Breville BIC300 Operating Instructions

Breville Customer Service Centre

Australian Customers

Mail: PO Box 22

Botany NSW 2019
AUSTRALIA

Phone: [phone]

Fax: [phone]

Customer Service:

Email:

[e-mail]

www.breville.com.au

Breville is a registered trademark of Breville Pty. Ltd. A.B.N. 98 000 092 928.

Due to continued product improvement, the products illustrated/photographed

in this booklet may vary slightly from the actual product.

Copyright Breville Pty. Ltd. 2011.

New Zealand Customers

Mail: Private Bag 94411

Botany Manukau 2163
Auckland NEW ZEALAND

Phone:

0800 273 845

Fax: [phone]

Customer Service:

Email:

[e-mail]

BIC300 Issue - A11

the Quick Time

Instruction Booklet

™

BIC300

CONGRATULATIONS

on the purchase of your new Breville

the Quick Time

™

CONTENTS

4 Breville recommends safety first

6 Know your Breville

the Quick Time

™

8 Induction cooking

10 Operating your

the Quick Time

™

14 Care, cleaning & storage

16 Troubleshooting

3

BREVILLE RECOMMENDS SAFETY FIRST

At Breville we are very safety conscious. We design and manufacture consumer products with
the safety of you, our valued customer, foremost in mind. In addition we ask that you exercise
a degree of care when using any electrical appliance and adhere to the following precautions.

IMPORTANT SAFEGUARDS

READ ALL INSTRUCTIONS
BEFORE USE AND SAVE FOR
FUTURE REFERENCE

• Carefully read all instructions before

operation and save for future reference.

• Remove and safely discard any

packaging material and promotional
labels before using the Breville
induction cooker for the first time.

• To eliminate a choking hazard for young

children, remove and safely discard the
protective cover fitted over the pins of
the power plug when unpacking this
appliance for the first time.

• Do not place the appliance near the

edge of a bench top, counter or table
during operation. Ensure that the
surface is level, clean and free of water
and other substances.

• Do not place this appliance on a hot

gas or electric burner, or where it could
touch a heated oven.

• Always operate the induction cooker on a

dry, stable and heat resistant surface. Do
not use on a cloth-covered surface, near
curtains or other flammable materials.

• Position the induction cooker clear of

walls, and other heat sensitive materials
such as cloths and curtains. Minimum of
200mm distance.

• Do not use this appliance on a sink

drain board.

• Do not leave the appliance unattended

when in use.

• Always ensure the induction cooker is

properly assembled before use. Follow
the instructions provided in this book.

• If the appliance is not in use for an

extended period, disconnect the
appliance from the power outlet.

4

• Use only cooking saucepans and pots

suitable for use with an induction cooker.

• Extreme caution must be used when

the appliance is in use with an
induction safe cooking saucepan.
Do not move the appliance during
cooking or while a saucepan remains
on the induction cooker.

• Do not operate the appliance in the

vicinity of magnetically sensitive objects
(eg magnetic cards).

• The outer surface will be hot when the

appliance is operating and for some time
after use.

• The appliance is not intended to be

operated by means of an external timer
or separate remote control system.

• The temperature of accessible surfaces

will be high when the appliance is
operating and for some time after use.

• Do not place anything on top of the

appliances surface (except induction
cooker pots and pans) when in use and
when stored.

• Do not place metallic utensils, non-

compatible induction cookware, lids,
knives, forks, spoons or other metallic
objects on the induction cooker glass
ceramic plate, as these may be heated
and become hot when the appliance is
switched on.

• Do not insert sharp objects into the

ventilation system.

• To avoid overheating, do not place

any aluminium foil or metal plates on
the appliance.

• Do not touch the hot surface of the glass

ceramic plate. The induction cooker
does not heat up itself during cooking,
but the temperature of the cookware
heats up the glass ceramic plate.

BREVILLE RECOMMENDS SAFETY FIRST

• Do not heat any opened or unopened

cans on the induction cooker.

• Always switch the on/off switch to the

off position, switch the appliance off at
the power outlet, then unplug the power
cord and cool completely, if appliance
is not in use, before cleaning, before
attempting to move the appliance, and
when storing the appliance.

• Maximum weight of pot and content

should not exceed 6kg.

• Keep the appliance clean. Follow

cleaning instructions provided in this
book (page 14).

IMPORTANT SAFEGUARDS FOR
ALL ELECTRICAL APPLIANCES

• Fully unwind the cord before use.

• To protect against electric shock, do not

immerse the cord, plug or appliance in
water or any other liquid.

• Do not allow the cord to hang over the

edge of a table or bench, touch hot
surfaces or become knotted.

• This appliance is not intended for use

by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
use of the appliance by a person
responsible for their safety.

