FACSIMILE EQUIPMENT
PARTS REFERENCE LIST
MODEL: FAX-8650P
(For Germany / United Kingdom / France /
Norway / Belgium / Netherlands /
Switzerland / Sweden)
© Copyright Brother 1998
All rights reserved
No part of this publication may be reproduced in any form
or by any means without permission in writing from the
publisher.
Specifications are subject to change without prior notice.
NOTES FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q' ty
(3) Description
Note: No orders without Parts Code or Tool No. can be accepted.
[Example]
(1) (2) (3)
REF.NO. CODE Q' TY DESCRIPTION REMARKS
2. Parts change will be informed by the technical information.
COUNTRIES
GERMANY ----- GER
UNITED KINGDOM ----- UK
FRANCE ----- FRA
NORWAY ----- NOR
BELGIUM ----- BEL
NETHERLANDS ----- NLD
SWITZERLAND ----- CHE
SWEDEN ----- SWE
REF.NO. CODE Q'TY DESCRIPTION REMARKS
1 SCANNER FRAME ATTACHMENT
2 LH0698001 1 GEAR DRIVE UNIT
(2-1) LH0695001 1 PAPER FEED SOLENOID ASSY
3 UL6300004 1 MULTI-PURPOSE SHEET FEEDER, WHITE(1138)
4 UU7134001 1 LASER UNIT
5 UU7442001 1 HEAT-FIXING UNIT, 240V
5-1 UL6880001 1 FU LAMP, 240V
(5-2) UL6667001 1 THERMISTOR ASSY
(5-3) UL6681001 1 PINCH ROLLER ASSY
(5-4) UL6682001 4 PINCH ROLLER SPRING
6 UG4557001 1 LOW-VOLTAGE POWER SUPPLY PCB ASSY, 230V(WITHOUT AC CORD)
7 087412016 3 TAPTITE, CUP B M4X20
8 087311016 2 TAPTITE, CUP B M3X10
9 UG4220001 1 TONER SENSOR PCB ASSY
10 087310815 1 TAPTITE, CUP B M3X8
11 UG4635001 1 TONER SENSOR HARNESS
12 085411215 3 TAPTITE, BIND B M4X12
13 UU7043001 1 SCANNER SPONGE
14 085411215 1 TAPTITE, BIND B M4X12
15 UU7044001 1 MAIN COVER ASSY, WHITE(1138)
16 UL6887001 1 EL BOARD
17 087320616 1 TAPTITE, CUP S M3X6
18 085411215 1 TAPTITE, BIND B M4X12
19 UU7051001 1 FAN
20 UU7054001 1 FAN SUPPORT
21 UU7055001 1 INSULATION FILM
22 085411215 1 TAPTITE, BIND B M4X12
23 UU7056001 1 REGISTRATION SENSOR ACTUATOR
24 UU7057001 1 SHEET FEEDER COVER SENSOR ACTUATOR
25 UU7058001 1 TOP COVER SENSOR ACTUATOR
26 UG4509001 1 SPEAKER
27 085411215 1 TAPTITE, BIND B M4X12
28 087320616 1 TAPTITE, CUP S M3X6
29 UF6559001 1 SCREW, PAN (WASHER) M4X8DB
30 UU7062001 1 BOTTOM PLATE
31 UD4019001 2 RUBBER FOOT
32 085411215 7 TAPTITE, BIND B M4X12
33 087320616 3 TAPTITE, CUP S M3X6
34 002300616 2 SCREW, PAN M3X6
35 UU7064001 1 OPTION COVER
36 0A5300805 2 SCREW, PAN (S/P WASHER) M3X8
37 UU7322001 1 SPACER 30X145
38 UL6717001 1 PAPER EJECTION SENSOR ACTUATOR
