SST C–SERIES
TAKING POWER TO THE NEXT LE VEL
INTRODUCING THE NEW C–SERIES
OUR GOAL
For over 30 years, Bryston has had a continuing commitment
to design and manufacture the most accurate and reliable
audio electronics. The performance, value, and reliability
of our amplifiers, and our unrivaled warranty, have brought
us recognition in the world of pro audio, as well as with
reviewers and home users. But there is no product that
cannot be made better. To this end, we maintain an
extensive research and development program, constantly
investigating techniques, technologies, and devices that
promise improvements to all aspects of our amplifiers. The
Bryston SST C–Series is the direct result of this on-going
quest, and represents a significant step forward in the art
and science of audio amplification.
PERFORMANCE
WITHOUT COMPROMISE
WHAT WE’VE DONE
Among the advances included in the SST C–Series are: faster,
more linear and more reliable output transistors for better high
frequency accuracy; doubled filter capacitance for even deeper
and better-controlled bass; a new proprietary grounding protocol
which eliminates the need for ground-lift switches and reduces
system noise; and a new computer-modeled heatsink profile for
cooler operation and longer component life. Modular design
and separate power supplies for each channel ensure cross-talk
is essentially nonexistent, and provide precise and focused
soundstaging. Components mount directly into glass-epoxy
circuit boards, eliminating variations in signal travel and wire
interaction. Reviewers agree: sound quality is improved to a
stunning degree, realizing a higher, and far more consistent
standard of musical accuracy across a line of amplifiers than
ever before possible.
With today ’s increased clar ity and dynamic range in
recordings and movie soundtracks, you need equipment
that not only equals, but surpasses, the parameters of the
most demanding material available. The SST C–Series is
without peer in meeting this performance challenge.
Modular design with independent power
supplies each with its own transformer for
precise sound-staging.
Above Bryston model 6B SST 3-channel amplifier
I
SONIC SUPERIORITY BY DESIGN
DESIGN PHILOSOPHY
ENSURES SONIC SUPERIORITY
From input to output, all the circuitry in the C–Series of
amps has been optimized for the most accurate performance
possible. All analog signal circuitry is fully discrete to avoid
the compromises, phase shift, and non-linearities inherent
in IC’s. The Bryston C–Series amplifiers incorporate an
innovative gain stage topology, which yields a substantially
lower noise floor through the use of low-impedance
pathways within the amplifier, and has strong advantages
in reducing overall distortion. Bryston’s computer controlled
distortion analyzers confirm that IM distortion of less than
10 parts per million (below 0.0009%) are typical for this
new circuitry. All SST amplifiers use Bryston’s proprietary
output stage, which we call “Quad-Complementary.” The
Quad-Complementary topology improves linearity to a new
standard of accuracy, while virtually eliminating aggressive
higher harmonic distortion products. The overall harmonic
distribution of Bryston’s Quad-Complementary output stage
closely approaches an ideal Class-A output, except that the
overall distortion is actually much lower. (True class-A output
stages suffer from relatively high current-induced distortion
levels, consisting of mostly lower-order harmonics). The
listening characteristics display a high degree of transparency
without harshness or grain. The annoyances previously ascribed
to ‘transistor sound’ are absent, and the amplifier seems to
combine the seductive lushness of tube equipment with the
focus and accuracy of solid-state.
Quick-connect 12 Volt trigger
input allow remote on/off
triggering of your amplifier(s).
Above Bryston SP 1.7 Processor can provide on/off trigger
signal for all Bryston SST amplifiers.
Power LEDs on the front panel indicate each
channel’s functional status — green for power-on,
red for overdrive.
Above LED indicators on Bryston 9B SST C-Series 5-channel amplifier.
MODULAR DESIGN/INDEPENDENT
POWER SUPPLIES
No matter how good an amplifier’s signal path may be,
it’s meaningless if it’s starved in the power supply, an all
too common way of cutting costs. One of the things that
makes the Bryston SST Series unusual is our insistence that
every amplifier in the line have a completely separate and
independent power supply for each channel, including its
own toroidal transformer.
2
SOLID CONSTRUCTION
Bryston’s research has shown that separate power supplies
provide the best imaging, clarity, and dynamic range — all
attributes that are especially crucial given the emerging
and demanding high resolution digital sources. The power
supplies employ multiple filter capacitors per channel, rather
than single pairs of larger filter cans, allowing improved high
frequency response, and reducing overall losses in the supply.