• Children should be supervised to ensure

that they do not play with the appliance.

• It is recommended to regularly inspect

the appliance. Do not use the appliance
if the power supply cord, plug or
appliance becomes damaged in any
way. Return the entire appliance to the
nearest authorised Breville Service
Centre for examination and/or repair.

• Any maintenance other than cleaning

should be performed at an authorised
Breville Service Centre.

• This appliance is for household use only.

Do not use in moving vehicles or boats.
Do not use outdoors. Do not use this
appliance for anything other than its
intended use. Misuse may cause injury.

• Do not use harsh abrasives, caustic

cleaners or oven cleaners when cleaning
this appliance.

• The installation of a residual current

device (safety switch) is recommended
to provide additional safety protection
when using electrical appliances. It
is advisable that a safety switch with
a rated residual operating current
not exceeding 30mA be installed in
the electrical circuit supplying the
appliance. See your electrician for
professional advice.

WARNING

Fully unwind the cord from the cord
storage facility before use.

Before use, people with electronic
implants such as pacemakers, etc.,
And or other health issues should
consult their doctor, as the induction
cooker generates a magnetic field.

If the glass ceramic plate surface is
cracked, switch off the appliance to
avoid the possibility of electric shock.

Return the appliance to the nearest
authorised Breville service centre
for repair.

Always keep in mind that the induction
cooker, after being switched off, will
continue to radiate residual heat on the
glass ceramic plate heating surface.

Do not use these induction cooker
within reach of young children.

SAVE THESE
INSTRUCTIONS

5

5

KNOW

your Breville the Quick Time

™

KNOW YOUR BREVILLE - THE QUICK TIME

A

A

B

C

D

E

™

F
G

H
I

A. Silicon handle covers

for heat protection

B. Induction safe 20cm casserole pot

Tri-ply stainless steel

C. Ceramic glass cooktop
D. Power On/Off
E. Control dial

for precise temperature, power and time
selection.

J

F. LED screen
G. 2100 Watt heat element
H. Integrated safety

with pot detection and safety cut out.

I. Menu selector
J. Non-slip feet

7

KNOW YOUR BREVILLE - THE QUICK TIME

™

Digital Screen

O

K. Power mode: 10 levels

(P-1 minimum power to
P-10 maximum power)

L. Menu selector
M. Adjustable temperature mode

60°C to 220°C

N. Timer: 1 to 180 minutes
O. Power On/Off

K

L

MN

8

INDUCTION COOKING

with your Breville the Quick Time

™

PAGE HEADER.....INDUCTION COOKING

WHAT IS INDUCTION COOKING?

An induction cooker creates an
electromagnetic field to heat the cooking
saucepan/pot. Very little energy is wasted
heating the glass ceramic plate, as most of
the heat is transferred directly to the food.

As the majority of the heat is absorbed
by the saucepan/pot, the cooking surface
remains cooler to the touch than most
traditional cooktops making cooking fast,
safe and energy efficient.

Induction
Cookware

Heat is generated
in the pot.

Magnetic Field

Power Coil

SUITABLE COOKWARE FOR
INDUCTION COOKING

To achieve maximum efficiency, it is
essential to use the correct type of
saucepans/pot.

NOTE

All saucepan/pot’s require a base
diameter between 12cm to 21cm to
operate the induction cooker.

Unsuitable saucepan/pot’s are;

• Ceramic

• Heat resistant glassware

• Any pottery

• Copper or aluminium

• With feet

• With a curved based

• With a base diameter less than 12cm

A Breville induction safe 18/8 stainless steel
20cm casserole pot has been included with
your induction cooker to get you started.

The pot base is made of a high quality
aluminium core sandwiched between two
layers of solid stainless steel.

Ergonomic handles are also made of solid
stainless steel with silicon covers for heat
protection.

Most suitable saucepan/pot’s are;

• Stainless Steel with an iron base or core

• Cast iron

• With ferrous metals

(one that can be magnetised)

• Induction compatible cookware

10

Stainless Steel

Aluminium

Stainless Steel

OPERATING

your Breville the Quick Time™

PAGE HEADER.....

OPERATING YOUR BREVILLE - THE QUICK TIME

™

BEFORE FIRST USE

Before using your Breville induction cooker
become familiar with all the parts.

Remove and safely discard all packaging
materials and promotional labels.

Wipe the glass ceramic plate surface with a
soft damp cloth and dry thoroughly.

Do not immerse the power cord, power plug
and any other part of the induction cooker
in water or any other liquid.

OPERATION OF YOUR BREVILLE
INDUCTION COOKER

1. Place the induction cooker on a dry, level

work surface.

2. Position the Breville Casserole Pot that

is enclosed or an induction compatible
saucepan/pot in the centre of the
circular design on the glass ceramic
plate surface, ensure liquid or food is
inside the saucepan/pot.