39 ----- NOT USED
40 ----- NOT USED
41 ----- NOT USED
42 ----- NOT USED
43 ----- NOT USED
44 087311016 2 TAPTITE, CUP B M3X10
45 UU7065001 1 SCANNER GROUNDING PLATE
46 087310815 1 TAPTITE, CUP B M3X8
47 UF7676001 1 ANTI-STATIC BRUSH
48 UG3732001 1 BATTERY ASSY
49 UU7006001 1 ROM COVER, WHITE(1138)
FAX8650P, Ver.G
REF.NO. CODE Q'TY DESCRIPTION REMARKS
50 UU7001001 1 TOP COVER, WHITE(1138)
51 UG4502001 1 CIS & PANEL-MAIN HARNESSES
52 UU7168001 2 HARNESS SUPPORT SPONGE
53 087411215 2 TAPTITE, CUP B M4X12
54 UU7170001 2 TOP COVER STOPPER 12
55 087411215 2 TAPTITE, CUP B M4X12
56 087320616 2 TAPTITE, CUP S M3X6
57 085411215 4 TAPTITE, BIND B M4X12
58 UF7187001 1 SHIELD FILM
59 UU7090001 1 DOCUMENT GUIDE BASE, WHITE(1138)
60 UL6740001 1 LASER CAUTION LABEL
61 UL6741001 1 TONER CAUTION LABEL
62 ----- NOT USED
63 UG4634001 1 HEARTER HARNESS (BROWN AND BLUE WIRES)
64 UU1480001 1 CONTROL PANEL ASSY, WHITE(1138)
64-1 UU7003001 1 CONTROL PANEL, WHITE(1138)
64-2 UG4519001 1 CONTROL PANEL PCB ASSY
64-3 UG4552000 1 LCD
64-4 UG4553001 1 FPC KEY
64-5 UU7004001 1 PANEL REAR COVER
64-6 UU7101001 1 DOCUMENT PRESSURE BAR
64-7 UU7147001 1 DOCUMENT PRESSURE BAR SPRING
64-8 UU7521001 1 SEPARATION RUBBER
64-9 UU7105001 1 ADF SPRING PLATE
64-10 UU7106001 1 SPRING PLATE, ADF FRONT
64-11 UF6116001 1 TAPTITE, PAN B M3X6
64-12 UU7107001 1 DOCUMENT FRONT SENSOR ACTUATOR
64-13 UU7108001 1 DOCUMENT REAR SENSOR ACTUATOR
64-14 UU7505001 1 ANTI-STATIC BRUSH 1
64-15 UF7187001 1 SHIELD FILM
64-16 UU7285001 1 ANTI-VIBRATION RUBBER
64-17 087310815 2 TAPTITE, CUP B M3X8
64-18 UF4393003 1 KEY, TEL, WHITE(1138)
64-19 UU7099001 1 KEY, VOLUME, WHITE(1138)
64-20 UF4576003 1 KEY, SHIFT, WHITE(1138)
64-21 UF8176003 3 KEY, ONE TOUCH, WHITE(1138)
64-22 UF8173002 1 KEY, STOP, ORANGE(3172)
64-23 UF8172004 1 KEY, START, BLUE(6238)
64-24 UU7100001 1 KEY, COPY 2, WHITE(1138)
64-25 UF9118001 3 KEY, FUNCTION 1, WHITE(1138)
64-26 UF5581005 1 KEY, FUNCTION 2, WHITE(1138)
64-27 UU1477001 1 CIS SHIELD FILM
64-28 UU7506001 1 ANTI-STATIC BRUSH 2
65 UU7451001 1 PANEL SHEET FOR GER
65 UU7452001 1 PANEL SHEET FOR UK/CHE
65 UU7453001 1 PANEL SHEET FOR FRA
65 UU7454001 1 PANEL SHEET FOR NOR
65 UU7455001 1 PANEL SHEET FOR BEL
65 UU7456001 1 PANEL SHEET FOR NLD
65 UU7457001 1 PANEL SHEET FOR SWE
66 UU7139001 1 ADDRESS LABEL
67 UG4633001 1 MASK ROM-PC/LAN
68 UG4639001 1 MAIN PCB ASSY
69 UG4668003 1 NCU PCB ASSY FOR GER
FAX8650P, Ver.G