In the 9B SST, and 6B SST models we carry the modular
concept further, making the channels removable.
SUPERIOR INGREDIENTS
We use only the finest components — such as 0.1% metal-
film resistors, polypropylene capacitors, custom-wound
toroidal transformers, and hand-matched transistors — to
reduce noise and distortion to the absolute minimum. Gold-
plated balanced or single-ended (RCA) input connectors are
standard as well as gold-plated 5-way loudspeaker binding
posts, to eliminate possible causes of distortion from
corrosion. As befits products intended for use on stage as
well as in the home, the SST chassis are extremely robust.
FLEXIBILITY & FEATURES
SST amplifiers offer feature flexibility. For example, all allow
a choice of input connection — balanced XLR-F, balanced
1/4” phone, or single-ended RCA jack — together with a
switch to select gain settings. A trigger input allows system-
wide on/off control. Overall, the SST Series itself facilitates
flexibility in putting together the total system through a
variety of channel and power output options.
THE RESULT
Although the description of circuit innovations can indicate
the research and commitment we bring to the design and
manufacturing of our products, it’s not the whole story. The
purpose of all this technology is to place you within the scene
of the movie, or to transport you to the actual musical event.
Whether you can experience all the drama, movement, and
emotions intended is the one truly meaningful measure of
any audio/video system. Take the time to visit your Bryston
dealer and audition our SST Amplifiers. We think that you’ll
rediscover how exciting audio can be.
5.1 CHANNEL
Typical 5.1 Surround hook-up using
Bryston 9B SST C–Series Amplifier.
3
RELIABILITY & SUPPORT
BUILT TO LAST
The techniques and custom materials that Bryston brings to
bear every day in the construction of audio equipment are
more typically found in industrial plants building military
and aerospace electronics. Our traditional adherence to
proprietary parts, sophisticated construction techniques, and
in-depth testing prevents the unit-to-unit variability typical
of mass produced product and assures that your amplifier
will perform for many years without concern.
HAND ASSEMBLED WITH CARE:
All audio products we make are hand assembled and
individually tested by a dedicated team of Bryston employees
in our own North American manufacturing facility.
UNIQUE BURN-IN PROCEDURE
Each and every Bryston audio product undergoes an
extensive quality control “burn-in” procedure. Following a
complete operational checkout, every amplifier is placed on
a test-bench and run for 100 hours at full output (one-hour
on/one-hour off for additional thermal stress), with a high
frequency square-wave input and a capacitive load. This
extremely rigorous burn-in quickly “matures” components
and weeds out any potential premature failures. The result is
reliable trouble-free performance for many years.
EASY SYSTEM UPGRADES
We’ve designed the SST Series to take into account that
systems change. There’s a full range of channel and power
options, several amplifiers may be operated in bridged mono
mode, and the 9B SST may be ordered with as few as 3
channels, and later expanded up to 5 channels.
ON-LINE CUSTOMER SUPPORT
The Bryston website allows for downloading of technical
bulletins, product addenda, and complete user manuals.
OUR WARRANTY
Our commitment to build-quality and quality assurance is
why every product we manufacture features an unlimited,
transferable warranty, a warranty that remains unequaled by
any other audio manufacturer in the world.
Input flexibility: XLR or 1/4” phone jack for
balanced signals and RCA jack for single-ended
source; input gain is selectable.
Above left to right Model 4B SST input connectors, balanced/
single-ended switch, and (Pro model only) input gain adjustment.
We make all amplifiers available in standard 19” faceplates with
handles, as well as the 17” versions. Either size aluminum front panel
may be ordered in a silver or black finish. A special order 19” C–Series
rack mount version is also available on request.
Above ( left to right ) 7B SST 19” faceplate; 14B SST 17” version.
4
7B SST C–SERIES
The 7B SST single-channel amplifier employs a
balanced-output design that reduces THD and IMD
to unprecedented low values (typically 0.001% or less).
With a low noise floor (typically below -118dB) and
excellent signal tracking characteristics (slew rate of 120
Volts per microsecond), the 7B SST monoblock assures
a new degree of transparency, musicality, and ease of
SST C–SERIES
listening. Capable of delivering a truly prodigious 600
Watts continuously into 8 Ohms, and with tremendous
power reserves, the 7B SST offers virtually perfect
freedom from overload on any type of speaker or music.