3. Insert the power plug into a 230V or

240V power outlet and switch power
outlet ‘On’.

NOTE

Ensure the saucepan/pot is positioned
in the centre of the circular design on
the glass ceramic plate surface.

WARNING

Never use the saucepan/pot when
empty, ensure liquid or food is inside
the saucepan/pot.

4. The LED screen will initially display

(888:), a sound will beep and the
appliance will be activated and start in a
standby mode by flashing (–) symbol.

5. Press the power on/off

A beep will sound.

button once.

6. By default, the induction cooker will

automatically set to the power level mode

P at level P-6. The LED screen will flash
P-6 (5 times) and indicator light will

illuminate next to P power level icon.
The induction cooker is now heating at
this power level and is ready to use.

NOTE

When appliance is in standby mode,
the appliance is not heating, when
the standby on/off switch is pressed
the LED illumination indicated power
is activated by default P-6 and a fan
automatically starts working during
the heating process.

NOTE

A fan will run continuously during the
heating process.

WARNING

Induction cooking glass ceramic
plate surface is hot after cooking.
Do Not Touch!

The induction cooker offers two heating
options the Power level mode or the
Adjustable temperature mode. Each of these
heating options can be combined with a
Timer mode. Heating options and Timer
mode can be selected by simply pressing
the Menu button.

As the power level mode is the default
heating option on the induction cooker, there
is no need to press the menu button to go
to this heating option. However, if the Menu
button is accidentally pressed, press the
Menu button twice to go back to the power
level mode. A corresponding indicator light
will illuminate on the LED screen, adjacent
to the Power level P icon. A beep will sound
every time Menu button is pressed.

12

PAGE HEADER.....

OPERATING YOUR BREVILLE - THE QUICK TIME

™

To select the Adjustable temperature mode
heating option, press the menu button twice
and a corresponding indicator light will
illuminate on the LED screen, adjacent to
the temperature C˚ icon. A beep will sound
every time Menu button is pressed.

To select the timer mode, press the menu
button once after heating option is selected
and a corresponding indicator light will
illuminate on the LED screen, adjacent to
the timer

icon. A beep will sound every

time Menu button is pressed.

POWER LEVEL MODE

1. When power level mode is selected,

a corresponding indicator light will
illuminate on the LED screen, adjacent
to the power P icon. A beep will sound
every time Menu button is pressed.

2. The induction cooker will initially be set

to level P-6 by default. The LED screen
will flash P-6.

3. Select the desired power levels using

the control dial turn dial clockwise
to increase power and anti-clockwise
to decrease power. The power levels
are adjustable on a scale from P-1
minimum power to P-10 maximum
power. A beep will sound each time
power level is changed.

4. During the selection period, the display

on the LED screen will continue to flash
until the desired power level has been
selected, the LED screen will cease
flashing after approximately 5 seconds
and display selected power.

5. The induction cooker will then begin

heating. Be careful as temperature is
reached a lot faster than traditional
cooking methods.

6. In this power level mode, it is also

possible to set the cooking time with
the Timer mode. Refer to timer mode

details.

7. When cooking is complete, press the

power on/off

button once to the
standby mode. A beep will sound. Switch
‘Off’ at the power outlet and unplug the
power cord.

NOTE

The power level mode can be adjusted
at any time during the cooking
process by adjusting the control dial.

ADJUSTABLE TEMPERATURE MODE

1. When temperature mode is selected,

a corresponding indicator light will
illuminate on the LED screen, adjacent
to the temperature C˚ icon. A beep
will sound every time Menu button is
pressed.

2. The induction cooker will initially set to

140°C by default. The LED screen will
flash 140°C.

3. Select the desired temperature using

the control dial, turn dial clockwise to
increase temperature and anti-clockwise
to decrease temperature.

4. The temperature is adjustable on a scale

from 60°C to 220°C. A beep will sound
each time temperature is changed.

5. During the selection period, the

LED screen will continue to flash until
the desired temperature has been
selected, the LED screen will cease
flashing after approx. 5 seconds and
display selected temperature.

6. The induction cooker will then

begin heating.

7. In this adjustable temperature C˚ mode,

it is also possible to set the cooking time
with the timer mode. Refer to the timer
mode

details, page 13.

13

PAGE HEADER.....

OPERATING YOUR BREVILLE - THE QUICK TIME

™

8. When cooking is complete, press the

power on/off
standby mode. A beep will sound. Switch
‘off’ at the power outlet and unplug the
power cord.

NOTE

Temperature can be adjusted at any
time during the cooking process,
and the Breville induction cooker
temperatures can be lowered or
increased on a scale of 60˚C to 220˚C.

button once to the

TIMER MODE

1. Power level and/or Adjustable

temperature mode must be selected
prior to setting the Timer mode.

