BT DIVERSE 5210 User Manual

User Guide

BT DIVERSE 5210

This equipment is not designed for making emergency telephone calls when the power fails. Alternative arrangements should be made for access to emergency services.

This product is intended for connection to analogue public switched telephone networks and private switchboards in the UK.

FOR SMS

TEXT MESSAGING YOU MUST SUBSCRIBE

TO A CALLER DISPLAY SERVICE

AND YOU MUST NOT WITHHOLD

YOUR TELEPHONE NUMBER.

A QUARTERLY FEE IS PAYABLE.

Please open this page for an ‘At a glance’ guide to your BT Diverse 5210.

At a glance

Microphone

Hash/Keyguard

Hold down to switch the keypad guard on and off.

Extra Directory

Used to store 10 additional names and numbers.

Keypad

Red phone

Press to end a call, return the display to idle or turn the power on and off.

Display

Displays the status of your handset.

Handsfree

Use to answer calls or make a call in handsfree mode.

Green phone

For making and answering calls.

Recall

Press for use with switchboards and certain Network Ser vices or press and hold to enter a pause.

Calls list

Lets you access your lists – calls, text and voice mail.

Right hand side

Takes you into the redial list.

Left hand side

Allows you to make an internal call.

Right hand side

Takes you into the menu options

Star/bell

Switches the handset ringer on and off.

One button

As well as being the number one button hold down to access your Voice Mail service.

Directory

Used to store numbers and names in the directory.

INT MENU

GHI

PQRS

ABC

JKL

TUV

DEF

MNO

WXYZ

Base

Base underside

Contact points

Power socketTelephone line cord socket

BT Diverse Helpline – 08457 908 070

In this guide

At a glance 1

Main menu structure 4

Messages 5

Quick guide 6

Quick guide to handset display icons 7

Introduction 8

Unpacking your BT Diverse 5210 8 For your records 8

Safety instructions 9

Setting up 10

Using the telephone 14

Making and ending calls 14 Handsfree 15 Using the directory 16 Character map 17 Redial 19 Secrecy 20 Paging and internal calls 21

Caller Display and other BT Calling Features 23

Caller Display 23 Calls list 23

Call Waiting 26 Other BT Calling Features 26

Additional features 29

Voice Mail 29

Handset settings 31 Base Station settings 36

Base Station PIN 36

Using additional handsets and bases 38

Registering additional handsets 38

Help 41 General information 43

Guarantee 43 BT Accessories and

Replacement Items 43 Technical information 44 Switchboard compatibility 44 Setting pauses 46

Index 47

Hints and tips boxes

In this user guide, we’ve included helpful tips and important notes. They are shown in boxes like this.

Helpline

If you experience any difficulties with your BT Diverse 5210, please call the BT Diverse Helpline on 08457 908 070.

Please refer to the separate Using SMS User Guide for instructions on using the SMS functionality.

BT Diverse Helpline – 08457 908 070

Menu structure

SMS Write message

Incoming Outgoing Settings Service Centres Service Centre 1 ->

Service Centre 5

Select Services Withhold Number

For All Calls Call Divert All Calls

No Answer When Busy

Call Waiting On

Off

Cancel Ringback

Calendar/Clock Date/Time

Time Mode 12 Hour

24 Hour

Audio Settings Earpiece Volume

Handsfree Volume Ringer Volume Ringer Melody External Calls

Internal Calls

Advisory Tones Key Tones

Battery Low Off

On During Call

Confirmation Tone

Handset Settings Auto Answer

Language Register Handset Reset Handset

Base Settings System-PIN

Base Reset Additional Features Dialling mode Tone

Pulse Tone-Earth

Recall 80 ms

to 800 ms

Repeater Mode

Voice Mail Set Key 1

BT Diverse Helpline – 08457 908 070

Messages

Press to get to your Mailbox and access your text messages, voicemail and Calls list.

The following functions are available:

Note

If you make a mistake, you can return to the previous menu by pressing the RED PHONE button. If you keep pressing the RED PHONE button you will return to the

idle screen.

Note

If your handset is registered to a BT Diverse 5250 answering machine base, you will have additional menu’s in Voice Mail. Please refer to your BT Diverse 5250 guide to see what further menus are now available.

SMS Calls List Delete entry

Copy to directory Date and time Status Delete list

BT Diverse Helpline – 08457 908 070

Quick guide

Switch the handset OFF/ON: Hold down. (default is ON)

Switch Keyguard

Hold down.

on/off

Switch handset

Hold down.

ringer off

Make a call or .