Single-channel (mono-block) amplifier
600 W into 8 Ohms
900 W into 4 Ohms
The 14B SST is also available in a special 120 Volt 20 Amp
version (requires a dedicated 20 Amp AC outlet).
The 7B SST is also available in a special version for
very low impedance loads, i.e., 2 Ohms and below.
One advantage of the 7B SST’s
Monoblock design is that it allows you
to place the amplifier adjacent to the
loudspeaker, providing improved performance through lower cable resistance.
14B SST C–SERIES
Probably the best value “esoteric” high power
2-channel amplifier on the market today, the 14B SST
is basically a pair of 7B SST amplifiers on a single
compact chassis. Its superbly low noise floor yields
an inky black silence between notes for hauntingly
realistic reproduction. As a dual mono modular
design, it has the power to drive, with breath-taking
ease and clarity, speakers which have been considered
“impossible” loads in the past.
Dual-channel (stereo) amplifier
600 W into 8 Ohms
900 W into 4 Ohms
5
4B SST C–SERIES
The Bryston 4B is something of a legend. As our
most popular model, it has attained international
status as an amplifier suitable for the finest and most
sophisticated sound systems. In its latest incarnation,
the 4B SST, it is a dual mono design delivering a
massive 300 Watts per channel into 8 Ohms.
Whatever the venue, be it recording studio, concert
stage, broadcast facility, home theater installation, or
state-of-the-art stereo system, the 4B SST continues
as the number one choice.
FUEL FOR THE SENSES
Dual-channel (stereo) amplifier
300 W into 8 Ohms
500 W into 4 Ohms
The 4B SST may also be operated in
bridged mono, providing 900 Watts
into 8 Ohms
3B SST C–SERIES
The 3B SST stereo amplifier, at 150 Watts per
channel at 8 ohms, provides all the sonic virtues
and the same high value as our more powerful 4B
SST but in a package which is both compact and
less costly. Historically, the 3B has found favor in
a wide range of audio/video systems which call for
medium to high amounts of power but wish to avoid
sacrificing sonic accuracy and long-term reliability.
Dual-channel (stereo) amplifier
150 W into 8 Ohms
250 W into 4 Ohms
The 3B SST may also be switched to
bridged mono, providing 400 Watts
into 8 Ohms
6
6B SST C–SERIES
The Bryston 6B SST provides three channels of
powerful amplification in a single chassis. Consisting
of three totally independent amplifier modules, each
with its own power transformer and power supply,
each audio channel will supply effortless power even
to the world’s most demanding loudspeakers. The 6B
SST is a convenient solution for home theater left-
center-right amplification and is also a great way of
tri-amplifying 3-way loudspeakers.
EFFORTLESS POWER
3 – channel amplifier
300 W into 8 Ohms
500 W into 4 Ohms
SPECIFICATIONS AVAILABLE TO ALL SST AMPLIFIERS
Distortion < 0.005% from 20Hz to 20kHz at rated output into 8 Ohms
IM or THD+noise
Noise
Slew rate Greater than 60 volts per microsecond
Power bandwidth From less than 1 Hz to over 100 kHz
< 0.007% from 20Hz to 20kHz at rated output into 4 Ohms
(Measured with input shorted; 20Hz. to 20kHz.)
>110dB below rated output @ 29dB gain (-75dBu)
>113dB below rated output @ 23dB gain (-78dBu)
>116dB below rated output @ 17dB gain (-78dBu)*
setting available on models 6B & 9B only
*
3 – position
sensitivity switch:
1V, 2V, or 4V
Polarity
switch
on each
channel
SST C–SERIES
Damping factor Over 300 at 20 Hz, ref. 8 Ohms
Input Impedance 50k Ohms single-ended, 20k Ohms balanced (10k each leg)
7
9B SST C–SERIES
The Bryston 9B SST is a modular, 5-channel, singlechassis power amplifier delivering 140 Watts per
channel into 8 Ohms. The 9B, however, is unique
among SST amps — although it also employs
modular construction in which each channel is selfcontained with audio circuitry, connectors, and an
independent power supply, the 9B channel module
differs in that it is built on its own removable
assembly. This means that not only may any channel
be easily swapped in the unlikely event of failure,
but also that the 9B may be configured with fewer
channels if an application so requires. Indeed, the
9B SST may be ordered in a 3, 4 or 5 channel
version. Modular channels are available separately
for later expansion.