REF.NO. CODE Q'TY DESCRIPTION REMARKS
(81)
UU7503001
1
OWNER'S MANUAL ASSY FOR BEL
(INCLUDING 2 OWNER'S MANUALS(REF.NO.81-1),
WARRANTY CARD AND TRAY EXTENSION ASSY(REF.NO.81-2))
(81)
UU7195001
1
OWNER'S MANUAL ASSY FOR NLD
69 UG4669004 1 NCU PCB ASSY FOR UK
69 UG4672005 1 NCU PCB ASSY FOR FRA
69 UG4677007 1 NCU PCB ASSY FOR NOR
69 UG4670008 1 NCU PCB ASSY FOR BEL
69 UG4671009 1 NCU PCB ASSY FOR NLD
69 UG4668010 1 NCU PCB ASSY FOR CHE
69 UG4669026 1 NCU PCB ASSY FOR SWE
(69-1) UG6776000 1 ARRESTER:RA102 (LOCATION:A1)
(69-2) UG6775000 1 ARRESTER:RA311 (LOCATION:A2)
(69-3) UG6798000 2 PHOTO COUPLER:TLP621 (LOCATION:PH2,PH4)
(69-4) UG3272000 1 IC:THS-65 (LOCATION:T3)
(69-5) ----- NOT USED
(69-5) ----- NOT USED
70 UG4505001 1 NCU HARNESS
71 UG4527001 1 HIGH-VOLTAGE POWER SUPPLY PCB ASSY
72 UG4507001 1 HV FLAT CABLE 12
73 ----- NOT USED
74 UG3625001 1 TELEPHONE LINE CORD FOR GER
74 UG3626001 1 TELEPHONE LINE CORD FOR UK
74 UG3627001 1 TELEPHONE LINE CORD FOR FRA
74 UG3629001 1 TELEPHONE LINE CORD FOR NOR
74 UG1575001 1 TELEPHONE LINE CORD FOR BEL
74 UG3631001 1 TELEPHONE LINE CORD FOR NLD
74 UG3469000 1 TELEPHONE LINE CORD FOR CHE
74 UG3635001 1 TELEPHONE LINE CORD FOR SWE
75 UU7114001 2 PAPER EJECTION TRAY, WHITE(1138)
76 ----- NOT USED
77 ----- NOT USED
78 UU7117001 1 DUST COVER
79 UU7110001 1 KEY, COPY 1, WHITE(1138)
80 ----- NOT USED
(81) UU7497001 1 OWNER'S MANUAL ASSY FOR GER
(INCLUDING OWNER'S MANUAL(REF.NO.81-1),
WARRANTY CARD AND TRAY EXTENSION ASSY(REF.NO.81-2))
(81) UU7238001 1 OWNER'S MANUAL ASSY FOR UK
(INCLUDING OWNER'S MANUAL(REF.NO.81-1),
3 WARRANTY CARDS, CAUTION LABEL AND
TRAY EXTENSION ASSY(REF.NO.81-2))
(81) UU7239001 1 OWNER'S MANUAL ASSY FOR FRA
(INCLUDING OWNER'S MANUAL(REF.NO.81-1),
2 WARRANTY CARDS AND TRAY EXTENSION (REF.NO.81-2))
(81) UU7240001 1 OWNER'S MANUAL ASSY FOR NOR
(INCLUDING OWNER'S MANUAL(REF.NO.81-1),
2 WARRANTY CARDS AND TRAY EXTENSION (REF.NO.81-2))
(INCLUDING OWNER'S MANUAL(REF.NO.81-1),
2 WARRANTY CARDS AND TRAY EXTENSION (REF.NO.81-2))
(81) UU7242001 1 OWNER'S MANUAL ASSY FOR CHE
(INCLUDING 2 OWNER'S MANUALS(REF.NO.81-1),
WARRANTY CARD AND TRAY EXTENSION ASSY(REF.NO.81-2))
FAX8650P, Ver.G
REF.NO. CODE Q'TY DESCRIPTION REMARKS
(81) UU7243001 1 OWNER'S MANUAL ASSY FOR SWE
(INCLUDING OWNER'S MANUAL(REF.NO.81-1),
WARRANTY CARD AND TRAY EXTENSION ASSY(REF.NO.81-2))
(81-1) UU7498003 1 OWNER'S MANUAL FOR GER