Redial a number to scroll through the list to dial.

Copy a displayed

to display Copy to directory add name

number in the redial

display shows Save entry .

list to the directory

Dial from the

to name or number you want to dial .

directory

Dial from Calls list to display Calls List to display the number you want .

Adjust handsfree volume whilst in Display shows Volume to decrease/increase volume . handsfree mode

Adjust earpiece

display shows Volume to decrease/increase volume .

volume

Make internal call then select handset and click on .

Call all handsets to Call All .

Transfer call to

then select handset and click on . When user answers press .

another handset

Put caller on hold

then select handset and click on . When finished press .

while you make

Back will be selected press .

an internal call

Set date and time to display Calendar/Clock to display Date/Time

enter date enter time . Select am/pm .

OK OK

Int

OK OK OK

Page

BT Diverse Helpline – 08457 908 070

Quick guide to handset display icons

Redial, lists up to the last 5 dialled number.

Flashes to indicate new messages (e.g Calls or SMS).

For calling other handsets.

Opens the menu.

Shows the status of the handset battery.

Scroll through the menu.

Confirms the function displayed.

Scroll left and right when entering numbers or messages.

Deletes numbers/characters (from left to right).

Ringer off.

Handset locked.

Shows the number of the handset and is displayed in top left hand corner.

INT



eg. 1

INT MENU

BT Diverse Helpline – 08457 908 070

Introduction

Unpacking your BT Diverse 5210

If anything is missing, please contact your place of purchase immediately.

One BT Diverse 5210 base station

One BT Diverse 5200 handset

One power supply for the base station

One telephone line cord

Two AAA rechargeable batteries

One belt clip

Battery compartment cover

For guarantee purposes proof of purchase is required so please keep your receipt.

Enter your system PIN code here:

For more information on your system PIN,

see page 36.

For your records

Date of purchase:

Place of purchase:

INTRODUCTION

BT Diverse Helpline – 08457 908 070

Safety information

General

Only use the power supply included with the product. Using an unauthorised power supply will invalidate your guarantee and may damage the telephone. Power supply number is M-GA35-095130F.

For the handset use only AAA 1.2V Nickel Metal Hydride (NiMH) rechargeable batteries with a minimum capacity of 700 mAh. Never use other batteries or conventional alkaline batteries. They could lead to a short circuit or destroy the battery casing. Batteries and accessories are available from

www.withandwithoutwires.com

or call 0870 240 5522. If the Keyguard is switched on, it is

NOT possible to make calls, including emergency numbers (

999/112).

Do not open the base station or handset (other than to change batteries). This could expose you to high voltages or other risks.

Radio signals transmitted between the handset and base may cause interference to hearing aids.

This product should not be used near emergency/intensive care medical equipment and should not be used by people with pacemakers.

Never dispose of batteries in a fire. There is a serious risk of explosion and/or the release of highly toxic chemicals.

Cleaning

Simply clean the handset and base station with a damp (not wet) cloth, or an anti-static wipe. Never use household polish as this will damage the product. Never use a dry cloth as this may cause a static shock.

Environmental

Do not expose to direct sunlight. The product may heat up when the

batteries are being recharged. This is normal. However, we recommend that you do not place the product on antique/veneered wood to avoid damage.

Do not stand your product on carpets or other surfaces which generate fibres, or place it in locations preventing the free flow of air over its surfaces.

Do not submerge any part of your product in water and do not use it in damp or humid conditions, such as bathrooms.

Do not expose your product to fire, explosive or other hazardous conditions.

There is a slight chance that your phone could be damaged by an electrical storm. We recommend that you unplug the power and telephone line cord during an electrical storm.

SAFETY INFORMATION

BT Diverse Helpline – 08457 908 070

1 Connect the base station

Plug the power supply cable into the power socket on the underside of your base.

Plan the location

Situate your product close enough to the telephone and mains power sockets so that the cables will reach.

Make sure it is at least 1 metre away from other electrical products to avoid interference.

Do not situate the product in the bathroom or other humid areas.

Setting up

WARNING

Do not connect the telephone line cord to the phone socket until your handset is fully charged. This will prevent the risk of the phone being answered before the battery is charged. Answering the phone before the battery is fully charged may prevent it from reaching its optimum capacity.

