power supply cable into the power socket at the back of your charger.

3 Registering and charging

the handset

The display is protected by a plastic film. You can remove this protective plastic film from the display.

BT Diverse Helpline – 08457 908 070

SETTING UP

Inser t the two batteries supplied, as indicated inside the batter y compar tment and slide the battery compar tment cover shut.

Insert the batteries Registering the handset

If the icons on the display

flash continuously...

It means that the handset is not registered with the base station.

Ensure you have correctly carried out step 3 above. If the product is still not registered see Registering Manually on page 12.

All additional handsets you purchase will need to be individually registered with the base station before they will work.

The batter y cover may be found in the packaging with the batteries.

WARNING

Under no circumstances should non-rechargeable batteries be used. Using incorrect batteries will invalidate your guarantee and may damage the telephone.

To register your handset to a BT Diverse 5310 or 5350 base station, place it in the main BT Diverse 5300 base station with the display facing upward. After approx. one minute, the handset's internal number is displayed (e.g. 2). Successful registration is signalled by a confirmation tone.

Replace the newly registered handset into the charger and leave to charge for approximately 16 hours. The char ging status icon flashes on the handset to indicate that the batteries are being charged.

When the handset is registered the display will show:

BT Diverse Helpline – 08457 908 070

SETTING UP

To de-register a handset

Press the INT navigation button to display the list of internal handsets register ed to the base.

Press the UP or DOWN navigation button to select the handset you want to de-register.

Press the MENU options button. Press the DOWN navigation

button until the display shows

De-register Handset

. Press the OK options button. Enter the base station PIN

(original setting =

0000

). Press the OK options button. Display shows

de-register

handset?

Press the OK options button to confirm de-registration.

Press the RED PHONE button to return to the idle scr een.

INT

If the base is not a 5310 or 5350 you will need to follow the user guide for the base station you are registering the 5300 handset to.

To manually register a BT Diverse 5300 handset to another base station

If you want to register your handset to another base station you will need to manually register it.

On the handset to be registered:

Press the MENU options button. Press the DOWN navigation

button until the display shows

Handset Settings

. Press the OK options button. Press the DOWN navigation

button until the display shows

. Press the OK options button. Enter system PIN. Press the OK options button. If the base station is a

BT Diverse 5310 or 5350 base press the PAGE button for approximately three seconds.

After approximately one minute the handset will display its internal number. The handset is now registered and the handset display will return to the idle screen.

BT Diverse Helpline – 08457 908 070

SETTING UP

Battery level icons

When the batteries are almost flat a beep sounds and the display shows the empty battery icon. You will need to recharge your handset before you can use it. The various states of charge are shown below:

Batteries fully charged Batteries at 66% Batteries at 33% Batteries empty

Out of range?

If you go out of range of a base station for a long time while your handset is switched ON, it may take more than 20 minutes to ‘find’ the base station again when you come back within range. However, by simply switching the handset OFF for a moment, then ON again, it will find the base station within a few seconds.

Battery performance

Batteries and case may become warm during charging. This is normal.

Under ideal conditions, the handset batteries should give about 13 hours talktime or 170 hours standby time on a single charge. However, new NiMH batteries do not reach their full capacity until they have been in normal use for several days.

The charge capacity of rechargeable batteries will reduce with time as they wear out, so reducing the talk/standby time of the handset. Eventually they will need to be replaced. New batteries are available from

www.withandwithoutwires.com

or call 0870 240 5522. If you replace the handset batteries

with ones that have been fully charged, the battery indicator will not show full until the next charge cycle has been completed. Charge the handset until the batteries register full again. From then on the display will be correct.

BT Diverse Helpline – 08457 908 070

SETTING UP

Setting the date and time

Press the Menu options button. Press the DOWN navigation

button until the display shows

Calender/Clock

Press the OK options button.

Set Appointment

appears.

Press the DOWN navigation button until the display shows

Date/Time

. Press the OK options button. Enter the day/month/year, e.g.

05 10 03 for 5th October 2003. Press the OK options button. Enter the time – hours/minutes.

e.g. 0925 for 9:25am. Press the OK options button. Use the UP/DOWN navigation

buttons to select

am/pm

if in 12

hour mode. Press the OK options button. Press the DOWN navigation

button to

Time Mode

. Press the OK options button. Use the UP/DOWN navigation

buttons to select 12 or 24 hour display (12hr is the default).

Press the OK options button. Press the RED PHONE button

until you reach the idle display.

4 To fit the belt clip

Fit the belt clip onto the back of the handset.

SSlloott

BT Diverse Helpline – 08457 908 070

USING

To make an external call

Ensure the handset is switched ON.

Press the GREEN PHONE button. You will hear the dial tone.

Dial the number.

Using the telephone

Preparatory dialling

Enter the phone number first. If you make a mistake press

the



C options button to

remove any incorr ect digits. Press the GREEN PHONE

button to dial the number.

Making and ending calls

To end a call

Press the RED PHONE button.

Note

To exit a menu at any time, press the RED PHONE button. This will take you back one step. Keep pressing the RED PHONE button to return to the idle screen.

To switch the handset power on and off

Press and hold the RED PHONE button to switch the

handset of f. Press and hold the RED

PHONE button to switch the handset on again.

Call timer

Your handset automatically times the duration of all external calls, showing it on the display during your call and for a few seconds after it is finished.



+ 37 hidden pages
