BRAUN Triumph 9400 User Manual [fr]

Oral-B

™

powered

ROFESSIONAL CARE 9400/SOINS PROFESSIONELS 9400

Oral-B

English 4

Español 13

Français 21

Internet:

www.oralb.com www.braun.com www.service.braun.com www.oralb.ca

Braun GmbH Frankfurter Straße 145 61476 Kronberg/Germany

D 24.516.3

Type 3731 Modelo 3731 Modèle 3731

98973813/VI-09 GB/E/F Printed in Germany Impreso en Alemania Imprimé en Allemagne

D24

Explo

Vorserie

KURTZ

DESIGN

24.04.07

Oral-B

Oral-

IMPORTANT SAFEGUARDS

Oral-B Triumph™ has been carefully designed to offer you and your family a unique brushing experience that is both safe and effective. When using electrical products, however, basic safety precautions should always be followed.

Read all instructions before using.

DANGER

In order to reduce the risk of electrocution:

1. Do not place or store the charger where it can fall or be pulled into a tub or sink.

2. Do not place the charger in water or other liquid.

3. Do not reach for a charger that has fallen into water. Unplug immediately.

4. Do not use while bathing.

WARNING

To reduce the risk of burns, electrocution, fire or injury:

1. This appliance is not intended for use by children or persons with reduced physical or mental capabilities, unless they are supervised by a person responsible for their safety.

2. Use this product only for its intended use as described in this manual. Do not use attachments not recommended by the manufacturer.

3. Keep cord away from heated surfaces.

4. Never drop the appliance or insert any object into any opening of the appliance.

5. Never operate this product if it has been dropped or damaged, if it is not working properly, or if the SmartPlug is damaged or has been dropped into water. If any of these occur, please contact a service center and return the product for examination and repair.

6. If the product is dropped, the brush head should be replaced before the next use even if no damage is visible.

This appliance is provided with a SmartPlug with integrated Safety Extra Low Voltage power supply. Do not exchange or manipulate any part of it otherwise there is the risk of electric shock. Periodically check the SmartPlug for damage. A damaged or nonfunctioning appliance should no longer be used. Take it to an Oral-B Braun Service Center.

IMPORTANT

1. Do not touch the power plug with wet hands. This can cause an electric shock.

2. When unplugging, always hold the power plug instead of the cord.

3. Do not modify the product. Do not disassemble or repair. This may cause fire, electric shock or injury. Consult your dealer for repairs or contact an Oral-B Braun Service center.

4. Do not disassemble the product except when disposing of the battery.

5. When taking out the battery for disposal, use caution not to short the positive (+) and negative (–) terminals.

6. This product is not intended for use by children under age three.

CAUTION

If you are undergoing treatment for any oral care condition, consult your dental professional prior to use.

SAVE THESE INSTRUCTIONS

Description

Oral-B

a Oral-B® FlossAction™ brush head b On/off button c Mode button d Handle e SmartDisplay f SmartPlug charger (includes charging ring and SmartPlug) g Base plate h Base station i Protective cover j Oral-B

ProWhite™ brush head (not with all models)

Connecting and charging

Your toothbrush has a waterproof handle, is electrically safe and designed for use in the bathroom.

English

To assemble the base station (h) as charging unit, detach the base plate (g) first ( base station and attach the base plate as shown ( page 3). Then insert the protective cover (i) on the back of your base station (see diagram

• Plug the SmartPlug into an electrical outlet and place the

toothbrush handle (d) on the charging unit. Alternatively, Oral-B Triumph can be charged by placing the handle directly into the charging ring while the SmartPlug is plugged in.

• A battery symbol should appear in the SmartDisplay (e). The

battery symbol will fill up while the handle is being charged. Once the handle is fully charged, the battery symbol is completely filled with three bars. A full charge takes at least 12 hours and enables approximately two weeks of regular brushing (twice a day, 2 minutes).

Please note: If the battery symbol is not displayed immediately, continue charging. It will appear in 10–15 minutes.

• When the rechargeable battery is low, the battery symbol

with one remaining bar starts flashing. Your toothbrush will slow down and then stop. It is time to recharge your toothbrush. When the battery is fully discharged, the empty frame of the battery symbol flashes. It will then need a 15-minute charge before you can use it for a 2-minute brushing.

1, page 3). Place the charging ring into the

2 and 3,

4, page 3).

12 h

• For everyday use, the toothbrush handle can be stored on

the charging unit to maintain it at full power. There is no risk of overcharging the battery.

• To maintain the maximum capacity of the rechargeable battery, unplug the charging unit and fully discharge the handle by regular use at least every 6 months.