2. To select the Timer mode, press the

mode button once, a corresponding
indicator light will illuminate on the
LED screen adjacent to the timer mode

icon. A beep will sound.

3. Select the desired Time using the Control

dial. Turn dial clockwise to increase time
and anti-clockwise to decrease time. The
time is adjustable on a scale from
1 minute to 180 minutes. A beep will
sound each time the timing is changed.

4. During the selection period, the

LED screen will continue to flash,
when the desired time has been
selected, the LED screen will cease
flashing after approximately 5 seconds
and display selected.

NOTE

Turning the control dial slowly
increases or decreases the timing
by 1 minute increments, allowing
for accurate selection. A beep will
sound each time the time is changed.
Turning the control dial very quickly
clockwise increases timing by
10 minute increments, anticlockwise
decreases increments by 10 minute
increments fast motion selection.

5. Timer count down then commences

and when the selected time has lapsed,
a beep will sound 5 times and the
induction cooker will automatically
switch to stand-by mode.

NOTE

The Timer mode does not need to be
set to use the Power level mode or
Adjustable temperature mode.
To readjust power level and
temperature during cooking with
timer mode, switch off the appliance,
switch back on and reset.

WARNING

If the Breville induction cooker detects
the temperature on the glass ceramic
plate surface exceeding 100°C during
cooking, the heating process will cease
and the stand-by mode will activate for
60 seconds to reduce the temperature.
At the same time, the LED screen will
display the error message E6. This
error message will turn off when the
temperature falls below 100°C.

14

CARE, CLEANING

& STORAGE

for your Breville the Quick Time™

PAGE HEADER.....

CARE, CLEANING & STORAGE

CARE AND CLEANING

Before cleaning, press the power on/off

button once. A beep will sound. Switch
power off at the power outlet and unplug the
power cord from the power outlet.

Ensure induction cooker has completely
cooled down before cleaning and storage.

To clean, glass ceramic plate surface,
wipe with a slightly damp cloth using a
mild detergent, to remove any food residue.
Dry thoroughly.

NOTE

Do not use abrasives, harsh cleaning

solutions or metal scourer pads as

these may scratch the glass ceramic

plate surface and make subsequent

cleaning more difficult.

NOTE

Do not use abrasives or harsh cleaning

solutions to clean the glass ceramic

plate surface.

STORAGE

Before storage, press the power on/off
button once. A beep will sound. Switch off
at the power outlet and unplug power cord
from the power outlet.

Ensure the appliance is completely cooled,
clean and dry. Store the appliance flat on the
bench or in a convenient cupboard.

Do not place anything on top of the
appliance during storage.

WARNING

Do not immerse the breville induction
cooker or power cord and power plug
in water or any other liquid.

WARNING

To prevent damage to the appliance
do not use alkaline cleaning agents
when cleaning, use a soft cloth and
mild detergent.

16

TROUBLESHOOTING

PAGE HEADER.....

TROUBLESHOOTING

ERROR OR CODE

DISPLAYED ON

LED SCREEN

– Appliance is in ‘Standby’

POSSIBLE CAUSES WHAT TO DO

mode/ position

Place an Induction compatible saucepan/
pot on top of the glass ceramic plate.

HOT To warn the user the glass is

E0 Induction Cooking failed does

Err Non-compatible induction

E2 Appliance has overheated Allow the appliance to cool down,

E3, E4 Incorrect voltage Ensure the appliance is plugged into a

E5 Open circuit Appliance is to be taken to an authorised

E6 Glass ceramic plate is

Appliance does

not function

hot after normal use.

not work

saucepan/pot has been used.

The appliance has detected no
pot on the glass ceramic plate.

overheated

Appliance is not plugged in Plug the power plug into the wall socket.

Appliance is plugged in Appliance is to be taken to an authorised

Do not touch hot glass. Fan and display
will turn off when cooled down.

Appliance is to be taken to an authorised
Breville Service Centre inspection, repair
and/or replacement.

Use an induction compatible
saucepan/pot.

press power on/off
saucepan/pot and cool appliance before
switching power on.

230V or 240V power outlet.

Breville Service Centre for inspection,
repair and/or replacement.

Allow the appliance to cool down,
press power on/off
saucepan/pot and cool appliance before
switching power on.

Breville Service Centre for inspection,
repair and/or replacement.

button remove

button remove

Food is not heated You have used a pot not

The appliance

turns itself off

18

suitable for induction cooking

You have used a pot not
suitable for induction cooking

There is no pot on the plate Place an induction pot on the induction

Use an induction suitable pot.

Use an induction suitable pot.

plate, and switch the appliance back on.

PAGE HEADER.....

NOTES

19