(81-1) UU7244004 1 OWNER'S MANUAL FOR UK
(81-1) UU7244005 1 OWNER'S MANUAL FOR FRA
(81-1) UU7244007 1 OWNER'S MANUAL FOR NOR
(81-1) UU7498008 1 OWNER'S MANUAL FOR BEL(DUTCH)
(81-1) UU7201008 1 OWNER'S MANUAL FOR BEL/CHE (FRENCH)
(81-1) UU7198009 1 OWNER'S MANUAL FOR NLD
(81-1) UU7244010 1 OWNER'S MANUAL FOR CHE (GERMAN)
(81-1) UU7244026 1 OWNER'S MANUAL FOR SWE
(81-2) UL7157001 2 TRAY EXTENSION ASSY (WITH TUBE)
(82) ----- NOT USED
(83) UU7248001 1 DISK UNIT FOR UK/FRA/BEL/NLD/CHE
(83) UU7248002 1 DISK UNIT FOR NOR/SWE
(84) UE1888001 1 CARTON, BROTHER
(85) UE1852001 1 STYROFOAM ASSY
(86) UE2136001 1 BAG, 700X1000H (FOR MACHINE)
(86) UE2136002 1 BAG, 700X1000H, ONLY FOR FRA
(87) UE1855001 1 CARTON (FOR MANUAL)
(88) UU0456001 1 PROTECTION PAPER
(82) ----- NOT USED
90 UG4575001 1 AC CORD ASSY FOR GER/FRA/NOR/BEL/NLD/SWE
90 UG4576001 1 AC CORD ASSY FOR UK
90 UG4578001 1 AC CORD ASSY FOR CHE
91 UG4636001 1 NCU HARNESS B
92 UG4641001 1 FERRITE CORE NF-80
93 UU7165001 1 SIDE COVER, WHITE(1138)
94 UF7095000 1 MJ COVER, H/S
95 UF5745000 1 MJ COVER, EXT
(96) ----- NOT USED
(97) UF2978001 1 ECOLOGY STICKER FOR CHE <Eliminated>
(98) LE0019001 1 FERRITE CORE BAG ASSY
99 UG4640001 1 FERRITE CORE NF-50
(100) ----- NOT USED
(101) ----- NOT USED
FAX8650P, Ver.G
1. SCANNER FRAME ATTACHMENT
REF.NO. CODE Q'TY DESCRIPTION REMARKS
1 UU7002001 1 SCANNER FRAME
2 UU7012001 1 CIS SIDE SPRING
3 UU7434001 1 SCANNER DRIVE UNIT
3-1 UU7490001 1 SCANNER MOTOR
3-2 0A4300605 1 SCREW, PAN (S/P WASHER) M3X6
4 UU7029001 1 SCANNER GROUNDING LEAF SPRING
5 087320616 1 TAPTITE, CUP S M3X6
6 UU7030001 1 SEPARATION ROLLER GEAR
7 UU7031001 1 SEPARATION ROLLER
8 087311016 1 TAPTITE, CUP B M3X10
9 UF4369000 1 ROLLER SHAFT
10 UL6244002 2 PINCH ROLLER
11 UU7032001 2 PRESSURE ROLLER LEAF SPRING
12 UF4369000 1 ROLLER SHAFT
13 UF9009001 2 PRESSURE ROLLER
14 UU7033001 1 PINCH ROLLER LEAF SPRING
15 087310815 1 TAPTITE, CUP B M3X8
16 087320616 1 TAPTITE, CUP S M3X6
17 UG4595001 1 GROUNDING WIRE
18 UU7364001 1 ROLLER FILM
19 UG4630001 1 CIS UNIT
20 UU7035001 2 CIS LEAF SPRING
21 UU7036001 1 CIS FILM
22 UU7037001 1 DOCUMENT FEED ROLLER
23 UU7039001 2 GEAR 27
24 UU7284001 2 BUSHING 6
25 UU7040001 1 DOCUMENT EJECTION ROLLER
26 UF7187001 1 SHIELD FILM
27 UU7013001 2 CONTROL PANEL LOCK (LEAF SPRING)
28 087310815 2 TAPTITE, CUP B M3X8
29 UG4501001 1 SCANNER MOTOR HARNESS
30 087310815 1 TAPTITE, CUP B M3X8
FAX8650P, Ver.A
PL5X5349
