Brother HL-S7000DN User Manual

Product Safety Guide 1
(HL-S7000DN)
Please read this guide before attempting to operate the product, or before attempting any maintenance. Failure to follow these instructions may result in an increased risk of personal injury or damage to property, including through fire, electrical shock, burns or suffocation. Brother shall not be liable for damage caused where the product owner has failed to follow the instructions set out in this guide.
Read all of the instructions. Save them for later reference.

Symbols and conventions used in the documentation

The following symbols and conventions are used throughout the documentation.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injuries.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injuries.
Important
Important situation which, if not avoided, may result in damage to property or loss of product functionality.
indicates a potentially hazardous
Prohibition icons indicate actions that must not be performed.
This icon indicates that flammable sprays may not be used.
This icon indicates that organic solvents such as alcohol and liquids may not be used.
This icon indicates that you must not touch the indicated area.
1
This icon indicates that you must not stand on the indicated area.
This icon indicates that you may fall down if you stand on the indicated area.
Electrical Hazard icons alert you to possible electrical shock.
Fire hazard icons alert you to the possibility of fire.
Notes tell you how you should respond to a situation that may arise or give tips about how the operation works with other features.
Bold Bold typeface identifies specific
keys on the product’s control panel or on the computer screen.
Italics Italicized typeface emphasizes
an important point or refers you to a related topic.
Courier New
Text in Courier New font identifies messages on the LCD of the product.
Follow all warnings and instructions marked on the product.
Version A
USA/CAN
1

Compilation and Publication 1

WARNING
Under the supervision of Brother Industries, Ltd., this manual has been compiled and published, covering the latest product descriptions and specifications.
The contents of this manual and the specifications of this product are subject to change without notice.
Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical and other errors relating to the publication.

Choosing a location 1

Put your product on a flat, level, stable surface, such as a desk, that is free of vibration and shocks and is not slanted more than 2. Put the product near a standard grounded AC power outlet. Choose a location where the temperature remains between 64.4F and 91.4F (18C and 33C) and the humidity is between 20% to 80% (without condensation).
DO NOT expose the product to direct sunlight, excessive heat, open flames, corrosive gasses, moisture or dust. Doing so may create a risk of an electrical shock, electrical short or fire. It may also damage the product and/or render it inoperable.
DO NOT place the product near heaters, air conditioners, electrical fans, refrigerators, or water. Doing so may create the risk of a short circuit or fire, should water come into contact with the product (including condensation caused by heating/air conditioning/ventilation equipment).
2
CAUTION
DO NOT place the product near chemicals or in a place where chemicals could be spilled on it. Should chemicals come into contact with the product, there may be a risk of fire or electric shock. In particular, organic solvents or liquids such as benzene, paint thinner, polish remover, or deodorizer may melt or dissolve the plastic cover and/or cables, resulting in a risk of fire or electric shock. These or other chemicals may also cause the product to malfunction or become discolored.
DO NOT put the product in a location where any slot or opening in the product is obstructed or blocked. These slots and openings are provided for ventilation. Blocking the product’s ventilation could create a risk of overheating and/or fire.
Instead:
• Keep a gap of roughly 13 in. (330 mm) between the ventilation hole and the wall.
• Place the product on a solid surface. DO NOT place the product on a bed, sofa, rug, or other similar soft surface.
• DO NOT place this product in a “built-in” installation unless adequate ventilation is provided.
Plastic bags are used in the packing of your machine. Plastic bags are not toys. To avoid the danger of suffocation, keep these bags away from babies and children and dispose of them correctly.
Avoid placing your product in a high-traffic area. If you must place it in a high-traffic area, ensure that the product is in a safe location where it cannot be accidentally knocked-over, which could cause injury to you and serious damage to the product. Also ensure that cords are secured so as not to pose a tripping hazard.
DO NOT place heavy objects on the product. DO NOT place this product on an unstable cart, stand, or table, particularly if children are expected to be near the product. The product is heavy and may fall, causing injury to you or others, and serious damage to the product.
3
Important
• DO NOT put objects on top of the product. Doing so could increase the risk of overheating and/or fire should the product malfunction.
• DO NOT place your product next to devices that contain magnets or generate magnetic fields. Doing so may interfere with the operation of the product, causing print quality problems.
• DO NOT place your product next to sources of interference, such as speakers or the base units of non Brother cordless telephones. Doing so may interfere with the operation of the product’s electronic components.
• When lifting or moving the machine after the ink cartridge is installed, try to keep the machine as level as possible and do not keep the machine tilted for a long time. Tilting the machine may cause ink spillage and internal damage to the machine.
• DO NOT connect your product to an AC power outlet controlled by wall switches or automatic timers. Disruption of power can delete information from the product’s memory.
• DO NOT connect your product to an AC power outlet on the same circuit as large appliances or other equipment that requires a significant amount of electricity to operate. Operating this product in conjunction with the other product(s) could create an overvoltage, tripping your circuit breaker or blowing your fuse.
• If there is a power failure or the power cord of the machine is left unplugged for a long period of time, set the date and time again after the power is restored. If the date and time are not set, the product's automatic cleaning function will not work properly and print quality may decrease.
4