For electric specifications, see printing on the SmartPlug.

Brushing

Attach an Oral-B brush head to the handle. You can use any kind of toothpaste. To avoid splashing, guide the brush head

ral-B

ral-B O

Oral-B

to your teeth before switching the appliance on.

Brushing modes Oral-B Triumph offers different brushing modes for varying

oral care needs:

«Clean» – Exceptional mouth cleaning. «Sensitive» – Gentle, yet thorough cleaning for sensitive

areas. «Polish» – Exceptional polishing and natural whitening for occasional or everyday use.

How to switch between brushing modes:

• Your toothbrush automatically starts in the «Clean» mode when pressing the on/off button.

• To shift from the «Clean» to the «Sensitive» mode, press the mode button once.

• If you wish to switch to the «Polish» mode, press the mode button again.

• To return from any mode to the «Clean» mode, press and hold the mode button.

• To turn your brush off, press the on/off button.

Please note: the «Polish» mode is best used with an Oral-B ProWhite brush head (not with all models).

During brushing, the SmartDisplay shows the brushing mode you have selected, followed by a «smiley», when you reach the dental professional recommended 2-minute brushing time. The «smiley» will be displayed for 30 seconds before it disappears automatically. Alternatively, you can directly clear the «smiley» on the display by pushing the mode button.

Brushing technique

• Guide the brush head slowly from tooth to tooth.

• Hold the brush head in place for a few seconds before moving on to the next tooth.

• Brush the gums as well as the teeth, first the outsides, then the insides, finally the chewing surfaces.

• Do not press too hard or scrub, simply let the brush do all the work.

To promote optimal brushing your Oral-B Triumph has a pressure control feature to help ensure that the right degree of pressure is applied. This helps protect your gums from excessive brushing and makes your toothbrush easy to operate. If too much pressure is applied, the oscillating movement of the brush head will continue but the pulsation will stop. In addition to feeling the change, you can also hear a different sound.

In the first days of using your toothbrush, your gums may bleed slightly. In general, bleeding should stop after a few days. Should it persist after 2 weeks, please consult your dentist or dental hygienist. If you have sensitive teeth and gums, Oral-B recommends using the «Sensitive» mode.

Professional Timer

For an overall clean, the «Professional Timer» helps you brush the four quadrants of your mouth equally. It signals with a short stuttering sound at 30-second intervals that it is time to move to the next quadrant of your mouth, followed by a long stuttering sound when you reach the recommended 2-minute mark.

The «Professional Timer» memorizes the elapsed brushing time, even when the handle is briefly switched off during brushing. Only when pausing longer than 30 sec. the timer resets to the initial starting point.

Brush heads

Oral-B FlossAction brush head is recommended for everyday deep cleaning. It features micropulse bristles that get in hardto-reach areas between your teeth, gently removing hidden plaque.

For occasional or everyday whitening, please use the Oral-B ProWhite brush head (not with all models). It features a dentist-inspired polishing cup to remove surface stains from coffee, tea and tobacco for effective brightening.

Please note that children under 12 years old should not use the Oral-B ProWhite brush head.

Do not use the Oral-B FlossAction or Oral-B ProWhite brush head with braces. We recommend using the Oral-B Ortho brush head, which is specifically designed to clean around braces and wires.

The FlossAction™ and ProWhite™ brush heads feature blue Indicator

bristles helping you to monitor brush head replacement need. With proper brushing, twice a day for two minutes, the blue color will fade halfway approximately within 3 months, signaling that it is time to change the brush head.

Cleaning recommendations

• After brushing, rinse your brush head thoroughly under

running water.

• Remove the brush head from the handle and clean both

parts separately under running water. Then wipe them dry before you put the handle on the charging unit.

• Before cleaning your charging unit, make sure you

disassemble it first. The charging ring and the SmartPlug should never be placed in the dishwasher. However, all other parts (base station, base plate and protective cover) are dishwasher-safe.

• From time to time, you can also clean the charging ring and

the SmartPlug with a damp cloth. The SmartPlug charger should never be placed in water.

Environmental notice

This product is provided with a nickel-hydride battery, which does not contain any harmful heavy metals. Nevertheless, in the interest of protecting the environment, please do not dispose of the product in the household waste at the end of its useful life. Disposal can take place at an Oral-B Braun Service Center or at approved recycling or disposing locations in accordance with local regulations.

Battery removal at the end of the product’s useful life

Open the handle as shown, remove the battery and dispose of it according to local environmental regulations.

Caution! Opening the handle will destroy the appliance and invalidate the warranty.

Subject to change without notice.

Ni-MH