2 Plug the power supply

unit into the wall socket

SETTING UP

BT Diverse Helpline – 08457 908 070

WARNING

Under no circumstances should non-rechargeable batteries be used. Only use AAA 1.2V Nickel Metal Hydride (NiMH) rechargeable batteries with a minimum capacity of 700mAh.Using inappropriate batteries will invalidate your guarantee and may damage the telephone. Batteries and accessories are available from

www.withandwithoutwires.com or call 0870 240 5522.

3 Registering and charging

the handset

The display is protected by a plastic film. Remove the protective plastic film from the display.

INT

To register your handset, place it in the base station with the display facing upward. After approx. one minute, the handset’s internal number is displayed (e.g.: 1). Successful registration is

signalled by a confirmation tone. When the handset is registered the

display will show:

SETTING UP

Insert the batteries

Insert the two batteries supplied, as indicated inside the battery compartment and slide the battery compartment cover shut.

The battery cover may be found in the packaging with the batteries.

INT MENU

BT Diverse Helpline – 08457 908 070

Out of range?

If you go out of range of a base station for a long time while your handset is switched ON, it may take more than 20 minutes to ‘find’ the base station again when you come back within range. However, by simply switching the handset OFF for a moment, then ON again, it will find the base station within a few seconds.

Battery level icons

When the batteries are almost flat a beep sounds and the display shows the empty battery icon. You will need to recharge your handset before you can use it. The various states of charge are shown below:

Batteries fully charged Batteries at 66% Batteries at 33% Batteries empty

Battery performance

Batteries and case may become warm during charging. This is normal.

Under ideal conditions, the handset batteries should give about 13 hours talktime or 170 hours standby time on a single charge. However, new NiMH batteries do not reach their full capacity until they have been in normal use for several days.

The charge capacity of rechargeable batteries will reduce with time as they wear out, so reducing the talk/standby time of the handset. Eventually they will need to be replaced. New batteries are available from

www.withandwithoutwires.com

or call 0870 240 5522. If you replace the handset batteries

with ones that have been fully charged, the battery indicator will not show full until the next charge cycle has been completed. Charge the handset until the batteries register full again. From

then on the display will be correct.

SETTING UP

If the icons on the display

flash continuously...

It means that the handset is not registered with the base station.

Ensure you have correctly carried out step 3 above. If the product has still not registered, please see “Registering manually” on page 39.

All additional handsets you purchase will need to be individually registered with the base station before they will work with the BT Diverse 5210.

Leave the handset for approx. 16 hours in the base station to charge the batteries, as they are not charged in the factory. The battery status icon flashes on the handset to indicate that the batteries are being charged.

BT Diverse Helpline – 08457 908 070

4 Connect the telephone

line cord to the base and plug into the wall socket

Ensure that each end of the line cord is fitted into the correct socket.

Fit the belt clip onto the back of the handset.

Your BT Diverse 5210 is now

ready for use.

SSlloott

SETTING UP

Setting the date and time

Press the Menu options button. Press the

DOWN navigation

button until the display shows

Calendar/Clock

Press the

OK options button.

Date/Time

appears.

Press the

OK options button.

Enter the day/month/year, e.g. 05 10 03 for 5th October 2003.

Press the

OK options button.

Enter the time – hours/minutes. e.g.

0925 for 9:25am.

Press the

OK options button.

Use the

UP/DOWN navigation

buttons to select

am/pm

if in 12

hour mode. Press the

OK options button.

Press the

DOWN navigation

button to

Time Mode

Press the

OK options button.

Use the

UP/DOWN navigation buttons to select 12 or 24 hour display (12hr is the default).

Press the

OK options button.

Press the

RED PHONE button

until you reach the idle display.

Note

If you subscribe to a Caller Display service the time and date will be set with the first incoming call. However, the year setting will have to be changed manually. See opposite.

BT Diverse Helpline – 08457 908 070

To make an external call

Ensure the handset is switched ON.

Press the

GREEN PHONE

button. You will hear the dial tone.

Dial the number.

Using the telephone

Preparatory dialling

Enter the phone number first. If you make a mistake press

the



C options button to

remove any incorrect digits. Press the

GREEN PHONE

button to dial the number.

Making and ending calls

To end a call

Press the RED PHONE button.

Note

To exit a menu at any time, press the RED PHONE button. This will take you back one step. Keep pressing the RED PHONE button to return to the idle screen.

To switch the handset power on and off

Press and hold the RED PHONE button to switch the

handset off. Press and hold the

RED

PHONE button to switch the

handset on again.

USING

Call timer

Your handset automatically times the duration of all external calls, showing it on the display during your call and for a few seconds after it is finished.



+ 36 hidden pages