To use the product safely 1

WARNING
Please keep these instructions for later reference and read them before attempting any maintenance. If you do not follow these safety instructions, there is a possibility of a fire, electrical shock, burn or suffocation.
ELECTRICAL HAZARDS
Failure to follow the warnings in this section may create the risk of an electrical shock. In addition, you could create an electrical short, which may create the risk of a fire.
There are high voltage electrodes inside the product. Before you access the inside of the product, including for routine maintenance such as cleaning, make sure you have unplugged the power cord from the AC power outlet, as well as Ethernet (RJ-45) cables from the product. Never push objects of any kind into this product through cabinet slots, since they may touch dangerous voltage points or short out parts.
DO NOT handle the plug with wet hands.
Always make sure the plug is fully inserted.
DO NOT use this product during an electrical storm.
5
DO NOT allow this product to come into contact with water. This product should not be used around standing water including a bath tub, sink, or swimming pool, around appliances containing water including a refrigerator, or in a wet basement.
This product should be connected to an AC power source within the range indicated on the rating label. DO NOT connect it to a DC power source or inverter. If you are not sure what kind of power source you have, contact a qualified electrician.
Power Cord Safety:
• This product is equipped with a 3-wire grounded plug. This plug will only fit into a grounded
power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, call your electrician to replace your obsolete outlet. DO NOT defeat the purpose of the grounded plug.
• Use only the power cord supplied with this product.
• DO NOT allow anything to rest on the power cord.
• DO NOT place this product where people can walk on the cord.
• DO NOT place this product in a position where the cord is stretched or strain is otherwise put
on the cord. Doing so may cause the cord to become worn or frayed.
• DO NOT use the product or handle the cord if the cord has become worn or frayed.
• Unplug this product from the AC power outlet before you move the product.
• Brother strongly recommends that you DO NOT use any extension cord.
DO NOT use flammable substances, any type of spray, or an organic solvent/liquid containing alcohol or ammonia to clean the inside or outside of the product. Doing so could cause a fire or electrical shock. Instead, use only a dry, lint-free cloth. For instructions on how to clean the product, see uu User’s Guide: Routine Maintenance.
For users with pacemakers
This machine generates a weak magnetic field. If you feel anything wrong with the operation of your pacemakers when near the machine, move away from the machine and consult a doctor immediately.
6
CAUTION
DO NOT put your hands on the edge of the machine. Doing this may cause injury to your fingers by pinching them.
7
This machine is heavy and weighs more than 88 lb (40 kg). To prevent possible injuries at least two people should lift the machine by holding it from the front and back. Be careful with the output stopper when moving or lifting the machine. There is a risk of injury if your face or body strikes the output stopper. Be careful not to pinch your fingers when you set the machine back down.
DO NOT carry the machine by holding the paper tray or the duplex tray. Doing this may cause the machine to slip out of your hands. Only carry the machine by placing your hands under the entire machine.
DO NOT carry the product together with the optional lower trays, optional output tray, or the optional stabilizer. These optional devices are not attached to the product, therefore there is a risk of injury or damage if you attempt to carry them together.
8
When placing or repositioning your Brother machine on the optional stabilizer, make sure that all four stabilizer support legs are adjusted and rest firmly on the floor. Not adjusting the optional stabilizer support legs may cause the machine to move or fall over, resulting in injury to you.
Be careful not to trip on the legs of the optional stabilizer unit. Do not stand on the optional stabilizer unit. The printer and the optional stabilizer unit may move and cause you to fall.
DO NOT touch the hazardous moving parts. Keep fingers and other body parts away.
DO NOT push the optional output tray from the side after it is installed. The optional output tray may fall and cause injury to you.
9
Important
• DO NOT remove or damage any of the caution or warning labels affixed to the product.
Note
• DO NOT remove the serial number and instruction labels that are affixed to the product.
• Lightning and power surges can damage this product. We recommend that you use a quality surge protection device on the Ethernet (RJ-45) cable plugged into the product.
• Do not touch the print head, the shaded parts shown in the illustration. If you touch the print head, ink from the print head may stain your skin. If ink stains your skin, wash with soap at once.
10