19 in./48.3 cm wide rack
mount version (with handles)
Mounted rack depth
17 in./43.2 cm wide shelf
mount version (without handles)
Approx. weight
GAIN AND SENSITIVITY*
SETTING 7B SST 14B SST 4B SST 3B SST 6B SST 9B SST 2B SST 875 HT
1 Volt
2 Volt
4 Volt
5 – channel amplifier
Also available in:
4 – channel
3 – position
sensitivity
switch: 1V,
2V, or 4V
Polarity
switch
on each
channel
140W into 8 Ohms
3 – channel
7B SST
19 x 5.25 x 17.25 in.
48.25 x 13.3 x 43.8 cm
15.75 in./40.1 cm
17 x 5.25 x 15.75 in.
43.2 x 13.33 x 40.1 cm
55 lbs/25 kg
48.3 x 17.75 x 48.3 cm
43.2 x 18 x 48.5 cm
29dB; 2.3V 29dB; 2.3V 29dB; 1.8V 29dB; 1.3V 29dB; 1.8V 29dB; 1.1V 29dB; 1.0V 29dB; 0.9V
23dB; 4.6V 23dB; 4.6V 23dB; 3.6V 23dB; 2.6V 23dB; 3.6V 23dB; 2.2V 23dB; 2.0V 23dB; 1.8V
200 W into 4 Ohms
14B SST
19 x 7 x 19 in.
18 in./46 cm
17 x 7 x 19 in.
90 lbs/41 kg
19 x 5.25 x 17.25 in.
48.25 x 13.3 x 43.8 cm
15.75 in./40.1 cm
17 x 5.25 x 15.75 in.
43.2 x 13.33 x 40.1 cm
4B SST
60 lbs/27 kg
3B SST
19 x 5.25 x 12.5 in.
48.3 x 13.34 x 32 cm
11 in./28 cm
17 x 5.25 x 11 in.
43.2 x 13.3 x 28 cm
40 lbs/18 kg
Removable modular channels
each delivering 140 Watts @ 8 Ohms
6B SST
19 x 7 x 20.5 in.
48.3 x 18 x 52.1 cm
18.4 in./46.7 cm
17 x 7 x 19 in.
43.2 x 18 x 48.3 cm
96 lbs/43.5 kg
9B SST
19 x 5.25 x 19 in.
48.3 x 13.33 x 42 cm
17 in./43.2 cm
17 x 5.25 x 17.5 in.
43.2 x 13.3 x 44.5 cm
72 lbs/32.7 kg
17dB; 7.2V 17dB; 4.4V
2B SST
19 x 5.25 x 12.5 in.
48.3 x 13.34 x 32 cm
11 in./28 cm
17 x 5.25 x 11 in.
43.2 x 13.3 x 28 cm
30 lbs/13.6 kg
875 HT
19 x 3.5 x 19 in.
48.25 x 8.9 x 43.18 cm
11 in./28 cm
17 x 3.55 x 11 in.
43.2 x 13.3 x 28 cm
63 lbs/28.6 kg
*For Full Rated Power
8
2B SST C–SERIES
The first 2B started life way back in 1979 and has become
a Classic among discriminating audiophiles worldwide.
This latest version of our 2B incorporates all the new
SST circuitry and provides twice the power of our
original 2B.
From input to output, all the circuitry in the 2B SST
amplifier has been optimized for the most accurate
performance possible. The Bryston 2B SST amplifier is
a compact, high quality 100 watt per channel, (8 ohms),
stereo amplifier intended for use in home sound systems
requiring a musically accurate, extremely reliable, no
compromise power source.
2B SST C–SERIES
While the 2B has for years been thought of as an
exceptionally lucid and transparent amplifier for
traditional two-channel stereo setups, it is now finding
additional acceptance in such installations as multimedia
surround-sound systems, and in the most ambitious music
systems with multi-amplified speakers using electronic
crossovers.