Important safety instructions 1

1 Read all of these instructions.
2 Save them for later reference.
3 Follow all warnings and instructions marked on the product.
4 DO NOT attempt to service this product yourself because opening or removing covers may
expose you to dangerous voltage points and other risks and may void your warranty. Refer all servicing to a Brother Authorized Service Center.
For the location of your nearest Brother Authorized Service Center, please call:
In USA: 1-877-BROTHER (1-877-276-8437)
In Canada: 1-877-BROTHER
5 Unplug this product from the AC power outlet and refer all servicing to Brother Authorized
Service Personnel under the following conditions:
When the power cord is damaged or frayed. (DO NOT touch the damaged/frayed part while
unplugging your product.)
If liquid has been spilled into the product.
If the product has been exposed to rain or water.
If the product does not operate normally when the operating instructions are followed.
Adjust only those controls that are covered by the operating instructions. Improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal operation.
If the product has been dropped or the casing has been damaged.
If the product exhibits a distinct change in performance, indicating a need for service.
11

Regulation 1

WARNING
Important
Disconnect device
This product must be installed near an AC power outlet that is easily accessible. In case of emergencies, you must disconnect the power cord from the AC power outlet to shut off power completely.

Federal Communications Commission (FCC) Notice (USA only) 1

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
• Changes or modifications not expressly approved by Brother Industries, Ltd. could void the user’s authority to operate the equipment.
• A shielded interface cable should be used to ensure compliance with the limits for a Class A digital device.

Industry Canada Compliance Statement (Canada only) 1

This Class A digital apparatus complies with Canadian ICES–003.
Cet appareil numérique de la classe A est conforme à la norme NMB–003 du Canada.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.
L’utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
12

For use in the USA or Canada only 1

CAUTION
CAUTION
These products are made for use in the USA and Canada only. We cannot recommend using them overseas because the power requirements of your product may not be compatible with the power available in foreign countries. Using USA or Canada models overseas is at your own risk and may void your warranty.

LED radiation 1

When removing the output stopper, DO NOT view LED directly with optical instruments.
Class 1M LED product.
Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
This equipment is certified as Class 1M LED product as defined in IEC60825-1:2001.
Max. Radiation Power:
Green LED: 13.3 µW
Orange LED: 8.59 µW
(Measurement condition: Aperture 7 mm, Distance 100 mm)
Wave Length:
Green LED: typ. 528 nm
Orange LED: typ. 605 nm
Class 1M LEDs are located under the output stopper.
Viewing the LED output with certain optical instruments (for example, eye loupes, magnifiers and microscopes) within a distance of 100 mm may pose an eye hazard.

LAN connection 1

DO NOT connect this product to a LAN connection that is subject to over-voltages.
13

International ENERGY STAR® Qualification Statement 1

The purpose of the International ENERGY STAR® Program is to promote the development and popularization of energy-efficient office equipment.
As an ENERGY STAR® Partner, Brother Industries, Ltd. has determined that this product meets
®
the ENERGY STAR
specifications for energy efficiency.

Trademarks 1

The Brother logo is a registered trademark of Brother Industries, Ltd.
Microsoft, Windows, Windows Server and Internet Explorer are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
Apple, Macintosh, Safari and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries.
Linux is the registered trademark of Linus Torvalds in the U.S. and other countries.
AMD is a trademark of Advanced Micro Devices, Inc.
PowerPC is a registered trademark of IBM in the United States and/or other countries.
Adobe, PostScript and PostScript 3 are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.
Wi-Fi Protected Setup, WPA, WPA2, and Wi-Fi Protected Access are marks of the Wi-Fi Alliance.
Wi-Fi and Wi-Fi Alliance are registered marks of the Wi-Fi Alliance.
AOSS is a trademark of Buffalo Inc.
Each company whose software title is mentioned in this manual has a Software License Agreement specific to its proprietary programs.
Any trade names and product names of companies appearing on Brother products, related documents and any other materials are all trademarks or registered trademarks of those respective companies.
14

Open Source Licensing Remarks 1

Please visit Brother Solutions Center at http://solutions.brother.com/ to view Open Source Licensing Remarks and Copyright information.

Copyright and License 1

©2012 Brother Industries, Ltd. All rights reserved.
This product includes software developed by the following vendors:
©1983-1998 PACIFIC SOFTWORKS, INC. ALL RIGHTS RESERVED.
©2008 Devicescape Software, Inc. All rights reserved.
This product includes the “KASAGO TCP/IP” software developed by ZUKEN ELMIC, Inc.

Other Information 1

FlashFX® is a registered trademark of Datalight, Inc.
®
FlashFX
Copyright 1998-2010 Datalight, Inc.
U.S.Patent Office 5,860,082/6,260,156
FlashFX® Pro™ is a trademark of Datalight, Inc.
Reliance™ is a trademark of Datalight, Inc.
Datalight® is a registered trademark of Datalight, Inc.
Copyright 1989-2010 Datalight, Inc., All Rights Reserved
15