Dual-channel (stereo) amplifier
100W into 8 Ohms
180W into 4 Ohms
The 2B SST may also be operated in
bridged mono, providing 360 Watts
into 8 Ohms
9
875 HT C–SERIES AMPLIFIER
875 HT C–SERIES AMPLIFIER
The Bryston 875 HT amplifier represents a state-
of-the-art approach to the expanding home theater
marketplace. Providing all the features and flexibility
necessary to assemble a superb Home Theater Multi-
Channel Surround System.
The world famous all new SST technology is
implemented throughout the 875 HT amplifier
providing the sound quality and incredible flexibility
Bryston is famous for. The amplifier offers 8
channels of amplification which can be utilized as
independent 75 watt modules or any 2 adjacent
channels bridged to 250 watts. Two very large power
supplies provide all the reserve needed for the most
demanding material available.
FLEXIBLE OPTIONS
WOULD INCLUDE:
• 7.1 surround system incorporating 7 channels at
75 watts and 1 subwoofer channel at 75 watts
• 6.1 surround system incorporating 6 channels at
75 watts and one subwoofer channel at 250 watts
• 5.1 surround system incorporating 3 channels
(left/center right) at 250 watts and 2 surround
channels at 75 watts
• 7.1 surround system incorporating 250 watts x 4
for surrounds and two back speakers with an
additional 3 channel amplifier (Bryston 6B SST)
for the front Left/Center Right speakers
875 Zone Amplifier available with features required
for implementing up to 4 high quality stereo zones.
A 4 channel version of the 875 Z is also available.
8 – channel amplifier
75W into 8 Ohms
140W into 4 Ohms
250W Bridged into 8 Ohms
I0
20 – YEAR AMPLIFIER WARRANTY
In a world where most things seem to need frequent
upgrading, repair, or replacement, how can Bryston offer
a comprehensive, unconditional, and fully transferable
warranty on every audio product we make?
The answer would quickly become apparent if you were
to tour Bryston’s plant in Peterborough, Ontario, Canada.
State-of-the-art design facilities, with the latest CAD and
circuit simulation software, and an inventory of some of the
best and most reliable parts on the planet, combine with
a manufacturing philosophy that eschews the artifacts of
mass production — robots, moving assembly lines, and,
frankly, shortcuts. Every Bryston audio component is
handcrafted by people who take great pride in building the
very best. Starting with a bare circuit board, for example,
each component is hand selected and installed, every wire
is cut and bent by hand, every connection is hand soldered.
On average, it takes thirty to thirty-five person-hours to
assemble a single Bryston product. Is this just some romantic
19th-century notion of the artisan-craftsman, or is there a
real benefit to you, the consumer? There is. Take the hand
soldering, for example. We could do the job much faster by
employing wave-soldering machines as many companies
do. But that would mean exposing the entire circuit board
to a molten-metal bath, a source of extreme heat shock
that could result in long-term reliability problems.
We don’t skimp on testing or rush our products through
some last-minute go/no-go check; at every stage individual
parts, completed circuit-boards, sub-assemblies, and final
assemblies are all put through rigorous inspection and testing
procedures. When completed, every Bryston amplifier
receives a comprehensive and carefully documented
test of all its functions, and the printed results of this
computer-aided analysis are actually packed and shipped
with each unit. During this intensive procedure, we not
only reject any product that falls outside of our advertised
specifications, but also any not meeting an even narrower
band of specifications that we use for internal testing. As a
result, you can expect each Bryston product to perform as
least twice as well as the advertised specifications.
Our 20-year amplifier warranty drives us in a different
direction from the typical manufacturer. We consider a
Bryston product to be a mutual investment: by you, in an
amplifier of lasting quality, and by us, in that we invest in
the quality of the product in order to be secure in offering
our warranty. It simply makes good economic sense to
produce the very best products we can.
As a result, it can be said that we don’t just make
amplifiers — we also make friends — extremely
satisfied customers who become life-long evangelists
for Bryston’s philosophy and tell their friends about our
products. And, after all, who wouldn’t want to give such
nice f riends a 20-year warranty?
Canada’s largest independent manufacturer of high-end audio electronics
for consumers and professionals. Founded 1962.
Bryston Limited P.O. Box 2170, 677 Neal Drive, Peterborough,
Ontario Canada K9J 7Y4 1-800-632-8217 bryston.ca
Loading...
